INTRODUCTION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 I
Introduction

Thank you for choosing “SANY” Full Hydraulic
Double Drum Vibratory Roller. We will offer you
high-quality products and star-grade after-sales
service. Our company, absorbing the domestic and
international advanced technology of rollers, and
based on long-term experience in designing and
manufacturing construction machinery, has
developed an innovative product -- Full Hydraulic
Double Drum Vibratory Roller. It is a kind of
engineering machinery with multiple purposes and
high efficiency. It can be widely used in the
construction of such projects as the high-grade
highway, airport, dam, port, railway and mine. It can
be used for the compaction of asphalt concrete
pavement and RCC concrete pavement, as well as
middle/small subgrade, sub-roadbed and stabilized
course.
In this Operation Manual, we will introduce to
you such contents as performance parameters,
technical characteristics, operating principle,
structural components, safety operation, and
maintenance of the machine.


In order to properly use the machine, you must
read this Operation Manual carefully before
operation. This helps:
 to know the machine better;
 to avoid troubles due to improper operation;
 to improve the machine reliability;
 To increase the service life of the machine; and
 To reduce the repair cost and downtimes.
Put this Manual within your reach for your
reference at any time. Only when you completely
understand the Operation Manual, can you operate
the machine expertly and safely.
Thank you for your trust in “SANY”. We wish
you great success in your business.













SANY Heavy Industry Co., Ltd.






 INTRODUCTION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 II

Special Instructions
You must carefully maintain and properly use
the roller. SANY accepts no liability resulting from
operations against the instructions.
 Before operation, you must read this Operation
Manual carefully. Carry out operation in
accordance with the detailed requirements.
 Use the roller for the purposes specified in the
Operation Manual. Do not use it for other
purposes.
 The machine must be operated by well-trained
and skillful operators. The operator must keep
calm, quick-witted and in steady mood during
operation.
 Do not ask unskilled technicians to repair or
disassemble the machine.
 The machine must be maintained according to
the requirements as specified in this Manual.
 Maintain the engine strictly as per the User’s
Guide provided by the engine manufacturer.

Acceptance
1. After receiving the roller, you must check the
machine and accessories against the list. If you
find the machine damaged or spare parts lost,
you must inform the department responsible for
shipping as soon as possible.
2. When contacting after-sales service staff of
SANY or local service department, do
remember to provide the model, and ex-factory
number of the roller and the serial number of
the engine.
3. The rating plate of the roller is shown in the
figure.

12500


4. The serial number of the engine may be found
on the engine rating plate.


























CUMMINS Engine
DEUTZ Engine
READING GUIDANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 III
Reading Guidance
1. Information
The Operation Manual is intended to
familiarize users with the use and maintenance of
the machine. You must put it in the cab for your
reference at any time. In the event of any damage
or lost, you should order another one from SANY
Heavy Industry Co., Ltd. The Operation Manual
covers the information for performance parameters,
technical characteristics, operating principle,
structural components, safety operation and
maintenance of the machine.
Some photos or details in figure or optional
components in the Operation Manual may differ
from your machine. For facilitating the explanation,
the guard board and cover have been removed.
Some modifications as a result of constant
improvement may not be covered in this Manual.
You must read this Manual carefully and keep it
with the machine.
If you have any queries about the machine or
this Manual, you can contact us for the latest
information.
2. Technical Specifications
This section provides the performance
parameters, technical characteristics, operating
principle and structural components of the machine.
It will help you have an overall idea about the
machine.
3. Operation
This section provides guidance for fresh
operators and reference for experienced operators.
It covers a variety of instruments, switches,
operating mechanism of the machine, as well as
the transportation of the machine.
Some photos and figures are provided to guide
the operator to check, start, operate and shut down
the machine according to the accurate procedures.
All instructions provided in this Manual are
about the basic operation technique. The
operator’s technique and skills will be enhanced as
he knows the machine better.
4. Maintenance
This section provides guidance for maintaining
the machine. The maintenance items are listed in
the maintenance and lubrication interval table. The
items without specific maintenance intervals are
listed under the title of “Maintenance Interval”.
5. Maintenance Interval
The maintenance interval is determined by
operating hours or natural time. No matter whether
it is calculated at operating hours or natural time,
the maintenance recommended must be carried
out within the maintenance interval which comes
first.
Under the extremely tough, dusty or damp
working conditions, the maintenance interval shall
be shortened.
When you carry out maintenance for certain
parts, other parts whose maintenance intervals are
shorter must also be maintained. For example,
during the maintenance carried every 500h’s
operation or 3 months, the maintenance items for
every 250h’s operation or 1 month, as well as those
for every 10h’s operation or each day must also be
maintained.
6. Engine Maintenance
The proper engine maintenance and overhaul
are essential for the normal operation of the
machine and engine. The owner of the machine is
liable for carrying out maintenance for the engine
as per the instructions stated in the Parts Manual.
Any personnel taking on repair, maintenance,
sales, rent or trade of the machine or engine must
not disassemble, modify or disable the devices or
parts installed on or in the machine or engine which
are in relation to emission and in accordance with
the laws and regulations. Some parts in the
machine or engine, such as exhaust system, fuel
system, electrical system, intake system or cooling
system, may be in relation to emission, so do not
alter or modify them without prior approval.
7. Machine Capability
The newly-added optional or refitted parts
unrecognized by SANY may go beyond the
designed capability of the machine, and
accordingly produce negative effect on machine
performance including stability and system
compatibility, such as braking and steering.

 READING GUIDANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 IV
8. Explanation of Signs

This is a symbol for "safety caution".This symbol on the machine or in this
Manual is used to identify dangers of personnel injury.
Please obey the precautions and methods suggested.
On the safety plates, this symbol is used together with the words "Danger",
"Warning" and "Caution".

This symbol is used to identify serious dangerwhich could result in death or
serious injury if no preventive measures are taken.

This symbol is used to identify medium danger which could result in major
injury if no preventive measures are taken.

This symbol is used to identify slight danger which could result in minor or
slight injury if no preventive measures are taken.
In this Manual, this symbol is also used to call attention to the safety
instructions.

In order to avoid confusion between the indications for machine protection and
personnel safety, this symbol is adopted to identify the possible machine
damage.

This symbol is used to identify the additional specific instructions.

This symbol is used to identify the additional specific instructions.

This symbol is used to identify unsafe operation that is not in accordance with
safety regulations and is easy to cause casualty. Do not carry out such an
operation when you see this symbol.

This symbol is used to identify the operation complying with safety
regulations..

This symbol is used to identify you must take the special considerations in the
operation, or else, it may cause accidents.

Caution
Danger
Warning
Important
Notes
Notice
READING GUIDANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 V


If the description in this Manual is different
from your machine, your machine prevails.

General Information
You must carefully read all the operation parts in
this Manual. For more information about the
operation of the machine, you can read this
Manual carefully or consult the local office of
SANY Heavy Industry Co., Ltd.


















Important
TABLE OF CONTENTS
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 VI
Table of Contents

Introduction .............................................................................................................................................I
Reading Guidance.................................................................................................................................III
Chapter 1 Technical Specification...........................................................................................................1
1.1 General Description ..................................................................................................................1
1.1.1 Overall Structure .............................................................................................................1
1.1.2 Main Technical Characteristics........................................................................................2
1.2 Technical Parameters................................................................................................................3
1.3 Function Description .................................................................................................................4
1.3.1 Frame Assembly .............................................................................................................4
1.3.2 Central Articulation Frame...............................................................................................5
1.3.3 Vibratory Drum Assembly................................................................................................6
1.3.4 Spraying System .............................................................................................................7
1.3.5 Cab and Control System.................................................................................................8
1.3.6 Safety Protection Device.................................................................................................8
1.4 Engine.......................................................................................................................................9
1.4.1 Air Intake System ..........................................................................................................10
1.4.2 Exhaust System ............................................................................................................ 11
1.4.3 Fuel System ..................................................................................................................12
1.5 Electrical Control Devices .......................................................................................................12
1.5.1 General .........................................................................................................................12
1.5.2 Cab Electrical System .............................................................................................................. 13
1.5.3 Engine Electrical System ..............................................................................................15
1.5.4 Monitoring Electrical System.........................................................................................17
1.5.5 Traveling and Brake Control System.............................................................................21
1.5.6 Vibration Control System ..............................................................................................22
1.5.7 Spraying Control System...............................................................................................23
1.5.8 Basic Structure of Distribution Control Cabinet .............................................................25
1.6 Hydraulic Control Devices .......................................................................................................26
1.6.1 Traveling Hydraulic System...........................................................................................26
1.6.2 Vibration Hydraulic System ...........................................................................................26
1.6.3 Steering Hydraulic System............................................................................................28
1.6.4 Brake Hydraulic System................................................................................................29
Chapter 2 Operation and Maintenance ................................................................................................31
2.1 Starting the Equipment ............................................................................................................31
2.1.1 Check before Starting:...................................................................................................31
2.1.2 Starting..........................................................................................................................35
2.1.3 Check after Starting with the Roller Running in Place ...................................................37
2.2 Check Before Operation..........................................................................................................37
2.3 Operating the Working Device ................................................................................................37
2.3.1 Engine Speed Control ...................................................................................................37
2.3.2 Traveling .......................................................................................................................37
2.3.3 Braking During Traveling...............................................................................................37
2.3.4 Vibratory Compaction....................................................................................................38
2.3.5 Spraying ........................................................................................................................40
TABLE OF CONTENTS
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 VII
2.3.6 Parking .........................................................................................................................42
2.3.7 Text Display .................................................................................................................. 42
2.4 Cleaning the Equipment ......................................................................................................... 48
2.5 Maintenance Interval .............................................................................................................. 48
2.5.1 Routine Maintenance ................................................................................................... 48
2.5.2 Periodic Maintenance................................................................................................... 48
2.5.3 Maintenance for Long-term Parking ............................................................................. 50
2.5.4 Maintenance of Electrical System ................................................................................ 50
2.5.5 Maintenance of Air Conditioning System...................................................................... 50
2.6 Checking the Bolts.................................................................................................................. 54
2.7. Checking the Functional Oil................................................................................................... 56
2.7.1 Checking for Oil Leaks ................................................................................................. 56
2.7.2 Checking the Oil and Water Levels .............................................................................. 56
2.7.3 Table of Oils and Auxiliary Materials............................................................................. 56
Chapter 3 Transportation of Roller....................................................................................................... 58
3.1 Transfer Vehicle...................................................................................................................... 58
3.2 Self-propelled Ascending Transfer Vehicle via Slope ............................................................. 58
3.3 Loading and Unloading by Crane ........................................................................................... 59
3.4 Winch Traction........................................................................................................................ 59
Index.................................................................................................................................................... 61
Appendix ............................................................................................................................................. 63
Overall Structure........................................................................................................................... 63
Hydraulic Basic Diagram .............................................................................................................. 64
Electrical Schematic Diagram....................................................................................................... 65




































 CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM ROLLER OPERATION MANUAL
 VIII





































































































Full Hydraulic Double Drum Vibratory Roller Operation Manual
Technical Specifications

1.1 General Description
1.2 Technical Parameters
1.3 Function Description
1.4 Engine
1.5 Electrical Control Devices
1.6 Hydraulic Control Devices









P1~29


CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 1
Chapter 1 Technical Specification

1.1 General Description
The SANY double drum vibratory roller adopts full
hydraulic transmission, double drum drive, double
drum vibration and self-propelled structure. Adopting
articulation steering, the front frame and the rear frame
are connected together by the central articulation frame,
and equipped with crab-walk mechanism with excellent
performance. The double drum vibratory roller is mainly
applicable for the compaction of asphalt concrete
pavement and RCC concrete pavement of high-grade
highway and high-standard projects such as railway
subgrade, airport, dam, dock, and for the compaction
of subgrade and sub-roadbed as well.

1.1.1 Overall Structure








1-Spraying system (two sets) 2-Rear frame assembly 3-Central articulation frame 4-Hydraulic system
5-Front frame assembly 6-Vibratory drum assembly (one set for front and rear respectively)
7-Power system assembly 8-Console assembly 9-Air conditioner 10-Cab
11-Electrical system 12-Covering parts assembly
Fig. 1-1 Overall Structure of Double Drum Vibratory Roller (With Cab)
 CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 2
1.1.2 Main Technical Characteristics
 Double drum two-gear stepless shifting traveling
and double frequency double amplitude vibration
system that can meet requirements for traction and
compaction in different conditions.
 Frame of fork foot type structure which makes it
easier to get close to the obstructions.
 Vibration bearing squirrel bag lubricating cooling
structure with national patent that can ensure roller
with longer service life.
 Double articulation steering crab-walk mechanism
that is convenient for compaction at curve and
curb.
 Intelligent electric control system for control of
engine speed, achieving the scientific matching
between output power and working condition.
 Three-stage filtering and stepless flow adjusting
spraying system, providing higher working quality.
 Three-grade damping and air-conditioned cab with
functions such as sound insulation, heat insulation,
waterproof, and dustproof, complying with the
design theory of ergonomics.
 Three-grade brake system with mechanical,
electrical and hydraulic control, ensuring safe and
reliable operation.
 Key parts such as engine, hydraulic system, and
vibratory bearing of international famous brands.
 Combination of industrial model and engineering
design with bright color and nice appearance.


















CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 3
1.2 Technical Parameters
See Table1-1 for details of the main technical
parameters. The parameters with * in this table are
those of diesel engine’s (Cummins) configuration.







Table1-1 Main Technical Parameters

 Model
Technical Parameters YZC10C YZC11C YZC12C YZC13C
Operating mass cab, kg 10800 11500 12500 13000
 Steer shed, kg 10400 11100 12100 12600
Front drum module mass, kg 5350 5700 6200 6500
Rear drum module mass, kg 5450 5800 6300 6500
Front drum static linear load, N/cm 273 291 285 298 Pa
ra
m
et
er
s
of

m
as
s
an
d
lo
ad

Rear drum static linear load, N/cm 278 296 289 298
Vibration frequency, Hz 40 / 50 40 / 50 42 / 50 42 / 50
Nominal amplitude, mm 0.75 / 0.37 0.82 / 0.39 0.75 / 0.37 0.81 / 0.39
Centrifugal force, kN 110 / 70 120 / 75 130 / 85 140 / 90
Vibratory drum diameter, mm 1248 1248 1250 1250
Vibratory drum width, mm 1920 1920 2135 2135 Pa
ra
m
et
er
s
of

co
m
pa
ct
io
n
m
ec
ha
ni
sm

Wheel rim thickness of vibratory drum, mm 19 19 20 20
Travel speed High speed, km / h 0~12 0~12 0~12 0~12
 Low speed, km / h 0~5.5 0~5.5 0~6.5 0~6.5
Theoretical gradeability Vibration, % 42 38 35 30
 Non vibration,% 45 42 40 35
Min. ground clearance, mm 400 400 400 400
Wheel base, mm 3280 3280 3280 3280
Steering angle ±35° ±35° ±35° ±35°
Vertical oscillation ±10° ±10° ±10° ±10°
Min. turning external diameter, mm 12240 12240 12460 12460
Crab type travel distance, mm ±170 ±170 ±170 ±170 Pa
ra
m
et
er
s
of
 p
ow
er
-d
riv
in
g
pe
rfo
rm
an
ce

Length × width × height, mm 5000×2120×3000 5000×2350×3000
Supplier Deutz Deutz Deutz Deutz
Model BF4M1013 BF4M1013 BF4M1013 BF4M1013
Rated rotary speed, r / min 2300 2300 2300 2300 En
gi
ne

Rated power, kW 88 88 88 88
Battery, V×Ah 24×100 24×100 24×100 24×100
Water tank, l 2×480 2×480 2×480 2×480
Fuel tank, l 200 200 200 200
Capacity
parameters
Hydraulic oil tank, l 110 110 110 110
 CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 4
1.3 Function Description
1.3.1 Frame Assembly
The structure of the front frame is shown in Fig.
1-2.
The frame is subdivided into front frame and rear
frame. The front and rear frames are connected with
the central articulation frame as an integral articulation
body to support the upper structure of the machine.
The front frame assembly comprises front frame
body, fuel tank and mud scraper. It is mainly used to
support the cab and front water box. The fuel tank is
composed of two detachable parts whose bottoms are
connected by a hose, and with oil filler on the left side.
The mud scraper is used to scrape foreign materials
stick on the vibratory drum. The spring device between
the mud scraper and drum can compress automatically
without adjustment.
In order to reduce the unfavorable influences on
drivers from vibration, a cushion block is set between
the front frame and cab.
The rear frame assembly comprises rear frame
body, mud scraper, etc. It is mainly used to support the
engine, hydraulic oil tank, and rear water box, etc.
[Fig.1-3].
An elastic cushion block is set between the
engine and rear frame. It also makes it easier to adjust
the engine to the horizontal position.
In order to conveniently secure the roller on the
transfer vehicle during installation and transportation,
four shackles are set on the front and rear frames.



































Fig.1-2 Front Frame
Fig.1-3 Rear Frame
Upper mud
scraper Lower mud scraper
Lower mud scraper
Rear frame
welding part
Upper mud scraper Turn lamp
CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 5
1.3.2 Central Articulation Frame
The front frame and rear frame are connected by
the central articulation frame as an integral part. It
comprises articulation seat, coupling support, steering
cylinder, crab-walk cylinder, slewing frame and slewing
bearing, etc. [Fig.1-4]. By the central articulation frame,
the steering of the machine and side-to-side oscillation
of front frame can be achieved. The maximum
difference of longitudinal centre lines between the front
and rear vibratory drum is 170mm.



























Oscillation: The double drum vibratory roller allows a
certain vertical relative oscillation between the front and
rear frames with an oscillating angle of ±8°. Therefore,
the roller can travel stably on the uneven road surface.
To make maintenance easier, the imported spindle
bearing with self-lubrication and centripetal joint is
used.













































Fig.1-4 Central Articulation Frame
Crab-walk cylinder Slewing frame Slewing bearing
 CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 6
1.3.3 Vibratory Drum Assembly
The vibratory drum assembly [Fig.1-5] comprises
vibratory drum body (contact roller), shaft, amplitude
modulation apparatus, cushion block, driving motor,
vibratory motor, elastic coupling, vibratory bearing,
traveling support, bearing seat, plum blossom plate, left
and right fork feet, etc.
The vibratory drum body is composed of wheel
rim rolled with Q345A steel plate and spoke plate
welded onto it. The smooth and flat external surface of
the wheel rim and the even wall thickness ensure a
uniform vibratory compaction and render a function of
static compaction.
The vibratory bearing is mounted in the inner
holes of spoke plates at the left and right ends of the
vibratory drum. In view of the high requirement for
coaxiality between the inner holes of spoke plate, you
must use the special SANY vibratory drum process
equipment to ensure the coaxiality.
The bearing seat, vibratory bearing, vibratory
shaft, amplitude modulation apparatus and elastic
coupling are installed in the vibratory drum body. The
chamber is filled with gear oil to lubricate and cool the
vibratory bearing.
The rubber cushion blocks are set between the
vibratory drum and front frame to insulate the frame
from the vibration of vibratory drum.



































1-Fork foot 2-Contact roller 3-Traveling support 4-Vibratory bearing 5-Amplitude modulation
apparatus 6-Shaft 7-Reducer 8-Cushion block 9-Driving motor
Fig.1-5 Structure of Vibratory Drum Assembly
CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 7

Amplitude Modulation Apparatus
The amplitude modulation apparatus is a sealed
column welded component. It mainly comprises
movable eccentric mass, fixed eccentric mass and
retainer pin. Its schematic diagram is shown in [Fig.1-6].
The rotation direction of the vibratory shaft is changed
through changing the rotation direction of vibratory
motor. With the help of retainer pin, the fixed eccentric
mass and movable eccentric mass overlap or
counteract each other to change the eccentricity of the
vibratory shaft, so as to achieve high amplitude and low
amplitude and realize amplitude modulation.


1.3.4 Spraying System
Function: The spraying system and mud scraper
can effectively prevent drums from stick asphalt and
other foreign materials.
Structure: The spraying system comprises water
pump, spraying control switch, three-stage filter, front
and rear water boxes, pipeline and water level alarm
[Fig.1-7].


The pressure spraying system is subdivided into
two sets of independent spraying systems (front and
rear). Each system is provided with two pumps sharing
a pipeline. In the event that one pump is defective, you
can just connect the cables with the other pump to turn
to the use it for water supply. [Fig.1-8]
The spraying system sprays water under the
action of pressure. One water box, made of molded
glass fiber reinforced plastic and with a capacity of
480L, is respectively set at the front and rear sides. The
driver can see the spraying points clearly in the cab
and spray water according to specific conditions.
The pressure spraying has two modes, namely,
fixed spraying flow and adjustable spraying flow control.
You can operate the knob controller for stepless
spraying flow adjustment in the latter mode.
The hi-precision three-stage filter and new-typed
nozzle effectively prevents the nozzle from blockage,
reduces maintenance frequency and times and
improves the reliability of operation.






























Fig.1-8 Spraying System
Fig.1-6 Amplitude Modulation Apparatus
Fluid
Fig.1-7 Schematic Diagram for
Spraying Pipeline

Water
box
 CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 8
1.3.5 Cab and Control System
With special appearance design and in full
considerationof operational comfort of man-machine,
the cab makes the operation comfortable and reliable,
features beautiful and tasteful appearance, elegant and
bright interior trimming, renders broad visual field, and
offers international first-class practicability. During the
course of driving, the driver can see the surface of the
front and rear drums conveniently, which is favorable
for compaction work. The operable small door set in
the cab not only facilitates compaction at curb, but also
helps in ventilation. Besides, the door is also provided
with a special anti-collision device. When carrying out
compaction at curb, drivers can lean against the
specially-designed cushion comfortably and poke their
heads out to check the compaction. In addition, the cab
is air-conditioned and with full sealed damping
structure.
The integral console can rotate and slide leftward
and rightward. This enlarges the visual field and
facilitates the observation and compaction at curb. See
[Fig.1-9].


1.3.6 Safety Protection Device
The SANY full hydraulic double drum vibratory
roller is equipped with perfect and complete safety
protection device:
Articulating fixed safety rod: it is used to secure
the articulation frame when loading and unloading the
machine for delivery or parking it for a long time;
Starting locking device: when the traveling handle
of the machine is set at the traveling gear but without
returning to neutral position, the engine can’t be
started;
Emergency brake device;
Steering indicator lamp;
Automatic protection device of covering parts: the
gas spring with protective sleeve can prevent the
covering parts from accidental falling.












































Fig.1-9 Rotary Console
CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 9
1.4 Engine
The power device supplies power for each part
of the roller. Generally, the vibratory roller adopts
diesel engine as the power unit.
The detailed structure of the power device of
double drum vibratory roller is shown in Fig. 1-10.
A DEUTZ BF4M1013 turbocharged water-cooled
diesel engine is adopted for the double drum
vibratory roller. It features good reliability, fuel
economy, low noise and low emission, which
completely meet the requirements of EPA standard.
According to the customer demands, the
4BTA3.9 turbocharged water-cooled diesel engine
(Cummins) also could be equipped in the double
drum vibratory roller. Some parameters of the two
types of diesel engines are shown in Table 1-2.













































































1
5
7
9
10
11
6
5
7
2
11
3
1 4
8
9
10
1-Diesel engine 2-Air intake device 3-Exhaust device 4-Aerofoil 5-Coupling device 6-Double pump
7-Throttle control 8-Double diesel secondary filter 9-Diesel primary filter with oil water separator
10-Oil drain device 11-Steering pump
Fig. 1-10 Structure of Power Device
 CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 10




Table 1-2 Diesel Engine Parameters

The power device comprises the
following parts:
1.4.1 Air Intake System
The air intake system provides clean and dry air
of appropriate temperature to the engine for
combustion, so as to minimize the abrasion of
engine and ensure the optimized engine
performance. Besides, this system effectively filters
the dust away during the reasonable maintenance
interval accepted by users and keeps the intake
resistance within the limit value.
The air intake system is simple but effective. All
air filters are two-stage dry-type air filters, with a
cleaning efficiency of 99.9%. During the first stage,
the larger dust is separated under the effect of
centrifugal force and collected in a rubber container.
You must periodically remove the collected dust.
During the second stage, the rest dust is filtered by a
paper filter element. The air filter is of sufficient dust
capacity, so you may replace the filter element within
a reasonable interval. Once the filter element is
blocked by dust, the intake resistance will increase
and the air volume taken into engine will decrease,
and accordingly, the engine power may be affected.
Thus, you must periodically clean or replace the air
filter element in accordance with the engine
maintenance requirements. See [Fig.1-11].






























Manufacturer DEUTZ Cummins
Engine model BF4M1013 4BTA3.9-C125
Engine type
Turbocharged water-cooled diesel
engine
Turbocharged water-cooled diesel
engine
Rated power 88kW 93kW
Rated rotation speed 2300rpm 2200rpm
Max. torque 438N•m (1400r/min) 475N•m (1400r/min)
Qty of cylinder 4 cylinders 4 cylinders
Displacement 4.76L 3.9L
Oil consumption 229g/Kwh 229g/Kwh
1
33
32
3
1
1-Mounting rack 2-Air filter 3-Air pre-filter
Fig. 1-11 Air Intake System
CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 11
1.4.2 Exhaust System

The exhaust system not only ensures the
optimized engine performance, but also discharges the
exhausted gas into the atmospheric air quietly. The
exhaust system of double drum vibratory roller
comprises heat telescopic tube, muffler and exhaust
tube. See [Fig. 1-12].














































































4
1
4
3
2
1
1-Heat telescopic tube 2-Connecting tube 3-Muffler 4-Exhaust tube
Fig. 1-12 Exhaust System
 CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 12
1.4.3 Fuel System
The fuel system of the engine mainly comprises
fuel tank, oil tube, oil water separator and fuel
secondary filter.
(1) Fuel Tank
The fuel tank is mounted at the rear of the front
frame. It is composed of two detachable parts whose
bottoms are connected by a hose, with oil filler on the
left side. A cleaning port is set at the side face of the
fuel tank. You can periodically clean the tank by this
port. An oil-drain bolt is set at the bottom of the tank.
You can use it to drain the accumulated water and dirt.
A filter grill is set at the oil filler to filter the larger
grains in the oil.
(2) Oil Tube
The oil-in and oil-return tubes of fuel circuit are
made of self-clasping oil-proof pressure-proof hoses.
As the Deutz engine adopts the single pump which
holds the large oil-in and oil-return volumes, the
diameter of its oil-in and oil-return tube should be
respectively more than 12mm and 10mm. If the length
of oil tube exceeds 3m, you must use the tube with
greater diameter. As the Cummins engine employs the
in-line pump or rotor pump, its oil-in and oil-return
volumes are less than that of Deutz engine. Still, we
adopt the self-clasping hose with the same tube
diameter as that for Deutz. Such a tube will not be
damaged or crushed in the event of considerable
vacuum.
(3) Oil Water Separator and Fuel Filter
The fuel, more or less, contains moistures and
impurities. This may lead to premature abrasion of
engine and oil conveyer, and then cause faults in
engine such as black smoke emission and abnormal
stalling. Therefore, an oil water separator and a fuel
filter are set in the fuel circuit to prevent the moisture
and impurity form entering the fuel system.
The fuel will encounter some resistances when
passing the oil water separator and fuel filter. Thus, the
oil water separator and fuel filter should satisfy the
limited pressure value ofdiesel engine’s oil circuit.
Once the resistance of oil circuit system exceeds the
limit value of engine, the engine power will be
insufficient. Therefore, you must drain the water in oil
water separator daily and replace the fuel filter element
periodically.

1.5 Electrical Control Devices
1.5.1 General
The electrical system of the double drum vibratory
roller is a functional extended platform with a certain
remoter monitoring ability. It is based on SIEMENS
S7-200 as the control core and TD400 text display and
alarm lamp as the man-machine interface. It can
supply the power system, traveling system, vibratory
system and spraying system with corresponding
control and protection to achieve constant engine
speed control, multi-mode vibration control, intelligent
spraying control and three-grade brake parking
automatic control. It satisfies the technical requirements
of high-standard road construction and ensures
effective and safe operation of the system.
The electrical system comprises battery, starter
motor, generator, PLC, lighting lamps, electric
instruments, display, safety protection elements,
acoustic-optic alarming devices, an automatic/manual
vibration device (with two gears for frequency selection)
and an automatic/manual flow adjusting spraying
system. In addition, windscreen wipers are set at the
front and rear of the air-conditioned cab. The system
has a voltage of 24V. It is negative earthed and adopts
single-wire system. The starter motor, generator, linear
step motor, PLC, display, instruments, lighting lamps,
various sensors and other electrical elements are all
manufactured by world-renowned companies. The
configuration of the whole electric appliance system is
up to the international advanced level. The mating of
each element has been precisely calculated and
subjected to endurance test, which renders the system
high reliability, long life and high efficiency.

CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 13
1.5.2 Cab Electrical System
In order to ensure safe traveling, improve the driving
comfort level, some auxiliary electrical appliances are set
in the cab. These comprises upper beam lamp, lower
beam lamp, left turn lamp, right turn lamp, horn, front
windshield wiper and washer, rear windshield wiper, inner
lamp, radio recorder and air conditioner. See [Fig. 1-13].
















The front and rear working lamps are respectively
controlled by a knob switch on the instrument panel.
The upper beam lamp switch also offers instrument
background illumination at night. The front and rear
turn lamps provide indication and warning for turning
and parking. They are respectively controlled by knob
switches S11/S19. The inner lamp provides the night
illumination for the cab.
The air conditioner equipped in the double drum
vibratory roller has two modes: heating and
refrigeration. It can be controlled directly by the control
panel at the left side of the driver’s seat base. Its control
panel is shown in [Fig. 1-14]. Please refer to the Use of
Air Conditioner for the use and maintenance of air
conditioner.
 CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 14





















The radio recorder installed on the double drum
roller has such characteristics as two receiving
wavebands of AM/FM, automatic receiving and saving
functions, clear and fruity sound. As the radio recorder
is mounted at the right front of the cab roof, the driver
can operate it directly through the radio recorder control
panel. The function of the control panel is shown in [Fig.
1-15].

































































Fig.1-14 Air Conditioner Control Panel
Air volume switch
Indicator lamp
Temperature control switch
1 2 3 4
8
9
2 3 35 36 410
1-Power supply 2-Sound effect 3-Previous 4-Next 5-Automatic saving 6-Band
7-Preset 8-Volume up 9-Volume down 10-Crystal screen
Fig.1-15 Radio Recorder Operation Panel
CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 15


(1) You must cut off the power before replacing bulb or
other power terminations. Besides, you must use the
one of original model and trademark, as otherwise it
will cause unexpected damage.
(2) Only when the engine is started, can the air
conditioner be operated and used effectively.


1.5.3 Engine Electrical System
The engine electrical system provides the
complete vehicle with power, and controls the starting,
parking and the engine speed. It mainly comprises
ignition switch, DC contactor, battery, starter motor,
generator, oil cut-off electromagnet, linear step motor.
The schematic diagram is shown in [Fig.1-16].
Before starting the engine, make sure the
traveling handle, emergency stop switch S12 and
vibration control switch S16 have been reset to the
neutral position. Insert the switch key and turn it right to
the working position. At this moment, the charging
indicator lamp, alarm indicator lamp and neutral
position indicator lamp are lit up, while other indicator
lamps are off. It indicates the circuit is normal and gets
ready for starting. Then, turn the key right to the starting
position to ignite and start the engine. After that,
release the key immediately and have it return to the
working position automatically. After that, the machine
is started.
The default setting for engine speed control is
“manual” adjustment. The engine speed is controlled
by the throttle switch S2 on the instrument panel. The
engine speed decreases when the switch is turned to
left and increases when it is turned to right, with an
adjustment range of 750rpm-2450rpm. When the
engine speed control is set as “automatic” in the
function setting menu on the display, the engine will be
under constant engine speed control. In this case, the
engine speed will automatically adjust according to
different work conditions, with a deviation of ±25rpm.
For the static compaction state, the engine speed can
automatically adjust to 2100rpm; for the transfer to
other worksites, the engine speed can automatically
adjust to 2200rpm; and for the vibration state, the
engine speed can automatically adjust to 2300rpm.
Moreover, 10 seconds after the traveling handle
returning to the neutral position, the engine speed can
automatically return to an idle speed of 850rpm.


























Caution
Caution
 When starting the engine, you must set the
traveling control handle and vibration
control switch to the neutral position.
 Before starting the engine again, you must
turn the key to “off” position first.
 The engine starting time should not exceed
10s. Wait for at least 3min before starting
the engine again. If you fail to start the
engine for three times successively, you
must stop starting, find out the cause and
rectify the trouble.
 CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 16
























Fig.1-16 Schematic Diagram for Engine Electrical System
CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 17

1.5.4 Monitoring Electrical System
The system can display, at real time, such
parameters as engine speed, accumulated working
time, coolant temperature, traveling speed and fuel
level. Besides, it provides indication or warning for the
neutral working positionof traveling pump, oil fill
pressure, engine oil pressure, air filter pressure and
water level in water box. Furthermore, the system
supplies the man-machine interfaces to realize all kinds
of actions or commands.
It mainly comprises TD400 text display, water
thermometer, fuel gauge, neutral position indicator
lamp, charging indicator lamp, crab-walk indicator lamp,
combined alarm indicator lamp, traveling handle and
various control switches, etc.
TD400 text display [Fig. 1-17] can display such
parameters as engine speed, accumulated working
time and traveling speed at real time. You can set the
time, switch the manual/automatic engine speed
control mode, and switch the continuous/intermittent
spraying control mode on the display. Besides, you can
find text alarm information about blocked air filter, low
engine oil pressure, water shortage in water box and
low brake pressure on the display. The water
thermometer monitors the engine’s coolant
temperature with an indication range of 0-120 . The ℃
fuel gauge indicates the fuel level in fuel tank with an
indication range of 0-1/1. The charging indicator lamp
alarms for charging fault and supplies the engine with
initial exciting current. The crab-walk indicator lamp
indicates whether the drum is in the crab-walk position.
In the event of blocked air filter, low engine oil pressure
or water shortage in water box, the combined alarm
indicator lamp will flash at a frequency of 1Hz. However,
it will be always on when warning against low brake
pressure.























Fig. 1-17 Text Display












Text display area
Configurable key Function shift key Confirm
key
Menu key
Arrow key
 CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 18

Key Function Purpose
ENTER Select and confirm
Select the menu or confirm the
value on the display
ECS Escape
Exit from the menu or cancel the
selection
 Move the cursor up/down
Scroll display the menu options
upward/downward, or
progressively increase/decrease
the value
 Move the cursor left/right
Move the cursor left/right, or
display the value

Function keys F1~F8
Implement the tasks configured by
“Text display guide”

Function keys F9~F16
SHIFT function keys (F9~F16) on
TD400C display can implement the
tasks configured by “Text display
guide”


CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 19

Table 1-1 Meanings of Symbols on Display

Turn lamp switch

Manual/automatic
selection switch

Charging indicator lamp

Water temperature alarm

High-frequency vibration

Vibration frequency
selection switch

Low-frequency vibration

Engine oil pressure
alarm

Brake pressure

Air filter alarm

Neutral position indicator
lamp
Spaying control switch

Front windshield wiper

Gear-shift switch

Rear windshield wiper

Headlamp switch

Manual brake

Rear lamp switch

Crab-walk indicator lamp

Horn

Alarm indicator lamp

Washer switch

Water shortage indicator
lamp
Vibration mode selection
switch







 CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 20










23
L




1-Front working lamp switch 2-Spraying flow adjusting knob 3-Horn switch 4-Spaying control switch
5-Charging indicator lamp 6-Fuel level gauge 7-Vibration control switch 8-High/low frequency change-over
switch 9-Great-shift switch 10-Neutral position indicator lamp 11-Vibration mode selection switch 12-Text
display 13-Crab-walk control switch 14-Crab-walk indicator lamp 15-Engine speed control switch 16-Coolant
thermometer 17-Alarm indicator lamp 18-Emergency stop switch 19-Turn indicator switch 20-Manual brake
switch 21-Key switch 22-Rear working lamp switch 23-Traveling control handle 24-Vibration button switch

Fig. 1-18 Control Device








CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 21

Text Display Operation
When the key switch is turned to position “I”, and
the host computer is energized, the backlight of text
display will be lit up and the system will be initialized. In
this case, the computer is started. In 5s, the startup
interface of “SANY Heavy Industry Quality Changes
the World” flashes. After another 5s, the language
selection interface appears. Press F1 to choose
Chinese version and F3 to choose English version and
press the corresponding function key for confirmation.
If you do not select any option, the system will skip this
process automatically and acquiesce in the previous
operation. After that, the main interface appears. Press
F1 to choose operation description, F2 to choose
real-time parameters, F3 to choose function setting.
3s after startup of the engine, the text display will
automatically shift to the “Real-time Parameters”
interface from the main interface. It enters into
monitoring state to show such parameters as working
hours, traveling speed, engine speed, fuel level and
coolant temperature. Pressing the to exit the
interface and press the to enter the alarm indication
interface for checkup.
If the alarm information appears during operation,
such as blocked air filter, too high coolant temperature,
too low engine oil pressure and water shortage in water
box, the text display will immediately shift to the “Alarm
Indication” interface from the current interface. You can
find the relevant alarm figures and the alarm indicator
lamp on instrument panel will flash.
On the main interface, you can press ”ENT” to
enter the time setting mode. Press the left or right
arrow key to choose the value you want to set, and
press up or down arrow key to set the value. After
setting, press “ENT” and “F4” synchronously for
confirmation (letter ‘T’ beside the clock will become ‘S’).














1.5.5 Traveling and Brake Control System
The traveling and brake control system controls
the traveling speed and brake of the double drum
vibratory roller. It also sends the speed signal detected
by the speed sensor to the controller for constant
traveling speed control.
It mainly comprises gear shift valve, brake valve,
brake release valve, crab-walk valve, pressure relay
and speed sensor. The circuit diagram is shown in
[Fig.1-19].
When the engine runs at a speed over 1000rpm,
push the traveling handle off the neutral position, then
the PLC will get the traveling command and output a
high level signal into the relay to drive the
electromagnetic valve Y1. In this way, the machine
begins traveling at a speed of 0m/min-110m/min.
When transiting to another worksite at a high speed,
turn on the gear switch, and then the PLC will output a
high level signal into the relay to drive the
electromagnetic valves Y3 and Y5. In this way, the
traveling motor will run at a high rotation speed but
small displacement, and the traveling speed will be
0m/min-200m/min. When you wish crabbing upon the
requirements of working conditions, gently turn the
crab-walk switch on the handle S13 forward or
backward by hand, then the electromagnetic valve Y10
or Y11 will be energized for left or right crabbing.
1. Service braking: this part has already been
introduced under Hydraulic System.
2. Parking braking: when the switch S19 is turned
on, the brake valve Y4 will be de-energized. Then the
machine stops and its brake takes effect.
Caution
• All elements and devices on the
instrument panel are precise
instrument. You must not beat or tap
them with hard object and you must
keep the surfaceclean.
• You must keep the terminals of all
sensors clean and dry. Meanwhile,
check each terminal for looseness.
The loose terminal may affect the
correct and stable indication of the
instruments.
 CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 22
3. Emergency braking: when the emergency stop
switch S12 is pressed, all electromagnetic valves will
be de-energized, resulting in the stopping of vibration
and spraying, meanwhile, the machine stops and its
brake takes effect immediately.

1.5.6 Vibration Control System
The vibration control system controls the
automatic or manual start/stop of vibration, the switch
of the high/low vibration frequency and the vibration of
the front/rear drums. It mainly comprises
electromagnetic valve Y8/Y9 for the flow cut-off of
vibration pump and electromagnetic valve Y6/Y7 of
vibratory switch valve. The circuit diagram is shown in
[Fig. 1-19].
Turn the vibration control switch S16 to “Manual”
and press the button switch S17 on the traveling
handle, then the PLC will get the commands of forced
vibration. At this moment, if the frequency selection
switch S18 is at the initial position, the high-frequency
vibration electromagnetic valve Y8 will be energized
and the machine will vibrate at high frequency;
contrarily, if the switch S18 is turned on, the machine
will vibrate at low frequency. Press the switch S17
again, then the machine will stop. Turn the switch S16
to “Automatic”, the machine will vibrate automatically
when the traveling speed ≥25m/min, or stop vibration
when the speed ＜25m/min. If you want to stop
vibration ahead of schedule, you can press the switch
S17 for stopping the vibration forcedly. Under particular
circumstance, if you wish single drum vibration, you
can turn the mode selection switch S15 left to have the
front drum vibrate; turn it right to have the rear drum
vibrate. If you turn the switch at neutral position, both
the front and rear drums will vibrate at the same time.



CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 23














































1.5.7 Spraying Control System
The spraying control system controls the spraying
mode (Manual/ Automatic), adjusts the spraying flow in
proportion manually and detects for water shortage in
water box. It mainly comprises DC pressure regulator
A3, water cut-out electromagnetic valve Y12, water
pumps M8/M9 and liquid level switch S7. See [Fig.
1-20].
Turn the spraying control switch S14 to “Manual”,
then the DC pressure regulator A3 will be energized
and begin to work. It will output a PWM current signal
to drive the water pump M8/M9. When the switch S14
is turned to “Automatic”, once the traveling control
handle is off neutral position, the PLC will output a low
level signal and the relay K4 will reset. In this case, the
DC pressure regulator A3 is energized and begins to
work. That is to say, the spraying will start automatically.
When the traveling handle is at neutral position, the
relay K4 is energized, the regulator A3 is de-energized,
and the spraying will stop. Turn the knob of
potentiometer RP1 to adjust the spraying flow
steplessly, so as to satisfy different construction
technical requirements. Under particular circumstance,
you can select “intermittent spraying” in the function
setting menu on the display to have the water pump
under intermittent mode. In this way, you can not only
ensure the spraying effect, but also greatly reduce the
water consumption and save water by about 50%.

















Fig. 1-19 Circuit Diagram for Traveling and Vibration Control System

 CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 24















































Fig.1-20 Circuit Diagram for Spraying Control System
Fig.1-21 Scbematic Diagram for Distribution Cabinet
CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 25
1.5.8 Basic Structure of Distribution Control
Cabinet
The distribution control cabinet is the control
center of the whole electrical system. It realizes some
required action, provides the PLC and sensors with the
required regulated power and short circuit protection,
supplies the communication interface for program
uploading and downloading and renders a certain
capacity of remote monitoring and data maintaining. It
receives the signals from the operation system and
sensors, and then processes (amplification, filtering,
reshaping) and outputs them to the PLC module. After
certain calculation, the signals from PLC will go through
relays, amplifiers and drives to drive the correspondent
loads to carry out the required actions. The distribution
control cabinet mainly comprises drive H435, flasher
relay, control relay, starter relay, circuit board assembly,
central module CPU224, expansion module EM223.
The element layout is shown in [Fig. 1-21].
1. Starter relay: a relay with a working voltage of
12V-32V, a load capacity of 90A and a working
temperature of -40℃-65℃;
2. Circuit board assembly: a home-made part;
3. Control relay: a relay with a working voltage of
16V-30V, a load capacity of 30A-20A and a
working temperature of -40℃-100℃;
4. Central module CPU224: a module with 14 digital
input and 10 digital output (including two 20kHz
high-speed pulses output), a working voltage of
20.4V-28.8V, a load capacity of 750mA, a logic “1”
signal ＞15V and a working temperature of
0℃-50℃;
5. Flasher relay: a relay with a work voltage of
16V-30V, a load capacity of 110W and a working
temperature of -40℃-100℃;
6. DC pressure regulator HSKQ-5/5A1: refer to
Spraying Control System;
7. Expansion module EM223: a module with 4 digital
input/output, a working voltage of 20.4V-28.8V, a
load capacity of 2.0A, a logic “1” signal ＞15V
and a working temperature of 0℃-50℃;
8. Expansion module 6ES7231-0HC22-0XA01: a
module with 4 analog input;
9. DC contactor ZLJM-100A1: a power control relay;
10. Drive H435/H420: a step motor drive with high
performance has a working voltage of 18V-32V,
max. drive current of 3.5A, a responding
frequency of 200kHz and a working temperature
of 0℃-50℃.
































 CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 26
1.6 Hydraulic Control Devices
The double drum vibratory roller is a full hydraulic
driven roller. Its hydraulic system mainly comprises four
subsystems: traveling hydraulic system, vibration
hydraulic system, steering hydraulic system and brake
hydraulic system.
1.6.1 Traveling Hydraulic System
The traveling hydraulic system of YZC12C double
drum vibratory roller adopts a parallel closed circle with
one cam-type axial piston pump and two inclined-axis
axial piston motors, see [Fig. 1-22]. In order to ensure
the normal work of the closed circle, the system is also
equipped with servo valve, multi-function valve
(high-pressure overflow valve and one-way oil fill valve),
pressure cut-off valve, oil fill overflow valve and flushing
valve.
The main functions of all valves above are as follows:
1. Servo valve: you can turn the electric control
handle to control the movement of the oil cylinder,
so as to have the machine move forward, park
and reverse.
2. Multi-function valve: it comprises high-pressure
overflow valve and one-way oil fill valve. When the
main oil circuit pressure of the system exceeds the
rated pressure ofthe high-pressure overflow valve,
the valve overflows to protect the system element.
Its rated pressure is 400bar. The one-way oil fill
valve is used to fill oil to the side with lower
pressure. By doing so, it may compensate the lost
flow due to flushing of the flushing valve and
leakage of the system to avoid air suction.
3. Pressure cut-off valve: when the high-pressure
overflow valve actuates continuously, the pressure
cut-off valve will make the displacement servo
cylinder swing towards the small displacement
side. By doing so, it may avoid the oil temperature
rising due to long overflow of the high-pressure
overflow valve. Its rated pressure is 380bar.
4. Oil fill overflow valve: it is used to keep the oil fill
pressure of the system. Its rated pressure is
24bar.
5. Flushing valve: It is used to flush some hydraulic
oil in the side with lower pressure of the main oil
circuit into oil tank. It works with the one-way oil fill
valve to keep the exchange of hydraulic oil in the
main oil circuit.
During operation, once the current and current
direction of the driving pump electrical system is
changed, the tilt angle of swashplate and the output
flow and direction of the pump will be changed.
Accordingly, the roller’s traveling direction and speed
will be changed. The variable plunger motor controls
the tilt angle of the inclined axis by the external control
valve to achieve shift between the min. and max.
displacement modes. In this way, the machine will have
two stepless adjustable gears to meet the different
operating requirements of traveling and compaction.
1.6.2 Vibration Hydraulic System
The vibration hydraulic system of YZC12C double
drum vibratory roller adopts a serial closed circle with a
cam-type axial piston pump and a cam-type axial
piston motor, see [Fig. 1-23]. The function valve blocks
integrated in the system and their functions are same
as those in hydraulic driving system. We will not give
more details here.
By controlling the servo electromagnetic valve of
vibratory pump, you can have two tilt angles of
vibratory pump swashplate. Thus, the vibratory pump
can output oil in different directions and flows.
Subsequently, the vibratory motor can run in different
direction and at different speed to drive the vibratory
drum to vibrate at two different frequencies and
amplitudes. Adjust the displacement limit screw on the
servo cylinder of vibratory pump to adjust the output of
pump, so as to adjust the vibration frequency of the
vibratory drum.
The vibration valve controls the shift between
three vibration modes to meet the requirements of road
compaction: front drum vibration, rear drum vibration
and both front and rear drums vibration. The vibration
valve mainly comprises valve body, cartridge
electromagnetic change valve, flushing valve and
one-way oil fill overflow valve. The cartridge
electromagnetic change valve controls the main oil
circuit to achieve front or rear drum vibration. The
flushing valve flushes some hydraulic oil in the side
with lower pressure of the main oil circuit into oil tank.
The flushing valve works with the one-way oil fill valve
to keep the exchange of hydraulic oil in the main oil
circuit. The one-way oil fill overflow valve prevents the
vibratory motor from overloading and air suction.
CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 27


















1-Oil fill pump 2-Oil fill overflow valve 3-Filter 4-Multi-function valve 5-Pressure cut-off valve
6- Servo valve 7-Driving pump 8-Control valve 9-Reducer 10-Brake 11-Driving motor
12- Flushing valve
Fig.1-22 Schematic Diagram for Traveling System
1-Vibration pump 2-Variable electromagnetic valve 3-Pressure cut-off valve 4-Multi-function valve
5-Filter 6-Oil fill pump 7-Vibratory motor 8-Vibration valve
Fig.1-23 Schematic Diagram for Vibration System
 CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 28

1.6.3 Steering Hydraulic System
The steering hydraulic system of YZC12C double
drum vibratory roller is an open circle with a max.
working pressure of 140bar. It mainly comprises
steering gear pump, full hydraulic steering gear,
steering cylinder, crab-walk cylinder and priority valve,
see [Fig. 1-24].
During working, the hydraulic oil from gear pump
goes through the priority valve and then reaches the
full hydraulic steering gear. After calculation by the
steering gear, the oil is distributed to the steering
cylinder to drive the articulation frame for steering.
When the machine is not steering, the pressure oil at
the LS port on steering gear drives the priority valve
element to have the system under ready condition for
crabbing. If the crab-walk valve doesn’t actuate, the
hydraulic oil will directly flow into the hydraulic oil tank
after passing the electromagnetic change valve with
H-type neutral function to achieve unloading of the
system. If the crab-walk valve is energized and
actuated, the hydraulic oil will drive the crab-walk
cylinder for crabbing.




1-Overloading overflow valve 2-Steering gear body 3-One-way valve 4-Two-way cushion overflow valve
5-Steering cylinder 6-Crab-walk cylinder 7-Hydraulic lock 8-Crab-walk control valve 9-Priority valve
10-Gear pump
Fig.1-24 Schematic Diagram for Steering System
CHAPTER 1 TECHNICAL SPECIFICATION
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 29
1.6.4 Brake Hydraulic System
In order to ensure safety working and traveling,
the brake system applies three models: service braking,
parking braking and emergency braking.
(1) Service Braking
Service braking adopts hydraulic brake which is
performed by controlling the traveling control lever.
When the traveling control lever is returned to the
neutral position from the working position, the flow from
the traveling pump to the traveling motor gradually falls
down to zero, the traveling motor stops and then the
roller stops.
The deceleration of service braking depends on
the time to turn the control handle to the neutral
position. Service brake features stable braking and less
impact on road surface, so it is often applied during
steering.
(2) Parking Braking
A normal closed wet multiple disc brake is
adopted in the planetary reducer. The machine
releases the brake by the hydraulic oil in brake release
system. When the traveling handle returns to the
neutral position from the working position and the
parking button is pressed after a moment or
immediately, the brake release system will be unloaded,
and the disc brakes in the front and rear reducer
brakes will take effect. In this way, the parking brake
ensures reliable braking and enhances the machine’s
safety.
(3) Emergency Braking
Under any circumstance, once the emergency
brake button is pressed down, the swashplate of the
traveling pump resumes to the neutral position
immediately and the hydraulic brake takes effect. At the
same time, the brake release system is unloaded, and
the front and rear reducers brake off.























































 CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 30







Full Hydraulic Double Drum Vibratory Roller Operation Manual
Operation & Maintenance

2.1 Starting the Equipment
2.2 Check before Operation
2.3 Operating the Working Device
2.4 Cleaning the Equipment
2.5 Maintenance Interval
2.6 Checking the Bolts
2.7 Checking the Functional Oil








P31~56

CHAPTER 2 OPERATION AND MAINTENANCEYZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 31

Chapter 2 Operation and Maintenance
2.1 Starting the Equipment
Before operating the roller, the drivers and
personnel in charge shall carefully read this Manual
and the relevant chapters in Diesel Engine User’s
Guide.


2.1.1 Check before Starting:
 Carefully check all parts for looseness, and tighten
them if necessary.
 Make sure the storage battery and its terminals are
in good condition.
(1) Check the engine oil level (the filler port is shown in
the figure) and fuel level (the fuel gauge is on the
control penal). Select and fill the appropriate oil in
accordance with the regulations. Discharge the air in
fuel.




(2) Check the coolant level, and fill some if insufficient.











































Filler port
Coolant level
 CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 32
(3) Check hydraulic oil level (between 1/2-2/3 of the oil
dipstick), and fill some if insufficient.













(4) Check the air filter and remove the accumulated
dust.












(5) Check the fuel filter in accordance with the Engine
User’s Guide. If necessary, clean it.



















Hydraulic oil level
Removing
accumulated dust
Fuel filter
CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 33
(6) Make sure the crab-walk device is in good condition
and the safety fixing rods on the front and rear frames
are at the unlocked position (i.e., operating position).














(7) Make sure the emergency brake is at the unlocked
position. Make sure the steering and parking brakes
are under normal condition.







(8) Make sure the vibration control switch is at the
neutral position.



















Safety fixing rod
Emergency brake
Vibration control switch
 CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 34
(9) Make sure the traveling handle is at the neutral
position and the vibration button is at the vibration stop
position (i.e., the button is not pressed down).










(10) Make sure the spraying system is in good
condition and the spraying control switch is at the
neutral position.





















































Vibration button
Spraying control switch
CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 35
2.1.2 Starting

(1) Turn on the main switch for power supply at the rear
frame. To do this, you must pull the lever to the position
as shown in the figure. After that, the whole machine
will be energized.
(2) Pull the throttle adjusting handle to the idle speed
position.
















(3) Insert the key switch, and turn it right to the working
position. At this moment, the charging indicator lamp,
low oil pressure indicator lamp, braking indicator lamp
and neutral position indicator lamp are lit up, while
other indicator lamps are off. Moreover, the display is
under initialization, which indicates the circuit is normal
and gets ready for starting.






(4) Turn the key switch right to ”start” position to ignite
the diesel engine. After that, immediately release the
key to have it return to working position automatically.
Then the starting work is done.
















Main switch for
power supply
Key switch
 CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 36
(5) After starting, set the throttle adjusting handle at idle
speed position, and then run it at low speed for 3~5 min
to warm the machine up. For the roller used for the first
time or have been parked for a long time, run it at low
speed for 5~10 min to warm the machine up (you can
properly increase the engine speed for warming up in a
cold days). After that, slowly adjust the throttle adjusting
handle to the rated speed position.



Precautions:
① The engine starting time should not exceed
10s. Wait for at least 3min before starting the
engine again. If you fail to start the engine for
three times successively, you must stop
starting, find out the cause and rectify the
trouble.
② You must turn off the radio recorder first before
turning on the power switch.


















































Caution
If you want to start the machine with
jumper cables, you must connect the negative
terminal with the negative one, and the positive
terminal with the positive one. Connect the
earth wire (negative terminal) lastly and cut off
the earth wire firstly. Otherwise, it may damage
the electrical system.
CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 37
2.1.3 Check after Starting with the Roller Running
in Place
(1) Check all indicator lamps as per the above
diagrams for control device and monitoring
device.
(2) Check the oil pressure gauge. It shall indicate
figures within 15s after starting. The value shall be
higher then 0.05MPa. (If the engine is at rated
speed, the value shall be higher than 0.4MPa.
(3) After starting the engine, the charging indicator
lamp will go out. The neutral position indicator
lamp keeps on before the roller starts traveling.

Precautions:
When the ambient temperature is lower than
-10 , ℃ you must take the following measures to help
starting. After that, you can carry out starting as per the
normal procedures.
① Preheat the engine oil and coolant to 60~80℃.
② Use diesel oil, engine oil, hydraulic oil and coolant
applicable to low temperature environment.
③ Take thermal insulation measures for storage
battery, or use low-temperature storage battery or
battery with enlarged capacity.
2.2 Check Before Operation
Pay attention to the following items when the roller
is under normal operation:
(1) During operation, no matter traveling at high/low
speed, vibrating or compacting, you must keep
the throttle at the full open position (namely, the
rated speed position), or else the roller may run
abnormally.
(2) Check the engine oil pressure and temperature at
any time. Shut down the machine for check
should you find any abnormal condition.
(3) Check the thermometer in hydraulic oil tank. The
temperature indication shall not exceed 80℃.
Shut down the machine for check if it exceeds
that value.
(4) Check all parts for looseness or abnormal sound.
If any, shut down the machine for check.
(5) Check the generator and other electric elements
for overheating or burnt-out. If any, shut down the
machine for check.
(6) Check each system for leaks. If any, shut down
the machine for check.

2.3 Operating the Working Device
After starting the engine, firstly make sure all
working systems, control devices, monitoring
instruments and displays are normal. After that, operate
the roller according to following procedures.
2.3.1 Engine Speed Control
There are two modes for controlling the engine
speed, namely, automatic mode and manual mode.
Manual mode: You can operate the engine speed
control switch on the panel for stepless engine speed
adjustment (from idle speed to rated speed).
Automatic mode: Under this mode, the engine
speed can be automatically controlled accordingto
different working conditions. For the static compaction
state, the engine speed can automatically adjust to
2100rpm; for the transfer to other worksites, the engine
speed can automatically adjust to 2200rpm; and for the
vibration state, the engine speed can automatically
adjust to 2300rpm. Moreover, 4 seconds after turning
the traveling handling to the neutral position, the engine
speed can automatically adjust to idle speed.

2.3.2 Traveling
When the traveling control lever is put forward
from neutral position, the roller will run forward; while it
is drew back from neutral position, the roller will run
backward. The distance between neutral position and
traveling control lever forward or backward determines
the traveling speed.
Two gears are available to meet the requirements
of different working conditions. Only under gear I, the
working gear, can the roller carry out vibration and
compaction. Under gear II, the traveling gear, the roller
can travel at high speed but can’t vibrate.

2.3.3 Braking During Traveling
If you wish to park the machine, turn the traveling
handle to the neutral position from traveling position,
and then the brake takes effect (static pressure
braking). The more rapidly you turn the handle, the
shorter the braking time is.
 CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 38
2.3.4 Vibratory Compaction
Before vibratory compaction, operate the high/low
frequency selection switch to select a proper vibration
frequency. After that, operate the vibration change-over
switch to select automatic/manual vibration mode.
There are two gears for vibratory
compaction——low frequency and high frequency
gears.

 Low frequency gear: great vibration force, high
amplitude and low vibration frequency;
 High frequency gear: small vibration force, low
amplitude and high vibration frequency. It is
controlled by high/low frequency selection switch.
Meanwhile, you must check the relevant
indication of high and low frequency indication
lamps.
 Automatic gear: under the auto vibration mode,
the vibration is controlled by the traveling speed:
when the traveling speed is more than 25m/min,
vibration starts; and when traveling speed is less
than this value, vibration stops automatically.
 Manual gear: under the manual vibration mode,
the vibration is controlled by the vibration on/off
button —when the button is pressed down,
vibration starts; when the button is pressed down
again, the button pops up and vibration stops. You
must set the gear switch at low speed position
before vibration.






The vibration is classified into three modes. Under
each mode, there are two frequencies and two
amplitudes for selection. The vibration is controlled by
vibration frequency selection switch and vibration mode
selection switch. Meanwhile, you must check the
relevant indication of high and low frequency indication
lamps.
















































Front & Rear Drum Vibration





Low frequency
High frequency
CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 39
Precautions:
(1) Stop vibration completely before shifting vibration
gear. After that, you can engage the desired gear.
In order to prevent against inertial impact due to
steering of the amplitude modulation apparatus,
never switch between the high and low
frequencies directly during vibration.
(2) Select the appropriate vibration frequency and
amplitude according to the thickness and types of
pavement.
(3) The vibration may be realized only when the
machine runs at a low traveling speed.
(4) Do not start vibration when the machine is in
standstill.
(5) Do not start vibration on hard road surface such
as concrete.
(6) Do not start traveling gearshift when the machine
is not parked steadily.






















Front Drum Vibration (Rear Drum doesn’t
Vibrate)












Rear Drum Vibration (Front Drum doesn’t
Vibrate)











 CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 40
2.3.5 Spraying
The spraying system can be controlled under
three modes, namely, stop, manual and automatic
modes. Under the automatic mode, you can set the
continuous spraying state and intermittent spraying
state (stop for 3s and spray for 4s) on the text display.
Under the manual mode, as long as the host
computer is energized, the spraying device can
continuously work under any working conditions.
Besides, you can operate the adjusting knob for
stepless spraying flow adjustment.
Under the automatic mode, the spraying device
can work only when the traveling handle is off the
neutral position. You can also operate the adjusting
knob for stepless spraying flow adjustment. In this way,
you can not only reduce the operating times, but also
save the water.

Spraying Procedures:
(1) Fill up the water tank (you must use filter grill for
water filling).












(2) Keep the front and rear spraying cut-off valves
open.
Water filler
Cut-off valve
CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 41

(3) Turn on the key switch and then the machine will
be energized.
(4) Turn the spraying control switch to the “manual”
position, and then the spraying system starts
working. Turn the flow regulating switch to adjust
the flow to the specified value.
(5) Turn the spraying control switch to the “automatic”
position and pull the traveling handle off the
neutral position, and then the spraying system
starts working. Turn the flow regulating switch,
and then the nozzle will spray water to the drum in
different water flows. You can adjust the flow to
the desired value and keep the switch at the
corresponding position.
(6) Under automatic spraying mode, you can select
the spraying mode (intermittent or continuous) on
the text display. Under the “intermittent” mode, the
system will spray water for 4s and stop spraying
for 3s. Under the “continuous” mode, the system
will spray water continuously.
Precautions:
① Normally, we suggested “Automatic + Continuous
Spraying” mode. It is easy for operation and
effective in saving water. In specific cases, if you
want an even spraying effect without too much
spraying flow, you can apply “Intermittent
Spraying” mode.
 ② Water Level Alarm: when the water shortage
alarm indicator on the text display flashes, the
remaining water in the water box is enough for
5~10m of operation only. You must fill water as
soon as possible. The alarm indicator is:






















Caution
(1) During the short-term shutdown, the
electromagnetic valve in pipelines can keep the
nozzle free of dripping water.
(2) In cold days, you must open the water filter
to drain the remaining water in the system, as
otherwise, the pipes may be frozen and
damaged.
(3) No water should enter the water pump
housing, as otherwise the water pump and
motor will be damaged.
(4) Frequently check and clean the filter element
and the grill in nozzle.
(5) Never fill the water containing acid, alkali
and pollutants into the water box, as otherwise
the system will be damaged.
(6) Do not remove the filter grill at the water box
inlet when filling water.
 CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 42
2.3.6 Parking
(1) Stop vibration, and turn the vibration control switch
to the neutral position (under the automatic
vibrationmode, you don’t need to stop vibration
separately).
(2) Push the traveling control lever slowly to the
neutral position to stop traveling.
(3) Stop spraying and turn the spraying control switch
to the neutral position.
(4) Turn the throttle adjusting handle to idle speed
position, and run the engine at a slow speed for a
while, so as to let the roller cool down gradually.
(5) Turn the ignition key left to the neutral position,
switch the engine off, and then all indicator lamps
will be off.
(6) Cut off the power supply.
(7) Place a timber block or rock block under the
vibratory drum if necessary.
(8) If the roller is to be parked for a long time, tightly
cover the console without cab structure.
2.3.7 Text Display
The roller is equipped with Siemens text display
TD400. It can display some system parameters, alarm
information, and it supports function setting. The control
penal is shown as follow:






1-Text display area 2-Arrow key 3-Configurable key 4-Function shift key 5-Confirm Key
6-Menu Key
Fig.1-14 Text Display
CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 43

Key Function Purpose
ENTER Select and confirm
Select the menu or confirm the value on the
display
ESC Escape Exit from the menu or cancel the selection
 Move cursor (up/down)
Scroll display the menu options
upward/downward, or progressively
increase/decrease the value
 Move cursor (right/left) Move the cursor left/right, or display the value

Functional keys F1~F8
Implement the tasks configured by “Text
display guide”
 Functional keys F9~F16
SHIFT function keys (F9~F16) on TD400C
display can implement the tasks configured
by “Text display guide”



The interface of TD400 can be classified
into several kinds as follows:

(1) Startup Interface
When the key switch is turned to position “I”,
and the host computer is energized, the backlight
of text display will be lit up and the system is
initialized. About 3s later, the startup interface of
“SANY Heavy Industry Quality Changes the
World” flashes, as shown in the right figure.



(2) Main Interface
After the startup interface, the text display will
automatically shift to the main interface.
In the main interface, you can perform the
operation according to the prompt in the Text
Display Area.
F1: check real-time parameters
F2: shift between English and Chinese
versions
F3: Function setting
F4: System setting







 CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 44
(3) Real-time Parameter Interface
In 3s after the startup of engine, if you do not
select any option, the text display will automatically
shift to the “Real-time Parameter” interface from
the main interface, and enter into monitoring state.
In real-time parameter interface, you can find
such parameters as traveling speed, engine speed,
working hours, spraying mode, and engine status.
As the TD400 Text Display Area can only display
four rows of characters, you can press the key
or the key to check the previous or next page.
Real-time parameter interface 1 is shown in the
right figure.
Precautions: the max. speed of CUMMINS engine
is 1800~2350rpm. Press the key once, the value
will increase or reduce by 50rpm.
Real-time parameter interface 2 is shown in the
right figure.




(4) EN and CHS Shift Interface
In the main interface, you can press F2 to shift
between English and Chinese versions. The
interface is shown in the right figure.











(5) Function Setting Interface
In the main interface, you can press F3 to
enter the Function Setting Interface. Function
setting interface 1 is shown in the right figure.


















































CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 45
In the function setting interface, you can set
the engine speed, max. spraying flow and the
braking time. Before setting, you need to input the
first class password.


Note:
The hour meter can be only modified when the
indication is 0. It can be modified only by SANY
Heavy Industry Co., Ltd.
Function setting interface 2 is as shown in the
right figure.

In function setting interface 2, you can press
F9 to set the engine state as “Manual” or ”Auto”.
The system default setting is Manual mode.
When the engine is under “AUTO” mode, you
can control the engine speed by the “speed control
switch” on the instrument panel.
Turn the switch to “rated speed” position, and
then the engine will work at the set max. speed.
Turn the switch to “idle speed” position, and
then the throttle will return to idle speed.
Turn the switch to “Auto” position, once the
traveling handle is off the neutral position, the
engine speed will increase immediately; in 10s
after the traveling handle returns to the neutral
position, the engine speed will automatically fall
down to idle speed.
When engine is under “Manual” mode, you
can press F13 to increase engine speed and press
F14 to reduce engine speed.
Press F11 to set the spraying control mode as
“continuous” or “intermittent”. The system default
setting is “continuous” mode.
The engine speed depends on the traveling
speed, gear and the vibration switch position.
When the vibration switch is not at “stop”
position, the engine speed is set as the max.
speed.
When the vibration switch is at “stop” position,
if the gear switch is at traveling or working gear and
the traveling speed exceed 85m/min, then the
engine speed equals to the set max. speed minus
100rpm; if the gear is working gear and the
traveling speed is less than 85m/min, then the
engine speed equals to the set. max. speed minus
200rpm.







































 CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 46

(6) System Setting Interface
In the main system interface, you can press F4
to enter system setting interface. The interface is
shown in the right figure.










Input the password, and then edit interface 1
appears.











Edit interface 2 is shown in the right figure.































































CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 47
(7) Alarm Information Interface (The alarm
information will always be shown on the display
when the alarm signal is not cleared.)

 High air filter pressure
 Low engine oil pressure
 Low braking pressure
 High water content in diesel
 Low water level in water box

This interface shows alarm information in 2
pages. It shows the above five pieces of alarm
information and one piece of maintenance
information. When the alarm information is not so
much, the interface will display information
according to the sequence above.
When alarm signal appears, such as blocked
air filter, high coolant temperature, low engine oil
pressure and water shortage in water box, the text
display will switch from the current interface to the
alarm information interface immediately. Meanwhile,
the relevant symbols and indicator lamps will be on.

(8) Maintenance Information Interface
(Press F4 to clear alarm information up.)

Carry out running-in maintenance.
Carry out first class maintenance.
Carry out second class maintenance.
Carry out thirdclass maintenance.

The maintenance information and alarm
information are shown in the same interface. The
former follows the latter. This interface shows
information in at most 2 pages.

Precautions:
 All elements on instrument panel ① are
precise elements. Do not beat or tap them with
hard object. Keep them clean.
 Keep all ② sensor adaptors clean and dry.
Besides, check and make sure the contact points
are tight, so as to ensure correct and stable
instrument indication.








































 CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 48
2.4 Cleaning the Equipment
 Remove the mud and sands on the roller’s
surface.
 Remove the dusts and oil stain on the surface of
engine, hydraulic elements and other parts.
 Remove the mud and sands on the surface of
drum or between the drum and mud scraper.
 Remove the dusts and mud at the air inlet and
the accumulated dust in the air filter.





















2.5 Maintenance Interval
Illustration:
 The technical maintenance of the roller is
subdivided into three kinds, namely, routine
maintenance, periodic maintenance and one-off
maintenance (troubleshooting).
 The periodic maintenance intervals are the
same as those specified in the engine user’s
guide.
 The engine shall be maintained in accordance
with the engine user’s guide.
 The periodic maintenance is scheduled from the
first engine operation.
 Once the maintenance after 1000h’s operation
is done, another new periodic maintenance
begins.

2.5.1 Routine Maintenance
(1) Cleaning the roller: remove the mud and
sands on the roller’s surface, as well as the
dusts and oil stain on the surface of engine,
hydraulic elements and other parts. No dirt
may enter the oil inlet and air filter.
(2) Clean the dust nozzle to remove the dust in
the air filter. Check the air filter daily. When the
dust indicator lamp is on, you must clean the
air filter.
(3) Check the connection and fastening of spare
parts. Tighten or replace the loose or broken
ones. Check whether the cushion block is
under normal compression state. Check the
connecting bolts between bearing seat and
vibratory drum, as well as the connecting bolt
of driving wheel rim for looseness or damage.
If any, fasten or replace them.
(4) Check and rectify the oil leakage at all parts.
Avoid environmental pollution by oil and other
harmful materials.
(5) Check engine oil level in crankcase, fuel level
in fuel tank and hydraulic oil in hydraulic oil
tank. Fill qualified new oil to the specified level.
(6) Check the nozzle, adaptor and filter of
spraying system. Keep the filter grill clean. Do
not remove the grill when filling water. After
operation each day, drain off the pipes. Clean
the water filter element daily.
(7) Check if there is water in the water pump
housing. The eroded working parts may lead
to damage of motor.

2.5.2 Periodic Maintenance
In addition to the above periodic maintenance,
you must carry out an overhaul to the machine and
change the lubricating oil in reducer every winter.
 Never wash the roller when the engine is
running.
 Do not use gasoline and other flammable
fluid as cleaning agent.
 Keep the exhaust tube, oil fillers and air filter
free of dirt and water.
 Before washing the roller with high-pressure
water, you must cover the oil filler and vent
device on the fuel tank and hydraulic oil tank.
Do not directly spray water to the oil tank
cover.
 Keep all electrical parts and control penal
free of water. Do not directly spray water to
the electrical parts and control panel.
 Cover the alternator and water pump with a
piece of waterproof film.
Caution
CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 49









Operation Time Action
After 50h’s operation
Before operating the machine, you must carry out a 50h’s running-in as per the
relevant specification in the engine user’s guide. After that, carry out technical
maintenance according to the following specifications:
(1) Carry out all work in routine maintenance.
(2) Change engine oil and replace oil filter. Drain the old oil when the machine is
warmed up and then fill new oil. Check if the engine oil level is as per
requirements after short-time operation.
(3) Change the lubricating oil of vibratory drum. Drain the old oil when the
machine is warmed up and then fill new oil.
(4) Change the lubricating oil of reducer. Drain the old oil when the machine is
warmed up and then fill new oil.
(5) Clean the diesel pre-filter element.
(6) Check the hydraulic oil level, and fill hydraulic oil to specified level.
(7) Check the coolant level in the engine, and fill coolant to specified level.
(8) Check the cushion block for crack. Replace it if the crack length exceeds
15mm.
(9) Check the reducer, spraying system and hydraulic system for leakage, and
rectify it if any.
(10) Clean the air filter every 50h’s operation of the engine.
After 100h’s operation
(1) Carry out all work in routine maintenance.
(2) Carry out maintenance to the engine as per the Maintenance after 100h’s
Operation in the engine user’s guide.
After 250h’s operation
(1) Carry out all work in maintenance after 100h’s operation.
(2) Carry out maintenance to the engine as per the Maintenance after 250h’s
Operation in the engine user’s guide.
(3) Check the oil level in each part of front & rear drums, and fill oil.
After 500h’s operation
(1) Carry out all work in maintenance after 250h’s operation.
(2) Carry out maintenance to the diesel engine as per the Maintenance after
500h’s Operation in the engine user’s guide.
(3) Check the flexibility of cushion block. Replace the heavily distorted or
damaged ones.
(4) Check such key parts as frame and vibratory drums for crack at the welded
part. Check the driving parts for distortion. If any, rectify it.
(5) Check the circuit of vibratory switch and control & monitoring device. Repair
the damaged part should you find any damage.
After 1000h’s
operation
(1) Carry out all work in maintenance after 500h’s operation.
(2) Carry out maintenance to the engine as per the Maintenance after 500h’s
Operation in the engine user’s guide.
(3) Replace the hydraulic oil filter element.
(4) Check the vibration frequency, and adjust it if necessary.
(5) Check the technical state of reducer, and maintain it in accordance with the
relevant requirements.
 CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 50
2.5.3 Maintenance for Long-term Parking
If the roller is to be parked for more than 3
months, you must carry out the following work:
(1) Carry out maintenance for long-term parking
according to the engine user’s guide, and
conduct anti-rust treatment.
(2) Clean the inner and outer surfaces of the roller,
and park it in a garage if possible. When you
park the machine outdoors, you must park it at
a ventilated place and cover it with canvas.
(3) Pad up the front and rear frames to the same
level, and adjust the thickness of timber block
till the cushion block is not subject to shearing
or tensile distortion.
(4) Fix the front and rear frames together with the
fixing device of central articulation frame.
(5) Lubricate or grease all lubricating points.
(6) Clean the surface of vibratory drum. Wipe off
the water with a piece of rag. Apply anti-rust
paint on the surface of vibratory drum. Apply
anti-rust oil on the exposed processed face of
assembly parts on vibratory drums.
(7) Remove the storage battery from the roller.
Clean its surface. Check the electrolyte level.
Charge the storage battery monthly.
(8) Bindup the air filter, dust outlets and air outlets
with a plastic or paper tape, so as to keep the
engine free of damp air.
(9) Drain off the spraying system, including the
water box, water pump, filter and all pipes.
(10) Fill up the fuel tank to avoid condensation and
dust.
(11) Fill oil into the hydraulic oil tank to the highest
level.

2.5.4 Maintenance of Electrical System
1. Storage Battery
(a) The storage battery used for the machine is
maintenance free. The battery must be firmly
secured on the machine. You must regularly
check it for looseness.
(b) If the roller is parked for a long term, you must
check the electricity of storage battery from
the window of densitometer at the upper part
of battery. The light green means the battery is
fully charged; the dark black means there is
electricity shortage and you must charge the
battery; and the bright color means you must
replace the battery.
(c) When installing the battery, connect the
positive terminal (+) first and then the negative
one (-). Apply some Vaseline on the terminals.
(d) To remove the storage battery, you must cut
off the negative terminal (-) first and then the
positive one (+).
2. Check the lighting and horn systems. Check
the tightness of each connector and nuts.
3. Check the tightness of sensor connectors.
4. Check the electric control cabinet for dust, and
clean it up if any. Check the tightness of
electrical parts.
5. After starting engine, make sure the working/
braking pressure indicator lamp is off. Check
the braking and steering functions.
6. Check the power relay for accumulated water.
If any, disassemble it to wipe off the water.
7. Regularly check the harness connectors for
accumulated water and oil stain. Keep the
connectors clean.
8. Check the connector and nuts on lamps,
sensors, horn and braking pressure switch for
looseness.
9. Check the harness for short circuit, breakage
or damage, and keep it in a good state.
10. Check the wiring in electric control cabinet for
looseness. Keep the wiring secured.



After operation, you must cut off the general
power supply, so as to avoid continuous
electric discharge.

2.5.5 Maintenance of Air Conditioning System
1. Normal Use
In order to ensure a favorable technical state
and working reliability, maximize the working
efficiency and prolong the service life, you
must pay attention to the following items when
using the air conditioner:
a. Maintain it in strict accordance with
manufacturer’s instruction.
b. Start the engine before using air conditioner.
After the engine has run stably for several
minutes, you can turn on the air conditioner,
and choose the proper air volume and
Caution
CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 51
refrigeration degree. (When you set the
refrigeration degree at the maximum, you
must also set the air volume at the maximum
to prevent the evaporator from undercooling
and icing up.)
c. Close the vents, windows and doors when
using the air conditioner, so as to achieve the
desired refrigeration or heating effect as soon
as possible and to save energy.
d. When you only wish ventilation effect, you can
turn on the heating switch but not the hot
water switch. By doing so, you can have
ventilation without starting the compressor or
hot water supply.
e. During refrigeration, close the hot water valve
to avoid heating, as otherwise, the
refrigeration effect may be affected.
f. Do not use the air conditioning system for a
long time when the engine is not working.
Otherwise, the battery electricity may be used
up and difficult engine startup may be caused,
g. In the season when you will not use the air
conditioner or you will park the machine for a
long time, you must start the engine every half
a month, and start the air conditioning system
for refrigeration for 5min~10min.

2. Routine Maintenance
(a) Keep the condenser clean. Its cleanliness is
closely related to the heat exchange effect.
Thus, you must regularly check the condenser
for oil stain and mud, and the cooling fin for
bend or blockage. If you find the surface of
condenser is dirty, use compressed air or
clean water to clean it up in time. By doing so,
you can keep the condenser in a sound
radiation condition and avoid excessive
condenser pressure and temperature and
deteriorated refrigeration efficiency due to
poor radiation performance. When cleaning
the condenser, do not touch the cooling fin or
even damage the refrigeration pipes.
(b) Keep the air filter in air duct clean. As the air
entering the cab will be filtered by the air filter,
you must regularly check the air filter for
blockage by dust or foreign materials, and
clean it if necessary. By doing so, you can
ensure a sufficient air volume. In order to
prevent the air duct of evaporator element
from blockage which may affect the air volume,
you must check and clean up the inside and
outside air filters weekly.
(c) Check periodically the condition and tightness
of compressor belt. Tension the belt in time if it
is loose. Replace it with the special belt for
vehicle air conditioner if it is cracked or
damaged. The new belt will stretch after being
used for 36h~48h, so you must tension it
again with a tensioning torque of 160N~200N.
(d) Regularly check the joints, connections, bolts
and screws of refrigeration system for
looseness. Check if the pipes collide with the
surrounding machine parts. Check the hose
for aging traces. Check if the shock isolation
rubber pad at the access hole of fender falls
off or is damaged.
(e) In such seasons as spring, autumn or winter
when you will not use air conditioner, you must
start the compressor of air conditioner for 5
min~10min every half a month. In this way, the
refrigerant, during circulation, can bring the
refrigerator oil to each part in the system, so
as to prevent the seal rings, compressor shaft
seals and other parts in system’s pipelines
from poor sealing and refrigerant leaks due to
lack of oil. Besides, it may keep the
compressor, expansion valve and other
moving parts in the system free of binding,
sticking or rusting. However, you must carry
out the maintenance at an ambient
temperature over 4℃. Otherwise, the oil will
not be sent to the required parts as soon as
the compressor is started as a result of
viscous refrigerator oil with poor fluidity, and
consequently, the compressor will be heavily
worn or even damaged.
3. Regular Maintenance
In addition to the foresaid routine maintenance
and inspection conducted by the driver, the air
conditioning system, as an important system, must
be subject to some necessary regular maintenance
and inspection by professional maintenance
personnel. Only by doing so, can the service life
and working reliability of air conditioner be
guaranteed.
The regular maintenance mainly comprises the
 CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 52
following items:
(a) Compressor
 Generally check and maintain the compressor
every three years: check if the air intake and
exhaust pressures conform to the
requirements; check the fastenings for
looseness; and check the compressor for air
leaks.
 Disassemble the compressor to check the air
intake valve and exhaust valve for damage
and distortion. If any, repair or replace the
intake and exhaust valve assembly.
 Once you have disassembled the compressor,
you must replace the seal rings and shaft
seals. Otherwise, leaks will occur at the
sealing parts of compressor.
(b) Condenser and Cooling Fan
 Generally check and maintain the condenser
and cooling fan annually: remove the foreign
materials and dust on the surface of
condenser; rectify and repair the coolingfin of
condenser by a pair of flat nose pliers;
carefully check the surface of condenser for
abnormality; and check for refrigerant leaks by
a leak detector.
 Recoat the anti-rust painting if it peels off, so
as to prevent leakage due to rusting and
perforation.
 Check whether the cooling fan of condenser
can normally run. Check the brush of fan motor
for heavy wear.
(c) Evaporator
 Generally, use a leak detector to check the
evaporator for leakage annually.
 Undo the evaporator cover every 2~3 years to
clean the inside and remove the foreign
materials in the air delivery duct.
(d) Electromagnetic Clutch
 Carry out overhaul to the electromagnetic
clutch every 1~2 years: check whether it
moves normally; check it for sliding; check the
joint surface for wear; and check the clutch
bearing for heavy wear.
 Use a feeler gauge to check if the clearance of
electromagnetic clutch conforms to the
requirement.

(e) Receiver Drier
 Under normal conditions, replace the receiver
drier every 3 years. However, if there is water
entering the receiver drier as a result of
mis-operation, you must replace it in time.
 You must also replace the receiver drier if the
pipeline is opened and ventilated for over 30
minutes.

(f) Expansion Valve
 Generally, maintain the expansion valve every
1~2 years.
 Check whether it moves normally; check if the
openness is proper; and check the filter grill
for blockage. Replace or adjust it if you find
any abnormality.
(g) Refrigeration System
 Fittings: Check the fittings annually. Check its
sealing condition by a leak detector.
 Piping: Check whether it collides with other
parts; check if the hose is aged and cracked;
and replace the hose every 3~5 years.














4. Others
(a) Tighten such fastenings as bolts and nuts every
three months.
(b) Check the shockproof and insulation rubber pad
for aging and distortion. If any, replace it.
(c) Check the heat insulating material of pipeline for
aging and failure annually.
(d) Check the refrigeration condition every two
years. The temperature difference between air inlet
and outlet must be 7 ~℃ 10 .℃

Notice
The foresaid periodic inspection and
maintenance intervals should be fulfilled
according to the specific working conditions
of air conditioner. In southern area where the
air conditioner is used frequently, you can
shorten the intervals, while in northern area,
you can extend the intervals.
CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 53

5. Maintenance Interval


Table 2-1 Maintenance Interval




























Assembly Action Interval
Fittings
Make sure the locking nut at each fitting is secured; make sure the hoses
and fittings are free of refrigerant leaks; make sure the hoses and pipes are
free of crack, aging, embitterment, crushing, and flattening.
Monthly
Rectify the distorted condenser fin; clean up the element blocked by foreign
materials.
Monthly
Condenser
Make sure condensation blower is free of damage in fan and runs normally. Monthly
Evaporator
Remove foreign materials in air-in and air-out ducts of evaporator element;
check the condensate water drain tube at the bottom for blockage, and clean
it up if any.
Annually
Check whether the connectors of pressure switch are secured. Every 3 months Liquid
reservoir Replace the liquid reservoir after using the air conditioner for some time Every 1000h
Refrigerant
Make sure only a little or no air bubble can be found from the check window
when the air conditioner is under operation. Or else, fill some refrigerant.
Monthly
Make sure the fastening bolts are secured.
Make sure the mounting surface of compressor and the rotary shaft seal of
main axle are free of refrigerant leaks.
Monthly
Check the compressor belt for heavy wear, and replace it if any. Monthly
Check the tightness of belt, and tension it if it gets loose. Monthly
Compressor
Run the air conditioner for a few minutes in the season when you will not use
it.
Monthly
 CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 54
2.6 Checking the Bolts
Check the tightness of the following bolts before
nearly working for the initial 50h. After that, check them
after every 250h’s operation. The tightening torques of
bolts are shown in Table 5-1 and Table 5-2.







Table 2-1 Tightening Torques of Bolts on Main Parts (N•m)
































Tightening Torque Connecting Parts Thread
Specification
Qty.
(N•m) （lbf·ft）
Left/right fork foot and frame Bolt M20×2×80 10.9 2×16 578 426
Right fork foot & reducer Screw M20×55 16 578 426
Reducer & travel end plum blossom plate Bolt M16×55 16 300 221
Travel end plum blossom plate & cushion
block
Nut M12×1.75 24 120
89
Cushion block & contact roller Bolt M12×40 10.9 24 120 89
Supporting seat & left bearing seat Bolt M16×1.5×55
10.9
8 300
221
End cover & supporting plate for shock
absorber
Bolt M16×1.5×45
10.9
12 300
221
Pressure cover & supporting seat Bolt M10×30 12.9 12 50 37
Vibratory end plum blossom plate &
supporting plate for reducer
Bolt M16×40 10.9 12 300
221
Vibratory end plum blossom plate &
cushion block
Nut 12×1.75 48 120
89
Vibratory end plum blossom plate &
connection sleeve
Screw M16×40 10.9 12 300
221
Left fork foot & connection sleeve Screw M16×40 10.9 12 300 221
Vibratory motor Bolt M14×1.5×35
10.9
2 196
145
Left/right bearing seat and drum Bolt M20×2×70 10.9 2×8 578 426
CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 55

Table 2-2 Tightening Torques of Other Bolts (N•m)



































































Tightening Torque Tightening Torque
Dimension
(N·m) (lbf·ft)
Dimension
(N·m) (lbf·ft)
M6 10~12 7~9 M16 214~256 158~189
M8 25~30 18~22 M18 294~353 217~260
M10 49~59 36~44 M20 417~500 308~369
M12 86~103 63~76 M22 568~680 419~502
M14 137~164 101~121 M24 722~864 533~637
Notice
 Use a torque spanner to tighten the loose bolts or nuts to the torque specified in the above tables.
Replace the damaged bolts or nuts with new ones of the same or higher grade.
 Make sure the threads in bolts and nuts are clean before the installation.
 Before fitting the bolts and nuts, lubricate them to ensure the friction coefficient.
 In the event of loose mounting bolts for counterweight, tighten it and contact the nearest
appointed dealer and the engineer of SANY company.
 The required tightening torque is expressed in N•m:
 For example: When using a 1m-long spanner to tighten bolts or nuts and turning the end of
spanner handle with a force of 120N, the torque produced is: 1m • 120N=120N • m.
 If you want to use a 0.25m-long spanner to produce the same torque as above: 0.25m y=120N • m;
 The force required must be: y=120N • m/ 0.25m=480N.
 CHAPTER 2 OPERATION AND MAINTENANCE
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 56
2.7. Checking the Functional Oil
2.7.1 Checking for Oil Leaks
(a) Check the connectors of pump, motor, multi-way
valve, valve body, hose and flange for leaks.
(b) Check the engine oil tank, tandem and worm-gear
box for oil leaks.
(c) Check the pipeline of the air conditioner for leaks.
(d) Check the pipelines in engine for oil, air and water
leaks.





2.7.2 Checking the Oil and Water Levels
(a) Check the lubricating oil, fuel and hydraulic oil levels
and fill new oil to the specified scales on oil dipstick.(b) Check the water level in the combined radiator and
fill water as per the requirements.


2.7.3 Table of Oils and Auxiliary Materials



Table 2-3 Oils and Auxiliary Materials





















Volume
Material
Recommended
Brand
Using Parts
(L) (GAL) Replace Time
Premium No.0
Light diesel
oil
Premium No.35
(winter)
Fuel oil tank of engine 200 52.8 Depend on season
and district
Engine oil
Shell diesel oil
CG-415W40
Crankcase of engine 13 3.4 250h or 2 month
(50h for the first time)
Running reducer 1.5 0.4
Replace oil in winter
and summer (50h for
the first time)
Industrial
lubricating oil
Shell gear oil
VG150
Vibratory drum 8 2.1 500h (50h for the
first time)
Running bearing of vibratory
drum
Fill 2/3 of capacity
Fill once when
operating heavy
repair
Lubricant
Shell lithium-based
grease NLG12
Circle bearing As required Fill once/shift
Deutz engine 110 29.1
Hydraulic oil
Shell hydraulic oil
46
Hydraulic
tank
Cummins
engine
80 21.1
2000h or
one year
Non-freezing
solution
Shell Freezeguard
(-45º)
Water box of engine 12.1 3.2 As required
CHAPTER 3 TRANSPORTION OF ROLLER
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 57







Full Hydraulic Single Drum Roller Operation Manual

Operation & Maintenance

2.1 Starting of Equipment
2.2 Check before Normal Operation
2.3 Operation of Working Device
2.4 Cleaning of Device
2.5 Maintenance Cycle
2.6 Check of Bolts
2.7 Check of Functional Oil








P28~45









Full Hydraulic Double Drum Vibratory Roller Operation Manual

Transportation of Roller

3.1 Transfer Vehicle
3.2 Self-propelled Ascending Transfer
Vehicle via Slope
3.3 Loading and Unloading by Crane
3.4 Winch Traction








P58~59

CHAPTER 3 TRANSPORTION OF ROLLER
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 58
 Chapter 3 Transportation of Roller
3.1 Transfer Vehicle
Either transportation on highway or railway, the
roller should be transported by the vehicles with proper
capacity and load capacity. The transfer vehicle must
meet the requirements of this kind of transportation
facilities such as max. load, engine power, brake
capacity and other conditions. You’d better transport
the roller exclusively without loading other machines
during each transportation.
(1) During transportation, necessary measures
should be taken to avoid slipping and rolling of the
roller.
(2) Keep a certain space away when passing
through the buildings, bridges, culverts and electric
facilities, etc.
(3) Use transfer vehicle for long-distance
transportation of roller.






















3.2 Self-propelled Ascending Transfer
Vehicle via Slope
You must use a slope to load and unload the large
double drum vibratory roller. Make sure the slope is in
the optimum condition. You must use metallic slope as
possible, but not the metamorphic slope which has
been placed for a long time. Besides, you must ensure
the slope with a sufficient width and strength to support
the machine and a gradient less than 15°.
Make sure the slope is placed between the
transfer vehicle and ground correctly; the slope is not
covered by greasy dirt, snow, ice and mud; and the
transfer vehicle is laid with foundation.
Start the roller and adjust its location to make its
front part aligned with the slope. After that, drive the
roller onto the transfer vehicle at a low speed. You must
place some timber blocks in advance at the position
where the roller is to be parked.



















Grade spacing Max. gradient: 15°
Timber block
CHAPTER 3 TRANSPORTION OF ROLLER
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 59
3.3 Loading and Unloading by Crane
You must use a crane to load the small double
drum vibratory roller on the transfer vehicle. All small
rollers have lifting holes. Before lifting the roller, lock the
steering mechanism to secure it against rotation. The
weight of the roller is marked on its rating plate. Check
the rating plate to confirm the machine weight before
lifting. Carry out lifting in strict accordance with the
safety regulations.







3.4 Winch Traction
Release all brakes of the roller. Fit the chain to the
roller. Load the winch on the transfer vehicle. You must
use the chain and cable with proper dimensions but not
the thick rope. Start the winch and drag the roller onto
the trailer.































































Never lift the machine with the front and rear
towing hooks. Otherwise, the machine may be
damaged.
Caution
Caution
Locking the Steering Mechanism
Lifting Hole
 Keep in mind that it is dangerous to load/unload
the roller on the transfer vehicle.
 When loading or unloading the roller on the
transfer vehicle, do not stay under or near the
roller. Never move or drag the machine by
hands as crushing accident may occur when
loading the roller.
 Make sure each part of the roller is secured.
 Do not use a crane to load and unload the large
roller.
INDEX
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 60







Full Hydraulic Single Drum Roller Operation Manual

Operation & Maintenance

2.1 Starting of Equipment
2.2 Check before Normal Operation
2.3 Operation of Working Device
2.4 Cleaning of Device
2.5 Maintenance Cycle
2.6 Check of Bolts
2.7 Check of Functional Oil








P28~45









Full Hydraulic Single Drum Roller Operation Manual

Transportation of Roller

3.1 Transfer Vehicle
3.2 Self-propelled Ascending Transfer
Vehicle via Slope
3.3 Loading and Unloading by Crane
3.4 Winch Traction









P47~48









Full Hydraulic Double Drum Vibratory Roller Operation Manual

Index













P61


INDEX
YZC12C FULL HYDRAULIC DOUBLE DRUM ROLLER OPERATION MANUAL
 61

Index
Ａ
Air Intake System......................................................10
Ｂ
Basic Structure of Distribution Control Cabinet .......25
Brake Hydraulic System ...........................................29
Braking During Traveling ..........................................37
Ｃ
Cab and Control System ............................................8
Central Articulation Frame ..........................................5
Check before Starting ...............................................31
Check After Starting with the Roller Running in place37
Check Before Operation...........................................37
Cleaning the Equipment ...........................................48
Checking the Bolts ....................................................54
Checking the Functional Oil......................................56
Ｅ
Electrical Control Devices.........................................12
Engine..........................................................................9
Exhaust System........................................................11
Engine Electrical System..........................................15
Engine Speed Control...............................................37
Ｆ
Frame Assembly .........................................................4
Function Description ...................................................4
Fuel System...............................................................12
Ｇ
General ......................................................................12Ｈ
Hydraulic Control Devices ........................................26
Ｌ
Loading and Unloading by Crane ............................59
Ｍ
Main Technical Characteristics...................................2
Monitoring Electrical System....................................17
Maintenance Interval ................................................ 48
Maintenance for Long-term Parking........................ 50
Maintenance of Electrical System ........................... 50
Maintenance of Air Conditioning System ................ 50
Ｏ
Operating the Working Device................................. 37
Overall Structure ......................................................... 1
Ｐ
Parking ...................................................................... 42
Periodic Maintenance............................................... 48
Ｒ
Routine Maintenance ............................................... 48
Ｓ
Safety Protection Device............................................ 8
Spraying System......................................................... 7
Spraying Control System.......................................... 23
Steering Hydraulic System....................................... 28
Starting the Equipment............................................. 31
Starting ...................................................................... 35
Self-propelled Ascending Transfer Vehicle via Slope58
Spraying \y.............................................................. 40
Ｔ
Text Display............................................................... 42
Technical Parameters................................................. 3
Traveling and Brake Control System....................... 21
Traveling Hydraulic System ..................................... 26
Traveling.................................................................... 37
Transfer Vehicle ........................................................ 58
Ｖ
Vibratory Compaction............................................... 38
Vibratory Drum Assembly........................................... 6
Ｗ
Winch Traction .......................................................... 59




APPENDIX
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 62







Full Hydraulic Double Drum Vibratory Roller Operation Manual

Appendix

Overall Structure
Hydraulic basic diagram
Electrical Schematic Diagram










P63~65

APPENDIX
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 63
Appendix
Overall Structure
1-Spraying system (two sets)
2-Rear frame assembly
3-Central articulation frame
4-Hydraulic system
5-Front frame assembly
6-Vibratory drum assembly
7-Power system assembly
8-Console assembly
9-Air conditioner
10-Cab
11-Electrical system
12-Covering parts assembly
APPENDIX
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 64
Hydraulic Basic Diagram

APPENDIX
YZC12C FULL HYDRAULIC DOUBLE DRUM VIBRATORY ROLLER OPERATION MANUAL
 65
Electrical Schematic Diagram

CHAPTER 3 TRANSPORTION OF ROLLER
YZC12C FULL HYDRAULIC DOUBLE DRUM ROLLER OPERATION MANUAL
 66
3.3 Loading and Unloading by Crane
Small double drum vibratory roller can be loaded
on the transfer vehicle with crane. All small rollers have
hoisting hole. Before hoisting the roller, its rotation
should be prevented which will lock the steering
mechanism. The weight of the roller is marked on its
name plate. Check and verify the machine weight on
the name plate when hoisting and operate according to
the safety regulations of the crane.






3.4 Winch Traction
Release all brakes of the single drum vibratory
roller, connect the chain to the roller and load the winch
on the transfer vehicle. Use chain and wire rope with
proper dimensions but not coarse rope. Start the winch
and drag the roller onto the trailer.


































































Caution
Caution
Locking Steering mechanism
Lifting hole
Hoisting on the positions of the front and rear
drawbar hooks are forbidden to avoid any
damages to the machine
 Keep in mind that it is dangerous to load the
single drum vibratory roller on the transport
vehicle.
 When loading the single drum vibratory roller on
the transport vehicle, do not stay at the area
below or adjacent to the single drum vibratory
roller. Don’t attempt to move or drag the
machine by hands. Please be aware that
loading of the double drum vibratory roller will
cause the compression damages.
 Make sure each part of the single drum vibratory
roller is not loose.
 Loading and unloading by crane is forbidden for
large roller.
INDEX
YZC12C FULL HYDRAULIC DOUBLE DRUM ROLLER OPERATION MANUAL
 67







Full Hydraulic Single Drum Roller Operation Manual

Operation & Maintenance

2.1 Starting of Equipment
2.2 Check before Normal Operation
2.3 Operation of Working Device
2.4 Cleaning of Device
2.5 Maintenance Cycle
2.6 Check of Bolts
2.7 Check of Functional Oil








P28~45









Full Hydraulic Single Drum Roller Operation Manual

Transportation of Roller

3.1 Transfer Vehicle
3.2 Self-propelled Ascending Transfer
Vehicle via Slope
3.3 Loading and Unloading by Crane
3.4 Winch Traction









P47~48









Full Hydraulic Double Drum Roller Operation Manual

Index














P68


INDEX
YZC12C FULL HYDRAULIC DOUBLE DRUM ROLLER OPERATION MANUAL
 68

Index
Ａ
Air Intake System.............................................................12
Ｂ
Basic Structure of Distribution Control Cabinet.........27
Brake Hydraulic System.................................................33
Brake During Traveling ...................................................42
Ｃ
Cab and Control System..................................................9
Center Articulation Frame ................................................5
Check to be conducted for the roller running in place
after startup of the engine..........................................41
Check Before Normal Operation.......................................41
Control of Spraying System...........................................45
Control of Text Display....................................................48
Cleaning of Device .............................................................54
Check of Bolts.....................................................................61
Check of Functional Oil .....................................................63
Ｅ
Electrical Control Devices..................................................14
Engine..................................................................................10
Exhaust System ...............................................................13
Electrical System of the Engine....................................18
Ｆ
Frame Assembly ................................................................4
Function Description ............................................................4
Fuel System ......................................................................14
Ｇ
General...............................................................................14
Ｈ
Hydraulic Control Devices.................................................29
Ｌ
Loading and Unloadingby Crane......................................66
Ｍ
Main Technical Characteristics .......................................1
Monitoring Operation of Electrical System ................ 20
Maintenance Cycle ............................................................ 54
Maintenance of Electrical System ............................... 56
Maintenance of Air Conditioning System................... 57
Ｏ
Operation of Rotary Speed of the Engine.................. 42
Operation of Working Device ........................................... 42
verall Structure ................................................................... 1
Ｐ
Parking............................................................................... 47
Please carry out the following checks prior to starting35
Periodic Technical Maintenance .................................. 55
Ｒ
Routine Maintenance ..................................................... 54
Ｓ
Safety Protection Device ................................................. 9
Spraying System ............................................................... 7
Sprinkling Control System............................................. 26
Steering Hydraulic System............................................ 32
Starting of Equipment........................................................ 35
Starting............................................................................... 39
Self-propelled Ascending Transfer Vehicle via Slope...... 65
Ｔ
Technical Maintenance for Long-term Parking......... 56
Technical Parameters ........................................................... 2
Traveling and Brake Control System.......................... 24
Traveling Hydraulic System .......................................... 29
Travel Operation.............................................................. 42
Transfer Vehicle.................................................................. 65
Ｖ
Vibratory Compaction Control ...................................... 43
Vibratory Drum Assembly................................................ 6
Ｗ
Winch Traction................................................................... 66




APPENDIX
YZC12C FULL HYDRAULIC DOUBLE DRUM ROLLER OPERATION MANUAL
 69







Full Hydraulic Double Drum Roller Operation Manual

Appendix

Overall Structure
Hydraulic basic diagram
Electrical Schematic Diagram











P70~72


APPENDIX
YZC12C FULL HYDRAULIC DOUBLE DRUM ROLLER OPERATION MANUAL
 70
Appendix
Overall Structure
1-Spraying system (two sets)
2-Rear frame assembly
3-Center articulation frame
4.-Hydraulic system
5-Front frame assembly
6-Vibratory drum assembly
7-Power system assembly
8-Console assembly
9-Air conditioner
10- Cab
11-Electrical system
12-Covering parts assembly
