Enhancing flexural performance of reinforced concrete beams using UHPC
overlay and external bonding of CFRP composites
Taraka M.R. Balla *,1 , Rahul Reddy Morthala 1 , S. Suriya Prakash
Department of Civil Engineering, Indian Institute of Technology Hyderabad, India
A R T I C L E I N F O
Keywords:
Strengthening
Overlay
RC beams
UHPC
CFRP
Flexure Loading
DIC
A B S T R A C T
Engineers constantly look for reliable and long-lasting strengthening solutions for deteriorated bridges and
building systems. Ultrahigh-performance concrete (UHPC) overlays can be an effective solution for repairing and
strengthening bridge decks, beams and slabs in buildings to increase durability and structural performance. This
study explores the effectiveness of an innovative hybrid strengthening technique for flexural members using
UHPC overlay and external bonding of carbon fibre-reinforced polymer (CFRP) composites. UHPC has a dense
material composition that results in high strength, stiffness, and durability. The flexural behaviour of reinforced
concrete (RC) beams strengthened with various hybrid configurations of UHPC overlay, and CFRP strengthening
is experimentally assessed in this study. Five full-scale specimens with different strengthening configurations are
tested under four-point loading. Test results show a maximum increase in flexural capacity of 63 % with only
UHPC overlay and 129 % with the hybrid configuration compared to the control RC beam. In addition, the digital
image correlation (DIC) results revealed an improved serviceability performance in terms of lesser deflections
and reduced crack widths due to UHPC overlay and FRP strengthening. The moment-curvature and load-
displacement response from the test results are compared with predictions of the analytical approach gener-
ated from the cross-section and member-level analysis. The cracking moment and ultimate strength of all the
tested beams are predicted using the proposed analytical approach. Predictions had a coefficient of variation
(COV) of 0.05 and 0.04, respectively, with test results.
1. Introduction
Strengthening reinforced concrete (RC) buildings and bridges are
often required for various reasons. They are often required to address
corrosion and deterioration due to extreme environmental conditions
and additional loading requirements due to changes in the use [1]. Also,
deterioration of top layers of bridge decks due to vehicular impact and
ageing, damage due to accidental loading, such as impact and blast
[2–4], defects in design and construction and upgradation of existing
structures need structural strengthening [5–7]. The combined effects of
vehicular loading, cracking, water and chloride ingress, concrete
delamination, and reinforcement corrosion lead to significant deterio-
ration of bridge elements. Strengthening using the overlay technique is
employed to restore the longevity and functionality of damaged bridge
decks [8,9].
Various materials, such as conventional concrete, high-performance
concrete, polymer-based composites and ultrahigh-performance
concrete (UHPC), are used in overlay applications [10–12]. The
different types of overlays are chosen based on factors such as the extent
of deterioration, budget constraints, and the desired lifespan of the
repaired structure. Overlay using UHPC is a prominent solution as it has
superior properties such as high strength, durability, and resistance to
environmental deterioration [13,14]. UHPC has raw materials like
cement, silica fume, river sand and steel fibres [15]. UHPC has an
exceptionally dense composition, developed using the modified
Andreasen and Andersen model [16]. Mix design using the particle
packing model can result in a highly impervious UHPC mix. The com-
parison of particle packing of conventional concrete and UHPC in
equivalent scale is shown in Fig. 1.
UHPC offers exceptional durability, high energy absorption, chemi-
cal resistance, and low permeability. It significantly blocks the entry of
harmful substances like water and chlorides compared to normal-
strength concrete (NSC). UHPC has a high compressive strength of
more than 120 MPa, a tensile strength of more than 6 MPa, and
considerable tensile strain hardening and softening behaviour. UHPC
* Corresponding author.
E-mail addresses: tarakaballa.iitr.iith@gmail.com (T.M.R. Balla), ce22resch01007@iith.ac.in (R.R. Morthala), suriyap@ce.iith.ac.in (S.S. Prakash).
1 Equivalent First Author
Contents lists available at ScienceDirect
Engineering Structures
journal homepage: www.elsevier.com/locate/engstruct
https://doi.org/10.1016/j.engstruct.2025.119951
Received 14 July 2024; Received in revised form 27 December 2024; Accepted 18 February 2025
Engineering Structures 330 (2025) 119951
Available online 24 February 2025
0141-0296/© 2025 Elsevier Ltd. All rights are reserved, including those for text and data mining, AI training, and similar technologies.
https://orcid.org/0000-0002-3770-690X
https://orcid.org/0000-0002-3770-690X
https://orcid.org/0000-0002-6487-3025
https://orcid.org/0000-0002-6487-3025
mailto:tarakaballa.iitr.iith@gmail.com
mailto:ce22resch01007@iith.ac.in
mailto:suriyap@ce.iith.ac.in
www.sciencedirect.com/science/journal/01410296
https://www.elsevier.com/locate/engstruct
https://doi.org/10.1016/j.engstruct.2025.119951
https://doi.org/10.1016/j.engstruct.2025.119951
http://crossmark.crossref.org/dialog/?doi=10.1016/j.engstruct.2025.119951&domain=pdf
has good rheological qualities like workability and self-compacting
properties, making casting easy using concreting equipment. It is an
outstanding choice for restoring and retrofitting deteriorated concrete
structures [17,18]. Using UHPC overlay is an effective solution for
repairing and strengthening deteriorated and damaged RC structural
elements to improve their strength and extend the service life of the
structure [19,20].
Some studies in the past have focused on understanding the effect of
flexural strengthening using UHPC [6,17,21,22]. Lampropoulos et al.
[17] investigated the flexural behaviour of RC beams strengthened using
UHPC. They validated the finite element (FE) models using the existing
test database to conduct the parametric study and understand the
different UHPC overlay combinations. They noted that all UHPC overlay
configurations were effective in improving flexural strength. Adding
reinforcement in the UHPC layer on the tension side was more effective
than only UHPC. Kadhim et al. [22] investigated the flexural behaviour
of CFRP-reinforced UHPC overlays in the tension side of RC beams both
experimentally and numerically. A significant improvement in the
flexural strength is observed with an increase in the CFRP reinforcement
in the overlays.
Paschalis et al. [6] conducted an experimental and numerical study
to understand the flexural behaviour of RC beams strengthened using
the UHPC overlay (on the tension side) with and without steel rein-
forcement. The UHPC overlay on the tension face is effective in delaying
the cracks. However, only the marginal flexural strength is observed.
They found that the UHPC overlay with steel reinforcement is highly
effective in improving the flexural strength. The existing studies [23–25]
revealed that using the CFRP fabric and laminates was highly effective in
improving the flexural performance of RC beams.
Providing UHPC overlay thickness (Fig. 2) increases the lever arm to
the existing reinforcement, improving the flexural capacity. External
bonding of fibre-reinforced polymer (FRP) composites on the tension
face, in addition to the UHPC overlay on the compression side can be an
effective hybrid strengthening solution for flexural members (Fig. 2). A
hybrid combination of UHPC overlay and externally bonded FRP can
significantly improve flexural performance in strength and ductility.
FRP has several advantages, such as a high strength and stiffness-to-
weight ratio, ease of installation, minimal labour,lightweight
