November 2012 DentalUpdate 623
Cariology
The Potential for Resin Infiltration
Technique in Dental Practice
Abstract: Caries infiltration is a micro-invasive treatment to arrest non-cavitated caries lesions. The method is based on the penetration of
low-viscosity light-curing resins, so called infiltrants, into the pores within the enamel lesion. That way, diffusion pathways for cariogenic
acids are occluded, resulting in a reduction or even arrest of lesion progression. A positive side-effect of caries infiltration is that lesions
change their optical properties and appear similar to sound enamel. Therefore, caries infiltration can also be used to camouflage
aesthetically disfiguring white spot lesions on buccal surfaces.
Clinical Relevance: Resin infiltration is a micro-invasive treatment to arrest and to camouflage non-cavitated proximal caries lesions that
virtually bridges non-invasive and restorative treatment options.
Dent Update 2012; 39: 623–628
The caries decline observed in many nations
in the past decades has led to the clinical
observation that today’s adolescents and
young adults present many fewer open
cavities compared with the generation of
their parents or grandparents. However, a
high number of caries lesions in earlier stages,
particularly in proximal surfaces, can still
be observed in these patients. This shift to
earlier stages should not be misinterpreted
to suggest that these individuals do not
need therapeutic (non-invasive) intervention
anymore, because many of the non-cavitated
lesions progress to cavitated stages.1,2 Rather,
these epidemiological changes present a
challenge not only to diagnose but also to
manage these lesions to avoid their further
progression.
The treatments of choice for
early non-cavitated caries lesions are non-
invasive interventions that support the
natural repair processes of the oral cavity.
However, these approaches usually depend
on good compliance and a sustained change
of a patient’s habits (eg oral hygiene, diet)
and therefore seem to have only limited
effectiveness. Invasive treatment may bring
the tooth into a ‘death spiral of restorations’
in which more and more tooth tissue gets
lost when restorations are often replaced,
even resulting in loss of tooth vitality or even
extraction of the tooth.3 For this reason,
the first restorative intervention should be
postponed as long as possible. Particularly for
proximal lesions, the collateral damage during
cavity preparation is high because relatively
large amounts of sound tissue have to be
removed to get access to the lesion. Therefore,
for proximal caries lesions radiographically
extending around the enamel dentine
junction, the treatment decision is often
difficult. Similar to caries sealing of occlusal
surfaces, caries infiltration aims to bridge
non-invasive and restorative interventions for
proximal caries lesions, providing a minimum
of tissue destruction, with the objective of
arresting the caries process (Figure 1).
Caries infiltration – principle
The aim of caries infiltration is
to occlude the pores within the lesion body
within enamel of non-cavitated caries lesions
with special low-viscosity light-curing resins,
so-called infiltrants. That way, diffusion
pathways for cariogenic acids are blocked,
resulting in a reduction, or even arrest, of
lesion progression (Figure 2). To enable
penetration of the infiltrant into the lesion
body, first the covering pseudo-intact surface
layer, as a result of the remineralization
processes, has to be removed.4 This can be
achieved by etching the lesion for 2 minutes
with 15% hydrochloric acid gel.5 Subsequently,
the lesion has to be properly desiccated to
allow capillary action to soak the resin into
the lesion body. Finally, the infiltrant must
be applied for sufficient time to infiltrate the
lesion deeply and be light-cured.
The limited access to the proximal
surfaces is a challenge for any therapeutic
intervention on this caries predilection
site. Therefore, in contrast to caries sealing
where a resin coating is created on the lesion
surface, for caries infiltration all resin excess is
removed from the surface before light-curing.
In the narrow and hardly accessible proximal
area, resin layers on the lesion surface are hard
to control clinically and might even promote
plaque stagnation and gingival inflammation.
Therefore, for caries infiltration the resinous
diffusion barrier is solely created within the
Hendrik Meyer-Lueckel
Sebastian Paris
Sebastian Paris, DDS, PhD, Associate
Professor, Clinic for Conservative
Dentistry and Periodontology, School
of Dental Medicine, Christian-Albrechts-
Universität zu Kiel, Germany and
Hendrik Meyer-Lueckel, DDS, PhD,
MPH, Head of Department, Department
of Operative Dentistry, Periodontology
and Preventive Dentistry, RWTH Aachen
University, Germany.
© MA Healthcare Ltd. Downloaded from magonlinelibrary.com by 144.082.238.225 on September 11, 2017.
Use for licensed purposes only. No other uses without permission. All rights reserved.
Cariology
624 DentalUpdate November 2012
lesion body, which greatly simplifies clinical
application.

Proximal application
Resin infiltration may be indicated
for active non-cavitated caries lesions
extending radiographically into the inner
half of enamel (E2) up to the outer third of
dentine (D1). In the commercially available
treatment kit for proximal infiltration (Icon®,
DMG, Hamburg, Germany), all necessary
materials are included, with the exception
of rubber dam. To allow application without
temporary tooth separation for some days,6
special foil applicators have been designed.
These applicators consist of two thin, welded
foils. One foil (white side of the applicator;
Figure 3d) protects the adjacent tooth from
contamination, whereas the other foil (green
side) has a perforation and thus allows
the discharge of the agents in the area of
the lesion. The treatment steps for caries
infiltration of proximal lesions are illustrated
in Figure 3.
The efficacy of caries infiltration
has been investigated in clinical trials with
a split-mouth design. In a study on German
young adults with medium caries risk, 4% of
infiltrated lesions progressed radiographically
within the three-year follow-up period,
whereas in the control group (risk-related
non-invasive intervention only) 46% of
lesions progressed.7,8 In a study on children
with high caries risk in Greenland, 23% of
infiltrated lesions in primary molars showed
radiographic lesion progression, whereas
for the control lesions progression of 62%
could be observed within one year. In this
study, fluoride varnish was applied at baseline
and after six months in both groups.9 These
results on randomized clinical trials are
promising, even if further research is needed
to evaluate the efficacy of resin infiltration
when performed by dental practitioners
in daily practice. In clinical studies, more
Figure 1. The various stages of the caries process of proximal lesions and appropriate local therapeutic
interventions. Caries infiltration is indicated for proximal lesions radiographically extending into the
inner half of enamel (E2) up to the outer third of dentine (D1) where non-invasive interventions often
fail and restorative options would go along with the destruction of high proportions of sound dental
hard tissues. Modified from Meyer-Lueckel et al14 and Paris et al.15
Figure 2. During caries infiltration the porosities
of non-cavitated caries lesions (red dots) are
occluded with resin (green). Hereby, the diffusion
pathways for cariogenic acids are blocked,
resulting in a reduction or even arrest of lesion
progression.15
lesion progressions were observed for caries
radiographically extending into the outer
third of dentine compared with lesions
extending just into enamel. This suggests that
(at least some) treatment failures might be
caused by inadvertently infiltratingcavitated
lesions which are more frequent in deeper
caries stages, since these caviations can only
partially be filled with the resin.10
As with all other therapeutic
interventions that aim to arrest lesion
progression, such as fluoridation or sealing,
the only way to assess the success of proximal
resin infiltration is to monitor the lesion
radiographically over time. For proximal caries
lesions, high quality bitewing radiographs
are the most accurate and reliable method
to monitor lesion progression. Intervals
between radiographs should be adjusted to
the individual caries risk. Special care should
be taken to align the sequential radiographs
similarly, since varying alignments between
two radiographs might result in a misleading
interpretation of caries progression or
regression, even when the lesion is stable.

Aesthetic effect
A positive side-effect of resin
infiltration is that fully infiltrated lesions
change their whitish opaque appearance
and look similar to sound enamel.11 White
spot lesions appear chalky due to the high
difference in the refractive indices (RI) of
apatite crystals (RI: 1.62) and the medium
within the lesion pores, which is either a
watery medium (RI: 1.33) or air (RI: 1.0).12
The higher the difference of RI, the more
visible light is scattered between the crystals
and the more whitish the lesion looks. For
this reason, desiccated lesions look even
whiter than wet ones. When the pores are
infiltrated with resin (RI: 1.52) light scattering
is significantly reduced because the difference
in RI compared with the pores of the apatite
crystals is rather low and thus the lesion
appears similar to sound enamel.
Buccal white spot lesions are
frequently observed after treatment with fixed
orthodontic appliances. After de-bonding
of the brackets the lesions can be arrested,
usually with non-invasive interventions
like biofilm control and local fluoridation.
However, because remineralization is usually
limited to superficial layers, only rather
shallow lesions disappear. Most lesions remain
as enamel scars even when they are arrested
© MA Healthcare Ltd. Downloaded from magonlinelibrary.com by 144.082.238.225 on September 11, 2017.
Use for licensed purposes only. No other uses without permission. All rights reserved.
November 2012 DentalUpdate 625
Cariology
and aesthetic improvement can often only be
achieved using quite invasive interventions,
like enamel micro-abrasion or composite
restorations. Resin infiltration can be used
to camouflage active non-cavitated buccal
Figure 3. Resin infiltration of a proximal caries lesion.15 (a) The bitewing radiograph indicates a proximal lesion on the mesial surface of tooth UL6. (b)
Clinically, the lesion is hardly visible but bleeding of the adjacent papilla on gentle probing is a predictor for lesion activity. (c) After tooth cleaning, rubber
dam is applied to avoid contamination of the lesion with blood, saliva, or crevicular fluid. A cow-horn ended explorer is used to probe the proximal surface
gently for possible cavitation. (d) After separation of the teeth with a special flattened wedge, a foil applicator is inserted into the proximal area using a
sawing motion. Although the tooth separation causes a slightly unpleasant feeling of pressure, usually no anaesthesia is necessary. (e) The etching gel
(Icon®etch) is injected into the applicator and spreads over the lesion surface. (f) After 2 minutes the etching gel is rinsed off properly and the lesion is
desiccated with compressed air. (g) In order to desiccate the lesion further ethanol (Icon®dry) is applied and (h) subsequently thoroughly evaporated with
compressed air. (i) The infiltrant is applied with another foil applicator. (j) After 3 minutes excess resin is removed from the lesion surface by air blowing
and the use of dental floss. (k) The infiltrated resin is hardened with blue light for 40 seconds. In order to infiltrate pores that possibly emerge within the
infiltrated lesion due to polymerization shrinkage, steps i–k are repeated, but for the second application of the resin 1 min is sufficient. (l) The result after
removing the rubber dam.
lesions that are perceived as aesthetical
impairment. The treatment steps are similar to
the proximal application (Figure 4).
In a South Korean study, 61%
of post-orthodontic caries lesions could be
masked completely using caries infiltration
and a partial masking effect could be
observed in another 33% of lesions.13
The masking effect can be
insufficient, if only an incomplete removal
© MA Healthcare Ltd. Downloaded from magonlinelibrary.com by 144.082.238.225 on September 11, 2017.
Use for licensed purposes only. No other uses without permission. All rights reserved.
Cariology
626 DentalUpdate November 2012
Figure 4. Resin infiltration of post-orthodontic
white spot lesions.15 (a) Buccal white spot
lesions some weeks after removal of orthodontic
appliances. (b) After application of light-curing
dam (OpalDam; Ultradent) the etching gel
(Icon®etch) is applied on to the buccal surfaces
for 2 minutes and subsequently rinsed off. (c)
After drying the lesions with compressed air,
ethanol (Icon®dry) is applied. The aesthetic result
can be estimated by the speed with which lesions
change their appearance during re-wetting. (d)
Lesions are properly desiccated with compressed
air. Most of the brownish discolorations could be
eroded together with the surface layer. (e) The
infiltrant (Icon®infiltrant) is applied for 3 minutes.
(f) Excess resin is removed with cotton rolls and
(g) the resin is light-cured for 40 seconds. In
order to infiltrate pores that might have occurred
due to polymerization shrinkage, steps e–g are
repeated once with a resin application time of
1 minute. (h) Polishing disks (Sof-lex™ discs, 3M
ESPE) are used to remove the oxygen-inhibited
resin layer and to polish the roughened enamel
surface. (i) Satisfying aesthetic result after
treatment.
occurs. Because rather inactive lesions
exhibit quite thick surface layers, it is often
necessary to repeat the etching step until
the surface layer is completely removed.
During each application, for 2 minutes, an
approximately 30 µm thick enamel layer is
eroded by the HCl-gel. To check if the surface
layer is completely removed, water or ethanol
should be dropped on the desiccated lesions.
When the penetration of these liquids into
the desiccated lesion results in a quick
change (within the first 3–5 seconds) in
lesion appearance (rapid change of refractive
index within the pores), this effect can also
be expected during the application of the
infiltrant and the procedure can be continued.
If this effect fails to appear, the etching
should be repeated until the masking effect
can be observed. Of course, the amount of
enamel erosion should be balanced with the
aesthetic impairment caused by the lesions
and alternative therapeutic options such as
remineralization and restorations should be
considered.
For the masking of developmental
defects like molar-incisor-hypomineralization,
hypomineralization of a permanent tooth
after apical trauma of the deciduous tooth
or fluorosis, resin infiltration cannot be
recommended at present, because these
lesions cannot be that easily infiltrated.13
Moreover, in contrast to the resin infiltration
of caries, the infiltration of developmental
defects has not been thoroughly scientifically
investigated.
Caution is also advised with
cavitated lesions. Nonetheless, infiltration of
enamel parts of caries lesions can be easily
combined with composite restorations. Since
the infiltrant has similar chemical properties
to bonding agents, composite resins can
be placed on to and adjacent to infiltrated
lesions. Cavities extending into dentine,
however, have to be restored conventionally
with dentine adhesives, because the infiltrant
is far too hydrophobic to be used for this
purpose.
Summary
Cariesinfiltration follows the
principle of caries sealing. However, the
resinous diffusion barrier is created inside the
lesion but not on the lesion surface, whereby
clinical application is simplified. Clinical
studies have shown that caries infiltration in
combination with non-invasive measures is
of the pseudo-intact surface layer is
accomplished. In this case, only incomplete
infiltration of the underlying lesion body
© MA Healthcare Ltd. Downloaded from magonlinelibrary.com by 144.082.238.225 on September 11, 2017.
Use for licensed purposes only. No other uses without permission. All rights reserved.
Cariology
628 DentalUpdate November 2012
more efficacious to arrest proximal lesions
extending radiographically up to the outer
third of dentine compared with non-invasive
measures alone. Thus, particularly for proximal
caries lesions radiographically extending
around the enamel-dentine junction, caries
infiltration is efficacious to slow down or even
arrest caries progression in order to postpone
or even avoid the first restorative intervention.
A positive side-effect of caries infiltration
is that infiltrated lesions lose their whitish
appearance. Buccal white spot lesions can
be arrested with non-invasive interventions
but often remain as whitish or brownish
enamel scars which are perceived as being
unaesthetic. Here caries infiltration can be
used to camouflage these defects, combining
hard tissue preservation on the one hand
and a good predictability of the treatment
outcome on the other hand.
Disclosure statement
The two authors receive a research
grant and royalties from DMG, Hamburg.
This article is partly based on a previous
publication: Paris, Dörfer, Meyer-Lückel:
Kariesinfiltration. Zahnärztliche Mitteilungen
2011; 101: 38–41.

References
1. Mejàre I, Kallestal C, Stenlund H. Incidence
and progression of approximal caries from 11
to 22 years of age in Sweden: a prospective
radiographic study. Caries Res 1999; 33: 93–100.
2. Mejàre I, Kallestal C, Stenlund H, Johansson H.
Caries development from 11 to 22 years of age:
a prospective radiographic study. Prevalence
and distribution. Caries Res 1998; 32: 10–16.
3. Qvist V. Longevity of restorations: the ‘death
spiral’. In: Dental Caries: The Disease and Its
Clinical Management. Fejerskov O, Kidd EAM,
eds. Oxford: Blackwell Munksgaard, 2008;
pp444–455.
4. Paris S, Meyer-Lueckel H, Kielbassa AM. Resin
infiltration of natural caries lesions. J Dent Res
2007; 86: 662–666.
5. Meyer-Lueckel H, Paris S, Kielbassa AM.
Surface layer erosion of natural caries lesions
with phosphoric and hydrochloric acid gels
in preparation for resin infiltration. Caries Res
2007; 41: 223–230.
6. Pitts NB, Longbottom C. Temporary tooth
separation with special reference to the
diagnosis and preventive management
of equivocal approximal carious lesions.
Quintessence Int 1987; 18: 563–573.
7. Meyer-Lueckel H, Bitter K, Paris S. Randomized
controlled clinical trial on proximal caries
infiltration – three-year follow-up. Caries Res
2012; 46: 544–548.
8. Paris S, Hopfenmuller W, Meyer-Lueckel H.
Resin infiltration of caries lesions: an efficacy
randomized trial. J Dent Res 2010; 89: 823–826.
9. Ekstrand KR, Bakhshandeh A, Martignon S.
Treatment of proximal superficial caries lesions
on primary molar teeth with resin infiltration
and fluoride varnish versus fluoride varnish
only: efficacy after 1 year. Caries Res 2010; 44:
41–46.
10. Paris S, Bitter K, Naumann M, Dorfer CE, Meyer-
Lueckel H. Resin infiltration of proximal caries
lesions differing in ICDAS codes. Eur J Oral Sci
2011; 119: 182–186.
11. Paris S, Meyer-Lueckel H. Masking of labial
enamel white spot lesions by resin infiltration
– a clinical report. Quintessence Int 2009; 40:
713–718.
12. Kidd EAM, Fejerskov O. What constitutes dental
caries? Histopathology of carious enamel
and dentin related to the action of cariogenic
biofilms. J Dent Res 2004; 83 Spec No C: C35–
C38.
13. Kim S, Kim EY, Jeong TS, Kim JW. The
evaluation of resin infiltration for masking
labial enamel white spot lesions. Int J Paediatr
Dent 2011; 21: 241–248.
14. Meyer-Lueckel H, Fejerskov O, Paris S. [Novel
treatment options for proximal caries]. Schweiz
Monatsschr Zahnmed 2009; 119: 454–461.
15. Paris S, Dörfer C, Meyer-Lückel H.
Kariesinfiltration. Zahnärztliche Mitteilungen
2011; 101: 38–41.
© MA Healthcare Ltd. Downloaded from magonlinelibrary.com by 144.082.238.225 on September 11, 2017.
Use for licensed purposes only. No other uses without permission. All rights reserved.
