Commercial Aquaponics
 Ken Semmens Matthew Ferrell

 Examples – “Business Model”

 Production System
 University of the Virgin Islands Recirculating
Aquaculture System
 Flowing Water System at Reymann Memorial Farm
This presentation
is intended to help you understand
more about aquaponics on a
commercial scale.
 Rob Nash
 Commercial system
 Started as tilapia, but it was found to energy intensive in the
winter
 Sells at local farmers market, contracts with restaurants
 2-3 dollars a head lettuce, sells kale, peppers, and tomato's as
well
 Brings lettuce still attached to net pots and roots
 His farmers market activities drive system sales


Business Model
Restaurant, Farm Market, System Sales

 Nate Story- Zip Grow Towers
 Commercial Vertical system
 Aim is to locate very close to city
markets
 Sell live products in store
 Use as much space as possible within
grow house
 At one point used tilapia, but has
moved on to non food fish

Business Model
Retail and System Sales


Marc Laberge from Quebec (http://www.cultures-
aquaponiques.com/team.htm).

He raises rainbow trout and lettuce. He sells about
$1000 worth of smoked trout a week and 6,800
heads of lettuce. He has survived for 8 years just
doing production. Now he sells franchises.
Business Model
Off the farm, grocery, and franchises
 Green Acre Aquaponics
 Based on modified UVI system
 Been in operation 3 years
 Supplement their organic wholesale food and CSA
products
 Large percent of income directly related to their teaching.
 Commercial guide cost $995
 Classes are $1295 per person


Business Model
Wholesale , CSA , tours and education

Growhaus - Variation on the UVI Design
 Hybrid System
 25% Beds with substrate
 75% Rafts
 Plants primary
 Fish secondary

Tilapia
Fingerlings
Tilapia
grow out
Settle solid
waste
Substrate
Reservoir
1st raft
channel
2nd raft
channel
3rd raft
channel
Pump
Growhaus - Denver
Tilapia
Fingerlings
Tilapia
grow out
Settle solid
waste
Substrate
Reservoir
1st raft
channel
2nd raft
channel
3rd raft
channel
Pump
Growhaus - Denver

 Will Allen’s Growing Power
 Is a multi disciple agriculture
learning center
 Aquaponics is a small part of the
system
 Charge for tours and sell produce
 Use mostly volunteer labor and
“internships”
 Many paid positions are grant
funded or through Americorps.


Business Models
Nonprofit, Educational and Agri-tourism
 After School Matters
 Allen Foundation
 Andrah Foundation, Ruth Knoll
 Anonymous Family Foundation
 Bayshore Community
Foundation Fund
 Bradshaw Knight Foundation
 Brewers Community
Foundation, Inc.
 Brico Fund
 Bruce and Muriel Hach
Scientific Foundation
 C.G. Schmidt Construction
Company
 Ceres Foundation
 Chicago Community Trust,
Searle Family Fund
 Chicago Department of Family
and Support Services
 Chicago Police Department
Force for Good
 Chicago State University
Foundation
 City of Chicago Community
Development Grants
Administration
 City of Milwaukee, Community
Development Grants
Administration
 Clif Bar Family Foundation
 Community Benefit Trust Fund
 Cream City Foundation -
Joseph R. Pabst LGBT
Infrastructure Fund
 Critical Mass Leadership
Education
 Dagoba Organic Chocolate
 David & Julia Uihlein
Charitable Foundation
 Farm Aid
 First Unitarian Society of
Milwaukee
 GE Foundation Matching Gifts
 The Goggio Family Foundation
 Greater Milwaukee
Foundation
 Greater Milwaukee
Foundation, Henry & Mary
Franke Idea Fund
 Greater Milwaukee
Foundation, Frank Kirkpatrick
Fund
 Greater Milwaukee
Foundation, Kopmeier Family
Fund
 Greater Milwaukee
Foundation, Walter and Olive
Stiemke Fund
 Green Bay Packers Foundation
 H.H. Camp Foundation
 Headwaters Foundation for
Justice – Young Donors Circle
Fund
Business Model
Nonprofit - contributors
 Helen Bader Foundation
 Jane Bradley Pettit Foundation
 Jessie Smith Noyes Foundation
 JPMorgan Chase Foundation
 J.R. Albert Foundation
 Kohl’s Stores A-Team
 LaSalle Bank
 Lawson Valentine Foundation
 L.E. Phillips Family Foundation, Inc.
 Liberty Property Trust
 Linda and Jock Mutschler
Foundation
 Lubar Family Foundation - Sheldon
& Marianne Lubar Charitable Fund
 Manaaki Foundation
 Medical College of Wisconsin,
Healthier Wisconsin Partnership
Program
 Meshewa Farm Foundation
 Miller Brewing Company
 Milwaukee Area Workforce
Investment Board
 Milwaukee County Community
Development Block Grant
 National Education Association
Foundation
 Northwestern Mutual Foundation
 Patrick and Anna Cudahy Fund
 Parkways Foundation
 Richard and Ethel Herzfeld
Foundation
 Rotary Club of Mitchell Field
Charitable Foundation
 Scott’s Miracle Grow
 Service Club of Milwaukee
 Silver Spring Neighborhood Center
 St. Pius Congregation
 State of Wisconsin Office of Energy
Independence
 The 11-10-02 Foundation
 The Barnwood Foundation
 The Cleveland Foundation
 The Community Foundation
Serving Boulder County
 The E-Z Coffee Stand
 The Gardner Foundation
 The J.M. Kaplan Fund
 The John D. and Catherine T.
MacArthur Foundation
 The McCormick Foundation
 The Monches Foundation
 The Robert R. McCormick
Foundation
 The Seed Fund
 University of Wisconsin Extension
 USA for Africa
 US Environmental Protection
Agency Environmental Justice
Grants Program
 USDA Community Food Projects
 USDA Farmers Market Promotion
Program
 The following businesses and
individuals have contributed their
time, money, and materials:
 Growing Power's Board of
Director's and the Chicago Advisory
Board for their guidance and
generosity with their time
 Will Allen, Milwaukee
Business Model
Nonprofit - contributors

 Alterra Coffee
 Avec, Chicago
 Blackbird, Chicago
 Bleeding Heart Bakery,
Chicago
 Breadsmith Bakery,
Milwaukee
 Columbia College, Chicago
 Dagoba Organic Chocolate
 Dave Ditscheit, Milwaukee
 First Slice Cafe, Chicago
 Floriole Bakery, Chicago
 Fraiche Kitchen, Chicago
 Get Me Greg's, Chicago
 Gino's Deli & Catering,
Milwaukee
 Goodness Greeness,
Chicago
 Joan Jacobs, Milwaukee
 Jonathan’s Bagel,
Milwaukee
 Lakefront Brewery,
Milwaukee
 Kitchen Chicago, Chicago
 Magilo's Produce,
Milwaukee
 Elizabeth Malone,
Milwaukee
 Arthur Marburg,
Milwaukee
 Marcus Corporation,
Milwaukee
 Outpost Cooperative,
Milwaukee
 The Publican, Chicago
 Red Hen Bread, Chicago
 Seedling Fruit, Michigan
 Sendik's Grocery,
Milwaukee
 The Signature Room,
Chicago
 The Simple Soyman,
Milwaukee
 Sprecher Brewery,
Milwaukee
 Sunday Dinner, Chicago
 Dave Swanson, Milwaukee
 Vella Cafe, Chicago
 Whole Foods, Chicago
 Wild Flour Bakery,
Milwaukee
Business Model
Nonprofit - contributors
 Currently aquaponics is a viable business that seems
to require diversification of productsand services.

 It is difficult, though possible, to run a farm with
revenue from the produce alone.
Take home message:
Reymann Memorial Farm (WVU)
Cold Flowing Water System
Wardensville, WV
Spring
Trout
Raceway
Aquaponic
Channel
with rafts
Polishing
Pond
Discharge
to Stream
Cold Flowing Water System
Facility Components at Reymann Memorial Farm
Plants adapted to cool root zone:
• Watercress
• Lettuce
• Swiss Chard
• Kale
• Kohlrabi
• Broccoli
• Cabbage
• Nasturtium
• Calendula
• Dianthus
• Mums


Greenhouse
High Tunnel
 Nutrient levels low, do not accumulate
 Seeking to determine what grows well and rates of
production
 First goal - product value, second goal - improve
water quality.
 More information on this work covered in Research
Update part of today’s program.
Reymann Memorial Farm (WVU)
UVI -best known, most well researched
aquaponic production system
Diagram from Recirculating Aquaculture Systems by Timmons et al 2002, pg 637. NRAC pub 01-002
Slides from Plant Production Presentation at the 2012
Aquaponics Association Meeting
James Rakocy,
PhD
Director/Consultant of The Aquaponics Doctors
http://theaquaponicsdoctors.com/

Formerly:

AES Director, Professor of Aquaculture at University of the Virgin Islands

Pioneered Aquaponics research and development.

Nutrients Required for Plant Growth
 Macronutrients
– C Carbon*
– O Oxygen*
– H Hydrogen*
– N Nitrogen
– K Potassium**
– Ca Calcium**
– Mg Magnesium
– P Phosphorus
– S Sulfur


 Micronutrients
– Cl Chlorine
– Fe Iron**
– Mn Manganese
– B Boron
– Zn Zinc
– Cu Copper
– Mo Molybdenum
* Supplied by CO2 and H2O ** Must be supplemented
Rakocy 2012
Production Methods
 Staggered
 Allows weekly harvests
 Facilitates market development
 Maintains uniform nutrient uptake
 Batch
 Easier management
 Can deplete nutrients


Rakocy 2012
Seedling Production
Greenhouse or shade house
 Protected area
Keep it clean
 Metal tables
 Install drain if concrete floor
 Weed barrier if gravel floor
Planting media and dead plant material can
harbor
 insects and disease

Rakocy 2012
Planting Media
Soilless potting mix
Coir (coconut fibers) + Vermiculite
 60% + 40% mix
 Free from pythium
 Requires fertilizer supplementation
 Labor required to prepare mix
Rakocy 2012
Planting Media
 Peat potting mix (i.e.
Promix BX)
– Inexpensive
– Readably available
– Contains micronutrients
for seedling growth
– Can have pythium
spores
 Jiffy peat pellets
– Expensive
– Easy to use
– Can have pythium
spores
 Oasis root cubes
– Expensive
– Requires additional
nutrients
– Dries out quickly in
greenhouse
 Rockwool
– Expensive
– Non-biodegradable
Rakocy 2012
Seedling Production
 Fill flat with mix
 Seed at required depth for plant variety
 Automatic seeder for small and surface planted seeds
 Cover flat until seeds germinate
 Many seeds germinate better in the dark
 Keeps mice from stealing seeds
 Keeping covered too long causes seedlings to elongate
and have weak stems
 Water as needed
 Some seeds prefer dryer conditions than others
 Use mist nozzle for first week
 Fertilize 2-3 times weekly
Rakocy 2012
Rakocy 2012

Rakocy 2012
Rakocy 2012
Rakocy 2012
Rakocy 2012
Rakocy 2012
Rakocy 2012
Rakocy 2012
Rakocy 2012
Rakocy 2012
Rakocy 2012
Watering Equipment
Hozon Siphon Mixer
– 1:16 proportioning device
Rakocy 2012
NPK Nitrogen, Potassium,
Phosphorous
N - Nitrogen - shoots
P - Phosphorous - roots
K - Potassium - flowers and fruit

Use 9-45-15 for seedling production
– Promotes strong root formation
Rakocy 2012
Rakocy 2012
Rakocy 2012
Rakocy 2012
Rakocy 2012

Deep Flowing Channels

 Six channels
 100 ft x 4 ft x 16 in
 Total water volume
 18,000 gallons
 3 hr retention time
 72 rafts
 8 ft x 4 ft
 Growing area
 2304 ft2



 100 ft x 4 ft x 16 in


– 72 Rafts
2.4 m x 1.2 m x 3.8 cm
(8 ft x 4 ft x 1.5 in)
214 m2 surface area
(2,304 ft2)
Rakocy 2012
Raft Preparation
 Closed-cell polystyrene (Dow blue board, not
scored)
 Dow Styrofoam® Square Edge Extruded
 4 ft x 8 ft x 1.5 in
 Paint
 White, latex, non-toxic, roof paint
 Plant holes – 1.87 in
 Use template for spacing
 Spacing varies for vegetable variety
 Net pots: 2 in x 2 in
Rakocy 2012
Rakocy 2012
Production Management
pH maintained at 7.0
 KOH
 Ca(OH)2
Chelated iron
 2 ppm (mg/liter)
 Chelated iron is 13% pure so multiply by 7.7
 (i.e., 15.4 mg of product gives 2 mg of iron)
Manage net tanks with cleaning schedule to
control nitrate levels
Biological pest control
 Integrated pest management Rakocy 2012
Rakocy 2012

Rakocy 2012
Lettuce
High nitrogen levels promotes leafy growth
Short production cycle generates steady
cash flow
Strong demand
Rakocy 2012
Lettuce Production Cycle
Greenhouse Phase
 Week 1
– Day 0: seed
 Week 2
– Day 7: thin flat
– Day 7, 10, 13: fertilize
 Week 3
– Day 14, 16, 19:
fertilize
Aquaponic System Phase
 Week 4
– Day 21: transplant to
aquaponic system
– Day 23, 26: spray with BT
 Week 5
– Day 30, 33: Spray with BT
 Week 6
– Day 37, 40: Spray with BT
 Week 7
– Day 42, 45: Spray with BT
– Day 49: Harvest
Rakocy 2012
Rakocy 2012
Lettuce Harvest Procedures
 Move sheets with mature plants to one end of the raft
 Lift sheets to harvesting stand or harvest in place
 Cut off lettuce stalk with a sharp knife and remove
lower poor quality leaves
 Discard any poor quality lettuce
 Pack 24 lettuce heads to a box
 Weigh several randomly selected boxes minus the
empty box weight to calculate total harvest weight and
average weight per head of lettuce.
 Count box to determine total lettuce number and
percentage of marketable yield

Rakocy 2012
Lettuce Harvest Procedures
 Lettuce that is not distributed immediately should
be stored in a moist refrigerated room
 Surface of the sheets should be washed with
dechlorinated water to remove any dead leaves
and quickly returned to hydroponic tanks
 Plants roots and growing media should be
removed from net pots and discarded
 Cleaned net pots should be disinfected by soaking
them in water containing bleach, rinsed and then
dried before they are used again.
Rakocy 2012
Rakocy 2012
Rakocy 2012
Rakocy 2012
Rakocy 2012
Rakocy 2012
Rakocy 2012
Lettuce Production Values
Type Romaine Crisphead Leaf Bibb
Variety Parris
Island
Montello Sierra Boston
Bibb
Density
(plants/raft)
48 60 60 88
Harvest
(cs/sheet)
2 2.5 2.5 3.67
Value
($/case)
30 25 25 20
Total 60 62.5 62.50 73.4
Rakocy 2012
Leaf Lettuce
 Sierra
 20/m2, 60 per raft
 Staggered production
18 rafts harvested/week
 Market value
$1.00/head
 Value$196/m2/year
~$41,900/system/year

Rakocy 2012

Rakocy 2012
Romaine Lettuce
 Parris Island
 16/m2, 48 per raft
 Staggered production
18 rafts harvested/week
 Market value
$1.25/head
 Value
$157/m2/yearr
~$33,600/system/yearr
Rakocy 2012
Pythium spp.
 Root fungus
 No IPM control
 Low temperature
reduces growth and
impact of some
Pythium species
 Select resistant
varieties

Rakocy 2012
Basil Production
 48 plants/sheet
 Staggered production
 Complete harvest recommended
 Cut and come again at 4 week intervals is
alternative
 Grow for 3 months
 Harvest (cut) three times then remove
 Reduces survival and increases pythium
 Seedlings
 3 weeks in greenhouse

Rakocy 2012
Basil
Genovese
16/m2, 48 per
raft
Market value
 $10.00/lb
Value
 $515/m2/yr

$110,210/system/yr

 Rakocy 2012
Melon Production
2 plants/sheet
 Use one side only and allow plants to run on
ground
 Plant other side with companion crop
 Or construct narrow hydroponic tanks
< 3 month crop
Plants die as melons ripen on the vine
Seedlings
 1-2 weeks in greenhouse
Rakocy 2012
Cantaloupe
 Jaipur
 0.67/m2, 2 per raft
 Market value
 $3.99 each
 Value
 Each: $46.28/m2/yr
 $9,900/system/yr



Rakocy 2012
Revenue for Various Crops
Crop $/m2/yr $/ft2/yr
Leaf lettuce (20/m2) 196 18.22
Romaine lettuce
(16/m2)
157 14.59
Basil (16/m2) 515 47.86
Okra (3.7/m2) 15 1.39
Cantaloupe (0.67/m2) 46 4.28
Rakocy 2012
Plant Pest and Disease Control
No synthetic chemical pesticides

Biological controls used to control insects

 IPM to reduce pest pressure


Rakocy 2012
Biological Controls
 Dipel
 Bacteria
 Controls
caterpillars

 Armicarb
 Potassium
 bicarbonate
 Controls fungus,
 powdery mildew.
 Changes pH of leaf
 surface making it
 unsuitable for
 fungus growth
 BotaniGard
 Fungus
 Controls soft bodied
insects (white flies,
aphids)

Rakocy 2012
 Application
of Dipel with
gas powered
backpack
sprayer
Rakocy 2012
Soaps and Oils
Coats insect causing
death.
Kills all insects
 Including beneficial
Ladybugs, wasps, bees
Rakocy 2012
Barriers
Shade cloth
Tangle foot
Rakocy 2012
Thank you, Jim, for sharing these
slides.

Questions?
