PROBLEM 12.14
Solve Problem 12.13, assuming that the coefficients of
friction between block A and the incline are 0.25sμ = and
0.20.kμ =
PROBLEM 12.13 The two blocks shown are originally at
rest. Neglecting the masses of the pulleys and the effect of
friction in the pulleys and between block A and the incline,
determine (a) the acceleration of each block, (b) the tension
in the cable.

SOLUTION
We first determine whether the blocks move by computing the friction force required to maintain block A in
equilibrium. T = 175 lb. When B in equilibrium,
 req0: 175 200sin 30 0xF FΣ = − ° − =
 req 75.0 lbF =
 0: 200cos30 0 173.2 lbyF N NΣ = − ° = =
 0.25(173.2 lb) 43.3 lbM sF Nμ= = =
Since req , blocks will move ( up and down).mF A B> F
We note that
1
.
2B Aa a=
Block A

 (0.20)(173.2) 34.64 lb.kF Nμ= = =

200
0 : 200sin 30 34.64
32.2x A A AF m T aΣ = − ° − + = (1)
