b) Xd = 6, Xq = 3.86
c) Xd = 3, Xq = 3.86
d) Xd = 6, Xq = 2.5
View Answer
Answer: d
Explanation: Xd=V(max)/I(min) = 30/5 = 6 ohms;
Xq=V(min)/I(max) = 25/10=2.5 ohms.
13. A synchronous motor is operated at a bus voltage of 1.5 pu and drawing 1.0 pu at zpf
leading current. Its synchronous reactance is 0.4 pu. What is the excitation emf of the motor?
a) 2.0 pu
b) 1.5 pu
c) 1.0 pu
d) 1.1 pu
View Answer
Answer: d
Explanation: E = V-I*X = 1-0.5=0.5 pu.
14. Consider a 3-phase alternator with negligible armature resistance and high rotational inertia
delivering power to an isolated load when the armature terminals got short circuited. After
sometime, the mechanical
power input to the shaft of the machine is terminated at time t0. The short-circuit current
circulating in the armature will change till the machine comes to halt at ‘ts’. Which one of the
curves depicts this phenomena?
a)
