Vol.:(0123456789)
Environmental Chemistry Letters (2024) 22:1521–1561
https://doi.org/10.1007/s10311-023-01693-0
REVIEW ARTICLE
Mathematical modeling of the anodic oxidation of organic pollutants:
a review
Ekaterina Skolotneva1  · Andrey Kislyi2 · Anastasiia Klevtsova2 · Davide Clematis1 · Semyon Mareev2 ·
Marco Panizza1
Received: 15 May 2023 / Accepted: 28 December 2023 / Published online: 27 February 2024
© The Author(s), under exclusive licence to Springer Nature Switzerland AG 2024
Abstract
Anodic oxidation is a promising method for removing organic pollutants from water due to its high nonselectivity and
effectiveness. Nevertheless, its widespread application is limited due to its low current efficiency, high energy consumption
and low treatment rates. These problems may be overcome by the optimization of the process parameters, reactor design and
electrode geometry, by coupling the experimental investigations with mathematical modeling. Here we review the modeling
of anodic oxidation with focus on basics of this process, the competition phenomenon in real wastewater, flow cells and batch
cells, historical aspects, general modeling equations, modeling with plate electrodes, modeling with porous 3-dimension
electrodes and the density functional theory. Mathematical modeling can provide current, voltage and concentration
distributions in the system. Mathematical modeling can also determine the effects on the performance of parameters such as
diffusion layer thickness, flow velocity, applied current density, solution treatment time, initial concentration and diffusion
coefficients of organic pollutants, electrode surface area, and oxidation reaction rate constant. Mathematical models allow
to determine whether the limiting factor of the process is kinetics or diffusion, and to study the impact of competition of
phenomena. The density functional theory provides information on probable reaction pathways and by-products.
Keywords Electrochemical oxidation · Organic pollutant · Mathematical model · Hydroxyl radical · Mass transport ·
Density functional theory
Abbreviations
Blue-TiO2 Blue-titanium dioxide
C6H6 Benzene
CH3COCH3 Acetone
(C2H5)3N Triethylamine
CH3OH Methanol
Cl− Chloride ions
ClCH꞊CCl2 Trichloroethylene
ClO3
− Chlorate
CO2 Carbon dioxide
H2 Hydrogen
H2CO3 Carbonic acid
H2O Water
IrO2-Ta2O5 Iridium dioxide-tantalum pen-
toxide electrode
NaClO4 Sodium perchlorate
NO2 Nitrogen dioxide
O3 Ozone
O3/H2O2 Ozone/hydrogen peroxide
PO4
3− Phosphate
RuO2-TiO2 Ruthenium oxide-titania
electrode
S2O8
2− Peroxodisulfate
Ti4O7 Sub-stoichiometric titanium
oxide
Ti/Pt Titanium covered by platinum
electrode
B Boron
Carbon/Graphite Carbon-coated graphite
electrode
CH3CH3 Ethane
CH3COOH Acetic acid
C6H5NH2 Aniline
 * Ekaterina Skolotneva
 ekaterina.skolotneva@edu.unige.it
 * Semyon Mareev
 mareev-semyon@bk.ru
1 Department of Civil, Chemical and Environmental
Engineering, University of Genoa, Via All’Opera Pia, 15,
16145 Genoa, Italy
2 Physical Chemistry Department, Kuban State University, 149
Stavropolskaya Str., Krasnodar, Russia 350040
http://crossmark.crossref.org/dialog/?doi=10.1007/s10311-023-01693-0&domain=pdf
http://orcid.org/0000-0003-1101-9447
1522 Environmental Chemistry Letters (2024) 22:1521–1561
C6H5OH Phenol
Cl2 Chlorine
ClO− Hypochlorite
ClO4
− Perchlorate
C2O6
2− Peroxodicarbonate
HCO3
− Hydrogen carbonate
HClO Hypochlorous acid
HCOOH Formic acid
NaCl Sodium chloride
Na2SO4 Sodium sulfate
O2 Oxygen
OCH3 Methoxy groups
·OH Hydroxyl radicals ()
P2O8
4− Peroxodiphosphate
SO4
2− Sulfate
TinO2n−1 Magnéli phases of sub-
stoichiometric titanium oxides
Ti/PbO2 Titanium-coated lead dioxide
electrode
Ti/SnO2 Titanium-coated tin dioxide
electrode
List of symbols
A Electrode area (m2)
c Concentration (mol m−3)
cs Concentration at the electrode
surface (mol m−3)
CR Concentration of anodic
reactants (mol m−3)
ctp Tracer particles concentration
(mol m−3)
COD Chemical oxygen demand
(mol O2 m−3)
D Diffusion coefficient of the
compound (m2 s−1)
dreac Reaction zone thickness (m)
f Body force (N kg−1)
i Current density (A cm−2)
ilim Limiting current density
(A  m−2)
ilim,ne− Limiting current density of
DET(A  m−2)
i0 Exchange current density(A
 cm−2)
j Flux density (mol m−2  s−1)
k·OH ·OH recombination rate
constant (m3 mol−1  s−1)
P Given loading (mol COD s−1)
Pe Peclet number
R Reactive term (mol m−3  s−1)
Rc Electrolyte ohmic resistance
(Ω)
ri Oxidation rate of each
compound in the reaction zone
(mol m−2  s−1)
Sh Sherwood number
t Time (s)
ts Special time (s)
u Linear fluid velocity (m s−1)
VR Reservoir volume (m3)
ΔVwork Cell potential (V)
X COD conversion (%)
Xcr Critical conversion
Α Electron transfer coefficient
Areq Required electrode area (m2)
cb Bulk concentration (mol m−3)
C0 Concentration of cathodic
reactants (mol m−3)
C Dimensionless tracer particles
concentration
ctp
0 Initial tracer particles
concentration (mol m−3)
COD0 Initial chemical oxygen
demand (mol O2 m−3)
Esp Specific energy consumption
(kW h kg COD−1)
F Faraday’s constant(C mol−1)
i Current intensity (A)
iappl Applied current density (A
 m−2)
ilim
0 Initial limiting current density
(A m−2)
i·OH Initial limiting current density,
corresponding to the total
mineralization of organic
compounds (A m−2)
J Flux (mol s−1)
km Mass transfer coefficient (m
 s−1)
Lx Axial length (m)
p Applied pressure (Pa)
Qcr Critical specific charge (Ah
 m−3)
R Universal gas constant (J
 mol−1 K −1)
Re Reynolds number
Sc Smidt number
T Temperature (K)
tcr Critical time (s)
uint Interstitial liquid velocity (m
 s−1)
V Volume of electrolyte (dm3)
ΔVi Oxidation potential of each
process (V)
1523Environmental Chemistry Letters (2024) 22:1521–1561
Xl Dimensionless axial length
(m)
x Axis coordinate along the
distance (m)
z Charge
Greek letters
δ [delta] Diffusion layer thickness (m)
ε [epsilon] Effectiveness factor
εCl− [epsilon Cl] Faradic yield as a function of
chloride (Cl−) concentration
ηa [eta a] Overpotential of anodic
reaction (V)
θ [theta] Dimensionless time
μ [mu] Dynamic viscosity (Pa s)
τ [tau] Electrolysis time (s)
φ [phi, small letter] Electric potential (V)
αi [alpha i] Proportion of electrons
involved in a particular
electrochemical process
corresponds to each process i
α·OH [alpha OH] Term accounts for the fraction
of current directed toward ·OH
production
δ(exp) [delta exp] Diffusion layer thickness
obtained experimentally (m)
εi [epsilon i] Faradaic yield
ηc [eta c] Overpotential of cathodic
reaction (V)
θi [theta i] Parameter represents the
oxidation efficiency
ρ[rho] Liquid density (kg  m−3)
ϕ [phi] Dimensionless parameter
expressing the ratio between
the chemical reaction rate and
the mass transfer coefficient
φ [phi, small bold letter] Normalized current efficiency
Introduction
Electrochemical advanced oxidation processes are
increasingly being used to treat wastewater from
organic pollutants. Electrochemical advanced oxidation
processes are defined as purification processes occurring
at temperatures and pressures close to their values in the
environment, at which the generation of hydroxyl radicals
(·OH) occurs with a sufficient rate to promote the oxidation
of organic pollutants (Chaplin 2014; Sirés et  al. 2014;
Moreira et al. 2017; Brosler et al. 2023). In recent years,
electrochemical advanced oxidation processes have attracted
increasing attention from researchers, as evidenced by the
growing number of well-cited review articles on the topic
(Cuerda-Correa et al. 2019; Seibert et al. 2020; da Silva et al.
2021; Ganiyu et al. 2021; Titchou et al. 2021). One such
process is anodic oxidation, which allows providing reagent-
free removal of contaminantsby completely oxidizing them
to inorganic substances (McBeath et al. 2019; Yang 2020;
Hu et al. 2021; Fu et al. 2023).
Many organic pollutants have been effectively removed
using anodic oxidation: aromatic compounds (Polcaro et al.
2003; Borrás et al. 2004; Mascia et al. 2007; Lin et al. 2020),
dyes (Galus and Adams 1964; Brillas and Martínez-Huitle
2015; Cruz-Díaz et al. 2018), pharmaceuticals (Lan et al.
2018; Trellu et al. 2018b; Zhang et al. 2021), pesticides
(Trellu et  al. 2021), contaminants of emerging concern
(Shahid et  al. 2021) and microplastics (Kiendrebeogo
et  al. 2021; Ricardo et  al. 2021). The use of anodic
oxidation can significantly reduce the damage caused to
the ecosystem by wastewater from some industries, such as
the pharmaceutical, textile, petroleum, paper and tannery
industries (Garcia-Segura et al. 2018).
It is rather difficult to achieve high current efficiencies in
the anodic oxidation process due to the kinetic and diffusion
limitations of the process (Panizza and Cerisola 2009).
The influence of these restrictions is reduced in two main
directions: optimization of the anode structure, i.e., design
of porous anodes with specified characteristics (porosity
and pore size), as well as the use of promising materials for
its manufacture, e.g., boron-doped diamond and TinO2n−1
(Magnéli phases of sub-stoichiometric titanium oxides)
(Ganiyu et al. 2019; He et al. 2019; Hu et al. 2021; Cui
et al. 2022; Kumar et al. 2022; Ma et al. 2022). Hybrid plants
are being developed that combine anodic oxidation with
other organic pollutant removal processes (Hu et al. 2021).
Energy consumption can be reduced by using renewable
energy sources, application of microbial fuel cells, and
photocatalysis (Gude 2016; Ge et al. 2017; Ganiyu et al.
2020). At the same time, the understanding of this process
needs to be improved. Thereby, mathematical models play
an extremely important role.
In the literature, there are various mathematical models
developed to describe the anodic oxidation process of
organic compounds (Newman and Tiedemann 1975;
Comninellis 1994; Simond et al. 1997; Panizza et al. 2001a;
Kapałka et al. 2008; Rodriguez et al. 2012; Trellu et al.
2016; Misal et al. 2020; Skolotneva et al. 2021). In these
models is described the process on a plate (two-dimensional)
electrodes (Comninellis 1994; Simond et al. 1997; Kapałka
et  al. 2008; Trellu et  al. 2016). There are also models
that describe the process on porous (three-dimensional)
electrodes (Newman and Tiedemann 1975; Misal et  al.
2020; Skolotneva et al. 2021). Some models make it possible
to obtain an analytical solution of the problem and can be
a convenient tool for qualitative analysis of the influence
of the main process parameters on the system behavior
1524 Environmental Chemistry Letters (2024) 22:1521–1561
(Comninellis 1994; Simond et al. 1997; Trellu et al. 2016).
These models rarely accurately account for all factors, but
they greatly simplify the understanding of the basic patterns
of the process. Other problems are solved numerically,
allowing to obtain a more accurate solution taking into
account hydrodynamic characteristics of experimental
system that can be applied to specific experimental system
(Skolotneva et al. 2021; Monteil et al. 2021). Such models
are more cumbersome and require certain computing
resources but can give a more detailed idea of the process.
Finally, there are empirical models, that make it possible to
study the influence of various factors on the anodic oxidation
process occurring in a particular experimental system
(Ghazouani et al. 2016; Kothari and Shah 2020).
As regards the state of the art in the field of modeling the
electrochemical oxidation process of organic pollutants, a
relatively small number of publications should be noted here,
compared, for example, with the number of publications in
the field of fuel cell or electrode plating modeling. The first
anodic oxidation models were presented by Comninellis
(1994). Since then, several other models have been
developed to improve understanding of the anodic oxidation
process. It is also noticeable that over the past decade only a
few essentially new mathematical models in this area have
been presented (Marshall and Herritsch 2018; Skolotneva
et al. 2020; Misal et al. 2020).
Review articles that consider anodic oxidation models in
general or for predicting the behavior of specific experimental
systems are very useful for the scientific community. These
articles provide an opportunity for a quick and relatively sim-
ple formation of an idea about the anodic oxidation knowledge
area. Review articles can also help the reader take a new per-
spective at the description of the study object and can contrib-
ute to the development of new model ideas. At the same time,
it should be noted that the number of review articles in which
various aspects of anodic oxidation modeling are considered
in detail is extremely small (Russo 2021).
This review article is devoted to a detailed description of
the theoretical aspects of the anodic oxidation process. A
lot of effort has gone into making this paper a starting point
in modeling electrochemical oxidation processes for those
who are interested. In this review, a simple description of the
most common models is presented, their main advantages
and disadvantages are indicated, and various approaches for
the anodic oxidation modeling are considered.
Basics of the anodic oxidation process
The application of the anodic oxidation process to remove
organic pollutants is possible due to partial degradation or
complete mineralization using electrochemical oxidation
reactions. The electrocatalytic properties of anodic materials
play an undeniable role in the organic removal efficiency of
the anodic oxidation process.
Anodic oxidation of organic compounds for wastewater
treatment is implemented in two main ways (Fig. 1):
Direct anodic oxidation—a process that involves direct
electron transfer reactions between the anode surface
and organic pollutants, i.e., electron transfer occurs on
the electrode surface without the participation of other
substances (Martínez-Huitle and Ferro 2006; Panizza and
Cerisola 2009). Electrons are capable of oxidizing some
organic pollutants at lower potentials than the oxygen
evolution reaction (Panizza and Cerisola 2009; Garcia-
Segura and Brillas 2011). The direct oxidation process
usually requires the adsorption of pollutants onto the anode
surface (see scheme in Fig. 1), which limits the process
rate. It does not lead to the complete combustion of organic
pollutants, R (Eq. 1), and thus surface deactivation of an
electrode may occur (Rodgers et al. 1999; Rodrigo et al.
2001).
Indirect anodic oxidation—a process in which organic
pollutants are oxidized under the effect of highly oxidizing
species generated on the anode surface, which act as
intermediaries for the movement of electrons between
the electrode and organic compounds (Martínez-Huitle
and Ferro 2006; Brillas et al. 2009; Panizza and Cerisola
2009; Sirés et al. 2014; Brillas and Martínez-Huitle 2015;
Martínez-Huitle et al. 2015). Different kinds of oxidizing
species can be generated by the anodic oxidation process
(Fig.  1b,c,d). Some of the most important are reactive
oxygen species, such as ·OH. The generation of large
quantities of ·OH from the water dissociation onto the
surface of the anode material, M, with a high-oxygen
overpotential proceeds as follows:
With consequent oxidation of organic pollutants:
Degradation products may be carbon dioxide (CO2),
water (H2O) and other inorganic oxides of heteroatoms
contained in the initial organic molecule.
Theoretically, anodic oxidation is possible at low
potentials before oxygen evolution (direct anodic oxidation),
but under these conditions, the anode surface is rapidly
deactivated due to the deposition of a polymer layer on it
(fouling).The fouling depends on the adsorption properties of
the anode surface, as well as on the concentration and
nature of organic compounds. This effect can be avoided
(1)R → (R⋅)+ + e−
(2)M + H2O → M(⋅OH) + H+ + e−
(3)R +M(⋅OH) → degradation byproducts
1525Environmental Chemistry Letters (2024) 22:1521–1561
by conducting anodic oxidation in the range of the water
dissociation potentials, due to the intermediate products of
the oxygen evolution reaction (indirect anodic oxidation,
Fig.1 b,c,d).
The efficiency of the process depends on the operating
conditions and primarily on the nature of electrode mate-
rial. In particular, anodes with a low oxygen evolution
overpotential, such as electroactive ruthenium oxide with
titanium oxide nanotube array (RuO2–TiO2), oxide mixture
of iridium dioxide and tantalum pentoxide (IrO2–Ta2O5),
titanium covered by platinum (Ti/Pt), carbon-coated graphite
(Carbon/Graphite), are referred to as "active" (Fig. 2), as
they are involved in “chemical” adsorption of ·OH (Fig. 1b).
These anodes contribute to the partial and selective oxida-
tion of pollutants, i.e., electrochemical conversion, whereas
anodes with a high-oxygen evolution overpotential, such as
titanium-coated lead dioxide (Ti/PbO2), titanium-coated tin
dioxide (Ti/SnO2), boron-doped diamond or sub-stoichio-
metric titanium oxide (Ti4O7), exhibit "non-active" behavior
and therefore are ideal electrodes for electrochemical incin-
eration of organic pollutants to CO2 in wastewater treatment.
Furthermore, the boron-doped diamond electrodes are the
most suitable non-active anodes due to good chemical and
electrochemical stability, long lifetime, and a wide range
of water dissociation potentials. Thereby, boron-doped
diamond electrodes are promising anodes for industrial-
scale wastewater treatment. It is known that when using
boron-doped diamond electrodes, many water contaminants
are completely mineralized, and in some cases (namely, at
kinetic limitations) the current efficiency of the process can
R (pollutant)
Rох(product)
di
re
ct
 e
le
ct
ro
n
tra
ns
fe
r
adsorption
desorption
a
Oxidant
precursor
(H2O)
½ O2
H+
H+
Rox(product)
R(pollutant)
*chems-chemisorption
b
Oxidant
precursor
(H2O)
½ O2+ H2
H+
Rox(product)
R(pollutant)
c
Oxidant
precursor
Stable
oxidants
Rox(product)
R(pollutant)
2 3 2
4 4 3SO Cl PO CO− − − −( , , , )
Rox(product)
R(pollutant)
Rox(product)
R(pollutant)
Activated
oxidants
Activation
d
Fig. 1 Processes involved in the anodic oxidation: a Direct oxidation:
the molecule of organic pollutant (R (pollutant)) is first adsorbed on
the electrode surface (Rads), and then oxidized (Roxads) by direct elec-
tron transfer (e−); Indirect oxidation: b Generation of reactive oxy-
gen (O2) on active anode: hydroxyl radicals (·OH) formed from the
discharge of water (H2O) is adsorbed on the active site and interacts
with the material of electrode (·OHads), which leads to the formation
of higher oxide. The reactive oxygen in this case is chemisorbed (–
Ochems); c Generation of O2 on non-active anode:·OH formed from the
discharge of H2O is adsorbed on the active site (·OHads), but it cannot
interact with the material of electrode, thus, the O2 in this case is phy-
sisorbed; d Generation of other reactive species: from the oxidation
of common electrolytes such as sulfate (SO4
2−), chloride (Cl−), phos-
phate (PO4
3−) and carbonate (CO3
2−) many stable oxidant agents can
be formed. Rox(product)—organic product of oxidation, H+—hydro-
gen ion, Stable oxidants: peroxodisulfate (S2O8
2−), active chlorine
 (Cl2), peroxodiphosphate (P2O8
4−), peroxodicarbonate (C2O6
2−)
1526 Environmental Chemistry Letters (2024) 22:1521–1561
reach nearly 100% (Martínez-Huitle and Ferro 2006; Panizza
and Cerisola 2009; Sirés et al. 2014; Brillas and Martínez-
Huitle 2015; Martínez-Huitle et al. 2015, 2018; Ganiyu et al.
2018).
Recently, TinO2n−1 has been proposed as a new economic
anode material for the electrocatalytic oxidation of organic
pollutants (Ganiyu et  al. 2019). Nevertheless, plate
 TinO2n−1 has been achieved slightly less efficiency in the
electrochemical oxidation of organics than in the boron-
doped diamond anode (Ma et al. 2023b). But it is possible
to prepare 3D porous electrodes made of TinO2n−1, and in
this case the efficiency increases significantly (Ma et al.
2023a). Another promising material based on titanium
oxides, namely, blue-titanium dioxide (blue-TiO2) nanotube
arrays, has been proposed for use as an anode material in
the anodic oxidation process (Kim et al. 2014). According
to Cai et al. (2019), blue-TiO2 nanotube anode compared
to the boron-doped diamond anode had a comparable and
even better characteristics, such as ·OH production activity
and total organic carbon (TOC), chemical oxygen demand
(COD) removal, with a lower energy consumption. Reactive
electrochemical membranes based on blue-TiO2 nanotube
arrays are also known, which make it possible to achieve
complete removal of organics in a single-pass flow-through
mode (Wang et al. 2022).
Indirect oxidation is used to prevent fouling of the
electrode by eliminating the direct electron transfer between
the organic compounds and the anode surface. Therefore,
the oxidizing species generated electrochemically at the
anode oxidize the contaminants in the bulk solution.
Among the oxidizing species generated at the anode,
active chlorine (Cl2) is the most common and widely used
for wastewater treatment (Garcia-Segura et al. 2018). The
probable mechanism for the electrogeneration of active Cl2
species mediated by reactive oxygen species is proposed by
Bonfatti et al. (2000), Neodo et al. (2012) and Rosestolato
et  al. (2014). The oxygen transfer reactions are carried
out by adsorbed oxychlorinated species formed according
to reaction (Eq. 4), as an intermediate of the Cl2 release
(Eq. 5) as in Fig. 1d. Formed hypochlorous acid (HClO) is a
weak acid (pKa 7.5), that is in equilibrium with hypochlorite
 (ClO−) (Eq. 6). Therefore, pH solution value significantly
affects the concentration of Cl2 compounds and thus the
efficiency of the oxidation process (Scialdone et al. 2021;
Hao et  al. 2022). Indeed, Cl2 prevails at very low pH,
HClO—in moderate acidic conditions, and ClO−—in basic
conditions. However, the formation of other intermediate
oxidants, such as chlorate (ClO3
−) and perchlorate (ClO4
−),
is possible (Eqs. 7–12), which are less active compared to
 ClO− (Titchou et al. 2021). Therefore, their formation is
an undesirable process. The generation rate of ClO3
− and
 ClO4
− can be reduced by the irradiation of the solution
(Kiwi et al. 2000). It should be noted that Cl2 can lead to the
formation of chlorinated by-products which could be toxic
(de Moura et al. 2014; Mostafa et al. 2018).
(4)M(⋅OH) + Cl− → M(HOCl)
(5)M(HOCl) → M + 1∕2Cl2 + OH−
(6)HClO ⇄ H+ + ClO−
(7)Cl− + ⋅OH → ClOH−
⋅
Oxidation power
Oxygen evolution overpotential (V)
Chemisorbed ·OH Physisorbed ·OH
1.4 – 1.7
RuO2-TiO2
1.5 – 1.8
IrO2-Ta2O5
1.7 – 1.9
Ti/Pt
1.7
Carbon/
Graphite
1.8 – 2.0
Ti/PbO2
1.9 – 2.2
Ti/SnO2
BDD,
2.2 – 2.6
Ti4O7
Active Non-active
Fig. 2 Classification of the electrode materials used in anodic oxi-
dation. The value of oxygen evolution overpotential determines the
mechanism of O-transfer reaction for each electrode. Electrodes with
the value of oxygen evolution overpotential (V) > 1.8 V can be clas-
sified as active anodes: ruthenium dioxide (RuO2)-titanium dioxide
 (TiO2), iridium dioxide (IrO2)-tantalum pentoxide (Ta2O5), titanium
(Ti)-platinum (Pt), carbon/graphite; and the ones with the value of
oxygen evolution overpotential < 1.8 V can be classified as non-active
anodes: titanium (Ti)/lead dioxide (PbO2), titanium (Ti)/tin dioxide
 (SnO2), boron-doped diamond (BDD) or sub-stoichiometric titanium
oxide (Ti4O7); hydroxyl radicals(·OH). Adapted with the permission
of Taylor & Francis from Garcia-Rodriguez et al. (2022)
1527Environmental Chemistry Letters (2024) 22:1521–1561
Most often, the electrodes used to produce active Cl2
consist of Pt or a mixture of metal oxides, for example RuO2,
 TiO2 and IrO2. These electrodes have good electrocatalytic
properties, long-term stability, low price and may be applied
to a wide range of pollutants, such as olive oil, textile and
tannery wastewaters (Martínez-Huitle and Ferro 2006;
Brillas et al. 2009; Panizza and Cerisola 2009; Sirés et al.
2014; Brillas and Martínez-Huitle 2015; Martínez-Huitle
et al. 2015, 2018; Chung et al. 2018; Ganiyu et al. 2018).
Other oxidizing species are electrogenerated during the
oxidation of common electrolytes such as sulfate (SO4
2−),
phosphate (PO4
3−) and hydrogen carbonate (HCO3
−)
yielding peroxodisulfate (S2O8
2−), peroxodiphosphate
 (P2O8
4−) and peroxodicarbonate (C2O6
2−) according
to reactions (13–22) (Serrano et  al. 2002; Velazquez-
Peña et  al. 2013; de Paiva Barreto et  al. 2015; Ganiyu
and Gamal El-Din 2020). In comparison, these species
are weaker oxidants than ·OH and active Cl2 and are not
capable of completely mineralizing the organic pollutants.
Nevertheless, they could facilitate the oxidation of some
organic molecules, i.e., S2O8
2− accelerates the degradation
rate of polystyrene microplastics (Kiendrebeogo et al. 2022).
(8)HOCl + ⋅OH → ClO ⋅ +H2O
(9)ClO− + ⋅OH → ClO ⋅ +HO−
(10)ClO−
2
+ ⋅OH → ClO ⋅2 +HO
−
(11)ClO ⋅2 + ⋅ OH → ClO−
3
+ H+
(12)ClO−
3
+ ⋅OH → ClO−
4
+ H+ + e−
(13)2HSO−
4
→ S2O
2−
8
+ 2H+ + 2e−
(14)HSO−
4
→ SO−
4
⋅ +H+ + e−
(15)2PO3−
4
→ P2O
4−
8
+ 2e−
(16)HPO2−
4
→ PO2−
4
⋅ +H+ + e−
(17)SO2−
4
+ ⋅OH → SO−
4
⋅ +HO−
(18)HSO−
4
+ ⋅OH → SO−
4
⋅ +H2O
(19)HPO2−
4
+ ⋅OH → PO2−
4
⋅ +H2O
(20)PO3−
4
+ ⋅OH → PO2−
4
⋅ +HO−
Thus, in the indirect oxidation, the supporting electrolyte
has a significant effect on the oxidation kinetics. In this
regard, for accurate mathematical description of the anodic
oxidation process, it is necessary to take into account
reactions involving the inorganic matrix. In the anodic
oxidation process, in addition to active species and oxidation
products of organic pollutants, gaseous products such as
oxygen (O2) and hydrogen (H2) are also formed according
to Eqs. 23–24.
The gas formation on the electrodes can significantly
reduce the process efficiency for the following reasons:
• Gas bubbles released on the electrode surface can lead
to undesired blockage of the electroactive electrode
surface, resulting in energy losses and redistribution
of current density in the system (Angulo et al. 2020).
Energy losses and redistribution of current density are
due to the fact that gas bubbles have an extremely low
electrical conductivity, which leads to an increase in the
ohmic resistance of the solution.
• The bubbles are a steric obstacle to the delivery of the
contaminant to the electrode surface. It can also lead
to blocking of reaction centers and a decrease in anode
reactivity (Liu et al. 2013).
• The oxygen evolution reaction consumes part of the
electric current in the system and therefore reduces the
current efficiency.
• In systems with porous electrodes, gas bubbles can block
the pores, which leads to a decrease in the hydrodynamic
permeability of the system (Sun et al. 2013; Geng and
Chen 2017).
At the same time, the gas bubbles formation can have a
positive effect. According to Wu et al. (2008) and Ahmed
et  al. (2016), it was reported that gas bubbles can be
used to prevent fouling and can increase the efficiency of
electrochemical backwashing by physically removing the
contaminant layer on the electrode surface.
O2 and H2 are not involved in the oxidation process, so
the rate of their generation is reduced as much as possible.
The O2 evolution rate can be reduced by selecting the
anode material and optimizing the current regimes. The H2
evolution rate directly depends on the current density. H2
(21)HCO−
3
+ ⋅OH → CO−
3
⋅ +H2O
(22)CO2−
3
+ ⋅OH → CO−
3
⋅ +HO−
(23)M(⋅OH) → M + 1∕2O2 + H+ + e−
(24)H2O → HO− + 1∕2H2
1528 Environmental Chemistry Letters (2024) 22:1521–1561
current efficiency in most cases is about 90% (Roy Ghatak
2020). This means that most of the current consumption of
the cathode is flowed on H2 evolution rate. In addition, the
released H2 can be recuperated to part of the spent energy
using fuel cells or gas turbines. At the same time, the process
could potentially recover 70% of the energy (total in the form
of heat and in the form of electricity) (Roy Ghatak 2020).
It should be noted that the implementation of such energy
recovery is easier in the case of separate collection of gaseous
products. This means the use of cells with separation of the
cathode and anode chambers using porous partitions or
membranes.
At present, mathematical modeling of the bubble formation
on the surface of plate electrodes is quite well developed.
The work of Taqieddin et  al. (2018) provides a detailed
discussion of model approaches to describing the processes
of nucleation, growth of bubbles and their detachment from
the surface. In review on modeling of bubble formation, the
interfacial supersaturation and surface coverage, models for
calculating the ohmic resistance of gas dispersions in aqueous
solutions and the influence of the gas evolution rate on the
mass transfer coefficient, km, are discussed (Zhao et al. 2019).
There are only few models describing gas formation
inside the pores of porous electrodes. Ateya and El-Anadouli
(1991) considered the electrode kinetics using the Butler-
Volmer equation and the change in the resistivity of the gas-
electrolyte dispersion that fills the pore space, as a result of
a change in the ratio of gas and electrolyte volume fractions,
hydrodynamic characteristics, porosity, thickness and
specific surface area of the electrode. Several dimensionless
groups of parameters have been proposed that describe the
behavior of the system. Saleh et al. (2006) and Saleh (2007,
2009) improved the Ateya’s group model. In their work, the
electrical conductivity of the electrode matrix was taken into
account.
It should be noted that the modeling approaches described
in these articles are common to all electrolysis systems
and do not take into account the specific features of the
anodic oxidation process. For the best of our knowledge,
currently, there is only one mathematical model simulating
the gas bubbles formation during anodic oxidation process.
In a study by Mareev et  al. (2021), a one-dimensional
nonstationary model was proposed to describe the anodic
oxidation process in a system with reactive electrochemical
membranes. The authors introduced the function of the
dependence of the gas volume fraction on the concentration
of O2. This allowed the authors to take into account the
influence of the gas fraction on the electrical conductivity
of the solution and the hydrodynamic permeability of the
porous anode. The effects of undesired blockage of the
surface and pore blocking were also investigated.
Competition phenomena in real wastewater
treatment
Nonselectivity is considered the main advantage of anodic
oxidation, as it allows the treatment of raw wastewaters
which are usually a mixture of different organic compounds
without online composition control and choice of specific
purification technology for each compound. However, most
laboratory studies are performed with single-contaminant
solutions, and consequently, their results may not be relevant
for mixtures. This section aims to clarify which competitive
phenomena between mixture components require attention
when treating real wastewaters.
First of all, there is competition between the oxidation
of two or more organic compounds: An organic compound
with a higher degradation rate constant is oxidized first, and
the difference inremoval rates depends on the difference
in the values of the degradation rate constants (Groenen-
Serrano et al. 2013). It should also be born in mind that
relative reaction rates measured in a single-component
solution cannot be used to predict the oxidation process in a
mixture, since the presence of additional organic compounds
may interfere with each other’s degradation rates (Chaplin
2014). In general, interfering compounds have little effect
on the degradation rate of strongly adsorbed contaminants,
while their effect on the degradation rate of weakly adsorbed
contaminants can be significant. It should be noted that
by-products formed in the process of mineralization of
organic pollutants are also involved in the competition
for oxidizing agents and, therefore, interfere with the
degradation rates of initial contaminants.
Another important point is the fact that real wastewaters
may contain low concentrations of bio-refractory or toxic
compounds together with high concentrations of non-toxic
or biodegradable compounds that can be removed by other
more conventional and cheaper methods. Since the initial
concentration has an effect on the oxidation efficiency,
this results in a lower removal efficiency of target toxic
compound as the non-toxic compounds with higher initial
concentration are preferentially degraded (Moreira et al.
2017; Najafinejad et al. 2023). Moreover, it is pointed out
that in laboratory studies of anodic oxidation target pollutant
has a concentration an order of magnitude higher than in
the environment, which also leads to the overestimation of
removal efficiency in laboratory conditions (Garcia-Segura
et al. 2020).
Since high energy consumption is the main disadvantage
of electrochemical oxidation, it is always necessary to pay
attention to the value of electrical conductivity of treated
solutions. The higher electrical conductivity of the solu-
tion leads to a lower ohmic voltage drop and, consequently,
to a lower the required cell voltage. However, many real
1529Environmental Chemistry Letters (2024) 22:1521–1561
wastewaters have low electrical conductivity, e.g., pharma-
ceutical industries, food industries, hospital wastewaters,
resulting in the need to add supporting electrolyte, i.e., usu-
ally sodium sulfate (Na2SO4), sodium chloride (NaCl) and
sodium perchlorate (NaClO4) (Clematis and Panizza 2021).
Nevertheless, this poses a range of related issues such as cost
and transportation of reagents, the need for the authorization
procedure. On the other hand, there is wastewater contain-
ing more than one electrolyte, e.g., textile dyeing, tannery
petroleum effluents (Garcia-Segura et al. 2018). In this case,
the interaction of these electrolytes with each other can have
both synergetic and inhibition effects on the efficiency of
degradation. Inorganic salts in the anodic oxidation process
can act as precursors of various radicals and other oxidiz-
ing species, which can lead to both an increase in oxidation
efficiency and the formation of toxic by-products (see the
section above). At the same time, some types of electrolytes,
e.g., nitrates, do not form oxidizing agents, but can act as
scavengers of ·OH, thus reducing the oxidation efficiency of
target organic compounds.
In addition to the competitive effects described above,
which are mainly inherent in multi-component systems and
real wastewater, there are competitive phenomena, which are
observed even in single-component systems, for example,
the well-known competition between target reaction and
the parasitic reaction of oxygen evolution. If the system
parameters are not properly selected, the second reaction
will preferentially occur, thereby reducing the current
efficiency. In this review, much attention is paid to the
competition between the reaction rate and the mass transfer
rate, which plays a key role in determining the efficiency of
the process. Anodic oxidation occurs most effectively when
the mass transfer rate of the pollutant to the reaction zone is
equal to the rate of its removal.
As it is seen from above, to understand which param-
eters need to be improved to achieve greater efficiency of
the anodic oxidation process of organic pollutants and to
enable its optimization, it is necessary to distinguish the
contribution of different competitive phenomena. It is often
difficult to perform such investigations by experimental
methods; therefore, mathematical modeling is required.
It allows to determine the limiting stage of the process, to
obtain a detailed description of the degradation mecha-
nism, to analyze the influence of various parameters on the
system behavior and to predict the most optimal operating
conditions. Application of mathematical modeling is highly
advised at development of systems for treatment of real
wastewater by anodic oxidation.
Implementation of anodic oxidation devices
The cell design has an extremely large impact on the
efficiency of the anodic oxidation process (Sandoval et al.
2022). In mathematical models, the cell design determines
the fluid dynamics parameters used in the calculations:
the distribution of fluid flow rates and the diffusion layer
thickness. The more precisely these parameters are defined,
the more accurately it is possible to describe mass transfer
and, consequently, the efficiency of the system.
There are several main principles by which electrochemi-
cal reactors can be classified (Fig. 3). The primary method of
classification may be the operation mode. In batch cells, the
portion of solution is placed into the reactor before the reac-
tion starts and there is no addition or withdrawal of material
during the operation process. In continuous flow cells, the
solution is pumped through the cell (Foutch and Johannes
2003). It should be noted that some researchers use the term
“batch mode” to describe the recirculation regime of liq-
uid flow. This can create some confusion, because then the
flow cell can be operated in a batch mode (Martínez-Huitle
et al. 2015). This approach emphasizes the characteristics of
Fig. 3 Classification of reactors
used in anodic oxidation. There
are four main principles of clas-
sification: operation mode, flow
mode, reactor architecture and
electrode geometry. Adapted
with the permission of MDPI
from Liu et al. (2022)
Operation mode
• Batch mode
• Continuous mode
Reactor architecture
• Mixed-tank reactor
• Plate frame/Filter press
reactor
• Tubular reactor
Flow mode
• Flow-by
• Flow-through
Electrode geometry
• Plate electrode
• Mesh electrode
• Porous electrode
• Particle electrode
2D
3D
Anodic oxidation
reactor design
1530 Environmental Chemistry Letters (2024) 22:1521–1561
the process: The feed solution is passed through the reactor
more than once, therefore, the same portion of the solution
is treated. However, since the primary interest in this section
is the essential differences in the hydrodynamics of flow and
non-flow cells, the term "batch cell" is used only for cells
through which no solution is pumped.
Here the short review of reactors design used in anodic
oxidation is presented. The more comprehensive and
detailed reviews for in-depth reading are aimed at those
who are interested: (Martínez-Huitle et al. 2015; Cornejo
et al. 2020; Rivera et al. 2021; Sandoval et al. 2022; Liu
et al. 2022).
Batch cells
Mixed-tank cells are one of the most used batch cells due to
the simplicity of its design and application (Martínez-Huitle
et al. 2015). A scheme of a typical one is shown in Fig. 4a.
The main advantage of such cell is their extreme flexibility
and simplicity compared to other reactors design. The disad-
vantages of this design are its markedly lower efficiency due
to the big volume of dead zones and poor mass transfer com-
pared to flow cells and the lack of scalability. It is believed
that this cell type is applicable only for the preliminary labo-
ratory studies and forthe organic contaminants oxidation in
solutions with very high concentrations, where cell design
limitations are not significant to the anodic oxidation process
(Martínez-Huitle et al. 2015).
Mixed-tank cell is mostly used with plate electrodes in
parallel configuration (Magro et al. 2020; Salvestrini et al.
2020; Periyasamy et al. 2022; Ma et al. 2023b). However, in
the literature there are also examples of implementation of
this cell with mesh, foam and porous electrodes (Hao et al.
2022; Ma et al. 2022, 2023a).
Flow cells
The main advantage of flow cells is enhanced mass
transport properties, which makes it possible to work with
solutions with rather low concentrations of pollutants,
as well as the possibility to scale-up the plant for the
industrial applications. Three main architectures of flow
electrochemical reactors are discussed below.
Mixed-tank cells can be also used in a continuous flow
mode (Fig. 4b). As all advantages of mixed-tank reactors
described above (flexibility and simplicity of application)
are remained in flow mode and as this reactor design is
suitable for the treatment of large volumes requiring high
contact time, they are the most often used cells for anodic
oxidation processes (Martínez-Huitle et al. 2015). The main
drawback of this type of cells is the poor mass transport
characteristics (big dead zones volume); therefore, it is hard
to scale-up this type of reactors and stirring conditions in
such cells are one of the most important parameter for the
anodic oxidation process efficiency (de Oliveira et al. 2011).
Plate frame (Fig. 5a) and filter press (Fig. 5b) reactors
consist of electrodes fitted in a parallel plate assembly held
by a frame, and they are commonly used configuration in
anodic oxidation processes. Reactors can be accompanied
by electrodes of different geometry, i.e., plate, mesh, porous;
also, additional elements can be added: membrane to sepa-
rate electrode chambers or turbulence promoters to enhance
mass transfer. The main advantage of this cell type is rela-
tively uniform current and potential distribution and well-
defined fluid flow in a rectangular channel which are good
for the scale-up (Frías-Ferrer et al. 2011). However, dead
zones are the major problem of these reactors and the ideal
mixing conditions cannot be achieved, which reduces the
mass transfer.
In tubular reactor, the solution is continuously input-
ted and outputted through a tube. The configuration with
one tubular electrode and one rod electrode (Fig. 5c) is the
Fig. 4 Mixed-tank reactor (cell)
in: a conventional batch mode,
when withdraw or addition of
material are not stipulated by
the reactor design and in: b
continuous flow mode when
there are inlet and outlet in the
walls of reactor. Redrawn with
the permission of Elsevier from
Santos et al. (2020)
Inlet
Outlet
Cathode Anode
Magnetic stirring
Cathode Anode
Magnetic stirring
a b
1531Environmental Chemistry Letters (2024) 22:1521–1561
Rod
cathode
Porous
anode
Feed water
Permeate
c
a
outletinlet
anode cathode
e−e−
Anode Outlet
Gasket
b
Conductive tape
Cathode
BezelElectrolytic
cell
Bezel
Inlet
Inlet OutletAnode Cathode
d
R + H2O
RO + O2 H2
Anode
Cathode
Nafion
e
Fig. 5 Types of main flow cells: a traditional plate frame reactor
(adapted with the permission of MDPI from Liu et al. (2022)), e−—
electron, b filter press reactor (reprinted with the permission of Else-
vier from Zhang (2022)), c tubular reactor with tubular anode and
rod cathode (reprinted with the permission of MDPI from Skolot-
neva (2020)), d tubular reactor with electrodes placed perpendicu-
larly to the flux (reprinted with the permission of Elsevier from Wang
(2015)), e reactor with ion-exchange membrane, oxygen (O2), hydro-
gen (H2), water (H2O), organic pollutant (R), oxidized organic pollut-
ant (RO), Nafion—Nafion™ ion exchange membrane
Fig. 6 Types of flow modes: a
flow-through mode—current is
parallel to liquid flow, b flow-by
mode—current is perpendicular
to liquid flow, e − – electron.
Reprinted with the permission
of MDPI from Liu et al. (2022)
1532 Environmental Chemistry Letters (2024) 22:1521–1561
most common, but the placement of assembly of mesh or
porous electrodes perpendicular to the liquid flux (Fig. 5d)
is also possible. This type of reactor has fewer dead zones
and achieves the same output as a filter press reactor at a
smaller reactor volume. The drawback of tubular reactor is
its complexity regarding operating conditions compared to
ones described above.
Flow cells can be realized in two different configurations:
(i) flow-through, i.e., current is parallel to the liquid flow
(Fig. 6a) and (ii) flow-by, i.e., current is perpendicular to the
liquid flow (Fig. 6b). The use of flow-through cells is pre-
ferred because in this mode the mass transfer coefficient, km,
is 2–6 times higher than in flow-by mode (10−6–10−5 m  s−1
in flow-by mode and 10−5–10−4 m  s−1 in flow-through)
(Chaplin 2014). In addition, flowing the solution toward the
electrode can significantly reduce the thickness of the diffu-
sion layer, which decreases the diffusion length of organic
molecules and is therefore favorable for overcoming diffu-
sion limitations.
Flow cells with plate electrodes
Plate electrodes in a parallel configuration are the most often
used type of electrodes applied in anodic oxidation processes
(Cornejo et al. 2020). This is due to the simplicity of their
manufacturing. These electrodes can be fitted in all main
types of electrochemical cells. As it has been said above,
mixed-tank cell is the most used in anodic oxidation, and
many studies have been implemented with this cell in flow
mode (Pillai and Gupta 2015; Rivera et al. 2015a; Magro
et al. 2020; Monteil et al. 2021).
The plate electrodes are also used in plate frame and filter
press reactors. The commercial and well-studied reactor
FM01-LC (ICI Chemicals & Polymers Ltd, Electrochemical
Technology, Cheshire, UK) is broadly used in laboratory
investigations and as a pre-pilot plant of anodic oxidation
process (Butrón et al. 2007; Nava et al. 2007, 2014). Another
type of commercial cell applied for the anodic oxidation
process is DiaCell®, which is the cell with disk electrodes
(area 70 cm2) operated in flow-by mode (Chatzisymeon
et  al. 2009; Cano et  al. 2016; Gomez-Ruiz et  al. 2017;
Armijos-Alcocer et al. 2017). There are also many reports
of implementation of home-made plate frame and filter
press reactors (Costa et al. 2009; García et al. 2013; Degaki
et al. 2014; Farinos and Ruotolo 2017; Barbosa et al. 2018;
Ghazouani et  al. 2019). To improve mass transfer, the
turbulence promoters can be installed (Mascia et al. 2013).
The ion-exchange membrane can be implemented in plate
frame reactors to separate anode and cathode chambers and
to greatly increase the conductivity of the system. Home-
made reactors and commercial CabECO® cell were realized
in this configuration (Vasconcelos et al. 2016; Isidro et al.
2018, 2019; Mora-Gómez et al. 2020; Carrillo-Abad et al.
2020). The use of such cells seems promising in poorly con-
ducting solutions (Clematis and Panizza 2021).
Implementation of plate electrodes in tubular reactors
are rare due to the poor hydrodynamic properties of this
configuration. Nevertheless, there a few studies in which
plate electrodes are placed in tubular reactor perpendicularly
to the liquid flux (Brito et al. 2018; Ghazouani et al. 2020).
Regarding mass transfer characteristics and flow regime,
these are essentially round-shaped filter press reactors.
The most significant disadvantage of all cells with plate
electrodes is the mass transport limitations through the
diffusion layer thickness (δ). The thickness of the stationary
diffusion layer in electrochemical flow cells can reach
100 μm, depending on the velocity of the forced flow of the
solution, the length of the channel and the distance betweenthe electrodes. That is, the efficiency of the oxidation process
is highly dependent on the rate of diffusion of organic
pollutants through diffusion layer. The use of electrodes
with a large surface area only slightly increases the values
of the mass transfer coefficient, since the characteristics of
the surface roughness of the electrodes are smaller than the
diffusion layer thickness. The use of porous electrodes in a
flow-through configuration makes it possible to overcome
these diffusion limitations.
Flow cells with mesh electrodes
Mesh electrodes have an extended electroactive area than
plate electrodes and are suitable for use in a flow-through
configuration. They require less pressure drop for solution
pumping than porous electrodes, which corresponds to
lower energy consumption. These features make it possible
to produce mesh electrodes from cheaper materials with high
performance. Thus, there are several studies proved that the
performance of mesh electrodes made of cheaper material
under some conditions is compared with the one of plate
boron-doped diamond as they promote mass transfer (Degaki
et al. 2014; Nava et al. 2014; Farinos and Ruotolo 2017).
Mesh electrodes are mostly used in filter press and tubular
reactors (Nava et al. 2008, 2014; Skban Ibrahim et al. 2014;
Degaki et al. 2014; Wang et al. 2015; Vijayakumar et al.
2016; Xu et al. 2016; Farinos and Ruotolo 2017). Although
there are examples of mesh electrodes implementation in
mixed-tank cells operated in both bath and flow modes
(Santos et al. 2020; Hao et al. 2022), in tubular reactors
they usually form a tube and work together with the rode
cathode (Skban Ibrahim et al. 2014; Vijayakumar et al.
2016; Xu et al. 2016). However, there are configurations
in which mesh electrodes are placed perpendicularly to the
flux (Wang et al. 2015). It should be noted that boron-doped
diamond can be synthesized as a mesh, and this shape is
advised (Nava et al. 2008; Mascia et al. 2016).
1533Environmental Chemistry Letters (2024) 22:1521–1561
Flow cells with porous electrodes
Porous electrodes have a several of advantages over mesh
electrodes. They allow to combine separation and removing
of organic pollutants. And they have even a more developed
electroactive surface area, several times greater than the one
of mesh electrodes. The main drawback of porous electrodes
is fouling.
Porous electrodes can be fabricated in two main
shapes for implementation in different types of reactors.
They can be flat for installation in plate frame and filter
press reactors or tubular to form a tube of tubular reactor
(Vecitis et al. 2011; Gao et al. 2014; Li et al. 2016; Zhang
et al. 2016, 2022; Duan et al. 2016; Trellu et al. 2018b).
As the mass transport limitation through the diffusion
layer is the main problem that porous electrodes aim
to solve, pore size is the key parameter that determines
the efficiency of such electrodes. To overcome diffusion
limitations average pore size should be comparable or
less than the diffusion layer thickness (which is around
100 μm). However, it should bear in mind that the lower
the pore radius the lower permeability and the higher
pressure drop across the porous electrode is required
to pump the solution. Thus, the trade-off between short
diffusion distance and low permeability should be well
optimized.
Flow cells with particle electrodes
Particle electrodes are made up of many granules of
conductive material (carbon, metal, metal oxide) filling the
space between plate electrodes in traditional plate frame
reactor. Under applied electrical bias, these particles are
polarized and form a large number of microelectrodes. At
the same time, electrochemical reaction can occur at the
surface of each particle. Thus, particle electrodes have an
enhanced electroactive surface area and a short diffusion
length to the electrode surface, comparable to porous
electrodes. Moreover, as particle electrodes usually fill
the whole reactor volume the conductivity of the system
is increased which reduces the ohmic losses. Additional
advantage of using such electrodes is adsorption which
can increase the degradation efficiency due to the increase
in the concentration of pollutants on the electrode surface
(Ma et al. 2021).
Many materials were used as particle electrodes
for water treatment in recent years. The most common
ones are carbon-based materials (Sowmiya et al. 2016;
Alighardashi et  al. 2018; Mengelizadeh et  al. 2019).
Catalyst-loaded particles are also used (Yan et al. 2011;
Wang et al. 2019; Zhang et al. 2019). Recently, Ti4O7
particle electrode was first implemented (Kislyi et  al.
2023). They showed excellent removing efficiency closed
to 100%.
Particle electrodes can be used in two main cell
types: fixed bed and fluidized bed. In fixed bed reactor,
the particles do not move as the solution passes through
the cell, whereas in fluidized bed reactor the solution
flows upward and, therefore, the particles are constantly
moving and mixed. The hydrodynamic conditions in fixed
bed reactors are closed to the ones of porous electrodes,
while the mathematical description of flow pattern in
fluidized bed is much more complicated and requires more
computational resources.
Historical aspects
In this subsection, we briefly presented the main works in
the field of anodic oxidation, concerning the development of
ideas about this process, and the emergence of new materials
and models. Date-linked historical references provide a
sense of the path taken to the existing understanding of
this process, and a schematic representation (Fig. 7) helps
readers to consolidate the information.
• 1820s: Reinhold and Erman were among the first to use
electricity as an oxidizing or reducing agent (Piersma and
Gileadi 1966).
• 1830s: Ludersdorff investigated products obtained using
various electrodes for the oxidation of alcohol (Piersma
and Gileadi 1966).
• 1840s: Kolbe was the first to obtain ethane (CH3CH3)
by electrolysis of alkali acetates, which led to extensive
research on the electrolysis of aromatic hydrocarbons and
their derivatives (Piersma and Gileadi 1966).
• 1850s: Friedel, during the electrolytic oxidation of
acetone (CH3COCH3), found a mixture of formic, acetic
and carbonic acids (HCOOH, CH3COOH, H2CO3) with
the release of O2 and CO2 at the anode (Piersma and
Gileadi 1966).
• 1880s: The first anodic oxidation of benzene (C6H6) was
performed (Piersma and Gileadi 1966).
• 1900s: Many works concerning the electrolytic oxidation
of organic substances existed in early 1900. However,
most of the works did not fully cover the topic and were
chaotic (Law and Perkin 1905).
• 1900–1950s: The anodic oxidation of a species such
as CH3CH3, or many other organic species, has been
extensively studied (Bockris 1972).
• 1960s: There have been attempts to use electrogenerated
ozone (O3) for the treatment of municipal and industrial
wastewater and experiments have been carried out on the
anodic oxidation of various organic compounds: 1963—
anodic oxidation of triethylamine ((C2H5)3N) (used in the
production of mineral fertilizers, herbicides, medicines,
1534 Environmental Chemistry Letters (2024) 22:1521–1561
1535Environmental Chemistry Letters (2024) 22:1521–1561
paints) (Dapo and Mann 1963), 1964—anodic oxidation
of methanol (CH3OH) (Oxley et al. 1964), 1964—anodic
oxidation of CH3OH of triphenylmethane dyes (used
chiefly in copying papers, in hectograph and printing
inks, and in textile applications) (Galus and Adams 1964)
• 1970s: The improved methods of ozonation began to be
investigated, this made it possible to completely oxidize
refractory organic matter. Extensive investigation of
this technology commenced in the 70 s, when Nilsson
et  al. (1973) investigated the anodic oxidation of
phenolic compounds, Kuhn (1971)—anodic oxidation
of cyanide, Papouchado et  al. (1975)—anodic
oxidationpathways of phenolic compounds, Mieluch
et al. (1975)—electrochemical oxidation of phenolic
compounds in aqueous solutions.
• 1980s: The ozone/hydrogen peroxide (O3/H2O2)
system was investigated by Nakayama et al. (1979)
for wastewater treatment, and more recently by Brunet
and Dore (1984) and Duguet et  al. (1985). Duguet
and coauthors showed that the addition of peroxide
enhanced the efficiency of oxidation of several organic
substances, trihalomethane precursors, and also
increased the rate of O3 transfer. Kirk et al. (1985)—
anodic oxidation of aniline (C6H5NH2) for waste water
treatment. Sharifian and Kirk (1986)—electrochemical
oxidation of phenol (C6H5OH). Chettiar and Watkinson
(1983) studied the anodic oxidation of phenolics
found in coal conversion effluents. Glaze et al. (1987)
defined advanced oxidation processes as water
treatment processes. These processes are based on
the in situ generation of a powerful oxidizing agent,
such as ·OH, at a concentration sufficient to effectively
decontaminate waters. In the above studies, the
influence of the nature of the electrode material during
anodic mineralization of organics was studied in detail;
it was found that the optimal process conditions are
achieved at high-oxygen overpotential anodes.
• 1990s: The potential of electrochemical conversion or
destruction of organic substrates in wastewater remains
relevant in the 1990s (Kötz et al. 1991; Comninellis and
Pulgarin 1993; Comninellis 1994). 1991—Comninel-
lis studied the electrochemical oxidation of C6H5OH
for waste water treatment using a Pt anode (Comninel-
lis and Pulgarin 1991), and in 1994, he was the first to
propose an “active” electrode mechanism for organic
oxidation (Comninellis 1994). First mathematical mod-
els of anodic oxidation processes were proposed in the
following works (Simond and Comninellis 1997; Simond
et al. 1997; Cañizares et al. 1999; Chen et al. 1999). Beck
et al. (1998) and Fisher et al. (1998) investigated a new
electrode material with very promising characteristics: It
consists of a silicon support coated by a layer of synthetic
diamond, heavily doped with boron (B) to obtain accept-
able electrical conductivity. Chen et al. (1999) found
that Ebonex® porous ceramics (Ti4O7) is applicable for
anodic oxidation of trichloroethylene (ClCH꞊CCl2). Fur-
ther, this material was very popular in the field of anodic
oxidation.
• 2000s–2010s: The boron-doped diamond and Ti4O7
were recognized as the most promising materials for the
anodic oxidation process. The decade was plenty by the
different models of anodic oxidation (Rodrigo et al. 2001;
Panizza et al. 2001a; Cañizares et al. 2002, 2003; Xu
2016) with numerical (Mascia et al. 2007, 2012; Panizza
et al. 2008; Kapałka et al. 2009; Polcaro et al. 2009;
Donaghue and Chaplin 2013) and analytical solutions
(Panizza et al. 2001a; Kapałka et al. 2008). Most of them
are considered in the following sections.
• 2020s: Two interesting mathematical models were
presented by Misal et al. (2020) for anodic oxidation
system with porous electrode and by Monteil et  al.
(2021) for flow cells with plate electrodes in serial mode.
Ma et al. (2023a, b) developed a 3D-printed electrode
made of TinO2n−1. This is the starting point for the new
development of anodic oxidation.
General equations used for anodic oxidation
modeling
Material balance law
The fundamental equation used in almost all models
described below is the material balance law (Eq. 25). This
equation allows to relate the change in the concentration of
a chemical compound over time to its causes: emergence
or escape of a substance from a volume as a result of the
incoming fluxes of this substance (the first term) and the
formation or decomposition of this substance in a reaction
(the second term).
here c is the concentration, t is the time, j is the flux density,
and R is the reactive term.
Equation (25) can be applied to describe the change in
concentrations of all substances present in the solution:
target component, by-products, and reactive oxygen species.
If one writes down this equation for each considering
compound, one obtains a system of equations related only
by reaction terms. The more precisely the reactions are
(25)
�c
�t
= −∇j + R
Fig. 7 Development of anodic oxidation of organic pollutants,
 TinO2n−1 (Magnéli phases of sub-stoichiometric titanium oxides). The
progression in mathematical modeling in this area began in the late
1990s
◂
1536 Environmental Chemistry Letters (2024) 22:1521–1561
described, the more accurately the relationship between
the concentrations of all components of the system can be
investigated. However, increasing the number of reactions
and considering more components significantly complicates
the mathematical problem. For simplification, usually only
the most important components of the system are considered:
the target organic compound and reactive species, while
by-products are excluded from consideration. The influence
of by-products mineralization on the performance can be
taken into account applying lamped constant (Kapałka et al.
2009; Trellu et al. 2016; Ma et al. 2023a).
Flux density equations
To calculate the first summand of Eq. (25), it is necessary
to know the equation for the flux density. For this case,
there are several options, the choice of which depends on
the physical properties of simulated system and the aim of
the model: Fick's law, the Nernst-Planck equation and the
use of the mass transfer coefficient.
Most often, the first Fick's law is used to describe the flux
density (Eq. 26). This equation gives an expression for the
diffusion flux of matter and does not consider the migration
and convection components of mass transfer. Indeed, in
most cases for the simulation of anodic oxidation process
the consideration of migration is redundant. A background
electrolyte is added to reduce the resistance of the solution,
and the transport number of the target organic compound
(as well as by-products, and many uncharged radicals) is
often negligible compared to the transport number of the
background electrolyte (Bard and Faulkner 2001).
here j is the flux density, D is the diffusion coefficient of the
compound, c is the concentration.
Some researchers attempt to consider the convection
using Fick's equation with a convective term (Eq. 27)
(Rivero et al. 2018; Skolotneva et al. 2020). However,
this greatly complicates the mathematical problem as
it becomes necessary to determine the velocity field,
which is often difficult as hydrodynamics calculations are
required.
here j is the flux density, D is the diffusion coefficient of the
compound, c is the concentration, and u is the linear fluid
velocity.
In cases where the considered compound is charged
organics or radical is charged, and no background
electrolyte is used, migration cannot be neglected and the
Nernst-Planck equation should be used to describe the flux
density (Eq. 28) (Geng and Chen 2016):
(26)j = −D∇c
(27)j = −D∇c + cu
here j is the flux density, D is the diffusion coefficient of the
compound, c is the concentration, z is the charge, F is the
Faraday’s constant, R is the universal gas constant, T is the
temperature, φ is the electric potential.
Most researchers simplify the problem of convection
accounting by using an equation containing the mass
transfer coefficient to describe the flux density (Eq. 29)
(Gherardini et al. 2001; Cañizares et al. 2003; Lan et al.
2018; Monteil et al. 2021). The mass transfer coefficient
provides of proportionality between the flux density
and the difference in the concentration of substance
in the zones between which transfer occurs, and thus,
it reflects the co-transport of matter by diffusion and
convection (in contrast to Eq. (27)). This constant can
be measured in an independent experiment using a
standardized ferrocyanide-ferricyanide limiting current
method (Cañizareset al. 2006). There disadvantages of
this approach are obvious: (i) The mass transfer coefficient
depends on each experimental setup; (ii) it is impossible
to distinguish the influence of diffusion and convection.
Nevertheless, this approach can be justified especially
in cases when the process under kinetic limitations is
modeled.
here j is the flux density, km is the mass transfer coefficient,
cb is the bulk concentration, and cs is the concentration on
the electrode surface.
Electrochemical and chemical reactions
There are two types of reactions in anodic oxidation
processes: chemical and electrochemical reactions.
Electrochemical reactions are those occurring directly
on the electrode surface: formation of reactive oxygen
species, oxidation of organics by direct electron transfer
and formation of gases. Chemical reactions are oxidation
reactions of organic molecules by radicals in solution within
the reaction zone.
To model electrochemical reactions, Faraday's
fundamental law is applied. It relates the current density
and the flux of reactants or products of the reaction that
allow this current to flow (Eq. 30).
here j is the flux density, i is the current density, z is the
charge, and F is the Faraday’s constant.
(28)j = −D(∇c + zc
F
RT
∇�)
(29)j = −km(cb − cs)
(30)j = −
i
zF
1537Environmental Chemistry Letters (2024) 22:1521–1561
When describing the anodic oxidation process, it is often
sufficient to apply only Faraday's law, since the reactions in
many cases occur under mass transfer limitation, and thus
the reaction rate can be considered as infinite. Nevertheless,
with this approach one has to make the assumption that only
one electrochemical reaction takes place, or the reactions
occur sequentially, otherwise, the current density distribu-
tion between different reactions has to be calculated which
requires the application of additional equations. The advan-
tage of this approach is the simplicity of the mathematical
model; the disadvantage is the inability to take into account
the properties of the electrode material.
To model several reactions occurring in parallel or to
describe the kinetics in the process performed under current
control, the Butler-Volmer equation is used (Eq. 31) (Bard
and Faulkner 2001). This equation relates the rate of a
chemical reaction to the electrode potential. It reflects the
properties of electrode material by kinetic parameters: an
exchange current density and electron transfer coefficient.
Nevertheless, the application of this equation complicates
the mathematical problem, and the kinetic parameters are
often difficult to determine experimentally, therefore, they
become fitting parameters of the model.
here i is the current intensity, i0 is the exchange current
density, C0 and CR are the concentrations of cathodic and
anodic reactants, respectively, Α is the electron transfer
coefficient, ηc and ηa are overpotentials of cathodic and
anodic reactions, respectively, F is the Faraday’s constant,
R is the universal gas constant, and T is the temperature.
Chemical reactions in the anodic oxidation process are
most often modeled as pseudo-first-order reactions (Pol-
caro et al. 1999; Ghazouani et al. 2016, 2020). It is assumed
that the concentration of oxidizing species is so large that
it does not significantly change during the reaction and can
be included in the reaction rate constant. The study of the
concentration distribution of the oxidizing species near the
electrode surface or the modeling of competitive phenom-
ena occurring during the oxidation of several components
requires the application of a second-order reaction model
(Kapałka et al. 2009; Donaghue and Chaplin 2013; Groenen-
Serrano et al. 2013).
Simulation of the flow pattern
The hydrodynamic regime strongly has a huge impact on
the efficiency of the electrochemical system as it determines
the mass transfer coefficient, which in turn significantly
affects the performance of the anodic oxidation system.
For example, velocity field obtained from the fluid
(31)i = i0
[
CO exp
(
−AF�c
RT
)
− CR exp
(
(1 − A)F�a
RT
)]
dynamics modeling can be inserted in a convection term of
Nernst-Plank equation (Eq. 32). Here a brief overview of
approaches to modeling hydrodynamics in anodic oxidation
systems will be presented; for a more complete and detailed
understanding, the reader is referred to the following papers
(Frías-Ferrer et al. 2011; Rivera et al. 2015b, 2021; Zhou
et al. 2018; Catañeda et al. 2019).
It should be noted here that in most models of anodic
oxidation the fluid dynamics are not simulated. To
describe related mass transport, researchers use empirical
characterization technics such as mass transport coefficient
(Eq.  33) or classical models of ideal reactors such as
continuous stirred tank reactor or plug flow reactor model
(Cañizares et al. 2002, 2004; Polcaro et al. 2009). In latter
case, to characterize the deviation of flow from ideal plug
flow behavior the residence time distribution curves are
usually obtained from experiment and dispersed plug flow
model is applied (Eq. 31) (Bengoa et al. 2000; Mascia et al.
2012, 2016). Sometimes the dependence of mass transport
on hydrodynamics is described using the well-known
dimensionless group correlation (Reynolds (Re), Sherwood
(Sh) and Smidt (Sc) numbers) (Eq. 33) (Nava et al. 2007;
Cruz-Díaz et al. 2018).
here C = ctp/ctp
0 is the dimensionless tracer particles
concentration, ctp is the tracer particles concentration, ctp
0
is the initial tracer particles concentration, Pe is the Peclet
number which describes flow dispersion, θ = tsuint/Lx is the
dimensionless time, uint is the interstitial liquid velocity,
ts is the special time, Lx is the axial length, Xl = x/Lx is
dimensionless axial length, x is the axis coordinate along
the reactor length, and a, b and c are constants found from
experimental data (Rivera et al. 2010).
Computational fluid dynamics is a powerful technic to
obtain precise fluid flow distribution and velocity field in
a reactor volume. It applies different numerical methods
(mostly volume element and finite element methods) to
solve fundamental transport equations within the simulated
domain. The most complete description of the velocity field
is given by the fundamental governing law of fluid motion—
Navier–Stokes equations (Eqs. 34–35) (Łukaszewicz and
Kalita 2016). However, other equations could be applied,
for example, the Darcy’s law, describing the liquid flow into
the porous matter (Mareev et al. 2021).
(32)
�C
��
=
1
Pe
�
2C
�X2
l
−
�C
�Xl
(33)Sh = aRebScc
(34)
�u
�t
+ (u ⋅ ∇)u = −
1
�
∇p +
�
�
Δu + f
1538 Environmental Chemistry Letters (2024) 22:1521–1561
here u is the linear fluid velocity, t is the time, ρ is the liquid
density, p is the applied pressure, μ is the dynamic viscosity
and f is the volume force.
Modeling of anodic oxidation with plate
electrodes
Plate electrodes are the most common in the anodic oxidation
due to their simple implementation. It is convenient to use
them in batch mode of oxidation processes. Nowadays,
one of the best “non-active” electrodes is the boron-doped
diamond, which is usually plate. Thus, most of the models
refer to anodic oxidation systems with plate electrodes.
Table 1 presents the classification of models of anodic
oxidation on plate electrodes proposed by authors and key
parameters of each group of models. These models and their
example are described in detail in following sections.
Kinetic models
First group of models that we propose to classify as “kinetic
models.” They are based on the material balance equations
that describe the kinetics of several chemical reactions, but
do not consider in any way the mass transfer mechanisms;
such models allow obtaining the reaction rate constants from
the time dependence of the concentration of the components
in the system. In addition, they make it possibleto take into
account the appearance of by-products during the conversion
of organics into CO2, H2O and other inorganic compounds.
(35)div u = 0
Probably, the first kinetic model was proposed by
Comninellis (1994). This straightforward model utilizes only
kinetic relations and allows calculating of the instantaneous
current efficiency of electrochemical oxidation taking into
account the oxygen evolution reaction. The equation for the
calculation of instantaneous current efficiency is presented
as the ratio of the target organic oxidation reaction rate to the
sum of the rates of this reaction and oxygen evolution reac-
tion. Obtained dependencies for the instantaneous current
efficiency show that in the case of active anodes, it is inde-
pendent of the anode potential, and in the case of non-active
anodes, the potential affects the instantaneous current effi-
ciency. Also, for all anode types, the instantaneous current
efficiency depends on the nature of the organic compound,
its concentration and the anode material.
Popović and Johnson (1998) developed a simple
mathematical model that can describe the total current
resulting from competitive reactions of the anodic
O-transfer and oxygen evolution. At the stage of the
problem formulation, oxygen adsorption on the electrode
surface was taken into account. A simple equation for the
half-wave potential is also derived. This model allows to
build the current–voltage characteristics of the system. A
good comparison between the experimental and theoretical
data confirms the assumptions made in the problem
formulation (anodic discharge of H2O is the prerequisite
for oxidation of the studied organic compound by the
O-transfer mechanism). The next work of these authors
improved this model tacking into account the reactant
adsorption (Popović et al. 1998).
The most used model belonging to this group is the
pseudo-first-order kinetic model (Fig. 8) (Cañizares et al.
1999; Polcaro et al. 1999; Ghazouani et al. 2016, 2020;
Trellu et al. 2016). This model assumes that the concen-
tration of radicals is high enough to make them unrestrict-
edly available for the reaction with molecules of organic
compounds and to assume that their concentration does not
change during the oxidation process, so the rate of chemical
reaction does not depend on their concentration. It should be
noted that Fig. 8 represents only the most general case of the
pseudo-first-order model. For example, each compound, Ri,
can be formed and/or removed in several parallel chemical
reactions and then the number of terms in the right-hand
side of the material balance equation for this component
will obviously equal the number of corresponding reac-
tions. With the pseudo-first-order model, it is also possible
to describe the adsorption process.
Cañizares et al. (1999) proposed a simple nonstationary
mathematical model of electrooxidation of C6H5OH
considering the three reaction pathways at the active sites
of the anodes: direct degradation or electrochemical cold
combustion, chemical oxidation, and polymerization.
This model allows evaluation of the influence of current
Table 1 Key parameters of models of anodic oxidation on plate elec-
trodes
Model type Key parameters
Kinetic models Chemical reactions rate constants
Two-mode models Initial concentration of organic compound
Mass transfer coefficient
Electrode surface area
Applied current density
Multy-zone models Diffusion layer thickness (as reaction zone
thickness is assumed to be equal to it)
Applied current density
Chemical reactions rate constants
Mass transfer coefficient
Diffusion-kinetic models Diffusion layer thickness
Diffusion coefficients
Applied current density
Initial concentration of organic compound
Chemical reactions rate constants
1539Environmental Chemistry Letters (2024) 22:1521–1561
intensity on the process and predicts the time dependencies
of concentration, Faradic efficiency and electrochemical
oxidation index. This study shows that kinetic constants
increase with the current intensity, the fraction of C6H5OH
processed by the direct oxidation pathway is approximately
constant and independent of the current intensity, and the
electrochemical oxidation index decreases with the current
intensity increase.
Polcaro et al. (1999) investigated the electrochemical
oxidation of chlorophenol on a plate anode and used a
kinetic time-dependent model similar to that presented
in the previous paragraph, which also takes into account
the degradation of intermediates (Cañizares et al. 1999).
The model is based on a system of three linear differential
equations of the material balance, which allows to obtain
a simple analytical solution. An analysis of the reaction
constants determined using the model by fitting the
theoretical and experimental data makes it possible to reveal
limiting chemical reactions at different anodes: The rate of
a ring-opening reaction to form aliphatic acids is an order
of magnitude higher in the case of Ti/SnO2 compared to Ti/
PbO2.
Similar models are also used in another papers by Ghaz-
ouani et al. (2016, 2020) and Trellu et al. (2016) to describe
the reduction of nitrates and the oxidation or reduction of
their by-products in the presence and absence of chloride
ions (Cl−) (Ghazouani et al. 2016) and also the combination
of electrocoagulation and anodic oxidation for the simul-
taneous removal of nitrates and phosphates, and the humic
acids mineralization on the boron-doped diamond anode
surface (Trellu et al. 2016; Ghazouani et al. 2020).
The main disadvantage of these studies is the huge
amount of fitting parameters. Furthermore, the rate constants
defined by such an approach could not be considered
reliable and independent experiments are required for their
accurate determination. However, such models allow a
better understanding of the mechanisms involved and the
related kinetics. They are more often used as “auxiliary”
ones and cannot help the researcher to determine the optimal
parameters of the oxidation process or the influence of
various factors on the process.
Two‑mode models
Such models consider two different operating regimes
(current control and mass transfer control); using some
assumptions, it is easy to obtain an analytical expression
for the dependence of the concentration of the oxidized
compound on time, the hydrodynamic parameters of the
system (using the mass transfer coefficient), the applied
current density and the electrical current consumption.
The earliest description of a two-mode model was pro-
posed by Simond et al. (1997). In his study, the model takes
into account the electrochemical oxidation of organic com-
pounds and oxygen evolution reaction at the active anode.
Two different cases are considered: negligible concentration
polarization, i.e., current control and significant concentra-
tion polarization, i.e., mass transfer control. The model
Fig. 8 General representation
of pseudo first-order kinetic
model. It assumes that the rate
of each reaction depends only
on the concentration of organic
compound. Material balance
equation is written for each
considered component (Ri) of
the system. Rate constants (ki),
hydroxyl radicals (·OH), e−
(electron)
Pseudo first-order kinetic model
products
Mineralization pathway
[ ]1
1 1
= −
d R
k R
dt
[ ]2
2 2 1 1
= − +
d R
k R k R
dt
[ ]
1 1− −= − +n
n n n n
d R
k R k R
dt
1 2
, ,.., −nk k k fitting parameters....
Material balance equations:
1
k
1
R
/OH e⋅ −− 2
R 2
k
/OH e⋅ −− 3
R nk
/OH e⋅ −−.... nR
1540 Environmental Chemistry Letters (2024) 22:1521–1561
consists of simple equations giving the current efficiency as
in the pioneering work of Comninellis (1994), but it takes
into account the surface coverage of higher oxide, its satu-
ration concentration and the mass transfer coefficient in the
case of significant concentration polarization. This model
allows obtaining the ratio ofthe rate constants of the organic
species oxidation and the oxygen evolution reaction, i.e.,
the correlation between the reactivity of the organic to be
oxidized and the nature of redox couple on the anode. The
authors proposed the dimensionless parameter, ϕ, expressing
the ratio between the chemical reaction rate and the mass
transfer coefficient, km, and the effectiveness factor, ε, evalu-
ating how much the current efficiency decreases as a result
of concentration polarization. The expression obtained in
this study shows that the surface coverage of higher oxide
increases linearly with the applied current and depends on
the morphology of the anode. This model was experimen-
tally validated by Simond and Comninellis (1997).
Panizza et al. (2001a) proposed a model, which allows
obtaining the time dependence of chemical oxygen demand
and instantaneous current efficiency during the electrochem-
ical oxidation of organic pollutants in a batch recirculation
system. The main assumption of this model is that the rate
of the electrochemical combustion of the organic compounds
by generated ·OH radicals and/or direct electron transfer is
a fast reaction and is controlled by mass transport of the
organic compounds toward the anode. Using this assump-
tion and some others, mass balance law and Faraday’s law
analytical expressions for temporal trends of chemical oxy-
gen demand are obtained (Tables 2, 3). Two main modes
of the electrolysis process under galvanostatic conditions
were introduced in this work: the first, iappl < ilim, where the
process is under current control, instantaneous current effi-
ciency is 100% and the chemical oxygen demand decrease
linearly with time: the second, iappl > ilim, where the pro-
cess is under mass transport control, secondary reactions,
i.e., oxygen evolution, commence, resulting in instantane-
ous current efficiency < 100% followed by a decrease, and
the chemical oxygen demand also decreases exponentially
(Fig. 9). The model shows that an increase in the current
density at the same initial concentration of organics leads to
a decrease in the current efficiency due to an increase in the
fraction of the current consumed for the oxygen evolution
reaction, while the temperature has a negligible effect on the
process efficiency.
In the series of works by Gherardini et al. (2001), Rodrigo
et al. (2001) and Iniesta et al. (2001b, a), this model was
experimentally validated and was successfully applied with-
out any moderation in the later work of Fierro et al. (2009).
It should be noted that in the study of Gherardini et al.
(2001) a new parameter, the normalized current efficiency,
Table 2 Equations for the calculation of critical values describing the
transition from the current control to the mass transport control
tcr—critical time (s), α = iappl/ilim0, iappl—applied current density (A
 m−2), ilim0—initial limiting current density (A m−2), VR—reservoir
volume (m3), A—electrode area (m2), km—mass transfer coefficient
(in the electrochemical reactor) (m s−1), Xcr—critical conversion,
Qcr—critical specific charge (Ah m−3), 4—number of exchanged
electrons per mol of O2, F—Faraday’s constant (C mol−1), COD0—
initial chemical oxygen demand (mol O2 m−3)
Parameter Equation
Critical time (s) tcr =
1−�
�
VR
Akm
Critical conversion Xcr = 1 − �
Critical specific charge (Ah m−3) Qcr = i0
lim
(1−�)
km3600
=
4FCOD0(1−�)
3600
Table 3 Equations that describe
parameters evolution during
organics oxidation at boron-
doped diamond electrode
ICE—instantaneous current efficiency (%), A—electrode area (m2), km—mass transfer coefficient (in the
electrochemical reactor) (m s−1), VR—reservoir volume (m3), α = iappl/ilim0, iappl—applied current density
(A m−2), ilim0—initial limiting current density (A m−2), COD—chemical oxygen demand (mol O2 m−3),
t—time (s), COD0—initial chemical oxygen demand (mol O2 m−3), τ—electrolysis time (s), X—COD
conversion, V—volume of electrolyte (dm3), tcr—critical time (s), Esp—specific energy consumption
(kW h kg COD−1), F—Faraday’s constant (C mol−1), 8—equivalent mass of O2, Vd—potential of water
decomposition, Rc—electrolyte ohmic resistance (Ω), Areq—required electrode area (m2), 4—number of
exchanged electrons per mol of O2, P—given loading (mol COD s−1). Adapted from Panizza et al. (2008)
Parameter Under current limited control (iappl < ilim) Under mass transport control (iappl > ilim)
ICE ICE = 1 ICE = exp
(
−
Akm
VR
t +
1−�
�
)
COD COD(t) = COD0
(
1 −
�Akm
VR
t
)
COD(t) = �COD0 exp
(
−
Akm
VR
t +
1−�
�
)
τ � =
XV
�Akm
τ = tcr −
V
Akm
[
ln
(
1−X
α
)]
= −
V
Akm
[
ln
(
1−X
α
)
−
1−α
α
]
Esp Esp =
1
3600
F
8
(
Vd + RcA�i
0
lim
)
Esp =
1
3600
F
8
(
Vd + RcA�i
0
lim
) 1−α[1+ln(1−X∕α)]
X
Areq Areq = 4F
XP
�i0
lim
Areq =
4FP
�i0
lim
{
1 − �
[
1 + ln
(
1−X
�
)]}
1541Environmental Chemistry Letters (2024) 22:1521–1561
φ, is introduced. This parameter can be defined as the ability
of the anode to promote the electro-oxidation and to reduce
the side reaction of oxygen evolution. Starting from the
model described above by Panizza et al. (2001b), a model
was developed to predict the specific energy consumption
and the required electrode active area for the electrochemical
oxidation of organic compounds on boron-doped diamond
anode. The authors showed that an increase in conversion
leads to an increase in both required electrode area and
specific energy consumption, and an optimization problem
exists, also, the relative importance of these two quantities
must be taken into account for each situation. Kapałka et al.
(2008) summarize the research carried out starting from the
model by Panizza et al. (2001a) on the electrochemical oxi-
dation of organic pollutants for wastewater treatment since
the end of the 1990s. This paper proposes to use an operat-
ing mode to maximize the efficiency of the process in which
the applied current density constantly approaches the limit
value, but does not reach it. Later work of Panizza et al.
(2008) applies the formulated above model to multiple cur-
rent steps electrolysis and to semi-continuous current control
electrolysis and shows that this approach allows obtaining
the 100% process efficiency.
Lan et al. (2018) have extended the model of Panizza
et al. (2001a) by taking into account two possible ways of
oxidation: the direct electron transfer and the oxidation via
·OH. They assumed that the reaction of ·OH generation
occurs only when the applied current density, iappl, is higher
than the limiting current density of direct electron transfer,
ilim,ne−. They also introduced into consideration the initial
limiting current density, i·OH, corresponding to the total
mineralization of organic compounds. This permitted them
to distinguish three regimes of oxidation: (1) iappl ≤ ilim,ne−;
(2) ilim,ne− < iappl < i·OH; (3) iappl > i·OH The developed model
has been implemented for the investigation of the salt effect,
i.e., the oxidation of organic compounds by electrogenerated
oxidizing species from the salt. This model allows an
evaluation of different oxidation pathways: direct electron
transfer, reaction with ·OH or with strong electrogenerated
oxidants.
The work of Monteil et al. (2021) can be attributed to
this group of models. The authors have investigated a new
4
= appl
cr
m
i
COD
Fk
0( ) 1 = −α 
 
m
R
AkCOD t COD t
V
3
2(mol O m )COD −
0
1( ) exp −α = α − + α 
m
R
AkCOD t COD t
V
1exp −α = − + α 
m
R
AkICE t
V
( )t h
( )t h
crt
(%)ICE
Zone A Zone Ba
b
Fig. 9 a Typical evolution of chemical oxygen demand (COD) and
b instantaneous current efficiency (ICE) as a function of time. Zone
A—under the kinetics control COD decreases linearly while the ICE
value remains constant at 100%. This is because mass transfer is fast
enough to ensure a high concentration at the electrode surface, hence,
the CODremoval rate is determined by the oxidation reaction rate
which is constant at a given applied current; ICE is constant because
all applied current is consumed by the organic oxidation reaction.
Zone B—under the mass transfer control both COD and ICE decrease
exponentially. In these conditions, the rate of concentration decrease
at the electrode surface is higher than the mass transfer of the sub-
stance from the solution, hence, COD removal rate is determined by
the mass transfer coefficient, km, which constantly decreases; ICE is
reduced because not all of the applied current is consumed by the
organic oxidation reaction. COD0—initial chemical oxygen demand
(mol O2 m−3), t—time (s), A—electrode area (m2), km—mass transfer
coefficient (in the electrochemical reactor) (m s−1), VR—reservoir vol-
ume (m3), α = iappl/ilim0, iappl—applied current density (A m−2), ilim0—
initial limiting current density (A m−2), CODcr—critical COD value
at which the transition from current control to mass transport control
occurs, tcr -critical time at wich the transition from current control to
mass transport control occurs. Redrawn with the permission of ACS
Publications from Panizza and Cerisola (2009)
1542 Environmental Chemistry Letters (2024) 22:1521–1561
continuous flow electrochemical reactor with boron-doped
diamond anode and carbon felt cathode. They used a simple
model similar to the one described above, i.e., the authors
derived the equations representing the anodic oxidation rate
for two modes of operation, current control and mass transfer
control, and substituted them into the mass balance law but
they do not solve this problem analytically. Instead of this,
they combined the kinetic model with the hydrodynamic
one. For the modeling of hydrodynamics, two approaches
were used: the dispersed plug flow reactor model and the
model of continuous stirred tank reactors in series with dead
zone. The latter was chosen for the combination with the
kinetic model. The model has only one fitting parameter—
the mass transfer coefficient and the solution is obtained
numerically. The experimental data and the theoretical ones
have a good agreement. However, the authors emphasize that
the model needs to be improved by considering mediated
electrochemical oxidation and by improving the description
of mass transfer phenomena.
To summarize all of the above, it should be clarified again
that these models provide simple analytical expressions for
modeling the oxidation of organic pollutants under mass
transfer limitations. This simplicity is achieved by assuming
that the oxidation reaction of organic compounds by ·OH is
much faster than the oxygen evolution reaction. However,
there is experimental evidence to refute this. Adams et al.
(2009) showed that the composition of oxygen-evolving
anodes can influence the kinetics of oxidation of organic
pollutants even when the applied current density is much
higher than the limiting current. In the experimental work
of Fierro et al. (2009), it is shown that at currents below the
limit current, the oxidation reaction of organics proceeds
in parallel with the oxygen evolution reaction. These
observations once again confirm that the assumption of a
much higher rate of oxidation of organic compounds than
the rate of the oxygen extraction reaction is not always valid.
Nevertheless, for boron-doped diamond electrodes such
models can be applied successfully.
Multi‑zone models
Multi-zone modeling approach divides the system under
study into two or three zones: one or two electrochemical
zones close to electrodes where ·OH (or other oxidating
radicals) exist and where oxidation/reduction takes place
and bulk zone where there is no radicals and the chemi-
cal reaction there can be neglected. The models are based
on the material balance equation, which is written for each
component within each zone separately; it is often assumed
that concentration within one zone is spatially independent
and changes only over the time (Fig. 10) (Table 4).
Cañizares et al. (2002, 2003) were the first who presented
a multi-zone model to describe the oxidation of phenol and
carboxylic acids on the boron-doped diamond electrode.
Two zones were considered: the electrochemical zone, i.e.,
the thickness of which is equal to the diffusion layer thick-
ness and was measured experimentally, and the bulk zone. In
both zones, the concentration of each compound is consid-
ered to be only time dependent and constant at any position
of the zone. The authors assume that this approximation
is valid if the residence time in the electrochemical cell is
small and the concentration profiles in the flow direction are
negligible. In the bulk zone, the concentration is the same as
the concentration measured experimentally. In the reaction
zone, the concentration has a value between the concentra-
tion at the anode surface (which cannot be measured) and
the concentration in the bulk zone. Mass transport processes
between both zones were quantified by assuming that the
local rate of exchange between reaction and bulk zones is
proportional to the concentration difference in these two
zones. For modeling the kinetics in the reaction zone, the
following equation is used:
in which ri is the oxidation of each compound, i, in the
reaction zone, r·OH is the OH generation rate (assumed to
be r·OH = i/F, i is the current intensity (A), F is the Faraday’s
constant), is multiplied by the instantaneous current
efficiency (ICE) to give the amount of ·OH that oxidizes
organics and by θi to determine the quantity of ·OH that
attacks organics. The parameter θi represents the oxidation
efficiency and depends on the organic composition and the
operating conditions.
In this model, it is a fitting parameter. In the literature, a
similar parameter can be found, but its value is related only
to the electrode properties (Gherardini et al. 2001). The reac-
tions in the bulk zone are neglected. For each compound in
each zone, the material balance equation is applied.
This model gives a good agreement with experimental
data, and the only adjustable parameters are the oxidizability
factors for the different organic compounds. Cañizares et al.
(2004) presented a modification of the model described
above, in which three zones are considered and a new
approach to reactivity description is introduced. The main
innovation in this article is the estimation of the electrical
current fraction going to each reaction. It is assumed that
the difference between the cell potential, ΔVwork, and the
oxidation or reduction potential, Vi, is the driving force
occurring due to the distribution of electrons. Thus, the
fraction of current directed to each reaction can be calculated
using the following equation:
(36)ri = k
⋅OH(ICE)�i
(37)�i =
�
ΔVwork − ΔVi
�
∑
i
�
ΔVwork − ΔVi
�
1543Environmental Chemistry Letters (2024) 22:1521–1561
here αi is the proportion of electrons involved in a particular
electrochemical process corresponds to each process, i,
ΔVwork is the cell potential and ΔVi is the oxidation potential
of each process i.
Theoretical data obtained using this model are in good
agreement with experimental ones, which confirms that the
proposed assumptions are consistent for the formulation of
the problem.
Polcaro et al. (2009) present a simple stationary math-
ematical model of Cl−, ClO3
− and Cl2 transport in an elec-
trolysis system. The presence and transport of organic pol-
lutants were not considered. All three zones are represented
as perfectly stirred reactors. The main feature of this model
is its simplicity (the resulting equation system consists of
six algebraic equations). This model takes into account the
convective transfer of system components and allows us to
calculate the faradaic yield as well as the concentration of
 Cl2 derivatives in a permeate solution.
The multi-zone models are easy to use and allowpredict-
ing the concentration of system components at the outlet of
the electrolyzer and determining of optimal parameters of
the system. The main disadvantage of such models is the
oversimplification of the reaction mechanisms and mass
transport in diffusion layers.
Diffusion‑kinetic models
Diffusion-kinetic models are also based on the material bal-
ance equation that takes into account the diffusion of organic
pollutants inside the reaction zone and the kinetics of sev-
eral chemical or electrochemical reactions (Table 5). These
models allow to calculate the reaction zone thickness and
describe the mass transfer limitations (Fig. 11).
Probably, Mascia et al. (2007) were the first to present the
time-dependent diffusion-kinetic model of anodic oxidation.
Fick’s second law in differential form with chemical reaction
Fig. 10 Three zones model.
The system is divided into three
zones according to the presence/
absence of the oxidizing radical
and, thus, depending on the
presence/absence of chemical
reaction. Each zone (cathodic
and anodic reaction zones and
chemical reaction zone) is
presented as continuous stirred-
tank reactor. All reactors are
interconnected by mass transfer
equation, km—mass transfer
coefficient
stirrer stirrer
stirrer
km km
Cathodic
reaction zone
Chemical reaction zone
Anodic reaction
zone
Feed
solution
Treated
solution
Table 4 Three-zone models
Ci—concentration of the ith species (mol m−3), Ri—reactive term (mol m−3  s−1), t—time (s), dreac—reaction zone thickness (m), δ (exp)—
diffusion layer thickness obtained from the experiment (m), ·OH—hydroxyl radicals, r·OH –·OH generation rate, i—current intensity (A), F—
Faraday’s constant (C mol−1), ri—oxidation of each compound i, in the reaction zone, ICE—instantaneous current efficiency (%), θi—parameter
represents the oxidation efficiency, ii—current density spent on ith electrochemical reaction, αi—proportion of electrons involved in a particular
electrochemical process corresponds to each process i, ΔVwork—cell potential, ΔVi—oxidation potential of each process i, εi—faradaic yield of
each process i
Cañizares et al. (2002, 2003) Cañizares et al. (2004) Polcaro et al. (2009)
Equation on which model is based Mass balance law:�Ci
�t
= Ri
Relation between zones Mass transfer equation
Reaction zone thickness dreac = �(exp)
Zones, considered as stirred-tank reactors All zones
Electrode reactions r
⋅OH =
i
F
ii = �i
i
F
,
�i =
(ΔVwork−ΔVi)
∑
i
(ΔVwork−ΔVi)
ii = �i
i
F
,
Chemical reactions ri = k
⋅OHICE�i, Second-order rate First-order rate
1544 Environmental Chemistry Letters (2024) 22:1521–1561
Ta
bl
e
5
 C
om
pa
ris
on
 o
f d
iff
us
io
n-
ki
ne
tic
 m
od
el
s
C
—
co
nc
en
tra
tio
n
(m
ol
  m
−
2 ),
t—
tim
e
(s
),
J—
flu
x
(m
ol
 m
−
2   s−
1 ),
R—
re
ac
tiv
e
te
rm
 (m
ol
  m
−
3   s−
1 ),
O
ER
—
O
xy
ge
n
ev
ol
ut
io
n
re
ac
tio
n,
 C
lO
3·—
ch
lo
ra
te
, C
lO
4−
—
pe
rc
hl
or
at
e,
 x
—
di
st
an
ce
 (m
),
δ—
di
ffu
si
on
 la
ye
r t
hi
ck
ne
ss
 (m
),
∞
—
fa
r d
ist
an
ce
, α
·O
H
—
th
e
te
rm
 a
cc
ou
nt
s f
or
 th
e
fr
ac
tio
n
of
 c
ur
re
nt
 d
ire
ct
ed
 to
w
ar
d
·O
H
 p
ro
du
ct
io
n,
 i a
pp
l—
ap
pl
ie
d
cu
rr
en
t d
en
si
ty
 (A
  m
−
2 ),
F—
Fa
ra
da
y’
s c
on
st
an
t
(C
  m
ol
−
1 ),
D
—
di
ffu
si
on
 c
oe
ffi
ci
en
t (
m
2   s
−
1 ),
A—
el
ec
tro
de
 a
re
a
 (m
2 ),
ε C
l−
—
fa
ra
di
c
yi
el
d
as
 a
 f
un
ct
io
n
of
 c
hl
or
id
e
 (C
l−
)
co
nc
en
tra
tio
n;
 in
de
x
i r
ef
er
s
to
 o
rg
an
ic
 c
om
po
un
d,
 ·O
H
—
hy
dr
ox
yl

ra
di
ca
ls
, D
L—
di
ffu
si
on
 la
ye
r,
B
—
bu
lk
 so
lu
tio
n,
 O
X
—
ac
tiv
e
ch
lo
rin
e
 (C
l 2)
 sp
ec
ie
s,
0—
in
iti
al
 st
at
e
K
ap
ał
ka
 e
t a
l.
(2
00
9)
G
ro
en
en
-S
er
ra
no
 e
t a
l.
(2
01
3)
D
on
ag
hu
e
an
d
C
ha
pl
in

(2
01
3)
M
as
ci
a
et
 a
l.
(2
00
7)
M
as
ci
a
et
 a
l.
(2
01
0)
Th
e
eq
ua
tio
n
on
 w
hi
ch
 th
e
m
od
el
 is
 b
as
ed
M
as
s b
al
an
ce
 la
w
:�
C
i
�
t
=
−
d
iv
J
i
+
R
i
Th
e
co
ns
id
er
in
g
re
ac
tio
ns
 in

w
hi
ch
 th
e
·O
H
 a
re
 sp
en
t
O
xy
ge
n
ev
ol
ut
io
n
re
ac
tio
n
or or
ga
ni
c
ox
id
at
io
n
O
xy
ge
n
ev
ol
ut
io
n
re
ac
tio
n
or
/
an
d
ox
id
at
io
n
of
 o
ne
 o
r t
w
o
or
ga
ni
c
sp
ec
ie
s
O
xy
ge
n
ev
ol
ut
io
n
re
ac
tio
n
an
d
or
ga
ni
c
ox
id
at
io
n
an
d
th
e
re
ac
tio
n
of
 C
lO
4−

fo
rm
at
io
n
fro
m
 C
lO
3·
D
ea
ct
iv
at
in
g
pr
oc
es
se
s
an
d
or
ga
ni
c
ox
id
at
io
n
In
iti
al
 c
on
di
tio
ns
–
C
i(
∀
x
,t
=
0
)
=
C
0 i
–
C
D
L
⋅
O
H
=
0
C
D
L
i
=
C
B i
=
C
i0
,∀
x
C
D
L
⋅
O
H
=
C
D
L
O
X
=
C
B O
X
=
0
C
D
L
i
=
C
B i
=
C
i0
,∀
x
B
ou
nd
ar
y
co
nd
iti
on
s
C
⋅
O
H
=
0
at
x
=
∞
C
⋅
O
H
(x
=
0
) o
bt
ai
ne
d
fro
m
 th
e
as
su
m
pt
io
n
th
at
 a
ll
cu
rr
en
t
is
 d
ire
ct
ed
 to
 ·O
H
 fo
rm
at
io
n
(i.
e.
, J
⋅
O
H
(x
=
0
)
=
i a
p
p
l/
F
)
C
⋅
O
H
=
0
at
x
=
�
C
⋅
O
H
(x
=
0
) o
bt
ai
ne
d
fro
m
 th
e
as
su
m
pt
io
n
th
at
 a
ll
cu
rr
en
t
is
 d
ire
ct
ed
 to
 ·O
H
 fo
rm
at
io
n
(i.
e.
, J
⋅
O
H
(x
=
0
)
=
i a
p
p
l/
F
)
— J
⋅
O
H
(x
=
0
)
=
�
⋅
O
H
i a
p
p
l/
F
,
α
ob
ta
in
ed
 fr
om
 th
e
fit
tin
g
th
e
ad
di
tio
na
l e
xp
er
im
en
ta
l
da
ta
D
⋅
O
H
�
C
⋅
O
H
�
x
=
−
i a
p
p
l
A
F
,x
=
0
D
i
�
C
D
L
i
�
x
=
0
,
x
=
0
C
D
L
i
=
C
B i
,x
=
�
C
⋅
O
H
=
0
,
x
→
∞
D
⋅
O
H
�
C
⋅
O
H
�
x
=
−
(
1
−
�
C
l−
)
i a
p
p
l
A
F
,x
=
0
D
i
�
C
D
L
i
�
x
=
0
,
x
=
0
C
D
L
i
=
C
B i
,x
=
�
C
⋅
O
H
=
0
,
x
→
∞
Th
e
re
ac
tio
n
zo
ne
 th
ic
kn
es
s
1
nm
–1
 μ
m
 <
 20
 n
m
 <
 1
μm
 <
 10
 n
m
–
Th
e
m
ax
im
um
 su
rfa
ce
 H
O
•
co
nc
en
tra
tio
n
 <
 0.
07
 m
M
(in
 th
e
ab
se
nc
e
of
 o
rg
an
ic

sp
ec
ie
s)
 <
 0.
1
m
M
(in
 th
e
ab
se
nc
e
of
 o
rg
an
ic

sp
ec
ie
s)
 <
 0.
02
 m
M
(in
 th
e
pr
es
en
ce
 o
f o
rg
an
ic

sp
ec
ie
s)
 <
 0.
5
μM
(in
 th
e
pr
es
en
ce
 o
f
or
ga
ni
c
sp
ec
ie
s)
–
1545Environmental Chemistry Letters (2024) 22:1521–1561
term was used to describe the processes in the diffusion layer
near the electrode surface. The bulk solution is considered
to be ideally mixed. The model takes into account the oxida-
tion of all intermediate products as a second-order reaction.
It is believed that the entire electrical current of the system
is spent on the formation of ·OH; side reactions with ·OH
are modeled using a first-order reaction with a lumped con-
stant. This model makes it possible to calculate both the time
dependences of the concentration of all components of the
systems in bulk solution and their distribution in the entire
diffusion layer. Later Mascia et al. (2010) presented a model,
based on ones, which were previously published by Mascia
et al. (2007) and Polcaro et al. (2009). The proposed model
combines all the advantages of multi-zone and diffusion-
kinetic models.
The work of Kapałka et al. (2009) proposes a station-
ary one-dimensional model describing the formation of a
·OH concentration profile in proximity to the boron-doped
diamond anode surface. The spatial ·OH concentration dis-
tribution is described by analytical expression, which is a
solution of Fick’s second law with a chemical reaction term.
Two limiting cases are considered: the absence of organic
compounds, when only ·OH recombination reaction occurs,
and the presence of organic compounds, when there is no
recombination reaction and only organic oxidation reac-
tion takes place. The surface concentration of ·OH is found
by assuming that all current is directed to the ·OH forma-
tion and that the concentration of the organic compound is
constant and spatially independent.Using this model, the
authors estimated the reaction zone thickness: It is equal
to 1 μm in the absence of organic substances and is of the
order of nanometers or tens of nanometers in the case of
the presence of organic substances. The work of Skolotneva
et al. (2020) expanded the above model, an analytical expres-
sion was obtained for the distribution of the concentration
of ·OH, taking into account both parallel reactions, but with
the same assumptions. The results of this work show that in
the current problem formulation the impact of the recombi-
nation reaction on the thickness of the reaction zone in the
presence of organic compounds is insignificant.
In the study of Donaghue and Chaplin (2013), a one-
dimensional steady-state model was developed to under-
stand ClO4
− formation as a function of organic compound
concentration and current density. This model allows one
to describe the transport of compounds in a diffusion layer
adjacent to the anode surface, as well as theoretically deter-
mine the inhibition of ClO4
− formation in the presence of
organic substances. Several fitting parameters are used, i.e.,
the diffusion coefficients of organic substances and the rate
constant of the reaction of ClO3· with ·OH. The surface con-
centration of ClO3
− radicals and the fraction of the current
directed to ·OH generation are used as the boundary con-
ditions and obtained by fitting the model and the data of
additional experiments. The problem is solved numerically.
The discrepancy between the fitted values of the diffusion
coefficients of organic substances and those calculated by
the Wilke and Change method is explained by the fact that
organic substances may be involved in some physical or
chemical processes that are not taken into account by the
model. Calculations using this model show that the inhibi-
tion of ClO4
− formation linearly depends on the thickness
of the ClO4
− formation reaction zone, which confirms the
assumption that free ·OH exist in the volume of the reaction
zone, and are not only adsorbed on the anode surface.
The one-dimensional nonstationary diffusion-kinetic
model of Groenen-Serrano et al. (2013) allows one to cal-
culate the time and spatial dependencies of ·OH and organic
substances concentration near the surface of a boron-doped
diamond film anode during competitive oxidation, i.e., in the
presence of two organic substances. The model does not use
any fitting parameters, and it takes into account that ·OH are
simultaneously consumed in two parallel reactions: recom-
bination and oxidation of organic substances. The problem
is solved numerically. The study shows two main points:
(1) Substance with a higher rate constant is predominantly
oxidized, and (2) substance begins to be noticeably removed
only when the substance which is oxidized more favorably
reaches a sufficiently low concentration. Authors claim that
the model could be developed to describe systems with more
than two compounds.
Ma et al. (2023a, b) using a kinetic-diffusion model based
on Fick's second law and the Butler-Volmer equation stud-
ied the mechanism of paracetamol oxidation on plate TiOx
and boron-doped diamond anodes. This is the first work
that takes into account both the parallel competitive course
C, mM
x, nm
reaction zone
diffusion layer
CHO
CR
H2O
Ri
R'i+1
·OH
Ri
Ri+1
COH
Distance from electrode surface
·OH and R
concentrations
Fig. 11 Typical concentration profiles of hydroxyl radicals (·OH)
and organic compounds (R) during the anodic oxidation process. Ini-
tial organic compound (Ri), organic compound oxidized by hydroxyl
radical (Ri+1), organic compound oxidized by direct electron transfer
(R′i+1). The dependence of ·OH and R concentrations (C·OH and CR,
respectively) on the distance (x) from the electrode surface is pre-
sented. The reaction zone thickness is usually tens of times less than a
diffusion layer thickness (δ)
1546 Environmental Chemistry Letters (2024) 22:1521–1561
of electrochemical reactions (the reaction of the formation
of ·OH and the oxidation of paracetamol by direct electron
transfer), and homogeneous reactions in the volume of the
solution (recombination of ·OH, degradation of the target
component and mineralization of by-products). It was shown
that the oxidation of paracetamol on the surface of boron-
doped diamond and Ti4O7 electrodes is due to ·OH, but in
the presence of scavengers of these radicals, such as ethanol,
direct electron transfer becomes the main mechanism. It was
also found no significant competition between the mother
molecule and degradation by-products under mass transport
limitation.
Marshall and Herritsch (2018) proposed a model of
the oxidation of an organic compound on an active anode,
which most fully describes the kinetics of oxygen evolution
reaction. The model takes into account the competitiveness
of the organic oxidation reaction and oxygen evolution
reaction, describes the first two steps of oxygen evolution
reaction using the Butler-Volmer equation, and describes
mass transfer using Fick's second law. All oxygen evolution
reaction stages are considered reversible, organic oxidation
is not. The kinetic parameters for oxygen evolution reaction
are adjusted according to the experiment without organic
compounds, only the processes in diffusion layer are
modeled. It is assumed that diffusion layer is of constant
thickness, and the concentration in the volume of the
solution does not change. The model opens a new pathway
for the oxidation of organic compounds, i.e., molecular
oxygen forms a higher oxide with an active site, which then
oxidizes the organic compound molecule, which makes it
possible to exceed the efficiency of 100%. Also, this model
allows to determine the number of active sites per unit
electrode area and the surface coverage of adsorbed oxygen
and ·OH.
All the works presented in this section (except for the
last one) theoretically confirm that during oxidation on a
non-active electrode in the reaction zone a homogeneous-
like reaction occurs between organic substances and ·OH.
Thereby, ·OH is not adsorbed but can diffuse from the anode
surface, forming a thin reaction zone, the thickness of which
varies from 1 nm in the presence of organic substances to
1 μm in the absence of it. It means that the rate constants of
purely homogeneous reactions between organic compounds
and ·OH can be used in calculations. Also, each of these
works reveals the parameters that affect the reaction zone
thickness and allows to separately quantify their effects:
the applied current density, the nature and the initial
concentration of organic substances.
All the presented models are one-dimensional and only
indirectly take into account the two-dimensionality of the
system. Therefore, the roughness of the electrode surface
and the lateral concentration distribution along the solution
flow are not quantitatively included in the existing models.
Modeling of anodic oxidation with porous
3D electrodes
The features of porous electrodes
As it has been said above, the implementation of porous
electrodes in flow-through configuration is the most
promising way to solve mass transport limitation problem
existing in anodic oxidation (Chaplin 2014; Trellu et al.
2018a).
The use of porous electrodes in electrochemistry is
no longer a novelty. Paul Léon Hulin developed the first
patent for a flow-through porous electrode in 1893 (Hulin
1897). Since then, porous electrodes are widely used in
electrochemistry, and nowadays, many advanced areas
of electrochemistry are inconceivable without porous
electrodes.
They have found their application for energy storage:
Numerous porous electrode materials are used in lithium-
ion batteries, and various carbon-based nanocomposites are
currently pursued as supercapacitor electrodes (Vu et al.
2012; Jiang et al. 2013). Optimized for salt storage, ion
and electron transportporous electrodes have significant
potential for capacitive deionization (Porada et al. 2013).
3D electrodes are also exploited as sensors and for
heterogeneous catalysis (Sun et al. 2012; Walcarius 2012;
Zhu et al. 2017).
The wide application of porous electrodes is due to their
valuable advantages:
• The pores ensure good entry of the electrolyte to the
electrode surface.
• The surface area of the porous material is relatively large,
which facilitates charge transfer across the electrode or
electrolyte interface.
• The walls of active material surrounding the pores can be
very thin (micrometers to tens of micrometers), reducing
path lengths for molecule diffusion.
• The small feature sizes permit increased utilization of
active material.
• The walls and pores in a porous electrode can be
bicontinuous, thereby providing continuous electron
transport paths through the active phase (walls) and the
electrolyte phase (pores).
Porous electrodes used for anodic oxidation are also
called reactive electrochemical membranes, as they com-
bine separation and electrooxidation processes. A timeline
of reactive electrochemical membranes development and
investigation is summarized in Wei et al. (2020), which was
updated and expanded by Andersson et al. (1957), Hayfield
(1983), Smith et al. (1998), Qi et al. (2022) and Yin et al.
1547Environmental Chemistry Letters (2024) 22:1521–1561
(2023) (Fig. 12). The results obtained over the past ten years
have shown that such a solution is a revolutionary technol-
ogy for the electrooxidation of organic pollutants for water
purification systems (Trellu et al. 2016; Gayen et al. 2018;
Fu et al. 2019). Research in this direction is carried out by
the world's leading laboratories in the field of electrochem-
istry. Recent research has been focused on the development
of porous TinO2n−1 electrodes in order to improve (i) the
electroactive surface area and (ii) mass transport conditions,
particularly in flow-through configuration (Radjenovic et al.
2020; Mousset 2022). Therefore, it is important to be able
to control the porous structure of the material (Trellu et al.
2018a).
In Trellu et al. (2018b), Gayen et al. (2018) and Fu et al.
(2019), it was shown that a high degree of purification can
be achieved with certain system parameters, e.g., pumping
rate, solution concentration, current strength, though the
energy consumption increases. For some pollutants, a local
maximum is observed on the dependence curve of energy
consumption on the flux density of organic substances. Thus,
the formation of insoluble fouling in the dead zone occurs
and, in addition, the degradation of the anodes.
However, there are a number of problems that are espe-
cially noticeable when working with porous electrodes.
During electrolysis, gas bubbles formed in the pores of the
electrode can act as fouling substances, they partially or
completely block the pores, which leads to a decrease in the
hydrodynamic permeability of the system and a decrease in
the mass transfer coefficient. There is one more problem—
heterogeneity of properties such as conductivity, reaction
rate and diffusivity across the electrode. As a result, the
experimental characterization of a porous electrode is much
more complicated than that of a plate electrode.
Modeling of anodic oxidation in the systems
with reactive electrochemical membranes
Compared to plate electrodes, the mathematical description
of systems with porous electrodes is difficult because it is
necessary to describe the transport of particles within their
volume. So, in pores, in addition to normal diffusion (diffu-
sion along the x-axis, Fig. 13), there is also axial diffusion:
from the center of the pore to its walls. A similar problem
exists for the distribution of electric current: Its streamlines
can be bent not only due to the inhomogeneity of the system
conductivity but also because the electrochemical reactions
that cause the flow of current proceed unevenly over the
volume of the electrode. In addition, the surface areas of
the pores are not equally accessible, that is, the path that
the specie needs to overcome from the center of the pore to
its wall at each point along the x-axis is different (Fig. 13).
Polcaro and Palmas (1997) presented a simulation of
the oxidation of 2-chlorophenol and 2,6-dichlorophenol on
porous carbon felt in a fixed bed mode. This model can be
attributed to the kinetic group. It makes possible to predict
the dependence of the concentration of the initial compo-
nent and intermediate reaction products on time, as well
as the effect of the applied current density on the process
efficiency. The model takes into account the adsorption
of organic compounds on carbon as a pseudo-first-order
reaction. It is believed that the entire current goes to the
generation of ·OH. As in works with kinetic models for
Ti oxides were first
synthesized and
characterized,1957
Commercially available
material Ebonex ® – TiOx
was patented, 1983
Electrochemical cell
including an electrode
comprising TinO2n−1
disclosed for use with
 redox reactions, 1988
Focused on Ti4O7
material, 1998
First REM was
fabricated from a
commercially
available Ebonex®
electrode, 2013
Ti4O7 REM with high purity
was synthesized by
mechanical pressing of
TiO2 powders, 2022
IrO2
REM,
2015
Ti4O7
REM,
2014
RuO2-Sb2O5-
SnO2 REM, 2017
Stainless steel
mesh/polymeric
REM, 2015
Electrocatalytic
membrane
reactor, 2010
Seepage electrode
reactor, primary
 REM, 2009
Nano-MnO2
REM, 2013
Actual wastewater
Treatment / Pilot
study, 2016-2017
Study of mechanism
of anti-fouling and
regeneration, 2016
TiO2
mesoflower
interlayer REM,
2016
Nanostructure
macroporous
PbO2 REM, 2017
Bi-doped
SnO2-TinO2n−1
REM, 2018
TiO2-REM doped
with Pd-Based
catalyst , 2018
Ti sub-oxide
REM, 2018
Ceramic-REM
TiO2-SnO2-Sb
anode, 2018
Effect study of
pore structure
of REM, 2018
Coal-
based
carbon
REM,
2018
Carbotherma
l reduction of
TiO2 REM,
2018
Carbon-Ti4O7
REM, 2019
Ozonation
and REM
coupled
process
with Ti4O7
electrode,
2020
Moving-bed
REM, 2019
Pd-Cu/Ti4O7
REM , 2020
Manganese
oxide-coated
graphite felt
REM, 2020
Model
study of
REM,
2020
EO of bio-treated landfill
leachate using a novel
dynamic reactive
electrochemical
membrane (DREM), 2023
SnO2-Sb
REM,
2016
3-D printed
electrodes,
2023
1950s 1980s 1990s 2000s 2010s 2020s
is
Fig. 12 Development of reactive electrochemical membranes (REMs)
during 1957–2023. The explosive development of electrochemical
membrane technology began in the 2010s. The figure is redrawn from
Wei et  al. (2020) with modifications from Andersson et  al. (1957),
Hayfield (1983), Smith et  al. (1998), Qi et  al. (2022) and Yin et  al.
(2023)
1548 Environmental Chemistry Letters (2024) 22:1521–1561
plate electrodes, the model formulation consisted of four
(according to the number of compounds, the change in
the concentration of which is modeled) material balance
equations with a reaction term. The problem was solved
analytically, the reaction rate constants were found by pro-
cessing the experimental data, and only one was a fitting
parameter.
Mascia et al. (2012) presented a simple two-dimensional
stationary convection–diffusion model of active Cl2 gen-
eration for water disinfection in fixed bed reactors with
3D electrodes (titanium coated with Ru/Ir oxides) in con-
tinuous mode. This model takes into account only the direct
electron transfer reaction, and pseudo-first-order kinetics is
used to describe chemical and electrochemical reactions. As
a continuation of Mascia's work on modeling plate elec-
trodes, the new model assumes that the reactor is divided
into several zones: two reaction zones (cathode and anode)
and three flow zones (inlet, outlet and between the reac-
tion zones) (Mascia et al. 2007, 2010). Fluid dynamics are
modeled using residence time distribution. The hydrody-
namic was interpretedby a simple plug flow model, in which
axial dispersion accounts for the non-ideal flow behavior
of the system. The common limiting current technic has
been adopted for mass transport characterization. Mascia
et al. (2016) apply the same model to describe the genera-
tion of various oxidizing radicals in a fixed bed reactor with
three-dimensional conductive diamond grid electrodes. The
main differences are (1) one-dimensional approximation is
applied and (2) electrochemical reactions are modeled not as
pseudo-first-order kinetics but in accordance with Faraday’s
law. These models allow to simulate the performances of
such reactor.
In classical electrochemistry, a great contribution to the
modeling of porous electrodes was made by John Newman
group’s (Newman and Tiedemann 1975; Trainham and New-
man 1977). In these works, a one-dimensional model of
flow-through porous electrodes operating above and below
the limiting current was developed. The model takes into
account the possibility of multiple reactions occurring and
it shows a nonuniform distribution of reaction rates due to
ohmic, mass transfer, and heterogeneous kinetic limitations.
The model makes it possible to calculate the distribution
of the potential, currents, and concentration of the target
component inside the porous electrode.
a
Transition to 3D unit cell 3D unit cell 2D unit cell
Diffusion
layer
Electrode
Electrode
Electrode
Diffusion layer
1D unit cell (Newman-Misal-Chaplin model)
CR
jn
Cw
i
ik
( )n m W Rj k C C= −
jx
Electrode
Diffusion
layer
Electrode
j(CR)
с
b
d e
Fig. 13 a Transition from real electrode to b 1D,e 2D and d 3D
model unit cells (Skolotneva et al. 2020; Misal et al. 2020). b In the
transition to one-dimensional geometry, the cross-section of the elec-
trode is considered, the porous structure is modeled using porosity.
c In the transition to a three-dimensional structure, a uniform pore
distribution is assumed and then d an individual pore is modeled. e
As the 3D pore has axial symmetry, a transition to 2D geometry is
possible. ik—current density in solution (A m−2), i—current density
in electrode material (A m−2), jx—flux density of reactive species in
the solution flow direction (mol m−2  s−1), jn—flux density of reactive
species to the pore wall (mol m−2  s−1), CR—concentration of reac-
tive species in the pore bulk (mol m−3), Cw—concentration of reac-
tive species at the pore wall (mol m−3), km—mass transfer coefficient
(m s.−1)
1549Environmental Chemistry Letters (2024) 22:1521–1561
Based on the classical works of Newman, Misal et al.
(2020) have developed a stationary reactive transport model
for the study of electrochemical oxidation (and reduction)
of sulfamethoxazole using reactive electrochemical mem-
branes based on Ti4O7 and Pd-Cu/Ti4O7. Two phases are
considered: the solution phase and the electrode material
phase. The current in the solution is due to the occurrence of
(electro) chemical reactions (this model considers only one
reaction—the oxidation or reduction of sulfamethoxazole
by direct electron transfer, the rate of which is described by
the Butler-Volmer equation). The local electrical neutral-
ity assumption is used, while the charge that has left the
phase of the electrode material automatically passes into the
solution phase and vice versa. The effects of axial diffusion,
dispersion and convection are included. Some parameters
(specific surface area, exchange current density and formal
potentials) were optimized according to the experimental
data. The simulations allowed for an analysis of the effect of
the applied potential and flow rate on the concentration, cur-
rent, and potential distribution within the porous electrode
under both anodic and cathodic polarizations. Under anodic
conditions, the entire volume of the reactive electrochemical
membrane was assumed to be electroactive. It is shown that
under kinetically limited conditions the reactive area was
approximately uniformly distributed in the bulk of the reac-
tive electrochemical membrane but shifted to the inlet of the
electrode under mass transport-limited conditions. In their
further article, authors applied the model to simulate the
anodic oxidation of perfluorooctanoic acid and perfluorooc-
tanesulfonic acid on a porous Ti4O7 anode disk and showed
that increasing the reactive electrochemical membrane phase
conductivity above a certain threshold value did not improve
the conversion of organics as the solution phase resistance
limited the performance of anodic oxidation (Khalid et al.
2022). The authors also developed the reactors-in-series
model and found that increasing the specific surface area
of reactive electrochemical membranes and operating under
conditions that minimize the total number of reactors is the
efficient approach for anodic oxidation of target organic
compounds.
This model was applied by Skolotneva et al. (2021) to
describe the oxalic acid oxidation by direct electron transfer
simultaneously with the oxygen evolution reaction on Mag-
néli phase reactive electrochemical membrane. The addition
of the second chemical reaction leads to a sharp increase
in the number of adjustable parameters. It is shown that at
low oxalic acid fluxes the oxygen evolution reaction domi-
nates in the system, but the concentration of oxygen just
slightly surpasses the solubility limit. The reaction rates rise
from the center of reactive electrochemical membrane bulk
toward the inlet and outlet if the kinetic limit is not reached.
This behavior is due to the similar values of electrode and
solution phase conductivities. At conditions close to the
kinetic limit the rate of direct electron transfer of oxalic
acid increases from the outlet to the inlet of reactive elec-
trochemical membrane. Using a brief theoretical analysis, it
was found that even at a high oxalic acid flux (70 mgC  L−1)
99.9% removal and 50% current efficiency may be achieved
at high current densities (− 300 A  m−2).
Mareev et al. (2021) have modified the model of Newman
for investigation of the influence of gas bubble formation
on the efficiency of anodic oxidation of paracetamol in the
tubular electrolyzer with Magnéli phase reactive electro-
chemical membrane as an anode. Two electrode reactions
(·OH generation and oxygen evolution) were considered.
The special balance equation was deduced to simulate the
transition of solved oxygen into the gas phase. The authors
also used Darcy’s law to describe the hydrodynamics with
Helmholtz–Smoluchowski equation to take into account the
electroosmotic flow. The results confirm that the considera-
tion of bubble formation is necessary to describe with high
accuracy the permeate flux in such systems; the oxygen bub-
bles form during the first 15 min of the experiment and, after
that, their size remains constant (under applied conditions);
the zeta potential of the reactive electrochemical membrane
pore surface changes with time. Nevertheless, this model
contains a large amount of fitting parameters and the oxygen
evolution reaction is modeled in a way that is inconvenient
in the literature. It should be noted that some works are exist
in the literature, where the oxygen evolution into the porous
electrode phase is modulated, but they do not consider other
reactions (such as oxidation of organic pollutants or recom-
bination of ·OH) (Saleh et al. 2006; Saleh 2007, 2009).
To the best of our knowledge, only one paper is presented
a two-dimensional micrometer scale model of the transport
of organic species during the anodic oxidation in the system
with reactive electrochemical membrane operated in flow-
through mode (Skolotneva et al. 2020). The pore shape was
considered cylindrical throughout the reactive electrochemi-
cal membrane depth and the cylindrical symmetry assump-
tion was applied to present the system in two coordinates.
The organic oxidation by direct electron transfer andoxygen
evolution reaction was not taken into account, and the con-
ductivity of the electrode phase was considered to be several
times higher than that of the solution phase. The model takes
into account the convection using the Navier–Stokes equa-
tion. The assumptions decrease the number of adjustable
parameters to only one—the rate constant of by-products
mineralization reaction. In contrast to the results obtained
using the Misal model, this work shows that the electrical
current streamlines thicken at the entrance to the pore and
become less dense in its depth, which means that the elec-
troactive portion of the electrode is located at the entrance
of the pore. However, the calculated reaction zone thick-
ness is in good agreement with previous studies (see the
reaction–diffusion models) and the effect of two crucial
1550 Environmental Chemistry Letters (2024) 22:1521–1561
geometrical parameters of reactive electrochemical mem-
brane, porosity and pore radius, is as expected in the litera-
ture: The degradation rate decreases with increasing pore
radius or decreasing porosity (Trellu et al. 2018a).
There is a single paper in the literature in which the tran-
sition line model is developed for the simulation of an elec-
trochemical impedance spectrum to study the fouling in the
reactive electrochemical membrane (Jing and Chaplin 2016).
Although earlier, the model of the impedance of porous
film electrode by Bisquert (2000) was applied to extract
the electroactive surface area of the reactive electrochemi-
cal membrane (Zaky and Chaplin 2013). Jing and Chaplin
were the first, whose work was deduced especially to the
simulation of reactive electrochemical membrane fouling.
The main advantage of this work is that it can accurately
detect changes in the impedances at the three physical inter-
faces (outer membrane surface, active and support layers)
and therefore is capable of detecting the dominant fouling
mechanism (e. g., adsorption at outer, active and support
layers, and pore blockage at the outer membrane surface).
To apply the electrochemical impedance spectroscopy
model to the reactive electrochemical membrane, authors
have transformed the three-dimensional porous geometry
into one dimension by assuming the reactive electrochemical
membrane contains a collection of cylindrical homogeneous
pores of uniform radius. This model was validated experi-
mentally in a separate study (Jing et al. 2016).
Wei et  al. (2017) modeled the flow dynamics in the
tubular electrolyzer (one of the ends of the cylinder was
sealed, and the reactor seemed to be a dead end) with a
tubular porous Ti membrane electrode by computational
fluid dynamics. The mass and momentum transport inside
the reactor is described by the Navier–Stokes equation with
a source term for porous media in the momentum term. The
authors have investigated the influence of reactor length and
diameter on its performance. They found that the distribution
of permeate velocity along the tubular reactor was uniform
and the short length and large diameter of the reactor provide
an enhanced mass transfer.
Wang et al. (2015) presented a 3D model through which
a novel tubular electrochemical reactor with a mesh-plate
electrode perpendicular to fluid flow and a traditional
concentric tubular reactor were compared. Fluid dynamics
is described by the Navier–Stokes equations and the
re-normalization group k-epsilon turbulence model, and the
kinetics of organic oxidation is described by the Comninellis
model for reactions limited by mass transfer with some
simplifications (it is assumed that all organic compounds
have the same diffusion coefficient). The results of this
work show that the orthogonal flow through the mesh-plate
electrodes clearly enhanced the mass transfer coefficient
and improved the removal rate of pollutants in tubular
electrochemical reactors. Earlier Ibrahim et al. (2013) have
used computational fluid dynamics and residence time
distribution to investigate the flow dynamics in the tubular
electrochemical reactor with a cylindrical mesh anode. The
obtained results show that the application of mesh electrodes
positively affects the performance of the reactor and in such
systems the presence of dead zones and short-circuiting in
the reactor decreased with an increase in the flow rate.
Modeling anodic oxidation
in the FM01‑LC electrochemical reactor
The FM01-LC is a laboratory-scale, electrochemical filter
press cell with a projected electrode area of 64 cm2 and a
rectangular electrolyte flow channel which was originally
based on the larger FM21-SP electrolyzer of 2100  cm2
projected electrode area designed for the chlorine-alkali
industry then diversified to other applications. Currently,
this flow reactor is used in many areas of electrochem-
istry (chloralkali synthesis, electrosysntesis, electrowin-
ning, metal ion removal and recycling, electrooxidation of
organic pollutants, flow batteries and fuel cells for energy
conversion and storage). Such a wide range of applications
is due to two main advantages of FM01-LC: (1) flexible
cell design, which may accommodate different types of
electrodes (textured, coated, profiled or porous), polymer
mesh turbulence promoters and microporous separators
or ion-exchange membranes and (2) well-studied fluid
dynamics that make this cell a flow cell with controlled
hydrodynamics (Rivera et al. 2015a) (Fig. 14).
There is a wide range of works on the modeling of
hydrodynamics in FM01-LC with different configurations
(Trinidad and Walsh 1996; Trinidad et al. 2006; Rivero
et al. 2012; Cruz-Díaz et al. 2014). Let us consider the
ones that describe the FM01-LC with mesh electrodes
because these reactors are used in the system of anodic
oxidation of organic compounds. Bengoa et al. (2000)
modeled the flow pattern in the electrochemical cell using
a coupled model: a dispersed plug flow model for reaction
zone and a continuous stirred-tank reactors in series for
inlet–outlet. They reported the influence of the inlet geom-
etry of the cell on flow establishment in the reaction area.
In the paper of Rivera et al. (2010), the liquid phase mix-
ing flow pattern is studied at low and intermediate Reyn-
olds numbers by means of the residence time distribution
model combined with the “axial dispersion model” and
“plug dispersion model” and using ‘closed-closed vessel”
boundary conditions. Under these conditions, the effects of
canalization and stagnant zones are important, and devia-
tions from the ideal flow pattern should be considered.
Cruz-Díaz et  al. (2012) presented a parametric flow
dispersion model with an electrochemical reaction rate
limited by mass transfer expression coupled with Poisson
and continuous stirred tank equations for describing the
1551Environmental Chemistry Letters (2024) 22:1521–1561
electrooxidation of thiourea in FM01-LC reactor coupled
to recirculation continuous stirred tank. The stagnant zones
through the reactor are assumed negligible, and the electrical
conductivity of the liquid bulk phase and electrode meshes
is assumed to be the same. The model formulation consists
of three equations: the material balance equation in differ-
ential form with a reaction term for the reactor, Poisson's
equation and the material balance equation in integral form
without a reaction term for recirculating continuous stirred
tank. Since the authors assume that the electrochemical
reaction is carried out under limiting current density condi-
tions, the reaction rate depends only on the mass transfer
coefficient. The boundary conditions were set considering a
closed-closed vessel system and using the tertiary potential
model discussed by Fedkiw (1981). The problem was solved
numerically. This work is aimed at obtaining the concentra-
tion dependence of the target component on time and the
potential distribution inside the FM01-LC. In addition, this
model does not contain fittingparameters. Cruz-Díaz et al.
(2018) introduced another work in which they modified the
above model to describe the electrochemical oxidation of
dyeing wastewater. The main difference of the new model
is that it also considers indirect electrochemical oxidation.
It is assumed that only the formation of oxidizing species
at the anode (modeled as pseudo-first-order reactions) and
their reduction at the cathode (modeled as reactions limited
by mass transfer, and their rate is expressed only through
the mass transfer coefficient) occur in the reactor. In turn,
the oxidation of organics and dye proceeds in recirculation
continuous stirred tank (modeled as homogeneous second-
order reactions). Also, Poisson’s equation is removed from
the model. The new model contains four fitting parameters
(reaction rate constants) and describes well the evolution of
different chemical species.
Density functional theory
Determining the kinetics of the oxidation reaction of an
organic compound during anodic oxidation is an extremely
complicated task. The main problem is that the oxidation
reaction rate of by-products is high and often they cannot
even be detected. As a result, experimental methods for
determining reaction pathways and rate constants of
oxidation reactions are not applicable. Density functional
theory modeling can be used to gain insights into probable
reaction pathways for the electrochemical oxidation of aimed
organic compounds and subsequent by-product formation.
Density functional theory is a successful theory to calcu-
late the electronic structure of atoms, molecules, and solids.
Its goal is the quantitative understanding of material proper-
ties from the fundamental laws of quantum mechanics. Den-
sity functional theory is today the most widely used method
to study interacting electrons, and its applicability ranges
from atoms to solid systems, from nuclei to quantum fluids.
Knowledge of the electronic structure allows one to calculate
the adsorption energies, the reaction energies and activation
barriers, which in turn helps to determine a thermodynami-
cally favorable reaction pathway.
The choice of approximating functions and solution
methods plays a key role in modeling the electronic structure
using density functional theory. In existing studies on density
functional theory modeling of chemical reactions occurring
during the anodic oxidation of organic compounds frequency
and geometry optimization as well as energy calculations are
performed using built-in basis sets of the Gaussian software
package. Exchange and correlation are mostly modeled with
gradient-corrected Becke, three-parameter, Lee–Yang–Parr
functionals. Also in all models the implicit water solvation
is taking into account. The activation energy is calculated
mostly according to Marcus theory (Jing and Chaplin 2017;
Gayen et al. 2018; Lin et al. 2020). Also Anderson and Kang
Fig. 14 The FM01-LC electro-
chemical reactor. This is one of
the most used and studied filter
press reactors. It has rectan-
gular electrolyte flow channel.
Redrawn with the permission
of Elsevier from Rivera et al.
(2015a) Electrolyte outlet
Electrolyte inlet
Turbulence promoter
Channel distributor
Electrode attachment
1552 Environmental Chemistry Letters (2024) 22:1521–1561
method can be applied (Azizi et al. 2011; Zaky and Chaplin
2014). The following is a brief review of the results obtained
by density functional theory modeling in the field of anodic
oxidation of organic pollutants.
In the paper of Zaky and Chaplin (2014), density
functional theory simulations were performed to elucidate
possible reaction mechanisms of p-substituted phenols.
The authors were looking for a reason why p-nitrophenol
and p-methoxyphenol react differently. The results of the
study showed that the 2 e− oxidation mechanism is most
likely for p-methoxyphenol, and the 1 e− polymerization
mechanism is for p-nitrophenol. It was shown that
benzoquinone is not oxidized by direct electron transfer. It
was also calculated which carbon atoms are most likely to
be hit by the ·OH radical for different forms of p-nitrophenol
and p-methoxyphenol. Electron-donating substituents, i.e.,
–OCH3 (methoxy) groups, increase the electron density of
the phenolic ring and allow direct electron transfer reactions
to proceed at lower anodic potentials relative to p-substituted
phenolic compounds with electron withdrawing substituents,
i.e., –NO2 (nitrogen dioxide). Therefore, the anodic
potential at which the mechanism for p-substituted phenolic
compound removal switches from the 1e− polymerization
mechanism to the 2e− oxidation mechanism, is determined
by the electronegativity of the substituent.
Jing and Chaplin (2017) published a study in which den-
sity functional theory simulations were performed to inves-
tigate the possibility of direct electron transfer oxidation of
·OH probes (coumarin, p-benzoquinone, terephthalic acid,
p-chlorobenzoic acid). Results of these simulations indicate
that oxidation of coumarin proceeds at potentials much less
than that for ·OH formation, the oxidation of p-chloroben-
zoic acid occurred via direct electron transfer at potentials
less than 2.3 V and both reactions pathways (direct elec-
tron transfer and via ·OH oxidation) take place at potentials
more than 2.3 V. Both terephthalic acid and p-benzoquinone
were found to be unreactive to direct electron transfer reac-
tions. Density functional theory simulations were also used
to investigate the possibility of these four probe molecules
undergoing the Forrester-Hepburn mechanism. The results
indicated that the nucleophilic addition or substitution of
·OH to coumarin, terephthalic acid, and p-chlorobenzoic
acid was unlikely to be significant at room temperature.
Results from this study indicated that terephthalic acid is
the most appropriate ·OH probe compound for the charac-
terization of electrochemical and catalytic systems.
Gayen et al. (2018) studied the mineralization of model
agricultural contaminants—atrazine and clothianidin.
Density functional theory simulations provided potential-
dependent activation energy profiles for atrazine,
clothianidin, and various oxidation products (desethyl
desisopropy atrazine, desisopropyl atrazine, desethyl
atrazine, cyanuric acid). Results from the density functional
theory simulations allow concluding that the mechanism of
oxidation of atrazine and clothianidin involves the direct
electron transfer and oxidation via ·OH radicals which
causes the rapid and complete mineralization of atrazine
and clothianidin at a very short residence time.
Lin et al. (2020) studied the formation of chlorinated
by-products during the oxidation of model compound—
resorcinol. Several pathways of resorcinol electrooxidation
have been proposed based on density functional theory
simulations. Based on the results of liquid chromatography-
mass spectrometry analysis and some assumptions, the
authors proposed several possible structures for the
chlorinated products and then also performed density
functional theory simulations to determine the potential-
dependent activation energy for proposed chlorinated
products via direct electron transfer.
It should be noted that, to the best of our knowledge,
there is only one paper in which density functional theory is
applied to model the activation barriers for reactions occur-
ring on the plate anode during the electrochemical oxidation.
Azizi et al. (2011) have investigated the possible mechanism
of ClO4
− formation from ClO3
− on the boron-doped diamond
anode. The model predicts the reaction rate of ClO4
− for-
mation as a function of electrode potential and temperature,
and two approaches are used: calculation of the direct elec-
tron transfer coefficient in Butler-Volmer equation (kinetic
model, Sect. 2.1) and quantum mechanical modeling (density
functional theory). The authors used the Accelrys Materials
Studiosoftware package for density functional theory simula-
tions. Using this model, it is possible to study the mechanism
of the oxidation reaction of ClO3
− ions to ClO4
− on boron-
doped diamond. In other words, the model allows to deter-
mine which of the parallel oxidation reactions (through direct
electron transfer or through ·OH) is predominant. Such an
approach allows to develop a mechanistic understanding of
 ClO4
− formation on boron-doped diamond electrode. Results
of density functional theory simulations show that direct
electron transfer of one electron from the ClO3
− molecule
is an activationless reaction at potentials more than 0.76 V,
the obtained ClO3
− radical is chemosorbed and it reacts with
physisorbed ·OH to form the ClO4
−.
Perspective
Recent achievements in the field of anodic oxidation
modeling enrich an understanding of this process and
facilitate the design of new more effective systems.
However, there are some weaknesses that require further
research. Here the possible ideas for future developments
are addressed:
1553Environmental Chemistry Letters (2024) 22:1521–1561
• Most of the models are one-dimensional, in which the
inhomogeneity of the surface and volume of the elec-
trode is taken into account only indirectly through the
dispersion coefficient (3D electrodes) or the mass transfer
coefficient (plate electrodes). Few 2D models are based
on rough approximations (homogeneity of the electrode
surface or cylindrical reactive electrochemical membrane
pores). The possible appearance of 3D models taking into
account the hydrodynamic characteristics of the liquid
flow in different geometries will make it possible to more
accurately estimate the contribution of the diffusion layer
thickness and the roughness of the electrode surface to
the characteristics of anode systems.
• The simultaneous presence of the hydrodynamics and
properties of the anode surface is rare, and therefore
additional fitting parameters are introduced into
the models, which reduces their predictive ability.
Verification of the model is possible only with strict
control of these two components.
• To simulate electrochemical reactions, most researchers
either assume that the entire applied current of the system
is spent on only one useful reaction, or assume that the
reactions occur in series. Simulation of electrochemical
reactions running simultaneously will allow a more
accurate determination of system efficiency. Application
of the Butler-Volmer equation to implement this feature
is most desirable.
• Most studies apply simplifying assumptions to
model chemical reactions. In particular, many use
lumped constant, as often the reaction pathway of the
mineralization of the target component and thus the
reaction by-products are unknown. Mechanisms of
reactions of organic compounds oxidation by direct
electron transfer and formation of some radicals also
require more detailed investigation. In this regard,
a wider application of density functional theory for a
mechanistic study of kinetics could be very fruitful.
Conclusion
The effectiveness of anodic oxidation for the removal of
most known organic pollutants has been proven in many
studies. Thus, anodic oxidation is a technology that responds
to the world's demand for clean drinking water and reduction
of natural water pollution. Nevertheless, further optimization
of the process is required for its widespread application. This
can be achieved through mathematical modeling, an essential
tool for the design of anodic oxidation systems, which
reflects the researchers' knowledge of system operation, the
essential interrelationships between system components, and
the influence of various parameters on system performance.
With the help of mathematical modeling it is possible to
develop a mechanistic understanding of anodic oxidation,
to optimize various trades-off and competitive phenomena
and to obtain a complete picture of the different system
characteristics (such as concentration, voltage, current,
flow velocity) as a function of position and time for different
reactor configurations and operating conditions. The high-
quality model also has predictive power, which can be used
to source insights to optimise performance and cell design.
To the best of our knowledge, the first comprehensive
systematical overview of existing mathematical models of
the anodic oxidation of organic compounds is presented in
this paper. All main approaches are described, equations and
boundary conditions are given for the simplest models, the
discussion on advantages and limitations of each group of
models is provided. The basic principles and equations used
for mathematical modeling of anodic oxidation are dissected
and described in detail. Short overviews of historical
pathway, of reactor’s design and of works applying density
functional theory are also provided. The current review
paper may be a starting point for beginning researchers.
It is shown that simulation can successfully determine the
mechanisms of the anodic oxidation process, identify its
limiting stages, and predict the behavior of experimental
systems. In recent years, a breakthrough has been made in
the field of describing the dissolved components' transport in
porous anodes. Based on the results of this literature review
and considering the main advances in modeling of anodic
oxidation and the challenges facing researchers to further
apply this process in practice, future developments have
been addressed.
Authors' contribution ES, DC, MP and SM contributed to
conceptualization and writing—review and editing; ES and SM
contributed to methodology; ES, AK and AK contributed to software,
project administration, funding, visualization and investigation; SM
contributed to resources; ES, AK, AK and SM contributed to writing—
original draft preparation; and SM, DC and MP supervised the study.
All authors have read and agreed to the published version of the
manuscript.
Funding This research was funded by Russian Science Foundation,
project No. 22-79-10177.
Availability of data and material Not applicable.
Code availability Not applicable.
Declarations
Conflict of interest The authors declare no conflict of interest.
Ethical approval Not applicable.
Consent to participate Not applicable.
Consent for publication Not applicable.
1554 Environmental Chemistry Letters (2024) 22:1521–1561
References
Adams B, Tian M, Chen A (2009) Design and electrochemical study of
 SnO2-based mixed oxide electrodes. Electrochim Acta 54:1491–
1498. https:// doi. org/ 10. 1016/j. elect acta. 2008. 09. 034
Ahmed F, Lalia BS, Kochkodan V et al (2016) Electrically conductive
polymeric membranes for fouling prevention and detection: a
review. Desalination 391:1–15. https:// doi. org/ 10. 1016/j. desal.
2016. 01. 030
Alighardashi A, Aghta RS, Ebrahimzadeh H (2018) Improvement of
carbamazepine degradation by a three-dimensional electrochemi-
cal (3-EC) process. Int J Environ Res 12:451–458. https:// doi.
org/ 10. 1007/ s41742- 018- 0102-2
Andersson S, Collén B, Kuylenstierna U et al (1957) Phase analy-
sis studies on the titanium-oxygen system. Acta Chem Scand
11:1641–1652. https:// doi. org/ 10. 3891/ acta. chem. scand. 11- 1641
Angulo A, van der Linde P, Gardeniers H et al (2020) Influence of
bubbles on the energy conversion efficiency of electrochemical
reactors. Joule 4:555–579. https:// doi. org/ 10. 1016/j. joule. 2020.
01. 005
Armijos-Alcocer KG, Espinoza-Montero PJ, Frontana-Uribe BA et al
(2017) Electrochemical degradation of nonylphenol ethoxylate-7
 (NP7EO) using a DiaClean® cell equipped with boron-doped
diamond electrodes (BDD). Water Air Soil Pollut 228:289.
https:// doi. org/ 10. 1007/ s11270- 017- 3471-9
Ateya BG, El-Anadouli BE (1991) Effects of gas bubbles on the polari-
zation behavior of porous flow through electrodes. J Electrochem
Soc 138:1331–1336. https:// doi. org/ 10. 1149/1.20857 81
Azizi O, Hubler D, Schrader G et al (2011) Mechanism of perchlorate
formation on boron-doped diamond film anodes. Environ Sci
Technol 45:10582–10590. https:// doi. org/ 10. 1021/ es202 534w
Barbosa AD, da Silva LF, de Paula HM et al (2018) Combined use
of coagulation (M. oleifera) and electrochemical techniques
in the treatment of industrial paint wastewater for reuse and/
or disposal. Water Res 145:153–161. https:// doi. org/ 10. 1016/j.
watres. 2018. 08. 022
Bard AJ, Faulkner LR (2001) Electrochemical methods: fundamen-
tals and applications, 2nd edn. Wiley, New York
Beck F, Krohn H, Kaiser W et al (1998) Boron doped diamond/
titanium composite electrodes for electrochemical gas genera-
tion from aqueous electrolytes. Electrochim Acta 44:525–532.
https:// doi. org/ 10. 1016/ S0013- 4686(98) 00115-7
Bengoa C, Montillet A, Legentilhomme P, Legrand J (2000) Charac-
terization and modeling of the hydrodynamic behavior in the
filter-press-type FM01-LC electrochemical cell by direct flow
visualization and residence time distribution. Ind Eng Chem
Res 39:2199–2206. https:// doi. org/ 10. 1021/ ie990 7730
Bisquert J (2000) Influence of the boundaries in the impedance of
porous film electrodes. Phys Chem Chem Phys 2:4185–4192.
https:// doi. org/ 10. 1039/ b0017 08f
Bockris JO (1972) Electrochemistry of cleaner environments.
Springer, US, Boston, MA
Bonfatti F, De Battisti A, Ferro S et al (2000) Anodic mineralization
of organic substrates in chloride-containing aqueous media.
Electrochim Acta 46:305–314. https:// doi. org/ 10. 1016/ S0013-
4686(00) 00586-7
Borrás C, Laredo T, Mostany J, Scharifker BR (2004) Study of the
oxidation of solutions of p-chlorophenol and p-nitrophenol on
Bi-doped PbO2 electrodes by UV-Vis and FTIR in situ spec-
troscopy. Electrochim Acta 49:641–648. https:// doi. org/ 10.
1016/j. elect acta. 2003. 09. 019
Brillas E, Martínez-Huitle CA (2015) Decontamination of waste-
waters containing synthetic organic dyes by electrochemical
methods. An updated review. Appl Catal B Environ 166–
167:603–643. https:// doi. org/ 10. 1016/j. apcatb. 2014. 11. 016
Brillas E, Sirés I, Oturan MA (2009) Electro-Fenton process and
related electrochemical technologies based on Fenton’s reac-
tion chemistry. Chem Rev 109:6570–6631. https:// doi. org/ 10.
1021/ cr900 136g
Brito CN, Ferreira MB, de Moura Santos ECM et al (2018) Elec-
trochemical degradation of azo-dye Acid Violet 7 using BDD
anode: effect of flow reactor configuration on cell hydrodynam-
ics and dye removal efficiency. J Appl Electrochem 48:1321–
1330. https:// doi. org/ 10. 1007/ s10800- 018- 1257-4
Brosler P, Girão AV, Silva RF et al (2023) Electrochemical advanced
oxidation processes using diamond technology: a critical
review. Environments 10:10020015. https:// doi. org/ 10. 3390/
envir onmen ts100 20015
Brunet R, Dore M (1984) Oxidation of organic compounds through
the combination ozone-hydrogen peroxide. Ozone Sci Eng
6:163–183. https:// doi. org/ 10. 1080/ 01919 51840 85510 19
Butrón E, Juárez ME, Solis M et al (2007) Electrochemical incin-
eration of indigo textile dye in filter-press-type FM01-LC
electrochemical cell using BDD electrodes. Electrochim Acta
52:6888–6894. https:// doi. org/ 10. 1016/j. elect acta. 2007. 04. 108
Cai J, Zhou M, Pan Y et al (2019) Extremely efficient electrochemi-
cal degradation of organic pollutants with co-generation of
hydroxyl and sulfate radicals on Blue-TiO2 nanotubes anode.
Appl Catal B Environ 257:117902. https:// doi. org/ 10. 1016/j.
apcatb. 2019. 117902
Cañizares P, Domínguez JA, Rodrigo MA et al (1999) Effect of the
current intensity in the electrochemical oxidation of aqueous
phenol wastes at an activated carbon and steel anode. Ind Eng
Chem Res 38:3779–3785. https:// doi. org/ 10. 1021/ ie990 1574
Cañizares P, Díaz M, Domínguez JA et al (2002) Electrochemical
oxidation of aqueous phenol wastes on synthetic diamond thin-
film electrodes. Ind Eng Chem Res 41:4187–4194. https:// doi.
org/ 10. 1021/ ie010 5526
Cañizares P, García-Gómez J, Lobato J, Rodrigo MA (2003) Elec-
trochemical oxidation of aqueous carboxylic acid wastes using
diamond thin-film electrodes. Ind Eng Chem Res 42:956–962.
https:// doi. org/ 10. 1021/ ie020 594+
Cañizares P, García-Gómez J, Lobato J, Rodrigo MA (2004) Modeling
of wastewater electro-oxidation processes part I. General descrip-
tion and application to inactive electrodes. Ind Eng Chem Res
43:1915–1922. https:// doi. org/ 10. 1021/ ie034 1294
Cañizares P, García-Gómez J, Fernández de Marcos I et al (2006)
Measurement of mass-transfer coefficients by an electrochemi-
cal technique. J Chem Educ 83:1204. https:// doi. org/ 10. 1021/
ed083 p1204
Cano A, Barrera C, Cotillas S et al (2016) Use of DiaCell modules
for the electro-disinfection of secondary-treated wastewater with
diamond anodes. Chem Eng J 306:433–440. https:// doi. org/ 10.
1016/j. cej. 2016. 07. 090
Carrillo-Abad J, Mora-Gómez J, García-Gabaldón M et al (2020) Com-
parison between an electrochemical reactor with and without
membrane for the nor oxidation using novel ceramic electrodes.
J Environ Manage 268:110710. https:// doi. org/ 10. 1016/j. jenvm
an. 2020. 110710
Catañeda LF, Rivera FF, Pérez T, Nava JL (2019) Mathematical mod-
eling and simulation of the reaction environment in electrochemi-
cal reactors. Curr Opin Electrochem 16:75–82. https:// doi. org/
10. 1016/j. coelec. 2019. 04. 025
Chaplin BP (2014) Critical review of electrochemical advanced oxi-
dation processes for water treatment applications. Environ Sci
Process Impacts 16:1182–1203. https:// doi. org/ 10. 1039/ c3em0
0679d
Chatzisymeon E, Xekoukoulotakis NP, Diamadopoulos E et al (2009)
Boron-doped diamond anodic treatment of olive mill wastewa-
ters: statistical analysis, kinetic modeling and biodegradability.
https://doi.org/10.1016/j.electacta.2008.09.034
https://doi.org/10.1016/j.desal.2016.01.030
https://doi.org/10.1016/j.desal.2016.01.030
https://doi.org/10.1007/s41742-018-0102-2
https://doi.org/10.1007/s41742-018-0102-2
https://doi.org/10.3891/acta.chem.scand.11-1641
https://doi.org/10.1016/j.joule.2020.01.005
https://doi.org/10.1016/j.joule.2020.01.005
https://doi.org/10.1007/s11270-017-3471-9
https://doi.org/10.1149/1.2085781
https://doi.org/10.1021/es202534w
https://doi.org/10.1016/j.watres.2018.08.022
https://doi.org/10.1016/j.watres.2018.08.022
https://doi.org/10.1016/S0013-4686(98)00115-7
https://doi.org/10.1021/ie9907730
https://doi.org/10.1039/b001708f
https://doi.org/10.1016/S0013-4686(00)00586-7
https://doi.org/10.1016/S0013-4686(00)00586-7
https://doi.org/10.1016/j.electacta.2003.09.019
https://doi.org/10.1016/j.electacta.2003.09.019
https://doi.org/10.1016/j.apcatb.2014.11.016
https://doi.org/10.1021/cr900136g
https://doi.org/10.1021/cr900136g
https://doi.org/10.1007/s10800-018-1257-4
https://doi.org/10.3390/environments10020015
https://doi.org/10.3390/environments10020015
https://doi.org/10.1080/01919518408551019
https://doi.org/10.1016/j.electacta.2007.04.108
https://doi.org/10.1016/j.apcatb.2019.117902
https://doi.org/10.1016/j.apcatb.2019.117902
https://doi.org/10.1021/ie9901574
https://doi.org/10.1021/ie0105526
https://doi.org/10.1021/ie0105526
https://doi.org/10.1021/ie020594+
https://doi.org/10.1021/ie0341294
https://doi.org/10.1021/ed083p1204
https://doi.org/10.1021/ed083p1204
https://doi.org/10.1016/j.cej.2016.07.090
https://doi.org/10.1016/j.cej.2016.07.090
https://doi.org/10.1016/j.jenvman.2020.110710
https://doi.org/10.1016/j.jenvman.2020.110710
https://doi.org/10.1016/j.coelec.2019.04.025
https://doi.org/10.1016/j.coelec.2019.04.025
https://doi.org/10.1039/c3em00679d
https://doi.org/10.1039/c3em00679d
1555Environmental Chemistry Letters (2024) 22:1521–1561
Water Res 43:3999–4009. https:// doi. org/ 10. 1016/j. watres. 2009.
04. 007
Chen G, Betterton EA, Arnold RG (1999) Electrolytic oxidation of
trichloroethylene using a ceramic anode. J Appl Electrochem
29:961–970. https:// doi. org/ 10. 1023/A: 1003541706 456
Chettiar M, Watkinson AP (1983) Anodic oxidation of phenolics
found in coal conversion effluents. Can J Chem Eng 61:568–574.
https:// doi. org/ 10. 1002/ cjce. 54506 10411
Chung CM, Hong SW, Cho K, Hoffmann MR (2018) Degradation of
organic compounds in wastewater matrix by electrochemically
generated reactive chlorine species: kinetics and selectivity. Catal
Today 313:189–195. https:// doi. org/ 10. 1016/j. cattod. 2017. 10.
027
Clematis D, Panizza M (2021) Electrochemical oxidation of organic
pollutants in low conductive solutions. Curr Opin Electrochem
26:100665. https:// doi. org/ 10. 1016/j. coelec. 2020. 100665
Comninellis C (1994) Electrocatalysis in the electrochemical conver-
sion/combustion of organic pollutants for waste water treatment.
Electrochim Acta 39:1857–1862. https:// doi. org/ 10. 1016/ 0013-
4686(94) 85175-1
Comninellis C, Pulgarin C (1991) Anodic oxidation of phenol for waste
water treatment. J Appl Electrochem 21:703–708. https:// doi. org/
10. 1007/ BF010 34049
Comninellis C, Pulgarin C (1993) Electrochemical oxidation of phenol
for wastewater treatment using SnO2 anodes. J Appl Electrochem
23:108–112. https:// doi. org/ 10. 1007/ BF002 46946
Cornejo OM, Murrieta MF, Castañeda LF, Nava JL (2020) Characteri-
zation of the reaction environment in flow reactors fitted with
BDD electrodes for use in electrochemical advanced oxidation
processes: a critical review. Electrochim Acta 331:135373.
https:// doi. org/ 10. 1016/j. elect acta. 2019. 135373
Costa CR, Montilla F, Morallón E, Olivi P (2009) Electrochemical
oxidation of acid black 210 dye on the boron-doped diamond
electrode in the presence of phosphate ions: effect of current
density, pH, and chloride ions. Electrochim Acta 54:7048–7055.
https:// doi. org/ 10. 1016/j. elect acta. 2009. 07. 027
Cruz-Díaz M, Rivera FF, Rivero EP, González I (2012) The FM01-LC
reactor modeling using axial dispersion model with a reaction
term coupled with a continuous stirred tank (CST). Electrochim
Acta 63:47–54. https:// doi. org/ 10. 1016/j. elect acta. 2011. 12. 038
Cruz-Díaz MR, Rivero EP, Almazán-Ruiz FJ et al (2014) Design of
a new FM01-LC reactor in parallel plate configuration using
numerical simulation and experimental validation with residence
time distribution (RTD). Chem Eng Process Process Intensif
85:145–154. https:// doi. org/ 10. 1016/j. cep. 2014. 07. 010
Cruz-Díaz MR, Rivero EP, Rodríguez FA, Domínguez-Bautista R
(2018) Experimental study and mathematical modeling of the
electrochemical degradation of dyeing wastewaters in presence of
chloride ion with dimensional stable anodes (DSA) of expanded
meshes in a FM01-LC reactor. Electrochim Acta 260:726–737.
https:// doi. org/ 10. 1016/j. elect acta. 2017. 12. 025
Cuerda-Correa EM, Alexandre-Franco MF, Fernández-González C
(2019) Advanced oxidation processes for the removal of anti-
biotics from water. An overview. Water 12:102. https:// doi. org/
10. 3390/ w1201 0102
Cui L, Zhang Y, He K et al (2022) Ti4O7 reactive electrochemical
membrane for humic acid removal: insights of electrosorption
and electrooxidation. Sep Purif Technol 293:121112. https:// doi.
org/ 10. 1016/j. seppur. 2022. 121112
da Silva SW, Welter JB, Albornoz LL et al (2021) Advanced electro-
chemical oxidation processes in the treatment of pharmaceutical
containing water and wastewater: a review. Curr Pollut Reports
7:146–159. https:// doi. org/ 10. 1007/ s40726- 021- 00176-6
Dapo RF, Mann CK (1963) Anodic oxidation of triethylamine. Anal
Chem 35:677–680. https:// doi. org/ 10. 1021/ ac601 99a054
de Moura DC, de Araújo CKC, Zanta CLPS et al (2014) Active chlo-
rine species electrogenerated on Ti/Ru0.3Ti0.7O2 surface: elec-
trochemical behavior, concentration determination and their
application. J Electroanal Chem 731:145–152. https:// doi. org/
10. 1016/j. jelec hem. 2014. 08. 008
de Oliveira GR, Fernandes NS, de Melo JV et al (2011) Electrocatalytic
properties of Ti-supported Pt for decolorizing and removing dye
from synthetic textile wastewaters. Chem Eng J 168:208–214.
https:// doi. org/ 10. 1016/j. cej. 2010. 12. 070
de OS Santos G, Gonzaga IMD, Dória AR et al (2020) Testing and
scaling-up of a novel Ti/Ru0.7Ti0.3O2 mesh anode in a microflu-
idic flow-through reactor. Chem Eng J 398:125568. https:// doi.
org/ 10. 1016/j. cej. 2020. 125568
de Paiva Barreto JP, de Freitas Araujo KC, de Araujo DM, Martinez-
Huitle CA (2015) Effect of sp3/sp2 ratio on boron doped diamond
films for producing persulfate. ECS Electrochem Lett 4:E9–E11.
https:// doi. org/ 10. 1149/2. 00615 12eel
Degaki AH, Pereira GF, Rocha-Filho RC et al (2014) Effect of specific
active chlorine species and temperature on the electrochemical
degradation of the reactive blue 19 dye using a boron-doped dia-
mond or DSA anode in a flow reactor. Electrocatalysis 5:8–15.
https:// doi. org/ 10. 1007/ s12678- 013- 0156-z
Donaghue A, Chaplin BP (2013) Effect of select organic compounds
on perchlorate formation at boron-doped diamond film anodes.
Environ Sci Technol 47:12391–12399. https:// doi. org/ 10. 1021/
es403 1672
Duan W, Ronen A, Walker S, Jassby D (2016) Polyaniline-coated car-
bon nanotube ultrafiltration membranes: enhanced anodic sta-
bility for in situ cleaning and electro-oxidation processes. ACS
Appl Mater Interfaces 8:22574–22584. https:// doi. org/ 10. 1021/
acsami. 6b071 96
Duguet JP, Brodard E, Dussert B, Mallevialle J (1985) Improvement
in the effectiveness of ozonation of drinking water through the
use of hydrogen peroxide. Ozone Sci Eng 7:241–258. https:// doi.
org/ 10. 1080/ 01919 51850 85523 66
Farinos RM, Ruotolo LAM (2017) Comparison of the electrooxida-
tion performance of three-dimensional RVC/PbO2 and boron-
doped diamond electrodes. Electrochim Acta 224:32–39.
https:// doi. org/ 10. 1016/j. elect acta. 2016. 12. 025
Fedkiw PS (1981) Ohmic potential drop in flow-through and flow-by
porous electrodes. J Electrochem Soc 128:831–838. https:// doi.
org/ 10. 1149/1. 21275 13
Fierro S, Ouattara L, Calderon EH et al (2009) Investigation of for-
mic acid oxidation on Ti/IrO2 electrodes. Electrochim Acta
54:2053–2061. https:// doi. org/ 10. 1016/j. elect acta. 2008. 06. 060
Fisher V, Gandini D, Laufer S et al (1998) Preparation and char-
acterization of Ti/Diamond electrodes. Electrochim Acta
44:521–524. https:// doi. org/ 10. 1016/ S0013- 4686(98) 00116-9
Foutch GL, Johannes AH (2003) Reactors in process engineering.
Encyclopedia of physical science and technology. Elsevier,
UK, pp 23–43
Frías-Ferrer Á, Tudela I, Louisnard O et al (2011) Optimized design
of an electrochemical filter-press reactor using CFD methods.
Chem Eng J 169:270–281. https:// doi. org/ 10. 1016/j. cej. 2011.
02. 053
Fu W, Wang X, Zheng J et al (2019) Antifouling performance and
mechanisms in an electrochemical ceramic membrane reactor for
wastewater treatment. J Memb Sci 570–571:355–361. https:// doi.
org/ 10. 1016/j. memsci. 2018. 10. 077
Fu R, Zhang P-S, Jiang Y-X et al (2023) Wastewater treatment by
anodic oxidation in electrochemical advanced oxidation process:
Advance in mechanism, direct and indirect oxidation detection
methods. Chemosphere 311:136993. https:// doi. org/ 10. 1016/j.
chemo sphere. 2022. 136993
https://doi.org/10.1016/j.watres.2009.04.007
https://doi.org/10.1016/j.watres.2009.04.007
https://doi.org/10.1023/A:1003541706456
https://doi.org/10.1002/cjce.5450610411
https://doi.org/10.1016/j.cattod.2017.10.027
https://doi.org/10.1016/j.cattod.2017.10.027
https://doi.org/10.1016/j.coelec.2020.100665
https://doi.org/10.1016/0013-4686(94)85175-1
https://doi.org/10.1016/0013-4686(94)85175-1
https://doi.org/10.1007/BF01034049
https://doi.org/10.1007/BF01034049
https://doi.org/10.1007/BF00246946
https://doi.org/10.1016/j.electacta.2019.135373
https://doi.org/10.1016/j.electacta.2009.07.027
https://doi.org/10.1016/j.electacta.2011.12.038
https://doi.org/10.1016/j.cep.2014.07.010
https://doi.org/10.1016/j.electacta.2017.12.025
https://doi.org/10.3390/w12010102https://doi.org/10.3390/w12010102
https://doi.org/10.1016/j.seppur.2022.121112
https://doi.org/10.1016/j.seppur.2022.121112
https://doi.org/10.1007/s40726-021-00176-6
https://doi.org/10.1021/ac60199a054
https://doi.org/10.1016/j.jelechem.2014.08.008
https://doi.org/10.1016/j.jelechem.2014.08.008
https://doi.org/10.1016/j.cej.2010.12.070
https://doi.org/10.1016/j.cej.2020.125568
https://doi.org/10.1016/j.cej.2020.125568
https://doi.org/10.1149/2.0061512eel
https://doi.org/10.1007/s12678-013-0156-z
https://doi.org/10.1021/es4031672
https://doi.org/10.1021/es4031672
https://doi.org/10.1021/acsami.6b07196
https://doi.org/10.1021/acsami.6b07196
https://doi.org/10.1080/01919518508552366
https://doi.org/10.1080/01919518508552366
https://doi.org/10.1016/j.electacta.2016.12.025
https://doi.org/10.1149/1.2127513
https://doi.org/10.1149/1.2127513
https://doi.org/10.1016/j.electacta.2008.06.060
https://doi.org/10.1016/S0013-4686(98)00116-9
https://doi.org/10.1016/j.cej.2011.02.053
https://doi.org/10.1016/j.cej.2011.02.053
https://doi.org/10.1016/j.memsci.2018.10.077
https://doi.org/10.1016/j.memsci.2018.10.077
https://doi.org/10.1016/j.chemosphere.2022.136993
https://doi.org/10.1016/j.chemosphere.2022.136993
1556 Environmental Chemistry Letters (2024) 22:1521–1561
Galus Z, Adams RN (1964) The anodic oxidation of triphenylmethane
dyes. J Am Chem Soc 86:1666–1671. https:// doi. org/ 10. 1021/
ja010 63a003
Ganiyu SO, Gamal El-Din M (2020) Insight into in-situ radical and
non-radical oxidative degradation of organic compounds in
complex real matrix during electrooxidation with boron doped
diamond electrode: a case study of oil sands process water treat-
ment. Appl Catal B Environ 279:119366. https:// doi. org/ 10.
1016/j. apcatb. 2020. 119366
Ganiyu SO, Zhou M, Martínez-Huitle CA (2018) Heterogeneous elec-
tro-Fenton and photoelectro-Fenton processes: a critical review
of fundamental principles and application for water/wastewater
treatment. Appl Catal B Environ 235:103–129. https:// doi. org/
10. 1016/j. apcatb. 2018. 04. 044
Ganiyu SO, Oturan N, Raffy S et al (2019) Efficiency of plasma elabo-
rated sub-stoichiometric titanium oxide (Ti4O7) ceramic elec-
trode for advanced electrochemical degradation of paracetamol
in different electrolyte media. Sep Purif Technol 208:142–152.
https:// doi. org/ 10. 1016/j. seppur. 2018. 03. 076
Ganiyu SO, Martínez-Huitle CA, Rodrigo MA (2020) Renewable
energies driven electrochemical wastewater/soil decontamina-
tion technologies: a critical review of fundamental concepts and
applications. Appl Catal B Environ 270:118857. https:// doi. org/
10. 1016/j. apcatb. 2020. 118857
Ganiyu SO, Martínez-Huitle CA, Oturan MA (2021) Electrochemical
advanced oxidation processes for wastewater treatment: advances
in formation and detection of reactive species and mechanisms.
Curr Opin Electrochem 27:100678. https:// doi. org/ 10. 1016/j.
coelec. 2020. 100678
Gao G, Zhang Q, Vecitis CD (2014) CNT-PVDF composite flow-
through electrode for single-pass sequential reduction-oxidation.
J Mater Chem A 2:6185–6190. https:// doi. org/ 10. 1039/ c3ta1
4080f
García O, Isarain-Chávez E, Garcia-Segura S et al (2013) Degrada-
tion of 2,4-dichlorophenoxyacetic acid by electro-oxidation and
electro-Fenton/BDD processes using a pre-pilot plant. Electro-
catalysis 4:224–234. https:// doi. org/ 10. 1007/ s12678- 013- 0135-4
Garcia-Rodriguez O, Mousset E, Olvera-Vargas H, Lefebvre O (2022)
Electrochemical treatment of highly concentrated wastewater: a
review of experimental and modeling approaches from lab- to
full-scale. Crit Rev Environ Sci Technol 52:240–309. https:// doi.
org/ 10. 1080/ 10643 389. 2020. 18204 28
Garcia-Segura S, Brillas E (2011) Mineralization of the recalcitrant
oxalic and oxamic acids by electrochemical advanced oxida-
tion processes using a boron-doped diamond anode. Water Res
45:2975–2984. https:// doi. org/ 10. 1016/j. watres. 2011. 03. 017
Garcia-Segura S, Ocon JD, Chong MN (2018) Electrochemical oxida-
tion remediation of real wastewater effluents: a review. Process
Saf Environ Prot 113:48–67. https:// doi. org/ 10. 1016/j. psep. 2017.
09. 014
Garcia-Segura S, Nienhauser AB, Fajardo AS et al (2020) Disparities
between experimental and environmental conditions: research
steps toward making electrochemical water treatment a real-
ity. Curr Opin Electrochem 22:9–16. https:// doi. org/ 10. 1016/j.
coelec. 2020. 03. 001
Gayen P, Chen C, Abiade JT, Chaplin BP (2018) Electrochemical oxi-
dation of atrazine and clothianidin on Bi-doped SnO2: TinO2n–1
electrocatalytic reactive electrochemical membranes. Environ
Sci Technol 52:12675–12684. https:// doi. org/ 10. 1021/ acs. est.
8b041 03
Ge M, Li Q, Cao C et al (2017) One-dimensional TiO2 nanotube pho-
tocatalysts for solar water splitting. Adv Sci 4:1600152. https://
doi. org/ 10. 1002/ advs. 20160 0152
Geng P, Chen G (2016) Magnéli Ti4O7 modified ceramic membrane for
electrically-assisted filtration with antifouling property. J Memb
Sci 498:302–314. https:// doi. org/ 10. 1016/j. memsci. 2015. 07. 055
Geng P, Chen G (2017) Antifouling ceramic membrane electrode modi-
fied by Magnéli Ti4O7 for electro-microfiltration of humic acid.
Sep Purif Technol 185:61–71. https:// doi. org/ 10. 1016/j. seppur.
2017. 05. 023
Ghazouani M, Akrout H, Jomaa S et al (2016) Enhancing removal of
nitrates from highly concentrated synthetic wastewaters using
bipolar Si/BDD cell: optimization and mechanism study. J Elec-
troanal Chem 783:28–40. https:// doi. org/ 10. 1016/j. jelec hem.
2016. 10. 048
Ghazouani M, Akrout H, Jellali S, Bousselmi L (2019) Compara-
tive study of electrochemical hybrid systems for the treatment
of real wastewaters from agri-food activities. Sci Total Environ
647:1651–1664. https:// doi. org/ 10. 1016/j. scito tenv. 2018. 08. 023
Ghazouani M, Bousselmi L, Akrout H (2020) Combined electroco-
agulation and electrochemical treatment on BDD electrodes
for simultaneous removal of nitrates and phosphates. J Environ
Chem Eng 8:104509. https:// doi. org/ 10. 1016/j. jece. 2020. 104509
Gherardini L, Michaud PA, Panizza M et al (2001) Electrochemical
oxidation of 4-chlorophenol for wastewater treatment: defini-
tion of normalized current efficiency (φ). J Electrochem Soc
148:D78–D82. https:// doi. org/ 10. 1149/1. 13681 05
Glaze WH, Kang JW, Chapin DH (1987) The chemistry of water treat-
ment processes involving ozone, hydrogen peroxide and ultravio-
let radiation. Ozone Sci Eng 9:335–352. https:// doi. org/ 10. 1080/
01919 51870 85521 48
Gomez-Ruiz B, Gómez-Lavín S, Diban N et al (2017) Efficient elec-
trochemical degradation of poly- and perfluoroalkyl substances
(PFASs) from the effluents of an industrial wastewater treatment
plant. Chem Eng J 322:196–204. https:// doi. org/ 10. 1016/j. cej.
2017. 04. 040
Groenen-Serrano K, Weiss-Hortala E, Savall A, Spiteri P (2013) Role
of hydroxyl radicals during the competitive electrooxidation of
organic compounds on a boron-doped diamond anode. Electro-
catalysis 4:346–352. https:// doi. org/ 10. 1007/ s12678- 013- 0150-5
Gude VG (2016) Wastewater treatment in microbial fuel cells: an over-
view. J Clean Prod 122:287–307. https:// doi. org/ 10. 1016/j. jclep
ro. 2016. 02. 022
Hao Y, Ma H, Proietto F et al (2022) Electrochemical treatment of
wastewater contaminated by organics and containing chlorides:
effect of operative parameters on the abatement of organics and
the generation of chlorinated by-products. Electrochim Acta
402:139480. https:// doi. org/ 10. 1016/j. elect acta. 2021. 139480
Hayfield PCS (1983) Electrode material, electrode and electrochemical
cell. Patent US 4(422):917
He Y, Lin H, Guo Z et al (2019) Recent developments and advances in
boron-doped diamond electrodes for electrochemical oxidation
of organic pollutants. Sep Purif Technol 212:802–821. https://
doi. org/ 10. 1016/j. seppur. 2018. 11. 056
Hu Z, Cai J, Song G et al (2021) Anodic oxidation of organic pollut-
ants: anode fabrication,process hybrid and environmental appli-
cations. Curr Opin Electrochem 26:100659. https:// doi. org/ 10.
1016/j. coelec. 2020. 100659
Hulin LP (1897) Process of electrolytic decomposition of solutions.
Patent US 586:236
Ibrahim DS, Veerabahu C, Palani R et al (2013) Flow dynamics and
mass transfer studies in a tubular electrochemical reactor with a
mesh electrode. Comput Fluids 73:97–103. https:// doi. org/ 10.
1016/j. compfl uid. 2012. 12. 001
Iniesta J, Michaud PA, Panizza M et al (2001a) Electrochemical oxida-
tion of phenol at boron-doped diamond electrode. Electrochim
Acta 46:3573–3578. https:// doi. org/ 10. 1016/ S0013- 4686(01)
00630-2
Iniesta J, Michaud PA, Panizza M, Comninellis C (2001b) Electro-
chemical oxidation of 3-methylpyridine at a boron-doped dia-
mond electrode: application to electroorganic synthesis and
https://doi.org/10.1021/ja01063a003
https://doi.org/10.1021/ja01063a003
https://doi.org/10.1016/j.apcatb.2020.119366
https://doi.org/10.1016/j.apcatb.2020.119366
https://doi.org/10.1016/j.apcatb.2018.04.044
https://doi.org/10.1016/j.apcatb.2018.04.044
https://doi.org/10.1016/j.seppur.2018.03.076
https://doi.org/10.1016/j.apcatb.2020.118857
https://doi.org/10.1016/j.apcatb.2020.118857
https://doi.org/10.1016/j.coelec.2020.100678
https://doi.org/10.1016/j.coelec.2020.100678
https://doi.org/10.1039/c3ta14080f
https://doi.org/10.1039/c3ta14080f
https://doi.org/10.1007/s12678-013-0135-4
https://doi.org/10.1080/10643389.2020.1820428
https://doi.org/10.1080/10643389.2020.1820428
https://doi.org/10.1016/j.watres.2011.03.017
https://doi.org/10.1016/j.psep.2017.09.014
https://doi.org/10.1016/j.psep.2017.09.014
https://doi.org/10.1016/j.coelec.2020.03.001
https://doi.org/10.1016/j.coelec.2020.03.001
https://doi.org/10.1021/acs.est.8b04103
https://doi.org/10.1021/acs.est.8b04103
https://doi.org/10.1002/advs.201600152
https://doi.org/10.1002/advs.201600152
https://doi.org/10.1016/j.memsci.2015.07.055
https://doi.org/10.1016/j.seppur.2017.05.023
https://doi.org/10.1016/j.seppur.2017.05.023
https://doi.org/10.1016/j.jelechem.2016.10.048
https://doi.org/10.1016/j.jelechem.2016.10.048
https://doi.org/10.1016/j.scitotenv.2018.08.023
https://doi.org/10.1016/j.jece.2020.104509
https://doi.org/10.1149/1.1368105
https://doi.org/10.1080/01919518708552148
https://doi.org/10.1080/01919518708552148
https://doi.org/10.1016/j.cej.2017.04.040
https://doi.org/10.1016/j.cej.2017.04.040
https://doi.org/10.1007/s12678-013-0150-5
https://doi.org/10.1016/j.jclepro.2016.02.022
https://doi.org/10.1016/j.jclepro.2016.02.022
https://doi.org/10.1016/j.electacta.2021.139480
https://doi.org/10.1016/j.seppur.2018.11.056
https://doi.org/10.1016/j.seppur.2018.11.056
https://doi.org/10.1016/j.coelec.2020.100659
https://doi.org/10.1016/j.coelec.2020.100659
https://doi.org/10.1016/j.compfluid.2012.12.001
https://doi.org/10.1016/j.compfluid.2012.12.001
https://doi.org/10.1016/S0013-4686(01)00630-2
https://doi.org/10.1016/S0013-4686(01)00630-2
1557Environmental Chemistry Letters (2024) 22:1521–1561
wastewater treatment. Electrochem Commun 3:346–351. https://
doi. org/ 10. 1016/ S1388- 2481(01) 00174-6
Isidro J, Llanos J, Sáez C et al (2018) Can CabECO® technology be
used for the disinfection of highly faecal-polluted surface water?
Chemosphere 209:346–352. https:// doi. org/ 10. 1016/j. chemo
sphere. 2018. 06. 106
Isidro J, Brackemeyer D, Sáez C et al (2019) Operating the CabECO®
membrane electrolytic technology in continuous mode for the
direct disinfection of highly fecal-polluted water. Sep Purif Tech-
nol 208:110–115. https:// doi. org/ 10. 1016/j. seppur. 2018. 04. 070
Jiang H, Lee PS, Li C (2013) 3D carbon based nanostructures for
advanced supercapacitors. Energy Environ Sci 6:41–53. https://
doi. org/ 10. 1039/ c2ee2 3284g
Jing Y, Chaplin BP (2016) Electrochemical impedance spectroscopy
study of membrane fouling characterization at a conductive sub-
stoichiometric TiO2 reactive electrochemical membrane: trans-
mission line model development. J Memb Sci 511:238–249.
https:// doi. org/ 10. 1016/j. memsci. 2016. 03. 032
Jing Y, Chaplin BP (2017) Mechanistic study of the validity of using
hydroxyl radical probes to characterize electrochemical advanced
oxidation processes. Environ Sci Technol 51:2355–2365. https://
doi. org/ 10. 1021/ acs. est. 6b055 13
Jing Y, Guo L, Chaplin BP (2016) Electrochemical impedance spec-
troscopy study of membrane fouling and electrochemical regen-
eration at a sub-stoichiometric TiO2 reactive electrochemical
membrane. J Memb Sci 510:510–523. https:// doi. org/ 10. 1016/j.
memsci. 2016. 03. 029
Kapałka A, Fóti G, Comninellis C (2008) Kinetic modelling of the
electrochemical mineralization of organic pollutants for waste-
water treatment. J Appl Electrochem 38:7–16. https:// doi. org/ 10.
1007/ s10800- 007- 9365-6
Kapałka A, Fóti G, Comninellis C (2009) The importance of elec-
trode material in environmental electrochemistry. Formation
and reactivity of free hydroxyl radicals on boron-doped diamond
electrodes. Electrochim Acta 54:2018–2023. https:// doi. org/ 10.
1016/j. elect acta. 2008. 06. 045
Khalid YS, Misal SN, Mehraeen S, Chaplin BP (2022) Reactive-
transport modeling of electrochemical oxidation of perfluoro-
alkyl substances in porous flow-through electrodes. ACS ES&T
Eng 2:713–725. https:// doi. org/ 10. 1021/ acses tengg. 1c003 62
Kiendrebeogo M, Karimi Estahbanati MR, Khosravanipour Mosta-
fazadeh A et al (2021) Treatment of microplastics in water by
anodic oxidation: a case study for polystyrene. Environ Pollut
269:116168. https:// doi. org/ 10. 1016/j. envpol. 2020. 116168
Kiendrebeogo M, Karimi Estahbanati MR, Ouarda Y et al (2022)
Electrochemical degradation of nanoplastics in water: analy-
sis of the role of reactive oxygen species. Sci Total Environ
808:151897. https:// doi. org/ 10. 1016/j. scito tenv. 2021. 151897
Kim C, Kim S, Choi J et al (2014) Blue TiO2 nanotube array as an
oxidant generating novel anode material fabricated by simple
cathodic polarization. Electrochim Acta 141:113–119. https://
doi. org/ 10. 1016/j. elect acta. 2014. 07. 062
Kirk DW, Sharifian H, Foulkes FR (1985) Anodic oxidation of ani-
line for waste water treatment. J Appl Electrochem 15:285–
292. https:// doi. org/ 10. 1007/ BF006 20944
Kislyi A, Moroz I, Guliaeva V et al (2023) Electrochemical oxida-
tion of organic pollutants in aqueous solution using a Ti4O7
particle anode. Membranes (basel) 13:521. https:// doi. org/ 10.
3390/ membr anes1 30505 21
Kiwi J, Lopez A, Nadtochenko V (2000) Mechanism and kinetics
of the OH-radical intervention during Fenton oxidation in the
presence of a significant amount of radical scavenger (Cl- ).
Environ Sci Technol 34:2162–2168. https:// doi. org/ 10. 1021/
es991 406i
Kothari MS, Shah KA (2020) Electrochemical oxidation for decolori-
zation of rhodamine-B dye using mixed metal oxide electrode:
modeling and optimization. Water Sci Technol 81:720–731.
https:// doi. org/ 10. 2166/ wst. 2020. 151
Kötz R, Stucki S, Carcer B (1991) Electrochemical waste water treat-
ment using high overvoltage anodes. Part I: physical and elec-
trochemical properties of SnO2 anodes. J Appl Electrochem
21:14–20. https:// doi. org/ 10. 1007/ BF011 03823
Kuhn AT (1971) Electrolytic decomposition of cyanides, phenols and
thiocyanates in effluent streams-a literature review. J Appl Chem
Biotechnol 21:29–34. https:// doi. org/ 10. 1002/ jctb. 50202 10201
Kumar A, Barbhuiya NH, Singh SP (2022) Magnéli phase titanium
sub-oxides synthesis, fabrication and its application for environ-
mental remediation: current status and prospect. Chemosphere
307:135878. https:// doi. org/ 10. 1016/j. chemo sphere. 2022. 135878
Lan Y, Coetsier C, Causserand C, Groenen Serrano K (2018) An exper-
imental and modelling study of the electrochemical oxidation of
pharmaceuticals using a boron-doped diamond anode. Chem Eng
J 333:486–494. https:// doi. org/ 10. 1016/j. cej. 2017. 09. 164
Law HD, Perkin FM (1905) Electrolytic oxidationof hydrocarbons of
the benzene series. Part I., hydrocarbons, containing the methyl
group. Trans Faraday Soc 1:31. https:// doi. org/ 10. 1039/ tf905
01000 31
Li D, Tang J, Zhou X et al (2016) Electrochemical degradation of
pyridine by Ti/SnO2-Sb tubular porous electrode. Chemosphere
149:49–56. https:// doi. org/ 10. 1016/j. chemo sphere. 2016. 01. 078
Lin M-H, Bulman DM, Remucal CK, Chaplin BP (2020) Chlorin-
ated byproduct formation during the electrochemical advanced
oxidation process at Magnéli phase Ti4O7 electrodes. Environ
Sci Technol 54:12673–12683. https:// doi. org/ 10. 1021/ acs. est.
0c039 16
Liu H, Vajpayee A, Vecitis CD (2013) Bismuth-doped tin oxide-
coated carbon nanotube network: improved anode stability and
efficiency for flow-through organic electrooxidation. ACS Appl
Mater Interfaces 5:10054–10066. https:// doi. org/ 10. 1021/ am402
621v
Liu J, Ren N, Qu C et al (2022) Recent advances in the reactor design
for industrial wastewater treatment by electro-oxidation process.
Water 14:3711. https:// doi. org/ 10. 3390/ w1422 3711
Łukaszewicz G, Kalita P (2016) Navier-Stokes equations. An Intro-
duction with applications. Springer International Publishing,
Switzerland
Ma J, Gao M, Shi H et al (2021) Progress in research and develop-
ment of particle electrodes for three-dimensional electrochemi-
cal treatment of wastewater: a review. Environ Sci Pollut Res
28:47800–47824. https:// doi. org/ 10. 1007/ s11356- 021- 13785-x
Ma J, Trellu C, Oturan N et al (2022) Development of Ti/TiOx
foams for removal of organic pollutants from water: influ-
ence of porous structure of Ti substrate. Appl Catal B Environ
317:121736. https:// doi. org/ 10. 1016/j. apcatb. 2022. 121736
Ma J, Trellu C, Oturan N et  al (2023a) Porous Magnéli phase
obtained from 3D printing for efficient anodic oxidation pro-
cess. Chem Eng J 456:141047. https:// doi. org/ 10. 1016/j. cej.
2022. 141047
Ma J, Trellu C, Skolotneva E et al (2023b) Investigating the reactiv-
ity of TiOx and BDD anodes for electro-oxidation of organic
pollutants by experimental and modeling approaches. Electro-
chim Acta 439:141513. https:// doi. org/ 10. 1016/j. elect acta. 2022.
141513
Magro C, Mateus EP, Paz-Garcia JM, Ribeiro AB (2020) Emerging
organic contaminants in wastewater: understanding electrochemi-
cal reactors for triclosan and its by-products degradation. Che-
mosphere 247:125758. https:// doi. org/ 10. 1016/j. chemo sphere.
2019. 125758
Mareev S, Skolotneva E, Cretin M, Nikonenko V (2021) Modeling
the formation of gas bubbles inside the pores of reactive electro-
chemical membranes in the process of the anodic oxidation of
https://doi.org/10.1016/S1388-2481(01)00174-6
https://doi.org/10.1016/S1388-2481(01)00174-6
https://doi.org/10.1016/j.chemosphere.2018.06.106
https://doi.org/10.1016/j.chemosphere.2018.06.106
https://doi.org/10.1016/j.seppur.2018.04.070
https://doi.org/10.1039/c2ee23284g
https://doi.org/10.1039/c2ee23284g
https://doi.org/10.1016/j.memsci.2016.03.032
https://doi.org/10.1021/acs.est.6b05513
https://doi.org/10.1021/acs.est.6b05513
https://doi.org/10.1016/j.memsci.2016.03.029
https://doi.org/10.1016/j.memsci.2016.03.029
https://doi.org/10.1007/s10800-007-9365-6
https://doi.org/10.1007/s10800-007-9365-6
https://doi.org/10.1016/j.electacta.2008.06.045
https://doi.org/10.1016/j.electacta.2008.06.045
https://doi.org/10.1021/acsestengg.1c00362
https://doi.org/10.1016/j.envpol.2020.116168
https://doi.org/10.1016/j.scitotenv.2021.151897
https://doi.org/10.1016/j.electacta.2014.07.062
https://doi.org/10.1016/j.electacta.2014.07.062
https://doi.org/10.1007/BF00620944
https://doi.org/10.3390/membranes13050521
https://doi.org/10.3390/membranes13050521
https://doi.org/10.1021/es991406i
https://doi.org/10.1021/es991406i
https://doi.org/10.2166/wst.2020.151
https://doi.org/10.1007/BF01103823
https://doi.org/10.1002/jctb.5020210201
https://doi.org/10.1016/j.chemosphere.2022.135878
https://doi.org/10.1016/j.cej.2017.09.164
https://doi.org/10.1039/tf9050100031
https://doi.org/10.1039/tf9050100031
https://doi.org/10.1016/j.chemosphere.2016.01.078
https://doi.org/10.1021/acs.est.0c03916
https://doi.org/10.1021/acs.est.0c03916
https://doi.org/10.1021/am402621v
https://doi.org/10.1021/am402621v
https://doi.org/10.3390/w14223711
https://doi.org/10.1007/s11356-021-13785-x
https://doi.org/10.1016/j.apcatb.2022.121736
https://doi.org/10.1016/j.cej.2022.141047
https://doi.org/10.1016/j.cej.2022.141047
https://doi.org/10.1016/j.electacta.2022.141513
https://doi.org/10.1016/j.electacta.2022.141513
https://doi.org/10.1016/j.chemosphere.2019.125758
https://doi.org/10.1016/j.chemosphere.2019.125758
1558 Environmental Chemistry Letters (2024) 22:1521–1561
organic compounds. Int J Mol Sci 22:5477. https:// doi. org/ 10.
3390/ ijms2 21154 77
Marshall AT, Herritsch A (2018) Understanding how the oxygen evo-
lution reaction kinetics influences electrochemical wastewater
oxidation. Electrochim Acta 282:448–458. https:// doi. org/ 10.
1016/j. elect acta. 2018. 06. 065
Martínez-Huitle CA, Ferro S (2006) Electrochemical oxidation of
organic pollutants for the wastewater treatment: direct and indi-
rect processes. Chem Soc Rev 35:1324–1340. https:// doi. org/
10. 1039/ b5176 32h
Martínez-Huitle CA, Rodrigo MA, Sirés I, Scialdone O (2015) Single
and coupled electrochemical processes and reactors for the abate-
ment of organic water pollutants: a critical review. Chem Rev
115:13362–13407. https:// doi. org/ 10. 1021/ acs. chemr ev. 5b003 61
Martínez-Huitle CA, Scialdone O, Rodrigo MA (2018) Electrochemi-
cal water and wastewater treatment. Elsevier Science
Mascia M, Vacca A, Palmas S, Polcaro AM (2007) Kinetics of the
electrochemical oxidation of organic compounds at BDD anodes:
modelling of surface reactions. J Appl Electrochem 37:71–76.
https:// doi. org/ 10. 1007/ s10800- 006- 9217-9
Mascia M, Vacca A, Polcaro AM et al (2010) Electrochemical treat-
ment of phenolic waters in presence of chloride with boron-
doped diamond (BDD) anodes: experimental study and math-
ematical model. J Hazard Mater 174:314–322. https:// doi. org/
10. 1016/j. jhazm at. 2009. 09. 053
Mascia M, Vacca A, Palmas S (2012) Fixed bed reactors with three
dimensional electrodes for electrochemical treatment of waters
for disinfection. Chem Eng J 211–212:479–487. https:// doi. org/
10. 1016/j. cej. 2012. 09. 091
Mascia M, Vacca A, Palmas S (2013) Electrochemical treatment as a
pre-oxidative step for algae removal using Chlorella vulgaris as
a model organism and BDD anodes. Chem Eng J 219:512–519.
https:// doi. org/ 10. 1016/j. cej. 2012. 12. 097
Mascia M, Monasterio S, Vacca A, Palmas S (2016) Electrochemical
treatment of water containing Microcystis aeruginosa in a fixed
bed reactor with three-dimensional conductive diamond anodes.
J Hazard Mater 319:111–120. https:// doi. org/ 10. 1016/j. jhazm at.
2016. 03. 004
McBeath ST, Wilkinson DP, Graham NJD (2019) Application of
boron-doped diamond electrodes for the anodic oxidation
of pesticide micropollutants in a water treatment process: a
critical review. Environ Sci Water Res Technol 5:2090–2107.
https:// doi. org/ 10. 1039/ C9EW0 0589G
Mengelizadeh N, Pourzamani H, Saloot MK et al (2019) Electro-
chemical degradation of reactive black 5 using three-dimen-
sional electrochemical system based on multiwalled carbon
nanotubes. J Environ Eng 145:04019021. https:// doi. org/ 10.
1061/ (ASCE) EE. 1943- 7870. 00015 17
Mieluch J, Sadkowski A, Wild J, Zoltowski P (1975) Electrochemical
oxidation of phenolic compounds in aqueous solutions [Ele-
ktrochemiczne utlenianie zwiazkow fenolowych w roztworze
wodnym]. Przem Chem 54:513–516
Misal SN, Lin M-H, Mehraeen S, Chaplin BP (2020) Modeling
electrochemical oxidation and reduction of sulfamethoxazole
using electrocatalytic reactive electrochemical membranes. J
Hazard Mater 384:121420. https:// doi. org/ 10. 1016/j. jhazm at.
2019. 121420
Monteil H, Pechaud Y, Oturan N et al (2021) Pilot scale continuous
reactor forwater treatment by electrochemical advanced oxida-
tion processes: development of a new hydrodynamic/reactive
combined model. Chem Eng J 404:127048. https:// doi. org/ 10.
1016/j. cej. 2020. 127048
Mora-Gómez J, García-Gabaldón M, Carrillo-Abad J et al (2020)
Influence of the reactor configuration and the supporting
electrolyte concentration on the electrochemical oxidation of
Atenolol using BDD and SnO2 ceramic electrodes. Sep Purif
Technol 241:116684. https:// doi. org/ 10. 1016/j. seppur. 2020.
116684
Moreira FC, Boaventura RAR, Brillas E, Vilar VJP (2017) Electro-
chemical advanced oxidation processes: a review on their appli-
cation to synthetic and real wastewaters. Appl Catal B Environ
202:217–261. https:// doi. org/ 10. 1016/j. apcatb. 2016. 08. 037
Mostafa E, Reinsberg P, Garcia-Segura S, Baltruschat H (2018) Chlo-
rine species evolution during electrochlorination on boron-doped
diamond anodes: in-situ electrogeneration of Cl2, Cl2O and ClO2.
Electrochim Acta 281:831–840. https:// doi. org/ 10. 1016/j. elect
acta. 2018. 05. 099
Mousset E (2022) Interest of micro-reactors for the implementation
of advanced electrocatalytic oxidation with boron-doped dia-
mond anode for wastewater treatment. Curr Opin Electrochem
32:100897. https:// doi. org/ 10. 1016/j. coelec. 2021. 100897
Najafinejad MS, Chianese S, Fenti A et al (2023) Application of elec-
trochemical oxidation for water and wastewater treatment: an
overview. Molecules 28:4208. https:// doi. org/ 10. 3390/ molec
ules2 81042 08
Nakayama S, Esaki K, Namba K et al (1979) Improved ozonation in
aqueous systems. Ozone Sci Eng 1:119–131. https:// doi. org/ 10.
1080/ 01919 51790 85508 39
Nava JL, Núñez F, González I (2007) Electrochemical incineration of
p-cresol and o-cresol in the filter-press-type FM01-LC electro-
chemical cell using BDD electrodes in sulfate media at pH 0.
Electrochim Acta 52:3229–3235. https:// doi. org/ 10. 1016/j. elect
acta. 2006. 09. 072
Nava JL, Recéndiz A, Acosta JC, González I (2008) Electrochemi-
cal incineration of vinasse in filter-press-type FM01-LC reac-
tor using 3D BDD electrode. Water Sci Technol 58:2413–2419.
https:// doi. org/ 10. 2166/ wst. 2008. 558
Nava JL, Sirés I, Brillas E (2014) Electrochemical incineration of
indigo. A comparative study between 2D (plate) and 3D (mesh)
BDD anodes fitted into a filter-press reactor. Environ Sci Pollut
Res 21:8485–8492. https:// doi. org/ 10. 1007/ s11356- 014- 2781-3
Neodo S, Rosestolato D, Ferro S, De Battisti A (2012) On the elec-
trolysis of dilute chloride solutions: influence of the electrode
material on Faradaic efficiency for active chlorine, chlorate and
perchlorate. Electrochim Acta 80:282–291. https:// doi. org/ 10.
1016/j. elect acta. 2012. 07. 017
Newman J, Tiedemann W (1975) Porous-electrode theory with bat-
tery applications. AIChE J 21:25–41. https:// doi. org/ 10. 1002/
aic. 69021 0103
Nilsson A, Ronlán A, Parker VD (1973) Anodic oxidation of phenolic
compounds. Part III. Anodic hydroxylation of phenols. A simple
general synthesis of 4-alkyl-4-hydroxycyclo-hexa-2,5-dienones
from 4-alkylphenols. J Chem Soc Perkin Trans 1:2337–2345.
https:// doi. org/ 10. 1039/ P1973 00023 37
Oxley JE, Johnson GK, Buzalski BT (1964) The anodic oxidation of
methanol: open-circuit transient reactions. Electrochim Acta
9:897–910. https:// doi. org/ 10. 1016/ 0013- 4686(64) 85040-4
Panizza M, Cerisola G (2009) Direct and mediated anodic oxidation
of organic pollutants. Chem Rev 109:6541–6569. https:// doi. org/
10. 1021/ cr900 1319
Panizza M, Michaud PA, Cerisola G, Comninellis C (2001a) Anodic
oxidation of 2-naphthol at boron-doped diamond electrodes. J
Electroanal Chem 507:206–214. https:// doi. org/ 10. 1016/ S0022-
0728(01) 00398-9
Panizza M, Michaud PA, Cerisola G, Comninellis CH (2001b) Elec-
trochemical treatment of wastewaters containing organic pollut-
ants on boron-doped diamond electrodes: prediction of specific
energy consumption and required electrode area. Electrochem
Commun 3:336–339. https:// doi. org/ 10. 1016/ S1388- 2481(01)
00166-7
Panizza M, Kapałka A, Comninellis C (2008) Oxidation of organic
pollutants on BDD anodes using modulated current electrolysis.
https://doi.org/10.3390/ijms22115477
https://doi.org/10.3390/ijms22115477
https://doi.org/10.1016/j.electacta.2018.06.065
https://doi.org/10.1016/j.electacta.2018.06.065
https://doi.org/10.1039/b517632h
https://doi.org/10.1039/b517632h
https://doi.org/10.1021/acs.chemrev.5b00361
https://doi.org/10.1007/s10800-006-9217-9
https://doi.org/10.1016/j.jhazmat.2009.09.053
https://doi.org/10.1016/j.jhazmat.2009.09.053
https://doi.org/10.1016/j.cej.2012.09.091
https://doi.org/10.1016/j.cej.2012.09.091
https://doi.org/10.1016/j.cej.2012.12.097
https://doi.org/10.1016/j.jhazmat.2016.03.004
https://doi.org/10.1016/j.jhazmat.2016.03.004
https://doi.org/10.1039/C9EW00589G
https://doi.org/10.1061/(ASCE)EE.1943-7870.0001517
https://doi.org/10.1061/(ASCE)EE.1943-7870.0001517
https://doi.org/10.1016/j.jhazmat.2019.121420
https://doi.org/10.1016/j.jhazmat.2019.121420
https://doi.org/10.1016/j.cej.2020.127048
https://doi.org/10.1016/j.cej.2020.127048
https://doi.org/10.1016/j.seppur.2020.116684
https://doi.org/10.1016/j.seppur.2020.116684
https://doi.org/10.1016/j.apcatb.2016.08.037
https://doi.org/10.1016/j.electacta.2018.05.099
https://doi.org/10.1016/j.electacta.2018.05.099
https://doi.org/10.1016/j.coelec.2021.100897
https://doi.org/10.3390/molecules28104208
https://doi.org/10.3390/molecules28104208
https://doi.org/10.1080/01919517908550839
https://doi.org/10.1080/01919517908550839
https://doi.org/10.1016/j.electacta.2006.09.072
https://doi.org/10.1016/j.electacta.2006.09.072
https://doi.org/10.2166/wst.2008.558
https://doi.org/10.1007/s11356-014-2781-3
https://doi.org/10.1016/j.electacta.2012.07.017
https://doi.org/10.1016/j.electacta.2012.07.017
https://doi.org/10.1002/aic.690210103
https://doi.org/10.1002/aic.690210103
https://doi.org/10.1039/P19730002337
https://doi.org/10.1016/0013-4686(64)85040-4
https://doi.org/10.1021/cr9001319
https://doi.org/10.1021/cr9001319
https://doi.org/10.1016/S0022-0728(01)00398-9
https://doi.org/10.1016/S0022-0728(01)00398-9
https://doi.org/10.1016/S1388-2481(01)00166-7
https://doi.org/10.1016/S1388-2481(01)00166-7
1559Environmental Chemistry Letters (2024) 22:1521–1561
Electrochim Acta 53:2289–2295. https:// doi. org/ 10. 1016/j. elect
acta. 2007. 09. 044
Papouchado L, Sandford RW, Petrie G, Adams RN (1975) Anodic oxi-
dation pathways of phenolic compounds Part 2. Stepwise elec-
tron transfers and coupled hydroxylations. J Electroanal Chem
65:275–284. https:// doi. org/ 10. 1016/ 0368- 1874(75) 85123-9
Periyasamy S, Lin X, Ganiyu SO et al (2022) Insight into BDD elec-
trochemical oxidation of florfenicol in water: kinetics, reaction
mechanism, and toxicity. Chemosphere 288:132433. https:// doi.
org/ 10. 1016/j. chemo sphere. 2021. 132433
Piersma BJ, Gileadi E (1966) The mechanism of electrochemical oxi-
dation of organic fuels. In: Modern Aspects of Electrochemistry
No. 4. Springer US, Boston, MA, pp 47–175
Pillai IMS, Gupta AK (2015) Batch and continuous flow anodic oxida-
tion of 2,4-dinitrophenol: modeling, degradation pathway and
toxicity. J Electroanal Chem 756:108–117. https:// doi. org/ 10.
1016/j. jelec hem. 2015. 08. 020
Polcaro AM, Palmas S (1997) Electrochemical oxidation of chloro-
phenols. Ind Eng Chem Res 36:1791–1798. https:// doi. org/ 10.
1021/ ie960 557g
Polcaro AM, Palmas S, Renoldi F, Mascia M (1999) On the perfor-
mance of Ti/SnO2 and Ti/PbO2 anodes in electrochemical degra-
dation of 2-chlorophenol for wastewater treatment. J Appl Elec-
trochem 29:147–151. https:// doi. org/ 10. 1023/A: 10034 11906 212
Polcaro AM, Vacca A, Palmas S, Mascia M (2003) Electrochemical
treatment of wastewater containing phenolic compounds: oxida-
tion at boron-doped diamond electrodes. J Appl Electrochem
33:885–892. https:// doi. org/ 10. 1023/A: 10258 15828 503
Polcaro AM, Vacca A, Mascia Met al (2009) Electrochemical treat-
ment of waters with BDD anodes: kinetics of the reactions
involving chlorides. J Appl Electrochem 39:2083–2092. https://
doi. org/ 10. 1007/ s10800- 009- 9870-x
Popović ND, Johnson DC (1998) A ring−disk study of the competition
between anodic oxygen-transfer and dioxygen-evolution reac-
tions. Anal Chem 70:468–472. https:// doi. org/ 10. 1021/ ac970
7803
Popović NĐ, Cox JA, Johnson DC (1998) A mathematical model for
anodic oxygen-transfer reactions at Bi(V)-doped PbO2-film
electrodes. J Electroanal Chem 456:203–209. https:// doi. org/ 10.
1016/ S0022- 0728(98) 00219-8
Porada S, Zhao R, van der Wal A et al (2013) Review on the science
and technology of water desalination by capacitive deionization.
Prog Mater Sci 58:1388–1442. https:// doi. org/ 10. 1016/j. pmats
ci. 2013. 03. 005
Qi G, Wang X, Zhao J et al (2022) Fabrication and characterization
of the porous Ti4O7 reactive electrochemical membrane. Front
Chem 9:1–11. https:// doi. org/ 10. 3389/ fchem. 2021. 833024
Radjenovic J, Duinslaeger N, Avval SS, Chaplin BP (2020) Facing
the challenge of poly- and perfluoroalkyl substances in water:
Is electrochemical oxidation the answer? Environ Sci Technol
54:14815–14829. https:// doi. org/ 10. 1021/ acs. est. 0c062 12
Ricardo IA, Alberto EA, Silva Júnior AH et al (2021) A critical review
on microplastics, interaction with organic and inorganic pollut-
ants, impacts and effectiveness of advanced oxidation processes
applied for their removal from aqueous matrices. Chem Eng J
424:130282. https:// doi. org/ 10. 1016/j. cej. 2021. 130282
Rivera FF, Cruz-Díaz MR, Rivero EP, González I (2010) Analysis
and interpretation of residence time distribution experimental
curves in FM01-LC reactor using axial dispersion and plug dis-
persion exchange models with closed–closed boundary condi-
tions. Electrochim Acta 56:361–371. https:// doi. org/ 10. 1016/j.
elect acta. 2010. 08. 069
Rivera FF, de León CP, Nava JL, Walsh FC (2015a) The filter-press
FM01-LC laboratory flow reactor and its applications. Electro-
chim Acta 163:338–354. https:// doi. org/ 10. 1016/j. elect acta. 2015.
02. 179
Rivera FF, de León CP, Walsh FC, Nava JL (2015b) The reaction envi-
ronment in a filter-press laboratory reactor: the FM01-LC flow
cell. Electrochim Acta 161:436–452. https:// doi. org/ 10. 1016/j.
elect acta. 2015. 02. 161
Rivera FF, Pérez T, Castañeda LF, Nava JL (2021) Mathematical
modeling and simulation of electrochemical reactors: a critical
review. Chem Eng Sci 239:116622. https:// doi. org/ 10. 1016/j. ces.
2021. 116622
Rivero EP, Rivera FF, Cruz-Díaz MR et al (2012) Numerical simula-
tion of mass transport in a filter press type electrochemical reac-
tor FM01-LC: comparison of predicted and experimental mass
transfer coefficient. Chem Eng Res Des 90:1969–1978. https://
doi. org/ 10. 1016/j. cherd. 2012. 04. 010
Rivero EP, Rodríguez FA, Cruz-Díaz MR, González I (2018) Reac-
tive diffusion migration layer and mass transfer wall function to
model active chlorine generation in a filter press type electro-
chemical reactor for organic pollutant degradation. Chem Eng
Res Des 138:533–545. https:// doi. org/ 10. 1016/j. cherd. 2018. 07.
010
Rodgers JD, Jedral W, Bunce NJ (1999) Electrochemical oxidation of
chlorinated phenols. Environ Sci Technol 33:1453–1457. https://
doi. org/ 10. 1021/ es980 8189
Rodrigo MA, Michaud PA, Duo I et al (2001) Oxidation of 4-chloro-
phenol at boron-doped diamond electrode for wastewater treat-
ment. J Electrochem Soc 148:60–64. https:// doi. org/ 10. 1149/1.
13625 45
Rodriguez S, Santos A, Romero A, Vicente F (2012) Kinetic of oxida-
tion and mineralization of priority and emerging pollutants by
activated persulfate. Chem Eng J 213:225–234. https:// doi. org/
10. 1016/j. cej. 2012. 09. 077
Rosestolato D, Fregoni J, Ferro S, De Battisti A (2014) Influence of
the nature of the electrode material and process variables on
the kinetics of the chlorine evolution reaction. The case of
 IrO2-based electrocatalysts. Electrochim Acta 139:180–189.
https:// doi. org/ 10. 1016/j. elect acta. 2014. 07. 037
Roy Ghatak H (2020) Simulated process integration of wastewater
electrooxidation with recuperated micro gas turbine for energy
recovery. Int J Hydrog Energy 45:31466–31480. https:// doi. org/
10. 1016/j. ijhyd ene. 2020. 08. 161
Russo D (2021) Kinetic modeling of advanced oxidation processes
using microreactors: challenges and opportunities for scale-up.
Appl Sci 11:1042. https:// doi. org/ 10. 3390/ app11 031042
Saleh MM (2007) Simulation of oxygen evolution reaction at porous
anode from flowing electrolytes. J Solid State Electrochem
11:811–820. https:// doi. org/ 10. 1007/ s10008- 006- 0227-7
Saleh MM (2009) Effects of gas bubbles on the concentration profiles
and conversion efficiency of three-dimensional packed-bed elec-
trodes. J Solid State Electrochem 13:343–351. https:// doi. org/ 10.
1007/ s10008- 008- 0545-z
Saleh MM, Awad MI, Kitamura F, Ohsaka T (2006) Mathematical
modeling of gas evolution from flowing electrolytes on stable
porous anodes of finite matrix phase conductivity. Electrochim
Acta 51:6331–6337. https:// doi. org/ 10. 1016/j. elect acta. 2006. 04.
017
Salvestrini S, Fenti A, Chianese S et al (2020) Electro-oxidation of
humic acids using platinum electrodes: an experimental approach
and kinetic modelling. Water 12:2250. https:// doi. org/ 10. 3390/
w1208 2250
Sandoval MA, Calzadilla W, Salazar R (2022) Influence of reactor
design on the electrochemical oxidation and disinfection of
wastewaters using boron-doped diamond electrodes. Curr Opin
Electrochem 33:100939. https:// doi. org/ 10. 1016/j. coelec. 2022.
100939
Scialdone O, Proietto F, Galia A (2021) Electrochemical production
and use of chlorinated oxidants for the treatment of wastewater
contaminated by organic pollutants and disinfection. Curr Opin
https://doi.org/10.1016/j.electacta.2007.09.044
https://doi.org/10.1016/j.electacta.2007.09.044
https://doi.org/10.1016/0368-1874(75)85123-9
https://doi.org/10.1016/j.chemosphere.2021.132433
https://doi.org/10.1016/j.chemosphere.2021.132433
https://doi.org/10.1016/j.jelechem.2015.08.020
https://doi.org/10.1016/j.jelechem.2015.08.020
https://doi.org/10.1021/ie960557g
https://doi.org/10.1021/ie960557g
https://doi.org/10.1023/A:1003411906212
https://doi.org/10.1023/A:1025815828503
https://doi.org/10.1007/s10800-009-9870-x
https://doi.org/10.1007/s10800-009-9870-x
https://doi.org/10.1021/ac9707803
https://doi.org/10.1021/ac9707803
https://doi.org/10.1016/S0022-0728(98)00219-8
https://doi.org/10.1016/S0022-0728(98)00219-8
https://doi.org/10.1016/j.pmatsci.2013.03.005
https://doi.org/10.1016/j.pmatsci.2013.03.005
https://doi.org/10.3389/fchem.2021.833024
https://doi.org/10.1021/acs.est.0c06212
https://doi.org/10.1016/j.cej.2021.130282
https://doi.org/10.1016/j.electacta.2010.08.069
https://doi.org/10.1016/j.electacta.2010.08.069
https://doi.org/10.1016/j.electacta.2015.02.179
https://doi.org/10.1016/j.electacta.2015.02.179
https://doi.org/10.1016/j.electacta.2015.02.161
https://doi.org/10.1016/j.electacta.2015.02.161
https://doi.org/10.1016/j.ces.2021.116622
https://doi.org/10.1016/j.ces.2021.116622
https://doi.org/10.1016/j.cherd.2012.04.010
https://doi.org/10.1016/j.cherd.2012.04.010
https://doi.org/10.1016/j.cherd.2018.07.010
https://doi.org/10.1016/j.cherd.2018.07.010
https://doi.org/10.1021/es9808189
https://doi.org/10.1021/es9808189
https://doi.org/10.1149/1.1362545
https://doi.org/10.1149/1.1362545
https://doi.org/10.1016/j.cej.2012.09.077
https://doi.org/10.1016/j.cej.2012.09.077
https://doi.org/10.1016/j.electacta.2014.07.037
https://doi.org/10.1016/j.ijhydene.2020.08.161
https://doi.org/10.1016/j.ijhydene.2020.08.161
https://doi.org/10.3390/app11031042
https://doi.org/10.1007/s10008-006-0227-7
https://doi.org/10.1007/s10008-008-0545-z
https://doi.org/10.1007/s10008-008-0545-z
https://doi.org/10.1016/j.electacta.2006.04.017
https://doi.org/10.1016/j.electacta.2006.04.017https://doi.org/10.3390/w12082250
https://doi.org/10.3390/w12082250
https://doi.org/10.1016/j.coelec.2022.100939
https://doi.org/10.1016/j.coelec.2022.100939
1560 Environmental Chemistry Letters (2024) 22:1521–1561
Electrochem 27:100682. https:// doi. org/ 10. 1016/j. coelec. 2020.
100682
Seibert D, Zorzo CF, Borba FH et al (2020) Occurrence, statutory
guideline values and removal of contaminants of emerging con-
cern by electrochemical advanced oxidation processes: a review.
Sci Total Environ 748:141527. https:// doi. org/ 10. 1016/j. scito
tenv. 2020. 141527
Serrano K, Michaud PA, Comninellis C, Savall A (2002) Electrochemi-
cal preparation of peroxodisulfuric acid using boron doped dia-
mond thin film electrodes. Electrochim Acta 48:431–436. https://
doi. org/ 10. 1016/ S0013- 4686(02) 00688-6
Shahid MK, Kashif A, Fuwad A, Choi Y (2021) Current advances in
treatment technologies for removal of emerging contaminants
from water: a critical review. Coord Chem Rev 442:213993.
https:// doi. org/ 10. 1016/j. ccr. 2021. 213993
Sharifian H, Kirk DW (1986) Electrochemical oxidation of phenol. J
Electrochem Soc 133:921–924. https:// doi. org/ 10. 1149/1. 21087
63
Simond O, Comninellis C (1997) Anodic oxidation of organics on
Ti/IrO2 anodes using Nafion® as electrolyte. Electrochim Acta
42:2013–2018. https:// doi. org/ 10. 1016/ S0013- 4686(97) 85476-X
Simond O, Schaller V, Comninellis C (1997) Theoretical model for
the anodic oxidation of organics on metal oxide electrodes.
Electrochim Acta 42:2009–2012. https:// doi. org/ 10. 1016/ S0013-
4686(97) 85475-8
Sirés I, Brillas E, Oturan MA et al (2014) Electrochemical advanced
oxidation processes: today and tomorrow. A review. Envi-
ron Sci Pollut Res 21:8336–8367. https:// doi. org/ 10. 1007/
s11356- 014- 2783-1
Skban Ibrahim D, Seethala Devi P, Veerababhu C, Balasubramanian
N (2014) Treatment of petroleum effluent using a tubular elec-
trochemical reactor. Pet Sci Technol 32:1932–1939. https:// doi.
org/ 10. 1080/ 10916 466. 2012. 701693
Skolotneva E, Trellu C, Cretin M, Mareev S (2020) A 2D convection-
diffusion model of anodic oxidation of organic compounds medi-
ated by hydroxyl radicals using porous reactive electrochemical
membrane. Membranes (basel) 10:7–10. https:// doi. org/ 10. 3390/
membr anes1 00501 02
Skolotneva E, Cretin M, Mareev S (2021) A simple 1D convection-
diffusion model of oxalic acid oxidation using reactive electro-
chemical membrane. Membranes (basel) 11:1–14. https:// doi. org/
10. 3390/ membr anes1 10604 31
Smith JR, Walsh FC, Clarke RL (1998) Electrodes based on Mag-
néli phase titanium oxides: the properties and applications of
Ebonex® materials. J Appl Electrochem 28:1021–1033. https://
doi. org/ 10. 1023/A: 10034 69427 858
Sowmiya S, Gandhimathi R, Ramesh ST, Nidheesh PV (2016) Granu-
lar activated carbon as a particle electrode in three-dimensional
electrochemical treatment of Reactive Black B from aqueous
solution. Environ Prog Sustain Energy 35:1616–1622. https://
doi. org/ 10. 1002/ ep. 12396
Sun Y-F, Liu S-B, Meng F-L et al (2012) Metal oxide nanostructures
and their gas sensing properties: a review. Sensors 12:2610–
2631. https:// doi. org/ 10. 3390/ s1203 02610
Sun X, Wu J, Chen Z et al (2013) Fouling characteristics and electro-
chemical recovery of carbon nanotube membranes. Adv Funct
Mater 23:1500–1506. https:// doi. org/ 10. 1002/ adfm. 20120 1265
Taqieddin A, Allshouse MR, Alshawabkeh AN (2018) Editors’
choice—critical review—mathematical formulations of electro-
chemically gas-evolving systems. J Electrochem Soc 165:E694–
E711. https:// doi. org/ 10. 1149/2. 07918 13jes
Titchou FE, Zazou H, Afanga H et al (2021) An overview on the elimi-
nation of organic contaminants from aqueous systems using elec-
trochemical advanced oxidation processes. J Water Process Eng
41:102040. https:// doi. org/ 10. 1016/j. jwpe. 2021. 102040
Trainham JA, Newman J (1977) A flow-through porous electrode
model: application to metal-ion removal from dilute streams.
J Electrochem Soc 124:1528–1540. https:// doi. org/ 10. 1149/1.
21331 06
Trellu C, Péchaud Y, Oturan N et al (2016) Comparative study on the
removal of humic acids from drinking water by anodic oxida-
tion and electro-Fenton processes: mineralization efficiency and
modelling. Appl Catal B Environ 194:32–41. https:// doi. org/ 10.
1016/j. apcatb. 2016. 04. 039
Trellu C, Chaplin BP, Coetsier C et al (2018a) Electro-oxidation of
organic pollutants by reactive electrochemical membranes. Che-
mosphere 208:159–175. https:// doi. org/ 10. 1016/j. chemo sphere.
2018. 05. 026
Trellu C, Coetsier C, Rouch J-C et al (2018b) Mineralization of organic
pollutants by anodic oxidation using reactive electrochemical
membrane synthesized from carbothermal reduction of TiO2.
Water Res 131:310–319. https:// doi. org/ 10. 1016/j. watres. 2017.
12. 070
Trellu C, Olvera Vargas H, Mousset E et al (2021) Electrochemical
technologies for the treatment of pesticides. Curr Opin Electro-
chem 26:100677. https:// doi. org/ 10. 1016/j. coelec. 2020. 100677
Trinidad P, Walsh FC (1996) Hydrodynamic behaviour of the FM01-
LC reactor. Electrochim Acta 41:493–502. https:// doi. org/ 10.
1016/ 0013- 4686(95) 00335-5
Trinidad P, Ponce de León C, Walsh FC (2006) The application of
flow dispersion models to the FM01-LC laboratory filter-press
reactor. Electrochim Acta 52:604–613. https:// doi. org/ 10. 1016/j.
elect acta. 2006. 05. 040
Vasconcelos VM, Ponce-de-León C, Nava JL, Lanza MRV (2016)
Electrochemical degradation of RB-5 dye by anodic oxidation,
electro-Fenton and by combining anodic oxidation–electro-Fen-
ton in a filter-press flow cell. J Electroanal Chem 765:179–187.
https:// doi. org/ 10. 1016/j. jelec hem. 2015. 07. 040
Vecitis CD, Gao G, Liu H (2011) Electrochemical carbon nanotube
filter for adsorption, desorption, and oxidation of aqueous dyes
and anions. J Phys Chem C 115:3621–3629. https:// doi. org/ 10.
1021/ jp111 844j
Velazquez-Peña S, Sáez C, Cañizares P et al (2013) Production of
oxidants via electrolysis of carbonate solutions with conduc-
tive-diamond anodes. Chem Eng J 230:272–278. https:// doi.
org/ 10. 1016/j. cej. 2013. 06. 078
Vijayakumar V, Saravanathamizhan R, Balasubramanian N (2016)
Electro oxidation of dye effluent in a tubular electrochemical
reactor using TiO2/RuO2 anode. J Water Process Eng 9:155–
160. https:// doi. org/ 10. 1016/j. jwpe. 2015. 12. 006
Vu A, Qian Y, Stein A (2012) Porous electrode materials for lithium-
ion batteries-how to prepare them and what makes them spe-
cial. Adv Energy Mater 2:1056–1085. https:// doi. org/ 10. 1002/
aenm. 20120 0320
Walcarius A (2012) Electrocatalysis, sensors and biosensors in ana-
lytical chemistry based on ordered mesoporous and macropo-
rous carbon-modified electrodes. TrAC Trends Anal Chem
38:79–97. https:// doi. org/ 10. 1016/j. trac. 2012. 05. 003
Wang J, Li T, Zhou M et al (2015) Characterization of hydrodynam-
ics and mass transfer in two types of tubular electrochemical
reactors. Electrochim Acta 173:698–704. https:// doi. org/ 10.
1016/j. elect acta. 2015. 05. 135
Wang Z, Li J, He X et al (2019) Organic pollutants removal per-
formance and enhanced mechanism investigation of surface-
modified steel slag particle electrode. Environ Prog Sustain
Energy 38:7–14. https:// doi. org/ 10. 1002/ ep. 12910
Wang L, Wang L, Shi Y et al (2022) Blue TiO2 nanotube electrocata-
lytic membrane electrode for efficient electrochemical degrada-
tion of organic pollutants. Chemosphere 306:135628. https://
doi. org/ 10. 1016/j. chemo sphere. 2022. 135628
https://doi.org/10.1016/j.coelec.2020.100682
https://doi.org/10.1016/j.coelec.2020.100682
https://doi.org/10.1016/j.scitotenv.2020.141527
https://doi.org/10.1016/j.scitotenv.2020.141527
https://doi.org/10.1016/S0013-4686(02)00688-6
https://doi.org/10.1016/S0013-4686(02)00688-6
https://doi.org/10.1016/j.ccr.2021.213993
https://doi.org/10.1149/1.2108763
https://doi.org/10.1149/1.2108763
https://doi.org/10.1016/S0013-4686(97)85476-Xhttps://doi.org/10.1016/S0013-4686(97)85475-8
https://doi.org/10.1016/S0013-4686(97)85475-8
https://doi.org/10.1007/s11356-014-2783-1
https://doi.org/10.1007/s11356-014-2783-1
https://doi.org/10.1080/10916466.2012.701693
https://doi.org/10.1080/10916466.2012.701693
https://doi.org/10.3390/membranes10050102
https://doi.org/10.3390/membranes10050102
https://doi.org/10.3390/membranes11060431
https://doi.org/10.3390/membranes11060431
https://doi.org/10.1023/A:1003469427858
https://doi.org/10.1023/A:1003469427858
https://doi.org/10.1002/ep.12396
https://doi.org/10.1002/ep.12396
https://doi.org/10.3390/s120302610
https://doi.org/10.1002/adfm.201201265
https://doi.org/10.1149/2.0791813jes
https://doi.org/10.1016/j.jwpe.2021.102040
https://doi.org/10.1149/1.2133106
https://doi.org/10.1149/1.2133106
https://doi.org/10.1016/j.apcatb.2016.04.039
https://doi.org/10.1016/j.apcatb.2016.04.039
https://doi.org/10.1016/j.chemosphere.2018.05.026
https://doi.org/10.1016/j.chemosphere.2018.05.026
https://doi.org/10.1016/j.watres.2017.12.070
https://doi.org/10.1016/j.watres.2017.12.070
https://doi.org/10.1016/j.coelec.2020.100677
https://doi.org/10.1016/0013-4686(95)00335-5
https://doi.org/10.1016/0013-4686(95)00335-5
https://doi.org/10.1016/j.electacta.2006.05.040
https://doi.org/10.1016/j.electacta.2006.05.040
https://doi.org/10.1016/j.jelechem.2015.07.040
https://doi.org/10.1021/jp111844j
https://doi.org/10.1021/jp111844j
https://doi.org/10.1016/j.cej.2013.06.078
https://doi.org/10.1016/j.cej.2013.06.078
https://doi.org/10.1016/j.jwpe.2015.12.006
https://doi.org/10.1002/aenm.201200320
https://doi.org/10.1002/aenm.201200320
https://doi.org/10.1016/j.trac.2012.05.003
https://doi.org/10.1016/j.electacta.2015.05.135
https://doi.org/10.1016/j.electacta.2015.05.135
https://doi.org/10.1002/ep.12910
https://doi.org/10.1016/j.chemosphere.2022.135628
https://doi.org/10.1016/j.chemosphere.2022.135628
1561Environmental Chemistry Letters (2024) 22:1521–1561
Wei X, Wang H, Yin Z et al (2017) Tubular electrocatalytic mem-
brane reactor for alcohol oxidation: CFD simulation and exper-
iment. Chin J Chem Eng 25:18–25. https:// doi. org/ 10. 1016/j.
cjche. 2016. 05. 020
Wei K, Cui T, Huang F et al (2020) Membrane separation coupled
with electrochemical advanced oxidation processes for organic
wastewater treatment: a short review. Membranes (basel) 10:1–
29. https:// doi. org/ 10. 3390/ membr anes1 01103 37
Wu ZH, Chen HB, Dong YM et al (2008) Cleaning using nanobub-
bles: defouling by electrochemical generation of bubbles. J
Colloid Interface Sci 328:10–14. https:// doi. org/ 10. 1016/j. jcis.
2008. 08. 064
Xu SG (2016) Modeling and experimental study of electrochemical
oxidation of organics on boron-doped diamond anode. CNL
Nucl Rev 7:103–117. https:// doi. org/ 10. 12943/ CNR. 2016.
00018
Xu A, Han W, Li J et al (2016) Electrogeneration of hydrogen peroxide
using Ti/IrO2–Ta2O5 anode in dual tubular membranes electro-
Fenton reactor for the degradation of tricyclazole without aera-
tion. Chem Eng J 295:152–159. https:// doi. org/ 10. 1016/j. cej.
2016. 03. 001
Yan L, Ma H, Wang B et al (2011) Electrochemical treatment of petro-
leum refinery wastewater with three-dimensional multi-phase
electrode. Desalination 276:397–402. https:// doi. org/ 10. 1016/j.
desal. 2011. 03. 083
Yang Y (2020) Recent advances in the electrochemical oxidation water
treatment: spotlight on byproduct control. Front Environ Sci Eng
14:85. https:// doi. org/ 10. 1007/ s11783- 020- 1264-7
Yin X, Li W, Zhu H et al (2023) Electrochemical oxidation of bio-
treated landfill leachate using a novel dynamic reactive elec-
trochemical membrane (DREM). J Hazard Mater 446:130745.
https:// doi. org/ 10. 1016/J. JHAZM AT. 2023. 130745
Zaky AM, Chaplin BP (2013) Porous substoichiometric TiO2 anodes as
reactive electrochemical membranes for water treatment. Environ
Sci Technol 47:6554–6563. https:// doi. org/ 10. 1021/ es401 287e
Zaky AM, Chaplin BP (2014) Mechanism of p-substituted phenol oxi-
dation at a Ti4O7 reactive electrochemical membrane. Environ
Sci Technol 48:5857–5867. https:// doi. org/ 10. 1021/ es501 0472
Zhang Y, Wei K, Han W et al (2016) Improved electrochemical oxida-
tion of tricyclazole from aqueous solution by enhancing mass
transfer in a tubular porous electrode electrocatalytic reactor.
Electrochim Acta 189:1–8. https:// doi. org/ 10. 1016/j. elect acta.
2015. 10. 119
Zhang L, Ma C, Liu L et al (2019) Fabrication of novel particle elec-
trode γ-Al2O3@ZIF-8 and its application for degradation of
Rhodamine B. Water Sci Technol 80:109–116. https:// doi. org/
10. 2166/ wst. 2019. 251
Zhang J, Zhou Y, Yao B et al (2021) Current progress in electrochemi-
cal anodic-oxidation of pharmaceuticals: mechanisms, influenc-
ing factors, and new technique. J Hazard Mater 418:126313.
https:// doi. org/ 10. 1016/j. jhazm at. 2021. 126313
Zhang Y, Ding J, Gao Q et al (2022) Synthesis of low-cost Ti4O7
membrane electrode for electrooxidation of tetracycline under
flow-through conditions: performance, kinetics and mechanism.
Process Saf Environ Prot 159:931–943. https:// doi. org/ 10. 1016/j.
psep. 2022. 01. 068
Zhao X, Ren H, Luo L (2019) Gas bubbles in electrochemical gas
evolution reactions. Langmuir 35:5392–5408. https:// doi. org/ 10.
1021/ acs. langm uir. 9b001 19
Zhou M, Oturan MA, Sirés I (2018) Electro-Fenton process. New
trends and scale-up. Springer Singapore
Zhu L, Liu X-Q, Jiang H-L, Sun L-B (2017) Metal–organic frameworks
for heterogeneous basic catalysis. Chem Rev 117:8129–8176.
https:// doi. org/ 10. 1021/ acs. chemr ev. 7b000 91
Publisher's Note Springer Nature remains neutral with regard to
jurisdictional claims in published maps and institutional affiliations.
Springer Nature or its licensor (e.g. a society or other partner) holds
exclusive rights to this article under a publishing agreement with the
author(s) or other rightsholder(s); author self-archiving of the accepted
manuscript version of this article is solely governed by the terms of
such publishing agreement and applicable law.
https://doi.org/10.1016/j.cjche.2016.05.020
https://doi.org/10.1016/j.cjche.2016.05.020
https://doi.org/10.3390/membranes10110337
https://doi.org/10.1016/j.jcis.2008.08.064
https://doi.org/10.1016/j.jcis.2008.08.064
https://doi.org/10.12943/CNR.2016.00018
https://doi.org/10.12943/CNR.2016.00018
https://doi.org/10.1016/j.cej.2016.03.001
https://doi.org/10.1016/j.cej.2016.03.001
https://doi.org/10.1016/j.desal.2011.03.083
https://doi.org/10.1016/j.desal.2011.03.083
https://doi.org/10.1007/s11783-020-1264-7
https://doi.org/10.1016/J.JHAZMAT.2023.130745
https://doi.org/10.1021/es401287e
https://doi.org/10.1021/es5010472
https://doi.org/10.1016/j.electacta.2015.10.119
https://doi.org/10.1016/j.electacta.2015.10.119
https://doi.org/10.2166/wst.2019.251
https://doi.org/10.2166/wst.2019.251
https://doi.org/10.1016/j.jhazmat.2021.126313
https://doi.org/10.1016/j.psep.2022.01.068
https://doi.org/10.1016/j.psep.2022.01.068
https://doi.org/10.1021/acs.langmuir.9b00119
https://doi.org/10.1021/acs.langmuir.9b00119
https://doi.org/10.1021/acs.chemrev.7b00091
	Mathematical modeling of the anodic oxidation of organic pollutants: a review
	Abstract
	Introduction
	Basics of the anodic oxidation process
	Competition phenomena in real wastewater treatment
	Implementation of anodic oxidation devices
	Batch cells
	Flow cells
	Flow cells with plate electrodes
	Flow cells with mesh electrodes
	Flow cells with porous electrodes
	Flow cells with particle electrodes
	Historical aspects
	General equations used for anodic oxidation modeling
	Material balance law
	Flux density equations
	Electrochemical and chemical reactions
	Simulation of the flow pattern
	Modeling of anodic oxidation with plate electrodes
	Kinetic models
	Two-mode models
	Multi-zone models
	Diffusion-kinetic models
	Modeling of anodic oxidation with porous 3D electrodes
	The features of porous electrodes
	Modeling of anodic oxidation in the systems with reactiveelectrochemical membranes
	Modeling anodic oxidation in the FM01-LC electrochemical reactor
	Density functional theory
	Perspective
	Conclusion
	References
