Autonomous Maintenance Stage 2
Quelle: JIPM (Japan Institute of Plant Maintenance)
7 Steps of Autonomous Maintenance
Independent servicing and maintenance of machines
and equipment by operators
Initial cleaning of machines
and equipment
Prevention of contamination,
improvement of servicing
Standards for cleaning
and servicing
Training of employees to do
independent servicing
Independent servicing
by operators
Standards for
safeguarding processes
Full application of Autonomous
Maintenance
* Initial cleaning, lubrication
* Marking of defects
* Restoring desirable conditions
* Elimination of leakage
* Improving access to check points
* Eliminating sources of dirt and contamination
* Use of checklists and check plans
* Visual management at machine
* Surroundings (standards for cleanliness and neatness)
* Develop knowledge of machine design
 and functions
* Train skills for independent servicing
* Independent servicing using
 check lists and maintenance plans
* Deepen knowledge of
 servicing and corrective
 maintenance
* Full use and continuous improvement
Cleaning is inspection!
1
2
3
4
5
6
7
Version 2.0
*
Autonomous Maintenance Stage 2
Autonomous Maintenance Step 2
Independent
maintenance
and servicing of
machines and
equipment by the operators
Prevention of contamination Improvement of servicing
Version 2.0
*
Autonomous Maintenance Stage 2
Before:
After:
- Initial cleaning of the machine
- Lubrication according to plan
- Marking of abnormalities
1. Preparation
2. Coordination fo activities
3. Action
4. Check-up on results
Abnormalities (e.g. leakages) can only be found if the machine or equipment ist clean!
Cleaning = Inspection!
4
3
2
1
Expiration
Goal
Review Step 1 of the Autonomous Maintenance
Version 2.0
*
Autonomous Maintenance Stage 2
Goals of Step 2
Prevention of contamination - improvement of maintenance
Determine sources of contamination
Introduce countermeasures
Improve maintainablity
These activities show the highest degree of success if teams consist of maintenance men, production operators, and members of the engineering department.
Version 2.0
*
Autonomous Maintenance Stage 2
Determine and show sources of contamination
Version 2.0
*
Autonomous Maintenance Stage 2
The 4 elements of the problem solving process
Version 2.0
*
Autonomous Maintenance Stage 2
Machine/object:
Topic:
Goal:
Datum:
Name:
1. Problem description
4. Solution evaluation
2. Cause of problem
3. Problem solution
5Why analysis
Why
Why
Why
Why
Why
Use of the
5Why analysis
method
(see sheet 09)
Leak of oil vapor
It is only insufficiently
filtered, condenses, and causes contamination
Contamination at the filter exit
Elimination
25.01.
W. Pfiffig
A Maintenance of filters
 at proscribed intervals.
B Replace disposable filters
 with different type which can be washed
 (costs, environment).
New Filter
Automat 03
Maintenance intervals
Week
Filter cleaning
04
X
05
06
07
08
09
10
11
12
X
X
It was recognized by observation of the process that
the filter must be cleanedex/changed every 3 weeks.
Alternative: Larger filter (costs!)
Analysis sheet for Autonomous Maintenance Step 2
Version 2.0
*
Autonomous Maintenance Stage 2
5Why analysis
Why does the machine get dirty?
Why does oil penetrate through filter?
Why are the filter mats very dirty?
Why weren’t they changed in time?
Why is there no maintenance plan?
„Because of oil penetrating though filter”
„Because filter mats are very dirty “
„Because they were not changed in time “
„Because there is no maintenance plan”
„Because prior to the introduction of TPM, nobody gave it any thought”
Version 2.0
*
Autonomous Maintenance Stage 2
Example cause effect diagram
Machine/object:
Topic:
Goal:
Datum:
Name:
1. Problem description
4. Solution evaluation
3. Problem solution
Leak of oil vapor
It is only insufficiently
filtered, condenses, and causes contamination
Contamination at the filter exit
Elimination
25.01.
W. Pfiffig
A Maintenance of filters
 at proscribed intervals.
B Replace disposable filters
 with different type which can be washed
 (costs, environment).
New Filter
Automat 03
Maintenance intervals
Week
Filter cleaning
04
X
05
06
07
08
09
10
11
12
X
X
It was recognized by observation of the process that
the filter must be cleanedex/changed every 3 weeks.
Alternative: Larger filter (costs!)
Version 2.0
*
Autonomous Maintenance Stage 2
2. Problem cause
Effect
Man
Method
Material
Machine
Environment
Cause-Effect-Diagramm (Fishbone Diagram)
Moving hands
Design fault
Too hard
Insufficient
Insufficient
point A to B
illumination
training
All possible causes are examined and evaluated as to their effect (degree of influence on the problem)
Version 2.0
*
Autonomous Maintenance Stage 2
Cause effect diagram
Booth dirty
Man
Method
Material
Machine
Environment
No TPM knowledge
Cleaning done only sporadically
Oil filter absorbs
 insufficiently
Formation of oil vapor
Contamination
of oil filter
no maintenance
plan
25.01.2001
Team:
K. Klever
W. Pfiffig
D. Nozzle impulse
Version 2.0
*
Autonomous Maintenance Stage 2
Sucess by teamwork
Workers/ operators give input on problem occur- ance details
Technicians/ engineers detail required design changes
Maintenance men carry out design changes
Together, they work out the improvement proposals
Version 2.0
*
Autonomous Maintenance Stage 2
Documentation on the machine board
11,4 actual condition door leaky,
 cooling water withdraw and lead
to contamination
Documentation of measures and improvements
Version 2.0
*
Autonomous Maintenance Stage 2
Auditing of Step 2
Audit - questionnaires
1
current No.
Characteristics
Points
2
3
4
5
Have abnormalities found in Step 1 been eliminated?
Have further abnorma- lities been found and documented in Step 2?
Were measures to take been identified?
What is the machine condition after Step 2?
Were operators sufficiently trained and educated?
Audit
 Step 1
Audit
Step 2
Audit
Step 3
Audit
 Step 4
Audit
Step 5
Audit
Step 6
Audit
Step 7
