This set of Electrical Machines Multiple Choice Questions & Answers (MCQs) focuses on “EMF
Polygon – 1”.
1. The angular slot pitch, γ is given by
a) γ= πP/Total number of slots Elect radians
b) γ= 180P/Total number of slots Elect degrees
c) γ= 180/Slots per pole Elect degrees
d) Any of the mentioned
View Answer
Answer: d
Explanation: Angle γ is the angle between adjacent slots.
2. Consider the following statements regarding the design of distributed armature winding in a
3-phase alternator:
(i) it reduces the phase-belt harmonics
(ii) it increases the utilization of the armature iron and copper
(iii) it increases rigidity and mechanical strength of the winding
(iv) it reduces copper in the overhang of the winding
Which of these statements are correct?
a) (i),(iii),(iv)
b) (ii),(iii),(iv)
c) (i),(ii),(iii)
d) (i),(ii),(iii),(iv)
View Answer
Answer: c
Explanation: Distributed armature winding does not reduce copper in the overhang of the
winding, also k​dn​=(sinqnγ/2)/(qsinnγ/2), k​dn​d​1​, implies it has the effect of reducing n​th​ harmonic
EMF, where q=slots per pole per phase.
3. What is the coil span for a 2 pole 18 slot machine?
a) 9
b) 4.5
c) 18
d) 6
View Answer
Answer: a
Explanation: Coil span= number of slots/number of poles= 18/2=9.
4. In a machine with coil span 9, if a coil has its one coil-side in slot 1, then its other coil-side
must be in ____________
a) slot 9
b) slot 8
c) slot 10
