Configuração MSLC

Page 1 of 1
GOVERNOR PART NUMBER 9907-005 SERIAL NUMBER 15381919

FIELD SERVICE NUMBER SC0036-10 DATE 18/5/2010

CUSTOMER Siner (Usina Baldin) ENGINEER César R. Oliveira

SYNCHRONIZER – MENU 1

Sync Gain 0,01
Sync Stability 1,55 Seconds
Slip Frequency Ref 0,0 Hertz
Slip Window 0,10 Hertz
Max Phase Window 8 Degrees
Voltage Matching Enabled
Voltage Window 1,0 %
Breaker Delay 0,10 Seconds
CB Close Hold Time 1,0 Seconds
Close Attempts 5
Reclose Delay 10 Seconds
Sync Reclose Alarm Disabled
Sync Timeout 0 Seconds
Sync Timeout Alarm Disabled
Auto Re-Synchronizer Disabled

LOAD CONTROL – MENU 2

Imp/Exp Control Gain 1,210
Imp/Exp Stability 1,000 Seconds
Imp/Exp Derivative 0 Seconds
Imp/Exp Deadband 0 %
Load Input Filter 1,00 Hertz
Import/Export Droop 0 %
Rated Load 45,00 MW
Import/Export Level -0,40 MW
Import/Export 4 mA 0 MW
Import/Export 20 mA 30,50 MW
Base Load 4 mA 0 %
Base Load 20 mA 100,0 %
Unload Ramp Rate 1,00 % / Second
Load Ramp Rate 1,00 % / Second
Raise Load Rate 1,00 % / Second
Lower Load Rate 1,00 % / Second
Utility Unload Trip 0,10 MW
Gen Unload Trip 5,0 %
Util High Limit PU 30,50 MW
Util High Limit DO 28,00 MW
Util High Limit Disabled
Utility Low Limit PU -2,00 MW
Utility Low Limit DO -1,00 MW
Utility Low Limit Disabled
Util Limit Switches Disabled
Generator Load High Disabled
Generator Load Low Disabled
Gen Limit Switches Disabled
Gen Load Switch1 PU 0,0 %
Gen Load Switch1 DO 10,0 %
Gen Load Switch2 PU 100,0 %
Gen Load Switch2 DO 90,0 %

PROCESS CONTROL – MENU 3

Process Control Gain 1,000
Process Stability 1,00 Seconds
Process Derivative 0 Seconds
Process Deadband 0 mA
Process Droop 0 Percent
Process Filter 1,00 Hertz
Process Reference 12,0 mA
Raise Reference Rate 0,10 mA/Second
Lower Reference Rate 0,10 mA/Second
High Limit PU 15,0 mA
High Limit DO 15,0 mA
High Limit Alarm Disabled
Low Limit PU 10,0 mA
Low Limit DO 10,0 mA
Low Limit Alarm Disabled
Process Switches Disabled

VAR/PF CONTROL – MENU 4

VAR/PF Control Mode Const Gen PF Control
VAR/PF Gain 1,00
VAR/PF Stabiliy 2,50 Seconds
Rated kVARS 33,00 MVAR
kVAR Reference 1,00 MVAR
 Generate
PF Reference 1,00 Leading
Const Gen PF Ref 0,92 Lagging
PF Deadband 0,015
Voltage Low Limit 12420 Volts
Voltage Low Alarm Disabled
Voltage High Limit 15180 Volts
Voltage High Alarm Disabled
Voltage Switches Disabled

CONFIGURATION – MENU 5

PT Winding Ratio 120,0 : 1
CT Rating 2000 : 5
Voltage Input 120 Vac
Voltage Display V-L-to-L
System Frequency 60 Hz
Process Action Direct
Network Address 16
Network Service Pin
Revert Status Lock In Last
Net Dropout Time 5,00 Seconds
Util Breaker Open Logic Indirect
