NetNumenU31 GPON NBI
Reference Manual for TL1
V1.1
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Tel: +86-755-26771900
Fax: +86-755-26770801
URL: http://ensupport.zte.com.cn
E-mail: support@zte.com.cn
LEGAL INFORMATION
Copyright © 2011 ZTE CORPORATION.
The contents of this document are protected by copyright laws and international treaties. Any reproduction or
distribution of this document or any portion of this document, in any form by any means, without the prior written
consent of ZTE CORPORATION is prohibited. Additionally, the contents of this document are protected by
contractual confidentiality obligations.
All company, brand and product names are trade or service marks, or registered trade or service marks, of ZTE
CORPORATION or of their respective owners.
This document is provided “as is”, and all express, implied, or statutory warranties, representations or conditions
are disclaimed, including without limitation any implied warranty of merchantability, fitness for a particular purpose,
title or non-infringement. ZTE CORPORATION and its licensors shall not be liable for damages resulting from the
use of or reliance on the information contained herein.
ZTE CORPORATION or its licensors may have current or pending intellectual property rights or applications
covering the subject matter of this document. Except as expressly provided in any written license between ZTE
CORPORATION and its licensee, the user of this document shall not acquire any license to the subject matter
herein.
ZTE CORPORATION reserves the right to upgrade or make technical change to this product without further notice.
Users may visit ZTE technical support website http://ensupport.zte.com.cn to inquire related information.
The ultimate right to interpret this product resides in ZTE CORPORATION.
Revision History
REVISION NO. REVISION DATE REVISION REASON
V1.0 29–04–2016 Published Version
V1.1 07–01–2017 Add some new commands.
Publishing Date: 07-01-2017
Contents
Chapter 1 Document Overview ................................................................. 1-1
1.1 Purpose............................................................................................................. 1-1
1.2 Scope................................................................................................................ 1-1
Chapter 2 TL1 Interface Overview............................................................. 2-1
Chapter 3 Important Notice ....................................................................... 3-1
3.1 Requests on TL1 Compatibility............................................................................ 3-1
3.2 Concurrent Operations to NE .............................................................................. 3-2
3.3 Error Code......................................................................................................... 3-2
3.4 Synchronization Alarm........................................................................................ 3-2
Chapter 4 TL1 Protocol .............................................................................. 4-1
4.1 Communication Protocol..................................................................................... 4-1
4.2 Command Format .............................................................................................. 4-2
4.2.1 Syntactical Operators ............................................................................... 4-2
4.2.2 TL1 Command Syntax Overview ............................................................... 4-3
4.2.3 Debug and Test TL1 ................................................................................. 4-7
Chapter 5 Unified Error Code Defination ................................................. 5-1
Chapter 6 NE Type Series Description ..................................................... 6-1
Chapter 7 TL1 Command Description ...................................................... 7-1
7.1 Service Provisioning .......................................................................................... 7-1
7.1.1 ADD-ONU【Add ONU】 ....................................................................... 7-1
7.1.2 CFG-ONU【Modify ONU Authorization Information】 ............................... 7-4
7.1.3 DEL-ONU【Delete ONU】 .................................................................... 7-7
7.1.4 CRT-SERVICEPORT【Create Service Port】 .......................................... 7-9
7.1.5 CHG-SERVICEPORT【Change Service Port】 ......................................7-23
7.1.6 DLT-SERVICEPORT【Delete Service Port】 ..........................................7-27
7.1.7 CHG-SERVICEPORTSTAT【Change Service Port Administrative
Status】 ............................................................................................7-30
7.1.8 BND-PORT-MVLAN【Bind Port to MVLAN】 ..........................................7-32
7.1.9 UBND-PORT-MVLAN【Unbind Port from MVLAN】 ................................7-36
7.1.10 CHG-PORTQOS-TRAFFICPRF【Modify Port QoS Traffic Profile】 .........7-39
7.1.11 DLT-PORTQOS-TRAFFICPRF【Delete Port QoS Traffic Profile】 ...........7-43
7.1.12 CHG-PORT-MAXLEARNTMAC【Change Port Maximum Number of
Learnt MAC Addresses】 ....................................................................7-47
I
7.1.13 CHG-PORTLOCATING【Change Port Identification】 ...........................7-50
7.1.14 CHG-PORT-DHCP【Modify port of DHCP】 .........................................7-57
7.1.15 CHG-PORT-PPPOEPLUS【Modify Port PPPoE Plus Information】 ........7-61
7.1.16 CHG-ONUVOIPIP【Change ONU VoIP IP】 ........................................7-66
7.1.17 DLT-ONUVOIPIP【Delete ONU VoIP IP Configuration】 ........................7-70
7.1.18 CRT-ONUSIPUSER【Create ONU SIP User】 .....................................7-72
7.1.19 DLT-ONUSIPUSER【Delete ONU SIP User】 ......................................7-75
7.1.20 CHG-ONU-STAT-PON【Change ONU Administrative Status】 ...............7-77
7.1.21 RST-ONU-PON【Restart ONU】 ........................................................7-79
7.1.22 ACT-LANPORT【Activate LAN Port】..................................................7-81
7.1.23 DACT-LANPORT【Deactivate LAN Port】 ...........................................7-82
7.1.24 ACT-VOIPPORT【Activate VoIP Port】................................................7-84
7.1.25 DACT-VOIPPORT【Deactivate VoIP Port】 .........................................7-86
7.1.26 CHG-ONUWANIP【Change WAN IP configuration】 .............................7-88
7.1.27 DLT-ONUWANIP【Delete WAN IP Configuration】................................7-95
7.1.28 CHG-ONUWAN【Change WAN configuration】 ....................................7-98
7.1.29 DLT-ONUWAN【Delete WAN configuration】 .....................................7-102
7.1.30 CRT-ONU-GEMPORT【Create ONU GEM Port】 ...............................7-103
7.1.31 DLT-ONU-GEMPORT【Delete ONU GEM Port】 ................................7-106
7.1.32 CRT-ONU-MVLAN【Create ONU MVLAN】 .......................................7-109
7.1.33 DLT-ONU-MVLAN【Delete ONU MVLAN】 ....................................... 7-111
7.1.34 CRT-ONU-PPPOE【Create ONU PPPoE】 ........................................ 7-114
7.1.35 CRT-ONU-SERVICE【Create ONU Service】 ................................... 7-116
7.1.36 DLT-ONU-SERVICE【Delete ONU Service】 .....................................7-120
7.1.37 CRT-ONU-STATICROUTE【Create ONU Static Route】 .....................7-122
7.1.38 CRT-ONU-TCONT【Create ONU T-CONT】 ......................................7-125
7.1.39 DLT-ONU-TCONT【Delete ONU T-CONT】 .......................................7-128
7.1.40 CRT-ONU-GEMPORT【Create ONU GEM Port】 ...............................7-130
7.1.41 DLT-ONU-GEMPORT【Delete ONU GEM Port】 ................................7-133
7.1.42 CRT-ONU-VPORTGEMPORTMAPPING【Create ONU VPort and
GEM Port Mapping】 ........................................................................7-136
7.1.43 CRT-ONUPORT-EXTENDEDVLANRULE【Create ONU PortExtended
VLAN Rule】 ...................................................................................7-139
7.1.44 CRT-ONUPORT-EXTENDEDVLAN【Create ONU Port Extended
VLAN】 ...........................................................................................7-141
7.1.45 CRT-ONUPORT-IGMP【Create ONU Port IGMP】 .............................7-143
7.1.46 DLT-ONUPORT-IGMP【Delete ONU Port IGMP】 ..............................7-146
II
7.1.47 CRT-ONUPORT-VLANTRANSLATION【Create ONU Port VLAN
Translation】....................................................................................7-149
7.1.48 DLT-ONUPORT-VLANTRANSLATION【Delete ONU Port VLAN
Translation】....................................................................................7-151
7.1.49 CHG-ONU-BRGPORT【Change ONU Bridge Port】 ..........................7-154
7.1.50 CHG-ONU-TARGETSTAT【Change ONU Target Status】 ...................7-156
7.1.51 CHG-ONU-VIDEOANI【Change ONU Video ANI Configuration】 .........7-158
7.1.52 CHG-ONU-VPORT【Change ONU VPort】 .......................................7-161
7.1.53 CHG-ONUGEMPORT-QOS【Change ONU GEM Port QoS】 ..............7-163
7.1.54 CHG-ONUPORT-VLAN【Change ONU Port VLAN】..........................7-166
7.1.55 CHG-ONUVIDEOPORT【Change ONU Video Port】 ..........................7-169
7.1.56 CHG-ONU-VOIP【Change ONU VoIP】 ............................................7-171
7.1.57 CLR-ONU-CONFDATA【Clear ONU Configuration Data】 ...................7-176
7.1.58 BND-ONU-DHCPSERVERPROFILE【Bind DHCP Server Profile to
ONU】 ............................................................................................7-178
7.1.59 UBND-ONU-DHCPSERVERPROFILE【Unbind DHCP Server Profile
from ONU】 .....................................................................................7-180
7.1.60 BND-ALARMPROFILE【Bind Alarm Profile】 .....................................7-182
7.1.61 UBND-ALARMPROFILE【Unbind Alarm Profile】 ...............................7-186
7.1.62 UBND-ONUPORT-VLAN【Unbind VLAN from ONU Port】 .................7-189
7.1.63 BND-ONUPORT-VLAN【Bind ONU Port to VLAN】 ...........................7-192
7.1.64 CHG-BOARD-ROGUEONUDETECT【Change Rogue ONU Detecting
Configuration】 ................................................................................7-194
7.1.65 CHG-ONU-ACS【Change ONU ACS】..............................................7-196
7.1.66 CHG-ONU-ETHPORT【Change ONU Ethernet Port】........................7-200
7.1.67 CHG-ONU-IPV4IPHOST【Change ONU IPv4 IP Host
Configuration】 ................................................................................7-203
7.1.68 CHG-ONU-VEIP【Change ONU VEIP】 ...........................................7-206
7.1.69 CHG-ONUPORT-MVLANTAGMODE【Change ONU Port MVLAN
Tag】 ..............................................................................................7-209
7.1.70 CHG-ONUPORT-PACKETFILTER【Change ONU Port Packet
Filter】 ............................................................................................ 7-211
7.1.71 BND-ONU-ONUPROFILE【Bind ONU Profile to ONU】 ......................7-214
7.1.72 UBND-ONU-ONUPROFILE【Unbind ONU Profile from ONU】.............7-217
7.1.73 RESTORE-ONUFACTORYCONF【Restore ONU Factory
Settings】 ........................................................................................7-219
7.1.74 CHG-ONUUNI-PON【Change ONU UNI Configuration】 .....................7-221
7.1.75 UPDATE-ONU-SOFTWARE【Update ONU Software】 .......................7-226
7.1.76 CHG-ONUWIFI【Change ONU WiFi configuration】 ...........................7-228
III
7.1.77 CHG-ONUWIFISSID【Change WiFi SSID】 .......................................7-232
7.1.78 CRT-ONU-MGCUSER【Create ONU MGC User】..............................7-238
7.1.79 DLT-ONU-MGCUSER【Delete ONU MGC User】...............................7-241
7.1.80 DLT-ONU-STATICROUTE【Delete ONU Static Route】......................7-244
7.1.81 CRT-ONU-TCONTBWPROFILE【Create ONU TCONT Bandwidth
Profile】 ..........................................................................................7-246
7.1.82 DLT-ONU-TCONTBWPROFILE【Delete ONU TCONT Bandwidth
Profile】 ..........................................................................................7-251
7.1.83 CRT-ONU-WANIP【Create ONU WAN IP】 .......................................7-253
7.1.84 CRT-ONUPROFILE【Create ONU Profile】 .......................................7-258
7.1.85 DLT-ONUPROFILE【Delete ONU Profile】 ........................................7-260
7.1.86 CHG-ONU-DMZ【Change ONU Demilitarized Zone】 .........................7-262
7.1.87 CHG-ONU-UPNP【Change ONU UPnP Configuration】 .....................7-264
7.1.88 CRT-ONU-PORTFORWARD【Create ONU Port Forward】 .................7-266
7.1.89 DLT-ONU-PORTFORWARD【Delete ONU Port Forward】 ..................7-269
7.1.90 CHG-ONU-PON【Change ONU Configuration】 .................................7-271
7.2 Resource and Query ......................................................................................7-275
7.2.1 LST-DEVINFO【Query Device Information】........................................7-275
7.2.2 LST-BRDINFO【Query Board Information】 .........................................7-278
7.2.3 LST-OLTATTR-PON【Query PON Port Attributes】...............................7-281
7.2.4 LST-ONU【Query ONU Information】 .................................................7-284
7.2.5 LST-ONUSTATE【Query ONU State】 ................................................7-291
7.2.6 LST-SERVICEPORT【List Service Port】 ............................................7-295
7.2.7 LST-PORTQOS-PRIPRF【List Port QoS Priority Profile】 .....................7-302
7.2.8 LST-PORT-MAXLEARNTMAC【Query Port Maximum Number of Learnt
MAC Addresses】 ............................................................................7-305
7.2.9 LST-PORTQOS-TRAFFICPRF【Retrieve Port QoS Traffic Profile】........7-310
7.2.10 LST-ONUTCONT【Query ONU TCONT Configuration】......................7-315
7.2.11 LST-ONUCFG【Query ONU Configuration Information】 .....................7-318
7.2.12 LST-OMDDM【Query Optical Module DDM Information】 ....................7-321
7.2.13 LST-LANPORT【Query LAN Port Information】 ..................................7-329
7.2.14 LST-LANPERF【Query LAN Port Performance】 ................................7-336
7.2.15 LST-PONPERF【Query PON Link Performance】 ..............................7-339
7.2.16 LST-UNREGONU【Query Unregistered ONU Status Information】 .......7-344
7.2.17 LST-ONU-SERVICE【Query ONU Service Configuration】 ..................7-350
7.2.18 LST-ONU-VIDEOANI【Query ONU Video ANI Configuration】 .............7-354
7.2.19 LST-ONU-VLANTRANSLATION【Query ONU VLAN Translation】 .......7-357
7.2.20 LST-ONU-VPORT【Query ONU VPort Configuration】........................7-361
IV
7.2.21 LST-ONU-VPORTGEMPORTMAPPING【Query ONU VPort and GEM
Port Mapping】 ................................................................................7-363
7.2.22 LST-ONUGEMPORT【Query ONU GEM Port Configuration】 .............7-366
7.2.23 LST-ONU-SIPUSER【Query the Information of ONU SIP User】 ..........7-369
7.2.24 LST-ONUPORT-VLAN【Query ONU Port VLAN】 ..............................7-374
7.2.25 LST-ONU-EXTENDEDVLAN【Query ONU Extended VLAN
Configuration】 ................................................................................7-378
7.2.26 LST-ONU-EXTENDEDVLANRULE【Query ONU Extended VLAN Rule
Configuration】 ................................................................................7-383
7.2.27 LST-ONU-VOIP【Query ONU VoIP Configuration】 ............................7-386
7.2.28 LST-ONU-VOIPIP【Query ONU VoIP IP Configuration】 .....................7-392
7.2.29 LST-ONU-IPV4IPHOST【Query ONU IPv4 IP Host】 ..........................7-401
7.2.30 LST-OLTMACADDRESS【Query OLT Learnt MAC Address】 .............7-405
7.2.31 LST-PORTMACADDRESS【List Mac address of ONU UNI】 ...............7-408
7.2.32 LST-VLANID【List VLAN ID】...........................................................7-415
7.2.33 LST-ONU-ONUPROFILE【Query ONU Profile of ONUBinding】 .........7-417
7.2.34 LST-ONUPROFILE【Query ONU Profile】 .........................................7-420
7.2.35 LST-ONUWANIP【Query ONU WAN IP】 ..........................................7-423
7.2.36 LST-ONU-VOIPLINESTAT【Query ONU VoIP Line Status】 ................7-429
7.2.37 LST-ONUUNI-PON【List ONU UNI Information】 ...............................7-433
7.2.38 LST-ONU-DETAIL【Query ONU Detail】 ...........................................7-436
7.2.39 LST-VLANID-TTP【List VLAN ID】 ...................................................7-444
7.2.40 LST-ONU-WIFI【Query ONU WiFi】 .................................................7-447
7.2.41 LST-ONU-WIFISSID【Query ONU WiFi SSID】..................................7-451
7.2.42 LST-TCONTBWPROFILE【Query TCONT Bandwidth Profile】 ............7-456
7.2.43 LST-ONUSIPPROFILE【Query ONU SIP Profile】..............................7-460
7.2.44 LST-ONUTYPEPROFILE【Query ONU Type Profile Information】 ........7-464
7.3 Alarm .............................................................................................................7-469
7.3.1 LST-ALARM【List Alarms】 ...............................................................7-469
7.4 System ...........................................................................................................7-473
7.4.1 LOGIN【Login EMS】 .......................................................................7-473
7.4.2 LOGOUT【Logout EMS】 ..................................................................7-475
7.4.3 SHAKEHAND【Shakehand Command】 .............................................7-476
V
Chapter 1
Document Overview
Table of Contents
Purpose .....................................................................................................................1-1
Scope.........................................................................................................................1-1
1.1 Purpose
This document describes how to use TL1 northbound interface (NBI) of Network Element
Management System(EMS) NetNumenU31 for ZTE's access network equipment. The
partner management system can use this interface to integrate with NetNumenU31.
1.2 Scope
This document describes TL1 NBI, including the usage, protocol, functionalities and details
about TL1 command for network element (NE) management. But this document doesn't
describe details of TL1 protocol and communication technology.
1-1
|07-01-2017 ZTE Proprietary and Confidential
Chapter 2
TL1 Interface Overview
NBI of NetNumenU31 is a important interface to communicate between NetNumenU31
and OSS. OSS will implement provisioning, operation, monitoring, assurance and
inventory management via NBI. Transaction Language 1 (TL1) interface is string-based
and human-readable, which can be rapidly developed and easily updated. Especially,
there is no special decoders are needed for TL1 debugging, and new messages can
be added to TL1 command with minimal effort. It is the most widely used management
protocol in telecommunications networks. TL1 facilitates communication between TL1
agent in NetNumenU31, and a TL1 client. The TL1 agent on NetNumenU31 provides
access to data stored on equipment and database of EMS. The TL1 client uses this
access to monitor and control the equipment. TL1 protocol communicates via TCP. Data
(TL1 Messages) is sent and received in the form of byte stream.
2-1
|07-01-2017 ZTE Proprietary and Confidential
Chapter 3
Important Notice
Table of Contents
Requests on TL1 Compatibility...................................................................................3-1
Concurrent Operations to NE .....................................................................................3-2
Error Code .................................................................................................................3-2
Synchronization Alarm ...............................................................................................3-2
3.1 Requests on TL1 Compatibility
With the development of network management, TL1 commands will be extended. Then,
it's extremely necessary to consider the compatibility of TL1 command. We try to give
the result of command in a style of table, which will show the name of each field firstly.
So, even though the format of the TL1 command response result changed following after
version changing, that would facilitate the TL1 client to find the associated column the
specified data located according to the position of field, and then to analyze them. This
kind of self-adaptive feature is very convenient for TL1 client to realize compatibility.
In addition, the delimiter that separate two fields in the output result can be configured in
NetNumenU31, eg. two continuous space characters or a TAB key.
The following gives an example about the changed TL1 output information:
Now
Take the output information about LST-DEVRACK command as an example:
List of All Racks Info
—————————————————–
DID DNAME RID NAME TYPE STATUS SHELFNUM
10.61.94.33 ZXDSL8220v3.x 1 Dslam Rack ZXDSL8220v3.x Up 1
—————————————————–
Later
The output information will change as following:
List of All Racks Info
—————————————————–
DID RID DNAME NAME TYPE STATUS SHELFNUM ALARM
10.61.94.33 1 ZXDSL8220v3.x Dslam Rack ZXDSL8220v3.x Up 1 ENV
—————————————————–
3-1
|07-01-2017 ZTE Proprietary and Confidential
Chapter 3 Important Notice
Please pay attention to the change of RID field position and the new-added ALARM field.
In this case, the TL1 client should be self-adaptive to these changes.
3.2 Concurrent Operations to NE
NetNumenU31 only supply the TL1 NBI, it doesn't control how to use it by the client. The
TL1 client could create concurrent service instances and send many commands to the
same NE at the same time; but this would result in some fails for some NEs, due to the NE
device configuration conflicts. So we don't suggest the TL1 client send many commands
to the same NE at the same time.
3.3 Error Code
Error code of the TL1 commandmay be changed, OSS should not decide business process
by the error code. If OSS already use the error code, Please test whether the error code
is changed before NetNumen U31 upgrading.
3.4 Synchronization Alarm
Dispose the alarm should be as qickly as possible when in the synchronization alarm
operation, which would be block the alarm sender if not quickly enough. Keep the receiving
alarm in a cache, and another thread dispose the alarm get from the cache should be
efficient, which is strongly recommend.
3-2
|07-01-2017 ZTE Proprietary and Confidential
Chapter 4
TL1 Protocol
Table of Contents
Communication Protocol ............................................................................................4-1
Command Format ......................................................................................................4-2
4.1 Communication Protocol
l Communication Protocol
Transaction Language -1 (TL1) defined by Telcordia(formerly Bellcore). It is the most
widely used management protocol in telecommunications networks. Because showed in
text format, it is very understandable for developers and operators without the help of
complicated debugging and protocol analyzer. Furthermore, TL1 supports active alarm
reporting, which will report the performance, alarm and other user-interested events to
users actively and real time so as to monitor the operational status of EMS and NE.
TL1 Northbound interface of NetNumen is a kind of application-layer protocol running on
TCP protocol. Through the Sockets based on TCP/IP, it can be used to send or respond
command between the module of Northbound interface and upper-layer system.
NetNumenU31 TL1 supports connection based on SSH in order to enhance the security
of communication.
l Communication Module
4-1
|07-01-2017 ZTE Proprietary and Confidential
Chapter 4 TL1 Protocol
Before sending TL1 command, the OSS needs to built a connection with the TCP of
NetNumenU31 TL1 interface module (ZTE TL1 Agent) through SOCKET. The default
TL1 service portof ZTE TL1 Agent is 9819-9833 and the default SSH service port is
8819-8833.
l Session Control
The maximum of TL1 connection that can support simultaneously is 50.
l Running Efficiency
Generally, it needs 1-10 sec to run a single TL1 command. In case of large scale network
management, the OSS should build multi TL1 connections to send TL1 command
concurrently so as to improve the running efficiency of TL1 command.
4.2 Command Format
4.2.1 Syntactical Operators
Table 1 Syntactical Operators
Index Symbol Description Example
1 < > Encapsulate an identification <int-num> means to input an
integer
2 [ ] Encapsulate an symbol or message a[b]c means that b is optional.
3 ' ' Encapsulate an alphabet 'a' means the English character a
not a variable identification.
4 ( ) Encapsulate several symbols and could
be used with * and +.
5 * Suffix, meaning the content in round
brackets could be showed for several
times or never be showed.
a(bc)* means a or abc or abcbc
etc.
6 + Suffix, meaning the content in round
brackets could be showed for one or more
times.
a(bc) + means abc or abcbc etc.
7 ^ Space character
8 cr Enter key
9 1f Change line
10 | Choose one of the items from several
items separated by this kind of symbol.
a|b|c means to choose one from a,
b and c.
4-2
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
11 ::= Separate two different block messages. Such as <digit> ::= (0|1|...|9) ,
meaning the value of <digit>
should be one of the integer
coming from 0 to 9 (here, including
0 and 9).
4.2.2 TL1 Command Syntax Overview
4.2.2.1 TL1 Command Syntax
Any request from an OSS is considered a TL1 command. The general structure of a TL1
command is:
<command_code>:<staging_parameter_blocks>:<message_payload_block>;
·Command Code
It determines the action to be taken at the NetNumenU31 as a result of receiving the input
message. Each command must begin with a command code consisting of a mandatory
verb followed by up to two optional identifiers, each separated by hyphen.
·Staging Parameter Block
These are a series of four data blocks following the command code that provide info to
establish and uniquely identify an object entity within an NetNumen to be managed by the
TL1 client and to specify certain options as to how the input command is to be executed in
the NetNumenU31. The structure of the staging parameter blocks consists of the following
series:
:[<target identifier>]:<access identifier(s)>:<correlation tag>:[<general block>]:
Each block may have one or more specifically defined parameters. The parameters within
each staging block may either be position-defined or name-defined.
·Message Payload Block
This block indicates the subject matter of the message. This section may consists of zero
or more data blocks in the form:
(:<Px>(,<Px>)*)*;
Here Px represents a data item. Each data block is delimited by colons (:) and the last
terminated by a semicolon (;). Each data block may have an unlimited number of data
items, each delimited by commas (,). The data items within a data block may be either
name-defined (<keyword>=<value>) or position-defined where values are specified and
the keyword is implied by its position in the data block.
4.2.2.2 Output Response Messages
A TL1 output response message is the response to a TL1 input command. The general
structure of a TL1 output response message is :
4-3
|07-01-2017 ZTE Proprietary and Confidential
Chapter 4 TL1 Protocol
<header> <response identification> [<text block>] <termination>
which consists of a optional text block and all the other blocks are essential.
·Header
The Header represents information to all output response.
<cr><lf><lf>^^^<sid>^<year>-<month>-<day>^<hour>:<minute>:<second>
It contains System identifier <sid>, date and time stamps.
<sid> is restricted to 20 characters maximum and identifies the NE generating the
message. The syntax of <sid> is any TL1 identifier or text string.
The <year><month><day> construct represent the day in which the output response is
generated.
The <hour><minute> <second> construct represent the time at which the output response
is generated.
·Response Identification
The form of the response identification is :
<cr><lf>M^^<ctag>^<completion code>
This construct consists of three components namely the character M, a correlation Tag
and a completion code.
The character M signifies that the message is the response to the input command.
The <ctag> must be the same as that of the input message to associate the response with
the proper input command.
The <completion code> acknowledges the completion of the input command as COMPLD
to indicate the successful completion of the command, DENY to indicate that the system
could not execute the command, or PRTL to indicate that the system was not able
to process the command for some of the object entities. Partial responses include a
description of the problem the system encountered while attempting to execute the
command
·Text Block
The optional [<text block>] is used to represent information specific to the particular
autonomous message. The format of the text block is as follows :
((<cr><lf>^^^<EN=error-code>^^^<ENDESC=error-description>) |
(<cr><lf>^^^<quotedline>))
Here:
EN=error-code
The error code identifying the fault condition of command, such as IDNE, which indicates
that the input parameter error - the device does not exist.
ENDESC=error-description
The error description for the fault, such as 'device operation failed'.
4-4
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
quotedline
The quoted line consists of parsable text and shall be preceded and followed by double
quotes.
The famat is :
< totalrecord =total-count><cr><lf><result>
Here, result is :
<cr><lf><title><cr><lf>(<->*)<cr><lf>(<attribs>((<values>)*))(<->*)<cr><lf><cr><lf>
-attribs::=<attrib>((^^<attrib>)*)<cr><lf>
-values::=<value>((^^<value>)*)<cr><lf>
·Terminator
The form of the terminator is :
<cr><lf>( ; | > )
The terminator is represented by either the semicolon (;) character or the greater than
(>) character. The semicolon (;) character is used to indicate the termination of the output
response message. The greater than (>) character is used to indicate that more output
associated with this response will follow under another header.
Since the size of the output message should not exceed 4096 bytes, it is important to
split the response into blocks with the same Ctag. The (>) terminator is also used for
intermediate responses in a timed measurement series.
4.2.2.3 Example
Function: Retrieve all NEs from EMS.
Command Format:
LST-DEV::[ (DID=device-id)| (DIP=device-IP)|(DNAME=device-name)]:CTAG::;
Here:
LST-DEV is command name.
DID, DIP and DNAME are three different optional parameters. When there is no any
message input in this parameter item, all of the equipment information will be returned.
Input:
LST-DEV:::5::;
Response:
736 2004-04-01 10:55:49
M 1 COMPLD
EN=0 ENDESC=No error
totalrecord =2
List of All Device Info
4-5
|07-01-2017 ZTE Proprietary and Confidential
Chapter 4 TL1 Protocol
————————————-
DID DIP DNAME DTYPE STATUS LOCATION
10.71.47.30 10.71.47.30 TEST ZXDSL9210 Up root.Shanghai.Pudong.Zhangjiang
10.71.47.31 10.71.47.31 TEST2 ZXDSL9210 Down root.Shanghai.Xinming
————————————-
Note:
This command tries to inquire all of the NE information. That is why there is no any
parameter input.
4-6
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
4.2.3 Debug and Test TL1
TL1 session can be created via a Telnet connection in order to debug and test a TL1
command rapidly. It is very easy, that is, create a telnet connection to TL1 agent firstly, and
then input command according to TL1 syntax, at last, click ENTER key to send command
to TL1 agent.
4-7
|07-01-2017 ZTE Proprietary and Confidential
Chapter 4 TL1 Protocol
The example of procedure is asfollows (Windows):
Assum that TL1 service IP of NetNumenU31 is 10.61.94.3 and service port is 9803, then
operate procedure is :
Create a telnet connection
a)Select Start > Run.
b)Enter cmd in the Run prompt box, and click OK.
c)At the DOS command prompt type:
telnet <TL1 service ip address > <port number> and press Enter.
That is :
telnet 10.61.94.3 9830
Excute TL1 command
d)Type or copy a TL1 command to open a TL1 session
Then the result of the command will be shown in DOS window.The example of a command
and its response result is as following figure.
Figure 1 The command example
Tips:
If you find that the DOS window can't display the response result of TL1 command, then
you can configure the DOS window to echo mode to resolve this problem.
4-8
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
The procedure is as follows:
a)Select Start > Run.
b)Enter regedit in the Run prompt box, and click OK.
c)Search item DebugFlags in [HKEY_CURRENT_USER\Software\Microsoft\Telnet]
d)Set value of DebugFlags to 0x00000010(16)
e)Open DOS window again to try TL1 command.
4-9
|07-01-2017 ZTE Proprietary and Confidential
Chapter 5
Unified Error Code Defination
An error code is a four-character mnemonic device in the response of an input command
describing why the command cannot be executed. Error codes are grouped into the
following categories:
Ixxx: Input
Dxxx: Device
Exxx: Exception
Sxxx: System
Axxx: Authentication
Txxx: Test
Error Code Error Type Error Description
IRC INPUT resource conflict
IDNE INPUT device does not exist
IRNE INPUT resource does not exist
IANE INPUT alarm does not exist
IMP INPUT missing parameter
IIPF INPUT invalid parameter format
IIPE INPUT input parameter error
IRE INPUT resource has existed
DDNS DEVICE device may not support this operation
DDOF DEVICE device operation failed
DDB DEVICE device is busy
SENS SYSTEM EMS may not support this operation
SSOF SYSTEM system operation failed
EEH EXCEPTION exception happens
5-1
|07-01-2017 ZTE Proprietary and Confidential
Chapter 6
NE Type Series Description
NE Type Series NE Type
C300M Series C300M/C350M/MSG6000/MSG6020
C300Mv4 Series C300Mv4/C350Mv4
DSL Series ZXDSL8220V3/ZXDSL9210/ZXDSL9800/ZXDSL9803/ZXDSL9800V3/ZXDS-
L9803V3/ZXDSL9806H/ZXDSL9806I/ZXDSL9812/ZXDSL9816/ZXDSL9836/Z-
XDSL9856/ZXA10 9806V/ZXA10 9818/ZXA10 9819G/ZXA10 9836V/ZXA10
9852G/ZXA10 9852V
xDSL-MDU
Series
ZXDSL9806H/ZXDSL9806I/ZXDSL9812/ZXDSL9816/ZXDSL9836/ZXDSL9856/
ZXA10 9806V/ZXA10 9818/ZXA10 9836V/ZXA10 9852V
G.fast-MDU
Series
ZXA10 9819G/ZXA10 9852G
LAN-MDU
Series
F402/F802/F803/F803V1/F803V3/F803G-8/F803-8/F803G-16/F803-
16/F804/F805/F805PB/F806PB/F809/F821/F822/F822B/F822P/F823/F823P/F-
829/F822P/F832/F833/F839
F82x Series
(Deprecated)
F820/F821/F822/F823/F829/F822P/F803V3/F809
C300 Series C300/C320v1.2
C300v2 Series C300v2/C320v2/C350v2
C300v3 Series C300v3.0/C320v3.0/C350v3
C600 Series C600/C650/C680
6-1
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7
TL1 Command Description
Table of Contents
Service Provisioning ..................................................................................................7-1
Resource and Query .............................................................................................7-275
Alarm .....................................................................................................................7-469
System...................................................................................................................7-473
7.1 Service Provisioning
7.1.1 ADD-ONU【【【Add ONU】】】
l Description
This command could be used for adding ONU.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.1/C220v1.2/C300 Series/C300v2 Series/C300v3
Series/C600 Series
PON ONU F820/LAN-MDU Series/xDSL-MDU Series/FTTH ONU
l Command Format
ADD-ONU::OLTID=olt-name,PONID=ponport_location:CTAG::[AUTHTYPE=auth-type],
ONUID=onu-index[,PWD=onu-password][,ONUNO=onu-no]
[,RID=rid][,HEXPWD=hex-password][,NAME=name]
[,DESC=onu description],ONUTYPE=onu-type[,SPLITTERID=id]；
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
OLTID String SIZE(128) OLT IP address or
name, ID
Required
7-1
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
PONID String SIZE(128)
Rack-Shelf-
Slot-PON Port
Number
PON Port location
information, located by
Rack-Shelf-Slot-PON
Port, NA means
nothing
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
AUTHTYPE String MAC
LOID
LOIDONCEON
SN
SNONCEON
PASSWORD
PWDONCEON
RID
SNRID
HEXPASSWORD
SNPWD
Authorization Mode,
default as LOID
Optional
ONUID String SIZE(64) Authorization
Information;
If the authorization
mode for AUTHTYPE
is MAC, then ONUID
means MAC address;
If the authorization
mode for AUTHTYPE
is LOID, then ONUID
means LOID;
If the authorization
mode for AUTHTYPE
is PASSWORD,
then ONUID means
PASSWORD;
If the authorization
mode for AUTHTYPE
is RID, then ONUID
means RID;
If the authorization
mode for AUTHTYPE
is HEXPASSWORD,
Required
7-2
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
then ONUID means
hex password.
If the authorization
mode for AUTHTYPE is
SNPWD, then ONUID
means SN+password,
for example,
ZTEG10000251/xdn.
PWD String SIZE(128) LOID PASSWORD Optional
ONUNO Integer 1-512 ONU authorization
number
Optional
NAME String SIZE(128) ONU Name Optional
DESC String SIZE(64) ONU description;
When it is necessary
to keep NMS and
equipment description
the same, the
description field cannot
be Chinese characters.
Optional
ONUTYPE String SIZE(32) ONU type Required
SPLIT-
TERID
String SIZE(32) Optical splitter ID Optional
RID String SIZE(36) Register ID
If the authorization
mode for AUTHTYPE
is SNRID, then ONUID
means SN and RID
means RID.
Optional
HEXPWD String SIZE(14) Hex Password Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
7-3
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
None.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
GPON If Authorization type is PASSWORD, the length of password is 10. The
OLT will cut off the password if it is over 10.
l Revision History
Revision Date Notes
2014–07–24 Add RID and SNRID
authorization type
NetNu-
menU31R20V12.15.20T95
2015–08–08 New Command Parameters:
HEXPWD
New Command Parameter
Values：HEXPASSWORD for
AUTHTYPE
7.1.2 CFG-ONU【【【Modify ONU Authorization Information】】】
l Description
This command is used for modifying ONU authorization information such as
authorization mode, authorization identification information, etc as changing ONU.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.1/C220v1.2/C300 Series/C300v2 Series/C300v3
Series/C600 Series
PON ONU F820/LAN-MDU Series/xDSL-MDU Series/FTTH ONU
l Command Format
CFG-ONU::OLTID=olt-name,PONID=ponport_location,ONUIDTYPE=onuid-type,
ONUID=onu-index:CTAG::AUTHTYPE=auth-type[,AUTHINFO=onu-index][,PWD=password]
[,RID=rid];
l Operated Target Identifier
7-4
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Parameter
Name
Type Value Range Description Optional Description
OLTID String SIZE(128) OLT IP address, name,
or ID
Required
PONID String SIZE(128)
Rack–Shelf–Slot-
–PON Port
To locate a PON port by
Rack-Shelf-Slot-PON
Port ID. Type NA
when this parameter is
absent.
Required
ONUID-
TYPE
String SIZE(128) ONU identifier type:
ONU_NAME
MAC
LOID
ONU_NUMBER
SN
PASSWORD
Required
ONUID String SIZE(128) ONU identifier.
The value could
be chosen from
ONU_NAME, MAC,
LOID,ONU_NUMBER,
SN and PASSWORD
to uniquely identify an
ONU on the PON port.
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
AUTHTYPE String MAC
LOID
LOIDONCEON
PASSWORD
SN
PWDONCEON
RID
SNRID
Authorization type Required
AUTHINFO String SIZE(128) MAC, LOID,
PASSWORD, RID
or SN of the ONU
Optional, MAC
address format:
XX-XX-XX-XX-XX-XX
PWD OCTET
STRING
SIZE(1-12) Password for SN or
LOID。
Optional
7-5
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
RID String SIZE(36) RID
If the authorization
mode for AUTHTYPE
is SNRID, then
AUTHINFO means
SN and RID means
RID.
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1：
CFG-ONU::OLTID=10.63.194.46,PONID=1-1-8-1,ONUIDTYPE=LOID,
ONUID=8981720182101:CTAG::AUTHTYPE=LOID,
AUTHINFO=089866666666,PWD=17445245;
Response ：
ZTE_PONOAM 2013-10-31 14:55:48
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark：
This command is used to change LOID and LOID Password.
Command 2：
CFG-ONU::OLTID=10.63.194.46,PONID=1-1-8-1,
ONUIDTYPE=ONU_NUMBER,ONUID=2:CTAG::AUTHTYPE=SNRID,
AUTHINFO=ZTEG10012454,RID=5452354;
Response ：
ZTE_PONOAM 2014-11-31 16:25:21
M CTAG COMPLD
EN=0 ENDESC=No Error
;
7-6
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Remark：
This command is used to change SN and RID.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
GPON If Authorization type is PASSWORD, the length of password is 10. The
OLT will cut off the password if it is over 10.
l Revision History
Revision Date Notes
NetNu-
menU31R20V12.15.20T85
2014-12-23 New Command Parameters：
RID
New Command Parameter
Values：RID,SNRID for
AUTHTYPE
7.1.3 DEL-ONU【【【Delete ONU】】】
l Description
This command is used for deleting ONU.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.1/C220v1.2/C300 Series/C300v2 Series/C300v3
Series/C600 Series
PON ONU F820/LAN-MDU Series/xDSL-MDU Series/FTTH ONU
l Command Format
DEL-ONU::OLTID=olt-name,PONID=ponport_location:CTAG::ONUIDTYPE=onuid-type,
ONUID=onu-index;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-7
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
OLTID String SIZE(128) OLT IP address or
name, ID
Required
PONID String SIZE(128)
Rack-Shelf-
Slot-PON Port
Number
PON Port location
information, located by
Rack-Shelf-Slot-PON
Port, NA means
nothing
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUID-
TYPE
String SIZE(128) ONU identifier :
ONU_NAME
MAC
LOID
ONU_NUMBER
SN
PASSWORD
Required
ONUID String SIZE(128) ONU identifier.
The value could
be chosen from
ONU_NAME, MAC,
LOID, ONU_NUMBER,
SN and PASSWORD
to uniquely identify an
ONU on the PON port..
Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
None.
l Average Command Response Time
Scenario Average Response Time (s)
7-8
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Notes
Point Details
GPON If Authorization type is PASSWORD, the length of password is 10. The
OLT will cut off the password if it is over 10.
l Revision History
Revision Date Notes
7.1.4 CRT-SERVICEPORT【【【Create Service Port】】】
l Description
This command is used to create a service port.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN C300M Series/C300Mv4 Series
l Command Format
CRT-SERVICEPORT::(DID=device-id|DNAME=device-name)
(,PID=port-id|[,PID=port-id],OID=onu-id):CTAG::SERVICEPORTID=service-port-id
[,VIFTYPE=virtual-interface-type][,VIFID=virtual-interface-id],
MODE=mode[,DESC=desc][,ADMINSTAT=admin-status][,USERVID=user-vid]
[,USERSVID=user-svid][,USERCOS=user-cos]
[,USERETHERTYPE=user-ether-type][,USERDEFETHERTYPE=user-define-ether-type]
[,USERETHERTYPEFILTER=user-ether-type-filter]
[,ALLOWEDETHERTYPE=allowed-ether-type]
[,ALLOWEDUSERDEFETHERTYPE=allowed-user-define-ether-type]
[,STARTUSERVID=start-user-vid][,ENDUSERVID=end-user-vid][,USERDSCP=user-dscp]
[,NETWORKCVID=network-cvid][,NETWORKCTAGCOS=network-ctag-cos]
[,NETWORKSVID=network-svid][,NETWORKSTAGCOS=network-stag-cos]
[,TLSSVID=tls-svid][,TLSCVID=tls-cvid]
[,INGRESSTRAFFICPRF=ingress-traffic-prf]
[,EGRESSTRAFFICPRF=egress-traffic-prf]
[,QOSQUEUEID=qos-queue-id][,VLANMERGE=vlan-merge];
7-9
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under Certain
Conditions: Must choose
one between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required Under Certain
Conditions: Must choose
one between DID and
DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Required Under Certain
Conditions: Must choose
one between PID and
(PID,OID)
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the
ONU while DID or
DNAME indicates
the OLT device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required Under Certain
Conditions: Must choose
one between PID and OID
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
SERVICE-
PORTID
Integer 1–128 Service Port ID Required
VIFTYPE String VPort Virtual Interface Type
If VIFTYPE is not
input, the default
value is VPort when
operated target
identifier is ONU.
VIFTYPE is invalid
when operated target
identifier is physical
port.
Optional
7-10
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
VIFID Integer 1-128 Virtual Interface ID Required Under Certain
Conditions: Must input
when OID is specified
MODE String Untag
UntagAndEther-
Type
Priority
Tag
Tls
TagAndEtherType
TagAndCosPrior-
ity
VlanRangeTag
VlanRangeTa-
gAndEtherType
VlanRangeTa-
gAndCos
CVlanTranspar-
ent
DoubleVlanTag
DoubleTlsVlan
Service Port Mode
C300/C320v1.2/C300
M Series supports:
Untag
UntagAndEtherType
Priority
Tag
TagAndCosPriority
VlanRangeTag
Tls
C300v2.0/C300v3.0/
C320v2.0/C320v3.0/
C300Mv4/C350Mv4
supports:
Untag
UntagAndEtherType
Priority
Tag
Tls
TagAndEtherType
TagAndCosPriority
VlanRangeTag
VlanRangeTagAndE-
therType
VlanRangeTagAnd-
Cos
CVlanTransparent
DoubleVlanTag
DoubleTlsVlan
Required
DESC Octet
String
SIZE(0-64) Service Port
Description
The size is 0-32
when NE type is
C300/C320v1.2/
C300M Series
The size is 0-64 when
NE type is C300v2.0/
C300v3.0/C320v2.0/
C320v3.0/C300Mv4/
C350Mv4
Optional
7-11
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
ADMIN-
STAT
String Enable
Disable
Administrative Status Optional
USERVID Integer 1–4094 User VLAN ID
Supported by C30
0/C320v1.2/C300M
Series when mode is:
Tag
TagAndEncap
TagAndEtherType
TagAndCosPriority
DoubleVlanTag
TagAndDscp
Supported by
C300v2.0/
C300v3.0/C320v2.0/
C320v3.0/C300Mv4/
C350Mv4 when mode
is:
Tag
TagAndEtherType
TagAndCosPriority
DoubleVlanTag
Optional
USERSVID Integer 1–4094 User SVLAN ID
Supported by C30
0/C320v1.2/C300M
Series when mode is:
DoubleVlanTag
Supported by
C300v2.0/
C300v3.0/C320v2.0/
C320v3.0/C300Mv4/
C350Mv4 when mode
is:
DoubleVlanTag
Optional
USERCOS Integer 0–7 User CoS Priority
Supported by C30
0/C320v1.2/C300M
Series when mode is:
Priority
TagAndCosPriority
VlanRangeTagAnd-
CosPriority
Supported byC300v2.0/
Optional
7-12
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
C300v3.0/C320v2.0/
C320v3.0/C300Mv4/
C350Mv4 when mode
is:
Priority
TagAndCosPriority
VlanRangeTagAnd-
Cos
USERETH-
ERTYPE
String PPPoE
IPoE
UserDefined
User Ethernet Type
Supported by C30
0/C320v1.2/C300M
Series when mode is:
UntagAndEtherType
TagAndEncap
TagAndEtherType
VlanRangeTagAn-
dEncap
VlanRangeTagAndE-
therType
Supported by
C300v2.0/C300v3.0/
C320v2.0/C320v3.0/
C300Mv4/C350Mv4
when mode is:
UntagAndEtherType
TagAndEtherType
VlanRangeTagAndE-
therType
Optional
USERDE-
FETHER-
TYPE
String Hex
value:e.g.0x8180
User Defined Ethernet
Type
Required when
USERETHERTYPE is
UserDefined
Optional
USERET-
HERTYPE-
FILTER
String Enable
Disable
User Ethernet Type
Filter
Supported by C30
0/C320v1.2/C300M
Series
Optional
7-13
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
AL-
LOWEDE-
THER-
TYPE
String AllEtherType
PPPoE
IPoE
UserDefined
Allowed User Ethernet
Type
Supported by
C300v2.0/C300v3.0/
C320v2.0/C320v3.0/
C300Mv4/C350Mv4
when mode is:
Untag
Priority
Tag
VlanRangeTag
VlanRangeTagAnd-
Cos
DoubleVlanTag
Deprecated
ALLOWE-
DUSERDE-
FETHER-
TYPE
String Hex
value:e.g.0x8180
Allowed User Defined
Ethernet Type
Required when
ALLOWEDETHER-
TYPE is
UserDefined
Deprecated
STAR-
TUSERVID
Integer 1–4094 User Starting VLAN ID
Supported by C30
0/C320v1.2/C300M
Series when mode is:
VlanRangeTag
VlanRangeTagAn-
dEncap
VlanRangeTagAndE-
therType
VlanRangeTagAnd-
CosPriority
CVlanTransparent
Supported by
C300v2.0/C300v3.0/
C320v2.0/C320v3.0/
C300Mv4/C350Mv4
when mode is:
VlanRangeTag
VlanRangeTagAndE-
therType
VlanRangeTagAnd-
Cos
CVlanTransparent
Optional
7-14
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
EN-
DUSERVID
Integer 1–4094 User Ending VLAN ID
Supported by C30
0/C320v1.2/C300M
Series when mode is:
VlanRangeTag
VlanRangeTagAn-
dEncap
VlanRangeTagAndE-
therType
VlanRangeTagAnd-
CosPriority
CVlanTransparent
Supported by
C300v2.0/C300v3.0/
C320v2.0/C320v3.0/
C300Mv4/C350Mv4
when mode is:
VlanRangeTag
VlanRangeTagAndE-
therType
VlanRangeTagAnd-
Cos
CVlanTransparent
Optional
USERD-
SCP
Integer 0–63 User DSCP Priority
Supported by C30
0/C320v1.2/C300M
Series when mode is:
tagAndDscp
Optional
NETWOR-
KCVID
Integer 1–4094 Network CVLAN ID
Supported by C30
0/C320v1.2/C300M
Series when mode is:
Untag
UntagAndEtherType
Priority
Tag
TagAndEncap
TagAndEtherType
TagAndCosPriority
DoubleVlanTag
TagAndDscp
Supported by
C300v2.0/
C300v3.0/C320v2.0/
Optional
7-15
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
C320v3.0/C300Mv4/
C350Mv4 when mode
is:
Untag
UntagAndEtherType
Priority
Tag
TagAndEtherType
TagAndCosPriority
DoubleVlanTag
NET-
WORKC-
TAGCOS
Integer 0–7 Network CVLAN CoS
Priority
Supported by
C300/C320v1.2/C300
M
Series when mode is:
Untag
UntagAndEtherType
Priority
Tag
TagAndEncap
TagAndEtherType
TagAndCosPriority
DoubleVlanTag
TagAndDscp
Supported by
C300v2.0/C300v3.0/
C320v2.0/C320v3.0/
C300Mv4/C350Mv4
when mode is:
Untag
UntagAndEtherType
Priority
Tag
TagAndEtherType
TagAndCosPriority
DoubleVlanTag
Optional
7-16
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
NETWOR-
KSVID
Integer 1–4094 Network SVLAN ID
Supported by C30
0/C320v1.2/C300M
Series when mode:
Untag
UntagAndEtherType
Priority
Tag
TagAndEncap
TagAndEtherType
TagAndCosPriority
DoubleVlanTag
TagAndDscp
VlanRangeTag
VlanRangeTagAn-
dEncap
VlanRangeTagAndE-
therType
VlanRangeTagAnd-
CosPriority
Supported by
C300v2.0/C300v3.0/
C320v2.0/C320v3.0/
C300Mv4/C350Mv4
when mode is:
Untag
UntagAndEtherType
Priority
Tag
TagAndEtherType
TagAndCosPriority
VlanRangeTag
VlanRangeTagAndE-
therType
VlanRangeTagAnd-
Cos
DoubleVlanTag
Optional
7-17
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
NET-
WORK-
STAGCOS
Integer 0–7 Network SVLAN CoS
Priority
Supported by C30
0/C320v1.2/C300M
Series when mode is:
Untag
UntagAndEtherType
Priority
Tag
TagAndEncap
TagAndEtherType
TagAndCosPriority
DoubleVlanTag
TagAndDscp
VlanRangeTag
VlanRangeTagAn-
dEncap
VlanRangeTagAndE-
therType
VlanRangeTagAnd-
CosPriority
Supported by
C300v2.0/C300v3.0/
C320v2.0/C320v3.0/
C300Mv4/C350Mv4
when mode is:
Untag
UntagAndEtherType
Priority
Tag
Tls
TagAndEtherType
TagAndCosPriority
VlanRangeTag
VlanRangeTagAndE-
therType
VlanRangeTagAnd-
Cos
DoubleVlanTag
Optional
7-18
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
TLSSVID Integer 1–4094 TLS SVLAN ID
Supported by C30
0/C320v1.2/C300M
Series when mode is:
Tls
DoubleTlsVlan
Supported by
C300v2.0/C300v3.0/
C320v2.0/C320v3.0/
C300Mv4/C350Mv4
when mode is:
Tls
DoubleTlsVlan
Optional
TLSCVID Integer 1–4094 TLS CVLAN ID
Supported by C30
0/C320v1.2/C300M
Series when mode is:
DoubleTlsVlan
Supported by
C300v2.0/C300v3.0/
C320v2.0/C320v3.0/
C300Mv4/C350Mv4
when
mode is :
DoubleTlsVlan
Supported by C600
when mode is :
Tls
Optional
INGRES-
STRAF-
FICPRF
String SIZE(1–32) Ingress Traffic Profile Optional
EGRES-
STRAF-
FICPRF
String SIZE(1–32) Egress Traffic Profile Optional
QOSQUE-
UEID
Integer 0–7 QoS Queue ID Optional
7-19
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
VLAN-
MERGE
String Enable
Disable
VLAN Merge Enabling
Supported by
C300v2.0/C300v3.0/
C320v2.0/C320v3.0/
C300Mv4/C350Mv4
when
mode is :
Tag
TagAndEtherType
TagAndCosPriority
Deprecated
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDNS, DDOF
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command :
CRT-SERVICEPORT::DID=10.63.204.165,OID=1-1-6-1-1:5::
SERVICEPORTID=1,VIFTYPE=VPort,VIFID=1,MODE=Untag,
DESC=UntagDesc,NETWORKCVID=100,NETWORKSVID=120;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create service port on 10.63.204.165,
and SERVICEPORTID is 1, VPort is 1, MODE is Untag,
NETWORKCVID is 100, NETWORKSVID is 120.
No.2 Command :
CRT-SERVICEPORT::DID=10.63.204.165,OID=1-1-6-1-1:5::
SERVICEPORTID=2,VIFTYPE=VPort,VIFID=1,MODE=TagAndEtherType,
DESC=TagAndEtherTypeDesc,USERVID=100,USERETHERTYPE=UserDefined,
7-20
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
USERDEFETHERTYPE=0x8180,USERETHERTYPEFILTER=Enable,NETWORKCVID=200;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create service port on 10.63.204.165,
and SERVICEPORTID is 2, VPort is 1, MODE is TagAndEtherType,
USERVID is 100, USERDEFETHERTYPE is 0x8180,
USERETHERTYPEFILTER is enabled, NETWORKCVID is 200.
No.3 Command :
CRT-SERVICEPORT::DID=10.63.204.165,OID=1-1-6-1-1:5::
SERVICEPORTID=3,VIFTYPE=VPort,VIFID=1,
MODE=VlanRangeTag,DESC=VlanRangeTagDesc,
STARTUSERVID=100,ENDUSERVID=120,NETWORKSVID=200;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create service port on 10.63.204.165,
and SERVICEPORTID is 3, VPort is 1, MODE is VlanRangeTag,
STARTUSERVID is 100, ENDUSERVID is 120, NETWORKSVID is 200.
No.4 Command :
CRT-SERVICEPORT::DID=10.63.204.165,OID=1-1-6-1-1:5::
SERVICEPORTID=4,VIFTYPE=VPort,VIFID=2,MODE=Tag,USERVID=20,
NETWORKCVID=30,EGRESSTRAFFICPRF=0G_2G,QOSQUEUEID=1;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
7-21
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Remark:
This command is used to create service port on 10.63.204.165,
and SERVICEPORTID is3, VPort is 1, MODE is Tag, USERVID is 20,
NETWORKCVID is 30, EGRESSTRAFFICPRF is 0G_2G, and QOSQUEUEID is 1.
No.5 Command :
CRT-SERVICEPORT::DID=10.63.196.151,OID=1-1-2-1-1:5::
SERVICEPORTID=2,VIFTYPE=VPort,VIFID=1,MODE=VlanRangeTag,
STARTUSERVID=100,ENDUSERVID=120,NETWORKSVID=200;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create service port on 10.63.196.151,
and SERVICEPORTID is 2, VPort is 1, MODE is VlanRangeTag,
STARTUSERVID is 100, ENDUSERVID is 120, and NETWORKSVID is 200.
No.6 Command :
CRT-SERVICEPORT::DID=10.63.196.151,PID=1-1-2-1:5::
SERVICEPORTID=2,MODE=VlanRangeTag,
STARTUSERVID=100,ENDUSERVID=120,NETWORKSVID=200;
Response:
0 2016-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create service port on 10.63.196.151,
and SERVICEPORTID is 2, MODE is VlanRangeTag,
STARTUSERVID is 100, ENDUSERVID is 120, and NETWORKSVID is 200.
l Average Command Response Time
Scenario Average Response Time (s)
7-22
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-9-12 New TL1 Command
NetNumenU31R20V12.14.20T80 2014-11-18 New Command Parameters:
VLANMERGE
NetNumenU31R20V12.16.20T100 2015-12-25 New Command Parameters for
Mode Tls: NETWORKCTAGCOS,
NETWORKSTAGCOS
NetNumenU31R20V12.16.20T105 2016-3-29 New Command Parameter
Values: VlanRangeTag,
VlanRangeTagAndEtherType,
VlanRangeTagAndCos for MODE
NetNumenU31R20V12.16.20T105 2016-5-27 New Command Parameters: PID
Change OID, VIFID from Required to
Optional
NetNumenU31R20V12.16.20T105 2016-6-30 New Command Parameter Values:
UntagAndEtherType, Priority for
MODE
NetNumenU31R20V12.17.20T115 2017-1-10 Deprecate Command Parameters:
ALLOWEDETHERTYPE,
ALLOWEDUSERDEFETHERTYPE,
VLANMERGE
7.1.5 CHG-SERVICEPORT【【【Change Service Port】】】
l Description
This command is used to change service port configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
7-23
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
CHG-SERVICEPORT::(DID=device-id|DNAME=device-name)
(,PID=port-id|[,PID=port-id],OID=onu-id):CTAG::SERVICEPORTID=service-port-id
[,INGRESSTRAFFICPRF=ingress-traffic-prf][,EGRESSTRAFFICPRF=egress-traffic-prf]
[,NETWORKCTAGCOS=network-ctag-cos][,NETWORKSTAGCOS=network-stag-cos]
[,DESC=desc];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Required Under
Certain Conditions:
Must choose one
between PID and
(PID,OID)
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device. (e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required Under
Certain Conditions:
Must choose one
between PID and OID
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
SERVICE-
PORTID
Integer 1-128 Service Port ID Required
INGRES-
STRAF-
FICPRF
String SIZE(1–32) Ingress Traffic Profile
"--" means delete traffic
profile.
Optional
7-24
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
EGRES-
STRAF-
FICPRF
String SIZE(1–32) Egress Traffic Profile
"--" means delete traffic
profile.
Optional
NET-
WORKC-
TAGCOS
Integer 0–7 Network CVLAN CoS
Priority
Supported when mode
is:
Untag
Tag
TagAndEtherType
TagAndCosPriority
DoubleVlanTag
For more details
regarding mode,
please refer to
parameter MODE
of command
CRT-SERVICEPORT
Optional
NET-
WORK-
STAGCOS
Integer 0–7 Network SVLAN CoS
Priority
Supported when mode
is:
Tls
For more details
regarding mode,
please refer to
parameter MODE
of command
CRT-SERVICEPORT
Optional
DESC Octet
String
SIZE(1–64) Description
"--" means to clear the
description.
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
IDNE, IRNE, IMP, IIPE, DDNS, DDOF, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
7-25
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Command 1:
CHG-SERVICEPORT::DID=10.63.204.165,OID=1-1-6-1-1:5::SERVICEPORTID=3,
INGRESSTRAFFICPRF=INTEST,EGRESSTRAFFICPRF=EGTEST;
Response:
0 2014-10-28 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the configuration of Rack1/Shelf1/Slot6/Port1/ONU1
/ServicePort3 on NE 10.63.204.165.
Command 2:
CHG-SERVICEPORT::DID=10.63.204.165,OID=1-1-6-1-1:5::SERVICEPORTID=3,
NETWORKSTAGCOS=5;
Response:
0 2015-12-25 00:00:00
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the configuration of Rack1/Shelf1/Slot6/Port1/ONU1
/ServicePort3 on NE 10.63.204.165.
Command 3:
CHG-SERVICEPORT::DID=10.63.204.165,PID=1-1-6-1:5::SERVICEPORTID=3,
NETWORKSTAGCOS=5;
Response:
0 2016-05-27 00:00:00
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the configuration of
Rack1/Shelf1/Slot6/Port1/ServicePort3 on NE 10.63.204.165.
Command 4:
7-26
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
CHG-SERVICEPORT::DID=10.63.204.165,PID=1-1-6-1:5::SERVICEPORTID=3,
DESC=Test;
Response:
0 2016-09-19 15:33:07
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the description of
Rack1/Shelf1/Slot6/Port1/ServicePort3 on NE 10.63.204.165.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-10-28 New TL1 Command
NetNumenU31R20V12.16.20T100 2015-12-25 New Command Parameters：
NETWORKCTAGCOS, NETWORK-
STAGCOS
NetNumenU31R20V12.16.20T105 2016-5-27 Change OID from Required to Optional
NetNumenU31R20V12.16.20T110 2016-9-19 New Command Parameters：DESC
7.1.6 DLT-SERVICEPORT【【【Delete Service Port】】】
l Description
This command is used to delete a service port.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN C300M Series/C300Mv4 Series
7-27
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Command Format
DLT-SERVICEPORT::(DID=device-id|DNAME=device-name)
(,PID=port-id|[,PID=port-id],OID=onu-id):CTAG::
SERVICEPORTID=service-port-id;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Required Under
Certain Conditions:
Must choose one
between PID and
(PID,OID)
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device. (e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required Under
Certain Conditions:
Must choose one
between PID and OID
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
SERVICE-
PORTID
Integer 1-128 Service Port ID Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
7-28
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Error Code
DDNS, DDOF
Refer to Chapter 5 Unified ErrorCode Definition for more details.
l Example
Command 1:
DLT-SERVICEPORT::DID=10.63.204.165,OID=1-1-6-1-1:5::SERVICEPORTID=1;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete service port 1 on 10.63.204.165.
Command 2:
DLT-SERVICEPORT::DID=10.63.204.165,PID=1-1-6-1:5::SERVICEPORTID=1;
Response:
0 2016-05-27 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete service port 1 on 10.63.204.165.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-9-16 New TL1 Command
7-29
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
NetNumenU31R20V12.16.20T105 2016-5-27 New Command
Parameters: PID
Change OID from Required
to Optional
7.1.7 CHG-SERVICEPORTSTAT【【【Change Service Port
Administrative Status】】】
l Description
This command is used to change the administrative status of a service port.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN C300M Series/C300Mv4 Series
l Command Format
CHG-SERVICEPORTSTAT::(DID=device-id|DNAME=device-name)
(,PID=port-id|[,PID=port-id],OID=onu-id):CTAG::
SERVICEPORTID=service-port-id,ADMINSTAT=admin-status;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Required Under
Certain Conditions:
Must choose one
between PID and
(PID,OID)
7-30
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device. (e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required Under
Certain Conditions:
Must choose one
between PID and OID
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
SERVICE-
PORTID
Integer 1-128 Service Port ID Required
ADMIN-
STAT
String Enable
Disable
Administrative Status Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDNS, DDOF
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-SERVICEPORTSTAT::DID=10.63.204.165,OID=1-1-6-1-1:5::
SERVICEPORTID=1,ADMINSTAT=Disable;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to disable service port 1 on 10.63.204.165.
Command 2:
CHG-SERVICEPORTSTAT::DID=10.63.204.165,PID=1-1-6-1:5::
SERVICEPORTID=1,ADMINSTAT=Disable;
7-31
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Response:
0 2016-05-27 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to disable service port 1 on 10.63.204.165.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-9-16 New TL1 Command
NetNumenU31R20V12.16.20T105 2016-5-27 New Command
Parameters: PID
Change OID from Required
to Optional
7.1.8 BND-PORT-MVLAN【【【Bind Port to MVLAN】】】
l Description
This command is used to bind port to MVLAN.
l Applicable NE
NE Category NE Type Notes
DSL DSL Series
PON ONU F820/LAN-MDU Series
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN MSAG5200/MSAG5200V3/MSG5208/C300M Series/C300Mv4
Series
l Command Format
7-32
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
BND-PORT-MVLAN::(DID=device-id|DNAME=device-name),(PID=port-id)|(OID=onuid[,
ONUPORT=onu-port]):CTAG::MVLANID=mvlan-id[,
(VINTERFACE=vinterfaceid|VPI=vpi,VCI=vci)][,BINDTYPE=1/2][,
PROTOCOLTYPE=IGMP/MLD];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under Certain
Conditions: Must choose
one between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required Under Certain
Conditions: Must choose
one between DID and
DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Required Under Certain
Conditions: Must choose
one between PID and
OID
OID String rack-shelf-
slot-port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device. (e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required Under Certain
Conditions: Must choose
one between PID and
OID
ONUPORT String [rack-][shelf-][slot-
]port
UNI Port of ONU (e.g.
3-2: slot3-port2 If no
slot, 2: port2 1-1-3-2:
rack1-shelf1-slot3-
port2)
Optional
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
MVLANID Inte-
ger
1-4094 MVLAN ID Required
7-33
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
VINTER-
FACE
Inte-
ger
0-128 Virtual Interface ID
(When virtual interface
type is BrgPort:
C300M Series/ C300Mv-
4/C350Mv4:0-10
DSL Series:1-8
MSAG5200:0-7
When virtual interface
type is VPort:1-128
)
Optional
VPI Inte-
ger
0-255 VPI Optional: Must choose
VPI and VCI at the same
time
VCI Inte-
ger
0-65535 VCI Optional: Must choose
VPI and VCI at the same
time
BINDTYPE Inte-
ger
1:Source
2:Receive
Bind Type Optional
PROTO-
COLTYPE
String IGMP
MLD
PROTOCOLTYPE
If not input,the default
value is IGMP.
Supported by
C300v2.0/C300v3.0.
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
IDNE、IRNE、IMP、IIPE、DDNS、DDOF、EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command :
BND-PORT-MVLAN::DID=10.61.94.77,PID=1-1-7-1:5::MVLANID=200,BINDTYPE=1;
Response:
0 2014-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
7-34
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Remark:
This command is used to bind Rack1/Shelf1/Slot7/Port1 as a source port to MVLAN
200 on NE 10.61.94.77.
No.2 Command :
BND-PORT-MVLAN::DID=10.61.94.77,PID=1-1-3-11:5::MVLANID=200,BINDTYPE=2;
Response:
0 2014-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to bind Rack1/Shelf1/Slot3/Port11 as a receiving port to
MVLAN 200 on NE 10.61.94.77.
No.3 Command :
BND-PORT-MVLAN::DID=10.61.94.77,OID=1-1-2-1-1:5::MVLANID=200,
VINTERFACE=3,BINDTYPE=2,PROTOCOLTYPE=MLD;
Response:
0 2014-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to bind Rack1/Shelf1/Slot2/Port1/ONU1/VPort3 as a receiving
port to MVLAN 200 on NE 10.61.94.77.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
7-35
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
NetNu-
menU31R20V12.14.20T80
2014-10-28 Change Operated Target
Identifier:ONUPORT from
Required to Optional
NetNu-
menU31R20V12.15.20T95
2015-11-3 New Command Parameters：
PROTOCOLTYPE
7.1.9 UBND-PORT-MVLAN【【【Unbind Port from MVLAN】】】
l Description
This command is used to unbind port from MVLAN.
l Applicable NE
NE Category NE Type Notes
DSL DSL Series
PON ONU F820/LAN-MDU Series
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series/C600
Series
MSAN MSAG5200/MSAG5200V3/MSG5208/C300M Series/C300Mv4
Series
l Command Format
UBND-PORT-MVLAN::(DID=device-id|DNAME=device-name),(PID=port-id)|(OID=onu-id[,
ONUPORT=onu-port]):CTAG::MVLANID=mvlan-id[,
(VINTERFACE=vinterface-id|VPI=vpi,VCI=vci)][,BINDTYPE=1/2][,PROTOCOLTYPE=IGMP/MLD];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under Certain
Conditions: Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required Under Certain
Conditions: Must
choose one between
DID and DNAME
7-36
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Required Under Certain
Conditions: Must
choose one between
PID and OID
OID String rack-shelf-
slot-port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device. (e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required Under Certain
Conditions: Must
choose one between
PID and OID
ONUPORT String [rack-][shelf-][slo-
t-]port
UNI Port of ONU (e.g.
3-2: slot3-port2 If no
slot, 2: port2 1-1-3-2:
rack1-shelf1-slot3-
port2)
Optional
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
MVLANID Integer 1-4094 MVLAN ID Required
VINTER-
FACE
Integer 0-128 Virtual Interface ID
(When virtual interface
type is BrgPort:
C300M Series/ C300M-
v4/C350Mv4:0-10
DSL Series:1-8
MSAG5200:0-7
When virtual interface
type is VPort:1-128
)
Optional
VPI Integer 0-255 VPI Optional: Must choose
VPI and VCI at the same
time
VCI Integer 0-65535 VCI Optional: Must choose
VPI and VCI at the same
time
BINDTYPE Integer 1:Source
2:Receive
Bind Type Optional
7-37
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
PROTO-
COLTYPE
String IGMP
MLD
PROTOCOLTYPE
If not input,the default
value is IGMP.
Supported by
C300v2.0/C300v3.0.
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
IDNE、IRNE、IMP、IIPE、DDNS、DDOF、EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command :
UBND-PORT-MVLAN::DID=10.61.94.77,PID=1-1-7-1:5::MVLANID=200,BINDTYPE=1;
Response:
0 2014-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to unbind Rack1/Shelf1/Slot7/Port1 from MVLAN 200 on NE
10.61.94.77.
No.2 Command :
UBND-PORT-MVLAN::DID=10.61.94.77,PID=1-1-3-11:5::MVLANID=200,VINTERFACE=1,
BINDTYPE=2;
Response:
0 2014-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to unbind Rack1/Shelf1/Slot3/Port11 from MVLAN 200 on NE
10.61.94.77.
No.3 Command :
7-38
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
UBND-PORT-MVLAN::DID=10.61.94.77,OID=1-1-2-1-1:5::
MVLANID=200,VINTERFACE=3,BINDTYPE=2,PROTOCOLTYPE=MLD;
Response:
0 2014-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to unbind Rack1/Shelf1/Slot2/Port1/ONU1/VPort3 from
MVLAN 200 on NE 10.61.94.77.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNu-
menU31R20V12.14.20T80
2014-10-28 Change Operated Target
Identifier:ONUPORT from
Required to Optional
NetNu-
menU31R20V12.15.20T95
2015-11-3 New Command Parame-
ters：PROTOCOLTYPE
7.1.10 CHG-PORTQOS-TRAFFICPRF【【【Modify Port QoS Traffic
Profile】】】
l Description
This command is used to change port QoS traffic profile.
l Applicable NE
NE Category NE Type Notes
DSL DSL Series
MSAN MSAG5200/MSAG5200V3/MSAG5208/C300M
Series/C300Mv4 Series
7-39
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
l Command Format
CHG-PORTQOS-TRAFFICPRF::(DID=device-id|DNAME=device-name),
(PID=port-id|([PID=port-id,]OID=onu-id[,ONUPORT=onu-port])):CTAG::
VINTERFACETYPE=virtual-interface-type,(SVLANID=svlan-id[,CVLANID=cvlan-
id]|VINTERFACEID=vinterface-id,| (VPI=vpi,VCI=vci))[,DIRECTION=direction],
TRAFFICPRF=traffic-profile-name;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under Certain
Conditions: Must choose
one between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required Under Certain
Conditions: Must choose
one between DID and
DNAME
PID String rack-shelf-
slot-port
Port ID (e.g 1-1-3-5) Case 1: PID. PID Required
Case 2: [PID,]OID. PID
Optional, OID Required
OID String rack-shelf-
slot-port-onu
MacAddress
SN/LOID/Pa-
ssword
ONU ID. It's used to
identify the ONU while
DID or DNAME indicates
the OLT device.
(e.g.1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Case 1: PID. PID Required
Case 2: [PID,]OID. PID
Optional, OID Required
ONUPORT String [rack-][shelf-]
[slot-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required Under Certain
Conditions: Must choose
one between PID and
(OID,ONUPORT)
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
7-40
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
VINTER-
FACE-
TYPE
String VLAN
BrgPort
VPort
Virtual Interface Type.
(VPort is supported
by PON OLT/C300
Mv4/C350Mv4.)
Required
SVLANID Integer 1-4094 S-VID Optional
CVLANID Integer 1-4094 C-VID Optional
VINTER-
FACEID
Integer 1-128 Virtual Interface ID Optional
VPI Integer 0-255 VPI
Not supported by MSAN.
Optional
VCI Integer 0-65535 VCI
Not supported by MSAN.
Optional
DIREC-
TION
String Ingress
Egress
Direction
(Default value is Egress.)
Optional
TRAF-
FICPRF
String SIZE(0-32) Traffic Profile Name Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
IIAC, IMP, IIPE, DDOF
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command :
CHG-PORTQOS-TRAFFICPRF::DID=10.63.173.29,PID=1-1-3-1:5::
VINTERFACETYPE=VLAN,SVLANID=5,TRAFFICPRF=TEST.PRF;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change port QoS traffic profile of Rack1/
Shelf1/Slot3/Port1/SVLANID5 on 10.63.174.29.
No.2 Command :
7-41
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
CHG-PORTQOS-TRAFFICPRF::DID=10.63.173.29,PID=1-1-3-1:5::
VINTERFACETYPE=BrgPort,VINTERFACEID=1,TRAFFICPRF=TEST.PRF;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change port QoS traffic profile of Rack1/
Shelf1/Slot3/Port1/BrgPort1 on 10.63.174.29.
No.3 Command :
CHG-PORTQOS-TRAFFICPRF::DID=10.63.173.29,PID=1-1-3-1:5::
VINTERFACETYPE=BrgPort,VPI=8,VCI=81,DIRECTION=Egress,TRAFFICPRF=TEST.PRF;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change port QoS traffic profile of Rack1/
Shelf1/Slot3/Port1/BrgPort(8/81) on 10.63.174.29.
No.4 Command :
CHG-PORTQOS-TRAFFICPRF::DID=10.63.173.29,OID=1-1-3-1-1:5::
VINTERFACETYPE=VPort,VINTERFACEID=1,TRAFFICPRF=TEST.PRF;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change port QoS traffic profile of Rack1/
Shelf1/Slot3/Port1/ONU1/VPort1 on 10.63.174.29.
l Average Command Response Time
Scenario Average Response Time (s)
7-42
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-9-23 New Command Parameter
Values:VPort for VINTERFACETYPE
NetNu-
menU31R20V12.16.20T105
2016-4-27 Change ONUPORT from Required to
Optional
Change Command Parameters：
(OID=onu-id[,ONUPORT=onu-port])
to ([PID=port-id,]OID=onu-
id[,ONUPORT=onu-port])
7.1.11 DLT-PORTQOS-TRAFFICPRF【【【Delete Port QoS Traffic
Profile】】】
l Description
This command is used to delete port QoS traffic profile.
l ApplicableNE
NE Category NE Type Notes
PON ONU xDSL-MDU Series
MSAN MSAG5200V3/C300M Series/C300Mv4 Series
PON OLT C300v2 Series/C300v3 Series/C600 Series
l Command Format
DLT-PORTQOS-TRAFFICPRF::(DID=device-id|DNAME=device-name),(PID=port-id|
(OID=onu-id,ONUPORT=onu-port)):CTAG::VINTERFACETYPE=virtual-interface-type,
(SVLANID=svlan-id[,CVLANID=cvlan-id]|VINTERFACEID=vinterface-id,|
(VPI=vpi,VCI=vci))[,DIRECTION=direction];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-43
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DID String SIZE(1-100) NE ID Required Under Certain
Conditions: Must choose
one between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required Under Certain
Conditions: Must choose
one between DID and
DNAME
PID String rack-shelf-
slot-port
Port ID (e.g 1-1-3-5) Required Under Certain
Conditions: Must choose
one between PID and OID
OID String rack-shelf-
slot-port-onu
MacAddress
SN/LOID/Pa-
ssword
ONU ID. It's used to
identify the ONU while DID
or DNAME indicates the
OLT device.
(e.g.1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required Under Certain
Conditions: Must choose
one between PID and OID
ONUPORT String [rack-][shelf-]
[slot-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required Under Certain
Conditions: Must choose
one between PID and
(OID,ONUPORT)
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
VINTER-
FACE-
TYPE
String VLAN
BrgPort
VPort
Virtual Interface Type.
(VPort is supported
by PON OLT/C300
Mv4/C350Mv4.)
Required
SVLANID Integer 1-4094 S-VID Optional
CVLANID Integer 1-4094 C-VID Optional
VINTER-
FACEID
Integer 1-128 Virtual Interface ID Optional
VPI Integer 0-255 VPI
Not supported by MSAN.
Optional
VCI Integer 0-65535 VCI
Not supported by MSAN.
Optional
7-44
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DIREC-
TION
String Ingress
Egress
Direction
(If DIRECTION is not
input, the ingress and
egress traffic profiles will
be deleted.)
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
IIAC, IMP, IIPE, DDOF
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command :
DLT-PORTQOS-TRAFFICPRF::DID=10.63.173.29,PID=1-1-3-1:5::
VINTERFACETYPE=VLAN,SVLANID=5;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete port QoS traffic profile of
Rack1/Shelf1/Slot3/Port1/SVLANID5 on 10.63.173.29.
No.2 Command :
DLT-PORTQOS-TRAFFICPRF::DID=10.63.173.29,PID=1-1-3-1:5::
VINTERFACETYPE=BrgPort,VINTERFACEID=1;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete port QoS traffic profile of
Rack1/Shelf1/Slot3/Port1/BrgPort1 on 10.63.173.29.
7-45
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
No.3 Command :
DLT-PORTQOS-TRAFFICPRF::DID=10.63.173.29,PID=1-1-3-1:5::
VINTERFACETYPE=BrgPort,VPI=8,VCI=81,DIRECTION=Egress;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete port QoS traffic profile of
Rack1/Shelf1/Slot3/Port1/BrgPort(8/81) on 10.63.173.29.
No.4 Command :
DLT-PORTQOS-TRAFFICPRF::DID=10.63.173.29,OID=1-1-3-1-1:5::
VINTERFACETYPE=VPort,VINTERFACEID=1;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete port QoS traffic profile of
Rack1/Shelf1/Slot3/Port1/ONU1/VPort1 on 10.63.173.29.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-9-23 New Command Parameter Val-
ues:VPort for VINTERFACETYPE
7-46
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
7.1.12 CHG-PORT-MAXLEARNTMAC【【【Change Port Maximum
Number of Learnt MAC Addresses】】】
l Description
This command is used to change maximum number of learnt MAC addresses.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600
Series
MSAN C300M Series
DSL DSL Series
l Command Format
CHG-PORT-MAXLEARNTMAC::(DID=device-id|DNAME=device-name),(PID=port-
id|([PID=port-id,]OID=onu-id[,ONUPORT=onu-port])):CTAG::[VIFTYPE=virtual-interface-type,][(VIFID=vinterface-id|SERVICENAME=service-name)][,VLANID=vlan-id][,MACLIMITSTAT=mac-limit-status][,MAXLEARNTMAC=max-learnt-mac];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional
Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one
between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one
between DID and
DNAME
PID String rack-shelf-slot-port Port ID (e.g. 1-1-3-5) Case 1: PID. PID
Required
Case 2: [PID,]OID.
PID Optional, OID
Required
7-47
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
OID String rack-shelf-slot-port-
onu
MacAddress
SN/LOID/Password
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g.1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Case 1: PID. PID
Required
Case 2: [PID,]OID.
PID Optional, OID
Required
ONUPORT String [rack-][shelf-][slot-]p-
ort
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-
shelf1-slot3-port2)
Required Under
Certain Conditions:
Must choose one
between PID and
(OID,ONUPORT)
l Command Parameter
Parameter
Name
Type ValueRange Description Optional
Description
VIFTYPE String VPort
ServicePort
BrgPort
Virtual Interface Type. (If
VIFTYPE is not input, the
default value is VPort when
operated target identifier is
ONU, and the default value
is BrgPort when operated
target identifier is physical
port.)
Optional
VIFID Integer 1-256 Virtual Interface ID.
(When operated target
identifier is ONU, VIFID
means VPort number.
When operated target
identifier is physical port,
VIFID means bridge port
number.)
Optional
VLANID Integer 1-4094 VLAN ID Optional
MACLIMITSTAT String Enable
Disable
MAC Limit Status Optional
MAXLEARNT-
MAC
Integer 0-32768 Maximum Number of
Learnt MAC Addresses
Optional
SERVICENAME String SIZE(1-64) Service Name. Optional
7-48
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
IDNE、DDOF
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command :
CHG-PORT-MAXLEARNTMAC::DID=10.61.94.33,OID=1-1-1-1-1:5::VIFID=1,
MACLIMITSTAT=Enable,MAXLEARNTMAC=10;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No error
;
Remark:
This command is used to set maximum number of learnt MAC addresses of
Rack1/Shelf1/Slot1/Port1/ONU1/VPort1 to 10 on 10.61.94.33.
No.2 Command :
CHG-PORT-MAXLEARNTMAC::DID=10.61.94.33,OID=1-1-1-1-1:5::VIFTYPE=VPort,VIFID=1,
MACLIMITSTAT=Disable;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No error
;
Remark:
This command is used to disable MAC address limit of
Rack1/Shelf1/Slot1/Port1/ONU1/VPort1 on 10.61.94.33.
No.3 Command :
CHG-PORT-MAXLEARNTMAC::DID=10.61.94.33,PID=1-1-1-1:5::VLANID=20,
MACLIMITSTAT=Enable,MAXLEARNTMAC=10;
Response:
0 2004-04-01 10:55:49
7-49
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
M 5 COMPLD
EN=0 ENDESC=No error
;
Remark:
This command is used to set maximum number of learnt MAC addresses of
Rack1/Shelf1/Slot1/Port1/VLAN20 to 10 on 10.61.94.33.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision HistoryRevision Date Notes
NetNumenU31R20V12.13.20T50 2013-8-14 Delete Command Parameters: VIFTYPE
New Command Parameters: VLANID
Change Command Parameters:
LEARNTMACSTATUS to MACLIMITSTAT
Change VIFID from Required to Optional
NetNumenU31R20V12.16.20T105 2016-4-27 New Command Parameters：VIFTYPE
New Command Parameters：
SERVICENAME
7.1.13 CHG-PORTLOCATING【【【Change Port Identification】】】
l Description
Change the port identification.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.1/C220v1.2/C300 Series/C300v2 Series/C300v3
Series/C600 Series
MSAN MSAG5200V3/C300M Series/C300Mv4 Series
DSL DSL Series
l Command Format
7-50
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
CHG-PORTLOCATING::(DID=device-id|DNAME=device-name),(PID=port-id|OID=oid):
CTAG::[VIFTYPE=virtual-interface-type,][(VIFID=vinterface-id|SERVICENAME=service-name)]
[,FORMAT=format-value][,REMOTEIDSTAT=remoteid-status][,REMOTEIDNAME=
remoteid-name][,REMOTEIDPRF=remoteid-profile][,DHCPSYNTAXPRF=dhcp-syntax-profile,
PPPOESYNTAXPRF=pppoe-syntax-profile];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under Certain
Conditions:Must choose
one between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required Under Certain
Conditions:Must choose
one between DID and
DNAME
PID String rack-shelf-
slot-port
Port ID (e.g 1-1-3-5) Required Under Certain
Conditions:Must choose
one between PID and
OID
OID String rack-shelf-
slot-port-onu
MacAddress
SN/LOID/Pas-
sword
ONU ID. It's used to
identify the ONU while
DID or DNAME indicates
the OLT device.
(e.g.1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required Under Certain
Conditions:Must choose
one between PID and
OID
l Command Parameter
Parame-
ter Name
Type Value Range Description Optional
Description
VIFTYPE String VPort
ServicePort
BrgPort
Virtual Interface Type.
(If VIFTYPE is not input, the
default value is VPort when
operated target identifier is ONU,
and the default value is BrgPort
when operated target identifier is
physical port.)
Optional
VIFID Integer 1-256 Virtual Interface ID.
Not supported by DSL Series.
Optional
7-51
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
SERVICE-
NAME
String SIZE(1-64) Service Name. Optional
FORMAT String CTC
DSL-FORUM
DSL-FORUM-
RACKFRAME
CNC
TT
KT
TI
ST
CISCO
JUNIPER
CTCDSLAM
KPN
FLEXIBLE-
SYNTAX
FT
DT
SILKNET
VODAFONE
BHARTIAIRTEL
CUC
[Syntax Profile]
The format of port
identification:
CTC: China Telecom
DSL-FORUM: DSL Forum
DSL-FORUM-RACKFRAME:
DSL Forum with Rack and Frame
(Supported by DSL Series)
CNC: China Netcom
TT: T.Telekom
KT: Korea Telecom (Supported
by C300 Series/MSAG5200V3)
TI: Telecom Italia
ST: Singapore Telecommunica-
tions Limited (Singtel) (Supported
by C300 Series/MSAG5200V3)
CISCO: CISCO (Supported by
DSL Series)
JUNIPER: Juniper (Supported by
DSL Series)
CTCDSLAM: China Telecom
DSLAM (Supported by DSL
Series)
KPN: KPN (Supported by DSL
Series)
FLEXIBLE-SYNTAX: Flexible
Syntax
FT:France Telecom
DT:TR156
SILKNET:Georgia Telcom
VODAFONE:Vodafone
BHARTIAIRTEL:Bharti Airtel
CUC:China Unicom
[Syntax Profile](Syntax Profile
Name, Supported by C300M
Series)
Not supported by C600 Series.
Optional
RE-
MOTEID-
STAT
String Enable
Disable
Remote ID Status
Not supported by C600 Series.
Optional
7-52
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
RE-
MOTEID-
NAME
String SIZE(1-64) Name of Remote ID.
--:delete remote ID name
Optional
RE-
MOTEID-
PRF
String SIZE(1-32) Remote ID Profile.
--:delete remote ID profile
Supported by C300v2 Series and
C300v3 Series
Not supported by C600 Series.
Optional
DHCP-
SYNTAX-
PRF
String SIZE(1-32) DHCP Syntax Profile.
Supported by DSL Series.
Not supported by C600 Series.
Optional
PP-
POESYN-
TAXPRF
String SIZE(1-32) PPPoE Syntax Profile.
Supported by DSL Series.
Not supported by C600 Series.
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command :
CHG-PORTLOCATING::DID=10.63.196.242,OID=1-1-1-2-1:CTAG::VIFID=1,
FORMAT=DSL-FORUM,REMOTEIDSTAT=Enable,REMOTEIDNAME=test;
Response:
ZTE-EB9A30BF27A 2010-09-27 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the port identification of Rack1/Shelf1/Slot1/Port2
Onu1 on 10.63.196.242.
No.2 Command :
CHG-PORTLOCATING::DID=10.63.196.242,OID=1-1-1-3-1:CTAG::VIFID=1,
FORMAT=DSL-FORUM,REMOTEIDSTAT=Enable;
Response:
7-53
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
ZTE-EB9A30BF27A 2010-09-27 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the port identification of Rack1/Shelf1/Slot1/Port3
Onu1 on 10.63.196.242.
No.3 Command :
CHG-PORTLOCATING::DID=10.63.196.242,OID=1-1-1-4-1:CTAG::VIFID=1,
FORMAT=DSL-FORUM;
Response:
ZTE-EB9A30BF27A 2010-09-27 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the port identification of Rack1/Shelf1/Slot1/Port4
Onu1 on 10.63.196.242.
No.4 Command :
CHG-PORTLOCATING::DID=10.63.194.46,OID=1-1-17-1-1:CTAG::VIFTYPE=ServicePort,
VIFID=1,FORMAT=FLEXIBLE-SYNTAX;
Response:
ZTE-EB9A30BF27A 2013-02-04 16:18:05
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the port identification of
Rack1/Shelf1/Slot17/Port1/Onu1/ServicePort1 on 10.63.194.46.
No.5 Command :
CHG-PORTLOCATING::DID=10.63.194.43,PID=1-1-3-1-2:CTAG::VIFID=1,FORMAT=AAA;
Response:
ZTE-EB9A30BF27A 2013-03-05 16:18:05
M CTAG COMPLD
EN=0 ENDESC=No Error
7-54
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
;
Remark:
This command is used to change the port identification of
Rack1/Shelf1/Slot3/Port1/Pvc2 on 10.63.194.43. AAA is the syntax profile name.
No.6 Command :
CHG-PORTLOCATING::DID=10.63.174.165,PID=1-1-3-1:CTAG::VIFID=1,
FORMAT=FLEXIBLE-SYNTAX,DHCPSYNTAXPRF=TestDhcp,
PPPOESYNTAXPRF=TestPppoe;
Response:
ZTE-EB9A30BF27A 2013-03-10 16:18:05
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the DHCP and PPPoE syntax profile of
Rack1/Shelf1/Slot3/Port1 on 10.63.174.165.
No.7 Command :
CHG-PORTLOCATING::DID=10.63.194.43,PID=1-1-4-1:CTAG::FORMAT=AAA;
Response:
ZTE-EB9A30BF27A 2013-04-25 16:18:05
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the port identification of Rack1/Shelf1/Slot4/Port1
on 10.63.194.43. AAA is the syntax profile name.
No.8 Command :
CHG-PORTLOCATING::DID=10.63.194.43,PID=1-1-4-1:CTAG::REMOTEIDPRF=–;
Response:
ZTE-EB9A30BF27A 2013-04-25 16:18:05
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
7-55
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
This command is used to delete the remote ID profile of Rack1/Shelf1/Slot4/Port1 on
10.63.194.43.
No.9 Command :
CHG-PORTLOCATING::DID=10.63.194.43,PID=1-1-3-1-2:CTAG::SERVICENAME=HIS,
FORMAT=AAA;
Response:
ZTE-EB9A30BF27A 2013-03-05 16:18:05
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the port identification of
Rack1/Shelf1/Slot3/Port1/Onu1/ServiceName HIS on 10.63.194.43. AAA is the
syntax profile name.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.13.20T40 2013-4-10 New Command Parameters: DHCPSYN-
TAXPRF, PPPOESYNTAXPRF
NetNumenU31R20V12.13.20T40 2013-4-25 Change VIFID from Required to Optional
NetNumenU31R20V12.13.20T50 2013-7-12 New Command Parameters:
REMOTEIDPRF.
Change Value Range of VIFID from
1–128 to 1–256.
NetNumenU31R20V12.14.20T75 2014-4-4New Command Parameters：
SERVICENAME
NetNumenU31R20V12.15.20T90 2015-4-2 New Command Parameter Values:
FT, DT, SILKNET, VODAFONE,
BHARTIAIRTEL, CUC for FORMAT
7-56
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
NetNumenU31R20V12.17.20T115 2016-12-29 New Command Parameter Values:
DSL-FORUM-RACKFRAME
7.1.14 CHG-PORT-DHCP【【【Modify port of DHCP】】】
l Description
Modify the DHCP configuration of port.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series
MSAN MSAG5200V3/C300M Series/C300Mv4 Series
PON ONU xDSL-MDU Series/G.fast-MDU Series/LAN-MDU
Series
l Command Format
CHG-PORT-DHCP::(DID=device-id|DNAME=device-name),(PID=port-id|OID=oid):CTAG::
[VIFTYPE=virtual-interface-type,][(VIFID=vinterface-id|SERVICENAME=service-name),]
[OPTION82STAT=option82-status][,SNOOPINGSTAT=snooping-status]
[,TRUSTSTAT=trust-status][,TRUSTPOLICY=policy-value];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
PID String rack-shelf-slot-
port
Port ID(e.g 1-1-3-5) Required Under
Certain Conditions:
Must choose one
between PID and OID
7-57
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g.1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one between
PID and OID
l Command Parameter
Parameter
Name
Type Value Range Description Optional
Description
VIFTYPE String VPort
ServicePort
BrgPort
Virtual Interface Type.
(If VIFTYPE is not input, the
default value is VPort when
operated target identifier is
ONU, and the default value is
BrgPort when operated target
identifier is physical port.)
Optional
VIFID Integer 1-256 Virtual Interface ID. Optional
SERVICE-
NAME
String SIZE(1-64) Service Name. Optional
OPTION82
STAT
String Enable
Disable
DHCP Option82 Status
Not Supported by C300v3
Series.
Optional
SNOOP-
INGSTAT
String Enable
Disable
DHCP Snooping Status Optional
TRUST-
STAT
String Trust
Untrust
DHCP Trust Status For PON OLT
and MSAN:
Must choose
TRUSTSTAT
and TRUST-
POLICY at
the same time
For PON
ONU:
Optional
7-58
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
TRUST-
POLICY
String Keep
Replace
Discard
Add
Trust Policy
Keep: Retain the existing port
identification information.
Replace: Overwrite port
identification information.
Discard: Drop messages with
port identification information.
Add: Add port identification
information.
For PON OLT and MSAN:
If TRUSTSTAT is Trust,
TRUSTPOLICY should be
configured as Keep or Replace.
If TRUSTSTAT is Untrust,
TRUSTPOLICY should be
configured as Discard or Add.
For PON OLT
and MSAN:
Must choose
TRUSTSTAT
and TRUST-
POLICY at
the same time
For PON
ONU: Not
applicable
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command :
CHG-PORT-DHCP::DID=10.63.196.242,OID=1-1-1-2-1:5::VIFID=1,
SNOOPINGSTAT=Enable;
Response:
ZTE-EB9A30BF27A 2010-09-27 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to modify the DHCP information of Rack1/Shelf1/Slot1/Port2
ONU 1 VPort 1 on NE 10.63.196.242.
No.2 Command :
CHG-PORT-DHCP::DID=10.63.196.242,OID=1-1-3-1:5::VIFID=1,OPTION82STAT=Enable;
7-59
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Response:
ZTE-EB9A30BF27A 2010-09-27 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to modify the DHCP information of Rack1/Shelf1/Slot3/Port1
BridgePort 1 on NE 10.63.196.242.
No.3 Command :
CHG-PORT-DHCP::DID=10.63.196.242,OID=1-1-1-2-1:5::VIFID=1,OPTION82STAT=Enable,
TRUSTSTAT=Trust,TRUSTPOLICY=Keep;
Response:
ZTE-EB9A30BF27A 2010-09-27 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to modify the DHCP information of Rack1/Shelf1/Slot1/Port2
ONU 1 VPort 1 on NE 10.63.196.242.
No.4 Command :
CHG-PORT-DHCP::DID=DID=10.63.194.46,OID=1-1-17-1-1:5::VIFTYPE=ServicePort,
VIFID=1,OPTION82STAT=Disable,SNOOPINGSTAT=Enable,TRUSTSTAT=Untrust,
TRUSTPOLICY=Add;
Response:
ZTE-EB9A30BF27A 2013-02-04 16:18:05
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to modify the DHCP information of Rack1/Shelf1/Slot17/Port1
ONU 1 ServicePort 1 on NE 10.63.194.46.
No.5 Command :
CHG-PORT-DHCP::DID=10.63.194.46,OID=1-1-17-1-1:5::VIFTYPE=VPort,SERVICENAME
=HIS,OPTION82STAT=Disable,SNOOPINGSTAT=Enable,
TRUSTSTAT=Untrust,TRUSTPOLICY=Add;
Response:
7-60
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
ZTE-EB9A30BF27A 2013-02-04 16:18:05
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to modify the DHCP information of Rack1/Shelf1/Slot17/Port1
ONU 1 SERVICENAME HIS on NE 10.63.194.46.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.13.20T40 2013-4-25 Change VIFID from
Required to Optional.
NetNumenU31R20V12.13.20T50 2013-7-12 Change Value Range of
VIFID from 1–128 to 1–256.
NetNumenU31R20V12.14.20T70 2014-2-18 New Command
Parameters：
SERVICENAME.
NetNumenU31R20V12.17.20T115 2016-12-29 New Applicable NEs：PON
ONU
7.1.15 CHG-PORT-PPPOEPLUS【【【Modify Port PPPoE Plus
Information】】】
l Description
This command is used to modify port PPPoE plus information.
l Applicable NE
NE Category NE Type Notes
MSAN MSAG5200V3/C300M Series/C300Mv4 Series
7-61
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
PON OLT C220v1.1/C220v1.2/C300 Series/C300v2
Series/C300v3 Series
DSL Series xDSL-MDU Series
l Command Format
CHG-PORT-PPPOEPLUS::(DID=device-ID|DNAME=device-name),
(PID=portid|OID=oid):CTAG::[VIFTYPE=virtual-interface-type,]
(VIFID=vinterface-id|SERVICENAME=service-name),STATUS=pppoeplus-status
[,TRUSTSTAT=trust-status,TRUSTPOLICY=trust-policy];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID(e.g 1-1-3-5) Required
Under Certain
Conditions:Must
choose one between
PID and OID
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g.1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one between
PID and OID
l Command Parameter
Parameter
Name
Type Value Range Description Optional
Description
7-62
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
VIFTYPE String VPort
ServicePort
BrgPort
Virtual Interface Type.
(If VIFTYPE is not input, the
default value is VPort when
operated target identifier is
ONU, and the default value is
BrgPort when operated target
identifier is physical port.)
Optional
VIFID Integer 1-256 Virtual Interface ID.
Not supported by DSL Series.
Optional
SERVICE-
NAME
String SIZE(1-64) Service Name. Optional
STATUS String Enable
Disable
PPPoE Plus Status Required
TRUST-
STAT
String Trust
Untrust
PPPoE Plus Trust Status Optional:
Must choose
TRUSTSTAT
and
TRUSTPOLICY
at the same time
TRUST-POLICY
String Keep
Replace
Discard
Add
Trust Policy
Keep: Retain the existing port
identification information.
Replace: Overwrite port
identification information.
Discard: Drop messages with
port identification information.
Add: Add port identification
information.
If TRUSTSTAT is Trust,
TRUSTPOLICY should
be configured as Keep or
Replace. If TRUSTSTAT
is Untrust, TRUSTPOLICY
should be configured as
Discard or Add.
Optional:
Must choose
TRUSTSTAT
and
TRUSTPOLICY
at the same time
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
7-63
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DDOF, IPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command :
CHG-PORT-PPPOEPLUS::DID=10.63.156.129,PID=1-1-6-1:5::VIFID=1,STATUS=Disable;
Response:
ZTE-EB9A30BF27A 2010-05-19 10:18:28
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to modify port PPPoE plus information of Rack1/
Shelf1/Slot6/Port1 on 10.63.156.129.
No.2 Command :
CHG-PORT-PPPOEPLUS::DID=10.63.194.46,OID=1-1-17-1-1:5::
VIFTYPE=ServicePort,VIFID=1,STATUS=Enable;
Response:
ZTE-EB9A30BF27A 2013-02-04 16:18:05
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to modify port PPPoE plus information of
Rack1/Shelf1/Slot17/Port1/Onu1/ServicePort1 on 10.63.194.46.
No.3 Command :
CHG-PORT-PPPOEPLUS::DID=10.63.194.43,PID=1-1-4-1:5::STATUS=Disable;
Response:
ZTE-EB9A30BF27A 2013-04-25 10:18:28
M 5 COMPLD
EN=0 ENDESC=No Error
;
No.4 Command :
CHG-PORT-PPPOEPLUS::DID=10.63.194.46,OID=1-1-17-1-1:5::
VIFTYPE=ServicePort,SERVICENAME=HIS,STATUS=Enable;
Response:
7-64
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
ZTE-EB9A30BF27A 2013-02-04 16:18:05
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to modify port PPPoE plus information of
Rack1/Shelf1/Slot17/Port1/Onu1/ServiceName HIS on 10.63.194.46.
No.5 Command :
CHG-PORT-PPPOEPLUS::DID=10.63.156.129,PID=1-1-6-1:5::VIFID=1,STATUS=Disable,
TRUSTSTAT=Untrust,TRUSTPOLICY=Add;
Response:
ZTE-EB9A30BF27A 2010-05-19 10:18:28
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to modify port PPPoE plus information of Rack1/
Shelf1/Slot6/Port1 on 10.63.156.129.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.13.20T40 2013-4-25 Change VIFID from Required to
Optional.
NetNumenU31R20V12.13.20T50 2013-7-12 Change Value Range of VIFID from
1–128 to 1–256.
NetNumenU31R20V12.14.20T75 2014-4-4 New Command Parameters：
SERVICENAME
NetNumenU31R20V12.14.20T75 2014-5-21 New Command Parameters：
TRUSTSTAT, TRUSTPOLICY
7-65
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
7.1.16 CHG-ONUVOIPIP【【【Change ONU VoIP IP】】】
l Description
This command is used to change GPON ONU VoIP configuration information.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series/C600
Series
l Command Format
CHG-ONUVOIPIP::(DID=device-id|DNAME=device-name)[,PID=port-id]
[,OID=onu-id]:CTAG::[ONUPROFILENAME=onu-profile-name],VLANPROFILENAME=
vlan-profile-name,(IPHOSTID=iphost-id|IPV6HOSTID=ipv6-host-id),
IPMODE=ip-mode[,IPPROFILENAME=ip-profile-name]
[,IP=ip-address][,IPPREFIXLENGTH=ip-prefix-length][,PPPOEUSER=pppoe-user]
[,PPPOEPWD=pppoe-pwd][,ONUIDENTIFIER=onu-identifier];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional
Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one
between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one
between DID and
DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used to
identify the ONU while
DID or DNAME indicates
the OLT device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required Under
Certain Condi-
tions:Must choose
one between OID
and ONUPRO-
FILENAME
7-66
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Command Parameter
Parameter
Name
Type Value Range Description Optional
Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile NAME Required Under Cer-
tain Conditions:Must
choose one between
OID and ONUPRO-
FILENAME
VLANPRO-
FILENAME
String SIZE(1-64) VLAN Profile Name Required
IPHOSTID Integer 1-255 IP Host ID Required
Under Certain
Conditions:Must
choose one between
IPHOSTID and
IPV6HOSTID
IPV6HOSTID Integer 1-255 IPv6 Host ID Required
Under Certain
Conditions:Must
choose one between
IPHOSTID and
IPV6HOSTID
IPMODE String Static
PPPoE
DHCP
IP Allocation Mode
Static: Static IP
PPPoE: PPPoE
DHCP: DHCP
Required
IPPROFILE-
NAME
String SIZE(1-64) IP Profile Name Optional:
Required when
IPMODE is Static
IP String IpAddress IP Address
Valid when IPMODE is
Static
Optional:
Required when
IPMODE is Static
IPPRE-
FIXLENGTH
Integer 0–128 IP Address Prefix
Length
Valid when IPMODE is
Static
Optional:
Required when
IPMODE is Static
PPPOEUSER String SIZE(1-128) PPPoE User Name
Valid when IPMODE is
PPPoE
Optional:
Required when
IPMODE is PPPoE
7-67
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
PPPOEPWD String SIZE(0-25) PPPoE Password
Valid when IPMODE is
PPPoE
Optional:
Required when
IPMODE is PPPoE
ONUIDENTI-
FIER
String SIZE(0-25) ONU Identifier
Valid when IPMODE is
DHCP
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONUVOIPIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::
VLANPROFILENAME=vlanProfile,IPHOSTID=1,IPMODE=Static,
IPPROFILENAME=ipProfile,IP=10.63.204.220,IPPREFIXLENGTH=24;
Response:
ZTE-SH10083644D01 2014-10-21 10:41:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure the ONU VoIP IP information of Rack1/
Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IP allocation mode is static IP.
Command 2:
CHG-ONUVOIPIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::
VLANPROFILENAME=vlanProfile,IPHOSTID=1,IPMODE=PPPoE,
PPPOEUSER=zte,PPPOEPWD=zte123;
Response:
ZTE-SH10083644D01 2014-10-21 10:41:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
7-68
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Remark:
This command is used to configure the ONU VoIP IP information of Rack1/
Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IP allocation mode is PPPoE.
Command 3:
CHG-ONUVOIPIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::
VLANPROFILENAME=vlanProfile,IPHOSTID=1,IPMODE=DHCP;
Response:
ZTE-SH10083644D01 2014-10-21 10:41:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure the ONU VoIP IP information of Rack1/
Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IP allocation mode is DHCP.
Command 4:
CHG-ONUVOIPIP::DID=10.63.156.26:CTAG::ONUPROFILENAME=remote-profile,
VLANPROFILENAME=vlanProfile,IPHOSTID=1,IPMODE=Static,IPPROFILENAME=
ipProfile,IP=10.63.204.220,IPPREFIXLENGTH=24;
Response:
ZTE-SH10083644D01 2017-04-21 10:41:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to modify VoIP IP of ONU profile remote-profile on NE
10.63.156.26.
Command 5:
CHG-ONUVOIPIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::
VLANPROFILENAME=vlanProfile,IPMODE=DHCP,IPV6HOSTID=1;
Response:
ZTE-SH10083644D01 2018-08-28 10:41:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
7-69
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
This command is used to configure the ONU VoIP IPinformation of Rack1/
Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, IP allocation mode is DHCP and IPv6
Host ID is 1.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-10-30 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-4-27 New Command
Parameters：
ONUPROFILENAME
NetNumenU31R20V12.18.20T140 2018-8-28 New Command
Parameters：IPV6HOSTID
7.1.17 DLT-ONUVOIPIP【【【Delete ONU VoIP IP Configuration】】】
l Description
This command is used to delete GPON ONU VoIP configuration inforamtion.
l Applicable NE
NE Category NE Type Not-
es
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
DLT-ONUVOIPIP::(DID=device-ID|DNAME=device-name)[,PID=port-id][,OID=onu-id]:CTAG::
[ONUPROFILENAME=onu-profile-name];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-70
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value
Range
Description Optional Description
ONUPRO-
FILENAME
String SIZE(1-
64)
ONU Profile
Name
Required Under Certain
Conditions:Must choose one between
OID and ONUPROFILENAME
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
DLT-ONUVOIPIP::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::;
Response：
7-71
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
ZTE-SH10083644D01 2014-03-18 10:41:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete GPON ONU VoIP IP configuration information from
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.204.51.
Command 2:
DLT-ONUVOIPIP::DID=10.63.204.51:CTAG::ONUPROFILENAME=remote-profile;
Response：
ZTE-SH10083644D01 2017-04-25 10:41:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete GPON ONU VoIP IP configuration information from
ONU profile remote-profile on NE 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-10-30 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-4-25 New Command Parameters:
ONUPROFILENAME
7.1.18 CRT-ONUSIPUSER【【【Create ONU SIP User】】】
l Description
This command is used to create ONU SIP user information.
l Applicable NE
7-72
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series/C600
Series
MSAN C300Mv4 Series
l Command Format
CRT-ONUSIPUSER::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id,ONUPORT=onu-port:CTAG::USERPHONE=user-phone,
[SIPPROFILENAME=sip-profile-name][,USERNAME=user-name][,
AUTHUSERNAME=auth-user-name][,AUTHPASSWORD=auth-password][,
MEDIAPROFILENAME=media-profile-name];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
ONUPORT String [rack-][shelf-][slo-
t-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
7-73
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Parameter
Name
Type Value Range Description Optional Description
USER-
PHONE
String SIZE(1-128) User Phone Number Required
SIPPRO-
FILENAME
String SIZE(1-64) SIP Profile Name
Only support GPON. It
is required for GPON.
Optional
USER-
NAME
String SIZE(1-25) User Name Optional
AU-
THUSER-
NAME
String SIZE(1-50) User Authentication
Name
Optional
AUTH-
PASS-
WORD
String SIZE(0-25) User Authentication
Password
Optional
MEDI-
APROFILE-
NAME
String SIZE(1-64) Media Profile Name
Only support GPON.
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONUSIPUSER::DID=10.63.204.51,OID=1-1-5-7-1,ONUPORT=1:CTAG::
USERPHONE=12354678,SIPPROFILENAME=testSipProfile,USERNAME=sip001,
AUTHUSERNAME=uer1,AUTHPASSWORD=aa;
Response:
0 2013-08-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
7-74
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
This command is used to create the ONU SIP user of Rack1/
Shelf1/Slot5/Port7/ONU1/POTS1 on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-09-11 New TL1 Command
7.1.19 DLT-ONUSIPUSER【【【Delete ONU SIP User】】】
l Description
This command is used to delete ONU SIP user information.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series/C600
Series
MSAN C300Mv4 Series
l Command Format
DLT-ONUSIPUSER::(DID=device-id|DNAME=device-name)[,PID=port-id],OID=onu-id,
ONUPORT=onu-port:CTAG::;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
7-75
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
ONUPORT String [rack-][shelf-][slo-
t-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
None.
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
DLT-ONUSIPUSER::DID=10.63.204.51,OID=1-1-5-7-1,ONUPORT=1:CTAG::;
Response::
0 2013-08-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
7-76
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Remark:
This command is used to delete the ONU SIP user of Rack1/
Shelf1/Slot5/Port7/ONU1/POTS1 on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-09-11 New TL1 Command
7.1.20 CHG-ONU-STAT-PON【【【ChangeONU Administrative
Status】】】
l Description
This command is used to change ONU administrative status.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.1/C220v1.2/C300 Series/C300v2 Series/C300v3
Series/C600 Series
l Command Format
CHG-ONU-STAT-PON::(DID=device-ID|DNAME=device-name),OID=onu-ID:
CTAG::STATUS=adminstatus;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(0-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
7-77
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DNAME String SIZE(0-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter Name Type Value Range Description
STATUS Integer 1–Enable
2–Disable
ONU Administrative Status
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF、IIPE、EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONU-STAT-PON::DID=10.46.41.14,OID=1-1-8-1-1:CTAG::STATUS=Enable;
应答：
NETSH180492D1 2012-07-04 16:54:48
M 5 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to enable administrative status of
Rack1/Shelf1/Slot8/Port1/ONU1 on 10.46.41.14.
l Average Command Response Time
7-78
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T70 2014–02–20
7.1.21 RST-ONU-PON【【【Restart ONU】】】
l Description
This command is used to restart the specified ONU.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2
Series/C300v3 Series/C600 Series
Support EPON and GPON
l Command Format
RST-ONU-PON::(DID=device-ID|DNAME=device-name) ,OID=onu-id:CTAG::;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
7-79
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command:
RST-ONU-PON::DID=10.46.41.14,OID=1-1-6-1-1:CTAG001::;
Response：
XUZHILU 2012-02-10 16:38:06
M Ctag001 COMPLD
EN=0 ENDESC=No Error;
Remark:
This command is used to restart Rack1/Shelf1/Slot6/Port1/ONU1 onOLT 10.46.41.14.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
7-80
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
7.1.22 ACT-LANPORT【【【Activate LAN Port】】】
l Description
This command is used for activating the LAN port.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3
Series/C600 Series
PON ONU F820/LAN-MDU Series/xDSL-MDU Series/FTTH
ONU
l Command Format
ACT-LANPORT::ONUIP=onu-name|OLTID=olt-name[,PONID=ponport_location,
ONUIDTYPE=onuid-type,ONUID=onu-index],ONUPORT=onu-port:CTAG::;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
ONUIP String SIZE(128) IP address, name, or
ID of the ONU that has
management IP
Required
Under Certain
Conditions:Must
choose one between
ONUIP and OLTID
OLTID String SIZE(128) OLT IP address, name,
or ID
Required
Under Certain
Conditions:Must
choose one between
ONUIP and OLTID
PONID String SIZE(128)
Rack–Shelf–Slot-
–PON Port
To locate a PON port by
Rack-Shelf-Slot-PON
Port ID. Type NA
when this parameter is
absent.
Optional:PONID
ONUIDTYPE and
ONUID must choose at
the same time
ONUID-
TYPE
String SIZE(128) ONU identifier type
(ONU_NAME, MAC,
LOID, ONU_NUMBER)
Optional:PONID
ONUIDTYPE and
ONUID must choose at
the same time
7-81
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
ONUID String SIZE(128) ONU identifier. The
value could be chosen
from ONU_NAME,
MAC, LOID and
ONU_NUMBER to
uniquely identify an
ONU on the PON port.
Optional:PONID
ONUIDTYPE and
ONUID must choose at
the same time
ONUPORT String SIZE(128)
Rack-Shelf-Slot-
ONU Port ID
To locate an
ONU port by
Rack-Shelf-Slot-ONU
Port ID. Type NA
when this parameter is
absent.
Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
None.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Modifier Notes
7.1.23 DACT-LANPORT【【【Deactivate LAN Port】】】
l Description
7-82
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
This command is used for deactivating the LAN port.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3
Series/C600 Series
PON ONU F820/LAN-MDU Series/xDSL-MDU Series/FTTH
ONU
l Command Format
DACT-LANPORT::ONUIP=onu-name|OLTID=olt-name[,PONID=ponport_location,ONUIDTYPE=onuid-type,ONUID=onu-index],ONUPORT=onu-port:CTAG::;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
ONUIP String SIZE(128) IP address, name, or
ID of the ONU that has
management IP
Required
Under Certain
Conditions:Must
choose one between
ONUIP and OLTID
OLTID String SIZE(128) OLT IP address, name,
or ID
Required
Under Certain
Conditions:Must
choose one between
ONUIP and OLTID
PONID String SIZE(128)
Rack–Shelf–Slot-
–PON Port
To locate a PON port by
Rack-Shelf-Slot-PON
Port ID. Type NA
when this parameter is
absent.
Optional:PONID
ONUIDTYPE and
ONUID must choose at
the same time
ONUID-
TYPE
String SIZE(128) ONU identifier type
(ONU_NAME, MAC,
LOID, ONU_NUMBER)
Optional:PONID
ONUIDTYPE and
ONUID must choose at
the same time
ONUID String SIZE(128) ONU identifier. The
value could be chosen
from ONU_NAME,
MAC, LOID and
ONU_NUMBER to
uniquely identify an
ONU on the PON port.
Optional:PONID
ONUIDTYPE and
ONUID must choose at
the same time
7-83
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
ONUPORT String SIZE(128)
Rack-Shelf-Slot-
ONU Port ID
To locate an
ONU port by
Rack-Shelf-Slot-ONU
Port ID. Type NA
when this parameter is
absent.
Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
None.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Modifier Notes
7.1.24 ACT-VOIPPORT【【【Activate VoIP Port】】】
l Description
This command is used for activating the VoIP port.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C600 Series
7-84
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
PON ONU F820/LAN-MDU Series/xDSL-MDU Series/FTTHONU
l Command Format
ACT-VOIPPORT::ONUIP=onu-name|[OLTID=olt-name,PONID=ponport_location,
ONUIDTYPE=onuid-type,ONUID=onu-index],ONUPORT=onu-port:CTAG::;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
ONUIP String SIZE(128) IP address, name, or
ID of the ONU that has
management IP
Required Under Cer-
tain Conditions:Must
choose one between
ONUIP and (OLT-
ID,PONID,ONUID-
TYPE,ONUID)
OLTID String SIZE(128) OLT IP address, name,
or ID
Required Under Cer-
tain Conditions:Must
choose one between
ONUIP and (OLT-
ID,PONID,ONUID-
TYPE,ONUID)
PONID String SIZE(128)
Rack-Shelf-Slot-
PON Port ID
To locate a PON port by
Rack-Shelf-Slot-PON
Port ID. Type NA
when this parameter is
absent.
Required Under Cer-
tain Conditions:Must
choose one between
ONUIP and (OLT-
ID,PONID,ONUID-
TYPE,ONUID)
ONUID-
TYPE
String SIZE(128) ONU identifier type
(ONU_NAME, MAC,
LOID, ONU_NUMBER)
Required Under Cer-
tain Conditions:Must
choose one between
ONUIP and (OLT-
ID,PONID,ONUID-
TYPE,ONUID)
ONUID String SIZE(128) ONU identifier. The
value could be chosen
from ONU_NAME,
MAC, LOID and
ONU_NUMBER to
uniquely identify an
ONU on the PON port.
Required Under Cer-
tain Conditions:Must
choose one between
ONUIP and (OLT-
ID,PONID,ONUID-
TYPE,ONUID)
7-85
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
ONUPORT String SIZE(128)
Rack-Shelf-Slot-
ONU Port ID
To locate an
ONU port by
Rack-Shelf-Slot-ONU
Port ID. Type NA
when this parameter is
absent.
Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
None.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Modifier Notes
7.1.25 DACT-VOIPPORT【【【Deactivate VoIP Port】】】
l Description
This command is used for deactivating the VoIP port.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C600 Series
7-86
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
PON ONU F820/LAN-MDU Series/xDSL-MDU Series/FTTH
ONU
l Command Format
DACT-VOIPPORT::ONUIP=onu-name|[OLTID=olt-name,PONID=ponport_location,
ONUIDTYPE=onuid-type,ONUID=onu-index],ONUPORT=onu-port:CTAG::;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
ONUIP String SIZE(128) IP address, name, or
ID of the ONU that has
management IP
Required Under Cer-
tain Conditions:Must
choose one between
ONUIP and (OLT-
ID,PONID,ONUID-
TYPE,ONUID)
OLTID String SIZE(128) OLT IP address, name,
or ID
Required Under Cer-
tain Conditions:Must
choose one between
ONUIP and (OLT-
ID,PONID,ONUID-
TYPE,ONUID)
PONID String SIZE(128)
Rack-Shelf-Slot-
PON Port ID
To locate a PON port by
Rack-Shelf-Slot-PON
Port ID. Type NA
when this parameter is
absent.
Required Under Cer-
tain Conditions:Must
choose one between
ONUIP and (OLT-
ID,PONID,ONUID-
TYPE,ONUID)
ONUID-
TYPE
String SIZE(128) ONU identifier type
(ONU_NAME, MAC,
LOID, ONU_NUMBER)
Required Under Cer-
tain Conditions:Must
choose one between
ONUIP and (OLT-
ID,PONID,ONUID-
TYPE,ONUID)
ONUID String SIZE(128) ONU identifier. The
value could be chosen
from ONU_NAME,
MAC, LOID and
ONU_NUMBER to
uniquely identify an
ONU on the PON port.
Required Under Cer-
tain Conditions:Must
choose one between
ONUIP and (OLT-
ID,PONID,ONUID-
TYPE,ONUID)
7-87
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
ONUPORT String SIZE(128)
Rack-Shelf-Slot-
ONU Port ID
To locate an
ONU port by
Rack-Shelf-Slot-ONU
Port ID. Type NA
when this parameter is
absent.
Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
None.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Modifier Notes
7.1.26 CHG-ONUWANIP【【【Change WAN IP configuration】】】
l Description
This command is used to change WAN IP configuration mode when the WAN on the
ONU is routed, the IP configuration mode is consisted of Static, PPPoE, DHCP.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3
Series/C600 Series
7-88
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
MSAN C300Mv4 Series
l Command Format
CHG-ONUWANIP::(DID=device-id|DNAME=device-name)[,PID=port-id],OID=onu-id
:CTAG::(IPHOSTID=iphost-id|IPV6HOSTID=ipv6-host-id)[,IPMODE=ip-mode]
[,ONUIDENTIFIER=onu-identifier] [,IP=ip-address][,IPMASKLEN=ip-mask-length]
[,(IPPROFILENAME=ip-profile-name|IPGATEWAY=ip-gateway)][,PPPOEUSER=pppoe-user]
[,PPPOEPWD=pppoe-pwd] (,VLANPROFILENAME=vlan-profile-name|VID=vlan-id)
[,PPPOEMODE=pppoe-mode][,PPPOESERVICENAME=pppoe-service-name];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
7-89
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
IPHOSTID Integer 1-255 IP Host ID Required
Under Certain
Conditions:Must
choose one between
IPHOSTID and
IPV6HOSTID
IPV6HOSTID Integer 1-255 IPv6 Host ID Required
Under Certain
Conditions:Must
choose one between
IPHOSTID and
IPV6HOSTID
IPMODE String Static
PPPoE
DHCP
IP Configuration Mode
If not input, the default
mode will be PPPoE.
Static: Static IP
PPPoE: PPPoE
DHCP: DHCP
Optional
ONUIDENTI-
FIER
String SIZE(0-25) ONU Identifier
Valid if IPMODE is
DHCP
Optional
IP String IpAddress IP Address
Valid if IPMODE is
Static
Optional:
Required if IPMODE is
Static
IPMASKLEN Integer 1–255 IP Mask Length
Valid if IPMODE is
Static
Optional:
Required if IPMODE is
Static
IPPROFILE-
NAME
String SIZE(1-64) IP Profile Name Optional:
Required if IPMODE is
Static,
then must choose
one between
IPPROFILENAME
and IPGATEWAY.
IPGATEWAY String IpAddress IP Gateway
Valid if IPMODE is
Static
Optional:
Required if IPMODE is
Static,
then must choose
one between
IPPROFILENAME
and IPGATEWAY.
7-90
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
PP-
POEUSER
String SIZE(1-32) PPPoE User Name
Valid if IPMODE is
PPPoE
Optional:
Required if IPMODE is
PPPoE
PPPOEPWD String SIZE(1-32) PPPoE Password
Valid if IPMODE is
PPPoE
Optional:
Required if IPMODE is
PPPoE
VLANPRO-
FILENAME
String SIZE(1-64) VLAN Profile Name Required
Under Certain
Conditions:Must
choose one between
VLANPROFILENAME
and VID
VID Integer 1-4094 VLAN ID for WAN
if not input, the VID
of WAN will be not
changed
Required
Under Certain
Conditions:Must
choose one between
VLANPROFILENAME
and VID
PPPOE-
MODE
String Auto
Chap
Pap
PPPoE Mode
Valid if IPMODE is
PPPoE
If not input, the default
mode will be Auto
Optional
PPPOESER-
VICENAME
String SIZE(1-60) PPPoE Service Name
Valid if IPMODE is
PPPoE
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer toChapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONUWANIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::IPHOSTID=1,IPMODE=PPPoE,
PPPOEUSER=zte,PPPOEPWD=ztewan,VLANPROFILENAME=VLAN100;
7-91
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Response:
ZTE-SH10083644D01 2013-12-17 10:01:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure ONU WAN IP information of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IP allocation mode is PPPoE.
Command 2:
CHG-ONUWANIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::IPHOSTID=1,IPMODE=PPPoE,
PPPOEUSER=zte,PPPOEPWD=ztewan,VID=100;
Response:
ZTE-SH10083644D01 2013-12-17 10:01:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure ONU WAN IP information of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IP allocation mode is PPPoE.
Command 3:
CHG-ONUWANIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::IPHOSTID=1,IPMODE=DHCP,
VLANPROFILENAME=VLAN100;
Response:
ZTE-SH10083644D01 2013-12-17 10:01:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure ONU WAN IP information of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IP allocation mode is DHCP.
Command 4:
CHG-ONUWANIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::IPHOSTID=1,
IPMODE=DHCP,VID=100;
Response:
ZTE-SH10083644D01 2013-12-17 10:01:22
7-92
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure ONU WAN IP information of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IP allocation mode is DHCP.
Command 5:
CHG-ONUWANIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::IPHOSTID=1,IPMODE=Static,
IP=10.63.204.220,IPGATEWAY=10.63.204.254,IPMASKLEN=24,
VLANPROFILENAME=VLAN100;
Response:
ZTE-SH10083644D01 2013-12-17 10:01:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure ONU WAN IP information of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IP allocation mode is static IP.
Command 6:
CHG-ONUWANIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::IPHOSTID=1,IPMODE=Static,
IP=10.63.204.220,IPGATEWAY=10.63.204.254,IPMASKLEN=24,VID=100;
Response:
ZTE-SH10083644D01 2013-12-17 10:01:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure ONU WAN IP information of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IP allocation mode is static IP.
Command 7:
CHG-ONUWANIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::VLANPROFILENAME=VLAN100,
IPHOSTID=1,IPMODE=PPPoE,PPPOEUSER=zte,PPPOEPWD=ztewan,
PPPOESERVICENAME=servicewan;
Response:
ZTE-SH10083644D01 2017-02-27 10:41:22
7-93
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure ONU WAN IP information of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IP allocation mode is PPPoE,
PPPoE service name is servicewan.
Command 8:
CHG-ONUWANIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::IPMODE=PPPoE,
PPPOEUSER=zte,PPPOEPWD=ztewan,VLANPROFILENAME=VLAN100,IPV6HOSTID=1;
Response:
ZTE-SH10083644D01 2018-08-28 10:01:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure ONU WAN IP information of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IPv6 Host ID is 1.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.13.40T70 2014-1-8 New Command Parameters: IP-
MODE,IP,IPMASKLEN,IPGATE-
WAY,ONUIDENTIFIER
NetNumenU31R20V12.15.20T90 2015-4-28 New Command Parameters:
IPPROFILENAME,VLANPROFILENAME
7-94
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
NetNumenU31R20V12.17.20T115 2017-2-27 New Command Parameters:
PPPOESERVICENAME
NetNumenU31R20V12.18.20T140 2018-8-28 New Command Parameters:IPV6HOSTID
7.1.27 DLT-ONUWANIP【【【Delete WAN IP Configuration】】】
l Description
This command is used to delete ONU WAN IP configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C600
Series
l Command Format
DLT-ONUWANIP::(DID=device-id|DNAME=device-name)[,PID=port-id][,OID=onu-id]:CTAG::
[ONUPROFILENAME=onu-profile-name],(IPHOSTID=iphost-id|IPV6HOSTID=ipv6-host-id);
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
7-95
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile Name Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
IPHOSTID Integer 1-255 IP Host ID Required
Under Certain
Conditions:Must
choose one between
IPHOSTID and
IPV6HOSTID
IPV6HOSTID Integer 1-255 IPv6 Host ID Required
Under Certain
Conditions:Must
choose one between
IPHOSTID and
IPV6HOSTID
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
7-96
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Example
Command 1:
DLT-ONUWANIP::DID=10.63.194.46,OID=1-1-5-7-1:CTAG::IPHOSTID=2;
Response:
ZTE-SH10083644D01 2014-03-18 10:01:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete WAN IP configuration associated with IP Host 2 of
Rack1/Shelf1/Slot5/Port7/ONU1 on OLT 10.63.194.46.
Command 2:
DLT-ONUWANIP::DID=10.63.194.46:CTAG::ONUPROFILENAME=remoteProfile,
IPHOSTID=2;
Response:
ZTE-SH10083644D01 2017-05-18 10:01:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete GPON ONU WAN IP configuration information from
ONU profile remoteProfile on NE 10.63.194.46.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.13.40T70 2014-3-20 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-5-25 New Command Parameters:
ONUPROFILENAME
7-97
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
NetNumenU31R20V12.18.20T140 2018-8-28 New Command Parameters：
IPV6HOSTID
7.1.28 CHG-ONUWAN【【【Change WAN configuration】】】
l Description
This command is used to change WAN configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C600 Series
l Command Format
CHG-ONUWAN::(DID=device-id|DNAME=device-name)[,PID=port-id],OID=onu-id
:CTAG::WANID=wan-id[,IPHOSTID=iphost-id|IPV6HOSTID=ipv6-host-id],SERVICETYPE=
service-type[,UNILIST=uni-list][,SSIDLIST=ssid-list][,MVLAN=mvlan-id];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
7-98
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
WANID Integer 1-255 WAN ID Required
IPHOSTID Integer 1-255 IP Host ID
if not input, WAN is
bridged
Optional
Required
Under Certain
Conditions:Must
choose one between
IPHOSTID and
IPV6HOSTID if WAN is
routed
IPV6HOSTID Integer 1-255 IPv6 Host ID
if not input, WAN is
bridged
Optional
Required
Under Certain
Conditions:Must
choose one between
IPHOSTID and
IPV6HOSTID if WAN is
routed
SERVICE-
TYPE
String Internet
TR069
VoIP
Other
Service Type
Support multiple
choices. The type
should be separated by
a left slash if multiple
ones are selected
e.g. Inter-
net/TR069/VoIP
Required
UNILIST String SIZE(0-100) Associated UNIs
if not input, WAN does
not associate with any
UNI ports.
Support multiple
choices. The UNI port
should be separated by
a left slash if multiple
ones are selected
e.g. 1/2/3/5
Optional
7-99
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
SSIDLIST String SIZE(0-100) Associated SSIDs
if not input, WAN does
not associate with any
SSIDs.
Support multiple
choices. The SSID
should be separated by
a left slash if multiple
ones are selected
e.g. 1/2/3/5
Optional
MVLAN Integer 1–4094 MVLAN Optional
Required if
SERVICETYPE
contains ‘Other’
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONUWAN::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::WANID=1,IPHOSTID=1,
SERVICETYPE=Internet;
Response:
ZTE-SH10083644D01 2013-12-17 10:41:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure routed WAN 1 in Port1 of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and set associated IP Host to IP
Host 1, set service type to Internet. This WAN does not associate with any SSIDs or
UNI ports.
Command 2:
CHG-ONUWAN::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::WANID=1,SERVICETYPE=Internet,
7-100
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
UNILIST=1/2,SSIDLIST=1;
Response:
ZTE-SH10083644D01 2013-12-17 10:41:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure bridged WAN 1 in Port1 of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, set service type to Internet. This
WAN associates with SSID 1 and UNI port 1,2.
Command 3:
CHG-ONUWAN::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::WANID=1,SERVICETYPE=Internet,IPV6HOSTID=1;
Response:
ZTE-SH10083644D01 2018-08-28 10:41:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure routed WAN 1 in Port1 of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, set service type to Internet and
set associated IP Host to IPv6 Host1. This WAN does not associate with any SSIDs
or UNI ports.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.13.40T70 2014-1-8 New TL1 Command
NetNumenU31R20V12.18.20T140 2018-8-28 New Command Parameters:
IPV6HOSTID
7-101
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
7.1.29 DLT-ONUWAN【【【Delete WAN configuration】】】
l Description
This command is used to delete WAN configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C600 Series
l Command Format
DLT-ONUWAN::(DID=device-id|DNAME=device-name)[,PID=port-id],OID=onu-id:
CTAG::WANID=wan-id;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
WANID Integer 1-255 WAN ID Required
7-102
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
DLT-ONUWAN::DID=10.63.194.46,OID=1-1-5-7-1:CTAG::WANID=1;
Response：
ZTE-SH10083644D01 2014-03-18 10:41:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete WAN 1 configuration of
Rack1/Shelf1/Slot5/Port7/ONU1 on OLT 10.63.194.46.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.13.40T70 2014-03-20 New TL1 Command
7.1.30 CRT-ONU-GEMPORT【【【Create ONU GEM Port】】】
l Description
This command is used to create an ONU GEM port.
l Applicable NE
7-103
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series/C600 Series
l Command Format
CRT-ONU-GEMPORT::(DID=device-id|DNAME=device-name)[,PID=port-id][,
OID=onu-id]:CTAG::[ONUPROFILENAME=onu-profile-name],ONUGEMPORTID=onu-gemport-id,
TCONTID=tcont-id[,GEMPORTNAME=gemport-name][,ADMINSTAT=administrative-status]
[,GEMPORTID=gemport-id]
[,TCONTQUEUE=tcont-queue][,USTRAFFICPROFILENAME=upstream-traffic-profile-name]
[,DSTRAFFICPROFILENAME=downstream-traffic-profile-name];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
7-104
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile NAME Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
ONUGEM-
PORTID
Integer 1-255 ONU GEM Port ID Required
TCONTID Integer 1-255 T-CONT ID Required
GEMPORT-
NAME
String SIZE(1-64) GEM Port NAME Optional
ADMIN-
STAT
String Enable
Disable
Administrative Status Optional
GEMPOR-
TID
Integer 129-4095 Port-ID of GEM Port Optional
TCON-
TQUEUE
Integer 0-7 T-CONT Queue Optional
USTRAF-
FICPRO-
FILENAME
String SIZE(1-64) UpstreamTraffic Profile
Name
Optional
DSTRAF-
FICPRO-
FILENAME
String SIZE(1-64) Downstream Traffic
Profile Name
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONU-GEMPORT::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::ONUGEMPORTID=1,
TCONTID=1,USTRAFFICPROFILENAME=5M,DSTRAFFICPROFILENAME=10M;
Response:
0 2015-05-20 10:55:49
M CTAG COMPLD
7-105
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manualfor TL1
EN=0 ENDESC=No Error
;
Remark:
This command is used to create the ONU GEM port of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.204.51.
Command 2:
CRT-ONU-GEMPORT::DID=10.63.204.51:CTAG::ONUPROFILENAME=line-profile,
ONUGEMPORTID=1,TCONTID=1,USTRAFFICPROFILENAME=5M,
DSTRAFFICPROFILENAME=10M;
Response:
0 2017-04-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create a GEM port of ONU profile line-profile on NE
10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T90 2015-6-16 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-4-27 New Command
Parameters：
ONUPROFILENAME
7.1.31 DLT-ONU-GEMPORT【【【Delete ONU GEM Port】】】
l Description
This command is used to delete an ONU GEM port.
7-106
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series/C600
Series
MSAN C300Mv4 Series
l Command Format
DLT-ONU-GEMPORT::(DID=device-id|DNAME=device-name)[,PID=port-id][,OID=onu-id]
:CTAG::[ONUPROFILENAME=onu-profile-name,]ONUGEMPORTID=onu-gemport-id;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
7-107
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile
Name
Required Under Certain
Conditions:Must choose
one between OID and
ONUPROFILENAME
ONUGEM-
PORTID
Integer 1-255 ONU GEM Port
ID
Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
DLT-ONU-GEMPORT::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::ONUGEMPORTID=1;
Response:
0 2015-05-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete the ONU GEM port of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.204.51.
Command 2:
DLT-ONU-GEMPORT::DID=10.63.204.51:CTAG::ONUPROFILENAME=line-profile,
ONUGEMPORTID=1;
Response:
0 2017-04-25 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
7-108
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
This command is used to delete a GEM port from ONU profile line-profile on NE
10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T110 2016-10-31 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-4-25 New Command Parameters：
ONUPROFILENAME
7.1.32 CRT-ONU-MVLAN【【【Create ONU MVLAN】】】
l Description
This command is used to create an ONU MVLAN.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
l Command Format
CRT-ONU-MVLAN::(DID=device-id|DNAME=device-name)[,PID=port-id][,
OID=onu-id]:CTAG::[ONUPROFILENAME=onu-profile-name],MVLAN=mvlan;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
7-109
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile NAME Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
MVLAN Integer 1-4094 MVLAN Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONU-MVLAN::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::MVLAN=100;
Response:
0 2015-05-20 10:55:49
7-110
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create a MVLAN of Rack1/Shelf1/Slot5/Port7/ONU1 on
10.63.204.51.
Command 2:
CRT-ONU-MVLAN::DID=10.63.204.51:CTAG::ONUPROFILENAME=remote-profile,
MVLAN=100;
Response:
0 2017-04-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create an MVLAN of ONU profile remote-profile on NE
10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T95 2015-10-19 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-4-27 New Command
Parameters：
ONUPROFILENAME
7.1.33 DLT-ONU-MVLAN【【【Delete ONU MVLAN】】】
l Description
This command is used to delete an ONU MVLAN.
7-111
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600
Series
MSAN C300Mv4 Series
l Command Format
DLT-ONU-MVLAN::(DID=device-id|DNAME=device-name)[,PID=port-id][,OID=onu-id]:CTAG::
[ONUPROFILENAME=onu-profile-name,]MVLAN=mvlan;
l Operated Target Identifier
Parame-
ter Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under Certain
Conditions:Must choose one
between DID and DNAME
DNAME String SIZE(1-32) NE Name Required Under Certain
Conditions:Must choose one
between DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g.
1-1-5-2)
Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the
ONU while DID or
DNAME indicates
the OLT device.
(e.g. 1-1-1-2-1
00-18-FE-7C-
64-E4
ZTEG54998768)
Required Under Certain
Conditions:Must choose
one between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value
Range
Description Optional Description
7-112
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile
Name
Required Under Certain
Conditions:Must choose
one between OID and
ONUPROFILENAME
MVLAN Inte-
ger
1-4094 MVLAN Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, IDNE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
DLT-ONU-MVLAN::DID=10.63.204.233,OID=1-1-5-7-1:CTAG:::MVLAN=100;
Response:
0 2016-05-06 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete a MVLAN of Rack1/Shelf1/Slot5/Port7/ONU1 on
10.63.204.233.
Command 2:
DLT-ONU-MVLAN::DID=10.63.204.233:CTAG:::ONUPROFILENAME=remote-profile,MVLAN=100;
Response:
02017-04-25 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete a MVLAN 100 from ONU profile remote-profile on NE
10.63.204.233.
7-113
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T105 2016-5-19 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-4-25 New Command Parameters：
ONUPROFILENAME
7.1.34 CRT-ONU-PPPOE【【【Create ONU PPPoE】】】
l Description
This command is used to create ONU PPPoE configuration information.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
l Command Format
CRT-ONU-PPPOE::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id:CTAG::IPHOSTID=iphost-id[,NATENABLE=nat-enable][,
PPPOEMODE=pppoe-mode][,CONNECTTYPE=connection-type]
[,RELEASETIME=release-time],USERNAME=user-name,PASSWORD=password;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
7-114
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
IPHOSTID Integer 1-255 IP Host ID Required
NATEN-
ABLE
String Enable
Disable
NAT Enabling Optional
PPPOE-
MODE
String Auto
Chap
Pap
PPPoE Mode Optional
CONNECT-
TYPE
String Always
OnDemand
Manual
Connection Type Optional
RELEASE-
TIME
Integer 1–65535 Release Time
(Seconds)
Optional
USER-
NAME
String SIZE(1-128) PPPoE User Name Required
PASS-
WORD
String SIZE(1-25) PPPoE Password Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
7-115
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONU-PPPOE::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::IPHOSTID=1,
NATENABLE=Enable,PPPOEMODE=Auto,USERNAME=guest, PASSWORD=pwd;
Response:
0 2015-05-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create the ONU PPPoE information of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T100 2015-10-27 New TL1 Command
7.1.35 CRT-ONU-SERVICE【【【Create ONU Service】】】
l Description
This command is used to create an ONU service.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
l Command Format
7-116
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
CRT-ONU-SERVICE::(DID=device-id|DNAME=device-name)[,PID=port-id][,
OID=onu-id]:CTAG::[ONUPROFILENAME=onu-profile-name],SERVICENAME=service-name,
ONUGEMPORTID=gemport-id,MAPPINGTYPE=mapping-type[,COS=cos][,VID=vlan-id]
[,ONUPORT=onu-port];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile NAME Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
SERVICE-
NAME
String SIZE(1-64) Service Name Required
ONUGEM-
PORTID
Integer 1-255 ONU GemPort ID Required
7-117
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
MAPPING-
TYPE
String VLAN
CoS
CoSAndVLAN
Transparent
Untag
Mapping Type Required
COS String SIZE(1-32) CoS Priority(0-7).
CoS1/CoS2/CoS4-
CoS6/...（e.g. 1/4/6
1/3-5/7)
Required Under
Certain Conditions:
Mapping Type is CoS
or
CoSAndVLAN
VID String SIZE(1-255) VLAN ID(1-4094).
VID1/VID2/VID3-
VID9/...（e.g.
100/105/106
100/102-105/120)
Required Under
Certain Conditions:
Mapping Type is VLAN
or
CoSAndVLAN
ONUPORT String [rack-][shelf-][slo-
t-]port
Ethernet Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONU-SERVICE::DID=10.63.204.233,OID=1-1-5-7-1:CTAG::
SERVICENAME=service,ONUGEMPORTID=1,MAPPINGTYPE=VLAN,VID=100;
Response:
0 2015-06-06 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
7-118
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
This command is used to create ONU service of Rack1/ Shelf1/Slot5/Port7/ONU1 on
10.63.204.233.
Command 2:
CRT-ONU-SERVICE::DID=10.63.204.233,OID=1-1-5-7-1:CTAG::
SERVICENAME=service,ONUGEMPORTID=1,MAPPINGTYPE=VLAN,VID=100/102-104/120;
Response:
0 2015-06-06 10:56:23
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create ONU service of Rack1/ Shelf1/Slot5/Port7/ONU1 on
10.63.204.233.
Command 3:
CRT-ONU-SERVICE::DID=10.63.204.233,OID=1-1-5-7-1:CTAG::
SERVICENAME=service,ONUGEMPORTID=1,MAPPINGTYPE=VLAN,VID=100,ONUPORT=1;
Response:
0 2016-11-28 10:56:23
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create ONU service of Rack1/ Shelf1/Slot5/Port7/ONU1 on
10.63.204.233.
Command 4:
CRT-ONU-SERVICE::DID=10.63.204.233:CTAG::ONUPROFILENAME=remote-profile,
SERVICENAME=service,ONUGEMPORTID=1,MAPPINGTYPE=VLAN,VID=100;
Response:
0 2017-04-06 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create a service of ONU profile remote-profile on NE
10.63.204.233.
7-119
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T90 2015-6-9 New TL1 Command
NetNumenU31R20V12.17.20T115 2016-11-28 New Command Parameters：
ONUPORT
NetNumenU31R20V12.17.20T120 2017-4-27 New Command Parameters：
ONUPROFILENAME
7.1.36 DLT-ONU-SERVICE【【【Delete ONU Service】】】
l Description
This command is used to delete an ONU service.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
DLT-ONU-SERVICE::(DID=device-id|DNAME=device-name)[,PID=port-id]
[,OID=onu-id]:CTAG::[ONUPROFILENAME=onu-profile-name,]SERVICENAME=service-name;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional
Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
7-120
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command DescriptionDNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile
Name
Required Under Certain
Conditions:Must choose
one between OID and
ONUPROFILENAME
SERVICE-
NAME
Octet String SIZE(1-64) Service Name Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
DLT-ONU-SERVICE::DID=10.63.204.233,OID=1-1-5-7-1:CTAG::SERVICENAME=iptvService;
Response:
0 2016-09-06 10:55:49
M CTAG COMPLD
7-121
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete an ONU service of Rack1/ Shelf1/Slot5/Port7/ONU1
on 10.63.204.233.
Command 2:
DLT-ONU-SERVICE::DID=10.63.204.233:CTAG::ONUPROFILENAME=remote-profile,SERVICENAME=iptvService;
Response:
0 2017-04-25 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete an ONU service from ONU profile remote-profile on
NE 10.63.204.233.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T110 2016-9-28 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-4-25 New Command Parameters:
ONUPROFILENAME
7.1.37 CRT-ONU-STATICROUTE【【【Create ONU Static Route】】】
l Description
This command is used to create an ONU static route.
l Applicable NE
NE Category NE Type Notes
7-122
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
PON OLT C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
CRT-ONU-STATICROUTE::(DID=device-id|DNAME=device-name)[,PID=port-id]
[,OID=onu-id]:CTAG::[ONUPROFILENAME=onu-profile-name],DESTIPADDRESS=
destination-ip-address,DESTIPMASK=destination-ip-mask,NEXTHOPIPADDRESS=
next-hop-ip-address [,OUTPUTPORT=output-port];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional
Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one
between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one
between DID and
DNAME
PID String rack-shelf-slot-
por
Port ID (e.g.
1-1-5-2)
Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pas-
sword
ONU ID. It's used
to identify the
ONU while DID or
DNAME indicates
the OLT device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required Under
Certain Condi-
tions:Must choose
one between OID
and ONUPROFILE-
NAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional
Description
7-123
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
ONUPROFILE-
NAME
String SIZE(1-64) ONU Profile Name Required Under
Certain Condi-
tions:Must choose
one between OID
and ONUPROFILE-
NAME
DESTIPAD-
DRESS
IpAddress Destination IP
Address
Required
DESTIPMASK IpAddress Destination IP
Address Mask
Required
NEXTHOPIPAD
DRESS
IpAddress Next Hop IP
Address
Required
OUTPUTPORT Integer 1–255 Output Port Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONU-STATICROUTE::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::
DESTIPADDRESS=100.200.7.0,DESTIPMASK=255.255.255.0,
NEXTHOPIPADDRESS=192.168.4.1, OUTPUTPORT=10;
Response:
0 2015-05-17 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create an ONU static route of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.204.51.
Command 2:
7-124
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
CRT-ONU-STATICROUTE::DID=10.63.204.51:CTAG::ONUPROFILENAME=remote-profile,
DESTIPADDRESS=100.200.7.0,DESTIPMASK=255.255.255.0,
NEXTHOPIPADDRESS=192.168.4.1, OUTPUTPORT=10;
Response:
0 2017-05-17 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create a static route of ONU profile remote-profile on NE
10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T95 2015-10-22 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-5-17 New Command
Parameters：
ONUPROFILENAME
7.1.38 CRT-ONU-TCONT【【【Create ONU T-CONT】】】
l Description
This command is used to create an ONU T-CONT.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
l Command Format
7-125
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
CRT-ONU-TCONT::(DID=device-id|DNAME=device-name)[,PID=port-id]
[,OID=onu-id]:CTAG::[ONUPROFILENAME=onu-profile-name],
TCONTID=tcont-id[,TCONTNAME=tcont-name][,
BANDWIDTHPROFILENAME=bandwidth-profile-name] [,ALLOCID=alloc-id];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile NAME Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
TCONTID Integer 1-255 T-CONT ID Required
TCONT-
NAME
String SIZE(1-64) T-CONT NAME Optional
7-126
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
BAND-
WIDTH-
PROFILE-
NAME
String SIZE(1-64) T-CONT Bandwidth
Profile Name
Optional
ALLOCID Integer 256-4095 T-CONT Allocation ID Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONU-TCONT::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::TCONTID=1,
BANDWIDTHPROFILENAME=5M;
Response:
0 2015-05-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create the ONU T-CONT of Rack1/Shelf1/Slot5/Port7/ONU1
on 10.63.204.51.
Command 2:
CRT-ONU-TCONT::DID=10.63.204.51:CTAG::ONUPROFILENAME=line-profile,TCONTID=1,
BANDWIDTHPROFILENAME=5M;
Response:
0 2017-05-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create a T-CONT of ONU profile line-profile on NE
10.63.204.51.
7-127
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T90 2015-06-03 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-4-27 New Command
Parameters：
ONUPROFILENAME
7.1.39DLT-ONU-TCONT【【【Delete ONU T-CONT】】】
l Description
This command is used to delete an ONU T-CONT.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
DLT-ONU-TCONT::(DID=device-id|DNAME=device-name)[,PID=port-id]
[,OID=onu-id]:CTAG::[ONUPROFILENAME=onu-profile-name,]TCONTID=tcont-id;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
7-128
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DNAME String SIZE(1-32) NE Name Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile Name Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
TCONTID Integer 1-255 T-CONT ID Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
DLT-ONU-TCONT::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::TCONTID=1;
Response:
0 2016-10-31 10:55:49
7-129
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete the ONU T-CONT of
Rack1/Shelf1/Slot5/Port7/ONU1/TCONT1 on 10.63.204.51.
Command 2:
DLT-ONU-TCONT::DID=10.63.204.51:CTAG::ONUPROFILENAME=line-profile,TCONTID=1;
Response:
0 2017-04-25 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete a T-CONT from ONU profile line-profile on NE
10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T110 2016-10-31 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-4-25 New Command Parameters：
ONUPROFILENAME
7.1.40 CRT-ONU-GEMPORT【【【Create ONU GEM Port】】】
l Description
This command is used to create an ONU GEM port.
l Applicable NE
7-130
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series/C600 Series
l Command Format
CRT-ONU-GEMPORT::(DID=device-id|DNAME=device-name)[,PID=port-id][,
OID=onu-id]:CTAG::[ONUPROFILENAME=onu-profile-name],ONUGEMPORTID=onu-gemport-id,
TCONTID=tcont-id[,GEMPORTNAME=gemport-name][,ADMINSTAT=administrative-status]
[,GEMPORTID=gemport-id]
[,TCONTQUEUE=tcont-queue][,USTRAFFICPROFILENAME=upstream-traffic-profile-name]
[,DSTRAFFICPROFILENAME=downstream-traffic-profile-name];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
7-131
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile NAME Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
ONUGEM-
PORTID
Integer 1-255 ONU GEM Port ID Required
TCONTID Integer 1-255 T-CONT ID Required
GEMPORT-
NAME
String SIZE(1-64) GEM Port NAME Optional
ADMIN-
STAT
String Enable
Disable
Administrative Status Optional
GEMPOR-
TID
Integer 129-4095 Port-ID of GEM Port Optional
TCON-
TQUEUE
Integer 0-7 T-CONT Queue Optional
USTRAF-
FICPRO-
FILENAME
String SIZE(1-64) UpstreamTraffic Profile
Name
Optional
DSTRAF-
FICPRO-
FILENAME
String SIZE(1-64) Downstream Traffic
Profile Name
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONU-GEMPORT::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::ONUGEMPORTID=1,
TCONTID=1,USTRAFFICPROFILENAME=5M,DSTRAFFICPROFILENAME=10M;
Response:
0 2015-05-20 10:55:49
M CTAG COMPLD
7-132
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
EN=0 ENDESC=No Error
;
Remark:
This command is used to create the ONU GEM port of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.204.51.
Command 2:
CRT-ONU-GEMPORT::DID=10.63.204.51:CTAG::ONUPROFILENAME=line-profile,
ONUGEMPORTID=1,TCONTID=1,USTRAFFICPROFILENAME=5M,
DSTRAFFICPROFILENAME=10M;
Response:
0 2017-04-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create a GEM port of ONU profile line-profile on NE
10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T90 2015-6-16 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-4-27 New Command
Parameters：
ONUPROFILENAME
7.1.41 DLT-ONU-GEMPORT【【【Delete ONU GEM Port】】】
l Description
This command is used to delete an ONU GEM port.
7-133
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series/C600
Series
MSAN C300Mv4 Series
l Command Format
DLT-ONU-GEMPORT::(DID=device-id|DNAME=device-name)[,PID=port-id][,OID=onu-id]
:CTAG::[ONUPROFILENAME=onu-profile-name,]ONUGEMPORTID=onu-gemport-id;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
7-134
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile
Name
Required Under Certain
Conditions:Must choose
one between OID and
ONUPROFILENAME
ONUGEM-
PORTID
Integer 1-255 ONU GEM Port
ID
Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
DLT-ONU-GEMPORT::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::ONUGEMPORTID=1;
Response:
0 2015-05-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete the ONU GEM port of
Rack1/Shelf1/Slot5/Port7/ONU1on 10.63.204.51.
Command 2:
DLT-ONU-GEMPORT::DID=10.63.204.51:CTAG::ONUPROFILENAME=line-profile,
ONUGEMPORTID=1;
Response:
0 2017-04-25 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
7-135
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
This command is used to delete a GEM port from ONU profile line-profile on NE
10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T110 2016-10-31 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-4-25 New Command Parameters：
ONUPROFILENAME
7.1.42 CRT-ONU-VPORTGEMPORTMAPPING【【【Create ONU VPort
and GEM Port Mapping】】】
l Description
This command is used to create a mapping between ONU VPort and GEM port.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
l Command Format
CRT-ONU-VPORTGEMPORTMAPPING::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id:CTAG::VPORTID=vport-id,ONUGEMPORTID=gemport-id[,COS=cos][,VID=vlan-id];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-136
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
VPORTID Integer 1-256 VPort ID Required
ONUGEM-
PORTID
Integer 1-255 ONU GEM Port ID Required
COS Integer 0-7 CoS Optional
VID Integer 1-4094 VLAN ID Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
7-137
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
CRT-ONU-VPORTGEMPORTMAPPING::DID=10.63.204.233,OID=1-1-5-7-1:CTAG::
VPORTID=1,ONUGEMPORTID=2;
Response:
0 2015-06-06 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create amapping between VPort 1 andGEMport 2 of Rack1/
Shelf1/Slot5/Port7/ONU1 on 10.63.204.233.
Command 2:
CRT-ONU-VPORTGEMPORTMAPPING::DID=10.63.204.233,OID=1-1-5-7-1
:CTAG::VPORTID=1,ONUGEMPORTID=2,COS=7,VID=1066;
Response:
0 2015-06-06 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create a mapping with CoS(7) and VLAN(1066) between
VPort 1 and GEM port 2 of Rack1/ Shelf1/Slot5/Port7/ONU1 on 10.63.204.233.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T90 2015-06-10 New TL1 Command
7-138
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
7.1.43 CRT-ONUPORT-EXTENDEDVLANRULE【【【Create ONU Port
Extended VLAN Rule】】】
l Description
This command is used to create ONU port extended VLAN rule.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
l Command Format
CRT-ONUPORT-EXTENDEDVLANRULE::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id,ONUPORT=onu-port:CTAG::[PORTTYPE=port-type],
FILTERRULENAME=filter-rule-name,TREATMENTRULENAME=treatment-rule-name;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
7-139
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
ONUPORT String [rack-][shelf-][slo-
t-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
PORTTYPE String Ethernet
WiFi
VEIP
IPHost
UNI Port Type Optional
If not input, the default
UNI type is Ethernet.
FILTERRU-
LENAME
String SIZE(1-64) Filter Rule Name Required
TREAT-
MENTRU-
LENAME
String SIZE(1-64) Treatment Rule Name Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONUPORT-EXTENDEDVLANRULE::DID=10.63.204.51,OID=1-1-5-7-1,ONUPORT=1:
CTAG::PORTTYPE=Ethernet,FILTERRULENAME=filterRule,TREATMENTRULENAME
=treatmentRule;
Response:
0 2015-05-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
7-140
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Remark:
This command is used to create an extended VLAN rule of
Rack1/Shelf1/Slot5/Port7/ONU1/Ethernet port1 on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T95 2015-08-08 New TL1 Command
7.1.44 CRT-ONUPORT-EXTENDEDVLAN【【【Create ONU Port
Extended VLAN】】】
l Description
This command is used to create ONU port extended VLAN information.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
l Command Format
CRT-ONUPORT-EXTENDEDVLAN::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id,ONUPORT=onu-port:CTAG::[PORTTYPE=port-type],DSMODE=downstream-mode;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
7-141
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
ONUPORT String [rack-][shelf-][slo-
t-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
PORTTYPE String Ethernet
WiFi
VEIP
IPHost
UNI Port Type Optional
If not input, the default
UNI type is Ethernet.
DSMODE String InverseUpstream
Transparent
Downstream Mode Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
7-142
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Example
Command 1:
CRT-ONUPORT-EXTENDEDVLAN::DID=10.63.204.51,OID=1-1-5-7-1,ONUPORT=1:CTAG::
PORTTYPE=Ethernet,DSMODE=InverseUpstream;
Response:
0 2015-05-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create the extended VLAN information of
Rack1/Shelf1/Slot5/Port7/ONU1/Ethernetport1 on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T95 2015-08-08 New TL1 Command
7.1.45 CRT-ONUPORT-IGMP【【【Create ONU Port IGMP】】】
l Description
This command is used to create ONU port IGMP information.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
7-143
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
CRT-ONUPORT-IGMP::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id,ONUPORT=onu-port:CTAG::[PORTTYPE=port-type],
IGMPPROFILENAME=igmp-profile-name[,MAXGROUPNUM=max-group-number]
[,MAXBANDWIDTH=max-bandwidth][,BANDWIDTHENFORCE=bandwidth-enforce];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional
Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used to
identify the ONU while
DID or DNAME indicates
the OLT device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
ONUPORT String [rack-][shelf-][slo-
t-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional
Description
PORTTYPE String Ethernet
VEIP
UNI Port Type Optional
If not input, the
default UNI type is
Ethernet.
7-144
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
IGMPPRO-
FILENAME
String SIZE(1-64) IGMP Profile Name Required
MAX-
GROUP-
NUM
Integer 0-1000 Maximum Group Number
Value 0 indicates no limit
Optional
MAXBAND-
WIDTH
Integer 0-2147483648 Maximum Bandwidth
(kbps)
Value 0 indicates no limit
Optional
BAND-
WIDTHEN-
FORCE
String Enable
Disable
Bandwidth Enforcing
Enabling
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IDNE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONUPORT-IGMP::DID=10.63.204.51,OID=1-1-5-7-1,ONUPORT=1:CTAG::
IGMPPROFILENAME=igmpProfile,MAXGROUPNUM=100;
Response:
0 2015-08-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create IGMP information of
Rack1/Shelf1/Slot5/Port7/ONU1/Ethernet port 1 on 10.63.204.51.
7-145
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Command 2:
CRT-ONUPORT-IGMP::DID=10.63.204.51,OID=1-1-5-7-1,ONUPORT=1:CTAG::
PORTTYPE=VEIP,IGMPPROFILENAME=igmpProfile,MAXGROUPNUM=100;
Response:
0 2016-05-23 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create IGMP information of
Rack1/Shelf1/Slot5/Port7/ONU1/VEIP port 1 on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T100 2015-12-01 New TL1 Command
NetNumenU31R20V12.16.20T105 2016-05-23 New Command
Parameters：PORTTYPE
7.1.46 DLT-ONUPORT-IGMP【【【Delete ONU Port IGMP】】】
l Description
This command is used to delete an ONU port IGMP.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
7-146
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DLT-ONUPORT-IGMP::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id,ONUPORT=onu-port:CTAG::[PORTTYPE=port-type];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional
Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used to
identify the ONU while
DID or DNAME indicates
the OLT device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
ONUPORT String [rack-][shelf-][slo-
t-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional
Description
PORTTYPE String Ethernet
VEIP
UNI Port Type Optional
If not input, the
default UNI type is
Ethernet.
l Response Format
7-147
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IDNE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
DLT-ONUPORT-IGMP::DID=10.63.204.51,OID=1-1-5-7-1,ONUPORT=1:CTAG::;
Response:
0 2015-08-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete an IGMP of Rack1/Shelf1/Slot5/Port7/ONU1/Ethernet
port 1 on 10.63.204.251.
Command 2:
DLT-ONUPORT-IGMP::DID=10.63.204.51,OID=1-1-5-7-1,ONUPORT=1:CTAG::
PORTTYPE=VEIP;
Response:
0 2016-05-23 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete an IGMP of Rack1/Shelf1/Slot5/Port7/ONU1/VEIP
port 1 on 10.63.204.251.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
7-148
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T110 2016-09-29 New TL1 Command
7.1.47 CRT-ONUPORT-VLANTRANSLATION【【【Create ONU Port
VLAN Translation】】】
l Description
This command is used to create ONU port VLAN translation.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series/C600
Series
MSAN C300Mv4 Series
l Command Format
CRT-ONUPORT-VLANTRANSLATION::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id,ONUPORT=onu-port:CTAG::[PORTTYPE=port-type],USERVID=user-vid
[,USERCOS=user-cos]([,CVID=cvid][,SVID=svid])[,CTAGCOS=ctag-cos]
[,STAGCOS=stag-cos];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-por Port ID (e.g. 1-1-5-2) Optional
7-149
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
OID String rack-shelf-slot-port-
onu
MacAddress
SN/LOID/Password
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
ONUPORT String [rack-][shelf-][slot-]p-
ort
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
PORTTYPE String Ethernet
MulticastGEMPort
UnicastGEMPort
WiFi
VEIP
WAN
UNI Port Type Optional
If not input, the default
UNI type is Ethernet.
USERVID Integer 1-4094 User VLAN ID Required
USERCOS Integer 0-7 User CoS Priority Optional
CVID Integer 1-4094 CVLAN ID Required Under
Certain Conditions:
At least choose one
between CVID and
SVID
SVID Integer 1-4094 SVLAN ID Required Under
Certain Conditions:
At least choose one
between CVID and
SVID
CTAGCOS Integer 0-7 CVLAN CoS PriorityOptional
STAGCOS Integer 0-8 SVLAN CoS Priority
Value 8 indicates
copying priority from
inner VLAN priority
Optional
l Response Format
7-150
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONUPORT-VLANTRANSLATION::DID=10.63.204.233,OID=1-1-5-7-1,ONUPORT=1:
CTAG::PORTTYPE=Ethernet,USERVID=115,CVID=100,SVID=200;
Response:
0 2015-12-06 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create VLAN translation of Rack1/
Shelf1/Slot5/Port7/ONU1/Ethernet port 1 on 10.63.204.233.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T100 2016-01-11 New TL1 Command
7.1.48 DLT-ONUPORT-VLANTRANSLATION【【【Delete ONU Port
VLAN Translation】】】
l Description
This command is used to delete ONU port VLAN translation.
7-151
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series/C600
Series
MSAN C300Mv4 Series
l Command Format
DLT-ONUPORT-VLANTRANSLATION::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id,ONUPORT=onu-port:CTAG::[PORTTYPE=port-type],USERVID=user-vid
[,USERCOS=user-cos];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-por Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-port-
onu
MacAddress
SN/LOID/Password
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
ONUPORT String [rack-][shelf-][slot-]p-
ort
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
7-152
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Parameter
Name
Type Value Range Description Optional Description
PORTTYPE String Ethernet
MulticastGEMPort
UnicastGEMPort
WiFi
VEIP
WAN
UNI Port Type Optional
If not input, the default
UNI type is Ethernet.
USERVID Integer 1-4094 User VLAN ID Required
USERCOS Integer 0-7 User CoS Priority Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
DLT-ONUPORT-VLANTRANSLATION::DID=10.63.204.233,OID=1-1-5-7-1,ONUPORT=1:
CTAG::PORTTYPE=Ethernet,USERVID=115;
Response:
0 2015-12-06 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete VLAN translation of Rack1/
Shelf1/Slot5/Port7/ONU1/Ethernet port 1 on 10.63.204.233.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
7-153
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T100 2016-01-11 New TL1 Command
7.1.49 CHG-ONU-BRGPORT【【【Change ONU Bridge Port】】】
l Description
This command is used to change ONU bridge port configuration information.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series/C600
Series
MSAN C300Mv4 Series
l Command Format
CHG-ONU-BRGPORT::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id,ONUPORT=onu-port:CTAG::[UPBWPRF=up-bandwidth-profile-name][,
DOWNBWPRF=down-bandwidth-profile-name];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-por Port ID (e.g. 1-1-5-2) Optional
7-154
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
OID String rack-shelf-slot-port-
onu
MacAddress
SN/LOID/Password
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
ONUPORT String [rack-][shelf-][slot-]p-
ort
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
UPBWPRF String SIZE(1-64) Upstream Bandwidth
Profile Name
Optional
DOWNBW-
PRF
String SIZE(1-64) Downstream
Bandwidth Profile
Name
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONU-BRGPORT::DID=10.63.204.233,OID=1-1-5-7-1,ONUPORT=1:CTAG::
UPBWPRF=5M,DOWNBWPRF=10M;
Response:
7-155
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
0 2015-06-06 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change rate limiting of Rack1/
Shelf1/Slot5/Port7/ONU1/bridge port 1 on 10.63.204.233.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T100 2015-12-15 New TL1 Command
7.1.50 CHG-ONU-TARGETSTAT【【【Change ONU Target Status】】】
l Description
This command is used to change GPON ONU target status.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series/C600
Series
l Command Format
CHG-ONU-TARGETSTAT::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id:CTAG::TARGETSTAT=target-status;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-156
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
TARGET-
STAT
String Inactive
OMCIReady
Target Status Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONU-TARGETSTAT::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::
TARGETSTAT=OMCIReady;
Response：
7-157
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
0 2014-12-22 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change ONU target status of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T85 2014-12-22 New TL1 Command
7.1.51 CHG-ONU-VIDEOANI【【【Change ONU Video ANI
Configuration】】】
l Description
This command is usedto change ONU video ANI configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series
l Command Format
CHG-ONU-VIDEOANI::(DID=device-id|DNAME=device-name)[,PID=port-id],OID=onu-id
:CTAG::[ADMINSTAT=admin-status][,AGCMODE=agc-mode,AGC=agc];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-158
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ADMIN-
STAT
String Enable
Disable
Administrative Status Optional
AGCMODE String None
Broadband
Optical
AGC Mode Optional
AGC Integer -128–127 AGC (0.1dB) Required Under
Certain Conditions:
Broadband or Optical
mode.
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None
l Error Code
DDOF, IIPE, EEH
7-159
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONU-VIDEOANI::DID=10.63.173.78,OID=1-1-2-1-1:CTAG::AGCMODE=Optical,AGC=12;
Response：
0 2015-04-10 10:19:37
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change video ANI configuration of
Rack1/Shelf1/Slot2/Port1/ONU1 on 10.63.173.78.
Command 2:
CHG-ONU-VIDEOANI::DID=10.63.173.78,OID=1-1-2-1-1:CTAG::ADMINSTAT=Enable;
Response：
0 2016-05-09 10:32:43
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change video ANI configuration of
Rack1/Shelf1/Slot2/Port1/ONU1 on 10.63.173.78.
Command 3:
CHG-ONU-VIDEOANI::DID=10.63.173.78,OID=1-1-2-1-1:CTAG::ADMINSTAT=Enable,
AGCMODE=Optical,AGC=12;
Response：
0 2016-05-09 11:13:42
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change video ANI configuration of
Rack1/Shelf1/Slot2/Port1/ONU1 on 10.63.173.78.
l Average Command Response Time
7-160
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T90 2015-04-10 New TL1 Command
NetNumenU31R20V12.16.20T105 2015-05-09 New Command Parameters：
ADMINSTAT
7.1.52 CHG-ONU-VPORT【【【Change ONU VPort】】】
l Description
This command is used to change ONU VPort configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
l Command Format
CHG-ONU-VPORT::(DID=device-id|DNAME=device-name)[,PID=port-id],OID=onuid:
CTAG::VPORTID=vport-id[,MAPPINGTYPE=mapping-type][,VPORTNAME=vport-name];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
7-161
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
VPORTID Integer 1-256 VPort ID Required
MAPPING-
TYPE
String VLAN
CoS
CoSAndVLAN
OneToOne
Mapping Type Optional
VPORT-
NAME
String SIZE(1-128) VPort Name Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONU-VPORT::DID=10.63.204.233,OID=1-1-5-7-1:CTAG::
VPORTID=1,MAPPINGTYPE=VLAN;
Response:
7-162
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
0 2015-06-06 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure VLAN mapping type of Rack1/
Shelf1/Slot5/Port7/ONU1/VPort1 on 10.63.204.233.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T90 2015-06-05 New TL1 Command
7.1.53 CHG-ONUGEMPORT-QOS【【【Change ONU GEM Port QoS】】】
l Description
This command is used to change ONU GEM port QoS information.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series
l Command Format
CHG-ONUGEMPORT-QOS::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id:CTAG::ONUGEMPORTID=onu-gemport-id[,ONUPORT=onu-port]
[,USPRI0QUEUE=upstream-priority0–queue][,USPRI1QUEUE=upstream-priority1–queue]
[,USPRI2QUEUE=upstream-priority2–queue][,USPRI3QUEUE=upstream-priority3–queue]
[,USPRI4QUEUE=upstream-priority4–queue][,USPRI5QUEUE=upstream-priority5–queue]
[,USPRI6QUEUE=upstream-priority6–queue][,USPRI7QUEUE=upstream-priority7–queue];
l Operated Target Identifier
7-163
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUGEM-
PORTID
Integer 1-255 ONU GEM Port ID Required
ONUPORT String [rack-][shelf-][slo-
t-]port
Ethernet Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Optional
DSQUEUE Integer 0-7 Downstream Queue Optional
USPRI0Q-
UEUE
Integer 0-7 Upstream Priority0
Queue
Optional
USPRI1Q-
UEUE
Integer 0-7 Upstream Priority1
Queue
Optional
USPRI2Q-
UEUE
Integer 0-7 Upstream Priority2
Queue
Optional
7-164
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
USPRI3Q-
UEUE
Integer 0-7 Upstream Priority3
Queue
Optional
USPRI4Q-
UEUE
Integer 0-7 Upstream Priority4
Queue
Optional
USPRI5Q-
UEUE
Integer 0-7 Upstream Priority5
Queue
Optional
USPRI6Q-
UEUE
Integer 0-7 Upstream Priority6
Queue
Optional
USPRI7Q-
UEUE
Integer 0-7 Upstream Priority7
Queue
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONUGEMPORT-QOS::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::ONUGEMPORTID=1,
ONUPORT=1,DSQUEUE=2;
Response:
0 2015-05-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the QoS information of
Rack1/Shelf1/Slot5/Port7/ONU1/GEM port1 on 10.63.204.51.
Command 2:
CHG-ONUGEMPORT-QOS::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::ONUGEMPORTID=1,
USPRI0QUEUE=0,USPRI1QUEUE=0,USPRI2QUEUE=1,
USPRI3QUEUE=1,USPRI4QUEUE=2,USPRI5QUEUE=2,
USPRI6QUEUE=3,USPRI7QUEUE=3;Response:
0 2018-11-1 10:55:49
7-165
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the QoS information of
Rack1/Shelf1/Slot5/Port7/ONU1/GEM port1 on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T95 2015-08-08 New TL1 Command
NetNumenU31R20V12.18.20T140 2018-11-5 New Command Parame-
ters: USPRI0QUEUE,US-
PRI1QUEUE, US-
PRI2QUEUE,US-
PRI3QUEUE, US-
PRI4QUEUE,US-
PRI5QUEUE, US-
PRI6QUEUE,US-
PRI7QUEUE
7.1.54 CHG-ONUPORT-VLAN【【【Change ONU Port VLAN】】】
l Description
This command is used to change ONU port VLAN.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
l Command Format
CHG-ONUPORT-VLAN::(DID=device-id|DNAME=device-name)[,PID=port-id][,
7-166
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
OID=onu-id],ONUPORT=onu-port:CTAG::[ONUPROFILENAME=onu-profile-name]
[,PORTTYPE=port-type][,VLANMODE=vlan-mode][,PVID=pvid][,COS=cos];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
ONUPORT String [rack-][shelf-][slo-
t-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile NAME Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
7-167
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
PORTTYPE String Ethernet
MulticastGEMPort
UnicastGEMPort
WiFi
VEIP
WAN
UNI Port Type Optional
If not input, the default
UNI type is Ethernet.
VLAN-
MODE
String Tag
Trunk
Hybrid
Transparent
VLAN Mode Optional
PVID Integer 1-4094 PVID Optional
COS Integer 0-7 CoS Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONUPORT-VLAN::DID=10.63.204.233,OID=1-1-5-7-1,ONUPORT=1:CTAG::
PORTTYPE=Ethernet,VLANMODE=Hybrid,PVID=115,COS=4;
Response:
0 2015-06-06 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to set VLAN mode to hybrid of Rack1/
Shelf1/Slot5/Port7/ONU1/ETHUNI1 on 10.63.204.233,and PVID is set to 115,CoS
is set to 4.
Command 2:
CHG-ONUPORT-VLAN::DID=10.63.204.233,ONUPORT=1:CTAG::ONUPROFILENAME=
remote-profile,PORTTYPE=Ethernet,VLANMODE=Hybrid,PVID=115,COS=4;
Response:
7-168
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
0 2017-04-06 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to modify Ethernet port 1 VLAN information of ONU profile
remote-profile on NE 10.63.204.233.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T90 2015-06-15 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-4-27 New Command
Parameters：
ONUPROFILENAME
7.1.55 CHG-ONUVIDEOPORT【【【Change ONU Video Port】】】
l Description
This command is used to change GPON ONU video port information.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series
l Command Format
CHG-ONUVIDEOPORT::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id,ONUPORT=onu-port:CTAG::ADMINSTAT=admin-status;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-169
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
ONUPORT String [rack-][shelf-][slo-
t-]port
Video Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ADMIN-
STAT
String Enable
Disable
Administrative Status Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
7-170
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Command 1:
CHG-ONUVIDEOPORT::DID=10.63.204.51,OID=1-1-5-7-1,ONUPORT=1:CTAG::
ADMINSTAT=Enable;
Response:
0 2014-11-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to enable the administrative status of Rack1/
Shelf1/Slot5/Port7/ONU1/Video Port1 on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T90 2014-11-28 New TL1 Command
7.1.56 CHG-ONU-VOIP【【【Change ONU VoIP】】】
l Description
This command is used to change the VoIP of ONU.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
CHG-ONU-VOIP::(DID=device-id|DNAME=device-name)[,PID=port-id][,OID=onu-id]:CTAG::
[ONUPROFILENAME=onu-profile-name][,PROTOCOLTYPE=protocol-type]
[,USEDCONFMETHOD=used-conf-method][,H248REGMODE=h248-reg-mode]
7-171
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
[,ONUDOMAIN=onu-domain][,H248EQUIPMENTNAME=h248-equipment-name]
[,MGCREGMODE=mgc-reg-mode][,LINENAMESN=line-name-sn]
[,IPALLOCATINGMODE=ip-allocating-mode][,CONFSVRADDRESS=conf-svr-address]
[,CONFSVRVALIDATIONSCHEME=conf-svr-validation-scheme]
[,CONFSVRUSERNAME=conf-svr-user-name][,CONFSVRPASSWORD=conf-svr-password]
[,CONFSVRREALM=conf-svr-realm];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUPROFILE-
NAME
String SIZE(1-64) ONU Profile Name Required Under Certain
Conditions:Must choose
one between OID and
ONUPROFILENAME
7-172
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
PROTO-
COLTYPE
StringNone
SIP
H.248
MGCP
Non-OMCI
Protocol Type Optional
USEDCONFM-
ETHOD
String Default
OMCI
ConfFile
TR069
IETF
Used Configuration
Method
Optional
H248REG-
MODE
String IPv4
Domain
EquipName
H.248 Registration
Mode
Optional
Valid when
PROTOCOLTYPE is
H.248
ONUDOMAIN String SIZE(1-128) ONU Domain Optional
Valid when
PROTOCOLTYPE is
H.248
Required when
H248REGMODE is IPv4
or Domain
H248EQUIP-
MENTNAME
String SIZE(1-25) H.248 Equipment
Name
Optional
Valid when
PROTOCOLTYPE is
H.248
Required when
H248REGMODE is IPv4
or EquipName
MGCREG-
MODE
String Wildcard
Individual
MGC Registration
Mode
Optional
Valid when
PROTOCOLTYPE is
MGCP
LINENAMESN String SIZE(1-25) Line Name Serial
Number
Optional
Valid when
PROTOCOLTYPE is
MGCP
IPALLOCAT-
INGMODE
String Single
Dual
Multiple
IP Allocating Mode Optional
CONFSVRAD-
DRESS
String SIZE(1-128) Configuration Server
Address
Optional
7-173
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
CONFSVR-
VALIDATION-
SCHEME
String Disable
MD5
Basic
Configuration Server
Validation Scheme
Optional
CON-
FSVRUSER-
NAME
String SIZE(1-50) Configuration Server
User Name
Optional
Required when CON-
FSVRVALIDATION-
SCHEME is MD5 or
Basic
CONFSVR-
PASSWORD
String SIZE(1-32) Configuration Server
Password
Optional
Required when CON-
FSVRVALIDATION-
SCHEME is MD5 or
Basic
CONFSVR-
REALM
String SIZE(1-32) Configuration Server
Realm
Optional
Required when CON-
FSVRVALIDATION-
SCHEME is MD5
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONU-VOIP::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::PROTOCOLTYPE=SIP;
Response：
0 2016-02-25 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the VoIP protocol type of
Rack1/Shelf1/Slot5/Port7/ONU1 on NE 10.63.204.51.
Command 2：：：
CHG-ONU-VOIP::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::PROTOCOLTYPE=SIP,
7-174
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
USEDCONFMETHOD=OMCI,IPALLOCATINGMODE=Single,CONFSVRADDRESS=10.63.204.5,
CONFSVRVALIDATIONSCHEME=MD5,CONFSVRUSERNAME=zte,CONFSVRPASSWORD=zte,
CONFSVRREALM=@zte;
Response：
0 2017-04-26 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:：
This command is used to change the SIP VoIP information of
Rack1/Shelf1/Slot5/Port7/ONU1 on NE 10.63.204.51.
Command 3：：：
CHG-ONU-VOIP::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::PROTOCOLTYPE=H.248,
H248REGMODE=IPv4,ONUDOMAIN=ztedomain,H248EQUIPMENTNAME=zteequip,
CONFSVRADDRESS=10.63.204.5,CONFSVRVALIDATIONSCHEME=Disable;
Response：
0 2017-04-26 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the H.248 VoIP information of
Rack1/Shelf1/Slot5/Port7/ONU1 on NE 10.63.204.51.
Command 4：：：
CHG-ONU-VOIP::DID=10.63.204.51:CTAG::ONUPROFILENAME=remote-profile,
PROTOCOLTYPE=MGCP,MGCREGMODE=Wildcard,LINENAMESN=ztezte,
CONFSVRADDRESS=10.63.204.5,CONFSVRVALIDATIONSCHEME=Basic,
CONFSVRUSERNAME=zte,CONFSVRPASSWORD=zte;
Response：
0 2017-04-26 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
7-175
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
This command is used to change the MGCP VoIP information from ONU profile
remote-profile on NE 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T100 2016-3-4 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-4-28 New Command Parameters：
ONUPROFILENMAE,
USEDCONFMETHOD,
H248REGMODE, ONUDOMAIN,
H248EQUIPMENTNAME,
MGCREGMODE, LINENAMESN,
IPALLOCATINGMODE,
CONFSVRADDRESS,
CONFSVRVALIDATIONSCHEME,
CONFSVRUSERNAME,
CONFSVRPASSWORD,
CONFSVRREALM
7.1.57 CLR-ONU-CONFDATA【【【Clear ONU Configuration Data】】】
l Description
This command is used to clear the configuration data of an ONU.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series
l Command Format
CLR-ONU-CONFDATA::(DID=device-id|DNAME=device-name)[,PID=port-id][,OID=onu-id]
:CTAG::;
l Operated Target Identifier
7-176
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Optional
l Command Parameter
None.
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CLR-ONU-CONFDATA::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::;
Response:
0 2015-08-20 10:55:49
M CTAG COMPLD
7-177
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
EN=0 ENDESC=No Error
;
Remark:
This command is used to clear the configuration data of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T95 2015-09-18 New TL1 Command
7.1.58 BND-ONU-DHCPSERVERPROFILE【【【Bind DHCP Server
Profile to ONU】】】
l Description
This command is used to bind DHCP server profile to ONU.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
l Command Format
BND-ONU-DHCPSERVERPROFILE::(DID=device-ID|DNAME=device-name)[,PID=port-id],
OID=onu-id:CTAG::DHCPSERVERPROFILENAME=dhcpserver-profile-name;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-178
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
DHCPSER-
VERPRO-
FILENAME
String SIZE(1-32) DHCP Server Profile
Name
Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
BND-ONU-DHCPSERVERPROFILE::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::
DHCPSERVERPROFILENAME=testDhcpServerProfile;
7-179
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Response：
0 2015-05-13 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to bind DHCP server profile testDhcpServerProfile to
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T90 2015-05-13 New TL1 Command
7.1.59 UBND-ONU-DHCPSERVERPROFILE【【【Unbind DHCP Server
Profile from ONU】】】
l Description
This command is usedto unbind DHCP server profile from ONU.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
l Command Format
UBND-ONU-DHCPSERVERPROFILE::(DID=device-ID|DNAME=device-name)[,PID=port-id],
OID=onu-id:CTAG::;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-180
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
None.
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
UBND-ONU-DHCPSERVERPROFILE::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::;
Response：
0 2013-08-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
7-181
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Remark:
This command is used to unbind DHCP server profile form
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.15.20T90 2015-05-13 New TL1 Command
7.1.60 BND-ALARMPROFILE【【【Bind Alarm Profile】】】
l Description
This command is used to bind alarm profile.
l Applicable NE
NE
Category
NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series/C600 Series
l Command Format
BND-ALARMPROFILE::(DID=device-id|DNAME=device-name)[,BID=board-id|[,P-
ID=port-id][,OID=onu-id[,ONUPORT=onu-port]]]:CTAG::ALARMPROFILENAME=al-
arm-profile-name;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
7-182
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DNAME String SIZE(1-32) NE Name Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
BID String rack-shelf-slot Board ID (e.g. 1-1-5) Optional
Can't be input with PID
and OID at the same
time.
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
Can't be input with BID
at the same time.
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Optional
Can't be input with BID
at the same time.
ONUPORT String [rack-][shelf-][slo-
t-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Optional
Valid if OID is input.
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ALARMPRO-
FILENAME
String SIZE(1-32) Alarm Profile Name Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Example
Command 1:
7-183
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
BND-ALARMPROFILE::DID=10.63.194.46:CTAG::ALARMPROFILENAME=alarm-
profile-Ne;
Response：
xuzhilu-PC 2014-10-22 10:44:33
M CTFG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to bind alarm profile alarm-profile-Ne to OLT 10.63.194.46.
Command 2:
BND-ALARMPROFILE::DID=10.63.194.46,BID=1-1-5:CTAG::ALARMPROFILE-
NAME=alarm-profile-Board;
Response：
xuzhilu-PC 2014-10-22 10:46:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to bind alarm profile alarm-profile-Board to Rack1/Shelf1/Slot5
on OLT 10.63.194.46.
Command 3:
BND-ALARMPROFILE::DID=10.63.194.46,PID=1-1-5-2:CTAG::ALARMPROFILE=a-
larm-profile-Port;
Response：
xuzhilu-PC 2014-10-22 10:51:45
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to bind alarm profile alarm-profile-Port to
Rack1/Shelf1/Slot5/Port2 on OLT 10.63.194.46.
Command 4：：：
BND-ALARMPROFILE::DID=10.63.194.46,OID=1-1-5-2-10:CTAG::ALARMPROFILE-
NAME=alarm-profile-ONU;
7-184
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Response：
xuzhilu-PC 2014-10-22 10:51:45
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to bind alarm profile alarm-profile-ONU to
Rack1/Shelf1/Slot5/Port2/ONU10 on OLT 10.63.194.46.
Command 5：：：
BND-ALARMPROFILE::DID=10.63.194.46,PID=1-1-5-2,OID=ZTEG0A2B3366:CT-
AG::ALARMPROFILENAME=alarm-profile-ONU;
Response：
xuzhilu-PC 2014-10-22 10:58:05
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to bind alarm profile alarm-profile-ONU to ONU of
Rack1/Shelf1/Slot5/Port2 on OLT 10.63.194.46.
Command 6：：：
BND-ALARMPROFILE::DID=10.63.194.46,OID=1-1-5-2-10,ONUPORT=2:CT-
AG::ALARMPROFILENAME=alarm-profile-ONUPORT;
Response：
xuzhilu-PC 2014-10-22 11:02:16
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to bind alarm profile alarm-profile-ONUPORT to
Rack1/Shelf1/Slot5/Port2/ONU10/ONUPORT2 on OLT 10.63.194.46.
Average Command Response Time
Scenario Average Response Time (s)
7-185
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Notes
Table 7-1 aaa
Point Details
Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-10-22 New TL1 Command
7.1.61 UBND-ALARMPROFILE【【【Unbind Alarm Profile】】】
l Description
This command is used to unbind alarm profile.
l Applicable NE
NE
Category
NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series/C600 Series
l Command Format
UBND-ALARMPROFILE::(DID=device-id|DNAME=device-name)[,BID=board-id|[,P-
ID=port-id][,OID=onu-id[,ONUPORT=onu-port]]]:CTAG::;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
7-186
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
BID String rack-shelf-slot Board ID (e.g. 1-1-5) Optional
Can't be input with PID
and OID at the same
time.
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
Can't be input with BID
at the same time.
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Optional
Can't be input with BID
at the same time.
ONUPORT String [rack-][shelf-][slo-
t-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Optional
Valid if OID is input.
l Command Parameter
None
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Defination for more details.
l Example
Command 1:
UBND-ALARMPROFILE::DID=10.63.194.46:CTAG::;
Response：
xuzhilu-PC 2014-10-22 11:04:11
M CTAG COMPLD
EN=0 ENDESC=No Error
;
7-187
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Remark:
This command is used to unbind alarm profile from OLT 10.63.194.46.
Command 2:
UBND-ALARMPROFILE::DID=10.63.194.46,BID=1-1-5:CTAG::;
Response：
xuzhilu-PC 2014-10-22 11:12:32
M CTAGCOMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to unbind alarm profile from Rack1/Shelf1/Slot5 on OLT
10.63.194.46.
Command 3:
UBND-ALARMPROFILE::DID=10.63.194.46,PID=1-1-5-2:CTAG::;
Response：
xuzhilu-PC 2014-10-22 11:15:15
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to unbind alarm profile from Rack1/Shelf1/Slot5/Port2 on OLT
10.63.194.46.
Command 4：：：
UBND-ALARMPROFILE::DID=10.63.194.46,OID=1-1-5-2-10:CTAG::;
Response：
xuzhilu-PC 2014-10-22 11:20:51
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to unbind alarm profile from Rack1/Shelf1/Slot5/Port2/ONU10
on OLT 10.63.194.46.
Command 5：：：
UBND-ALARMPROFILE::DID=10.63.194.46,PID=1-1-5-2,OID=ZTEG0A2B3366:CTAG::;
7-188
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Response：
xuzhilu-PC 2014-10-22 11:22:17
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to unbind alarm profile from ONU of Rack1/Shelf1/Slot5/Port2
on OLT 10.63.194.46.
Command 6：：：
UBND-ALARMPROFILE::DID=10.63.194.46,OID=1-1-5-2-10,ONUPORT=2:CTAG::;
Response：
xuzhilu-PC 2014-10-22 11:23:36
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to unbind alarm profile from
Rack1/Shelf1/Slot5/Port2/ONU10/ONUPORT2 on OLT 10.63.194.46.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-10-22 New TL1 Command
7.1.62 UBND-ONUPORT-VLAN【【【Unbind VLAN from ONU Port】】】
l Description
This command is used to unbind VLAN from ONU port.
l Applicable NE
7-189
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series
MSAN C300Mv4 Series
l Command Format
UBND-ONUPORT-VLAN::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id,ONUPORT=onu-port:CTAG::[PORTTYPE=port-type],VID=vid;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-port Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-port-
onu
MacAddress
SN/LOID/Password
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
ONUPORT String [rack-][shelf-][slot-]p-
ort
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
7-190
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
PORTTYPE String Ethernet
MulticastGEMPort
UnicastGEMPort
WiFi
VEIP
WAN
UNI Port Type Optional
If not input, the default
UNI type is Ethernet.
VID String 1-4094
All
VLAN ID Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
UBND-ONUPORT-VLAN::DID=10.63.204.233,OID=1-1-5-7-1,ONUPORT=1:CTAG::
PORTTYPE=Ethernet,VID=115;
Response:
0 2015-06-06 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to unbind VLAN 115 from Rack1/
Shelf1/Slot5/Port7/ONU1/Ethernet port 1 on 10.63.204.233.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
7-191
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Revision Date Notes
NetNumenU31R20V12.16.20T100 2016-01-11 New TL1 Command
7.1.63 BND-ONUPORT-VLAN【【【Bind ONU Port to VLAN】】】
l Description
This command is used to bind ONU port to VLAN.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series
MSAN C300Mv4 Series
l Command Format
BND-ONUPORT-VLAN::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id,ONUPORT=onu-port:CTAG::[PORTTYPE=port-type],VID=vid;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-por Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-port-
onu
MacAddress
SN/LOID/Password
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
7-192
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
ONUPORT String [rack-][shelf-][slot-]p-
ort
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
PORTTYPE String Ethernet
MulticastGEMPort
UnicastGEMPort
WiFi
VEIP
WAN
UNI Port Type Optional
If not input, the default
UNI type is Ethernet.
VID String 1-4094
All
VLAN ID Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
BND-ONUPORT-VLAN::DID=10.63.204.233,OID=1-1-5-7-1,ONUPORT=1:CTAG::
PORTTYPE=Ethernet,VID=115;
Response:
0 2015-06-06 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to bind VLAN 115 to Rack1/ Shelf1/Slot5/Port7/ONU1/Ethernet
port 1 on 10.63.204.233.
7-193
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T100 2015-12-15 New TL1 Command
7.1.64 CHG-BOARD-ROGUEONUDETECT【【【Change Rogue ONU
Detecting Configuration】】】
l Description
This command is used to change the rogue ONU detecting configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series
MSAN C300Mv4 Series
l Command Format
CHG-BOARD-ROGUEONUDETECT::(DID=device-id|DNAME=device-name),
BID=board-id:CTAG::DETECTSTAT=detect-status[,LOCATINGSTAT=locating-status]
[,AUTOSHUTDOWNSTAT=auto-shutdown-status];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
7-194
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
BID String rack-shelf-slot Board ID (e.g. 1-1-5) Required
l Command Parameter
Parameter Name Type Value
Range
Description Optional Description
DETECTSTAT String Enable
Disable
Detect Status Required
LOCATINGSTAT String Enable
Disable
Locating Status Optional
AUTOSHUT-
DOWNSTAT
String Enable
Disable
Auto-shutdown Status Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-BOARD-ROGUEONUDETECT::DID=10.63.204.233,
BID=1-1-5:CTAG::DETECTSTAT=Enable,LOCATINGSTAT=Enable,
AUTOSHUTDOWNSTAT=Enable;
Response:
0 2015-12-06 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure the regue ONU detecting of Rack1/ Shelf1/Slot5on 10.63.204.233.
7-195
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T100 2015-12-31 New TL1 Command
7.1.65 CHG-ONU-ACS【【【Change ONU ACS】】】
l Description
This command is used to change the ACS configuration of ONU.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
CHG-ONU-ACS::(DID=device-id|DNAME=device-name)[,PID=port-id]
[,OID=onu-id]:CTAG::[ONUPROFILENAME=onu-profile-name],
ADMINSTAT=administrative-status,VALIDATIONSCHEME=validation-scheme,
TAGTYPE=tag-type[,URI=uri][,USERNAME=user-name][,PWD=password]
[,REALM=realm]
[VID=vlan-id][,PRIORITY=priority];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
7-196
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile NAME Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
ADMIN-
STAT
String Enable
Disable
Administrative Status Required
VALIDA-
TION-
SCHEME
String Disable
MD5
Basic
Validation Scheme Required
TAGTYPE String Untagged
Tagged
Tag Type Required
URI String SIZE(1-128) URI Optional
USER-
NAME
String SIZE(1-25) User Name Required Under Cer-
tain Conditions:VAL-
IDATIONSCHEME is
MD5 or Basic
7-197
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
PWD String SIZE(1-25) Password Required Under Cer-
tain Conditions:VAL-
IDATIONSCHEME is
MD5 or Basic
REALM String SIZE(1-25) Realm Required Under Cer-
tain Conditions:VAL-
IDATIONSCHEME is
MD5
VID Integer 1-4094 VLAN ID Required
Under Certain
Conditions:TAGTYPE
is Tagged
PRIORITY Integer 0-7 priority Required
Under Certain
Conditions:TAGTYPE
is Tagged
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IDNE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONU-ACS::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::ADMINSTAT=Enable,
VALIDATIONSCHEME=Disable,TAGTYPE=Tagged,URI=10.2.3.6,VID=100,
PRIORITY=7;
Response：
0 2016-04-25 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the ACS configuration of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.204.51(administrative status is enable,
tag type is Tagged, URI is 10.2.3.6,
7-198
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
validation scheme is disable, VLAN ID is 100, priority is 7).
Command 2:
CHG-ONU-ACS::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::ADMINSTAT=Enable,
VALIDATIONSCHEME=MD5,TAGTYPE=Untagged,URI=zte.com.cn,USERNAME=admin,
PWD=admin,REALM=realmtest;
Response：
0 2016-04-25 12:23:12
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the ACS configuration of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.204.51(administrative status is enable,
tag type is Untagged, URI is zte.com.cn,
validation scheme is MD5, user name is admin, password is admin, realm is
realmtest).
Command 3:
CHG-ONU-ACS::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::ADMINSTAT=Enable,
VALIDATIONSCHEME=Basic,TAGTYPE=Untagged,URI=zte.com.cn,USERNAME=admin,
PWD=admin;
Response：
0 2016-04-25 12:45:24
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the ACS configuration of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.204.51(administrative status is enable,
tag type is Untagged, URI is zte.com.cn,
validation scheme is Basic, user name is admin, password is admin).
Command 4:
CHG-ONU-ACS::DID=10.63.204.51:CTAG::ONUPROFILENAME=remote-profile,
ADMINSTAT=Enable,VALIDATIONSCHEME=Disable,TAGTYPE=Tagged,URI=10.2.3.6,
VID=100,PRIORITY=7;
Response：
7-199
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
0 2017-07-17 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change ONU ACS of ONU profile remote-profile on NE
10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T105 2016-04-25 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-5-17 New Command
Parameters：
ONUPROFILENAME
7.1.66 CHG-ONU-ETHPORT【【【Change ONU Ethernet Port】】】
l Description
This command is used to change ONU ethernet port configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
CHG-ONU-ETHPORT::(DID=device-id|DNAME=device-name)[,PID=port-id],OID=onu-id,
ONUPORT=onu-port:CTAG::[ADMINSTAT=admin-status][,DUPLEXSPEED=duplex-speed];
l Operated Target Identifier
7-200
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-port Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-port-
onu
MacAddress
SN/LOID/Password
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Optional
ONUPORT String [rack-][shelf-][slot-]p-
ort
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter Name Type Value Range Description Optional
Description
ADMINSTAT String Enable
Disable
Administrative Status Optional
7-201
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DUPLEXSPEED String Auto
Half10M
Full10M
Half100M
Full100M
Full1000M
Full10000M
Duplex and Speed Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, IDNE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONU-ETHPORT::DID=10.63.204.233,OID=1-1-6-1-1,ONUPORT=1:CTAG::
DUPLEXSPEED=Full1000M;
Response:
0 2016-09-26 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change ethernet port duplex and speed of
Rack1/Shelf1/Slot6/Port1/ONU1/UNI1 on 10.63.204.233.
Command 2:
CHG-ONU-ETHPORT::DID=10.63.204.233,OID=1-1-6-1-1,ONUPORT=1:CTAG::
ADMINSTAT=Enable,DUPLEXSPEED=Full1000M;
Response:
0 2016-09-26 10:55:49
M CTAG COMPLD
7-202
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
EN=0 ENDESC=No Error
;
Remark:
This command is used to change ethernet port configuration of
Rack1/Shelf1/Slot6/Port1/ONU1/UNI1 on 10.63.204.233.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T110 2016-09-26 New TL1 Command
7.1.67 CHG-ONU-IPV4IPHOST【【【Change ONU IPv4 IPHost
Configuration】】】
l Description
This command is used to change ONU IPv4 IP host configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
CHG-ONU-IPV4IPHOST::(DID=device-id|DNAME=device-name)[,PID=port-id],OID=onu-
id:CTAG::IPHOSTID=iphost-id[,IPOPTIONS=ip-options][,ONUIDENTIFIER=onu-identifier]
[,IP=ip][,IPMASK=ip-mask][,GATEWAY=gateway][,PRIMARYDNS=primary-dns]
[,SECONDARYDNS=secondary-dns];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-203
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
IPHOSTID Integer 1–2 IP Host ID Required
IPOP-
TIONS
String EnableDHCP
RespondPing
RespondTraceR-
oute
EnableIpStack
IP Options
(e.g. EnableDHCP
EnableDHCP/Re-
spondPing
/RespondTraceRoute)
Optional
ONUIDEN-
TIFIER
String SIZE(1-25) ONU Identifier Optional
IP String IpAddress IP Address Optional
IPMASK String IpAddress IP Mask Optional
GATEWAY String IpAddress Gateway Optional
PRIMA-
RYDNS
String IpAddress Primary DNS Optional
SECONDA-
RYDNS
String IpAddress Secondary DNS Optional
7-204
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONU-IPV4IPHOST::DID=10.63.173.78,OID=1-1-2-1-
1:CTAG::IPHOSTID=1,IPOPTIONS=EnableDHCP/RespondPing/RespondTraceRoute,
ONUIDENTIFIER=test,IP=10.1.2.3,IPMASK=255.255.255.0,GATEWAY=10.1.2.1,
PRIMARYDNS=10.1.3.1,SECONDARYDNS=10.1.3.2;
Response：
0 2016-05-10 15:29:24
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change IP host configuration of
Rack1/Shelf1/Slot2/Port1/ONU1 on 10.63.173.78.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T105 2016-05-10 New TL1 Command
7-205
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
7.1.68 CHG-ONU-VEIP【【【Change ONU VEIP】】】
l Description
This command is used to change ONU VEIP configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
CHG-ONU-VEIP::(DID=device-id|DNAME=device-name)[,PID=portid],OID=onu-id,
ONUPORT=onu-port:CTAG::[ADMINSTAT=admin-status]
[,INTERDOMAINNAME=interdomain-name][,PORTASSIGNENABLE=port-assign-enable]
[,PROTOCOLTYPE=protocol-type][,ASSIGNEDPORT=assigned-port][,IPHOSTID=iphost-id];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-port Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-port-
onu
MacAddress
SN/LOID/Password
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
7-206
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
ONUPORT String [rack-][shelf-][slot-]p-
ort
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ADMIN-
STAT
String Enable
Disable
Administrative Status Optional
INTERDO-
MAINNAME
String SIZE(1-25) Interdomain Name Optional
PORTAS-
SIGNEN-
ABLE
String Enable
Disable
Port Assign Enable Optional
PROTO-
COLTYPE
String TCP
UDP
Protocol Type Required Under Cer-
tain Conditions: when
PORTASSIGNEN-
ABLE is Enable
AS-
SIGNED-
PORT
Integer 0-65535 Assigned Port Required Under Cer-
tain Conditions: when
PORTASSIGNEN-
ABLE is Enable
IPHOSTID Integer 1-255 IP Host ID Required Under Cer-
tain Conditions:when
PORTASSIGNEN-
ABLE is Enable
7-207
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, IDNE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONU-VEIP::DID=10.63.204.233,OID=1-1-5-7-1,ONUPORT=1:CTAG::
ADMINSTAT=Enable,INTERDOMAINNAME=domain,
PORTASSIGNENABLE=Enable,PROTOCOLTYPE=UDP,
ASSIGNEDPORT=1000,IPHOSTID=1;
Response:
0 2015-12-06 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change VEIP configuration of
Rack1/Shelf1/Slot5/Port7/ONU1/VEIP1 on 10.63.204.233.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T105 2016-06-23 New TL1 Command
7-208
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
7.1.69 CHG-ONUPORT-MVLANTAGMODE【【【Change ONU Port
MVLAN Tag】】】
l Description
This command is used to change the MVLAN tag mode of ONU port.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series
MSAN C300Mv4 Series
l Command Format
CHG-ONUPORT-MVLANTAGMODE::(DID=device-id|DNAME=device-name)[,PID=port-id][,
OID=onu-id],ONUPORT=onu-port:CTAG::[ONUPROFILENAME=onu-profile-name],
MVLANTAGMODE=mvlan-tag-mode;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
7-209
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
ONUPORT String [rack-][shelf-][slo-
t-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile NAME Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
MVLAN-
TAGMODE
String Stripped
NotStripped
Translated
MVLAN Tag Mode Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONUPORT-MVLANTAGMODE::DID=10.63.204.51,OID=1-1-5-7-1,ONUPORT=1:CTAG::
MVLANTAGMODE=Stripped;
Response:
0 2016-09-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the MVLANtag mode of
Rack1/Shelf1/Slot5/Port7/ONU1/ONU Port1 on 10.63.204.51.
7-210
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Command 2:
CHG-ONUPORT-MVLANTAGMODE::DID=10.63.204.51,ONUPORT=1:CTAG::
ONUPROFILENAME=remote-profile,MVLANTAGMODE=Stripped;
Response:
0 2017-04-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to modify MVLAN tag mode of ONU profile remote-profile on
NE 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.16.20T110 2016-10-31 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-4-27 New Command
Parameters：
ONUPROFILENAME
7.1.70 CHG-ONUPORT-PACKETFILTER【【【Change ONU Port Packet
Filter】】】
l Description
This command is used to change the packet filter of ONU port .
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series
MSAN C300Mv4 Series
7-211
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Command Format
CHG-ONUPORT-PACKETFILTER::(DID=device-id|DNAME=device-name)[,PID=port-id],
OID=onu-id,ONUPORT=onu-port:CTAG::[PORTTYPE=port-type][,IPV4MULTICAST=
ipv4-multicast][,IPV6MULTICAST=ipv6-multicast][,IPV4BROADCAST=ipv4-broadcast]
[,RARP=rarp][,IPX=ipx][,NETBEUI=netbeui][,APPLETALK=apple-talk][,BPDU=bpdu]
[,ARP=arp][,PPPOE=pppoe];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
ONUPORT String [rack-][shelf-][slo-
t-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
7-212
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
PORTTYPE String Ethernet
IpHost
Port Type
If not input, the default
port type is Ethernet
Optional
IPV4MUL-
TICAST
String Forward
Discard
IPv4 Multicast Filter Optional
IPV6MUL-
TICAST
String Forward
Discard
IPv6 Multicast Filter Optional
IPV4BROA-
DCAST
String Forward
Discard
IPv4 Broadcast Filter Optional
RARP String Forward
Discard
RARP Filter Optional
IPX String Forward
Discard
IPX Filter Optional
NETBEUI String Forward
Discard
Net BEUI Filter Optional
AP-
PLETALK
String Forward
Discard
Apple Talk Filter Optional
BPDU String Forward
Discard
BPDU Filter Optional
ARP String Forward
Discard
ARP Filter Optional
PPPOE String Forward
Discard
PPPoE Filter Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONUPORT-PACKETFILTER::DID=10.63.204.51,OID=1-1-5-7-1,ONUPORT=2
:CTAG::PORTTYPE=Ethernet,IPV4MULTICAST=Forward,BPDU=Discard;
7-213
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Response:
0 2016-11-10 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the packet filter of
Rack1/Shelf1/Slot5/Port7/ONU1/UNI2 on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.17.20T115 2016-11-15 New TL1 Command
7.1.71 BND-ONU-ONUPROFILE【【【Bind ONU Profile to ONU】】】
l Description
This command is used to bind ONU profile to ONU.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series/C600
Series
MSAN C300Mv4 Series
l Command Format
BND-ONU-ONUPROFILE::(DID=device-ID|DNAME=device-name)[,PID=port-id],
OID=onu-id:CTAG::(ONUPROFILENAME=onu-profile-name
|(ONULINEPROFILENAME=onu-line-profile-name,ONUREMOTEPROFILE-
NAME=onu-remote-profile-name));
l Operated Target Identifier
7-214
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUPRO-
FILENAME
String SIZE(1-32) ONU Profile Name Required Under Cer-
tain Conditions:Must
choose one between
ONUPROFILENAME
and (ONULINE-
PROFILENAME，
ONUREMOTEPRO-
FILENAME)
ONULINE-
PROFILE-
NAME
String SIZE(1-32) ONU Line Profile Name Required Under Cer-
tain Conditions:Must
choose one between
ONUPROFILENAME
and (ONULINE-
PROFILENAME，
ONUREMOTEPRO-
FILENAME)
7-215
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
ONURE-
MOTEPRO-
FILENAME
String SIZE(1-32) ONU Remote Profile
Name
Required Under Cer-
tain Conditions:Must
choose one between
ONUPROFILENAME
and (ONULINE-
PROFILENAME，
ONUREMOTEPRO-
FILENAME)
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
BND-ONU-ONUPROFILE::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::
ONUPROFILENAME=testOnuProfile;
Response：
0 2013-08-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to bind ONU profile testOnuProfile to
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.204.51.
Command 2:
BND-ONU-ONUPROFILE::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::
ONULINEPROFILENAME=testOnuLineProfile,ONUREMOTEPROFILENAME
=testOnuRemoteProfile;
Response：
0 2013-08-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
7-216
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Remark:
This command is used to bind ONU line profile testOnuLineProfile and ONU remote
profile testOnuRemoteProfile to Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.204.51.
Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-08-20 New TL1 Command
NetNumenU31R20V12.14.20T80 2014-10-22 New Command Parame-
ters: ONUREMOTEPRO-
FILENAME,ONULINEPRO-
FILENAME
7.1.72 UBND-ONU-ONUPROFILE【【【Unbind ONU Profile from
ONU】】】
l Description
This command is used to unbind ONU profile from ONU.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
UBND-ONU-ONUPROFILE::(DID=device-ID|DNAME=device-name)[,PID=port-id],
OID=onu-id:CTAG::;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-217
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) OptionalOID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
None.
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
UBND-ONU-ONUPROFILE::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::;
Response：
0 2013-08-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
7-218
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Remark:
This command is used to unbind ONU profile form Rack1/Shelf1/Slot5/Port7/ONU1
on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-08-20 New TL1 Command
7.1.73 RESTORE-ONUFACTORYCONF【【【Restore ONU Factory
Settings】】】
l Description
This command is used to restore ONU factory settings.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C600 Series
PON ONU F820/LAN-MDU Series/xDSL-MDU Series
l Command Format
RESTORE-ONUFACTORYCONF::(DID=device-id|DNAME=device-name)[,OID=onu-id]:
CTAG::;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
7-219
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DNAME String SIZE(1-32) NE Name Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Optional: Required
if DID or DNAME
indicates the OLT
device. Not required
if DID or DNAME
indicates the MDU
device.
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
RESTORE-ONUFACTORYCONF::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::;
Response:
NETSH180492D1 2014-01-22 10:34:48
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to restore factory settings of Rack1/Shelf1/Slot5/Port7/ONU1
on OLT 10.63.156.26.
Command 2:
RESTORE-ONUFACTORYCONF::DID=10.63.204.101:CTAG::;
Response:
NETSH180492D1 2014-01-22 10:40:15
M CTAG COMPLD
7-220
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
EN=0 ENDESC=No Error
;
Remark:
This command is used to restore factory settings of the MDU 10.63.204.101.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.13.40T70 2014-1-26 New TL1 Command
7.1.74 CHG-ONUUNI-PON【【【Change ONU UNI Configuration】】】
l Description
This command is used to change ONU UNI configuration.
l Applicable NE
NE
Category
NE Type Notes
PON OLT C220v1.1/C220v1.2/C300 Series/C300v2 Series/C300v3 Series/C600
Series
PON ONU F820/LAN-MDU Series/xDSL-MDU Series
l Command Format
CHG-ONUUNI-PON::(DID=device-id|DNAME=device-name)[,OID=onu-id],ONU-
PORT=onu-port:CTAG::[PORTTYPE=port-type][,STATUS=status]
[,BWTEMPLATE=bw-template][,PVC=pvc][,VLANMODE=vlan-mode,PVLAN=
pvlan,CVLAN=CVLAN][,ACCESSMODE=access-mode][,IPRETRIEVEMODE=
ip-retrieve-mode]
[,ALARMNAME=alarm-name,ALARMREPORTCONTROL=alarm-report-control];
l Operated Target Identifier
7-221
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Optional
ONUPORT String [rack-][shelf-][slot-]
port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2:rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
PORTTYPE String Ethernet
MulticastGEMPort
UnicastGEMPort
WiFi
VEIP
WAN
UNI Port Type Optional
If not input, the default
UNI type is Ethernet.
STATUS String enable
disable
UNI Port
Administrative Status
Optional
BWTEM-
PLATE
String SIZE(0-63) Bandwidth Profile
Name
Optional
7-222
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
PVC String SIZE(0-32) PVC NO.
Required only when
UNI is DSL
Optional
VLANMODE String tag
transparent
translate
trunk
hybrid
VLAN Mode Optional
PVLAN Integer 0-4094 TLS VLAN Optional
CVLAN String SIZE(0-100) Format is : PVID-TAG-
VLAN1/TAGVLAN2…
If PVID is -1, it is not
configured.
Optional
ACCESS-
MODE
String oam
snmp
Access Mode
If not input, MDU uses
SNMP, and SFU uses
OAM.
Optional
IPRETRIEV-
EMODE
String NoControl
FromONU
FromNetwork
Forbidden
DHCP IP Address
Retrieving Mode of
ETH UNI，supported
by GPON SFU.
NoControl: DHCP IP
address is retrieved
from ONU or network.
FromONU: DHCP IP
address is retrieved
from ONU.
FromNetwork: DHCP
IP address is retrieved
from network.
Forbidden: DHCP IP
address retrieving is
forbidden.
Optional
ALARM-
NAME
String SelfLoopbacked ONU Port Alarm
Name
Only supported by
EPON.
Optional
ALARMRE-
PORTCON-
TROL
String Enable
Disable
Alarm Report Control
Only supported by
EPON.
Optional
7-223
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONUUNI-PON::DID=10.46.41.14,OID=1-1-8-1-1,PORT=1:CTFG::STATUS=en-
able,VLANMODE=hyrbid,PVLAN=0,CVLAN=100-46/85/309;
Response：
NETSH180492D1 2012-07-03 17:54:48
M CTFG COMPLD
EN=0 ENDESC=No Error
;
Remark：
This command is used to change configuration of
Rack1/Shelf1/Slot8/Port1/ONU1/ETHUNI1 on OLT 10.46.41.14. Administrative
status is set to enable, VLAN mode is set to Hybrid, PVLAN is set to 0, PVID is set to
100, and tagged VLAN 46,85 309 are bound to this port.
Command 2:
CHG-ONUUNI-PON::DID=10.46.41.157,PORT=2-1:CTFG::STATUS=enable;
Response：
NETSH180492D1 2012-07-12 08:54:48
M CTFG COMPLD
EN=0 ENDESC=No Error
;
Remark：
This command is used to enable administrative status of Slot2/Port1 on MDU
10.46.41.157.
Command 3：
CHG-ONUUNI-PON::DID=DID=10.46.41.14,OID=1-1-8-1-1,ONUPORT=1:CTFG::
PORTTYPE=VEIP,VLANMODE=Tag,CVLAN=100;
Response：
7-224
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
NETSH180492D1 2014-03-20 11:15:22
M CTFG COMPLD
EN=0 ENDESC=No Error
;
Remark：
This command is used to change configuration of
Rack1/Shelf1/Slot8/Port1/ONU1/VEIPUNI1 on OLT 10.46.41.14. VLAN mode is set
to Tag, PVID is set to 100.
Command 4：
CHG-ONUUNI-PON::DID=DID=10.46.41.14,OID=1-1-8-1-1,ONUPORT=1:CTFG::
IPRETRIEVEMODE=FromNetwork;
Response：
NETSH180492D1 2014-09-09 10:35:12
M CTFG COMPLD
EN=0 ENDESC=No Error
;
Remark：
This command is used to change the DHCP IP address retrieving mode of
Rack1/Shelf1/Slot8/Port1/ONU1/ETHUNI1 on OLT 10.46.41.14.DHCP IP address of
the Ethernet UNI will be retrieved from network.
Command 5：
CHG-ONUUNI-PON::DID=DID=10.46.41.14,OID=1-1-8-1-1,ONUPORT=1:CTFG::ALARMNAME=SelfLoopbacked,ALARMREPORTCONTROL=Enable;
Response：
NETSH180492D1 2017-03-08 10:35:12
M CTFG COMPLD
EN=0 ENDESC=No Error
;
Remark：
This command is used to enable the self-loopbacked alarm report of
Rack1/Shelf1/Slot5/Port7/ONU1/Ethernet port 1 on 10.46.41.14.
Average Command Response Time
Scenario Average Response Time (s)
l Notes
7-225
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.13.40T70 2014-03-20 New Command Parameters: PORTTYPE
NetNumenU31R20V12.14.20T80 2014-09-09 New Command Parameters:
IPRETRIEVEMODE
NetNumenU31R20V12.17.20T115 2017-3-9 New Command Parameters: ALARM-
NAME， ALARMREPORTCONTROL
7.1.75 UPDATE-ONU-SOFTWARE【【【Update ONU Software】】】
l Description
This command is used to update the software of ONU.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
UPDATE-ONU-SOFTWARE::(DID=device-id|DNAME=device-name),PID=port-id:CTAG::
SWVER=software-version,ONULIST=onu-list;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
7-226
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
SWVER String SIZE(1-64) ONU Software Version Required
ONULIST String SIZE(1-500) ONU List (e.g.
1-5/8/10)
Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
UPDATE-ONU-SOFTWARE::DID=10.63.204.51,PID=1-1-5-7:CTAG::SWVER=f460914.bin,
ONULIST=1-2/7;
Response：
0 2017-04-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to update the software version of
Rack1/Shelf1/Slot5/Port7/ONU1 ONU2 ONU7 on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
7-227
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Revision History
Revision Date Notes
NetNumenU31R20V12.17.20T120 2017-4-25 New TL1 Command
7.1.76 CHG-ONUWIFI【【【Change ONU WiFi configuration】】】
l Description
This command is used to change ONU WiFi configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3
Series/C600 Series
MSAN C300Mv4 Series
l Command Format
CHG-ONUWIFI::(DID=device-id|DNAME=device-name),OID=onu-id:CTAG::
WIFIID=wifi-id[,CHANNEL=channel][,ADMINSTAT=admin-stat]
[,RADIOMEASENABLING=radio-meas-enabling][,ISOLATIONENABLING=isolation-enabling]
[,WORKINGMODE=working-mode][,SGIENABLING=sgi-enabling]
[,REGULATORYDOMAIN=regulatory-domain][,CHANNELBANDWIDTH=channel-bandwidth]
[,QOSTYPE=qos-type][,TXRATE=tx-rate][,TXPOWER=tx-power];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
7-228
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter Name Type Value Range Description Optional
Description
WIFIID Integer 1-8 WiFi ID Required
CHANNEL String 1-13
Auto
WiFi Channel Optional
ADMINSTAT String Enable
Disable
Administrative
Status
Optional
RADIOMEASEN-
ABLING
String Enable
Disable
Radio
Measurement
Enabling
Optional
ISOLATIONEN-
ABLING
String Enable
Disable
Isolation Enabling Optional
WORKINGMODE String 802Dot11b
802Dot11g
802Dot11n
802Dot11b-11g
802Dot11b-11g-
11n
Working Mode Optional
SGIENABLING String Enable
Disable
SGI Enabling Optional
Valid when
WORKING-
MODE is
802Dot11n or
802Dot11b-11g-
11n
7-229
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
REGULATORYDO-
MAIN
String Other
USA
Canada
ETSI
Spain
France
MKK
China
Russia
Brazil
Egypt
Germany
Greece
Hongkong
Italy
Korea
UK
Portugal
Lithuania
Regulatory Domain Optional
CHANNELBAND-
WIDTH
String 20MHz
40MHz
Channel Bandwith Optional
Valid when
WORKING-
MODE is
802Dot11n or
802Dot11b-11g-
11n
QOSTYPE String Disable
WMM
SSID
QoS Type Optional
TXRATE String Auto
1Mbps
2Mbps
5Dot5Mbps
6Mbps
9Mbps
11Mbps
12Mbps
18Mbps
24Mbps
36Mbps
48Mbps
54Mbps
Transmitting Rate Optional
7-230
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
TXPOWER String 100Percent
80Percent
60Percent
40Percent
20Percent
Transmitting Power Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to 5 Unified Error Code Defination for more details.
l Example
Command 1:
CHG-ONUWIFI::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::WIFIID=1,CHANNEL=Auto;
Response:
ZTE-SH10083644D01 2013-08-30 10:41:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change channel to automatic in WiFi1 of
Rack1/Shelf1/Slot5/Port7/ONU1 on NE 10.63.156.26.
Command 2:
CHG-ONUWIFI::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::WIFIID=1,ADMINSTAT=Enable,
REGULATORYDOMAIN=China,WORKINGMODE=802Dot11b-11g-11n,TXRATE=12Mbps,
TXPOWER=80Percent;
Response:
ZTE-SH10083644D01 2017-05-04 10:41:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
7-231
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
This command is used to change WiFi configuration in WiFi1 of
Rack1/Shelf1/Slot5/Port7/ONU1 on NE 10.63.156.26.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.13.40T60 2013-12-17 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-5-4 Change CHANNEL from
Required to Optional
New Command
Parameters：
ADMINSTAT,
RADIOMEASENABLING,
ISOLATIONENABLING,
SGIENABLING,
WORKINGMODE,
REGULATORYDOMAIN,
CHANNELBANDWIDTH,
QOSTYPE, TXRATE,
TXPOWER
7.1.77 CHG-ONUWIFISSID【【【Change WiFi SSID】】】
l Description
This command is used to change WiFi SSID configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
CHG-ONUWIFISSID::(DID=device-id|DNAME=device-name),OID=onu-id:CTAG::
7-232
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
WIFIID=wifi-id,SSID=ssid,ADMINSTAT=administrative-status
[,SSIDNAME=ssid-name][,HIDEENABLING=hide-enabling]
[,ISOLATIONENABLING=isolation-enabling][,MAXUSERNUM=maximum-user-number]
[,AUTHALG=authentication-algorithms][,WEPENCRYPTENABLING=wep-encryption-enabling,
WEPKEYLEN=wep-key-length,WEPKEYFORMAT=wep-key-format,
WEPKEYVALUE=wep-key-value,WEPDEFAULTKEY=wep-default-key]
[,ENCRYPT=encrypt,PASSWORD=password,
PWDUPDATEINTERVAL=password-update-interval];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
OID String rack-shelf-slot-port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional
Description
WIFIID Inte-
ger
1-8 WiFi ID Required
SSID Inte-
ger
1-8 WiFi SSID Required
ADMINSTAT String Enable
Disable
SSID Administrative Status Required
7-233
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
SSIDNAME String SIZE(1-32) SSID Name Optional
HIDEEN-
ABLING
String Enable
Disable
Hide Enabling Optional
ISOLATIO-
NENABLING
String Enable
Disable
Isolation Enabling Optional
MAXUSER-
NUM
Inte-
ger
1-65535 Maximum User Number Optional
AUTHALG String OpenSystem
SharedKey
WpaPsk
Wpa2Psk
WpaPskAnd-
Wpa2Psk
SSID Authentication Algorithms Optional
WEPEN-
CRYPTEN-
ABLING
String Enable
Disable
WEP Encryption Enabling Optional
Valid if
AUTHALG is
OpenSystem or
SharedKey
WEP-
KEYLEN
String 64
128
WEP Key Length Optional
Valid if
AUTHALG is
OpenSystem or
SharedKey
WEPKEY-
FORMAT
String ASCII
Hex
WEP Key Format Optional
Valid if
AUTHALG is
OpenSystem or
SharedKey
WEPKEY-
VALUE
String SIZE(23|43|55
|107)
WEP Key Value
The WEP encryption key value
that consists of four groups ASCII
or hex value, format as follows:
WEPKEYLEN + WEPKEYFOR-
MAT
64 + ASCII -- each group consists
of 5 bytes string
128 + ASCII -- each group consists
of 13 bytes string
Optional
Valid if
AUTHALG is
OpenSystem or
SharedKey
7-234
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
64 + Hex -- each group consists of
10 bytes hex string
128 + Hex -- each group consists
of 26 bytes hex string
e.g.
64 + ASCII：
a1b2c/3d4e5/6f7g8/h9i0j
64 + Hex：
123456ABCD/ABCD123456/432
DEF3245/A123456789
WEPDE-
FAULTKEY
Inte-
ger
1-4 WEP Default Key Optional
Valid if
AUTHALG is
OpenSystem or
SharedKey
ENCRYPT String Aes
Tkip
Wep
WPA Encryption Algorithm
Support multiple choices. The
algorithm should be separated by
a left slash if multiple ones are
selected
e.g. Aes/Tkip/Wep
Optional
Valid if
AUTHALG is
WpaPsk ,
Wpa2Psk or
WpaPskAnd-
Wpa2Psk
7-235
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
PASSWORD String SIZE(8-63) WPA Encryption Key Value Optional:
Valid if
AUTHALG is
WpaPsk ,
Wpa2Psk or
WpaPskAnd-
Wpa2Psk
PWDUP-
DATEINTER-
VAL
Inte-
ger
100–1000 WPA Encryption Key Updating
Interval(s)
if not input, the default interval is
600s
Optional
Valid if
AUTHALG is
WpaPsk ,
Wpa2Psk or
WpaPskAnd-
Wpa2Psk
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to 5 Unified Error Code Defination for more details.
l Example
Command 1:
CHG-ONUWIFISSID::DID=10.63.156.26,OID=1-1-5-7-1,ONUPORT=1:CTAG::WIFIID=1,
SSID=1,ADMINSTAT=Enable,SSIDNAME=zte-Test;
Response:
ZTE-SH10083644D01 2013-08-30 10:41:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to activate SSID1 in WiFi1 of Rack1/Shelf1/Slot5/Port7/ONU1
on 10.63.156.26, and set the name to zte-Test.
7-236
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Command 2:
CHG-ONUWIFISSID::DID=10.63.156.26,OID=1-1-11-3-1:CTAG::WIFIID=1,
SSID=1,ADMINSTAT=Enable,SSIDNAME=zte-Test,AUTHALG=WpaPskAndWpa2Psk,
ENCRYPT=Aes/Tkip,PASSWORD=telsurzte1;
Response:
ZTE-SH10083644D01 2013-08-30 10:41:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This comman is used to activate SSID1 in WiFi1 of Rack1/Shelf1/Slot11/Port3/ONU1
on 10.63.156.26, and set the name to zte-Test, change the desirable authentication
algorithms and assign the WPA password.
Command 3:
CHG-ONUWIFISSID::DID=10.63.156.26,OID=1-1-11-3-1:CTAG::WIFIID=1,SSID=1,
ADMINSTAT=Enable,ADMINSTAT=Enable,SSIDNAME=zte-Test,AUTHALG=OpenSystem,
WEPENCRYPTENABLING=Enable,WEPKEYLEN=64,WEPKEYFORMAT=ASCII,
WEPKEYVALUE=12345/67890/12345/67890,WEPDEFAULTKEY=1;
Response:
ZTE-SH10083644D01 2017-05-03 11:21:12
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to activate SSID1 inWiFi1 of Rack1/Shelf1/Slot11/Port3/ONU1
on 10.63.156.26, and set the name to zte-Test, change the desirable authentication
algorithms and assign the WEP password.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
7-237
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Revision Date Notes
NetNumenU31R20V12.13.40T60 2013-12-17 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-5-3 New Command Parameters：
HIDEENABLING,ISOLATIONEN-
ABLING,
MAXUSERNUM,WEPEN-
CRYPTENABLING,
WEPKEYLEN,WEPKEYFORMAT,
WEPKEYVALUE,WEPDEFAULT-
KEY
New Command Parameter
Values：
OpenSystem, SharedKey for
AUTHALG
7.1.78 CRT-ONU-MGCUSER【【【Create ONU MGC User】】】
l Description
This command is used to create ONU MGC user information.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
CRT-ONU-MGCUSER::(DID=device-id|DNAME=device-name)[,PID=port-id][,OID=onu-id],
ONUPORT=onu-port:CTAG::[ONUPROFILENAME=onu-profile-name,]
MGCPROFILENAME=mgc-profile-name[,SIGNALCODE=signal-code]
[,MEDIAPROFILENAME=media-profile-name];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-238
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
ONUPORT String [rack-][shelf-][slo-
t-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile Name Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
MGCPRO-
FILENAME
String SIZE(1-64) MGC Profile Name Required
7-239
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
SIGNAL-
CODE
String LoopStart
GroundStart
LoopReverseBat-
tery
CoinFirst
DialToneFirst
Multiparty
Signal Code Optional
MEDI-
APROFILE-
NAME
String SIZE(1-64) Media Profile Name Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONU-MGCUSER::DID=10.63.204.51,OID=1-1-5-7-1,ONUPORT=1:CTAG::
MGCPROFILENAME=mgcprofile,SIGNALCODE=LoopStart;
Response:
0 2017-04-28 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create the ONU MGC user of Rack1/
Shelf1/Slot5/Port7/ONU1/POTS1 on NE 10.63.204.51.
Command 2：：：
CRT-ONU-MGCUSER::DID=10.63.204.51,ONUPORT=1:CTAG::
ONUPROFILENAME=remote-profile,MGCPROFILENAME=mgcprofile,
MEDIAPROFILENAME=mediaprf;
Response:
0 2017-04-28 10:55:49
7-240
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create the ONU MGC user from ONU profile remote-profile
on NE 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.17.20T120 2017-4-28 New TL1 Command
7.1.79 DLT-ONU-MGCUSER【【【Delete ONU MGC User】】】
l Description
This command is used to delete ONU MGC user information.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
DLT-ONU-MGCUSER::(DID=device-id|DNAME=device-name)[,PID=port-id][,OID=onu-id],
ONUPORT=onu-port:CTAG::[ONUPROFILENAME=onu-profile-name];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-241
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
ONUPORT String [rack-][shelf-][slo-
t-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile Name Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
7-242
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
DLT-ONU-MGCUSER::DID=10.63.204.51,OID=1-1-5-7-1,ONUPORT=1:CTAG::;
Response:
0 2017-04-28 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete the ONU MGC user of Rack1/
Shelf1/Slot5/Port7/ONU1/POTS1 on NE 10.63.204.51.
Command 2：：：
DLT-ONU-MGCUSER::DID=10.63.204.51,ONUPORT=1:CTAG::
ONUPROFILENAME=remote-profile;
Response:
0 2017-04-28 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete the ONU MGC user of POTS1 from ONU profile
remote-profile on NE 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.17.20T120 2017-4-28 New TL1 Command
7-243
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
7.1.80 DLT-ONU-STATICROUTE【【【Delete ONU Static Route】】】
l Description
This command is used to delete an ONU static route.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
DLT-ONU-STATICROUTE::(DID=device-id|DNAME=device-name)[,PID=port-id]
[,OID=onu-id]:CTAG::[ONUPROFILENAME=onu-profile-name],DESTIPADDRESS=
destination-ipaddress,DESTIPMASK=destination-ip-mask;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional
Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-por Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-port-
onu
MacAddress
SN/LOID/Password
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
7-244
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Command Parameter
Parameter
Name
Type Value Range Description Optional
Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile Name Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
DESTIPAD-
DRESS
IpAd-
dress
Destination IP
Address
Required
DESTIPMASK IpAd-
dress
Destination IP
Address Mask
Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, IDNE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
DLT-ONU-STATICROUTE::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::
DESTIPADDRESS=100.200.7.0,DESTIPMASK=255.255.255.0;
Response:
0 2017-05-17 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete a static route of Rack1/Shelf1/Slot5/Port7/ONU1 on
10.63.204.233.
Command 2:
7-245
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DLT-ONU-STATICROUTE::DID=10.63.204.233:CTAG::ONUPROFILENAME=
remote-profile,DESTIPADDRESS=100.200.7.0,DESTIPMASK=255.255.255.0;
Response:
0 2017-05-17 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete a static route from ONU profile remote-profile on NE
10.63.204.233.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.17.20T120 2017-5-17 New TL1 Command
7.1.81 CRT-ONU-TCONTBWPROFILE【【【Create ONU TCONT
Bandwidth Profile】】】
l Description
This command is used to create ONU TCONT bandwidth profile.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
CRT-ONU-TCONTBWPROFILE::(DID=device-id|DNAME=device-name):CTAG::
PROFILENAME=profile-name,BWTYPE=bandwidth-type[,FIXEDBW=fixed-bandwidth]
7-246
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
[,ASSUREDBW=assured-bandwidth][,MAXIMUMBW=maximum-bandwidth]
[,PRIORITY=priority][,WEIGHT=weight];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
l Command Parameter
Parameter Name Type Value Range Description Optional
Description
PROFILENAME String SIZE(1-64) Profile Name Required
BWTYPE String Fixed
Assured
AssuredAndNonassured
BestEffort
All
Bandwidth
Type
Required
7-247
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
FIXEDBW Integer 64-9953280 Fixed
Bandwidth
Unit: kbps
Required
Under Certain
Conditions:
BWTYPE is
Fixed or
All
ASSUREDBW Integer 64-9953280 Assured
Bandwidth
Unit: kbps
Required
Under Certain
Conditions:
BWTYPE is
Assured,
AssuredAnd-
Nonassured or
All
MAXIMUMBW Integer 64-9953280 Maximum
Bandwidth
Unit: kbps
Required
Under Certain
Conditions:
BWTYPE is
AssuredAnd-
Nonassured,
BestEffort or
All
PRIORITY Integer 1-4 Priority Optional: Valid
if BWTYPE is
BestEffort or
All
7-248
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
WEIGHT Integer 1-1000 Weight Optional: Valid
if BWTYPE is
BestEffort or
All
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONU-TCONTBWPROFILE::DID=10.63.204.51:CTAG::
PROFILENAME=test,BWTYPE=Fixed,FIXEDBW=1000;
Response:
0 2017-04-27 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create ONU TCONT bandwidth profile test
with BWTYPE Fixed on 10.63.204.51.
Command 2:
CRT-ONU-TCONTBWPROFILE::DID=10.63.204.51:CTAG::PROFILENAME=test,BWTYPE=Assured,ASSUREDBW=2000;
Response:
0 2017-04-27 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
7-249
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
;
Remark:
This command is used to create ONU TCONT bandwidth profile test
with BWTYPE Assured on 10.63.204.51.
Command 3:
CRT-ONU-TCONTBWPROFILE::DID=10.63.204.51:CTAG::
PROFILENAME=test,BWTYPE=AssuredAndNonassured,
ASSUREDBW=2000,MAXIMUMBW=3000;
Response:
0 2017-04-27 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create ONU TCONT bandwidth profile test
with BWTYPE AssuredAndNonassured on 10.63.204.51.
Command 4:
CRT-ONU-TCONTBWPROFILE::DID=10.63.204.51:CTAG::
PROFILENAME=test,BWTYPE=BestEffort,
MAXIMUMBW=3000,PRIORITY=1,WEIGHT=100;
Response:
0 2017-04-27 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create ONU TCONT bandwidth profile test
with BWTYPE BestEffort on 10.63.204.51.
Command 5:
CRT-ONU-TCONTBWPROFILE::DID=10.63.204.51:CTAG::
PROFILENAME=test,BWTYPE=All,FIXEDBW=1000,
ASSUREDBW=2000,MAXIMUMBW=3000,PRIORITY=1,WEIGHT=100;
Response:
0 2017-04-27 10:55:49
7-250
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create ONU TCONT bandwidth profile test
with BWTYPE All on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.17.20T120 2017-4-27 New TL1 Command
7.1.82 DLT-ONU-TCONTBWPROFILE【【【Delete ONU TCONT
Bandwidth Profile】】】
l Description
This command is used to delete ONU TCONT bandwidth profile.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
DLT-ONU-TCONTBWPROFILE::(DID=device-id|DNAME=device-name):CTAG::
PROFILENAME=profile-name;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-251
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
PROFILE-
NAME
String SIZE(1-64) Profile Name Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
DLT-ONU-TCONTBWPROFILE::DID=10.63.204.51:CTAG::
PROFILENAME=test;
Response:
0 2017-04-27 10:56:29
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
7-252
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
This command is used to delete ONU TCONT bandwidth profile test on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.17.20T120 2017-4-27 New TL1 Command
7.1.83 CRT-ONU-WANIP【【【Create ONU WAN IP】】】
l Description
This command is used to create an ONU WAN IP.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
CRT-ONU-WANIP::(DID=device-id|DNAME=device-name)[,PID=port-id][,OID=onu-id]
:CTAG::[ONUPROFILENAME=onu-profile-name][,IPADDRTYPE=ip-address-type],
IPHOSTID=iphost-id,VLANPROFILENAME=vlan-profile-name,IPMODE=ip-mode[,
IPPROFILENAME=ipprofile-name][,IP=ip-address][,IPPREFIXLENGTH=
ip-prefix-length][,PPPOEMODE=pppoe-mode][,PPPOEUSER=pppoeuser]
[,PPPOEPWD=pppoe-pwd][,PPPOESERVICENAME=pppoe-service-name]
[,ONUIDENTIFIER=onuidentifier][,RSPPINGENABLING][,RSPTRACERSENABLING];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-253
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
por
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile NAME Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
IPADDR-
TYPE
String IPv4
IPv6
IP Address Type Optional
IPHOSTID Integer 1-255 IP Host ID Required
VLANPRO-
FILENAME
String SIZE(1-64) VLAN Profile Name Required
IPMODE String Static
PPPoE
DHCP
IP Configuration Mode
Static: Static IP
PPPoE: PPPoE
DHCP: DHCP
Required
7-254
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
IPPROFILE-
NAME
String SIZE(1-64) IP Profile Name Optional:
Valid if IPMODE is
Static
IP String IpAddress IP Address Optional:
Valid if IPMODE is
Static
IPPRE-
FIXLENGTH
Integer 0–128 IP Prefix Length Optional:
Valid if IPMODE is
Static
PPPOE-
MODE
String Auto
Chap
Pap
PPPoE Mode Optional
Valid if IPMODE is
PPPoE
PP-
POEUSER
String SIZE(1-32) PPPoE User Name Optional:
Valid if IPMODE is
PPPoE
PPPOEPWD String SIZE(1-32) PPPoE Password Optional:
Valid if IPMODE is
PPPoE
PPPOESER-
VICENAME
String SIZE(1-60) PPPoE Service Name Optional:
Valid if IPMODE is
PPPoE
ONUIDENTI-
FIER
String SIZE(1-25) ONU Identifier Optional
Valid if IPMODE is
DHCP
RSPPIN-
GENABLING
String Enable Disable Respond to Pings
Enabling
Optional
RSPTRAC-
ERSEN-
ABLING
String Enable Disable Respond to Router
Solicitation Enabling
Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
7-255
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONU-WANIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::VLANPROFILENAME
=VLAN100,IPHOSTID=1,IPMODE=PPPoE,PPPOEUSER=zte,PPPOEPWD=ztewan;
Response:
ZTE-SH10083644D01 2017-05-17 10:01:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create an ONU WAN IP information of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IP allocation mode is PPPoE.
Command 2:
CRT-ONU-WANIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::VLANPROFILENAME
=VLAN100,IPHOSTID=1,IPMODE=DHCP;
Response:
ZTE-SH10083644D01 2017-05-17 10:01:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create an ONU WAN IP information of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IP allocation mode is DHCP.
Command 3:
CRT-ONU-WANIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::VLANPROFILENAME
=VLAN100,IPHOSTID=1,IPMODE=Static,IPPROFILENAME=ipProfile,
IP=10.63.204.220,IPPREFIXLENGTH=24,RSPPINGENABLING=Enable,
RSPTRACERSENABLING=Enable;
Response:
ZTE-SH10083644D01 2017-05-17 10:01:22
7-256
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create an ONU WAN IP information of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IP allocation mode is Static.
Command 4:
CRT-ONU-WANIP::DID=10.63.156.26:CTAG::ONUPROFILENAME=remote-profile,
VLANPROFILENAME=VLAN100,IPHOSTID=1,IPMODE=DHCP;
Response:
ZTE-SH10083644D01 2017-05-1710:01:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create a WAN IP of ONU profile remote-profile on NE
10.63.156.26.
Command 5:
CRT-ONU-WANIP::DID=10.63.156.26,OID=1-1-5-7-1:CTAG::IPADDRTYPE=IPv6,
VLANPROFILENAME=VLAN100,IPHOSTID=1,IPMODE=PPPoE,PPPOEUSER=zte,
PPPOEPWD=ztewan;
Response:
ZTE-SH10083644D01 2017-09-17 10:01:22
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create an ONU IPv6 WAN IP information of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IP allocation mode is PPPoE.
Command 6:
CRT-ONU-WANIP::DID=10.63.204.232,OID=1-1-4-1-7:CTAG::
IPADDRTYPE=IPv6,VLANPROFILENAME=VLAN35,IPMODE=Static,IPHOSTID=1,
IPPROFILENAME=lzz,IP="1:1:1:1:1:1:1:1";
Response:
ZTE-SH10083644D01 2017-09-17 10:01:22
M CTAG COMPLD
7-257
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
EN=0 ENDESC=No Error
;
Remark:
This command is used to create an ONU IPv6 WAN IP information of
Rack1/Shelf1/Slot5/Port7/ONU1 on 10.63.156.26, and IP allocation mode is Static.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.17.20T120 2017-5-17 New TL1 Command
NetNumenU31R20V12.17.20T125 2017-9-24 New Command Parameters：
IPADDRTYPE
7.1.84 CRT-ONUPROFILE【【【Create ONU Profile】】】
l Description
This command is used to create an ONU profile.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
CRT-ONUPROFILE::(DID=device-id|DNAME=device-name):CTAG::
PROFILETYPE=profile-type,PROFILENAME=profile-name;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-258
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional
Description
PROFILETYPE String Line
Remote
Profile Type Required
PROFILENAME String SIZE(1-64) Profile Name Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONUPROFILE::DID=10.63.204.232:CTAG::PROFILETYPE=Line,PROFILENAME=line-profile;
Response:
0 2017-04-25 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create an ONU line profile line-profile on NE 10.63.204.51.
l Average Command Response Time
7-259
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.17.20T120 2017-4-25 New TL1 Command
7.1.85 DLT-ONUPROFILE【【【Delete ONU Profile】】】
l Description
This command is used to delete an ONU profile.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series/C600 Series
MSAN C300Mv4 Series
l Command Format
DLT-ONUPROFILE::(DID=device-id|DNAME=device-name):CTAG::
PROFILETYPE=profile-type,PROFILENAME=profile-name;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
l Command Parameter
7-260
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Parameter Name Type Value Range Description Optional Description
PROFILETYPE String Line
Remote
Profile Type Required
PROFILENAME String SIZE(1-64) Profile Name Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
DLT-ONUPROFILE::DID=10.63.204.232:CTAG::PROFILETYPE=Line,PROFILENAME=line-profile;
Response:
0 2017-04-25 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete an ONU line profile line-profile on NE 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.17.20T120 2017-4-25 New TL1 Command
7-261
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
7.1.86 CHG-ONU-DMZ【【【Change ONU Demilitarized Zone】】】
l Description
This command is used to change ONU demilitarized zone configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series
MSAN C300Mv4 Series
l Command Format
CHG-ONU-DMZ::(DID=device-id|DNAME=device-name)[,PID=port-id],OID=onu-id
:CTAG::[DMZENABLING=dmz-enabling][,IPHOSTID=ip-host-id]
[,LANHOSTIPTYPE=lan-host-ip-type][,LANHOSTIP=lan-host-ip];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
7-262
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Parameter Name Type Value Range Description Optional
Description
DMZENABLING String Enable
Disable
Demilitarized
Zone Enabling
Status
Optional
IPHOSTID Integer 1-255 IP Host ID Optional
LANHOSTIPTYPE String IPv4
IPv6
LAN Host IP Type
The default value
is IPv4
Optional
LANHOSTIP String IpAddress LAN Host IP Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONU-DMZ::DID=10.63.173.78,OID=1-1-2-1-1:CTAG::DMZENABLING=Enable,IPHOSTID=1,
LANHOSTIPTYPE=IPv4,LANHOSTIP=13.1.1.13;
Response:
0 2017-09-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the ONU demilitarized zone configuration of Rack1/
Shelf1/Slot2/Port1/ONU1 on NE 10.63.173.78.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
7-263
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Revision History
Revision Date Notes
NetNumenU31R20V12.17.20T125 2017-9-22 New TL1 Command
7.1.87 CHG-ONU-UPNP【【【Change ONU UPnP Configuration】】】
l Description
This command is used to change the ONU UPnP configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series
MSAN C300Mv4 Series
l Command Format
CHG-ONU-UPNP::(DID=device-id|DNAME=device-name),[PID=port-id,]OID=onu-id:CTAG::
UPNPENABLING=upnp-enabling[,IPHOSTID=ip-host-id];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional
Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one
between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one
between DID and
DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
7-264
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
OID String rack-shelf-slot-
port-onuMacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional
Description
UPNPEN-
ABLING
String Enable
Disable
ONU UPnP Enabling Required
IPHOSTID Integer 1-255 IP Host ID Required Under
Certain Condi-
tions:UPNPEN-
ABLING is Enable
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONU-UPNP::DID=10.63.204.232,OID=1-1-4-8-2:CTAG::UPNPENABLING=Enable,
IPHOSTID=1;
Response:
0 2017-09-21 11:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
7-265
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Remark:
This command is used to change the UPnP configuration of
Rack1/Shelf1/Slot4/Port8/ONU2 on 10.63.204.232.
Command 2:
CHG-ONU-UPNP::DID=10.63.204.232,OID=1-1-4-8-2:CTAG::UPNPENABLING=Disable;
Response:
0 2017-09-21 11:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to change the UPnP configuration of
Rack1/Shelf1/Slot4/Port8/ONU2 on 10.63.204.232.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.17.20T125 2017-9-21 New TL1 Command
7.1.88 CRT-ONU-PORTFORWARD【【【Create ONU Port Forward】】】
l Description
This command is used to create ONU port forward.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series
MSAN C300Mv4 Series
l Command Format
7-266
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
CRT-ONU-PORTFORWARD::(DID=device-id|DNAME=device-name)[,PID=port-id],OID=onu-id
:CTAG::PORTFWDID=port-forward-id[,PORTFWDSTAT=port-forward-stat]
[,PROTOCOLTYPE=protocol-type][,MAPPINGTYPE=mapping-type][,IPHOSTID=ip-host-id]
[,IPTYPE=ip-type][,LANHOSTIP=lan-host-ip][,LANHOSTMAC=lan-host-mac]
[,LANSTARTPORT=lan-start-port][,LANENDPORT=lan-end-port]
[,WANSTARTPORT=wan-start-port][,WANENDPORT=wan-end-port]
[,WANSTARTIP=wan-start-ip][,WANENDIP=wan-end-ip];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter Name Type Value Range Description Optional
Description
PORTFWDID Integer 1-255 Port Forward
Index
Required
PORTFWDSTAT String Enable
Disable
Port Forward
Status
Optional
7-267
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
PROTOCOLTYPE String TCP
UDP
TCPAndUDP
Protocol Type Optional
MAPPINGTYPE String IP
MAC
Mapping Type Optional
IPHOSTID Integer 1-255 IP Host ID Optional
IPTYPE String IPv4
IPv6
IP Type
If not input, the
default IP type is
IPv4
Optional
LANHOSTIP String IpAddress LAN Host IP Optional
Required when
MAPPINGTYPE is
IP
LANHOSTMAC String MacAddress LAN Host MAC Optional
Required when
MAPPINGTYPE is
MAC
LANSTARTPORT Integer 1-65535 LAN Starting Port Optional
LANENDPORT Integer 1-65535 LAN Ending Port Optional
WANSTARTPORT Integer 1-65535 WANStarting Port Optional
WANENDPORT Integer 1-65535 WAN Ending Port Optional
WANSTARTIP String IpAddress WAN Starting IP Optional
WANENDIP String IpAddress WAN Ending IP Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CRT-ONU-PORTFORWARD::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::
PORTFWDID=1,PORTFWDSTAT=Enable,MAPPINGTYPE=IP,LANHOSTIP=2.2.2.2,
LANSTARTPORT=2121,WANSTARTIP=3.3.3.3,WANSTARTPORT=21;
7-268
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Response:
0 2017-09-20 10:55:49
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to create the ONU port forward of Rack1/
Shelf1/Slot5/Port7/ONU1 on NE 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.17.20T125 2017-9-20 New TL1 Command
7.1.89 DLT-ONU-PORTFORWARD【【【Delete ONU Port Forward】】】
l Description
This command is used to delete ONU port forward.
l Applicable NE
NE Category NE Type Notes
PON OLT C300v2 Series/C300v3 Series
MSAN C300Mv4 Series
l Command Format
DLT-ONU-PORTFORWARD::(DID=device-id|DNAME=device-name)[,PID=port-id],OID=onu-id
:CTAG::PORTFWDID=port-forward-id;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-269
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
DID String SIZE(1-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
PORTFW-
DID
Integer 1-255 Port Forward Index Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
DLT-ONU-PORTFORWARD::DID=10.63.204.51,OID=1-1-5-7-1:CTAG::PORTFWDID=1;
Response:
0 2017-09-20 10:55:49
7-270
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
M CTAG COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to delete the ONU port forward 1 of Rack1/
Shelf1/Slot5/Port7/ONU1 on NE 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.17.20T125 2017-9-20 New TL1 Command
7.1.90 CHG-ONU-PON【【【Change ONU Configuration】】】
l Description
This command is used to change ONU configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.1/C220v1.2/C300
Series/C300v2 Series/C300v3
Series
Only support command pa-
rameters OMCCENCRYPT
and UPSTREAMFECEN-
ABLING by C300v2 Series
and C300v3 Series
MSAN C300Mv4 Series Only support command pa-
rameters OMCCENCRYPT
and UPSTREAMFECEN-
ABLING
l Command Format
CHG-ONU-PON::(DID=device-id|DNAME=device-name),OID=onu-id:CTAG::[OID=
onu-id][,IPADDRESS=ip-address][,ODN=odn][,ONUNAME=onu-name]
7-271
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
[,USERNAME=user-name][,DESC=desc][,OMCCENCRYPT=omcc-encrypt]
[,ONUTYPE=onu-type][,UPSTREAMFECENABLING=upstream-fec-enabling];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
wordONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
l Command Parameter
Parameter Name Type Value Range Description Optional
Description
IPADDRESS String SIZE(0-63) IP Address Optional
ODN String SIZE(0-63) ODN ID Optional
ONUNAME String SIZE(0-63) ONU Name Optional
USERNAME String SIZE(0-63) Username Optional
DESC String SIZE(0-63) Description of ONU Optional
OMCCENCRYPT String Enable
Disable
OMCC Encryption Enabling
Only support GPON.
Optional
ONUTYPE String SIZE(1-64) ONU Type Optional
UPSTREAMFE-
CENABLING
String Enable
Disable
Auto
Upstream FEC Enabling
Only support GPON.
Optional
7-272
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
None.
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
CHG-ONU-PON::DID=10.63.204.211,OID=1-1-5-3-1:0545::DESC=for test;
Response:
NETSH180492D1 2012-07-02 16:54:48
M 0545 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure description of Rack1/Shelf1/Slot5/Port3/ONU1 on
OLT 10.63.204.211.
Command 2:
CHG-ONU-PON::DID=10.46.41.14,OID=1-1-8-1-3:0545::ONUNAME=for
test,ODN=1-1,IPADDRESS=10.10.10.7,DESC=for tesbianbian,USERNAME=xubin;
Response:
NETSH180492D1 2012-07-02 16:55:48
M 0545 COMPLD
EN=0 ENDESC=No Error
;
Remark:
This command is used to configure name, ODN ID, IP address, description and
username of Rack1/Shelf1/Slot8/Port1/ONU3 on OLT 10.46.41.14.
Command 3:
CHG-ONU-PON::DID=10.46.41.14,OID=1-1-8-1-6:0545::OID=AA-BB-11-22-33-44;
Response:
NETSH180492D1 2012-07-02 16:56:29
M 0545 COMPLD
7-273
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
EN=0 ENDESC=No Error
Remark:
This command is used to configure MAC address of Rack1/Shelf1/Slot8/Port1/ONU6
on OLT 10.46.41.14.
Command 4:
CHG-ONU-PON::DID=10.63.204.211,OID=1-1-5-3-1:0545::OMCCENCRYPT=
Enable;
Response:
NETSH180492D1 2014-03-18 16:58:10
M 0545 COMPLD
EN=0 ENDESC=No Error
Remark:
This command is used to enable OMCC encryption of
Rack1/Shelf1/Slot5/Port3/ONU1 on OLT 10.63.204.211.
Command 5:
CHG-ONU-PON::DID=10.63.204.211,OID=1-1-5-3-1:0545::ONUTYPE=
F420;
Response:
NETSH180492D1 2015-12-18 13:18:13
M 0545 COMPLD
EN=0 ENDESC=No Error
Remark:
This command is used to change ONU type of Rack1/Shelf1/Slot5/Port3/ONU1 on
OLT 10.63.204.211.
Command 6:
CHG-ONU-PON::DID=10.63.204.211,OID=1-1-5-3-1:0545::UPSTREAMFECENABLING=
Enable;
Response:
NETSH180492D1 2015-07-18 13:18:13
M 0545 COMPLD
EN=0 ENDESC=No Error
Remark:
This command is used to change ONU upstream FEC enabling of
Rack1/Shelf1/Slot5/Port3/ONU1 on OLT 10.63.204.211.
l Average Command Response Time
7-274
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.13.40T70 2014-3-20 New Command Parameters:
OMCCENCRYPT
NetNumenU31R20V12.16.20T100 2015-12-23 New Command Parameters:
ONUTYPE
NetNumenU31R20V12.17.20T120 2017-7-18 New Command Parameters:
UPSTREAMFECENABLING
7.2 Resource and Query
7.2.1 LST-DEVINFO【【【Query Device Information】】】
l Description
This command is used for querying the type, software version, memory, CPU,
temperature, etc of the NE (OLT and ONU).
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.1/C220v1.2/C300 Series/C600
Series
PON ONU F820/LAN-MDU Series/xDSL-MDU
Series
l Command Format
LST-DEVINFO::ONUIP=onu-name|OLTID=olt-name[,PONID=ponport-location,
ONUIDTYPE=id-type,ONUID=onu-index]:CTAG::;
l Operated Target Identifier
7-275
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Parameter
Name
Type Value Range Description Optional
Description
ONUIP String SIZE(128) IP address, name, or
ID of the ONU that
has management IP
OLTID String SIZE(128) OLT IP address,
name, or ID
PONID String SIZE(128)
Rack–Shelf–Slot–
PON Port ID
To locate a
PON port by
Rack-Shelf-Slot-PON
Port ID. Type NA
when this parameter
is absent.
Required for the
ONU that has no
management IP
ONUIDTYPE String ONU_NAME,
MAC,
LOID, ONU_NUM-
BER
ONU identifier
type (ONU_NAME,
MAC, LOID,
ONU_NUMBER)
ONUID String SIZE(128) ONU identifier.
The value could
be chosen from
ONU_NAME,
MAC, LOID and
ONU_NUMBER to
uniquely identify an
ONU on the PON
port.
Required for the
ONU that has no
management IP
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
Parameter Name Type Value Range Description
DEVNAME String SIZE(128) Device name
DEVIP String SIZE(128) Device IP
DT String SIZE(255) Device type
DEVER String SIZE(255) Software version
MEM Integer 0–100 Memory utilization rate
Unit: %
CPU Integer 0–100 CPU utilization rate
Unit: %
7-276
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
TEMPERATURE Integer -50–100 Temperature
Unit: ℃
l Error Code
DDOF、IIPE、EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command :
LST-DEVINFO::OLTID=10.63.173.78:CTAG::;
Response：
PON001 2014-02-26 16:42:30
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
List of Device Info
—————————————————–
DEVNAME DEVIP DT DEVER MEM CPU TEMPERATURE
10.63.173.78 10.63.173.78 C300v2.0 V2.0.0 45 1 53
—————————————————–
;
Remark:
This command is used to list device information of 10.63.173.78.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
7-277
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
7.2.2 LST-BRDINFO【【【Query Board Information】】】
l Description
This command is used for querying the board information such as type, status, version,
etc.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C600 Series
PON ONU F820/LAN-MDU Series/xDSL-MDU
Series
l Command Format
LST-BRDINFO::ONUIP=onu-name|OLTID=olt-name[,PONID=ponport_location,
ONUIDTYPE=id-type,ONUID=onu_index][,BOARDID=board-name]:CTAG::;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional
Description
ONUIP String SIZE(128) IP address, name, or
ID of the ONU that
has management IP
OLTID String SIZE(128) OLT IP address,
name, or ID
PONID String SIZE(128)
Rack–Shelf–Slot–
PON Port ID
To locate a
PON port by
Rack-Shelf-Slot-PON
Port ID. Type NA
when this parameter
is absent.
Required for the
ONU that has no
management IP
ONUIDTYPE String ONU_NAME,
MAC,
LOID, ONU_NUM-
BER
ONU identifier
type (ONU_NAME,
MAC, LOID,
ONU_NUMBER)
7-278
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
ONUID String SIZE(128) ONU identifier.
The value could
be chosen from
ONU_NAME,
MAC, LOID and
ONU_NUMBER to
uniquely identify an
ONU on the PON
port.
Required for the
ONU that has no
management IP
BOARDID String SIZE(128)
Rack-Shelf-Slot
To locate a board
by Rack-Shelf-Slot.
Type NA when this
parameter is absent.
Optional. Query
all boards if the
BOARDID is
absent.
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
Parameter Name Type Value Range Description
BOARDID String SIZE(128)
Rack-Shelf-Slot
To locate a board by
Rack-Shelf-Slot. Type NA
when this parameter is absent.
BSTAT String Normal
Fault
Offline
Board status
BOARDTYPE String SIZE(128) Board type
BSERVICE String Power
ETH
ADSL
VDSL
POTS
E1
GPON
EPON
SCU
Other
Board service type
PNUM Integer 0–64 Number of ports
SWVER String SIZE(255) Software version
HWVER String SIZE(255) Hardware version
MEM Integer 0–100 Memory utilizationrate
Unit: %
7-279
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
CPU Integer 0–100 CPU utilization rate
Unit: %
l Error Code
DDOF、IIPE、EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command :
LST-BRDINFO::OLTID=10.63.173.78:CTAG::;
Response：
PON001 2014-02-26 16:42:30
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=4
List of Board Info
—————————————————–
BOARDID BSTAT BOARDTYPE BSERVICE PNUM SWVER HWVER MEM CPU
1-1-0 Normal PRWG Power 0 – – 0 0
1-1-10 Normal SCTMB Control 5 V2.0.0 130100 45 1
1-1-14 Normal GTGH GPON 16 V2.0.0 120700 16 32
1-1-21 Normal GUSQ ETH 4 V2.0.0 090200 23 1
—————————————————–
;
Remark:
This command is used to list board information of 10.63.173.78.
No.2 Command :
LST-BRDINFO::OLTID=10.63.173.78,BOARDID=1-1-14:CTAG::;
Response：
PON001 2014-02-26 16:42:30
M CTAG COMPLD
EN=0 ENDESC=No Error
7-280
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
totalrecord=1
List of Board Info
—————————————————–
BOARDID BSTAT BOARDTYPE BSERVICE PNUM SWVER HWVER MEM CPU
1-1-14 Normal GTGH GPON 16 V2.0.0 120700 16 32
—————————————————–
;
Remark:
This command is used to list board information of board 1-1-14 on 10.63.173.78.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
7.2.3 LST-OLTATTR-PON【【【Query PON Port Attributes】】】
l Description
This command is used to query PON port attributes.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.1/C220v1.2/C300 Series/C300v2
Series/C600 Series
l Command Format
LST-OLTATTR-PON::(DID=device-id|DNAME=device-name),(BID=board-id|
PID=port-id):CTAG::;
l Operated Target Identifier
7-281
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(0-100) NE ID Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
DNAME String SIZE(0-32) NE Name Required Under
Certain Conditions:
Must choose one
between DID and
DNAME
BID String rack-shelf-slot Board ID (e.g. 1-1-15) Required Under
Certain Conditions:
Must choose one
between BID and PID
PID String rack-shelf-slot-
port
Port ID（e.g.
1-1-15-2）
Required Under
Certain Conditions:
Must choose one
between BID and PID
l Command Parameter
None
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
Parameter Name Type Value Range Description
DID String SIZE(0-100) NE ID
DNAME String SIZE(0-32) NE Name
PID String rack-shelf-slot-port Port ID（e.g. 1-1-15-2）
ADMINSTATUS String up
down
Administrative Status
OPERSTATUS String up
down
Operational Status
HWAUTHSTAT String enable
disable
Hardware Authentication Status
EPON Supported.
l Error Code
7-282
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
LST-OLTATTR-PON::DID=10.46.41.14,PID=1-1-8-1:CTAG::;
Response：
SH10083644D02 2012-07-12 15:48:38
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
List of OLT information
—————————————————–
DID DNAME PID ADMINSTATUS OPERSTATUS HWAUTHSTAT
10.46.41.14 10.46.41.14 1-1-8-1 up down disable
—————————————————–
;
Remark:
This command is used to query EPON port attributes of Rack1/Shelf1/Slot8/Port1 on
10.46.41.14.
Command 2:
LST-OLTATTR-PON::DID=10.63.194.46,BID=1-1-2:CTAG::;
Response：
AE8D4F1CB00A4CB 2014-03-17 14:46:27
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=8
List of OLT information
—————————————————–
DID DNAME PID ADMINSTATUS OPERSTATUS HWAUTHSTAT
10.63.194.46 10.63.194.46 1-1-2-1 up down –
7-283
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
10.63.194.46 10.63.194.46 1-1-2-2 up down –
10.63.194.46 10.63.194.46 1-1-2-3 up up –
10.63.194.46 10.63.194.46 1-1-2-4 up down –
10.63.194.46 10.63.194.46 1-1-2-5 up down –
10.63.194.46 10.63.194.46 1-1-2-6 up up –
10.63.194.46 10.63.194.46 1-1-2-7 up down –
10.63.194.46 10.63.194.46 1-1-2-8 up down –
—————————————————–
;
Remark:
This command is used to query GPON ports attributes of Rack1/Shelf1/Slot2 on
10.63.194.46.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.13.40T70 2014-03-20 New Command Parameters：BID
7.2.4 LST-ONU【【【Query ONU Information】】】
l Description
This command is used for querying all ONUs or a specific ONU under the OLT.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.1/C220v1.2/C300 Series/C300v2 Series/C300v3
Series/C600 Series
PON ONU F820/LAN-MDU Series/xDSL-MDU Series
l Command Format
LST-ONU::[ONUIP=onu-ip|OLTID=olt-name[,PONID=ponport_location[,ONUIDTY-
7-284
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
PE=onuid-type,ONUID=onu-index]]]:CTAG::[NAME=onu-name];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional
Description
ONUIP String SIZE(128) IP address or name
of the ONU that has
management IP
Required for the ONU
with management IP
OLTID String SIZE(128) OLT IP address or
name
Optional
PONID String SIZE(128)
Rack–Shelf–Sl-
ot–PON Port ID
To locate a
PON port by
Rack-Shelf-Slot-PON
Port ID. Type NA
when this parameter
is absent.
Optional
ONUIDTYPE String SIZE(128) ONU identifier type:
ONU_NAME
MAC
LOID
ONU_NUMBER
SN
PASSWORD
Optional
ONUID String SIZE(128) ONU identifier.
The value could
be chosen from
ONU_NAME,
MAC, LOID,
ONU_NUMBER, SN
and PASSWORD to
identify a single ONU
on the PON port.
Optional
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
NAME String SIZE(1-127) ONU Name Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
7-285
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Parameter Name Type Value Range Description
OLTID String SIZE(128) OLT IP address or name
PONID String SIZE(128)
Rack–Shelf–Slot–PON
Port ID
To locate a PON port by
Rack-Shelf-Slot-PON Port ID.
Type NA when this parameter is
absent.
ONUNO Integer 0-512 ONU authorization number
NAME String SIZE(128) ONU name
DESC String SIZE(128) ONU description
ONUTYPE String SIZE(128) ONU type
IP String SIZE(128) ONU management IP
AUTHTYPE String ONU_NAME
MAC
LOID
ONU_NUMBER
SN
PASSWORD
Authorization type. Return “--”
when the authorization type is
absent.
MAC String SIZE(128) Registration MAC of the ONU
LOID String SIZE(64) Return “--” in case of MAC
authorization mode
PWD String SIZE(128) LOID PASSWORD. Return “--” if
the PASSWORD is absent.
SWVER String SIZE(128) Software version
l Error Code
DDOF, IIPE
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
LST-ONU::OLTID=10.63.194.46:CTAG::;
Response：
ZTE_10.63.204.161 2013-11-12 13:58:10
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=11
7-286
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
list of ONU
—————————————————–
OLTID PONID ONUNO NAME DESC ONUTYPE IP AUTHTYPE MAC LOID PWD
SWVER
10.46.41.12 1-1-3-1 1 – – ZTE-F821-lxd – MAC 000000000062 – – V1.2.0P3C1
10.46.41.12 1-1-3-1 2 – – ZTE-F821-lxd – MAC 000000000407 – – V1.2.0P3
10.46.41.12 1-1-3-1 5 – – ZTE-F820 10.46.41.196 MAC 08181A28F427 – –
V1.1.0P3T17
10.46.41.12 1-1-3-1 6 – – ZTE-F820 10.46.41.197 MAC 000000109917 – –
V1.0.0P7T3
10.46.41.12 1-1-3-2 32 – – ZTE-F821-lxd 10.46.41.92 MAC 0000EF101991 – –
V1.2.0P3
10.46.41.12 1-1-3-2 34 – – ZTE-F821-10GAS 10.46.41.94 MAC 201310171618 –
– V1.2.0P3
10.46.41.12 1-1-6-1 1 ONU-1:1 – ZTEG-F829 – SN – ZTEG87654321 – –
10.46.41.12 1-1-6-1 2 2– ZTE-F601 – SN – ztegDDDDDDDD – –
10.46.41.12 1-1-6-3 2 ONU-3:2 – ZTEG-F821 10.46.41.91 SN – ZTEG00123858 –
–
10.46.41.12 1-1-6-3 34 gponname – ZTEG-F821 – SN – ZTEG10097165 – –
10.46.41.12 1-1-6-5 1 ONU-5:1 – ZTEG-F829 – SN – ZTEG87654321 – –
—————————————————–
;
Remark:
This command is used to query ONU information on OLT 10.63.173.78.
Command 2：：：
LST-ONU::OLTID=10.63.194.46,PONID=1-1-9-1:CTAG::;
Response：
ZTE_10.63.204.161 2013-11-12 14:05:57
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=4
list of ONU
—————————————————–
7-287
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
OLTID PONID ONUNO NAME DESC ONUTYPE IP AUTHTYPE MAC LOID PWD
SWVER
10.63.194.46 1-1-9-1 5 F621-RJO8JM-001 – ZTE-D402 – SN – ZTEG55262235 – –
10.63.194.46 1-1-9-1 4 – – ZTE-D420 – LOIDONCEON – 22228760002 – –
10.63.194.46 1-1-9-1 2 – – ZTE-D420 – MAC 112233445566 – – –
10.63.194.46 1-1-9-1 1 1 – ZTE-9806 100.63.204.102 SN – znx111 – –
—————————————————–
;
Remark：
This command is used to query ONU information of Slot9/Port1 on OLT 10.63.173.78.
Command 3：：：
LST-ONU::OLTID=10.63.194.46,PONID=1-1-3-1,ONUIDTYPE=ONU_NUMBER,
ONUID=1:CTAG::;
Response：
ZTE_10.63.204.161 2013-11-12 14:09:36
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
list of ONU
—————————————————–
OLTID PONID ONUNO NAME DESC ONUTYPE IP AUTHTYPE MAC LOID PWD
SWVER
10.63.194.46 1-1-3-1 1 1 – E8-C – SN – 513542647247 – –
—————————————————–
;
Remark：
This command is used to query ONU information of Slot9/Port1 on OLT 10.63.173.78
by ONU identifier.
Command 4：：：
LST-ONU::ONUIP=10.63.204.102:CTAG::;
Response：
ZTE_10.63.204.161 2013-11-12 14:11:01
M CTAG COMPLD
EN=0 ENDESC=No Error
7-288
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
totalrecord=1
list of ONU
—————————————————–
OLTID PONID ONUNO NAME DESC ONUTYPE IP AUTHTYPE MAC LOID PWD
SWVER
10.63.194.46 1-1-2-1 3 wwww dddd – ZTE-9806 10.63.204.102 MAC
BBBBBBBBBBBB – – –
—————————————————–
;
Remark：
This command is used to query ONU information by management IP address
10.63.204.102.
Command 5:
LST-ONU:::CTAG::NAME=TEST_1111;
Response：
zxpon-x86-ss2 2014-03-19 14:11:40
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=2
list of ONU
—————————————————–
OLTID PONID ONUNO NAME DESC ONUTYPE IP AUTHTYPE MAC LOID PWD SWVER
10.63.204.165 1-1-6-1 6 TEST_1111 – E8-C – SN – 313131231231 – –
10.63.194.46 1-1-12-6 1 TEST_1111 – ZTE-F622 – SN – ZTEG87655321 – –
—————————————————–
;
Remark:
This command is used to query ONU information named TEST_1111.
Command 6:
LST-ONU::ONUID=ZTEG31231231:CTAG::;
Response：
zxpon-x86-ss2 2016-05-26 14:11:40
7-289
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
M CTAG COMPLD
totalrecord=1
list of ONU
—————————————————–
OLTID PONID ONUNO NAME DESC ONUTYPE IP AUTHTYPE MAC LOID PWD
SWVER
10.63.204.165 1-1-6-1 6 TEST_1111 – E8-C – SN – ZTEG31231231 – –
—————————————————–
;
Remark:
This command is used to query ONU information which ONUID is ZTEG31231231.
Command 7：：：
LST-ONU::OLTID=10.63.194.46,PONID=1-1-9-0:CTAG::;
Response：
ZTE_10.63.204.161 2017-04-18 14:05:57
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=4
list of ONU
—————————————————–
OLTID PONID ONUNO NAME DESC ONUTYPE IP AUTHTYPE MAC LOID PWD
SWVER
10.63.194.46 1-1-9-1 5 F621-RJO8JM-001 – ZTE-D402 – SN – ZTEG55262235 – –
10.63.194.46 1-1-9-1 4 – – ZTE-D420 – LOIDONCEON – 22228760002 – –
10.63.194.46 1-1-9-2 2 – – ZTE-D420 – MAC 112233445566 – – –
10.63.194.46 1-1-9-2 1 1 – ZTE-9806 100.63.204.102 SN – znx111 – –
—————————————————–
;
Remark：
This command is used to query ONU information of slot 9 on OLT 10.63.173.78.
l Average Command Response Time
Scenario Average Response Time (s)
7-290
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.13.40T70 2013-03-20 Change OLTID from Required to Optional
New Command Parameter: NAME
NetNu-
menU31R20V12.16.20T100
2016-05-26 Support to query ONU by ONUID(ONU
identifier)
NetNu-
menU31R20V12.17.20T120
2017-04-18 Support to query ONU by slot
7.2.5 LST-ONUSTATE【【【Query ONU State】】】
l Description
This command is used for querying the type, software version, memory, CPU,
temperature, etc of the NE (OLT and ONU).
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.1/C220v1.2/C300 Series/C300v2 Series/C300v3
Series/C600 Series
PON ONU F820/LAN-MDU Series/xDSL-MDU Series
l Command Format
LST-ONUSTATE::OLTID=olt-name,PONID=ponport_location[,ONUIDTYPE=id-type,
ONUID=onu-index]:CTAG::;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional
Description
OLTID String SIZE(128) OLT IP address,
name, or ID
Required
7-291
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
PONID String SIZE(128)
Rack–Shelf–Slot–
PON Port ID
To locate a
PON port by
Rack-Shelf-Slot-PON
Port ID. Type NA
when this parameter
is absent.
Required
ONUIDTYPE String ONU_NAME,
MAC,
LOID, ONU_NUM-
BER
ONU identifier type:
ONU_NAME
MAC
LOID
ONU_NUMBER
SN
PASSWORD
Optional. Query
the status of all
ONUs under the
OLT PON port if
this parameter is
absent.
ONUID String SIZE(128) ONU identifier.
The value could
be chosen from
ONU_NAME,
MAC, LOID,
ONU_NUMBER,
SN and PASSWORD
to uniquely identify
an ONU on the PON
port.
Optional. Query
the status of all
ONUs under the
OLT PON port if
this parameter is
absent.
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
Parameter Name Type Value Range Description
ONUID String SIZE(128) ONU identifier. The value is
ONU_Number. It is used for
uniquely locating the ONU
under the PON port.
AdminState String UP
DOWN
Administration state
OperState String UP
Power-Off
LOS
Operation status
AUTH String MAC
LOID
Authorization type
7-292
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
AUTHINFO String SIZE(64) Authorization information.
AUTHINFO is the MAC add
ress if AUTH is MAC
authorization. AUTHINFO
is LOID if AUTH is LOID
authorization.
ONUIP String SIZE(128) ONU management IP
LASTOFFTIME String SIZE(128) ONU last offline time (including
power-off and LOS). The
time format is “YYYY-MM-DD
HH-MM-SS”. Report “--” in this
field for the online ONUs.
LASTOFFREASON String Unknown
OLTLOS
ONULOS
ONULOF
ONUSF
ONULOA
ONULOAM
ONUAuthorization-
Failed
ONUPowerOff
ONUDeactivationSuc-
ceeded
ONUDeactivationFailed
ONUReboot
ONUShutdown
ONU last offline reason.
Unknown: unknown reason
OLTLOS: OLT LOS
ONULOS: ONU LOS
ONULOF: ONU LOF
ONUSF: ONU SF
ONULOA: ONU LOA
ONULOAM: ONU LOAM
ONUAuthorizationFailed: ONU
authorization failed
ONUPowerOff: ONU power off
ONUDeactivationSucceeded:
ONU deactivation succeed
ONUDeactivationFailed: ONU
deactivation failed
ONUReboot: ONU reboot
ONUShutdown: ONU
shutdown
LASTONTIME String SIZE(128) ONU last online time. The
time format is “YYYY-MM-DD
HH-MM-SS”.
l Error Code
DDOF、IIPE、EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
7-293
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Example
No.1 Command :
LST-ONUSTATE::OLTID=10.63.173.78,PONID=1-1-14-9:CTAG::;
Response：
PON001 2014-02-26 16:42:30
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=4
list of ONU state
—————————————————–
ONUID AdminState OperState AUTH AUTHINFO ONUIP LASTOFFTIME
LASTOFFREASON LASTONTIME
1 UP LOS SN ZTEG00000022 – 2014-10-27 14:49:26 ONULOS 2014-10-27
14:31:27
2 UP LOS SN ZTEG00000001 – 2014-10-15 14:29:58 ONULOS 2014-10-15
14:10:37
3 UP LOS SN 555544444444 – – – –
7 UP LOS SN ZTEG10073950 – – – –
—————————————————–
;
Remark:
This command is used to list ONU state of port 1-1-14-9 on 10.63.173.78.
No.2Command :
LST-ONUSTATE::OLTID=10.63.173.78,PONID=1-1-14-9,ONUIDTYPE=SN,
ONUID=ZTEG00000022:CTAG::;
Response：
PON001 2014-02-26 16:42:30
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
list of ONU state
7-294
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
—————————————————–
ONUID AdminState OperState AUTH AUTHINFO ONUIP LASTOFFTIME
LASTOFFREASON LASTONTIME
1 UP LOS SN ZTEG00000022 – 2014-10-27 14:49:26 ONULOS 2014-10-27
14:31:27
—————————————————–
;
Remark:
This command is used to list ONU state of port 1-1-14-9 on 10.63.173.78.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
7.2.6 LST-SERVICEPORT【【【List Service Port】】】
l Description
This command is used to list service ports.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
MSAN C300M Series/C300Mv4 Series
l Command Format
LST-SERVICEPORT::(DID=device-id|DNAME=device-name)
(,PID=port-id|[,PID=port-id],OID=onu-id):CTAG::
[SERVICEPORTID=service-port-id][,DESC=desc];
7-295
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under Certain
Conditions: Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required Under Certain
Conditions: Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Required Under Certain
Conditions: Must
choose one between
PID and (PID,OID)
OID String rack-shelf-
slot-port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device. (e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required Under Certain
Conditions: Must
choose one between
PID and OID
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
SERVICE-
PORTID
Integer 1-128 Service Port ID
If SERVICEPORTID is
not specified, all the
results will be returned,
otherwise only the
result relative with
specific attributes will be
returned.
Optional
DESC String SIZE(1-64) Service Port Description
If DESC is not specified,
all the results will be
returned, otherwise only
the result relative with
specific attributes will be
returned.
Optional
7-296
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
Title of Response Result: "Service port information of the device " + device-id
Parameter
Name
Type Value Range Description
DID String SIZE(1-100) NE ID
DNAME String SIZE(1-32) NE Name
PID String rack-shelf-slot-port Port ID
OID String rack-shelf-slot-port-onu
MacAddress
SN/LOID/Password
ONU ID
VIFTYPE String VPort Virtual Interface Type
VIFID Integer 1–128 Virtual Interface ID
SERVICEPOR-
TID
Integer 1–128 Service Port ID
DESC Octet
String
SIZE(0-64) Service Port Description
ADMINSTAT String Enable
Disable
Administrative Status
OPERSTAT String -- Operational Status
Deprecated
MODE String Untag
UntagAndEtherType
Priority
Tag
Tls
TagAndEtherType
TagAndCosPriority
VlanRangeTag
VlanRangeTagAndEther-
Type
VlanRangeTagAndCos
CVlanTransparent
DoubleVlanTag
DoubleTlsVlan
Service Port Mode
7-297
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
USERETHER-
TYPE
String NotConfigured
PPPoE
IPoE
UserDefined
User Ethernet Type
USERDE-
FETHERTYPE
String Hex Value: e.g. 0x8180 User Defined Ethernet Type
USERETHER-
TYPEFILTER
String Enable
Disable
User Ethernet Type Filter
ALLOWEDE-
THERTYPE
String -- Allowed User Ethernet Type
Deprecated
ALLOWE-
DUSERDE-
FETHERTYPE
String -- Allowed User Defined Ethernet
Type
Deprecated
USERVID Integer 1–4094 User VLAN ID
USERSVID Integer 1–4094 User SVLAN ID
USERCOS Integer 0–7 User CoS Priority
STAR-
TUSERVID
Integer 1–4094 User Starting VLAN ID
ENDVUSERID Integer 1–4094 User Ending VLAN ID
USERDSCP Integer 0–63 User DSCP Priority
NETWORKCVID Integer 1–4094 Network CVLAN ID
NETWORKC-
TAGCOS
Integer 0–7 Network CVLAN CoS Priority
NETWORKSVID Integer 1–4094 Network SVLAN ID
NETWORK-
STAGCOS
Integer 0–7 Network SVLAN CoS Priority
TLSSVID Integer 1–4094 TLS SVLAN ID
TLSCVID Integer 1–4094 TLS CVLAN ID
INGRESSTRAF-
FICPRF
String SIZE(1–32) Ingress Traffic Profile
EGRESSTRAF-
FICPRF
String SIZE(1–32) Egress Traffic Profile
QOSQUEUEID Integer 0–7 QoS Queue ID
VLANMERGE String -- VLAN Merge Enabling
Deprecated
l Error Code
DDOF、IIPE、EEH
7-298
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
Command 1:
LST-SERVICEPORT::DID=10.63.204.167,OID=1-1-6-1-1:5::SERVICEPORTID=1;
Response:
ZTE_10.63.204.69 2014-09-19 11:43:15
M 5 COMPLD
EN=0 ENDESC=No Error
totalrecord=1
Service port information of the device 10.63.204.167
—————————————————–
DID DNAME PID OID VIFTYPE VIFID SERVICEPORTID DESC ADMINSTAT
OPERSTAT MODE USERETHERTYPE USERDEFETHERTYPE USERETHERTYPEFILTER
ALLOWEDETHERTYPE ALLOWEDUSERDEFETHERTYPE USERVID USERSVID
USERCOS STARTUSERVID ENDUSERVID USERDSCP NETWORKCVID
NETWORKCTAGCOS NETWORKSVID NETWORKSTAGCOS TLSSVID TLSCVID
INGRESSTRAFFICPRF EGRESSTRAFFICPRF QOSQUEUEID VLANMERGE
10.63.204.167 C300v2.0-10.63.204.167 – 1-1-6-1-1 VPort 1 1 –
Enable – TagAndEtherType UserDefined 0x8180 – – – 300
– – – – – 350 – – – – – – – – –
—————————————————–
;
Remark:
This command is used to list information of service port 1 of
Rack1/Shelf1/Slot6/Port1/ONU1 on 10.63.204.167.
Command 2:
LST-SERVICEPORT::DID=10.63.204.167,OID=1-1-6-1-1:5::;
Response:
ZTE_10.63.204.69 2014-09-19 11:43:15
M 5 COMPLD
EN=0 ENDESC=No Error
7-299
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
totalrecord=2
Service port information of the device 10.63.204.167
—————————————————–
DID DNAME PID OID VIFTYPE VIFID SERVICEPORTID DESC ADMINSTAT
OPERSTAT MODE USERETHERTYPE USERDEFETHERTYPE USERETHERTYPEFILTER
ALLOWEDETHERTYPE ALLOWEDUSERDEFETHERTYPE USERVID USERSVID
USERCOS STARTUSERVID ENDUSERVID USERDSCP NETWORKCVID
NETWORKCTAGCOS NETWORKSVID NETWORKSTAGCOS TLSSVID TLSCVID
INGRESSTRAFFICPRF EGRESSTRAFFICPRF QOSQUEUEID VLANMERGE
10.63.204.167 C300v2.0-10.63.204.167 – 1-1-6-1-1 VPort 1 1 –
Enable – TagAndEtherType UserDefined 0x8180 – – – 300
– – – – – 350 – – – – – – – – –
10.63.204.167 C300v2.0-10.63.204.167 – 1-1-6-1-1 VPort 1 2 desc
Disable – Tls – – – AllEtherType – – – – –
– – – – – – 200 – – – – –
—————————————————–
;
Remark:
This command is used to list information of service port of
Rack1/Shelf1/Slot6/Port1/ONU1 on 10.63.204.167.
Command 3:
LST-SERVICEPORT::DID=10.63.204.167,PID=1-1-6-1:5::;
Response:
ZTE_10.63.204.69 2016-05-27 11:43:15
M 5 COMPLD
EN=0 ENDESC=No Error
totalrecord=2
Service port information of the device 10.63.204.167
—————————————————–
DID DNAME PID OID VIFTYPE VIFID SERVICEPORTID DESC ADMINSTAT
OPERSTAT MODE USERETHERTYPE USERDEFETHERTYPE USERETHERTYPEFILTER
7-300
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
ALLOWEDETHERTYPE ALLOWEDUSERDEFETHERTYPE USERVID USERSVID
USERCOS STARTUSERVID ENDUSERVID USERDSCP NETWORKCVID
NETWORKCTAGCOS NETWORKSVID NETWORKSTAGCOS TLSSVID TLSCVID
INGRESSTRAFFICPRF EGRESSTRAFFICPRF QOSQUEUEID VLANMERGE
10.63.204.167 C300v2.0-10.63.204.167 1-1-6-1 – – – 1 –
Enable – TagAndEtherType UserDefined 0x8180 – – – 300
– – – – – 350 – – – – – – – – –
10.63.204.167 C300v2.0-10.63.204.167 1-1-6-1 – – – 2 desc
Disable – Tls – – – – – – – – –
– – – – – – 200 – – – – –
—————————————————–
;
Remark:
This command is used to list information of service port of Rack1/Shelf1/Slot6/Port1on 10.63.204.167.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-9-16 New TL1 Command
NetNumenU31R20V12.14.20T80 2014-11-18 New Response Parameters:VLAN-
MERGE
NetNumenU31R20V12.16.20T105 2016-3-29 New Response Parameter
Values: VlanRangeTag,
VlanRangeTagAndEtherType,
VlanRangeTagAndCos for MODE
NetNumenU31R20V12.16.20T105 2016-5-27 New Command Parameters: PID
Change OID from Required to Optional
NetNumenU31R20V12.16.20T105 2016-6-30 New Response Parameter Values:
UntagAndEtherType, Priority for MODE
7-301
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
NetNumenU31R20V12.17.20T115 2017-1-10 Deprecate Response Parameters:
OPERSTAT, ALLOWEDETHERTYPE,
ALLOWEDUSERDEFETHERTYPE,
VLANMERGE
NetNumenU31R20V12.19.20T150 2019-4-10 New Command Parameters: DESC
7.2.7 LST-PORTQOS-PRIPRF【【【List Port QoS Priority Profile】】】
l Description
This command is used to list port QoS priority profile.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series
MSAN MSAG5200V3/C300M Series/C300Mv4 Series
l Command Format
LST-PORTQOS-PRIPRF::(DID=device-id|DNAME=device-name),(PID=port-id|
(OID=onu-id[,ONUPORT=onu-port])):CTAG::[VIFID=virtual-interface-id|
SERVICENAME=service-name];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under Certain
Conditions: Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required Under Certain
Conditions: Must
choose one between
DID and DNAME
PID String rack-shelf-slot-port Port ID (e.g 1-1-3-5) Required Under Certain
Conditions: Must
choose one between
PID and OID
7-302
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
OID String rack-shelf-slot-port-
onu
MacAddress
SN/LOID/Password
ONU ID. It's used
to identify the
ONU while DID
or DNAME indicates
the OLT device.
(e.g.1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required Under Certain
Conditions: Must
choose one between
PID and OID
ONUPORT String [rack-][shelf-][slot-]p-
ort
UNI Port of ONU
(e.g. 3-2:
slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-
shelf1-slot3-port2)
Required Under
Certain Conditions:
Must choose one
between PID and
(OID,ONUPORT)
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
VIFID Inte-
ger
1-128 Virtual Interface ID.
(When operated target
identifier is ONU, VIFID
means VPort number.
When operated target
identifier is physical port,
VIFID means bridge port
number. Supported by
C300v2.0/C300v3.0/C300
Mv4/C350Mv4.)
Optional
SERVICE-
NAME
String SIZE(1-64) Service Name Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
Title of Response Result: Port QoS Profile
Parameter
Name
Type Value Range Description
DID String SIZE(1-100) NE ID
PID String rack-shelf-slot-port Port ID (e.g 1-1-3-5)
7-303
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
OID String rack-shelf-slot-port-onu
MacAddress
SN/LOID/Password
ONU ID. It's used to identify
the ONU while DID or DNAME
indicates the OLT device.
(e.g.1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
ONUPORT String [rack-][shelf-][slot-]port UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-slot3-port2)
COSQUEUEMA-
PPRF
String SIZE(0-32) CoS Mapping Queue Profile Name
QUEUEPRF String SIZE(0-32) Queue Block Profile Name
VIFTYPE String VPort Virtual Interface Type
VIFID Integer 1-256 Virtual Interface ID
l Error Code
DDNS, DDOF
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command :
LST-PORTQOS-PRIPRF::DID=10.61.94.35,PID=1-1-5-2:5::;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
totalrecord=1
Port QoS Profile
————————————-
DID PID OID ONUPORT COSQUEUEMAPPRF QUEUEPRF VIFTYPE VIFID
10.61.94.35 1-1-5-2 – – QUEUE_MAP_PRF QUEUE_BOLCK_PRF – –
————————————-
;
Remark:
This command is used to list QoS priority profile of Rack1/Shelf1/Slot5/Port2 on
10.61.94.35.
No.2 Command :
7-304
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
LST-PORTQOS-PRIPRF::DID=10.61.94.35,OID=1-1-5-2-1:5::VIFID=1;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
totalrecord=1
Port QoS Profile
————————————-
DID PID OID ONUPORT COSQUEUEMAPPRF QUEUEPRF VIFTYPE VIFID
10.61.94.35 – 1-1-5-2-1 – QUEUE_MAP_PRF QUEUE_BOLCK_PRF VPort 1
————————————-
;
Remark:
This command is used to list QoS priority profile of
Rack1/Shelf1/Slot5/Port2/ONU1/VPort1 on 10.61.94.35.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-9-12 New Command Parameters:VIFID,
SERVICENAME
New Response Parameters:VIFTYPE,
VIFID
7.2.8 LST-PORT-MAXLEARNTMAC【【【Query Port Maximum Number
of Learnt MAC Addresses】】】
l Description
This command is used to query port maximum number of learnt MAC addresses.
l Applicable NE
7-305
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C600 Series
MSAN C300M Series
DSL DSL Series
l Command Format
LST-PORT-MAXLEARNTMAC::(DID=device-id|DNAME=device-name),(PID=port-id|(OID=onu-id[,ONUPORT=onu-port])):CTAG::[VIFID=virtual-interface-id][,VLANID=vlan-id];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under Certain
Conditions:Must choose
one between DID and
DNAME
DNAME String SIZE(1-32) NE Name Required Under Certain
Conditions:Must choose
one between DID and
DNAME
PID String rack-shelf-
slot-port
Port ID (e.g. 1-1-3-5) Required Under Certain
Conditions:Must choose
one between PID and
OID
OID String rack-shelf-
slot-port-onu
MacAddress
SN/LOID/Pas-
sword
ONU ID. It's used to
identify the ONU while
DID or DNAME indicates
the OLT device.
(e.g.1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required Under Certain
Conditions:Must choose
one between PID and
OID
ONUPORT String [rack-][shelf-][
slot-]port
UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-
slot3-port2)
Required Under Certain
Conditions: Must choose
one between PID and
(OID,ONUPORT)
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
7-306
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
VIFID Integer 1-256 Virtual Interface ID.
(When operated target
identifier is ONU, VIFID
means VPort number.
When operated target
identifier is physical port,
VIFID means bridge port
number.)
Optional
VLANID Integer 1-4094 VLAN ID Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
Parameter Name Type Value Range Description
DID String SIZE(1-100) NE ID
DNAME String SIZE(1-32) NE Name
PID String rack-shelf-slot-port Port ID (e.g 1-1-3-5)
OID String rack-shelf-slot-port-onu
MacAddress
SN/LOID/Password
ONU ID. It's used to identify
the ONU while DID or DNAME
indicates the OLT device.
(e.g.1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
ONUPORT String [rack-][shelf-][slot-]port UNI Port of ONU
(e.g. 3-2: slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-shelf1-slot3-
port2)
VIFTYPE String BrgPort
VPort
Virtual Interface Type
VIFID Integer 1-256 Virtual Interface ID
VLANID Integer 1-4094 VLAN ID
MACLIMITSTAT String Enable
Disable
MAC Limit Status
MAXLEARNTMAC Integer 0-32768 Maximum Number of Learnt
MAC Addresses
l Error Code
DDOF、IDNE、IIPE、EEH
7-307
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31GPON NBI Reference Manual for TL1
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command :
LST-PORT-MAXLEARNTMAC::DID=10.63.204.51,PID=1-1-5-1:CTAG::;
Response:
ZTE-EB9A30BF27A 2013-04-25 12:11:22
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
Maximum learnt MAC addresses of the device 10.63.204.51 1-1-5-1
————————————————————
DID DNAME PID OID ONUPORT VIFTYPE VIFID VLANID MACLIMITSTAT
MAXLEARNTMAC
10.63.204.51 C300M 1-1-5-1 – – – – – Enable 20
————————————————————
;
Remark:
This command is used to query the maximum number of learnt MAC addresses of
Rack1/Shelf1/Slot5/Port1 on 10.63.204.51.
No.2 Command :
LST-PORT-MAXLEARNTMAC::DID=10.63.204.51,PID=1-1-5-1:CTAG::VLANID=4;
Response:
ZTE-EB9A30BF27A 2013-04-25 12:11:22
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
Maximum learnt MAC addresses of the device 10.63.204.51 1-1-5-1
————————————————————
DID DNAME PID OID ONUPORT VIFTYPE VIFID VLANID MACLIMITSTAT
MAXLEARNTMAC
7-308
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
10.63.204.51 C300M 1-1-5-1 – – – – 4 Enable 20
————————————————————
;
Remark:
This command is used to query the maximum number of learnt MAC addresses of
Rack1/Shelf1/Slot5/Port1/VLAN4 on 10.63.204.51.
No.3 Command :
LST-PORT-MAXLEARNTMAC::DID=10.63.204.51,OID=1-1-1-1-1:CTAG::VIFID=1;
Response:
ZTE-EB9A30BF27A 2013-04-25 12:11:22
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
Maximum learnt MAC addresses of the device 10.63.204.51 1-1-1-1-1
————————————————————
DID DNAME PID OID ONUPORT VIFTYPE VIFID VLANID MACLIMITSTAT
MAXLEARNTMAC
10.63.204.51 C300 – 1-1-1-1-1 – VPort 1 – Enable 20
————————————————————
;
Remark:
This command is used to query the maximum number of learnt MAC addresses of
Rack1/Shelf1/Slot1/Port1/ONU1/VPort1 on 10.63.204.51.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
7-309
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
NetNumenU31R20V12.13.20T50 2013-8-13 New Command
7.2.9 LST-PORTQOS-TRAFFICPRF【【【Retrieve Port QoS Traffic
Profile】】】
l Description
This command is used to retrieve port QoS traffic profile.
l Applicable NE
NE Category NE Type Notes
DSL DSL Series
MSAN MSAG5200/MSAG5200V3/MSAG5208/C300M
Series/C300Mv4 Series/C600 Series
PON OLT C300 Series/C300v2 Series/C300v3 Series
l Command Format
LST-PORTQOS-TRAFFICPRF::(DID=device-id|DNAME=device-name),(PID=port-id|
(OID=onu-id,ONUPORT=onu-port)):CTAG::[VINTERFACETYPE=virtual-interface-type]
[,(SVLANID=svlan-id[,CVLANID=cvlan-id]|VINTERFACEID=vinterface-id,|
(VPI=vpi,VCI=vci))][,DIRECTION=direction];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(1-100) NE ID Required Under Certain
Conditions: Must
choose one between
DID and DNAME
DNAME String SIZE(1-32) NE Name Required Under Certain
Conditions: Must
choose one between
DID and DNAME
PID String rack-shelf-slot-port Port ID (e.g
1-1-3-5)
Required Under Certain
Conditions: Must
choose one between
PID and OID
7-310
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
OID String rack-shelf-slot-port-
onu
MacAddress
SN/LOID/Password
ONU ID. It's used
to identify the
ONU while DID or
DNAME indicates
the OLT device.
(e.g.1-1-1-2-1
00-18-FE-7C-
64-E4
ZTEG54998768)
Required Under Certain
Conditions: Must
choose one between
PID and OID
ONUPORT String [rack-][shelf-][slot-]p-
ort
UNI Port of ONU
(e.g. 3-2:
slot3-port2
If no slot, 2: port2
1-1-3-2: rack1-
shelf1-slot3-port2)
Required Under
Certain Conditions:
Must choose one
between PID and
(OID,ONUPORT)
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
VINTER-
FACETYPE
String VLAN
BrgPort
VPort
Virtual Interface
Type.
(VPort is supported
by PON OLT/C300
Mv4/C350Mv4.)
Optional
SVLANID Integer 1-4094 S-VID Optional
CVLANID Integer 1-4094 C-VID Optional
VINTER-
FACEID
Integer 1-128 Virtual Interface ID Optional
VPI Integer 0-255 VPI
Not supported by
MSAN.
Optional
VCI Integer 0-65535 VCI
Not supported by
MSAN.
Optional
DIRECTION String Ingress
Egress
Direction Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
7-311
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Title of Response Result: Port QoS Traffic Profile
Parameter
Name
Type Value Range Description
DID String SIZE(1-100) NE ID
PID String rack-shelf-slot-port Port ID (e.g 1-1-3-5)
OID String rack-shelf-slot-port-onu
MacAddress
SN/LOID/Password
ONU ID. It's used to identify
the ONU while DID or DNAME
indicates the OLT device.
(e.g.1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
VINTERFACE-
TYPE
String VLAN
BrgPort
VPort
Virtual Interface Type
SVLANID Integer 1-4094 S-VID
CVLANID Integer 1-4094 C-VID
VINTERFACEID Integer 1-128 Virtual Interface ID
DIRECTION String Ingress
Egress
Direction
TRAFFICPRF String SIZE(0-32) Traffic Profile Name
VPI Integer 0-255
Not supported by MSAN.
VPI
VCI Integer 0-65535
Not supported by MSAN.
VCI
l Error Code
DDNS, DDOF
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command :
LST-PORTQOS-TRAFFICPRF::DID=10.61.94.35,PID=1-1-5-2:5::;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
totalrecord=1
Port QoS Traffic Profile
7-312
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
—————————————————————————
DID PID OID VINTERFACETYPE SVLANID CVLANID
VINTERFACEID DIRECTION TRAFFICPRF VPI VCI
10.61.94.35 1-1-5-2 – VLAN 5 – – Egress TEST.PRF 8 81
—————————————————————————
;
Remark:
This command is used to retrieve port QoS traffic profile of Rack1/Shelf1/Slot5/Port2
on 10.61.94.35.
No.2 Command :
LST-PORTQOS-TRAFFICPRF::DID=10.61.94.35,PID=1-1-5-2:5::
VINTERFACETYPE=BrgPort, VINTERFACEID=1;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
totalrecord=1
Port QoS Traffic Profile
—————————————————————————
DID PID OID VINTERFACETYPE SVLANID CVLANID
VINTERFACEID DIRECTION TRAFFICPRF VPI VCI
10.61.94.35 1-1-5-2 – BrgPort – – 1 Egress TEST.PRF 8 81
—————————————————————————
;
Remark:
This command is used to retrieve port QoS traffic profile of
Rack1/Shelf1/Slot5/Port2/BrgPort1 on 10.61.94.35.
No.3 Command :
LST-PORTQOS-TRAFFICPRF::DID=10.61.94.35,PID=1-1-5-2:5::
VINTERFACETYPE=BrgPort,VPI=8,VCI=81;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
7-313
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
totalrecord=1
Port QoS Traffic Profile
—————————————————————————
DID PID OID VINTERFACETYPE SVLANID CVLANID
VINTERFACEID DIRECTION TRAFFICPRF VPI VCI
10.61.94.35 1-1-5-2 – BrgPort – – – Egress TEST.PRF 8 81
—————————————————————————
;
Remark:
This command is used to retrieve port QoS traffic profile of
Rack1/Shelf1/Slot5/Port2/BrgPort(8/81) on 10.61.94.35.
No.4 Command :
LST-PORTQOS-TRAFFICPRF::DID=10.61.94.35,OID=1-1-5-2-1:5::
VINTERFACETYPE=VPort, VINTERFACEID=1;
Response:
0 2004-04-01 10:55:49
M 5 COMPLD
EN=0 ENDESC=No Error
totalrecord=1
Port QoS Traffic Profile
—————————————————————————
DID PID OID VINTERFACETYPE SVLANID CVLANID
VINTERFACEID DIRECTION TRAFFICPRF VPI VCI
10.61.94.35 – 1-1-5-2-1 VPort – – 1 Egress TEST.PRF – –
—————————————————————————
;
Remark:
This command is used to retrieve port QoS traffic profile of Rack1/
Shelf1/Slot5/Port2/ONU1/VPort1 on 10.61.94.35.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
7-314
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.14.20T80 2014-9-23 New Command Parameter Values:VPort
forVINTERFACETYPE
New Response Parameter Values:VPort
for VINTERFACETYPE
7.2.10 LST-ONUTCONT【【【Query ONU TCONT Configuration】】】
l Description
This command is used to query ONU TCONT configuration.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C300v2 Series/C300v3 Series/C600
Series
l Command Format
LST-ONUTCONT::(DID=device-id|DNAME=device-name)[,PID=port-id][,OID=onu-id]
:CTAG::[ONUPROFILENAME=onu-profile-name];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
DID String SIZE(0-100) NE ID Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
DNAME String SIZE(0-32) NE Name Required
Under Certain
Conditions:Must
choose one between
DID and DNAME
PID String rack-shelf-slot-
port
Port ID (e.g. 1-1-5-2) Optional
7-315
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
OID String rack-shelf-slot-
port-onu
MacAddress
SN/LOID/Pass-
word
ONU ID. It's used
to identify the ONU
while DID or DNAME
indicates the OLT
device.
(e.g. 1-1-1-2-1
00-18-FE-7C-64-E4
ZTEG54998768)
Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Command Parameter
Parameter
Name
Type Value Range Description Optional Description
ONUPRO-
FILENAME
String SIZE(1-64) ONU Profile NAME Required
Under Certain
Conditions:Must
choose one
between OID and
ONUPROFILENAME
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
Title of Response Result: List of ONU TCONT information
Parameter Name Type Value Range Description
DID String SIZE(0-100) NE ID
DNAME String SIZE(0-32) NE Name
OID String rack-shelf-slot-port-onu ONU ID
-- means not supported
ONUTCONTID Integer 1-255 TCONT ID in ONU
TCONTNAME String SIZE(0-64) TCONT Name
TCONTALLOCID Integer 256-4095 Global Allocated ID of TCONT
BANDWIDTH-
PROFILE
String SIZE(0-64) Bandwidth Profile Name
l Error Code
DDOF, IIPE, EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
7-316
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Command 1:
LST-ONUTCONT::DID=10.63.173.78,OID=1-1-2-1-1:CTAG::;
Response：
SH10083644D02 2014-03-19 14:19:37
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=3
List of ONU TCONT information
—————————————————–
DID DNAME OID ONUTCONTID TCONTNAME TCONTALLOCID
BANDWIDTHPROFILE
10.63.173.78 MT-OLT 1-1-2-1-1 1 HSI 264 T1-10M
10.63.173.78 MT-OLT 1-1-2-1-1 2 VoIP 265 T1-5M
10.63.173.78 MT-OLT 1-1-2-1-1 3 test 266 T1-20M
—————————————————–
;
Remark:
This command is used to query TCONT configuration of
Rack1/Shelf1/Slot2/Port1/ONU1 on 10.63.173.78.
Command 2:
LST-ONUTCONT::DID=10.63.173.78:CTAG::ONUPROFILENAME=line-profile;
Response：
SH10083644D02 2017-07-19 14:19:37
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=3
List of ONU TCONT information
—————————————————–
DID DNAME OID ONUTCONTID TCONTNAME TCONTALLOCID
BANDWIDTHPROFILE
7-317
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
10.63.173.78 MT-OLT – HSI 264 T1-10M
10.63.173.78 MT-OLT – 2 VoIP 265 T1-5M
10.63.173.78 MT-OLT – 3 test 266 T1-20M
—————————————————–
;
Remark:
This command is used to query TCONT configuration of ONU profile line-profile on
NE 10.63.173.78.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.13.40T70 2014-3-20 New TL1 Command
NetNumenU31R20V12.17.20T120 2017-7-19 New Command
Parameters：
ONUPROFILENAME
7.2.11 LST-ONUCFG【【【Query ONU Configuration Information】】】
l Description
This command is used for querying the configuration information including ONU state,
fiber length, authorization information, etc of a certain ONU.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C600 Series
PON ONU F820/LAN-MDU Series/xDSL-MDU Series
l Command Format
7-318
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
LST-ONUCFG::OLTID=olt-name,PONID=ponport_location,ONUIDTYPE=id-type,
ONUID=onu-index:CTAG::;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional
Description
OLTID String SIZE(128) OLT IP address,
name, or ID
Required
PONID String SIZE(128)
Rack–Shelf–Slot–
PON Port ID
To locate a
PON port by
Rack-Shelf-Slot-PON
Port ID. Type NA
when this parameter
is absent.
Required
ONUIDTYPE String ONU_NAME,
MAC,
LOID, ONU_NUM-
BER
ONU identifier
type (ONU_NAME,
MAC, LOID,
ONU_NUMBER)
Required
ONUID String SIZE(128) ONU identifier.
The value could
be chosen from
ONU_NAME,
MAC, LOID and
ONU_NUMBER to
uniquely identify an
ONU on the PON
port.
Required
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
Parameter Name Type Value Range Description
AdminState String UP
DOWN
Administration state
OperState String UP
Power-Off
LOS
Operation status
AUTHTYPE String MAC
LOID
LOIDONCEON
Authorization type
7-319
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
AUTHINFO String SIZE(64) Authorization information.
If AUTHTYPE is MAC
authorization, AUTHINFO
is MAC address. If AUTHTYPE
is LOID authorization,
AUTHINFO is LOID.
Length Double 0–100 Optical fiber length
Unit: km
UsFixedBw Integer 0–40000 Upstream fixed bandwidth
Unit: Mbit/s
UsAssuredBw Integer 0–40000 Upstream assured bandwidth
Unit: Mbit/s
UsMaxBw Integer 0–40000 Upstream maximum bandwidth
Unit: Mbit/s
DsMaxBw Integer 0–40000 Downstream maximum
bandwidth
Unit: Mbit/s
l Error Code
DDOF、IIPE、EEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command :
LST-ONUCFG::OLTID=10.63.173.78,PONID=1-1-14-9,ONUIDTYPE=SN,
ONUID=ZTEGC409D896:CTAG::
Response：
PON001 2014-02-26 16:42:30
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
list of ONU configuration
—————————————————–
AdminState OperState AUTHTYPE ONUID Length UsFixedBw UsAssuredBw
UsMaxBw DsMaxBw
UP UP SN ZTEGC409D896 0.0050 – – – –
7-320
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
—————————————————–
;
Remark:
This command is used to list ONU configuration of port 1-1-14-9 on 10.63.173.78.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
7.2.12 LST-OMDDM【【【Query Optical Module DDM Information】】】
l Description
This command is used to query the optical module DDM information including ETH
optical module, OLT PON optical module, and ONU PON optical module.
l Applicable NE
NE Category NE Type Notes
PON OLT C300 Series/C300v2 Series/C300v3 Series/C600 Series
PON ONU F820/LAN-MDU Series/xDSL-MDU Series
l Command Format
LST-OMDDM::ONUIP=onu-name|OLTID=olt-name[,PONID=ponport_location[,ONU-
IDTYPE=id-type,ONUID=onu-index]][,PORTID=lanport_index][,PEERFLAG=flag]
[,FRDB=from-database]:CTAG::[CHANNELID=channel-id];
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional
Description
7-321
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
ONUIP String SIZE(128) IP address or name
of the ONU that has
management IP
Required for the ONU
with management IP
OLTID String SIZE(128) OLT IP address or
name
Required for the
ONU that has no
management IP
PONID String SIZE(128)
Rack-Shelf-Slot-
PON Port ID
To locate a
PON port by
Rack-Shelf-Slot-PON
Port ID. Type NA
when this parameter
is absent.
Optional
ONUIDTYPE String SIZE(128) ONU_NAME,
MAC, LOID,
ONU_NUMBER
Optional
ONUID String SIZE(128) ONU identifier. The
value could be one
of ONU_NAME,
MAC, LOID and
ONU_NUMBER to
identify a single ONU
on the PON port.
Optional
PORTID OCTET
STRING
SIZE(128)
Rack-Shelf-Slot-
Port ID
To locate a portby
Rack-Shelf-Slot-Port
ID. Type NA when this
parameter is absent.
Optional
It is used to query
uplink optical module
information.
PEERFLAG OCTET
STRING
True
False
The default value
is False. It is
used to optical
power information
of opposite end.
Optional
FRDB OCTET
STRING
True
False
From Database. If
it is true, statistical
data are got from
database. Otherwise,
from NE.
The pre-condition of
using statistical data
in database is that the
policy of "AccessLay-
erDevice_Resource
and Performance
Optional
7-322
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Data Retrieve Policy"
has run successfully.
l Command Parameter
Parameter Name Type Value Range Descrip-
tion
Optional
Description
CHANNELID Integer 1-8 Channel ID Optional
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
Title of Response Result: List of Optical Power Info
Parameter Name Type Value Range Description
ONUID OCTET
STRING
SIZE(128) Return “--” when querying the
OLT optical module.
Return the ONU identifier
when querying the ONU optical
module, and the value is
ONU_Number.
RxPower OCTET
STRING
-40 - 10 Receiving optical power
unit: dBm
RxPowerR OCTET
STRING
Normal
High
Low
To check whether the receiving
optical power is normal.
TxPower OCTET
STRING
-40 - 10 Transmission optical power
unit: dBm
TxPowerR OCTET
STRING
Normal
High
Low
To check whether the
transmission optical power
is normal.
CurrTxBias OCTET
STRING
0 - 131 Bias current
unit: mA
7-323
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
CurrTxBiasR OCTET
STRING
Normal
High
Low
To check whether the bias
current is normal.
Temperature OCTET
STRING
-45 - 90 Temperature
unit: ℃
TemperatureR OCTET
STRING
Normal
High
Low
To check whether the
temperature is normal.
Voltage OCTET
STRING
0 - 6.55 Power supply voltage
unit: V
VoltageR OCTET
STRING
Normal
High
Low
To check whether the power
supply voltage is normal.
PTxPower OCTET
STRING
-40 - 10 Transmission power supply of
the opposite end
unit: dBm
PRxPower OCTET
STRING
-40 - 10 Receiving power supply of the
opposite end
unit: dBm
ChannelId Integer 1-8 Channel ID
This response parameter will be
shown only when the parameter
'port.isSupportComboPon'
in the TL1 configuration file
'an-pon-tl1-param.properties' is
enable.The default value of this
parameter is disable.
l Error Code
DDOF, IIPE
Refer to Chapter 5 Unified Error Code Definition for more details.
7-324
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
l Example
Command 1:
LST-OMDDM::OLTID=10.46.41.14,PONID=1-1-7-1:CTAG::;
Response：
ZTE_10.63.204.128 2014-05-07 09:53:54
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
List of Optical Power Info
—————————————————–
ONUID RxPower RxPowerR TxPower TxPowerR CurrTxBias CurrTxBiasR
Temperature TemperatureR Voltage VoltageR PTxPower PRxPower
– – – 4.122 Normal 7.858 Normal 43.75 Normal 3.352 Normal – –
—————————————————–
;
Remark:
This command is used to query PON port optical module DDM information from OLT.
Command 2：：：
LST-OMDDM::OLTID=10.46.41.14,PONID=1-1-6-5,ONUIDTYPE=SN,ONUID=ZTEG-
00E00008:CTAG::;
Response：
ZTE_10.63.204.128 2014-05-07 09:59:18
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
List of Optical Power Info
—————————————————–
ONUID RxPower RxPowerR TxPower TxPowerR CurrTxBias CurrTxBiasR
Temperature TemperatureR Voltage VoltageR PTxPower PRxPower
16 -17.049 Normal 1.938 Normal 14.976 Normal 33.863 Normal 3.32 Normal – –
7-325
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
—————————————————–
;
Remark：
This command is used to query ONU optical module DDM information from OLT.
Command 3：：：
LST-OMDDM::OLTID=10.46.41.14,PONID=1-1-6-5,PEERFLAG=true:CTAG::;
Response：
ZTE_10.63.204.128 2014-05-07 10:01:26
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=7
List of Optical Power Info
—————————————————–
ONUID RxPower RxPowerR TxPower TxPowerR CurrTxBias CurrTxBiasR
Temperature TemperatureR Voltage VoltageR PTxPower PRxPower
– – – 3.239 Normal 12.814 Normal 49.3 Normal 3.155 Normal – –
1 -20.044 Normal – – 14.784 Normal 33.003 Normal 3.32 Normal 1.978 -16.98
2 – – – – – – – – – – – –
11 -20.07 Normal – – 14.8 Normal 33.027 Normal 3.32 Normal 1.928 -16.98
12 – – – – – – – – – – – –
13 – – – – – – – – – – – –
16 -20.044 Normal – – 14.77 Normal 32.968 Normal 3.3 Normal 1.987 -17.032
—————————————————–
;
Remark：
This command is used to query PON port optical module DDM information from OLT,
including information of ONU.
Command 4：：：
LST-OMDDM::OLTID=10.63.193.209,PORTID=1-1-19-2:CTAG::;
Response：
7-326
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
ZTE_10.63.204.128 2014-05-07 10:01:26
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
List of Optical Power Info
—————————————————–
ONUID RxPower RxPowerR TxPower TxPowerR CurrTxBias CurrTxBiasR
Temperature TemperatureR Voltage VoltageR PTxPower PRxPower
– -30.659 Normal -5.026 Normal 7.83 Normal 40.968 Normal 3.223 Normal – –
—————————————————–
;
Remark：
This command is used to query uplink port optical module DDM information from OLT.
Command 5:
LST-OMDDM::OLTID=10.46.41.14,PONID=1-1-6-5,ONUIDTYPE=SN,ONUID=ZTEG-
00E00008:CTAG::FRDB=True;
Response：
ZTE_10.63.204.128 2014-05-07 10:59:23
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
List of Optical Power Info
—————————————————–
ONUID RxPower RxPowerR TxPower TxPowerR CurrTxBias CurrTxBiasR
Temperature TemperatureR Voltage VoltageR PTxPower PRxPower
16 -17.049 Normal 1.938 Normal 14.976 Normal 33.863 Normal 3.32 Normal – –
—————————————————–
;
Remark:
This command is used to query ONU optical module DDM information from database.
7-327
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
Command 6：：：
LST-OMDDM::OLTID=10.63.193.209,PORTID=1-1-19-2:CTAG::CHANNELID;
Response：
ZTE_10.63.204.128 2014-05-07 10:01:26
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
List of Optical Power Info
—————————————————–
ONUID RxPower RxPowerR TxPower TxPowerR CurrTxBias CurrTxBiasR
Temperature TemperatureR Voltage VoltageR PTxPower PRxPower ChannelId
– -30.659 Normal -5.026 Normal 7.83 Normal 40.968 Normal 3.223 Normal – – 1
—————————————————–
;
Remark：
This command is used to query optical module DDM information of PON port channel
1 from OLT(supporting combo PON).
Command 7：：：
LST-OMDDM::OLTID=10.63.193.209,PORTID=1-1-19-2:CTAG::;
Response：
ZTE_10.63.204.128 2014-05-07 10:01:26
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
List of Optical Power Info
—————————————————–
ONUID RxPower RxPowerR TxPower TxPowerR CurrTxBias CurrTxBiasR
Temperature TemperatureR Voltage VoltageR PTxPower PRxPower ChannelId
– -30.659 Normal -5.026 Normal 7.83 Normal 40.968 Normal 3.223 Normal – – 1
– -30.659 Normal -5.026 Normal 7.83 Normal 40.968 Normal 3.223 Normal – – 2
7-328
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
—————————————————–
;
Remark：
This command is used to query optical module DDM information of PON port from
OLT(supporting combo PON).
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
l Revision History
Revision Date Notes
NetNumenU31R20V12.13.40T70 2014-05-07 New Command Parameters: FRDB
NetNu-
menU31R20V12.16.20T110
2016-08-30 New Command Parameters: CHANNELID
New Response Parameters: ChannelId
7.2.13 LST-LANPORT【【【Query LAN Port Information】】】
l Description
This command is used to query LAN port information.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.1/C220v1.2/C300 Series/C300v2 Series/C300v3
Series/C600 Series
PON ONU F820/LAN-MDU Series/xDSL-MDU Series
l Command Format
LST-LANPORT::ONUIP=onu-name|(OLTID=olt-name[,PONID=ponport_location,ONUIDTYPE=onuid-type,ONUID=onu-index])[,PORTID=port_index]:CTAG::;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional Description
7-329
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
ONUIP OC-
TET
STR-
ING
SIZE(1-128) IP address or name, or
ID of the ONU which
has management IP
Required for the ONU
that has management
IP
OLTID OC-
TET
STR-
ING
SIZE(1-128) OLT IP address or
name, ID
Required for the OLT
or the ONU that has
no management IP
PONID OC-
TET
STR-
ING
SIZE(1-128) PON Port location
information, located
by Rack-Shelf-Slot-
PON Port, Type NA
when this parameter
is absent
Required for the
ONU that has no
management IP
ONUID-
TYPE
OC-
TET
STR-
ING
ONU_NAME
ONU_NUMBER
MAC
LOID
SN
PASSWORD
ONU Identifier type Required for the
ONU that has no
management IP
ONUID OC-
TET
STR-
ING
SIZE(1-128) ONU Identifier, the
value could be chosen
from ONU_NAME,
MAC, LOID,
ONU_NUMBER, SN
and PASSWORD,one
of which could identify
a single ONU of PON
port.
Required for the
ONU that has no
management IP
PORTID OC-
TET
STR-
ING
SIZE(1-128) To locate the
LAN port by
Rack-Shelf-Slot-LAN
Port ID; Type NA
when this parameter
is absent.
Optional
l Command Parameter
None.
l Response Format
Refer to Section 4.2.2.2 for detailed TL1 command response format.
l Response Parameters
7-330
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
Title of Response Result: "list of lan port info"
Parameter
Name
Type Value Range Description
ONUIP OCTET
STRING
SIZE(0-128) ONU management IP，Return “--”
when ONU IP is absent.
OLTID OCTET
STRING
SIZE(0-128) OLT IP address or name, ID.
PONID OCTET
STRING
SIZE(0-128) PON Port location information,
located by Rack-Shelf-Slot-PON
Port，Return “--” when ONU IP is
absent.
ONUID OCTET
STRING
SIZE(0-128) ONU Identifier，Return “--” when
ONU IP is absent.
PORTID OCTET
STRING
SIZE(0-128) LAN port ID，Return “--” when
ONU IP is absent.
ADMINSTATUS OCTET
STRING
UP
DOWN
Administrative status.
DUPLEX OCTET
STRING
Full
Half
Auto
Auto-Full
Auto-Half
Working mode.
SPEED OCTET
STRING
Auto
10M
100M
1000M
Auto-10M
Auto-100M
Auto-1000M
Speed.
RateLimitUs INTE-
GER
0-1000000 Upstream rate limit (Unit:kbps).
RateLimitDs INTE-
GER
0-1000000 Downstream rate limit (Unit:kbps).
l Error Code
DDOF、EEEH
Refer to Chapter 5 Unified Error Code Definition for more details.
l Example
No.1 Command:
7-331
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
LST-LANPORT::OLTID=10.63.194.46:CTAG::;
Response:
ZTE_10.63.204.161 2013-11-13 10:29:02
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=4
list of lan port info
—————————————————–
ONUIP OLTID PONID ONUID PORTID ADMINSTATUS DUPLEX SPEED
RateLimitUs RateLimitDs
– 10.63.194.46 – – 1-1-20-1 UP Full 10000 – –
– 10.63.194.46 – – 1-1-20-2 UP Full 10000 – –
– 10.63.194.46 – – 1-1-20-3 UP Full – – –
– 10.63.194.46 – – 1-1-20-4 UP Full – – –
—————————————————–
;
Remark:
This command is used to query all the LAN port information for OLT.
No.2 Command:
LST-LANPORT::OLTID=10.63.194.46,PORTID=1-1-20-1:CTAG::;
Response:
ZTE_10.63.204.161 2013-11-13 10:29:22
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
list of lan port info
—————————————————–
ONUIP OLTID PONID ONUID PORTID ADMINSTATUS DUPLEX SPEED
RateLimitUs RateLimitDs
– 10.63.194.46 – – 1-1-20-1 UP Full 10000 – –
—————————————————–
7-332
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
;
Remark:
This command is used to query the specified LAN port information for OLT.
No.3 Command:
LST-LANPORT::OLTID=10.63.194.46,PONID=1-1-9-1,ONUIDTYPE=MAC,
ONUID=11-22-33-44-55-66:CTAG::;
Response:
ZTE_10.63.204.161 2013-11-13 10:37:09
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=4
list of lan port info
—————————————————–
ONUIP OLTID PONID ONUID PORTID ADMINSTATUS DUPLEX SPEED
RateLimitUs RateLimitDs
– 10.63.194.46 1-1-9-1 2 1-1-1-1 UP Auto Auto – –
– 10.63.194.46 1-1-9-1 2 1-1-1-2 UP Auto Auto – –
– 10.63.194.46 1-1-9-1 2 1-1-1-3 UP Auto Auto – –
– 10.63.194.46 1-1-9-1 2 1-1-1-4 UP Auto Auto – –
—————————————————–
;
Remark:
This command is used to query all the LAN port information for the ONU that has no
management IP.
No.4 Command:：：：
LST-LANPORT::OLTID=10.63.194.46,PONID=1-1-3-1,ONUIDTYPE=LOID,
ONUID=56666789888,PORTID=1-1-1-1:CTAG::;
Response:
ZTE_10.63.204.161 2013-11-13 10:36:22
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
7-333
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
list of lan port info
—————————————————–
ONUIP OLTID PONID ONUID PORTID ADMINSTATUS DUPLEX SPEED
RateLimitUs RateLimitDs
– 10.63.194.46 1-1-3-1 10 1-1-1-1 UP Auto Auto 0 0
—————————————————–
;
Remark:
This command is used to query specified LAN port information for the ONU that has
no management IP.
No.5 Command:
LST-LANPORT::ONUIP=10.63.204.102:CTAG::;
Response:
ZTE_10.63.204.161 2013-11-13 10:41:35
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=16
list of lan port info
—————————————————–
ONUIP OLTID PONID ONUID PORTID ADMINSTATUS DUPLEX SPEED
RateLimitUs RateLimitDs
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-1 UP Full 10M 1024 2048
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-2 UP Full 10M 0 2048
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-3 UP – – 0 0
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-4 UP – – 0 0
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-5 UP – – 0 0
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-6 UP – – 0 0
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-7 UP – – 0 0
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-8 UP – – 0 0
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-9 UP – – 0 0
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-10 UP – – 0 0
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-11 UP – – 1000 1000
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-12 UP – – 0 0
7-334
|07-01-2017 ZTE Proprietary and Confidential
Chapter 7 TL1 Command Description
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-13 UP – – 0 0
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-14 UP – – 0 0
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-15 UP – – 0 0
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-16 UP – – 0 0
—————————————————–
;
Remark:
This command is used to query all the LAN port information for the ONU that has
management IP.
No.6 Command:
LST-LANPORT::ONUIP=10.63.204.102,PORTID=1-1-1-1:CTAG::;
Response:
ZTE_10.63.204.161 2013-11-13 10:46:03
M CTAG COMPLD
EN=0 ENDESC=No Error
totalrecord=1
list of lan port info
—————————————————–
ONUIP OLTID PONID ONUID PORTID ADMINSTATUS DUPLEX SPEED
RateLimitUs RateLimitDs
10.63.204.102 10.63.194.46 1-1-9-1 1 1-1-1-1 UP Full 10M 1024 2048
—————————————————–
;
Remark:
This command is used to query specified LAN port information for the ONU that has
management IP.
l Average Command Response Time
Scenario Average Response Time (s)
l Notes
Point Details
7-335
|07-01-2017 ZTE Proprietary and Confidential
NetNumenU31 GPON NBI Reference Manual for TL1
l Revision History
Revision Date Notes
7.2.14 LST-LANPERF【【【Query LAN Port Performance】】】
l Description
This command is used for querying the ETH performance information of theOLT uplink
port or ONU LAN port.
l Applicable NE
NE Category NE Type Notes
PON OLT C220v1.2/C300 Series/C600 Series
PON ONU F820/LAN-MDU Series/xDSL-MDU Series
l Command Format
LST-LANPERF::ONUIP=onu_name|OLTID=olt_name[,PONID=ponport_location,
NUIDTYPE=id-type,ONUID=onu_index],PORTID=lanport_index:CTAG::;
l Operated Target Identifier
Parameter
Name
Type Value Range Description Optional
Description
ONUIP String SIZE(128) IP address, name, or
ID of the ONU that
has management IP
OLTID String SIZE(128) OLT IP address,
name, or ID
PONID String SIZE(128)
Rack–Shelf–Slot–
PON Port ID
To locate a
PON port by
Rack-Shelf-Slot-PON
Port ID. Type NA
when
