Strategies and engineering aspects on the scale‑up of bioreactors
for different bioprocesses
Ariane Fátima Murawski de Mello1  · Luciana Porto de Souza Vandenberghe1  ·
Leonardo Wedderhoff Herrmann1  · Luiz Alberto Júnior Letti1  · Walter José Martinez Burgos1  ·
Thamarys Scapini1  · Maria Clara Manzoki1  · Priscilla Zwiercheczewski de Oliveira1  · Carlos Ricardo Soccol1
Received: 28 July 2023 / Revised: 11 September 2023 / Accepted: 13 September 2023 / Published online: 10 October 2023
© Jiangnan University 2023
Abstract
Bioreactors are central equipment used in the majority of bioprocesses. Different models of bioreactors have been devel-
oped for different processes, which can be applied either for submerged or for solid-state fermentation. Scale-up involves
the development of bioprocess in bench, pilot, and industrial scales. Optimal conditions are first screened and determined
in the bench scale and so that the process can be transferred to a larger scale. This transferring requires the proper reproduc-
tion of conditions and performance, being a major challenge since important aspects, such as aeration and agitation, are
critical for cells development. In this case, scale-up strategies are employed to maintain bioprocesses’ performance. These
strategies are based on geometric similarity aspects of bioreactors, agitation, and aeration conditions, which must follow the
requirements of each bioprocess and the used microorganisms. Operational conditions significantly impact cell growth and,
consequently, the biosynthesis of different biomolecules, which must then be reproduced at higher scales. For this purpose,
one or more operating factors can be maintained constant during scale-up with the possibility to predict, for example, the
power consumption of large-scale bioreactors or aeration conditions in an aerobic culture. This review presents the most
employed bioreactors’ scale-up strategies. In addition, the scale-up of other bioreactors models, such as pneumatic and solid-
state fermentation bioreactor and even photobioreactors, will also be described with some examples.
Keywords Bioreactors · Bioprocess · Bioproducts · Scale-up · Biomolecules
Introduction
Bioprocesses and fermentation have been developed since
antiquity, with products such as beer, wine, bread, vinegar,
and others, being obtained with the purpose of food con-
servation [1]. With technology development and knowledge
about how these bioprocesses occur, highly pure biomol-
ecules could be produced in larger scales. Nowadays, it is
possible to manufacture a variety of bioproducts—such as
organic acids, biofuels, bioplastics, biopesticides, pharma-
ceutics, aromas, and others—by fermentation. However, this
kind of process is usually more complex than the chemical
routes, mainly because cells with specific physicochemical
requirements are used [2]. Besides, in order for a bioprod-
uct to reach the market, some steps need to be followed for
proper process implementation and scale-up.
Usually, bioprocess development will occur in three
scales: laboratory or bench, pilot and, finally, industrial
(see e-Supplementary material) [3]. In bench scale, small
volumes are applied, either in flasks (50–500 mL) or in
bioreactors (1–15 L) for conditions screening and process
optimization. Therefore, different nutrients sources and
physicochemical conditions (such as temperature, pH, agi-
tation, and aeration rates) for maximum biomass and product
yields and minimum cost can be easily tested [4]. Besides,
optimization and simulations via experimental design can
be conducted, and models can be developed and validated
on this scale [5]. With all the optimal conditions determined
and the process tested in a bench-scale bioreactor, it can be
transferred to pilot scale (bioreactors of 50–500 L).
This process will implicate in maintaining some param-
eters (mainly involving aeration and agitation) constant
 * Luciana Porto de Souza Vandenberghe
 lvandenberghe@ufpr.br
1 Department of Bioprocess Engineering and Biotechnology,
Federal University of Paraná, Centro Politécnico, Curitiba,
Paraná 81531-980, Brazil
http://orcid.org/0000-0003-4103-8462
http://orcid.org/0000-0003-0267-1185
http://orcid.org/0000-0002-2301-3942
http://orcid.org/0000-0003-3733-6133
http://orcid.org/0000-0003-4377-6530
http://orcid.org/0000-0003-1184-3049
http://orcid.org/0000-0002-0892-8132
http://orcid.org/0000-0002-2688-8090
http://orcid.org/0000-0001-7630-6864
http://crossmark.crossref.org/dialog/?doi=10.1007/s43393-023-00205-z&domain=pdf
366 Systems Microbiology and Biomanufacturing (2024) 4:365–385
1 3
among scales, along with the geometrical similarity of the
bioreactors. The pilot scale will function as a demonstration
step for determining if the developed bioprocess is viable
and establishing important parameters that could not be opti-
mized in the laboratory (e.g., agitation influence in shear
forces) [6]. With the economic and technical viability of
the project being demonstrated in pilot scale, the bioprocess
can finally reach the industrial and commercial steps. Scal-
ing up the process from pilot to industrial will also involve
similarity criteria to assure the process success. Bioprocess
scale-up will, therefore, always involve the design of bio-
reactors among all scales. This type of equipment can be
considered the heart of the bioprocesses as they will hold
the cells needed for the bioproduct manufacturing. There-
fore, the accurate choice of the bioreactor is imperative in
all scales, depending on the mode of operation, moisture
content, financial resources available, and cells applied [7].
In this sense, bioprocess and bioreactor scale-up are
straightly interconnected. During scale-up, it is important
to provide the precise conditions for microbial development
and growth, while guaranteeing the economic and technical
viability of the project. In the present review, the aspects
influencing scale-up, along with the main strategies applied
for different bioreactors, will be discussed and examples of
implemented industrial processes and bioreactors will be
given.
Bioprocess aspects influencing scale‑up
Operation modes
Bioprocesses can be operated in different manners along
the fermentation time, depending on the microbial demands
in terms of substrate consumption, product formation, and
possible inhibitions. Essentially, there are three modes of
operation (Table 1): batch, fed-batch, and continuous, and
they differ accordingly to feeding of fresh media and/or
withdrawal of fermented broth during the process [8]. The
simplest mode of operation is batch, wherein there is no
addition or withdrawal of media across the fermentation
time. Therefore, due to metabolic dynamics, the broth is
constantly changing, generating an unsteady state [9, 10].
Batch operation mode can be highly applied in a labora-
tory scale for initial tests of production, and screening the
optimal conditions for producing the desired biomolecule.
Similar to batch fermentation, there is no withdrawal of fer-
mented broth during the fed-batch process. However, there
is addition of new media during the fermentation time [11].
The feeding solution can consist only of the carbon source,
or of a nutrient solution, or it can be the complete media,
depending on the nutritional needs of the cells and it can Ta
bl
e
1
 A
dv
