<p>PLµS® Controls</p><p>Electronic Cam Switch</p><p>October 1, 2018</p><p>10/18</p><p>• Warranty Policy</p><p>• How to Order / Typical Systems</p><p>• Keyboard/Controller</p><p>Part Number Breakdown</p><p>• Resolver Part Number Breakdown</p><p>• PLµS® Plug-In Module</p><p>• 6000 Series</p><p>• 5000 Series</p><p>• PLµS® Accessories and Spare Parts</p><p>• Typical Systems Cost</p><p>• Electronic Cam Switches</p><p>• Spare Parts</p><p>• Output Modules</p><p>• Options</p><p>13647 Metric Rd • Roscoe, IL 61073 • 815-389-2620 • FAX 815-389-3304</p><p>800-228-5487 (U.S.A. and Canada)</p><p>Warranty Policy</p><p>1. Electro Cam Corp. warrants that for a period of twelve (12) months from the date of shipment</p><p>to the original purchaser, its new product to be free from defects in material and workman-</p><p>ship and that the product conforms to applicable drawings and specifications approved by</p><p>the Manufacturer. This warranty period will be extended on Distributor or OEM orders to a</p><p>maximum of eighteen (18) months to take into consideration Distributor or OEM shelf time.</p><p>2. The remedy obligations of Electro Cam Corp. under this warranty are exclusive and are</p><p>limited to the repair, or at its option, the replacement or refund of the original purchase price</p><p>of any new apparatus which proves defective or not in conformity with the drawings and</p><p>specifications. Shipment of the claimed defective product to Electro Cam Corp. shall be at</p><p>the cost of the consumer. Shipment of the repaired or replacement product to the consumer</p><p>shall be at the cost of Electro Cam Corp. All claims must be made in writing to Electro Cam</p><p>Corp., 13647 Metric Road, Roscoe, IL 61073 USA.</p><p>3. In no event, and under no circumstances, shall Electro Cam Corp. be liable for:</p><p>a. Any product damaged or lost in shipment. Inspection for damage should be made before</p><p>acceptance or signing any delivery documents releasing responsibility of the delivering</p><p>carrier.</p><p>b. Product failure or damages due to misuse, abuse, improper installation or abnormal con-</p><p>ditions of temperature, dirt or other contaminants as determined at the sole discretion of</p><p>Electro Cam Corp.</p><p>c. Product failures due to operation, intentional or otherwise, above rated capacities as</p><p>determined at the sole discretion of Electro Cam Corp.</p><p>d. Non-authorized expenses for removal, inspection, transportation, repair or rework.</p><p>nor shall the manufacturer ever be liable for consequential and incidental</p><p>damages, or in any amount greater than the purchase price of the equipment.</p><p>4. There are no warranties which extend beyond the description on the face hereof. This war-</p><p>ranty is in lieu of all other warranties, expressed or implied, including (but not</p><p>limited to) any implied warranties of merchantability or fitness for a particular</p><p>purpose, all of which are expressly disclaimed. Any legal proceeding arising out of the</p><p>sale or use of this apparatus must be commenced within eighteen (18) months of the date</p><p>of shipment from the manufacturer.</p><p>4</p><p>How to Order</p><p>PS-5144 Keyboard/Controller</p><p>Resolver</p><p>Resolver Cable</p><p>Output Cable (if required)</p><p>SLIMLINE™ Output Modules</p><p>SLIMLINE™ Analog Modules</p><p>PS-6144 Controller</p><p>PS-6400 Keypad/Display</p><p>Keypad-to-controller cable</p><p>Resolver</p><p>Resolver Cable</p><p>Output Cable (if required)</p><p>SLIMLINE™ Output Modules</p><p>SLIMLINE™ Analog Modules</p><p>Typical Systems</p><p>Resolver-Based</p><p>Resolver or Encoder-Based</p><p>Separate Output Rack</p><p>Encoder-Based</p><p>PS-5001/5004/5034 Keyboard/Controller</p><p>Encoder</p><p>Encoder Cable</p><p>Output Rack</p><p>Output Rack Cable</p><p>Output Modules (PS-5001/5004 only)</p><p>Input Modules (PS-5004 only)</p><p>Analog Output Module (-A option only)</p><p>Resolver-Based</p><p>PS-5101/5104/5134 Keyboard/Controller</p><p>Resolver</p><p>Resolver Cable</p><p>Output Rack</p><p>Output Rack Cable</p><p>Output Modules (PS-5101/5104 only)</p><p>Input Modules (PS-5104 only)</p><p>Analog Output Module (-A option on PS-5X0X models)</p><p>Encoder-Based</p><p>PS-5011/5021*/5024* Keyboard/Controller</p><p>Encoder</p><p>Encoder Cable</p><p>Output Cable (if required)</p><p>SLIMLINE™ Output Modules (PS-5021*/5024* only)</p><p>SLIMLINE™ Input Modules (PS-5024 only)</p><p>SLIMLINE™ Analog Output Module</p><p>(-A option, PS-5021*/5024* only)</p><p>Resolver-Based</p><p>PS-5111/5121*/5124* Keyboard/Controller</p><p>Resolver</p><p>Resolver Cable</p><p>Output Cable (if required)</p><p>SLIMLINE™ Output Modules (PS-5121*/5124* only)</p><p>SLIMLINE™ Input Modules (PS-5124 only)</p><p>SLIMLINE™ Analog Output Module</p><p>(-A option, PS-5121*/5124* only)</p><p>*All PS-5X2X, PS-5144 & PS-6144 Models require use of the fused SLIMLINE™ Output or Input Modules (AC and/or DC), 1 Module per output circuit used.</p><p>Integral Output Rack</p><p>A PLµS® Programmable Limit Switch System must include the following:</p><p>• Input Transducer (resolver or encoder)</p><p>• Keyboard/Controller (PS-5XXX or PS-6XXX Series)</p><p>• Cables (transducer-controller, output rack-controller on separate rack models, output cable on</p><p>integral rack models)</p><p>• Output Rack (external or integral to controller) with:</p><p>AC and/or DC Output Modules</p><p>DC Sinking or</p><p>DC Sourcing Transistor outputs</p><p>System combinations are shown below. Cable lengths must be specified with order. Output modules</p><p>must be ordered with PS-5X0X/5X2X/5144 and PS-6144 controllers; one per output circuit used.</p><p>PL-1746-C0X Plug-In Module</p><p>Resolver</p><p>Resolver Cable</p><p>Option: C01/C02</p><p>PS-6400 Keypad/Display</p><p>Keypad to Controller Cable</p><p>Option: C01 only</p><p>I/O Rack - 16 or 8 output</p><p>I/O Rack Cable</p><p>NOTE: See Page 17 for Typical System Costs</p><p>Keyboard/Controller Part Number Breakdown</p><p>OPTIONS</p><p>A - Analog Output Proportioned</p><p>to RPM</p><p>D - Outputs based on direction of</p><p>rotation</p><p>F - Additional setpoint/program</p><p>storage</p><p>G - Gray Code Output (8 bit)</p><p>G10 - Gray Code Output (10 bit)</p><p>H - High Resolution (12 bit-4096)</p><p>L - Leading & Trailing Edge</p><p>Speed Compensation</p><p>P - Register Mark Phasing</p><p>U - CE Mark, 24 VDC input only</p><p>V - Vibration protective coating</p><p>W - Washdown boot</p><p>MB - Modbus™ communication</p><p>protocol available for</p><p>PS-X144 Models</p><p>MSV- Multiple controllers used with</p><p>one resolver</p><p>MSX- Mode 6, Analog Per Program,</p><p>Pulse Serial Number</p><p>INPUT/OUTPUT CONFIGURATION</p><p>0 - Separate I/O Rack & Modules</p><p>(Input Module required)</p><p>1 - DC Transistor Outputs only (1 Input)</p><p>2 - SLIMLINE™ I/O Modules on Keyboard/Controller</p><p>back</p><p>3 - Separate DC Transistor Rack (1 Input)</p><p>4 - DC Transistor Outputs and/or SLIMLINE™</p><p>Modules on Keyboard/Controller back with input</p><p>capability</p><p>TRANSDUCER SELECTION</p><p>0 - Encoder Input</p><p>1 - Resolver Input</p><p>2 - Quadrature Encoder</p><p>3 - Dual Resolver</p><p>TYPE OF OUTPUT</p><p>O - Separate Input/Output Rack with Modules</p><p>M - SLIMLINE™ Modules (PS-5X2X, PS-X144 & PS-4100-11-M16)</p><p>N - DC Sinking Output (PS-5X11, PS-5X34, PS-X144)</p><p>P - DC Sourcing Output (PS-5X11, PS-5X34, PS-X144)</p><p>Note: PS-X144 Models may have both DC Transistor Outputs & SLIMLINE™ Modules</p><p>INPUT VOLTAGE</p><p>10 - 120 VAC Input (Not available on PS-X14X Models)</p><p>20 - 240 VAC Input (Not available on PS-X14X Models)</p><p>24 - 24 VDC Input</p><p>P S - X X X X - X X - X X X - X</p><p>MODEL/DISPLAY SELECTION</p><p>5 - 8.5 x 6.5" LED Display</p><p>6 - 1/4 DIN LCD Display</p><p>FUNCTIONS</p><p>1 - Standard Features</p><p>4 - Output Enable Modes & Standard Features</p><p>Note: -C Communications & -E Expanded</p><p>Operator Enable are standard on all</p><p>controllers after 10-1-97</p><p>5</p><p>Plug-In Module Part Number Breakdown</p><p>NUMBER OF TRANSDUCERS</p><p>1 = One</p><p>SUB-CATEGORY</p><p>C01 = Display, 32 Real World I/O with</p><p>External I/O racks.</p><p>C02 = Display, Built-in 8 Inputs and 6</p><p>Sourcing DC Outputs, 1.5 A.</p><p>PLATFORM TYPE</p><p>1746 = SLC 500</p><p>TYPE TRANSDUCER</p><p>R - Resolver</p><p>E - Encoder</p><p>PL = Plugs into backplane.</p><p>Utilizes Allen-Bradley</p><p>technology</p><p>P L - X X X X - XXX - X X</p><p>NUMBER OF OUTPUTS</p><p>08 - 8 DC Outputs (PS-XX11 Models)</p><p>09 - 9 SLIMLINE™ Modules</p><p>(PS-5X2X Models)</p><p>16 - 16 AC and/or DC Outputs</p><p>16 DC Output on PS-5X11’s</p><p>17 - 17 AC and/or DC Outputs</p><p>24 - 24 AC and/or DC Outputs</p><p>32 - 32 DC Transistor Outputs</p><p>48 - 48 AC and/or DC Outputs</p><p>64 - 64 DC Transistor Outputs</p><p>Note: PS-X144 Models can have 25 outputs -</p><p>16 DC Transistor & 9 SLIMLINE™ Modules</p><p>Note: The options listed below are available only on select models. Contact the factory to</p><p>obtain confirmation. If volume warrants, Electro Cam may add these options to</p><p>other models.</p><p>PLµS® Plug-In Modules for the SLC-500</p><p>PL-1746-C01-R1 Plug-In Module</p><p>Plug-In Module only: Order keypad/display and I/O rack(s) separately.</p><p>PS-4108-13-L16* I/O Rack for PL-1746-C01</p><p>PS-4308-10-XXX I/O Rack Cable for PL-1746-C01</p><p>NOTE: Rack cable available in 2 foot increments, 50’ max. length.</p><p>*I/O racks use the Electro Cam SLIMLINE™ output modules. (NOTE: See Page 13 for module information)</p><p>PL-1746-C02-R1 Resolver based Plug-In Module (Sourcing)†</p><p>6 Sourcing DC outputs and 8 DC inputs onboard.</p><p>PS-6400-24-001 Keypad/Display</p><p>Keypad can be used with all PL-1746 Plug-In Modules</p><p>PS-6300-01-XXX Keypad-to-Controller Cable</p><p>“XXX” is the cable length in feet. (“010” = 10 ft.)</p><p>Cables are available in the following lengths:</p><p>• 2’ long</p><p>• From 5’ through 30’ long in 5’ increments</p><p>• From 30’ through 100’ long in 10’ increments</p><p>• From 100’ through 1000’ long in 50’ increments</p><p>Custom lengths other than those listed above are available for additional charge</p><p>Suggested PL-1746 Plug-In Module Accessories for CE Certification</p><p>348-7000-008 Ferrite Core 0443625006</p><p>348-7000-009 RFI Power Filter</p><p>6</p><p>PL-1746-C02</p><p>Plug-In Module</p><p>PL-1746-C01</p><p>Plug-In Module</p><p>This product incorporates patented technology which is licensed by Allen-Bradley Company, Inc. A-B has not technically approved, nor does it</p><p>warrant or support this product. All warranty and support for this product and its application is provided solely by Electro Cam Corp.</p><p>SLC-500 is a trademark of Allen-Bradley Company.</p><p>† See page 17 for sinking/sourcing definitions.</p><p>PS-6144-24-P16M09 Controller (Sourcing)† F, G, G10,</p><p>Controller only: Order keypad/display separately. 16 Sourcing† Transistor Outputs H, L, MSV,</p><p>Up to 9 SLIMLINE™ modules may be mounted on controller, 2 of which may be analog. MB, V, MSX</p><p>PS-6144-24-N16M09 Controller (Sinking)† F, G, G10,</p><p>Controller only: Order keypad/display separately. 16 Sinking† Transistor Outputs H, L, MSV,</p><p>Up to 9 SLIMLINE™ modules may be mounted on controller, 2 of which may be analog. MB, V</p><p>PS-6144-24-M17 Controller H, L, MSV</p><p>Controller only: Order keypad/display separately. MB, V</p><p>Up to 17 SLIMLINE™ AC or DC modules may be mounted on controller,</p><p>2 of which may be analog.</p><p>PS-6244-24-P16M09 Controller (Sourcing)† V</p><p>Controller only: Order keypad/display separately. 16 Sourcing† Transistor Outputs</p><p>Up to 9 SLIMLINE™ modules may be mounted on controller, 2 of which may be analog.</p><p>Must use 1000 ppr quadrature encoder.</p><p>PS-6244-24-N16M09 Controller (Sinking)† V</p><p>Controller only: Order keypad/display separately. 16 Sinking† Transistor Outputs</p><p>Up to 9 SLIMLINE™ modules may be mounted on controller, 2 of which may be analog.</p><p>Must use 1000 ppr quadrature encoder.</p><p>PS-6344-24-P16M09 Dual Resolver Controller (Sourcing)† V*</p><p>Controller only: Order keypad/display separately. 16 Sourcing† Transistor Outputs</p><p>Up to 9 SLIMLINE™ modules may be mounted on controller, 2 of which may be analog.</p><p>PS-6344-24-N16M09 Dual Resolver Controller (Sinking)† V*</p><p>Controller only: Order keypad/display separately. 16 Sinking† Transistor Outputs</p><p>Up to 9 SLIMLINE™ modules may be mounted on controller, 2 of which may be analog.</p><p>PS-6344-24-M17 Dual Resolver Controller V*</p><p>Controller only: Order keypad/display separately.</p><p>Up to 17 SLIMLINE™ AC or DC modules may be mounted on controller, 2 of which may</p><p>be analog.</p><p>PS-6400-24-001 Keypad/Display V, W</p><p>PS-6300-01-XXX Keypad-to-Controller Cable</p><p>“XXX” is the cable length in feet. (“010” = 10 ft.)</p><p>Cables are available in the following lengths:</p><p>• 2’ long</p><p>• From 5’ through 30’ long in 5’ increments</p><p>• From 30’ through 100’ long in 10’ increments</p><p>• From 100’ through 1000’ in 50’ increments</p><p>Custom lengths other than those listed above can be supplied for</p><p>an additional charge</p><p>PS-6X44 Controllers, Keypad/Display & Keypad Cable</p><p>PLµS® Keyboard/Controllers</p><p>PS-6144-24-P16M09</p><p>Controller</p><p>PS-6144-24-M17</p><p>Controller</p><p>PS-6344-24-N16M09</p><p>Dual Resolver Controller</p><p>PS-6400-24-001</p><p>Keypad/Display</p><p>Available</p><p>Options</p><p>7</p><p>*Modbus™ ASCII communication (-MB), Multiple Controllers (-MSV), High Resolution (-H), and Leading/Trailing Edge Speed</p><p>Compensation (-L) options are standard on PS-6344.</p><p>† See page 17 for sinking/sourcing definitions.</p><p>PS-5X0X</p><p>PS-5001, 5101, 5004, 5104</p><p>ENCODER-BASED</p><p>PS-5001-10-016 A,G,L,P,V,W</p><p>PS-5001-10-024 G,V,W</p><p>PS-5001-10-048* V,W</p><p>PS-5004-10-016 A,G,L,P,V,W</p><p>PS-5004-10-024 G,L,V,W</p><p>PS-5004-10-048* G,L,V,W</p><p>PLµS® Keyboard/Controllers</p><p>*NOTE: 2 output racks and 2 output rack cables required with 48- output systems.</p><p>Communications and Expanded Operator Enable features are standard.</p><p>RESOLVER-BASED</p><p>PS-5101-10-016 A,D,F,G,H,L,P,V,W</p><p>PS-5101-10-024 H,L,V,W</p><p>PS-5101-10-048* G,H,L,V,W</p><p>PS-5104-10-016 A,G,H,L,V,W</p><p>PS-5104-10-024 G,H,L,V,W</p><p>PS-5104-10-048* F,G,H,L,V,W</p><p>Available</p><p>Options</p><p>Available</p><p>Options</p><p>PS-5X11</p><p>PS-5144</p><p>PS-5X34</p><p>PS-5X2X</p><p>RESOLVER-BASED ONLY</p><p>PS-5034, 5134</p><p>PS-5021, 5121, 5024, 5124</p><p>PS-5011, 5111</p><p>Integral DC transistor output rack, sinking† or sourcing† output</p><p>For 240V AC input, change -10 to -20.</p><p>For 24V DC input, change -10 to -24.</p><p>ENCODER-BASED/Sinking†</p><p>PS-5011-10-N08 V,W</p><p>PS-5011-10-N16 G,L,P,V,W</p><p>ENCODER-BASED/Sourcing†</p><p>PS-5011-10-P08 L,V,W</p><p>PS-5011-10-P16 G,L,P,V,W</p><p>RESOLVER-BASED/Sinking†</p><p>PS-5111-10-N08 D,F,H,L,V,W</p><p>PS-5111-10-N16 D,F,G,H,L,P,V,W</p><p>RESOLVER-BASED/Sourcing†</p><p>PS-5111-10-P08 D,F,H,L,V,W</p><p>PS-5111-10-P16 D,F,G,H,L,P,V,W</p><p>Available</p><p>Options</p><p>Available</p><p>Options</p><p>Available</p><p>Options</p><p>Available</p><p>Options</p><p>Available</p><p>Options</p><p>Available</p><p>Options</p><p>Available</p><p>OptionsENCODER-BASED</p><p>PS-5021-10-M09 A,L,V,W</p><p>PS-5024-10-M09 A,L,V,W</p><p>RESOLVER-BASED</p><p>PS-5121-10-M09 A,D,H,L,P,U,V,W,</p><p>PS-5124-10-M09 A,H,L,P,U,V,W</p><p>Integral 9 position I/O rack, SLIMLINE™ modules used</p><p>For 240V AC input, change -10 to -20 .</p><p>For 24V DC input, change -10 to -24.</p><p>Requires external DIN rail-mounted, DC transistor output rack. (Specify sinking or sourcing† on rack)</p><p>For 240V DC input, change -10 to -20.</p><p>For 24V DC input, change -10 to -24.</p><p>ENCODER-BASED</p><p>PS-5034-10-032 V,W</p><p>PS-5034-10-064 V,W</p><p>RESOLVER-BASED</p><p>PS-5134-10-032 D,F,G,H,L,U,V,W</p><p>PS-5134-10-064 U,V,W</p><p>NOTE: 2 output rack cables required with -64- output systems.</p><p>Communications and Expanded Operator Enable features are standard.</p><p>available with -U option and 24V DC input. 32 output rack(s) also require -U option.</p><p>24V DC input voltage, DC transistor output, “real world” loads require SLIMLINE™ modules on</p><p>integral output rack.</p><p>RESOLVER-BASED (ONLY)</p><p>PS-5144-24-N16M09 (Sinking†) G,G10,H,L,MB,MSV,V,W</p><p>PS-5144-24-P16M09 (Sourcing†) G,G10,H,L,MB,MSV,V,W</p><p>PS-5144-24-M17 H,L,MB,MSV,V,W</p><p>Requires external rack and modules</p><p>For 240V AC input, change -10 to -20.</p><p>For 24V DC input, change -10 to -24.</p><p>NOTE: Communications and Expanded Operator Enable features are standard.</p><p>NOTE: Communications and Expanded Operator Enable features are standard.</p><p>available with -U option and 24V DC input.</p><p>NOTE: Communications, Expanded Operator Enable and Analog features are standard.</p><p>† See page 17 for sinking/sourcing definitions.</p><p>8</p><p>24V DC only can be used with PS-5144 resolver based controller.</p><p>9</p><p>Resolver Part Numbering System</p><p>Add option letter(s) to end of PLµS® controller part number. — Note: A & G options cannot be used together.</p><p>PLµS® Controller Options</p><p>A Analog output proportional to speed</p><p>D</p><p>Output directional ANDing</p><p>F Additional setpoint/program storage</p><p>G Gray code position output (8 bit)</p><p>G10 Gray code position output (10 bit)</p><p>H 12-Bit resolution (resolver-based systems)</p><p>L L eading & trailing edge speed compensation</p><p>MB Modbus ™ ASCII Communication</p><p>MSV Multiple controllers used with 1 resolver</p><p>MSX Mode 6, Analog Per Program, Pulse Serial Number</p><p>P Register Mark Phasing (eliminates external PGM SEL capability)</p><p>16 outputs only</p><p>U CE Mark, 24 VDC input only</p><p>V Vibration protective coating</p><p>W Washdown boot</p><p>Option Description Option Description</p><p>P S - 5 2 X X - X X X - X X X</p><p>SHAFT SIZE</p><p>12 - 1/8 DIA.</p><p>15 - 15 mm DIA.</p><p>20 - 20 mm DIA.</p><p>38 - 3/8" DIA., 2.06" Bolt Flange</p><p>62 - 5/8" DIA., 2.25" Bolt Flange</p><p>75 - 3/4" DIA.</p><p>LOCATION OF CABLE CONNECTION</p><p>W - With stripped & tinned leads</p><p>G - Right (120° from top on “A” housings)</p><p>R - Rear (not available on Geared Resolver)</p><p>L - Left (120° from top on “A” housings)</p><p>S - Top Side</p><p>HOUSING</p><p>A - Can housing w/flange or foot endbells</p><p>C - Stainless steel square housing</p><p>E - 74 mm bolt spacing, flange mount</p><p>S - Servo mount (.12 = size 11; .38 - size 25)</p><p>RATIO</p><p>11 - Standard 1:1 (Note: 3rd digit not used on Standard 1:1.)</p><p>021 - Geared 2:1 - Ext. shaft to internal resolver shaft</p><p>thru</p><p>361 - Geared 36:1 - Ext. shaft to internal resolver shaft</p><p>Various ratios available — contact Factory.</p><p>Resolver</p><p>PLuS® Part Number</p><p>TYPE OF CABLE CONNECTION</p><p>D - Military bayonet style connector</p><p>T - Terminal strip with NO conduit entrance</p><p>V - No connector, just stripped & tinned wires</p><p>S - Sealed connector — screw type</p><p>Note: “T” only available for PS-5262 stainless steel</p><p>NEMA 4X 5/8" shaft resolver. Part# PS-5903-01-001</p><p>conduit entrance sold separately.</p><p>PLµS® Resolvers</p><p>Standard Inch Diameter Shafts</p><p>PS-5212-11-SVW (unhoused, servo mount, size 11, .120" shaft)</p><p>PS-5238-11-ADR (flange mount, rear bayonet connector, 3/8" shaft)</p><p>PS-5238-11-ADS</p><p>(flange mount, top side bayonet connector, 3/8" shaft)</p><p>PS-5238-11-ADG (flange mount, right side bayonet connector, 3/8" shaft)</p><p>PS-5238-11-ADL (flange mount, left side bayonet connector, 3/8" shaft)</p><p>PS-5238-11-ASR (flange mount, rear sealed connector, 3/8" shaft)</p><p>PS-5238-11-ASS (flange mount, top side sealed connector, 3/8" shaft)</p><p>PS-5238-11-ASG (flange mount, right side sealed connector, 3/8" shaft)</p><p>PS-5238-11-ASL (flange mount, left side sealed connector, 3/8" shaft)</p><p>PS-5238-11-SDR (servo mount, rear bayonet connector, 3/8" shaft)</p><p>PS-5238-11-SDS (servo mount, top side bayonet connector, 3/8" shaft)</p><p>PS-5238-11-SDG (servo mount, right side bayonet connector, 3/8" shaft)</p><p>PS-5238-11-SDL (servo mount, left side bayonet connector, 3/8" shaft)</p><p>PS-5238-11-SSR (servo mount, rear sealed connector, 3/8" shaft)</p><p>(PS-5238-11-SSS servo mount, top side sealed connector, 3/8" shaft)</p><p>PS-5238-11-SSG (servo mount, right side sealed connector, 3/8" shaft)</p><p>PS-5238-11-SSL (servo mount, left side sealed connector, 3/8" shaft)</p><p>NOTE: The hole spacing on the mounting flange for 5238 resolvers is 2.064 inches.</p><p>PS-5262-11-ADR (flange mount, rear bayonet connector, 5/8" shaft)</p><p>PS-5262-11-ADS (flange mount, top side bayonet connector, 5/8" shaft)</p><p>PS-5262-11-ADG (flange mount, right side bayonet connector, 5/8" shaft)</p><p>PS-5262-11-ADL (flange mount, left side bayonet connector, 5/8" shaft)</p><p>PS-5262-11-ASR (flange mount, rear sealed connector, 5/8" shaft)</p><p>PS-5262-11-ASS (flange mount, top side sealed connector, 5/8" shaft)</p><p>PS-5262-11-ASG (flange mount, right side sealed connector, 5/8" shaft)</p><p>PS-5262-11-ASL (flange mount, left side sealed connector, 5/8" shaft)</p><p>NOTE: The hole spacing on the mounting flange for 5262 resolvers is 2.250 inches.</p><p>Stainless Steel Resolvers</p><p>PS-5262-11-CTG (horizontal foot mount, stainless steel NEMA 4X, right connector, 5/8" shaft)</p><p>PS-5262-11-CTL (horizontal foot mount, stainless steel NEMA 4X, left connector, 5/8" shaft)</p><p>NOTE: The PS-5262 stainless steel resolvers include a connector entrance for a 1/2" NPT fitting.</p><p>Connectors sold separately. Specify cable p/n PS-5300-02-XXX.</p><p>PS-5275-11-ADR (foot mount, rear bayonet connector, 3/4" shaft)</p><p>PS-5275-11-ADS (foot mount, top side bayonet connector, 3/4" shaft)</p><p>PS-5275-11-ADG (foot mount, right side bayonet connector, 3/4" shaft)</p><p>PS-5275-11-ADL (foot mount, left side bayonet connector, 3/4" shaft)</p><p>PS-5275-11-ASR (foot mount, rear sealed connector, 3/4" shaft)</p><p>PS-5275-11-ASS (foot mount, top side sealed connector, 3/4" shaft)</p><p>PS-5275-11-ASG (foot mount, right side sealed connector, 3/4" shaft)</p><p>PS-5275-11-ASL (foot mount, left side sealed connector, 3/4" shaft)</p><p>Geared Resolvers – non-returnable/non-refundable</p><p>PS-5275-021-ADS (foot mount, top side bayonet connector, 3/4" shaft, 2:1 gear)</p><p>PS-5275-021-ADG (foot mount, right side bayonet connector, 3/4" shaft, 2:1 gear)</p><p>PS-5275-021-ADL (foot mount, left side bayonet connector, 3/4" shaft, 2:1 gear)</p><p>PS-5275-041-ADS (foot mount, top side bayonet connector, 3/4" shaft, 4:1 gear)</p><p>PS-5275-041-ADG (foot mount, right side bayonet connector, 3/4" shaft, 4:1 gear)</p><p>PS-5275-041-ADL (foot mount, left side bayonet connector, 3/4" shaft, 4:1 gear)</p><p>PS-5275-051-ADS (foot mount, top side bayonet connector, 3/4" shaft, 5:1 gear)</p><p>PS-5275-051-ADG (foot mount, right side bayonet connector, 3/4" shaft, 5:1 gear)</p><p>PS-5275-051-ADL (foot mount, left side bayonet connector, 3/4" shaft, 5:1 gear)</p><p>PS-5275-071-ADS (foot mount, top side bayonet connector, 3/4" shaft, 7:1 gear)</p><p>PS-5275-071-ADG (foot mount, right side bayonet connector, 3/4" shaft, 7:1 gear)</p><p>PS-5275-071-ADL (foot mount, left side bayonet connector, 3/4" shaft, 7:1 gear)</p><p>PS-5275-101-ADS (foot mount, top side bayonet connector, 3/4" shaft, 10:1 gear)</p><p>PS-5275-101-ADG (foot mount, right side bayonet connector, 3/4" shaft, 10:1 gear)</p><p>PS-5275-101-ADL (foot mount, left side bayonet connector, 3/4" shaft, 10:1 gear)</p><p>PS-5275-181-ADS (foot mount, top side bayonet connector, 3/4" shaft, 18:1 gear)</p><p>PS-5275-221-ADS (foot mount, top side bayonet connector, 3/4" shaft, 22:1 gear)</p><p>PS-5275-221-ADG (foot mount, right side bayonet connector, 3/4" shaft, 22:1 gear)</p><p>PS-5275-221-ADL (foot mount, left side bayonet connector, 3/4" shaft, 22:1 gear)</p><p>PS-5275-361-ADS (foot mount, top side bayonet connector, 3/4" shaft, 36:1 gear)</p><p>PS-5275-361-ADG (foot mount, right side bayonet connector, 3/4" shaft, 36:1 gear)</p><p>PS-5275-361-ADL (foot mount, left side bayonet connector, 3/4" shaft, 36:1 gear)</p><p>PS-5275-11-ADS</p><p>Foot Mount</p><p>PS-5262-11-CTG</p><p>Stainless Steel</p><p>PS-5275-051-ADL</p><p>Foot Mount Geared</p><p>PS-5238-11-ADR</p><p>Flange Mount</p><p>10</p><p>NOTE: Consult Factory</p><p>if other ratios required.</p><p>Standard Metric Size Shafts</p><p>PS-5215-11-EDS (74mm flange mount, top side bayonet connector, 15mm shaft)</p><p>PS-5215-11-EDG (74mm flange mount, right side bayonet connector, 15mm shaft)</p><p>PS-5215-11-EDL (74mm flange mount, left side bayonet connector, 15mm shaft)</p><p>PS-5220-11-ADR (foot mount, rear bayonet connector, 20mm shaft)</p><p>PS-5220-11-ADS (foot mount, top side bayonet connector, 20mm shaft)</p><p>PS-5220-11-ADG (foot mount, right side bayonet connector, 20mm shaft)</p><p>PS-5220-11-ADL (foot mount, left side bayonet connector, 20mm shaft)</p><p>PS-5220-11-ASR (foot mount, rear sealed connector, 20mm shaft)</p><p>PS-5220-11-ASS (foot mount, top side sealed connector, 20mm shaft)</p><p>PS-5220-11-ASG (foot mount, right side sealed connector, 20mm shaft)</p><p>PS-5220-11-ASL (foot mount, left side sealed connector, 20mm shaft)</p><p>NOTE: Any resolver with “S” in the 2nd digit of suffix requires a PS-5300-03-XXX cable or a</p><p>PS-5300-04-XXX (formerly a special PS-5300-01-XXX-MHC)</p><p>PLµS® Resolvers (continued)</p><p>PLµS® Resolver Cables</p><p>PS-5300-01-XXX Cable</p><p>Standard cable with bayonet resolver connector at one end and tinned leads on the other end.</p><p>PS-5903-01-001</p><p>NEMA 4X - 1/2 NPT cable connector, used w/PS-5262 resolvers</p><p>PS-5300-02-XXX Cable</p><p>Standard cable with tinned leads at each end. (used w/PS-5262 stainless steel resolvers)</p><p>PS-5300-03-XXX Cable</p><p>Special polyurethane cable recommended for oily atmospheres, has a sealed connector on</p><p>resolver end and tinned leads on the other end.</p><p>PS-5300-04-XXX Cable</p><p>Standard cable with sealed connector on one end and tinned leads on the other end.</p><p>PS-5300-05-XXX Cable</p><p>Cable for -MSV option.</p><p>XXX = Cable length in feet (10’ cable = 010)</p><p>Available in 5’ increments from 5’ to 30’, 10’ increments from 30’-100’, and 50’ increments from 100’-1000’.</p><p>Lengths other than those listed above can be supplied for an additional charge.</p><p>PS-5238-11-ADR</p><p>Flange Mount</p><p>Resolver</p><p>with Cable</p><p>12</p><p>PLµS® Encoder Cables</p><p>PS-4300-01-XXX Cable</p><p>XXX = Cable length in feet (10' cable = 010) Available in 5’ increments from</p><p>5' to 30', 10' increments from 30'-100', and 50' increments from 100’-1000’.</p><p>PLµS® Encoders</p><p>PS-4256-11-DDR (NEMA 12, 0-1000 RPM)</p><p>PS-4456-11-DDR (NEMA 4X, 0-1000 RPM)</p><p>PS-4257-11-DDR (NEMA 12, 0-2000 RPM)</p><p>PS-4457-11-DDR (NEMA 4X, 0-2000 RPM)</p><p>PS-4256-11-DDR</p><p>PLµS® Encoder</p><p>• For use with Electro Cam Corp. PLµS® Programmable Limit Switches.</p><p>• Cable not included.</p><p>8-Bit Gray Code Encoders</p><p>Not for PLµS® Systems - For use with Programmable Logic Controllers</p><p>12 to 30V DC Input Power, Double Ended 3/4" Shaft</p><p>Sinking† DC Outputs</p><p>PS-4256-12-DDN (NEMA 12, 0-1000 RPM, low true)</p><p>PS-4256-12-DDH (NEMA 12, 0-1000 RPM, high true)</p><p>PS-4456-12-DDN (NEMA 4X, 0-1000 RPM, low true)</p><p>PS-4456-12-DDH (NEMA 4X, 0-1000 RPM, high true)</p><p>PS-4257-12-DDN (NEMA 12, 0-2000 RPM, low true)</p><p>PS-4257-12-DDH (NEMA 12, 0-2000 RPM, high true)</p><p>PS-4457-12-DDN (NEMA 4X, 0-2000 RPM, low true)</p><p>PS-4457-12-DDH (NEMA 4X, 0-2000 RPM, high true)</p><p>Sourcing† DC Outputs</p><p>PS-4256-12-DDP (NEMA 12, 0-1000 RPM)</p><p>PS-4456-12-DDP (NEMA 4X, 0-1000 RPM)</p><p>PS-4257-12-DDP (NEMA 12, 0-2000 RPM)</p><p>PS-4457-12-DDP (NEMA 4X, 0-2000 RPM)</p><p>Encoder Cable (Not for use with PLµS® Systems)</p><p>PS-4300-03-XXX (10 conductor, heavy duty shielded cable,</p><p>stripped, tinned, shield connector)</p><p>XXX = cable length in feet. (20’ cable - PS-4300-03-020)</p><p>Order cable length in 5’ increments.</p><p>† See page 17 for sinking/sourcing definitions.</p><p>Lengths other than those listed above can be supplied for an additional charge.</p><p>Net Forward Encoder Interface (NFEI)</p><p>PS-2252-12-TP1 (Net Forward Encoder Interface)</p><p>Backup Recognition Device - Eliminates erroneous encoder pulse counts caused by uncontrolled backward</p><p>movement, and counts forward pulses after encoder position exceeds the last forward position before reverse.</p><p>Accepts 5-15VDC standard quadrature encoder input.</p><p>13</p><p>Input / Output Racks</p><p>Input / Output Rack Cables</p><p>Output Modules</p><p>Input Modules</p><p>Output Cable</p><p>STANDARD</p><p>PS-4100-11-208</p><p>PS-4100-11-216</p><p>PS-4100-12-224*</p><p>*(2 I/O racks & cables used in -48 output systems)</p><p>PS-9006-0016 Terminal Strip Cover</p><p>(fits standard racks, 1 cover per 4 I/O)</p><p>PS-PB4R Auxiliary Output Rack</p><p>(4 standard output modules)</p><p>SLIMLINE™</p><p>PS-4100-11-M16-D (DIN Rail Mount)</p><p>(may use SLIMLINE™ analog module in position #16)</p><p>TRANSISTOR (low voltage DC, DIN rail)</p><p>PS-4100-12-N32-D (sinking†)</p><p>PS-4100-12-P32-D (sourcing†)</p><p>(2 output racks and cables in 64 output systems)</p><p>For CE, add -U to part number.</p><p>PS-4300-02-XXX Cable (Note: Cables should be 2 feet in length when mounted in an enclosure)</p><p>XXX = cable length in feet (4’ cable = 004), 1’, 2’, 3’, 4’, 5’ lengths</p><p>standard. Other standard lengths, specify XXX in 5’ increments up to 30’.</p><p>Consult factory for longer cable lengths.</p><p>STANDARD</p><p>EC-OAC5A-5</p><p>(24-280V AC, .01-3 Amps, 0 Cross Turn-On, N/C Contact)</p><p>EC-OAC5A-11</p><p>(24-280V AC, .01-3 Amps, Random Turn-On)</p><p>EC-ODC5 (0-60V DC, 0-3 Amps)</p><p>EC-ODC5A (0-200V DC, 0-1 Amp)</p><p>EC-ORR5*</p><p>(200V DC or AC peak max, 0.5A DC or AC peak max</p><p>switching — resistive loads only, 1.0A DC or AC peak max carry)</p><p>SLIMLINE™</p><p>EC-ODC060-3 (0-60V DC, 0-3 Amps)</p><p>EC-ODC200-1 (0-200V DC, 0-1 Amp)</p><p>EC-OAC240-3 (24-280V AC, .02-3 Amps)</p><p>EC-OAC240-3NC</p><p>(24-280V AC, .01-3 Amps, Random Turn-On)</p><p>EC-ORR000-0 (Resistive Loads Only)</p><p>(100V DC; 0.5 Amps / 130V AC; 0.5 Amps, Reed Relay)</p><p>*Not UL, CE or CSA rated</p><p>STANDARD</p><p>EC-IAC5 (90-140V AC, 11mA MAX)</p><p>EC-IAC5A (180-280V AC, 6mA MAX)</p><p>EC-IDC5 (10-32V DC, 32mA MAX)</p><p>SLIMLINE™</p><p>EC-IDC032 (10-32V DC, 32mA MAX)</p><p>EC-IAC120 (90-140V AC, 11mA MAX)</p><p>EC-IAC240 (180-280V AC, 6mA MAX)</p><p>ANALOG - ISOLATED</p><p>SLIMLINE™</p><p>(Used with PS-5X2X, PS-5144, PS-6144 & SLIMLINE™ output racks)</p><p>EC-SANL-010V (Isolated 0-10V DC)</p><p>EC-SANL-420M (Isolated 4-20mA)</p><p>PS-4300-04-XXX</p><p>(10 conductor, heavy duty shielded cable, stripped, tinned, shield connector)</p><p>XXX = cable length in feet (10’ cable = 010) — Order cable length in 5’ increments</p><p>(Used with low-voltage DC transistor output PLµS® Controllers)</p><p>† See page 17 for sinking/sourcing definitions.</p><p>PS-4100-11-216</p><p>Standard</p><p>PS-4100-12-X32</p><p>Transistor DIN Rail</p><p>PS-4100-11-M16-D</p><p>SLIMLINE™ DIN Rail</p><p>NOTE: I/O Racks for PL-1746 modules are listed on page 6.</p><p>PLµS® Accessories and Spare Parts</p><p>PS-4901-01-XXX Program Select Switch and Cable (XXX = cable length in feet)</p><p>(8 position rotary knob switch for remote program selection)</p><p>PS-4901-02-XXX-YYY Program Select Switch and Cable (XXX = cable length to PLµS®</p><p>YYY = length to external device) Identical to PS-4901 switch style with</p><p>cable ganged switching and dual cables for simultaneous switching of programs in</p><p>the PLµS® and another control device.</p><p>PS-4901-02-KEY Program Select Switch Key for the PS-4901-02-XXX-YYY</p><p>PS-4901-03-XXX Program Select Switch and Cable (XXX = cable length in feet)</p><p>8-position locking keyswitch prevents active program change without key,</p><p>supplied with 2 keys, fully wired when ordered with enclosure.</p><p>Supplied with wiring instructions and position label when ordered separately.</p><p>PS-4901-03-KEY Program Select Switch Key for the PS-4901-03-XXX</p><p>PS-4902-01-XXX Program Enable Switch and Cable (XXX = cable length in feet)</p><p>2-position locking keyswitch prevents unauthorized keyboard access;</p><p>no programming changes may be made. Supplied with 2 keys, soldered and</p><p>pre-tinned cable ends (fully wired when ordered with enclosure)</p><p>PS-4902-01-KEY Program Enable Switch Key for the PS-4902-01-XXX</p><p>PS-4902-04-XXX NEMA 4 Rated, 2 position, key operated switch. (XXX = cable length in feet)</p><p>May be used for power or program enable switch.</p><p>NOTE: When ordering with a PLµS® enclosure, cables should be 1 foot in length to avoid coiling.</p><p>Switches & Cables</p><p>PLµS® Enclosures</p><p>NEMA 12 Type Enclosures</p><p>PS-4912-01-001 14x12x6 NEMA 12 for PS-5XXX systems with 8 or 16 I/O racks or</p><p>PS-5X34 systems with 32 DC racks</p><p>PS-4912-01-002 14x12x8 NEMA 12 for 24-output PS-5X0X systems with 24 I/O rack</p><p>PS-4912-01-003 10x8x6 NEMA 12 for PS-5X2X & PS-5X11 integral output units</p><p>PS-4912-01-004 24x20x8 NEMA 12 for 48 output PS-5X0X systems with (2) 24 I/O racks</p><p>PS-4912-01-005 12x10x5 NEMA 12 for PS-5144 or other Integral output PS-5XXX units</p><p>PS-4912-01-006 12x12x6 NEMA 12 for system with PS-6144 controller & PS-6400 keypad</p><p>PS-4912-01-007 6x6x4 NEMA 12 for PS-6400 keypad only</p><p>PS-4912-01-008 14x12x8 NEMA 12 for system with PS-6400 keypad and PS-6144 controller</p><p>with additional space for accessories</p><p>14</p><p>When enclosures are purchased with a PLµS® system, the components are mounted at the factory for no additional charge.</p><p>When purchased separately, they are supplied with a cutout in the door for the controller referenced below and a sub-panel for</p><p>mounting I/O rack(s).</p><p>NEMA 4X Stainless Steel Type Enclosures</p><p>PS-4904-01-001 14x12x6 NEMA 4X Stainless Steel for PS-5XXX systems with 8 or 16 I/O racks</p><p>or PS-5X34 systems with 32 DC racks</p><p>PS-4904-01-002</p><p>20x16x6 NEMA 4X Stainless Steel for 24 output PS-5X0X systems</p><p>with 24 I/O rack</p><p>PS-4904-01-003 10x8x6 NEMA 4X Stainless Steel for PS-5X2X & PS-5X11 integral output units</p><p>PS-4904-01-004 24x20x8 NEMA 4X Stainless Steel for 48 output PS-5X0X systems with (2) 24 I/O racks</p><p>PS-4904-01-005</p><p>12x12x6 NEMA 4X Stainless Steel for PS-5144 or other integral output PS-5XXX units</p><p>PS-4904-01-006 12x12x6 NEMA 4X Stainless Steel for system with PS-6400 keypad & PS-6144 control</p><p>PS-4904-01-007 6x6x4 NEMA 4X Stainless Steel for PS-6400 keypad only</p><p>PS-4904-01-008</p><p>20x16x6 NEMA 4X Stainless Steel for system with PS-6400 keypad & PS-6144</p><p>controller with additional space for accessories</p><p>PS-4903-01-001 Sealed Conduit Entrance (provides seal & strain relief for Encoder cable exiting control cabinet)</p><p>PS-4903-01-002 Sealed Conduit Entrance (provides seal & strain relief for Resolver cable exiting</p><p>control cabinet)</p><p>NOTE: When ordering a PLµS® enclosure, I/O rack cables should be 2 feet in length,and Switch cables should be 1 foot in length.</p><p>15</p><p>Miscellaneous</p><p>PS-4904-99-001 Washdown Boot (Clear, 1/16" silicone rubber for PS-5XXX Series)</p><p>PS-4904-99-002</p><p>Washdown Boot (Clear, 1/16" silicone rubber for PS-6400 keypad/display)</p><p>PS-5300-01-MSC Connector (Bayonet-style resolver end of Resolver cable)</p><p>PS-5300-01-SSC Connector (Sealed-style resolver end of Resolver cable)</p><p>PS-9011-2803 Transistor Array (sinking†, for PS-5X11, PS-XX44 controllers & PS-4100-12-N32 Output Racks)</p><p>PS-9011-2580 Transistor Array (sourcing†, for PS-5X11, PS-XX44 controllers & PS-4100-12-P32 Output Racks)</p><p>PS-9101-0001 Sourcing† Transistor/Fuse Kit for PS-5X11, 5144/6144-P16M09 and 5X34 w/P32 rack</p><p>Includes: (2) PS-9011-2580, (2) PS-9005-0001, (2) PS-9000-0001</p><p>PS-9101-0002 Sinking† Transistor/Fuse Kit for PS-5X11, 5144/6144-N16M09, and 5X34 w/N32 rack</p><p>Includes: (2) PS-9011-2803, (2) PS-9005-0001 and (2) PS-9000-0001</p><p>EC-8004-0001 External Degree Wheel and Pointer</p><p>A double-ended shaft is required for this option. Can be used with Electro Cam Corp. encoders.</p><p>PLµS® Accessories and Spare Parts (continued)</p><p>Fuses & Suppressors</p><p>EC-9001-1010 MOV: 120V AC (Spike suppressor for AC inductive loads)</p><p>EC-9001-1615 Capacitor: 0.05 µfd, 1600V Noise suppressor for AC or DC inductive loads</p><p>EC-9001-2000 R-C Suppressor: 120 or 240V AC (Spike suppressor for AC inductive loads)</p><p>EC-9001-2020 MOV: 240V AC (Spike suppressor for AC inductive loads)</p><p>EC-9001-4004 Diode: 1N4004 (Spike suppressor for DC inductive loads)</p><p>EC-9001-5010 Load Resistor: 10K Ohm, 5 Watt</p><p>EC-9001-5363 Zener Diode (36V DC): 1N5363 (Spike suppressor for DC inductive loads)</p><p>EC-9001-5365 Zener Diode (36V DC) 1N5365B (Spike suppressor for DC inductive loads)</p><p>EC-9001-5369 Zener Diode (51V DC): 1N5369 (Spike suppressor for DC inductive loads)</p><p>EC-9001-5388 Zener Diode (200V DC): 1N5388 (Spike suppressor for DC inductive loads)</p><p>PS-9000-0001 Fuse: 1 Amp I/O rack logic power & PS-5X11 DC outputs. (pkg. of 5)</p><p>PS-9000-0005 Fuse: 5 Amp output (pkg. of 10) Each module’s output is individually fused on the rack</p><p>PS-9000-0500 Fuse: 1/2 Amp glass line fuse for keyboard/controller (pkg. of 5)</p><p>PS-9000-4114 Fuse: 1-1/4 Amp glass SLOBLO power fuse for PS-6144/6244 & PS-5X2X (pkg. of 5)</p><p>PS-9000-4500 Fuse: 1/2 Amp SLOBLO glass power fuse for PS-5144 keyboard/controller (pkg. of 5)</p><p>PS-9001-6010</p><p>SIP Resistor (10K, 10 pin, bussed-for PS-4256-12-DDN Encoder)</p><p>PS-9005-0001 Fuse: 1 Amp DC power fuse (used on 5144/6144 transistor outputs, pkg. of 5)</p><p>PS-9005-0002</p><p>Fuse: 2 amp for PL-1746-C02 & C03 outputs (pkg. of 5)</p><p>PS-9005-0004 4 Amp Fuses for SLIMLINE™ Modules (pkg. of 5) Also used on transistor output rack .</p><p>PS-9005-0250 Fuse:</p><p>1/4 Amp Accessory power for PS-5000 controllers (pkg. of 5)</p><p>Communication</p><p>PS-5401-01-020* PLµSNet™ II Upload/Download Utility (For most PLµS® Controllers)</p><p>PS-5402-01-012 Serial PLµSNet™ II Cable (RS-232, 12’, 9-pin to 9-pin)</p><p>PS-5402-03-XXX Cable (RS-485, Remote display, DB9-stripped & tinned)</p><p>PS-5402-04-XXX Cable (RS-485, Remote display, stripped & tinned-both ends)</p><p>* PS-5401-01-020 must be ordered with PS-5402-01-012 serial cable.</p><p>† See page 17 for sinking/sourcing definitions.</p><p>Terminal Blocks</p><p>PS-5300-01-TE2 Terminal Block (7 pin Resolver, 2 connector for PS-6344)</p><p>PS-5300-01-TER Terminal Block (7 pin Resolver connector on controllers)</p><p>PS-9006-0001 Terminal Block (PS-5X1X sinking† output, 1-8)</p><p>PS-9006-0002 Terminal Block (PS-5X1X sinking† output, 9-16)</p><p>PS-9006-0003 Terminal Block (PS-5X1X sourcing† output, 1-8)</p><p>PS-9006-0004 Terminal Block (PS-5X1X sourcing† output, 9-16)</p><p>PS-9006-0006 Terminal Block (PS-5X2X output, 1-4)</p><p>PS-9006-0007 Terminal Block (PS-5X2X output, 5-8)</p><p>PS-9006-0008 Terminal Block (PS-5XXX logic interface)</p><p>PS-9006-0009 Terminal Block (PS-5X2X output, #9)</p><p>PS-9006-0010 Terminal Block (PS-5XXX input power, 120/240V AC)</p><p>PS-9006-0011 Terminal Block (PS-5X34 output, 1-8)</p><p>PS-9006-0012 Terminal Block (PS-5X34 output, 9-16)</p><p>PS-9006-0013</p><p>Terminal Block (PS-5X34 output, 17-24)</p><p>PS-9006-0014 Terminal Block (PS-5X34 output, 25-32)</p><p>PS-9006-0015 Terminal Block (PS-5X34 sinking† , 16 pin DIP jumper)</p><p>PS-9006-0016 Terminal Strip Cover (PS-4100 standard output racks, 1 per 4 I/O)</p><p>PS-9006-0017 Terminal Block (PS-5144 DC user power for DC outputs)</p><p>PS-9006-0018 Terminal Block (PS-5144 DC power for logic inputs)</p><p>PS-9006-0019 Terminal Block (PS-5144 sinking/sourcing† output, 1-8)</p><p>PS-9006-0020 Terminal Block (PS-5144 sinking/sourcing† output, 9-16)</p><p>PS-9006-0023 Terminal Block (PS-5144 logic input, 1-8)</p><p>PS-9006-0024</p><p>Terminal Block (PS-5144 logic input, 9-16)</p><p>PS-9006-0025 Terminal Block (PS-5144 RS-485 communications)</p><p>PS-9006-0026 Terminal Block (PS-5144 input power, 20-30V DC)</p><p>PS-9006-0027 Terminal Block (PS-5144 module outputs, 17-20)</p><p>PS-9006-0028 Terminal Block (PS-5144 module outputs, 21-25)</p><p>PS-9006-0029 Terminal Block (PS-6X44 keypad port on controller, 7 pos.)</p><p>PS-9006-0030</p><p>Terminal Block (PS-XX44-M17 module outputs, 9-12, 8 pos.)</p><p>PS-9006-0031 Terminal Block (PS-XX44-M17 module outputs, 13-17, 10 pos.)</p><p>PS-9006-0033 Terminal Block (PS-XX44-M17 module outputs, 1-4, 8 pos.)</p><p>PS-9006-0034 Terminal Block (PS-XX44-M17 module outputs, 5-8, 8 pos.)</p><p>PS-9006-0038 Terminal Block (PS-6400 Keypad)</p><p>PS-9006-0039 Terminal Block (9 Pin Resolver connector on controllers)</p><p>PS-9006-0040 Terminal Block (PL-1746, Keypad connector, 7 pos.)</p><p>PS-9006-0041 Terminal Block (PL-1746 Resolver connector, 7 pos.)</p><p>PS-9006-0042 Terminal Block (PL-1746 24V DC input connector, 3 pos.)</p><p>PS-9006-0043 Terminal Block (PL-1746-C02/03 input connector, 10 pos.)</p><p>PS-9006-0044</p><p>Terminal Block (PL-1746-C02/03 output connector, 10 pos.)</p><p>DIN Rails</p><p>PS-4903-02-001 G Profile, G32, 9 inch length</p><p>PS-4903-02-002 G Profile, G32, 18 inch length</p><p>PS-4903-02-003 Top Hat Profile, 35 x 7.5, 9 inch length</p><p>PS-4903-02-004 Top Hat Profile, 35 x 7.5, 18 inch length</p><p>®</p><p>PLµS® Accessories and Spare Parts (continued)</p><p>16</p><p>† See page 17 for sinking/sourcing</p><p>definitions.</p><p>PS-5XXX Series Assuming:</p><p>120V AC input, $30 DC modules (or $35 modules for PS-5X2X) or sourcing outputs on PS-5X11; 10ft. encoder or</p><p>resolver cable, I/O rack (if required), 2 ft. rack (or jumper) cable; $675 encoder (PS-50XX) or $750 resolver.</p><p>Outputs PS-5011 PS-5111 PS-5001 PS-5101 PS-5021 PS-5121 PS-5004 PS-5104 PS-5024 PS-5124 PS-5034 PS-5134</p><p>8 2,210 2,400</p><p>9 2,360 2,625 2,460 2,725</p><p>16 2,670 2,860 3,263 3,543 3,363 3,643</p><p>16 3,343* 3,623* 3,443* 3,723*</p><p>24 3,753 4,033 3,853 4,133</p><p>25</p><p>32 3,193 3,473</p><p>48 5,086 5,366 5,186 5,466</p><p>64 3,806 4,086</p><p>Typical PLµS® System Costs</p><p>Based on Price List dated October 1, 2018</p><p>* If SLIMLINE™ Rack and SLIMLINE™ Modules are used.</p><p>PS-XX44 Assuming:</p><p>24 V DC input, $35 SLIMLINE™ modules, sinking or sourcing† on PS-X144-24-X16M09; $750 Resolver, 10 ft. Resolver</p><p>Cable, 10 ft. Keyboard Display Cable and PS-6400 Keypad/Display. (Keypad and Cable only on 6X44’s)</p><p>Outputs PS-5144-24-X16M09 PS-5144-24-M17 PS-6144-24-X16M09 PS-6144-24-M17 PS-6344-X16M09* PS-6344-M17*</p><p>17 3,655 4,110 5,205</p><p>25 3,475 3,930 5,025</p><p>* 2 Resolvers & cables quoted in 6344 systems</p><p>†SINKING or SOURCING (as pertaining to Electro Cam Corp. products)</p><p>Sinking means that when the logic is true and the output (or input device) is ON, the output (or input device) is providing a DC</p><p>common or ground to the connected device.</p><p>Sourcing means that when the logic is true and the output</p><p>(or input device) is ON, the output (or input device) is providing a</p><p>+DC voltage to the connected device.</p><p>This information is important when interfacing an Electro Cam Corp. product with another electronic device. If you are using an</p><p>Electro Cam Corp. product input to an Allen-Bradley 1746-IN16 “sinking” input card* or similar A-B device, you have to supply a</p><p>+DC voltage (Electro Cam Corp. Sourcing output) to this card, NOT a DC common or ground. In these cases, Sinking is what</p><p>the card does with the input voltage; sinks it to common or ground.</p><p>* Other manufacturers include, but not limited to: Koyo (formerly GE Series 1, Texas Instruments, or Siemens SIMATIC PLS’s) that use descrip-</p><p>tions similar to Allen-Bradley.</p><p>17</p><p>PL-1746-C01-R1</p><p>With Resolver & Cable 2,800</p><p>With Resolver & Cable, Keypad & Cable 3,555</p><p>PL-1746 PLµS® Plug-In Modules</p><p>PL-1746-C02</p><p>With Resolver & Cable 2,700</p><p>With Resolver & Cable, Keypad & Cable 3,455</p><p>Electronic Cam Switches</p><p>EC-2000 Series—12 to 30 VDC, NEMA 12 Enclosure</p><p>0 to 200 mA DC sinking outputs</p><p>EC-2004-12-DLN (4 Outputs, Left Hand Shaft Extension)</p><p>EC-2004-12-DRN (4 Outputs, Right Hand Shaft Extension)</p><p>EC-2004-12-DDN (4 Outputs, Double-Ended Shaft Extension)</p><p>( EC-2008-12-DLN 8 Outputs, Left Hand Shaft Extension)</p><p>EC-2008-12-DRN (8 Outputs, Right Hand Shaft Extension)</p><p>EC-2008-12-DDN (8 Outputs, Double-Ended Shaft Extension)</p><p>EC-2012-12-DLN (12 Outputs, Left Hand Shaft Extension)</p><p>EC-2012-12-DRN (12 Outputs, Right Hand Shaft Extension)</p><p>EC-2012-12-DDN (12 Outputs, Double-Ended Shaft Extension)</p><p>EC-2400 Series—12 to 30 VDC, NEMA 4X Stainless Steel Enclosure</p><p>Double-ended stainless steel shaft, 0 to 200 mA DC sinking outputs</p><p>EC-2404-12-DDN (4 Outputs)</p><p>EC-2408-12-DDN (8 Outputs)</p><p>EC-3000 Series—120 VAC Input, NEMA 12 Enclosure</p><p>Specify output modules separately (see page 20)</p><p>EC-3004-10-ALO (4 Outputs, Left Hand Shaft Extension)</p><p>EC-3004-10-ARO (4 Outputs, Right Hand Shaft Extension)</p><p>EC-3004-10-ADO (4 Outputs, Double-Ended Shaft Extension)</p><p>EC-3008-10-ALO (8 Outputs, Left Hand Shaft Extension)</p><p>EC-3008-10-ARO (8 Outputs, Right Hand Shaft Extension)</p><p>EC-3008-10-ADO (8 Outputs, Double-Ended Shaft Extension)</p><p>EC-3012-10-ALO (12 Outputs, Left Hand Shaft Extension)</p><p>EC-3012-10-ARO (12 Outputs, Right Hand Shaft Extension)</p><p>EC-3012-10-ADO (12 Outputs, Double-Ended Shaft Extension)</p><p>EC-3000 Series—240 VAC Input, NEMA 12 Enclosure</p><p>Specify output modules separately (see page 20)</p><p>EC-3004-20-ALO (4 Outputs, Left Hand Shaft Extension)</p><p>EC-3004-20-ARO (4 Outputs, Right Hand Shaft Extension)</p><p>EC-3004-20-ADO (4 Outputs, Double-Ended Shaft Extension)</p><p>EC-3008-20-ALO (8 Outputs, Left Hand Shaft Extension)</p><p>EC-3008-20-ARO (8 Outputs, Right Hand Shaft Extension)</p><p>EC-3008-20-ADO (8 Outputs, Double-Ended Shaft Extension)</p><p>EC-3012-20-ALO (12 Outputs, Left Hand Shaft Extension)</p><p>EC-3012-20-ARO (12 Outputs, Right Hand Shaft Extension)</p><p>EC-3012-20-ADO (12 Outputs, Double-Ended Shaft Extension)</p><p>18</p><p>Electronic Cam Switches (continued)</p><p>EC-3000 Series—12 VDC Input, NEMA 12 Enclosure</p><p>Specify output modules separately (see page 20)</p><p>EC-3004-12-DLO (4 Outputs, Left Hand Shaft Extension)</p><p>EC-3004-12-DRO (4 Outputs, Right Hand Shaft Extension)</p><p>EC-3004-12-DDO</p><p>(4 Outputs, Double-Ended Shaft Extension)</p><p>EC-3008-12-DLO (8 Outputs, Left Hand Shaft Extension)</p><p>EC-3008-12-DRO (8 Outputs, Right Hand Shaft Extension)</p><p>EC-3008-12-DDO</p><p>(8 Outputs, Double-Ended Shaft Extension)</p><p>EC-3012-12-DLO (12 Outputs, Left Hand Shaft Extension)</p><p>EC-3012-12-DRO (12 Outputs, Right Hand Shaft Extension)</p><p>EC-3012-12-DDO (12 Outputs, Double-Ended Shaft Extension)</p><p>EC-3000 Series—24 VDC Input, NEMA 12 Enclosure</p><p>Specify output modules separately (see page 20)</p><p>EC-3004-24-DLO (4 Outputs, Left Hand Shaft Extension)</p><p>EC-3004-24-DRO (4 Outputs, Right Hand Shaft Extension)</p><p>EC-3004-24-DDO</p><p>(4 Outputs, Double-Ended Shaft Extension)</p><p>EC-3008-24-DLO (8 Outputs, Left Hand Shaft Extension)</p><p>EC-3008-24-DRO (8 Outputs, Right Hand Shaft Extension)</p><p>EC-3008-24-DDO</p><p>(8 Outputs, Double-Ended Shaft Extension)</p><p>EC-3012-24-DLO (12 Outputs, Left Hand Shaft Extension)</p><p>EC-3012-24-DRO (12 Outputs, Right Hand Shaft Extension)</p><p>EC-3012-24-DDO</p><p>(12 Outputs, Double-Ended Shaft Extension)</p><p>EC-3400 Series—120 VAC Input, NEMA 4X Stainless Steel Enclosure</p><p>Double-ended stainless steel shaft, specify output modules separately (see page 20)</p><p>EC-3404-10-ADO (4 Outputs)</p><p>EC-3408-10-ADO (8 Outputs)</p><p>EC-3400 Series—240 VAC Input, NEMA 4X Stainless Steel Enclosure</p><p>Double-ended stainless steel shaft, specify output modules separately (see page 20)</p><p>EC-3404-20-ADO (4 Outputs)</p><p>EC-3408-20-ADO (8 Outputs)</p><p>EC-3400 Series—12 VDC Input, NEMA 4X Stainless Steel Enclosure</p><p>Double-ended stainless steel shaft, specify output modules separately (see page 20)</p><p>EC-3404-12-DDO (4 Outputs)</p><p>EC-3408-12-DDO (8 Outputs)</p><p>EC-3400 Series—24 VDC Input, NEMA 4X Stainless Steel Enclosure</p><p>Double-ended stainless steel shaft, specify output modules separately (see page 20)</p><p>EC-3404-24-DDO (4 Outputs)</p><p>E C-3408-24-DDO (8 Outputs)</p><p>19</p><p>Output Modules (Plug-In for EC-3000/EC-3400 Series)</p><p>EC-ODC5 (0 to 60 VDC @ 3 Amps max.)</p><p>(EC-ODC5A 0 to 200 VDC @ 1 Amp max.)</p><p>EC-OAC5A-11 (24 to 280 VAC @ 3 Amps Maximum—Random Turn-On)</p><p>EC-OAC5A-5 (24 to 280 VAC @ 3 Amps Maximum—0 Cross Turn-On, N/C Contact)</p><p>EC-ORR5 Reed Relay, Max Switching Voltage: 200V DC or peak AC,</p><p>Max Switching Current: 0.5A DC or peak AC (resistive loads only),</p><p>Max Carry Current: 1.0A DC or peak AC</p><p>Values marked on actual unit denote derated operating parameters.</p><p>Options</p><p>“CF” (Recommended for Highly Contaminating Environments)</p><p>Conformal coating on both sides of printed circuit boards of standard units. For standard units, add “CF”</p><p>extension to Unit Model Number. CF is standard on NEMA 4X units. Example: EC-3004-10-ADO-CF</p><p>4 Switch Units for EC-2004 & EC-3004</p><p>8 or 12 Switch Units for EC-2008/2012 & EC-3008/3012</p><p>“CFX” (Recommended for High Shock and Vibration)</p><p>Conformal coating on both sides of printed circuit boards. Removable jumpers replace DIP switches.</p><p>Add “CFX” extension to Unit Model Number. Example: EC-3004-10-ADO-CFX</p><p>4 Switch Units for EC-2004/2404 & EC-3004/3404</p><p>for 8 or 12 Switch Units EC-2008/2012, EC-2408/2412, EC-3008/3012 & EC-3408/3412</p><p>Sprocket Disengagement Clutch</p><p>EC-8001-035-030 (A.S.A. No. 35, 30 Tooth C.R.S. Sprocket)</p><p>EC-8001-040-022 (A.S.A. No. 40, 22 Tooth C.R.S. Sprocket)</p><p>EC-8001-040-024 (A.S.A. No. 40, 24 Tooth C.R.S. Sprocket)</p><p>EC-8001-040-025 (A.S.A. No. 40, 25 Tooth C.R.S. Sprocket)</p><p>EC-8001-041-022 (A.S.A. No. 41, 22 Tooth C.R.S. Sprocket)</p><p>EC-8001-041-024 (A.S.A. No. 41, 24 Tooth C.R.S. Sprocket)</p><p>Consult factory on availability of special sprockets not listed.</p><p>Pulse Generating Discs – non-returnable/non-refundable</p><p>Pulse generating discs must be specified when ordering EC-2000/2400 Series or EC-3000/3400 Series units,</p><p>as they cannot be added in the field.</p><p>The pulse disc replaces one set of adjustable cams, output module still needed at this position on</p><p>EC-3000/3400 Series units. See page 20 for ordering descriptions of pulse discs.</p><p>External Degree Wheel and Pointer (EC-8004-0001)</p><p>A double-ended shaft is required for this option. External degree wheel and pointer must be ordered when ordering</p><p>the EC-2000/2400 Series or EC-3000/3400 Series units.</p><p>Specify mounting (right or left) as viewed from above with conduit entrance toward you, and clockwise or counterclockwise</p><p>as viewed from the end of the shaft on which the degree wheel is to be mounted. If not specified, it will be mounted on</p><p>left for clockwise rotation.</p><p>Spare Parts & Accessories</p><p>EC-8004-5000 Degree Wheel Decal—Clockwise from Left</p><p>DEC-8004-6000 egree Wheel Decal—Counterclockwise from Left</p><p>EC-8004-7000 Degree Wheel Decal—Bidirectional</p><p>EC-9000-0003 Fuse Package—(10)</p><p>3 Amp Output Fuses for all EC-3000 Units</p><p>EC-9000-0250 Fuse Package—(5) 1/4 Amp Input Fuses for all EC-3000 and EC-3400 Units</p><p>20</p><p>Spare Parts & Accessories (continued)</p><p>EC-9001-3250 Fuse Package — (2) 1/4 Amp and (3) 3 Amp Fuses for all EC-3000/EC-3400 Units</p><p>EC-9001-3500 Fuse Package — (2) 1/2 Amp and (3) 3 Amp Fuses for Special DC EC-3000 Units</p><p>EC-9001-0606 Key — 606 Woodruff</p><p>EC-9001-5010 Load Resistor — 5W, 10K Ohms</p><p>EC-9001-0001 Wrench — 1" Spare</p><p>EC-9001-0678 Key — 3/16" Square x 7/8" Long (Special for “MDS” Cam Switches)</p><p>EC-155-7000-007 4 Position Terminal Block Cover</p><p>EC-155-7000-008 5 Position Terminal Block Cover</p><p>EC-250-7000-008 1/2" Conduit Fitting</p><p>Suppressors</p><p>EC-9001-1615 Capacitor — 0.05 µfd, 1600V Noise Suppressor for AC or DC Inductive Loads</p><p>EC-9001-4004</p><p>Diode — 1N4004 Spike Suppressor for DC Inductive Loads</p><p>EC-9001-2000</p><p>R-C Suppressor — 120 or 240 VAC Spike Suppressor for AC Inductive Loads</p><p>EC-9001-1010</p><p>Varistor (MOV) — 120 VAC Spike Suppressor for AC Inductive Loads</p><p>EC-9001-2020 Varistor (MOV) — 240 VAC Spike Suppressor for AC Inductive Loads</p><p>EC-9001-5369 Zener Diode (51 VDC) — 1N5369 Spike Suppressor for DC Inductive Loads</p><p>EC-9001-5388 Zener Diode (200 VDC) — 1N5388 Spike Suppressor for DC Inductive Loads</p><p>EC-9001-E36A P6KE36A Tranzorb</p><p>Printed Circuit Boards</p><p>Each PCB assembly listed below includes top and bottom boards. These boards are not available separately except as noted</p><p>below. For voltage changes in the 3000 Series, replace -10 with either -20, -12 or -24. Pricing listed below.</p><p>EC-2000 Series and EC-3000 Series</p><p>EC-2004-12-PCB Replacement circuit board set for EC-2004</p><p>EC-2000-102-PCB* EC-2008 .............................. requires 2 EC-2000-102-PCB</p><p>EC-2012 .............................. requires 3 EC-2000-102-PCB</p><p>EC-2008-TOP-PCB Top Board</p><p>EC-2012-TOP-PCB Top Board</p><p>EC-3004-10-PCB Replacement circuit board set for EC-3004</p><p>EC-3008-10-PCB Replacement circuit board set for EC-3008</p><p>EC-3012-10-PCB Replacement circuit board set for EC-3012</p><p>* These units include the bottom board only. Top board should be ordered separately.</p><p>• For EC-2400 and EC-3400 Series units, specify a “4" in the second digit place of the part number.</p><p>Example: EC-3404-10-PCB.</p><p>• For CF option, add CF after the PCB extension in the part number on standard units. CF is standard on</p><p>NEMA 4X units. Example: EC-3004-10-PCB-CF.</p><p>• For CFX option, add CFX after the PCB extension in the part number.</p><p>Example: EC-3004-10-PCB-CFX.</p><p>21</p><p>How to order EC-2000/2400 Series Switches</p><p>(12 to 30 VDC Input, 0 to 200ma DC sinking type outputs)</p><p>EXAMPLE: EC-2008-12-DDN-CFX-D-1-1/60-4-2/3</p><p>The example part number is for a Series EC-2000 control with a standard NEMA 12 enclosure, 8 outputs, double shaft</p><p>extension, with CFX shock and vibration option, and 5 pulse discs (1 disc with 60 -3° slots and 4 discs with 3 -60° slots)</p><p>mounted on the control shaft.</p><p>EC-2008 - 12 - D - D - N - CFX - D - 1 - 1/60 - 4 - 2/3</p><p>Series & Enclosure</p><p>EC-20 = EC-2000 Series:</p><p>Standard NEMA 12</p><p>enclosure with gasketed</p><p>JIC oil-tight cover.</p><p>EC-24 = EC-2400 Series:</p><p>NEMA 4X enclosure and</p><p>shaft are stainless steel.</p><p>Shaft Type</p><p>D = Double</p><p>extension</p><p>(standard</p><p>on EC-2400</p><p>series)</p><p>L = Left hand</p><p>extension</p><p>R = Right hand</p><p>extension</p><p>High Shock or</p><p>Vibration Options</p><p>NOTE: CFX is required</p><p>when high shock or vibra-</p><p>tion is possible.</p><p>CFX = Extra conformal</p><p>coating on bottom PC</p><p>board & DIP switches</p><p>are replaced by push-in</p><p>jumpers to change light</p><p>energizing (0-180°) /</p><p>dark energize (181°-</p><p>360°) mode.</p><p>CF = Extra conformal coat-</p><p>ing on both sides of PC</p><p>boards.(Dip switches</p><p>used)</p><p>D-Disc Required</p><p>Pulse generating discs</p><p>must be ordered when</p><p>ordering control units.</p><p>They cannot be added</p><p>in the field. The pulse</p><p>disc is mounted to the</p><p>control cam shaft and</p><p>replaces one set of</p><p>adjustable cams.</p><p>The first disc listed</p><p>will be mounted in the</p><p>furthest right position,</p><p>etc.</p><p>Input Voltage</p><p>12 = 12-30VDC</p><p>Type of Input</p><p>D = DC Input</p><p>Output Type</p><p>N = Sinking type</p><p>output Number of</p><p>discs per type</p><p>Discs</p><p>1/1 = 1-3° slot</p><p>1/10 = 10-3° slots</p><p>1/60 = 60-3° slots</p><p>2/1 = 1-180° slot</p><p>2/2 = 2-90° slots</p><p>2/3 = 3-60° slots</p><p>2/4 = 4-45° slots</p><p>2/6 = 6-30° slots</p><p>2/8 = 8-22.5° slots</p><p>2/16 = 16-11.2° slots</p><p>2/32 = 32-5.6° slots</p><p>2/64 = 64-2.8° slots</p><p>5/2 = 2-5° slots</p><p>** **</p><p>**These extensions used only if CFX/CF and/or pulse disc (-s) are required.</p><p>How to order EC-3000/3400 Series Switches</p><p>(Specify plug-in output modules separately)</p><p>EXAMPLE: EC-3012-10-ADO-CFX-D-1-1/60-4-2/3 with (5) EC-ODC5* & (7) EC-OAC5A-11*</p><p>EC-3012 - 10 - A - D - O - CFX - D - 1 - 1/60 - 4 - 2/3** **</p><p>Series & Enclosure</p><p>EC-30 = EC-3000 Series:</p><p>Standard NEMA 12 enclo-</p><p>sure with gasketed JIC</p><p>oil-tight cover.</p><p>EC-34 = EC-3400 Series:</p><p>NEMA 4X enclosure and</p><p>shaft are stainless steel.</p><p>Number</p><p>of Outputs</p><p>04 = 4 outputs</p><p>08 = 8 outputs</p><p>12 =12 outputs</p><p>One output</p><p>module required</p><p>per output. Shaft Type</p><p>D = Double</p><p>extension</p><p>(standard</p><p>on EC-3400</p><p>series)</p><p>L = Left hand</p><p>extension</p><p>R = Right hand</p><p>extension</p><p>High Shock or</p><p>Vibration Options</p><p>NOTE: CFX is required</p><p>when high shock or vibration</p><p>is possible.</p><p>CFX = Ext ra confor mal</p><p>coating on bottom PC</p><p>board & DIP switches</p><p>are replaced by push-in</p><p>jumpers to change light</p><p>energizing (0-180°) / dark</p><p>energize (181°-360°)</p><p>mode.</p><p>CF = Extra conformal coat-</p><p>ing on both sides of PC</p><p>boards. (Dip switches</p><p>used)</p><p>Type</p><p>of Input</p><p>A = AC Input</p><p>D = DC Input</p><p>Input</p><p>Voltage</p><p>10 = 120VAC</p><p>20 = 240VAC</p><p>12 = 12VDC</p><p>24 = 24VDC</p><p>Output Type</p><p>O = One AC or DC</p><p>output module</p><p>per switch.</p><p>D-Disc Required</p><p>Pulse generating discs</p><p>must be ordered when</p><p>ordering control units.</p><p>They cannot be added</p><p>in the field. The pulse</p><p>disc is mounted to the</p><p>control cam shaft and</p><p>replaces one set of</p><p>adjustable cams.</p><p>The first disc listed</p><p>will be mounted in the</p><p>furthest right position,</p><p>etc.</p><p>Discs</p><p>1/1 = 1-3° slot</p><p>1/10 = 10-3° slots</p><p>1/60 = 60-3° slots</p><p>2/1 = 1-180° slot</p><p>2/2 = 2-90° slots</p><p>2/3 = 3-60° slots</p><p>2/4 = 4-45° slots</p><p>2/6 = 6-30° slots</p><p>2/8 = 8-22.5° slots</p><p>2/16 = 16-11.2° slots</p><p>2/32 = 32-5.6° slots</p><p>2/64 = 64-2.8° slots</p><p>5/2 = 2-5° slots</p><p>Number of</p><p>discs per type</p><p>*Each output to be used requires an output module that is ordered and priced separately. Select the appropriate output modules listed on the</p><p>following page, depending on AC or DC voltage current. Modules will be mounted at factory in random sequence unless otherwise specified.</p><p>**These extensions used only if CFX/CF and/or pulse disc (-s) are required.</p><p>22</p><p>Number of</p><p>Outputs</p><p>04 = 4 outputs</p><p>08 = 8 outputs</p><p>12 =12 outputs</p><p>AC/DC Output Module Specifications</p><p>AC Outputs: EC-OAC5A-11 (Standard)</p><p>Load Voltage: 24 V rms min.</p><p>280 V rms max.</p><p>Load Current: 30 mA rms min.</p><p>3 A rms max. @/below 35°C (95°F)</p><p>Above 35°C derate 50 mA/°C</p><p>(27.8 mA/°F)</p><p>Turn On Time: 100 µs max. @ 60 Hz</p><p>Turn Off Time: 8.3 ms max. @ 60 Hz</p><p>Off State Leakage: 2 mA AC rms @ 120 VAC rms, 60 Hz</p><p>DC Outputs: EC-ODC5 (Standard) DC Outputs: EC-ODC5A (Standard)</p><p>General Specifications and Dimensions</p><p>Output Voltage: 0 to 60 VDC Output Voltage: 0 to 200 VDC</p><p>Output Current: 3 A @/below 35°C (95°F) Output Current: 1 A @/below 45°C (113°F)</p><p>Derate 35.7 mA/°C above 35°C Derate 18 mA/°C above 45°C</p><p>(19.8 mA/°F above 95°F) (10 mA/°F above 113°F)</p><p>Turn On Time: 50 µs max. Turn On Time: 50 µs max.</p><p>Turn Off Time: 50 µs max. Turn Off Time: 50 µs max.</p><p>Off State Leakage: 1 µA DC max. @ 24 VDC Off State Leakage: 1 µA DC max. @ 24 VDC</p><p>Dimensions and Weight</p><p>Model H W D Wt.(Lb.) Wt.(Kg)</p><p>EC-2004, EC-3004 4-3/8 6.0 6.0 9.0 4.0</p><p>EC-2008, EC-3008 4-3/8 8.0 8.0 13.5 6.1</p><p>EC-2012, EC-3012 4-3/8 10.0 8. 0 15.0 6.8</p><p>Dimensions and</p><p>weight also</p><p>apply to NEMA</p><p>4X units.</p><p>23</p><p>D W</p><p>Model EC-3004-10-ADO</p><p>NEMA 12 Screw Cover</p><p>H</p><p>Right Hand</p><p>Shaft Extension</p><p>Left Hand</p><p>Shaft Extension</p><p>13647 Metric Rd • Roscoe, IL 61073 USA • Web Site: http://www.electrocam.com • e-mail: ecam@electrocam.com</p><p>NOTE</p><p>Electro Cam Corp. believes that all information provided</p><p>herein is correct and reliable and reserves the right to</p><p>update at any time. Electro Cam Corp. does not assume</p><p>any responsibility for its use unless otherwise expressly</p><p>undertaken.</p><p>Copyright © 2002</p><p>All Rights Reserved</p><p>Neither this document nor any part may be reproduced or transmitted in</p><p>any form or by any means without permission in writing from the publisher.</p><p>, PLµS, SLIMLINE, and PLµSNET are all registered trademarks of</p><p>305 10/18</p>
