NOBLE DENTON MARINE SERVICES
Disclaimer
The extracted sections below are based on your selections in the wizard. DNV GL do not take on any
responsibility for your selection related to your project scope and DNV GL expressly disclaims any liability if
the outcome of the selection does not encompasses the need or does not fit for purpose.
Where DNV GL Noble Denton marine services is the Marine Warranty Survey provider, it should be read in
conjunction with DNVGL-SE-0080 Noble Denton marine services – marine warranty survey, which provides a
description of the process used by DNV GL Noble Denton marine services when providing marine warranty
survey (MWS) services to evaluate whether a marine operation can be accepted for the purposes of
insurance-related MWS. It addresses both ‘project’ and MODU/MOU related MWS.
The use of our standard presupposes and does not replace the application of industry knowledge,
experience and know-how throughout the marine operation activities. It should solely be used by
competent and experienced organizations, and does not release the organizations involved from exercising
sound professional judgment.
Full version of Standard - DNVGL-ST-N001 & DNVGL-ST-N002
DNVGL-ST-N001
Full version of Standard - DNVGL-ST-N001 & DNVGL-ST-N002
DNVGL-ST-N001 Marine operations and marine warranty (Edition: 2016-06)
SECTION 0 CHANGES – CURRENT
SECTION 1 Introduction
1.1 General
1.2 Objective
1.3 Scope
1.4 References
1.5 Definitions
1.6 Acronyms, abbreviations and symbols
SECTION 2 Planning and execution
2.1 Introduction
2.2 General project requirements
2.3 Technical documentation
2.4 Risk management
2.5 Planning of marine operations
2.6 Operation and design criteria
2.7 Weather forecast
2.8 Organization of marine operations
2.9 Monitoring
2.10 Inspections and testing
2.11 Vessels
SECTION 3 Environmental conditions and criteria
3.1 Introduction
3.2 Design environmental condition
3.3 Design environmental criteria for weather restricted operations
Page 1 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
3.4 Design criteria for weather unrestricted operations
3.5 Weather/metocean forecast requirements
3.6 Benign weather areas
SECTION 4 Ballast and other systems
4.1 Introduction
4.2 System and equipment design
4.3 Ballasting systems
4.4 Guiding and positioning systems
4.5 ROV systems
SECTION 5 Loading and structural strength
5.1 Introduction
5.2 Design principles
5.3 Specific design considerations
5.4 Testing
5.5 Load categorisation
5.6 Loads and load effects (responses)
5.7 Failure modes
5.8 Analytical models
5.9 Strength assessment
5.10 Materials and fabrication
SECTION 6 Gravity based structure (GBS)
6.1 Introduction
6.2 Floating GBS stability and freeboard
6.3 Structural strength
6.4 Instrumentation
6.5 GBS installation
SECTION 7 Cables, pipelines, risers and umbilicals
7.1 Introduction
7.2 Codes and standards
SECTION 8 Offshore wind farm (OWF) installation operations
8.1 Introduction
8.2 Planning
8.3 OWF installation vessels
8.4 Planning and execution
8.5 Load-outs of OWF components
8.6 Transport of OWF components
8.7 Installation of OWF components
8.8 Lifting operations and lifting tools
8.9 Information required for MWS approval
SECTION 9 Road transport
9.1 Introduction
9.2 Requirements
9.3 Information required
SECTION 10 Load-out
10.1 Introduction
10.2 General
10.3 Loads
10.4 Design calculations
10.5 Systems and equipment
10.6 Vessels
10.7 Operational aspects
10.8 Special cases
Page 2 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
10.9 Information required
SECTION 11 Sea voyages
11.1 Introduction
11.2 Towage or transport design/approval flow chart
11.3 Motion response
11.4 Default motion criteria – General
11.5 Default motion criteria – IMO
11.6 Default motion criteria – Ships
11.7 Default motion criteria – Specific cases
11.8 Directionality and heading control
11.9 Design and strength
11.10 Floating stability
11.11 Transport vessel or barge selection
11.12 Tug selection
11.13 Towing equipment
11.14 Voyage planning
11.15 Bilge & ballast pumping systems
11.16 Anchors (and alternatives) and mooring arrangements
11.17 Manned voyages
11.18 Specific for multiple towages
11.19 Specific for towing in ice
11.20 Specific for towage in the Caspian Sea
11.21 Specific for FSUs (FPSOs, FSOs, FLNG facilities, FRSUs etc.)
11.22 Specific for jacket voyages
11.23 Specific for ship towage
11.24 Specific for voyage to scrapping
11.25 Specific for towing of pipes and submerged objects
11.26 Specific for deep draught towages
11.27 Specific for jack-up voyages
11.28 Approaching a jack-up location
11.29 Rig move procedures (for all MOUs)
11.30 Specific for semi-submersible voyages
11.31 Information required
SECTION 12 Tow out of dry-dock or building basin
12.1 Introduction
12.2 Dry dock/construction basin
12.3 Design and strength
12.4 Mooring and handling lines for tow-out
12.5 Intact & damage stability
12.6 Under-keel clearance for leaving basin
12.7 Side clearances
12.8 Under-keel clearance outside basin
12.9 Towage and marine considerations
12.10 Information required
SECTION 13 Jacket installation operations
13.1 Introduction
13.2 Environmental conditions
13.3 Strength
13.4 Jacket buoyancy, stability and seabed clearance
13.5 Jacket lift
13.6 Jacket launch
13.7 Floating controlled upend and set-down ballasting
Page 3 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
13.8 Jacket position and set-down
13.9 Buoyancy tank
13.10 On-bottom stability and piling
13.11 Information required
SECTION 14 Construction afloat
14.1 Introduction
14.2 Loads and structures
14.3 Stability and damage stability
14.4 Mooring and fendering
14.5 Construction spread
14.6 Operational requirements
14.7 Information required
SECTION 15 Lift-off, mating and float-over operations
15.1 Introduction
15.2 General
15.3 Loads
15.4 Systems and equipment
15.5 Vessels
15.6 Operational aspects
15.7 Specific for lift-off operations
15.8 Specific for mating operations
15.9 Specific for float-over operations
15.10 Specific for docking operations
15.11 Information required
SECTION 16 Lifting operations
16.1 Introduction
16.2 Load factors
16.3 Derivation of hook, lift point and rigging loads
16.4 Sling and grommet design
16.5 Shackle design
16.6 Other lifting equipment design
16.7 Crane and installation vessel
16.8 Structural analysis
16.9 Lift point design
16.10 Fabrication yard lifts
16.11 Fabrication of rigging and lifting equipment
16.12 Certification and inspection of rigging and lifting equipment
16.13 Clearances
16.14 Bumpers and guides
16.15 Heave compensation
16.16 Operations and practical considerations
16.17 Subsea lifting and installation
16.18 Information required
SECTION 17 Mooring and dynamic positioning systems
17.1 Introduction
17.2 Codes and standards
17.3 Design environmental conditions
17.4 Environmental loads and motions
17.5 Mooring analysis
17.6 Design and strength
17.7 Clearances
17.8 Mooring equipment
Page 4 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
17.9 Procedural considerations
17.10 Special considerations for inshore & quayside moorings
17.11 Weather restricted mooring considerations
17.12 Information required
17.13 Dynamic positioning systems
SECTION 18 Decommissioning and removal of offshore installations
18.1 Introduction
18.2 General principles
SECTION 19 References
APPENDIX A Introduction
APPENDIX B Planning and execution
B.1 Documentation and certification for marine vessels
B.2 Documentation requiredfor lifting, towing and mooring gear - Informative
B.3 Iceberg management operations
B.4 Ensemble forecasting - informative
APPENDIX C Environmental conditions and criteria
C.1 General
C.2 Wind conditions
C.3 Wave conditions
APPENDIX D Ballasting and other systems
APPENDIX E Structural strength
E.1 Fillet weld checking
E.2 Bolted connections
APPENDIX F Gravity based structure (GBS)
APPENDIX G Cables, pipelines, risers and umbilicals
APPENDIX H Offshore wind farm installations - Informative
H.1 Introduction
H.2 General
H.3 Cable challenges/cables
H.4 Specific challenges/considerations for array cables
H.5 Exclusions from marine warranty scope
APPENDIX I Land transport
APPENDIX J Load-out
APPENDIX K Towage and sea transport
K.1 Example of main tow bridle with recovery system
K.2 Example of emergency towing gear
K.3 Example of Smit-type clench plate
K.4 Emergency anchor mounting on a billboard
K.5 Alternatives to the provision & use of an emergency anchor
K.6 Alternative arrangements for towing connections for ship towages
K.7 Example of cribbing / seafastening force calculations - Informative
K.8 Good practice recommendations for the tie-down of lifting slings - Informative
K.9 Good practice recommendations for towing - Informative
K.10 Ice Classification - Informative
K.11 Options for MOU voyages in ice - Informative
APPENDIX L Tow out of dry-dock or construction basin
APPENDIX M Jacket Installation
APPENDIX N Construction afloat
APPENDIX O Float-over, mating and float-off operations
APPENDIX P Lifting operations - Informative
P.1 2-Hook lift - load factors and derivation of lift point loads
P.2 Padeye calculations
Page 5 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
DNVGL-ST-N001 Marine operations and
marine warranty (Edition: 2016-06)
SECTION 0 CHANGES – CURRENT
This document (DNVGL-ST-N001 - Edition 2016-06) replaces the legacy DNV-OS-H-series and all legacy GL
Noble Denton Guidelines except 0009/ND, 0016/ND, which are addressed in the DNVGL-ST-N002 standard and
0021/ND which will be addressed in a service specification.
The following is a summary provided for guidance on where the contents of the legacy documents can be found
in this standard.
Sec.1 Introduction
Sec.2 Planning and execution
This section replaces the following parts of the VMO Standard and the ND Guidelines:
• DNV-OS-H101
• 0001/ND.
Sec.3 Environmental conditions and criteria
This section replaces the applicable sections of the legacy GL Noble Denton Guidelines and legacy DNV-OS-H-
series standards.
Sec.4 Ballast and other systems
This section replaces the following parts of the VMO Standard and the ND Guidelines:
• DNV, Marine Operations, General, DNV-OS-H101
• DNV, Load Transfer Operations, DNV-OS-H201
• GL Noble Denton, General Guidelines for Marine Projects, 0001/ND
• GL Noble Denton, Guidelines for Load-outs, 0013/ND
• GL Noble Denton, Guidelines for Float-over Installations / Removals, 0031/ND.
Sec.5 Loading and structural strength
This section replaces the applicable sections of the legacy GL Noble Denton Guidelines and legacy DNV-OS-H-
series standards.
Sec.6 Gravity based structure (GBS)
This section replaces the applicable sections of the following legacy documents:
• GL Noble Denton, Guidelines for concrete gravity structure construction & installation, 0015/ND
• DNV Offshore Standard, Load transfer operations, DNV-OS-H201.
Sec.7 Cables, pipelines, risers and umbilicals
Sec.8 Offshore wind farm (OWF) installation operations
This section replaces the applicable sections of the following legacy document:
• 0035/ND Guidelines for Offshore Wind Farm Infrastructure Installation.
Sec.9 Road transport
This section is new.
Sec.10 Load-out
This section replaces the applicable sections of the following legacy documents:
• DNV-OS-H201, Load transfer operations
• GL Noble Denton, Guidelines for Load-outs, 0013/ND
Sec.11 Sea voyages
This section replaces the applicable sections of the following legacy documents:
P.3 Calculation of SKL
APPENDIX Q Mooring and dynamic positioning systems
Q.1 Good practice recommendations for quayside mooring - Informative
Q.2 Dynamic positioning systems - Informative
APPENDIX R Decommissioning and removal of offshore installations
Page 6 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
• DNV-OS-H202, Sea transport operations
• DNV-OS-H203, Transit and Positioning of Offshore Units
• GL Noble Denton, Guidelines For Marine Transportations, 0030/ND.
Sec.12 Tow out of dry-dock or building basin
This section replaces the applicable sections of the following legacy documents:
• GL Noble Denton, General Guidelines for Marine Projects, 0001/ND
• DNV Offshore Standard, Load Transfer Operations, DNV-OS-H201.
Sec.13 Jacket installation operations
This section replaces the applicable sections of the following legacy documents:
• DNV Offshore Standard, Offshore Installation Operations (VMO Standard Part 2-4), DNV-OS-H204
• GL Noble Denton, Guidelines for Steel Jacket Transportation & Installation, 0028/ND.
Sec.14 Construction afloat
This section replaces the applicable sections of the following legacy documents:
• 0015/ND Guidelines for concrete gravity structure construction & installation
• DNV Offshore Standard DNV-OS-H201 Load Transfer Operations.
Sec.15 Lift-off, mating and float-over operations
This section replaces the applicable sections of the following legacy documents:
• GL Noble Denton, Guidelines For Float-Over Installations / Removals, 0031/ND
• DNV Offshore Standard DNV-OS-H201 Load Transfer Operations.
Sec.16 Lifting operations
This section replaces the applicable sections of the following legacy documents:
• GL Noble Denton, Guidelines For Marine Lifting & Lowering Operations, 0027/ND
• DNV Offshore Standard DNV-OS-H205 Lifting Operations (VMO Standard – Part 2-5)
• DNV Offshore Standard DNV-OS-H206 Load-out, transport and installation of subsea objects (VMO
Standard – Part 2-6).
Sec.17 Mooring and dynamic positioning systems
This section replaces the applicable sections of the following legacy documents:
• GL Noble Denton, Guidelines for Moorings , 0032/ND
• DNV-OS-H101 Marine Operations, General
• DNV-OS-H102 Marine Operations, Design and Fabrication
• DNV-OS-H203 Transit and Positioning of Offshore Units.
Section [17.13] replaces the applicable Dynamic Positioning related sections of the following legacy documents:
• GL Noble Denton, General Guidelines for Marine Projects, 0001/ND
• DNV Offshore Standard, Transit and Positioning of Offshore Units, DNV-OS-H203.
Sec.18 Decommissioning and removal of offshore installations
This section replaces Section 14 of 0001/ND “General Guidelines for Marine Projects”.
SECTION 1 Introduction
1.1 General
1.1.1
DNV GL Noble Denton marine services is a global provider of Marine Warranty Services and has set the industry
standard for marine operations and marine assurance activities for the last 50 years. Our collective industry best
practice and guidance documentation is referenced and used all over the world. This document includes the
harmonized legacy DNV standards and legacy GL Noble Denton guidelines, with the exception of those for
MODU/MOU site specific assessment.
1.1.2
Page 7 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Where DNV GL Noble Denton marine services is the Marine Warranty Survey provider, it should be read in
conjunction with DNVGL-SE-0080 Noble Denton marine services – marine warranty survey, /38/, which provides a
description of the process used by DNV GL Noble Denton marine services when providing marine warranty
survey (MWS) services to evaluate whether a marine operation can beaccepted for the purposes of insurance-
related MWS. It addresses both ‘project’ and MODU/MOU related MWS.
1.1.3
This document may be used in its complete form using the relevant sections based on the asset type and/or
operation. It is recommended that the reader uses the Noble Denton marine services wizard available through
My DNV GL (https://my.dnvgl.com/ (https://my.dnvgl.com/)) for easier access and to obtain the relevant sections
based on asset type and/or operation.
1.1.4
The use of this standard presupposes and does not replace the application of industry knowledge, experience
and know-how throughout the marine operation activities. It should solely be used by competent and
experienced organizations, and does not release the organizations involved from exercising sound professional
judgment. DNV GL has however no obligations or responsibility for any services related to this standard
delivered by others. DNV GL has a qualification scheme mandatory to approval engineers and surveyors
providing services related to this standard. This ensures that all approvals and certificates delivered are carried
out by well qualified personnel who understand the intention behind the standard, the limitations and the correct
interpretations. The use of this document is at the user's sole risk. DNV GL does not accept any liability or
responsibility for loss or damages resulting from any use of this document.
1.1.5
Further provisions and background information are contained in the appendices.
1.1.6
In some cases risk assessments can be used to justify project-specific deviations from the standard criteria
provided that the results are acceptable. When such risk assessments show that the risk levels are increased
relative to those inherent in the standard criteria, the operation may be approved subject to disclosure by the
client to, and agreement by, the insurance underwriters.
1.1.7
Execution of operations not adequately covered by this Standard shall be specially considered in each case.
1.1.8
Fulfilment of all requirements in this Standard does not guarantee compliance with international and national
(statutory) regulations, rules, etc. covering the same subjects/operations.
1.1.9
This Standard should if required be used together with other recognized codes or standards applicable for
marine operations.
1.1.10
In case of conflict between other codes or standards and this document, the latter shall be governing if this
provides a higher level of safety or serviceability.
1.1.11
By recognized codes or standards are meant national or international codes or standards applied by the majority
of professionals and institutions in the marine and offshore industry.
1.1.12 SWL and WLL:
Page 8 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
a. Safe Working Load (SWL) has generally been superseded by Working Load Limit (WLL) though both are in
common use during the change-over period. However confusion can arise due to the very different safety
factors being assumed by different equipment manufacturers and for different uses (e.g. mooring, lifting
or towing). Whenever possible this standard uses minimum breaking load (MBL) or ultimate load capacity
(ULC) to avoid these problems.
b. If the WLL or SWL of a shackle or other equipment is documented but the MBL or ULC is not, the owner or
operator should obtain a document from the manufacturer stating the minimum Safety Factor - defined as
(MBL or ULC) / (WLL or SWL as appropriate).
c. There is often some confusion about the differences between WLL and SWL. SWL is a derated value of
WLL, following an assessment by a competent person of the maximum static load the item can sustain
under the conditions in which the item is being used. SWL may be the same or less than WLL but can never
be more.
1.2 Objective
1.2.1
This standard is intended to ensure marine operations are designed and performed in accordance with
recognized safety levels and to describe “current industry good practice”. Where applicable, this standard can
be used in the approval of the marine operation(s) for Marine Warranty Survey purposes.
1.3 Scope
1.3.1
This standard addresses the marine operations that can occur during the development of an offshore asset or
when objects are moved by water from one place to another. It addresses the Marine Warranty Survey
requirements relevant to load-out, construction afloat, voyages and installation and the load cases that should be
addressed in the design.
1.3.2
The integrity of the final structure in the installed condition is the responsibility of the Assured and would
normally be verified and accepted by the certifying authority. The Marine Warranty Survey company takes no
responsibility for the installed condition unless the Marine Warranty Survey scope specifically addresses this case
e.g. for jack-up location approval.
1.3.3
With the exception of location approval of MOUs (Mobile Offshore Units) which are covered in DNVGL-ST-
N002, /39/, this standard covers most offshore assets and operations that are likely to require MWS approval.
1.4 References
1.4.1 Normative (i.e. mandatory) references
1.4.1.1
The standards and guidelines in Table 1-1 include provisions, through which reference in this text constitute
provisions of this standard.
Table 1-1 Normative (i.e. mandatory) standards
Id Name Date Revision
AISC: 360/10
Specification for Structural Steel Buildings, (included in
AISC Steel Construction Manual 14 Edition)
2010 14
DNVGL-OS-C101
Design of offshore steel structures, general – LRFD
method
2015
th
Page 9 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
DNVGL-ST-N002
Site specific assessment of mobile offshore units [due to
be issued in 2016, until then GL Noble Denton 0009/ND
“Guidelines for site specific assessments of jack-ups”
applies]
2016
EN 1993 Eurocode 3, Design of steel structures
IMO IMDG International Maritime Dangerous Goods Code 2006
IMO Intact
Stability Code
Intact Stability Code
2008 and later
amendments
IMO International
Convention on
Load Lines
IMO International Convention on Load Lines,
Consolidated Edition 2002
2002
IMO COLREGS
IMO International Regulations for Preventing Collisions
at Sea, 1972 (amended July 2015) (COLREGS)
1972
(amended
July 2015)
IMO ISM Code
IMO International Safety Management Code - ISM Code
- and Revised Guidelines on Implementation of the ISM
Code by Administrations
2002
IMO ISPS Code
International Ship and Port Facility Security Code
(amendment to SOLAS convention)
2002
(effective
2004)
IMO Resolution
A.1024(26)
Guidelines for ships operating in polar waters Jan 2010
ISO 19901-5
Petroleum and Natural Gas Industries “Specific
requirements for offshore structures – Part 5: Weight
control during engineering and construction”.
2016
1.4.2 Informative references
1.4.2.1
All references appear in Sec.19.
1.5 Definitions
1.5.1 Verbal forms
Table 1-2 Definitions of verbal forms
Term Definition
shall
verbal form used to indicate requirements strictly to be followed in order to conform to the
document
should
verbal form used to indicate that among several possibilities one is recommended as particularly
suitable, without mentioning or excluding others, or that a certain course of action is preferred but
not necessarily required
may verbal form used to indicate a course of action permissible within the limits of the document
Where Guidance Notes have been included they are used for giving additional information, clarifications or
advice to increase the understanding of preceding text. Therefore Guidance Notes shall not be considered as
giving binding or defining requirements. Any values in GuidanceNotes are not a requirement and shall be
considered as an initial recommendation.
1.5.2 Terms
1.5.2.1
Underlined definitions are defined elsewhere in Table 1-3.
Page 10 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Table 1-3 Definition of terms
Term Definition
1 intercept (angle)
The first angle of static inclination at which the wind overturning moment is equal to
the righting moment (see Figure 11-3 and Figure 11-4)
24-hour Move
A jack-up move taking less than 24 hours between entering the water and reaching
a safe air gap with at least two very high confidence good weather forecasts for the
48 hours after entering the water, having due regard to area and season.
2 intercept (angle)
The second angle of static inclination at which the wind overturning moment is
equal to the righting moment (see Figure 11-3 and Figure 11-4)
9-Part sling
A sling made from a single laid sling braided nine times with the sling rope and
eyes forming each eye of the 9-part sling.
A&R Winch
The Abandonment and Retrieval winch on a lay vessel whose primary purpose is to
lower the pipeline to the seabed and to retrieve it back to the lay vessel with
sufficient working tension to control the pipe catenary within safe code limits at all
stages.
Accidental Limit State
The limit state related to an accidental event. This can apply to either the intact
structure resisting accidental loads (including operational failure) or the load
carrying capacity of the structure in a damaged condition.
Added Mass
Added mass or virtual mass is the inertia added to a system because an
accelerating or decelerating body shall move some volume of surrounding water as
it moves through it, since the object and fluid cannot occupy the same physical
space simultaneously.
This is normally calculated as Mass of the water displaced by the structure
multiplied by the added mass coefficient.
Added Mass
Coefficient
Non-dimensional coefficient dependant on the overall shape of the structure
Alpha Factor
The maximum ratio of operational criteria/design environmental condition to allow
for weather forecasting inaccuracies. See [2.6.9]
Angle of Loll The static angle of inclination after flooding, without wind heeling (see Figure 11-4)
Approval
The act, by the designated the MWS company representative, of issuing a
Certificate of Approval.
Array Cable(s)
Generic term collectively used for Inter Turbine Cables and Collector Cables. See
also Infield Cables
Asset An structure or object subject to an insurance warranty or at risk from an operation
Assured
The Assured is the person who has been insured by some insurance company, or
underwriter, against losses or perils mentioned in the policy of insurance.
Barge A non-propelled vessel commonly used to carry cargo or equipment.
Base weight
The calculated weight of a structure, excluding all allowances and contingencies.
Sometimes known as net weight
Bend Restrictor
A device with several interlocking elements that lock when a design radius is
achieved.
Bend Strain Reliever
(BSR)
A tapered plastic sleeve fitted to a flexible pipe, umbilical or cable at the transition
between a stiff section (typically an end fitting or connector) and the normal body
of the pipe, umbilical or cable. Also known as Bend Stiffener
Bending Factor γ
A partial safety factor that accounts for the reduction in strength caused by bending
round a shackle, trunnion, diverter or crane hook.
Benign (weather) area An area with benign weather as described in [3.6]
Bifurcated tow
The method of towing 2 (or more) tows, using one tow wire, where the second (or
subsequent) tow(s) is connected to a point on the tow wire ahead of the preceding
tow, and with each subsequent towing pennant passing beneath the preceding
tow. See [11.18.1.4]
st
nd
b
Page 11 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Bird-caging
A phenomenon whereby armour wires locally rearrange with an increase and/or
decrease in pitch circle diameter as a result of accumulated axial and radial stresses
in the armour layer(s).
Bollard Pull (BP)
Certified continuous static bollard pull of a tug. The mean bollard pull developed in
a test by a tug at 100% of the Maximum Continuous Rating (MCR) of main engines
over a period of 10 minutes. This is used for the selection of tugs and sizing of
towing equipment.
Maximum bollard pull (at 110% of MCR) should not be used for tug selection.
Buckle “Wet”/“Dry”
A local collapse of pipe cross section in the span of pipe between the lay vessel and
the seabed. “Dry” means that the pipe wall is not breached and “Wet” means that
the pipe wall is breached and seawater floods into the pipe.
Bundle
A configuration of two or more pipelines joined together and either strapped or
contained within a carrier or sleeve pipe.
Burial Assessment
Survey (BAS)
A survey to assess the expected burial depths on a cable route using purpose built
sledges equipment with bottom penetrating sonar equipment or by towing a
miniature plough.
Burial Protection Index
(BPI)
A process to optimise cable burial depth requirements based on a risk assessment
of threats to the cable and the soil strengths in the location of each risk.
Cable Burial
A submarine power cable is trenched into the seabed and covered with soil
providing complete burial of a cable.
Cable Grips
Cable Grips are used to pull or support cables and pipes. They work on the
principle of the harder the pull, the tighter the grip.
Cable Tank A circular storage area where cable is coiled.
Cable-laid grommet
A single length of unit rope laid up 6 times over a core, as shown in IMCA M
179 /81/, to form an endless loop. Sometimes known as an endless sling
Cable-laid sling
A sling made up of 6 unit ropes laid up over a core unit rope, as shown in IMCA M
179, /81/, with a hand spliced eye at each end.
Cargo
Where the item to be transported is carried on a vessel, it is referred to throughout
this standard as the cargo. If the item is towed on its own buoyancy, it is referred to
as the tow.
Cargo overhang Distance from the side of the vessel to the extreme outer edge of the cargo
Cargo ship safety
certificates
(Safety Construction)
(Safety Radio)
(Safety Equipment)
Certificates issued by a certifying authority to attest that the vessel
• complies with the cargo ship construction and survey regulations,
• has radiotelephone equipment compliant with requirements and
• carries safety equipment that complies with the rules applicable to that vessel
type.
Carrier or Sleeve pipe The outer casing of a bundle or pipe-in-pipe.
Cats-paw
An extreme type of loop thrown into cables where a combination of low tension
and residual torsion forms a twisted loop. Commonly seen at repair Final Splice
locations where the Final Splice is lowered too quickly.
Certificate of Approval
(CoA)
A formal document issued by a MWS company surveyor stating that, in his/her
judgement and opinion, all reasonable checks, preparations and precautions have
been taken to keep risks within acceptable limits, and an operation may proceed.
Certified Having (or proved by) a certificate from an acceptable source
Chinese Fingers
Also known as pulling socks are used to pull or support cables and pipes. They
work on the principle of the harder the pull, the tighter the grip.
Classification
A system of ensuring ships are built and maintained in accordance with the Rules of
a particular Classification Society. Although not an absolute legal requirement, the
advantages (especially as regards insurance) mean that almost all vessels are
maintained in Class.
Client
The company to which the MWS company is contracted to perform marine warranty
or consultancyactivities.
Page 12 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Cold Stacking
Cold stacking is where the unit is expected to be moored or jacked-up for a
significant period of time and will have minimum or, in some cases, no services or
personnel available.
Column stabilised unit
A MOU which floats on its columns during operation or transit (e.g. semi-
submersible).
Competent person
A Competent Person carrying out a thorough
examination/assessment /analysis/certification shall have such appropriate practical
and theoretical knowledge and experience of the equipment and/or activity.
Although the competent person may often be employed by another organisation,
this is not necessary, provided they are sufficiently independent and impartial to
ensure that in-house examinations are made without fear or favour. However, this
should not be the same person who undertakes routine maintenance of the
equipment as they would then be responsible for assessing their own maintenance
work.
Note: Where local or national regulations define a Competent Person with more
onerous requirements, then the definition in these local or national regulations
shall apply.
Consequence Factor
γ
Factor applied in the design of critical components to ensure that these
components have an increased factor of safety in relation to the consequence of
their failure.
Controlled Depth Tow
(CDT)
A special towing operation where the pipe string or bundle is made almost
buoyant and towed at a controlled depth within the water column, suspended
between a lead and trail tug.
Crane vessel
The vessel, ship or barge on which lifting equipment is mounted. For the purposes
of this document it is considered to include: crane barge, crane ship, derrick barge,
floating shear-leg, heavy lift vessel, semi-submersible crane vessel (SSCV) and jack-
up crane vessel.
Cribbing
An arrangement of timber baulks, secured to the deck of a barge or vessel, formally
designed to support the cargo, generally picking up the strong points in vessel
and/or cargo.
Cross Linked
Polyethylene (XLPE)
A type of AC cable conductor insulation commonly used on submarine power
cables.
Cross Sectional Area
(CSA)
Normally the CSA of a single conductor in a submarine power cable x 3. For
example a submarine power cable with 3x600 mm in its designation would be a
cable with three conductors each of 600 mm .
Dead Man Anchor
(DMA)
Anchor or multiple anchors (which may be clump weights, sometimes buried),
typically used to initiate pipelay.
Deck mating
The act of installing integrated topsides over a substructure, generally by float-over
and ballasting. Deck mating may take place inshore or offshore, onto a floating or a
previously installed substructure.
Deck Support Unit
(DSU)
Unit installed on the vessel grillage to support the structure before and during the
float-over. It can be designed to either provide a rigid vertical support and allow
horizontal movement or utilise elastomers to absorb vertical and horizontal
installation motions and forces.
Deep water
This is determined on a case by case basis but for installation of subsea equipment
it is generally taken as greater than 500 m.
Demolition towage Towage of a “dead” vessel for scrapping.
Design environmental
condition
The design wave height, wave period, wind speed, current and other relevant
environmental conditions specified for the design of a particular voyage or
operation.
Determinate lift
A lift where the slinging arrangement is such that the sling loads are statically
determinate, and are not significantly affected by minor differences in sling length
or elasticity e.g. two and three point lifts
Double tow
The operation of towing two tows with two separate tow wires by a single tug. See
[11.18.1.2]
Dry Towage The operation of transporting a cargo on a barge.
b
2
2
Page 13 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Dunnage
Typically dunnage is inexpensive material used to protect cargo during transport.
Dunnage also refers to material used to support loads and prop tools and
materials. See cribbing.
Dynamic Amplification
Factor (DAF)
The factor by which the weight is multiplied, to account for accelerations and
impacts during the operation
Dynamic Angle The smallest angle at which the area ratio in [11.10.3.1] is satisfied
Dynamic hook load Static hook load multiplied by the DAF.
Engineered lift
A lift which is planned, designed and executed in a detailed manner, with thorough
supporting documentation. See [16.1.1.4].
Export Cable(s)
Submarine power cables connecting the offshore wind farm transformer station to
a landfall connection.
Factored weight
The calculated weight of a structure, including all allowances and contingencies.
Sometimes known as gross weight.
Fatigue Limit State
The limit state related to the capacity of the structure to resist accumulated effect of
repeated loading.
Field Joint Coating
(FJC)
Refers to single or multiple layers of coating applied to girth welds and associated
cutback of the line pipe coating. Coating can be applied in factory or field.
Final Splice
The location where a second joint is inserted into a cable system during a repair
and includes the excess slack in the cable where the two ends of the final splice
come to the surface.
Flag state
The state under which a commercial vessel is registered or licenced. It has the
responsibility to enforce regulations over vessels registered under its flag,
including inspections, certification and issuance of safety or pollution prevention
documents.
Floating off-load The reverse of floating on-load
Floating on-load
The operation of transferring a cargo, which itself is floating, onto a vessel or barge,
which is submerged for the purpose.
Floating Production
System (FPS)
Including FPV, FPU, FPSO, FGSO, spar (buoy) or TLP
Float-Over
The operation of installation/removal of a structure onto or from a fixed host
structure by manoeuvring and ballasting the transport vessel to effect load transfer
Forecasted
Operational Criteria
The metocean limits used when assessing weather forecasts to determine the
acceptability of proceeding with (each phase of) an operation beyond the next
Point of No Return.
For a weather restricted operation/voyage these equal the Operational Limiting
Criteria multiplied by an Alpha factor.
Freeboard
Freeboard is defined as the distance from the waterline to the watertight deck
level. In commercial vessels, it is measured relative to the ship's load line.
“Effective freeboard” is the minimum vertical distance from the still water surface to
any opening (e.g. an open manhole) or downflooding point, after accounting for
vessel trim and heel.
Global Positioning
System (GPS)
A satellite based system providing geographic coordinate location.
Grillage
A structure, secured to the deck of a barge or vessel, formally designed to support
the cargo and distribute the loads between the cargo and barge or vessel.
Heave Vessel motion in a vertical direction
Heavy Transport
Vessel (HTV)
A vessel which is designed to ballast down to submerge its main deck, to allow self-
floating cargo(es) to be on-loaded and off-loaded.
Host Structure
The host structure (e.g. jacket, GBS, TLP) onto which the structure or structure deck
will be floated and supported, or from which it will be removed.
Page 14 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Hydro-acoustic
Positioning Reference
(HPR)
A through water acoustic link between a vessel and a seabed beacon. Used to
locate and track vehicles in thewater column and can be used as a DP reference.
Indeterminate lift
Any lift where the sling loads are not statically determinate, typically lifts using four
or more lift points
Inshore Mooring A mooring operation in relatively sheltered coastal waters, but not at a quayside.
Inspection and Test
Plan (ITP)
A plan in which all test, witness and hold points for all aspects of a cable installation
are listed.
Insurance Warranty
A clause in the insurance policy for a particular venture, requiring the Assured to
seek approval of a marine operation by a specified independent survey house.
International
Association of
Classification Societies
(IACS)
A listing of IACS members is given on the IACS web site
http://www.iacs.org.uk/explained/members.aspx
(http://www.iacs.org.uk/explained/members.aspx)
International Cable
Protection Committee
(ICPC)
A trade body representing and lobbying on behalf of subsea cable owners. For
historical reasons membership is predominately comprised of telecom companies.
International
Convention for the
Safety Of Life At Sea
SOLAS, /92/
An international treaty concerning the safety of merchant and other ships and
MOUs.
International Maritime
Organization (IMO)
The United Nations specialized agency with responsibility for the safety and
security of shipping and the prevention of marine pollution by ships
International Safety
Management (ISM)
The ISM Code provides an International standard for the safe management and
operation of ships and for pollution prevention.
Intersection Point
The point at which two straight sections or tangents to a pipeline curve, or two
slings, meet when extended.
ISM Code
International Safety Management Code - the International Management Code for
the Safe Operation of Ships and for Pollution Prevention - SOLAS Chapter IX, /92/
I-tube
A vertical tube fitted to offshore structures to install product between the seabed
and the structure topsides.
Jacket
A sub-structure, positioned on the seabed, generally of tubular steel construction
and secured by piles, designed to support topsides facilities.
Jack-up
A self-elevating MODU, MOU or similar, equipped with legs and jacking systems
capable of lifting the hull clear of the water.
J-Lay
A laying method where the pipe joints are raised to a nearly vertical angle in a
tower mounted on a pipelay vessel in a tower, assembled and lowered, curved
through approximately 90° (J shape) to lie horizontally on the sea-bed.
J-tube
A J shaped tube fitted to offshore structures to install product between the seabed
and the structure topsides.
Kilometre Point
The position of on pipeline route at a given distance from an agreed reference
point, typically at or near one end.
Lay Back
The horizontal offset from the last pipe support on the lay vessel to the touch down
point on the seabed.
Leg Mating Unit (LMU)
Unit that is designed and installed between the structure and the host structure in
order to absorb vertical and horizontal installation motions and forces. The units are
normally either installed on the host structure legs to receive the structure, or on
the structure leg stubs, in order to interface with the host structure legs. LMU’s can
be also installed on the removal vessel.
Lift point
The connection between the rigging and the structure to be lifted. May include
padear, padeye or trunnion
Page 15 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Lifting Beam
A lifting beam is a structure designed to be connected to a lifting appliance at a
single point, and structure being lifted is connected to the bottom of the beam at
two or more lift points. The beam shall resist the bending moments. It is not
designed to carry compression loads.
Lightship weight The weight of the hull plus permanently installed items.
Limit state
A state beyond which the product or component no longer satisfies the given
acceptance criteria
Limit State 1 (LS1)
An ASD/WSD design condition where the loading is gravity dominated; also used
when the exclusions of [5.9.7.1 3)] apply.
Limit State 2 (LS2)
An ASD/WSD design condition where the loading is dominated by
environmental/storm loads, e.g. at the 10 year or 50 year return period level or, for
weather restricted operations, (where the operational limiting criteria are less than
the design environmental criteria due to the application of an Alpha Factor, see
[2.6.9]).
Line pipe Coated or uncoated steel pipe sections, intended to be assembled into a Pipeline
Linear Cable Engine
(LCE)
An industry term commonly used to refer collectively to cable lay tensioners.
Link beam/link span
The connecting beam between the quay and the barge or vessel. It may provide a
structural connection, or be intended solely to provide a smooth path for skidshoes
or trailers/SPMTs.
Load Factor (LF)
A factor used on a design load in a limit state analysis and is also used in the design
of slings and grommets used for lifting operations.
Load line
The maximum depth to which a ship may be loaded in the prevailing circumstances
in respect to zones, areas and seasonal periods. A Load line Certificate is subject to
regular surveys, and remains valid for 5 years unless significant structural changes
are made.
Load transfer
operation
The operation to transfer the load (i.e. an object) from/to vessel(s) without using
cranes, i.e. by using (de-)ballasting. Typical load transfer operations are load-out,
lift-off, mating and float-over.
Load-in
The transfer of an assembly, module, pipes or component from a barge or vessel,
e.g. by horizontal movement or by lifting.
Load-out
The transfer of an assembly, module, pipes or component onto a barge or vessel,
e.g. by horizontal movement or by lifting.
Load-out Support
Frame (LSF)
A structural frame that supports the structure during fabrication and load-out and
may support the structure on a barge/vessel above grillage.
Load-out, floating A Load-out onto a floating vessel.
Load-out, grounded A Load-out onto a grounded vessel.
Load-out, lifted A Load-out performed by crane.
Load-out, skidded
A Load-out where the structure is skidded, using a combination of skidways,
skidshoes or runners, propelled by jacks or winches.
Load-out, trailer A Load-out where the structure is wheeled onto the vessel using trailers or SPMTs.
Location move
A move of a MODU or similar, which, although not falling within the definition of a
field 24-hour move, may be expected to be completed with the unit essentially in
24-hour field move configuration, without overstressing or otherwise endangering
the unit, having due regard to the length of the move, and to the area (including
availability of shelter points) and season.
Magnetic Particle
Inspection (MPI)
A Non-Destructive Testing (NDT) process for detecting surface and slightly
subsurface discontinuities in ferroelectric materials such as iron
Marine operation See Operation
Marine Warranty
Survey company
MWS Company
The Marine Warranty Survey (MWS) company is one that is specified on an
insurance warranty and has been contracted to approve specified operations as a
condition of the insurance.
Page 16 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Marine Warranty
Survey company
surveyor (MWS
company surveyor)
An MWS company surveyor is employed to review the proposed procedures and
equipment and, when satisfied that they and the weather forecasts are suitable, to
issue a Certificate of Approval for each relevant operation. He /she may also attend
during such operations to monitor that the procedures are followed or to agree any
necessary changes.
Matched pair of slings
A matched pair of slings is fabricated or designedso that the difference in length
does not exceed 0.5d for cable laid slings or grommets and 1.0d for single laid
slings or grommets, where d is the nominal diameter of the sling or grommet. See
Section 2.2 of IMCA M 179 /81/ for cable laid details
Material Factor γ
A factor used on a material’s yield stress in a limit state analysis and is also a factor
used in the design of slings and grommets used for lifting operations. Note: For
slings and grommets, the material factor is a function of the age, certification and
material type.
Maximum Continuous
Rating (MCR)
Manufacturer’s recommended Maximum Continuous Rating of the main engines.
Mechanical
Termination
A sling eye termination formed by use of a ferrule that is mechanically swaged onto
the rope. See ISO 2408 and 7531, /104/ and /105/.
Minimum Bend Radius
(MBR)
Specified by the manufacturer of a flexible pipe, umbilical or cable. This is the
minimum radius to which a flexible, umbilical or cable can be bent without
compromising its integrity.
Minimum Breaking
Load (MBL)
The minimum value of breaking load for a particular sling, grommet, wire or chain,
shackle etc.
Mobile Mooring
Mooring system, generally retrievable, intended for deployment at a specific
location for a short-term duration, such as those for mobile offshore units.
Mobile Offshore Unit
(MOU)
For the purposes of this document, the term may include Mobile Offshore Drilling
Units (MODUs), and non-drilling mobile units such as accommodation,
construction, lifting or production units including those used in the offshore
renewables sector.
Monopile Tubular structure used as foundation for offshore wind turbine generator.
Moored Vessel Within the scope of this document refers to any structure which is being moored.
Mooring System
Consists of all the components in the mooring system including shackles
windlasses and other jewellery and, in addition, rig/vessel and shore attachments
such as bollards.
Most Probable
Maximum Extreme
(MPME)
The value of the maximum of a variable with the highest probability of occurring
over a period of 3 hours.
NOTE The most probable maximum is the value for which the probability density
function of the maxima of the variable has its peak. It is also called the mode or
modus of the statistical distribution. It typically occurs with the same frequency as
the maximum wave associated with the design sea state.
Multiple towage
The operation of towing more than one tow by a single tug, or more than 1 tug
towing one tow. See [11.18]
Nacelle
The part of the wind turbine on top of the tower, where the hub, gearbox,
generator and control systems are located.
Non-Destructive
Testing (NDT)
Ultrasonic scanning, magnetic particle inspection, eddy current inspection or
radiographic imaging or similar. Can also include visual inspection.
Not To Exceed (NTE)
weight
Sometimes used in projects to define the maximum weight of a structure for an
operation. See [5.6.2.2]
Off-hire survey
A survey carried out at the time a vessel, barge, tug or other equipment is taken off-
hire, to establish the condition, damages, equipment status and quantities of
consumables, intended to be compared with the on-hire survey as a basis for
establishing costs and liabilities.
Off-load The reverse of load-out
b
Page 17 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Offshore Converter
Station
The offshore converter station transforms the collected energy from the offshore
transformer stations (several wind parks) to Direct Current in order to send it to a
land based converter station.
Offshore pull The pulling of a pipeline away from the shore using a lay vessel
Offshore Transformer
Station
The offshore transformer station is transforming the collected energy from the wind
turbines to a higher voltage.
On-hire survey
A survey carried out at the time a vessel, barge, tug or other equipment is taken on-
hire, to establish the condition, any pre-existing damages, equipment status and
quantities of consumables. It is intended to be compared with the off-hire survey as
a basis for establishing costs and liabilities. It is not intended to confirm the
suitability of the equipment to perform a particular operation.
Operation reference
period
The Planned Operation Period, plus the contingency period. See [2.6.2] to [2.6.4]
Operation, marine
operation
Generic term covering, but not limited to, the following activities which are subject
to the hazards of the marine environment:
a. Load-out/load-in
b. Voyage
c. Lift/Lowering (offshore/inshore)
d. Tow-out/tow-in
e. Float-over/float-off
f. Jacket launch/jacket upend
g. Pipeline installation
h. Construction afloat
Operational Limiting
Criteria
The metocean limits used when assessing weather forecasts to determine the
acceptability of proceeding with (each phase of) an operation beyond the next
Point of No Return.
For a weather restricted operation/voyage these equal the design environmental
condition multiplied by an Alpha factor.
Padear
A lift point consisting of a central member, which may be of tubular or flat plate
form, with horizontal trunnions round which a sling or grommet may be passed
Padeye
A lift point consisting essentially of a plate, reinforced by cheek plates if necessary,
with a hole through which a shackle may be connected
Permanent Mooring
Mooring system normally used to moor floating structures deployed for long-term
operations, such as those for a floating production system.
Pigging
The practice of passing a device known as a “pig” through a pipeline for
maintenance (e.g. for cleaning, gauging or inspection) without stopping the flow in
the pipeline.
Pipe carrier A vessel specifically designed or fitted out to transport Line pipe
Pipe-in-Pipe A single rigid pipe held within a carrier pipe by spacers and/or solid filler.
Pipelay
The operation of assembling and laying the pipeline on the seabed, from start-up
point to lay-down point.
Pipeline
Any marine pipeline system for the carriage of oil, gas, water or other process
fluids. It may be of rigid material or flexible layered construction. For the purposes
of this document the term pipeline includes flowlines as defined in API RP 1111, /3/
Planned Operation
Period
The planned duration of the operation from the forecast before either the
operation start or Point of No Return, as appropriate, to a condition when the
operations/structures can safely withstand a seasonal design storm (also termed
“safe to safe” duration) this excludes the contingency period
Platform The completed steel or concrete structure complete with topsides
Point of No Return
(PNR)
The last point in time, or a geographical point along a route, at which an operation
could be aborted and returned to a safe condition.
Port (or point) of
shelter
See Shelter point
Page 18 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Port of refuge
A location where a towage or a vessel seeks refuge, as decided by the Master, due
to events which prevent the towage or vessel proceeding towards the planned
destination. A safe haven where a towage or voyage may seek shelter for survey
and/or repairs, when damage is known or suspected.
Pre-Loading
The testing of soil foundations or anchors by loading to check that they can take
subsequent loads. For jack-up foundations it is often done be adding water ballast
to pre-load tanks or (with units with more than 3 legs) by pre-driving by removing
load from other legs in turn.
Procedure A documented method statement for carrying out an operation
Product
A generic term used within this standard to reference pipelines (rigid and flexible),
risers, jumpers, umbilicalsand submarine cables.
Pull Back Method
A J-tube pull-in operation where the pull-in winch is mounted on the installation
vessel and the end of the pull-in wire connected to the cable runs from the vessel to
the J-tube bottom end up and over a sheave and back to the installation vessel
pull-in winch.
Quadrant
A structure, usually with rollers, to limit the MBR as the cable travels over or though
it and changes direction, typically during loading or laying during second end J
tube pull in operations.
Quadratic Transfer
Function (QTF)
Refers to the matrix that defines second order mean wave loads on a vessel in bi-
chromatic waves. When combined with a wave spectrum, the mean wave drift loads
and low frequency loads can be calculated.
Quayside Mooring A mooring that locates a vessel alongside a quay (usually at a sheltered location).
Recognized
Classification Society
(RCS)
Member of IACS with recognized and relevant competence and experience in
specialised vessels or structures, and with established rules and procedures for
classification/certification of such vessels/structures under consideration.
Reduction Factor, γ
The Reduction Factor used in the design of slings or grommets representing the
largest values of γb and γs.
Redundancy Check
Check of the failure load case associated with the applicable extreme (survival)
environment, e.g. the one line broken case.
Reel Lay (for rigid
pipe)
A laying method where the pipeline is pre-assembled into long strings or stalks and
wound onto a large reel with the pipe experiencing plastic deformation when
wound on and off the reel and straightened when reeled off. Typical lay angles of
20 to 90 degrees are achieved.
Registry
Registry indicates who may be entitled to the privileges of the national flag, gives
evidence of title of ownership of the ship as property and is required by the need of
countries to be able to enforce their laws and exercise jurisdiction over their ships.
The Certificate of Registry remains valid indefinitely unless name, flag or ownership
changes.
Remotely (Controlled)
Operated Vehicle
(ROV)
A device deployed subsea on a tether or umbilical, typically equipped with a
subsurface acoustic navigation system and thrusters, to control its location and
attitude, and a lighting and video system. Additional devices such as manipulators,
acoustic scanning for touch down monitoring, etc., may also be provided.
Response Amplitude
Operator (RAO)
Defines the vessel’s (first order) response in regular waves and allows calculation of
vessel wave frequency (first order) motion in a given sea state using spectral
analysis techniques.
Rig
General reference term often used to describe a jack-up or semi-submersible
(Mobile Offshore Drilling Unit or MODU)see MOU) e.g. ‘Rig move procedures’
Rigging
The slings, shackles and other devices including spreaders used to connect the
structure to be lifted to the crane
Rigging weight
The total weight of rigging, including slings, shackles and spreaders, including
contingency.
Righting Arm (GZ) Righting Moment divided by the displacement
Risk assessment
A method of hazard identification where all factors relating to a particular operation
are considered.
r
Page 19 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Rope
An assembly of strands wrapped around a core. When a rope is used for cable-laid
sling or cable-laid grommet it is referred to as a unit rope (as per IMCA M 179 /81/).
Rotor Configuration consisting of the complete set of blades, connected to the hub.
Route Planning List
(RPL)
A tabularised list of the coordinates defining the route along which a submarine
cable is to be installed and the planned installation slack. A post installation RPL will
record the as-built cable route coordinates, installed slack and burial depths.
Routine lift
“Everyday” lift, without detailed design, planning or documentation, such as
general cargo lifting operations or lifting portable units on/off a supply vessel. See
[16.1.1.4].
Safe condition
A condition where the object is considered to be exposed to a normal level of risk
of damage or loss. See guidance note to [2.5.1.2]
Safe Working Load
(SWL)
SWL is a derated value of WLL, following an assessment by a competent person of
the maximum static load the item can sustain under the conditions in which the
item is being used. See [1.1.12]
Safety Management
System (SMS)
A structured and documented system enabling Company personnel to implement
the Company safety environmental protection policy.
Sand Jacks
A compartment filled with sand that is incorporated into the LMU to allow the final
controlled lowering of the structure onto the host structure
Scour pit
The result of scour around a pile, leg etc. See “Dynamics of scour pits and scour
protection”, /119/
Sea room
The distance that a disabled vessel or tow in bad weather can drift before
grounding. See [11.14.1.5]
Seafastenings
The means of restraining movement of the loaded structure on or within the barge
or vessel
Self-Propelled Modular
Transporter (SPMT)
A trailer system having its own integral propulsion, steering, jacking, control and
power systems.
Semi-submersible
A floating structure normally consisting of a deck structure with a number of widely
spaced, large cross-section, supporting columns connected to submerged
pontoons.
Serviceability Limit
State (SLS)
A design condition where the structure is required to fulfil its primary operational
function.
Setback
The space on the derrick floor where stands of drill pipe or tubing are “setback”
and racked in the derrick. It can also mean the amount of drill pipe etc. in this area.
Shelter point (or port
of shelter, or point of
shelter)
An area or safe haven where a towage or vessel may seek shelter, in the event of
actual or forecast weather outside the design limits for the voyage concerned. A
planned holding point for a staged voyage
Shore pull The pulling of a cable or pipeline to the shore from a lay barge/vessel
Simultaneous
Operations (SIMOPS)
Operations usually involving various parties and vessels requiring co-ordination
and definitions of responsibilities.
Single Laid Sling
A sling normally made up of 6 strands laid up over a core, as shown in ISO 2408
and 7531, (/104/ and /105/), with terminations each end.
Single tow The operation of towing a single tow with a single tug.
Site Move
An operation to move a structure or partially assembled structure in the yard from
one location to another. The site move may precede a load-out if carried out as a
separate operation or may form part of a load-out. The site move may be subject to
approval if so desired.
Skew Load Factor
(SKL)
A factor to account for additional loading caused by rigging fabrication tolerances,
fabrication tolerances of the lifted structure and other uncertainties with respect to
asymmetry and associated force distribution in the rigging arrangement.
Skidshoe
A bearing pad attached to the structure which engages in the skidway and carries a
share of the vertical load
Page 20 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Skidway
The lower continuous rails, either on the quay or on the vessel, on which the
Structure is loaded out, via the Skidshoes.
Slack Management
A generalized term used by the submarine cable installation industry to refer to the
control of cable pay-out out against a pre-defined installation plan.
Slamming loads
Transient loads on the structure due to wave impact when lifting through the splash
zone.
S–Lay
A laying method where the pipe is assembled horizontally, fed out of the stern or
bow of the barge or vessel, typically over a stinger
Can alsobe without stinger at certain depths or at the end of the shore pull before
the water depth increases to a depth where stinger becomes necessary, and then
makes a double curve (shallow S shape) to lie horizontally on the sea-bed.
Sling design Load
The maximum calculated dynamic axial load in a lifting sling, including all relevant
load factors.
Sling eye A loop at each end of a sling, either formed by a splice or mechanical termination
Specified Minimum
Yield Stress (SMYS)
The minimum yield stress specified in standard or specification used for purchasing
the material.
Splice
That length of sling where the rope (or unit rope for cable-laid sling) is connected
back into itself by tucking the tails of the strands (or unit ropes) back through the
main body of the rope (or unit ropes), after forming the sling eye
Spreader beam or bar
(frame)
A spreader bar or frame is a structure designed to resist the compression forces
induced by angled slings, by altering the line of action of the force on a lift point
into a vertical plane. The structure shall also resist bending moments due to
geometry and tolerances.
Spud
A large metal post which penetrates the seabed under its own weight and is used
to prevent lateral movement of a barge. A dredge barge will typically have two
spuds in guides near its stern.
Staged voyage
A weather restricted voyage in which there is a commitment to seek shelter (or jack-
up at a stand-by location) on receipt of a weather forecast in excess of the
operational criteria. See [11.14.4.1].
Static Hook Load (SHL)
The weight plus the rigging weight (see [16.3.2]). This load is suspended by a crane
hook during lifting operations.
Strand
An assembly of wires wound together to create a strand. Wire rope consists of
multiple strands wound together. For example: 6x36 wire rope construction
indicates that the wire rope consists of 6 strands, each having 36 wires.
Structure
The object to be transported, lifted or installed, or a sub-assembly, component or
module.
Submerged Weight Weight of the Structure minus the weight of displaced water.
Suitability survey
A survey intended to assess the suitability of a tug, barge, vessel or other
equipment to perform its intended purpose. Different and distinct from an on-hire
survey.
Surge
Barge or vessel motion in the longitudinal direction OR
A change in water level caused by meteorological conditions
Survey
Attendance and inspection by a MWS company surveyor.
Other surveys which may be required for a marine operation, including suitability,
dimensional, structural, navigational and Class surveys.
Surveyor
The MWS company representative carrying out a ‘Survey’ or an employee of a
contractor or Classification Society performing, for instance, a suitability,
dimensional, structural, navigational or Class survey.
Sway Vessel motion in the transverse direction
System Pressure Test
A pressure test at a pressure normally at a 1.25 to 1.5 times the pipeline design
pressure (for rigid pipelines), which is made after installation operations are
substantially or wholly completed, to provide proof of pressure and strength
integrity of the pipeline and spools.
Page 21 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Tandem tow
The operation of towing two or more tows in series with one tow wire from a single
tug, the second and subsequent tows being connected to the stern of the tow
ahead.
Tangent Point The point where the bend of a pipeline begins or ends.
Tensioner Equipment to keep and control tension in the product during installation operation.
Termination factor γ
A partial safety factor that accounts for the reduction in strength caused by a splice
or mechanical termination.
Tether
A tether is a mooring line used for pulling and mooring the installation /removal
vessel into the required position. It may also be the umbilical to an ROV or part of a
TLP’s mooring system.
Tidal range
Where practicable, the tidal range referred to in this document is the predicted
tidal range corrected by location-specific tide readings obtained for a period of not
less than one lunar cycle before the operation.
Tonnage
A measurement of a vessel in terms of the displacement of the volume of water in
which it floats, or alternatively, a measurement of the volume of the cargo carrying
spaces on the vessel. Tonnage measurements are principally used for freight and
other revenue based calculations. Tonnage Certificates remain valid indefinitely
unless significant structural changes are made.
Tonnes
Metric tonnes of 1,000 kg (approximately 2,204.6 lbs) are used throughout this
document. The necessary conversions shall be made for equipment rated in long
tons (2,240 lbs, approximately 1,016 kg) or short tons (2,000 lbs, approximately 907
kg).
Touch Down (TD)
Seabed location at which a submarine pipeline or cable touches down on the
seabed during installation, or a mooring line during operation.
Tow
The item being towed. This can be a barge or vessel (laden or un-laden) or an item
floating on its own buoyancy.
Towage
The operation of towing a non-propelled barge or vessel (whether laden or not,) or
other floating object (wet tow) by tug(s).
Towed bundle
A pipeline system comprising one or more pipelines, tubes or cables contained
within a carrier pipe, and fitted with towing and trailing heads. The bundle is usually
assembled on land and launched. The bundle may be towed off- bottom, on
surface, or at an intermediate controlled depth.
Tower (OWF)
The tubular element from the top of the flange on the foundation to the bottom of
the flange below the nacelle, generally built up of several sections.
Towing arrangements
The hardware from the towing winch to the towing connections plus the bridle
recovery and emergency towing equipment. (They do not normally include the
towing procedures.)
Towline connection
strength
Ultimate load capacity of towline connections, including connections to vessel,
bridle and bridle apex.
Towline Pull Required
(TPR)
The towline pull computed to hold the tow, or make a certain speed against a
defined weather condition.
Trailer
A system of steerable wheels, connected to a central spine beam by hydraulic
suspension which can be raised or lowered. Trailer modules can be connected
together and controlled as a single unit. Trailers generally have no integral
propulsion system, and are propelled by tractors or winches. See also SPMT.
Transition Piece A tubular structure on top of a monopile to provide support for the tower.
Transport The operation of transporting a cargo on a powered vessel.
Trunnion
A lift point consisting of a horizontal tubular cantilever, round which a sling or
grommet may be passed. An upending trunnion is used to rotate a structure from
horizontal to vertical, or vice versa, and the trunnion forms a bearing round which
the sling, grommet or another structure will rotate.
s
Page 22 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Tug
The vessel performing a towage (including tug supply and anchor handling towing
vessels). Approval by the MWS company of the tug will normally include
consideration of the general design, classification, condition, towing equipment,
bunkers and other consumable supplies, emergency communication and salvage
equipment, and manning.
Tug efficiency (T or
T )
Effective bollard pull produced in the weather considered divided by the certified
continuous static bollard pull.
Tug Management
Positioning System
(TMPS)
A system installed on the AHV and the anchoring vessel to allow the accurate
placing of the tug and anchors.
Ultimate Limit State
(ULS)
The limit state related to the maximumload carrying capacity. Also see Limit State 1
and Limit State 2. (ULS)
Ultimate Load
Capacity (ULC)
Ultimate load capacity of a wire rope, chain or shackle or similar is the certified
minimum breaking load. The load factors allow for good quality splices in wire
rope.
Ultimate load capacity of a padeye, clench plate, delta plate or similar structure, is
defined as the load, which will cause general failure of the structure or its
connection into the barge or other structure.
Ultrasonic Testing (UT)
Detection of flaws or measurement of thickness by the use of ultrasonic pulse-
waves through steel or some other materials.
Umbilical
Typically a combination of cables and flexible pipes used to provide energy and/or
chemicals and remote control for equipment (e.g. subsea), or to provide
communications and life support for a diver
Under-Keel Clearance
(UKC)
The clearance below the keel or base of a vessel or structure, after allowances for
motions, and the seabed (or the host structure during mating operations)
Unit Rope
The rope from which a cable-laid sling or cable-laid grommet may be constructed,
made from either 6 or 8 strands around a steel core, as indicated in ISO 2408 and
7531, (/104/ and /105/) and IMCA, M 179, /81/
Variable Load
Weight added to the Lightship weight to obtain the total weight for a particular
towage or operation, including cargo, liquids and temporary equipment.
Vessel
A marine craft designed for the purpose of transporting by sea or construction
activities offshore. This can include ships and barges
Voyage
For the purposes of this standard, voyage covers both towages and transport from
one place to another.
Watertight
A watertight opening is an opening fitted with a closure designated by Class as
watertight, and maintained as such, or is fully blanked off so that no leakage can
occur when fully submerged.
Wear Factor, γ
A factor used in the design of slings and grommets used for lifting operations to
account for physical condition of the sling or grommet.
Weather restricted
operation
An operation for which (any of) the applied characteristic environmental conditions
are less than the characteristic environmental conditions calculated based on the
statistical extremes for the area and season. See also 2.6.7
Weather restricted
voyage
A voyage for which the strength or stability will not meet the weather unrestricted
environmental criteria (typically 10 year return). It can either be or staged (see
[11.14.4.1]) or weather-routed (see [11.14.4.4]) depending on the sea room and
shelter point availability.
Weather routed
voyage
A weather restricted voyage in which a weather forecasting organisation advises
the relevant captain on the best route to avoid weather exceeding the Operational
Limiting Criteria. (See [11.14.4.4]).
Weather routeing may also be used for non-weather restricted voyages to reduce
fuel costs or voyage time.
Weather unrestricted
operation
An operation for which (all of) the applied characteristic environmental conditions
are calculated based on the statistical extremes for the area and season. See also
2.6.62.6.5.
e
eff
w
Page 23 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Weather unrestricted
towage
Any towage which does not fall within the definition of a weather restricted towage,
or any towage of a MODU or similar which does not fall within the definition of a 24-
hour move or location move.
Weather unrestricted
voyage
Any voyage which does not fall within the definition of a weather restricted voyage
Weather Window
A period that the forecasted environmental conditions are less than or equal to
OP (the Forecast Operation Criteria).
Weathertight
A weathertight opening is an opening closed so that it is able to resist any
significant leakage from one direction only, when temporarily immersed in green
water or fully submerged.
Weighing Contingency
Factor
A factor applied to the weighed weight of an object to account for uncertainties in
the weighing equipment.
Weight Contingency
Factor
A factor applied to the weight of an object, when an object is not to be weighed, to
account for uncertainties related to the design and fabrication of the object.
Wet towage The operation of transporting a floating object by towing it with a tug.
Wind Heeling Arm
(WHA)
Wind Heeling Moment divided by the displacement
Working Load Limit
(WLL)
The maximum static load which a piece of equipment is authorized to sustain in
general service when the rigging and connection arrangements are in accordance
with the design. See [1.1.12].
1.6 Acronyms, abbreviations and symbols
1.6.1
Underlined acronyms and abbreviations in Table 1-4 are defined in Table 1-3.
Table 1-4 Acronyms and abbreviations
Short Form In full
ABS American Bureau of Shipping
ADL Absolute minimum Deployable Length (of towline)
AHC Active Heave Compensation
AHV Anchor Handling Vessel
AISC American Institute of Steel Construction
ALARP As Low As Reasonably Practicable
ALS Accidental Limit State
AMS Anchor Management System
API American Petroleum Institute
ASD Allowable Stress Design (effectively the same as WSD)
ASOG Activity Specific Operations Guidelines (for DP – See [17.13.4.1 11))
ASPPR Arctic Shipping Pollution Prevention Regulations
ATA Automatic Thruster Assist
AUT Automatic Ultrasonic Testing
AWTI Above Water Tie-In
BAS Burial Assessment Survey
BBL Bridle Breaking Load
BHP Brake Horse Power
WF
Page 24 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
BP Bollard Pull
BPI Burial Protection Index
BSR Bend Strain Reliever
CAMO Critical Activity Mode of Operation (for DP – See [17.13.4.1 11))
CASPRR Canadian Arctic Shipping Pollution Prevention Regulations
CBP Continuous Bollard Pull
CDT Controlled Depth Tow
CGBL Calculated Grommet Breaking Load
CoB Centre of Buoyancy
CoG Centre of Gravity
COMOP Combined Operations
COSHH Control of Substances Hazardous to Health
CR Continuity Resistance
CRBL Calculated Rope Breaking Load
CSA Cross Sectional Area
CSBL Calculated Sling Breaking Load
CSV Construction Support Vessel
DAF Dynamic Amplification Factor
DMA Dead Man Anchor
DP Dynamic Positioning or Dynamically Positioned
DSU Deck Support Unit
DSV Diving Support Vessel
DTL Deployable Towline Length (see [11.13.4.3])
D Factor for ratio of mean to specified bolt pretension
ECA Engineering Criticality Assessment
EPC Engineering, Procurement and Construction
EPIRB Emergency Position Indicating Radio Beacon
ESD Emergency Shut Down
FAT Factory Acceptance Tests
FBE Fusion Bonded Epoxy
FEA Finite Element Analysis
FEED Front End Engineering Design
FGSO Floating Gas Storage and Offloading Vessel
FJC Field Joint Coating
FLNG Floating Liquefied Natural Gas
FLS Fatigue Limit State
FMEA Failure Modes and Effects
FMECA Failure Modes, Effects and Criticality Analysis
FOI Floating Offshore Installation
FoS Factor of Safety
FPS Floating Production System
u
Page 25 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
FPSO Floating Production, Storage and Offloading Vessel
FPU or FPV Floating Production Unit or Floating Production Vessel
FRSU Floating Storage Re-gasification Unit
F Sling or grommet design load
FSE Free Surface Effect
FSO Floating Storage and Offloading Vessel
FSU Floating Storage Unit (including FPSO, FSO, FLNG facility, FRSU etc.)
Gamma b, γ Bending Factor
Gamma c, γ Consequence Factor
Gamma f, γ Load Factor
Gamma m, γ Material Factor
Gamma r, γ Reduction Factor
Gamma s, γ Termination Factor
Gamma sf, γ Combined factors (Load, Consequence, Reduction, Wear, and Material and Twist)
Gamma w, γ WearFactor
Gamma weight,
γ
Weight Contingency Factor (unweighed objects only)
GBS Gravity Base Structure (foundation)
GM Initial metacentric height
GMDSS Global Maritime Distress and Safety System
GN Guidance Note
GPS Global Positioning System
GZ Righting Arm
HAT Highest Astronomical Tide
HAZID Hazard Identification
HAZOP HAZards and OPerability study
HDD Horizontal Directional Drilling
h Factor for fillers in bolted connections
HIRA Hazard Identification and Risk Assessment
HPR Hydro-acoustic Positioning Reference
HSEQ Health, Safety, Environment and Quality
HTV
Heavy Transport Vessel. (not to be confused with HLV (Heavy Lift Vessel) which has heavy
lifting gear)
HVAC High Voltage Alternating Current
HVDC High Voltage Direct Current
IACS International Association of Classification Societies
ICPC International Cable Protection Committee
IMCA International Marine Contractors Association
IMDG Code International Maritime Dangerous Goods Code
IMO International Maritime Organization
IOPP Certificate International Oil Pollution Prevention Certificate (see also MARPOL)
SD
b
c
f
m
r
s
sf
w
weight
f
Page 26 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
IR Insulation Resistance
ISM International Safety Management
ISO International Standards Organisation
ITP Inspection Test Plan
JSA Job Safety Analysis
k Hole clearance factor
LARS Launch And Recovery System
LAT Lowest Astronomical Tide
LBL Long Baseline Array
LCE Linear Cable Engine
LMU Leg Mating Unit
LOA Length Over All
LRFD Load and Resistance Factor Design
LS1 Limit State 1
LS2 Limit State 2
LSF Load-out Support Frame
MAOP Maximum Allowable Operating Pressure
MARPOL International Convention for the Prevention of Pollution from Ships 1973/78, as amended
MBL Minimum Breaking Load
MBR Minimum Bend Radius
MCR Maximum Continuous Rating
MDR Master Document Register
MLWS Mean Low Water Spring Tides
MoC
(procedure)
Management of Change (procedure)
MODU Mobile Offshore Drilling Unit
MOU Mobile Offshore Unit
MPI Magnetic Particle Inspection
MPME Most Probable Maximum Extreme
MRU Motion Reference Unit
MSL Mean Sea Level
MWS Marine Warranty Survey
n/a Not Applicable
NDT Non Destructive Testing
NMD Norwegian Maritime Directorate
N Number of slip planes for bolted connections
NTE (weight) Not To Exceed (weight)
OCIMF Oil Companies International Marine Forum
OD Outside Diameter
OP Operational limiting criteria
OP Forecasted operational criteria
s
s
LIM
WF
Page 27 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
OSS Out of Straightness Survey
OTDR Optical Time Domain Reflectometry
OWF Offshore Wind Farm
PHC Passive Heave Compensation
PIC Person In Charge
PLEM Pipeline End Manifold
PLET Pipeline End Termination
PNR Point of No Return
PRT Pipeline Recovery Tooling/Tool
PSA Petroleum Safety Authority Norway
QC Quality Control
QCFAT Quality Control Factory Acceptance Test
QRA Quantified Risk Analysis
QTF Quadratic Transfer Function
RAO Response Amplitude Operator
RCS Recognized Classification Society
ROV Remotely (Controlled) Operated Vehicle
RPL Route Planning List
RTBL Required Towline Breaking Load
SART Search and Rescue Radar Transponder
SCR Steel Catenary Riser
SE Shore End
SF Safety Factor
SHL Static Hook Load
SIMOPS Simultaneous Operations
SJA Safe Job Analysis
SKL Skew Load Factor
SLS Serviceability Limit State
SMC Safety Management Certificate
SMS Safety Management System
SMYS Specified Minimum Yield Stress
SOLAS International Convention for the Safety Of Life At Sea, /92/,
SOPEP Shipboard Oil Pollution Emergency Plan
SPMT Self-Propelled Modular Transporter
SSCV Semi-submersible crane vessel
SWL Safe Working Load
TA Thruster Assist
TAM Task Appropriate Mode
T Minimum fastener pretension for bolted connections
TBL Towline Breaking Load
T Contingency period
b
C
Page 28 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
TD Touch Down
TDR Time Domain Reflectometry
T or T Tug efficiency
TLP Tension Leg Platform
TMPS Tug Management Positioning System
TMS Tether Management System
T Peak period
T Planned operational Period (without contingencies, T )
TPR Towline Pull Required
T Operation Reference Period (including contingencies, T )
T Time to safely cease the operation
T Time between weather forecasts
T Zero-up crossing period for waves
UKC Under-Keel Clearance
UKCS United Kingdom Continental Shelf
ULC Ultimate Load Capacity
ULS Ultimate Limit State
UNCLOS United Nations Law of the Sea
USBL Ultra Short Baseline Array
UT Ultrasonic Testing
UTM Universal Transverse Mercator
UXO Unexploded Ordnance
VIV Vortex Induced Vibration
VLA Vertical Load Anchors
WF Weather Forecast
WHA Wind Heeling Arm
W Lower bound design weight
WLL Working Load Limit
WMO World Meteorological Organisation
WROV Work class Remotely Operated Vehicle
Wrt with respect to
WSD Working Stress Design (effectively the same as ASD)
WTG Wind Turbine Generator
W Upper bound design weight
SECTION 2 Planning and execution
2.1 Introduction
2.1.1 Scope
e eff
p
POP C
R C
safe
WF
z
ld
ud
Page 29 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2.1.1.1
This Section includes the general requirements for planning, organization, execution and documentation of
marine operations.
2.1.2 Revision history
2.1.2.1
This section replaces the following parts of the VMO Standard and the ND Guidelines:
• DNV-OS-H101
• 0001/ND.
2.2 General project requirements
2.2.1 Project organisation
2.2.1.1
An appropriate Project organisation chart shall be set up, illustrating how the marine operations integrate with
the rest of the project.
2.2.1.2
All project interfaces between (key) contractors shall be clearly defined.
2.2.1.3
For organisation during the marine operation see [2.8].
2.2.2 Health, safety and environment
2.2.2.1
Personnel safety shall be duly considered throughout the marine operation(s). This subject shall be managed by
the client or his nominated contractor in accordance with local jurisdiction, as well as appropriate guidelines and
specifications regarding health, safety and the environment (HSE).
Guidance note:
By following the recommendations in this Standard it is assumed that the safety of personnel and an acceptable
working environment are ensured in general during the operations. However, specific personnel safety issues
are not covered.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.2.3 Jurisdiction
2.2.3.1
Marine operations are subject to national and international regulations and standards on personnel safety and
protection of the environment. It should also be noted that a marine operation can involve more than one
nation’s area of jurisdiction, and that for barges and vessels the jurisdiction of the flag state will apply.
Documented relevant regulatory approval is a prerequisite to MWS approval.
2.2.3.2
If a part of the marine operations is to be carried out near other facilities or their surroundings any safety zone(s)
defined by the owner shall be duly considered.
2.2.4 Quality assurance and administrative procedures
2.2.4.1
A quality management system in accordance with the current version of ISO 9001, /106/, or equivalent should be
adopted by the designer(s) and installation contractor(s) and be in place.
Page 30 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2.2.5 Technical procedures
2.2.5.1
Technical procedures shall be in place to control engineering related to the marineactivities.
2.2.5.2
The technical procedures shall consider the planning and design process. For this process it is recommended
that the following sequence is adopted:
a. Identify relevant and applicable regulations, rules, company specifications, codes and standards, both
statutory and self-elected.
b. Identify physical limitations. This may involve pre-surveys of structures, local conditions and soil
parameters.
c. Plan the overall operation i.e. evaluate operational concepts, available equipment, limitations, economic
consequences, etc.
d. Describe/define unambiguously with adequate detailing the design basis and main assumptions, see
[2.2.7].
e. Carry out engineering and design analyses.
f. Develop operation procedures.
2.2.5.3
The procedures shall include sufficient information to ensure agreement and uniformity on all relevant matters
such as:
a. International and national standards and legislation
b. Certifying authority/regulatory body standards
c. Marine warranty survey company standards and guidelines
d. Project criteria
e. Design basis
f. Metocean criteria
g. Calculation procedures
h. Change management.
Guidance note:
It will also normally be applicable to include requirements to assure compliance, where relevant, with any
peer-reviewed best industry practice, e.g. IMCA, MTS, GOMO, NORSOK, etc.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.2.6 New technology
2.2.6.1
Design and planning of marine operations shall as far as feasible be based on well proven principles, techniques,
systems and equipment.
2.2.6.2
If new technology or existing technology in a new environment is used, this technology should be documented
through an acceptable qualification process, e.g. in DNV-RP-A203, /45/.
2.2.7 Design basis and design brief
2.2.7.1
A design basis and/or a design brief shall be developed and provided for early acceptance in order to obtain a
common basis and understanding for all parties involved during design, engineering and verification.
2.2.7.2
The Design Basis should describe the basic input parameters, main assumptions, characteristic environmental
conditions, characteristic loads/load effects, load combinations and load cases, including those for the proposed
marine operations.
Page 31 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2.2.7.3
The Design Brief(s) should describe the planned verification activities, analysis methods, software tools, input
specifications, acceptance criteria, etc.
2.3 Technical documentation
2.3.1 General
2.3.1.1
Fulfilment of all the requirements in this Standard applicable for the considered marine operation(s) shall be
properly documented. Guidance on required documentation is given throughout this Standard. However, it shall
always be thoroughly evaluated if additional documentation is required.
2.3.1.2
A document plan describing document hierarchy, issuance schedule and scope for each document should be
provided for major marine operations/projects.
Guidance note:
Normally this will be in the form of MDR(s) that are distributed for review/mark-up by involved parties including
the MWS Company.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.3.1.3
A system/procedure ensuring that all required documentation is produced in due time and distributed
according to plan, should be implemented.
2.3.1.4
It shall be ensured that all the documentation pertaining to a specific marine operation has been accepted by
Authorities, Company, other Contractors and MWS, as relevant, before any operation starts.
2.3.2 Documentation required
2.3.2.1
The design basis shall be clearly documented, see [2.2.7].
2.3.2.2
Environmental conditions for the actual area shall be documented by reliable statistical data, see Sec.3.
2.3.2.3
The acceptability of the following shall be documented: the object, all equipment, temporary or permanent
structures, vessels, etc. involved in the operation. Recognized certificates (e.g. classification documents) are
normally acceptable as documentation if the basis for certification is clearly stated and complies with the
philosophy and intentions of this Standard.
Guidance note 1:
By basis for certification it is meant acceptance standard, basic assumptions, design loads, including dynamics,
limitations, etc. For items without certificates see [2.3.2.4].
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 2:
Note that all elements of the marine operation should be properly documented. This also includes onshore
facilities such as quays, bollards and foundations.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Page 32 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2.3.2.4
Design calculations/analysis shall be documented by design reports and drawings.
2.3.2.5
The condition of all involved equipment, structures and vessels shall be documented as acceptable by means of
certificates and test, survey and NDT reports.
Guidance note:
For vessels, such documentation may be recent inspections to acceptable industry standards, e.g. OVID or
CMID, provided all relevant non-conformances are closed out. See also [2.11.2].
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.3.2.6
Operational aspects shall be documented in form of operation manuals and records.
2.3.2.7
Relevant qualifications of key personnel shall be documented.
2.3.2.8
Required 3 Party verification, e.g. to fulfil the warranty clause, shall be properly documented. See also [2.4.4].
2.3.3 Documentation quality and schedule
2.3.3.1
An integrated document numbering system for the entire project is suggested, including documents produced
by client, contractors, sub-contractors and vendors.
2.3.3.2
Documents relating to marine operations should be grouped into levels according to their status, for example:
a. Criteria and design basis documents
b. Procedures and operations manuals
c. Supporting documents, including engineering calculations, systems operating manuals and equipment
specifications and certificates.
2.3.3.3
The documentation shall demonstrate that philosophies, principles and requirements of this Standard are
complied with. This documentation shall be provided to the MWS Company.
Guidance note:
The operation and document type dictates the level of review by the MWS company. The following terms have
been used as an indication of the level of detail:
• Documented – An in-depth document that is subjected to a detailed review by the MWS company e.g.
analysis reports, procedures and operation manuals
• Submitted – A document that is provided to the MWS company in advance where the checking is limited
e.g. a certificate to confirm that piece of equipment has the required capacity. In some cases this could be
immediately prior to the operation but this may lead to delays if the documents are incorrect and/or
insufficient.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.3.3.4
Documentation for marine operations shall be self-contained, or clearly refer to other relevant documents.
2.3.3.5
The quality and details of the documentation shall be such that it allows for independent reviews of plans,
procedures and calculations, for all parts of the operation.
rd
Page 33 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2.3.3.6
All significant updates shall be clearly identified in revised documents.
2.3.3.7
The document schedule shall allow for the required (agreed) time for independent reviews.
Guidance note:
The time available for review should be at least 10 working days, and more for complex documents.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.3.4 Input documentation
2.3.4.1
Applicableinput documentation, such as;
• documents covering the aspects described in [2.2.5],
• relevant parts of contractual documents,
• concept descriptions,
• basic/FEED engineering results,
• environmental studies including weather window analysis for weather restricted operation.
should be identified before any detailed design work is performed.
2.3.5 Output documentation
2.3.5.1
Documentation shall be prepared to prove that all relevant design and operational requirements are fulfilled.
Typical output documentation is:
a. Planning documents including design briefs and basis, schedules, concept evaluations, general
arrangement drawings and specifications.
b. Design documentation including motion analysis, load analysis, global strength analysis, local design
strength calculations, stability and ballast calculations and structural drawings.
c. Operational manuals/procedures, see [2.3.7] and [2.9.5].
d. Operational records, see [2.3.8].
2.3.6 Availability of technical documentation
2.3.6.1
All relevant documentation shall be available and accessible on site or on board during execution of the
operation. In addition to the marine operations manual this should include the documents referenced therein.
2.3.6.2
The top level procedure document should define the On-Scene Commander in the event of an emergency
situation and the interfaces between the various parties involved.
2.3.6.3
Vessel and equipment certificates and NDT reports shall be submitted. See [B.1] and [B.2] for the information
that is typically required.
Guidance note:
In order to avoid possible delays due to unacceptable or incomplete documentation, it is recommended that
such documentation is submitted for review as soon as possible.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.3.6.4
Procedure documents, intended to be used as an active tool during marine operations should include a section
which clearly shows their references to higher and lower level documents, and should list all inter-related
documents.
Guidance note:
Page 34 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
A document organogram is often helpful as shown in Figure 2-1.
Figure 2-1 Example of document organogram
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Page 35 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2.3.7 Marine operation manuals
2.3.7.1
An operational procedure shall be developed for the planned operation, and shall reflect characteristic
environmental conditions, physical limitations, design assumptions and tolerances.
Guidance note:
For complex operations it is recommended that a high level presentation of the marine operation is made
available as an animation or picture series. See also 2.8.3.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.3.7.2
The operational procedures shall be described in a marine operation manual covering all aspects of the
operation and should include the following, as applicable:
a. reference documents
b. general arrangement
c. permissible load conditions
d. outline execution plan
e. organogram and lines of command
f. job-descriptions for key personnel
g. safety plan, see [2.3.7.5]
h. authorities and permits including notification and approval requirements
i. contractual approvals and hand over, see also [2.3.7.4]
j. environmental criteria, including design and operational criteria
k. weather (forecast) and current/wave reporting
l. operational bar chart, showing the anticipated duration of each activity, inter-related activities, key
decision points, hold points
m. specific step-by-step instructions (procedures/task plans) for each phase of the operation including
sequence, timing, resources and check lists
n. reference to related drawings and calculations, e.g. environmental loads, moorings, ballast, stability,
bollard pull
o. permissible draughts, trim, and heel and corresponding ballasting plan
p. how to handle any changes in the procedure during the operation, see also 2.2.5.3 h).
q. contingency and emergency plans
r. emergency preparedness bridging document
s. monitoring during the operation, see [2.9.5]
t. clearances and tolerances
u. systems and equipment including layout
v. systems and equipment operational instructions
w. vessels involved
x. tow routes and ports of refuge
y. navigation
z. safety equipment
aa. recording and reporting routines
ab. sample forms
ac. equipment operation history
ad. check lists for preparation and performance of the operation.
2.3.7.3
Operational limiting criteria for marine operations or parts thereof shall be clearly stated in the Manual.
2.3.7.4
The Manual shall describe the decision point for issuing the CoA from the MWS company. It may also be found
relevant to include (other) “gates” at which agreement from representatives of the principal parties involved
should be obtained before continuing to next stage of operation.
2.3.7.5
A safety plan shall be included in the operation manual. This plan consists of the safety rules that apply to
minimise the following risks encountered during each operation:
a. Risks inherent from the metocean conditions
b. Risks incurred by construction, transport, installation and commissioning activities
c. Risks to the environment
Page 36 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
d. Risks due to simultaneous operations (SIMOPS) – see IMCA M 203, /83/
e. Risks due to working on live assets, etc.
2.3.7.6
Essential documentation in the form of certificates, release notes and classification documents for all equipment
and vessels involved in the marine operation shall be enclosed and/or listed in the Manual. See also 2.3.6.3.
2.3.8 Operation records and reporting
2.3.8.1
The execution of marine operations shall be logged. Recording form templates shall be included in the marine
operations manual.
2.3.8.2
The following should as a minimum be recorded during the operation:
a. log of (main) tasks carried out
b. any modifications in the agreed procedure
c. unexpected events and any deviations from or alterations of procedure imposed by such
d. environmental conditions and
e. critical monitoring results.
2.3.8.3
Any significant modifications in the agreed procedure shall be reported promptly to the MWS Company.
Guidance note:
It is recommended that all changes to previously agreed/approved procedures are signed off by the principal
representatives of the parties involved. See also [2.3.7.2 p)], and that this is described in the MOC procedure.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.3.8.4
For larger projects, communications to the client (and MWS company) on site should be confirmed in writing,
e.g. by daily reports.
2.3.8.5
Regular, at least daily, reports shall be issued to MWS company from operations (e.g. towage) where the MWS
company is not attending.
2.3.8.6
Any incidents, accidents or near-misses relevant to the safety of the structure or future marine operations shall be
reported to MWS company.
2.4 Risk management
2.4.1 General
2.4.1.1
Risk management shall be applied to the project to reduce the overall risk. The preferred approach is to address
the following:
a. Identification of potential hazards
b. Preventative measures to avoid hazards wherever possible
c. Controls to reduce the potential consequences of unavoidable hazards
d. Mitigation of the consequences, should hazards occur.
2.4.1.2
The overall responsibility for risk management shall be clearly defined when planning marine operations.
Page 37 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Guidancenote:
It is recommended that risk management is performed according to DNV-RP-H101, /54/, in order to ensure a
systematic evaluation and handling of risk. It is also a premise for a successful risk management that a project
team with sufficient competence to understand the marine operation and the potential risk/hazard is mobilized,
see [2.8].
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.4.1.3
Risk evaluations shall be carried out at an early stage for all marine operations in order to define the extent of risk
management required, and to identify and mitigate risk as early in the design process as possible.
Guidance note 1:
The type and amount of risk evaluations should be based on the complexity of each marine operation. DNV-RP-
H101, /54/, Appendix D.5 gives advice on how to carry out initial risk evaluations. The effect of (planned)
redundancy, back-up, safety barriers, and emergency procedures should be taken into account in the (initial) risk
estimates. Contingency situations with a documented (joint) probability of occurrence less than 10-4 per
operation may be disregarded.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 2:
Ideally, each of the various studies outlined should be managed by a competent independent person familiar
with the overall concept, but outside the team carrying out the relevant system or structure design or operational
management.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.4.1.4
Risk assessments shall be documented and the mitigated risks accepted by the MWS company.
2.4.1.5
Detailed hazard studies should include the personnel and organisations involved in the design of structures and
systems, as well as those involved in the marine operation and the MWS company. The studies shall be
performed for:
a. Each major marine operation.
b. Each major system essential to the performance and safety of marine operations. For example, the power
generation and the ballast and compressed air systems.
Guidance note:
Hazard identification activities (see [2.4.2]) may be used to systematically evaluate risk applicable to any
operation, to compare levels of risk between alternative proposals or between known and novel methods,
and to enable rational choices to be made between alternatives.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.4.2 Hazard identification activities
2.4.2.1
Risk identification techniques and methods shall be used as applicable for the intended operation. Examples of
applicable techniques and methods are:
a. Preliminary risk assessment in order to assess concepts and methods
b. Hazard Identification Analysis (HAZID)
c. Early Procedure Hazard and Operability study (EP HAZOP)
d. Hazard Identification and Risk Assessment (HIRA)
e. Design Review (DR)
f. System HAZOP
g. Failure Mode Effect (and Criticality) Analysis (FMEA/FMECA)
h. Procedure HAZOP
i. Semi-Quantitative Risk Analysis (SQRA)
j. Safe Job Analysis (SJA) / Job Safety Analysis (JSA).
Guidance note:
DNV-RP-H101, /54/, Appendix B defines and describes most of the risk identifying activities listed above in
detail. The HAZOP is not only focused on possible hazards, but also on issues related to the operability of
an activity or operation, the plant or system, including possible improvements.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Page 38 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2.4.2.2
All identified possible hazards shall be reported and properly managed.
2.4.3 Risk reducing activities
2.4.3.1
Relevant corrective actions from the risk identifying activities shall be implemented in the planning and execution
of the operations.
2.4.3.2
The following risk reducing activities for marine operations shall be used as applicable for the intended
operation:
a. Operational feasibility assessments
b. Document verification
c. Familiarisation
d. Personnel safety plans
e. Emergency preparedness
f. Marine readiness verification
g. Inspection and testing
h. Survey of vessels
i. Toolbox talk
j. Safe Job Analysis / Job Safety Analysis
k. Survey of operations.
Guidance note:
DNV-RP-H101, /54/, Appendix C describes the above listed risk reducing activities in detail. Note that Safe
Job Analysis is in DNV-RP-H101, /54/, mentioned only in Appendix B - Hazard Identification Activities.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.4.4 3 party verification and MWS
2.4.4.1
As a part of the risk management the requirements for 3 Party verification of calculations, procedures, vessels,
equipment, etc. and survey of the operations shall be defined.
2.4.4.2
If applicable a Marine Warranty Survey company shall be contracted to ensure that the marine warranty clause is
fulfilled.
2.4.4.3
It shall be ensured that the MWS (marine warranty survey) Company’s (minimum) scope of work has been
adequately defined to fulfil the intention of the marine warranty clause. Specific requirements of warranty clause
to be given to MWS as early as possible.
2.4.4.4
Thorough knowledge of this Standard shall be documented in order to carry out marine warranty survey with the
intention of confirming compliance with this Standard.
2.5 Planning of marine operations
2.5.1 Philosophy
2.5.1.1
Marine operations shall be planned according to safe and sound practice, and according to defined codes and
rd
rd
Page 39 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
standards.
2.5.1.2
A marine operation shall be designed to bring an object from one defined safe condition to another.
Guidance note:
“Safe Condition” is defined as a condition where the object is considered to be exposed to a normal level of risk
of damage or loss (i.e. the risk is similar to that expected for the in-place condition). Normally this will imply a
(support) condition for which it is documented that the object fulfils the design requirements applying the
relevant weather unrestricted, see [2.6.6], environmental loads.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.5.1.3
Risk management, see [2.4], should normally be included in the planning.
2.5.2 Type of operation
2.5.2.1
To define the (sub-) operations as either weather unrestricted or weather restricted can have a great impact on
the safety and cost of the operation. Hence, the type of operation should, if possible, be defined early in the
planning process. See also [2.6.5].
2.5.2.2
The planning and design of marine operations should normally be based on the assumption that it can be
necessary to halt the operation and bring the object to a safe condition e.g. by reversing the operation.
2.5.2.3
For operations passing a point where the operation cannot be reversed, a point of no return (PNR) shall be
defined. The first safe condition after passing a PNR shall be defined and considered in the planning.
2.5.3 Operations in ice areas
2.5.3.1
The risk of significant ice shall be considered in the operation planning. I.e. operations in ice areas should be
subject to suitable ice management operations, details of which appear in [B.3].
2.5.3.2
Towages in ice are considered in [11.19] and voyages in [K.11].
2.5.3.3
The evacuation from rigs/offshore structures in ice shall be properly planned.
Guidance note:
ISO 19906, /103/ Clause 18 and Annex A.18 provide appropriate normative requirements and informative
guidance for escape, evacuation and rescue (EER) operations from Arctic offshore structures.
Additional guidance on the design of an appropriate EER system may be found in DNVGL Barents 2020
(2012), /21/, Chapter 4. This includes performance standards for emergency response vessels and guidance for
Arctic evacuation methods.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.5.4 Contingency and emergency planning andprocedures
2.5.4.1
All possible emergency situations shall be identified, and contingency procedures or actions shall be prepared
for these situations.
Guidance note:
Page 40 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Foreseeable emergencies and contingencies can include:
a. Severe weather
b. Planned precautionary action in the event of forecast severe weather
c. Structural parameters approaching pre-set limits
d. Stability parameters approaching pre-set limits
e. Failure of mechanical, electrical or control systems
f. DP or power failure "black ship"
g. Fire
h. Collision, grounding
i. Leakage, flooding
j. Pollution
k. Structural failure
l. Equipment failure
m. Mooring failure
n. Icebergs, excessive ice (see also [2.5.3.3])
o. Human error
p. Man overboard
q. Personnel accidents or medical emergencies
r. Terrorism and sabotage.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.5.4.2
Possible emergency situations to be considered may be defined or excluded based on conclusions from risk
identifying activities, see [2.4.2].
2.5.4.3
Contingency and emergency planning shall consider redundancy, back-up equipment, supporting personnel,
emergency procedures and other relevant preventive measures and actions.
2.5.4.4
The contingency procedures should form part of the operational procedures.
2.6 Operation and design criteria
2.6.1 Introduction
2.6.1.1
Marine operations shall be executed ensuring that the assumptions made in the planning and design process are
fulfilled.
2.6.1.2
Marine operations shall be classified as weather restricted or as weather unrestricted (see [2.6.5]).
Guidance note:
The main difference between these operations is how the environmental loads are selected. See Table 5-1.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.6.2 Operation reference period - T
2.6.2.1
The duration of marine operations shall be defined by an operation reference period, T :
T = T +T
where
T = Operation reference period
T = Planned operation period
T = Estimated maximum contingency time.
R
R
R POP C
R
POP
C
Page 41 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2.6.2.2
The start and completion points for the intended operation or parts of the operation shall be clearly defined. See
also [2.6.7.3] and [2.6.7.4].
2.6.3 Planned operation period – T
2.6.3.1
The planned operation period, T , shall if possible be based on a detailed schedule for the operation.
Guidance note:
In cases (e.g. in the early planning phase) were a detailed schedule is not available T can be based on
experience with similar operations.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.6.3.2
The time estimated for each task in the schedule should be based on a reasonably conservative assessment of
experience with same or similar tasks.
Guidance note:
Normally a probability of (maximum) 10-20% of exceeding T during the actual operations should be aimed at.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.6.3.3
Time delaying incidents that are experienced frequently should be included in T .
2.6.4 Estimated contingency time – T
2.6.4.1
Contingency time, T , shall be added to cover:
a. General uncertainty in the planned operation time, T
b. Unproductive time during the operation, e.g. to solve unforeseen procedural problems
c. Possible contingency situation(s), see [2.5.3], that will require additional time to complete the operation.
Guidance note:
It is normally not necessary to add the estimated additional time from several (two) rare independent
contingency situations. However, it can be relevant to consider that more than one of the frequently
experienced incidents mentioned in [2.6.3.3] (e.g. equipment malfunction) may occur.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.6.4.2
If T uncertainties and the required time for contingency situations is not assessed in detail the operation
reference period should normally be taken to be at least twice the planned operation period, i.e.T  ≥ 2 × T .
Guidance note:
A contingency time T of 50% of T can normally be accepted for:
• Operations with an extensive experience basis from similar operations, e.g. positioning (anchoring) of
MOUs.
• Towing operations with redundant tug(s) and properly assessed towing speed, see Sec.11 for more
information.
• Repetitive operations where T has been accurately defined based on experience with the actual
operation and vessel.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.6.4.3
A contingency time T less than 6 hours is normally not acceptable unless thoroughly documented.
Guidance note:
T < 6 hours is unlikely to be acceptable except for short simple marine operations involving only robust
equipment.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
POP
POP
POP
POP
POP
C
C
POP
POP
R POP
C POP
POP
C
C
Page 42 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2.6.5 Weather unrestricted and restricted operations
2.6.5.1
An operation shall be defined as weather unrestricted, see [2.6.6], or weather restricted, see [2.6.7]. See [2.5.2]
and Figure 2-2 for further guidance.
2.6.5.2
Operations with a duration that is too long to be planned as weather restricted, see [2.6.7.1], may still be defined
as weather restricted if a continuous surveillance of actual and forecasted weather conditions is implemented,
and the operation can be halted and the object brought into a safe condition within the maximum allowable
period for a weather restricted operation. See flowchart in Figure 2-2.
Guidance note:
The indicated maximum allowable period for a weather restricted operation, as per [2.6.7.1], is a theoretical
value. For most continuous operations a considerably shorter period should be documented in order to make
the operation feasible without risking too much delay.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Figure 2-2 Flow chart to determine whether an operation is weather restricted or weather unrestricted
2.6.6 Weather unrestricted operations
2.6.6.1
Marine operations that cannot be defined as weather restricted (see [2.6.5] and [2.6.7]) shall be defined as
weather unrestricted operations. Environmental criteria for these operations should be based on extreme value
statistics, see Sec.3. If found beneficial, operations of shorter duration may also be defined as weather
unrestricted.
Guidance note:
A reduction in the weather criteria based on extreme value statistics could in some situations be acceptable
Page 43 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
based on active use of the (long term) weather forecast. Such typical situations are:
• Operations in areas and seasons where it has been shown and documented that the long term weather
forecasts can predict any extreme weather conditions within the defined T for the operation.
• Open (Ocean) voyages where the vessel speed is sufficient to avoid extreme weather conditions.
Such a reduction in the design criteria may be accepted by the MWS company, but normally an accidental load
case (ALS) considering extreme value statistics should be included.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.6.6.2
For operations where the design environmental condition is based on extreme value statistics, the forecasted
operational limiting criteria may theoretically be taken equal to the design environmental condition. However, it
is normally not recommended that an operation is started if extreme weather conditions are expected, and a
start criterion may apply.
Guidance note:
Note that certain operations require a start criterionalthough designed for weather unrestricted conditions.
Further information is given for the respective operations in this Standard.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.6.7 Weather restricted operations
2.6.7.1
Marine operations with a reference period (T ) less than 96 hours and a planned operation time (T ) less than
72 hours may normally be defined as weather restricted. However, in areas and/or seasons where the duration of
the reliable weather forecast is less than 96 hours, the maximum allowable T is the duration of the reliable
forecast.
Guidance note:
The above indicated limits for T and T define the maximum allowable period for a weather restricted
operation.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.6.7.2
A weather restricted operation shall be planned to be executed within a reliable weather window, see Figure 2-3.
2.6.7.3
The planned operation period start point for a weather restricted operation shall normally be defined as being at
the issuance of the last weather forecast. See Figure 2-3.
Figure 2-3 Operation Periods
2.6.7.4
The operation shall only be considered completed when the object is in a safe condition, see [2.5.1.2].
R
R POP
R
R POP
Page 44 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2.6.7.5
Restricted operations may be planned with design environmental conditions selected independent of statistical
data, i.e. set by owner, operator or contractor.
Guidance note:
If the weather restricted design environmental condition is too low, severe waiting on weather delays can occur.
The design environmental condition should be selected based on an overall evaluation of operability i.e. there
should be an acceptable probability of obtaining the required weather window. See also [3.3].
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.6.7.6
The start of a weather restricted operation is conditional on an acceptable weather forecast, see [2.7.3].
2.6.7.7
Operations that could be carried out within the maximum allowed period may be planned with (possible) stops
in (case of) periods with weather conditions above the OP . The following shall be taken into account:
a. Increased risk for halting (and re-starting) due to additional operations.
b. Increased risk due to the nature of the “temporary” safe position of the object.
c. Increased weather risk due to an increased total operation period.
2.6.7.8
If the planning indicated in [2.6.7.7] is implemented the Alpha (α) factors shall be adjusted accordingly, e.g.:
• Depending on the risk evaluations in [2.6.7.7 b)] and [2.6.7.7 c)] it may be applicable to reduce the Alpha
factor for the final stage of the operation due to an increased total operation period.
• If no significant increased risk is identified due to [2.6.7.7 a)] and [2.6.7.7 b)] alpha factor(s) according to
[2.6.9.3] applies.
2.6.8 Operational limiting criteria
2.6.8.1
Operational limiting environmental criteria (OP ) shall be established and clearly described in the marine
operation manual.
2.6.8.2
The OP shall not be taken greater than the minimum of:
• The environmental design criteria. See [3.3].
• Maximum wind and waves for safe working and object handling (e.g. on vessel deck) or transfer conditions
for personnel.
• Weather restrictions for equipment (e.g. ROV and cranes).
Guidance note:
Weather restrictions for equipment should be based on specified limitations if available. They may also be
assessed and/or refined based on items as criticality, back-up equipment and contingency procedures.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
• Limiting weather conditions of diving system (if any).
• Limiting conditions for position keeping systems.
• Any limitations identified, e.g. in HAZID/HAZOP, based on operational experience with involved vessel(s),
equipment, tools, etc.
• Limiting weather conditions for carrying out identified contingency plans.
2.6.9 Forecasted and monitored operational limits, alpha factor (α)
2.6.9.1
Uncertainty in both the monitoring and the forecasting of the environmental conditions shall be considered. This
should be done by defining a forecasted (and, if applicable, monitored at the operation start) operational criteria
- OP , defined as OP  = α × OP .
Guidance note:
LIM
LIM
LIM
WF WF LIM
Page 45 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
To ensemble weather forecasts which identify the expected ‘spread’ of weather conditions and assess the
probability of particular weather events could be an alternative for applying the tabulated alpha factors. Such
weather forecasts will anyhow give useful additional information to evaluate uncertain weather situations. Further
description of ensemble forecasting is in [B.4].
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.6.9.2
The planned operation period (T , see [2.6.3]) from issuance of the weather forecast to the operation is
completed shall be used as the minimum time for selection of the Alpha Factor. See Figure 2-3.
2.6.9.3
For operations that can be halted, see [2.6.5.2], the Alpha Factor can normally be selected based on a T
defined as the time between weather forecasts plus the required time to safely cease the operation and bring the
handled object into a safe condition. If a proper procedure based on continuously reliable (see [2.9.3])
monitoring readings, is established the time between weather forecasts can normally be disregarded in the
estimation of T . However, the maximum expected reaction time from monitoring readings above OP to
initiation of ceasing of the operation, shall be included in T . A reaction time below 2 hours should normally not
be considered.
2.6.9.4
The following should be used as guidelines for selecting the appropriate Alpha Factor for waves:
a. The expected uncertainty in the weather forecast should be calculated based on statistical data for the
actual site and the operation schedule, i.e. T . The Alpha Factor should be calibrated to ensure that the
probability of exceeding the operational environmental limiting criteria (OP ) by more than 50% in LRFD
(see [2.6.11]) is less than 10 .
b. Reliable wave and/or vessel response monitoring system(s) and applied weather forecast level, see [2.7.2],
could be taken into account.
2.6.9.5
Special considerations should be made regarding uncertainty in the wave periods i.e. if the operation is
particularly sensitive to some wave periods (e.g. swell), the uncertainty in the forecasted wave periods shall also
be considered.
2.6.10 Selection of alpha factors
2.6.10.1
The (tabulated) Alpha Factor(s) shall be selected based on:
• The applicable table, see [2.6.10.4] and Table 2-1
• Operational limiting criteria, OP , see [2.6.8]
• The planned operational period, T , see [2.6.9.2]
2.6.10.2
The Alpha Factor could be assumed to vary in time for one operation, e.g. for an operation with T = 36 hours,
H = 4.0 m, the Alpha Factor is 0.79 for the first 12 hours, 0.76 for the next 12 hours and 0.73 for the last 12 hours
of the operation.
2.6.10.3
Design wave heights less than one (1) meter are normally not applicable for offshore operations. If a smaller
design wave height nevertheless has been applied the Alpha Factor should be duly considered in each case.
2.6.10.4
In the North Sea and the Norwegian Sea the Alpha Factor table to be used shall be selected using Table 2-1
considering the applied weather forecast (WF) level, see [2.7.2], applicable environmental monitoring, see
[2.9.3], and design method (LRFD or ASD/WSD).
2.6.10.5
POP
POP
POP WF
POP
POP
LIM
-4
LIM
POP
POP
s
Page 46 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...The uncertainty in forecasted and actual weather conditions shall be considered also in other offshore areas than
mentioned in 2.6.10.4. If reliable data is not available to establish alpha factors, see 2.6.9.4, the approach in
2.6.10.4 should also be used for other areas.
Guidance note:
The tabulated Alpha Factors are based on the work performed in a Joint Industry Project during the years 2005-
2007 with the aim to establish a revised set of α-factors for European waters. For details of the JIP see DNV
Report 2006_1756 Rev. 03, “DNV Marine Operation Rules, Revised Alpha Factor JIP Project”.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Table 2-1 Selection of Alpha Factor table(s)
WF level A1 A2 & B C
Environmental monitoring? Yes No Yes No Yes No
Wave Alpha Factor – LRFD Table 2-7 Table 2-6 Table 2-5 Table 2-4 Table 2-3 Table 2-2
Wave Alpha Factor –
ASD/WSD
Table
2-14
Table
2-13
Table
2-12
Table
2-11
Table
2-10
Table 2-9
Wind Alpha Factor – LRFD Table 2-8
Wind Alpha Factor –
ASD/WSD
Table 2-15
2.6.11 Tabulated alpha factor – LRFD method
2.6.11.1
The Alpha Factor for waves applying LRFD, see [5.9.8], shall be selected according to Table 2-1 and are given in
Table 2-2 through Table 2-7. Values for wind are in Table 2-8.
Table 2-2 LRFD Alpha Factor for waves, Level C – No Environmental Monitoring
Planned
Operation
Period [h]
Operational limiting (OP ) significant wave height [m]
H = 1 1 < H < 2 H = 2 2 < H < 4 H = 4 4 < H < 6 H ≥6
T ≤ 12 0.65
Linear
Interpolation
0.76
Linear
Interpolation
0.79
Linear
Interpolation
0.80
T ≤ 24 0.63 0.73 0.76 0.78
T ≤ 36 0.62 0.71 0.73 0.76
T ≤ 48 0.60 0.68 0.71 0.74
T ≤ 72 0.55 0.63 0.68 0.72
Table 2-3 LRFD Alpha Factor for waves, Level C – With Environmental Monitoring
Planned
Operation
Period [h]
Operational limiting (OP ) significant wave height [m]
H = 1 1 < H < 2 H = 2 2 < H < 4 H = 4 4 < H < 6 H ≥6
T ≤ 4 0.90
Linear
Interpolation
0.95
Linear
Interpolation
1.00
Linear
Interpolation
1.00
T ≤ 12 0.72 0.84 0.87 0.88
T ≤ 24 0.66 0.77 0.80 0.82
T ≤ 36 0.62 0.71 0.73 0.76
T ≤ 48 0.60 0.68 0.71 0.74
T ≤ 72 0.55 0.63 0.68 0.72
Table 2-4 LRFD Alpha Factor for waves, Level A2 or B – No Environmental Monitoring
Planned
Operation
Period [h]
Operational limiting (OP ) significant wave height [m]
H = 1 1 < H < 2 H = 2 2 < H < 4 H = 4 4 < H < 6 H ≥6
T ≤ 12 0.68 Linear 0.80 Linear 0.83 Linear 0.84
LIM
s s s s s s s
POP
POP
POP
POP
POP
LIM
s s s s s s s
POP
POP
POP
POP
POP
POP
LIM
s s s s s s s
POP
Page 47 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
T ≤ 24 0.66
Interpolation
0.77
Interpolation
0.80
Interpolation
0.82
T ≤ 36 0.65 0.75 0.77 0.80
T ≤ 48 0.63 0.71 0.75 0.78
T ≤ 72 0.58 0.66 0.71 0.76
Table 2-5 LRFD Alpha Factor for waves, Level A2 or B – With Environmental Monitoring
Planned
Operation
Period [h]
Operational limiting (OP ) significant wave height [m]
H = 1 1 < H < 2 H = 2 2 < H < 4 H = 4 4 < H < 6 H ≥6
T ≤ 4 0.90
Linear
Interpolation
0.95
Linear
Interpolation
1.00
Linear
Interpolation
1.00
T ≤ 12 0.72 0.84 0.87 0.88
T ≤ 24 0.66 0.77 0.80 0.82
T ≤ 36 0.65 0.75 0.77 0.80
T ≤ 48 0.63 0.71 0.75 0.78
T ≤ 72 0.58 0.66 0.71 0.76
Table 2-6 LRFD Alpha Factor for waves, Level A1 – No Environmental Monitoring
Planned
Operation
Period [h]
Operational limiting (OP ) significant wave height [m]
H = 1 1 < H < 2 H = 2 2 < H < 4 H = 4 4 < H < 6 H ≥6
T ≤ 12 0.72
Linear
Interpolation
0.84
Linear
Interpolation
0.87
Linear
Interpolation
0.88
T ≤ 24 0.69 0.80 0.84 0.86
T ≤ 36 0.68 0.78 0.80 0.84
T ≤ 48 0.66 0.75 0.78 0.81
T ≤ 72 0.61 0.69 0.75 0.79
Table 2-7 LRFD Alpha Factor for waves, Level A1 – With Environmental Monitoring
Planned
Operation
Period [h]
Operational limiting (OP ) significant wave height [m]
H = 1 1 < H < 2 H = 2 2 < H < 4 H = 4 4 < H < 6 H ≥6
T ≤ 4 0.90
Linear
Interpolation
0.95
Linear
Interpolation
1.00
Linear
Interpolation
1.00
T ≤ 12 0.78 0.91 0.95 0.96
T ≤ 24 0.72 0.84 0.87 0.90
T ≤ 36 0.68 0.78 0.80 0.84
T ≤ 48 0.66 0.75 0.78 0.81
T ≤ 72 0.61 0.69 0.75 0.79
2.6.11.2
The appropriate Alpha Factor for wind should be selected (estimated) considering the following:
• Statistical data and local experience for the actual site.
• Planned operation period from issuance of weather forecast, T .
• Applied wind speed compared with the maximum possible wind speed, i.e. 10 year return wind speed.
• Criticality of exceeding the design wind speed, e.g. by considering the contribution from wind on the total
design load.
2.6.11.3
If no reliable data is available the Alpha Factors indicated in Table 2-8 shall be considered as the maximum
allowable.
POP
POP
POP
POP
LIM
s s s s s s s
POP
POP
POP
POP
POP
POP
LIM
s s s s s s s
POP
POP
POP
POP
POP
LIM
s s s s s s s
POP
POP
POP
POP
POP
POP
POP
Page 48 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Table 2-8 LRFD Recommended Alpha Factor for wind
Planned Operation Period
Operational limiting (OP ) wind speed – V
V < 0.5 x V10 year return V > 0.5 x V10 year return
T ≤ 24 0.80 0.85
T ≤ 48 0.75 0.80
T ≤ 72 0.70 0.75
2.6.11.4
The possibility for unpredictable strong wind, e.g. squalls and polar lows, should be duly considered in the
selected Alpha Factor for wind (and if relevant also for waves). Alternatively, if possible, operational contingency
actions that sufficiently reduce the criticality of such wind, could be planned.
2.6.12 Tabulated alpha factor - ASD/WSD method
2.6.12.1
The Alpha factors for waves and wind applicable to the ASD/WSD, see [5.9.7] design approach shall be selected
based on Table 2-1 and are shown in Table 2-2 through Table 2-8. These factors are calibrated for the ASD/WSD
format, with the objective of ensuring that a given structure will be treated equally under ASD/WSD and LRFD.
The Alpha factors for ASD/WSD are therefore lower than the values given in [2.6.11] because the inherent safety
margin in ASD/WSD checks is less than that in LRFD checks, so higher design values are needed to achieve this
equivalence.
Table 2-9 ASD/WSD Alpha Factor for waves, Level C – No Environmental Monitoring
Planned
Operation
Period [h]
Operational Limiting (OP ) significant wave height [m]
H = 1 1 < H < 2 H = 2 2 < H < 4 H = 4 4 < H < 6 H ≥6
T ≤ 12 0.58
Linear
Interpolation
0.68
Linear
Interpolation
0.70
Linear
Interpolation
0.71
T ≤ 24 0.56 0.65 0.68 0.69
T ≤ 36 0.55 0.63 0.65 0.68
T ≤ 48 0.53 0.61 0.63 0.66
T ≤ 72 0.49 0.56 0.61 0.64
Table 2-10 ASD/WSD Alpha Factor for waves, Level C – With Environmental Monitoring
Planned
Operation
Period [h]
Operational Limiting (OP ) significant wave height [m]
H = 1 1 < H < 2 H = 2 2 < H < 4 H = 4 4 < H < 6 H ≥6
T ≤ 4 0.80
Linear
Interpolation
0.85
Linear
Interpolation
0.89
Linear
Interpolation
0.89
T ≤ 12 0.64 0.75 0.77 0.78
T ≤ 24 0.59 0.69 0.71 0.73
T ≤ 36 0.55 0.63 0.65 0.68
T ≤ 48 0.53 0.61 0.63 0.66
T ≤ 72 0.49 0.56 0.61 0.64
Table 2-11 ASD/WSD Alpha factors (waves) - Level A2 or B – No Environmental Monitoring
Planned
Operation
Period [h]
Operational Limiting (OP ) significant wave height [m]
H = 1 1 < H < 2 H = 2 2 < H < 4 H = 4 4 < H < 6 H ≥6
T ≤ 12 0.61 Linear
Interpolation
0.71 Linear
Interpolation
0.74 Linear
Interpolation
0.75
T ≤ 24 0.59 0.69 0.71 0.73
T ≤ 36 0.58 0.67 0.69 0.71
LIM d
d d
POP
POP
POP
LIM
s s s s s s s
POP
POP
POP
POP
POP
LIM
s s s s s s s
POP
POP
POP
POP
POP
POP
LIM
s s s s s s s
POP
POP
POP
Page 49 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
T ≤ 48 0.56 0.63 0.67 0.69
T≤ 72 0.52 0.59 0.63 0.68
Table 2-12 ASD/WSD Alpha Factor for waves, Level A2 or B – With Environmental Monitoring
Planned
Operation
Period [h]
Operational Limiting (OP ) significant wave height [m]
H = 1 1 < H < 2 H = 2 2 < H < 4 H = 4 4 < H < 6 H ≥6
T ≤ 4 0.80
Linear
Interpolation
0.85
Linear
Interpolation
0.89
Linear
Interpolation
0.89
T ≤ 12 0.64 0.75 0.77 0.78
T ≤ 24 0.59 0.69 0.71 0.73
T ≤ 36 0.58 0.67 0.69 0.71
T ≤ 48 0.56 0.63 0.67 0.69
T ≤ 72 0.52 0.59 0.63 0.68
Table 2-13 ASD/WSD Alpha factors (waves) - Level A1 – No Environmental Monitoring
Planned
Operation
Period [h]
Operational Limiting (OP ) significant wave height [m]
H = 1 1 < H < 2 H = 2 2 < H < 4 H = 4 4 < H < 6 H ≥6
T ≤ 12 0.64
Linear
Interpolation
0.75
Linear
Interpolation
0.77
Linear
Interpolation
0.78
T ≤ 24 0.61 0.71 0.75 0.77
T ≤ 36 0.61 0.69 0.71 0.75
T ≤ 48 0.59 0.67 0.69 0.72
T ≤ 72 0.54 0.61 0.67 0.70
Table 2-14 ASD/WSD Alpha factors (waves) - Level A1 – With Environmental Monitoring
Planned
Operation
Period [h]
Operational Limiting (OP ) significant wave height [m]
H = 1 1 < H < 2 H = 2 2 < H < 4 H = 4 4 < H < 6 H ≥6
T ≤ 4 0.80
Linear
Interpolation
0.85
Linear
Interpolation
0.89
Linear
Interpolation
0.89
T ≤ 12 0.69 0.81 0.85 0.85
T ≤ 24 0.64 0.75 0.77 0.80
T ≤ 36 0.61 0.69 0.71 0.75
T ≤ 48 0.59 0.67 0.69 0.72
T ≤ 72 0.54 0.61 0.67 0.70
2.6.12.2
If no reliable data is available the Alpha Factors indicated in Table 2-15 shall be considered as the maximum
allowable in ASD/WSD. See also [2.6.11.2] and [2.6.11.4].
Table 2-15 ASD/WSD Alpha factors (wind - all forecast requirements)
Planned Operation Period
Operational Limiting Wind Speed (V )
V < 0.5 x V10 year return V > 0.5 x V10 year return
T ≤ 24 0.71 0.76
T ≤ 48 0.67 0.71
T ≤ 72 0.62 0.67
POP
POP
LIM
s s s s s s s
POP
POP
POP
POP
POP
POP
LIM
s s s s s s s
POP
POP
POP
POP
POP
LIM
s s s s s s s
POP
POP
POP
POP
POP
POP
d
d d
POP
POP
POP
Page 50 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2.7 Weather forecast
2.7.1 General
2.7.1.1
Arrangements shall be made for receiving weather forecasts at regular intervals before, and during, the marine
operations. Such weather forecasts shall be from recognized sources and be project specific.
Guidance note:
Public domain weather forecast(s) may be found acceptable as Level C forecasting, but the inherent increased
uncertainty should be considered. Applicable Alpha Factors are found by multiplying the factors in Table 2-2
(Table 2-9) and Table 2-15 (Table 2-16) with 0.75.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.7.1.2
Independent weather forecasts shall be taken from different weather providers. The providers shall be different
organizational bodies. Each body shall document which different atmospheric and oceanographic models have
been evaluated and taken into account in the generation of the forecasts.
2.7.1.3
The weather forecasts (WF) shall be area/route specific. For non-stationary marine operations (e.g. sea voyages
or subsea laying operations) it shall be ensured that weather forecasts comprise the position (at the time of the
WF) of the transport vessel/barge and all alternative routes that could be chosen in the period covered by the
weather forecast.
2.7.1.4
Weather forecast procedures should consider the nature and duration of the planned operation, see [2.7.2.1].
2.7.1.5
The weather forecasts shall be in writing and the confidence level(s) should be stated.
2.7.1.6
In addition to a general description of the weather situation and its predicted development, the weather forecast
shall, as relevant, include:
• wind speed and direction
• waves and swell, significant and maximum height, mean or peak period and direction
• rain, snow, lightning, ice etc.
• tide variations and/or storm surge
• visibility
• temperature
• barometric pressure
• possibility for unpredictable strong wind, see [2.6.11.4].
for each 12 hours for a minimum of the T plus 24 hours. In addition an outlook for at least the next 24 hours
should normally be included.
2.7.1.7
The forecast shall clearly define forecasted parameters, e.g. average time and height for wind, characteristic
wave periods (T or T ). The content and format of the weather forecast should be agreed with the meteorologist
in due time before the operation starts.
2.7.2 Weather forecast levels
2.7.2.1
The required weather forecast level shall be selected based on the operational sensitivity to weather conditions
and the operation reference period (T ). The following weather forecast levels are defined in this standard:
• Level A that applies to major marine operations sensitive to environmental conditions.
• Level B that applies to environmental sensitive operations of significant importance with regard to value
R
z p
R
Page 51 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
and consequences
• Level C that applies to conventional marine operations less sensitive to weather conditions, and carried
out on a regular basis.
2.7.2.2
For operations that require a Level A weather forecast it shall be thoroughly considered to have the dedicated
meteorologist present on site. See Table 2-16 for further advice regarding selection of the forecast level and for
requirements to the weather forecast procedure.
Table 2-16 Weather forecast levels
Weather Forecast
Level
A1 A2 B C
Operation
Sensitivity
High Moderate Low
Examples
• mating operations
• offshore float over
• multi barge towing
• major (e.g. GBS) tow out
operations
• offshore installation
operations
• jack-up rig moves.
• sensitive laying
operations
• tow-out
operations
• weather routed
sea transports
• offshore lifting
• subsea
installation
• semi-
submersible rig
moves
• standard laying
operations.
• onshore/inshore
lifting
• load-out operations
• short tows in
sheltered
waters/harbour
tows
• standard sea
transports without
any specified wave
restrictions.
Meteorologist on
site
Yes No No
Dedicated
Meteorologist
Yes Yes No No
Minimum
independent WF
sources
2 2 1
Maximum WF
interval
12 hours 12 hours 12 hours
Notes:
1. See 2.7.1.1 GN.
2. Meteorologist shall be consulted if the weather situation is unstable and/or close to the defined limit.
3. See [2.7.1.2] for definition of independent WF sources.
4. It is assumed that the dedicated meteorologist (and other involved key personnel) will consider weather
information/forecasts from several (all available) sources.
5. The most severe weather forecast shall be used.
6. Based on sensitivity with regards to weather conditions smaller intervals may be required. However, see
[2.7.3.5].
2.7.3 Acceptance criteria
2.7.3.1
The acceptance criteria for the weather forecast(s) shall clearly define the applicable limitations, see [2.6.9] and
the minimum required weather window, see [2.6.2] and Figure 2-3. The acceptance criteria shall be included in
the marine operation manual.
2.7.3.2
If the weather forecasts received from the two sources do not agree the most severe weather forecast should be
considered governing, unless otherwise justified. If the discrepancy between the forecasts is significant the
weather situation should be carefully evaluated to determine whether it is too uncertain to safely start an
operation.
1)
2)
2)
4) 5)
6)
Page 52 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2.7.3.3
Based on the available weather forecasts the weather situation shall be assessed according to a worst case
scenario development. This is particularly important for unstable weather situationsand for forecasts which are
stated (considered) to be of low confidence.
2.7.3.4
Uncertainties in forecasted weather window duration shall be duly considered i.e. the forecasted weather
window duration should be conservatively assessed.
2.7.3.5
Weather forecasts are based on extensive computer analyses. In cases where forecast updates are made at
intervals of less than 12 hours it shall be documented that the updates are based on sufficient data to be as
accurate as ordinary forecasts.
2.8 Organization of marine operations
2.8.1 General
2.8.1.1
The organisation and responsibility of key personnel involved in marine operations shall be established and
described before execution of marine operations. The responsibilities and duties of each function shall be clearly
defined to minimise uncertainties and overlapping responsibilities.
2.8.1.2
Organisation charts, including names and functional titles of key personnel, shall be included in the marine
operations manual. Authority during the operation shall be clearly defined.
2.8.1.3
Operations shall be carried out in accordance with the conditions for design, the approved documentation, and
sound practice, such that unnecessary risks are avoided. This is the responsibility of the operation
superintendent or manager.
2.8.1.4
Responsibilities in possible emergency situations shall be described.
2.8.1.5
Access to the area for the operation should be restricted. Only authorised personnel should be allowed into the
operation area.
Guidance note:
Where necessary, a suitable security and tracking system should be in use to record personnel on the structure
or vessels, to track their whereabouts.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.8.2 Qualification and training
2.8.2.1
Operation supervisors shall possess thorough knowledge and have experience from similar operations. Other
key personnel shall have knowledge and experience within their area of responsibility.
2.8.2.2
CVs for supervisors and key personnel involved in major marine operations shall be submitted.
2.8.2.3
Vessel manning and personnel qualifications shall as a minimum fulfil statutory requirements. Additional
Page 53 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
manning shall be considered for complex operations or to satisfy specific project requirements.
2.8.2.4
Adequate training appropriate to each individual’s function and situation should be given, including job training,
site safety training and briefings, marine safety and survival training.
2.8.2.5
A qualification matrix is recommended for correct tracking and control of personal qualifications.
2.8.2.6
Computer simulation and training, and/or model tests can give valuable information for the personnel carrying
out the operation. Where relevant, a full-mission simulation should be undertaken.
2.8.3 Familiarisation and briefing
2.8.3.1
Operation supervisors shall familiarise themselves with all aspects of the planned operations and possess a
thorough knowledge with respect to limitations and assumptions for the design.
2.8.3.2
Key personnel shall familiarise themselves with the operations. A thorough briefing by the supervisors regarding
responsibilities, communication, work procedures, safety and other items of importance shall be performed.
2.8.3.3
Other personnel participating in the operations shall be briefed about the operation with emphasis on their
assigned tasks/responsibilities and safety.
Guidance note:
The use of visual aids for presenting complex marine operations is highly recommended, either through picture
series and/or animations.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.8.3.4
For complex marine operations a separate and detailed familiarisation program shall be prepared and
thouroughly implemented involving all personnel.
Guidance note:
Familiarisation should for offshore operations normally be initiated prior to vessel mobilisation. The
familiarisation should cover all involved personnel, including marine crew, project personnel and third party, and
should address all aspects of the operation.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.8.4 Communication and reporting
2.8.4.1
Communication lines and primary and secondary means of communication shall be defined, preferably in a
communication chart, including as appropriate:
• Client’s representative and 3 Party/MWS representative (if relevant)
• Overall project management
• Operation management
• Involved vessels
• Mooring systems and marine spread
• Ballast system operation
• Monitoring
• Weather forecasting
• Support services
• Field engineers providing expertise as required
• Safety
• Statutory, regulatory and approving bodies
rd
Page 54 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
• Emergency response.
2.8.4.2
Communication systems, including radio channels, telephone numbers, e-mail addresses and out-of-hours
numbers shall be identified and checked for accuracy.
2.8.4.3
The primary operational communication system should be used only for information needed for managing and
controlling the operation. Important information should be given dedicated lines/channels.
2.8.4.4
The planned flow of information during the operation shall be described.
2.8.4.5
A common language understood by all personnel involved should be used for VHF/UHF communication. Radio
channels should be allocated early to avoid possible interference.
Guidance note:
If a common language could lead to misunderstandings, it can be acceptable to use two or more languages.
Such communication needs to be duly planned and rehearsed.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.8.4.6
Communication of important information that may be misunderstood, e.g. monitoring results, should be
confirmed in writing.
2.8.4.7
All communication and reporting should be made available for continuous monitoring by the MWS during the
operation. (See also [2.3.8]).
2.8.5 Shifts
2.8.5.1
For operations with a planned duration exceeding 12 hours, a shift plan shall be established.
2.8.5.2
Where personnel changes occur during the course of an operation because of shift changes, these shall be
identified. Every effort should be made to avoid changes of key personnel during critical stages of the operation.
2.8.5.3
Where transfer of responsibility is involved, times of and procedures for hand-over from one organisation to
another (e.g. from fabrication to marine operations, from on-shore to offshore) shall be identified.
2.8.5.4
When continuous operations using more than 1 shift are not standard practice then special provision to prevent
fatigue shall be made for operations that could continue beyond normal working hours. This includes provision
of suitably experienced and briefed alternate personnel with good hand-overs at each shift change.
2.9 Monitoring
2.9.1 General
2.9.1.1
Actual parameters should be monitored and compared against those used in design to as great an extent as
practicable during and also if applicable before marine operations.
Page 55 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2.9.1.2
The monitoring methods should duly reflect the required accuracy (i.e. acceptable monitoring tolerances).
2.9.1.3
Target values and maximum deviations from target values, i.e. tolerances, for monitoring should be clearly
defined.
Guidance note:
Maximum allowable measured deviations should normally be within 75% of ‘deviations considered in the design’
less the ‘monitoring tolerance’.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.9.1.4
General and back-up requirements to monitoring instrumentationsystems are given in [4.2].
2.9.2 Environmental conditions
2.9.2.1
Environmental conditions can be monitored by both direct monitoring of environmental conditions and by
monitoring responses caused by environmental effects, see [2.9.3].
2.9.2.2
For marine operations particularly sensitive to environmental conditions such as waves, swell, current, tide etc.,
systematic monitoring of these conditions before and during the operation shall be arranged.
Guidance note:
In some areas, tide behaviour can vary considerably locally. In such cases a local tide variation curve should be
established based on extensive tide monitoring including at least one period with the same lunar phase as for
the planned operation. Tidal variations should be plotted against established astronomical tide curves. Any
discrepancies should be evaluated, considering barometric pressure and other weather effects.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.9.2.3
Expected values, for the remaining time of the operation, of significant environmental conditions should be
continuously predicted during execution of a marine operation. Such predictions should, as relevant, be based
on the monitored variations, tabulated values and weather forecasts.
2.9.3 Loads and/or responses
2.9.3.1
Full scale monitoring can be used for the determination of responses (e.g. accelerations on a vessel) or loading
effects (e.g. strain-gauge measurements). All full scale load and/or response monitoring should be carried out
according to agreed procedures, see e.g. [2.9.5].
Guidance note:
Full scale monitoring is normally carried out to meet one or both of the following objectives:
• To obtain valuable design information for future projects.
• To control that design criteria (ULS or FLS) are not exceeded during an operation.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.9.3.2
During full scale monitoring it can be difficult to accurately measure the load which causes the measured
response. The information obtained may therefore be of a statistical nature, and the use of statistical methods
can be necessary in order to draw conclusions.
Guidance note:
Page 56 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Full scale monitoring has limitations, e.g. as indicated above, that need to be duly considered if such monitoring
is used as an (assisting) operational means of control.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.9.4 Alpha factor related monitoring
2.9.4.1
It shall be documented that monitoring systems and procedures used as a means to increase the Alpha Factor
for waves have adequate accuracy and reliability. Normally this implies fulfilment of all the following:
• Continuous monitoring.
• The monitoring device should be adequately located (e.g. no shielding effects) to give correct readings
and not in any case more than 3 (three) nautical miles from the location of the operation.
• Documented monitoring accuracy better than ±5% of the measured maximum values.
• Statistical treatment of the results which continuously indicate the expected maximum value within a
defined time period (normally 3 hours).
• It should be possible to relate the response monitoring results to the wave conditions. See also [2.9.3].
• A secondary system and/or procedure that will detect any significant erroneous results produced by the
primary system.
2.9.4.2
A procedure shall be made that describes how the interface between monitoring results and weather forecasts is
to be handled.
Guidance note:
The procedure should, as a minimum, cover the following:
• Discrepancies between weather forecast for the present time and monitoring results.
• How to calibrate the weather forecast for the coming hours based on the monitoring results.
• Feed-back to meteorologist(s)
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.9.5 Monitoring procedure
2.9.5.1
A monitoring procedure describing at least monitoring methods and intervals, responsibilities, reporting and
recording shall be prepared.
2.9.5.2
Any unforeseen monitoring results shall be reported without delay.
2.9.6 Back-up and contingency
2.9.6.1
The requirements of [4.2.1.10] apply.
2.9.6.2
If the monitoring back-up system does not have the same accuracy as the original system this should be
considered in the contingency planning.
2.10 Inspections and testing
2.10.1 General
2.10.1.1
Testing and inspection of equipment, structures, systems and vessels shall be carried out according to relevant
and recognized codes/standards and/or relevant specifications, functional requirements and assumptions for the
design.
Page 57 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2.10.1.2
Inspection during the operation shall include a systematic review and evaluation of monitoring results, see [2.9].
2.10.1.3
The MWS company shall identify any inspections and tests to be witnessed by its own representatives.
2.10.2 Test program
2.10.2.1
The required inspections and tests both in the preparation phase and during the operation shall be described in
a test and inspection program.
2.10.2.2
The test and inspection results shall be documented.
Guidance note:
The inspections and testing can be documented by reports and completed checklists.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.10.2.3
For larger operations it is recommended that a test/commissioning program is developed specifying the
planned inspections and tests. The test program should indicate expected characteristics, and state acceptance
criteria based on the design assumptions.
Guidance note:
Acceptance criteria for tests may also be functional requirements.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.10.3 Systems
2.10.3.1
All systems and their back-up shall be tested before the start of an operation. Such tests shall demonstrate that
they function as intended. If critical, the capacity of the system shall be adequately checked.
2.10.3.2
Change over from a primary to a secondary system shall be tested.
2.10.3.3
Instrumentation systems shall be calibrated and tested before the operation. The calibration procedure may be
subject to review.
2.10.3.4
Essential systems shall be function and capacity tested in their final configuration and connected to the same
power supply/HPU as intended to be used during operation. If several consumers are connected to the same
power supply/HPU, the test should be performed realistically with all consumers running in order to test capacity.
2.10.3.5
Emergency systems/functions and fail safe configurations should, as far as practically possible, be tested in a
realistic scenario with adequate loading.
2.10.4 Communication
2.10.4.1
Page 58 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Primary and secondary means of communication shall be tested before operation.
2.10.4.2
For operations with complex communication and reporting procedures, or where proper information flow is vital,
a run-through of communication routines shall be carried out.
Guidance note:
This rehearsal should be performed with the nominated personnel and under conditions similar to those
expected during the actual operation. See also [2.8.4.5].
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.10.5 Inclining tests
2.10.5.1
The requirement to perform inclining and/or displacement tests shall be agreed with the MWS Company.
Guidance note:
Vessels with a valid Trim and Stability booklet, including all modifications since the last inclining test, do NOT
normally require an inclining test when conservative estimates of cargo weight and centre of gravity show
adequate reserves of intact and damagestability.
Where ideally an inclining test would be performed but may not give sufficiently accurate results the calculations
may be based on outputs from the weight control programme checked against a displacement test. This would
only apply if there is a sufficient reserve of stability to cover possible inaccuracies.
Where a number of very similar units are constructed at the same place, the requirement for inclining tests on the
later units may be reduced after a study of weight variations (from displacement tests) and Centre of Gravity
variations (from inclining tests) of the previous units, and agreement with the MWS company.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.10.5.2
Where inclining and/or displacement tests are required:
a. They should be performed before any marine operation where the displacement, centre of gravity or
stability may be critical.
b. They should be performed according to guidelines in IMO Intact Stability Code 2008, /89/, Part B Annex 1.
c. if applicable an allowance shall be made for the presence and compressibility of any air cushion
d. if the vessel is not axisymmetric then inclining tests may be required about two axes, as agreed with the
MWS company. (This normally applies to bodies with an irregular shaped plan view, not vessels with a list).
e. Upon completion of the inclining test, a report containing measurements/readings and corresponding
calculations of displacement (and light displacement if relevant), metacentric height (GM), and the position
of the centre of gravity of the structure, should be prepared.
f. The output from the inclining test should be used to check and calibrate the output from the weight
control programme. A rigorous weight control system should be enforced from the inclining test until the
relevant marine operation is completed.
g. A sensitivity analysis of the parameters affecting the test results should be performed.
2.11 Vessels
2.11.1 General
2.11.1.1
This section includes general requirements for vessels involved in marine operations. Where applicable, further
requirements are given for each type of operation vessel in Sec.6 through Sec.18.
2.11.1.2
Vessels shall satisfy the relevant hydrostatic stability requirements given in [11.10].
2.11.1.3
A general description of the vessel systems to be used shall be documented. Ballast and towing
equipment/systems shall be described in detail if used.
Page 59 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2.11.1.4
Vessels should be suitable for their planned tasks during the operation.
Guidance note:
If there is any doubt about the vessel suitability for a specific operation it is recommended to carry out an
independent suitability survey of the vessel.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.11.1.5
See [17.13] for further requirements to Dynamic Positioned vessels.
2.11.2 Condition and inspections
2.11.2.1
All vessels shall be in acceptable condition and with valid certificates, see [B.1].
2.11.2.2
All vessels involved in the operations should be inspected before the operation to confirm compliance with the
design assumptions, validity of certificates, suitability (see [2.11.1.4]) and acceptable condition.
2.11.2.3
The global and local condition of the vessels with respect to corrosion shall be confirmed and considered in
strength verifications.
2.11.3 Structural strength
2.11.3.1
Adequate global and local structural strength shall be documented for all vessels.
Guidance note:
The strength may be documented by either ensuring that the vessel is operated within the Class requirements,
see [2.11.4], or by calculating the strength according to the relevant requirements in Sec.5.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.11.3.2
If the allowable deck load is based on load charts, the limitations and conditions for these with respect to
number of loads and simultaneousness of loads shall be clearly stated. The applied design factors shall be
specified.
2.11.4 Class requirements
2.11.4.1
Where a vessel is classed by a Classification Society it shall be operated in accordance with requirements from
the Society. The limitations for Class as given in “Appendix to Class Certificate” or similar shall be submitted.
2.11.4.2
For Mobile Offshore Units the following annexes (or similar) to the maritime certificates shall be submitted;
• Annex I - Operational limitations,
• Annex II - Resolutions according to which the unit has been surveyed, and possible deviations from these.
2.11.4.3
Valid recommendations (conditions) given by the Classification Society shall be submitted.
Guidance note:
Page 60 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Modifications to vessel structure or equipment can require approval from the Classification Society.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.11.4.4
If it is planned to use a vessel or its equipment (e.g. crane) outside the limitations stated by Class, a statement of
acceptance from Class shall be submitted.
2.11.5 Certificates
2.11.5.1
All required certificates shall be valid, or relevant exemptions shall be submitted.
Guidance note:
The documents (certificates) to be carried on board different types of vessels can be found in IMO FAL.2/Circ.87-
MEPC/Circ.426-MSC/Circ.1151.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.11.6 Navigation lights and shapes
2.11.6.1
All vessels and towed objects (unless submerged) shall carry the lights and shapes, towed objects required by
the International Regulations for Preventing Collisions at Sea, 1972 amended 1996 (COLREGS, /91/) and any
local regulations.
2.11.6.2
Navigation lights shall be independently powered (e.g. from an independent electric power sources or from gas
containers). Fuel or power sources shall be adequate for the maximum duration of the towage, plus a reserve.
Spare mantles or bulbs should be carried, even if the tow is un-manned.
Guidance note:
Solar powered navigation lights should be compliant with UL 1104 (USCG) and/or EN14744 (EU Marine
Equipment Directive). Additional power provided by solar panels may be considered if an adequate track record
is documented.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.11.6.3
Where possible, a duplicate system of lights should be provided.
2.11.6.4
Towed objects which may offer a small response to radar, such as barges or concrete caissons with low
freeboard, should be fitted with a radar reflector. The reflector should be mounted as high as practical.
Octahedral reflectors should be mounted in the “catch-rain” orientation.
2.11.7 Contingency situations
2.11.7.1
All vessels shall be selected with due consideration to possible contingency situations.
Guidance note:
This could e.g. result in the selection of redundant (twin screw) tugs for towing operations in narrow waters. See
also the operation-specific requirements in Sec.10 to Sec.18 of this Standard for further guidance.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2.11.7.2
Where several tugs (vessels) are involved, a stand-by tug to assist or remove vessels in case of black-out, engine
failure, etc. should be considered.
Page 61 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
SECTION 3 Environmental conditions and criteria
3.1 Introduction
3.1.1 General
3.1.1.1
This Section refers to the environmental design criteria applicable for marine operations. The focus is on the
criteria applicable to weather unrestricted marine operations however, design environmental criteria for weather
restricted marine operations are addressed in [3.3].
3.1.1.2
Metocean criteria are generally used for analysis to a recognisedstandard (including relevant safety factors). In
this standard, the environmental criteria to be used for the ASD/WSD approach are different to those to be used
for the LRFD approach.
3.1.1.3
Each marine operation shall be designed to withstand the loads caused by the most adverse environmental
conditions expected. In the case of a voyage this shall account for the areas and seasons through which it will
pass. Any agreed mitigating measures may be taken into account.
3.1.1.4
For each phase of a voyage or marine operation, the design criteria should be defined, consisting of the design
wave or sea state, design wind and, if relevant, design current. It should be noted that the maximum wave and
maximum wind may not occur in the same geographical area, in which case it may be necessary to check the
extremes in each area, to establish governing load cases.
3.1.2 Scope
3.1.2.1
The environmental design criteria should be established dependent on the duration of each discreet phase of a
marine operation, which may be a weather restricted or a weather unrestricted operation as defined in [2.6.5].
3.1.2.2
This section defines the default return periods that can be used to determine applicable environmental criteria.
App.C gives more detailed approaches for the determination of design winds and waves as a function of the
exposure duration and location-specific metocean parameters.
3.1.3 Revision history
3.1.3.1
This section replaces the applicable sections of the legacy GL Noble Denton Guidelines and legacy DNV-OS-H-
series standards.
3.2 Design environmental condition
3.2.1
The design environmental condition consists of the wave height, wind speed, current and other relevant
environmental conditions specified for the design of a particular marine operation.
3.2.2
Page 62 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
A weather unrestricted operation is not limited by practical aspects, and therefore the operational criteria are the
design environmental condition. In this case the design environmental condition is based on extreme statistical
data and is addressed in [3.4].
3.2.3
The environmental design data should be representative of the geographical area or site and operation in
question.
3.2.4
Where it is impractical and/or uneconomical to design marine operations based on extreme statistical data, the
design environmental condition can be set independent of extreme statistical data for weather restricted
operations - see [2.6.7] and [3.3].
3.3 Design environmental criteria for weather restricted operations
3.3.1
For weather restricted operations the design wind could be selected independent of statistical data.
Guidance note:
Characteristic wind velocities less than 10 m/s are generally not recommended. See also [3.3.4] for general
considerations.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
3.3.2
The ratio between forecasted wind and design wind should be determined in accordance with Table 2-8 or
Table 2-15 as applicable.
3.3.3
Wave conditions for weather restricted operations, i.e. operations with wave heights (and/or periods) selected
independent of statistical data, should be as described by [C.3.4].
3.3.4
The significant wave height(s) and associated period(s) should be selected considering:
• Feasibility and safety of the planned operation.
• Typical weather conditions at the site.
• Operation period.
• Uncertainties in weather forecasts.
Guidance note:
Other factors such as the length of delay that can be accepted due to waiting on weather, and possible
contractual obligations should be considered as found relevant.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
3.3.5
Maximum wave height for weather restricted operations should be calculated according to the following
equation:
H = STF × H
where
STF = 2.0 for all reference periods.
Guidance note:
For short reference periods STF < 2.0 may be acceptable. See DNV-RP-H102, /55/, Table 2.2 for guidelines.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
An appropriate range of wave periods associated with H should be considered. In the absence of other data,
the range of T can be taken as:
max s
max
ass
Page 63 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
3.3.6
Where relevant, applicable information from [3.4] may be used e.g. [3.4.12].
3.4 Design criteria for weather unrestricted operations
3.4.1 General
3.4.1.1
Whilst an operation may be defined as weather unrestricted, specific portions can be dependent on suitable
weather forecasts, e.g. the departure of a tow from safe haven as described in [11.14.1.4]. Such restrictions shall
be agreed before the start of an operation and are normally included on the Certificate of Approval.
3.4.2 Environmental statistics
3.4.2.1
Environmental phenomena are usually described by physical variables of statistical nature. Statistical data should
as far as possible be used to establish characteristic environmental conditions. The statistical description should
reveal the extreme conditions as well as the long and short-term variations.
3.4.2.2
Statistical data used as basis for establishing characteristic environmental criteria shall cover a sufficiently long
time period.
Guidance note:
For meteorological and oceanographic data a minimum of three to four years of data collection is
recommended. When using seasonal data longer periods are required. See DNV-RP-C205 /46/ for more info.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
3.4.2.3
The validity of older (typically more than 20 years) statistical data should be carefully considered with respect to
both monitoring methods/accuracy and possible long term climate changes.
3.4.2.4
If statistical environmental data are assumed to follow a two-parameter Weibull distribution, the regression
analysis should be performed with emphasis on a correct representation of the extreme values.
Guidance note:
Regression analysis of two-parameter Weibull distributions are recommended based on the 30% highest data
points, i.e. P(x > X) = 0.3.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
3.4.3 Return periods for determining environmental criteria (apart from moorings)
3.4.3.1
The return periods that shall be used for determining environmental criteria for weather unrestricted marine
operations (apart from moorings and the elevated operation of jack-ups), should be related to its operation
reference period, as defined in [2.6.2]. For design criteria for moorings see [3.4.4], and for the elevated
operation of jack-ups see DNVGL-ST-N002, /39/.
3.4.3.2
As general guidance, the criteria in Table 3-1 may be applied provided that the independent extremes are
considered concurrently.
3.4.3.3
Page 64 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
The intention of the return periods and load, safety and material factors used in the LRFD approach is to ensure a
probability for structural failure less than 1/10000 per operation (10-4 probability). Note that this probability level
defines a structural capacity reference. When the probability of operational errors is included, the total
probability of failure is increased.
Guidance note:
When including operational errors, the level of probability of total loss per operation cannot be accurately
defined. However, the recommendations and guidance given in this Standard are introduced in order to obtain a
probability of total loss As Low As Reasonable Practicable (ALARP principle).
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
3.4.3.4
The return periods for the ASD/WSD approach have been calibrated with the objective of ensuring that a given
structurewill be treated equally under ASD/WSD and LRFD. The inherent safety margin in ASD/WSD checks is
less than that in LRFD checks, so that higher design values are needed to achieve this equivalence.
3.4.3.5
Seasonal and/or directional variations may be used. Data for the month(s) of the operation and the following
month shall be used. If the operation is to be carried out in the first 10 days of the month, the data used shall
include the preceding month.
3.4.3.6
When seasonal variations are taken into account, this shall not imply a shorter return period, as would occur if the
monthly return period values are derived from only the data in that month without adjustment of the target
probability level. There are differing approaches to obtaining the monthly or seasonal data at required return
period (e.g. the “one year return”). One approach is to perform an extreme value analysis by month/season, and
consider a conditional probability corresponding to that month/season. For example, to determine the N-year
return period extremes for say March, perform extreme value analysis on the subset of data for March, consisting
of 3 hr sea-states, 240 per month in the data, and fit a Weibull curve to the cumulative distribution function.
Select the required probability level for the N-yr extreme calculated as: 1/(365.25*8*N*C) where C = conditional
probability for month = 1/12. Another approach is to obtain relative weightings of the severity of each month in a
year, and scale the monthly or seasonal values such that the worst month in the year has the same extremes as
the all-year value at the required return period.
3.4.3.7
Similarly, when directional variations are taken into account, this shall not imply a shorter return period.
Table 3-1 Metocean minimum design return periods, T – unrestricted operations
Operation
reference
period
ASD / WSD LRFD
Wind
Wave and
Current
Wind
Wave and
Current
Up to 3 days T ≥5 year T ≥3 month T ≥10 year T ≥1 month
3 to 7 days T ≥10 year T ≥1 year T ≥10 year T ≥3 month
7 days to 1
month
T ≥25 year, (or obtain
from 10 yr and 50 yr
environmental criteria
values using: 10yr +
0.7*(50 yr-10 yr) )
T ≥10 year T ≥10 year T ≥1 year
1 month to 1
year
T ≥75 year (or obtain
from 50 yr and 100 yr
environmental criteria
values using: 50yr
+0.7*(100 yr-50 yr) )
T ≥50 year T ≥100 year T ≥10 year
More than 1
year
100 year return T ≥100 year T ≥100 year T ≥100 year
d
3) 3)
1)
2)
1)
2)
4)
d d d d
d d d d
d
d d d
d
d d d
d d d
Page 65 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Notes:
1. More accurate design wind speeds may be determined as a function of the operation reference period
and site-specific metocean parameters using the method shown in [C.1].
2. More accurate design waves may be determined as a function of the operation reference period and
site-specific metocean parameters using the method shown in [C.3].
3. See [3.4.3.6].
4. Operations up to 3 days may also be defined as weather restricted operations. See Section [2.6.7].
5. 1 year return period for a 3 month seasonal period will normally be acceptable.
3.4.3.8
If conditions are determined using the joint probability of different parameters, then the return period should be
increased by a factor of 4 i.e. 10 years to say 50 years and 50 years to 200 years, unless the loadings are
dependent on a single parameter in which case the value of that parameter shall be taken from a joint probability
combination in which it is maximised.
3.4.3.9
For voyages that are governed for ULS and ALS by a single sea area, the operation reference period may be
taken as 7 days to 1 month. For FLS the whole voyage shall be considered, see [11.9.12].
3.4.3.10
For voyages, the design extremes may be reduced below the 10 year seasonal return, to give the same
probability of encounter as a 30 day exposure to a 10 year seasonal storm. In this case the “adjusted” design
extremes are defined in terms of the 10% risk level, see [3.4.17.3]. The design extremes for weather unrestricted
voyages shall not be reduced below the 1 year seasonal return.
3.4.4 Return periods for determining environmental criteria for moorings
3.4.4.1
Table 3-2 identifies minimum return periods applicable to a various of mooring types for weather unrestricted
operations. The return periods specified in this document are based on ISO 19901-7 /100/, however the
selection of return period will depend on the choice of the design code (See 17.2 for acceptable mooring codes)
and the associated factor of safety. For weather restricted operations, see [3.3]. More onerous, local
requirements can override the requirements stated in Table 3-2, for example ISO 19901-7, Annex B.
Table 3-2 Return periods for determining environmental criteria for moorings
MOORING TYPE RETURN PERIOD
Quayside/Inshore 100 year
Offshore - Mobile near another asset 10 year
Offshore - Mobile in Open Location 5 year
Notes:
1. Where the exposure is limited to less than 30 days, or unit capable of leaving the quay on receipt of
poor weather forecast, 10 year return period extremes can be used in the assessment.
3.4.4.2
For mobile moorings deployed for a duration extending beyond the inspection cycle of the components of the
mooring system, the system and its components should be assessed against the requirements for designing a
permanent mooring sytem.
3.4.4.3
Joint probability data should only be used when permitted by the referenced standard.
3.4.4.4
1)
1)
Page 66 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Mobile moorings should generally be designed with reference to a 10 year return period when in the vicinity of
any other infrastructure. Where a mobile mooring is in an open location, with reduced consequence from
mooring failure, a five year return period may be acceptable. Where applicable seasonal/monthly and/or
directional metocean data as in [3.4.5] can be used with the specified return period.
3.4.4.5
When evaluating the consequence of failure, consideration should be given to whether risers will be connected,
proximity to other installations and the type of operation being undertaken. For pipe laying operations, the
expected duration of the operation, plus a suitable contingency value, should be addressed.
3.4.5 Use of seasonal/directional metocean data for moorings
3.4.5.1
Metocean data specific to the month(s) or season(s) during which the mooring will be utilised may be used
where appropriate.
3.4.5.2
Directional metocean data may also be used with suitable spreading functions to reflect directional divergence
in the design environment.
3.4.6 Wind
3.4.6.1
The averaged wind velocity over a defined time is referred to as the mean wind.
Guidance note:
Forecasted wind velocity is normally given as the 10 minute mean wind (t = 10 min) at a reference height of
10 m (z = 10 m).
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
3.4.6.2
The design wind speed shall generally be the 1 minute mean velocity at a reference height of 10 m above sea
level. A longer or shorter averaging time should be used for design depending upon the nature of the operation,
the size of the structure involved and the response characteristics of the structure to wind.
Guidance note 1:
The following averaging times are given as examples;
- Fixed structures L < 50 m 3 [s]
- Fixed structures L > 50 m 15 [s]
- For any structure if wave load dominating 1 [minute]
- Quay mooring, small vessels/objects 15 [s]
- Quay mooring, large (Wind area > 2000 m ) vessels/objects 1 [minute]
- Stability calculations, normally 1 [minute]
- Catenary mooring of vessels/objects 10 [minutes]
- Catenary mooring of GBS 60 [minutes]
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---Guidance note 2:
OCIMF (2007) gives further guidance with respect to mean wind periods to be used for quay mooring of vessels.
For static wind calculations on lifted objects the recommendations for fixed structures above normally apply. See
also DNV2.22, /16/, Appendix A.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
3.4.6.3
For dynamic wind analysis the mean wind period recommended for the applied wind spectrum should be used.
mean
2
Page 67 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
See [3.4.6.7].
3.4.6.4
The mean wind velocity varies with the averaging time and height above the sea surface or height above ground
(yard lift). For these reasons, the averaging time for wind speeds and the reference height shall always be
specified.
3.4.6.5
The wind velocity profile in open sea can be related to a reference height (z ) and mean time period (t )
according to the equation below, see also Table 3-3 and ISO 19901-1 “Metocean design and operational
considerations”, /98/.
Where:
z = Height above sea surface.
z = Reference height 10 [m].
t = Averaging time for design.
t = Reference averaging time 10 [minutes].
U(z, t )= Average wind velocity.
U(z , t
) = Reference wind speed.
Table 3-3 Wind profile, U(z, t )/ U(z , t )
z (m)
Averaging time
3 s 15 s 1 min. 10 min. 1 hour
1 0.93 0.86 0.79 0.69 0.60
5 1.15 1.08 1.01 0.91 0.82
10 1.25 1.17 1.11 1.00 0.92
20 1.34 1.27 1.20 1.10 1.01
50 1.47 1.39 1.33 1.22 1.14
100 1.56 1.49 1.42 1.32 1.23
Guidance note:
The wind profile given in Table 3-3 is for open sea and should not be considered applicable to (partly) sheltered
inshore locations. Wind profiles for such locations should be selected based on local data.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
3.4.6.6
Gust wind: For elements or systems sensitive to wind oscillations (e.g. where dynamics or fatigue governs the
design) the short and long term wind variations should be considered.
3.4.6.7
The wind variations may be described by a wind spectrum. See e.g. DNV-RP-C205, /46/; NORSOK N-003, /111/
or ISO 19901-1, /98/.
3.4.6.8
Squalls: If squalls are possible during a marine operation maximum realistic (in the actual area) characteristic
wind speeds during squalls shall be considered in the planning and execution of the operation.
Guidance note:
Squalls are strong winds (22 knots or more) characterised by a sudden onset, duration of minimum 1 minute, and
then a rather sudden decrease in speed. Squalls are caused by advancing cold air and are associated with active
weather such as thunderstorms. Their formation is related to atmospheric instability and is subject to seasonality.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
r r, mean
r
mean
r, mean
mean
r r,
mean
mean r r, mean
Page 68 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
3.4.7 Wind for moorings
3.4.7.1
In addition to the requirements in [3.4.6], for permanent moorings the more onerous of the following should be
considered:
• Steady one minute mean velocity; or
• One hour mean plus a suitable gust spectrum. Generally the ISO 19901-1 gust spectrum, /98/, would be
applicable unless an alternative can be clearly justified.
3.4.7.2
For mobile moorings either a steady state wind speed or a suitable gust spectrum may be used depending upon
the stiffness of the mooring system.
3.4.7.3
For inshore or quayside moorings care shall be taken to ensure that all natural periods of response of the system
have been considered. Some of the mooring system response periods may be shorter than one minute but on
the other hand the use of shorter gust periods may not represent a sustained design wind that will act at the
same time across the whole of the structure. The representative design wind sampling period, therefore, has to
be carefully established on a case by case basis for inshore and quayside moorings, but the averaging time shall
not be longer than 1 minute if applying static wind load.
3.4.7.4
For locations prone to squall events, system design should include assessment for squall events. Guidance on
squall assessment is provided in DNVGL-OS-E301, /27/.
3.4.8 Waves - design methods
3.4.8.1
Wave conditions are defined by characteristic wave height, H , or the significant wave height, H , and
corresponding periods.
3.4.8.2
Wave conditions for design may be described either by a deterministic design wave method, or by a stochastic
method.
3.4.8.3
In the deterministic method the design sea states are represented by regular periodic waves characterised by
wave length (or period), wave height and possible shape parameters.
3.4.8.4
In the stochastic method the design sea states are represented by wave energy spectra characterised by main
parameters H and T or T .
3.4.9 Waves - weather unrestricted operations, general
3.4.9.1
Characteristic wave conditions for weather unrestricted operations shall be based on long term statistical data.
3.4.9.2
Long term variations of waves may be described by a set of sea states characterised by the wave spectrum
parameters.
3.4.10 Wind seas and swell
3.4.10.1
c s
s z p
Page 69 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
All possible combinations of wind seas and swell should be considered.
Guidance note:
The wave conditions in a sea state can be divided into two classes, i.e. wind seas and swell. Wind seas are
generated by local wind, while swell have no relationship to the local wind. Swells are waves that have travelled
out of the areas where they were generated. Note that several swell components may be present at a given
location.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
3.4.11 Characteristic waves for weather unrestricted operations
3.4.11.1
Characteristic values shall be based on the defined operation reference period. Periods less than 3 days shall not
be used. These can be based on the return periods given in Table 3-1 or Table 3-2 as applicable. Alternatively,
the Characteristic significant wave height, H may be taken according to [C.3.2.1] and the corresponding
maximum wave height, H , may be taken according to [C.3.2.2].
Guidance note 1:
The significant wave height where m is the sea surface variance. In sea states with only a narrow
band of wave frequencies, H is approximately equal to (the mean height of the largest third of the zero
up-crossing waves).
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 2:
The H corresponds to an approximate 10% probability of exceeding this individual wave height during the
anticipated operation reference period. If an alternative method is applied it should be documented that this
corresponds to an equal or less probability.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
3.4.11.2
When a regular wave analysis is applicable, the design maximum wave shall be the most probable highest
individual wave in the design sea state, assuming an exposure of 3 hours. The determination of the height, crest
elevation and kinematics of the maximum wave should be determined from an appropriate higher-order wave
theory and account for shallow water effects. For most practical purposes the kinematics of regular deterministic
waves can be described by the following theories:
h/λ ≤ 0.1
Solitary wave theory for particularly shallow water
0.1 < h/λ ≤ 0.3
Stokes 5 order wave theory or Stream Function wave theory.
h/λ > 0.3
Linear wave theory (or Stokes 5 order)
where
h = water depth.
λ = wave length.
A range of wave height-period combinations shall be investigated, including those that can cause resonance, see
[C.3.3].
For more information on the kinematics of regular waves, see DNV-RP-C205,/46/.
3.4.11.3
Sea states shall include all relevant spectra up to and including the design storm sea state for the construction
site or voyage route. Long-crested seas shall be considered unless there is a justifiable basis for using short-
crested seas or these are more critical, see [3.4.12]. Consideration should be given to the choice of spectrum.
3.4.11.4
Wave spectra defined by the Jonswap or the Pierson-Moskowitz spectra are most frequently used. Wave
conditions with combined wind sea and swell may be described by a double peak wave spectrum. See DNV-RP-
C205, /46/, for further guidance.
3.4.11.5
s, c
max, c
0
s
max, c
th
th
Page 70 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
In the simplest method the peak period (T ) for all sea states considered, should be varied. In areas where swell
is insignificant, the range of T can be taken as:
in areas where swell is significant, the range of T can be taken as:
 for H ≤ 5.7 m
 for H > 5.7 m
where:
H = significant wave height in metres
T = wave peak period in seconds
Guidance note:
The equations for areas where swell could be significant are based on the equations for T given in [C.3.4.3],
assuming that T = 1.24T for steep waves (gamma = 5) and T = 1.4T for long waves (gamma = 1.0). The relation
between zero-crossing period T and the spectral peak period T can be found in Table 3-4. See also DNV-RP-
H103, /56/, Sec.2.2.6 or DNV-RP-C205, /46/, Sec.3.5.5.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Alternatively, see [C.3.4.3].
3.4.11.6
The effects of swell, see [3.4.14], should also be considered if not already covered in this peak period range. A
reduced range of T may be used if the route or site-specific data and natural periods allow.
3.4.11.7
However, [3.4.11.5] incorrectly assumes that all periods are equally probable. As a result this method should
generally produce higher design responses than would be the case when using the more robust H -T method
described in [3.4.11.8], which may be used when desired.
3.4.11.8
In the alternative method, a contour (IFORM) is constructed within the H -T plane that identifies equally
probable combinations of H and T for the design return period. This contour should also cover swell. The
contour should be checked for accuracy e.g. against the theoretical constraints on wave breaking. H -T
combinations from around the contour should be tested in motion response calculations to identify the worst
case response (there is no need to consider a range of T with each H ).
3.4.11.9
The relationship between the peak period T and the zero-up crossing period T is dependent on the spectrum.
For a mean JONSWAP spectrum (γ=3.3) T /T = 1.286; for a Pierson-Moskowitz spectrum (γ=1) T /T = 1.41.
3.4.11.10
Table 3-4 indicates how the characteristics of the JONSWAP wave energy spectrum vary over the range of
recommended sea states. The constant, K, varies from 13 to 30 as shown in the equation in [3.4.11.4]. T is the
mean period (also known as T ).
Table 3-4 Value of JONSWAP γ, ratio of T :T and T : T for each integer value of K
Constant K γ T / T T / T Constant K γ T / T T / T
13 5.0 1.24 1.17 22 1.4 1.37 1.27
14 4.3 1.26 1.18 23 1.3 1.39 1.28
15 3.7 1.27 1.19 24 1.1 1.40 1.29
16 3.2 1.29 1.20 25 1.0 1.40 1.29
17 2.7 1.31 1.21 26 1.0 1.40 1.29
18 2.4 1.32 1.23 27 1.0 1.40 1.29
19 2.1 1.34 1.24 28 1.0 1.40 1.29
p
p
p
s
s
s
p
z
p z p z
z p
p
s p
s p
s p
s p
p s
p z
p z p z
1
m
p z p 1
p z p 1 p z p 1
Page 71 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
20 1.8 1.35 1.25 29 1.0 1.40 1.29
21 1.6 1.36 1.26 30 1.0 1.40 1.29
3.4.11.11
For operations involving phases sensitive to extreme sea states, such as temporary on-bottom stability or green
water assessment, the maximum wave height and associated period should be used.
3.4.11.12
For precise operations sensitive to small fluctuations of the sea level even under calm sea state conditions, the
occurrence of long period, small amplitude swell on the site should be checked and its effects on the operations
evaluated.
3.4.11.13
Attention should also be paid to areas prone to strong currents acting against the waves which would amplify the
steepness of the sea state (i.e. reduce the wave encounter period that drives dynamic response).
3.4.12 Short crested seas
3.4.12.1
A directional short crested wave spectrum, see the equation below, may be applied based on non-directional
spectra.
where
= Wave spectrum, see [3.4.11.4].
θ = Angle between direction of elementary wave trains and the main direction of the short crested
wave system.
= Directional short crested wave power density spectrum.
= Directional function.
3.4.12.2
Energy conservation requires that the directional function fulfils;
In absence of more reliable data the following directional function may be applied for wind sea,
where
Γ( ) = gamma function. Due consideration should be taken to reflect an accurate correlation
between the actual sea-state and the constant n. Typical values for wind seas are n = 2 to n = 10. Swell
should normally be taken as long crested, n > 10.
Guidance note:
For cases where long crested seas are conservative, it is recommended that long crested seas are used for the
original design work. If short crested seas are introduced in connection with estimating extremes, the exponent,
n, should not be taking lower than 10 without more detailed documentation. Swell seas should be taken as long
crested. For fatigue assessment, where low and moderate sea states are governing the fatigue accumulation, n
could be taken as the most unfavourable value between 2 and 6.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
3.4.12.3
Short crested seas should not be considered for significant wave heights exceeding 10 m, unless they cause
more onerous response(s).
Page 72 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
3.4.13 Waves for moorings
3.4.13.1
In addition to the requirements in [3.4.8], for mobile moorings it is generally acceptable to consider a single
extreme significant wave height and a range of associated peak periods corresponding to the relevant return
period for a location.
3.4.13.2
For permanent moorings a number of H -T combinations along the 100 year return period contour line shall be
considered in the analysis. If a contour plot is not available, a sensitivity study by varying peak period for the 100
year return period sea state is required. This is to ensure that extreme line tensions due to low frequency motion
at lower periods are captured in the analysis, especially for ship shaped floaters.
3.4.13.3
Long crested waves shall be assumed for analysis unless otherwise documented.
3.4.14 Swell
3.4.14.1
Swell type waves should be considered for operations sensitive to long period motion or loads.
3.4.14.2
Swell type waves may be assumed regular in period and height, and may normally also be assumed
independent of wind generated waves.
3.4.14.3
Critical swell periods should be identified and considered in the design verification.
3.4.14.4
Characteristic height(s) and period(s) for swell type waves for weather restricted operations may be selected
independently of statistical data.
3.4.14.5
Characteristic height(s) and period(s) for swell type waves for weather unrestricted operations should be based
on statistical data and the applicable return periods.
3.4.15 Current
3.4.15.1
The design current shall be the rate at mean spring tides, taking account of variations with depth and increases
caused by the design environmental condition, storm surge, fluvial (river) and wind-driven components.3.4.15.2
Currents can be divided into two different categories:
• Tidal currents
• Residual currents that remain when the tidal component is removed, including river outflows, surge, wind
drift, loop and eddy currents.
3.4.15.3
Tidal currents can be predicted reliably, subject to long term measurement (at least one complete lunar cycle at
the same season of the year as the actual planned operation). Residual currents can only be reliably predicted or
forecast using sophisticated mathematical models.
s p
Page 73 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
3.4.16 Other parameters
3.4.16.1
Other factors including the following may be critical to the design, operations or voyages and should be
addressed:
• Water level including tide and surge
• Sea icing, icing on superstructure
• Exceptionally low temperature
• Large temperature differences
• Water density and salinity
• Bad visibility.
3.4.17 Calculation of “adjusted” design extremes, weather unrestricted voyages
3.4.17.1
The risk of encounter of extreme conditions on a particular voyage is dependent on the length of time that it
spends in those route sectors where extreme conditions are possible. If the length of time is reduced, then the
probability of encountering extreme conditions is similarly reduced.
3.4.17.2
It is generally accepted that for a prolonged weather unrestricted voyage the wind and wave design criteria
should be those with a probability of exceedance per voyage of 0.1 or less. For a voyage of 30 days (or more),
through meteorologically and oceanographically consistent areas, this corresponds to the 10 year monthly
extreme.
3.4.17.3
Many voyages last less than 30 days, or are potentially exposed to the most severe conditions for less than 30
days. Consequently, for shorter exposures, the 10 year monthly extreme may be adjusted for reduced exposure.
This value is equivalent to the 10 voyage extreme and is also referred to as the 10% risk level extreme. This shall
not be confused with the 10% exceedance value for the voyage, as discussed in [3.4.19.6].
3.4.17.4
When the 10% risk level extremes are less than the 1 year return monthly extremes, the 1 year monthly extremes
are the minimum that shall be used for design.
3.4.17.5
If the 10 year extremes are due to a tropical cyclone it may not be appropriate to design to adjusted extremes.
This is likely to be the case for barge or MODU towages that are not able to respond effectively to weather
routeing.
3.4.18 Calculation of exposure
3.4.18.1
For the purpose of the calculation of “adjusted” extremes the exposure time to potentially extreme or near
extreme conditions is calculated taking consideration of the following points:
• The initial 48 hours of the voyage is assumed to be covered by a reliable departure weather forecast and is
excluded
• The speed of the voyage is reduced by taking the monthly mean wave heights along the route into
consideration as described in [3.4.18.3].
• The speed of the voyage is adjusted to take into consideration the mean currents as described in
[3.4.18.4].
• A contingency time of 25 per cent of the time is added. This allowance is to account for severe adverse
weather, for tug breakdowns or other operational difficulties
• A minimum exposure time of 3 days is considered.
3.4.18.2
The voyage duration in each route sector shall be calculated using the speed in the monthly mean sea state for
each route sector and shall allow for adverse currents and adverse prevailing winds as described in [3.4.18.3].
Page 74 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
3.4.18.3
The effect of the mean sea state on the voyage speed in each route sector shall be calculated as a function of the
wave height in which the voyage is assumed to come to a dead stop, b (metres). This can typically be taken 5 m
for barge towages, and 8 m for ships. The speed in the each route sector can be taken as the calm weather
speed is multiplied by the factor, F, for that route sector defined by:
where H is the monthly mean wave height in that route sector.
3.4.18.4
The effect of the mean current on the voyage speed in each route sector shall be calculated by adding the
current vector (resolved with respect to the voyage heading).
3.4.18.5
For the calculation of exposure to the extreme conditions only prevailing winds or currents which act to delay the
voyage shall be taken into account.
3.4.19 Calculation of “adjusted” extremes
3.4.19.1
The probability of non-exceedance of a value of wind speed or significant wave height in a particular route sector
is expressed as a cumulative frequency distribution (e.g. a Weibull distribution).
3.4.19.2
The probability that during some 3 hour period for waves (or 1 hour for wind) the voyage will experience a
significant wave height (or wind speed) less than some value x is given by F (X).
3.4.19.3
If it takes M hours to pass through the route sector and making the assumption that consecutive wave height and
wind speed events are independent then the probability of not exceeding the value x is given by
where N = M/T where T = 1 hour is applied for winds and T = 3 hours for waves, which are a more persistent
form of energy.
3.4.19.4
If it is reasonable to expect that extremes of wind speed or wave height could occur in more than one route
sector then the probability of not exceeding the value x is given by the product
3.4.19.5
The probability of encountering an extreme value of wind speed or significant wave height, during a particular
voyage, that is reached or exceeded once on average for every 10 voyages, is 0.1. The value of x is varied until
to give the 10 voyage extreme for the voyage or towage.
3.4.19.6
This value is also referred to as the “adjusted” extreme for the voyage, or as having a risk level of 10%. The
method can be adjusted to give other risk levels (e.g. 1% or 5%). This should not be confused with the
percentage exceedance (see Guidance Note to [3.4.19.7]).
m
x
Page 75 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
3.4.19.7
The extremes used for design shall not be less than the 1 year return monthly extremes.
Guidance note:
The percentage exceedance is obtained as follows:
• Given a series of values of wind speed or significant wave height, as may be observed during a complete
voyage, some value y will be exceeded at some times but not others and the percentage exceedance of
value y is equal to:
• If each observed value of wind speed or significant wave height is assumed to last for some duration
(typically 1 hour for winds and 3 hours for waves) then for example, during a voyage lasting 10 days there
will be 240 wind events and 80 wave events. On the voyage, if a wind speed greater than 30 knots is
observed during 24 separate, hourly occasions then the percentage exceedance of 30 knots is 10%.
• The 10% risk level (as defined in [3.4.17.3]) for a voyage along a specific route, departing on a specific date
is expected to occur only once, on average, in every 10 voyages. However a value with a 10% exceedance
level for the same route and departure date is likely to occur on average for 10% of the time on every
voyage.
• Thus a 10% exceedance value is far more likely to occur than a 10% risk level value, or an adjusted, 10 year
extreme value.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
3.4.20 Criteria from voyage simulations
3.4.20.1
If continuous time series of winds and waves are available along the entire voyage route (e.g. from hindcast data
or satellite observations), an alternative way to develop criteria with a specified risk of exceedancein a single
voyage is to perform tow simulations. A large number of simulations can be performed, with uniformly spaced (in
time) departure times during the specified month of departure over the number of years in the database. For
each simulated voyage, the maximum wind speed and the maximum wave height experienced somewhere
along the tow route are retained. Then the probability distribution of these voyage-maxima can be used to
determine the design value with a specified risk of exceedance. For example, the value exceeded once in every
20 voyages, on average, can be determined by reading off the value of wave height from the distribution of
voyage-maximum wave heights at the 95 percentile level.
3.4.20.2
If fatigue during tow is an issue, the complete distributions of winds and waves experienced during the simulated
voyages (not just the voyage-maximum values) can be retained. These can be used to give scatter diagrams of
wave height against period and/or direction, and wind speed against direction.
3.4.20.3
The voyage simulation method can be made to be very realistic and account for variation of speed due to
inclement weather or ocean currents, weather avoidance en-route through forecasting/routeing services, or the
use of safe havens, etc. If the voyage simulator cannot accommodate all these features, a reasonably
conservative estimate of criteria can be derived by using a conservative (slow) estimate of the average speed.
Care should be taken when choosing the average speed estimate - a slow speed may not be conservative if it
results in the vessel apparently arriving in a route sector late enough to miss severe weather, which might have
been encountered if arrival had been earlier.
3.4.21 Metocean database bias
3.4.21.1
Regardless of whether the method described in [3.4.19] or the method described in [3.4.20] is used, it is
important to know the accuracy of the metocean database being used. Specifically, if there is a known bias in the
wind or wave statistics for any segment of a tow, it is essential to adjust the criteria accordingly.
3.4.22 Metocean data for bollard pull requirements
3.4.22.1
The design extremes are not normally used for calculation of bollard pull requirements (except when there is
limited sea room), which is covered in [11.12.2]
th
Page 76 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
3.5 Weather/metocean forecast requirements
3.5.1
The requirements for weather forecasting are given in [2.7] and the requirements for environmental monitoring
in [2.9].
3.6 Benign weather areas
3.6.1
Areas considered benign are shown in Table 3-5 and Figure 3-1 for different months. In general they have the
following characteristics:
• virtually free of monsoons, Tropical Revolving Storms or Tropical Cyclones
• exceeding Beaufort Force 5 for <20% of any month (in a “typical” year)
• However these areas may experience sudden vicious squalls and very rare tropical storms or cyclones.
Table 3-5 Northern and Southern boundaries of benign weather areas by month
Page 77 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Figure 3-1 Map showing benign weather areas
SECTION 4 Ballast and other systems
4.1 Introduction
4.1.1 Scope
4.1.1.1
This section includes general requirements to system and equipment design. It covers all (temporary) systems,
see [4.2.1.7], used during marine operations, with emphasis on ballast systems.
4.1.2 Revision history
4.1.2.1
This section replaces the following parts of the VMO Standard and the ND Guidelines:
• DNV, Marine Operations, General, DNV-OS-H101
• DNV, Load Transfer Operations, DNV-OS-H201
• GL Noble Denton, General Guidelines for Marine Projects, 0001/ND
• GL Noble Denton, Guidelines for Load-outs, 0013/ND
• GL Noble Denton, Guidelines for Float-over Installations / Removals, 0031/ND
4.2 System and equipment design
Page 78 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
4.2.1 General
4.2.1.1
Systems and equipment shall be designed, fabricated, installed, and tested in accordance with relevant codes
and standards.
4.2.1.2
Systems and equipment shall, as far as possible, be designed to be fail safe and arranged such that a single
failure in one system or unit cannot spread to another unit. The most probable failures, e.g. loss of power or
electrical failures, shall result in the least critical of any possible new conditions.
4.2.1.3
Alarm system(s) should be incorporated for essential functions and be audible/visible at operators’ station.
4.2.1.4
Work stations shall be arranged to provide the user with good visibility and easy access to controls required for
the operations.
4.2.1.5
Systems and equipment shall be selected based on a thorough consideration of functional and operational
requirements for the complete operation. Emphasis shall be placed on reliability and the expected behaviour in
possible contingency situations.
4.2.1.6
Depending on the complexity and duration of the operation, and the structure itself, risk evaluations may be
required to determine the systems and equipment required for a safe operation, see [2.4.2]. Such studies shall
include normal operations as well as emergency situations.
4.2.1.7
The following systems shall be considered where applicable:
1. power supply
2. fuel supply
3. electrical distribution systems
4. machinery control systems
5. alarm systems
6. valve control systems
7. bilge and ballast systems
8. compressed air systems
9. firefighting systems
10. Cooling systems
11. ROV systems
12. lifting systems
13. positioning systems, see Guidance Note
14. communications systems and
15. instrumentation systems for monitoring of;
◦ loads and/or deformations
◦ environmental conditions, such as tide
◦ ballast and stability conditions
◦ heel, trim, and draught
◦ position (navigation)
◦ tide
◦ under-keel clearance and
◦ penetration/settlements.
Guidance note:
Object guiding and positioning systems, including structural and functional requirements are covered in
[4.4]. If applicable, the requirements in this section should be considered regarding mechanical parts and
operation of such systems. Vessel position systems are described in Sec.17.
Page 79 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.2.1.8
Computerised control or data acquisition systems should be equipped with uninterruptible power supply system
(UPS).
4.2.1.9
All systems shall be inspected and tested according to [2.10].
4.2.1.10
Where a permanent system is complimented by a temporary system, the integration of the two systems shall be
inspected and tested according to [2.10].
4.2.2 Back-up
4.2.2.1
All essential systems, parts of systems or equipment shall have back-up or back-up alternatives. Necessary time
for a change over to the back-up system or equipment shall be assessed.
Guidance note:
It is recommended that the marine operation manual includes an inventory of main spare parts available on site.
It is also recommended to assess the necessity of having repair or service personnel available on site during
operations.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.2.2.2
All back-up systems should be designed and fabricated to the same standard as the primary systems.
4.2.2.3
Back-up systems should be adequately separated from the main system such that failure of any component does
not adversely affect the safe conduct of the operation.
4.2.2.4
For systems consisting of multiple independent units, back-up may be provided by havinga sufficient number of
available spare units available on site.
4.2.2.5
If umbilicals are necessary to provide power and/or hydraulic services during any marine operation, adequate
back-up capability shall be provided, and fail-safe systems shall be incorporated into critical controls.
4.2.2.6
Automatic control systems shall be provided with a possibility for manual overriding.
4.3 Ballasting systems
4.3.1 General
4.3.1.1
This sub-section is mainly applicable for ballasting and de-ballasting of vessel(s) involved in load transfer
operations.
Guidance note:
See [11.15] regarding pumping capacity requirements during voyages. For jacket installations additional
requirements apply, see [13.7.2]. For ballasting of (crane) vessels during lifting see Sec.16.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Page 80 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
4.3.1.2
Regardless of any requirement to change draught during construction, towage or installation operations, floating
structures should normally be fitted with a means of pumping out water from all compartments.
4.3.1.3
The (de)ballasting system design shall properly consider the operation class (see [4.3.2]) as well as functional
requirements related to:
• lay-out and reliability of the system
• tank capacities including contingency situations
• ballasting capacity including contingency situations
• strength limitations
• easily controllable ballasting
• tide
4.3.1.4
General requirements to (de)ballasting systems are given in [4.2.1].
4.3.1.5
Adequate testing of the ballast system considering the actual operation shall be carried out, see [2.10].
4.3.2 Ballast system power supply
4.3.2.1
Adequate power supply considering the actual operation shall be provided for the ballast system.
4.3.2.2
The need for emergency power supply due to the following situations shall be considered:
a. Breakdown of any one power unit
b. Breakdown of the common energy supply
c. Unexpected increase in the consumption of energy above the expected value.
Guidance note:
The back-up capacity for accidental conditions represented by a) and b) may be spare units in stand-by
position. The back-up capacity for conditions represented by c) may be spare capacity in the main unit or a
back-up unit installed to assist the main unit.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.3.2.3
Sufficient main and back-up power supply capacity should be documented by calculations.
Guidance note:
Necessary power supply for ballasting should be based in the required ballasting capacity given in Table 4-2 for
the relevant load-out class. For evaluations of back-up requirements, an independent power supply source
should be regarded as a “pump system”, see note 3) in Table 4-2.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.3.3 Operation classes
4.3.3.1
An operation class should be defined for load transfer operations see Table 10-1 for load-outs and Table 15-1 for
lift-off, mating and float-over operations.
4.3.4 Ballast system lay-out and reliability
4.3.4.1
Page 81 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
The ballast pumps may be the vessel’s internal pumps, pumps purposely installed for the operation/project, or a
combination of these. Internal vessel pumps that are not frequently in use, as the primary pumping means,
should be carefully considered and demonstrated fit for purpose.
Guidance note:
Internal vessel pumps can have unreliable service records. Also, permanent piping systems are inherently
inflexible.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.3.4.2
Where accurate control of the ballast amount is crucial, ballasting by flooding (i.e. opening of bottom valves)
and/or de-ballasting by air pressurisation (or ballasting by vacum – low pressure) of ballast tanks shall be avoided
during load transfer phases.
Guidance note:
Ballasting by flooding during load transfer phases where accurate control of ballast amount is crucial may be
allowed if the system has sufficient redundancy (e.g. double valves to compensate a failure to close a valve)
and/or back-up ballast plans are available where mechanical failures can be compensated by an alternative
ballast procedure.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.3.4.3
Umbilicals used for air pressurisation of submerged vessel compartments should be connected to valves at the
vessel tanks.
4.3.4.4
Where a compressed air system is used, the time lag needed to pressurise or de-pressurise a tank should be
taken into account, as should any limitations on differential pressure across a bulkhead. It should be
remembered that compressed air systems cannot always fill a tank beyond the external waterline. Air pressurised
vessel tanks shall be fitted with safety (pressure relief) valves.
4.3.4.5
Hoses, umbilicals and power cables shall be placed with due consideration to other ongoing activities during the
load transfer.
4.3.4.6
Required access throughout the load transfer for (possibly) needed equipment, e.g. fork lifts for replacing
pumps, should be demonstrated.
4.3.4.7
All internal compartments shall be cleaned of debris before ballasting starts.
4.3.4.8
When inlets are near the seabed, care shall be taken to avoid sucking in mud or sand that can block the pumping
systems or filters.
4.3.4.9
Where inlets or outlets are near the seabed, care shall be taken to avoid scour that could have adverse effects on
foundations of any structure or grounded vessel, or reduce under-keel clearances.
4.3.4.10
Except when in use for inlet or discharge, all openings to sea shall be protected by a double barrier.
4.3.4.11
Any external valves and pipework shall be protected against collision and fouling by towlines, mooring lines or
handling wires.
4.3.4.12
Page 82 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
All essential pipework in temporary systems should be of permanent-type construction and shall be
hydrostatically tested to a minimum of 1.3 times the design pressure. Temporary flexible hoses shall only be
used when a risk assessment, in accordance with [2.4], demonstrates the acceptability of the system.
Guidance note:
For offshore operations temporary flexible hoses are not generally permitted unless their use cannot be avoided,
for instance for supply of back-up compressed air from a compressor barge alongside.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.3.4.13
Permanent-type ballast sytems used in marine operations should fulfil the Class requirements for construction
and testing.
Guidance note:
For permanent ballast systems not subject to Class approval the requirement in [4.3.4.12] apply.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.3.5 Ballast tank capacity
4.3.5.1
The ballast tanks shall meet the capacity requirements in Table 4-1 for the required floating position(s)
throughout the operation for both planned and contingency situations.
4.3.5.2
A reasonable amount of residual water in the tanks should be taken into account.
Guidance note:
The amount to be considered will depend on details and location of the pumping intake(s), heel/trim of the
vessel and structural elements at the tank bottom. For tanks in use during the load transfer without any special
arrangements allowing easy tank stripping, the minimum water head should be taken equal to the height of the
tank bottom stiffeners plus 0.05 metres.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.3.5.3
The required tank capacities should include relevant spare capacity to compensate for the following:
a. Tide levels below or above the predicted values.
b. Total vessel weight, including vessellightship, consumables and temporaries (e.g. project equipment,
grillages, etc.), being higher or lower than expected
c. Possible object weight and CoG variations
d. Operational delays.
Table 4-1 Tank capacity requirements
Operation
Class
The tank capacity shall be adequate for the following scenarios (see Table 10-1 for load-out
classes and Table 15-1 for float-ons and float-offs).
All
• Normal (planned) operations
• Spare tank capacity to cover items [4.3.5.2] and [4.3.5.3] shall be ensured in all
situations.
• Any necessary pumping capacity contingency involving modifications in ballasting
procedures. See Table 4-2.
1
• See All
• Reversing of the operation. Tide compensation if stop of load transfer, considering
maximum possible (defined) duration of the load transfer.
2
• See All
• Ballasting through a complete tide cycle at any stage of the load transfer. Maximum tide
variations within the operation period (T ) shall be considered. Reversing of the
operation, if applicable.
R
Page 83 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
3
• See All
• Ballasting through a complete tide cycle at any stage of the load transfer. Maximum tide
variations for at least the coming 3-5 days shall be considered.
4
• See All
• Reversing of the operation, if applicable.
5 • See All
4.3.6 Ballast pumping capacity
4.3.6.1
The ballast pumping capacity shall meet the capacity requirements in Table 4-1 for the required floating position
(s) throughout the operation for both planned and contingency situations. Pump capacity shall be based on the
published pump performance curves, taking account of the maximum head for the operation and pipeline
losses.
4.3.6.2
Adequate capacity shall be documented considering the requirements to nominal, spare and back-up capacity
given in this sub-section.
4.3.6.3
The nominal ballasting capacity shall be determined by the worst combination of expected tide rise/fall and
planned load transfer velocity.
4.3.6.4
For operation classes 2 and 3, it shall be documented that the ballast systems have capacity to compensate for
the tide rise/fall through one complete tide cycle with the object in any position.
Guidance note:
If the tidal range increases in the days following the planned operation start, this should be considered when
evaluating the consequences of a delayed start or delays during the operation.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.3.6.5
Pumps which require to be moved around the barge in order to be considered as part of the back-up capacity,
shall be easily transportable, and may only be so considered if free access is provided at all stages of load-out
between the stations at which they may be required. Adequate resources shall be available to perform this
operation.
4.3.6.6
Spare pumps should normally be installed and tested in the position they are planned to be used as back-up.
However, for pumps that may be replaced during the operation, spare pumps in stand-by position that require
minimum replacement time may be used. Required number of spare pumps should be conservatively assessed.
The replacement time shall be documented. See [4.3.4.6].
4.3.6.7
Requirements for minimum total ballasting capacity, including back-up, are given in Table 4-2, including the
notes.
Table 4-2 Ballast pumping capacity requirements
Operation Class
Normal Operation
Load transfer as planned
Tide Compensation
Load transfer unexpectedly stopped
1
Minimum 200% capacity with intact
system and minimum 120% capacity in all
tanks with any one pump system failed.
Minimum 150% capacity with intact system
and minimum 100% capacity in all tanks
with any one pump system failed.
Page 84 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
2
Minimum 130% capacity with intact
system and minimum 100% capacity in all
tanks with any one pump system failed.
As for Class 1
3
Minimum 130% capacity with intact
system and a contingency plan covering
pump system failure.
As for Class 1
4 As for Class 2 No requirements
5 As for Class 3 No requirements
Notes:
1. 100% pump capacity during normal operation is the capacity required to carry out the operation at the
planned speed. The required pump capacity for a reduced speed could be acceptable as “100%”, if
ballast calculations are documented for this case, and the impact of the increased activity duration is
properly taken into account.
2. 100% pump capacity during tide compensation is the capacity required to compensate for the
maximum expected tidal rate of change.
3. A pump system includes the pump(s) which will cease to operate due to a single failure in any
component.
4. The back-up requirement X% capacity in all tanks could be covered by a modified ballast procedure
giving X% capacity in all tanks involved in this modified procedure.
4.3.7 Vessel strength considerations
4.3.7.1
All ballast conditions shall be checked against longitudinal strength requirements. Any hull beam strength
limitations shall be considered in the ballast procedure.
4.3.7.2
The effect of hull beam deflections on the object support load distribution shall be considered, see [5.6.11].
4.3.7.3
Differential pressures across bulkheads shall be demonstrated to be within allowable values.
4.3.7.4
Any restrictions, e.g. any requirement to mimic the vessel voyage condition, on ballast condition(s) during
welding of seafastening shall be considered.
4.3.7.5
Possible significant strength reduction due to cut outs (e.g. for ballast hoses, pumps or other equipment) in
structural elements shall be considered.
4.3.8 Ballasting control
4.3.8.1
A straightforward ballasting control system and procedure shall be used.
Guidance note:
It is recommended that it is possible to operate the ballast pumps from one control centre during operation. For
multi barge operations, a control centre on each barge may be applicable. However, the control centre at one of
the barges should be defined as the master ballast control centre. The arrangement should be such that
simultaneous de-ballasting can be effected for all the relevant tanks at each stage.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.3.8.2
It shall be thoroughly documented how the ballasting will be done (controlled) for all possible combinations of
tide level and load transferred.
Page 85 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
4.3.8.3
Each tank should preferably be used to compensate one effect (see Guidance Note) only. To use a system/tank
for compensation of more than two effects shall be avoided.
Guidance note:
In order to maintain maximum control with the ballasting it could be advisable to use separate systems/tanks for
compensation of the effects of tide variation, weight transferred, and CoG position in both directions (trim and
heel).
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.3.8.4
A ballasting control monitoring system including back-up shall be established. A communication system shall be
established when pumps are operated manually away from the control centre.
4.3.9 Ballast calculations
4.3.9.1
Ballast calculations shall be carried out in order to establish required nominal capacity (i.e. the 100% capacity,
see note 1 in Table 4-2) pumping capacities.
4.3.9.2
For ballast calculations the expected CoG and weight without any contingencies should normally be used as the
base case. However, the effect of possible weight and CoG variations shall be considered, see [5.6.2].
4.3.9.3
The ballast calculations shall include sufficient steps to accurately define the required ballasting throughout the
(load transfer)operation.
4.3.9.4
All considered contingency situations shall also be covered with an adequate number of ballast calculation steps.
4.3.9.5
The results of the ballast calculations, i.e. required pumping in all steps, shall be clearly outlined in ballast
procedure(s).
4.3.10 Contingency and back-up
4.3.10.1
Means for adequate handling of all ballast system contingencies identified in the risk management process shall
be provided.
4.3.10.2
The contingencies indicated in Table 4-3 shall be considered. Minimum requirements to back-up have also been
indicated.
Table 4-3 Contingency requirements
No Contingency situation Minimum requirement
1
Tidal velocities above (or below) the predicted
values.
Spare pump(s) or spare capacity in the main pump
(s). See Table 4-2 for specific requirements.
2
Unplanned stops in load transfer (e.g. object
movement stopped due to repair work, etc.)
Adequate tank and pump capacities to handle the
situation. See Table 4-1 and Table 4-2 for specific
requirements.
3 Reversal of operation, if required.
Ballast procedures/calculations with
corresponding pump lay-out and tank capacities
for this case shall be documented.
Page 86 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
4 Reduced pump capacity.
Spare pump capacity. See Table 4-2 for specific
requirements in %.
5 Breakdown of ballast pump(s).
Spare pump(s) or spare capacity in the main pump
(s). See Table 4-2 for specific requirements.
6 Breakdown of power supply, including cables.
Back-up required, see [4.3.2.2], or adequate
pump capacity, see Table 4-2, considering any
power supply unit failed shall be documented.
7 Failure of any control panel/switchboard.
Sufficient back-up to fulfil the requirements in
Table 4-2 for one pump system failure. Alternative
pump/valve control methods (locations and
procedures) could also be accepted as back-up.
See Notes.
8 Failure of any ballast valve or hose/pipe.
Notes:
1. All remotely controlled valves shall be capable of operation by a secondary, preferably manual system.
Any automatic or radio controlled system shall have a manual override system.
2. The secondary valve operation system may be by ROV, provided that ROV access and a suitable ROV
are available at all stages of the operation. The time for the ROV to get to and operate the valve shall
ensure that the valve can be operated before the flow through it is critical.
4.4 Guiding and positioning systems
4.4.1 General
4.4.1.1
This sub section applies for design and verification of (object) guiding and positioning systems to be used for
marine operations.
Guidance note 1:
Guiding systems are often designed with a primary and secondary system. The primary system is normally
designed to absorb possible impact energy, and provide guiding onto the secondary system. The secondary
system is normally designed to ensure accurate and controlled positioning of the object.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 2:
Additional operational specific guidance and requirements to guiding and positioning systems for lifting may be
found in [16.14]. Requirements to positioning systems for vessels are given in Sec.17.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.4.1.2
Guides and bumpers shall have sufficient strength and ductility to resist impact and guiding loads during
positioning without causing operational problems (e.g. excessive positioning tolerances), and without
overloading members of the supporting structure. Plastic deformation of guides and bumpers due to impact
loads may be allowed. The possibility and consequences of multiple impacts shall be considered.
4.4.1.3
After the design impact(s), guides and bumpers shall be able to resist loads due to the environmental conditions
during operation, and operational loads from tugger lines, mooring lines etc.
4.4.1.4
After the design impact(s), guides and bumpers shall also provide a positive clearance towards neighbouring
and supporting structure, and maintain their functionality.
4.4.1.5
DNV-RP-H102, /55/, Sec. 3.3.5 contains more recommendations and guidelines especially related to guiding
systems used during removal of offshore platforms.
4.4.1.6
Page 87 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
The stiffness of bumper and guide members should be as low as possible, in order that they may deflect
appreciably without yielding.
4.4.1.7
Design of bumpers and guides should cater for easy sliding motion of the guide in contact with a bumper.
Sloping members should be at an acute angle to the vertical. Ledges and sharp corners should be avoided in
areas of possible contact, and weld beads should be ground flush.
4.4.1.8
As-built bumper and guide dimensions shall be documented.
4.4.2 Characteristic loads
4.4.2.1
Characteristic impact loads for bumpers should be based on impact and deformation energy considerations.
Alternatively for lifts in air only, the characteristic guide loads may be calculated according to the simplified
method in [16.14.4].
4.4.2.2
Realistic impact velocities, impact positions and deformation patterns shall be assumed.
4.4.2.3
Characteristic loads for the guiding and positioning phase shall be based on environmental conditions during
operation, in addition to operational loads from tugger lines, mooring lines etc.
4.4.2.4
Combination of horizontal and vertical loads during guiding shall be considered in the design load cases.
Realistic friction coefficients shall be used.
4.4.2.5
Characteristic loads for positioning lines (tugger lines, mooring lines, etc.) and attachments (padeyes, brackets
etc.) shall be the expected maximum line tension. Possible dynamic effects shall be considered.
4.4.2.6
The characteristic loads shall be used as the basis for determining the maximum entry speed of the lifted object
into the guiding system.
4.4.3 Design verification
4.4.3.1
Structural strength of guiding and positioning systems should be verified according to Sec.5.
4.4.3.2
The connection into the object and the members framing the bumper or guide location should be at least as
strong as the bumper or guide.
4.4.3.3
The bumpers and guides shall be designed as either
• To the ASD/WSD approach LS2 or,
• To the LRFD approach ULS.
4.4.3.4
To avoid overloading the supporting structure it shall be designed either
• To the ASD/WSD approach LS1 or,
Page 88 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
• To the LRFD approach ULS with an additional load factor of 1.3.
4.4.3.5
Positioning padeyes should be designed to behave in a ductile manner in case of overloading.
4.4.3.6
Submerged brackets or padeyes shall be arranged such that failure will not breach any tank or compartment.
4.4.4 ALS conditions
4.4.4.1
If greater impact loads (velocities) than used in the ULS verification are considered possible, the guide system
should be verified for ALS.
4.4.4.2
If the ALS (impact) load considered can cause failure (extensive damage) in the guiding system, it should be
documented that installation of the object still will be feasible. Alternatively it should be possible to reverse the
operation and return the object to a safe condition.
4.4.5 Position monitoring systems
4.4.5.1
The positioning equipment system accuracy and redundancy shall be specified. System accuracy shall be
suitable for congested areas or where dimensional tolerances become tighter, e.g. for tie-ins, capture of docking
piles.
4.4.5.2
System redundancy shall be in accordance with [4.2.1.10] appropriate to safety criticality and operational
criticality requirements.
4.4.5.3
Sub-surfacepositioning of ROV’s or other targets shall interface with the surface positioning system and should
display on the same equipment. Subsea acoustic transceivers/beacons shall be separately identifiable and on
coordinated channels. Survey systems using line-of-sight shall recognise and cater for crossing surface vessels
possibly occluding the system. Survey systems should be commissioned and calibrated before start of
installation operations.
4.4.5.4
Normally, two independent on board positioning monitoring systems (PMSs) shall be utilized for operational
monitoring and control purposes. Both systems shall be in operation at any time, each serving as the back-up for
the other. Each should be fed by an independent power source.
4.4.5.5
Where underwater accuracy is important, at least one PMS shall be an underwater, hydro-acoustic reference
system.
4.5 ROV systems
4.5.1 Planning
4.5.1.1
ROV systems and tooling shall be selected based on the environmental conditions that are to be expected at the
worksite during the planned and contingency intervention/observation tasks.
Page 89 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
4.5.1.2
When planning for a subsea operation, the following ROV limitations and recommendations should be noted:
a. Minimum practical operational depth in the expected wave conditions, also considering possible wake
from vessel thrusters.
b. ROV working range, i.e. maximum horizontal offset vs. available tether length, considering the worst
expected current conditions.
c. Planning and design of the ROV operation shall as far as possible minimise the operational influence of the
ROV operator's skill and experience.
d. Poor visibility due to e.g. disturbed soil conditions, stirred up by contact or thruster or tool use close to
seabed.
e. Access to working site.
4.5.1.3
Planned ROV downtime and statistical uptime of ROV shall be taken into consideration when establishing T ,
see [2.6.3]. If statistical data for ROV uptime is not available a conservative estimate shall be made.
4.5.1.4
For subsea operations where the operation reference period (T , see [2.6.2])is based on using ROVs (i.e. ROV
activities are on critical path), ROV contingencies shall be documented and available. This can include a back-up
ROV spread on an independent system, i.e. there shall be no possible single failure identified that may cause an
unacceptable long downtime for both ROV spreads.
4.5.1.5
The need for backup of essential ROV tools shall be assessed, and if applicable, the time needed to switch ROV
tools/skids between ROVs shall be considered in the planning.
4.5.1.6
ROV tooling shall be provided with sufficient spares and back-up tooling to allow the work to proceed with
minimum delay.
4.5.1.7
For operations requiring assistance of both ROV(s) and diver(s), any restrictions on simultaneous working shall be
considered and be clarified in advance.
4.5.2 Stationkeeping and positioning
4.5.2.1
The stationkeeping capability and manoeuvrability of the ROV during operation shall be considered. If the ROV
is carrying equipment or is equipped with tooling packages/skids, this needs to be accounted for.
Guidance note:
Any ROV manipulator or tooling operation that requires the pilot to actively control the position of the ROV, e.g.
if the target is moving, during performance of the task should be avoided. See also 4.5.2.3.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.5.2.2
The required ROV thrust capacity shall be documented by verified capability plots (if available) and/or detailed
calculations considering:
• maximum current speeds at applicable depth(s), see 3.4.3.
• approprate drag areas and -factors for ROV, cable and any tools
• all relevant relative ROV and current directions
• need for spare capacity, to be at least 30% for crucial ROV operations.
Guidance note:
If detailed calculations are not made the horizontal current force on the ROV and the submerged cable may be
taken as:
[kN]
where
POP
R
Page 90 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
d = diameter of submerged cable [m]
l = projected length of submerged cable [m]
A = projected cross sectional area of ROV including any tools [m ]
v = maximum current velocity [m/s]
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.5.2.3
Grab bars to aid ROV positioning for manipulative or observation tasks should be provided where critical path
ROV operations are planned.
4.5.3 Testing
4.5.3.1
For complex and critical stages of the installation that are dependent on ROV operations, Client/Contractor shall
demonstrate ROV capability of executing the planned intervention. This can be demonstrated by used of 3D
models, mock-up tests, previous experience, etc.
Guidance note:
This may involve the manufacture of mock-ups. If mock-ups are used, great care shall be taken to ensure that the
mock-ups replicate the actual item.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.5.3.2
System Integration Testing should be carried out onshore to prove that the integration of all components and
tooling can be achieved.
4.5.3.3
Dry tests and FAT should be carried out for critical and complex systems, the failure of which would result in
significant and unacceptable schedule delay.
4.5.3.4
Before acceptance of ROV operations, maintenance records and dive logs for each ROV should be submitted.
Sufficient spares should be available.
4.5.4 Launch and recovery system
4.5.4.1
Once installed, the launch and recovery system (LARS) shall be load tested according to the applied
design/certification standard.
4.5.4.2
ROV launching and recovery restrictions shall be defined based on the capacity of the launch and recovery
system, including capacity of the umbilical. In addition any restrictions related to operational aspects need to be
considered.
Guidance note:
The following should be considered as rough guidance when establishing the ROV restrictions:
• The launch and recovery system should incorporate a (guide/cursor) system that ensures adequate
clearance with vessel side during lowering through the splash zone in the limiting wave conditions.
• Overboard launching and retrieval of large ROV's is not generally recommended to take place in sea
states exceeding 2.5-3.0 m (H ) if the ability to operate in a safe manner under more severe conditions has
not been documented. Higher waves may be applicable if the launch and recovery always may take place
on leeward, for Moon-pool ROV operations and if heavy weather side rail systems are used.
• High wind speeds, and operational aspects (e.g. risk of entanglement) may also be critical.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.5.4.3
cab
cab
ROV
2
cur
s
Page 91 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
The over-boarding system shall be safely operated within its intended design limit and due consideration of ROV
recovery needs to accounted for in the definition of the weather criteria.
4.5.4.4
Launch and recovery shall as much as practically possible take place at safe distance from sensitive subsea
infrastructure. See [5.6.6.6].
4.5.4.5
A tether management system (TMS) should be used in deep water sites to ease the deployment of the ROV to
the worksite. The tether shall be of sufficient length to allow the ROV to get from the TMS to the worksite.
4.5.5 Monitoring
4.5.5.1
Video monitoring of all subsea operations should in general be provided, e.g. ROV, diver-operated, etc. Any
critical part of the operation should be performed with such monitoring.
4.5.5.2
All diving and complex Work-ROV operations should be monitored by independentROV with monitoring as its
only task in the period it is carrying out such critical monitoring.
4.5.5.3
The ROV used for monitoring subsea operations should, as far as practically possible, be operated from the
installation vessel.
4.5.5.4
If the ROV operation has to be performed by a vessel other than the installation vessel, the stability and reliability
of the video-link system between the vessels shall be proven under the given conditions.
Guidance note:
Some operations can require a large horizontal distance between the installation vessel and the observation
ROV, thus necessitating a separate ROV vessel. The video-link should be tested before start of operation.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4.5.5.5
Means for locating and tracking of the ROV from the surface are required for navigational purposes and
emergency recovery.
4.5.6 Human factors
4.5.6.1
The feasibility of subsea operations often relies on the correct completion of tasks by ROV - it should therefore
be ensured that ROV operators have the necessary experience and skills.
4.5.6.2
If complex operations reliant on the skill of the ROV operator alone cannot be avoided, ROV operator experience
shall be evaluated. Training sessions specially adapted for the proposed operation can be appropriate.
4.5.7 Deepwater ROV operations
4.5.7.1
ROV equipment capacities shall be chosen to suit the relevant depth and consider the following:
• Both the ROV and any ROV tooling should be “depth rated”, and their stated depth limitation should not
be exceeded.
Page 92 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
• General wear on the complete ROV spread during deep water operations is more extensive than during
moderate depth operations, it is important therefore that all required maintenance is done before
operation.
• During deep water operations special attention shall be given to lubrication systems which can be affected
by the external water pressure.
4.5.7.2
Current forces acting on the umbilical and ROV shall be defined, see guidance note in [4.5.2.2].
4.5.7.3
Potential effects due to resonance in wires, cables, umbilicals, etc. shall be investigated and accounted for in the
design.
SECTION 5 Loading and structural strength
5.1 Introduction
5.1.1 General
5.1.1.1
This section addresses loading categorisation, load effects, load cases and load combinations.
5.1.1.2
The requirements for structural strength are given, mainly related to steel structures. For structures of other
materials, adequate safety levels shall be achieved by use of recognized standards.
5.1.2 Scope
5.1.2.1
This section presents the requirements for strength checking of steel structures using both Allowable Stress
Design (ASD) / Working Stress Design (WSD) and Load and Resistance Factor Design (LRFD). Alternatively,
probabilistic methods can be used.
5.1.2.2
The ASD/WSD and LRFD checks have differing inherent levels of safety. To compensate, this Standard has
differing requirements for the design loading. It is therefore important that the applied environmental loading is
determined using the return period applicable to the checking method selected.
5.1.3 Revision history
5.1.3.1
This section replaces the applicable sections of the legacy GL Noble Denton Guidelines and legacy DNV-OS-H-
series standards.
5.2 Design principles
5.2.1 Introduction
5.2.1.1
The object subject to marine warranty survey, together with the associated equipment shall be shown to possess
adequate strength to resist the loads imposed during the marine operation.
Page 93 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
5.2.1.2
The overall design shall be performed with due consideration to the execution of marine operations.
5.2.1.3
Structures shall be robustly designed such that an incident does not lead to consequences disproportional to the
original cause.
5.2.1.4
Simple load and stress patterns shall be aimed for in the design.
5.2.1.5
Structural elements should be fabricated according to the requirements given in DNVGL-OS-C401, /26/, or
another recognized standard.
5.2.1.6
Structural components and details should be designed so that the structure behaves, as far as possible, in a
ductile manner.
Guidance note:
A structure or a structural element, can exhibit brittle behaviour even if it is made of ductile materials e.g. when
there are sudden changes in section properties, when exposed to low temperatures.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.3 Specific design considerations
5.3.1 Connections
5.3.1.1
Connections should be designed with smooth transitions and proper alignment of elements. Stress
concentrations should be avoided as far as possible.
5.3.1.2
The transmission of tensile stresses through the thickness of rolled steel elements (plates, beams etc.) should be
avoided unless materials with proven (tested) z-quality are applied. Alternatively, the material can be subject to
non-destructive testing (NDT) using UT to demonstrate that it is free of laminations, see [5.10.2.3 5)].
5.3.1.3
Structural details above the still water level shall be so arranged that water will not be trapped in the structure if
this can cause damage such as e.g. rupture due to freezing of the water, when the operation is in an area and
season when this can occur.
5.3.2 Penetrations
5.3.2.1
The object shall be reinforced as necessary in the area adjacent to any penetrations (e.g. for risers or J-tubes)
below the water line against hydrostatic pressures and against accidental impact from dropped objects and
vessel impact if likely at any draught.
5.3.2.2
Penetrations shall be positively sealed to prevent the ingress of water whilst the structure is afloat.
5.3.3 Doubler plates
5.3.3.1
Doubler plates are generally recommended for use:
Page 94 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
• When attaching seafastenings or sacrificial anodes to permanent steel work subject to fatigue or if the
permanent structure could be damaged when the attachments are burnt off after use.
• To avoid welding onto other welds.
5.3.3.2
Doubler plates are generally NOT recommended for use when tension can cause overstress in the doubler plate
or the structure to which it is attached.
5.3.4 Tension connections
5.3.4.1
Where tension connections to a vessel deck are required, attention shall be given to the connection between the
deck plate and underdeck members. In cases of any doubt about the condition, an initial visual inspection should
be undertaken, to establish that fully welded connections exist, and that the general condition is fit for purpose.
Further inspection may be required, depending on the stress levels imposed and the condition found. See also
[5.10.2.3 5)] regarding through-thickness properties of the deck plate.
Guidance note:
The welds between vessel deck plates and under deck stiffeners/bulkheads (including cut out infills) are normally
small and can limit the capacity.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.3.5 Bolted connections for seafastening
5.3.5.1
Appendix [E.2] gives the requirements for bolted connections for seafastenings which involving cyclic loading
due to the dangers of progressive collapse.
5.3.6 Light-weight metallic and composite structures
5.3.6.1
The designers or manufacturers shall specify any handling/connection requirements which shall appear in the
relevant procedures and towing/transport manuals.
Guidance note:
Tugger line systems are especially important when handling light-weight alloy, composite and other items in
order to avoid any impact with seafastening,grillage or offshore structures which could cause plastic
deformations.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.3.6.2
The structural strength of objects of innovative design and/or material shall be documented.
Guidance note:
Particular attention should be given to local strength in way of supports, seafastening etc.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.3.7 Compressed air
5.3.7.1
Compressed air may be used to resist hydrostatic head on internal or external walls during ballasting, for
reducing draught, or for reducing overall bending moments by air cushions in skirt cells under well controlled
conditions. However its absence should not, in general, result in structural collapse i.e. it should be used only to
increase structural safety factors.
5.3.7.2
Where the requirements of [5.3.7.1] cannot be met, then a risk assessment shall be carried out to determine
possible causes and probabilities of loss of compressed air. Mitigating measures to reduce the risks to an
acceptable level shall be agreed with the MWS company.
Page 95 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
5.3.7.3
Some practical considerations on the use of compressed air are given in [12.6.2].
5.3.8 Inspection
5.3.8.1
Sufficient access for inspection, maintenance, and repair shall be provided during planning of the operation.
5.3.8.2
Instrumentation (monitoring) can be used as a supplement to other inspection, see [2.9].
5.3.9 Existing structures
5.3.9.1
Strength calculations for marine operations often include the verification of existing steel structures of e.g.
barges, other vessels and objects for dismantling. The calculations shall account for any reductions in the design
capacity. Examples of possible causes include:
• corrosion
• damage
• modifications not shown on drawings.
5.3.9.2
Existing structures should normally be inspected in order to assess possible reductions in the design capacity,
see [5.3.9.4], [5.9.8.4], [5.10.2.2], and [5.10.2.3 5)]. See DNV-RP-H102, /55/ for further guidance on existing
structures and their inspection.
5.3.9.3
Project related strength verifications of vessels should normally be carried out conservatively with either the as-
built thickness reduced to account for possible corrosion or based on detailed inspections including thickness
measurements. Where the thickness is reduced to account for corrosion the thickness used in calculations should
be the thickness indicated on the as-built drawings less the vessel’s class corrosion allowance, or reduced by 0.2
mm per year from each side. For new vessels with a proper corrosion protection system, e.g. painting or coating,
no thickness reduction need to be considered for the first five years of the vessel’s life.
Guidance note:
Typical corrosion allowance requirements can be found in the DNV GL Rules for classification: Ships, /35/, Jan
2015, Pt.3 Ch.3 Sec.3. Normally a total thickness allowance of 3 mm is applicable for the top 1.5 m of ballast
tanks.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.3.9.4
Weld capacity should be calculated according to [5.9.7.1] for ASD/WSD or [5.9.8.4] for LRFD, as applicable.
Guidance note:
When checking vessel welds the following should be noted:
a. Class acceptance for these welds can be required, especially for new/reinforced welds.
b. All loads (force components) normal to the deck plate should generally be considered transferred to the
under deck welds. However, when the force is only compressive, i.e. there is no tension force in any load
combination, this force component may be assumed to be transferred through direct contact between the
deck plate and the web frames/bulkheads, and the weld may be checked for shear stress only, see item f).
If the force varies between compression and tension, the weld should be able to transfer also the
compression force in order to ensure intact welds, unless the capacity of the seafastening system is
documented in ALS assuming that the connection under consideration is broken.
c. All loads (force components) parallel to the deck plate can be disregarded, see however item f).
d. The dispersion angle through the deck plate should be taken as maximum 45° unless a greater dispersion
can be justified.
Page 96 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
e. Size reduction due to possible corrosion should be considered. If not otherwise documented the size
should be as shown on the drawing less the Class corrosion allowance.
f. Note that shear stress in stiffener/girder welds due to local bending/shear in these should be included in
the equivalent stress (the effects due to global vessel behaviour can be ignored).
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.3.10 Protection against accidental damage
5.3.10.1
The structure shall be protected against accidental damage by application of the following two principles:
• reduction of damage probability
• reduction of damage consequences.
5.3.10.2
If damage to piping, equipment, structures, etc. could lead to severe consequences (e.g. accidental flooding,
explosion, fire or pollution) such items shall be protected to minimise the risk of accidental damage.
Guidance note:
Protection may be established by methods such as providing a sheltered location, by local strengthening of the
structure, or by appropriate fender systems.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.4 Testing
5.4.1 General
5.4.1.1
Testing can be used in order to establish or verify design parameters. Material and weld testing should be
carried out according to a relevant recognized standard, e.g. DNVGL-OS-C401, /26/, see also [5.10] which
summarises key requirements.
5.4.1.2
Adequate and reliable test data should be used to verify/correlate values that are considered unreliable based
on theoretically calculations only. This is particularly relevant for geometrically complex structures and for new
design or operational concepts.
5.4.1.3
For marine operations, such (project) specific testing is normally most relevant to determine or verify:
• response, e.g. motions by model testing,
• loads, e.g. by direct measuring of loads in model tests and
• resistance, e.g. by load testing or testing of friction.
5.4.2 Model testing
5.4.2.1
Model testing is most frequently used for the determination of response and loading effects but can also be used
for determination of structural resistance.
5.4.2.2
Model tests should be carried out according to a verified test program/procedure using:
• models representing the object(s), vessel(s) and real conditions as accurately as required,
• qualified test personnel,
• adequate testing facilities, and
• calibrated monitoring equipment with sufficient accuracy.
Page 97 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
5.4.2.3
Normally the testing should be combined with theoretical calculations.
5.4.2.4
The laws of similarity shall be considered in order to ensure that the quantities measured in the model test can
be correctly transformed.
5.4.2.5
Effects that can influence the measured quantities and that are not represented in the model test shall be
identified and the consequences of these effects should be evaluated.
Guidance note:
For example, the correct relative stiffness (of vessels/structures) will normally not be obtainable in model tests
and effects of this on the results should be evaluated.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.4.3 Full scale load testing
5.4.3.1
Full scale load testing should be carried out according to agreed procedures.
5.4.3.2
Requirements for standardised load testing, e.g. of lifting appliances,are not described in this standard. Such
testing should be carried out as described in the relevant standard, e.g. DNV 2.22, /16/, and DNV 2.7-3, /17/.
5.4.3.3
Full scale load testing may be carried out by loading test pieces to destruction. The characteristic strength
should normally be defined based on the 5 or the 95 percentile of the test results, whichever is the most
conservative.
5.4.3.4
If sufficient design documentation is not available to verify the strength (capacity) of an item, it can be acceptable
to document the strength of the item by means of a load test.
Guidance note:
Typical items for which this type of testing could be applicable include:
• Anchors for which no holding power calculations have been carried out.
• Shore bollards without relevant certificates or where the underground design and workmanship is not
documentation.
• Holding power of clamps or other types of connections.
• Local soil capacity (deflection), e.g. of load-out tracks.
• Existing (steel) structures with no/limited inspection access.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.4.3.5
For such tests the load should normally be at least 0.9 times the maximum design load (i.e. including load factor)
for the item. All relevant load directions should be tested.
5.4.3.6
A thorough inspection shall be carried out of items that have been subject to testing. Defects that could reduce
the strength (capacity) shall not be allowed.
5.4.4 Testing of friction
5.4.4.1
Testing may be carried out in order to establish applicable friction coefficients. The testing conditions should
represent the expected friction surface and load intensity as close as possible.
th th
Page 98 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
5.4.4.2
In marine operations the dynamic friction coefficient will normally be the most relevant and testing of this should
hence be included unless it is not needed for the particular application.
5.4.4.3
Where testing is carried out, a detailed test procedure shall be documented.
Guidance note:
The test procedure should consider the following:
a. Possible variations in applicable conditions (e.g. wet and dry surfaces). See [5.4.4.1] and [5.4.4.2].
b. Dynamic friction, if applicable, should be tested and measured by a recognised method.
c. The characteristic friction coefficient should be defined based on the 5 or the 95 percentile confidence
level of the test results, whichever is the most conservative.
d. At least 5 test pieces should be made, and each tested at least twice for each actual condition.
e. The design friction coefficient is calculated using the characteristic friction coefficient and an appropriate
material factor. See [5.9.8.6], [5.9.5.3] and [5.9.6.2].
f. Where fewer tests are performed e.g. because of the scale, more conservative material factors should be
used.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.5 Load categorisation
5.5.1 Introduction
5.5.1.1
This section defines load categories and describes loads of general interest for marine operations.
5.5.1.2
The appropriate characteristic value should be defined (calculated) for all relevant loads.
5.5.1.3
More detailed descriptions of the loads to be considered are given for each type of marine operation/object
type in Sec.6 to Sec.18.
5.5.1.4
See [5.6] for load combinations, [5.7] for the failure modes to be considered, [5.8] for guidance on analytical
models and [5.9] for strength assessment.
5.5.2 Load categories
5.5.2.1
Loads and load effects shall be categorised as follows:
• Permanent Loads - G
• Variable Functional Loads - Q
• Deformation Loads - D
• Environmental Loads - E
• Accidental Loads - A.
5.5.2.2
The characteristic values of loads shall be selected as indicated in Table 5-1 for all applicable loads.
Table 5-1 Characteristic load selection
Load category
Limit states – Temporary design conditions
ULS FLS
ALS
SLSIntact
structure
Damaged
structure
th th
1)
2)
Page 99 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Variable (Q)
Specified
value
Specified
load history
Specified value(s)
Environmental (E) –
Weather restricted
Specified
value
Specified
load history
NA
Specified value(s)
Environmental (E) –
Weather unrestricted
Operations
Based on
statistical
data
Expected
load history
Based on statistical data &
Accidental (A) NA NA
Specified
value
NA NA
Deformation (D)
Expected
extreme
value
Expected
load history
Specified value(s)
Notes:
1. See [5.5.3] to [5.5.7] for definitions of load categories
2. See [5.9.1.3] for definitions of limit states.
3. The specified value (load history) shall, if relevant be justified by calculations. See also [5.6.6].
4. See [2.6.6]
5. See Sec.3.
6. Joint probability of accident and environmental condition could be considered.
5.5.3 Permanent loads (G)
5.5.3.1
Permanent loads are loads which will not be moved or removed during the phase of the marine operation being
considered. Such loads can be due to:
• weight of stationary structures
• weight of permanent ballast and equipment that cannot be removed
• external/internal hydrostatic pressure of permanent nature
• pretension.
5.5.3.2
Characteristic permanent loads shall be based on reliable data. For weight see [5.6.2].
5.5.4 Variable functional loads (Q)
5.5.4.1
Variable functional loads are loads that can be moved, removed or added. Such loads can be due to:
• operation of winches
• pull/push forces
• weight of moving structures
• loads from adjacent vessels
• ballasting
• operational impact loads
• stored materials, equipment or liquids.
5.5.4.2
Characteristic variable functional loads shall be specified with maximum and minimum values, which shall be
considered as necessary to determine the worst case(s).
5.5.5 Deformation loads (D)
5.5.5.1
Deformation loads are associated with inflicted deformations. Such loads can be caused by:
• installation or set down tolerances
• barge hull beam global deformations caused by moving ballast water (or temperature)
2) 2)
2)
4) 5)
5) 6)
Page 100 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
• structural restraints between structures
• differential settlements
• temperature deformations.
5.5.5.2
Characteristic deformation loads shall be maximum or minimum specified values, which shall be considered as
necessary to determine the worst case(s). The specified values shall, if applicable, be based on results from
analysis considering extreme conditions.
5.5.6 Environmental loads (E)
5.5.6.1
All loads caused by environmental phenomena shall be categorised as environmental loads. Such loads can be
due to phenomena including:
• wind
• waves
• current
• storm surge
• tide
• ice.
5.5.6.2
Where applicable, see [5.6.11], seafastening (and grillage/cribbing) reactions due to barge hull beam global
deformations caused by waves should be considered as environmental loads. See also [5.6.17].
5.5.6.3
Gravity load components caused by the roll and pitch angles of a floating object due to wind and waves, shall be
categorised as environmental loads.
5.5.6.4
The environmental design loads shall be calculated based on a process involving, as applicable:
• definition of characteristic conditions - see [2.2.7]
• calculation of characteristic loads – see [5.5] and [5.6]
• load analysis - see [5.6.2] to [5.6.11]
• motion analysis - see [5.6.12]
• selection of load cases - see [5.6.13]
• load factors - see [5.9].
5.5.7 Accidental loads (A)
5.5.7.1
Accidental loads are loads associated with exceptional or unexpected events or conditions. Such loads can be
due to:• collisions from vessels
• dropped objects
• loss of hydrostatic stability
• flooding
• loss of internal pressure.
5.5.7.2
Characteristic accidental loads shall be based on realistic accidental scenarios. See also [5.6.6].
5.6 Loads and load effects (responses)
5.6.1 General
Page 101 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
5.6.1.1
This section describes the loads and load effects that should be considered.
5.6.2 Weight and centre of gravity (CoG)
5.6.2.1 Introduction
1. For calculation purposes, conservative values of weight and CoG should be used.
2. Weight control shall be performed by means of a well-defined and documented system, complying with
ISO 19901-5 – Weight control during engineering and construction, /99/.
3. ISO 19901-5 states (inter alia) that:
◦ “Class A (weight control) will apply if the project is weight or CoG-sensitive for lifting and marine
operations or during operation (with the addition of temporaries), or has many contractors with
which to interface. Projects may also require this high definition if risk gives cause for concern”.
◦ “Class B (weight control) shall apply to projects where the focus on weight and CoG is less critical for
lifting and marine operations than for projects where Class A is applicable”.
◦ “Class C (weight control) shall apply to projects where the requirements for weight and CoG data
are not critical”.
4. Class A weight control shall apply unless it can be shown and agreed with the MWS company that a
particular structure and all its marine operations are not weight or CoG sensitive.
5. Weight reports should be issued in accordance with Section 6 of /99/. Contents and format of weight
reports that are not in accordance shall be agreed with MWS company at an early stage of the project.
5.6.2.2 Weight considerations
1. An upper bound design weight (W ) shall be defined for all operations. Where the minimum weight could
be critical in an operation e.g. voyage motions, a lower bound design weight (W ) shall be defined.
Guidance note 1:
The upper/lower bound design weights are normally defined to cover the expected range of weights in
the weight report with additional margins to account for uncertainties during the design process and the
factors in [2)] or [5.6.2.2 3)] for unweighed and weighed objects respectively.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 2:
Where a Not To Exceed (NTE) weight has been defined and used as the upper bound design weight the
actual maximum permissible value is less than the NTE weight.
In addition to any in-place considerations, the following can control the NTE weight:
◦ Draught and stability for tow-out, towages, mating operations and installation;
◦ Allowable stresses in the structure for marine operations;
◦ Limitations due to crane, load-out trailers, other equipment or ground-bearing capacity.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2. Where an object (excluding piles) is not to be weighed, the following shall be true for the as-built weight
report:
W ≤ W /γ
W ≥ W γ (where applicable)
Where:
W
= Factored weight in weight report
W
= Base weight in weight report
W = Upper bound design weight
W = Lower bound design weight
γ = Unweighed object weight margin factor as per Table 5-2
3. Where an object (excluding piles) is to be weighed, the following shall be true for the final weighed
condition corrected for any post weighing modifications:
W ≤W /γ
W ≥ W γ (where applicable)
Where:
W = Net weight in weight report
W = Upper bound design weight
W = Lower bound design weight
γ = Factor to account for weighing equipment inaccuracy i.e. ( )
ud
ld
Report, Factored ud Weight
Report, Base ld Weight
Report,
Factored
Report,
Base
ud
ld
Weight
Weighed ud Weighing
Weighed ld Weighing
Weighed
ud
ld
Weighing
Page 102 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
4. The weight contingency factors for piles shall be agreed with the MWS company and shall consider the
following as a minimum:
◦ plate thickness tolerance
◦ fabrication tolerances.
Table 5-2 Unweighed object weight margin factors
Weight Class
(as defined by ISO 19901-5, /99/)
γ
A 1.05
B and C 1.10
5.6.2.3 Centre of gravity factors
a. For weight Class A and B structures, see [5.6.2.1 3)], a CoG envelope shall be applied to allow for CoG
inaccuracies. For Class C structures a CoG envelope is recommended.
b. The size of the CoG envelope should reflect the operational and structural sensitivity to CoG variations and
the most conservative centre of gravity position within the envelope should be taken.
Guidance note 1:
For early design stages, too small an envelope should be avoided and envelope sizes should generally be
no less than 0.05L x 0.05B x 0.05H, where L, B and H are the Length, Breadth and Height of the structure.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 2:
For operations with a linear relation between shift in CoG and resulting load effects, or operations less
sensitive to CoG shifts, the inaccuracy in estimated CoG may alternatively be accounted for by an
inaccuracy factor applied to the weight. This factor should normally not be taken less than 1.05.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
c. For Class C, if a CoG envelope is not used then a CoG inaccuracy factor of 1.10 shall be applied to the
weight. Where it can be documented that a lower CoG inaccuracy factor is applicable, this should be
agreed with the MWS company.
d. The CoG contingency factors for piles shall be determined considering the pile length and the plate
manufacturer’s plate thickness tolerance specification.
e. Normal weighing operations can be used only to identify the CoG position in a horizontal plane.
Consequently, inaccuracies in the vertical CoG position should be specially considered for operations that
are sensitive to the vertical CoG position. If applicable the vertical CoG can be verified by means of an
inclining test (see [2.10.5]).
5.6.2.4 Weight control
a. The actual weight and CoG position shall be determined by weighing unless agreed otherwise with MWS
company.
Guidance note:
Gravity based structures and launched jackets are generally excluded from being weighed.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
b. A weighing procedure for the structure shall be produced and include the specification, including
accuracy, for all equipment. The accuracy of the weighing equipment shall be certified by a Competent
Body. The weighing should preferably be carried out a minimum of 3 times with the load cells
interchanged between each of the weighing operations.
c. Before any structure is weighed, a predicted weight and CoG report shall be issued, so that the weighed
weight and CoG can immediately be compared with the predicted results. The cause(s) of significant
deviations between the weighed and predicted results (both weight and CoG) shall be investigated and
reported.
d. Where weight is added to/removed from the structure after weighing, a weight control system shall be
adopted to ensure that the weight and CoG details based on the weighing are updated with any changes.
The weight changes due to items that are added and removed shall include their weighing contingency
factors.
e. The final calculated or weighed weight and CoG values shall be documented. Where the calculated or
weighed weight, including weighing and contingency factors, or the CoG is outside the design values
considered, the effects of the deviations shall be quantified and the operational procedures and
documents modified as required.
f. When the installation of a large number of nominally identical items is to be approved, the weight control
programme should bedocumented to show the effects of all potential variations on the final weights and
the results documented by a competent person.
Weight
Page 103 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
g. See [18.2.1.2] for weight control for decommissioning/removal.
5.6.2.5 Buoyancy
a. Buoyancy (hydrostatic external load) normally counteracts another load and shall be categorised
accordingly.
b. Where the buoyancy or distribution of buoyancy is critical to the marine operation, the dimensional and
buoyancy control and monitoring shall be maintained to an appropriate degree of accuracy.
c. The buoyancy of the object and the position of the centre of buoyancy should be determined on the basis
of an accurate geometric model.
d. Characteristic buoyancy loads should be based on maximum and/or minimum expected values.
e. Buoyant cargoes, particularly where the buoyancy contributes to stability requirements, shall be
adequately secured against lift-off unless it can be shown that lift-off will not occur.
5.6.3 Wind loads
5.6.3.1
Wind loads shall be calculated based on the characteristic wind speed, see Sec.3, and recognised calculation
methods.
5.6.3.2
Wind induced loads shall be based on projected area. The total wind load shall consider both lateral and parallel
load components.
5.6.3.3
The possibility of lift effects and their magnitude shall be considered.
5.6.3.4
The gravity components due to wind induced heeling shall be considered.
Guidance note:
DNV-RP-C205, /46/, gives further information with respect to shape coefficients as well as to effects of wind
direction relative to member, solidification and shielding.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.6.4 Current loads
5.6.4.1
Current loads shall be calculated based on the characteristic current velocity, see Sec.3, and recognised
methods.
5.6.4.2
The increase in current velocities/loads due to shallow waters or narrow channels shall be considered.
Guidance note:
DNV-RP-C205, /46/, gives further information with respect to shape coefficients as well as to effects of flow
direction relative to member, solidification and shielding.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.6.5 Wave-current loads
5.6.5.1
Combined wave-current induced drag loads shall be calculated considering the vector sum of the current and
wave particle velocities.
5.6.5.2 First order wave loads
a. Wave loads should be estimated according to a deterministic or stochastic design method. A wave period
range according to [3.4.11.5] and [3.4.11.2] should be investigated.
Page 104 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Guidance note:
If any responses are found governing for the response should be checked in these
areas with
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
b. Wave loads shall be determined using methods applicable for the location and operation, taking into
account the type of structure, its size and shape and its response characteristics.
c. The effects of wave elevation shall be evaluated, and if necessary included in the design.
d. Wave slamming, see [5.6.5.4], hydrodynamic and hydrostatic loads on members protruding over the
vessel side shall be considered. The effect of such loads on the motion characteristics and on the
seafastenings and grillage/cribbing shall be taken into account.
5.6.5.3 Second order wave loads
a. Second order wave drift forces can be important in the design of some marine operations. The effects of
second order drift forces shall be considered in these cases, which include large volume structures,
mooring and positioning systems, towing resistance estimates, etc. Second order wave loads consist of
mean wave drift forces and slow varying wave drift forces.
b. Long period responses excited by slow drift forces shall be investigated.
5.6.5.4 Slamming loads and breaking waves
a. Cargo overhangs and elements in the splash zone or overhanging the periphery of the floating body shall
be investigated with regards to possible slamming loads and/or immersion.
b. The effect of shock pressures on surfaces in the splash zone, caused by breaking waves, shall be
investigated for conditions up to the design sea state for all headings.
c. Loads due to slamming and breaking waves should normally be calculated according to DNV-RP-
C205, /46/.
Guidance note:
Further information regarding slamming loads and breaking waves can be found in DNV GL Rules for
classification: Ships /37/ Pt.3 Ch.10 and NORSOK N-003, /111/.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.6.5.5 Green water
a. The possible effects of green water (extensive amounts of water on deck due to waves), shall be
considered. The effects on both the structure and stability (weight and free surface) shall be investigated.
Guidance note:
See e.g. NORSOK N-003, /111/, for further information regarding green water effects. Design forces for
sea pressure from green water can be based on requirements for deck houses, see DNV GL Rules for
classification: Ships, /36/, Pt.3 Ch.4 Sec. 5.3.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
b. Deck cargoes vulnerable to damage from green water on deck should be protected by breakwaters or
increasing freeboard.
5.6.5.6 Swell
a. The effects of loads and motions due to swell shall be considered. See [3.4.14] and [5.6.18]. Swell can be
governing for operations designed for small irregular waves (e.g. weather restricted tows). In such cases
swell operational limits and forecasting shall be established.
5.6.6 Accidental loads
5.6.6.1
Accidental loads should be defined based on relevant accidental scenarios. In many cases the probability of
accidental scenarios can be reduced to a level such that there is no need to consider them further.
5.6.6.2
The accidental load design principles indicated in DNV-OS-A101, /40/, should be considered as applicable for
the planned marine operation. DNVGL-RP-C204, /31/, gives further guidance related to design philosophy and
calculation of relevant accidental loads due to e.g. collisions and dropped objects.
Page 105 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
5.6.6.3
Load effects due to all possible accidental scenarios/conditions shall be considered. Accidental cases and
contingency situations may be defined or excluded based on results from HAZOP’s or risk
evaluations/assessments.
5.6.6.4
DNV-OS-A101, /40/, is, in general, based on annual probabilities, whilst this Standard is based on probability per
operation. This can be considered when the (magnitude of) applicable accidental loads are defined. However,
unless a justification for lower loads is documented the loads indicated in DNV-OS-A101, /40/, should be
considered.
5.6.6.5 Vessel collision
a. Characteristic collision loads shall be estimated from energy considerations. Estimates of the collision
energy should be based on reasonable assumptions of possible collision scenarios, velocities, directions,
ship or object type, size, mass and added mass. Estimates of deformation energy should be based on the
most likely impact points and probable deformation patterns.
b. The behaviour of the vessels or structures during the impact, and thus the distribution of impact energy
between kinetic rotation and translation and deformation energy, should be considered by dynamic
equilibrium or energy considerations.
c. Local effects (deformation, damage, etc.) and global load effects (acceleration, global stress, etc.) shall be
considered.
Guidance note:
In some cases collisions will have been covered under the design and classification of the vessel.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---5.6.6.6 Dropped objects
a. Loads caused by dropped objects can be relevant for some ALS load cases. The characteristic load due to
a dropped object should be based on the weight of objects that could fall and their potential fall height.
b. For objects falling through water maximum possible impact velocity should be considered. The maximum
velocity is normally the terminal (free fall in water) velocity. See DNV-RP-H103, /56/, [4.7.3.5] and DNV-RP-
F107, /52/, [5.3] for guidance.
c. Loads on subsea items due to dropped objects may be ignored if operations that could cause dropped
objects are carried out at a safe distance. The safe distance should be calculated considering the
maximum possible dispersion angle for each type of object falling through the water. The effect of current
should be considered. Risk analysis may be used in order to eliminate physical possible high dispersion
angles by showing that the risk of hitting specified critical locations is acceptably low for such high angles.
See DNV-RP-F107, /52/, for further risk assessment guidance. If detailed assessments are not made, the
safe distance can normally be taken as the larger of 50 meters or that determined from a dispersion angle
of 20° to the vertical.
5.6.6.7 Other causes
a. Other relevant accidental loadings shall be considered. These can include, but are not limited to, cases
such as: “one line broken”; “one compartment damaged”; malfunction of critical systems e.g. heave
compensation, leaking valves; erroneous operation e.g. the use of the wrong valve; unexpected values of
parameters e.g. deformations, friction, vessel GM, tidal variation, weights & CoG’s, etc.
b. The static loads resulting from any one compartment damage, as described in [11.10.4] to [11.10.7], shall
be considered and, if significant, designed for as a LS2 or ULS case.
5.6.7 Dynamics
5.6.7.1
The potential for dynamic response shall be investigated, and the effects shall be included in the design analysis
when they are of significance. Dynamic response is typically caused by wave forces, wind loads (gusts), vortex
shedding in air or water, slamming loads, etc.
5.6.7.2
Dynamics shall be investigated by recognised methods using realistic assumptions for the natural period,
damping, material properties etc.
5.6.7.3
Page 106 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
The response to dynamic effects e.g. structural stress and deflections can be relevant for all Limit States.
5.6.7.4
Means of determining whether vortex shedding could be critical for any particular member are contained in
Section 9 of “DNV-RP-C205 Environmental Conditions and Environmental Loads”, /46/ and Section 7.2 of
“Dynamics of Fixed Marine Structures” - Barltrop and Adams, /122/.
5.6.8 Non-linearities
5.6.8.1
Non-linear effects shall be considered in cases where these significantly influence the estimated responses. Non-
linear effects are typically caused by:
• non-linear materials
• non-linear geometry (large-displacement effects)
• non-linear damping
• non-linear combination of load components or response components
• wave elevation e.g. due to wave-in-deck, non-linear effects of drag-loading (especially with current), etc..
5.6.8.2
Non-linear load effects due to combinations of environmental loads should be taken into account e.g. wave-
current drag forces are a function of the square of the sum of the wave and current particle velocities.
5.6.9 Friction
5.6.9.1
Possible unfavourable effects of friction shall be considered. Well documented favourable effects of friction may
be included in the design.
5.6.9.2
A friction coefficient range, i.e. both a maximum and a minimum friction coefficient, should be considered in the
design calculations or it should be proven that a conservative minimum (or maximum) coefficient suffices.
5.6.9.3
The characteristic friction coefficient range shall be defined according to recognised industry standards or tests,
see [5.4]. Indicative operation-specific values are given Table 10-2, [11.9.2], Table 11-8, Table 11-20, Table 13-5
and in DNV-RP-H102, /55/, Table 2-4. For soil-material interfaces, guidance is provided in DNV-RP-F109, /53/,
Section 3.4.6 and DNV-RP-F105, /51/, Section 7. Pipe-Soil Interaction.
5.6.9.4
The lower bound design friction coefficient (μ ) shall be the lower bound characteristic value (μ ) divided by a
material factor.
5.6.9.5
The upper bound design friction coefficient (μ ) shall be the upper bound characteristic value (μ ) multiplied by
a material factor.
5.6.9.6
The appropriate material (safety) factor for friction shall be selected dependent upon the limit state considered
and the risk involved in exceeding (or going below) the design friction. See [5.9.7] or [5.9.8.6], [5.9.5] and [5.9.6].
These are also applicable to both ASD/WSD.
5.6.9.7
The minimum design friction force shall be taken as the minimum design load (i.e. including relevant load
factors) perpendicular to the friction surface multiplied by μ .
ld lc
ud uc
ld
Page 107 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
5.6.9.8
The maximum design friction force shall be taken as the maximum design load (i.e. including relevant load
factors) perpendicular to the friction surface multiplied by μ .
5.6.9.9
If the friction coefficient range is based on uncertain data the consequences of the maximum possible variation in
friction coefficients shall be evaluated. See [5.6.14].
5.6.9.10
Vibrations, varying or uncertain surface conditions etc. affecting the friction shall be considered.
5.6.9.11
Restraint effects caused by combination of friction and global deflections shall be considered.
5.6.10 Tolerances
5.6.10.1
Loads caused by operational or fabrication tolerances exceeding the tolerances stated in the design
standards/codes shall be considered. Typical examples include:
• set-down tolerances (load-out, positioning)
• shimming tolerances
• uncertain deformation (in load distributing material)
• fabrication tolerances, see [5.10.1.4].
5.6.10.2
Loads caused by effects described in [5.5.5].
5.6.11 Relative deflections
5.6.11.1
The effects of relative deflections between structures shall be considered and included in the design whenever
applicable. These can be of particular significance when they induce loads in connections and supports such as
grillages and seafastenings. The causes of relative deflections include:
• vessel deflection (longitudinal bending) in waves,
• ballasting, de-ballasting or re-distribution of ballast,
• temperature differences,
• relative deflections that need to be considered during the operation.
5.6.11.2
For sea voyages the potential effects of longitudinal wave bending effects should always be considered when:
a. The towed hull is not a classed, seagoing vessel or barge, or
b. The cargo is longer than about 1/3 of the transport barge or vessel length, or
c. The cargo is supported longitudinally on more than 2 groups of supports, or
d. The relative stiffness of the hull and cargo could cause unacceptable stresses to be induced in either, or
e. The seafastening design allows little or no flexibility between cargo and vessel.
5.6.11.3
Some cargoes, such as large steel jackets, can be inherently much stiffer than the barge, and will reduce vessel
deflections, at the expense of increased cargo stresses.
5.6.11.4
See also [11.9.3.2] for friction, [11.9.5] for seafastening design and [11.27.4.3] for jack-ups.
5.6.11.5
The restraint loads should be defined in the same category as the load that causes the relative deflections, i.e.
ud
rd
Page 108 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...restraint loads caused by environmental conditions should be defined as E-loads, see [5.5.6].
5.6.12 Motion analysis
5.6.12.1 General
1. Motions of floating objects shall be determined for the relevant environmental conditions and loads. These
may be from simplified conservative estimates, however it is normally recommended that the analysis (and
tests) described in this sub-section are carried out.
Guidance note:
Detailed analyses and model tests are not normally needed for the transportation of smaller cargoes on
standard vessels.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2. Inertia loads due to motion should be calculated for all six degrees of freedom.
Guidance note:
This includes also an evaluation of mass (rotational) inertia effects from roll and pitch. These effects should
as a minimum be quantified, and the effect evaluated. This is particularly relevant for barge voyages with
large roll motions.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
3. Testing of models, see [5.4.2], or full scale structures, see [5.4.3], may be carried out where the accuracy of
theoretical approaches is uncertain, or where the design is particularly sensitive for motions.
Guidance note:
Estimation of motions from model testing or by theoretical calculation has associated advantages and
disadvantages. The two approaches are generally to be considered as complimentary rather than as
alternatives.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4. It is recommended that theoretical calculations are correlated against relevant model test data (if available)
in cases where strongly non-linear behaviour is expected. Such cases can occur when, for example:
◦ overhanging cargo is occasionally submerged, or
◦ there are large changes in the waterplane area with draught.
5. The analytical models should be checked with respect to sensitivity to input parameters, see [5.6.14].
6. Recognised and well proven six-degree of freedom linear or linearized computer programs, utilising the
strip theory or 3D sink source techniques are generally recommended. Special consideration shall be
given to non-linear damping effects. The effect of forward speed shall be evaluated, where this is more
onerous.
7. Computer programs shall be validated against a suitable range of model test or full scale results in
irregular seas. When using new software or for new or unconventional applications or new problems, this
validation shall be documented. Similarly justification of drag coefficients, added mass and damping shall
be documented.
Guidance note:
Guidance on drag and added mass coefficients for a range of standard shapes can be found in DNV-RP-
C205 /46/.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
8. First-order motion response analysis program generally report heave in a global fixed axis system. In these
cases heave shall be assumed to be parallel to the global vertical axis and therefore the component of
heave parallel to the deck at the computed roll or pitch angle (theta) is additive to the forces caused by the
static gravity component and by the roll or pitch acceleration.
9. In general, motion response calculations should be based upon a 3D panel model of the vessel. If a 2D
strip theory model is used, the computer program needs to include the proper treatment of head/stern
sea wave excitation loads. Simplified calculations should only be applied for non-critical routine operations
or screening purposes.
5.6.12.2 Wave headings
a. The full range of wave headings shall be analysed. Spacing between the analysed wave headings should
not exceed 45°.
Guidance note:
For the cases where reduced design wave heights are acceptable from some headings, see [11.8], this
applies to all headings. However, symmetry can be considered when relevant provided appropriate
means of accounting for cargo CoG offset are included.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Page 109 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
b. Short crested sea shall be considered for wave analysis where all headings are not carried out with equal
wave heights i.e. typically motion analysis in order to find limiting installation wave heights for different
vessel headings.
Guidance note:
If short crested waves are considered the spacing between analysed wave headings should normally not
exceed 22.5°. See also [3.4.12].
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
c. Short crested sea may be considered for wave analysis where all headings are included with equal wave
height i.e. typically motion analysis for sea voyages without any heading restrictions.
5.6.12.3 Wave periods
a. A wave period range with corresponding wave heights, see [3.4], shall be considered when evaluating
characteristic motions and accelerations.
5.6.12.4 Response amplitude operators (RAO’s)
a. RAO’s for the basic six degrees of freedom can be utilised to calculate displacements, velocities,
accelerations, and reaction forces for points in a body fixed co-ordinate system, or to establish RAO’s for
these points. These RAO’s may be used for calculation of significant and maximum responses.
b. When combining different responses, the phase angle between the different components may be
considered.
c. The gravity component shall be considered when determining the RAO’s for inertia loads (e.g. transverse
accelerations).
5.6.13 Load cases and load combinations
5.6.13.1
Loads and load effects shall be combined to form load cases that are applicable to and physically feasible for the
actual object(s) and type of operation under consideration.
5.6.13.2
All possible load cases which can influence the feasibility of the marine operation shall be considered in the
design.
5.6.13.3
Characteristic loads may be combined taking into account their probability of simultaneous occurrence.
5.6.13.4
Characteristic static (mean) load components and characteristic dynamic (varying) load components which are
statistically independent may be combined according to the formulae below.
where
F = Characteristic static load components
F = Amplitude of dynamic load components
Guidance note:
Dynamic load components in the above formulae are normally restricted to loads with periods less than
10 minutes. The maximum values of dynamic loads with periods greater than 10 minutes are normally added as
static loads (i.e. F equal to the maximum load, and F =0).
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.6.13.5
Correlated dynamic load components shall be added as vectors, unless statistical data of simultaneous
occurrence are available. Load components due to first order motions should be considered to be correlated.
The combination of these components is described in [5.6.15.2] and [5.6.15.4].
i,mean
i,amp
i,mean i,amp
Page 110 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
5.6.14 Sensitivity analysis
5.6.14.1
The load cases shall include a parametric sensitivity analyses whenever a single load or parameter significantly
affects the design or selection of the method or equipment to determine whether small changes significantly
affect the design.
5.6.14.2
Where the operational safety is critically dependent on a sensitive input, conservative characteristic values shall
be used.
5.6.15 Loads due to motions and wind
5.6.15.1
Load cases for each heading shall be derived by the addition of fluctuating loads resulting from wind and wave
action to static loads resulting from gravity and still water initial conditions.
5.6.15.2
In lieu of a refined analysis the worst possible combination of the individual responses for the same heading,
including components from the self-weight and wind, shall be combined, i.e.:
where
S = Design load or load effect.S( ) = Response/load effect function.
F , F , F = Inertia forces (vectors), in x, y and z directions including relevant load factors and gravity
components.
F , F = Wind forces (vectors), in x and y directions including relevant load factors. The horizontal load
components due to wind induced heel or trim shall be included.
W = Load due to self-weight (vectors).
5.6.15.3
Alternatively, the fluctuating components shall be the worst possible combination of the loads resulting from
calculations or model tests carried out in accordance with [11.3.7.1] through [11.3.7.3], with due account to be
taken of the effects of phase. All influential loadings shall be considered: however the following static and
environmental loadings are the most likely to be of importance:
S = Loadings caused by gravity including the effects of the most onerous ballast condition on the
voyage.
F = Loadings caused by the wind heel and trim angle.
F = Loadings caused by surge and sway acceleration
F = Loadings caused by pitch and roll acceleration
F = Loadings caused by the gravity component of pitch and roll motion
F = Loadings caused by direct wind
F = Loadings caused by heave acceleration, including heave.sin(theta) terms
F = Loadings caused by wave induced bending
F = Loadings caused by slam and the effects of immersion.
5.6.15.4
One of the following four methods in this paragraph shall be used to determine the design loadings:
a. Except as noted in [11.7.2.1], the effects of phase differences between the various motions can be
considered, if resulting from model test measurements, or if the method of calculation has been suitably
validated.
b. In cases where it is not convenient or possible to determine the relative phasing of extreme wind loadings
and heave accelerations with roll/sway or pitch/surge maxima, a reduction of 10 percent may be applied
to fluctuating load cases F through F which combine maximum wind and wave effects. However, if wind
induced or wave induced loads individually exceed the reduced load, then the greatest single effect shall
be considered.
c. The total loads may be calculated by combination of loads as follows:
d
x y z
wx wy
1
1
2
3
4
5
6
7
8
1 8
Page 111 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
where:
F = Maximum load due to wind and wave motions
F = Loads based on 1 hour mean wind speed
F = Loads based on 1 minute mean wind speed
F = F through F as applicable
d. For deck cargo units carried on ships assessed using DNV GL Rules for the Classification of Ships, /36/,
Part 3, Chapter 4, Section 3, see [11.6].
Guidance note:
If the deck cargo is carried on a vessel classed an earlier edition of the DNV Rules for the Classification of
Ships, the earlier version can be used.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.6.15.5
Where transfer functions for motions are available these may be combined to a transfer function for the actual
response or load effect. The phasing between the different components may be considered.
Guidance note:
This method requires careful evaluation of the responses to be analysed. All responses which will be governing
for the design should be considered.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.6.16 Default motion criteria
5.6.16.1
For loads computed in accordance with [11.4], the loads applied to the cargo shall be:
S +F +F +F +F
where: S , F , F , F and F are as defined in [5.6.15.3].
The effects of buoyancy and wave slam loading shall also be considered if appropriate.
As stated in [11.7.2.1] roll and pitch cases are to be considered separately. Combined roll and pitch are not
required.
Guidance note:
Quartering seas should also be included if deemed critical for any structural element. (See also IMO Res. A.714
(17), Annex 13 regarding allowable angles of securing devices.) Quartering seas can be included by combining
80% of the horizontal transverse and 60% of the longitudinal acceleration with both the minimum and maximum
vertical acceleration.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.6.17 Loads due to restraint deflections, vessel motions and wind
5.6.17.1
Restraint loads due to vessel deflections in waves, see [5.6.11], loads due to vessel motions and wind may be
combined as shown below.
where
F = Total design load
F = Maximum loads due to deflections
F = Maximum load due to wave motions and wind.
5.6.18 Loads due to irregular waves and swell
5.6.18.1
Loads and load effects from irregular waves and swell shall be combined. These loads and load effects may
normally be combined assuming that they are statistically independent. See [5.6.13.4].
mot
#(1 hour)
#(1 min)
# 1 8
1 1 3 4 6
1 1 3 4 6
tot
def
mot
Page 112 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
5.7 Failure modes
5.7.1
All relevant failure modes shall be investigated. A failure mode is relevant if it is considered possible and the
anticipated consequence(s) of the failure cannot be disregarded.
5.7.2
The relevant failure modes can be grouped as either as global (total system) or local (individual members) as
indicated in the following sections.
5.7.3
Global modes of failure include:
• structural collapse
• overturning
• sliding
• lift-off
• loss of hydrostatic or hydrodynamic stability
• sinking
• settlement
• free drift.
5.7.4
Local modes of failure include:
• plastic deformation (yield)
• buckling
• fracture
• large deflections
• excessive vibration.
5.8 Analytical models
5.8.1
The analytical models used for evaluation of loads, responses, structural behaviour and resistance shall be
relevant considering: the design philosophy, the type of operation and the possible failure modes. The models
should satisfactorily simulate the behaviour of the object’s structures, its supports and the environment.
5.8.2
Design analyses shall be carried out considering all relevant loads and failure modes, see [5.7].
5.8.3
The design analysis shall be thoroughly documented that the results shown to satisfy the relevant requirements
and criteria.
5.9 Strength assessment
5.9.1 General
5.9.1.1
Structural strength can be assessed using either ASD/WSD methodology or LRFD methodology. These are
discussed below.
5.9.1.2
Whichever methodology is applied, the loading conditions/limit states shown in Table 5-1 shall be considered
Page 113 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
when verifying structural strength.
5.9.1.3
A limit state is commonly defined as a state in which the structure ceases to fulfil the function, or to satisfy the
conditions, for which it was designed. See also DNVGL-OS-C101, /24/, Ch.2 Sec.3.
5.9.1.4
Limit states shall be defined for all possible failure modes, see [5.7].
5.9.1.5
The FLS and SLS load cases requirements are the same for ASD/WSD and for LRFD. It is however important that
the load cases for assessed for the ALS and LS / ULS are developed using the applicable environmental inputs
for ASD/WSD or LRFD.
Table 5-3 Description of loading conditions/limit states
Loading condition / limit state ASD / WSD name LRFD name
Maximum capacity, usually for maximum environmental and
functional loads (permanent, variable, deformation)
LS1
LS2
ULS-a
ULS-b
Loading history – important for structures exposed to
significant cyclic/repetitive loading
FLS FLS
Intact structure subjected to loads from an accidental event ALS-I ALS-I
Damaged structure subjected to post-damage loading ALS-D ALS-D
Serviceability checks (alignment, clearances, deflection,
vibration, etc.)
SLS SLS
5.9.2 Design approach
5.9.2.1
The format of the ASD/WSD method implies that strength/capacityverification of structures or systems involves
the following steps:
• Identify all relevant limit states, see [5.9.1].
• Identify all relevant loading conditions, see [5.6.13].
• For each loading condition define the relevant characteristic loads, see [5.5.2], and design conditions, see
Table 5-1.
• For each loading condition and failure mode, see [5.6] and [5.7], find the design loads
• For each loading condition determine the design load effect, see [5.6]
• Ensure adequate safety by proving that the design load effect does not exceed the allowable, as
described in [5.9.4], [5.9.5], [5.9.6] and [5.9.7],
LS2 is applicable only when the loading is dominated by environmental/storm loads, e.g. for weather
unrestricted operations the extreme loads due to the applicable design return period environmental criteria, see
Table 3-1; for weather restricted operations, where an Alpha Factor according to [2.6.9] is to be applied. Any LS2
load case may be treated as a gravity-load dominated limit state (LS1).
5.9.2.2
The format of the LRFD method implies that strength/capacity verification of structures or systems involves the
following steps:
• Identify all relevant limit states, see [5.9.1].
• For each limit state define the relevant characteristic loads, see [5.5.2], and design conditions, see Table
5-1.
• For each limit state find the design loads by applying the relevant load/design factors, see [5.9.4.2],
[5.9.5.2], [5.9.6.2] and [5.9.8.3].
• For each limit state determine the design load effect, see [5.6] and [5.9.3.2 b)].
• For each limit state determine the characteristic resistance, see [5.9.3.3].
• For each limit state determine the design resistance, see [5.9.3.2 d)].
• Ensure adequate safety by proving that the design load effect does not exceed the design resistance, See
[5.9.3.2 a)].
Page 114 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
5.9.3 LRFD checks
5.9.3.1 General
a. Where the LRFD (load and resistance factor design) method is used for design verification the load and
material factors specified in this section shall be used according to the principles of the method.
Guidance note:
The safety factor format applied for lifting slings in Sec.16 could be regarded as an ASD/WSD (permissible
stress) method, but the safety level is correlated according to the applicable LRFD factors.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.9.3.2 Acceptance criteria
a. The level of safety is considered to be satisfactory if the design load effect, S , does not exceed the design
resistance, R , i.e.:
S ≤ R for all limit states
The equation S = R defines the respective limit state.
b. A design load effect is an effect (e.g. stress, mooring line load, sling load, deformation, overturning
moment, cumulative damage) due to the most unfavourable combination of design load(s) i.e.:
where
S = design load effect
F = design load(s)
S = load effect function.
c. A design load (F ) is obtained by multiplying the characteristic load (F ) by the appropriate load factor, see
[5.9.8.3], [5.9.4.2], [5.9.5.2] and [5.9.6.2].
d. A design resistance (R ) is obtained by dividing the characteristic resistance (R ), see [5.9.3.3], by a material
or design factor, see [5.9.8.3], [5.9.4.1 g)], [5.9.5.2] and [5.9.6.2].
5.9.3.3 Characteristic resistance
a. R shall be calculated based on the characteristic values of the relevant parameters or determined by
testing. Characteristic values should be based on the 5 or the 95 percentile of the test results, whichever
is the most conservative. See also [5.4].
Guidance note 1:
The resistance for a particular load effect is, in general, a function of parameters such as structural
geometry, material properties, environment and load effects (interaction effects).
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 2:
The characteristic static resistance of steel, f , is to be taken as the smaller of:
◦ the guaranteed minimum yield stress, f , or
◦ 0.85 times minimum tensile strength of the material.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 3:
R for materials not mentioned e.g. concrete, concrete reinforcement, wood, synthetic materials, soil, etc.
could normally be based on recommendations/requirements in the applied design code or standard. For
soil see DNVGL-OS-C101 /24/ Section 10 1.3.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
b. R for (wire & fibre) ropes and chains should be taken as the certified MBL.
5.9.4 Fatigue limit states – FLS
5.9.4.1 General
a. For all structures exposed to significant cyclic loads during a marine operation the possibilities and effects
of fatigue should be considered.
b. The FLS design conditions should be based on the defined operation period and the anticipated or
expected load history during the marine operation. See Table 5-3.
c. Possible dynamic load effects due to e.g. slamming and vortex shedding should be investigated. See
[5.6.7].
d. Restraint loads, see [5.6.17.1], could be important and shall hence be thoroughly evaluated and included
in the FLS calculations.
e. The FLS shall be evaluated according to procedures given in a recognised code or standard. See e.g.
d
d
d d
d d
d
d
d c
d c
c
th th
c
y
c
c
Page 115 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
DNVGL-OS-C101, /24/, Ch.2 Sec.5 for general requirements for checking of fatigue limit states.
Guidance note 1:
Reference can be made to DNVGL-RP-C203, /29/, and DNV CN 30.7, /20/, for practical details with respect
to fatigue design.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 2:
For new structures that are susceptible to fatigue, it is advisable to check for adequate fatigue life by
analysis for voyages over about 50 days, including possible waiting time at sea, where the nominal peak-
stress range is less than 350 N/mm and the SCF does not exceed 2.5. If the peak-stress range is increased
to 550 N/mm then a fatigue analysis is advisable for voyages over about 10 days.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 3:
New-build MOU's are normally verified for fatigue for the initial delivery voyage in the classification
process and a separate analysis is not normally required for this voyage. For subsequent voyages, it is
desirable to undertake a fatigue analysis, however in many cases there is insufficient time and/or data
regarding prior use. In such cases it is good practice to undertake a thorough NDT inspection of fatigue-
critical areas before the voyage and to repair any cracks, see [11.27.4.4].
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
f. For mooring systems, the FLS is mainly of concern for steel components where fatigue endurance limits
the design. For fibre-rope segments, the time-dependent strength can limit the design; consequently
stress rupture or creep failure should be incorporated in the checks for ULS and ALS as appropriate. See
also DNVGL-OS-E301, /27/.
g. Where structural items e.g. grillages and seafastenings, are to be re-used they should be demonstrated to
have sufficient fatigue life for the sequence of planned operations, including all previous operations. An
appropriate inspection regime shall be proposed including NDT at appropriate intervals e.g. close visual
examination after every use and NDT after every 10 uses; if there are highly utilised areas, more frequent
NDT could be appropriate. For bolts, see [E.2].
5.9.4.2 Design factors - FLS
a. All load factors shall be:
γ =1.0
b. Design fatigue factors (DFF) shall be applied to increase the probability of avoiding fatigue failures
c. The calculated cumulative damage ratios for the defined design conditions times the applicable DFF
according to Table 5-4 shallbe less or equal to 1.0.
d. Lower values for the Miner’s sums than 1.0 can be relevant if the structure has been or will be subjected to
fatigue loading before or after the considered marine operation. In such cases the maximum allowable
Miner’s sum for the actual marine operations shall be determined by considering the total load history the
structure will be exposed to.
Table 5-4 Design fatigue factors (DFF)
Inspection during operation (and
repair) planned
Elements in inspection category I
Elements in inspection categories
II & III
Yes 2.0 1.0
No 3.0 2.0
Notes:
1. The elements shall be categorised according to the definitions in Table 5-9.
2. Higher DFF than indicated may be applicable based on other (project) governing codes.
3. The indicated DFF are applicable only for the fatigue utilization during the considered marine operation.
Hence, if the fatigue utilization is combined with the utilization from other phases, see [d)], a different
DFF may be applicable.
5.9.5 Accidental limit states – ALS
5.9.5.1 General
1. Accidental limit states for marine operations include verification of:
◦ ALS-I: The intact structure or system for the defined accidental load effect(s) combined with other
relevant load effects, see Table 5-5 (i.e. loads of type E may be ignored).
◦ ALS-D: The damaged structure or system, see [5.9.5.1 2)], for relevant design load effects, see Table
2
2
f
Page 116 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
5-5.
Guidance note:
See also Table 5-3 for definition of ALS-I and ALS-D.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
2. The damage to the structure or system in ALS-D is normally defined by either:
◦ the damage caused by the defined accidental load effect(s) or,
◦ a defined damaged or an accidental condition/scenario, see [5.6.6].
5.9.5.2 Design approach and load and resistance factors
a. Accidental loads are defined in [5.6.6].
b. Design against accidental loads shall primarily consider global failure modes, see [5.7.3]. E.g. increasing of
local strength which may reduce the safety against overall failure of the structure should be avoided.
c. Load factors should in ALS normally, see [d)], be taken according to Table 5-5 or Table 5-6.
d. Load factors greater than 1.0 shall be considered if an LRFD method ALS load or condition is not
considered to have a sufficient low, i.e. ≤10-4 per operation, probability. If working to the ASD/WSD
approach, the factors should be similarly increased.
e. The characteristic environmental load (E) in the ALS-D load condition should/may be defined considering
the probability of the analysed accident/damage and the anticipated maximum period (i.e.T , see [2.6.2])
the damaged situation will remain.
Table 5-5 ASD/WSD Load factors for ALS
Type AISC 14 WSD option strength checking allowables
ALS-I 0.6
ALS-D 0.6
Notes:
1. The load factor of 0.6 for the ASD/WSD case arises because the basic allowable stress in
AISC WSD 14  edition is 0.6*yield. In order to effectively work to yield, the load is multiplied by 0.6 and
used with the standard allowable of 0.6*yield.
Table 5-6 LRFD Load factors for ALS
Load
Condition
Load Categories
G Q D E A
ALS-I 1.0 1.0 1.0 NA 1.0
ALS-D 1.0 1.0 1.0 1.0 NA
Notes:
1. Load categories G, Q, D, E and A are described in [5.5.2]
5.9.5.3 Material factor - ALS
The material factor may in ALS generally be taken equal to:
γ =γ /1.15
where γ = the applicable material factor in ULS, see [5.9.8.3].
Guidance note:
E.g. the ALS material factor for steel wire ropes may be taken as γ  = 1.5/1.15 = 1.3.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.9.6 Serviceability limit states – SLS
5.9.6.1 General
a. For some marine operations it is relevant to check SLS related to the feasibility of the operation. Such
serviceability limit states could be associated with required clearances, push/pull capacities and vessel
(barge) level (compared e.g. with quay height).
b. See DNVGL-OS-C101, /24/, Ch.2 Sec.7 for typical SLS requirements for offshore steel structures.
R
th
th
m, ALS m
m
m, ALS
Page 117 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
5.9.6.2 Safety factors
a. For SLS related to feasibility the load factors are normally equal to 1.0. Relevant safety factors/margins
should be defined considering the actual operation. See Sec.6 to Sec.18 for guidance.
b. SLS for structural elements shall normally be checked applying load and material factors equal to 1.0.
Guidance note:
In SLS the object (or equipment/vessel) owner is free to define higher load- and material factors if this is
found applicable.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.9.7 ASD/WSD strength checks for structural steel subject to LS1 or LS2 loading
5.9.7.1 Design approach
1. The ASD/WSD design approach is described in 5.9.2.1.
2. The primary structure and any critical temporary works like lifting attachments, spreader bars and
seafastenings shall be of high quality structural steelwork with full material certification and NDT inspection
certificates showing appropriate levels of inspection.
3. The infrequent load cases, generally limited to survival and damaged cases, including design cases for
weather restricted operations where an Alpha factor according to [2.6.12] is to be applied, may be treated
as an LS2 case (environmental load dominated). This does not apply to:
a. Steelwork subject to deterioration and/or limited initial NDT unless the condition of the entire load
path has been verified, for example the underdeck members of a barge or vessel.
b. Steelwork subject to NDT before elapse of the recommended cooling and waiting time as defined
by the Welding Procedure Specification (WPS) and NDT procedures. In cases where this cannot be
avoided by means of a suitable WPS, it may be necessary to increase the strength or impose a
reduction on the design/permissible sea state.
c. Steelwork supporting sacrificial bumpers and guides.
d. Spreader bars, lift points and primary steelwork of lifted items.
e. Structures during a load-out.
4. Traditionally AISC has also been considered a reference code, e.g. by API RP2A. If the ANSI/AISC 360-10
American National Standard “Specification for Structural Steel Buildings” of June 2010 (in the AISC 14
edition) is used, the allowables shall be compared against member stresses determined using a load
factor on all loads (dead, live, environmental, etc.) of no less than the applicable of those detailed in Table
5-7.
Guidance note:
The API RP2A 22 edition references the 9 Edition of AISC, which includes the traditional “1/3 increase”
for infrequent environmentally dominated load cases. The 14 Edition does not reference the 1/3 increase,
instead it allows the referencing code to specify load factors. The LS2 load factors herein effectively allow
the 1/3 increase.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5. Stresses in welds shall be assessed according to either:
a. The method given in DNVGL-OS-C102 Ch.2 Sec.9.2.5, /25/, or equivalent, or
b. The method illustrated by the example given for the assessment of fillet welds for brackets given in
[E.1].
c. The permissible usage factors for a) and b) are as follows:
◾ Where the loads are due to accelerations determined according to Class Rules, see [11.6]:
◾ 0.60 for welds made at fabrication site
◾ 0.52 for welds made on board the vessel.
◾ Where the loads are determined using other approaches given in this standard:
◾ LS1 (cases where the loading is gravity dominated – see Table 5-3):
0.58 for welds made at fabrication site
0.51 for welds made on board the vessel.
◾ LS2 (cases where the loading is dominated by environmental/storm loads – see Table
5-3):
0.78 for welds made at fabricationsite
0.67 for welds made on board the vessel.
d. Below deck welds in vessels classed to DNV ship rules may be checked against 90f in shear on the
weld throat and 160f for normal stress perpendicular to the weld throat, where f is the material
factor for the applicable strength group as given in /15/.
Guidance note:
If good welding conditions, see [5.10.2.2], and weld fit-up (e.g. control of correct/no gaps to deck
plate) on board the vessel are ensured by procedures and well planned inspection it could be
acceptable to increase the permitted utilisations to those applicable for welds made at a fabrication
site.
th
nd th
th
1
1 1
Page 118 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
6. The allowable strength of slip critical bolted connections shall be assessed according to the method given
in [E.2]. The permissible usage factors for slip critical bolted connections, assuming all loads are assessed
using the LS1 condition as shown in Table 5-7, are as follows:
a. Where the loads are due to accelerations determined according to Class Rules, see [11.6]::
◾ η = 0.48 for joints made with standard hole clearances.
◾ η = 0.42 for joints made with oversize or slotted holes.
b. Where the loads are determined using other approaches given in this standard:
◾ η = 0.62 for joints made with standard hole clearances.
◾ η = 0.55 for joints made with for oversize or slotted holes.
The design of non-tubular connections shall be in accordance with an appropriate standard such as AISC /2/,
using a consistent safety format and factors.
Table 5-7 Load factors for use the ASD/WSD method and AISC 14 edition
Type AISC 14 WSD option strength checking allowables
Limit State 1 (LS1) 1.00
Limit State 2 (LS2) 0.75
Notes:
1. The load factor of 0.75 for ASD/WSD in the LS2 case arises because the basic allowable stress in
AISC WSD 14  edition is 0.6*yield and the traditional 1/3 increase to 0.8*yield (i.e. to 0.6*yield*4/3) for
environmental load cases is not included. As an alternative, the load is multiplied by 3/4 and used with
the standard allowable of 0.6*yield in order to achieve the safety levels that have been used and
accepted over many years.
2. Any load case may be treated as a gravity-load dominated limit state (LS1).
3. Where the loads are due to accelerations determined according to DNV and DNV GL Class Rules, see
[11.6], LS2 shall be used with a load factor of 1.2.
5.9.8 LRFD strength checks for structural steel subject to ULS loading
5.9.8.1 General
DNVGL-OS-C101, /24/, Ch.2 Sec.4 gives provisions for checking of ultimate limit states for typical structural
elements used in offshore steel structures.
5.9.8.2 Load factors - ULS
For the ultimate limit states (ULS) the two load conditions “ULS-a” and “ULS-b” as given in the Table 5-8 shall be
considered.
Table 5-8 Load factors for ULS
Load
Condition
Load Categories
G Q D E A
ULS-a 1.3 1.3 1.0 0.7 NA
ULS-b 1.0 1.0 1.0 1.3 NA
Notes:
1. Load categories G, Q, D, E and A are described in [5.5].
a. For loads and load effects that are well controlled a reduced load factor γ = 1.2 may be used for the G and
Q loads instead of 1.3 in load condition ULS-a.
Guidance note:
Examples where γ = 1.2 may be applicable are:
◦ External hydrostatic pressure caused by an accurately defined water level.
◦ Loads due to an accurately distributed (i.e. static determinate) well defined self-weight.
◦ Functional loads accurately defined (limited) by the maximum (possible) capacity of equipment.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
b. Where a permanent load G (e.g. self-weight or hydrostatic pressure) causes favourable load effects, a load
factor γ = 1.0 shall be used for this load in load condition a. See also [5.6.2.2] and [5.6.2.3].
th
th
3)
3)
th
f
f
f
Page 119 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
c. In cases where the load is the result of counteracting and independent large hydrostatic pressures the
appropriate load factor shall be applied to the pressure difference. However, the pressure difference
should not be taken less than 0.1 times the hydrostatic pressure.
d. In dynamic problems the application of load factors should be given special consideration. In lieu of a
probabilistic analysis, the load effects may be found by application of load factors after having found the
responses, e.g. after having solved the equations of motion for vessel motion response analysis.
5.9.8.3 ULS material factors
a. Applicable material factors in ULS are given in [5.9.8.4] to [5.9.8.6]. Material factors for materials not
mentioned in [5.9.8.4] to [5.9.8.6] e.g. concrete, concrete reinforcement, wood, synthetic materials, soil,
etc. shall be in accordance with a recognised code or standard. See also [5.9.3.3].
b. If a material factor γ = 1.0 is found more unfavourable than the indicated values, γ = 1.0 shall be used.
5.9.8.4 Material factors for structural steel:
1. In ULS the material factors for steel structures should be taken as minimum: γ =1.15.
2. For members in compression a higher material factor may be applicable. The material factor should
normally be chosen according to the applied design code, but never smaller than 1.15.
3. If EN 1993 (Eurocode 3) /61/ is used for calculation of structural resistance, the material factors listed in
DNVGL-OS-C101, /24/, Ch.2 Sec.4 for steel structures and DNVGL-OS-C101, /24/, Ch.2 Sec.8 for welded
connections shall be applied.
Guidance note:
See also Table 6-1 in NORSOK N-004, /112/, for applicable material factors.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4. In ULS the material factor for static strength of tubular joints should be chosen according to the applied
design code, but never smaller than 1.15.
5. An increased (i.e. larger than 1.15) material factor shall be considered if the production is carried out in an
environment where reduced control of dimensions, materials and fabrication could be expected, e.g.
welding on board vessels. The following minimum material factors, γ , apply when the weld capacity is
calculated according to DNVGL-OS-C101 Ch.2 Sec.8, /24/, EN 1993-1-8 or [E.1]:
◦ For welds made at fabrication site: γ = 1.3
◦ For welds made on board the vessel: γ = 1.5
Guidance note:
If good welding conditions, see [5.10.2.2], and weld fit-up (e.g. control of correct/no gaps to deck plate)
on board the vessel are ensured by procedures and well planned inspection γ = 1.3 could be found
adequate.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.9.8.5 Material factors for ropes, chain and bolts
1. The design load in any chain, wire or webbing strap used for seafastening should not exceed the certified
(lifting) Working Load Limit (WLL) of the seafastening.
2. In ULS the material factor for certified steel wire ropes and chains should normally be taken as:
γ = 1.5
Guidance note:
γ = 1.15/0.85/0.9 = 1.5
where
1.15 is the general steel material factor,
0.85 is a factor to account for that the characteristic strength, see [5.9.3.3] Guidance Note 2, of ropes and
chains is based on the tensile strength (MBL), and
0.9 is a general factor because wire ropes are considered more vulnerable to “undetectable” wear and
material irregularities than regular steel structures. For new ropes with a 3.2 certificate it may be
acceptable to use 1.0, see [15.10]. (Note also that an additional wear factor could be applicable).
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
3. For fibre ropes the material factor depends on the material and relevant failure mode. The following
minimum factors apply:
◦ Polyester: 1.65
◦ HMPE and Aramid: 2.0
◦ Other fibre materials: 2.5.
Guidance note:
For fibre slingssubject to a robust certification process, other material factors may be considered
m m
m
mW
mW
mW
mW
m
m
Page 120 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
acceptable; however, γ should not be less than 1.65
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
4. When using DNVGL-OS-C101 /24/, Ch 2 Sec 4.8, Eurocode 3 /61/ or [E.2], the material factor for slip
resistant bolt connections shall be taken as minimum:
◦ γ = 1.25 for standard clearances in the direction of the force.
◦ γ = 1.4 for oversize holes or long slotted holes in the direction of the force.
Guidance note:
[E.2] provides for further information regarding slip resistant bolt connections and an alternative
methodology.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.9.8.6 Material factors for friction
a. A material factor of minimum γ = 1.4 should normally be used to calculate the lower bound design
friction coefficient for load bearing friction effects.
b. A material factor of maximum γ = 0.8 should normally be used to calculate the upper bound design
friction coefficient. See [5.4].
Guidance note:
In each case, the design friction coefficient should obtained by dividing the characteristic friction
coefficient by the material factor.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.10 Materials and fabrication
5.10.1 Design considerations
5.10.1.1 Applicable codes
a. In general material selection, fabrication method, and non-destructive testing should be carried out
according to a recognised offshore code, e.g. DNVGL-OS-C101, /24/, or DNVGL-OS-C401, /26/.
Guidance note:
Recognised codes or standards are meant to be national or international codes or standards applied by
the majority of professional people and institutions in the marine and offshore industry.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
b. Independent of the applied code, it shall be documented that the requirements in this section [5.10] are
fulfilled.
5.10.1.2 Structural categories
1. Structural elements and connections shall be grouped in categories determined according to:
◦ type of stress
◦ presence of cyclic loading
◦ presence of stress concentrations
◦ presence of restraint
◦ loading rate
◦ consequences of failure
◦ redundancy.
2. Guidelines for selection of applicable materials for offshore steel structures can be found in DNVGL-OS-
C101, /24/, Ch.2 Sec.3.
Guidance note:
For steel with yield stress below 500 MPa, the test temperature need not be taken lower than -40° C
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
3. For materials in temporary structures used for marine operations, the following apply:
◦ The design temperature, see DNVGL-OS-C101, /24/, Ch.2 Sec.3.2, should be defined based on the
season and location(s) of the marine operation. Note that a design temperature above 0ºC may be
applicable.
◦ See Table 6-1 for guidelines regarding selection of structural category. See also DNVGL-OS-
C101, /24/, Ch.2 Sec.3.3.
◦ For materials that could be welded under adverse conditions the yield strength (SMYS) should not
exceed 355 MPa.
m
m
m
m
m
Page 121 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
5.10.1.3 Material quality
a. Selection of steel types shall be determined based on the structural application and the required category
Table 5-9.
b. All steel materials shall be suitable for the intended service conditions and shall have adequate properties
of strength, ductility, toughness, weldability and corrosion resistance.
c. Material types and qualities should comply with requirements in DNV-OS-B101, /23/.
d. Non-structural steels shall have mechanical properties and weldability suitable for the intended
application.
Table 5-9 Structural categories
Selection criteria for structural
category Examples for typical
structures involved in
marine operations
Recommended
structural
category
NORSOK N-004
Equivalent /112/
Insp.
Cat.,
DNV
GLFailure
consequence
Structural
part
DNVGL-OS-C101
Substantial, the
structure
possesses
limited
residual
strength
Complex
joints
• Padeyes and
other lifting
points
• Seafastening
elements
without
redundancy
• Spreader bars
Special DC1 – SQL1 I
Simple joints
and
members
Primary (Special) DC2 – SQL2
(SQL1)
I or
II
Not substantial,
the structure
possesses
residual
strength
Complex
joints
Structures for
connection of:
• Mooring and
towing lines
• Grillages
• Redundant
seafastening
elements
Primary (Special) DC3 – SQL2
(SQL1)
II
Simple joints
and
members
Primary (Special) DC4 – SQL3
(SQL1)
II
Un-substantial,
as local failure
will be without
substantial
consequences
Any
structural
part
• Bumpers and
guides
• Fender
structures
• Redundant
(parts of)
grillages
Secondary DC5 – SQL4 III
Notes:
1. Complex joints are joints where the geometry of connected elements and weld type leads to high
restraint and to tri-axial stress pattern.
2. Residual strength (redundant) means that the structure meets requirements corresponding to the
damaged condition in the check for ALS, with failure in the actual joint or component as the defined
damage.
3. Selection where the joint strength is based on transference of tensile stresses in the through thickness
direction of the plate.
4. The design classes and material selection according to NORSOK M-120, /110/ should be considered as
guidance only.
5. Extent of NDT to be according to DNV GL category I in Table 5-10, but category II may be used as
“input” in Table 5-10 regarding waiting time for these welds. Regarding extent of inspection according
to NORSOK M-101, /109/ inspection category B is normally acceptable.
5.10.1.4 Tolerances
a. As-built deviations shall not exceed fabrication tolerances assumed in the applied structural codes and
standards, or in the design analysis, unless specially considered on a case-by-case basis.
b. Acceptance of any as-built deviations exceeding specified tolerances shall be confirmed in writing by, as
applicable, the owner, designer, installation contractor, etc.
c. DNVGL-OS-C401, /26/, Ch.2 Sec.2.5 indicates fabrication tolerances that are normally acceptable.
4)
2)
1)
3) 3) 5)
2)
1)
2)
3) 3)
3) 3)
2)
Page 122 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
d. Some marine operations procedures can be difficult (or impossible) to execute when standard tolerances
are applied. In these cases consideration can be given to defining and documenting the consequences of
using tolerances that are less onerous than those indicated in DNVGL-OS-C401, /26/
5.10.2 Fabrication
5.10.2.1 Workmanship
a. Workmanship during fabrication shall be of good standard and according to accepted practice. See also
DNVGL-OS-C401, /26/, Ch.2, Sec.1 and Sec.2.1 through 2.5.
b. Guidelines regarding assembly and welding can be found in DNVGL-OS-C401, /26/, Ch.2 Sec.2.6.
5.10.2.2
Marine work Environmental conditions during marine construction work can be unfavourable and the time
available is often limited. Also accurate fit-up can be difficult to obtain e.g. due to a dented barge deck. Such
issues regarding marine work shall be duly considered in the planning of the work. See also [5.9.8.4].
Guidance note:
Due to the special conditions during marine construction work, the following precautions are recommended:
a. Welding procedure specifications should be qualified by welding procedure tests carried out under
conditions representative of the actual working environment; see DNVGL-OS-C401, /26/, Ch.2 Sec.1.2.5.
b. Thorough inspections of fit-up and welding should be planned for.
c. Weather conditionsand forecast to indicate acceptable conditions for welding considering the welding
method and available shelter at the welding locations.
d. Use of increased weld size in order to compensate for inaccurate fit-up (i.e. over-sized gaps) to be
considered.
e. Robust and well proven welding methods and procedures to be applied.
f. Use of material with improved weldability; see DNVGL-OS-C101, /24/, Ch.2 Sec.3.4.2, to be considered.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
5.10.2.3 Weld inspection
1. All NDT (non-destructive testing) of structures and structural components shall be carried out by qualified
personnel and covered by written specifications and procedures.
2. Personnel evaluating results from NDT shall possess thorough knowledge and experience with NDT.
3. The NDT method selected shall be suitable for detection of the type of defects considered detrimental to
the safety and integrity of the structures.
4. The extent of NDT shall be based upon the importance of the connection in question. Aspects which shall
be considered in specifying the extent of NDT are:
◦ stress level and stress direction
◦ cyclic loading
◦ material toughness
◦ redundancy of the member
◦ overall integrity of the structure
◦ accessibility for examination.
5. Where through thickness properties of the steel are used, the material should be certified accordingly
(Z-quality). Where this is not feasible, the material under through-thickness tension should be checked for
laminations after the recommended cooling and waiting time as defined by the Welding Procedure
Specification (WPS) and NDT procedures. The reason for waiting is that laminations can also be subject to
hydrogen embrittlement, the same as welds, see SSC-290, /118/, for more details of lamellar tearing. If
access is not possible after welding, pre-welding checks could be acceptable.
Guidance note 1:
For non-critical seafastenings and their supports, through-thickness testing should be carried out when the
tensile stress normal to any plate exceeds 100 MPa.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 2:
The tensile stress should be calculated in a section between the deck plate and the weld (i.e. not in the
critical weld section). If the under deck weld is smaller, this weld should be used as a reference, see also
Guidance note to [11.9.5.27]. Stresses greater than 100 MPa, caused by e.g. a local moment on
seafastening brackets can generally be accepted in limited areas without lamination testing.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Page 123 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
6. Requirements to non-destructive testing (NDT) of welds can be found in DNVGL-OS-C401, /26/, Ch.2
Sec.3. Equivalent standards may be used e.g. EEMUA 158 “Construction specification for fixed offshore
structures in the North Sea” /59/ and AWS D1.1/D1.1M-2015 “Structural welding code – steel” /8/.
7. Minimum extent of inspection should be as shown in DNVGL-OS-C401, /26/, Ch.2 Sec.3 Table 1 with
“Inspection Category” as defined in Table 5-9. See also Table 5-10 for a summary and especially note 4) to
the table.
8. Normally final inspection and NDT of welds shall not be carried out before 48 hours after completion.
However, for materials with yield strength of 355 MPa or less this could be reduced to 24 hours. See
NORSOK M-101, /109/, Sec.9.1 and DNVGL-OS-C401, /26/, Ch.2 Sec.3. 2 for further details.
9. For marine operations with weld inspection on the critical path, the minimum waiting time should be
selected according to Table 5-10 however, the decreased waiting may only be used if the precautions
listed in [5.10.2.2] are fulfilled.
Guidance note:
Weld inspection can be completed after a voyage has commenced provided that procedures are in place
to remediate or mitigate any defects that are found.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Table 5-10 Minimum extent of NDT and waiting time
Inspection
Category
Minimum extent of NDT Minimum waiting time before NDT
Visual Other
SMYS ≤355
MPa
SMYS ) > 355
MPa
I 100% 100% 24 hours 48 hours
II 100% 20% Cold weld 24 hours
III 100% 5% Cold weld 24 hours )
Notes:
1. Test method to be selected according to the type of connection, see DNVGL-OS-C401, /26/, Ch.2
Sec.3, Table C1.
2. SMYS to be defined according to the specification for the actual material used and not according
to the minimum required design value.
3. For thickness less than 40 mm the limiting SMYS is 420 MPa.
4. The use of PWHT (post weld heat treatment) can reduce the required waiting time.
5. An increased % extent shall be evaluated if defects are found and/or the weld conditions and
precautions, see [5.10.2.2], are not fully satisfactory.
6. The NDT can start when the weld is cold, but it is recommended to wait as long as practicable.
SECTION 6 Gravity based structure (GBS)
6.1 Introduction
6.1.1 General and scope
6.1.1.1
This Section is mainly applicable to “Condeep”-type gravity based structures (with one or more columns above a
submerged base). However the principles will apply to most types of steel and concrete gravity based platforms.
6.1.1.2
The areas shown in Table 6-1 are covered. Depending on the type of structure and method of construction,
some or all of the following sections will give the relevant requirements.
Table 6-1 Requirements for different GBS phases
General requirements See Sec.2 to Sec.4
Stability and freeboard (all phases) See [6.2]
Structural strength See [6.3] and Sec.5
Temporary ballasting and compressed air systems See [4.3]
1)
2)
3)
2
3)
4) 4)
5) 6) 4)
5) 6) 4
Page 124 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Construction basin and tow-out See Sec.12
Construction and/or solid ballasting afloat See Sec.14
Deck-mating (inshore or offshore) See Sec.15
Towage(s) See Sec.11
Instrumentation See [6.4]
Installation at location See [6.5]
Ensuring on-bottom stability See [13.10]
6.1.2 Revision history
6.1.2.1
This section replaces the applicable sections of the following legacy documents:
• GL Noble Denton, Guidelines for concrete gravity structure construction & installation, 0015/ND
• DNV Offshore Standard, Load transfer operations, DNV-OS-H201
6.2 Floating GBS stability and freeboard
6.2.1 General
6.2.1.1
Sufficient positive stability and reserve buoyancy shall be ensured during all stages of the marine operations.
Both intact and damage stability shall be evaluated, on the basis of an accurate geometric model. This shall
include inclining tests of the GBS in accordance with [2.10.5] at stages agreed with the MWS company.
6.2.1.2
In calculations of stability and reserve buoyancy/freeboard, due allowance shall be included for uncertainty in
mass, buoyancy, volume, location of centre of gravity, density of liquid and solid ballast, and density of seawater.
6.2.1.3
The output of the weight control programme as described in [5.6.2] shall be taken into account.
6.2.1.4
Stability calculations should include corrections and allowances for:
a. Free surface
b. Air cushion
c. Icing
d. Influence of moorings, including a check on the consequences of failure.
e. Temporary Loads and Structures (including any cantilevered structures)
6.2.1.5
The number of openings in buoyant elements adjacent to the sea shall be kept to a minimum. Where
penetrations are necessary for access, piping, ventilation, electrical connections, etc. arrangements shall be
made to maintain watertight integrity. During construction phases, particular attention should be paid to
openings near the waterline, which will vary as construction proceeds.
6.2.1.6
Damage stability requirements shall be evaluated considering the operation procedure, environmental loadsand responses, the duration of the operation and the consequences of possible damage. Compartments that
may be subject to flooding or partial flooding include:
a. Compartments adjacent to the sea
b. Compartments inside the structure, crossed by seawater filled pipes
c. Skirt compartments containing compressed air.
Page 125 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
6.2.1.7
Special attention should be paid to flooding which may be caused by:
a. Impact loads from vessels
b. Damage to structure or pipework from dropped objects
c. Mechanical system failure
d. Human error.
6.2.1.8
The consequences of water ballast escaping from any compartments above the waterline, or the escape of air
from any air cushion shall be evaluated where applicable.
6.2.1.9
Flooding as a result of vessel impact is assumed to occur in a zone bounded by two horizontal planes normally
positioned 5 m above and 8 m below the waterline. These levels should be reviewed if deep draught vessels are
likely to be operating nearby.
6.2.1.10
For operations where the structure cannot meet damage stability criteria, measures shall be taken to minimise
the risk, by:
a. Limiting the exposure period
b. Providing additional local structural strength
c. Providing additional protection, such as fendering
d. Minimising vessel movements near the structure
e. Dedicated procedures and experienced personnel.
6.2.1.11
For operations where at any stage stability or reserve buoyancy is critical or where damage stability cannot be
obtained, a risk assessment in accordance with [2.4] shall be carried out. The duration of the critical condition
should be minimised. Requirements for back-up or protection systems, or special procedures should be
assessed.
6.2.2 Intact stability
6.2.2.1
The initial GM shall not be less than 0.5 m (after allowing for all possible inaccuracies in measuring it) unless
agreed with MWS Company.
6.2.2.2
The maximum inclination of the floating GBS or platform should not exceed 5° in the design environmental
condition as defined in [3.1] apart from possible exceptions during installation as described in the guidance note
to [6.5.4.4]. Calculation of maximum inclination should take into account:
a. Maximum amplitude of pitch or roll motion in the design sea state, plus
b. Inclination due to design wind, plus
c. Inclination due to mooring line tensions or required towline pull.
Guidance note:
The maximum inclination of 5° is due to the large height of GBS structures and the corresponding motion
experienced at this height.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
6.2.2.3
During towing, the static inclination in still water when subjected to 50% of required towline pull should not
normally exceed 2°. Differential ballasting may be used to reduce the static inclination resulting from towline pull
only by not more than 1°.
Page 126 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
6.2.2.4
The area under the righting moment curve shall be not less than 140% of the area under the overturning
moment curve as shown in Figure 11-2. Both curves shall be bounded by the least of:
a. The second intercept of the righting and overturning moment curves
b. The angle of downflooding
c. The angle which would cause any part of the GBS to touch bottom in the minimum water depth at the
construction site or along the towage route. This requirement may be deleted for installation at the
offshore site.
d. The angle at which allowable stresses are reached in any part of the structure, construction equipment,
topsides or topsides attachments, if applicable.
6.2.2.5
The wind used for overturning moment calculations should be the design wind for the operation, as defined in
[3.3]. Short duration operations during construction or towage may be considered as weather restricted
operations, provided the structure can achieve or be returned to a safe condition, within the operation reference
period
6.2.3 Effective freeboard
6.2.3.1
For inshore towages and construction afloat, the effective freeboard, as defined in Table 1-3, shall not be less
than the greater of:
a. 1 m above the design wave crest height, with allowance for run-up, all around the structure, under the
design storm loading from the most critical direction,
b. 6 m in the intact condition, if the unit does not have one-compartment damage stability.
6.2.3.2
For offshore towages, after damage, an effective freeboard of not less than 5 m shall remain above the design
wave crest height, with allowance for run-up, all around the structure, from the most critical direction. Calculation
of the freeboard shall account for motions experienced as a result of the design environmental conditions and
mooring line tensions or required towline pull.
6.2.4 Damage stability for tow-out and inshore tows
6.2.4.1
For tow-out from dry-dock, one-compartment damage stability is not required as it is a controlled operation and
the under-keel clearance is limited.
6.2.4.2
For other inshore tows the structure should have one-compartment damage stability, as defined in [6.2.1.6]
through [6.2.1.9].
6.2.4.3
If one-compartment damage stability requirements cannot be fulfilled, the requirements for construction afloat in
[6.2.5.2] shall apply.
6.2.5 Damage stability during construction afloat
6.2.5.1
During the period of construction afloat, the platform shall possess one-compartment damage stability, for as
much of the construction period as is practical.
6.2.5.2
When the platform does not possess one-compartment damage stability, then in addition to [6.2.1.10]:
a. A means should be available to compensate for inclination due to flooding of any compartment, and
b. There shall be sufficient structural strength in the outer walls to withstand impact loads from the
Page 127 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
construction spread and vessels, which may be in close proximity to the platform, and
c. Fendering may be used to reduce impact loads in critical areas, and
d. Lifting of heavy objects shall be carefully controlled. Protection shall be provided against dropped objects.
Any lifts which, if dropped, could endanger the platform shall be identified and additional precautions
taken, and
e. Any objects or equipment on barges alongside, which if dropped, could endanger the platform shall be
similarly identified and additional precautions taken, and
f. Rigorous procedures shall be developed to minimise the risk of flooding. These shall include
consideration of collision, leakage through the ballast or other systems, reliability and redundancy of
pumping arrangements and power supplies, and
g. At all times there shall be adequately trained personnel on board the platform, and
h. As per [6.2.1.11], a risk assessment of flooding shall be carried out in accordance with [2.4].
6.2.6 Damage stability for offshore tows and installation
6.2.6.1
When towing on the caisson or columns the platform should possess one-compartment damage stability.
6.2.6.2
It is acknowledged that for an offshore tow, the requirement in [6.2.6.1] might be impractical, in which case:
a. The structure shall be locally reinforced within the zone defined in [6.2.1.9], to withstand impact from the
largest towing or attending vessel, and/or
b. Rigorous procedures shall be developed to minimise the risk of flooding, and
c. A risk assessment of flooding shall be carried out in accordance with [2.4].
6.2.6.3
It is acknowledged that during installation, it might be impractical to provide reinforcement against collision over
the full range of waterlines. Planning and risk assessmentshall include a procedure to return the structure to the
reinforced waterline should the installation operation be aborted.
6.3 Structural strength
6.3.1 Concrete gravity structures - load cases
6.3.1.1
The requirements of Sec.5 apply.
6.3.1.2
Load cases shall be derived by the addition of fluctuating loads resulting from wind, wind heel, wave action and
the effect of towline pull or mooring loads to the static forces resulting from gravity and hydrostatic loads for the
following temporary phases before it is safely installed:
1. tow-out from construction basin or dry-dock (with and without any air cushion)
2. the most critical construction afloat stages
3. any towages, with or without a deck
4. deep submergence for deck mating
5. installation on the seabed, including:
◦ any impact with the seabed including any rocks or debris during installation
◦ penetration and grouting phases
◦ any impact with scour protection during its placement.
◦ Any other critical phase as agreed with the MWS company
6.3.1.3
Accidental loadings shall also be considered for all of the phases in [6.3.1.2].
6.3.1.4
The specific load cases considered shall be documented. For all load cases it shall be documented that the
design (global and local) is acceptable.
Page 128 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
6.3.1.5
The unit shall be able to safely withstand a static heel angle of 10°, or any greater angle required during
construction, towage or installation. If it has damage stability, the unit shall also be able to withstand the static
and dynamic loads caused by the flooding of any one compartment in the lesser of the 10-year return period
environmental conditions or a 25 m/s wind and associated waves. These should be assessed as LS1 or ULS
conditions, unless it is demonstrated that alternative criteria apply.
6.3.1.6
Hydrostatic loads on the substructure at the deepest draught during deck-mating can be the governing load
case. It shall be demonstrated that a thorough independent check of the calculations covering this load case has
been carried out, and that the design and reinforcement details assumed in the calculations concur with the as-
built condition.
6.3.1.7
Any limitations on the maximum allowable duration of deep immersion due to concrete creep, in relation to the
structural stability of the unit, should be established and the procedures planned accordingly.
6.3.2 Structural concrete
6.3.2.1
The strength of concrete and its reinforcement including any pre- or post-tensioning shall comply with a
recognised and appropriate concrete design code, such as those listed in ISO 19903, /101/. Any time-
dependent properties of the materials shall be taken into account. Adequate global and local strength shall be
documented.
6.3.2.2
The strength of the structure in the installed condition should be covered by the relevant certifying authority or
classification society who will normally refer to a suitable offshore structural code or rules such as DNV-OS-C502
– Offshore Concrete Structures, /41/, or the GL Rules, /68/.
6.3.2.3
Testing of concrete for permanent works should be covered by the certifying authority and testing for temporary
works should follow the same requirements.
6.4 Instrumentation
6.4.1
Instrumentation shall be in accordance with [4.2] and adequate instrumentation shall be installed to monitor the
following, as applicable, during the operation to ensure loads, etc., remain within analysis and/or operational
limits and assumptions:
a. The water level in all compartments, quantity and percentage
b. Status of all valves
c. Pump status and flow rates
d. Main and emergency power supply status
e. Platform draught, heel and trim
f. Compartment air pressure
g. Compressor status
h. Air cushion pressure
i. Water seal level in skirt compartments
j. Status of access doors and manholes.
6.5 GBS installation
6.5.1 General
6.5.1.1
Page 129 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
This section describes the general requirements for the installation of a concrete gravity platform at its final
offshore location. The installation procedures will vary, depending on parameters including:
a. The size and design of the platform
b. Water depth
c. The positioning tolerances required in all 6 degrees of freedom
d. The positioning/stationkeeping system proposed
e. Whether cranes, winches or external buoyancy is required for lowering and/or positioning
f. Whether the operation involves docking over a template, docking piles or other structures
g. Stability at all stages of immersion
h. Whether a vertical or inclined installation is required
i. Tolerances on differential ballast levels
j. The skirt design, and penetration method
k. Whether under-base grouting is required
l. Whether solid ballast or scour protection is required.
6.5.2 Survey
6.5.2.1
The position of the site location shall be given in both geographical and grid coordinates.
6.5.2.2
The water depth and bathymetric tolerances shall be determined.
6.5.2.3
When determining the extent of the survey area, the following shall be accounted for:
a. Tolerances on site survey position
b. Inaccuracy of position monitoring systems during installation
c. Operational tolerances
d. The approach corridor
e. Whether a holding location is required close to the site
f. Whether an inclined installation, with previous off-site touch-down is required
g. The proximity of any other platforms or subsea assets at or near the location.
6.5.2.4
The bottom topography shall be established by swathe bathymetry, high resolution echo sounder techniques,
side scan sonar, and checked by magnetometer and ROV video for obstructions and possible unexploded
ordnance. The extent of any required levelling or other seabed preparation should be decided at the design
stage.
Guidance note:
Swathe bathymetry is now available in portable units and is installed on most survey vessels so should be used as
standard on all survey projects. Due to constraints imposed by calibration and processing requirements (single
point obstructions may be removed in processing), conventional high-resolution bathymetry and side scan sonar
should be run in conjunction.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
6.5.2.5
The seabed and sub-seabed conditions shall be established by coring, magnetometer, in-situ testing, lab testing
and sub-bottom profiling.
6.5.2.6
Sufficient current surveys shall be completed to determine the current profile with depth.
6.5.2.7
The area should be checked to ensure that there are no travelling sand-waves or other seabed erosion/accretion
that could affect the structure during installation.
6.5.2.8
Page 130 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
A site survey of the installation area covering the full area of any anchor pattern, carried out not more than 4
weeks before the start of installation, shall be provided to verify the location of all subsea infrastructure, debris
and obstructions.
6.5.3 Seabed preparation
6.5.3.1
The required tolerances for level and compaction shall be documented at an early stage.
6.5.3.2
Where surveys shows the seabed is out of tolerance it shall be prepared to correct for uneven levels or
consistency. Description of the preparation works, including details of how tolerances shall be achieved, shall be
documented.
Guidance note:
Typical seabed preparation methods include:
a. Controlled dumping and compacting of gravel before final levelling
b. Placing sand-bags
c. Excavating of unsuitable soils before replacing as in a) or b).
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---6.5.4 Installation method principles
6.5.4.1
In general it is desirable for all installation phases to be reversible though this may not always be possible,
especially if there are temporary unstable phases.
6.5.4.2
The approval criteria shall be agreed with the MWS Company. The agreed criteria shall depend on the
installation methods and consider the following:
a. The required external assistance (e.g. temporary buoyancy, winches, cranes, etc.)
b. Range of positive stability at all stages of installation. Also see [6.5.4.4].
c. Length of weather windows required and sensitivity to bad weather or strong currents
d. Possible requirement of scour protection immediately after emplacement (see [6.5.7]).
6.5.4.3
For structures towed on their side, an agreed Up–End procedure shall be documented.
6.5.4.4
Ideally platforms should be shown to be stable at all phases of the installation.
Guidance note:
Shallow draught platforms frequently undergo a phase of instability during submergence of the base, and an
inclined installation procedure may then be used in which case the requirements of [6.5.4.5] will apply.
Sometimes it may be necessary to touch down on one edge to achieve stability or to use temporary buoyancy or
crane /winch assistance.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
6.5.4.5
In the event of an inclined installation the following shall be considered:
a. All machinery, systems and personnel, if aboard, shall be able to work efficiently in the inclined condition
b. Monitoring of ballast levels, and allowable differential levels
c. Structural capacity of the skirt at touch down, and possible impact loads imposed
d. Skirt touch down, if on the final site, may disturb the seabed, and prejudice the final skirt penetration or
base slab bearing
e. If the skirt touch down is on the final site, accurate position control may be difficult in the inclined condition
f. If skirt touch down is remote from the final site, the deballast capability required by [4.3.5] will be used.
Page 131 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
6.5.5 Positioning and position monitoring systems
6.5.5.1
The positioning system shall be designed to meet the required installation tolerances. This will normally be by
means of tugs, often the tow fleet is rearranged into a star configuration.
6.5.5.2
Where more precise positioning is required, the tugs may be connected at the bow to pre-laid anchors though
other mooring systems are possible. Mooring systems shall comply with Sec.17.
6.5.5.3
Where the position and orientation tolerances are not critical, the tugs may be in free floating configuration.
6.5.5.4
Where docking piles are to be used the requirements in [13.8.4] apply
6.5.5.5
A position monitoring system in accordance with [4.4.5] shall be provided. The system shall allowing monitoring
of capturing docking piles if being used.
6.5.6 Ensuring on-bottom stability/skirt penetration
6.5.6.1
The requirements in [13.10.1] apply including specifying the depth(s) of any required penetration(s).
6.5.6.2
Calculations shall be documented to demonstrate that the base or skirts will penetrate to the required depths.
The calculations shall specify if negative pressure is required in addition to gravity/buoyancy loads. Additionally
the calculations should consider the following:
a. expected (and maximum and minimum) soil friction
b. expected (and maximum) suction versus penetration depth
c. soil sealing differential pressure versus penetration depth
d. capacity of suction pumps
6.5.6.3
A venting system sufficient to ensure foundation integrity shall be provided to allow water in the skirt
compartments to escape and where required to allow negative pressure to be applied.
Guidance note:
Design of the pipework should take into account the requirements for removal on decommissioning.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
6.5.6.4
Skirts shall be shown to meet the requirements of [4.4.5.1] for all expected loads during the installation process.
6.5.6.5
If differential pressure or suction is applied, then it shall be demonstrated that an adequate seal can be obtained
at the skirt tip, with minimal risk of “piping” between outside and inside each skirt compartment.
6.5.6.6
Requirements to minimum pumping pressure and flow rate should be established
6.5.6.7
All relevant parameters shall be controlled, monitored and recorded during the installation. This shall include:
a. differential pressure (suction)
Page 132 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
b. penetration
c. flow rate
6.5.7 Anti-scour precautions
6.5.7.1
All locations, especially with high current speeds, should be investigated to see if scour could cause problems
during the installation and subsequent temporary stages.
6.5.7.2
Details of anti-scour precautions where required shall be documented. Possible solutions to scour include:
• Controlled rock dumping or placing sand-bags immediately after the unit is installed. Care shall be taken
to avoid any damage to the unit especially near penetrations, pipelines, cables or other sub-sea assets.
Scour may start immediately after installation, especially in bad weather.
• Artificial seaweed or other seabed stabilisation methods. This solution needs to be demonstrated to be
successful under these conditions.
• Increased skirt lengths, though this should have been determined at an early design stage.
SECTION 7 Cables, pipelines, risers and umbilicals
7.1 Introduction
7.1.1
This section is currently under development and therefore for work related to cables, pipelines, risers or
umbilicals the following legacy documents apply:
• 0029/ND, GL Noble Denton, Guidelines for Submarine Pipeline Installation
• 0035/ND, Section 10 (for cables), of GL Noble Denton, Guidelines for Offshore Wind Farm Infrastructure
Installation, and
• DNV-OS-H206 ,DNV Offshore Standard, Load-out, transport and installation of subsea objects (VMO
Standard Part 2-6).
7.1.2
The legacy documents shall be used in their entirety including any referenced documents and NOT the
equivalent sections of this Standard.
Guidance note:
For example if DNV-OS-H206 is applied then DNV-OS-H101, and DNV-OS-H102 and DNV-OS-H205 also apply
along with any other referenced documents.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
7.1.3
For the installation by lifting of other subsea equipment the requirements of this document should apply unless
agreed otherwise.
Guidance note:
Generally, where subsea equipment is installed by lifting as part of a project using the documents referenced in
[7.1.1] then the legacy documents would apply.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
7.2 Codes and standards
7.2.1
A number of recognised standards and design codes covering pipelines, risers and umbilicals are already in
existence and should be considered.
Page 133 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
Guidance note 1:
The following are examples of relevant industry standard codes:
• Pipelines in general: API RP 1111, /3/and BS EN 14161, /10/,
• Risers in general: API RP 2RD, /4/
• Submarine pipelines: DNV-OS-F101, /42/,
• Dynamic risers: DNV-OS-F201, /43/,
• Flexible pipe systems: ISO 13628-2, /95/, or ISO 13628-11, /97/,
• Umbilicals: ISO 13628-5, /96/,
• Subsea power cables: see Guidance note 4.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 2:
Generally the default for rigid pipeline system design and approval is DNV-OS-F101 Submarine Pipeline
Systems. DNV-OS-F101 Sec.10 gives requirements for installation/offshore construction of submarine pipeline
systems.Parts of DNV-OS-F101 Sec.10 are also generally applicable for flexible pipes and risers.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 3:
Detailed guidance regarding installation of cables may be found in DNV-RP-J301 Sec. 6.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
SECTION 8 Offshore wind farm (OWF) installation
operations
8.1 Introduction
8.1.1 General
8.1.1.1
This section gives the MWS requirements for installing offshore wind farm infrastructure (apart from cables which
are covered in Sec.7). Operators should also consider national and local regulations, which can be more
stringent. Background information is in App.H.
8.1.2 Scope
8.1.2.1
This standard provides requirements and guidance for installation of offshore wind farms, in particular:
• Foundations including monopiles, steel jackets, gravity bases, suction bases, floating bases including
spars, TLPs and semisubmersibles.
• Towers, turbines and blades to be installed on foundations.
• Offshore substations, offshore converter platforms, offshore transformer station, control and other
platforms, including those on jack-up platforms.
8.1.3 Revision history
8.1.3.1
This section replaces the applicable sections of the following legacy document:
• 0035/ND Guidelines for Offshore Wind Farm Infrastructure Installation.
8.2 Planning
8.2.1 General
8.2.1.1
Page 134 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
See Sec.2 for general planning requirements and Sec.3 for environmental conditions and criteria.
8.2.2 Tolerances and criteria
8.2.2.1
Tolerances and criteria should be agreed with the MWS company at an early stage of the project.
Guidance note 1:
The selection of many installation tolerances and criteria will be a trade-off between reducing the cost of
manufacture and reducing the costs of delays waiting for good weather in consequence. Manufacturers often
prefer tighter installation tolerances which require better weather criteria for installation. It is generally beneficial
to select the transport/installation contractors before such tolerances and criteria are fixed as they may
significantly affect the installation methods, risks and costs.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 2:
The MWS company normally has input to the selection to ensure that the tolerances and criteria are not so
severe that there is a possibility that the equipment may never be able to be installed without taking
unacceptable risks.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
8.2.2.2
Such tolerances may include:
a. Position and orientation of monopiles, pile templates, jackets and other structures.
b. Pile or structure verticality.
c. Clearances between piles inside pile sleeves, including allowances for weld beads and grout keys.
8.2.2.3
Such criteria may include:
a. Wind speeds (at specified heights and gust durations) for critical lifts.
b. Any restrictions on current speeds or wave heights (and how they will be measured) for specific
operations. These could include stabbing piles or jackets into templates.
c. Degree of acceptable damage to grout keys during piling.
d. Any restrictions on helicopter or vessel movements within the field in bad visibility or other adverse
conditions.
e. Any restrictions on transfer of people and equipment onto fixed or floating installations by various means.
f. Requirements for disposal of any dredged materials, drilling cuttings or soil plugs removed from piles (to
comply with national or international laws or conventions, and to avoid problems with other contractors).
g. Piling operations – sound effects on sea life.
8.2.3 Vulnerable items or areas
8.2.3.1
Due to the many parties and vessels working in close proximity, it is necessary that each party understands what
items are particularly vulnerable to actions by others. These items need to be identified at an early stage so that
they can be considered in the relevant risk assessments. The list of vulnerable items needs to be updated and
promulgated as required during the life of the wind farm.
8.2.3.2
Typical vulnerable items or areas may include:
a. J-tube entry holes being covered with soil or debris.
b. Changes in seabed level (from scour, dredging, jack-up footprints, drill cuttings, etc.) varying the natural
frequency of foundations.
c. Scour can also affect jack-up foundations, cables, anchors etc. Scour model tests may be required in areas
with high current speeds and soft or sandy seabeds.
d. Damage to grout seals and back-up seals.
e. External fittings (including anodes, J-tubes, etc.) being damaged by dropped objects, vessel collision or
mooring lines.
f. Operations of divers (vulnerable to propellers and propeller wash, noise and blast, bubble curtains, cables
and dropped or lowered objects).
Page 135 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
8.2.4 Planned moorings
8.2.4.1
Geotechnical and bathymetric surveys should determine at an early design stage if the seabed will provide good
anchor holding and may determine the type of anchors that will be needed. If anchor holding is poor (leading to
a high probability of dragging anchors damaging cables) then prelaid or piled anchors may be desirable.
Allowable anchor locations should be agreed at the same time as the cable routes.
8.3 OWF installation vessels
8.3.1 Jack-ups – general
8.3.1.1
Jack-up legs can be a major threat to cables. The as-laid cable routes should be updated as required and
properly distributed through the project in order to prevent cable damages. A suitable safe distance shall be
maintained between the as-laid cable route and the intended positions of the jack-up legs. This is of particular
importance in OWF developments where cable laying/installation is progressing near turbine installation
activities in a similar time frame.
8.3.2 Jack-ups in weather unrestricted operations
8.3.2.1
Jack-ups that are designed and classed for elevated operations in conditions in excess of those at the installation
site (either all year or for particular months) shall comply with the requirements of DNVGL-ST-N002, /39/
8.3.2.2
The jack-up can operate at a lower air gap than required for survival in a design storm as long as it is able to jack-
up to a safe air gap for a design storm before bad weather.
Guidance note:
If a breakdown prevents jacking up, then the crew may need to be evacuated.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
8.3.3 Jack-ups in weather restricted operations
8.3.3.1
Jack-ups that cannot comply with [8.3.2] for a specific location and season shall comply with the requirements for
weather restricted operations in [2.6.5].
Guidance note:
Useful practical guidance on weather restricted jack-up operations is given in Section 5.3 of RenewableUK
Guidelines for Jack-ups, /115/, but note that [2.6.7] allows a greater operational window. This is summarised as:
a. Agree procedure documents which include limiting criteria, allowing for uncertainty due to monitoring
and the forecasting of the environmental conditions (see [2.6.9]), for relevant decision points and identify
suitable alternative jack-up locations between the site and safe ports.
b. The jack-up is only to leave a safe location to go to the installation site on receipt of a favourable weather
forecast with high confidence to cover the time (including a contingency for delays) from departure to
return to a safe location.
c. The jack-up is to leave the installation site unless there is a confident good weather forecast to cover the
remaining time on site and to return to a safe port or to elevate to a safe air gap at a suitable stand-by
location, including a contingency for delays.
d. If the jack-up cannotreach a safe port or location before meeting bad weather (above the laden jacking
limits of the jack-up, typically about 1 m to 1.5 m significant wave height), then it should jack-up to survival
air gap at a suitable shallow water location and evacuate the crew if necessary.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
8.3.3.2
The procedures and criteria described in [8.3.3.1] shall be the subject of a risk assessment in accordance with
Page 136 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
[2.4].
8.3.3.3
Jack-ups can also operate on DP or when moored afloat to save time jacking up and down and pre-loading.
These operations require favourable weather and shall follow the weather restricted operations requirements in
[2.6.7]. The use of the crane in floating mode shall be specified in the vessel’s operation manual with the
associated allowable environmental limits and approved by the classification society.
8.3.3.4
Jack-ups can operate in semi-jacked-up condition (vessel stabilised in water by a low leg pre-loading and a
reduced draught) under good weather conditions. This condition can make it feasible to operate the jack-up at
critical locations where the risk of punch through is high. It will require approval by the vessel’s classification
society as it is not typically a normal operating condition.
8.3.4 Crane vessels (seagoing)
8.3.4.1
Any crane vessel or sheerlegs shall be classed for operating in the relevant area. The design and operating
criteria shall be defined according to Sec.2.
8.3.4.2
Carrying a suspended load on a crane hook in transit offshore is not generally considered good practice, unless
it is for very short distances in calm weather. In bad weather the load can be very difficult to control, stability is
reduced and the crane can be overloaded. Approval of such operations will require agreement from the vessel’s
Classification Society and a risk assessment in accordance with [2.4].
8.3.5 Inshore crane vessels and barges
8.3.5.1
Inshore crane vessels and barges shall only be used if allowed by their class notation and:
a. The MWS company has agreed procedure documents which include limiting environmental criteria for
relevant decision points and identifies safe ports or locations. These criteria shall take into consideration
the Alpha Factors described in [2.6.9]
b. The vessel is only to leave a safe port or location to go to the installation site on receipt of a confident
good weather forecast to cover the period from departure to safe return, including a contingency for
delays.
c. The vessel to leave the installation site unless there is a confident good weather forecast to cover the
remaining time on site and to reach a safe port or location, including a contingency for delays.
8.3.6 Grounded OWF installation vessels and barges
8.3.6.1
Some vessels working in shallow water may need to be grounded at low water or over one or more tidal cycles.
This can only be approved provided that:
a. The vessel’s classification society allows such operations.
b. The seabed is such that the vessel will not be damaged and it will not hold the vessel down when
attempting to refloat.
c. There is a method (e.g. moorings or “spuds”) for holding the vessel on location when grounding and
floating off in the design conditions agreed with the MWS company at the design stage without damaging
any cables or other structures or equipment.
d. A confident good weather forecast is obtained before grounding to cover the period (including a suitable
allowance for delays) until float-off without exceeding the operational criteria.
8.3.7 Other OWF installation vessels
8.3.7.1
The following vessels usually do not require the approval of the MWS company unless their operations represent
a risk for other structures or operations.
Page 137 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
a. Crew transfer or accommodation vessels with proprietary crew access arrangements.
b. Escort and stand-by vessels can be needed in some areas to warn off other vessels, especially during
sensitive operations or transports.
c. Bubble curtain deployment and energising vessels which can be needed if regulations on piling noise
pollution apply (see [13.10.2]).
8.3.7.2
In some cases, it may be unclear whether the approval of the MWS company is required or not for smaller vessels
approaching existing structures. Planned operations should be discussed between the OWF owner, the
Underwriter and the MWS company in order to identify the major risks for the existing structure and decide case
by case the scope of the MWS company.
8.4 Planning and execution
8.4.1 Procedures and manuals
8.4.1.1
Technical documentation shall be completed for all operations. See [2.3] for details. In general, this should
include:
a. The anticipated timing and duration of each operation, including contingencies.
b. The limiting wave states, wind speeds and currents, and where applicable any visibility/day-light,
temperature and precipitation limits, as well as the site-specific equipment or methodology prescribed for
measuring each limit-state.
c. The transport route including shelter points.
d. The arrangements for control, manoeuvring and mooring of barges and/or other craft alongside
installation vessels.
e. Effects on and from any other simultaneous operations (SIMOPs – see IMCA M 203, /83/).
f. Contingency and emergency plans.
g. Requirements from the relevant MWS company standards for each individual phase.
8.4.2 Weight control
8.4.2.1
The requirements in [5.6.2] apply.
8.4.2.2
The manufacturer shall supply a weight statement with tolerance and CoG envelope for all weight-sensitive
items.
8.4.2.3
When a large number of virtually identical items are built with very good quality control, reduced weight
contingency factors can be agreed with the MWS company based on the standard deviation from weighing of
initial items, with random subsequent weighing used to confirm consistency of manufacture.
8.4.2.4
Where rigorous quality control is in place, and predictions of final weights in initial weighings are demonstrated
to be accurate, a reduced requirement for weighing can be agreed with the MWS company.
8.4.3 Weather restricted operations and weather forecasts
8.4.3.1
For requirements see [2.6.7] for requirements for weather restricted operations and [2.7] for weather forecasts.
8.4.3.2
For areas with high tidal currents there can be additional restrictions on operations due to the need to wait for
slack (or slacker) tides for current-sensitive operations such as:
Page 138 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
• Moving jack-ups on or off location
• Stabbing piles or installing jackets, substructures or equipment on the seabed
• Bringing cargo vessels alongside installation vessels.
• Diving operations.
8.4.3.3
When high currents are combined with shallow water then additional current forces will be caused by “blockage”
effects. These shallower conditions also lead to increased seabed turbulence due to wave action, and additional
contingency measures can be necessary to make allowances for accelerated scouring around jack-legs and
spudcans. However suitable moorings, stabbing guides and other aids can help to reduce the sensitivity to
currents and decrease downtime waiting for slack tide.
8.4.3.4
Weather forecasts shall follow the requirements in [2.7]. Forecasts for wind speed shall specify the height (to be
agreed in advance) and wind speeds measured on site should be corrected to that height for direct comparison.
The swell height, direction, and period should alsobe included, as well as the probability of precipitation, fog
and lightning within the next 24 hours. The time of sunrise and sunset, and the phase of the moon can be
advantageous though these will normally be found in nautical almanacs.
8.4.3.5
For subsea lifts in areas where it is known that high currents exist in the water column, in-field monitoring of
currents (speed and direction) should be considered to enhance the regular forecasts. The monitoring of sub-sea
currents with acoustic Doppler or similar systems should be considered when the operational limits of ROVs, and
drag on piles during stabbing can lead to operational delays.
8.4.4 Site and route survey requirements
8.4.4.1
As well as ensuring that all positional, bathymetric, soil and current surveys are performed using the same datum
and coordinate systems, various requirements to ensure sufficient accuracy like the frequency of survey
equipment calibration (for salinity, temperature etc.) shall be agreed. There shall be an agreed procedure for
ensuring that all survey results are disseminated to all relevant parties as required.
8.4.4.2
The “as built” locations of structures, cables and subsea equipment shall be recorded accurately on charts using
a common survey datum used by all parties. These charts shall be kept updated, including all jack-up footprints
as soon as they are made and issued to all vessels operating in the field. “No anchoring” zones shall be well
marked.
8.4.4.3
In advance of the final detailed design being carried out for the foundations, the seabed material, geophysical,
and geotechnical surveys of the sub-bottom profile should have been carried out, as well as magnetometer
surveys for ferrous objects, including UXO. The Cone Penetrometer Test results and other appropriate survey
details for each foundation location should be documented, to jack-up vessel operators. This will allow them to
carry out site-specific assessments in accordance with ISO 19905-1, /102/, and to assess the possibility of
scouring around jack-legs and spudcans.
8.4.4.4
Unexploded ordnance (UXO) disposal, although important, is not generally subject to a Marine Warranty and is
normally excluded. However it is recommended that it will be managed in accordance with the requirements of
‘Risk Management Framework’ provided in CIRIA C754, Assessment and management of unexploded ordnance
(UXO) risk in the marine environment, /13/ or similar.
8.4.4.5
Additional requirements for the cable route surveys are given in Sec.7.
8.4.5 Scour protection
Page 139 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
8.4.5.1
If scour is a possible problem, procedures or contingency procedures shall be prepared and anti-scour materials
stockpiled and deployment equipment prepared for mobilisation. See [8.4.3.3] and [8.4.4.3] for information that
will help in prediction of scour.
Guidance note 1:
“Dynamics of scour pits and scour protection”, /119/ gives the results of research into scour on early UK offshore
wind farms.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 2:
Cables are generally be trenched or otherwise protected in scour-prone areas. However additional precautions
can be required close to J-tubes or I-tubes at monopiles or platforms, especially immediately after laying.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 3:
Scour around jack-up legs can make them more vulnerable to punch-through and around cables can make them
more vulnerable to damage.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
8.4.5.2
Care shall be taken when laying scour protection to ensure that bad weather and/or high currents during the
installation phase do not cause damage to the lower layers.
8.4.6 Wet storage of jackets or OWF foundations
8.4.6.1
Any unpiled jackets or foundations should be able to comply with the requirements in [13.10] for the return
period applicable to the operation reference period given in [3.4]. This can require any chosen location to be
sheltered from high waves and currents.
8.4.6.2
A constant exclusion zone for marine traffic shall be enforced.
8.5 Load-outs of OWF components
8.5.1 Structure load-out
8.5.1.1
Load-outs shall be in accordance with Sec.6. However the following special cases apply, as applicable.
a. Special consideration should be given to purpose-built lifting appliances for blades. The lifting tool
Certificate shall specify the maximum load and any limits regarding the overall dimensions of the lifted
item and any environmental limitations (e.g. maximum wind speed).
b. In the event of structural modifications to an item of lifting equipment, it shall be re-approved by a
Recognized Classification Society before further use.
c. Bolts used for removable lifting lugs shall generally be used one time only. In special cases, re-use can be
accepted as described in [E.2] but only if initial pretensioning does not exceed 60% of the bolt yield
strength and the loads during lifting have not exceeded the maximum design values. For re-use of bolts, a
detailed inspection plan with regular NDT including rejection criteria and exchange intervals should be
documented. As a minimum, bolts should be visually inspected after each lift and with MPI (Magnetic
Particle Inspection) after every 3 lifts unless fatigue calculations accepted by the MWS company show that
less frequent inspections are acceptable.
d. Re-useable lifting lugs shall be tested in accordance with [16.9.7].
8.6 Transport of OWF components
8.6.1 General
Page 140 of 543Noble Denton marine services - Marine Warranty Wizard
18/01/2017https://mww.dnvgl.com/Document/Get?projectId=2883&docName=DNVGL-ST-N00...
8.6.1.1
Sea voyages are covered in Sec.11 and road transport in Sec.9. The rest of [8.6] describes items specific to OWF
components.
8.6.1.2
Seafastening of blades and other fragile components require special care to avoid damage from welding or
locating guides. Where friction is required to resist some or all of the seafastening forces, the coefficients of
friction shall be shown to be adequate in both the wet and dry states. See [11.9.2].
8.6.1.3
The requirements of [E.2] will apply for bolted connections used for seafastening. The strength of bolted
connections may be assessed to DNVGL-OS-C101 /24/, Ch 2 Sec 4.8, Eurocode 3 /61/ or [E.2]
8.6.1.4
Minimum clearance between cargo items to be lifted is given in [16.13.2] and [16.13.3].
8.6.2 Transport of complete rotor
8.6.2.1
Rotors with diameters of well over 100 m may be transported horizontally (rotor axis vertical) on vessels or
barges of only about 30 to 40 m beam. The voyage and installation planning shall account for the large
overhangs in particular avoiding wave slam on the blades.
Guidance note 1:
The blades will generally be very vulnerable to wave slam, especially when the vessel rolls and/or pitches into a
wave.
---e-n-d---of---G-u-i-d-a-n-c-e---n-o-t-e---
Guidance note 2:
Normally the voyage and installation planning considers some or all of the following:
a. The rotor being designed to safely withstand the accelerations (from [11.3]).
b. Reducing to negligible the probability of wave slam on the blades by securing them well above the still
water level.
c. Selecting vessels that can be ballasted to reduce the motions in likely wind and wave combinations.
d. Doing motion response calculations to optimise the loading and ballasting arrangements so as to
minimise the probability of wave slam on the blades in likely wind and wave combinations.
e. Weather routing the transport to avoid any weather that could cause wave slam on the blades. (This cannot
always be practicable for some seasons and longer routes between suitable shelter points).
f. Developing procedures to avoid blade collision damage when coming alongside
