Microstructure and high-temperature wear behaviour of Inconel 625
multi-layer cladding prepared on H13 mould steel by a hybrid additive
manufacturing method
Jingbin Hao a,b,*, Fangtao Hu a,*, Xiawei Le a, Hao Liu a, Haifeng Yang a, Jing Han a
a School of Mechatronic Engineering, China University of Mining and Technology, Xuzhou, China
b Jiangsu Engineering Technology Research Centre on Intelligent Equipment for Fully Mining and Excavating, China University of Mining and Technology, Xuzhou, China
A R T I C L E I N F O
Associate Editor: Jian Cao
Keywords:
Hybrid additive manufacturing
Laser cladding
Ultrasonic surface rolling
Inconel 625
H13 steel
Microstructure
High-temperature wear behaviour
A B S T R A C T
To improve the high-temperature performance of a hot-working mould, high-temperature wear-resistant multi-
layer laser cladding was prepared on the forming surface of the mould by a hybrid additive manufacturing
(HAM) method. First, an Inconel 625 multi-layer cladding was fabricated on the H13 mould steel by laser
cladding. Then, the multi-layer laser cladding was milled by CNC. Finally, the milled multi-layer cladding was
subjected to ultrasonic surface rolling (USR) treatment. The microstructure and high-temperature wear behav-
iour of the multi-layer cladding prepared by HAM were studied using SEM, EDS, and a high-temperature trib-
ometer. The results show that the multi-layer laser cladding after USR has a smooth nanolayer. The surface
roughness is below 0.15 μm. The multi-layer cladding has better high temperature wear resistance than the
substrate. The microstructure of the multi-layer cladding from the surface to the substrate is composed of coaxial,
columnar, and dendritic grains. After USR treatment, the dendritic grains are grown in the processing direction
and significantly refined.
1. Introduction
With the development of the moulding industry, the mould steel has
been also developing rapidly. Due to the development of industrial
production techniques and the continuous emergence of new materials,
the working conditions of moulds are becoming more onerous, and new
requirements are constantly being imposed on the performance, quality,
and variety of mould steels. Higher-grade manufacturing tools are
required to satisfy the continuous development of extreme
manufacturing (Guo and Lu, 2019), at the same time, tool wear in the
manufacturing has been becoming increasingly complicated (Jiang
et al., 2020). H13 steel is the most widely applied and most represen-
tative type of hot-work die steel: it has the characteristics of high
hardenability and high toughness; has excellent crack resistance, and
could be water-cooled when used in-service; however, its
high-temperature wear resistance is moderate. While re-heating to
above 540 ℃, its hardness decreases rapidly. To improve the perfor-
mance of H13 steel to meet the production requirements, researchers
have continued to study its properties and behaviour. The earliest
methods used to improve its performance involved adding other metal
elements to H13 (Yongliang, 1997); Gao et al. added rare earth to H13,
and found that adding 0.015 wt.% of rare earth could improve the
mechanical properties of H13 (Gao et al., 2015). Later, people modified
the surface of H13 steel to improve its high-temperature wear resistance
and corrosion resistance. Chang et al. conducted surface oxidation
research on H13 steel and found that the oxide layer can enhance the
polarisation resistance and quickly generate a passivation layer to
improve the corrosion resistance (Chang et al., 2010). Liu et al. com-
bined shot-peening and nitriding to fabricate a composite nitriding layer
on the surface of H13 steel, and studied its thermal fatigue cracking
performance (Liu et al., 2019a). With the development of laser cladding
technology, many scholars used laser prepared a cladding layer on the
surface of H13 steel to improve the performance of H13 steel and meet
the requirements of various working conditions. The cladding layer
prepared by Tong et al. using a mixed powder of 75 % Cr and 25 % Ni on
the surface of H13 had better anti-cracking, anti-oxidation, and corro-
sion properties (Tong et al., 2013). Others prepared a nanolayer on the
surface of H13, and the wear resistance and corrosion resistance of this
layer were significantly improved (Jiang and Molian, 2001).
Ultrasonic surface rolling (USR) technology is a new type of
* Corresponding author at: School of Mechatronic Engineering, China University of Mining and Technology, Xuzhou, China.
E-mail address: fangtaohu@cumt.edu.cn (J. Hao).
Contents lists available at ScienceDirect
Journal of Materials Processing Tech.
journal homepage: www.elsevier.com/locate/jmatprotec
https://doi.org/10.1016/j.jmatprotec.2020.117036
Received 2 August 2020; Received in revised form 17 December 2020; Accepted 23 December 2020
Journal of Materials Processing Tech. 291 (2021) 117036
2
ultrasonic assisted surface modification method. This method could
promote the nanocrystallisation of surface grains. Nanocrystalline ma-
terials exhibit unique properties superior to traditional coarse-grained
materials because of their small grain size (usually less than 100 nm),
high interface density, and large volume fraction (Lu and Lu, 2004). If a
certain thickness and performance of nanostructured crystal layer can be
prepared on the surface of the traditional coarse-grained material, then
the overall performance of the material can be greatly improved through
the optimisation of the surface texture performance: not only can
traditional materials be better utilised, it also reduces production costs
(Wang et al., 2019). The gradient nanostructure prepared by Wang et al.
on the surface of IF steel by USR technique can suppress the generation
of cracks under high load and has good wear resistance (Wang et al.,
2018). Cheng et al. found that the samples have the longest fatigue life
by comparing the USR process with the traditional process (Cheng et al.,
2016). Huang et al. prepared nanolayers on the surface of 316 L steel by
USR technology, and found that nanometric particles enhanced the fa-
tigue resistance by suppressing the generation of cracks and adapting to
the amplitude of cyclic plastic strain (Huang et al., 2015).
At present, laser cladding technology has been used to prepare high-
quality multi-layer cladding (Heigel et al., 2016); Liu had conducted
laser cladding of cast iron to build a well bonded NiCoCr alloy coating
using a multi-layer cladding deposition approach instead of preheating
(Liu et al., 2016), therefore, in the present research, a hybrid additive
manufacturing (HAM) method that integrates multi-laser cladding and
USR technology was used to prepare a high-temperature alloy cladding
layer with a nanolayer on the surface of H13 steel to enhance the
high-temperature wear resistance of H13 steel.
2. Experimental work and material characterisation
2.1. Materials and experimental design
The HWL-RW1500 system was used to prepare the cladding layer.
The system is mainly composed of a semiconductor laser as a fibre-
coupled continuous output laser with a coaxial powder feeding device,
the powder feeder model is an HW-02SF device. High-purity Inconel 625
spherical alloy powder was selected as the original powder, its particle
size is 45− 105 μm, and its chemical composition is summarised in
Table 1.
Argon was used as the protective gas, one, three and six layers of
multi-layer and multi-pass cladding were prepared on the surface of H13
steel by coaxial powder feeding. The optimised laser parameters were as
follows: a laser power of 1400 W, a scanning speed of 3.33 mm/s, a
powder-feeding rate of 3.8 g/min, a spot diameter of 2 mm, a carrier gas
flowrate of 4 L/min, and an overlap rate of 42 %. After comparing and
studying the chessboard scanning strategy, the zig-zag scanning strategy
and the re-melting scanning strategy(Gu et al., 2020), a more suitable
method was developed to obtain high-quality cladding layer and the
scanning path is shown in Fig. 1: each layer used two scanning directions
and the scanning directions of two adjacent layers differ.
2.2. USR process
After cladding, the cladding layer was milled, and then USR was
performed at room temperature (this USR procedure was repeated four
times. The following parameters were used: a rolling ball diameter of
14 mm, an ultrasonic vibration frequency of 28 kHz, a vibration
amplitude of 5 μm, and an applied static force of 300 N. The processes of
SLC and USR are shown in Fig. 2, and the result of HAM is illustrated in
Fig. 3.
2.3. High-temperature friction and wear test
The HT-1000 high-temperature friction and wear tester was used to
compare the friction and wear experiments of the samples before and
after rolling at a temperature of 600 ℃. Before the experiment, we
removed surface defects from the abrasion samples with sandpaper, then
cleaned them with alcohol. The experimental parameters were: grinding
ball with a rotation radius of 2.5 mm, loading 5 N, friction applied at
600 rpm, wearing time of 20 min, and 6-mm diameter grinding balls
made of Si3N4.
2.4. Microstructural analysis
The sample was cut into pieces measuring 5 mm × 5 mm × 3 mm,
polished, and etched with aqua regia. The microstructure and composi-
tion distribution of the cladding layer were ascertained by a scanning
electron microscope (SEM) with an energy dispersive spectrometer
(EDS).
2.5. Micro-hardness test
The MTHV-1MMDTe type hardness tester was used to measure the
microhardness of the cladding layer, the applied load was 500 gf, and
Table 1
Main chemical composition of Inconel 625.
Main chemical composition (wt%)
Cr C Si Al Co Mo Nb Ti Mn Fe Ni
20− 30 ≤0.1 ≤0.5 ≤0.4 ≤1 ≤8− 10 3.15− 4.15 0.65− 1.15 0.5 ≤5 Bal.
Fig. 1. The scanning strategy.
Fig. 2. Schematic of laser cladding (a) and ultrasonic rolling (b).
J. Hao et al.
Journal of Materials Processing Tech. 291 (2021) 117036
3
the pressure holding time was 10 s. The hardness at a given position was
measured three times and the mean average taken.
3. Results and discussion
3.1. Multi-layer cladding process and cladding layer height
When repairing hot-working moulds, it is necessary to form multiple
layers and multiple layers of cladding. The overlapping rate and the Z-
axis lift are important factors that affect the quality of the multilayer lap
cladding. Setting the overlapping rate as a variable, 30 %, 40 %, and 50
% overlapping rates were set to conduct the cladding experiment on the
substrate: it was found that a 40 % overlapping rate provided a better
surface quality. We continued to search around 40 %, finding that a 42 %
overlapping rate has the best cladding quality while other process
parameters remain unchanged.
When performing multi-layer cladding, the lifting amount ΔZ on the
Z-axis needs to be controlled. ΔZ should be consistent with the thickness
of the single-pass cladding layer to ensure the same cladding process
conditions for each layer; however, in actual multi-layer cladding,
thermal deformation of parts and other factors will cause a certain de-
viation between ΔZ and the thickness of a single cladding layer. As a
result of the cumulative effect, the accuracy of the multi-layer cladding
is decreased; therefore, it is necessary to ensure the accuracy and
reasonableness of lifting amount ΔZ.
According to the cladding strategy in this article, the value of ΔZ is
determined according to the calculation model of multi-layer cladding
over a single track, as shown in Fig. 4, and then adjusted accordingly
according to specific experiments. This model makes the following as-
sumptions: (1) The cross-section of each cladding layer is a circular arc,
and the cross-sectional area is equal; (2) The curvature of the track re-
mains unchanged after cladding (Zhu et al., 2010).
In theory, it is necessary to ensure that after cladding a layer, it re-
mains flat relative to the previous layer, so
SABH = SBCD + SGHF 3a)
SCDFG = SOAFD − SOFD (3b)
FD = W,AE = h,CD = ΔZ (3c)
ΔZ =
(
4h2+w2
8h
)2
arcsin
(
4Wh
4h2+w2
)
−
W(W2 − 4h2)
16h
W
(3d)
where r is the radius of the arc, h represents the height of a single
cladding, and W is the width of a single track.
It can be seen from the above formula that ΔZ is a function of the
width W and the height h of the single track. In practice, the width and
height of the single reverse cladding layer should be determined
Fig. 3. The sample of hybrid additive manufacturing; a represents the sample after laser cladding, b is the sample after milling, c is the sample after USR.
Fig. 4. The Z-axis cladding lift calculation model.
Fig. 5. The section of samples after HAM; a is the section through one-layer cladding, b is the section through three-layer cladding, c is the section through six-
layer cladding.
J. Hao et al.
Journal of Materials Processing Tech. 291 (2021) 117036
4
according to the results of the cladding process experiment, and then ΔZ
is derived through the above formulation.
Fig. 5 shows the sections of samples after HAM, the average height
increased significantly as the number of layers increasing; the average
height of a single cladding layer is 2.2 mm, the average height of the
three layers is 5.2 mm, and the average height of the six layers is
9.6 mm.
3.2. Microstructure and EDS analysis of multi-layer cladding
It can be seen from Fig. 6 that the first cladding layer forms metal-
lurgical bond with the substrate, in result of the maximum temperature
gradient and slow growth rate, planar crystals appear at the junction
(Zhang et al., 2015). Planar crystals are also found between the substrate
and the first layer and between the first layer and the second layer,
which appear as white and bright colour bands between the two regions
(Figs. 6a and 6b).
Fig. 7 illustrates the microstructure diagram of the middle part in the
multi-layer laser cladding both before USR and after USR. It could be
seen in Figs. 6 and 7 that both samples show the same composition, the
cladding layers were composed of planar crystals, cellular crystals,
equiaxed crystals, and dendritic crystals from bottom to top. This phe-
nomenon was related to the temperature gradient G and the solidifica-
tion rate R during the solidification of the cladding layer.
As shown in Fig. 8, the value of G/R may cause a change in the so-
lidification method, the value of product GR determines the size of the
solidification structure (Liu et al., 2019b); at the bottom near the sub-
strate, faster heat dissipation leads to a larger temperature gradient
during solidification and a faster solidification rate, so planar crystals
are formed here. The first layer dissipates heat faster, so when the sec-
ond layer is cladding, the value of G/R is still large enough to form
planar crystals, thus a white and bright colour band can still be observed
at the junction between the two layers. The temperature continues to
increase with the increase in the number of cladding layers, so the value
of G/R from the third layer is not large enough to form planar crystals,
Fig. 6. a is the first layer after USR, b is the first layer before USR.
Fig. 7. a is themicrostructure diagram of the middle part of the multi-layer laser cladding sample after USR; b is the microstructure diagram of the middle part of the
multi-layer laser cladding sample after USR.
Fig. 8. The effects of G and R on the morphology and scale of the solidified
microstructure; G/R determines morphology of solidified structure, GR de-
termines the size of the solidified structure.
J. Hao et al.
Journal of Materials Processing Tech. 291 (2021) 117036
5
and more equiaxed dendrites appear. As the top layer is in contact with
the air and the movement of the laser, the direction of G is changed, so
dendrites which are growing along the direction of laser scanning
appear on the top of the top layer (Luo et al., 2019).
The USR processing head can apply a certain amplitude of ultrasonic
mechanical vibration along the normal direction of the workpiece sur-
face. Under a certain feed condition, the working head transmits the
static pressure and ultrasonic shock vibration to the surface of the
rotating mechanical parts, resulting in a crushing effect, thus, the metal
undergoes substantial elasto-plastic deformation. After USR, the surface
of the workpiece shows a certain degree of elastic recovery, and the
generated plastic flow fills the valleys on the surface of the workpiece
with peaks, thereby greatly reducing the surface roughness Ra to the
nanometric level and improving the comprehensive performance in-
dicators of the surface (Yang et al., 2017). Meanwhile, under the com-
bined action of ultrasonic impact and static pressure rolling, the violent
and uniform plastic deformation on the surface of the metal workpiece
will inevitably cause the original crystal grains on the surface of the
workpiece to be broken and refined. Reciprocating processing can make
the surface of the part evenly stressed, while increase the amount and
depth of deformation, to achieve crystal grains with further refinement
and homogenisation, thereby obtaining a nanostructured layer (Sun
et al., 2017).
Fig. 9 illustrates the surface profile before and after USR; after USR
the surface roughness decreased from 0.355 μm to 0.120 μm. After USR,
severe plastic deformation had occurred; it is well known that severe
plastic deformations are beneficial in obtaining ultrafine-grained
metallic materials accompanied by the improvements of mechanical
properties such as microhardness and strength. The plastic deformation
can refine grains and increase dislocation density. The dislocation slip-
ping, accumulation, and rearrangement can lead to formation of small-
angle grain boundaries and substructures, which can improve its me-
chanical properties (Wenbo et al., 2019). As shown in Fig. 10, under the
dual action of static pressure and ultrasonic vibration, the surface of the
sample processed by USR, and the crystal grains are squeezed and
elongated. As illustrated in Fig. 10a, the top of the surface is a severely
deformed region that is plastically deformed, the particles are extruded,
elongated, and the growth direction is parallel to the machined surface.
In the middle of the surface slight plastic deformation occurs, the growth
of the dendrites is oriented towards the processing direction, and the
dendrites are remarkably refined. Fig. 10a demonstrates the surface
after USR which is a nanolayer with a thickness of about 20 μm formed
parallel to the processing direction.
X-ray energy spectrum (EDS), is used to analyse the types and con-
tents of elements in the micro-region of the material by using SEM and
transmission electron microscope (TEM): using the characteristic X-rays
generated when electron beams interact with substances. EDS provides
information on the chemical composition of the sample, qualitatively
and semi-quantitatively detecting most elements. A three-layer cladding
layer is selected as the research object to study the changes in element
content in the cladding layers with depth after multilayer laser cladding.
Fig. 11 shows the EDS line scan analysis result of the Ni, Fe, Cr, and
Mo contents of three-layer laser cladding from top to bottom. In the
multi-layer cladding, the contents Ni, Fe, Cr, and Mo are uniformly
Fig. 9. The surface roughness before USR(a) and after USR(b).
Fig. 10. a is the surface of multi-layer cladding after USR, b is the surface of multi-layer cladding before USR.
Fig. 11. Line scanning analysis of the three-layer cladding layer.
J. Hao et al.
Journal of Materials Processing Tech. 291 (2021) 117036
6
distributed along the depth direction. This uniform element distribution
is attributed to the re-melting of the pre-cladding layer, indicating that
the previous layer must undergo solidification and re-melting can
strengthen the interlayer bonding strength of multi-layer cladding,
enhance the quality of multi-layer cladding, and improve the moulding
quality and service life of remanufactured parts.
The EDS results in Fig. 11 also demonstrate that the upper and lower
composition in the bonding zone between the substrate and the bottom
layer shows a significant change, but the composition in the bonding
zone is relatively stable, possibly because, during laser cladding the el-
ements in the cladding layer and the substrate penetrate each other to
form a bonding zone with uniform composition and a certain thickness.
The bonding zone with a certain thickness indicates that the great
dilution of multi-layer cladding, the bonding strength between the
cladding layer and the substrate will be enhanced with the increasing of
the dilution, which implies that the two parts are well bonded.
3.3. High-temperature friction and wear behaviour
As shown in Figs. 12(b, d, and f), there are scratches along the sliding
direction on the wear surface of the sample before USR, showing a
furrow-like morphology, which indicates that abrasive wear occurs on
the surface; for the sample examined before USR, the surface roughness
is larger, and the rough peak is sharper, therefore the furrow is more
easily formed, and the abrasive wear is more severe; the wear surface of
the sample before USR is oxidised, because the load applied by the
grinding ball to the sample causes local adhesion of the contact surface,
and then during the relative sliding process, the adhered part is sheared
Fig. 12. a, c, and e are the sample after USR; b, d, and f are the sample before USR; c and d are grooves.
J. Hao et al.
Journal of Materials Processing Tech. 291 (2021) 117036
7
to form blocky peeling features, and some of the oxide thus removed is
compacted by the grinding ball to form a bulging massive oxide layer,
this is a typical feature of adhesive wear, at the same time, plastic
deformation and tear-like fractures caused by adhesive wear are
observed. When the friction pair components move relative to each
other, the plastic deformation of the surface accelerates the diffusion of
oxygen into the metal, forming an oxide layer, due to the low strength of
the resulting oxide film, it is peeled off by the grinding ball and caused
oxidative wear.
Compared with the sample after USR, as shown in Figs. 12 (a, c, and
e), the area and depth of oxide exfoliation of the sample before USR are
significantly increased; abrasive wear causes more groovesand their
width and depth are significantly increased. The grooves on the samples
before USR always connect with the regions of exfoliation, however, the
grooves in the samples after USR are slender and mutually independent.
Differing from the continuous large area peeling off, the peeling-off re-
gions of the samples after USR are more widely scattered. In the samples
examined after USR, there is little debris adherent to the regions of
exfoliation, but in the samples inspected before USR the regions of
exfoliation are covered in such debris: the debris will further aggravate
the abrasive wear. Figs. 12 (e and f) show the adherent regions on the
surface of the samples after USR as larger than those seen beforehand;
these adherent regions consist of a broken oxide film, the increase in the
area of the adherent regions can play a better protective role and relieve
the wear and peel of the soft continuous substrate on the coating surface.
These show that the sample (after USR) has a better high-temperature
wear performance.
Comparing the friction coefficient before and after rolling, as shown
in Fig. 13, the friction coefficient after rolling is always lower; in the first
five minutes, the large friction coefficient is due to the large number of
fine particles attached to the wear surface, which results in a large
contact stress during the grinding process. The friction coefficient de-
creases and remains stable at 0.42 after five minutes of the high-
temperature friction and wear experiment (possibly because the fric-
tion oxide blocks hinder the direct contact between the sample and the
counter-rotating balls, thus contributing to the reduction in the coeffi-
cient of friction and the wear and tear).
3.4. Micro-hardness
Microscopic hardness is an important feature used to measure the
mechanical properties of the cladding layer. Fig. 14 illustrates the dis-
tribution of the microhardness along the depth of the cross-section of
single-layer, three-layer and six-layer laser cladding. It can be seen that
the average hardness of the cladding layer is 277.4 HV, which is
significantly higher than the average hardness of the substrate
(248.7 HV): the average surface hardness of the parts after HAM is
547.5 HV, which is significantly higher than that of the substrate. This is
mainly because, in the HAM process, it is equivalent to work-hardening
of the surface of the cladding layer, and USR breaks the grains on the
surface of the parts, the grain size is refined, the interface increases, and
dislocations are hindered, thus further improving the surface hardness of
the parts.
USR subjects the surface of the cladding layer to a certain depth of
plastic deformation, so that the original crystal grains are broken and
refined. The reciprocating processing generates a uniform stress on the
surface of the cladding layer, also it increases the amount and depth of
deformation to refine the crystal grains, thus, a certain depth of nano-
layer is obtained. The increase in surface hardness of the cladding layer
is attributed to the combined effect of grain refinement and work
hardening, therefore, the nanostructure of the metal surface is
confirmed to increase the surface hardness after multilayer laser clad-
ding, and then improve its fatigue resistance and abrasion resistance.
4. Conclusions
(1) We successfully prepared high-quality one-layer, three-layer, and
six-layer cladding layers on the surface of H13 die steel through a hybrid
additive manufacturing (HAM) method. The bonding between the
layers, the cladding layer and the substrate is satisfactory. The entire
cladding layer is composed of planar crystals, cellular crystals, equiaxed
dendrites, and dendrites from bottom to top.
(2) After USR, the surface roughness is reduced from 0.355 μm to
0.120 μm. The surface of the cladding layer (after USR) forms a nano-
layer with a depth of about 20 μm. This is the zone of plastic deforma-
tion after USR: the dendritic grains therein are squeezed, elongated, and
thus refined.
(3) Through HAM, the surface hardness of a hot-working mould is
significantly improved: this plays an important role in improving its
fatigue resistance and wear resistance.
(4) The high-temperature friction and wear experiment results show
that the wear mechanisms of the cladding layer before and after USR are
similar; compared with the sample before USR, the cladding layer after
USR has a smaller coefficient of friction, and suffers less wear.
CRediT authorship contribution statement
Jingbin Hao: Conceptualization, Funding acquisition, Supervision,
Validation, Writing - review & editing. Fangtao Hu: Formal analysis,
Investigation, Methodology, Writing - original draft. Xiawei Le:
Fig. 13. Friction coefficient of the sample before USR (A) and the sample after
USR (B).
Fig. 14. The distribution of the microhardness along the depth of the cross-
section of single-layer, three-layer, and six-layer laser cladding.
J. Hao et al.
Journal of Materials Processing Tech. 291 (2021) 117036
8
Investigation. Hao Liu: Resources. Haifeng Yang: Resources. Jing Han:
Resources.
Declaration of Competing Interest
The authors declare that they have no known competing financial
interests or personal relationships that could have appeared to influence
the work reported in this paper.
Acknowledgements
This work was supported by the Fundamental Research Funds for the
Central Universities (2020ZDPYMS22), and the Priority Academic Pro-
gram Development of Jiangsu Higher Education Institutions (PAPD).
References
CHANG, S.-H., TANG, T.-P., HUANG, K.-T., 2010. Improvement of aluminum Erosion
behavior and corrosion resistance of AISI H13 tool steel by oxidation treatment. Isij
Int. 50, 569–573.
Cheng, M., ZHANG, D., CHEN, H., QIN, W., LI, J., 2016. Surface nanocrystallization and
its effect on fatigue performance of high-strength materials treated by ultrasonic
rolling process. Int. J. Adv. Manuf. Technol. 83, 123–131.
Gao, J., FU, P., LIU, H., LI, D., 2015. Effects of rare earth on the microstructure and
impact toughness of H13 steel. Metals 5, 383–394.
Gu, D., GUO, M., ZHANG, H., SUN, Y., WANG, R., ZHANG, L., 2020. Effects of laser
scanning strategies on selective laser melting of pure tungsten. 2, 92–104.
Guo, D., Lu, Y., 2019. Overview of Extreme Manufacturing.
Heigel, J.C., Gouge, M.F., Michaleris, P., PALMER, T.A., 2016. Selection of powder or
wire feedstock material for the laser cladding of Inconel (R) 625. J. Mater. Process.
Technol. 231, 357–365.
Huang, H.W., WANG, Z.B., LU, J., LU, K., 2015. Fatigue behaviors of AISI 316L stainless
steel with a gradient nanostructured surface layer. Acta Mater. 87, 150–160.
Jiang, W.P., Molian, P., 2001. Nanocrystalline TiC powder alloying and glazing of H13
steel using a CO2 laser for improved life of die-casting dies. Surf. Coat. Technol. 135,
139–149.
Jiang, G., JIANGUO, Z., YANAN, P., RENKE, K., YOSHIHARU, N., PAUL, S., XIAOBIN, Y.,
BAORUI, W., DONGMING, G., 2020. A critical review on the chemical wear and
wear suppression of diamond tools in diamond cutting of ferrous metals. 2, 5–27.
Liu, H., HAO, J., HAN, Z., YU, G., HE, X., YANG, H., 2016. Microstructural evolution and
bonding characteristic in multi-layer laser cladding of NiCoCr alloy on compacted
graphite cast iron %. J Journal of Materials Processing Tech. 232.
Liu, B., WANG, B., YANG, X., ZHAO, X., QIN, M., GU, J., 2019a. Thermal fatigue
evaluation of AISI H13 steels surface modified by gas nitriding with pre- and post-
shot peening. Appl. Surf. Sci. 483, 45–51.
Liu, H.M., LI, M.B., QIN, X.P., HUANG, S., HONG, F., 2019b. Numerical simulation and
experimental analysis of wide-beam laser cladding. Int.J. Adv. Manuf. Technol. 100,
237–249.
Lu, K., Lu, J., 2004. Nanostructured surface layer on metallic materials induced by
surface mechanical attrition treatment. Materials Science and Engineering a-
Structural Materials Properties Microstructure and Processing 375, 38–45.
Luo, K.Y., XU, X., ZHAO, Z., ZHAO, S.S., CHENG, Z.G., LU, J.Z., 2019. Microstructural
evolution and characteristics of bonding zone in multilayer laser cladding of Fe-
based coating. J. Mater. Process. Technol. 263, 50–58.
Sun, Z., RETRAINT, D., BAUDIN, T., HELBERT, A.-L., BRISSET, F., CHEMKHI, M.,
ZHOU, J., KANOUTé, P.J.M.C., 2017. Experimental study of microstructure changes
due to low cycle fatigue of a steel nanocrystallised by Surface Mechanical Attrition
Treatment (SMAT). 124, 117–121.
Tong, X., DAI, M.-J., ZHANG, Z.-H., 2013. Thermal fatigue resistance of H13 steel treated
by selective laser surface melting and CrNi alloying. Appl. Surf. Sci. 271, 373–380.
Wang, P.F., HAN, Z., LU, K., 2018. Enhanced tribological performance of a gradient
nanostructured interstitial-free steel. Wear 402, 100–108.
Wang, C., HAN, J., ZHAO, J., SONG, Y., MAN, J., ZHU, H., SUN, J., FANG, L., 2019.
Enhanced wear resistance of 316 l stainless steel with a nanostructured surface layer
prepared by ultrasonic surface rolling. Coatings 9.
Wenbo, Q., JIANSHENG, L., YAOYAO, L., WEN, Y., CHENGBIAO, W., QINGZHONG, M.,
YUSHENG, L., 2019. Effect of rolling strain on the mechanical and tribological
properties of 316 l stainless steel. Arch. Proc. Inst. Mech. Eng. Part J J. Eng. Tribol.
1994-1996 141.
Yang, X., WANG, X., LING, X., WANG, D.J.R.I.P., 2017. Enhanced mechanical behaviors
of gradient nano-grained austenite stainless steel by means of ultrasonic impact
treatment. 7, 1412–1421.
Yongliang, L.I.W.L., 1997. The Tribological Properties and Microstructure of H13 Steel
After Si,N and St+N Ion Implantation., pp. 16–20.
Zhang, H., PAN, Y., HE, Y.Z., WU, J.L., YUE, T.M., GUO, S., 2015. Application prospects
and microstructural features in laser-induced rapidly solidified high-entropy alloys.
J. Cheminform. 46.
Zhu, G., ZHANG, A., LI, D., G.J.T.O.T.C.W.I. PI, 2010. Model of Layer Thickness of Thin-
walled Parts in Laser Metal Direct Manufacturing, p. 8.
J. Hao et al.
