d) 3*k*I
View Answer
Answer: a
Explanation: The phase current will be reduced by 1/1.73.
10. If para magnetic core is used in the place of the ferromagnetic core of the transformer, then
magnetostriction will
a) be vanished
b) reduce
c) increase
d) not be affected
View Answer
Answer: a
Explanation: If the core is not ferromagnetic then the transformer will not operate at all so no
humming sound.
11. When we magnetize the ferromagnetic core of the transformer, core length_______ and it
______ when demagnetized.
a) decreases, increases
b) decreases, decreases
c) increases,increases
d) none of the mentioned
View Answer
Answer: a
Explanation: Due to aligned magnetic dipoles in the material, the size will reduce by a small
margin and vice versa while demagnetization.
12. A 400 V, 10 KVA transformer at 50 Hz, is operated at the frequency of 40 Hz, then the
humming
a) increases
b) decreases
c) remains same
d) increases to very high
View Answer
Answer: a
Explanation: If the frequency is reduced, the core flux density increases, so the noise also will
increase.
13. While using three phase transformers, it is taken care about the third harmonics current in
the system.
This is present when transformer set is delta on either side.
a) True
b) False
View Answer
Answer: a
Explanation: Third harmonic current are co-phase in nature and require closed path which is
present in delta connected only.
