Journal Pre-proof
Evaluation of a regional nerve block with an experimental formulation of encapsulated
lidocaine in sheep
Erika A. Militana, Luis Campoy, Manuel Martin-Flores, Robin D. Gleed
PII: S1467-2987(20)30177-X
DOI: https://doi.org/10.1016/j.vaa.2020.07.036
Reference: VAA 545
To appear in: Veterinary Anaesthesia and Analgesia
Received Date: 22 April 2020
Revised Date: 9 July 2020
Accepted Date: 28 July 2020
Please cite this article as: Militana EA, Campoy L, Martin-Flores M, Gleed RD, Evaluation of a
regional nerve block with an experimental formulation of encapsulated lidocaine in sheep, Veterinary
Anaesthesia and Analgesia, https://doi.org/10.1016/j.vaa.2020.07.036.
This is a PDF file of an article that has undergone enhancements after acceptance, such as the addition
of a cover page and metadata, and formatting for readability, but it is not yet the definitive version of
record. This version will undergo additional copyediting, typesetting and review before it is published
in its final form, but we are providing this version to give early visibility of the article. Please note that,
during the production process, errors may be discovered which could affect the content, and all legal
disclaimers that apply to the journal pertain.
© 2020 Published by Elsevier Ltd on behalf of Association of Veterinary Anaesthetists and American
College of Veterinary Anesthesia and Analgesia.
https://doi.org/10.1016/j.vaa.2020.07.036
https://doi.org/10.1016/j.vaa.2020.07.036
RESEARCH PAPER
Running head (Authors) EA Militana et al.
Running head (short title) Encapsulated lidocaine
Evaluation of a regional nerve block with an experimental formulation of encapsulated
lidocaine in sheep
Erika A Militana, Luis Campoy, Manuel Martin-Flores & Robin D Gleed
Department of Clinical Sciences, College of Veterinary Medicine, Cornell University, Ithaca,
NY, USA

Correspondence: Luis Campoy, Department of Clinical Sciences, College of Veterinary
Medicine, Cornell University, 602 Tower Rd, Ithaca, NY 14853, USA. E-mail:
luis.campoy@cornell.edu


Abstract
Objective To compare the duration of nociceptive and proprioceptive blockade from an
experimental encapsulated lidocaine preparation with that of conventional lidocaine.
Study design Prospective, blinded, randomly assigned, crossover study.
Animals A total of six adult ewes, American Society of Anesthesiologists physical status I or II,
weighing 60.4 ± 18.0 kg (mean ± standard deviation).
Methods Under general anesthesia and guided by electrolocation, the common peroneal nerve
was blocked unilaterally with encapsulated lidocaine (0.1 mL kg−1, 200 mg mL−1) or
conventional lidocaine hydrochloride (0.1 mL kg−1, 20 mg mL−1). Each sheep was administered
Jo
urn
al
Pre-
pro
of
both treatments with an interval between treatments of 2 weeks. Nociception and proprioception
were scored (scales of 0–3) before anesthesia, at 0.5, 1, 2, 4, 8, 12, 16, 20 and 24 hours after
completion of local anesthetic injection, and every 12 hours thereafter, for 9 days. Nociceptive
and proprioceptive blockade ended the first time each score reached ‘0’; maximum blockade
duration was considered and recorded to be the time point immediately prior to this end point.
Significance of differences between treatments for duration of blockade was tested with the
Wilcoxon rank-sum test. Effects of time and treatment on nociceptive and proprioceptive
blockade were evaluated with mixed-effect models. Significance was set at padjusted (within the range of 50–100 µm) so
that they released continuously for 7 days. At the time of injection, the suspension contained 200
mg mL−1 of lidocaine, 94% of which was contained within the microcapsules while the balance
was free in the vehicle.
Jo
urn
al
Pre-
pro
of
Under the Cornell University Institutional Animal Care and Use Committee approval
(2006-0148), six adult Dorset ewes American Society of Anesthesiologists physical status I or II
and weighing 60.4 ± 18.0 kg [mean ± standard deviation (SD)] were used. Each sheep was
anesthetized twice with 2 weeks between anesthetic episodes. The encapsulated lidocaine
preparation (Encap, 200 mg mL−1; treatment Encap) was tested in one episode and 2% lidocaine
hydrochloride (Lidocaine hydrochloride USP, 20 mg mL−1; Hospira Inc., IL, USA; treatment
LidoHCl) was tested in the other. For each sheep, the order of the two treatments was assigned
randomly by withdrawing ballots from a closed envelope; the envelope contained three ballots
indicating that treatment Encap should be first, and another three indicating that treatment
LidoHCl should be first. During the first anesthetic episode, one peroneal nerve was blocked;
during the second episode, the contralateral peroneal nerve was blocked.
The animal was sedated with midazolam (0.2 mg kg−1; Midazolam hydrochloride;
Hospira Inc.) intravenously (IV) and approximately 10 minutes later, anesthesia was induced
with IV propofol (PropoFlo; Abbott Laboratories, IL, USA) until consciousness was lost,
swallowing reflex was absent and laryngeal abduction was satisfactory to achieve orotracheal
intubation. Isoflurane (Isoflurane USP; Phoenix Pharmaceutical Inc., MO, USA) was
administered in oxygen via a circle partial rebreathing system connected to the endotracheal
tube. The lungs were mechanically ventilated to achieve an end-tidal partial pressure of carbon
dioxide of 35–40 mmHg (4.5–5.5 kPa). The isoflurane concentration was adjusted to ensure
unconsciousness and immobility.
Peroneal nerve blocks were performed using a standard electrolocation-assisted
technique, similar to a previous description in dogs (Campoy et al. 2012). The peroneal nerve
block was located with the animal in lateral recumbency, with the limb to be blocked uppermost
Jo
urn
al
Pre-
pro
of
and extended in a natural position. The puncture site was identified in the groove formed by the
peroneus longus and lateral digital extensor muscles distal to the stifle joint.
The technique was performed using a stimulating needle (18 gauge, 5 cm Contiplex
Tuohy; B Braun Medical Inc., PA, USA) connected to a peripheral nerve locator (Innervator
232; Fisher & Paykel Healthcare Ltd., Auckland, NZ) at an initial output of 1 mA, frequency of
1 Hz and duration of 0.1 ms for both treatments. When the tip of the needle was located in close
proximity to the peroneal nerve, dorsiflexion of the foot was elicited. Injection was performed
around the nerve when muscular contractions were elicited at 0.4 mA but not at 0.2 mA, and
following negative blood aspiration and absence of resistance to injection. The same individual
(LC), unaware of treatment allocation, performed all injections.
Each sheep was recovered from anesthesia immediately after completion of each
injection and then returned to the pen where it had been previously housed. Nociceptive and
proprioceptive function were scored before anesthesia, at 0.5, 1, 2, 4, 8, 12, 16, 20 and 24 hours
after recovery from general anesthesia, and every 12 hours thereafter for 9 days by an
investigator who was unaware of treatment allocation (RDG) (Appendices A & B). Nociceptive
function was scored based on responses to application of mosquito forceps to the skin just
proximal to the craniolateral aspect of the coronary band. These responses included conscious
limb retraction accompanied by head turning or postural change. The concomitant response of a
head turn or posture change helped distinguish a conscious limb retraction from a withdrawal
reflex.
An over-the-needle catheter (14 gauge, 13 cm Teflon catheter; Mila International Inc.,
KY, USA) was placed in the external jugular vein of one sheep undergoing each treatment, such
that blood samples were collected from the same sheep on two occasions. A three-syringe
Jo
urn
al
Pre-
pro
of
technique was used for blood collection: the first syringe was attached to the catheter port and
used to aspirate a volume of fluid (blood and heparinized saline) equal to 10 times the volume of
the catheter, the second syringe was used to withdraw the blood sample (2 mL) and the contents
of the first syringe were injected back into the catheter, and a third syringe containing
heparinized saline (2 units mL−1; Heparin Sodium; B Braun Medical Inc., CA, USA) was used to
flush the catheter. Blood samples were collected before treatment injection, at 1, 4 and 24 hours
after completion of local anesthetic injection, and every 24 hours thereafter for 7 days.
Immediately after collection, the sample was placed in a glass blood collection tube containing
5.4 mg of K2-ethylenediamine tetra-acetic acid (EDTA BD Vacutainer; NJ, USA) and rotated
gently by hand 10 times to prevent clotting. The sample was then centrifuged at room
temperature for 10 minutes (674 g; Heraeus Labofuge 200; Thermo Fischer Scientific Inc., MA,
USA). The resultant plasma was removed using a pipette and added to a cryovial stored at –28
oC until delivered for analysis (NMS Labs; PA, USA). Lidocaine concentrations were measured
by gas chromatography with a lower reporting limit of 0.50 µg mL−1, similarly to a previously
reported technique (Watanabe et al. 1998).
The sheep were euthanized by IV barbiturate overdose (100 mg kg−1; Fatal Plus; Vortech
Pharmaceuticals Ltd, MI, USA) at the completion of the study, 10 days after the second
injection. Immediately after euthanasia, the peroneal nerve and surrounding tissues were
dissected bilaterally and examined for gross evidence of pathology at the injection site. The
peroneal nerve at the site of injection and the regional lymph nodes were harvested bilaterally
and processed for histological examination by a board-certified pathologist who was unaware of
which treatment was associated with a sample.

Jo
urn
al
Pre-
pro
of
Statistical analysis
A sample size of three animals was calculated (G*Power 3.1.5; Universität Kiel, Germany) with
α set at 0.05, β set at 0.95, and assuming normal distribution of data. Nociception duration was
assumed to be 72 ± 12 hours (mean ± SD) in the Encap treatment and 5 ± 2 hours (mean ± SD)
in the LidoHCl treatment (based on unpublished pilot data). The sample size software was set to
run a paired-sample, one-tailed test. The sample size was doubled to allow for possible loss of
data or uncooperative animals.
After treatment, nociceptive and proprioceptive blockade were recorded to have ended
the first time each score reached ‘0’; however, the maximum duration of blockade was
considered to be the time point immediately prior to the time point when scores first reached 0.
The significance (pLidoHCl (p = 0.008; Table 1). Median duration of proprioceptive blockade
was 6 hours longer in Encap than LidoHCl (p = 0.03; Table 1). Although the median Encap
Jo
urn
al
Pre-
pro
of
nociceptive blockade was 90 hours, one Encap-treated animal was an outlier with a nociceptive
blockade that lasted only 4 hours (Table 1); proprioceptive block lasted 4 hours in the same
animal.
Significant effects of time (p 11.7
± 2 µg mL−1 produce adverse effects in sheep (Morishima et al. 1990), it is reassuring that the
Jo
urn
al
Pre-
pro
of
lidocaine concentration in plasma after Encap (and LidoHCl) never exceeded 0.50 µg mL−1 in
the one sheep in which systematic measurements were made.
A major limitation of this study is the sample size, even though significant differences
were detected. Despite a power analysis suggesting that the sample size was adequate to detect
differences in median blockade duration, it was not designed to identify the frequency of certain
findings such as occurrence of prolonged proprioceptive deficits. These observations should
encourage the use of measures to detect and prevent complications associated with long-term
proprioceptive deficits, such as abrasions, especially when encapsulated preparations are
selected. In one of the animals in Encap, apparent conduction blockade was short for both
nociception and proprioception. The possibility that the test suspension was deposited farther
from the nerve than is optimal in this sheep cannot be excluded. Accurate perineural blockade is
technically difficult and subject to occasional failure, although other techniques, such as
ultrasound guidance, might reduce the failure rate. In addition, the experimental preparation was
viscous, prone to aggregation, and therefore difficult to inject through needles with an internal
diameter smaller than that of an 18 gauge needle. Ongoing assessment to confirm that
nociception blockade is effective in clinical patients would be justified, especially when direct
visualization of the target nerve and subsequent deposition of local anesthetic is precluded.
The sheep nociception model is difficult due to the stoic nature of the animal, causing
some degree of uncertainty in correctly identifyingpain. To address this limitation, and in an
attempt to add objectivity, a nociceptive withdrawal score was implemented, which was adapted
from a sheep model based on the use of a short-acting electrical stimulus to evoke a withdrawal
reaction accompanied by a nocifensive behavioral reaction (Rohrbach et al. 2014). Although the
current descriptors for nociceptive blockade were not used or described previously in response to
Jo
urn
al
Pre-
pro
of
a mechanically noxious stimulus such as mosquito forceps, the grading system is similar to the
behavioral reaction described for electrical stimulation. Furthermore, variability in the results
was in part minimized by blinding, randomization and the crossover design that allowed each
sheep to serve as its own control.

Conclusions
These findings suggest a clinical use for blocking peripheral nerves with PLGA-encapsulated
sustained-release lidocaine. Regional anesthesia as an adjunct to general anesthesia may
markedly improve postoperative pain control and reduce the reliance on systemic analgesics.


Acknowledgements
The authors thank Capsulated Systems Inc. for donating the study drug.

Author’s contributions
EAM: database search, data interpretation, preparation of manuscript, manuscript review. LC:
study design, data collection, data interpretation, manuscript review. MMF: study design,
statistical analysis, data interpretation, manuscript review. RDG: study design, manuscript
review. All authors read and approved the final version of the manuscript.

Conflict of interest statement
The authors declare no conflict of interest.

Jo
urn
al
Pre-
pro
of
References
Aman JE, Elangovan N, Yeh IL, Konczak J (2015) The effectiveness of proprioceptive training
for improving motor function: a systematic review. Front Hum Neurosci 8, 1075.
Campoy L, Martin-Flores M, Ludders JW et al. (2012) Comparison of bupivacaine femoral and
sciatic nerve block versus bupivacaine and morphine epidural for stifle surgery in dogs. Vet
Anaesth Analg 39, 91–98.
Capdevila M, Ramin S, Capdevila X (2017) Regional anesthesia and analgesia after surgery in
ICU. Curr Opin Crit Care 23, 430–439.
Chang CB, Cho WS (2012) Pain management protocols, peri-operative pain and patient
satisfaction after total knee replacement: a multicentre study. J Bone Joint Surg Br 94, 1511–
1516.
Gokin AP, Philip B, Strichartz GR (2001) Preferential block of small myelinated sensory and
motor fibers by lidocaine: in vivo electrophysiology in the rat sciatic nerve. Anesthesiology
95, 1441–1454.
Kessler J, Marhofer P, Hopkins PM, Hollmann MW (2015) Peripheral regional anaesthesia and
outcome: lessons learned from the last 10 years. Br J Anaesth 114, 728–745.
Lascelles BD, Rausch-Derra LC, Wofford JA, Huebner M (2016) Pilot, randomized, placebo-
controlled clinical field study to evaluate the effectiveness of bupivacaine liposome
injectable suspension for the provision of post-surgical analgesia in dogs undergoing stifle
surgery. BMC Vet Res 12, 168.
Makadia HK, Siegel SJ (2011) Poly(lactic-co-glycolic) acid (PLGA) as biodegradable controlled
drug delivery carrier. Polymers (Basel) 3, 1377–1397.
Jo
urn
al
Pre-
pro
of
Mashimo T, Uchida I, Pak M et al. (1992) Prolongation of canine epidural anesthesia by
liposome encapsulation of lidocaine. Anesth Analg 74, 827–834.
Morishima HO, Finster M, Arthur GR, Covino BG (1990) Pregnancy does not alter lidocaine
toxicity. Am J Obstet Gynecol 162, 1320–1324.
NOCITA-Package Insert (2018b) www.aratana.com
Ordahan B, Kucuksen S, Tuncay I et al. (2015) The effect of proprioception exercises on
functional status in patients with anterior cruciate ligament reconstruction. J Back
Musculoskelet Rehabil 28, 531–537.
Paavola A, Yliruusi J, Kajimoto Y et al. (1995) Controlled release of lidocaine from injectable
gels and efficacy in rat sciatic nerve block. Pharm Res 12, 1997–2002.
Richard BM, Newton P, Ott LR et al. (2012) The safety of EXPAREL® (bupivacaine liposome
injectable suspension) administered by peripheral nerve block in rabbits and dogs. J Drug
Deliv 2012, 962101.
Rohrbach H, Zeiter S, Andersen OK et al. (2014) Quantitative assessment of the nociceptive
withdrawal reflex in healthy, non-medicated experimental sheep. Physiol Behav 129, 181–
185.
Santamaria CM, Woodruff A, Yang R, Kohane DS (2017) Drug delivery systems for prolonged
duration local anesthesia. Mater Today (Kidlington) 20, 22–31.
Sato S, Baba Y, Tajima K et al. (1995) Prolongation of epidural anesthesia in the rabbit with the
use of a biodegradable copolymer paste containing lidocaine. Anesth Analg 80, 97–101.
Suzuki T, Kosugi K, Suto T et al. (2018) Sustained-release lidocaine sheet for pain following
tooth extraction: a randomized, single-blind, dose-response, controlled, clinical study of
efficacy and safety. PLoS One 13, e0200059.
Jo
urn
al
Pre-
pro
of
Tobe M, Obata H, Suto T et al. (2010) Long-term effect of sciatic nerve block with slow-release
lidocaine in a rat model of postoperative pain. Anesthesiology 112, 1473–1481.
Wang CF, Djalali AG, Gandhi A et al. (2009) An absorbable local anesthetic matrix provides
several days of functional sciatic nerve blockade. Anesth Analg 108, 1027–1033.
Wang CF, Pancaro C, Gerner P, Strichartz G (2011) Prolonged suppression of postincisional
pain by a slow-release formulation of lidocaine. Anesthesiology 114, 135–149.
Watanabe T, Namera A, Yashiki M et al. (1998) Simple analysis of local anaesthetics in human
blood using headspace solid-phase microextraction and gas chromatography-mass
spectrometry-electron impact ionization selected ion monitoring. J Chromatogr B Biomed
Sci Appl 709, 225–232.
Yin QQ, Wu L, Gou ML et al. (2009) Long-lasting infiltration anaesthesia by lidocaine-loaded
biodegradable nanoparticles in hydrogel in rats. Acta Anaesthesiol Scand 53, 1207–1213.


Jo
urn
al
Pre-
pro
of
Figure 1 (a) Nociceptive and (b) proprioceptive scores in six sheep administered
perineural injection of the peroneal nerve with encapsulated lidocaine (treatment Encap) or
conventional 2% lidocaine (treatment LidoHCl) before (time 0) and after recovery from general
anesthesia. Data are mean ± standard error of the mean. Data at 0 and 0.5 hours are not shown
for either treatment for clarity.


Figure 2 Dissection of the lateral aspect of a pelvic limb in a sheep 10 days after injection
around the peroneal nerve with encapsulated lidocaine. Injection site is identified by the
arrowhead. No gross abnormalities of the nerve or surrounding tissue were detected.


Figure 3 Histological preparation of peroneal nerve perineural tissue obtained from a sheep 10
days after injection of encapsulated lidocaine and stained with hematoxylin and eosin.
Phagocytosed microcapsules (arrowhead) can be seen within the clear cytoplasmic vacuoles
(magnification ×100).

Jo
urn
al
Pre-
pro
of

Appendix A Nociceptive blockade scoring system.
Score
0
Description
No block – apparently instant response to applying mosquito forceps
1 Delayed response to applying mosquito forceps
2 Almost able to clamp mosquito forceps to first ratchet
3 No response even after first ratchet of the mosquito forceps

Jo
urn
al
Pre-
pro
of
Appendix B Proprioceptive blockade scoring system
Score
0
Description
No block – no fetlock joint knuckling observed even when chased
1 Some impairment, occasional fetlock joint knuckling when chased
2 Fetlock joint knuckling when standing, but able to achieve normal position
3 Persistent fetlock joint knuckling while standing

Jo
urn
al
Pre-
pro
of
Table 1 Duration (hours) of nociceptive and proprioceptive blockade [median (range)] in
six sheep after perineural injection of encapsulated lidocaine (treatment Encap) or
conventional lidocaine (treatment LidoHCl) for peroneal nerve block. Nociceptiveand
proprioceptive blockades ended for each sheep the first time the scores were ‘0’, with
maximum duration blockade considered to be the time point immediately prior to this
observation period.
Parameter
Treatment
p
Encap LidoHCl
Nociception
(hours) 90 (4–180) 2 (1–8) 0.008
Proprioception
(hours) 8 (1–72) 2 (1–4) 0.03

Jo
urn
al
Pre-
pro
of
0
1
2
3
36 60 84 108 132 156 180 204
Time (hours)
P
ro
p
io
ce
p
ti
v
e
sc
o
re
(0
-3
)
Encap
LidoHCl
1 2 4 8 1216 20 24
(b)
Jo
urn
al
Pre-
pro
of
0
1
2
3
36 60 84 108 132 156 180 204
Time (hours)
N
o
ci
ce
p
ti
v
e
sc
o
re
(0
-3
)
Encap
LidoHCl
1 2 4 8 1216 20 24
(a)
Jo
urn
al
Pre-
pro
of
Jo
urn
al
Pre-
pro
of
Jo
urn
al
Pre-
pro
of
