Calypso

























Advanced
Course
Training
Manual
December 2001

Software-Rev.
3.2, 3.4

September 2002

Software rev. 3.6
Contents
Calypso Advanced Course

This manual is protected by copyright. No part of its contents may be copied, reproduced,
translated, further processed by electronic means, or passed on without the express
consent of Carl Zeiss 3D Metrology Services GmbH.

We reserve the right to alter the contents of this manual as required!

 Carl Zeiss 3D Metrology Services GmbH. All rights reserved.

Software-Revision: 3.6
Edition: 09/2002

Printed in Germany

4tth Edition, September 2002


Carl Zeiss 3D Metrology Services GmbH
Heinrich-Rieger-Str. 1
73430 Aalen

e-mail address
hopp@zeiss3d.de








Special information on this edition:

The text and graphics contained in this training manual lay no claim to completeness or
correctness.


Please notify your instructor of any flaws or insufficiencies you may discover in the
following sections.

Your cooperation will help us improve Calypso training for further course participants.

Since the software described here is constantly being revised deviations from the
procedures described here may occur at a later point in time.

Please take this point into consideration when working with Calypso in the future.



Calypso Advanced Course
 The way to become a Calypso Specialist




Contents
Calypso Advanced Course


Prerequisites
 Calypso Basic Training
 4 - 6 weeks practical experience on the CMM or
 Knowledge of another measuring software
package

This course:
 deals with more Calypso functions
 is a 4 day course
 is recommended to be taken at a Training Center
 starts at 8:00 a.m., ends at 4:00 p.m. with a break from
12:15 – 13:00
 offers handouts where necessary, you should bring your
own copy of the Calypso User Manual



Day 1 Comprehension ↓ Comprehension ↓
Review
 Questions from Basic Training
 Questions from praxis
 Probe Qualification ☺
 Automatic probe qualification
 Gauge calibration
 Special probes
disk probe, cylinder probe, inclined probe

Special Alignment ☺
 Base system using offset plane
 Alignment with iteration
 RPS with loop
 3D best fit with a loop
 Characteristics Editor:
Change coordinate system




Day 2 Comprehension ↓ Comprehension ↓
Testing Forms ☺
 Scanning
 Filters
 Outliers
 Form plots
 Measuring Force (option)
CAD ☺
 Offline programming
 CAD file types
 Healing
 Extracting
 CAD modification

Special features and constructions ☺
 Recall of points from
polyline, circles, cylinders
 Rectangle, Slot, circle on cone,
radius point, sphere point
 average feature,
Min/Max coordinates
 Evaluation constraints





Customer Training
Calypso Advanced Training
Carl Zeiss 3D
Metrology
Services
GmbH
 Name: Company:
Contents
Calypso Advanced Course


Day 3 Comprehension ↓ Comprehension ↓
Extended programming functionality ☺
 Pattern: linear and round
 Formula
 Loop
 Break condition
 Bore pattern
 Conditional branching

Exercises on
Advanced programming functions ☺

 This subject area lends itself to further exercises –
also offline – using records


Day 4 Comprehension ↓ Comprehension ↓
Autorun
 Palet measurment
 Serial measurement
 Privileges

Records ☺
 Userdefined record
 Userinformation at CNC-Start
 Exporting results
Program optimization ☺
 Order to run from feature list
 Sub-Groups
 Miniplan
 Block edges

Day 5 Comprehension ↓ Comprehension ↓
Discussion
 Special customer measuring problems
 Programming work pieces you have brought to the
training
 Editing measuring tasks
 Furthering your knowledge of new functions

Further Training Courses
 Introduction to Curve Metrology
 Introduction to PCM

Review
 Trainer assesses course
 Participants assess course




Special training courses or workshops are offered for
advanced Calypso program options:



Curve Option, 3 days
PCM Option, 3 days
CAM Import Filter Option, on request
Workshop on User Defined Printout, 1 day
Workshop on Programming Strategy, 1 day




Contents
Calypso Advanced Course



List of Contents

Worksheet 1: Probe Qualification

1.1: Automatic Probe Qualification
The automatic probe qualification will help you to become familiar
with handling probes.
1.2: Gage Calibration
Recalibration of a stylus on a plug or ring gage. Prerequisite for
high accuracy measurements and for calibration of special probes
in the following section.
1.3: Special Probes
Qualification of disk and cylinder probes which have to be
recalibrated on a gage.

Worksheet 2: Special Alignments
2.1: Base alignment with Offset Plane
The offset plane as feature and use as alignment element
2.2: Change Axial Alignment
Selecting the axial alignment when orientating the axial alignment
of the workpiece different from that of the machine
2.3: Startsystem
2.4: Iterative Alignment
Single points on the practice cube are calculated to features.
These form a coordinate system. The iteration is executed with
loops.
2.5: RPS Alignment with Loop
Special alignment for sheet metal measurement
2.6: 3D Best Fit with Loop
2.7: 3D Fit to a Curved Pipe
2.8 Changing a Coordinate System with the Editor
2.9 Rotation on a Straight Line through the Origin

Worksheet 3: Form Elements / Scanning
3.1: Basics about Filters and Outliers
3.1.1: Filters
3.1.2: Outliers
3.1.3: Minimum circumscribed and maximum inscribed elements /
Tangential elements
3.2: Form element with the help of an example
 Definition of scanning paths
 Scanning settings
 Filters
 Outliers
 Tangential elements
 Default Measurement Strategy
 Minimum circumscribed and maximum inscribed elements
 Exercises
3.3 Flatness with a Reference
Contents
Calypso Advanced Course
Worksheet 4: CAD

4.1: Offline Programming
CAD File Types
Healing
Extracting
CAD Modification
4.2: Measurement Strategy
Default Values
Creating a Grid

Worksheet 5: Special Features and Constructions

5.1 Recall Feature Points from Polyline
5.2 Recall Feature Points from Circles
5.3 Recall Feature Points from Cylinder
5.4 Recall Feature Points from Curve
5.5: Slot, Rectangle
Circle on Cone
Radius points, Angle point,
 Mean value
Contour point
Min/Max coordinates
Minimum/Maximum
5.6: Limiting Degrees of Freedom
5.7: Form Characteristics, DIN Surface Form

Worksheet 6: Advanced Programming Functions,
Formula, Loop

6.1: Circular Pattern, Linear Pattern
Measurement of 6 holes as circular pattern
6.2: Radius from Diameter with Formula
The radius is calculated from the diameter value of a circle using
a formula
6.3: Probing positions
Measure hole and refer further probings to the center point
6.4: Break Condition
The CNC run is cancelled if the values are too large
6.5: LOOP on result (SIGMA) Break Condition with Loop
Characteristic with repetition if values are bad
6.6: Bore Pattern
True Position using bore pattern
6.7 Linear pattern with formula
6.8 Calculation of the depth of a groove
6.9 Conditional Branching
Contents
Calypso Advanced Course

Worksheet 7: Auto Run

7.1: Pallet Measurement
7.2: Series Measurement

Worksheet 8: Printout

8.1: One-line Printout
8.2: User Defined Printout
8.3 Exporting Results


Worksheet 9: Probe Route Optimization

9.1: Probe route optimization with probe head predeflection




Worksheet: Menu Design
Calypso Advanced Course 0 - 1
 Worksheet: Menu Design

Redesigning, saving and loading toolbars



Calling up the editor

Using the Toolbar Editor, you can decide which symbols
should be shown in whichreal cylinder.



Calypso Advanced Course Worksheet 5: Special Part Features
Calypso Advanced Course 5 - 9






As usual recall surface lines lying opposite to
one another as 2D line. These lines can be
checked for parallelism as they have been
recorded along the actual direction.





























Calypso Advanced Course Worksheet 5: Special Part Features
5 - 10 Calypso Advanced Course
Calypso Advanced Course Worksheet 5: Special Features
Calypso Advanced Course 5 - 11
 Worksheet 5.4: Recall Feature Points from Curve



Note: This evaluation can only be carried out if the “Curve” option is known.
As this subject is covered in the “Curve Measurement” training course, it does not need to
be examined in depth.

The recall of curve points is mentioned here for the sake of completeness and because of
the interesting application options.



Job: Extract points from a curve and calculate a geometric feature from these.
Here the curve is measured on the top of the cube. Then approx. 10 of the curve
points are used to calculate a circle.





















Calypso Advanced Course Worksheet 5: Special Features
 5 - 12 Calypso Advanced Course

Calypso Advanced Course Worksheet 5: Special Features
Calypso Advanced Course 5 - 13


Worksheet 5.5: Special Features



(Slot, rectangle, circle on cone, sphere point)


Job: Becoming familiar with new features on the practice cube


Slot:

1. Define a base alignment on the practice
cube:

Primary datum: “Plane_top”
Secondary datum: “Plane_front”
Zero pt in X: “Circle1”
Zero pt in Y: “Circle1”
Zero pt in Z: “Plane_top”

2. Define the safety cube.

Caution: there is no automatic feature
recognition for the following features.

3. Move the “slot” feature from the toolbox to
the Features page.

4. Open the feature and probe with at least 5
probing points:

• First probe two points on one side of
the slot.
• Probe one point in the summit of a
curve.
• Probe one point on the other side of
the slot.
• Probe one point in the summit of the
second curve.
• You can probe the other points where
you want.

Output the characteristics for the length, width
and angle.
 Think which axis the angle refers to.






Circle1




















Calypso Advanced Course Worksheet 5: Special Features
5 - 14 Calypso Advanced Course


Rectangle:

As there is no rectangle on our practice cube,
we have to construct a rectangle over the bore
pattern on the lower left.

Proceed as follows:

1. Move the “rectangle” feature from the
toolbox to the Features page.
You have to probe the “rectangle” feature
with at least 8 points. These probing points
must be distributed so that each side is
probed with two points.

2. Probe 8 single points in the holes.
Distribute the points as shown in the figure
on the right. =>

3. Open the “rectangle” feature and recall the
8 points to the feature (Feature Point
Recall).

4. You have to enter the value for the depth of
the shaft manually in the Length input box.
In this exercise the value is –20.

Caution !!!
Don’t forget to set the clearance plane
correctly for the individual points, otherwise a
collision will occur.

5. Safety groups have to be defined for the
points 2-3, 4-5 and 6-7:
• Open the “CNC” pull down menu.
Under “Navigation”, “Define Safety
Group”, open the relevant window.
• Create three new safety groups
and close the window with “OK”.
• Assign the points to the
corresponding safety groups (Tip:
use the Feature Editor).

6. Output the characteristics for the length,
width and angle.
Think which axis the angle refers to.





































Calypso Advanced Course Worksheet 5: Special Features
Calypso Advanced Course 5 - 15


Circle on Cone:

1. Move the “Circle on Cone” feature from the
toolbox to the Features page.

2. Open the feature and probe the circle on
the cone with at least three probing points.

3. Enter the “Cone angle” manually.
In this exercise the value for the cone angle
is 20°.
After you have confirmed the input with
ENTER, you can see in the CAD window
how the vectors (yellow arrows) of the
individual probing points align themselves.
Now the radius correction can be calculated
correctly and the circle is output with its
real diameter.

4. Output the characteristic for the diameter.


Radius, sphere and angle point:

With the radius, sphere and angle point
features, you can select the radius correction,
which applies in order to be able to define the
contact point correctly for the single point
measurements in various situations.


Sphere point:

For the sphere point, the measured value is
corrected in the direction of the connecting line
between the probe ball center point and the
defined center point.

1. Move the “Sphere point” feature from the
toolbox to the Features page.




2. Open the feature and enter the midpoint
and radius of the sphere (see figure).




































Calypso Advanced Course Worksheet 5: Special Features
5 - 16 Calypso Advanced Course


3. With the definition template option, probe a
point. Now the actual radius of the sphere
and the coordinates of the probing point are
output.

4. Output the characteristic for the radius.


You should have now created the following
characteristics:























Let the complete measurement plan run in the
CNC mode.













Calypso Advanced Course Worksheet 5: Special Features
Calypso Advanced Course 5 - 17
 Worksheet 5.6: Evaluation Constraints



Job: A measuring problem, which frequently occurs, is the measurement of a small circle
section.
The center point of the circle to be measured is often defined. I.e. the coordinates
are defined with e.g. the X value and Y value.
A circle is calculated from the probing points; its diameter represents a
characteristic.

Or the radius is defined and the center point coordinates are requested.

Both versions are shown here.
You can carry out the exercise on any work piece; this example uses a support.















Calypso Advanced Course Worksheet 5: Special Features
5 - 18 Calypso Advanced Course

Clamp the support; define a base alignment and the safety cube. You can carry out this
exercise on the CAD model.

Make four probings on the circle to be measured.









Enter the nominal values correctly.





Define X, Y and D as well as a radius
measurement.















Calypso Advanced Course Worksheet 5: Special Features
Calypso Advanced Course 5 - 19



Run the program and create a compact printout.

In the following, you will change the evaluation and create a compact printout for comparison.
We recommend you save these printouts.


Compact printout for the “normal” Gauß circle




Constrain the degree of freedom:
Evaluation
Evaluation Constraints.






Using the “Evaluation Constraints”
function with the circle you can
define the vectors for X, Y and Z or
the radius.



















Calypso Advanced Course Worksheet 5: Special Features
5 - 20 Calypso Advanced Course



Constrain the X, Y degrees of
freedom: The actual values of the
circle are “fixed” on the nominal.









Constrain the radius degree of
freedom; the radius is “fixed” on the
nominal.






Carry out various evaluations and observe the compact printout.



X, Y valueconstrained:




Radius constrained:



Calypso Advanced Course Worksheet 5: Special Features
Calypso Advanced Course 5 - 21

Representation in the custom printout with
• Gauß circle without constraint
• Circle with constraint of X and Y
• Circle with constraint of radius




Calypso Advanced Course Worksheet 5: Special Features
5 - 22 Calypso Advanced Course


Calypso Advanced Course Worksheet 6: Advanced Programming Functions
Calypso Advanced Course 6 - 1
 Worksheet 6: Advanced Programming Functions


With formulas and loops you have numerous ways of making CNC programs flexible.
These exercises will help you to become familiar with this topic.

Note that the use of parameters follows on directly from the use of formulas, conditions and
loops.
Further training is required for the parameter coded measuring runs topic. Loops and condition
functions are also used here.


1. Rotational pattern, Linear pattern
Measurement of 6 holes as rotational pattern
2. Radius from diameter with formula
The radius is calculated from the diameter value of a circle using a formula
3. Probing positions
Measure hole and refer further probings to the center point
4. Break condition
The CNC run is cancelled if the values are too large
5. LOOP on result, Break condition with loop
Characteristic with repetition if values are bad
6. Bore pattern
True Position using bore pattern
7. Linearteilung und Formel
8. Calculation of the depth of a groove
The depth of a groove is measured on a shaft
9. Conditional branching
A cycle should branch into different program variants dependent of the presence/absence
of a hole

Calypso Advanced Course Worksheet 6.1: Rotational pattern, Linear pattern
6 - 2 Calypso Advanced Course
Worksheet 6.1: Rotational pattern, Linear pattern



Job: Measure 6 holes as rotational pattern.
By specifying a rotational pattern, the measuring run for a circle is extended to all 6
circles of the pattern.



 Load CAD model
 Define the alignment
 Generate a rotational pattern for 6 circles

















Calypso Advanced Course Worksheet 6.1: Rotational pattern, Linear pattern
Calypso Advanced Course 6 - 3




















1. Load CAD model

CAD
 Load “Welle_1.sat”

Load the part as usual; create the alignment with suitable features.

CAD
 Modify Chart Settings
 Silhouette on


Note:
Make sure the origin from the CAD model is
placed in a suitable location.




2. Origin of the model:

CAD
 Modification
 Transformation
 Nominal vectors


Z= 20.0000


If you enter 20.000 in Z for “Translation”, the
model is then moved by this value. The origin will
lie on the height of the plane with the holes.




Calypso Advanced Course Worksheet 6.1: Rotational pattern, Linear pattern
6 - 4 Calypso Advanced Course
























1. Create base alignment

Probe the surface with the holes, a plane for primary datum and ZP.
Circle on the diameter 32 for origins in X/Y.
Secondary datum with the first 10 mm circle
MPH:
The base system should be defined with features, which do not have any circle segments,
polylines or grids. Therefore new features have to be generated/probed here.



2. Define features

Probe cylinder with 32 mm diameter.
Measure plane on the surface with the 6 holes with polyline
(these features will be used in a later exercise).

MPH: here a plane can be generated with polylines and where necessary intermediate
positions.


Define circle





Enter nominal values

















3. Create pattern

Nominal Input
 Pattern




Calypso Advanced Course Worksheet 6.1: Rotational pattern, Linear pattern
Calypso Advanced Course 6 - 5




































Select Rotational Pattern








This CAD is displayed once you have
filled in the page and concluded with
.


















Define Circle Segment:
Circle
 Strategy: 4 points from 0° to 360°

Generate Diameter as characteristic: Select D


The circle in the features list is displayed as follows:

Circle 2 is made up to 6 individual circles

Calypso Advanced Course Worksheet 6.1: Rotational pattern, Linear pattern
6 - 6 Calypso Advanced Course



View as characteristic:






View of Custom Printout
Calypso Advanced Course Worksheet 6.2: Radius from Diameter
Calypso Advanced Course 6 - 7
 Worksheet 6.2: Radius from Diameter


Job: The radius is calculated from the diameter value of a circle using the formula
option.


Procedure:

1. Existing measurement plan

2. Measure hole as circle with enough points for a form check, close circle

3. Take another circle from the toolbox

4. Open second circle,
Nominal Definition
 Recall One Feature

5. Select the first circle

Note:
With the “Recall” function, a copy of the
first circle is created. This copy has yellow
highlighted nominals to identify it as
theoretical feature.

These yellow nominals are the actuals
(measured values) of the first circle.
The formula can now access these
nominals.

6. Using the right mouse button, click on the
nominal for “D” and select “Formula”.


7. Enter the following formula:






Note:
In this formula window, inputs are possible corresponding to the prescribed syntax. All
features and characteristics can be accessed.
The return value is the result of the formula, which can also be displayed first with the
“Calculate” button.

8. Create the “D” characteristic from the second circle.
This characteristic is entered with the diameter icon, but is actually a radius. Renaming
ensures clarification. The nominal should also be entered correctly in the characteristic as
the current actual has been accepted during the generation.
Calypso Advanced Course Worksheet 6.3: Probing positions
6 - 8 Calypso Advanced Course
Worksheet 6.3: Probing positions


Job: Measure hole and refer further probings to the center point



 Measure hole 1 as the center point of the bore pattern.
 Probings in holes 2-5 should be defined relative to hole 1.
 If for example circle 1 were offset by 0.5 mm, the probings in the other holes should also
be offset.















Calypso Advanced Course Worksheet 6.3: Probing Positions
Calypso Advanced Course 6 - 9

Procedure:

1. Measuring the center hole results in circle 3, for example.

2. Insert another circle in the list from the toolbox: Circle4

3. Open Circle4 and assign the nominals with formulas as shown below.






1. In Strategy, assign the circle a Circle Auto Path with 4 probings.

2. Copy the circle 3 times and change the formula corresponding to the nominals of the other
holes.

3. Form the diameter characteristics and start the run.

4. CMM with trigger probe head: If the bore pattern itself is relatively accurate, the retract path
can be lessened to save time.

Calypso Advanced Course Worksheet 6.3: Probing positions
6 - 10 Calypso Advanced Course
Notes:
Calypso Advanced Course Worksheet 6.4 : Break Condition
Calypso Advanced Course 6 - 11
 Worksheet 6.4: Break Condition

Job: Cancel a CNC run because the values are too large


1. Existing measurement plan

2. Measure the hole as circle with sufficient points for a form check

3. Roundness as characteristic

4. Run program to collect points

5. Set the break condition
Click the “ Roundness” feature
right mouse button: Condition

This window opens:

Click on Post condition

The formula window is opened
Enter formula – see below.















6. Start this CNC run.
Createvalues, which are wrong in order to check the break criterion.
Calypso Advanced Course Worksheet 6.4 : Break Condition
6 - 12 Calypso Advanced Course

Calypso Advanced Course Worksheet 6.5: Break Condition based on Deviation
Calypso Advanced Course 6 - 13
 Worksheet 6.5: Break Condition based on Standard Deviation


Job: This exercise demonstrates the use of the LOOP function. Here the loop is used
to repeat the measurement of a feature based on a result (e.g. Sigma standard
deviation)


1. Open a measurement plan and establish
a base alignment.
2. Measure another plane (Plane4) taking
one point in each corner.
Normally a diameter is used to check the
form. We are using a plane for testing the
function better.
3. Using the right mouse button open the
formula in the Z nominal input box.
4. In the Formula window enter the
following:
0+(LOOP1*0)
This formula establishes the loop counter
LOOP1 in the feature. The first zero in
the formula represents the nominal
dimension; the next part is the actual
loop counter. This counter multiplied by
zero will always be zero.


5. After clicking OK create a characteristic for the Z location.


Worksheet 6.5: Break Condition based on Deviation
6 - 14 Calypso Advanced Course

6. Select the Z dimension characteristic for the plane, click on this with
the right mouse button and select Loop.
7. Click Insert and enter the maximum loop program cycles (5
in End).


8. Using the right mouse button, click in
the Break Condition field and select
Formula.
9. Enter the following formula in the
formula field:
getActual("Plane4").sigmaso
that the following holes are measured.

1, 2, 5, 6, 7




You can try out this exercise
on other work pieces.



Calypso Advanced Course Worksheet 6.7: Linear Pattern and Formula
Calypso Advanced Course 6 - 25



































Linear pattern with formula



Create another circle, e.g. Circle2







Set a formula for the Y value









Enter values as shown on the right.




Think of a suitable measuring strategy.



Create characteristics.


Group the characteristics together so
that a loop can be inserted over these
characteristics.






Check the incrementation of the Y value in the
printout.


What solution can you think of for the “2nd
row”?

Adapt the run on the measuring machine.
Calypso Advanced Course Worksheet 6.7: Linear Pattern and Formula
6 - 26 Calypso Advanced Course


Notes

Calypso Advanced Course Worksheet 6.8:Groove Depth
Calypso Advanced Course 6 - 27
 Worksheet 6.8: Calculating the depth of a groove

Job: Calculate the depth of a groove on a shaft.


























The depth of the groove cannot be measured
directly.
Probings in the base of the groove are possible,
but not probings at the highest position on the
vertical axes.

An alternative would be the “slot” feature. Here you
can evaluate the depth of the hole, but this
dimension is dependent directly upon the probing
strategy.




Calypso Advanced Course Worksheet 6.8: Groove Depth
6 - 28 Calypso Advanced Course

Using a formula solves this problem:

The diameter or the radius of the shaft is easy to determine.
In addition to this, the space axis with zero dimension is located in the center of the shaft.

By probing a Z point, you will get a value, which you can subtract from the radius.

Try this simple application without
further instructions.















Calypso Advanced Course Worksheet 6.9: Conditional Branching
Calypso Advanced Course 6 - 29
6.9 Conditional branching







Job:

A program is to be developed, whereby one or another
part of a CNC cycle is run dependent on the presence or
absence of a hole


In detail:
A characteristics group includes a check of the top circle
segment diameter.
A second group checks the roundness and position of the
cylinder on the front side of the cube.


The measurement plan therefore consists of two groups.


Calypso Advanced Course Worksheet 6.9: Conditional Branching
6 - 30 Calypso Advanced Course
Design the measurement plan using Conditions according to the above guidelines.

If the condition is true (correct):
Hole present -> measure the top circle segment.

If the condition is false (incorrect):
hole absent -> measure the cylinder.

Under no circumstances should both
be measured!

The corresponding graph could look like
this:














As Calypso should branch dependent on a hole, this must be “checked” with a probe point.



If the Z value is near to zero (or at least > -1), so there is no hole: the cylinder must be
measured

Otherwise the Z value is around –8 and the hole can be measured as a circle.



Calypso Advanced Course Worksheet 6.9: Conditional Branching
Calypso Advanced Course 6 - 31
The following steps:

1. Generate a probe point in the hole
2. Caution – danger of collision! If there is no hole, the machine will travel at high speed
up to 2 mm in front of the anticipated probing.

3. Create the characteristic “Z value” from this point. This Z value is checked from the
Conditions as follows.

4. Make the Circle Segment group the first entry in the measurement plan.


5. Assign a condition to the Circle Segment group with a right mouse click.




6. Insert the custom printout
illustrated.












7. Now the program initially
checks the point.

8. Then the condition is applied in the Circle Segment group. If the outcome is “no”, the
circle segment is not measured. Only the cylinder measurement is carried out in this case.

9. If the condition is satisfied (“yes”), the circle segment is measured and subsequently also
the cylinder. This, however, should be avoided.

10. A check must also be carried out before the Cylinder group, which results in the exact
opposite of the first check.



11. Test the cycle by covering the hole with a coin.
Caution – danger of collision!






Calypso Advanced Course Worksheet 6.9: Conditional Branching
6 - 32 Calypso Advanced Course


Worksheet 7: Auto-Run Interface
Calypso Advanced Course 7 - 1
 Worksheet 7: The Auto-Run Interface



The “Auto-Run” function enables you to carry out two different types of runs:



1. Pallet measurement:
Several identical parts are measured in succession on a pallet.

This requires an exact work fixture, as the same measurement plan is offset by X and
Y values of the clamping positions.



2. Series measurement:
Several different parts are measured automatically in succession.

Different measurement plans are run through one after the other.





The function works with a special user interface which lets Calypso run in the background.
This interface is intended for users who only have user rights to start programs.
The user rights should be set explicitly in Autorun for each user; these do not influence the
user rights in Calypso.



Worksheet 7: Auto-Run Interface
7 - 2 Calypso Advanced Course
1. Pallet mode

1.1 Preparations

 Create a complete measurement plan for the part to be measured.
 Create a base alignment on the pallet itself.
To do this, use a separate measurement plan. A base alignment from three
single points each with the origins in X, Y and Z may suffice.
 Define distances between positions on the pallet in X and Y, clamp workpieces on
pallet.


1.2. Setting up the pallet mode

Close all measurement plans.

Open the Auto-Run Interface:

CNC
 Autorun

The Auto-Run Interface window is opened.

1.Give the layer a new name:

Layer
 Rename
 Palette1


2.Insert a pallet:

Edit
 Pallet
 Enter


1.3. Enter pallet parameters (right mouse
button)

⇒ Pallet alignment=base alignment of
the pallet (see Preparations)
⇒ Pallet name
⇒ Distances between positions on the
pallet in X and Y
⇒ No. of rows in X and Y.
⇒ (Exercise example: Input of the
thread bores of the granite table
each with three rows: 200/3, 200/3)


Worksheet 7: Auto-Run Interface
Calypso Advanced Course 7 - 3











1.4. Insert measurement plan:

Right mouse button on pallet icon or:
Edit
 Pallet
 Insert measurement plan
 e.g. click on “Shaft2” measurement
plan





1.5. Define run loop:

Right mouse button on pallet icon or:

Edit
 Pallet
 Define Run Loop

Enter the number of runs:
Right mouse button, Insert
Here from 1 to 4, Step 1:
Means the first four positions will be measured.

Alternatively you can select the occupied positions
directly in the pallet icon.





1.6. Define measurement plan parameters:

Right mouse button on pallet icon or:

Edit
 Pallet
 Measurement plan
parameters

Enter:
⇒ Base alignment
⇒ Speed
⇒ Custom Printout
etc.








1.7. Start pallet measurement
Press start button

Calypso Advanced Course Worksheet 7: Auto-Run Interface
7 - 4 Calypso Advanced Course













2. Series measurement

2.1 Preparations

 Create complete measurement plans for the parts to be measured.
Each measurement plan has its own base alignment.


2.2. Set up the series measurement

Close all measurement plans

Open Auto-Run Interface:

CNC
 Autorun

The Auto-Run Interfacewindow is opened.

1.Give the layer a new name:

Layer
 Rename
 Pallet

2.3. Insert measurement plans

Edit
 Edit measurement plan

Select a measurement plan from the list.


2.4. Enter parameters

Select a measurement plan each time.

Edit
 Measurement plan
 Enter CNC start parameters




2.5. Start the programs

Click on the measurement plans which you want to start. The measurement plans are
selected, you will see a frame.
For further selection use the Strg button.

The measurement plans are run through in the order they are selected.
Click on “Order” if you want to change this.


Calypso Advanced Course Worksheet 7: Auto-Run Interface
Calypso Advanced Course 7 - 5



3. Layer change


You can create several layers and change between these layers in the auto-run mode:


Select the icon:

or

Edit
 Layer
 Enter layer

Select the layer you want.


This icon is added to the layer:








By double-clicking or by using the right mouse button,
you can jump to another layer.
This branching must be created for each layer you
want.
The same applies for switching back.


Calypso Advanced Course Worksheet 7: Auto-Run Interface
7 - 6 Calypso Advanced Course
 Add your own pictures to the auto-run interface

Example of a customized interface:
There is an image stored for each CNC run.
A background image can also be defined.

These functions are activated by clicking the right mouse button on the background or on the
run.
























The images must be available in *.bmp, *.jpg or *:gif format.
See the User Manual for a detailed description.



Exercises:

1. Design your own user interface

2. Create a new user, who only has limited user rights.




Worksheet 8.1: One-line Custom Printout
Calypso Advanced Course 8 - 1
 Worksheet: One Line Custom Printout


Job: The default custom printout consists of one section with icons and several
lines.
For extensive measurement plans, this leads to several pages of printout.
What you can do here is reduce this to one line per characteristic.

Note:
To change the printout, you must be familiar with common graphics programs as well as
understand the relationship between printout header and feature list.






Worksheet 8.1: One-line Custom Printout
8 - 2 Calypso Advanced Course

Procedure:

1. Open the Calypso graphics program:
Resources
 Design Custom Printout
 Characteristic

2. Click on the “Load” (= open folder) icon

Note:
All printout formats (header, characteristic, feature...) are in a directory under
C:\om\protform\... When you open this graphics program for the first time the file
C:\opt\om\protform\default\cffra.gra is always loaded.
If this file is changed in the “default” folder, the version supplied is destroyed.
For this reason you must first save it under a different name!


3. Overwrite the name as shown below:



4. Edit the characteristic display as follows:
Delete the icon, move the entries, set vertical lines.

Worksheet 8.1: One-line Custom Printout
Calypso Advanced Course 8 - 3

5. If the position of nominal and actual values etc. are moved, the printout header must
be adapted:
Load the graphics program for the printout header:
Resources
 Design Custom Printout
 Report Header File Editor

When this graphics program is opened, the following file is always loaded
“C:\opt\om\protform\default\vphead.gra”.

Here as well you must save the “single line” folder under another name straightaway.

6. Edit according to how the characteristic looks. Title and numerical value must be
beneath one another.

Note:
Check how this looks by printing out on the printer. If the first time the titles are not
correct, then change this till you have what you want.


7. Also edit the printout header for follow-on pages:
Resources
 Design Custom Printout
 Report Header File Editor

 When this graphics program is opened, the following file is always loaded
“C:\opt\om\protform\default\header.gra”.
This is the printout header for the follow-on pages from page two.



8. Assign this new printout header to a measurement plan:

Resources
 Format Custom Printout
 Output format: one-line

9. The result you will get is illustrated on the next page.
Worksheet 8.1: One-line Custom Printout
8 - 4 Calypso Advanced Course










































You can change the printout header in the same way. To do this load the vphead.gra
file and edit.
Worksheet 8.2: User Defined Output
Calypso Advanced Course 8 - 5
 Worksheet 8.2: User Defined Output


Job: The default custom printout is to be replaced by a printout showing a
graphics display of the work piece. The characteristics should be on the side
and refer to the relevant features in the illustration.

Note:
To change the printout, you must be familiar with common graphics programs as well as
understand the relationship between printout header and feature list.









Worksheet 8.3: Log design
8 - 6 Calypso Advanced Course

Procedure:

1. Create measurement plan with characteristics.




Open the Calypso graphics program:
Resources
 Design Custom Printout
 User Defined Output


2. Click on the “Load” icon (=open folder)

Note:
The printout header formats for the
user-defined category are found in a
separate folder.





3. Insert picture from screen.





Worksheet 8.3: Log layout
Calypso Advanced Course 8 - 7

5. Note the list of available characteristics.
By clicking, you enter the characteristics in
the form and align the features on the side.























6. Format the page so that it fits the print area of
your printer.
File
 Format




7. Assign characteristic to graphics using arrows.





8. Now all that is missing is the
printout header itself.
You can generate a new
header; the simplest way of
doing this is to copy the
header of a default printout
into the form.





Worksheet 8.3: Log design
8 - 8 Calypso Advanced Course

9. The output must now be modified for the measurement plan, which is opened:

Resources
 Format Custom Printout

Here the list output is
deactivated and the user
defined printout
activated. If this step is
not done, then the
printer will output both
printouts.













10. Start the run and check the printout.



Worksheet 8.3: Log layout
Calypso Advanced Course 8 - 9
Worksheet 8.3: Log design


Job: Several changes to the log are to be carried out in this section.
As the available options are of a very diverse nature, this section only
serves as an introduction and, of course, does not show all possibilities.


1. Attach a comment to the measurement characteristic

2. Insert a text element in the measurement plan

3. Insert a log header variable in the characteristic
(PCM function)

4. Save compact log

5. Generate a user-defined log header field




1st Job: Attach a comment to the measurement characteristic


Create a measurement plan with useful characteristics and consider both presentation and
compact logs.

Shown here without a comment,
the characteristic “diameter” should be assigned a comment.



Worksheet 8.3: Log design
8 - 10 Calypso Advanced Course

Select the diameter and right mouse
click to rename the characteristic.










Enter a commentary text, which should
comprise at least two lines here as an
example.




Display of the log after a new run:












Please note that the length of the characteristic in the presentation log is increasedif the
comment extends over several lines.


Worksheet 8.3: Log layout
Calypso Advanced Course 8 - 11

2nd Job: Insert text element

Select the text element from the toolbox and insert it at a relevant place in the
measurement plan.

Important: The appearance of the text is subject to the usual rules for a characteristics-
oriented run. The appearance of the log may influence the text element through selective
CNC runs or program changes.




















Start the CNC run with all measuring characteristics.
The logs appear as follows.




Worksheet 8.3: Log design
8 - 12 Calypso Advanced Course

3rd Job: Insert a variable into the log Variable

This job can only be carried out with the “PCM” option.


The exercise involves selecting the ”part number incremental” from the log header
variables, familiar from earlier exercises and inserting them into a characteristic as a
comment.

Bear in mind that this example only serves to give an idea of the complex options for
linking variables using formulas.
Think out your own applications as a means of consolidating the subject.


Sequence:

Take the diameter from the
previous example, open it and
delete the comment.
Now click the right mouse in the
commentary field and select
“Formula”.

Enter in the formula field:


The function "getRecordHead()" reads a variable from the list of log header variables, in
this case the variable "partnbinc". This is the part number incremental.



The log now shows the part
number as a comment.











4th Job: Save compact log

The compact log is stored as a text file.
Name of the text file: "cprotokoll.txt" in the measurement plan directory:
...calypso\opt\om\workarea\inspections\

Work out a routine whereby the compact log is automatically saved to another
directory or onto disk following completion of a CNC run.


Worksheet 8.3: Log layout
Calypso Advanced Course 8 - 13
5th Job: Generate a user-defined log header field

This function allows you to design the log header with freely defined field names.


Preparation:



Orientate yourself in Explorer: this requires the
file "userfields.txt" to be edited.

It is found in the directory
...Calypso\opt\om\protform

and has e.g. the following content:








Each individual line defines a new field according to the following rules (also see User
Manual):

You will, for example, see the following three lines in the file userfields.txt:

u_field1,FELD 1,RE
u_field2,FELD 2,R
u_field3,FELD 3,E



Element Significance
Name used in the result file, must begin with “u_”
Description is shown in dialogs
Display control E = appears in dialog when editing,
 R = appears in dialog at CNC start,
 RE = appears in both dialogs

You can generate any number of further filed according to this principle; other fields may
already be defined in Calypso:


u_company,WERK:,RE
u_run_number,Bearbeitung:,R
u_examble,BEISPIEL:',E

Worksheet 8.3: Log design
8 - 14 Calypso Advanced Course

Application:


The log header should appear as follows:



Generate three new fields according to the above pattern:

u_machine,Machine-Number:,RE
u_shift,User Shift:,RE
u_username,User Name:,RE

Save the file "userfields.txt". These fields are now available.

Open the log header editor in the normal way.





The new fields are now offered.


Place these fields in the log header such that the desired
display appears.






Worksheet 9: Probe Route Optimization
Calypso Advanced Course 9 - 1
 Worksheet 9: Optimizing Probe Routes

9.1 Probe route optimization with probe head predeflection


Job: Probe route optimization with probe head predeflection


During movement of the CMM, the measuring probe head is predeflected.
This means that if a collision occurs, the braking path which is possible is increased due to
this higher deflection path.

This predeflection however may by a hindrance when probing in blind holes or on narrow
edges.

Example:

Point P1 is to be probed 0.5 mm from the surface P_Ref.
If P1 is approached directly from the SG-X safety plane, the probe ball may briefly come
into contact with the surface P_Ref (due to the probe head deflection).


Probe route optimization:

• A local coordinate system “P_loc” is formed with P_Ref as origin.
• The nominal coordinates of P_Ref are increased in the opposite direction to the
material in –X. This then takes into consideration possible large fluctuations in the
material.
• The P1 probing point is approached in the “P_loc” coordinate system.
• P1 and P_ref are set to a new safety group “SG-X_loc”. (CNC/Navigation/Safety
Group). The probe is then only retracted to the safety distance.
• The safety distance of P_Ref must be selected relatively small to P1.
• If necessary, the speed for P1 and P_Ref can be reduced in the measurement plane
editor-features page.

Worksheet 9: Probe Route Optimization
9 - 2 Calypso Advanced Course

Note:

This reduction in speed is only effective for travel movements in the feature from the
safety distance (not from the safety cube!)

If necessary, you can set additional intermediate positions in the P1 feature before and
after the probing.
You must set the intermediate positions so that the travel path part is the greatest in the
direction of P1.
Intermediate positions are accepted if the push button in the XY joystick on the control
panel is pressed when the P1 feature is open.

As an alternative to this, an intermediate position can be created in the P1 feature strategy
window using the “Intermediate position” icon.

To evaluate P1, the relevant coordinate system must be recalled.order.






Properties

• easy to operate
• comprises 2 input windows
• integrated: all functions have graphic symbols
• additional search function, format, help, job protocol,
trash bin, output
• key administration is always at the extreme right and
cannot be deleted
• maximal length same as the space above the workspace
• one toolbar definable per user
• saved under one’s own name as...\home\om*.config
• symbols may be moved from the lower to the upper window with drag&drop


See User Manual for further operating instructions



Exercise:

Define a menu bar according to your notions.

Example:





Worksheet: Menu Design
0 - 2 Calypso Advanced Course

Some application tips:

To insert a symbol at the right end of the toolbar (in front of the key group): Click on Insert
at the End.
- or -
To insert at another place along the toolbar
Mark the symbol in the upper window and click on Insert Before Selection.

The toolbar in the upper window is expanded accordingly. If there is no more space
available for the symbol to be inserted, a message will appear.
To remove a symbol from the toolbar: Mark it in the upper window and click on Remove
button.

Once the toolbar is to your satisfaction: Save with Save As..., if you want to transfer it to
the workspace at a later time.
- or -
Click on Accept to make the toolbar immediately effective for your workspace.

Close both windows with OK.


Keyboard operation
All functions can also be operated in both windows using the keyboard (Windows
standard).
With Enter (= double click), you can insert the marked symbol at the end of the toolbar;
Strg+Enter (= Strg + double click) inserts a preceding space.


Mouse operation (drag&drop)
You can also drag symbols from the list in the lower window into the toolbar in the upper
window with the mouse (using drag&drop).
If you press Strg, a space is inserted before the symbol. If you press Shift at the same
time, a space is inserted after the symbol. If you press both keys, spaces will be inserted
both before and after the symbol.





Calypso Advanced Course Worksheet 1: Probe Qualification
Calypso Advanced Course 1 - 1


Worksheet 1: Probe Qualification


Contents:
1. Automatic Probe Qualification
The automatic probe qualification will help you to become familiar with handling
probes.
2. Gage Qualification
Recalibration of a stylus on a plug or ring gage. Prerequisite for high accuracy
measurements and for qualification of special probes in the following section.
3. Special Probes
3.1. Disk probe
3.2. "Inclined" probe
3.3. Cylinder probe















Calypso Advanced Course Worksheet 1: Probe Qualification
1 - 2 Calypso Advanced Course















Calypso Advanced Course Worksheet 1: Probe Qualification
Calypso Advanced Course 1 - 3



1. Automatic Probe Qualification



Job: Automatic run of the probe qualification



⇒ A measurement plan must be created for this purpose.
⇒ The contents of this measurement plan must deal with the qualification only.
⇒ The styli must be qualified once before hand manually.
⇒ CNC-Start window: Navigate using position points only.






Calypso Advanced Course Worksheet 1: Probe Qualification
1 - 4 Calypso Advanced Course











1. Open the new measurement plan
2. Insert the Stylus Qualification feature:
Open the toolbox
Resources
 Probe Qualification
3. You have to take a “Probe
Qualification” feature from the toolbox
for every probe.
4. Assign a probe to every “Probe
Qualification”.

5. Open the Probe Qualification
Ref. Sphere position
Note: The reference sphere position
must be defined once at the start.
6. Probe the reference sphere manually;
the automatic definition is then
started.


7. Close the Probe Qualification.
8. Start the CNC run:
CNC-Start window: Use Position Points Only
9. The qualification is now carried out automatically in the same place as previously where
the “Position definition” was defined.

The stylus qualification now runs
automatically for every probe, which
– has the “Probe Qualification” feature
and
– is located in the probe rack.

Otherwise the CNC run stops and
requests a manual probe change.








Caution:
The “no generation“ mode remains active at the next CNC start, even if another program is
started!
Switch back to “automatic” without fail, as otherwise the threat of serious collisions may exist!

Calypso Advanced Course Worksheet 1: Probe Qualification
Calypso Aufbaukurs 1 - 5
 2. Gage Qualification


Job: Measure with high accuracy a diameter in a specific location in the measuring
volume.

⇒ The accuracy required cannot be guaranteed with the normal qualification (standard or
tensor).
⇒ A calibration standard – plug or ring gage – is assembled at the location in the measuring
volume and measured with the probe as a circle. The nominal diameter of the calibration
standard is entered.
⇒ With this gage qualification, influencing parameters such as bend are recorded.

⇒ These parameters can be kept ready for later measurements.







Calypso Advanced Course Worksheet 1: Probe Qualification
1 - 6 Calypso Advanced Course






1. Record the bending parameters

2. Resources
 Utilities
 Gage correction

This is a “normal” circle
with the “Gage Correction
Qualification” property.
(Alternatively, a circle can
be taken which is given
the “Gage Correction
Qualification” property for
“Evaluation”)

3. Enter D: 100mm
(for gage 100 mm
diameter)
This circle is now given
the nominal diameter of
the gage.

4. Measure the circle once in
the CNC run.
The circle must be
measured using the
scanning method.
The bending parameters
are now recorded and can
be kept ready for other
circles.

5. Use the bending
parameters
Measure circle
Open circle
Evaluation
 Gage Correction

6. Measure and correct another circle with similar diameter

The correction values are taken into consideration.

7. Form the characteristic
Diameter, roundness,.....

8. Important:
The gage calibration is effective for all measurement plans.
Therefore: Create a measurement plan just for the gage calibration.
Stylus dependent: Only the corrected stylus can be used.
When checking the diameter this should be as near as possible to the ring gage diameter
and
when calibrating the gage, its position should be as near as possible to its position for the
later measurement.


Calypso Advanced Course Worksheet 1: Probe Qualification
Calypso Advanced Course 1 - 7
 3. Special Probes

3.1 Disk probe


Job: Qualify a disk probe



⇒ Qualification of the disk probe on the calibration sphere
⇒ Recalibration on the calibration standard
⇒ Manual correction of probe data







Calypso Advanced Course Worksheet 1: Probe Qualification
1 - 8 Calypso Advanced Course

A disk probe is not a complete sphere but a
section of a sphere.




When working with the probe there is
always the risk that probings will be made
with the edge of the disk and not with the
flat side.











To qualify the probe:

1. Assemble a disk probe
2. Calibrate “manually” with 8 points in
2 section heights
3. Clamp a ring gage or plug gage on
the table
4. Create a base system on the ring /
plug gage
5. Measure this “calibration standard”
as circle
6. Output of the diameter in the default
printout:
7. The deviation from the actual
diameter must now be corrected.
Open the probe data and edit the
radius.
8. Measure the plug / ring gage again
and view the diameter.
9. If necessary carry out a correction.



Calypso Advanced Course Worksheet 1: Probe Qualification
Calypso Advanced Course1 - 9
3.2 Qualifying an inclined probe







⇒ Qualify the inclined probe as usual
⇒ Determine the inclination of the shaft with the cylinder feature
⇒ Recalibrate with the correct vector data







Calypso Advanced Course Worksheet 1: Probe Qualification
1 - 10 Calypso Advanced Course

1. Assemble an inclined probe.
2. Qualify the inclined probe as usual
on the calibration sphere. When you
are doing this, make sure you probe
in the direction of the shaft.
3. Once you have completed the
calibration, change to the Features
page.
4. Probe eight points at two heights on
the sphere of the calibration standard
using the shaft of the probe (see
photo).





5. The software outputs a cylinder with the diameter of the calibration sphere. The
inclination of the cylinder axis, output via the projected angles A1 and A2, is defined
using the inclined position of the probe shaft.



6. Close the cylinder in order to call up
the Features representation window
using the corresponding icon. The
feature must be selected to do this.

7. The Features representation window is opened:


 Open the popup menu in the Mode field and select “Change”.
 Click on the “Angle” option.
 Click on “Vector”.
Calypso Advanced Course Worksheet 1: Probe Qualification
Calypso Advanced Course 1 - 11

8. Open the cylinder feature again and make a note of the actual values of the vector
components Nx, Ny and Nz.


9. Change to the “Resources”
page and open the window for
the probe definition.
10. Open the probe
administration using the
relevant icon.

11. Edit the values for shaft X,
shaft Y and shaft Z. Close the
page and calibrate the stylus
again in the CNC mode.





Calypso Advanced Course Worksheet 1: Probe Qualification
1 - 12 Calypso Advanced Course
Notes:
Calypso Advanced Course Worksheet 1: Probe Qualification
Calypso Advanced Course 1 - 13
3.3 Qualifying a cylinder probe







⇒ Qualify the cylinder probe in the manual mode
⇒ Recalibrate on the calibration sphere
⇒ Manual correction of the probe data







Calypso Advanced Course Worksheet 1: Probe Qualification
1 - 14 Calypso Advanced Course

1. Assemble a cylinder probe.
2. Calibrate the probe manually on
the equator of the calibration
sphere with eight points at two
heights.




3. The software calculates a sphere
within the cylinder.
(see drawing)



4. After you have completed the
calibration, change to the Features
page.
5. Measure a circle on the equator of
the calibration sphere.
6. Compare the diameter of the circle
with the diameter of the calibration
sphere.
7. The deviation from the actual
diameter must now be corrected.
8. Open the probe data and edit the
probe radius. (Cf. Qualifying a disk
probe)



9. If necessary, repeat this procedure
several times.

































Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 1
 Worksheet 2: Special Alignments

1. Offset Plane
The offset plane as feature and use as alignment element
2. Change axial alignment
3. Startsystem
4. Iterative Alignment
Single points on the practice cube are calculated to features.
These form an alignment. The iteration is executed with loops.
5. RPS
Special alignment for sheet metal measurement
6. 3D Best Fit on the Practice Cube with Loops
7. 3D Best Fit with Loops
A pipe with 4 bends is shown with the X, Y and Z points of the bend points. The bend
points are used for the 3D best fit.
8. Change the coordinate system using the Editor
Change the coordinate system for several elements simultaneously
9. Rotation on a straight line through the origin














Calypso Advanced Course Worksheet 2 : Alignments
2 - 2 Calypso Advanced Course




Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 3


Worksheet 2.1: Alignment with Offset Plane



This exercise uses a theoretical plane 50 mm above the
work piece for the alignment, the primary datum.
This plane cannot be probed directly but has to be
defined with 3 points on the cube, which have to be
corrected in the height.

This Offset Plane is a feature in Calypso and must be
probed with exactly 3 points.

1. Open new measurement plan.

2. Insert Offset Plane in the measurement
plan
open this plane



3. Probe three single points on the practice cube.
- Point 1 upper rear.
- Point 2 in circular slot
- Point 3 in the slot at the front



4. The points must be corrected so that a plane is
created at a height of
50 mm above the cube.
5. According to the
drawing the correction
values are:
- Point 1: -50 mm
- Point 2: -58 mm
- Point 3: -60 mm.

 The plus/minus sign
originates from the offset
height you want and
determines the dimension by
which the individual point must
be corrected.


6. Close Offset Plane
.

See next page


Calypso Advanced Course Worksheet 2 : Alignments
2 - 4 Calypso Advanced Course

7. In the Offset Plane:

Evaluation
 Edit


Correct the points, make sure
the plus/minus sign is correct.








8. Select other useful features
for the alignment and probe.
9. Create the base alignment.
10. Define the safety cube.
11. Edit the clearance distance
and retract distance.

Please note, that each point in the offset plane is probed as in a normal plane with
the default retract distance (2mm). This is not possible for the points in the slot.

Note: Later in the exercise, the cube is tilted by several degrees. Take this into
consideration with the probing points and the retract distances for all the features.
12. Start the run to check the alignment.
13. Tilt the cube so that you can actually see it is tilted and start the run again.

Note:
At the CNC start you can choose between the
“Offset” base system and “Offset(CNC)”.

Offset(CNC) uses the base system determined
last in the CNC run.

Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 5

14. Points to be taken into consideration when correcting the probe points.


15. With this alignment, the first run results in an offset plane with an error with the
“wrong” correction in machine coordinates.

If the alignment is repeated and the
plane direction of the first run
accessed, the result improves
considerably. In a third cycle – with
the correction direction of the second
alignment – the error approaches
zero.

The resource here is a loop.


16. When you call up the base
alignment, click on loop and then on
Insert.
Enter the values as shown in the
illustration.


17. Start the run again.
The base alignment is now run
through three times.



Calypso Advanced Course Worksheet 2 : Alignments
2 - 6 Calypso Advanced Course

18. At the end, take a look at the values in the default printout.
The value “A” is of interest here; it is the total of the shift, rotation and tilt values.
The value “A” specifies the amount by which the coordinate system has changed
since the last alignment.
19. In a later exercise, this value is requested by a break condition.
20. The illustrations below show the A values in the first, second and third cycle.








Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 7


Worksheet 2.2: Changing axial alignment


Mount a work piece on the measuring machine and create a base system; the work piece
coordinate system is automatically aligned close to the machine’s coordinate system with
slight angular variances.

Or load a CAD model; in this case, a zero point and the corresponding alignments are
preset.

Itmay be necessary to define the work piece in a completely different direction. For
instance, to show the Z axis of the work piece in the Y direction.

This exercise should illustrate how the base system may be changed in such a case.

Use a work piece and the CMM or a CAD model and work offline.

.



Here it is important that you have
to manually change the
automatic recognition of axial
alignments.






Worksheet: Iterative Alignment
2 - 8 Calypso Advanced Course

The offline programming is shown here as an
example:
1. Define a cylinder in the circular slot
2. Use this cylinder as the primary datum
(spatial orientation).
3. Set the axis direction of this cylinder to
“X-axis”.

Create and enter the other
elements of the base
system.








4. The secondary datum (rotation in the plane)
must also be checked manually and corrected
as necessary.

5. Set the distance
between the circle and
axis using the “Special”
function (rotate to
distance).

The coordinate system is now defined as in the drawing, the axial orientations are chosen
arbitrarily.

This type of programming generally calls for special attention when processing further
elements. The automatism for axial orientation and probing routes is calculated
accordingly. The conceptualization of the change in position usually requires the user’s
complete attention.
Please pay special attention to the definition of the safety cube on the following page.


Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 9

Definition of the safety cube for a change in axial position:

Until now, the safety cube was normally achieved by approaching the
 "rear, top, right” corner and
 "front, lower, left" corner
of the work piece.

The “rear, top, right” corner is the point with the high X, Y and Z coordinate values

referenced to the base system.

If the basis system is now rotated, “rear, top, left” are to be interpreted with reference to
the basis system and NOT according to the machine coordinate system!

A message appears if the corners of the safety cube are entered incorrectly.



Worksheet: Iterative Alignment
2 - 10 Calypso Advanced Course

Worksheet 2.3: Start System and Base System
Calypso Advanced Course 2 - 11
 Worksheet 2.3: Start System and Base System


What does a start system do?

































Practical exercise :

Important:
A start system is used in

• base systems with scanning elements.
Scanning elements cannot be manually re-measured! A start system is inserted in
this case.
• base systems comprising complex links.
A system start can be used here to reduce the work of manual calibration.


The base system is placed in the center of the upper bore, a start system on the front
right edge of the cube.

Any CNC program should be started by means of the start system.

Worksheet 2.3: Start System and Base System
2 - 12 Calypso Advanced Course
 Method:


Measuring the elements for the base system

• plane with 4 points
• circle with scanning
technology
• straight line with two
points



Creating the base system in
the center of the bore:



















Measuring the points and creating the start
system:




Worksheet 2.3: Start System and Base System
Calypso Advanced Course 2 - 13





The start system is selected
with Preparation – Select
Base System.













Only fill out the zero points.

Thus, the axis directions
remain aligned with the
device axes.












Create arbitrary measurement
characteristics in order to enable
a useful CNC start.




Test the start system with the
available options “manual
alignment” etc.



Worksheet 2.3: Start System and Base System
2 - 14 Calypso Advanced Course
 Worksheet 2.4: Iterative Alignment

Alignment using plane with 3 probings at different heights and iteration


A coordinate system is generated by means of an offset plane, whereby the offset plane
has to be generated manually using the formula.

Dieses bedeutet eine grössere Variabilität, da eine beliebige Anzahl von Messpunkten für
die Offsetebene zur Verfügung stehen können.






A work piece rests on three points, which are located at different heights. A plane is to be
defined with these three points, which is declared as primary datum in WCS 2.
This is the classic calculation for an offset plane.
An offset plane from the toolbox always consists of exactly three probings, which can be
corrected, in their height.

In this exercise, an offset plane is to be
calculated from individual points using the
formula.
Advantage: More than three points can be
used.


This new WCS should be run through at
least twice so that the correction of the
offset probings is created in the correct
alignment.


Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 15




1. Load CAD model of the practice cube.

2. Click on 3 points in the CAD window:
1st point (P1) on the top surface
2nd point (P2) in the slot at the front
3rd point (P3) in the slot at the back

3. Add 2 more points (P4, P5) from the toolbox to
the list.

4. Open the first of these points (P4)
Recall one feature: Point 2
Edit the Z value with the formula:
correction by 10 mm.

5. Open the second point (P5), recall P3, correction
by 8 mm.

6. Take a plane from the toolbox and
define using recall of point 1, 4, 5.
This plane is the same as the top
surface.

7. Form the first symmetry point from 2
probings (P6, P7): front right, front
left

8. Form the second symmetry point
from 2 probings (P8, 9): front right –
front left

9. Calculate 3D line from these 2
symmetry points

10. Set point 10 at front for Y=0

11. Basissystem erzeugen:

Ebene 1 für Primär
3D-Gerade für Sekundär
3D-Gerade für NP in X
Punkt 10 für NP in Y
Ebene 1 für NP in Z



12. Place a loop over this alignment.

13. Sicherheitsquader setzen






Calypso Advanced Course Worksheet 2 : Alignments
2 - 16 Calypso Advanced Course








14. Start the CNC cycle and interpret the results!













Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 17


Worksheet 2.5: RPS with Loops

This exercise will demonstrate the use of the RPS Alignment function.
RPS is short for Reference Point System.
RPS alignment is based on the 3-2-1 rule. The point, space point and intersection features can
be used with RPS alignment.
RPS alignments are primarily used for measuring body panels.

1. Open a new measurement plan.


2. Probe six individual points on the
practice cube.
- Two points on the top plane.
- One point in the slot. This will make a total
of three points in the Z-axis.
- Two points on the front plane.
- One point on the right side plane.


















3. Call up Base Alignment and
select RPS Method.
Calypso Advanced Course Worksheet 2 : Alignments
2 - 18 Calypso Advanced Course

4. Select the features for the base
alignment: all six points

5. Insert the point data for each
point and select in which axis
they are to be constrained.

See table with point data.
6. Select OK.
7. Measure a circle and create the
Diameter characteristic.
8. Define clearance planes.
9. Run the program. The six
points will be taken at the value
location that was entered
manually from the table.
10. Open the Base Alignment.

11. Click on Loop and enter the
number of cycles
Select OK.













Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 19
 Worksheet 2.7:3D Best Fit on the Practice Cube

This procedure can be used to align work pieces for which no unequivocal restraints are
defined. The 3D best fit is a method of achieving the best possible fit between any number
of points or geometrical features and their specified geometry.

In our example we want to construct the eight corners of the practice cube as intersection
points and, using the procedure described above, fit them until the total of all the errors
squared is a minimum between nominal and actual points (best fit acc. to Gauß).

1. Open new measurement plan.
2. Go to the Features page and probe the six
planes of the cube with the star probe.













3. Open the Tool Box and copy the
“Intersection” construction four
times to your measurement plan.



4. Intersect the planes
“front” with “right”
“right” with “rear”
“rear” with “left”
“left” with “front”.
These settings may not correspond to the illustration

on the next page.


Calypso Advanced Course Worksheet 2 : Alignments
2 - 20 Calypso Advanced Course

5. Four intersection lines are
created:










6. Now intersect the intersection
lines with “Plane top” and “Plane
bottom”. Four penetration points
are created. Name the
penetration points with
Intersection1 to 8. You can see
the location of the points in the
illustration on the right.






7. Eight intersection points are
created:









8. Call up the Base Alignment and
select 3D Best Fit Method.









Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 21

9. Select the features for the alignment: all eight intersection points.

10. Specify the nominal position for the intersection points.
Compare with below:


11. Define safety cube.
12. Define loops for base alignment
with break condition.


13. Note: The break condition must
be entered using the formula.
Activate input field and open the
formula window using the right
mouse button.
Close window with OK.

14. Start the measurement plan in
the CNC mode.
Calypso Advanced Course Worksheet 2 : Alignments
2 - 22 Calypso Advanced Course

Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 23
 Worksheet 2.6: 3D Best Fit on Tubular Bodies

Best fit with several spatially defined points

Part of exercise without measuring machine

⇒ A pipe with several bends is to be measured.
⇒ The individual bend points as well as the start and end of the pipe are listed as XYZ
coordinates in a table.
⇒ The tolerances for each point are 0.1 mm.
⇒ The sections are measured as cylinder.
⇒ The alignment is to be calculated as best fit over all points.
⇒ Several runs will be required for approximation.




In this exercise, a practice piece will be used with a prepared measurement plan. This
measurement plan “Pipe 100” already includes the measured features.
The measurement plan can be put together without the measuring machine.





Calypso Advanced Course Worksheet 2 : Alignments
2 - 24 Calypso Advanced Course
1. Precondition:


The “rohr100” measurement plan:



Table of bend points:

 Point X Y Z

 1 0 0 0
 2 37.3 -35.4 -11.5
 3 144.5 5.4 -63.1
 4 245.7 7.7 -106.7
 5 372.4 24.7 167.8
 6 397.9 -23.7 184.3


Point 1: Intersection of Plane 1 - Cylinder 1
Point 2: Intersection of Cylinder 1 - Cylinder 5
Point 3: Intersection of Cylinder 5 - Cylinder 4
Point 4: Intersection of Cylinder 4 - Cylinder 3
Point 5: Intersection of Cylinder 3 - Cylinder 2
Point 6: Intersection of Cylinder 2 - Plane 2


These intersections must be created in the following.

Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 25
2. Creating constructions (intersections)

Create an intersection 6 times

Tool Box
 Constructions
 Intersection

Here is an example:


You can see that previously there were only machine coordinates. The coordinate values
in the construction are later converted automatically to the base alignment during the best
fit.







Calypso Advanced Course Worksheet 2 : Alignments
2 - 26 Calypso Advanced Course
3. 3D Best Fit

The 3D best fit creates an alignment. This can be the base alignment or an alignment,
which is needed later.

A base alignment should be created here.

1. Call up Base Alignment:


2. A new base alignment with the method:
3D Best Fit







Here you will also find the loops needed for
later.
















3. Select the features:






The relevant features are
transferred to the mask and have
to be given the nominals of the
individual intersections manually.

Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 27

The entered data:











4. Insert loops:























After the best fit, the alignment is in the position required:


















In the next step, characteristics are defined from the intersections.
Calypso Advanced Course Worksheet 2 : Alignments
2 - 28 Calypso Advanced Course

5. Open Intersection1,
mark X, Y, Z as
characteristic
Specify tolerances.





6. Repeat for intersections
2 to 6.













7. For the sake of clarity, combine the
characteristics of each intersection in a group
and give the group a new name.















8. CNC start of all groups as simulation

9. Adapt the program on the measuring machine.



Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 29
Worksheet 2.8: Changing the coordinate system using the
Editor

The Editor changes the characteristics of objects; the assignment of a coordinate system is
only one of the characteristics.









Job:
Part 1: Assign a new coordinate system to the circles 1-4 (Z, Y values) without opening the
elements.

Part 2: Carry out the same procedure for defining the evaluation. Set the “Gauss 150” filter for
all the circles.


Calypso Advanced Course Worksheet 2 : Alignments
2 - 30 Calypso Advanced Course
Part 1:


Create the program incl. the 2nd
coordinate system.








Assign the new coordinate system
to the first circle (circle 4 here).






















Select the Editor.






Simply select “Coordinate
system”.





Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 31



Now select the 3 other circles (5-7),
which are also to be transferred to the
coordinate system.



Close with OK.











The assignment is now concluded. Check the coordinate system in each of the circles.





Part 2:

Carry out the same procedure for defining the
evaluation. Set the “Gauss 150” filter for circle 4
and apply the same evaluation method.





















Calypso Advanced Course Worksheet 2 : Alignments
2 - 32 Calypso Advanced Course



Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 33
 Worksheet 2.9: Base System

Rotation on a straight line through the origin










Practical exercise:

The functions presented here:
”Rotation on a straight line through the origin” and
”Rotation at equal deviation”
are both derivatives of the common “Rotation on a path”.

Practical application should be checked on a case-by-case basis.

The function is investigated in more depth on the following pages.




Calypso Advanced Course Worksheet 2 : Alignments
2 - 34 Calypso Advanced Course
 Rotation on a straight linethrough
the origin







Set the coordinate system on Level 1, zero point
Z, X in Circle 1 and the direction of the X-axis
through Circle 2.




Up until now, this would have been a normal alignment, in which an axis direction (X) is given
by Circle 2.
Now, not the axis direction, but a straight line is rotated on Circle 2.
How is this straight line produced?
In a coordinate system, a point is defined by two values, e.g. X=50, Z=28.
A straight line is drawn from the origin to this point.

On the work piece, this straight line is now rotated to the actual value of the bore.








Calypso Advanced Course Worksheet 2 : Alignments
Calypso Advanced Course 2 - 35
Further procedure:

Click on “Special” and enter the values in the relevant fields:


The function rotates the coordinate system around a given axis, such that the straight line
placed through the origin intersects the tertiary reference plane.
This gives rise to the same conditions for the X-values as for the Y-values of the point on the
straight line and of the tertiary reference.


Calypso Advanced Course Worksheet 2 : Alignments
2 - 36 Calypso Advanced Course



Worksheet 3: Filters and Outliers
Calypso Advanced Course 3 - 1
 Worksheet 3: Form Elements

3.1 Basics about filters and outliers

3.1.1 Filters

Data is mainly filtered in order to segregate the different types of deviation (form
deviation, waviness and roughness), but is also used for compensating any measurement
deviations.

Goal: Filtering is used in roughness metrology in separating the long-waved
components gained in the roughness measurement such as waviness and
form.
 In coordinate metrology, the short-wave components defined in the probed
profile, such as the roughness components which have been recorded
despite a large probe ball, have to be eliminated.

In Calypso you can choose between two different types of filter:

• Gauß (ISO 11562)

Characteristics:
Only 50% of the values are accepted with this cutoff wave length.
 The amplitude of the short wave length is therefore damped by half.

• 2 RC (ISO 4291)
(R = Resistance; C = Capacitor)

Characteristics:
75% of the values are accepted with this cutoff wave length.
The amplitude of the short wave length is therefore damped by a quarter.
The 2RC filter is a mathematical imitation of a real RC filter.

Each of these two filter types can be subdivided into two different types of filter:

• High-pass filter

Characteristics:
High frequencies pass the filter, low ones are filtered.
=> Waviness is filtered out.

• Low-pass filter

Characteristics:
Low frequencies pass the filter, high ones are filtered.
=> Surface roughness is filtered out.


Worksheet 3: Filters and Outliers
3 - 2 Calypso Advanced Course


*Cutoff wavelength: The cutoff wave length λc is the wavelength of
 (straightness profile) vibrations in the input signal whose amplitude is let
through the filter at a specific transmission ratio
(previously 75%, today 50%).

No. of waves ng: Describes the number of waves per rotation.
(roundness profile)

Note: Filters are only recommended for high numbers of points
i.e. for scanned features.
 There should be at least 7 measured points per wave.


Recommended values for the cutoff wave length:

Mean roughness index Ra in µm Mean peak to valley height Rz in µm λc in µm
 to 0.025 to 0.1 0.25
over 0.25 to 0.4 over 0,1 to 1.6 0.8
over 0.4 to 3.2 over 1.6 to 12.5 2.5
over 3.2 to 12.5 over 12.5 to 50 8.0
over 12.5 to 100 over 50 to 400 25
over 100 over 400 80


Recommended values for cutoff vibration number:

Diameter in mm Roundness tolerance in µm
 to 2.5 2.5 to 5 5 to 10 over 10
 to 10 150 50 50 50
over 10 to 50 500 150 150 50
over 50 to 120 1500 500 500 150
over 120 to 250 1500 1500 500 500
over 250 1500 1500 1500 1500








3.1.2 Outliers

A measured point is tagged as an outlier if it is further than a defined threshold* from the
computed Gauß element.

*Threshold = Factor * Standard delta

Outlier inside workpiece: impression in the material
Outlier outside workpiece: rise in the material



Calypso Advanced Course Worksheet 3: Form Elements / Scanning
Calypso Advanced Course 3 - 3







Reset “Set Default Measurement
Strategy”
4 pts, 0 -360°


Worksheet 3: Form Elements

3.2 Form element with the help of an example

In this section you will learn:
• how to define scanning paths
• how the optimum parameters in Calypso can be set automatically
• the effect of the scanning speed on the result
• the effect of filtering
• all about outliers
• how to use tangential and minimum features
• how to use the default measurement strategy
• how to read the DIN characteristics evaluation




1. Measure a circle in the cylinder on the front of
the practice cube.

2. Place the “Circle Auto Path” measurement
strategy in this feature.
You can also use holes of another workpiece
for this exercise.







3. Let this feature run once.
Do not yet change the settings in the Circle
Auto Path!

4. Open the default printout so you can keep
checking the results.






Calypso Advanced Course Worksheet 3: Form Elements / Scanning
3 - 4 Calypso Advanced Course

Click on Step Width and Expected
Tolerance.





Click on Calculate
Here you are asked what the feature is
to be used for.
As the circle has not yet been assigned
to an evaluation such as e.g. diameter,
Calypso needs this information for
calculating the setting values.




Click on Calculate and then on
Location, Size and Form, see how the
speed and step width change.











Click on Basic Settings. The
System Set Up page with which
you are already familiar is
displayed.

By making changes in these
pages, you can change the basic
parameters.

Make sure that the changes do
not impair the behavior of the
measuring machine in the
scanning mode.



Calypso Advanced Course Worksheet 3: Form Elements / Scanning
Calypso Advanced Course 3 - 5
 In the next section, three characteristics are linked
with this circle. Use the circle
For a location: Z value
For a size: Diameter
For a form: Roundness.

A graphics evaluation is possible in the
Roundness.






In the Features list select the circle and
call “Check use ..” with the right
(middle) mouse button.
You will see where this is used. This
step is also available in the
measurement strategy, the tolerance
required is also displayed.












Calypso Advanced Course Worksheet 3: Form Elements / Scanning
3 - 6 Calypso Advanced Course


In the steps which follow, you will change the scanning settings step by step and can create a
printout for comparison.




The steps:

1. Set the scanning speed to a
maximum value: for a diameter of 30
mm e.g. 80 mm/sec.


2. Set the scanning speed to a
minimum value: e.g. 2 mm/sec
Are there any changes?

Plot the result so you can see this more
clearly.


Discuss the differences in the results
and application possibilities.


Calypso Advanced Course Worksheet 3: Form Elements / Scanning
Calypso Advanced Course 3 - 7
 In the next step the result will be filtered.

Make sure the circle has
been scanned with a slow
measurement strategy
(10 mm/sec).

Enter the Roundness and
click on the circle. In the
selection menu which
appears, you can change
the feature for this
“Roundness” evaluation
as your want.
The original feature
remains unchanged.

Look at the plot.
Change the filter several times and observe
the results:

1. Click on “Filter” and set a filter for 150
W/U. The roundness is 0.0127 as
before.
The default printout explains this
calculation which at first seems
incomprehensible:2. Click on "Filter" and set a filter for 50 W/U.






The filter is basically used to separate the actual
form from short-wave roughness.
If sensible filtering is used, the measurement
results are not falsified.

The size of the filter depends on the customer’s
specifications.

Now discuss the results and application possibilities.
Calypso Advanced Course Worksheet 3: Form Elements / Scanning
3 - 8 Calypso Advanced Course

In the next step outliers are eliminated.

Note: First remove all filter settings

Open the Roundness and click on the circle.
In the selection menu which is displayed you
can change the feature for this “Roundness”
evaluation as you want.

The original feature remains unchanged.


1. First set a factor of 3.
Here all points are removed which lie
more than three times the sigma
dispersion value away from the
computed circle.













2. Click on “Outlier” and set a factor of 2.
This means that all measured points in
the circle which are more than 2 times
the value of the dispersion away from
the computed circle are not included in
the evaluation.

3. You can also delete the neighboring
points around the outlier up to the
computed circle, this then gives you to a
large extent a corrected circle.



For the bore function, outliers “into the
material” would usually not be significant.
But they can considerably falsify the
result.
Set the outlier elimination
correspondingly.

Change the outlier several times and observe the results.
Discuss the results and application possibilities.
Calypso Advanced Course Worksheet 3: Form Elements / Scanning
Calypso Advanced Course 3 - 9
4. Now add a filter with a filter value of 150 W/U and output the results as a plot.





Calypso Advanced Course Worksheet 3: Form Elements / Scanning
3 - 10 Calypso Advanced Course




Another possibility is to use tangential
elements such as Minimum Circumscribed
and Maximum Inscribed Elements.

Note: Remove all filters and outliers.


Selection can also made in the menu for the respective
feature.


The Maximum Inscribed Circle is the largest inscribed
circle and can be combined well with the “Outlier” and
“Filter” functions.

Carry out various evaluations.




Observe in particular how the diameter and
the center point change for the minimum
circumscribed, maximum inscribed and
minimum circle.














In the menu you can select the minimum circle or Tschebycheff evaluation. Compared to the
Gauss evaluation, note the effect of the outliers here.


Calypso Advanced Course Worksheet 3: Form Elements / Scanning
Calypso Advanced Course 3 - 11

Using the Features Settings Editor you can define parameters for the filter while you are
creating the feature.
This is particularly helpful when programming on the CAD model.

Set new values for the filter.


























Calypso Advanced Course Worksheet 3: Form Elements / Scanning
3 - 12 Calypso Advanced Course

Exercise:
In the Calypso Basic Course, a True Position of a circle was calculated to 2 surfaces.

Carry out this example again and observe the automatic evaluation of the individual features.




DIN characteristics always use the prescribed
evaluation form such as the minimum circle when
calculating the diameter.
Open the default printout and evaluate a few DIN
characteristics.














Calypso Advanced Course Worksheet 3: Form Elements / Scanning
Calypso Advanced Course 3 - 13
Worksheet 3: Form Measurement

3.3 Form Measurement: DIN Flatness with Reference Length


DIN ISO 1101 Flatness with Reference Length can be measured for planes. In contrast to
DIN ISO 1101 Flatness, here the flatness of sub-rectangles from the plane is measured. You
can define the size of these rectangles and their degree of overlap yourself.
You can also set a threshold, which the angle between any individual sub-rectangle and the
entire plane must not exceed.
The measurement values obtained from the flatness measurement can be evaluated in
different ways.

- Flatness in relation to single a sub-plane
For each rectangle, the difference between the maximum and minimum separation of the
actual points on the rectangle to the fitted sub-plane of the rectangle is specified.

- - Flatness in relation to the entire plane
For each rectangle, the difference between the maximum and minimum separation of the
actual points on the rectangle to the fitted total plane is specified.
Thus, for every rectangle, you obtain a measurement value for the flatness. For the output, you
can decide which of these different results should be displayed:

- all flatnesses
- all flatnesses, which exceed a predetermined tolerance
- the maximum flatness.





Exercise procedure

In this exercise, an area of the exercise cube is measured as a plane and the various DIN
Flatness functions are evaluated:

1. DIN Flatness and preset plot
2. DIN Flatness as a progression
3. DIN Flatness as a CAD plot

4. DIN Flatness in relation to
⇒ a sub-plane
⇒ the entire plane
⇒ output variations


Calypso Advanced Course Worksheet 3: Form Elements / Scanning
3 - 14 Calypso Advanced Course


Firstly measure the front face of the exercise cube
with a polyline.


Enter a flatness and a flatness with reference into
the measurement plan.












Evaluate as before.


1. DIN Flatness and preset plot

The plot display can be adapted with “Edit“.
























Calypso Advanced Course Worksheet 3: Form Elements / Scanning
Calypso Advanced Course 3 - 15


2. DIN Flatness as a progression
 Flatness of line segments

“Progression” is not often displayed and is not
commonly used for evaluating a polyline.





















3. DIN Flatness as a CAD plot

Proceed as follows in order obtain the adjacent
view as a plot:

− load CAD model
− open plane
− click right mouse in the ACIS window,
select display actual points
− close plane
− open DIN flatness
− CAD - View – Save View
− enter name, Flatness1 in this case
− click on "Graphic"
− in the upper menu select "CAD view "
− Select measurement characteristic
"Flatness1",
− Click on "Plot"




Calypso Advanced Course Worksheet 3: Form Elements / Scanning
3 - 16 Calypso Advanced Course


4. DIN Flatness with reference

Principles:

The plane (Fig. 1) is defined by the spatial point
E0, the u-axis (u) and the v-axis (v). In the u and
v directions it has lengths A and B. E0 can lie in
any corner of the rectangle.
A rectangle with edge lengths a and b in the u
and v directions is specified as a tolerance zone.




Starting from E0, this rectangle is shifted “line-
by-line” from the “bottom upwards” parallel to u and v, whereby each rectangle shifted gives
rise to its own tolerance zone. Fig, 2 shows the sequence of, in this case, 16 tolerance zones,
which do not overlap (overlap 0%).











Fig. 3 shows the same succession of 56 tolerance
zones in this case, whereby they overlap by 50%.
The indexing of the tolerance zones is omitted for
clarity.










All calculations are with reference to the plane comprising all valid measurement points (i.e.
without overlap or outliers,…) and are based on the selected evaluation method. The
measurement points can be filtered.
There are principally two types of evaluation:
• Case 1: Flatness relative to the sub-plane of each rectangle (corresponds to ANSI or ISO)
• Case 2: Flatness of each rectangle relative to the entire plane (special application).
The flatness of a rectangle is the difference between the greatest and smallest deviation (max
– min) in the rectangle. The edge of a rectangle belongs to the rectangle.Calypso Advanced Course Worksheet 3: Form Elements / Scanning
Calypso Advanced Course 3 - 17


The Input Page:


Input parameters:





Evaluation type:
Sub-plane

The sub-plane is calculated for
every rectangle according to the
selected evaluation method.

If the sub-plane of a rectangle
is incalculable (too few
measurement points,
measurement points on a line,
angle between the sub-plane
and the entire plane greater than a limit angle), the
flatness of this rectangle must be calculated in the
same way as flatness in relation to the entire plane,
and a corresponding note entered in the protocol for
this sub-plane.

Entire plane
The greatest and smallest error in each rectangle is calculated in relation to the entire plane,
from which the flatness of each rectangle is found. If there is no measurement point or only
one in a rectangle, the flatness of this rectangle is zero and a corresponding note entered in
the protocol for this sub-plane.

Overlapping rectangles
The rectangles can either be adjoining or overlapping. The relevant specification lies between
0% for adjoining and 90% for maximum overlapping. This means that each rectangle is
shifted by (100% - x%) x edge length, starting from E0, “line-by-line” from the “bottom
upwards” parallel to u and v.


Calypso Advanced Course Worksheet 3: Form Elements / Scanning
3 - 18 Calypso Advanced Course

Only maximum flatness:
Only the maximum flatness inclusive of its location.






All flatnesses outside tolerance:
The maximum flatness and all flatness inclusive of their locations.



Visualization of
the individual
flatnesses is
possible by
clicking in the
list.












All flatnesses
The maximum flatness and all
flatnesses inclusive of their
locations.







The working and compact protocol
documents the values in detail.








Calypso Advanced Course Worksheet 4 : CAD
Calypso Advanced Course 4 - 1
Worksheet 4: CAD



Calypso always works together with the CAD window.
You have already used some of the functions in your work up till now.
Exercises have already been programmed offline.
We will now take a closer look at other functions. This can be done on customer work pieces.

1. Offline programming
CAD file types
Healing
Extracting
CAD modification

2. CAD measuring strategy: Default data
During the preparation of a measurement plan, part features are created from the model.
A measuring strategy can be assigned automatically to these features.
The settings for the measuring strategy are described here.





Calypso Advanced Course Worksheet 4 : CAD
4 - 2 Calypso Advanced Course


Calypso Advanced Course Worksheet 4 : CAD
Calypso Advanced Course 4 - 3
 Worksheet 4.1: CAD import and preparing IGES, VDA

The purpose of this exercise is to provide an explanation of the Calypso file types as
well as healing functions.

CAD Model File Types
Currently Calypso supports the following file types:

ACIS files .sat
CATIA files .exp
STEP files .stp
IGES files .igs
VDAFS files .vda
Unigraphics
ProE .prt>

It is important when importing models, that the file
extension is correct. Calypso recognizes the file type by
its extension.

Importing the model

Using the Windows NT explorer, copy the CAD file
XYZZZ.igs to the directory: …opt\om\cad…
Open a new measurement plan.
Define the probe and qualify the styli. For this exercise we will be using the star probe.



From the CAD pull down menu, select CAD File Load…
This opens the select window:
From the Files of Type select IGES.
Select the file you want XYZZZZ then Open.

The model will be loaded to the Calypso CAD
window.


Calypso Advanced Course Worksheet 4 : CAD
4 - 4 Calypso Advanced Course
 Possible errors while importing:


If the CAD model does not appear on
the screen, from the task bar select
Scheme ACIS Interface Driver
extension.
If an error occurred while loading, this
window provides a list of entities that
did not load, or causes of the load
error.
A log file will also be created with the
model names.
Here this is YXZZZZ.log. This file
contains further information and
possibly an error list.













Preparing the model



Once the model has been loaded, click on the
Render button.
If the model does not render, some (or all) of the entities were not converted. For these cases,
Calypso provides a utility called “Healing”. Healing is the process of converting CAD surface
data to Calypso’s solid ACIS format.

There are three steps to this process:

Simplification
Stitching
Build Geometry




Calypso Advanced Course Worksheet 4 : CAD
Calypso Advanced Course 4 - 5

Example of an incorrectly loaded model:



Holes after conversion.









2. Example of an incorrect model



















Open the CAD pull down menu CAD File.

The three options are found here:

Minimal Model Preparation:
This selection carries out the Simplification.

Autohealing
This option carries out all three steps.
Both processes are automatic and do not need additional input from the user.

Step-By-Step Healing
This selection allows interaction between the user and the healing process.
In this exercise we will choose Step By Step Healing.
Calypso Advanced Course Worksheet 4 : CAD
4 - 6 Calypso Advanced Course


Simplification

The healing process starts by attaching an
accumulation of attributes that will be used
throughout the various phases of the healing
process.

The first step “cleans up” the model.
Inaccuracies, zero-length edges and
duplicate vertices are removed.
Incoming models often contain geometry,
which are not mathematically described.
Simplification converts these into their
analytical forms (arc, cylinder, cone, plane)
wherever possible.
This calculation requires a tolerance in order
to have a limiting value for the simplification.
Attributes are attached to the geometry so
that they can be easily identified during the
actual simplification.

Select
Transformation CAD Model
 Simplification Start.


Stitching

The stitching function provides the means to stitch a set of faces together to form a single
sheet or solid body.
Stitching essentially involves the pairing of vertices and edges in the data.
In the case of a surface model, which lacks topology, such as from IGES, this phase adds
topology to the model. The analysis phase determines a tolerance to be used when deciding
whether or not two surfaces should share an edge or vertex.

Select
Transformation CAD Model
Stitching Start.


Build Geometry

Geometry building heals inaccuracies in the model. In this phase, a series of geometric
operations are performed to improve the precision of face, edge, and vertex data. These
operations adjust and correct, where possible, the geometry ensuring that: every vertex lies on
the underlying curve, every edge (formed by an intersection) lies on two adjoining faces.
Parametric curves lie on the corresponding faces.



Do NOT select this option. Close the Transformation CAD Model window with


The information on the healing process is from SPATIAL TECHNOLOGY INC.
To learn more, visit their web site at http://www.spatial.com.


Calypso Advanced Course Worksheet 4 : CAD
Calypso Advanced Course 4 - 7

Converter settings:


The converter settings can be matched to the
quality of the model to improve the import
functions:









If the conversion is inadequate, you
can also activate the function
“Conversion of incorrectly defined
geometry”.











Calypso Advanced Course Worksheet 4 : CAD
4 - 8 Calypso AdvancedCourse




Worksheet 4.2: Default Measurement Strategy
Calypso Advanced Course 4 - 9


Worksheet 4.2: Default Measurement Strategy


Job: The procedure defines the measurement strategy for accepting or
creating part features when extracting from the CAD model.
Load the exercise cube as a CAD model
Then process the default settings:
CAD
 Extract
 Set Default Measurement Strategy.

Default plane settings:
Click on the Plane button.






Click on Settings and open the grid.











In the following window you can change the grid
length and grid width with
 Quantity or
 Separation.

The edge separation and the meander or line route
methods are important.


Worksheet 4.2: Default Measurement Strategy
4 - 10 Calypso Advanced Course


Example:

Set Step Width to: 2
If a plane is extracted, there will be a probe point every 2 mm.
The “Single Points” box has no affect on switching measuring devices
Set Grid Length to number 5,
set Grid Width to number 3.
Set Edge Separation to: 0.5
A separation of 0.5 mm is maintained to all edges and gaps.
Set Range to:
Meander
the measurement
sequence proceeds as
a meander.






These default settings take effect when a surface is generated on the CAD model:

Click on “Generate Solid Geometry“ and then on the desired surface.
Open the surface, now the grid is visible.


Try another example using the “Distance”.





Worksheet 4.2: Default Measurement Strategy
Calypso Advanced Course 4 - 11

Circle default settings:
Click on Circle and open the Circle
section.
Speed and Step Width are settings
for measuring probes
Set Number of Points to 9:
This will generate 9 points on each
circle section.
Set the Probe Radius Factor to 1.5
Minimum distance to the “end” of a
cylinder.
Set the Start Angle to 0
Starting point for probing.
Set the Angular Range to 360
The arc of a circle. Positive values
indicate counter-clockwise.


Cylinder default settings
Click on the cylinder button and
open a Circle Auto Path.
Set Number of Points to: 5
This will generate 5 points on each
section of the cylinder.
Circle Path
Several options are possible here:
Probe Radius Factor
Minimum distance to the edge of a cylinder.

Percent
Within the restriction of the probe radius
factor, this places the generated path at a
percentage of the cylinder’s overall length.

Measuring Height
Direct input of path location from origin of
feature.

Number
Number of equally spaced circle paths.

Worksheet 4.2: Default Measurement Strategy
4 - 12 Calypso Advanced Course



Straight line default settings:
Enter the settings in the same way














Calypso Advanced Course Worksheet 5: Special Part Features
Calypso Advanced Course 5 - 1
 Worksheet 5.1: Recall Feature Points from Polyline


Recall enables you to carry out more calculations from data already gained from
previous features.






Job: Measure a plane with one or several polylines and recall the measured points to the
“Line” feature in order to carry out a Straightness evaluation.







Calypso Advanced Course Worksheet 5: Special Part Features
5 - 2 Calypso Advanced Course

This exercise is done on the CAD model.



Create a base system and safety cube as usual.



Take a plane from the toolbox and set a polyline with
3 lines on the right hand side of the cube.









Enter the “3D Line” twice
in the measurement plan.









Open a line and define the nominal input
with “Recall Feature Points”.










Select the plane; note the buttons, which
appear in the top bar:








First click on the button on the left, the actual points are displayed in the feature as crosses.
You can now select the ones you want using the button on the right.

Calypso Advanced Course Worksheet 5: Special Part Features
Calypso Advanced Course 5 - 3

The actual points (!!) are displayed as red
crosses.


Select the scanning path on the left with the
“lasso”.









These points are accepted and calculated as
3D line.





Create a second 3D line with another
scanning path.





Evaluate a Straightness for each of the 3D
lines.

Plot the result.

Try and interpret the plot output.






Calypso Advanced Course Worksheet 5: Special Part Features
5 - 4 Calypso Advanced Course
Worksheet 5.2: Recall Feature Points from Circles



Job: Measure three circles in a hole and recall the measured points in the “Cylinder” part
feature.






















Take a cylinder from the toolbox.








Select "Nominal Input –
Recall Feature Points".








Select the three circles.







Calypso Advanced Course Worksheet 5: Special Part Features
Calypso Advanced Course 5 - 5




With the remaining buttons in the
header, the actual data from the
circles can be displayed and
selected.



Using the lasso, you can place a box
around the circles and select the
actual points.


The cylinder you want is then
calculated and is available as
calculated feature.
























Calypso Advanced Course Worksheet 5: Special Part Features
5 - 6 Calypso Advanced Course
 Worksheet 5.3: Recall Feature Points from Cylinder



Job: Measure a cylinder with 2 circle auto paths and with 4 surface lines. Recall the
points of the surface lines to the “line” feature in order e.g. to carry out a
straightness evaluation of the cylinder.







Measure a cylinder with eight points;
define 2 circle auto paths and 4
surface lines.


















Define a measuring strategy suitable for the
measuring machine for the form elements.






Run the program.


You can use a 2D line or a 3D line for the straightness evaluation.
The 2D line is calculated on the surface of the work piece, the 3D
line through the probe ball center points.


Now consider how usable the various results are for your
measuring task.
Calypso Advanced Course Worksheet 5: Special Part Features
Calypso Advanced Course 5 - 7

Start with the Recall Feature
Points.








There is an important new feature
here with the Recall Feature
Points function:


You can make the individual
measuring strategies of the
cylinder visible and select them
with the right mouse button.










Path (3) is the first surface line.







You get the 2D line you wanted and you can use this in
the Straightness evaluation.

The graphical evaluation of the form plot gives you a
visual impression of the cylinder surface area.









Note:

The scanning path, which has been evaluated, was made in the direction of the nominal
cylinder (!!!).

Therefore the evaluation cannot be used here, see also plot.

Calypso Advanced Course Worksheet 5: Special Part Features
5 - 8 Calypso Advanced Course


Consider the following:
in the nominal cylinder the A1 and A2
angles are rounded off to the value
“0”.

Therefore the surface lines are
scanned in the direction of the axis
and not in the direction of the “true”
cylinder.

Here a “pre-alignment” is necessary
in order to then measure in the
aligned coordinate system.


A typical evaluation could be the parallelism of two lines lying opposite to one another.

It is then possible to see whether the cylinder has taken on a conical form for example.




Start a new exercise by measuring a
cylinder, here from 2 circles with
feature point recall.













Create a new alignment with the
spatial rotation of the first cylinder.





In this alignment you now measure the
