Slope Stability Analysis: Slide3
Module 2B
When to model in 3D?
1. If pit slope geometry is 3D
2. If failure mechanism is 3D
3. If material strength is anisotropic and not aligned (is oblique) to 2D cross-section
4. If spatial variation in material and other properties is 3D
5. If challenging to identify ‘critical’ or ‘representative’ 2D cross-section
6. If factors of safety of 2D (closely-spaced) cross-sections vary significantly
• If one chooses most conservative FoS design might be too conservative
• If one chooses least conservative FoS design might be too optimistic
7. If challenging to ‘smear’ influence of discrete support/structural elements
• when supports (such as soil nails) are oriented in different directions or spacing varies
8. If end effects are important
Model Generation Workflow
3
1. Import and
clean geometry
2. Define
material
properties
3. Create
external
4. Divide all
5. Assign
material
properties
6. Collapse small
volumes
7. Assign roles to
surfaces
8. Select
analysis method
9. Select slip
surface options
10. Add search
limits
11. Compute
12. Interpret
13. Additional
analysis
Interface
• View can be enlarged by double clicking in individual viewport window
• Viewport settings can be customised (View > Display options > Viewports)
LOCKED TOP VIEW ROTATE
LOCKED FRONT VIEW LOCKED RIGHT VIEW
Model Requirements
The following model parameters need to be defined before Computing a Slide3 model:
• Geometry (import surfaces, volumes, create geometry within Slide3 and Divide All to create
3D model)
• Loading (if applicable)
• Support (if applicable)
• Groundwater (if applicable)
• Material strengths
• Analysis method
• Search method
• Search limits
Geometry
• Full 3D geometry
• Geometry can be created from scratch
or imported from a variety of file
formats
• Boundary surfaces can be interpolated
from borehole data using the Borehole
Manager
• Import from Slide
• 2D models can be created in Slide and
imported into Slide3. The 2D model will
automatically be converted into an
equivalent 3D model. You can then
compare the results to see the effect of
2D vs 3D.
3D model of open pit mine
Analysis Methods
The following LE methods have been adapted
for 3D analysis:
• Bishop (moment equilibrium)
• Janbu (force equilibrium)
• Spencer (force and moment
equilibrium)
• GLE (force and moment equilibrium
with interslice force function)
3D critical slip surface
Slip Surfaces & Search Methods
The 3D slip surface shapes which can
be generated are:
• Spherical
• Ellipsoidal
• Spline (NEW)
• Mutli-Planar
• Wedge
Spherical slip surface Ellipsoid surface with Spline optimization
Slip Surfaces & Search Methods
Traditional methods
• Grid Search
• Auto Refine
Advanced methods optimized for speed and
efficiency
• Cuckoo search
• Particle swarm
Slip surfaces can conform to the shape of bedrock
using an Infinite Strength material
Main: 2D view of slip surface sliding on bedrock
(infinite strength material)
Top: 3D view of slip surface sliding on bedrock
Loading
Loads can be added as:
• Point loads
• Distributed loads
• Seismic loads
Loads can be applied at any 3D orientation or
location.
Loads can only be applied once an external
boundary has been defined.
Groundwater
Pore pressure can be defined using:
• Water surfaces (water table or piezo line)
• Water pressure grids
• Ru coefficients
• Groundwater > Add Water Surface
Loading & Support Options
Slide3 offers all support types found in Slide2
• End Anchored
• GeoTextile
• Grouted Tieback
• Grouted Tieback with Friction
• Pile/Micro Pile
• Soil Nail
• User Defined
Support can be applied at any 3D orientation
Bolt pattern applied to slope face
Loading & Support Options
• Loading options include
• Point Loads
• Distributed Loads
• Seismic Loads
• Loads can be applied at any 3D
orientation or location
Uniform surcharge load at crest of curved slope
section
Groundwater Definition
Groundwater pore pressure can be defined using
• Water surfaces (Water Table or Piezo Line)
• Water Pressure Grids
• Ru coefficients
Pore pressure grids from RS3 finite element
analysis can be imported into Slide3
Water table above ground surface at toe
creates ponded water
Material Models
• Mohr-Coulomb
• Undrained
• Infinite Strength
• Anisotropic
Strength
• Shear/Normal
Function
• C/Phi Function
• Generalized
Hoek-Brown
• Power Curve
• Vertical Stress
Ratio
• Barton-Bandis
• Hyperbolic
• Discrete Function
• Drained-
Undrained
• Generalized
Anisotropic
• SHANSEP
Slide3 offers a wide variety of strength models for soil and rock:
The Generalized Anisotropic Strength option allows you
to create virtually any customized anisotropic material
model incorporating multiple failure criteria applied over
user-defined 3D orientations.
Results and Data Interpretation
Global minimum 3D
surface
Contour any input or
output data on surface
Show all surfaces, pick
surfaces, export surfaces
Show results on 2D cutting
planes
Filter output by safety
factor
Advanced Features
• Excess Pore Pressure
• Rapid Drawdown Analysis
• Unsaturated Shear Strength
• Anisotropic regions
• Tension cracks
Tension Crack
• If a slip surface intersects a Tension Crack surface, the slip surface will be
truncated by the Tension Crack surface.
• The tension crack essentially terminates the slip surface, thereby removing
the tensile stresses from the calculations.
Symmetry
• If model geometry is symmetric and the
material model is not anisotropic, it can be
expected that the critical slip surface is
symmetric
• This symmetry can be enforced in engine
computations by enabling the symmetry
option within project settings
Slide2 Section Cut
Results – Interpretation
Review
• Global minimum/s (for all analysis methods calculated)
• Show all slip surfaces (to ensure adequate coverage across area of interest)
• Surface safety maps (readily highlights low FOS areas)
• Column Viewer (check for tension, review material properties assigned to column bases)
• Contour plots e.g. of stress, strength, pore pressure, etc. (validate results)
• Use Slide2 Section Creator (to compare results with 2D)
• Import and overlay monitoring data if available (reconcile results with slope monitoring data)
Results – Global Minimum
Results – Show All Surfaces
Interpretation – Surface Safety Map
Interpretation – Surface Safety Map
FOS = 1.48
~ 800 slip surfaces FOS = 1.33
~ 5000 slip surfaces
The number of slip surfaces calculated will have an impact on the results.
Interpretation – Column Viewer
Interpretation – Contour Plots
Interpretation – Slide2 Comparison
Interpretation – Slide2 Comparison
3D FOS
2D FOS
Calibration with Radar Monitoring Data
Probabilistic Analysis
Probabilistic analysis uses distribution of material strength/s to see
the range in FOS values that are calculated from combinations of
different strengths sampled from within the distribution.
Sampling methods:
• Monte-Carlo: Input distribution is sampled at random
• Latin-Hypercube: Distribution is divided into sections and
each section is sampled, to ensure distribution is covered
• Response Surface: FOS is predicted using a small number of
strategically placed samples
Analysis types:
• Global Minimum: The global minimum surface for a
deterministic analysis is used. The new samples are input,
and the FOS is calculated using that same surface
• Overall Slope: For each simulation (new sample), the slip
surface search is repeated, and new global minimums may
be found
• Multiple Minima: The surfaces searched in the deterministic
analysis to determine the global minimum are used, and the
samples are changed for each surface
𝑃𝑟𝑜𝑏𝑎𝑏𝑖𝑙𝑖𝑡𝑦 𝑜𝑓 𝐹𝑎𝑖𝑙𝑖𝑢𝑟𝑒 𝑃𝐹 =
# 𝑜𝑓 𝑠𝑖𝑚𝑢𝑙𝑎𝑡𝑖𝑜𝑛𝑠 𝑤𝑖𝑡ℎ 𝐹𝑆 < 1
𝑇𝑜𝑡𝑎𝑙 # 𝑜𝑓 𝑠𝑖𝑚𝑢𝑙𝑎𝑡𝑖𝑜𝑛𝑠Back Analysis
• Activate the Probabilistic Analysis in Project Settings to complete a back
analysis in Slide3
• Enter the distribution of material strengths for each material to be back
analysed
Back Analysis – Example
Initial FOS = 1.66 View Scatter Plot in Results
Back Analysis – Example
Select combination of material strength that is estimated to provide a FOS < 1
Back Analysis – Example
Modify material parameters in new Slide3 model Back analysed FOS = 0.96
Simple Methods to Importing and
Extruding Slide 2D Models
Introduction
The model analyzes the slope stability of a soil (yellow) with a weak layer
(green) to see the effect of geometry
• The factor of safety is affected by the size of model and the loading force
Example Model 1
Base model with continuous loading
200 m
95 m
Example Model 2
Base model with centered load
200 m
95 m
20 m
10 m
Step 3: Applying New Loading
The resulted model should look like below
Results Comparison
Slide3 Example 1: GLE FS 1.03 Slide3 Example 2: GLE FS 1.1Slide2 result : GLE FS 1.01
Base Normal Stress Contours
Model Creation by Importing Geometry
Files (DXF, STL)
Open Pit
Geometry and Geology of the open pit
mine
Step 5: Check Results
Interpret > Refresh Results
Slope Limits
Using Slope limits option, find the
factor of safety on the opposite
side of the pit
