CONSUMER, PURCHASER OR ANY OTHER PERSON USINGThe protective earth contact
test, which is accomplished through operator
contact with a touch pad, will detect whether a
ground connection is present (Figure 1).
TECH TIPS
Regular safety maintenance and testing is critical.
Figure 1: Initial Test Verifies Presence of Safety Ground
36 • SUMMER 2022
The test is not a genuine bonding test to verify
the current-carrying capacity of the bond,
but rather verifies the connection’s absence or
presence. This is indicated by a PROCEED or
FAULT message on the display. For maximum
safety, any further testing of the charger is
disabled, and a faulted bond must be repaired
by a qualified electrician.
Protective Conductor Resistance
The second test is protective conductor
resistance. This test verifies that exposed
metalwork on the charger is effectively
connected to the ground pin on the charger’s
socket or plug so that any possible fault
currents from electrical failure will be safely
diverted into the grounding system — not
through the body of an operator who happens
to be in contact with the charger.
An alligator clip or probe is used to touch
all possible points on the charger’s exposed
metalwork. Therefore, this test is not required
for chargers with no exposed metalwork or
protected by double insulation. The tester
measures the resistance to ground and displays
it, along with a comparison to a safe standard
of 0.5  Ω, which is typically indicated by a
green check mark or red X (Figure 2). Failure
must be repaired by a qualified electrician.
Trip Time and Touch Voltage Tests
The remaining safety tests are for touch voltage
and trip time. EV chargers afford redundant
safety protection through ground fault safety
interrupters (GFCIs) or residual current devices
(RCDs). These work by detecting an imbalance
in circuit current. The differential could go to
ground through a human being, or it could
find an unwanted path through equipment,
causing fire or electrical damage. To prevent
that, the device trips and opens the circuit.
But GFCIs and RCDs are delicate devices that
need to be checked. The charger tester applies
a calibrated current matching the protective
device’s rating and measures the time it takes
to trip. The tester further assures that the
trip time is fast enough to protect personnel
from injury. Typical configurable parameters
are voltage (230, 120), test current (30, 20,
and 6 mA), and maximum test time (300 ms,
12.5 s, 5.59 s), with the tester indicating pass
or fail. Another adjustment is angle of earth
leakage current, either starting at the positive
direction zero crossover (0 degrees) or negative
(180 degrees).
Once the test has started, the tester puts the
charger in charging mode and measures the
output voltage. Next, a touch voltage test is
performed to ensure that an inadequate ground
will not raise the voltage to a hazardous level
during testing. This test is adjustable at 25 V or
50 V. Earth leakage current is then measured
and displayed.
Nuisance Tripping
Once the safety checks have assured that the
EV charger can be operated without danger, a
nuisance tripping test is performed. Extraneous
currents such as the capacitive charging of long
extension cables can be sources of nuisance
tripping. This can be a hindrance to speedy and
TECH TIPS
SAFETY TESTING OF EV CHARGERS
Figure 2: Pass/Fail Indicates Progress and Results
efficient testing. But once recognized, it can
be eliminated by adjustment. The test applies
a calibrated earth ground leakage current
starting at approximately half the trip rating for
the protective device in the charger, and then
steadily increases the current until the device
trips. The current at which the device tripped
is displayed. The operator looks for a low trip
value.
There are four ways to perform this test:
 1. A 230 V AC current is ramped up to
30 mA in 2 mA steps of 300 ms duration
for 4.5 seconds.
 2. A DC current ramps at 6 mA for 2.5
seconds to prevent tripping of the AC
response, then holds at 3 mA DC for
11.25 seconds.
 3. For testing 120 V equipment, a 6 mA AC
test ramps up in 0.5 mA steps of 100 ms
duration for 4.5 seconds.
TECH TIPS
 4. At 20 mA AC, a similar test ramps up
in 1 mA steps of 100 ms duration for a
maximum of 2 seconds.
Results are displayed in trip current, with
0-degree or 180-degree options available.
Proximity Circuit
A proximity circuit prevents the vehicle from
moving during charging, an obvious safety
requirement. The circuit provides a signal so
the vehicle knows it is connected to a charger.
When the charger is connected, the voltage on
the proximity pin in the vehicle drops from
4.5 V to 1.5 V. The EV charger tester assures
this will happen by simulating the circuit of the
vehicle.
If the charger has separate connecting cables,
the connector applies a proximity pilot (PP)
resistance signal to the charger to indicate the
rating of the connection cable. The maximum
CONTACT US TODAY: 610.515.8775 • Fax (610) 258-1230
2200 NORTHWOOD AVE, EASTON, PA 18045 USA
For our complete inventory visit our website: www.belyeapower.com • sales@belyeapower.com
Call Today: 610.515.8775
 Electro Mechanical Relay
 Substation Equipment
 Grounding Resistors
 Motor Controls
 CT’s and PT’s
 Bushings
 Arresters
 Gauges
 Fuses
 And More....
No one has a wider range of
Electrical Power Equipment
and Parts. Our vast inventory has
new, used and obsolete parts.
Visit www.belyeapower.com
to nd the parts you need.
Belyea’s Vast Inventory
Has it All!
 Looking for Obscure, Obsolete,
New or Used Parts?
38 • SUMMER 2022
available current being indicated to the vehicle
via the control pilot (CP) signal is adjusted
accordingly. A charger tester verifies that
this happens correctly by using cables with
varied ratings. Test results are indicated by
two symbols: a closed connector indicates
proximity and a lock symbol indicates that the
connection is latched.
Control Pilot Check
Finally, a control pilot check verifies the
integrity of the communication between the
charger and the vehicle. There are three main
areas of communication:
 1. State of the vehicle/charger
 2. Maximum current to be drawn by the
vehicle
 3. Whether digital communication indicates
current
The first of these includes disconnected,
connected, charging, charging with ventilation,
CP to PE fault, and charger fault. The control
pilot signal is a 1 kHz square wave with the
charger state communicated using the signal
voltage level. Maximum current and digital
communication use are indicated by the
signal duty cycle. The charger tester takes the
place of the vehicle and allows the user to set
the CP code. The tester then reads the code
back from the charger as set out in Table 8
of IEC Standard 61851-1. This allows the
user to verify the correct operation of the
charger, ensuring that the charger responded as
expected. In addition, testing the control pilot
signal measures the charger output voltage and
frequency.
TECH TIPS
Output charging voltage and frequency should
be as expected for the utility supply to which
the charger is connected. Polarity should
read OK. Incorrect polarity is shown as INV.
Maximum current should match the rating of
the charger or connecting cable. Control pilot
voltage, duty cycle, and frequency should be
repeatable. The control pilot state read from
the charger should match the code set for the
test. A fault or error with the charger itself is
indicated.
CONCLUSION
Compared to transformers, electric motors,
building wiring, long runs of power cable,
and a plethora of other pieces of electrical
equipment, the electric vehicle charger may
seem a simple device. Don’t let that allow it
to slip off the chart for predictive/preventive
maintenance. EV chargers have potential
safety hazards that can be recognized and
corrected.
An EV charger tester should be part of
the electrical maintenance program.Both
equipment damage and personnel injury can
be prevented by testing and maintaining EV
chargers. Customers and clients are afforded
protection, compliance can be maintained
with standards agencies like OSHA, and legal
safeguards can be kept in place.
Jeffrey R. Jowett is a Senior Applications
Engineer for Megger in Valley Forge,
Pennsylvania, serving the manufacturing
lines of Biddle, Megger, and Multi-
Amp for electrical test and measurement
instrumentation. He holds a BS in biology
and chemistry from Ursinus College. He
was employed for 22 years with James G. Biddle Co., which
became Biddle Instruments and is now Megger.
SAFETY TESTING OF EV CHARGERS
CAN’T AFFORD TO WAIT FOR
ELECTRICAL
EQUIPMENT?
When equipment fails, every minute spent searching for what you need is bad for the
bottom line. Our massive inventory of millions of new, surplus and repurposed circuit
breakers, switchgear and related products is here for you. We have the expertise to see
the big picture, understand your problem and recommend the best solution. Already know
exactly what you need? Our website is constantly being updated with products and the
online buying process is easy.
Tap into the power of National Switchgear
at nationalswitchgear.com or
call us today at (800) 322-0149.
sm
40 • SUMMER 2022
IMPACT OF CHANGES
TO IEEE STD. 1584,
IEEE GUIDE FOR
PERFORMING
ARC-FLASH HAZARD
CALCULATIONS
PART 2
IMPACT OF 2018 CHANGES TO IEEE STD 1584, IEEE GUIDE FOR
PERFORMING ARC-FLASH HAZARD CALCULATIONS – PART 2
BY STEVE PARK, PE, Vertiv
In the Spring 2022 edition of NETA World, Part 1 of this article provided
a brief history and evolution of electrical safety over the past 50 years.
It was during this period that OSHA was formed and NFPA began
developing the 70E standard. We also reviewed some of the key changes
from the original 2002 edition of IEEE 1584 to the second edition in
2018, specifically examining the newly recommended arc flash calculation
process and variables included in the calculations.
In Part 2, we discuss the relevant impact
of these changes and how they affect the
calculated incident energy levels that we
depend on to select adequate PPE and keep our
workers safe.
Let’s start by considering the most frequently
asked questions related to this new arc flash
calculation process:
• Does a new study need to be performed
using the new method?
• How do the old and new methods
compare with respect to incident energy
calculations, and how significant are these
changes to the results of the analysis?
• Will the new calculations result in
significantly different incident energy
(IE) values?
COVER STORY
NETAWorld • 41
PH
O
TO
: ©
SH
U
TT
ER
ST
O
C
K.
C
O
M
/G
/P
IN
YO
+P
RO
M
PR
A
SE
RT
?S
EA
RC
H
TE
RM
=S
A
FE
TY
IMPACT OF 2018 CHANGES TO IEEE STD 1584, IEEE GUIDE FOR
PERFORMING ARC-FLASH HAZARD CALCULATIONS – PART 2
COMPARISON OF METHODS
While many variables must be considered when
comparing the two methods, I’ve put together
some scenarios that provide a practical comparison
that answers these questions. The comparison
focuses on low-voltage systems, as these are the
most prevalent systems workers are exposed to,
and this is where most accidents occur.
Two low-voltage scenarios are examined. The
first is a 208 V system; the second is a 480 V
system. For both scenarios, a fixed event
duration of 83.3  ms was used. Designed
interruption times for molded-case circuit
breakers are approximately 8.33 ms (1/2 cycle)
and 50 ms (3 cycles) for power circuit breakers.
For the following examples, a fixed duration
time of 83.3 ms (5 cycles) was used. As a result
of using a fixed duration for the calculations,
the reduced arcing current calculation was not
applicable for this analysis.
The following parameters were used in the
analysis:
Table 1: Parameters Used in Arc Flash
Calculations for Two Voltage Levels
208 V
Model
480 V
Model
Electrode Gap (mm) 25 32
Enclosure Standard Standard
Working Distance (in) 18 18
Arc Duration (ms) 83.3 83.3
The IEEE 1584-2002 calculations for a low-
voltage arc in an enclosure were compared
to the 2018 calculations for the vertical
conductor-electrode configuration (VCB),
vertical conductor-electrode terminated in
a metal enclosure (VCBB), and horizontal
conductor-electrode terminated in a metal
enclosure (HCB) configurations. The analysis
COVER
STORY
42 • SUMMER 2022
was performed utilizing a bolted fault current
ranging from 2 kA to 100 kA.
Figure 1 and Figure 2 show the incident energy
results of this analysis. Figure 1 shows the 2002
versus 2018 incident energy (IE) results for the
208 V example. Figure 2 shows the comparison
for the 480 V example.
The HCB calculations result in a significantly
higher incident energy than the VCB/VCBB
calculated energies and the energy calculated
under the 2002 model when considering a
typical range of bolted fault current values. The
HCB model is representative of large power
circuit breaker cubicles in switchgear, junction
boxes, and some disconnects versus what is
typically found in smaller panelboards (VCB/
VCBB). This higher IE for HCB equipment is
the result of the horizontal electrodes ejecting
the arc outwards directly towards the opening
and worker. If an arc occurs in the stab area of
a cubicle, and a circuit breaker is present, the
breaker is likely to disrupt the arc ejection and
decrease the IE below the calculated value.[1]
However, during the testing and development
of IE equations, a breaker was not present in
the cubicle, and there are currently no test
data or equations to quantify or support this
scenario. The vertical electrode models result in
less incident energy than the HCB orientation
because the arc tends to be ejected downward
and then reflected outward towards the worker.
Depending on the geometry of the enclosure
and the position of the worker, this could
intensify the IE at the worker’s legs and feet.
For the 208  V example and for equipment
with a vertical bus, the 2002 and 2018 analysis
methods provide similar results over a large
range of fault currents. For the 480 V example,
the vertical bus calculations also provide
relatively similar results, but the VCBB does
tend above the 2002 calculated values a bit
more than in the 208 V calculations. For both
the 208 V and 480 V calculations, the HCB
results immediately deviate above the 2002
results and remain significantly higher over the
range of currents studied.
For larger equipment (e.g., power circuit
breakers), typically with horizontal stab
construction, the new calculations indicate that
the previously recommended arc-rated personal
protective equipment (AR PPE) may not be
sufficient to protect workers from serious injury.
Work that has been previously performed with
minimal AR PPE may now require a much
higher AR PPE rating. The new IE calculated
results for equipment with a vertically oriented
bus (electrodes) remain similar to the 2002
calculated results. When performing the analysis
COVER STORY
IMPACT OF 2018 CHANGES TO IEEE STD 1584, IEEE GUIDE FOR
PERFORMING ARC-FLASH HAZARD CALCULATIONS – PART 2
0.00
2 10 20 30 40 50 60 70 80 90 100
1.00
2.00
3.00
4.00
5.00
6.00
7.00
8.00
IE
 (c
al
/
cm
2)
Fault current (kA)
2018 HCB
2002
2018 VCBB
2018 VCB
V = 208V
Gap = 25 mm
Standard Enclosure
Working Distance 18"
Duration = 83.3 ms
0.00
2.00
4.00
6.00
8.00
10.00
12.00
14.00
16.00
18.00
20.00
2 10 20 30 40 50 60 70 80 90 100
IE
 (c
al
/
cm
2)
Fault current (kA)
2018 HCB 2002
2018 VCBB
2018 VCB
V = 480V
Gap = 32 mm
Standard Enclosure
Working Distance 18"
Duration = 83.3 ms
0
5
10
15
20
25
30
35
40
45
50
2 10 20 30 40 50 60 70 80 90 100
A
rc
in
g
cu
rr
en
t (
kA
)
Fault current (kA)
2018 - 480V
2002 - 480V
2018 - 208V
2002 - 208V
VCB bus orientation (2018)
V = 480V
Gap = 32 mm
Standard EnclosureV = 208V
Gap = 25 mm
Standard Enclosure
0.00
2 10 20 30 40 50 60 70 80 90 100
1.00
2.00
3.00
4.00
5.00
6.00
7.00
8.00
IE
 (c
al
/
cm
2)
Fault current (kA)
2018 HCB
2002
2018 VCBB
2018 VCB
V = 208V
Gap = 25 mm
Standard Enclosure
Working Distance 18"
Duration = 83.3 ms
0.00
2.00
4.00
6.00
8.00
10.00
12.00
14.00
16.00
18.00
20.00
2 10 20 30 40 50 60 70 80 90 100
IE
 (c
al
/
cm
2)
Fault current (kA)
2018 HCB 2002
2018 VCBB
2018 VCB
V = 480V
Gap = 32 mm
Standard Enclosure
Working Distance 18"
Duration = 83.3 ms
0
5
10
15
20
25
30
35
40
45
50
2 10 20 30 40 50 60 70 80 90 100
A
rc
in
g
cu
rr
en
t (
kA
)
Fault current (kA)
2018 - 480V
2002 - 480V
2018 - 208V
2002 - 208V
VCB bus orientation (2018)
V = 480V
Gap = 32 mm
Standard Enclosure
V = 208V
Gap = 25 mm
Standard Enclosure
Figure 1: 2002 vs. 2018 IE Calculated Result Comparison at 208 V
Figure 2: 2002 vs. 2018 IE Calculated Result Comparison at 480 V
NETAWorld • 43
using the new methods, careful consideration
must be given to the model parameters to ensure
accurate results are rendered based on the best
available information.
Figure 3 compares the arcing current from
the 2002 and 2018 calculation methods using
the previous parameters and assumptions for
the 208  V and 480  V scenarios. This graph
shows that the 2018 calculated arcing currents
are typically 20%–25% higher than the 2002
values over the typical fault current range.
However, higher arcing currents don’t always
translate into higher IE and arc flash boundary
(AFB) values. If the previously calculated arcing
current values resulted in an event duration
based on the instantaneous element operation
of the upstream overcurrent protective device,
the slightly higher arcing current might
translate into only slightly higher IE and
AFB values. Conversely, if the previous arcing
current values did not activate an instantaneous
element of the upstream overcurrent protective
device, but only activated the short-time
element, the higher calculated arcing current
might result in a shorter duration event
(instantaneous element trip) and possibly lower
IE and AFB values. Each piece of equipment
must be evaluated on a case-by-case basis.
IMPACT OF CHANGES
The revised calculations per the 2018 edition
of IEEE 1584 may result in changes to
previously calculated arc flash incident energy
values and changes in arc-rated personal
protective equipment requirements for workers
compared to the 2002 edition methods. The
calculated incident energy may be higher
in some situations and lower or very similar
in others. With the possibility of significant
changes in incident energy between the old
method and the new method, and the changes
to low-energy equipment, those responsible
for facility electrical distribution systems —
and the safety of workers — should consider
revisiting their arc flash analysis to determine
whether their workers are adequately protected
against recognized hazards (OSHA’s General
Duty Clause). One potential advantage of this
re-evaluation is that, in some cases, workers
COVER STORY
may be able to perform some tasks with less-
cumbersome PPE than previously determined.
Re-Evaluating Electrical Hazards
Given the 2018 changes to IEEE 1584,
another critical question is whether you are
required to update a study performed using
the 2002 edition if there are no other factors
to consider (changes in the facility electrical
system or to the utility). No — there are no
requirements that force you to update your
study simply because IEEE 1584 has been
updated. Remember, use of IEEE 1584 is
voluntary and is not mandated by law. Other
means can be used to calculate and determine
the extent of electrical hazards associated with
arc flash events. However, this document is one
of the most recognized sources available, and
the recent update makes it even more accurate
for calculating arc flash incident energy levels.
Should you choose to use another method to
calculate the hazardous energy of an arc flash,
expect your methods to be highly scrutinized
and be prepared to defend them.
When considering whether an update is
required or not, we shouldn’t forget about one
key requirement from NFPA 70E, Standard for
Electrical Safety in the Workplace.[2] You may not
be required to update your study as a result of
IMPACT OF 2018 CHANGES TO IEEE STD 1584, IEEE GUIDE FOR
PERFORMING ARC-FLASH HAZARD CALCULATIONS – PART 2
0.00
2 10 20 30 40 50 60 70 80 90 100
1.00
2.00
3.00
4.00
5.00
6.00
7.00
8.00
IE
 (c
al
/
cm
2)
Fault current (kA)
2018 HCB
2002
2018 VCBB
2018 VCB
V = 208V
Gap = 25 mm
Standard Enclosure
Working Distance 18"
Duration = 83.3 ms
0.00
2.00
4.00
6.00
8.00
10.00
12.00
14.00
16.00
18.00
20.00
2 10 20 30 40 50 60 70 80 90 100
IE
 (c
al
/
cm
2)
Fault current (kA)
2018 HCB 2002
2018 VCBB
2018 VCB
V = 480V
Gap = 32 mm
Standard Enclosure
Working Distance 18"
Duration = 83.3 ms
0
5
10
15
20
25
30
35
40
45
50
2 10 20 30 40 50 60 70 80 90 100
A
rc
in
g
cu
rr
en
t (
kA
)
Fault current (kA)
2018 - 480V
2002 - 480V
2018 - 208V
2002 - 208V
VCB bus orientation (2018)
V = 480V
Gap = 32 mm
Standard Enclosure
V = 208V
Gap = 25 mm
Standard Enclosure
Figure 3: 2002 vs. 2018 Arcing Current Comparison at 208 V and 480 V
changes to IEEE 1584 methods and procedures,
but NFPA 70E does require a review every five
years of the data compiled and used to determine
hazards.  This ensures that, if there are changes to
any factors used to determine the level of hazards
(incident energy, arc flash boundary, etc.), the
impact of these changes will be examined at least
every five years.  This is also an excellent time to
incorporate the new IEEE 1584 methods and
procedures into the analysis for the entire facility.
While you may not be mandated to update your
study due to changes in IEEE 1584, should you
perform an update?
Areas with higher operating voltages (480
V) and/or areas where there are horizontal
electrodes (large power circuit breakers) are
two circumstances where you might consider
a revised study to ensure the calculated
incident energy is accurate. These are areas
where hazards may be significantly higher than
calculated under the previous methods.
A second scenario where you might want to
run a revised study is for equipment previously
classified as low-energy equipment:
Equipment below 240  V need not be considered
unless it involves at least one 125 kVA or larger low-
impedance transformer in its immediate power supply.
The change to the requirements for equipment
considered to be low risk (less than1.2 cal/cm2)
is significant and will affect many facilities
with existing arc flash studies. The revised
parameters for low-energy equipment stem
from the discovery that, under the previously
defined parameters, workers could be exposed
to IE levels above 1.2 cal/cm2. This important
change may require the analysis of equipment
not included in the previous arc flash study
(i.e., equipment assumed to have IE below
1.2 cal/cm2).
Sustainable arcs are possible but less likely in
three-phase systems operating at 240 V nominal
COVER STORY
BURLINGTON
ELECTRICAL
TESTING CO., LLC
AROUND THE CLOCK
RESPONSE SERVING THE
POWER INDUSTRY
BET is an independent third-party testing firm with more than 50 years of
experience serving industrial, commercial, and institutional facilities’ low- to
high-voltage electrical testing and maintenance needs, including:
• Acceptance Testing & Commissioning
• Switchgear Reliability Testing
• Protective Relay Setting
• Transformer Repair
• Transformer Oil Analysis
• Circuit Breaker Retrofits
• Battery Bank Testing
• Cable Fault Locating
• Meter Calibration
• Motor Testing & Surge Analysis
• Infrared & Ultrasonic Inspections
• Load Survey & Analysis
• Coordination & Short Circuit Studies
• Arc Flash Hazard Analysis
For scheduling call 215-826-9400or email sales@betest.com
Visit us at www.betest.com
NETAWorld • 45
skill set, experience, or aptitude). Someone
who operates an equipment disconnect, such
as a machine operator, may not require the
same level of training as someone who racks in
a large power circuit breaker or troubleshoots
electrical problems. While most workers
don’t need to know how to calculate arc flash
incident energy or arc flash boundaries to be
able to execute their daily tasks, they do need to
understand the factors that govern these values
so they can make informed decisions about the
required PPE and other safe work practices.
Everyone plays a vital role in safety. The more
knowledgeable your workers are and the more
dedicated to safety your company is, the
less you place your workers at risk of injury.
Employers must create a corporate work
environment where safety is more than just a
policy; it’s a culture!
CONCLUSION
Many excellent articles and papers are available
that contain various perspectives on arc flash
safety and electrical safe work practices. The
more you read, the more you learn. I’ve learned
a lot from reading papers, attending various
conferences, and listening to experts speak on
arc flash safety. One paper that recently crossed
my desk caught my attention. In this paper, it
stated that the new IEEE 1584-2018 still doesn’t
calculate conservatively or accurately enough
and additional correction factors (1.5-2.0X)
to incident energy should be applied to ensure
adequate PPE.[3] After reading this article, decide
for yourself whether additional safety factors or
multipliers are needed to keep your workers safe.
What I can conclude is that reported cases of
workers being seriously injured or killed by arc
flash are very low.[4] Granted, any serious injury
or death is a tragedy, and we all must continue
to strive for zero workplace injuries. However,
the focus on safety, arc flash analysis, use of
PPE, and education is keeping our workers
safer than ever before. Let’s keep up that good
work and continue to ensure our employees
are trained to identify hazards, determine their
severity, and select and use the proper PPE to
perform their tasks safely.
IMPACT OF 2018 CHANGES TO IEEE STD 1584, IEEE GUIDE FOR
PERFORMING ARC-FLASH HAZARD CALCULATIONS – PART 2
or less with an available short-circuit current less
than 2,000 A.
Equipment meeting new requirements that
were not included in the previous study should
now be included to ensure adequate PPE is
identified based on the calculated IE levels for
that equipment.
The biggest challenges of the new 2018 method
are in determining the enclosure size and bus
orientation of equipment. How are these
challenges being handled? Some clients choose
to use the worst case (horizontal electrode
orientation) for all equipment. However, if
the equipment does not contain horizontally
oriented electrodes, this may result in excessive
PPE requirements. Excessive levels of PPE
can cause worker fatigue and inability to
perform some tasks safely, which introduces
additional hazards. Some help and guidance is
provided in Annex G of IEEE 1584. Enclosure
dimensions, electrode gap, and orientation
can be standardized into a few categories, thus
simplifying data collection while retaining the
necessary level of accuracy.
Training and Education
As a final recommendation, one of the most
often overlooked components of safety is
education and training. Many companies
transmit communications and display posters
about the importance of worker safety but often
neglect to invest in the required safety education
and training for their workers. Old online
training materials used repeatedly will lose their
impact, and employees won’t pay attention to
the training. Keep the training materials fresh
and up-to-date and avoid repeating the same
videos year after year. Training should allow and
promote interaction, questions, and discussions.
One of the best ways to communicate key
objectives is through the use of case studies of
incidents and accidents.
Training and education is not a one-size-
fits-all solution. Employers must recognize
that the education and training provided to
one employee may be different than that for
another employee (based on responsibilities,
COVER STORY
[4] Gordon, L., J. Liechty, T. Matinez, E.
Stromberg, and J. Williams. “Electric
Injuries and Fatalities: Facts, Myths, and
Unknowns,” IEEE Paper No. ESW32.
Steve Park, PE, brings 40-plus years of
experience in the power system industry to
his position as Vertiv’s Director of Technical
Training. In this role, Steve oversees technical
training for Vertiv’s North America field
services including AC power products, DC
power products, thermal management
systems, monitoring, and independent testing services for High
Voltage Maintenance (HVM) and Electrical Reliability Services
(ERS). Much of his career and expertise is from various roles while
employed by HVM and ERS involving power system studies,
engineering and test reports, cable testing, forensic investigations,
test procedures/practices, and quality assurance. Steve gained a deep
understanding of the power systems industry during his career in
the U.S. Air Force, where he served 14 years on active-duty service
as a high-voltage lineman, electrical power distribution engineer,
and instructor of electrical engineering at the Air Force Institute
of Technology (AFIT). Steve earned his BSEE and MSEE from
Purdue University and an MBA from Indiana Wesleyan University.
Steve has been a registered Professional Engineer since 1992.
With this in mind, never forget that working on
energized equipment using PPE is a last resort!
When the decision is made that energized
work is required, you must have exhausted the
other five methods of risk control: elimination,
substitution, engineering controls, awareness,
and administrative controls. Working on
energized equipment and using PPE is at the
bottom of the list and is the least effective
means of ensuring worker safety.
REFERENCES
[1] IEEE. IEEE 1584-2002, IEEE Guide for
Performing Arc Flash Hazard Calculations,
New York, NY.
[2] National Fire Protection Association.
NFPA 70E, Standard for Electrical Safety in
the Workplace.
[3] Short, T. A., Eblen, M. L. “IEEE Standard
1584-2018 Predictions Compared With
Tests on Real-World Equipment,” IEEE
Industry Applications Magazine, January/
February 2022.
COVER STORY


48 • SUMMER 2022 CHECKLISTS AND EFFECTIVE JOB BRIEFINGS ARE IMPORTANT TO IMPROVING SAFETY
BY D. RAY CROW, DRC Consulting, Inc.
“People who are trying to change
the world need to use checklists.”
BUSINESSMAN AND AUTHOR GUY KAWASAKI
Checklists and effective job briefings are important to ensure hazards
that may exist when performing a task are addressed before starting the
job. In addition, job briefings are important to ensure people understand
their job roles and have a chance to speak up and recommend additional
safer work practices and make sure an action plan exists if things go
wrong. Job safety planning, job briefings, and the use of checklists before
starting a task are important to help prevent incidents and fatalities from
happening. People make mistakes. The use of job briefings and checklists
before the start of a job will help minimize the possibility of human error
when tasks are performed.[1][2]
FEATURE
CHECKLISTS AND
EFFECTIVE JOB
BRIEFINGS
ARE IMPORTANT TO
IMPROVING SAFETY
NETAWorld • 49CHECKLISTS AND EFFECTIVE JOB BRIEFINGS ARE IMPORTANT TO IMPROVING SAFETY
CHECKLISTS IMPROVE
HUMAN PERFORMANCE
“A checklist cannot fly a plane. Instead,
they provide reminders of only the most
critical and important steps.”
SURGEON AND AUTHOR ATUL GAWANDE
On October 30, 1935, an experimental
bomber known as the Flying Fortress (B-17)
crashed shortlyafter takeoff during a military
demonstration for the U.S. Army Air Corps at
Wright Airfield in Dayton, Ohio.
The cause of the incident was a pre-flight
failure to remove the gust locks that prevent
damage to the control surfaces of the airplane
while on the ground. The failure of the pilots
to complete this step before takeoff meant
they had no ability to control the plane once it
became airborne.[3]
FEATURE
PHOTO: © ISTOCKPHOTO.COM/PORTFOLIO/GONIN
Figure 1: B-17 Crash During Demonstration for U.S. Army Air Corps
(S
O
U
RC
E:
 W
W
W
.T
H
IS
D
AY
IN
AV
IA
TI
O
N
.C
O
M
/3
0-
O
C
TO
BE
R-
19
35
)
50 • SUMMER 2022
CHECKLISTS CREATE
ERROR-FREE SYSTEMS
Surviving pilots brainstormed how to prevent
the pre-flight requirements from ever being
missed again. The action taken by the
investigation team was to mandate the use of a
checklist that included pre-takeoff action items
for a pilot’s review.[4]
People can and do make mistakes, and the
use of checklists can prevent incidents from
happening. Checklists are a functional,
consistent method of combating human errors
before they occur. Checklists can be adapted
for use in a wide range of environments.
Aviation Checklists
Current Federal Aviation Regulations (FARs)[5]
mandate checklist use that “must be designed
so that flight crew members will not rely upon
memory for items to be checked.” Today, you
can’t take off or land in a commercial airplane
without a mandatory checklist being used by
pilots.
Checklists work to prevent an incident from
happening if a critical step does not pass the
requirements included in the checklist. Has
your flight ever been delayed or cancelled
due to items in the checklist not meeting all
requirements? If this did occur, were you glad
that a checklist was required before the flight
was allowed to takeoff?
NASA uses checklists for launching rockets into
space. Many launches have been cancelled due to
failure to meet the steps required in the checklist.
Checklists are widely used in the aircraft
industry and the U.S. Navy Submarine Service,
in critical maintenance facilities and hospital
operating rooms, and during the commissioning
of electrical projects. Use checklists to prevent
incidents from happening or to minimize the
results when unexpected events occur.
Surgical Checklists
Using checklists in hospitals during surgery
has been proven to prevent infections. Since
2008, bloodstream infections have decreased
by 44%, and surgical site infections have
decreased by 20%. Using checklists before
and during surgery has also cut complications
by 35% and deaths by 47%.[6] When catheters
are installed, the use of checklists has cut the
infection rate from 4% of cases to zero, saving
1,500 lives and nearly $200 million.[7]
Just OK Is Not OK
Training is not enough to ensure incidents will
not happen. When checklists are not used, the
most experienced and qualified people may
make mistakes.
Use checklists in your workplace. A good
checklist is precise, efficient, and easy to use
even in the most difficult situations. Checklists
not only offer the possibility of verification, but
also instill a discipline of higher performance.
Checklists can help ensure people follow the
required safety steps every time they perform a
specific task.
Checklists have proven to work best in
organizations that have a culture of safety
supported by organizational leaders who
prioritize safety in the workplace.[8]
USE CHECKLISTS FOR
ELECTRICAL TASKS
“No matter how expert you may be, well-
designed checklists can improve outcomes.”
AUTHOR AND ECONOMIST STEVEN LEVITT
Checklists have been proven to add safety for
personnel who perform electrical tasks.[9] They
can help prevent mistakes and omissions during
many electrical tasks. Checklists are a proven
method to help prevent qualified people from
skipping critical steps when completing tasks.
The use of checklists should be mandatory when
step-by-step procedures are required for safety.
Many mistakes have been prevented and lives
saved by the use of checklists that ensured steps
were not missed when tasks were performed.
FEATURE
CHECKLISTS AND EFFECTIVE JOB BRIEFINGS ARE IMPORTANT TO IMPROVING SAFETY
NETAWorld • 51
IMPROVE HUMAN
PERFORMANCE BY
ACTIVATING YOUR
LEADERSHIP
“Teamwork is the fuel that allows common
people to attain uncommon results.”
INDUSTRIALIST ANDREW CARNEGIE
Job safety planning, job briefings, and
checklists help prevent injuries and fatalities
from happening. They provide the opportunity
to think about and agree on the safe work
practices and PPE requirements to use for the
task to eliminate or minimize the risk to an
acceptable level prior to starting the job.[10][11]
Effective job briefings and a review of
existing checklists requires discussion and
communication. Ask open-ended questions
and get answers. Ensure everyone involved in
the task participates during the job briefing
and reviews the items included in the checklist.
Consider what might not be included in the
existing checklist. A best practice to improve
safety is to visit the job site before work starts
to look for hazards in the area that you may
not have considered.[12] Examples include an
FEATURE
energized overhead power line that exists in the
area where work is to take place or additional
people performing other tasks in the area where
you will be working.
Consider the possibility of language
barriers when job briefings are held. During
construction and other jobs, some people may
not understand what is being discussed. Use an
interpreter to resolve the issue.
Table 2: Items that Cause Incidents to Occur
Taking shortcuts
Being overconfident
Failure to pre-plan the work
Starting a task with incomplete instructions
Ignoring safety procedures
Mental distractions from work
Multitasking
Poor housekeeping
An effective job briefing should cover at least
the following topics:
• Hazards associated with the job
• Work procedures involved
• Special precautions, language issues
• Energy source controls
• Personal protective equipment (PPE)
requirements[13][14]
During the job briefing make sure everyone
answers the following questions:
• Do I thoroughly understand the job?
• Do I understand my role and everyone
else’s role in the job?
• Am I aware of all the hazards I may
possibly encounter during the job?
• Am I knowledgeable of all safety rules
and procedures applicable to this job?
• Do I have safeguards in place to protect
me from unexpected events?
CHECKLISTS AND EFFECTIVE JOB BRIEFINGS ARE IMPORTANT TO IMPROVING SAFETY
Table 1: Types of Electrical Checklists
Safety pre-task checklist
 Job hazard analysis (JHA)
 Safe work procedure (SWP)
Job briefing checklist
Requirements for an energized electrical work
permit (EEWP)
Required steps for a specific work practice
Requirements for standard operation procedures
(SOPs)
Specific switching procedure when changes to
your electrical power system are required
Substation project installation assessment
Substation inspection
Electrical control room inspection
Table 3: Actions You Can Take to Improve
Safety
Take immediate action when you identify potential
work hazards.
Control your personal workspace to maintain
safety.
Stop any work you think is unsafe.
Eliminate injuries by eliminating your unsafe acts.
Take actions to help prevent being hurt or in-
volved in an unsafe event.
REINFORCING THE
SAFETY CULTURE IN
YOUR ORGANIZATION
“Safety has to be everyone’s responsibility.
Everyone needs to know that they are
empowered to speak up if there’s an issue.”
NASA ASTRONAUT CAPTAIN SCOTT KELLY (RET.)
FEATURE
Make safety the number one priority in your
facility or company. Mandate job briefings
that include checklists before the start of jobs.
The job briefing should include shock risk
assessments and arc flash risk assessments.
Unsafework practices cause 91% of incidents
and injuries. In addition to the personal pain
of suffering an injury, incidents can result in
lost time, medical costs, equipment damage,
production loss, and legal costs. The risk
assessment procedure is designed to address
the potential for human error and its negative
consequences on people, processes, and the
work environment.
Shock Risk Assessment
The first choice in a shock risk assessment is
to eliminate the likelihood of occurrence
of injury. Determine whether additional
protective measures are required. For example,
wear rubber insulating gloves with leather
NETAWorld • 53CHECKLISTS AND EFFECTIVE JOB BRIEFINGS ARE IMPORTANT TO IMPROVING SAFETY
protectors and use insulating tools rated for the
voltage you could encounter if you accidentally
make contact with exposed energized electrical
conductors or circuit parts.
Arc Flash Risk Assessment
During the arc flash risk assessment, consider
the following issues:
• Design of the equipment as well as
its overcurrent protective devices and
operating times
• Electrical equipment operating condition
and maintenance
• Appropriate safety-related work practices
and PPE required for people within the
arc flash boundary
CONCLUSION
“Job briefings and checklists are the
most high-powered productive tools ever
discovered.”
AUTHOR AND SPEAKER BRIAN TRACY
An important feature in an electrical safety
program is the use of job briefings that include
checklists. Reinforcing important steps in safe
work practices through the use of job briefings
that include checklists will reduce incidents
and save lives. Ensure that job briefings include
shock as well as arc flash risk assessments..
Improve safety in your facility by including
these six steps:
 1. Create a culture that makes safety the
number one priority.
 2. Improve actions taken by management to
continually improve safety.
 3. Ensure that positive peer pressure to do
the right thing exists in your facility.
 4. Monitor actions taken by workers to
ensure they follow the safe work practices
outlined in your safety program and
training.
 5. Provide a good balance between leading
as well as lagging indicators in your safety
program.
 6. Perform a shock risk assessment and an arc-
flash risk assessment before starting work.
Using these steps will help drive the company
toward becoming an incident-free workplace.
REFERENCES
[1] Crow, Daryld Ray. “Checklists Save
Lives,” 2020 IEEE IAS Electrical Safety
Workshop (ESW2020-08), March 2020.
[2] Crow, Daryld Ray. “Effective Job
Briefings Improve Safety,” 2021
IEEE IAS Electrical Safety Workshop
(ESW2021-13), March 2021.
[3] “From the Ashes of the Model-299.”
Accessed at www.thisdayinaviation.
com/30-october-1935.
[4] “What the B17 Taught Us About
Checklists.” Accessed at What the B17
Taught Us About Checklists - Angle of
Attack (flyaoamedia.com).
[5] Code of Federal Regulations. Accessed at
eCFR :: 14 CFR 431.39 -- Mission rules,
procedures, contingency plans, and checklists.
[6] “Habitual Excellence in the Workplace
According to Paul O’Neill,” Pittsburgh
Post-Gazette. Accessed at ‘Habitual
excellence’: The Workplace According to
Paul O’Neill | Pittsburgh Post-Gazette.
May 13, 2012.
[7] Higgins, W.Y., and D.J. Boorman. “An
Analysis of the Effectiveness of Checklists
When Combined With Other Processes,
Methods, and Tools to Reduce Risk in
High Hazard Activities,” Boeing Technical
Journal 2016.
[8] Haynes A., Gawande A. “A Surgical
Safety Checklist to Reduce Morbidity
and Mortality in a Global Population,”
New England Journal of Medicine
360(5)491-499 (January 2009).
Doi:10.1056/NEJMas0810119.
PMID19144931.
[9] Gawande, Atul. The Checklist Manifesto.
Picador, New York, 2009 ISBN 978-0-
312-43000-9.
[10] National Fire Protection Association.
NFPA 70E, Standard for Electrical Safety
in the Workplace.
FEATURE
FEATURE
graduated from the University of Houston with a BSEE. After
graduation, he worked for Alcoa providing global engineering
support on the design, installation, and operation of power and
rectifier systems and electrical safety. Ray was a team leader for
writing multiple Alcoa electrical standards including electrical
safe work practice standards and training and was responsible
for providing internal electrical safety audits of Alcoa facilities.
After retiring from Alcoa, he worked for Fluor Global Services
and Duke Energy as a Principal Technical Specialist providing
design and consulting engineering for creating electrical safety
standards for companies, and providing safe work practice
training programs, assessments/audits of facilities, and plant
power distribution systems. Ray is a Life Senior Member
of IEEE, a principal member of the NFPA 70E Technical
Committee, Secretary of IEEE Std. P1584.1, Technical
Editor and Secretary of IEEE Std. P1814, Chair of PCIC
Working Group IEEE Std. 463, and was Secretary of IEEE
Std. 1584. In 2010, Ray received the IEEE/PCIC Electrical
Safety Excellence Award; in 2017, he received the IEEE/ESW
Outstanding Service Award. He has co-authored and presented
technical papers and tutorials for a number of IEEE IAS PCIC
conferences, IEEE IAS Pulp & Paper conferences, IEEE IAS
Electrical Safety Workshop conferences, and NETA’s PowerTest
conference.
[11] Occupational Safety and Health
Administration. OSHA 29 CFR Subpart
R 1910.269, Electric Power Generation,
Transmission, and Distribution.
[12] Forck, Mathew. “Four Key Steps to
Conducting an Effective Job Briefing,”
T&D World, July 1, 2019.
[13] Hanford Mission Support Contract.
“Conducting Pre-Task Job Briefings and
Post-Job Briefings,” April 28, 2011.
[14] Setcorret, LLC. WP0001-2015,
Job Briefings. Accessed at
JobBriefingsWorkPracticeExample.pdf
(setcorrect.com).
Daryld Ray Crow  is presently Owner
and Principal Technical Consultant for
DRC Consulting Inc., where he performs
consulting work for electrical safe work
practice standards, assessments/audits,
electrical safe work practice training,
and electrical engineering projects.  Ray
6605 W. WT Harris Blvd. Suite F • Charlotte NC 28269 | 13 Jenkins Court • Mauldin, SC 29662 | 9481 Industrial Center Drive, Suite 5 • Ladson, SC 29456
704.573.0420 • 844-383-8617 • 704.573.3693 (fax) • www.powerproducts.biz
Acceptance and Maintenance Testing
Commissioning
Circuit Breaker Repair and Retrofit
Infrared Scanning
MV Cable Terminations and Testing
Commissioning and Load Bank Testing
of UPS, Generators, and ATS
RETROFITTED BREAKER
etiprecision.com/NETA | 410-857-1880 | info@etiprecision.com
ETI Precision | 8430 Spires Way, Suite A | Frederick, MD 21701
ETI’s Newest Circuit
Breaker Test Set:
PI-5000 Gen2
The most rugged & reliable
portable high-current circuit
breaker tester available
BUILT FOR FIELD SERVICE
Modular design provides unparalleled
output capabilities in a portable unit.
MAXIMIZING TESTING FLEXIBILITY
Two-piece modular design provides
unequaled portability in environments
that are diff icult to access, such as
rooftops or basements.
INTUITIVE & EASY TO USE
Simple user interface of the proven MAC-21
controller, detachable interconnect pieces,
and Cam-Lok mains connections make the
PI-5000 Gen2 easy to set up, use, and
transport to the next job.
NEW SAFETY ENHANCEMENTS
Upgrades and improvements include protecting
your equipment and technicians from accidental
mains over-voltage situations.
ACHIEVE PEAK OUTPUT OF 60,000A
Continuous output of 4,000A and peak output
of 60,000A allows eff icient testing for a wide
variety of circuit breakers including draw-out
and molded-case.
Trusted by professionals
nationwide and shipping now.
Contact ETI Precision for a
PI-5000 Gen2 quote today.
56 • SUMMER 2022 MENTORSHIP IS CRITICAL IN THE ELECTRICAL SECTOR
BY MIKE DOHERTY, eHazard
Mentoring has been a critical and foundational component in the
electrical sector since its beginning.The basic tenants of electrical
tradesperson apprenticeships and electrical engineers in training has
always been coaching and mentoring by those with the interpersonal
skills, relevant expertise, and knowledge to be able to pass it on.
The electrical sector has always taken
particularly great pride in emphasizing and
teaching the safety requirements involved
in electrical work. The overall probability of
serious electrical incidents across all sectors is
generally low, but the physical consequences of
shock, electrocution, and/or arc-flash incidents
can be staggeringly high. The social, morale,
and economic costs are all potentially very high
as well.
RESEARCH AND STATISTICS
A 2010 study by Liberty Mutual Research
Institute for Safety found:
A study by a major insurance underwriter
reported that the second most expensive workers’
compensation claim was due to electrical
injuries.[1]
In 2022 and going forward, electrical sector
demographics will continue to change rapidly.
The baby boomer generation will be leaving the
workforce in droves by the end of the current
decade — and it’s already started.
In the United States, the Bureau of Labor
Statistics states in its Employment Projections —
2020-2030 Summary:
The labor force is expected to increase by 8.9
million, from 160.7 million in 2020 to 169.6
million in 2030. The labor force participation
rate is projected to decline, from 61.7 percent
MENTORSHIP
IS CRITICAL IN
THE ELECTRICAL
SECTOR
FEATURE
NETAWorld • 57MENTORSHIP IS CRITICAL IN THE ELECTRICAL SECTOR
in 2020 to 60.4 percent in 2030. The decline
in labor force participation is due to the aging
of the baby-boom generation, a continuation of
the declining trend in men’s participation, and a
slight decline in women’s participation. By 2030,
all baby boomers will be at least 65 years old.[2]
More specifically, the BLS Employment Outlook
Handbook notes:
Employment of electricians is projected to grow
9 percent from 2020 to 2030, about as fast as
the average for all occupations. About 84,700
openings for electricians are projected each year, on
average, over the decade. Many of those openings
are expected to result from the need to replace
workers who transfer to different occupations or
exit the labor force, such as to retire.[3]
And in Canada, the Province of Ontario is
offering free training and paid apprenticeships
for electricians. The news release states:
Data suggest the need to replace retiring workers
is elevated in the skilled trades. In 2016, nearly 1
in 3 journeypersons were aged 55 years or older.
Between July 2021 and September 2021, there
were 338,835 job vacancies (unfilled jobs) in
Ontario. About 8% (25,495) of all vacancies in
Ontario were in the construction sector.[4]
PASSING ON THE
EXPERIENCE
It is extraordinarily clear that the continuing
electrification of society is essential for ongoing
prosperity and success for all concerned.
Highly skilled electrical sector tradespeople,
technicians, technologists, and engineers have
been and will continue to be required. With
so many of these extremely skilled people soon
to leave the workforce in the next few years, it
is essential that the culture of electrical safety
and high-end technical excellence is passed on
to the outstanding workforce that is already in
place or starting out.
But time to do so is definitely running out.
Leaders in the electrical sector must step up to
ensure that their existing safety and technical
best practices are sustainable and will be in
place even after they move on. Ensuring
sustainability for best practices after present
leadership is gone is indicative of the very finest
management qualities. Outstanding formal
FEATURE
58 • SUMMER 2022
mentoring programs within the electrical
sector need to be developed and executed in
an accountable and due-diligent manner.
The costs to the electrical safety culture and,
in fact, to the electrical infrastructure if great
mentoring programs are not put in place will
be very difficult to recover from.
Those with decades of experience are generally
no smarter than those who are just starting
out. It is most obvious that the only way to
gain experience is to put in the time and effort
that experience facilitates — there is no other
way. Passing on the hard-won wisdom that was
realized over the course of their working life by
those willing to share is one of the main goals.
MENTOR REQUIREMENTS
What are the requirements to be an exceptional
mentor? The mentor needs to be an expert and
someone who has walked the talk. Ideally,
they will not be too far removed from the
current thinking of those they would work
with. It is imperative to understand the
potential differences between age groups and
demographics to ensure there is a potential
fit. Mentors need to be enthusiastic and, in
particular, bring real clarity to the interactions
they will have. The antonyms to clarity are
murkiness and vagueness. Mentors who bring
anything other than authentic clarity to the
discussions will not bring value.
These are professional relationships that need
to be respectful, honest, truthful, and caring.
No one has ever erected a monument to a
critic, and mentors must be able to listen with
real understanding. They must also be willing
to not impose their own beliefs too strongly.
They must be able to relate to the person they
are working with and put themselves in that
person’s shoes.
Mentors need to enjoy and be invested in the
success of others. In particular, along with great
listening skills, they must be exceptionally good
at receiving and giving feedback. Ideally, a
great mentor was a mentee themselves at one
time. The absolute best coaches in the sporting
world will tell you that their coaching style is
a compilation of a few great coaches that they
played for themselves. Those experiences along
with their own unique styles and mannerisms
will make for a terrific mentoring foundation.
A mentor is a person who provides the means,
counseling, help, and feedback you need to
flourish in your career, so it is very important
for the mentor to select people to work with
who are genuinely interested in accessing his or
her experience and knowledge.
MENTOR QUESTIONS
W. Edwards Deming said: “If you do not know
how to ask the right question, you discover nothing.”
Insightful questions should be used by mentors
to obtain successful outcomes with those they
work with. Asking exploratory questions in a
respectful and caring manner at the beginning
of the potential and ongoing relationship can
put the mentee at ease and let them know you
are there to help, guide, and assist. Mentor
questions can explore why the person is doing
what they’re doing:
• What do you really want to do and be in
the electrical sector? What is it that drives
your passion? Do you want to be a leader
in the electrical sector and, if so, what
would you like to be known for?
• Do you have a goal in mind regarding
where you want to go? How and when
are you going to get there? Are you
curious to be a lifelong learner and to
try things that you initially are not good
at, or do you prefer to do things you’re
already good at?
• What are you really good at and consider
to be some of your primary strengths to
get to your goals? What have you always
been outstanding at that made you stand
out from the rest?
• What are you currently not doing well
that is blocking you from getting to your
objectives? If you were to do a critical
assessment of yourself, what three things
are barriers, vulnerabilities, or roadblocks
to you in the electrical sector? What is it
that has been slowing you down — or is
MENTORSHIP IS CRITICAL IN THE ELECTRICAL SECTOR
FEATURE
NETAWorld • 59
slowing you down presently? Have you
had constructive feedback from others
regarding some of these barriers in school
or personally and, if so, what was it?• What outstanding qualities,
characteristics, and attributes do you
bring specifically to the electrical sector?
• Are you a great listener? Are
you empathetic? Are you a good
communicator? Do you have an
outstanding work ethic? What is the one
thing you do better than anybody else
and why?
• What are you going to do to constantly
improve on your journey through the
electrical sector? What are your priorities?
Do you believe these are the right priorities?
• Is electrical safety in particular embedded
in your DNA?
• Very important: How can I support you
and where do you think you need the
most assistance?
MENTEE QUESTIONS
It is also critical for the mentee to ask great
questions of the mentor, and it is up to the
mentor to facilitate and guide those questions
if necessary to ensure they have a good match.
• What led you to the education you
currently have? Was it well-planned or
MENTORSHIP IS CRITICAL IN THE ELECTRICAL SECTOR
did it just happen? What was the most
important thing you learned at school?
• If you could have done anything
differently in your education, what
would it have been?
• What was your very first job as a
student, and what was your very first
full-time job after your formal education
was done?
• Who are the three most impactful
people you have worked with and why?
Who are the three most impactful
managers you have worked with?
• How long has electrical safety been a
vital part of your personal culture? Who
has had the most influence on the things
you believe specifically about electrical
safety? Have you had or do you know of
any significant electrical incidents during
your working career? How has that
impacted you?
• When did you first hear about NFPA
70E or CSA Z462? How about NESC
(IEEE C2) or CAN/ULC–S801?
What do you believe is the single most
important concept in these standards?
• How will this mentoring relationship be a
benefit to me going forward?
• Did you have mentors yourself, and what
did you learn? How have they inspired you?
• What’s the very best advice you can give me?
FEATURE
most valuable things a mentor can provide is
exceptional networking opportunities. After
many years in the electrical sector, they will
typically have many connections that can
be invaluable to those starting out. Mentors
characteristically are highly respected, and
when they recommend a mentee to an
important connection, the possibilities can be
remarkable. In fact, as we all know, networking
usually has far more to do with career success
than many other things. Great mentors can
ensure great networking prospects.
It is important for mentees to let the mentor know
what it is they require. It is also critical to be on
time, be prepared, and be truly professional. They
must follow up with ideas, recommendations,
action items, and corrective action plans.
CONCLUSION
Mentoring in the electrical sector will be critical
for the rest of this decade in particular. It will
build skills, decrease employee turnover, and
• What is your own individual style?
• What are the three specific values you
believe are the most important within the
electrical sector?
• Are you an exceptional listener?
• What are three or four of your favorite
books and why?
• If you could only tell me one electrical
safety story, what would it be?
BENEFITS
Mentoring is intended to be extremely
beneficial to both parties. It should be equal
parts insight, motivation, and inspiration. To
be successful, the mentor and the mentee must
be sounding boards for each other. To ensure a
great relationship, they must honestly listen to
each other’s concerns and be able to brainstorm
any suggestions with tremendous clarity.
Mentors must continue to ask thought-
provoking questions, steer the relationship,
and ensure successful outcomes. One of the
FEATURE
certainly increase loyalty. High-end formal
mentoring programs can also significantly
improve retention rates for high-quality
electricians, technicians, technologists, and
engineers by building stronger company loyalty,
safety, and technical excellence.
REFERENCES
[1] “Work Related Electrical Injuries: Study
Sparks New Insights,” Liberty Mutual
Research Institute for Safety, Vol. 13, No. 3,
Winter 2010.
[2] Bureau of Labor Statistics. Employment
Projections —2020-2030 Summary. Available
at www.bls.gov/news.release/pdf/ecopro.pdf.
[3] Bureau of Labor Statistics, U.S.
Department of Labor. Occupational
Outlook Handbook, Electricians. Available
at www.bls.gov/ooh/construction-and-
extraction/electricians.htm.
[4] Ontario Newsroom. “Ontario Invests in
Electrical Training and Apprenticeships
Programs Across Province.” Available at
https://news.ontario.ca/en/release/1001770/
ontario-invests-in-electrical-training-and-
apprenticeships-programs-across-province.
Mike Doherty is an independent Electrical
Safety Consultant and training contractor
for e-Hazard and is President/Owner of Blue
Arc Electrical Safety Technologies Inc. Mike
has over 47 years of industrial and electrical
utility experience as an instrumentation
technician, licensed electrician, training
professional, electrical utility safety professional, and electrical
safety consultant. He is a Senior Member of IEEE and IEEE
(PCIC) Emeritus; Chair of ULC CAN/ULC-S801-14,
Standard on Electric Utility Workplace Electrical Safety
for Generation, Transmission and Distribution; and Past
Chair of the Association of Electrical Utility Safety Professionals
(AEUSP) in 2018 and 2019. He was Chair of CSA Z462
Technical Committee Workplace Electrical Safety Canada from
March 2006–December 2018 and continues to serve as a Z462
Technical Committee voting member on the current edition. Mike
was the 2013 recipient of the IEEE IAS Petroleum and Chemical
Industry Committee (PCIC) Electrical Safety Excellence Award,
the 2017 Best of Electrical Safety Technical Presentation Award
at NETA’s PowerTest Conference, and the 2019 IEEE Electrical
Safety Workshops Outstanding Service Award.
Original
DISCOVER & LOCATE LEAKAGE CURRENT
• Check for leakage current and locate
insulation breakdowns on live circuits
• Measures Low AC currents
(6mA, 60mA, and 600mA ranges)
• Critical noise shielding jaw allows for
high sensitivity of the probe resolution
(1µA, 10µA, and 100µA)
• Can be used as a standard clamp-on
meter measuring 60Arms, VAC
and VDC ranges, resistance and
continuity with a buzzer
• HOLD feature freezes value
and much more...
www.aemc.com
Trms Clamp-on Leakage Current Meter Model 566
Model 566
sales@aemc.com
Accommodates most
common conductors up to
.91” (23mm) in diameter
Contact Us Today: (800) 343-1391
FEATURE
62 • SUMMER 2022 BATTERY SAFETY
BY ANDREW SAGL, Megger
It’s happened to nearly everyone. You go to use a simple electrical
device…a flashlight, a voltmeter, a TV remote, or a child’s toy…and
the battery is dead. It has become exhausted and must be replaced.
Or worse, you open the device to find that the battery has corroded,
possibly damaging or even destroying the contacts. In some critical
respects, essentially the same thing can happen to the largest standby
battery system that might be providing backup support for a
substation, a computer room, a hospital, a manufacturing process —
anywhere uninterruptible power is essential.
Standby battery banks can corrode, short out,
lose capacity through unintentional grounds
or aging, and fall victim to a host of other
breakdowns and failures. They can also be victim
to an out-of-sight, out-of-mind mentality. Most
electrical functions are readily observable: The
lights are on, motors are running, the building
is heated. But standby batteries are tucked away
out of sight and often forgotten. That is, until
there’s an event.
When a utility experiences a fault, the battery
bank should immediately come on line and
provide alternate power until the utility comes
back on line. Failure to doso can be nothing
short of catastrophic. Switchgear can fail to
operate to open faults. Buildings can catch fire,
production lines stall and sacrifice materials,
computer rooms go off line and lose data, and
hospital patients on life support could die.
To prevent such tragedies, standby battery banks
must be tested regularly for their continued
ability to come on line and deliver full power
whenever utility service is interrupted.
TESTING BATTERY STRINGS
A battery string is tested with a battery impedance
tester that includes a DC current source that
injects a test current through the string, then
measures the voltage drop and calculates the
impedance. An array of problems, including
terminal corrosion, plate sulphation and
corrosion, dry-out, and many more can increase
the impedance to inhibit or prevent current
propagation and take the battery out of operation.
Many battery banks are arranged in tiers of
parallel strings. This can increase the supplied
current, capacity, or reliability of the strings.
Parallel strings allow the current delivery
BATTERY
SAFETY
FEATURE
NETAWorld • 63BATTERY SAFETY
capability to be doubled. They also increase
capacity, allowing the load to be supported for
a longer period.
Flooded lead-acid batteries, which are usually
used in series strings, can fail in a shorted
mode. They are not technically shorted and will
still allow current to pass through them. They
just aren’t making a contribution to the output,
but the string still remains in service.
Sealed lead acid batteries (VRLA), which are
typically used in parallel strings, tend to fail
in open mode. They are not literally open,
but current will not readily pass through
them. Failure of one battery will stop current
propagation in that string, but the parallel
strings will still permit current flow and
maintain the backup function. Lithium
ion batteries use a management system that
monitors safety parameters and will open the
battery in case of a hazard. Parallel strings are
recommended. If one cell opens, current can
still pass through the other string(s).
Accordingly, parallel strings have notable
advantages in overcoming failed cells and still
being able to provide critical backup power
FEATURE
PHOTO: © ISTOCKPHOTO.COM/PORTFOLIO/TONGPATONG
Figure 1: Series String
64 • SUMMER 2022
to avert emergencies. But their arrangement
introduces a fundamental testing complication.
When testing a series string, test current has
only one path — through the string. But when
testing a parallel string, test current has multiple
paths depending on the number of strings.
A battery tester measures the total current it is
able to inject, but it looks at the voltage drop
between the potential probes. In a series string,
current has a single path and remains constant,
giving an accurate measurement of impedance
across the cell (Figure 1).
In a parallel string, current is divided between
the strings. The impedance tester measures the
total current through the string but only the
voltage drop between the potential probes,
BATTERY SAFETY
FEATURE
Figure 2: Parallel String
Figure 3: Parallel String Sample Calculation
NETAWorld • 65
thereby calculating an inaccurate measurement
of cell impedance based on more current than is
actually traveling through the tested cell (Figure
2). A bad cell can therefore appear acceptable.
As an example, suppose the battery consisted
of two tiers of five cells, each with 100  mΩ
impedance (Figure 3). The charger is applying
half an amp. The impedance tester measures
0.0375 V across an individual cell. Since the
string is balanced, only 0.25 A is flowing
through the tested cell. The true measurement
for this cell’s impedance would be 150  mΩ.
However, the impedance tester measures the
total current propagating through the entire
string, which is 0.5 A. It calculates and displays
0.75 mΩ — half the actual value. It is obvious
that a deteriorated cell could test good under
these circumstances, potentially rendering the
string off line if called into service.
STANDARDS &
TECHNOLOGY
Traditionally, this issue was addressed by
IEEE Std. 1188, Recommended Practice for
Maintenance, Testing, and Replacement of
Valve-Regulated Lead-Acid (VRLA) Batteries
BATTERY SAFETY
FEATURE
for Stationary Applications. This standard
calls for taking the string off line and
segmenting the parallel strings. This is a lot
of work! Fortunately, modern technological
improvements have produced a convenient
methodology that allows the testing and
troubleshooting of parallel strings without
segmentation and without taking them off line.
The technological breakthrough that augments
this process is the split-core current clamp,
which appeared in the mid- to late-20th century.
The current clamp can intercept and measure
escape current that is propagating through the
parallel strings, and the measurement circuit
in the impedance tester can deduct this from
the calculation. The impedance of the specific
cell being tested is now calculated against the
specific current passing through it and not the
total current being injected by the impedance
tester (Figure 4). The measurement is correct
for the specific cell being tested, and faulty
high-impedance cells will not elude detection.
BATTERY FAILURE
Routine preventive maintenance of standby
batteries is easy to bypass because they aren’t
Figure 4: Parallel String with Current Clamp
66 • SUMMER 2022
visibly active on a daily basis like computers,
lighting, and machinery. But neglecting
maintenance can come at a high price and all at
once in the form of catastrophic and potentially
lethal failure.
Internal chemical decomposition can emit
gases that cause the battery to swell and
explode, releasing dangerous fumes. Failure
of backup power to utility circuit breakers
and relays can allow fault currents to wreak
enormous damage. VRLA batteries can emit
hydrogen as part of their normal operation. If
left unattended in a poorly ventilated, poorly
temperature-regulated battery room, hydrogen
gas can accumulate and ignite, producing an
explosion and massive structural damage.
And although not physically destructive or
threatening, failure of backup power to a
computer room can result in a crippling loss
of vital data.
BATTERY SAFETY
FEATURE
Finally, National Electric Reliability Council
(NERC) requirements have become mandatory
and enforceable for all bulk power system
owners, users, and operators in the United
States. Founded in 1968 in response to
devastating blackouts, NERC requirements
for stationary battery backup strings require
battery terminal connection resistance and
intercell connection resistance tests to be
performed and documented.
CONCLUSION
Modern technology has produced instruments
that make the seemingly daunting task of
testing the readiness and reliability of large,
multi-tiered battery banks an integral part
of your preventive/predictive maintenance
program. This can be accomplished without
taking the system off line. Data analysis and
storage software enables complete and detailed
record keeping for effective continuity of
the program and presentation for NERC
inspection. A comparatively small investment
of time and effort in a maintenance program
with a full-quality battery impedance tester can
prevent and save the cost of prohibitive damage
and outages in the electrical system.
Andrew Sagl is the Power Quality
and Battery Testing Product Manager
at Megger. He has been with Megger
for 20 years and is a specialist in power
quality and battery testing technology and
application. Andy develops and supports
power quality equipment in addition to
writing power quality and battery publications and delivering
training and seminar courses. He has a degree in electronics
and is a member of the IEEE Power Engineering Society and
Battery Standards Group. In the past, Andy hasspecialized
in nano-motor technology as well as military sub-systems and
weapons guidance systems.
Battery Destroyed by Thermal Runaway
800.331.2002 | PotomacTesting.com
POWER THROUGH WITH
CONFIDENCE
MAKE A REAL POWER MOVE...
PARTNER WITH MID-ATLANTIC’S PREMIER
PROVIDER OF ELECTRICAL TESTING,
ENGINEERING AND FIELD SERVICES.
Since 1985
68 • SUMMER 2022 IMPROVED METHOD FOR SAFE TIMING MEASUREMENT OF GIS CIRCUIT BREAKERS
BY RADENKO OSTOJIC, ADNAN SECIC, BUDO MILOVIC,
and KERIM OBARCANIN, DV Power
In gas-insulated substations (GIS), the high-voltage elements, including
conductors, circuit breaker interrupters, switches, current transformers
(CTs), and voltage transformers, are encapsulated in SF6 gas inside
grounded metal enclosures.[1] For that reason, direct access to circuit
breaker (CB) main circuit terminals for testing purposes is not possible.
The inaccessibility of main circuit terminals
requires several actions to be taken before
conducting the measurements. One of these
actions requires disconnecting the ground
connection (detachable shunt that connects the
main circuit to the grounded enclosure during
testing) from one side of the breaker. This
action reduces the safety of the test procedure.
According to regulations and demands
described in IEEE Std. 510-1983[2] and
Ostojic and Milovic,[3] all conducting points
in the substation must be grounded during
testing and maintenance. In the previously
published paper by Ostojic and Secic[4] on this
topic, we presented a novel method for testing
high-voltage (HV) circuit breakers in GIS
FEATURE
IMPROVED METHOD FOR SAFE
TIMING MEASUREMENT OF
GIS CIRCUIT
BREAKERS
NETAWorld • 69IMPROVED METHOD FOR SAFE TIMING MEASUREMENT OF GIS CIRCUIT BREAKERS
substations without the need to remove the
ground connection. This new method is based
on injecting high DC current through the
parallel connection of the grounding path and
main circuit, as well as measuring the response
signals on the CT’s secondary.
This method, however, is not applicable for GIS
configurations where the CT is not included
in the measurement circuit between the
maintenance grounding switches. It is also not
applicable for single-pole controlled GIS circuit
breakers (with three separated enclosures)
with very-low grounding path and enclosure
resistance (≤ 50–60 µΩ). Consequently, we
propose an improved GIS test method based
on the test procedure previously described in
Ostojic and Secic.[4]
GENERAL PROBLEM
IDENTIFICATION
To measure operating times [opening time
(O), closing time (C), open-close time (O-
C), close-open time (C-O), etc.] on the CB
main circuit in the GIS substation with the
conventional testing method, the CB main
contact terminals must be accessed through the
maintenance switches (Figure 1). By removing
or disconnecting the detachable shunt, one side
of the breaker is disconnected from the ground,
which enables measurements without removing
SF6 gas or opening the enclosure. However, the
procedure to remove this shunt is unsafe, time-
consuming, often impractical, and as such, is
undesirable for test personnel in the utilities.
[4] Furthermore, some GIS circuit breakers do
not have purpose-built detachable shunts and
FEATURE
PHOTO: © ISTOCKPHOTO.COM/PORTFOLIO/PIXHOUSE
70 • SUMMER 2022
test terminals that are isolated from the GIS
enclosure.[5]
If the detachable shunt is not removed or
disconnected, a parallel conducting circuit to
the one consisting of the tested main circuit
path is formed. The resistance of this parallel
circuit consists of the resistance of the GIS
enclosure and the grounding itself, and it is
often comparable to or even lower than the
resistance of the main circuit.
To experimentally verify this claim, a high-
precision micrometer with a test current of
500  A was used to measure GIS enclosure
resistance on several GIS substations. The
lowest measured value reached was 20 µΩ.
This prevents a conventional CB timing
measuring system from being able to deliver
reliable results.
EXISTING METHOD
SHORTCOMINGS
The test method proposed in Ostojic and
Secic[4] is based on the injection of the high
DC current in parallel through the main circuit
and GIS enclosure of all three poles and the
simultaneous measurement of the response
signals on the secondary of the CT during the
circuit breaker operation. One power source
must be connected between two marked access
points for testing (Figure 1) where the main
circuit is accessed through the maintenance
grounding switches. This power source is a
voltage-controlled DC current source with a
high current output (up to 500 A), based on
state-of-the-art power electronics converters.
Current transformers are an essential part of the
HV GIS substation. One (primary) terminal of
these elements is located in the pressurized gas
area, while the secondary terminal is accessible
in the auxiliary circuits.[6]-[8] These accessible
CT secondary terminals can be used for
measuring operation time in HV GIS circuit
breakers. The measuring instrument should
record either voltage or current on the CT
secondary; based on this, the instant of the CB
contacts touch or separation can be detected.
This method is successfully applied to GIS
circuit breakers where the CT is available
between test access points (grounding switch
terminals) as shown in Figure 1a, even if the
GIS switchgear does not have detachable
shunts and test terminals. Another approach
to this problem, described in Renaudin and
FEATURE
GIS enclosure
GIS enclosure
CB main contacts
Current
transformer
Maintenance
switches
Detachable shunts
Access points for testing
Parallel circuit through the ground
Parallel circuit
through the GIS
enclosure
GIS enclosure
GIS enclosure
CB main contacts
Current
transformer
Maintenance
switches
Detachable shunts
Access points for testing
Parallel circuit through the ground
(a) (b)
Figure 1: Electric Diagram of GIS CB, CTs Within (a) and Outside (b) Earthing Switches Circuit
IMPROVED METHOD FOR SAFE TIMING MEASUREMENT OF GIS CIRCUIT BREAKERS
NETAWorld • 71
Nenning,[9] is based on the usage of a Rogowski
coil to measure the current variation in the
ground conductor or the breaker path over
time.
However, the test method described in
Renaudin and Nenning[9] is not applicable in
the case when the tested circuit breaker does
not include the detachable shunts since there
is a permanent parallel connection across the
enclosure to the main circuit. The Rogowski
coil, essential for the current variation
measurement for this test method, cannot be
installed on such a circuit breaker.
For the method described in Ostojic and
Secic,[4] the first limitation is related to the GIS
configurations where the current transformer
cannot be included in the measurement circuit
(as shown in Figure 1b). In this case, there are
no response signals on the secondary of CT,
based on which a change in the main contact
state is detected.
Another challenge for Ostojic and Secic[4] is
related to some single-pole operated GIS circuit
breakers (each pole has its enclosure) with very-
low resistances of the pole’s enclosures (lower than
50–60  µΩ). Our experimental results showed
that a total current of 500  A, when divided
into three current paths (poles), is not always
enough to get a measurable response signal at the
secondary of CT. For example, if the resistance
FEATURE
of the GIS enclosure and the grounding path
is about 30 µΩ and the resistance of the main
arcing contact is about 1 mΩ, only about 5 A of
the total 166 A (one-third of 500 A) will initially
flow through the main circuit.
For CTs with high transmission ratios, e.g.
4,000:5, the value of the secondary current
will be around 5–6 mA, which can be highly
affected by external or measurement noise.
This again can make the circuit breaker timing
measurement results unreliable. The solutionANY PRODUCT
OR SERVICE REFERENCED OR ADVERTISED HEREIN FOR ANY INJURIES OR
DAMAGES OF ANY KIND WHATSOEVER, INCLUDING, BUT NOT LIMITED TO
ANY CONSEQUENTIAL, PUNITIVE, SPECIAL, INCIDENTAL, DIRECT OR INDIRECT
DAMAGES. NETA FURTHER DISCLAIMS ANY AND ALL WARRANTIES, EXPRESS
OF IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF
FITNESS FOR A PARTICULAR PURPOSE.
ELECTRICAL TESTING SHALL BE PERFORMED ONLY BY TRAINED ELECTRICAL
PERSONNEL AND SHALL BE SUPERVISED BY NETA CERTIFIED TECHNICIANS/
LEVEL III OR IV OR BY NICET CERTIFIED TECHNICIANS IN ELECTRICAL TESTING
TECHNOLOGY/LEVEL III OR IV. FAILURE TO ADHERE TO ADEQUATE TRAINING,
SAFETY REQUIREMENTS, AND APPLICABLE PROCEDURES MAY RESULT IN LOSS
OF PRODUCTION, CATASTROPHIC EQUIPMENT FAILURE, SERIOUS INJURY
OR DEATH.
ISSN 2167-3594 NETA WORLD JOURNAL PRINT
ISSN 2167-3586 NETA WORLD JOURNAL ONLINE
We are Your
Protective
Relay Solution
Largest inventory of protective
relays in the country
Dedicated group of 8 relay
specialists
Upgrade support
All All relays are supplied in
like-new condition, tested, and
with a 1-year warranty
79 Main Street, Seymour CT 06483
sertecrelays.net
1-800-521-0197
PRESENT
1945
P
R
O
T
E
C
T
IV
E
 R
E
L
A
Y
S
 T
H
R
O
U
G
H
 T
H
E
 Y
E
A
R
S
NETAWorld • 7
Summer is in full swing across the country, and I want to take some time to
focus on safety. You’ll find many of our articles in this edition of NETA World
revolve around some aspect of safety. Our cover story continues the discussion of
the 2018 changes to the arc flash calculation process in IEEE 1584. (Editor’s
note: Catch up on Part 1 in the Spring 2022 edition of NETA World).
I particularly want to focus my message on driving. Many times, we’re very focused on the electrical
hazards associated with the jobs we do, and rightly so. However, we often forget about some of
the other hazards that can sometimes be taken for granted.
For instance, perhaps the most dangerous thing each of us does every single day is drive to and
from our place of work. This has been minimized to some extent for office staff working
remotely during COVID, but has never changed for our technicians and engineers in the field.
NHTSA reported that 39,000 people were killed in car accidents in 2020. Compare that to 400
fatalities per year due to high-voltage electrical injuries reported by the NIH.
We’re constantly worried about getting to our jobsite on time, or maybe we’re running behind
or in a hurry to get prepared for the job. Then we’re anxious to get home or back to the
hotel after a hard day’s work. And especially during this era of technology, there are so many
distractions. The one that is possibly the most distracting is the cell phone.
I know these are things everyone already knows, but it’s good to remind everyone of this particular
hazard that exists every single day, on work as well as personal time.
Just a few tips and reminders for safe driving:
• Put your phone away when driving.
• Don’t eat and drive.
• Inspect your vehicle before use.
• Don’t drive fatigued.
• Practice defensive driving techniques.
• Slow down.
We work in a very dangerous industry, but remember that electrical hazards are just
one of many dangers that exist in the daily life of a field technician and engineer.
Plan ahead, and always put safety first!
Eric Beckman, PE, President
InterNational Electrical Testing Association
PRESIDENT’S DESK
PRESIDENT’S DESK
A SAFETY REMINDER
8 • SUMMER 2022 MOSE RAMIEH III: STAY INVOLVED TO STAY RELEVANT
Mose Ramieh III says his path to success in the electrical testing industry
has been “quite a road,” and his long list hits “just the high points.” A
former Navy man, Texas Longhorn, vlogger, CrossFit enthusiast, and
slow-cigar-smoking champion, Mose has been in the electrical testing
industry for 24 years. Over the years, he has held positions at four
companies in roles ranging from field service technician, operations, sales,
business development, and company owner.
Closing in on 25 years in the industry, this Level 4 NETA Technician
shares his thoughts on how to make the most of your own road to success.
NW: Please share your journey on how
you got to the job you currently hold. How
long have you been in the field; how did you
get started? What attracted you to electrical
testing?
Ramieh: My entry into the electrical testing
business began in November 1996 around
the time of my wedding. I was less than one
year from leaving the U.S. Navy, and my role
in the Navy was not a perfect fit. As a steam-
plant engineer, my job was to boil water into
steam to turn turbines. If those turbines turned
generators, my responsibility ended when those
electrons left the generator.
My father was weary of working for the electrical
testing company that employed him at that
time, and we had discussed the opportunity to
join him in business after I left the Navy. So in
August 1997, I left San Diego for Nashville,
Tennessee, to join my father in the business he
had started in January of that year — Power &
Generation Testing, Inc. (PGTI).
While I had some electrical background
from college and my time in the Navy, I had
very little experience working on utility and
industrial equipment. Because I also wanted
to avoid the son-of-the-owner negative
connotation that routinely occurs, I either
volunteered or was volun-told to participate
in every night, weekend, holiday, and outage.
The less attractive the role, the better. I was
going to earn my way. There was no going to
a training class. Every day on the job was the
classroom as I learned from some dedicated and
hardworking men. I should mention there was
also plenty of learning from books, equipment
manuals, and NETA World. This was before the
internet (LOL).
Before PGTI became a NETA company, I was
the first in our company to take and pass the
NICET exam, much to the surprise — dare I
say frustration and confusion — of the more
seasoned technicians we employed. After we
became a NETA company, I took and passed
Level 2 and Level 3 on the same day. At that
INSIGHTS & INSPIRATION
MOSE RAMIEH III:
STAY INVOLVED TO
STAY RELEVANT
NETAWorld • 9MOSE RAMIEH III: STAY INVOLVED TO STAY RELEVANT
time, it was a paper test, and it took weeks to
get a pass/fail notice.
Somewhere around 2005, I became an owner
in PGTI and continued to work daily in the
business. I worked in every role: sales, project
management, and field testing. I was the poster
child for being a jack of all trades and master
of none. My father and I worked to grow that
business and had many wonderful years (and
more than a few disagreements ). Ultimately,
in October 2015, we decided to sell the
business to CE Power. I’ll skip the details of my
time with CE Power other than to say it is hard
to go from being an owner to being a “sales
asset.” I left my company in September 2018.
So there I was, an unemployable NETA Level
4 Technician with time on my hands. I tried
some independent work and also worked as a
manufacturer’s rep. During this time, I was able
to travel to Chile for two months (June–August
2019) to put my NETA Level 4 skills to work.
It was during my time in Chile that I received
a call from Finley Ledbetter to become a part
owner in a company purchase in Michigan.
Our group of investors bought PowerTech
Services (PTS) in October 2019. I relocated
to Swartz Creek, Michigan, and spent most
of 2020 turning that business around. With a
good bit of hard work, and definitely a bit of
luck, PTS began to run well, allowing me to
return to my 24-year home base in Nashville in
November 2020,
Now I’m Vice President of Business
Development for CBS Field Services, which
is the rebranded name of PowerTech Services,
doing whatever is needed to help our business
be successful.
INSIGHTS & INSPIRATION
10 • SUMMER 2022
NW: What about this work keeps you
committed to the profession?
Ramieh: It’s ato this problem is to increase the test current
by at least twice the value of the required test
current per pole, which is about 330  A, or
about 1,000 A in total.
IMPROVED TEST METHOD
The improved test method presented is
applicable to the most demanding cases for
testing, such as a single-pole operated GIS CB
that has very-low resistance in its pole enclosures
or where CTs cannot be included in the
measurement circuit between test access points.
The first improvement to the GIS test method[4]
consists of replacing the high-frequency DC/
DC converter as a power source with high-
power lithium-polymer (Li-Po) batteries. The
reason for this is to eliminate converter noise.
As shown in Figure 2, three isolated battery-
based power sources are used to supply each
pole of the single-pole controlled CB with
IMPROVED METHOD FOR SAFE TIMING MEASUREMENT OF GIS CIRCUIT BREAKERS
Figure 2: Three Battery-Based Power Sources Used for GIS CB Testing
72 • SUMMER 2022
a high current. Therefore, three such power
sources integrated into one box will be needed
for testing this GIS configuration. The current
will be in the range of 400–500 A per pole,
depending on the battery charge levels and the
resistance of the tested circuit.
The second improvement is related to the
measurements on GIS breakers with the CT
placed outside of the grounding switch circuit.
In this case, instead of measuring the signal at
the secondary of the CT, the primary current
can be monitored within the power source.
Since each pole of the GIS circuit breaker is
supplied with a very-high DC current (400–
500 A), the change in the main contact state
will cause a change in the total current that is
measurable even in the case of the very-low
resistance of GIS enclosures and grounding
path. For easier detection of the signal
transients, it is possible to measure the current
signal through the measurement shunt or the
time derivative of this signal. This measurement
can be realized with a hardware differentiator
based on operational amplifiers.[10]
METHOD VERIFICATION
Verification of the improved test method for
GIS CB testing was performed on the GIS
circuit breaker model Energoinvest SFI 11
(manufactured in 1985), single-pole operated,
without purpose-built test terminals. Since
there were no purpose-built test terminals
(access points), test clamps of the current cables
were connected to the conducting points at the
GIS enclosure, placed as close as possible to the
earthing switches, as can be seen in Figure 3.
Since CTs were included in the test circuit,
response signals were measured at the CT
secondary. Besides the fact that the circuit
breaker was single-pole operated (with three
separate enclosures) and didn’t have purpose-
built test terminals, one more aggravating
circumstance was the very-low resistance of the
grounding path (around 60 µΩ).
The generated test current was in the range of
420–430 A per current output. The measured
current signal at the secondary of the CT
during opening and closing operations is
shown in Figure 4. As concluded in Ostojic and
Secic,[4] the highest or the lowest (depending
on the signal direction) turning point at the
response signal during the opening operation
matches with the instant of the arcing contact
separation, while the instant of the first
appearance of the current signal during the
closing operation matches with the instant of
the first contact touch.
With this in mind, and looking at Figure 4, it
can be seen that instants of the contacts opening
are around 21–22  ms, while the instants of
the contacts closing are in a range of 125–
128 ms. These instances can easily be detected
automatically with the appropriate software.
The results could not be verified by performing
timing measurement with the conventional
FEATURE
IMPROVED METHOD FOR SAFE TIMING MEASUREMENT OF GIS CIRCUIT BREAKERS
Figure 3: Connection of Current Clamps to Points Close to Earthing Switches
NETAWorld • 73
FEATURE
IMPROVED METHOD FOR SAFE TIMING MEASUREMENT OF GIS CIRCUIT BREAKERS
timing method since it is not applicable
for this case without dismantling the GIS
enclosure (a GIS circuit breaker doesn’t
have detachable shunts). Instead, specified
limit values prescribed by the OEM were
considered. According to these specifications,
circuit breaker model Energoinvest SFI  11
has an opening time in the range of 18–24 ms
and a closing time in the range 120–130 ms,
meaning that interpreted values are within the
allowed range.
CONCLUSION
Method verification has shown that this
improved test method with three isolated high-
power current sources (400–500 A per source)
is applicable for single-pole operated circuit-
breakers without test terminals and with very-
low resistance of the grounding path.
Because of the option of direct measurement of
the injected current changes as an alternative
to measurement of current signal response at
the (CT’s) secondary, this can be applied to all
configurations of GIS switchgear: three-pole or
single-pole controlled circuit breaker with or
without CT in the measurement circuit and
with or without test terminals.
REFERENCES
[1] Electric Power Substations Engineering.
Electrical Engineering Handbook, Edited
Figure 4: Signal Response at CT Secondary During a) Opening and b) Closing Operation
(a) (b)
by John D. McDonald, CRC Press
Published May 16, 2012. Reference -
536 Pages - 271 B/W Illustrations ISBN
9781439856383 - CAT# K12650.
[2] IEEE. IEEE Std. 510-1983, Recommended
Practices for Safety in High-Voltage and
High-Power Testing.
[3] Radenko Ostojic, Budo Milovic.
“New Requiremens in Circuit Breaker
Diagnostics: Integration of New Circuit
Breaker Test Methods,“ NETA World, 2014.
[4] Radenko Ostojic, Adnan Secic.
“Improving Safety in Operation Time
Measurement Procedure for Circuit
Breakers in Gas Insulated Substation,”
Research Disclosure, 2019.
[5] Philip Bolin. Mitsubishi Electric Power Gas-
Insulated Substation, 2003 by CRC Press LLC.
[6] IEEE. IEEE Std. C37.122.1-1993, Guide
for Gas-Insulated Substations.
[7] IEEE. IEEE Std. C37.123-1996, Guide
to Specifications for Gas-Insulated, Electric
Power Substation Equipment.
[8] IEC. IEC 62271-203:1990, Gas-Insulated
Metal-Enclosed Switchgear for Rated Voltages
of 72.5 kV and Above (3rd edition).
[9] T. Renaudin, A. Nenning. OMICRON
electronics. “On-Site Non-Intrusive
Testing of AC Circui Breakers,” CIGRÉ
Winnipeg 2017 Colloquium, Study
Committees A3, B4, & D1, Winnipeg,
Canada, September 30–October 6, 2017.
FEATURE
[10] Radenko Ostojic, Adnan Secic. “Combined
Current and Voltage Controlled Source in
Arcing Contacts Condition Assessment,“
NETA World, 2015.
Radenko Ostojic is a Test and Diagnosis
Engineer at DV Power – Sweden in
the field of circuit breaker testing and
maintenance. He has been employed at DV
Power since 2010 and works on improving
circuit breaker testing equipment and
developing new methods for circuit breaker
testing. Radenko’s area of special interest is testing circuit breakers
in enhanced safety conditions, which implies testing of circuit
breakers with both terminals grounded. He earned his BSEE at
the University of East Sarajevo.
Adnan Secic is an R&D Engineer at
DV Power – Sweden. As a project leader,
he is responsible for developing the circuit
breaker analyzer and timer (CAT) device
series. Adnan received his BS in electrical
engineering and MS from the University of
Sarajevo, and is in the final stage of Ph.D.
studies at the Faculty of Electrical Engineering and Computing
in Zagreb, Croatia.
Budo Milovic has been employed at DV
Power since 2007 and currently works as
a Technical Application Engineer for CAT
instruments and circuit breaker testing.
His area of interest is improvement of the
circuit breaker testing equipment. Budo
received his BSEE from the University of
East Sarajevo, Bosnia and Herzegovina.
Kerim Obarcaninis a Manager of the
Software Engineering Department at DV
Power – Sweden and an Industry Expert
Lecturer at the Sarajevo School of Science
and Technology, a collaboration partner of
Buckingham University, UK. His primary
research focus is on the domain of data
acquisition, conditioning, and algorithms for data processing.
Kerim is currently in the final stage of his Ph.D. studies at
the Faculty of Electrical Engineering in Sarajevo, Bosnia and
Herzegovina.
PFT-SERIES
AC High Voltage Dielectric Test Set
The PFT-503CM(F) AC Hipot series offers a convenient
one-piece field portable design offering a 0 to 50 kV AC
output, a 6 meter, 20 feet Shielded HV Output Cable, a Guard
Ground Circuit for accurate leakage current measurements, and
Transit protected meters to prevent meter damage between test sites.
The PFT-503CM(F) AC Hipot hipot test set provides continuously
adjustable output voltages for overvoltage withstand testing of
switchgear, circuit breakers, reclosers, vacuum bottles, hot sticks,
and other high voltage insulation requiring AC tests.
 31 County Rt. 7A • Copake, NY 12516
 p. 518.329.3275 • f. 518.329.3271
sales@hvinc.com • hvinc.com
ISO 9001 : 2015
 HIGH VOLTAGE, INC.
 For more information on these and
other high voltage test products, contact:
®
C
M
Y
CM
MY
CY
CMY
K
4426_HVI_NETA_Summer_2022_PRINT.pdf 1 3/1/22 9:21 AM
Features Include:
• QUICK-TRIP® Arc Flash Mitigation
• Scheduled Service Reminder
• Power Demand Metering
• Sluggish Breaker® Detection
• Remote Breaker Control (Trip/Close/QT)
• Current Unbalance Protection
• LSI Protection for Neutral
 And more...
UTILITYRELAY.COM | 888.289.2864 | URCSALES@UTILITYRELAY.COM
.
.
76 • SUMMER 2022 ACCEPTANCE TESTING COLLABORATION LEADS TO IMPROVED PROJECT DELIVERY
BY ERIC NATION, High Voltage Maintenance Corporation
Nearly 70 percent of early equipment failures can be traced to design,
installation, or startup deficiencies. That’s why it is so important to protect
a data center’s investment in new equipment or systems with acceptance
testing. A thorough check of electrical power systems and components
before energization can uncover and help correct problems that otherwise
would lead to project schedule delays or larger and more costly issues
in the future with impacts to data center downtime and consumer
dissatisfaction.
WHAT IS ACCEPTANCE
TESTING AND IS IT
NECESSARY?
Acceptance testing is the physical and electrical
inspection and testing of newly installed
electrical equipment. This involves thorough
visual and mechanical inspections using
calibrated test instruments to ensure electrical
components and completed systems operate
as designed.  It occurs before electrical system
commissioning and start-up as well as before
the new equipment is put into operation.
Taking this initial step verifies that
manufactured devices are free from defects,
operating as designed and intended, and
installed correctly as specified. It is important
that acceptance testing be performed by a
third-party testing firm that is unbiased and
independent in their evaluation and findings.
COMMON COSTLY ISSUES
A number of issues that can be costly to correct
after start-up can be found with acceptance
testing:
• Failure of cabling damaged during
installation
• Incorrect wiring
• Mechanical operating problems
• Nuisance tripping or breakers tripping
outside of manufacturer’s curves
• Improper relay settings and programming
• Compromised insulation dielectric
systems
• Improper grounding
• Wrong transformer taps and/or improper
ratios for proper voltage
• Instrument transformer and metering
circuit ratio and wiring issues
• Surge protection device defects
ACCEPTANCE TESTING
COLLABORATION
LEADS TO IMPROVED
PROJECT DELIVERY
INDUSTRY TOPICS
NETAWorld • 77ACCEPTANCE TESTING COLLABORATION LEADS TO IMPROVED PROJECT DELIVERY
• Switchgear bus and cable connections not
properly assembled
• Bus connections improperly torqued
Acceptance testing also avoids unnecessary
expenses for data centers. Finding system
and component anomalies during acceptance
testing — while equipment is still under
warranty and in a controlled environment
— is critical. Determining and correcting
deficiencies prior to startup can save an
owner capital and maintenance expenses by
preventing costly outages, equipment repairs,
and potential safety issues.
HYPERSCALE DATA CENTER
REQUIREMENTS
The hyperscale data center market continues
to grow and with the amount of digital
information being generated, there’s no end
in sight. With this growth comes a need for
new data centers and/or expansion of existing
facilities at a much greater rate to keep up with
digital demand. The increased demand for data
storage drives larger and more complex power
system requirements to handle the loading, not
only for the servers storing the data, but also
for the thermal systems required to cool the
data center equipment.
Traditionally, acceptance testing of the critical
power distribution infrastructure for these types
of facilities would have been performed fully at
the data center. The testing agency would work
alongside the electrical contractor during or in
many cases after installation to complete all
acceptance testing activities.
With the increased demand and the need to
bring these data centers on line faster, that
model has evolved. Collaboration between
equipment providers, installers, and the testing
agency has improved and enabled off-site
testing that shortens the overall construction
schedule for these projects. It is important
to note, however, that the quality assurance,
INDUSTRY TOPICS
PHOTO: © ISTOCKPHOTO.COM/PORTFOLIO/GORODENKOFF
testing, and commissioning aspects of the
project must always remain the goal without
compromises being made.
OFF-SITE TESTING
OPPORTUNITIES
A shift in the use of integrators creates an
opportunity for testing to begin off-site.
Acceptance testing at an integrator’s facility
or an equipment provider is becoming more
common and offers notable efficiencies.
Collaboration with a system integrator at their
location while the equipment is being built
allows the integrator and electrical contractor
to follow parallel paths with regard to all data
center assets.
The electrical contractor can be installing
system components while the integrator
is assembling the remaining portions of
the power system distribution equipment.
These components can be tested as they are
connected offsite, reducing time on-site by
upward of 40%. This time savings provides
an improvement to the overall construction
schedule that benefits all parties involved.
It is important to note that acceptance testing
will still need to be conducted at the final on-
site location to ensure no damage occurred
during shipping or final installation. This
multi-step approach will help save time overall
as the testing firm can uncover any issues and
make corrections off-site;  this leads to fewer
issues being found on-site.
Acceptance testing is best performed by the same
independent firm working with the integrator
at their location as well as with the electrical
contractor during installation on-site. Keeping a
consistent partner makes for smoother transitions,
increased efficiencies, standard processes and
procedures, communication improvements, etc.
While integrators are providing a customized
solution involving numerous components
INDUSTRY TOPICS
NETAWorld • 79
from various OEMs, the testing agency
conducting the acceptance testing must be
familiar with a wide range of manufacturers’
equipment. Utilizing qualified technicians who
can implement industry-recognized testing
methods and procedures will help ensure the
quality and consistency of testing at the data
center and off-site.
Equipment tested at the integrator site can
include skid-mounted systems in outdoor
enclosures. Each skid includesmedium- and
low-voltage equipment such as circuit breakers,
trip units, protective relays, wiring, metering,
instrument transformers, panelboards, batteries,
etc. The integtrator also includes their own
system for power, lighting, and HVAC controls.
The electrical contractor can be wiring the loads
at the data center and be ready and waiting
for the skids of low- and medium-voltage
switchboard and/or switchgear assemblies
to arrive. Testing at the data center includes
electrical contractor-installed equipment
fed from the skids, such as busways, circuit
breakers, bus plugs, disconnects, grounding,
etc. Tests are often conducted concurrently at
the site while integrator testing is under way.
Testing on equipment from the skids that cannot
be performed at the integrator includes items such
as interconnect wiring, grounding, and complete
system functional testing. These are completed at
the data center to close out the onsite testing.
CHOOSE THE RIGHT
PARTNER
Due to the importance of conducting proper
acceptance testing, selecting a good acceptance
testing firm whose experience and knowledge
you can trust is crucial. Consider the following
criteria when selecting a suitable acceptance
testing firm:
• Independence from the manufacturer to
ensure an unbiased, thorough assessment
of equipment
• Ability to accurately interpret test results
to determine the best course of action for
each unique customer environment
INDUSTRY TOPICS
• Previous work experience on similar
projects to determine the value added
• Technician certification and experience
to ensure thorough testing by a trained
professional
• Size of the firm and ability to staff with
qualified professionals to deliver the
project on time and within budget
• Awareness of all safety standards to
ensure safe work practices and require less
supervision
• Test equipment calibration program to
ensure accurate test results. You cannot
properly assess equipment if you are
unable to confirm the test equipment you
are using is in proper working order.
• Affiliations with reputable organizations
such as NETA, NICET, and NFPA to
confirm knowledge of testing standards
• Ability to perform new and innovative
testing services to ensure a complete
evaluation and comprehensive
recommendations
• Ability for the same company to be
utilized at the integrator as well as the
physical site
• Strong financial standing and the ability
to be a long-term provider
ACCEPTANCE TESTING COLLABORATION LEADS TO IMPROVED PROJECT DELIVERY
The above criteria are important when
identifying an independent testing company
that can become a trusted advisor to help
to extend system life, reduce downtime,
and improve the safety surrounding your
equipment.
CONCLUSION
Electrical systems are among a data center’s
most critical assets, and they can have a big
impact on the bottom line. In data centers that
power the online economy 24x7, even a brief
disruption can cost millions of dollars. Their
production and management cost is high,
and failures almost always lead to catastrophic
losses.
Hyperscale data centers are experiencing
substantial growth, requiring collaboration
and an integrated project delivery to
improve consistency and shorten the overall
construction schedule. Investing in thorough
acceptance testing by utilizing a trusted,
independent testing firm can save your
organization money during construction and
throughout the equipment life cycle.
Eric Nation is the General Manager of
High Voltage Maintenance Corporation
and has been with the company since
2001. He has over 20 years of experience
in the electrical services industry helping
customers increase the reliability of their
electrical systems. Eric is a member of
several professional organizations including the International
Electrical Testing Association (NETA) and the National
Electrical Contractors Association (NECA). He holds a BS from
Wright State university and an MBA from Miami University.
This article was first published in 7x24 Exchange
International, Spring 2021. Published by Data
Center and Mission Critical Association.
PowerSystemsTesting.1-2_NETA.WI15.indd 1 10/21/15 9:16 AM
INDUSTRY TOPICS
THE PREMIER ELECTRICAL MAINTENANCE AND SAFETY CONFERENCE

Exhibit to an audience of 500+ electrical testing professionals including
leading decision-makers looking for new products and services.
POWERTEST.ORG | 888.300.6382
HOSTED BY
OFFERING IN-PERSON AND
VIRTUAL ATTENDANCE OPTIONS
March 8– 12, 2023
Rosen Shingle Creek | Orlando, Florida
82 • SUMMER 2022 POWER FACTOR: UNDERSTANDING THE DIFFERENCE BETWEEN DPF AND TPF
BY KEN KIOUS, PowerSight
People often refer to power factor without understanding that there are
two types of power factor measurement, and it is important to understand
the difference between them. If you have a power factor problem, it could
mean you have:
• A power factor correction problem
that requires adding (or taking away)
capacitors
• A combination of a power factor
correction problem and harmonics that
make it look worse than it is
But how do you know which problem you
have? And how do you measure it?
WHAT IS DISPLACEMENT
POWER FACTOR?
Displacement power factor (DPF) is what
most people think of when they talk of power
factor. For those comfortable with the math,
it is the cosine of the angle between a driving
voltage and the resulting current. For the rest
of us, it is a measure of how much the driven
current waveform trails the driving voltage
waveform in an inductive circuit.
A few degrees of current phase lag makes very little
difference in the circuit, but as that lag increases, it
has an increasing effect on lowering the efficiency
of the system. The relationship between increasing
phase lag and the resulting lowered efficiency is
expressed by the cosine of the lag angle. Therefore,
rather than reporting the lag angle, we usually
POWER FACTOR:
UNDERSTANDING THE
DIFFERENCE BETWEEN
DPF AND TPF
INDUSTRY TOPICS
NETAWorld • 83POWER FACTOR: UNDERSTANDING THE DIFFERENCE BETWEEN DPF AND TPF
report the cosine of the lag angle. That provides a
more meaningful understanding of whether you
have a displacement problem or not.
The downward bending curve seen in Figure
1 for true power relative to apparent power
is exactly the same as the downward bending
curve of the cosine math function. Therefore,
the cosine of the lag angle is an exact measure
of how the true power component of apparent
power (V x A) decreases as phase lag increases.
For this reason, rather than reporting the lag
angle, we usually report the cosine of the lag angle
(Figure 2), which provides a more meaningful
understanding of whether you have a phase angle
displacement problem or not. In a system where
no harmonics are present, true power will be
equal to the apparent power times the DPF:
W = Vrms x Arms x DPF  (when no harmonics
are present)
WHAT IS TRUE POWER
FACTOR?
True power factor (TPF) is what most people
actually measure.  It is simply the ratio of true
power (KW) to the apparent power (KVA).
TPF = W / VA  (whether harmonics are present
or not)
It’s easy to measure and, traditionally, it is equal
to the DPF (the cosine of the phase angle). If
your TPF is low, you have a problem. The
only question is whether the problem is due to
current displacement or due to a combination
of harmonic distortion and displacement.
WHY YOU CARE ABOUT DPF
If DPF is low, it takes more current to supply
the same amount of power to a load.  We
typically see this with motors, which are
traditionally highly inductive loads. Inductance
causes the current to lag the voltage.
INDUSTRY TOPICS
PHOTO: © ISTOCKPHOTO.COM/PORTFOLIO/POBYTOV
120.00
True Power (KW)
100.00
80.00
60.00
40.00
20.00
0.00
1.20
1.00
0.80
0.60
0.40
0.20
0.00
Cos(Lag Angle)
Phase Lag Angle
120.00
True Power (KW)
100.00
80.00
60.00
40.00
20.00
0.001.20
1.00
0.80
0.60
0.40
0.20
0.00
Cos(Lag Angle)
Phase Lag Angle
Figure 1: True Power Relative to Apparent Power
Figure 2: Cosine of Lag Angle
84 • SUMMER 2022
Here is an example of how this plays out.
Suppose a single-phase motor that is running
off 120 V needs 1,200 W to run efficiently. If
there is no phase lag, then the lag angle equals
0 degrees. The cosine of 0 degrees is 1, and the
required current draw will be:
1,200 W/120 V/1= 10 A
Now, suppose the motor has very large
inductance and, as a result, the phase lag angle
is 60 degrees. The cosine of 60 degrees is 0.5,
resulting in a current draw of:
1,200 W/120 V/0.5 = 20 A
The required current for the same amount of work
has doubled because of the increased phase lag.
Figure 3 and Figure 4 are waveform captures that
illustrate what was just described. The circuits in
Figure 3 and Figure 4 consume nearly the same
power, but the circuit in Figure 3 has a large phase
lag of 60 degrees, resulting in a drop in DPF:
DPF = cos(60) = 0.50
The circuit in Figure 4 has no phase lag,
resulting in:
DPF = cos(0) = 1.00
INDUSTRY TOPICS
POWER FACTOR: UNDERSTANDING THE DIFFERENCE BETWEEN DPF AND TPF
PS4550_DPF_0.50_1214W_20A
V1n
120.4
I1
20.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.58.51
-100.0
-200.0
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
50.00
40.00
30.00
20.00
10.00
0.00
-10.00
-20.00
-30.00
-40.00
-50.00
W1 = 1.214KW
PF1 = 0.80
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.214KW
PFt = 0.50
PS4550_DPF_1.00_1339W_11A
V1n
120.4
I1
11.1
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.56.27
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
W1 = 1.339KW
PF1 = 1.00
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.339KW
PFt = 1.00
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
0.33%
I1
12.0
38.91%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
0.33%
I1
12.0
0.42%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)
90°
-90°
±180° 0°
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
V1n
I1
Phase Lag
V1,I1: -0.2°
V2,I2: NA
V3,I3: NA
Current
I1: 120.4V, 0.0°
I2: Too small
I3: Too small
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
Phase Lag
V1,I1: 22.1°
V2,I2: NA
V3,I3: NA
Current
I1: 12.0A, -22.1°
I2: Too small
I3: Too small
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
V
PS4550_PF_0.93_due_to_Harmonics
PS4550_PF_0.93_due_to_Phase_Lag
90°
-90°
±180° 0°
V1n
I1
PS4550_DPF_0.50_1214W_20A
V1n
120.4
I1
20.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.58.51
-100.0
-200.0
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
50.00
40.00
30.00
20.00
10.00
0.00
-10.00
-20.00
-30.00
-40.00
-50.00
W1 = 1.214KW
PF1 = 0.80
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.214KW
PFt = 0.50
PS4550_DPF_1.00_1339W_11A
V1n
120.4
I1
11.1
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.56.27
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
W1 = 1.339KW
PF1 = 1.00
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.339KW
PFt = 1.00
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
0.33%
I1
12.0
38.91%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
0.33%
I1
12.0
0.42%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)
90°
-90°
±180° 0°
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
V1n
I1
Phase Lag
V1,I1: -0.2°
V2,I2: NA
V3,I3: NA
Current
I1: 120.4V, 0.0°
I2: Too small
I3: Too small
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
Phase Lag
V1,I1: 22.1°
V2,I2: NA
V3,I3: NA
Current
I1: 12.0A, -22.1°
I2: Too small
I3: Too small
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
V
PS4550_PF_0.93_due_to_Harmonics
PS4550_PF_0.93_due_to_Phase_Lag
90°
-90°
±180° 0°
V1n
I1
Figure 3: Large Phase Lag
Figure 4: No Phase Lag
The circuit with large phase lag (Figure 3) requires
about twice the amount of current (I1 = 20 A) to
supply similar power compared to the circuit with
no phase lag (I1 = 10A) in Figure 4.
A single load with low DPF is usually not an
important thing, but what if there are 1,000 such
motors? Now the utility must supply twice the
current to accomplish the same amount of work
as if there were no phase lag. The user doesn’t
mind, because in most cases, they are paying for
true power (KW) not apparent power (KVA). But
the utility is unhappy because now their
distribution system is carrying twice the current
that is actually needed to perform the work for
the customer. That extra current results in twice
the resistive power loss in their distribution
system, which benefits no one.
A similar problem arises for the end user if:
• Larger gauge conductors are required to
supply the required amperage.
INDUSTRY TOPICS
• The facility is remote and the owner must
supply anoversized distribution system of
considerable length.
• The facility is geographically dispersed
(such as for oil-well pump jacks or
distributed fluid pumps).
Since they do not want to absorb the cost
of inefficiency, the utility fights back with a
power factor surcharge on your bill so you
will share their pain.  This surcharge can
be pretty steep, so power factor correction
circuitry to lower the required current and
eliminate power factor correction surcharges
(or lower the cable gauge requirements in your
dispersed or remote facility) may be a money-
saving investment.
WHY YOU CARE ABOUT TPF
TPF is often nearly equal to DPF, so if you care
about DPF, you probably care about TPF. The
two measurements deviate from each other
when harmonics are present.  In the modern
Industrial Electric Testing, Inc.
EC13004105 • 24 Hour Emergency Service
ACCEPTANCE AND MAINTENANCE TESTING AND REPAIR
Co NSul TING AND ENGINEERING SERv ICES
• Cables
• LV/MV Circuit Breakers
• Rotating Machinery
• Meters
• Automatic Transfer Switches
• Switchgear and Switchboard
Assemblies
• LV/MV Switches
• Relays - All Types
• Motor Control Centers
• Grounding Systems
• Transformers
• Insulating Fluids
• Thermographic Surveys
• Reclosers
• Surge Arresters
• Capacitors
• Batteries
• Ground Fault Systems
• Equipotential Ground
Testing
• Load Studies
• Transient Voltage Recording and Analysis
• Electromagnetic Field (EMF) Testing
• Harmonic Investigation
• Replacement of Insulating Fluids
• Power Factor Studies
11321 West Distribution Avenue • Jacksonville, Florida 32256 • (904) 260-8378
201 NW 1st Avenue • Hallandale, Florida 33009 • (954) 456-7020
86 • SUMMER 2022
era of non-linear loads and electronic power
supplies, significant harmonics can be present.
If the harmonic currents are not in phase with
their harmonic driving voltages, then the true
power (the KW) will be less than the apparent
power (the KVA), and the resulting TPF will be
lower than 1.00.
If you are monitoring a conventional motor
without a variable speed drive (VSD), you will
find that TPF is a pretty good measurement
of DPF, so talking simply of power factor
(PF) is usually accurate and explanatory. But
if you are monitoring an electronic load with
high harmonics, there is a good chance that
the DPF (the phase lag of the fundamental
frequency) is close to 1.00, even if the TPF is
much lower. Therefore, you should know your
load before you make assumptions about what
the TPF means.
To illustrate, Figure 5 and Figure 6 show
waveform captures from two different single-
phase simulations. Both circuits have a TPF of
0.93 with 12 A. However, they are completely
different situations that require completely
different mitigation methods if you want to raise
the TPF.
INDUSTRY TOPICS
POWER FACTOR: UNDERSTANDING THE DIFFERENCE BETWEEN DPF AND TPF
Figure 5: No Phase Lag; High Current-Waveform Distortion
Figure 6: No Harmonic Distortion; 22 Degrees of Phase Lag
PS4550_DPF_0.50_1214W_20A
V1n
120.4
I1
20.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.58.51
-100.0
-200.0
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
50.00
40.00
30.00
20.00
10.00
0.00
-10.00
-20.00
-30.00
-40.00
-50.00
W1 = 1.214KW
PF1 = 0.80
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.214KW
PFt = 0.50
PS4550_DPF_1.00_1339W_11A
V1n
120.4
I1
11.1
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.56.27
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
W1 = 1.339KW
PF1 = 1.00
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.339KW
PFt = 1.00
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
0.33%
I1
12.0
38.91%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
0.33%
I1
12.0
0.42%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)
90°
-90°
±180° 0°
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
V1n
I1
Phase Lag
V1,I1: -0.2°
V2,I2: NA
V3,I3: NA
Current
I1: 120.4V, 0.0°
I2: Too small
I3: Too small
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
Phase Lag
V1,I1: 22.1°
V2,I2: NA
V3,I3: NA
Current
I1: 12.0A, -22.1°
I2: Too small
I3: Too small
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
V
PS4550_PF_0.93_due_to_Harmonics
PS4550_PF_0.93_due_to_Phase_Lag
90°
-90°
±180° 0°
V1n
I1
PS4550_DPF_0.50_1214W_20A
V1n
120.4
I1
20.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.58.51
-100.0
-200.0
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
50.00
40.00
30.00
20.00
10.00
0.00
-10.00
-20.00
-30.00
-40.00
-50.00
W1 = 1.214KW
PF1 = 0.80
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.214KW
PFt = 0.50
PS4550_DPF_1.00_1339W_11A
V1n
120.4
I1
11.1
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.56.27
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
W1 = 1.339KW
PF1 = 1.00
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.339KW
PFt = 1.00
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
0.33%
I1
12.0
38.91%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
0.33%
I1
12.0
0.42%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)
90°
-90°
±180° 0°
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
V1n
I1
Phase Lag
V1,I1: -0.2°
V2,I2: NA
V3,I3: NA
Current
I1: 120.4V, 0.0°
I2: Too small
I3: Toosmall
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
Phase Lag
V1,I1: 22.1°
V2,I2: NA
V3,I3: NA
Current
I1: 12.0A, -22.1°
I2: Too small
I3: Too small
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
V
PS4550_PF_0.93_due_to_Harmonics
PS4550_PF_0.93_due_to_Phase_Lag
90°
-90°
±180° 0°
V1n
I1
NETAWorld • 87
INDUSTRY TOPICS
POWER FACTOR: UNDERSTANDING THE DIFFERENCE BETWEEN DPF AND TPF
The circuit in Figure 5 has no phase lag, but it has
high current-waveform distortion that results in
W/VA  =  0.93.  The circuit in Figure 6 has no
harmonic distortion, but it has 22 degrees of phase
lag, resulting in W/VA = 0.93. The voltage and
current RMS values are the same in both circuits.
The W and VA are also the same, but they represent
completely different challenges for mitigation.
Looking closer, we can see the harmonic
distortion content of the two circuits. We can
see that the simulation in Figure 7 has current
total harmonic distortion (THD) of 39%. The
simulation in Figure 8 has THD of 0%.
To complete this analysis, we can see the
phasor diagrams for the two single-phase
simulations. Figure 9 shows no displacement
(DPF = 1.00).  Figure 10 has 22 degrees of
displacement (DPF = 0.93).
Does it Matter?
If you have high harmonic content, it may not
matter. A desktop computer with a low TPF
due to harmonics probably makes no difference
to your facility. But if you have 1,000 desktop
computers with low TPF due to harmonics,
you likely have substantial harmonic currents
flowing through your facility wiring and
Figure 7: Total Harmonic Distortion of 39%
Figure 8: Zero Total Harmonic Distortion
PS4550_DPF_0.50_1214W_20A
V1n
120.4
I1
20.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.58.51
-100.0
-200.0
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
50.00
40.00
30.00
20.00
10.00
0.00
-10.00
-20.00
-30.00
-40.00
-50.00
W1 = 1.214KW
PF1 = 0.80
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.214KW
PFt = 0.50
PS4550_DPF_1.00_1339W_11A
V1n
120.4
I1
11.1
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.56.27
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
W1 = 1.339KW
PF1 = 1.00
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.339KW
PFt = 1.00
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
0.33%
I1
12.0
38.91%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
0.33%
I1
12.0
0.42%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)
90°
-90°
±180° 0°
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
V1n
I1
Phase Lag
V1,I1: -0.2°
V2,I2: NA
V3,I3: NA
Current
I1: 120.4V, 0.0°
I2: Too small
I3: Too small
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
Phase Lag
V1,I1: 22.1°
V2,I2: NA
V3,I3: NA
Current
I1: 12.0A, -22.1°
I2: Too small
I3: Too small
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
V
PS4550_PF_0.93_due_to_Harmonics
PS4550_PF_0.93_due_to_Phase_Lag
90°
-90°
±180° 0°
V1n
I1
PS4550_DPF_0.50_1214W_20A
V1n
120.4
I1
20.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.58.51
-100.0
-200.0
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
50.00
40.00
30.00
20.00
10.00
0.00
-10.00
-20.00
-30.00
-40.00
-50.00
W1 = 1.214KW
PF1 = 0.80
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.214KW
PFt = 0.50
PS4550_DPF_1.00_1339W_11A
V1n
120.4
I1
11.1
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.56.27
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
W1 = 1.339KW
PF1 = 1.00
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.339KW
PFt = 1.00
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
0.33%
I1
12.0
38.91%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
0.33%
I1
12.0
0.42%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)
90°
-90°
±180° 0°
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
V1n
I1
Phase Lag
V1,I1: -0.2°
V2,I2: NA
V3,I3: NA
Current
I1: 120.4V, 0.0°
I2: Too small
I3: Too small
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
Phase Lag
V1,I1: 22.1°
V2,I2: NA
V3,I3: NA
Current
I1: 12.0A, -22.1°
I2: Too small
I3: Too small
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
V
PS4550_PF_0.93_due_to_Harmonics
PS4550_PF_0.93_due_to_Phase_Lag
90°
-90°
±180° 0°
V1n
I1
88 • SUMMER 2022
INDUSTRY TOPICS
POWER FACTOR: UNDERSTANDING THE DIFFERENCE BETWEEN DPF AND TPF
through the distribution and step-downtransformers at your site.
You care about this because harmonic currents
have a heating effect that is far greater than
currents of the same magnitude at the
fundamental frequency. So you may measure
an overall current of 200 A and feel safe, but
the wiring in the cable trays and walls may
be dangerously heated.  Your distribution
transformers, if not properly K-rated, may
be overheating and in a dangerous condition,
and there may be hot spots on contacts and
connection points.
HOW TO MEASURE
POWER FACTOR
A standard power analyzer has all the
measurements you need to allow you to assess
your problems and verify your solutions with
regards to power factor.
Most power analyzers will measure and log TPF
— true power factor. If you are monitoring
an inductive load, this gives you a good
measurement for DPF — displacement power
factor — so you can take proper mitigating
measures. If you are monitoring an electronic
load, branch circuit, or service entrance, you
Figure 9: No Displacement
Figure 10: 22 Degrees of Displacement
PS4550_DPF_0.50_1214W_20A
V1n
120.4
I1
20.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.58.51
-100.0
-200.0
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
50.00
40.00
30.00
20.00
10.00
0.00
-10.00
-20.00
-30.00
-40.00
-50.00
W1 = 1.214KW
PF1 = 0.80
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.214KW
PFt = 0.50
PS4550_DPF_1.00_1339W_11A
V1n
120.4
I1
11.1
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.56.27
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
W1 = 1.339KW
PF1 = 1.00
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.339KW
PFt = 1.00
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
0.33%
I1
12.0
38.91%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
0.33%
I1
12.0
0.42%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)
90°
-90°
±180° 0°
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
V1n
I1
Phase Lag
V1,I1: -0.2°
V2,I2: NA
V3,I3: NA
Current
I1: 120.4V, 0.0°
I2: Too small
I3: Too small
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
Phase Lag
V1,I1: 22.1°
V2,I2: NA
V3,I3: NA
Current
I1: 12.0A, -22.1°
I2: Too small
I3: Too small
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
V
PS4550_PF_0.93_due_to_Harmonics
PS4550_PF_0.93_due_to_Phase_Lag
90°
-90°
±180° 0°
V1n
I1
PS4550_DPF_0.50_1214W_20A
V1n
120.4
I1
20.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.58.51
-100.0
-200.0
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
50.00
40.00
30.00
20.00
10.00
0.00
-10.00
-20.00
-30.00
-40.00
-50.00
W1 = 1.214KW
PF1 = 0.80
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.214KW
PFt = 0.50
PS4550_DPF_1.00_1339W_11A
V1n
120.4
I1
11.1
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.56.27
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
W1 = 1.339KW
PF1 = 1.00
W2 = 0.0
PF2 = NA
W3 = 0.0
PF3 = NA
Wt = 1.339KW
PFt = 1.00
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
0.33%
I1
12.0
38.91%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Phase_Lag
V1n
120.3
0.33%
I1
12.0
0.42%
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Harmonics (#)
90°
-90°
±180° 0°
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.54.15
20.00
15.00
10.00
5.00
0.00
200.0
150.0
100.0
50.0
0.0
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49
PF1 = 0.93 PF2 = NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
V1n
I1
Phase Lag
V1,I1: -0.2°
V2,I2: NA
V3,I3: NA
Current
I1: 120.4V, 0.0°
I2: Too small
I3: Too small
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
Voltage
V1n: 120.4V, 0.0°
V2n: Too small
V3n: Too small
V Unbalance: NA
Phase Lag
V1,I1: 22.1°
V2,I2: NA
V3,I3: NA
Current
I1: 12.0A, -22.1°
I2: Too small
I3: Too small
I Unbalance: NA
Power Factor
PF1: 0.93
PF2: NA
PF3: NA
PFt:NA
PF3 = NA PFt = 0.93
PS4550_PF_0.93_due_to_Harmonics
V1n
120.4
I1
12.0
200.0
100.0
0.0
Vo
lta
ge
 (V
)
C
ur
re
nt
 (A
)
Time (msec)Fundamental Frequency: 60.0Hz Captured on 02/10/21 at 13.50.15
-100.0
-200.0
20.00
10.00
0.00
-10.00
-20.00
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
PF1 = 0.93 PF2 = NA PF3 = NA PFt = 0.93
V
PS4550_PF_0.93_due_to_Harmonics
PS4550_PF_0.93_due_to_Phase_Lag
90°
-90°
±180° 0°
V1n
I1
INDUSTRY TOPICS
POWER FACTOR: UNDERSTANDING THE
DIFFERENCE BETWEEN DPF AND TPF
can get a sense of whether a displacement and/
or harmonic problem is present.
Simple calculations can guide you to make
the proper choice of power factor correction
equipment and verify that such equipment is
performing correctly. A good power analyzer
will log the true power (KW), the apparent
power (KVA), the average reactive power
(KVAR), and the true power factor (TPF). An
analyzer that will also log the signed (+/-) DPF
so you can verify the actual phase lag (or phase
lead) of current in each phase over time is ideal.
Most analyzers measure DPF and display
readings either on the analyzer itself (so you
can take a direct measurement while wearing
PPE with the analyzer in your hand) or on PC
software.   Analyzers with waveform capture,
phasor diagrams, and harmonic bar charts
allow you to directly see the components of
displacement and harmonics. Most analyzers
also measure and log the THD of each voltage
and each current so it is clear whether there is a
harmonics issue or not.
Most analyzers will log the THD of each
voltage and current so you can recognizeand
size the scale of your harmonic problems. Some
analyzers allow you to capture waveforms at
any time and then transform the waveform
into a harmonic breakdown of the magnitude
of each harmonic frequency, so you can decide
whether you wish to trap specific frequencies
or filter the full range of frequencies. Logging
individual harmonics can be beneficial in
designing a harmonic trap for a specific
harmonic.
When you mitigate, you will be able to verify
the effectiveness of the mitigation by examining
the log or waveforms. Of course, if low TPF
is the result of both harmonics and current
lag, your power analysis software will need to
separate the two causes so you can select the
correct mitigation action.
A solid report-creation wizard can provide
summary reports of before and after
mitigation.  It can also provide comparison
reports where the before and after are compared
directly, with percent improvement shown.
CONCLUSION
Power factor is often referred to without
understanding that there are two types of
power factor measurement, and it is important
to understand the differences. It is equally
important to know how to measure and
analyze power factor effectively and accurately.
Choosing the right power analyzer to meet your
needs will allow you to assess your problems
and verify your solutions.
Ken Kious is Founder and President
of Summit Technology, Inc.  He has a
BSEE from UC Davis and an MS in
Management from MIT. Ken has spent 30
years worrying about customers’ success in
doing power measurements and has created
numerous unique solutions for monitoring
and analyzing electric power.
ELECTRICAL TESTING
LEADING EDGE
on the
ELECTRICAL TESTING
LEADING EDGE
on the
ELEMCO SERVICES
offers a comprehensive array of state-of-the-art
electrical testing services and expertise.
HIGH, MEDIUM AND LOW VOLTAGE REPAIR
AND MAINTENANCE OF:
Switchgear / Circuit Breakers / Transformers / ATS Switches / Cables
TESTING, CALIBRATION AND REPAIR
OF METERS AND RELAYS
FIELD SERVICES:
Acceptance Testing and Commissioning / Infrared Surveys
Motor and Cable Testing
Load and Power Quality Recording and Analysis

CONTACT US TODAY • 24 HOUR SERVICE
228 Merrick Road, Lynbrook, NY 11563 (631) 589-6343
601 Union Street, Brooklyn, NY 11215 (718) 786-4900
WWW.ELEMCO.COM
L i c e n c e d i n N e w Y o r k a n d N e w J e r s e y
®
90 • SUMMER 2022 MEDIUM-VOLTAGE CIRCUIT BREAKER CONDITION ASSESSMENT
BY SIEGFRIED BERNHAUSER and ARI T IRRONIEMI, OMICRON electronics
Circuit breakers are indispensable in any electrical power system. They are
the only piece of equipment that can switch not only under normal load,
but also under fault conditions. They must be able to reliably disconnect
a faulty section from the grid as quickly as possible. Circuit breakers must
be able to meet this requirement even after they have been in service for a
long time. Their reliability is essential for the prevention of consequential
power system failures and the safety of the electrical power supply.
Typical tests include measuring operating
times and static contact resistance. A more
extensive condition assessment is possible
when further measurements, such as motion/
contact travel measurements or measurement
of the motor current signature, are performed.
For circuit breakers that are equipped with an
under-voltage release or an over-current release,
testing these features further increases the
available information that can be used during
the condition assessment of the circuit breaker.
MEDIUM-VOLTAGE CIRCUIT
BREAKERS
While old medium-voltage circuit breakers
often used oil as the interrupting medium,
in modern times, vacuum is the preferred
medium and is thus used almost exclusively.
Essential elements of a breaker include the
interrupter unit, the mechanical linkage, and
the operating mechanism with an energy
storage system. The energy that is needed to
operate a circuit breaker is high, and it must
be made available within a few milliseconds
— almost instantaneously. Springs are used
in most cases because they are simple in
comparison and very reliable at the same time.
Two separate springs allow the energy for the
opening and the closing operation to be stored.
In order to release the energy that is stored in
the springs, two coils are needed to control the
springs remotely. The opening spring is charged
during the closing operation of the breaker, and
the closing spring is charged by a motor.
TESTING MEDIUM-VOLTAGE
CIRCUIT BREAKERS
Following is a brief overview of the most
important medium-voltage circuit breaker
measurement methods.
MEDIUM-VOLTAGE
CIRCUIT BREAKER
CONDITION ASSESSMENT
INDUSTRY TOPICS
NETAWorld • 91
PHOTO: © ISTOCKPHOTO.COM/PORTFOLIO/GURUXOOX
MEDIUM-VOLTAGE CIRCUIT BREAKER CONDITION ASSESSMENT
Off-Service Measurement
Methods
• Timing. Timing measurements according
to IEC 62271-100[1] are used to
determine operation time and are part of
the most common tests. The timing test
uses a resistance or voltage threshold to
determine the state of the main contacts.
• Static contact resistance. Verifies
whether the resistance of the main
contacts allows the current to flow with
low losses.
• Dynamic contact resistance. Records the
contact resistance during the operation
of the breaker and delivers information
about wear-related problems with
main and arcing contacts, while also
determining timing results.
• Motion/contact travel. Verifies operating
mechanism and mechanical linkage and
indicates potential mechanical wear.
• Coil current. Records the current
signature curve of the command coils
during breaker operation during a timing
test. Deviations show possible electrical
or mechanical defects of the trip or close
control components. According to the
IEC, the trip coil shall work between
70% and 110% of nominal voltage, and
the close coil shall work between 85%
and 110% of nominal voltage.
• Motor current. The motor current
analysis records the inrush and steady-
state currents as well as the spring
charging time. According to the IEC,
the motor shall work between 85% and
110% of nominal voltage.
• Minimum pick-up. Determines the
minimum voltage necessary to trip and
close the breaker and verifies whether it
can reliably operate in the event of a low
DC supply.
• Under-voltage release test. Determines
the trip voltage of the under-voltage coil.
• Over-current release test. Used to
determine the current that trips the
breaker. Over-current releases are
commonly used together with self-
powered over-current protection relays.
In-Service Measurement Methods
• First-trip test. The first trip test is carried
out while the breaker is still in service
and has been in service for a long time.
Connections are made at the trip coil and
at the CT’s secondary side. The opening
times are measured by monitoring
secondary current of the CTs.
• Voltage-based timing measurement
(VTM). VTM is the only measurement
method available to measure the timing
of a medium-voltage GIS, since the
INDUSTRY TOPICS
92 • SUMMER 2022
main contacts are sealed and cannot be
accessed. It can be applied to all circuit
breakers with a voltage detection system
(VDS) that makes the main voltages
accessible.
UNDER-VOLTAGE RELEASE

Purpose of Under-Voltage Release
Circuit breakers are equipped with an under-
voltage release if the related protection system
has no supply voltage backup, for example, if
a protection relay is powered by a battery, but
the battery voltage is not monitored. If the
battery voltage falls below 70% of its nominal
voltage (see IEC 62271-1:2017[2] for details) so
it is no longer able to operate the protection
relay, any failure (e.g., an over-current) would
no longer be discovered. The under-voltage
release is often found in industry grids, as it
is a relatively cheap solution to make sure the
breaker is opened when a batteryfailure occurs.
An under-voltage release may operate when
supply voltage is between 35% and 70% of the
nominal voltage and must operate when the
supply voltage drops below 35%. In addition,
the under-voltage release prevents closing when
the release has operated, such as after opening
the circuit breaker.
Under-Voltage Release Test
The under-voltage coil is supplied, after
which the breaker is closed. Then the voltage
is ramped down in steps from the nominal
voltage until the under-voltage release trips
(Figure 1). This is the trip voltage.
OVER-CURRENT RELEASE

Purpose of Over-Current Releases
Current transformer releases are used on
circuit breakers in substations where no grid-
independent supply voltage is available. These
are low-cost stations with basic functionality.
Quite often, they do not have any remote-
control features, and the breakers do not have
a close coil. Such substations are common
in distribution grids where the downstream
infrastructure is not critical, such as in
residential areas.
Over-current releases are activated by a
current. The current comes from the tripping
transformer, which usually has a nominal
value of 0.5, 1.0, or 5 A AC. An over-current
relay feeds the current flow from the tripping
transformer to the circuit breaker. The tripping
transformer and the over-current relay (self-
powered over-current relay) are usually
powered by the secondary side of the CTs. In
the event of an over-current, the relay switches
the current of the tripping transformer to the
MEDIUM-VOLTAGE CIRCUIT BREAKER CONDITION ASSESSMENT
INDUSTRY TOPICS
Trip voltage
Supply
Under-voltage
coil
Breaker closed
Start
Ramping
End
Ramping
Breaker
trips
Nominal
Voltage
Main
Contacts
Time
Figure 1: Under-Voltage Release Test Signal
Start
Ramping
End ramping
Breaker
trips
Trip current
Current
Main
Contacts
Time
Figure 2: Over-Current Release Test Signal
NETAWorld • 93
circuit breaker; this causes it to open the main
contacts and isolate the faulty grid part.
Over-Current Release Test
With the breaker in closed position, a current
is ramped up in steps until the breaker trips
(Figure 2). This is the trip current.
Other Designations
• IEC 62271-100: Indirect current release
• ABB: Transformer operated release
• Siemens: Current transformer operated
release
• Also in use: Indirect over-current release
CLOSING TIME
CALCULATION FOR
CIRCUIT BREAKERS
WITHOUT A CLOSE COIL
All breakers should have at least a trip coil so
that faults can be isolated. Some old breakers or
breakers with over-current release do not have
a close coil. These breakers are closed manually.
According to IEC 62271-100,[1] closing time
is the elapsed time from the moment the close
coil is energized until the contacts touch all
poles (Figure 3).
For circuit breakers without a close coil, the
closing time calculation according to the IEC
standard cannot be applied. Therefore, an
alternative approach must be used. The closing
time can be the time when the circuit breaker
main contacts begin to move until the contacts
touch all poles (Figure 4).
REFERENCES
[1] IEC 62271-100
[2] IEC 62271-1:2017
Siegfried Bernhauser has worked
for OMICRON electronics in Klaus,
Austria, for more than 25 years. After
starting as a Technical Writer, he worked
as a Marketing Communications
Engineer with a focus on business-to-
business communication for power system
testing products such as the CMC 356, the CPC 100, the
CT Analyzer, the TESTRANO 600, the MPD 800, and
MEDIUM-VOLTAGE CIRCUIT BREAKER CONDITION ASSESSMENT
INDUSTRY TOPICS
the CIBANO 500. Most recently, he focused on producing
switchgear testing videos. Siegfried studied TV and film
production at the Danube University Krems, Austria.
Ari Tirroniemi has worked for
OMICRON electronics in Klaus, Austria,
for more than 15 years as a firmware
developer and later as Project Manager for
products such as DIRANA and CIBANO
500. He is currently an Application
Engineer focusing on circuit breaker testing.
Ari studied applied physics and electrical engineering at the
Linköping University of Technology, Sweden.
Coil energized Main contacts
close
End Pos.
Start Pos.
Coil
Current
Main
Contacts
Main
Contact
Motion
TimeClosing
Time
Motion Start Main
contacts
close
End Pos.
Start Pos.
Coil
Current
Main
Contacts
Main
Contact
Motion
TimeClosing
Time
Coil energized Main contacts
close
End Pos.
Start Pos.
Coil
Current
Main
Contacts
Main
Contact
Motion
TimeClosing
Time
Motion Start Main
contacts
close
End Pos.
Start Pos.
Coil
Current
Main
Contacts
Main
Contact
Motion
TimeClosing
Time
Figure 3: Closing Time Calculation According to IEC 62271-100[1]
Figure 4: Closing Time with Motion/Contact Travel as Start Reference
94 • SUMMER 2022 THE KEY TO RELAY PROTECTION SUCCESS: COOPERATION
BY ED KHAN, Doble Engineering
The objective of protective relays and protective schemes is to protect
electrical equipment such as transformers, lines, cables, bus bars, etc.
during abnormal system conditions. Hence, protective relaying demands
the utmost attention and diligence. However, when dealing with relay
protection, protection engineers may inadvertently focus only on the
relays. Engineers talk about selecting appropriate relays, applying correct
settings, checking out the wiring, ensuring correct interconnections, and
performing effective tests.
However, we must realize that relay protection
does not exist on an island. In addition to
protective relays, substations contain other critical
equipment including circuit breakers, current
transformers (CTs), potential transformers (PTs),
battery systems, and transformers.
In many large utilities, there is often a barrier
between the relay department and the substation
equipment department. Substation equipment,
along with relays and relay protection schemes,
is tested at regular intervals by the respective
departments.
There is little realization regarding the critical
dependency of relay protection on CTs,
circuit breakers, etc. Hence, we should avoid
isolating relay protection from CTs, PTs,
THE KEY TO RELAY
PROTECTION SUCCESS:
COOPERATION
ADVANCEMENTS IN INDUSTRY
PH
O
TO
: ©
 IS
TO
C
KP
H
O
TO
.C
O
M
/P
O
RT
FO
LIO
/I
N
D
YS
YS
TE
M
Figure 1: Building Blocks of a Relay Protection Scheme
NETAWorld • 95THE KEY TO RELAY PROTECTION SUCCESS: COOPERATION
breakers, and batteries. These are intertwined.
Figure 1 illustrates the building blocks of the
relay protection system: relays, current and
voltage transformers, breakers, batteries, and
communication links.
Failure in any one of these blocks will disrupt the
relay protection scheme.
As mentioned above, utilities perform tests
on CTs, PTs, the battery system, and circuit
breakers. However, the results of periodic
maintenance testing typically are not shared
with relay protection engineers. As an example,
protection staff may not be aware of newly
developed sluggishness in breaker opening
time or that the age of a CT may have led to
deterioration of the saturation characteristics
level. In some cases, we do notice an exchange
of CT, PT, and circuit breaker testing data
especially in the event of relay mis-operation
leading to forensic analysis. The team responsible
for maintaining relay settings should be kept
updated with these test results since access to this
knowledge can impact the assumptions used to
develop relay settings.
A HOLISTIC APPROACH TO
RELAY PROTECTION
The relay protection scheme is the nucleus with
all necessary logic built in; the other elements
support relay protection schemes. CTs and PTs
provide current and voltage inputs to the relays.
The relays in turn provide input to energize the
trip circuit resulting in opening of the breaker to
isolate the faulted section of the power system.
Station batteries, another building block of
relay protection, energize the tripcircuit with
a DC supply. Understanding how each of these
components contributes to proper operation
of the relay protection scheme is essential to
smooth operation of your protection system.
ADVANCEMENTS IN INDUSTRY
Relay
Protection
Scheme
CTs PTs
Communication
Links
Breakers Batteries
96 • SUMMER 2022
Relays
Engineers must select appropriate relays and
provide appropriate settings. The relays and
protection schemes must be tested at the time
of commissioning, and subsequent maintenance
must be performed at predefined intervals.
For relay testing, a software program that
provides a comprehensive test environment
flexible enough to accommodate technical
and operational requirements — including for
networks based on IEC 61850 standards — is
ideal. The right software can help standardize
elements of the relay testing program, reduce
complexity, provide consistency, and capture and
store important maintenance information and
test records. This automation enables increased
efficiency, accuracy, and productivity.
Any shortcomings in selection, setting, wiring,
or testing can lead to mis-operation of the
relay protection scheme during abnormal
system conditions. Some schemes include
communication links between the relays at
the two ends of a transmission line. End-
to-end testing must be performed to ensure
correct operation of the protective relay scheme
including receivers and transmitters.
Furthermore, digital substations built around
the IEC 61850 standard have different testing
needs than conventional substations. Testing in
digital stations involves extensive verification of
communication between the relays. There is a
need to test the entire system as an entity, and
system simulators can provide a solution for
testing IEC 61850-based protection devices and
schemes.
Current Transformers
The role of a CT is much simpler than the role
of a relay. CTs simply provide current to the
relays. The primary winding of the CT sees the
actual current in the circuit while its secondary
winding provides reduced current levels based
on the ratio of the CT. Under normal load
current, CTs reproduce currents correctly.
However, during short-circuit conditions when
fault current is high, CTs may not reproduce
the current accurately. Under such conditions,
the current provided to the relay is normally
lower than what it is expected. The degree of
inaccuracy will depend on the magnitude of
the short circuit current, X/R ratio, etc. This
behavior of the CT is due to saturation of the
CT core, which impacts the performance of
simple overcurrent, distance, and differential
relays.
It is very important to perform the following
tests on CTs:
• CT excitation
• Current ratio
• Polarity
• Ratio and phase angle error
• Insulation resistance
• Winding resistance
• Burden check
Each utility determines the maintenance interval
for testing based on its internal procedures.
Instruments designed specifically for testing CTs
can help increase productivity and save time
during commissioning. The ideal test set can
verify CT excitation curve, polarity, and ratio. It
can also perform phase angle and burden tests and
measure insulation level and winding resistance.
THE KEY TO RELAY PROTECTION SUCCESS: COOPERATION
ADVANCEMENTS IN INDUSTRY
Bushing CTs
In digital substations that implement process
bus, the analog values of CT outputs are fed
into a merging unit. The merging units provide
equivalent digitized samples that are fed into
IEC 61850-ready intelligent electronic devices
(IEDs). IEDs are essentially microprocessor
relays with significant built-in protection and
communication logic. The IEC 61850-ready
IEDs cannot accept analog signals from CTs and
PTs, hence digitized samples must be provided.
In this case, in addition to testing the CTs, the
merging units must be tested as well.
Some merging units have built-in optical CTs
and do not require input from conventional
inductive CTs. These merging units require
special testing tools and techniques.
Circuit Breakers
Circuit breakers must trip (open) when called
upon by the protective relaying. If the dedicated
breaker does not open, back-up protection will
ADVANCEMENTS IN INDUSTRY
Stand-Alone CTs
PH
O
TO
: ©
 W
W
W
.S
H
U
TT
ER
ST
O
C
K.
C
O
M
/G
/S
O
M
SI
T
98 • SUMMER 2022
cause other related breakers to open in order to
isolate the faulty equipment. However, the fault
clearance by backup relaying will cause an outage
of a larger part of the system; although this is
not desirable, it is necessary. For this reason, it is
essential for breakers to be maintained and tested
appropriately to perform this function.
In addition to a breaker failing to open, issues
can also be created if it takes longer than
necessary to open the contacts. In protective
schemes, breaker opening time is taken into
consideration when setting a relay scheme. An
actual contact opening time that exceeds the
time that was used in the relay settings can cause
unnecessary outage of a larger part of the system.
For example, when we set up a breaker failure
scheme, we use the breaker opening time in
the calculations. If the actual time turns out
to be greater, several breakers will trip as part
of a back-up scheme. This is an undesirable
situation leading to the tripping of the
entire bus. Similarly, when coordinating two
overcurrent relays, miscoordination will occur
if a breaker takes much longer to open. Hence,
testing breakers is critical to ensure that they
are operational within published parameters
including the contact opening times.
The following tests must be run to ensure the
integrity of circuit breakers:
 1. Breaker timing
 2. Static contact resistance
 3. Dynamic contact resistance
 4. Trip and close coil currents
 5. Minimum pickup voltage
 6. Travel time
 7. Power factor test
In addition, specific tests are conducted on SF6,
vacuum, and air-blast breakers. A state-of-the-
art circuit breaker analyzer can provide efficient
and accurate performance measures for all
types of circuit breakers. Digital circuit breaker
analyzers can perform dynamic resistance tests
and measure main contact and resistor contact
time, stroke, velocity, over-travel, bounce-back,
and contact wipes.
Battery System
The battery system plays a vital role in completing
the sequence of tripping circuit breakers when
called upon by the protective relaying scheme.
The trip coil that is responsible for tripping the
circuit breakers is energized when DC voltage is
provided to it, and the protective relays provide
the permissive. If relays provide the permissive but
no DC power is available, the trip coil will not
energize, and the breaker will not trip. Batteries
are a crucial link in the chain of events and must
be tested at regular intervals to ensure integrity.
To ensure the battery system is operational and
will comply within specified parameters, the
following tests are recommended:
 1. Impedance
 2. Intercell resistance
 3. Voltage (battery float and cell float)
 4. Specific gravity
 5. Current
 6. Temperature
 7. Discharge testing
 8. Infrared scanning
 9. Capacity testing
THE KEY TO RELAY PROTECTION SUCCESS: COOPERATION
ADVANCEMENTS IN INDUSTRY
Circuit Breaker
 WWW.DOBLE.COM/SERVICES
QUALITY LABORATORY
DATA FOR CRITICAL
DECISIONS
Reliable
Safe
Secure
EST.
1920
Specialty & routine testing on both liquid & solid dielectrics
Direct access to industry renowned subject matter experts
At the forefront of testing innovation
89+ years of laboratory experience
u
u
u
u
• Ratio and phase angle error
• Insulation resistance
• Winding resistance
• Burden check
• Power factor test
The tests to be conducted and the related
maintenance interval are listed in the
maintenance procedures. In general, the
ADVANCEMENTS IN INDUSTRY
Battery System
Potential Transformers/CCVTs
The impact of inductive and capacitive potential
transformers on relaychallenging business. It tests
you mentally and physically. There have been
times where I have wanted to throw my tools
down and walk out the door. So what keeps
me committed? The recognition I get when
customers and other industrial professionals
seek me out to help them solve problems. It’s
sort of like that sweet golf shot that keeps you
coming back and playing that frustrating game.
NW: What about this work is specifically
challenging for you, and how are you
overcoming that challenge?
Ramieh: I’m challenged by the “race to the
bottom” pricing of many clients, including
large utilities that shall remain nameless. As
salaries continue to increase for P&C talent,
customers continue to expect more for less.
NW: If you were talking to a young person
interested in knowing more about being an
electrical testing technician, how would you
describe the job, and what advice would you
give?
Ramieh: Every day is different. Just when
you think you have it all figured out, there
will be something new. A symptom of a
problem that you have never seen before will
derail your troubleshooting and challenge your
understanding of electrical power. It can be
frustrating to have to wait to take the NETA
Level 3 exam, but those five years are important
to become exposed to as many situations as
possible.
My best advice: There is always that point
in the project when the bulk of the work is
done. Everyone is tired and ready to go home.
Typically, one or two of the most experienced
technicians are tasked with getting the plant
back online. Inevitably, there will be something
that does not work like it is supposed to. It is
those moments where the greatest learning
happens. Be in the hip pocket of those guys
every chance you get. Avoid being the ones
who are hanging out at the truck waiting to
drive out the gate. Volunteer for every night,
weekend, difficult job, and emergency call-out.
That is where we begin to separate the good
technicians from the great ones.
Second best advice: Do not violate the laws of
physics to explain why something happened.
The vast majority of electrical problems and
failures are simple, and people try to make it
way too complicated.
NW: Describe one of your best work days…
What happened?
Ramieh: My best day was actually a
several-week-long project. It involved testing
a 34-breaker metal-clad substation three
times: once at the factory with the individual
sections free standing in a warehouse, and the
second time after the individuals sections were
packaged into their e-houses. The final testing
was after their installation onsite. The final
installation was completed in seven long days
involving dozens of men from the equipment
manufacturer, relay manufacturer, electrical
contractor, and our company. When the power
to the plant was restored, the client and I stood
outside the substation fence and enjoyed a cigar
in celebration of a project well done.
I also got a hug from a client. On a Friday
around 4:00 PM, a small data center lost
power, and their transfer switch didn’t
transfer to emergency. I got the second call
and was the first to arrive onsite. The facility
manager (a young lady) was frantic and her
boss (in New York City) was on the phone
attempting to give directions. Following
one of my rules (slow it down), I calmly
assessed the situation and politely ignored
the guy from New York City. Identifying the
problem, I enabled the transfer switch, and
the lights came back on at the data center.
She was so overjoyed, she gave me my first
and only customer hug for a job well done.
NW: Share the story of a day that didn’t
go as planned. How did you respond to the
situation and what did you learn?
INSIGHTS & INSPIRATION
MOSE RAMIEH III: STAY INVOLVED TO STAY RELEVANT
TO THIS DAY, MOSE
CLAIMS HE IS ON
CALL 24/7/365
TO ASSIST
ANYONE WITH
AN ELECTRICAL
CHALLENGE. THAT
INCLUDES YOU,
SO BE SURE TO
CONNECT WITH
HIM ON THE
SOCIALS.
Ramieh: I can think of several:
•	 A technician opened a switch under
load causing damage to equipment and
shutting down production.
•	 A set of grounds on a 161 KV system
was overlooked and closed in a live
switch, causing significant damage and an
extended outage.
•	 A technician re-energized a
13.8 KV system, and a potential
transformer drawer blew up because of
condensing moisture in the room.
•	 A technician inadvertently left a tool in a
breaker, and it exploded and caught fire.
Some lessons were also learned from pain:
•	 Superior performance is often the result
of prior bad experiences.
•	 In each of these situations, immediately
stepping up and taking ownership for
any contribution to the event would
have created customer loyalty in my
experience.
•	 When things go wrong, slow it down.
Rushing to fix the situation can create
additional issues and hazards.
•	 Take care of the people involved. They are
often scared and are beating themselves
up for the mistakes they made. You aren’t
helping by beating them more.
•	 Document the lessons learned and update
procedures and processes to avoid these
mistakes in the future.
NW: How important is ongoing training
and professional development in this field?
How do you keep updated on standards,
safety, and new technologies?
Ramieh: It’s important to stay involved in
the industry to stay relevant. Training and
professional development is important, but it
pales in the face of doing the work. The best
technician will get rusty if they aren’t in the
plants and substations doing the work.
INSIGHTS & INSPIRATION
E A S T E R N H I G H V O L T A G E , I N C . AREAS OF EXPERTISE
PREVENTATIVE ELECTRICAL MAINTENANCE
PROGRAMS
DATA CENTERS, COMMERICAL HIGH RISES,
CRITICAL ENVIRONMENTS & FINANCIAL
INSTITUTIONS
DEVELOPMENT & UPDATES OF ELECTRICAL
SINGLE LINE DIAGRAMS
EMERGENCY GENERATOR & PARALLELING
SWITCHGEAR TESTING
SITE SPECIFIC SAFETY & TECHNICAL TRAINING
24HR EMERGENCY SERVICE
INFRARED SCANNING
ACCEPTANCE TESTING
ENGINEERING STUDIES · ARC FLASH, SHORT
CIRCUIT & COORDINATION
11A SOUTH GOLD DRIVE, ROBBINSVILLE, NJ 08691 · (609) 890-8300 · www.easternhighvoltage.com
12 • SUMMER 2022
Building relationships with individuals and
companies that are developing the technology is
the best way. New testing technology? Become
an early adopter. Learn how to use it and be
part of the group that refines the technology.
Build your network so that when you come
across a situation you are not familiar with,
you can call on others for help. Avoid being an
island. As tempting (and easy) as it has been
for me to be a “cowboy” over the years, my best
results have come from involving other smart
individuals.
NW: What are some of the energy trends
you believe will affect your work in the
future (e.g., EVs, wind, solar, etc.)? How are
you preparing for future changes that may be
coming your way?
Ramieh: I’m of the opinion that I don’t
much care how the power is produced (carbon
fuels or renewable sources) — electrons are
electrons. In my view, my function and our
team’s function is to ensure that the power
systems that distribute that power are safe
and reliable. I am personally most curious
about energy storage systems and how they
could possibly change the future of power
production.
I am currently working on using wearable,
hands-free computer technology to see how
that will empower the technicians of the future,
including the availability of remote expert
assistance and streamlined testing processes.
NW: As an industry, what do you think
should be the No. 1 priority over the next
year? Where do we need to improve and grow
as an industry and a profession?
Ramieh: The No. 1 priority is recruiting the
next generation of technicians. The demand for
our services is only increasing, and the supply
of the men and women to do the work is not
keeping up. As an industry, we must focus on
hiring inexperienced people and training them
quickly.performance is important.
However, PTs/CCVTs do not undergo the type
of duty that CTs undergo, and the performance
of CTs has a much greater impact than those of
PTs/CCVTs. During short circuit faults, the high
current imposes extreme pressure on CTs. On the
other hand, the voltage during short-circuit faults
is depressed; therefore, the PTs do not experience
any stress and continue performing as usual.
Even with less stress imposed on PTs/CCVTs
during short circuit, these devices are prone to
damage due to other external and internal system
conditions. Hence, they may not perform at the
expected level of performance. PTs/CCVTs are as
critical as CTs in ensuring correct operation of the
relay protection scheme.
The recommended tests include:
• Voltage ratio
• Polarity
100 • SUMMER 2022
maintenance interval for PTs/CCVTs is much
longer than those for CTs.
Communication Links
Communication is a critical link in
several protection schemes. In high-speed
communication-assisted protection schemes,
communications between the two substations
are connected by a transmission line. The
relaying at each end depends on information
received from the other end to operate correctly.
The medium used for communication can be
fiber optic, power line carrier, microwave, etc.,
with transmitters and receivers installed at each
end. To test such relay schemes, utilities conduct
end-to-end testing to ensure the scheme works
appropriately, and this testing includes both the
transmitters and receivers.
in a digital substation designed per the IEC
61850 standard, the IEDs communicate with
each other using GOOSE (generic object-
oriented substation event) and SV (sampled
value) protocols. GOOSE/SV is a layer-2
protocol for messages transported over Ethernet.
In a conventional station, communication
between IEDs is accomplished via point-to-
point wiring. Hence, communication assumes
a much bigger role in a digital substation, and
the relay protection scheme relies heavily on
proper communication. Testing such protection
schemes involves extensive debugging of the
communication network.
CONCLUSION
Relay protection is a multifaceted scheme
comprised of relays, breakers, CTs/PTs/CCVTs,
batteries, and communication links. Effective
relay protection is achieved only if all constituent
components work together and perform within
an acceptable level of performance.

Ed Khan has been with Doble Engineer-
ing Company for 14 years working in var-
ious capacities including Product Manager
for protection testing-related instruments.
He is currently the Director of Protection
R&D and Protection Training at Doble.
In this capacity, he manages and con-
ducts the relay protection training program. Prior to Doble,
Ed worked for GE, ABB, SEL, KEMA, and others in various
capacities. He has 38 years of experience in system studies, pro-
tection applications, relay design, power plant design, teaching,
and product management. He has thorough knowledge about
product development, protection, harmonic analysis, harmon-
ic filter design, stability studies, real-time digital simulations,
generator protection, and more. Ed has written several articles
and has made presentations at several venues. He holds an MS
in electrical engineering from Texas A&M University.
ADVANCEMENTS IN INDUSTRY
THE KEY TO RELAY PROTECTION SUCCESS: COOPERATION
ORDER NOW
Visit NETAWORLD.ORG
or call 888.300.6382
FEATURING NEW CONTENT
Arc Energy Reduction System Test
Partial Discharge Survey for
Switchgear Updates
NEW
EDITION
2021
102 • SUMMER 2022
SPECIFICATIONS AND STANDARDS ACTIVITY
ANSI/NETA STANDARDS UPDATE
ANSI/NETA ETT–2022
REVISION COMPLETED
ANSI/NETA ETT, Standard for Certification of Electrical
Testing Technicians, has completed an American National
Standard revision process. ANSI administrative approval was
granted January 7, 2022. The new edition was released at
PowerTest in March 2022 and supersedes the 2018 edition.
ANSI/NETA ETT establishes minimum requirements
for qualifications, certification, training, and experience
for the electrical testing technician. It provides criteria for
documenting qualifications for certification and details the
minimum qualifications for an independent and impartial
certifying body to certify electrical testing technicians.
ANSI/NETA STANDARDS UPDATE
2021
STANDARD FORACCEPTANCE
TESTING SPECIFICATIONS
FOR ELECTRICAL POWER EQUIPMENT & SYSTEMS
ANSI/NETA ATS-2021
WWW.NETAWORLD.ORG
A
N
SI/N
ETA
 STA
N
D
A
RD
 FO
R C
ER
TIFIC
A
TIO
N
 O
F ELEC
TR
IC
A
L TESTIN
G
 TEC
H
N
IC
IA
N
S
ANSI/NETA ETT-2022
STANDARDS
2022
2022
STANDARD FOR
CERTIFICATIONOF ELECTRICAL TESTING TECHNICIANSFOR ELECTRICAL POWER EQUIPMENT & SYSTEMS
WWW.NETAWORLD.ORG
A
N
SI/N
ETA
 STA
N
D
A
RD
 FO
R ELECTRICA
L CO
M
M
ISSIO
N
IN
G
 SPECIFICA
TIO
N
S
ANSI/NETA ECS-2020
STANDARDS
2020
2020
STANDARD FOR
ELECTRICAL
COMMISSIONING SPECIFICATIONS
FOR ELECTRICAL POWER EQUIPMENT & SYSTEMS
REVISION
COMPLETE
REVISION
SCHEDULED
NETAWorld • 103
SPECIFICATIONS AND STANDARDS ACTIVITY
ANSI/NETA STANDARDS UPDATE
ANSI/NETA MTS–2019
REVISION SCHEDULED FOR 2022
A project intent notification was published in ANSI’s
Standards Action on October 26, 2021, announcing the
opening of a 45-day public comment period. The initial
ballot is expected to begin in June of 2022. A second ballot
is scheduled for issue in November of 2022. The revised
edition of NETA MTS is scheduled to debut at PowerTest
2023.
ANSI/NETA MTS contains specifications for suggested
field tests and inspections to assess the suitability for
continued service and reliability of electrical power
equipment and systems. The purpose of these specifications
is to assure that tested electrical equipment and systems
are operational and within applicable standards and
manufacturers’ tolerances, and that the equipment and
systems are suitable for continued service. ANSI/NETA
MTS–2019 revisions include online partial discharge
survey for switchgear, frequency of power systems studies,
frequency of maintenance matrix, and more. ANSI/NETA
MTS–2019 is available for purchase at the NETA Bookstore
at www.netaworld.org.
ANSI/NETA ECS–2020
LATEST EDITION
ANSI/NETA ECS, Standard for Electrical Commissioning
of Electrical Power Equipment & Systems, 2020 Edition,
completed the American National Standard revision process.
ANSI administrative approval was received on September 9,
2019. ANSI/NETA ECS–2020 supersedes the 2015 Edition.
ANSI/NETA ECS describes the systematic process of
documenting and placing into service newly installed or
retrofitted electrical power equipment and systems. This
document shall be used in conjunction with the most recent
edition of ANSI/NETA ATS, Standard for Acceptance Testing
Specifications for Electrical Power Equipment & Systems.
The individual electrical components shall be subjected to
factory and field tests, as required, to validate the individual
components. It is not the intent of these specifications
to provide comprehensive details on the commissioning
of mechanical equipment, mechanical instrumentation
systems, and related components.
The ANSI/NETA ECS–2020 Edition includes updates
to the commissioning process, as well as inspection and
commissioning procedures as it relates to low- and medium-
voltage systems.
Voltage classes addressed include:
• Low-voltage systems (less than 1,000 volts)
• Medium-voltage systems (greater than 1,000 volts and
less than 100,000 volts)
• High-voltage and extra-high-voltage systems (greater
than 100 kV and less than 1,000 kV)
References:
• ASHRAE, ANSI/NETA ATS, NECA, NFPA 70E,
OSHA, GSA Building Commissioning Guide
ANSI/NETA ATS–2021
LATEST EDITION
ANSI/NETA ATS, Standard for Acceptance Testing
Specifications for Electrical Power Equipment & Systems, 2021
Edition, has completed an American National Standard
revision process. ANSI administrative approvalwas granted
September 18, 2020. The new edition was released in March
2021 and supersedes the 2017 edition.
ANSI/NETA ATS covers suggested field tests and
inspections for assessing the suitability for initial
energization of electrical power equipment and systems.
The purpose of these specifications is to assure that tested
electrical equipment and systems are operational, are within
applicable standards and manufacturers’ tolerances, and are
installed in accordance with design specifications. ANSI/
NETA ATS-2021 new content includes arc energy reduction
system testing and an update to the partial discharge survey
for switchgear. ANSI/NETA ATS-2021 is available for
purchase at the NETA Bookstore at www.netaworld.org.
PARTICIPATION
Comments and suggestions on any of the standards
are always welcome and should be directed to NETA.
To learn more about the NETA standards review
and revision process, to purchase these standards,
or to get involved, please visit www.netaworld.org or
contact the NETA office at 888-300-6382.
104 • SUMMER 2022 NETA WELCOMES CFM SERVICES AS NETA ACCREDITED COMPANY
CFM Services, Inc. is an electrotechnical and
engineering service firm formed by Christian
Comtois, Stéphane Forgues, and Frédéric
Morin to offer quality services at competitive
prices. The young and dynamic company
specializes in electrical services and electrical
power. CFM offers maintenance services,
testing, installation, repair and engineering
in the areas of production, processing and
distribution of low-, medium- and high-voltage
electricity.
Since its debut, CFM Services has quickly
earned a standout spot on the electrical and
electrotechnical market with technicians and
engineers who are qualified to test, diagnose,
and repair your equipment with high-quality
service. CFM’s instruments are  at the cutting
edge of technology and are calibrated annually.
CFM’s team of engineers  provides a wide
range of engineering services and is available
to complete the simplest projects to the most
complex ones.
“CFM Services is excited to achieve NETA
accreditation because our existing and future
customers require the structure, expertise,
training, and documentation that NETA
provides,” says Frédéric Morin, Vice President
of Engineering. “While we believe we have
these qualities as a company and as highly
PH
O
TO
: ©
 IS
TO
C
KP
H
O
TO
.C
O
M
/P
O
RT
FO
LIO
/B
A
RT
C
O
NETA WELCOMES
CFM SERVICES AS
NETA ACCREDITED COMPANY
experienced field technicians, this is our
opportunity to show that more concisely
through NETA accreditation.”
“NETA recognizes the hard work NETA
Accredited Companies like CFM Services have
to put in to achieve this important milestone,”
says Eric Beckman, PE, President of National
Field Services, Inc. and current NETA
President. “NETA Accredited Companies
play a critical role in securing electrical power
system safety and reliability for all, and NETA
is a stronger organization due to the dedication
of these companies to our industry.”
CFM Services Inc.
845 St-Jacques Local 600
St-Jean-sur-Richelieu
Québec J3B 2N2
514-316-8512
info@cfmservices.ca
106 • SUMMER 2022 OUTSTANDING ACHIEVEMENT AWARD RECIPIENT KEN BASSETT:
‘NETA INSPIRED ME TO BE A FORCE FOR GOOD’
In NETA circles, Ken Bassett winning his third Outstanding Achievement
Award is business as usual. The Washington Commanders fan with a
sense of adventure was honored again for the third time at PowerTest
2022. A family-focused individual whose company includes many of his
family members, his influence in NETA is far-reaching.
“Ken is and has been one of the most dedicated
individuals within NETA. He’s done so much
for the organization, from strategic initiatives
to growing membership,” says Eric Beckman,
President of National Field Services and NETA
President. “He holds a passion for the industry,
and there’s no doubt NETA would not be
where it is today without Ken’s contributions
to the organization.”
Bassett, President of Potomac Testing, Inc.,
should have been the least surprised person
when the winner was announced, but humor
and humility are core features of his life.
OUTSTANDING ACHIEVEMENT
AWARD RECIPIENT KEN BASSETT:
‘NETA INSPIRED ME TO BE A FORCE FOR GOOD’
Ken Bassett Accepting the Outstanding Achievement Award.
NETAWorld • 107OUTSTANDING ACHIEVEMENT AWARD RECIPIENT KEN BASSETT:
‘NETA INSPIRED ME TO BE A FORCE FOR GOOD’
“My first reaction was ‘I’m going to have
one hell of a bar tab,’” Bassett laughed. “But
seriously, I was very surprised and caught off
guard. Every year, we have many deserving
individuals who support our association. To be
recognized this year, or any year, is surely an
honor.”
Ron Widup, Vice Chairman of NETA’s Board
of Directors and Senior Advisor for Technical
Services for Shermco Industries says Bassett’s
reputation for being one of the hardest-
working members of NETA as well as one of
the hardest-working members of the electrical
testing industry makes him a leading candidate
for the award every year.
Widup points to a favorite quote by Amy
Poehler — actress, comedian, writer, producer,
and director: Find a group of people who
challenge and inspire you, spend a lot of time with
them, and it will change your life. “Ken’s work
with NETA has inspired and changed us —
and that’s a good thing,” Widup says.
Ironically, Bassett says NETA inspired him to
be a force for good.
“Early on in my NETA career, I was fortunate
enough to interact with some amazing folks,”
Bassett says. “Those individuals represented
the Association in a truly inspiring way. The
Ken with Ron Widup and John White after
another successful Member Review Committee
meeting.
Ken with his daughters Crystal and Michelle, wife Jayne, and son Marshall hopping a plane to see
Denali Mountain.
108 • SUMMER 2022 OUTSTANDING ACHIEVEMENT AWARD RECIPIENT KEN BASSETT:
‘NETA INSPIRED ME TO BE A FORCE FOR GOOD’
meaningful work and accomplishments I have
experienced with the Association are things
they instilled in me as business-as-usual — the
NETA way of thinking.
“Mary Jordan, Charlie Blizard, Rod Hageman,
and Al Peterson are some of the early
relationships that influenced me extensively,”
Bassett continues. “At that time, NETA was
a smaller, scrappier association, and we had
to fight hard for everything we created and
accomplished. These folks helped inspire and
create the work-hard/play-hard culture that still
lives within NETA now. My continued belief
in our organization stems from the people I
have been fortunate enough to spend time
with since we joined NETA in 1993. These
past leaders had great vision and represented
our association well.”
Bassett says that can-do attitude will be one
of the most important things for NETA to
hold onto in the coming years. “NETA has
always been very mindful of its succession
of leadership, which has provided the ability
to maintain a high level of success over the
years. Proper planning has enabled NETA to
accomplish many goals over a long period of
time,” he notes.
Like any organization or association, NETA
must continue being mindful of what led to
its successes and, at the same time, adapt and
react to the industry it serves, Bassett says.
“During my tenure, acceptance of the NETA
standard has grown immensely, specifically
by A&E firms and end users. Additionally,
safety continues to be at the forefront of
our industry. And as the industries we serve
MEET KEN BASSETT
Bassett is President of Potomac Testing has
a NETA Accredited Company with service
centers located throughout the Mid-Atlantic
region. Established in 1985, Potomac Testing,
Inc. has earned its position as the Mid-Atlantic
leader in comprehensive low- and medium-
voltage electrical equipment services including
NETA acceptance and maintenance testing,
planned and emergency field services,
power quality and engineering studies,
andretrofitting and refurbishing electrical
equipment. Potomac Testing joined the TechPro
Power Group family of companies in 2020.
Bassett has served on NETA’s Board of
Directors since 1998. A past-President, he
currently chairs the Membership Committee,
co-chairs the Association Development Committee, and serves on the Nominating
Committee, NAMO Committee, Promotions & Marketing Committee, Conference
Committee, CTD Review Committee, and Finance Committee.
Bassett is a NETA Certified Test Technician with over 25 years of experience in the
operation and maintenance of electrical power distribution systems.
NETAWorld • 109OUTSTANDING ACHIEVEMENT AWARD RECIPIENT KEN BASSETT:
‘NETA INSPIRED ME TO BE A FORCE FOR GOOD’
continue to expand, where NETA mainly
supported industrial and commercial end
users, NETA now has a very large presence
within the utilities market, assisting them
with their required maintenance and system
upgrades.”
The strategic plan developed in 2019 was
dedicated to supporting the Association’s
growth, and Bassett’s focus on growing
membership has allowed NETA to stay ahead
of the ever-changing electrical testing industry.
“There is no argument that it takes many
people with passion and a desire to succeed for
an industry association like NETA to thrive,
and Ken has been an inspiration to all of us
as we work beside him,” says Ron Widup.
“Having a business in the Washington, DC,
metro area has also given Ken the unique ability
to listen first and speak second. This allows him
to get things done without weakening his — or
NETA’s — position. That’s a special leadership
talent that NETA has benefitted from many
times through the years.”
“My belief in our organization stems from the
people I have been fortunate enough to have
spent time with,” says Bassett. “These past
leaders had great vision and represented our
association well.”
Ken and family getting ready to launch at a hot-air balloon festival in Albuquerque.
Ken and Jayne cruising the strip during a NETA site visit in Dubai.
P O W E R T E S T 2 0 2 2 A W A R D R E C I P I E N T S
CONGRATULATIONS
JAMES R. WHITE ELECTRICAL SAFETY TRACK
Safety Performance and Corporate
Profitability as a Contractor in the High
Voltage Utility Sector
Ken Peterson
HAMPTON TEDDER TECHNICAL SERVICES
EQUIPMENT TRACK
Battery Health and Assessment through
Electrical Testing
Volney Naranjo & Sanket Bolar
MEGGER
RELIABILITY TRACK
Challenges and Opportunities: How the
Focus on Reliability Impacts the NETA
Practitioner
Alan Ross
ELECTRIC POWER RELIABILITY ALLIANCE
SALES & MANAGEMENT TRACK
Creating a Comprehensive Employee
Development Program: A Case Study
Stephanie McLaughlin
HOOD PATTERSON & DEWAR
RENEWABLE ENERGY TRACK
Improving the Reliability of MV Cables
through Testing & Diagnostic Techniques
for Wind Farm Applications
Jason Aaron & Charles Nybeck
MEGGER
BEST OVERALL PRESENTATION
Relay Panel Session
Drew Welton, Karl Zimmerman,
Chasen Tedder, Lorne Gara,
and Chris Werstiuk
THE JAMES R. WHITE SAFET Y AWARD
The James White Family
ALLIANCE RECOGNITION AWARD
Drew Welton
I N T E L L I R E N T
OUTSTANDING ACHIEVEMENT AWARD
Ken Bassett
P O TO M A C T E ST I N G
S TA N D O U T S E S S I O N S
T O P - T I E R B O O T H S A N D S U I T E S
MOST APPETIZING SUITE
MOST TECHNICAL SUITE
Electric Power Systems
MOST ENTERTAINING SUITE
ECP Solutions
MOST HOSPITABLE SUITE
Group CBS
MOST VISITED BOOTH
AVO Training Institute
MOST CREATIVE SUITE
Shermco Industries
MOST INNOVATIVE BOOTH
Intellirent
BEST IN SHOW BOOTH
Protec Equipment Resources
BULLOCK BREAKERS
BB
475 Annandale Blvd • Annandale • Minnesota 55302
www.bullockbreakers.com • Email: jason@bullockbreakers.com
• Thousands of Air Circuit Breakers in Stock!
• Switchgear Line-ups you can’t find anywhere else!
• Now Available as Reconditioned with AC-Pro Trip Units!
1-763-269-2832
40+ Years
Experience High Voltage - High Current - High Power Test Systems and Components
High Current Circuit Breaker Test Sets
 � 9 models available
 � 1,000 to 75,000 Amp Outputs
 � Updated control system, automated
 testing, data acquisition
Micro-Ohm Meters
 � Accurately measure very
 low contact resistances
 � Double ground
 measurements (substation)
 � 5 models available,
 10 to 200 Amp
DC Hipots with Automated Features
1-301-746-8118 • www.PhenixTech.com
info@phenixtech.com • 75 Speicher Drive, Accident, MD 21520 USA
A Wide Range of Test Systems Available
Unmatched Reliability and Performance!
 � 7” Full-color, touch screen display
 � Auto-ranging meters
 � Automatic voltage control or
 Manual control via infinity dial
 � Data acquisition
112 • SUMMER 2022 ALLIANCE RECOGNITION AWARD HONOREE KNOWN FOR EXPERTISE AND TRAINING
If the name Drew Welton sounds familiar, it’s most likely because his
technical presentations, including those at PowerTest, are some of the
most well-regarded and well-attended.
That accolade combined with his renown
for knowledge of substation maintenance
testing made him the obvious choice for this
year’s Alliance Recognition Award. The award
honors an individual who has been a dedicated
supporter of NETA and has also furthered the
industry and inspired others.
Welton, Vice President of Sales and Business
for intellirent, credits his success over the years
to the incredible support of his family, friends,
and colleagues.
“None of it would have been possible had I not
had great support from my family, especially
ALLIANCE RECOGNITION
AWARD HONOREE
KNOWN FOR EXPERTISE AND TRAINING
Drew Welton Accepting Alliance Recognition Award
NETAWorld • 113ALLIANCE RECOGNITION AWARD HONOREE KNOWN FOR EXPERTISE AND TRAINING
Stacey, my wife of 26 years,” he says. “This
industry we work in can be very demanding
in terms of time away from home and a
commitment to often working long hours.
My passion for the industry has always been a
driving force, especially because of all the great
people I’ve worked with.”
Among those treasured colleagues is Wayne
Hartmann, who has known Welton for more
than 30 years, worked with him in multiple
capacities, and considers him a friend.
“I have seen Drew grow in the industry and
transcend the roles of student, practitioner,
and now teacher,” says Hartmann, Solutions
Growth Leader, North America, for GE Grid
Automation. “He has embraced the power of
education as a philosophy with his numerous
papers, presentations, and training materials
that address testing and commissioning of
system protection and primary infrastructure.”
“We tag-teamed at Western Electric Institute’s
Relay School for years, and it was enjoyable and
a highlight of each year we taught there,” he says.
“I was there with an in-depth professional in
Drew, and the students, facilitators, and steering
committee could all see that.”
Neil McCaw, President of intellirent, says
Welton continues to exude that air of expertise
combined with a willingness to help and share
his knowledge.
“Drew’s passion and commitment to this
industry is unparalleled. He is deeply respected
by his colleagues and customers and is someone
who takes on challenges with optimism and a
commitment to solving the problem,” McCaw
says. “He is an amazing resource to customers
and his fellow employees and a huge contributor
in knowledge sharing in our field. The entire
intellirent team is thrilled to congratulate him
on this honor and achievement.”
Known for doing the work for work’s sake —
not for recognition or praise — Welton was
understandably surprised to hear his name
announced at the presentation.
“It took me a while to realize what was
happening, and I was wondering why my
boss was videotaping the presentation,”
he says. “These are all wonderful people,
and the emotion of the moment was quite
overwhelming.”
Much as the award was a surprise, Welton
admits that his career in electrical testing was
unexpected as well.“I really didn’t intend on working in this
particular industry. I have a bachelor’s degree
in business administration from a small college
in Colorado and sold radio advertising as my
first job,” he says.
Drew and Stacey Welton
114 • SUMMER 2022 ALLIANCE RECOGNITION AWARD HONOREE KNOWN FOR EXPERTISE AND TRAINING
“When I finally took to materials management,
I accepted a job with Beckwith Electric in
inventory control. Then Vice President of
Sales and Marketing Lew Roberson recognized
I had a gift for learning quickly and a strong
sales aptitude, so he provided me with the
opportunity to move into inside sales,” Welton
says.
“It was then I had the fortunate opportunity
to work for Charles ‘Chuck’ Mozina, who was
instrumental in teaching me so much about
protective relaying. What really helped me
turn the corner was an opportunity to join
OMICRON electronics in 1997, and over the
next 20 years or so, I came to love this industry
even more. There was so much to learn and
experience and so many great people to learn
from that I never stopped having fun.”
What Welton calls fun, intellirent’s Director of
Inside Sales Jason Creese calls a true passion for
and understanding of the industry as well as a
drive to invest in it.
“Drew’s commitment over his many years has
contributed to so many great opportunities
to learn, speak, and apply across the various
avenues within our industry,” Creese says.
“Drew is instrumental in our support of the
industry. In addition to equipment knowledge,
testing standards, and field application
awareness, he provides necessary insight into
up and coming technologies and training to
MEET DREW WELTON
Welton is the Vice President of Sales and Business
at intellirent, providing leadership to the sales teams
and developing business opportunities. He has
more than 25 years of experience in power system
engineering focused mainly on sales and sales
management for relays, controls, and primary and
secondary test equipment.
He got his start in the industry with Beckwith Electric,
then AREVA T&D before working almost 20 years
with OMICRON. Drew is a 20-year Senior Member
of IEEE-PES/IAS and an active member of the IEEE
Transformers Committee. He has authored technical
papers that have appeared in various technical
journals, including NETA World.
Welton received a bachelor’s degree in business
administration and management from Fort Lewis
College in Colorado. Today, he is highly regarded
for his knowledge of substation maintenance testing
and has conducted training sessions for substation
technicians and engineers across North America. His
technical sessions at PowerTest are highly regarded
and some of the most well-attended.
NETAWorld • 115
JET Electrical Testing, LLC is a 24/7 full
service testing company founded upon the
premise of providing exceptional customer
service and the most highly skilled
technicians in the industry. The team of
project managers, engineers, support staff,
and field technicians form the cohesive
team in which customers have relied on
year after year. JET specializes in
commissioning, preventative maintenance,
equipment repair, apparatus testing, and
emergency response/troubleshooting.
Electrical system reliability is JET’s goal.
24/7/365 Emergency Services:
609.285.2800
100 Lenox Drive, Lawrenceville NJ 08648
www.JETElectricalTesting.com
not only the team here at intellirent, but also
to our customers.”
Indeed, whether it was his own career or in the
training he provides, Welton says he always
advises others in the industry — especially
new or emerging professionals — to constantly
push to learn and grow.
“What was always important to me was helping
others and being able to share what I have learned
and experienced over the years. We often become
so complacent in our day-to-day routines that
new technologies designed to make our lives
better get overlooked. Sometimes people are
afraid to make changes or try new technologies
— especially in the field of electrical testing,”
he says. “Organizations such as NETA, IEEE-
PES/IAS, and others are continuously rewriting
standards and providing expert knowledge, and
we should be taking advantage of this. There is
always something new to improve upon.”
It’s that drive for education, improvement, and
growth that makes Welton special, Hartmann
says.
“Drew’s passion to pass on his knowledge and
experience to others truly makes him an industry
guy,” Hartmann says. “He’s the real deal.”
REAL WORLD LEARNING AT YOUR FINGERTIPS.
Introducing NETA Series III Handbooks
We’ve got answers.
Discover page after page of comprehensive, component-specific, technical resources for
training and reference purposes. Over 200 of the very best articles from NETA World
Journal and technical presentations from NETA’s PowerTest conferences.
To order, please visit netaworld.org or call 888.300.6382
NETAWorld • 117
Focused on generating powerful connections for the future, NETA’s
PowerTest Conference returned on February 28–March 4, 2022, with
more all-new content, attendee options, and networking opportunities
than ever.
The PowerTest Conference is the premier
electrical maintenance and safety conference.
It is the largest annual gathering of NETA
Accredited Company representatives and
industry professionals and is supported by
companies committed to safety, reliability,
and quality across the electrical power systems
industry.
The PowerTest 2022 agenda featured five
days of educational and interactive sessions
with an emphasis on shaping the future of the
electrical power systems industry and recreating
connections lost due to COVID. Electrical testing
technicians, engineers, and managers from a cross-
section of industries were represented and actively
engaged in making PowerTest 2022 a success.
GENERATING POWERFUL
CONNECTIONS FOR THE FUTURE
POWERTEST 2022: GENERATING POWERFUL CONNECTIONS FOR THE FUTURE
Luncheons Offered
Opportunities for
Networking
118 • SUMMER 2022 POWERTEST 2022: GENERATING POWERFUL CONNECTIONS FOR THE FUTURE
“As organizations gradually open up their
employee travel permissions in a post-pandemic
world, we were proud to welcome our loyal
and committed community to PowerTest
2022,” says NETA Executive Director Missy
Richard. “Attendees told us that the PowerTest
participants this year were the right people in
the right place at the right time. Connections
were made that will advance careers and lead to
new business.”
HIGHLIGHTS
2022 marked the first fully hybrid PowerTest,
featuring expert sessions and seminars available
in person at the Hyatt Regency Denver as
well as via PowerTest TV, a virtual conference
experience. And with on-demand content
available through June 30, PowerTest 2022 is
still more accessible than ever before:
• 332 full conference attendees
• 29 detailed, 45-minute technical
presentations by industry leaders
• 16 in-depth, 4-hour seminars covering
current topics and industry issues
• 65 Trade Show exhibitors
• More than 150 social passes for
networking events
• 18 companies delivered presentations
on the latest products and services at the
New Product Forum
Attendees were excited to be back in person
after an all-virtual event in 2021, and
exhibitors appreciated the meaningful, focused
conversations and strong leads.






50 Years of NETA
2022 marks NETA’s 50-year anniversary, and
PowerTest attendees joined in the celebration
of how far the association and the industry
have come and explored the possibilities of
the next 50 years. Special events included
a commemorative President’s Wall, all-new
contests, giveaways, and more for in-person as
well as virtual attendees.
Keynote Speaker
Acclaimed author Robert Bryce kicked off
PowerTest week with his keynote address. A
Keynote Speaker Robert Bryce
NETAWorld • 119POWERTEST 2022: GENERATING POWERFUL CONNECTIONS FOR THE FUTURE
passionateand engaging speaker, he is also
a leading thinker on global energy, power
systems, and innovation. Bryce’s sixth and
latest book, A Question of Power: Electricity and
the Wealth of Nations, was recently published,
and he is the producer of a feature-length
documentary, Juice: How Electricity Explains the
World. Attendees applauded his presentation on
energy’s impact around the world.
Monday Tracks
Monday’s sessions in six tracks were carefully
selected and presented by leading experts in the
field. Two new tracks, Sales & Management
and Renewable Energy, focused on navigating
today’s challenges and identifying tomorrow’s
industry trends.
Trade Show
Tuesday afternoon’s PowerTest Trade Show,
an industry favorite, featured 65 top-tier
vendors dedicated to providing PowerTest
attendees with actionable, real-world solutions
to everyday challenges. With door prize
giveaways, a complimentary lunch buffet, and
over five hours to explore the latest and greatest
products and services, the always-popular Trade
Show had something for everyone.
PowerTest TV featured access to exclusive on-
demand online content tailored to the needs
of electrical testing professionals as well as
opportunities to earn CEUs and NETA CTD
credits.
Attendees used PowerTest TV as a supplement
to in-person attendance or chose to participate
completely virtually with 2022’s robust,
easy-to-use platform. PowerTest TV’s virtual
registration provided access to approximately
30 hours (30 CTDs/3. 0 CEUs) worth of on-
demand content, and an addition bundle was
available for access to an extra 18 hours (18
CTDs/1.8 CEUs) of material.
NETA Exam Prep
The NETA Exam Prep Seminar at PowerTest
was back by popular demand. Open to NETA
Certified Technicians, this two-part seminar
offered a review of exam materials and the
ability to participate in the new NETA Practice
Exam. Attendees developed their knowledge and
boosted their exam confidence levels.
Reliability Track Presentation by Ross Ignall of Dranetz
120 • SUMMER 2022 POWERTEST 2022: GENERATING POWERFUL CONNECTIONS FOR THE FUTURE
NETA MEETINGS FEATURE
PEER DISCUSSION AND
LATEST NETA UPDATES
More than 120 NETA Accredited Company
representatives, Alliance Partners, and
Corporate Alliance participants gathered
on Sunday, February 28, 2022, at the Hyatt
Regency Denver for NETA’s 2022 Annual
Member and Alliance Meetings. The annual
meetings are held on the Sunday before
PowerTest and are the traditional kickoff to the
conference each year.
NETA Member Meeting
A gathering especially for representatives
and technicians from NETA Accredited
Companies, the NETA Member Meeting
brought reports from all sides of the association.
From updates on membership and strategic
initiatives to a review of program plans for the
coming year and recognition of volunteers and
committee chairs, the meeting also included
the nomination and election of officers. Newly
elected officers include 1st Vice President Bob
Shepard, Premier Power Maintenance; 2nd
Vice President Dan Hook, CBS Field Services;
and Secretary Chasen Tedder, Hampton
Tedder Technical Services; Eric Beckman,
National Field Services, continues as President
for another year. Leif Hoegberg, Electrical
Reliability Services, was elected to a three-year
Board of Directors term, while Dan Hook, Eric
Beckman, Chasen Tedder, and Dave Huffman,
Power Systems Testing, were re-elected.
NETA Member and Alliance
Meeting
NETA Corporate Alliance and Alliance
Partners were invited to join NETA Accredited
Companies for the second half of the Member
Meeting. Among other updates, participants
heard reports on industry activity from NETA
technical representatives.
Throughout PowerTest week, a series of special
events delivered opportunities for attendees to
network and lay the groundwork for future
collaborations. For upcoming Alliance Partner
events, watch your inbox for emails from
NETA and look for notices in NETA World
Journal. For additional information about the
NETA Alliance Program or to enroll, visit
www.netaworld.org/allianceprogram.
SAVE THE DATE :
POWERTEST 2023 IN ORLANDO

Join NETA and leading electrical power systems professionals at
the next premier industry conference March 8–12, 2023, at Rosen
Shingle Creek in Orlando, Florida. This year’s conference will look
and feel a little different with an all-new date pattern (Wednesday–
Sunday), but attendees will still find the tailored content and
valuable networking opportunities they’ve come to expect. Both
in-person and virtual attendance options will be offered, and early
bird registration is set to open September 1, 2022. Sponsorship
and exhibitor opportunities are available for companies seeking
leadership visibility at the event. NETA’s industry partners are
encouraged to reserve exhibit space and confirm sponsorships as
soon as possible. Inquiries should be directed to Laura McDonald
at 269-488-6382 or lmcdonald@netaworld.org.
2023
NETAWorld • 121TECH QUIZ
A N S W E R S
No. 137
ANSWERS
1. a. Occupational Safety and Health
Administration (OSHA). OSHA’s
mission is to ensure a safe and healthful
environment by setting and enforcing
standards and by providing training,
outreach, education, and assistance.
2. c. NFPA 70E. NFPA 70E, Standard
for Electrical Safety in the Workplace
helps companies and employees avoid
workplace injuries and fatalities due
to shock, electrocution, arc flash, and
arc blast and assists in complying with
OSHA 1910 Subpart S and OSHA 1926
Subpart K.
3. b. Safety briefing. A safety briefing is a
tool to increase safety awareness among
workers. It is used to discuss and share
information regarding potential hazards
and concerns.
4. c. Failure to identify or recognize
hazards. OSHA states that one root
cause of workplace injuries, illnesses,
and incidents is the failure to identify or
recognize hazards that are present or that
could have been anticipated. A critical
element of any effective health and safety
program is a proactive, ongoing process to
identify and assess hazards.
TECH QUIZ ANSWERS
5. d. All of the above. Electric shock,
arc flash, and arc blast are all hazards
associated with the use of electrical
energy. Each one must be identified and
then analyzed using a risk assessment.
6. b. Electrically safe working condition.
All other answers detail hazard control
methods, but only creating an electrically
safe working condition eliminates
the electrical hazards. An electrically
safe condition is a state in which an
electrical conductor or circuit part
has been disconnected from energized
parts, locked/tagged in accordance with
established standards, tested to verify
the absence of voltage and, if necessary,
temporarily grounded for personnel
protection.
Virginia Balitski, CET, Manager –
Training and Development has worked
for Magna IV Engineering since 2006.
Virginia started her career as a Field
Service Technologist and achieved NETA
Level 4 Senior Technician Certification.
She has since dedicated her time to the
advancement of training and safety in the electrical industry.
Virginia is a Certified Engineering Technologist through
ASET – The Association of Science & Engineering Technology
Professionals of Alberta. Virginia is current Vice-Chair of the
CSA Z462, Workplace Electrical Safety Technical Committee
and is a member of the NFPA 70E, Electrical Safety in the
Workplace Technical Committee. She was recently appointed
to the NETA Board of Directors.
122 • SUMMER 2022 NETA ACCREDITED COMPANIES
249th Engineer Battalion
249th EN BN S3 NCOIC
9450 Jackson Loop. Bldg. 1418
Fort Belvoir, VA 22060
(703) 805-9981
james.e.phillips180.mil@mail.mil
www.usace.army.mil/Home.aspx
249th Engineer Battalion, Alpha
Company
1251 Pirowski Rd, Bldg 1407
Schofield Barracks, HI 96857
(808) 787-4604
ali.n.abubekr.mil@mail.mil
SFC Aldher Maldonado Serrano
249th Engineer Battalion, Bravo
CompanyBldg 3-2631 Butner Rd
Fort Bragg, NC 28310-0001
(703) 853-3958
john.w.crosby.mil@mail.mil
SFC John Crosby
249th Engineer Battalion, Charlie
Company
9410 Jackson Loop Bldg 1416
Fort Belvoir, VA 22060-5116
(703) 806-1078
william.s.maddox13.mil@mail.mil
SSG William Maddox
249th Engineer Battalion, HHC
9450 Jackson Loop Bldg 1416
Fort Belvoir, VA 22060-5147
(571) 515-0173
SSG Michael Hamilton
ABM Electrical Power Services, LLC
720 S Rochester Ste A
Ontario, CA 91761-8177
(301) 397-3500
abm.com/Electrical
ABM Electrical Power Services, LLC
6541 Meridien Dr
Suite 113
Raleigh, NC 27616
(919) 877-1008
brandon.davis@abm.com
abm.com/Electrical
Brandon Davis
ABM Electrical Power Services, LLC
2631 S. Roosevelt St
Tempe, AZ 85282
(602) 722-2423
ABM Electrical Power Services, LLC
3600 Woodpark Blvd Ste G
Charlotte, NC 28206-4210
(704) 273-6257
ABM Electrical Power Services, LLC
6940 Koll Center Pkwy Suite# 100
Pleasanton, CA 94566
(408) 466-6920
ABM Electrical Power Services, LLC
9800 E Geddes Ave Unit A-150
Englewood, CO 80112-9306
(303) 524-6560
ABM Electrical Power Services, LLC
3585 Corporate Court
San Diego, CA 92123-1844
(858) 754-7963
ABM Electrical Power Services, LLC
1005 Windward Ridge Pkwy
Alpharetta, GA 30005
(770) 521-7550
abm.com/Electrical
ABM Electrical Power Services, LLC
4221 Freidrich Lane Suite 170
Austin, TX 78744
(210) 347-9481
ABM Electrical Power Services, LLC
11719 NE 95th St. Ste H
Vancouver, WA 98682
(360) 713-9513
Paul.McKinley@abm.com
www.ABM.com/Electrical
Paul McKinley
ABM Electrical Power Solutions
4390 Parliament Place
Suite S
Lanham, MD 20706
(240) 487-1900
ABM Electrical Power Solutions
3700 Commerce Dr # 901-903
Baltimore, MD 21227-1642
(410) 247-3300
www.abm.com
ABM Electrical Power Solutions
317 Commerce Park Drive
Cranberry Township, PA 16066-
6407
(724) 772-4638
christopher.smith@abm.com
Chris Smith - General Manager
ABM Electrical Power Solutions
814 Greenbrier Cir Ste E
Chesapeake, VA 23320-2643
(757) 364-6145
keone.castleberry@abm.com
www.abm.com
Keone Castleberry
ABM Electrical Power Solutions
1817 O’Brien Road
Columbus, OH 43228
(724) 772-4638
www.abm.com
www.abm.com
Absolute Testing Services, Inc.
8100 West Little York
Houston, TX 77040
(832) 467-4446
ap@absolutetesting.com
www.absolutetesting.com
Accessible Consulting Engineers, Inc.
1269 Pomona Rd Ste 111
Corona, CA 92882-7158
(951) 808-1040
info@acetesting.com
www.acetesting.com
Advanced Electrical Services
4999 - 43rd St. NE
Unit 143
Calgary, AB T2B 3N4
(403) 697-3747
accounting@aes-ab.com
Advanced Electrical Services Ltd.
9958 - 67 Ave
Edmonton, AB T6E 0P5
(403) 697-3747
www.aes-ab.com
www.aes-ab.com
Advanced Testing Systems
15 Trowbridge Dr
Bethel, CT 06801-2858
(203) 743-2001
pmaccarthy@advtest.com
www.advtest.com
Pat McCarthy
A&F Electrical Testing, Inc.
80 Lake Ave S Ste 10
Nesconset, NY 11767-1017
(631) 584-5625
kchilton@afelectricaltesting.com
www.afelectricaltesting.com
A&F Electrical Testing, Inc.
80 Broad St Fl 5
New York, NY 10004-2257
(631) 584-5625
afelectricaltesting@afelectricaltesting.com
www.afelectricaltesting.com
Florence Chilton
Alpha Relay and Protection Testing, LLC
2625 Overland Ave Unit A
Billings, MT 59102
(406) 671-7227
zfettig@arptco.com
www.arptco.com
Zeb Fettig
American Electrical Testing Co., LLC
25 Forbes Boulevard
Suite 1
Foxboro, MA 02035
(781) 821-0121
www.aetco.us
Jason Briggs
American Electrical Testing Co., LLC
5540 Memorial Rd
Allentown, PA 18104
(484) 538-2272
jmunley@aetco.us
www.aetco.us
American Electrical Testing Co., LLC
34 Clover Dr
South Windsor, CT 06074-2931
(860) 648-1013
jpoulin@aetco.us
www.aetco.us
Gerald Poulin
American Electrical Testing Co., LLC
76 Cain Dr
Brentwood, NY 11717-1265
(631) 617-5330
bfernandez@aetco.us
www.aetco.us
Billy Fernandez
American Electrical Testing Co., LLC
91 Fulton St., Unit 4
Boonton, NJ 07005-1060
(973) 316-1180
jsomol@aetco.us
www.aetco.us
Jeff Somol
AMP Quality Energy Services, LLC
352 Turney Ridge Rd
Somerville, AL 35670
(256) 513-8255
brian@ampqes.com
Brian Rodgers
AMP Quality Energy Services, LLC
41 Peabody Street
Nashville, TN 37210
(629) 213-4855
Nick Tunstill
Apparatus Testing and Engineering
11300 Sanders Dr Ste 29
Rancho Cordova, CA 95742-6822
(916) 853-6280
jcarr@apparatustesting.com
www.apparatustesting.com
Jerry Carr
Apparatus Testing and Engineering
7083 Commerce Cir Ste H
Pleasanton, CA 94588-8017
(916) 853-6280
jcarr@apparatustesting.com
www.apparatustesting.com
Jerry Carr
Applied Engineering Concepts
894 N Fair Oaks Ave.
Pasadena, CA 91103
(626) 389-2108
michel.c@aec-us.com
www.aec-us.com
Michel Castonguay
Applied Engineering Concepts
8160 Miramar Road
San Diego, CA 92126
(619) 822-1106
michel.c@aec-us.com
www.aec-us.com
Michel Castonguay
ARM CAMCO, LLC
667 Industrial Park Road
Ebensburg, PA 15931
(814) 472-7980
acct@armcamco.net
Sam Morello
NETA ACCREDITED COMPANIES Setting the Standard
NETAWorld • 123NETA ACCREDITED COMPANIES
NETA ACCREDITED COMPANIES Setting the Standard
BEC Testing
50 Gazza Blvd
Farmingdale, NY 11735-1402
(631) 393-6800
ddevlin@banaelectric.com
www.bectesting.com
Blue Runner Switchgear Testing, LLC
924 Highway 98 East
Suite C-200
Destin, FL 32541
(270) 590-4974
cneitzel@bluerunnerswitchgear.com
www.bluerunnerswitchgear.com
Chris Neitzel
Burlington Electrical Testing Co., LLC
300 Cedar Ave
Croydon, PA 19021-6051
(215) 826-9400
waltc@betest.com
www.betest.com
Walter P. Cleary
Burlington Electrical Testing Co., LLC
846 Waterford Drive
Delran, NJ 08075
(609) 267-4126
Capitol Area Testing, Inc.
P.O. Box 259
Suite 614
Crownsville, MD 21032
(757) 650-0740
carl@capitolareatesting.com
www.capitolareatesting.com
Carl VanHooijdonk
CBS Field Services
14311 29th St E
Sumner, WA 98390-9690
(253) 891-1995
dhook@westernelectricalservices.com
www.westernelectricalservices.com
Dan Hook
CBS Field Services
12794 Currie Court
Livonia, MI 48150
(810) 720-2280
mramieh@powertechservices.com
www.powertechservices.com
CBS Field Services
5680 S 32nd St
Phoenix, AZ 85040-3832
(602) 426-1667
www.westernelectricalservices.com
www.westernelectricalservices.com
CBS Field Services
3676 W California Ave Ste C106
Salt Lake City, UT 84104-6533
(888) 395-2021
www.westernelectricalservices.com
www.westernelectricalservices.com
CBS Field Services
4510 NE 68th Dr Unit 122
Vancouver, WA 98661-1261
(888) 395-2021
www.westernelectricalservices.com
Jason Carlson
CBS Field Services
5505 Daniels St.
Chino, CA 91710
(602) 426-1667
Matt Wallace
CBS Field Services
620 Meadow Ln.
Los Alamos, NM 87547
(505) 469-1661
CBS Field Services
5385 Gateway Boulevard #19-21
Lakeland, FL 33811
(810) 720-2280
CE Power Engineered Services, LLC
4040 Rev Drive
Cincinnati, OH 45232
(800) 434-0415
info@cepower.net
Jim Cialdea
CE Power Engineered Services, LLC
11620 Crossroads Cir
Middle River, MD 21220-2874
(410) 344-0300
Peter Earlston
CE Power Engineered Services, LLC
480 Cave Rd
Nashville, TN 37210-2302
(615) 882-9455
dave.mitchell@cepower.net
www.cepower.net
Dave Mitchell
CE Power Engineered Services, LLC
4089 Landisville Rd.
Doylestown, PA 18902
(215) 364-5333
CE Power Engineered Services, LLC
40 Washington St
Westborough, MA 01581-1088
(508) 881-3911
jim.cialdea@cepower.net
www.cepower.net
Jim Cialdea
CE Power Engineered Services, LLC
9200 75th Avenue N
Brooklyn Park, MN 55428
(877) 968-0281
jason.thompson@cepower.net
www.cepower.net
Cameron Dooley
CE Power Engineered Services, LLC
72 Sanford Drive
Gorham, ME 04038
(800) 649-6314
mike.roach@cepower.net
www.cepower.net
Michael Roach
CE Power Engineered Services, LLC
8490 Seward Rd.
Fairfield, OH 45011
(800) 434-0415
info@cepower.net
www.cepower.net
Jerry Daugherty
CE Power Engineered Services, LLC
1803 Taylor Ave.
Louisville, KY 40213
(800) 434-0415
Eric.croner@cepower.net
www.cepower.net
Eric Croner
CE Power Engineered Services, LLC
1200 W. West Maple Rd.
Walled Lake, MI 48390
(810) 229-6628
www.cepower.net
Ryan Wiegand
CE Power Engineered Services, LLC
10840 Murdock Drive
Knoxville, TN 37932
(800) 434-0415
don.williams@cepower.netwww.cepower.net
Don Williams
CE Power Engineered Services, LLC
3496 E. 83rd Place
Merrillville, IN 46410
(219) 942-2346
lucas.gallagher@cepower.net
www.cepower.net
Lucas Gallagher
CE Power Engineered Services, LLC
1260 Industrial Park
Eveleth, MN 55734
(218) 744-4200
Joseph Peterson
CE Power Engineered Services, LLC
401 Independence Pkwy S
La Porte, TX 77571
(361) 443-7714
Dusty Nations
CE Power Solutions of Florida, LLC
3502 Riga Blvd., Suite C
Tampa, FL 33619
(866) 439-2992
robert.bordas@cepowersol.com
www.cepowersol.com
Robert Bordas
CE Power Solutions of Florida, LLC
3801 SW 47th Avenue Suite 505
Davie, FL 33314
(866) 439-2992
robert.bordas@cepowersol.com
www.cepowersol.com
Robert Bordas
CFM Services, Inc.
845 St-Jaques local 600
St-Jean-sur-Richelieu, QC J3B 2N2
(514) 436-0052
frederic@cfmservices.ca
www.cfmservices.ca
Frederic Morin
Control Power Concepts
141 Quail Run Rd
Henderson, NV 89014
(702) 448-7833
jtravis@ctrlpwr.com
www.controlpowerconcepts.com
Dude Electrical Testing, LLC
145 Tower Drive, Unit 9
Burr Ridge, IL 60527-7840
(815) 293-3388
scott.dude@dudetesting.com
www.dudetesting.com
Scott Dude
Eastern High Voltage, Inc.
11A S Gold Dr
Robbinsville, NJ 08691-1685
(609) 890-8300
bobwilson@easternhighvoltage.com
www.easternhighvoltage.com
Robert Wilson
Electek Power Services, Inc.
870 Confederation Street
Sarnia, ON N7T2E5
(519) 383-0333
kgadsby@electek.ca
Kathy Gadsby
ELECT, P.C.
375 E. Third Street
Wendell, NC 27591
(919) 365-9775
btyndall@elect-pc.com
www.elect-pc.com
Barry W. Tyndall
Electrical & Electronic Controls
6149 Hunter Rd
Ooltewah, TN 37363-8762
(423) 344-7666
eecontrols@comcast.net
Michael Hughes
Electrical Energy Experts, LLC
W129N10818 Washington Dr
Germantown, WI 53022-4446
(262) 255-5222
tim@electricalenergyexperts.com
www.electricalenergyexperts.com
Tim Casey
Electrical Energy Experts, LLC
815 Commerce Dr.
Oak Brook, IL 60523
(847) 875-5611
Michael Hanek
Electrical Engineering & Service Co., Inc.
289 Centre St.
Holbrook, MA 02343
(781) 767-9988
jcipolla@eescousa.com
www.eescousa.com
Joe Cipolla
Electrical Equipment Upgrading, Inc.
21 Telfair Pl
Savannah, GA 31415-9518
(912) 232-7402
kmiller@eeu-inc.com
www.eeu-inc.com
Kevin Miller
124 • SUMMER 2022 NETA ACCREDITED COMPANIES
Electrical Reliability Services
610 Executive Campus Dr
Westerville, OH 43082-8870
(877) 468-6384
info@electricalreliability.com
www.electricalreliability.com
Electrical Reliability Services
5909 Sea Lion Pl Ste C
Carlsbad, CA 92010-6634
(858) 695-9551
www.electricalreliability.com
Electrical Reliability Services
1057 Doniphan Park Cir Ste A
El Paso, TX 79922-1329
(915) 587-9440
www.electricalreliability.com
Electrical Reliability Services
6900 Koll Center Pkwy Ste 415
Pleasanton, CA 94566-3119
(925) 485-3400
www.electricalreliability.com
Electrical Reliability Services
8500 Washington St NE Ste A6
Albuquerque, NM 87113-1861
(505) 822-0237
www.electricalreliability.com
Electrical Reliability Services
2275 Northwest Pkwy SE Ste 180
Marietta, GA 30067-9319
(770) 541-6600
www.electricalreliability.com
Electrical Reliability Services
12130 Mora Drive
Unit 1
Santa Fe Springs, CA 90670
(562) 236-9555
www.electricalreliability.com
Electrical Reliability Services
400 NW Capital Dr
Lees Summit, MO 64086-4723
(816) 525-7156
www.electricalreliability.com
Electrical Reliability Services
7100 Broadway Ste 7E
Denver, CO 80221-2900
(303) 427-8809
www.electricalreliability.com
Electrical Reliability Services
2222 W Valley Hwy N Ste 160
Auburn, WA 98001-1655
(253) 736-6010
www.electricalreliability.com
Electrical Reliability Services
221 E. Willis Road, Suite 3
Chandler, AZ 85286
(480) 966-4568
www.electricalreliability.com
Electrical Reliability Services
1380 Greg St. Ste. 216
Sparks, NV 89431-6070
(775) 746-4466
www.electricalreliability.com
Electrical Reliability Services
11000 Metro Pkwy Ste 30
Fort Myers, FL 33966-1244
(239) 693-7100
www.electricalreliability.com
Electrical Reliability Services
245 Hood Road
Sulphur, LA 70665-8747
(337) 583-2411
wayne.beaver@vertivco.com
www.electricalreliability.com
Electrical Reliability Services
9736 South Sandy Pkwy 500 West
Sandy, UT 84070
(801) 561-0987
www.electricalreliability.com
Electrical Reliability Services
6351 Hinson Street, Suite A
Las Vegas, NV 89118-6851
(702) 597-0020
www.electricalreliability.com
Electrical Reliability Services
36572 Luke Drive
Geismar, LA 70734
(225) 647-0732
www.electricalreliability.com
www.electricalreliability.com
Electrical Reliability Services
9636 Saint Vincent Ave Unit A
Shreveport, LA 71106-7127
(318) 869-4244
Electrical Reliability Services
1426 Sens Rd. Ste. #5
La Porte, TX 77571-9656
(281) 241-2800
www.electricalreliability.com
Electrical Reliability Services
9753 S. 140th Street, Suite 109
Omaha, NE 68138
(402) 861-9168
Electrical Reliability Services
190 E. Stacy Road
306 #374
Allen, TX 75002
(972) 788-0979
Electrical Reliability Services
4833 Berewick Town Ctr Drive
Ste E-207
Charlotte, NC 28278
(704) 583-4794
Electrical Reliability Services
324 S. Wilmington St.
Ste 299
Raleigh, NC 27601
(919) 807-0995
Electrical Reliability Services
8983 University Blvd
Ste. 104. #158
North Charleston, SC 29406
(843) 797-0514
Electrical Reliability Services
13720 Old St. Augustine Rd.
Ste. 8 #310
Jacksonville, FL 32258
(904) 292-9779
Electrical Reliability Services
4099 SE International Way Ste 201
Milwaukie, OR 97222-8853
(503) 653-6781
www.electricalreliability.com
Electrical Testing and Maintenance Corp.
3673 Cherry Rd Ste 101
Memphis, TN 38118-6313
(901) 566-5557
r.gregory@etmcorp.net
www.etmcorp.net
Ron Gregory
Electrical Testing, Inc.
2671 Cedartown Hwy SE
Rome, GA 30161-3894
(706) 234-7623
clifton@electricaltestinginc.com
www.electricaltestinginc.com
Electrical Testing Solutions
2909 Greenhill Ct
Oshkosh, WI 54904-9769
(920) 420-2986
tmachado@electricaltestingsolutions.com
www.electricaltestingsolutions.com/
Tito Machado
Electric Power Systems, Inc.
21 Millpark Ct
Maryland Heights, MO 63043-3536
(314) 890-9999
STL@epsii.com
www.epsii.com
James Vaughn
Electric Power Systems, Inc.
11211 E. Arapahoe Rd
Ste 108
Centennial, CO 80112
(720) 857-7273
den@epsii.com
www.epsii.com
Mike Benitez
Electric Power Systems, Inc.
120 Turner Road
Salem, VA 24153-5120
(540) 375-0084
rnk@epsii.com
www.epsii.com
Richard Kessler
Electric Power Systems, Inc.
1090 Montour West Ind Park
Coraopolis, PA 15108-9307
(412) 276-4559
PIT@epsii.com
www.epsii.com
Jon Rapuk
Electric Power Systems, Inc.
4300 NE 34th Street
Kansas City, MO 64117
(816) 241-9990
KAN@epsii.com
www.epsii.com
Rodrigo Lallana
Electric Power Systems, Inc.
1230 N Hobson St.
Suite 101
Gilbert, AZ 85233
(480) 633-1490
PHX@epsii.com
www.epsii.com
Mike Benitez
Electric Power Systems, Inc.
915 Holt Ave Unit 9
Manchester, NH 03109-5606
(603) 657-7371
MAN@epsii.com
www.epsii.com
Sam Bossee
Electric Power Systems, Inc.
3806 Caboose Place
Sanford, FL 32771
(407) 578-6424
ORL@epsii.com
www.epsii.com
Justin McGinn
Electric Power Systems, Inc.
1129 E Highway 30
Gonzales, LA 70737-4759
(225) 644-0150
BAT@epsii.com
www.epsii.com
Josh Galaz
Electric Power Systems, Inc.
684 Melrose Avenue
Nashville, TN 37211-3121
(615) 834-0999
NSH@epsii.com
www.epsii.com
James Vaughn
Electric Power Systems, Inc.
2888 Nationwide Parkway
2nd Floor
Brunswick, OH 44212
(330) 460-3706
CLE@epsii.com
www.epsii.com
Jon Rapuk
NETA ACCREDITED COMPANIES Setting the Standard
NETAWorld • 125NETA ACCREDITED COMPANIES
NETA ACCREDITED COMPANIES Setting the Standard
Electric Power Systems, Inc.
54 Eisenhower Lane North
Lombard, IL 60148
(815) 577-9515
CHI@epsii.com
www.epsii.com
George Bratkiv
Electric Power Systems, Inc.
1330 Industrial Blvd.
Suite 300
Sugar Land, TX 77478
(713) 644-5400
HOU@epsii.com
www.epsii.com
Electric Power Systems, Inc.
56 Bibber Pkwy # 1
Brunswick, ME 04011-7357
(207) 837-6527
BRU@epsii.com
www.epsii.com
Sam Bosse
Electric Power Systems, Inc.
1361 Glory Rd
Green Bay, WI 54304-5640
(920) 632-7929
info@energisinc.com
www.energisinc.com
ElectricPower Systems, Inc.
11861 Longsdorf St
Riverview, MI 48193-4250
(734) 282-3311
DET@epsii.com
www.epsii.com
Greg Eakins
Electric Power Systems, Inc.
4416 Anaheim Ave. NE
Albuquerque, NM 87113
(505) 792-7761
ABQ@epsii.com
www.epsii.com
Mike Benitez
Electric Power Systems, Inc.
3209 Gresham Lake Rd.
Suite 155
Raleigh, NC 27615
(919) 322-2670
RAL@epsii.com
www.epsii.com
Yigitcan Unludag
Electric Power Systems, Inc.
5850 Polaris Ave., Suite 1600
Las Vegas, NV 89118
(702) 815-1342
LAS@epsii.com
www.epsii.com
Devin Hopkins
Electric Power Systems, Inc.
7925 Dunbrook Rd.
Suite G
San Diego, CA 92126
(858) 566-6317
SAN@epsii.com
www.epsii.com
Devin Hopkins
Electric Power Systems, Inc.
6679 Peachtree Industrial Dr.
Suite H
Norcross, GA 30092
(770) 416-0684
ATL@epsii.com
www.epsii.com
Justin McGinn
Electric Power Systems, Inc.
306 Ashcake Road suite A
Ashland, VA 23005
(804) 526-6794
RIC@epsii.com
www.epsii.com
Chris Price
Electric Power Systems, Inc.
7169 East 87th St.
Indianapolis, IN 46256
(317) 941-7502
IND@epsii.com
www.epsii.com
Ben Hocking
Electric Power Systems, Inc.
7308 Aspen Lane North
Suite 160
Brooklyn Park, MN 55428
(763) 315-3520
MIN@epsii.com
www.epsii.com
Paul Cervantez
Electric Power Systems, Inc.
140 Lakefront Drive
Cockeysville, MD 21030
(443) 689-2220
WDC@epsii.com
www.epsii.com
Jon Rapuk
Electric Power Systems, Inc.
783 N. Grove Rd Suite 101
Richardson, TX 75081
(214) 821-3311
Thomas Coon
Electric Power Systems, Inc.
11912 NE 95th St. Suite 306
Vancouver, WA 98682
(855) 459-4377
VAN@epsii.com
www.epsii.com
Anthony Asciutto
Electric Power Systems, Inc.
Padre Mariano
272, Of. 602
Providencia, Santiago,
Electro Test, LLC
401 N. Cane Street
Unit A-4
Wahiawa, HI 96786
(808) 321-2028
bhelminen@electrotest.pro
www.electrotest.pro
Brad Helminen
Elemco Services, Inc.
228 Merrick Rd
Lynbrook, NY 11563-2622
(631) 589-6343
courtney@elemco.com
www.elemco.com
Courtney Gallo
EnerG Test, LLC
206 Gale Lane
Kennett Square, PA 19348
(484) 731-0200
info@energtest.com
www.energtest.com
EPS Technology
37 Ozick Dr.
Durham, CT 06422
(203) 679-0145
www.eps-technology.com
Sean Miller
ESR Electrical Services
425 S. 48th Street
Suite 114
Tempe, AZ 85281
(661) 644-2430
jacob@esreliability.com
Jacob Webb
ESR Electrical Services
5009 Pacific Hwy East, Unit 13
Fife, WA 98424
(800) 342-4560
chuck@esreliability.com
Charles Duncan III
ESR Electrical Services
3204 NE 13th Place
Hillsboro, OR 97124
(800) 342-4560
chuck@esreliability.com
Charles Duncan III
ESR Electrical Services
1737 NE 8th Street
Hermiston, OR 97838
(800) 342-4560
chuck@esreliability.com
Charles Duncan III
ESR Electrical Services
23421 Spicebush Terrace
Ashburn, VA 20148
(800) 342-4560
jacob@esreliability.com
Jacob Webb
Giga Electrical & Technical Services, Inc.
5926 E. Washington Boulevard
Commerce, CA 90040
(323) 255-5894
gigaelectrical@gmail.com
www.gigaelectrical-ca.com/
Hermin Machacon
Grubb Engineering, Inc.
2727 North Saint Mary’s St.
San Antonio, TX 78212
(210) 658-7250
rgrubb@grubbengineering.com
www.grubbengineering.com
Robert Grubb
Halco Testing Services
5773 Venice Boulevard
Los Angeles, CA 90019
(323) 933-9431
www.halcotestingservices.com
Don Genutis
Hampton Tedder Technical Services
4563 State St
Montclair, CA 91763-6129
(909) 628-1256
chasen.tedder@hamptontedder.com
www.httstesting.com
Chasen Tedder
Hampton Tedder Technical Services
3747 W Roanoke Ave
Phoenix, AZ 85009-1359
(480) 967-7765
www.httstesting.com
Linc McNitt
Hampton Tedder Technical Services
4113 Wagon Trail Ave.
Las Vegas, NV 89118
(702) 452-9200
www.httstesting.com
Roger Cates
Harford Electrical Testing Co., Inc.
1108 Clayton Rd
Joppa, MD 21085-3409
(410) 679-4477
testing@harfordtesting.com
www.harfordtesting.com
High Energy Electrical Testing, Inc.
5042 Industrial Road, Unit D
Farmingdale, NJ 07727
(732) 938-2275
judylee@highenergyelectric.com
www.highenergyelectric.com
High Voltage Maintenance Corp.
5100 Energy Dr
Dayton, OH 45414-3525
(937) 278-0811
www.hvmcorp.com
High Voltage Maintenance Corp.
24 Walpole Park S
Walpole, MA 02081-2541
(508) 668-9205
www.hvmcorp.com
High Voltage Maintenance Corp.
1052 Greenwood Springs Rd.
Suite E
Greenwood, IN 46143
(317) 322-2055
www.hvmcorp.com
www.hvmcorp.com
High Voltage Maintenance Corp.
355 Vista Park Dr
Pittsburgh, PA 15205-1206
(412) 747-0550
www.hvmcorp.com
126 • SUMMER 2022 NETA ACCREDITED COMPANIES
High Voltage Maintenance Corp.
8787 Tyler Blvd.
Mentor, OH 44061
(440) 951-2706
www.hvmcorp.com
www.hvmcorp.com
Greg Barlett
High Voltage Maintenance Corp.
24371 Catherine Industrial Dr Ste
207
Novi, MI 48375-2422
(248) 305-5596
www.hvmcorp.com
High Voltage Maintenance Corp.
3000 S Calhoun Rd
New Berlin, WI 53151-3549
(262) 784-3660
www.hvmcorp.com
High Voltage Maintenance Corp.
1 Penn Plaza
Suite 500
New York, NY 10119
(718) 239-0359
www.hvmcorp.com
High Voltage Maintenance Corp.
29 Diana Court
Cheshire, CT 06410
(203) 949-2650
www.hvmcorp.com
www.hvmcorp.com
Peter Dobrowolski
High Voltage Maintenance Corp.
941 Busse Rd
Elk Grove Village, IL 60007-2400
(847) 640-0005
High Voltage Maintenance Corp.
(410) 279-0798
www.hvmcorp.com
High Voltage Maintenance Corp.
10704 Electron Drive
Louisville, KY 40299
(859) 371-5355
High Voltage Maintenance Corp.
1 Penn Plaza, Suite 1500
New York, NY 10119
(718) 239-0359
New York Area Service Center
High Voltage Maintenance Corp.
Cincinnati/Kentucky
Area Satellite Office
(859) 371-5355
Hood Patterson & Dewar, Inc.
850 Center Way
Norcross, GA 30071
(770) 453-1415
info@hoodpd.com
https://hoodpd.com/
Brandon Sedgwick
Hood Patterson & Dewar, Inc.
15924 Midway Road
Addison, TX 75001
(214) 461-0760
info@hoodpd.com
https://hoodpd.com/
Hood Patterson & Dewar, Inc.
4511 Daly Dr.
Suite 1
Chantilly, VA 20151
(571) 299-6773
info@hoodpd.com
https://hoodpd.com/
Hood Patterson & Dewar, Inc.
1531 Hunt Club Blvd
Ste 200
Gallatin, TN 37066
(615) 527-7084
info@hoodpd.com
https://hoodpd.com/
Industrial Electric Testing, Inc.
11321 Distribution Ave W
Jacksonville, FL 32256-2746
(904) 260-8378
gbenzenberg@bellsouth.net
www.industrialelectrictesting.com
Gary Benzenberg
Industrial Electric Testing, Inc.
201 NW 1st Ave
Hallandale Beach, FL 33009-4029
(954) 456-7020
gbenzenberg@bellsouth.net
www.industrialelectrictesting.com
Gary Benzenberg
Industrial Tests, Inc.
4021 Alvis Ct Ste 1
Rocklin, CA 95677-4031
(916) 296-1200
greg@indtest.com
www.industrialtests.com
Greg Poole
Infra-Red Building and Power Service, Inc.
152 Centre St
Holbrook, MA 02343-1011
(781) 767-0888
Tom.McDonald@infraredbps.com
www.infraredbps.com
Thomas McDonald Sr.
JET Electrical Testing, LLC
100 Lenox Drive
Suite 100
Lawrenceville, NJ 08648
(609) 285-2800
jvasta@jetelectricaltesting.com
jetelectricaltesting.com
Joe Vasta
J.G. Electrical Testing Corporation
3092 Shafto Road
Suite 13
Tinton Falls, NJ 07753
(732) 217-1908
h.trinkowsky@jgelectricaltesting.com
www.jgelectricaltesting.com
KT Industries, Inc.
3203 Fletcher Drive
Los Angeles, CA 90065
(323) 255-7143
eric@kti.la
ktiengineering.com
Eric Vaca
Magna IV Engineering
1103 Parsons Rd. SW
Edmonton, AB T6X 0X2
(780) 462-3111
info@magnaiv.com
www.magnaiv.com
Virginia Balitski
Magna IV Engineering
141 Fox Cresent
Fort McMurray, AB T9K 0C1
(780) 791-3122
info@magnaiv.com
Ryan Morgan
Magna IV Engineering
3124 Millar Ave.
Saskatoon, SK S7K 5Y2
(306) 713-2167
info.saskatoon@magnaiv.com
Adam Jaques
Magna IV Engineering
96 Inverness Dr E Ste R
Englewood, CO 80112-5311
(303) 799-1273
info.denver@magnaiv.com
Kevin Halma
Magna IV Engineering
Avenida del Condor sur #590
Oficina 601
Huechuraba,
8580676
+(56) -2-26552600
info.santiago@magnaiv.com
Harvey Mendoza
Magna IV Engineering
Unit 110, 19188 94th Avenue
Surrey, BC V4N 4X8
(604) 421-8020
info.vancouver@magnaiv.com
Rob Caya
Magna IV Engineering
Suite 200, 688 Heritage Dr. SE
Calgary, AB T2H 1M6
(403) 723-0575
info.calgary@magnaiv.com
Morgan MacDonnell
Magna IV Engineering
4407 Halik Street Building E
Suite 300
Pearland, TX 77581
(346) 221-2165
info.houston@magnaiv.com
www.magnaiv.com
AricProskurniak
Magna IV Engineering
10947 92 Ave
Grande Prairie, AB T8V 3J3
1.800.462.3157
info.grandeprairie@magnaiv.com
Matthew Britton
Magna IV Engineering
531 Coster St.
Bronx, NY 10474
(800) 462-3157
Info.newyork@magnaiv.com
Donald Orbin
Midwest Engineering Consultants, Ltd.
2500 36th Ave
Moline, IL 61265-6954
(309) 764-1561
m-moorehead@midwestengr.com
www.Midwestengr.com
Monte Moorehead
M&L Power Systems, Inc.
109 White Oak Ln Ste 82
Old Bridge, NJ 08857-1980
(732) 679-1800
milind@mlpower.com
www.mlpower.com
Milind Bagle
MTA Electrical Engineers
350 Pauma Place
Escondido, CA 92029
(760) 658-6098
tim@mtaee.com
Timothy G. Shaw
MUSE
1000 23rd Ave BLDG 1360
Port Hueneme, CA 93043
(805) 982-1178
waverly.r.holland@navy.mil
Waverly Holland
National Field Services
651 Franklin
Lewisville, TX 75057-2301
(972) 420-0157
eric.beckman@natlfield.com
www.natlfield.com
Eric Beckman
National Field Services
1760 W. Walker Street
Suite 100
League City, TX 77573
(800) 420-0157
don.haas@natlfield.com
Donald Haas
National Field Services
1405 United Drive
Suite 113-115
San Marcos, TX 78666
(800) 420-0157
matt.lacoss@natlfield.com
www.natlfield.com
Matthew LaCoss
NETA ACCREDITED COMPANIES Setting the Standard
NETAWorld • 127NETA ACCREDITED COMPANIES
NETA ACCREDITED COMPANIES Setting the Standard
National Field Services
3711 Regulus Ave.
Las Vegas, NV 89102
(888) 296-0625
www.natlfield.com
National Field Services
2900 Vassar St. #114
Reno, NV 89502
(775) 410-0430
tylor.pereza@natlfield.com
www.natlfield.com
Tylor Pereza
National Field Services
21818 S. Wiliminton Ave #409
Carson, CA 90810
(310) 549-5673
Butch Bustamante
Nationwide Electrical Testing, Inc.
6515 Bentley Ridge Drive
Cumming, GA 30040
(770) 667-1875
Shashi@N-E-T-Inc.com
www.n-e-t-inc.com
North Central Electric, Inc.
69 Midway Ave
Hulmeville, PA 19047-5827
(215) 945-7632
bjmessina@ncetest.com
www.ncetest.com
Robert Messina
Orbis Engineering Field Services Ltd.
#300, 9404 - 41st Ave.
Edmonton, AB T6E 6G8
(780) 988-1455
accountspayable@orbisengineering.net
www.orbisengineering.net
Orbis Engineering Field Services Ltd.
#228 - 18 Royal Vista Link NW
Calgary, AB T3R 0K4
(403) 374-0051
Amin Kassam
Orbis Engineering Field Services Ltd.
Badajoz #45, Piso 17
Las Condes
Santiago,
+56 2 29402343
framos@orbisengineering.net
Felipe Ramos
Pace Technologies, Inc.
9604 - 41 Avenue NW
Edmonton, AB T6E 6G9
(780) 450-0404
www.pacetechnologies.com
Pace Technologies, Inc.
#10, 883 McCurdy Place
Kelowna, BC V1X 8C8
(250) 712-0091
Pace Technologies, Inc.
110-7685 56 St. SE
Calgary, AB T2C 5S7
(780) 450-0404
mcollins@pacetechologies.com
Micah Collins
Pacific Powertech Inc.
#110, 2071 Kingsway Ave.
Port Coquitlam, BC V3C 6N2
(604) 944-6697
okirby@pacificpowertech.ca
www.pacificpowertech.ca
Owen Kirby
Pacific Power Testing, Inc.
14280 Doolittle Dr
San Leandro, CA 94577-5542
(510) 351-8811
steve@pacificpowertesting.com
www.pacificpowertesting.com
Steve Emmert
Phasor Engineering
Sabaneta Industrial Park #216
Mercedita, PR 00715
(787) 844-9366
rcastro@phasorinc.com
www.phasorinc.com
Rafael Castro
Potomac Testing
1610 Professional Blvd Ste A
Crofton, MD 21114-2051
(301) 352-1930
kbassett@potomactesting.com
www.potomactesting.com
Ken Bassett
Potomac Testing
1991 Woodslee Dr
Troy, MI 48083-2236
(248) 689-8980
ldetterman@northerntesting.com
www.northerntesting.com
Lyle Detterman
Potomac Testing
12342 Hancock St
Carmel, IN 46032-5807
(317) 853-6795
Potomac Testing
1130 MacArthur Rd.
Jeffersonville, OH 43128
Power Engineering Services, Inc.
9179 Shadow Creek Ln
Converse, TX 78109-2041
(210) 590-6214
pes@pe-svcs.com
www.pe-svcs.com
Power Engineering Services, Inc.
4041 Ellis Road Suite 100
Friendswood, TX 77546
(210) 590-4936
pes@pe-svcs.com
www.pe-svcs.com
Power Engineering Services, Inc.
1001 Doris Lane
Suite E
Cedar Park, TX 78613
(210) 590-4936
pes@pe-svcs.com
www.pe-svcs.com
Power Products & Solutions, LLC
6605 W WT Harris Blvd
Suite F
Charlotte, NC 28269
(704) 573-0420 x12
adis.talovic@powerproducts.biz
www.powerproducts.biz
Adis Talovic
Power Products & Solutions, LLC
13 Jenkins Ct
Mauldin, SC 29662-2414
(800) 328-7382
raymond.pesaturo@powerproducts.biz
www.powerproducts.biz
Raymond Pesaturo
Power Products & Solutions, LLC
9481 Industrial Center Dr.
Unit 5
Ladson, SC 29456
(844) 383-8617
www.powerproducts.biz
www.powerproducts.biz
Power Solutions Group, Ltd.
425 W Kerr Rd
Tipp City, OH 45371-2843
(937) 506-8444
bwilloughby@powersolutionsgroup.com
www.powersolutionsgroup.com
Barry Willoughby
Power Solutions Group, Ltd.
251 Outerbelt St.
Columbus, OH 43213
(614) 310-8018
sspohn@powersolutionsgroup.com
www.powersolutionsgroup.com
Power Solutions Group, Ltd.
5115 Old Greenville Highway
Liberty, SC 29657
(864) 540-8434
fcrawford@powersolutionsgroup.com
www.powersolutionsgroup.com
Anthony Crawford
Power Solutions Group, Ltd.
172 B-Industrial Dr.
Clarksville, TN 37040
(931) 572-8591
Chris Brown
PowerSouth Testing, LLC
130 W. Porter St.
Suite 120
Cartersville, GA 30120
(678) 901-0205
samuel.townsend@powersouthtesting.com
www.powersouthtesting.com
Power System Professionals, Inc.
429 Clinton Ave
Roseville, CA 95678
(866) 642-3129
jburmeister@powerpros.net
James Burmeister
Power Systems Testing Co.
4688 W Jennifer Ave Ste 108
Fresno, CA 93722-6418
(559) 275-2171 ext 15
dave@pstcpower.com
www.powersystemstesting.com
David Huffman
Power Systems Testing Co.
600 S Grand Ave Ste 113
Santa Ana, CA 92705-4152
(714) 542-6089
www.powersystemstesting.com
Power Systems Testing Co.
6736 Preston Ave Ste E
Livermore, CA 94551-8521
(510) 783-5096
www.powersystemstesting.com
Power Test, Inc.
2220 Hwy 49
Harrisburg, NC 28075-7506
(704) 200-8311
rich@powertestinc.com
www.powertestinc.com
Praetorian Power Protection, LLC
PO Box 3366
Lynnwood, WA 98046
(206) 612-6367
MChislett@praetorianpower.com
Michael Chislett
Precision Testing Group
5475 Highway 86 Unit 1
Elizabeth, CO 80107-7451
(303) 621-2776
office@precisiontestinggroup.com
www.precisiontestinggroup.com
Premier Power Maintenance Corporation
4035 Championship Drive
Indianapolis, IN 46268
(317) 879-0660
bob.sheppard@premierpower.us
Premier Power Maintenance Corporation
2725 Jason Rd
Ashland, KY 41102-7756
(606) 929-5969
jay.milstead@premierpower.us
www.premierpowermaintenance.com
Jay Milstead
Premier Power Maintenance Corporation
3066 Finley Island Cir NW
Decatur, AL 35601-8800
(256) 355-1444
johnnie.mcclung@premierpower.us
www.premierpowermaintenance.com
Johnnie McClung
Premier Power Maintenance Corporation
7262 Kensington Rd.
Brighton, MI 48116
(517) 715-9997
steve.monte@premierpower.us
Steve Monte
128 • SUMMER 2022 NETA ACCREDITED COMPANIES
Premier Power Maintenance Corporation
1901 Oakcrest Ave., Suite 6
Saint Paul, MN 55113
(612) 430-0209
Zac.mrdgenovich@premierpower.us
Zac Mrdjenovich
Premier Power Maintenance Corporation
119 Rochester Dr.
Louisville, KY 40214
(256) 200-6833
Jeremiah.evans@premierpower.us
Jeremiah Evans
QP Testing, LLC
15941 S Harlem
Suite 222
Tinley Park, IL 60477
(815) 724-2216
spioppo@qp-testing.com
Steve Pioppo
RESA Power Service
50613 Varsity Ct.
Wixom, MI 48393
(248) 313-6868
lester.mcmanaway@resapower.com
www.resapower.com
RESA Power Service
3890 Pheasant Ridge Dr. NE
Suite 170
Blaine, MN 55449
(763) 784-4040
Michael.mavetz@resapower.com
www.resapower.com
Mike Mavetz
RESA Power Service
6148 Tim Crews Rd
Macclenny, FL 32063-4036
(904) 653-1900
mark.chapman@resapower.com
Mark Chapman
RESA Power Service
4540 Boyce Parkway
Cleveland, OH 44224
(800) 264-1549
garth.paul@resapower.com
www.resapower.com
Garth Paul
RESA Power Service
19621 Solar Circle, 101
Parker, CO 80134
(303) 781-2560
john.leusink@resapower.com
John Leusink
RESA Power Service
40 Oliver Terrace
Shelton, CT 06484-5336
(800) 272-7711
adam.stevens@resapower.com
Adam Stevens
RESA Power Service
13837 Bettencourt Street
Cerritos, CA 90703
(800) 996-9975
bryan.larkin@resapower.com
www.resapower.com
Bryan Larkin
RESA Power Service
2300 Zanker Road
Suite D
San Jose, CA 95131(800) 576-7372
bryan.larkin@resapower.com
www.resapower.com
RESA Power Service
1401 Mercantile Court
Plant City, FL 33563
(813) 752-6550
matt.rice@resapower.com
www.resapower.com
Matt Rice
RESA Power Service
6268 Route 31
Cicero, NY 13039
(315) 699-5563
art.mcmanus@resapower.com
Art McManus
RESA Power Service
#181-1999 Savage Road,
Vancouver, BC V6V OA5
(604) 303-9770
ralph.schmoor@resapower.com
Ralph Schmoor
RESA Power Service
3190 Holmgren Way
Green Bay, WI 54304
(920) 639-0742
kevin.carr@resapower.com
Kevin Carr
RESA Power Service
4552 Happy Valley Rd
Cave City, KY 42127
(270) 670-7942
matthew.reynolds@resapower.com
Matthew Scott Reynolds
RESA Power Service
1010 N. Plaza Drive
Visalia, CA 93291
(559) 651-0141
sean.broderick@resapower.com
Sean Broderick
RESA Power Service
2443 W. 12th St. Suite #3
Tempe, AZ 85281
(480) 730-8871
brandon.carrasco@resapower.com
Brandon Carrasco
Rondar Inc.
333 Centennial Parkway North
Hamilton, ON L8E2X6
(905) 561-2808
rshaikh@rondar.com
www.rondar.com
Rajeel Shaikh
Rondar Inc.
9-160 Konrad Crescent
Markham, ON L3R9T9
(905) 943-7640
Saber Power Field Services, LLC
9841 Saber Power Ln
Rosharon, TX 77583-5188
(713) 222-9102
mtummins@saberpower.com
www.saberpowerfieldservices.com
Mitchell Tummins
Saber Power Field Services, LLC
9006 Western View
Helotes, TX 78023
(210) 444-9514
jnorsworthy@saberpower.com
www.saberpowerfieldservices.com
Jacob Norsworthy
Saber Power Field Services, LLC
1908 Lone Star Rd. Suite A-D
Mansfield, TX 76063
(682) 518-3676
wosborne@saberpower.com
www.saberpowerfieldservices.com
Wesley Osborne
Saber Power Field Services, LLC
433 Sun Belt Dr. Suite C
Corpus Christi, TX 78408
(361) 452-1695
jnorsworthy@saberpower.com
www.saberpowerfieldservices.com
John Norsworthy
Saber Power Field Services, LLC
6097 Old Jefferson Hwy
Geismar, LA 70734
(877) 912-9102
colin.bamber@saberpower.com
www.saberpowerfieldservices.com
Colin Bamber
Saber Power Field Services, LLC
9672 IH-10
Orange, TX 77632
(346) 335-7011
wosborne@saberpower.com
www.saberpowerfieldservices.com
Wesley Osborne
Saber Power Field Services, LLC
2611 S. County Road 1206
Midland, TX 79706
(877) 912-9102
jnorsworthy@saberpower.com
Jacob Norsworthy
Scott Testing, Inc.
245 Whitehead Rd
Hamilton, NJ 08619
(609) 689-3400
rsorbello@scotttesting.com
www.scotttesting.com
Russ Sorbello
Sentinel Field Services, LLC
7517 E Pine St
Tulsa, OK 74115-5729
(918) 359-0350
vigneshpn@sentfs.com
www.sentfs.com
Vignesh Palanichamy
Shermco Industries
2425 E Pioneer Dr
Irving, TX 75061-8919
(972) 793-5523
info@shermco.com
www.shermco.com
Shermco Industries
112 Industrial Drive
Minooka, IL 60447-9557
(815) 467-5577
info@shermco.com
Shermco Industries
233 Faithfull Cr.
Saskatoon, SK S7K 8H7
(306) 955-8131
www.shermco.com
Shermco Industries
2231 E Jones Ave Ste A
Phoenix, AZ 85040-1475
(602) 438-7500
info@shermco.com
Shermco Industries
1711 Hawkeye Dr.
Hiawatha, IA 52233
(319) 377-3377
info@shermco.com
www.shermco.com
Shermco Industries
1705 Hur Industrial Blvd
Cedar Park, TX 78613-7229
(512) 267-4800
info@shermco.com
www.shermco.com
Shermco Industries
7015-8 St NE
Calgary, AB T2E 8A2
(403) 769-9300
www.shermco.com
Shermco Industries
5145 Beaver Dr
Johnston, IA 50131
(515) 265-3377
info@shermco.com
www.shermco.com
Shermco Industries
4510 South 86th East Ave.
Tulsa, OK 74145
(918) 234-2300
info@shermco.com
www.shermco.com
Shermco Industries
1375 Church Avenue
Winnipeg, MB R2X 2T7
(204) 925-4022
www.shermco.com
Shermco Industries
1033 Kearns Crescent
RM of Sherwood, SK S4K 0A2
(306) 949-8131
Shermco Industries
33002 FM 2004
Angleton, TX 77515-8157
(979) 848-1406
info@shermco.com
www.shermco.com
NETA ACCREDITED COMPANIES Setting the Standard
NETAWorld • 129NETA ACCREDITED COMPANIES
NETA ACCREDITED COMPANIES Setting the Standard
Shermco Industries
1355 Central Parkway S #700
San Antonio, TX 78232
(210) 392-9175
info@shermco.com
www.shermco.com
Shermco Industries
3731 - 98 Street
Edmonton, AB T6E 5N2
(780) 436-8831
www.shermco.com
Shermco Industries
417 Commerce Street
Tallmadge, OH 44278
(614) 836-8556
info@shermco.com
Shermco Industries
3807 S Sam Houston Pkwy W
Houston, TX 77053
(281) 835-3633
info@shermco.com
Shermco Industries
7050 S.109th Ave
La Vista, NE 68128
(402) 933-8988
info@shermco.com
Shermco Industries
1301 Hailey St.
Sweetwater, TX 79556
(325) 236-9900
info@shermco.com
www.shermco.com
Shermco Industries
2901 Turtle Creek Dr.
Port Arthur, TX 77642
(409) 853-4316
info@shermco.com
www.shermco.com
Shermco Industries
5145 NW Beaver Dr.
Johnston, IA 50131
(515) 265-3377
info@shermco.com
www.shermco.com
Shermco Industries
998 E. Berwood Ave.
Saint Paul, MN 55110
(651) 484-5533
info@shermco.com
www.shermco.com
Shermco Industries
37666 Amrhein Rd
Livonia, MI 48150
(734) 469-4050
Shermco Industries
2080 West Kenny Drive
Gonzales, LA 70737
(225) 647-9301
info@shermco.com
www.shermco.com
Shermco Industries
7136 Weddington Rd #128
Concord, NC 28027
(910) 568-1053
info@shermco.com
www.shermco.com
Shermco Industries
9475 Old Hwy 43
Creola, AL 36525
(251) 679-3224
info@shermco.com
Shermco Industries
5211 Linbar Dr. Suite 507
Nashville, TN 37211
(615) 928-1182
info@shermco.com
www.shermco.com
Shermco Industries
#307-2999 Underhill Ave
Burnaby, BC V5A 3C2
(972) 793-5523
Brad Wager
Shermco Industries
1411 Twin Oaks Street
Wichita Falls, TX 76302
(972) 793-5523
Trey Ingram
Shermco Industries
11800 Jordy Rd.
Midland, TX 79707
(972) 793-5523
Trey Ingram
Shermco Industries
6551 S Revere Parkway
Suite 275
Centennial, CO 80111
(877) 456-1342
www.shermco.com
www.shermco.com
Sigma Six Solutions, Inc.
2200 W Valley Hwy N Ste 100
Auburn, WA 98001-1654
(253) 333-9730
jwhite@sigmasix.com
www.sigmasix.com
John White
Sigma Six Solutions, Inc.
www.sigmasix.com
Quincy, WA 98848
(253) 333-9730
Chris Morgan
Southern New England Electrical Testing,
LLC
3 Buel St Ste 4
Wallingford, CT 06492-2395
(203) 269-8778
www.sneet.org
www.sneet.org
John Stratton
Star Electrical Services & General
Supplies, Inc.
PO Box 814
Las Piedras, PR 00771
(787) 716-0925
ahernandez@starelectricalpr.com
www.starelectricalpr.com
Aberlardo Hernandez
Taifa Engineering Ltd.
9734-27 Ave NW
Edmonton, AB T6N 1B2
(780) 405-4608
fsteyn@taifaengineering.com
Taurus Power & Controls, Inc.
9999 SW Avery St
Tualatin, OR 97062-9517
(503) 692-9004
powertest@tauruspower.com
www.tauruspower.com
Rob Bulfinch
Taurus Power & Controls, Inc.
8714 South 222nd St. STE A
Kent, WA 98031
(425) 656-4170
powertest@tauruspower.com
www.taruspower.com
TAW Technical Field Services, Inc.
5070 Swindell Rd
Lakeland, FL 33810-7804
(863) 686-5667
www.tawinc.com
Tidal Power Services, LLC
4211 Chance Ln
Rosharon, TX 77583-4384
(281) 710-9150
monty.janak@tidalpowerservices.com
www.tidalpowerservices.com
Monty Janak
Tidal Power Services, LLC
8184 Highway 44 Ste 105
Gonzales, LA 70737-8183
(225) 644-8170
darryn.kimbroug@tpsgse.com
www.tidalpowerservices.com
Darryn Kimbrough
Tidal Power Services, LLC
1056 Mosswood Dr
Sulphur, LA 70665-9508
(337) 558-5457
rich.mcbride@tidalpowerservices.com
www.tidalpowerservices.com
Rich McBride
Tidal Power Services, LLC
1806 Delmar Drive
Victoria, TX 77901
(281) 710-9150
kelly.grahmann@tps03.com
Kelly Grahmann
Titan Quality Power Services, LLC
1501 S Dobson Street
Burleson, TX 76028
(866) 918-4826
www.titanqps.com
Titan Quality Power Services, LLC
7630 Ikes Tree Drive
Spring, TX 77389
(281) 826-3781
Titan Quality Power Services, LLC
7000 Meany Ave.
Bakersfield, CA 93308
(661) 589-0400
Tony Demaria Electric, Inc.
131 W F St
Wilmington, CA 90744-5533
(310) 816-3130
neno@tdeinc.com
www.tdeinc.com
Neno Pasic
US Army Prime Power School
Bldg 12630, Flw 28
Fort Leonard Wood, MO 65473
(253) 380-0194
brandon.s.sheppard.mil@mail.mil
SSG Brandon Sheppard
Utilities Instrumentation Service, Inc.
2290 Bishop Cir E
Dexter, MI 48130-1564
(734) 424-1200
gary.walls@UIScorp.com
www.uiscorp.com
Gary Walls
Utilities Instrumentation Service - Ohio, LLC
998 Dimco Way
Centerville, OH 45458
(937) 439-9660
www.uiscorp.com
www.uiscorp.comNW: Is there anything else you’d like to
share?
Ramieh: The Internet of Things (IOT):
The technology exists today that virtually
every power system failure can be predicted
or prevented. The best part is that most of
this technology can be implemented on legacy
systems. What gets in the way is the cost and
a lingering perception that so long as the lights
are on, there isn’t a problem. The cost still
outweighs the benefit for many facilities.
This task of reflecting on my career (life) has
brought a great deal of gratitude and thanks
to mind. I am so thankful to have the support
of Dusti, my wife of 25 years. Her amazing
strength and resilience kept our family together
through the rough patches. Thankful that our
grown young men are finding their path into
adulthood. Thankful for the opportunity that
my father provided for us to work and grow
together. Thankful for all the electricians,
technicians, and engineers who worked with
me, trained me, challenged me, and coached me
over the years. Finally, I’m thankful for all the
friendships that I have built in this industry. So
many wonderful peers, partners, and customers.
I am blessed in so many ways. Thank you all.
INSIGHTS & INSPIRATION
MOSE RAMIEH III: STAY INVOLVED TO STAY RELEVANT
WANT TO TELL YOUR
STORY?
NETA World is looking for technicians,
emerging leaders, and industry thought
leaders to be featured in our Insight
& Inspiration department. If you know
someone who would make a great
interview — or if you would like to be
interviewed yourself — please contact
Carla Kalogeridis at ckalogeridis@
netaworld.org.
“We have all drunk from wells we did not dig;
We have been warmed by fires we did not build;
We have sat in the shade of trees we did not plant;
We are where we are because of what someone
else did.”
www.shermco.com l 888-SHERMCO
The largest NETA Accredited technical group
in the industry, that never compromises safety.
One Line. One Company.
As North America’s largest independent electrical testing company, our
most important Company core value should come as no surprise: assuring
the safety of our people and our customer’s people. First and foremost.
Our service technicians are NETA-certified and trained to comply and
understand electrical safety standards and regulations such as OSHA,
NFPA 70E, CSA Z462, and other international guidelines. Our entire
staff including technicians, engineers, administrators and management is
involved and responsible for the safety of our co-workers, our customers,
our contractors as well as our friends and families.
Our expertise goes well beyond that of most service companies. From
new construction to maintenance services, acceptance testing and
commissioning to power studies and rotating machinery service and repair,
if it’s in the electrical power system, up and down the line, Shermco does it.
14 • SUMMER 2022 SYNC CHECK SUPERVISION
BY STEVE TURNER, Arizona Public Service – Generation System Protection
The purpose of the sync check function (25) is to ensure that the voltage
magnitude, phase angle, and frequency of the generator (VX) and the
utility system (VS) are within a set of acceptable limits before the generator
is synchronized with the system via closing the circuit breaker that
connects them (Figure 1).
An improper sync can result in electrical and
mechanical transients that damage the prime
mover (for example, turbine), generator, GSU,
and other vital power system components.
Therefore, some users opt to externally
supervise the sync check.
This article describes an application that uses
two external relays to supervise the main sync
check. Figure 2 shows the output contact
arrangement for this scheme.
• R1 is the sync check output from the first
supervisory relay.
• R2 is the sync check output from the
second supervisory relay.
SYNC CHECK
SUPERVISION
RELAY COLUMN
Figure 1: Sync Check Application Diagram
Generator
52X
13.8 kV
PTRS
PTRX
A to B
R1
R2
25
a
c b
E25X Synchronism Check Enable
Y Select: Y, N
25VLOX Voltage Window - Low Threshold (volts)
Range = 0.00 to 300.00104.00
25VHIX Voltage Window - High Threshold (volts)
Range = 0.00 to 300.00127.00
25VDIFX Maximum Voltage Difference (%)
Range = 1.0 to 15.0, OFFS. 1
25RCFX Voltage Ratio Correction Factor
Range = 0.500 to 2.0001.000
GENV+ Generator Voltage High Required
Select: Y, NN
25SLO Minimum Slip Fequency (Hz)
Range = -1.00 to 0.990.00
25SHI Maximum Slip Frequency (Hz)
Range = -0.99 to 1.000.10
25ANG 1X Maximum Angle 1 (degrees)
Range = 0 to 8010
25ANG2X Maximum Angle 2 (degrees)
Range = 0 to 8030
CANGLE Target Close Angle (degrees)
Range = -15 to 15-3
SYNCPX Synchronism Check Phase (VABX, VBCX, VCAX or deg lag VABX)
Select: 0, 30, 60, 90, 120, 150, 180, 210, 240, 270, 300, 330, VABX, VBCX, VCAXVBCX
TCLOSDX Breaker Close Time for Angle Compensation (milliseconds)
Range = 1 to 1000, OFF83
Synchronism Check Elements
Phase Angle Limit: 0 90 (Degree)10
Upper Voltage Limit: 60 140 (V)127
Lower Voltage Limit: 40 120 (V)104
Sync Check Delay: 1 8160 (Cycles)1
Delta Voltage: 1.0 50.0 (V)5.8
Delta Frequency: 0.001 0.500 (Hz)0.100
+
–
Setting
25VHIX
filter|VS|
|VSf|
|Vpxc|
|(1-VPXc∕VSf)|•100%
+
–
+
–
+
–
+
–
+
–
+
–|(1-VPXc∕VSf)|•100%
Setting
25VDIFX
Relay
Word
Bits
59VPX
59VSX
GENVHI
GENVLO
VDIFX
25VCDB
VENX 1
Settings
25VLOX
BSYNCHX
GENV+ = Y
25VDIFX•0.80
GENV+ = Y
Vpxc = 25RCFX•VP (where 25RCFX is the setting and VP is determined by SYNCPX setting).
Setting
VDIFX
25VDIFX = OFF
59VPX
59VSX
BSYNCHX
SELOGIC
Setting
3.0
CYC
0
NETAWorld • 15SYNC CHECK SUPERVISION
• 25 is the output from the sync check
relay.
All three must close simultaneously to allow a
sync check.
R1 SETTINGS
Figure 3 shows the settings chosen for R1.
R2 SETTINGS
Figure 4 shows the settings chosen for R2.
These settings correspond directly to R1;
however, it does not provide as much control.
Therefore, R1 must be set to match R2.
COMMISSIONING
ANALYSIS

Voltage Magnitude
The scheme was a live system tested to ensure
it will work properly during synchronization.
Figure 5, Figure 6, and Figure 7 show the
measured voltage during these tests. VAB is
the generator potential while VX is the system
potential. Review of Figures 5 through 7 shows
that the magnitudes of VAB and VX are almost
identical (that is, matched).
Originally, R1 was set so that a sync was only
allowed when the generator potential magnitude
was greater than the system. However, R2 does
not provide this functionality if the generator
potential magnitude is greater than the real
power flows out of the machine into the system,
which prevents motoring on startup.
RELAY COLUMN
Generator
52X
13.8 kV
PTRS
PTRX
A to B
R1
R2
25
a
c b
E25X Synchronism Check Enable
Y Select: Y, N
25VLOX Voltage Window - Low Threshold (volts)
Range = 0.00 to 300.00104.00
25VHIX Voltage Window - High Threshold (volts)
Range = 0.00 to 300.00127.00
25VDIFX Maximum Voltage Difference (%)
Range = 1.0 to 15.0, OFFS. 1
25RCFX Voltage Ratio Correction Factor
Range = 0.500 to 2.0001.000
GENV+ Generator Voltage High Required
Select: Y, NN
25SLO Minimum Slip Fequency (Hz)
Range = -1.00 to 0.990.00
25SHI Maximum Slip Frequency (Hz)
Range = -0.99 to 1.000.10
25ANG 1X Maximum Angle 1 (degrees)
Range = 0 to 8010
25ANG2X Maximum Angle 2 (degrees)
Range = 0 to 8030
CANGLE Target Close Angle (degrees)
Range = -15 to 15-3
SYNCPX Synchronism Check Phase (VABX, VBCX, VCAX or deg lag VABX)
Select: 0, 30, 60, 90, 120, 150, 180, 210, 240, 270, 300, 330, VABX, VBCX, VCAXVBCX
TCLOSDX Breaker Close Time for Angle Compensation (milliseconds)
Range = 1 to 1000, OFF83
Synchronism Check Elements
Phase Angle Limit: 0 90 (Degree)10
Upper Voltage Limit: 60 140 (V)127
Lower Voltage Limit: 40 120 (V)104
Sync Check Delay: 1 8160 (Cycles)1
Delta Voltage: 1.0 50.0 (V)5.8
Delta Frequency: 0.001 0.500 (Hz)0.100
+
–
Setting
25VHIX
filter|VS|Utility Service Corporation
PO Box 1471
Huntsville, AL 35807
(256) 837-8400
apeterson@utilserv.com
www.utilserv.com
Alan D. Peterson
VISTAM, Inc.
2375 Walnut Ave
Signal Hill, CA 90755
(562) 912-7779
ulyses@vistam.com
130 • SUMMER 2022 ADVERTISERS
INDEPENDENT NETA
ACCREDITED COMPANIES
Absolute Testing Services Inc. . . . . . . . . . . . . . . . . . . . . . . . 19
American Electrical Testing Co., LLC . . . . . . . . . . . . . . . 25
Apparatus Testing and Engineering . . . . . . . . . . . . . . . . . . . 6
Burlington Electrical Testing . . . . . . . . . . . . . . . . . . . . . . . . 44
Eastern High Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Electrical Energy Experts, Inc. . . . . . . . . . . . . . . . . . . . . . . . 24
Elemco Services Inc. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
EnerG Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Industrial Electric Testing, Inc. . . . . . . . . . . . . . . . . . . . . . . 85
JET Electrical Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
North Central Electric, Inc. . . . . . . . . . . . . . . . . . . . . . . . . . 31
Potomac Testing, Inc. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Power Products & Solutions, Inc. . . . . . . . . . . . . . . . . . . . . 54
Power Systems Testing Co.  . . . . . . . . . . . . . . . . . . . . . . . . . 80
Scott Testing Inc.  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Shermco Industries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Taurus Power & Controls Inc.. . . . . . . . . . . . . . . . . . . . . . . 46
Tony Demaria Electric, Inc. . . . . . . . . . . . . . . . . . . . . . . . . . 97
ADVERTISERS
MANUFACTURERS AND
OTHER SERVICE PROVIDERS
AEMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Aero Tech Laboratories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
BCS Switchgear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Belyea Company . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Bullock Breakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Doble Engineering Company . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Doble Engineering Company, Phenix Technologies . . . . . . . . . . 111
e-Hazard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
ETI Precision  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
HV Diagnostics, Inc. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
High Voltage Electric Service Inc. . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
High Voltage, Inc. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
HV Technologies Inc. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Intellirent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Inside Front Cover
National Switchgear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
NETA ANSI/NETA ATS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
NETA Handbook Series III . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
NETA PowerTest 2022 Call for Exhibitors . . . . . . . . . . . . . . . . . . . 81
NETA PowerTest 2023 Call for Sponsors . . . . . . . . . . . . . . . . . . . . 26
NETA PowerTest 2023 Save the Date . . . . . . . . . . . . . . . . . . . . . . . . 33
OMICRON electronics Corp, USA . . . . . . . . . . . . . . . . . Back Cover
Protec Equipment Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Raytech USA Inc. . . . . . . . . . . . . . . . . . . . . . . . . . . . .Inside Back Cover
Sertec Relay Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Team UIS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Technitrol, Inc. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Thyritronics, Inc. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Utility Relay Company . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
ACCURATE
RELIABLE
SIMPLE TO USE
LIVE SUPPORT
888-484-3779 267-404-2676 raytechusa.com
To learn more about our product lines, request a quote, schedule a demonstration, for sales
or service, contact us 24/7.
Raytech’s
CAPO-12
is the most powerful,
accurate, easy-to-use
Capacitance
Power Factor
Test Set available
Known for precision and consistency,
our equipment delivers the highest accuracy
with repeatable results.
Ready to go right out of the box, Raytech equipment is simple to use –
just unpack, set up and start testing. Productivity is increased, saving
time and money. Raytech equipment is reliable, specifically made to
withstand the harsh environment of the testing industry. This is why
99% of the equipment sold by our company is still in service today,
and how we can offer a standard 5-year warranty with every instrument
at no additional cost. Free firmware updates are easy to download from
our website. Our exceptional 24/7 customer service and support set us
apart. You can always expect reliable, professional and personal assistance,
and we continue to support all instruments manufactured by Raytech.
Transformer Testing made quicker
and easier than ever before …
… was our vision for our new powerful and lightweight test set.
TESTRANO 600 is the world’s first portable, three-phase test system
that supports all of the common electrical tests done on power
transformers.
With just one set up for multiple tests, TESTRANO 600 significantly
reduces the wiring effort and testing time. Its specially designed
power amplifiers ensure a new level of accuracy, and the multi-
touch color display enables smart and comfortable operation.
www.omicronenergy.com/testrano-600
SCAN ME!
Brandon Dupuis
Regional Application Specialist
AD22008-TESTRANO600-NETA-8,5x11-ENU.indd 1 2022-05-06 08:54:32|VSf|
|Vpxc|
|(1-VPXc∕VSf)|•100%
+
–
+
–
+
–
+
–
+
–
+
–|(1-VPXc∕VSf)|•100%
Setting
25VDIFX
Relay
Word
Bits
59VPX
59VSX
GENVHI
GENVLO
VDIFX
25VCDB
VENX 1
Settings
25VLOX
BSYNCHX
GENV+ = Y
25VDIFX•0.80
GENV+ = Y
Vpxc = 25RCFX•VP (where 25RCFX is the setting and VP is determined by SYNCPX setting).
Setting
VDIFX
25VDIFX = OFF
59VPX
59VSX
BSYNCHX
SELOGIC
Setting
3.0
CYC
0
Generator
52X
13.8 kV
PTRS
PTRX
A to B
R1
R2
25
a
c b
E25X Synchronism Check Enable
Y Select: Y, N
25VLOX Voltage Window - Low Threshold (volts)
Range = 0.00 to 300.00104.00
25VHIX Voltage Window - High Threshold (volts)
Range = 0.00 to 300.00127.00
25VDIFX Maximum Voltage Difference (%)
Range = 1.0 to 15.0, OFFS. 1
25RCFX Voltage Ratio Correction Factor
Range = 0.500 to 2.0001.000
GENV+ Generator Voltage High Required
Select: Y, NN
25SLO Minimum Slip Fequency (Hz)
Range = -1.00 to 0.990.00
25SHI Maximum Slip Frequency (Hz)
Range = -0.99 to 1.000.10
25ANG 1X Maximum Angle 1 (degrees)
Range = 0 to 8010
25ANG2X Maximum Angle 2 (degrees)
Range = 0 to 8030
CANGLE Target Close Angle (degrees)
Range = -15 to 15-3
SYNCPX Synchronism Check Phase (VABX, VBCX, VCAX or deg lag VABX)
Select: 0, 30, 60, 90, 120, 150, 180, 210, 240, 270, 300, 330, VABX, VBCX, VCAXVBCX
TCLOSDX Breaker Close Time for Angle Compensation (milliseconds)
Range = 1 to 1000, OFF83
Synchronism Check Elements
Phase Angle Limit: 0 90 (Degree)10
Upper Voltage Limit: 60 140 (V)127
Lower Voltage Limit: 40 120 (V)104
Sync Check Delay: 1 8160 (Cycles)1
Delta Voltage: 1.0 50.0 (V)5.8
Delta Frequency: 0.001 0.500 (Hz)0.100
+
–
Setting
25VHIX
filter|VS|
|VSf|
|Vpxc|
|(1-VPXc∕VSf)|•100%
+
–
+
–
+
–
+
–
+
–
+
–|(1-VPXc∕VSf)|•100%
Setting
25VDIFX
Relay
Word
Bits
59VPX
59VSX
GENVHI
GENVLO
VDIFX
25VCDB
VENX 1
Settings
25VLOX
BSYNCHX
GENV+ = Y
25VDIFX•0.80
GENV+ = Y
Vpxc = 25RCFX•VP (where 25RCFX is the setting and VP is determined by SYNCPX setting).
Setting
VDIFX
25VDIFX = OFF
59VPX
59VSX
BSYNCHX
SELOGIC
Setting
3.0
CYC
0
Generator
52X
13.8 kV
PTRS
PTRX
A to B
R1
R2
25
a
c b
E25X Synchronism Check Enable
Y Select: Y, N
25VLOX Voltage Window - Low Threshold (volts)
Range = 0.00 to 300.00104.00
25VHIX Voltage Window - High Threshold (volts)
Range = 0.00 to 300.00127.00
25VDIFX Maximum Voltage Difference (%)
Range = 1.0 to 15.0, OFFS. 1
25RCFX Voltage Ratio Correction Factor
Range = 0.500 to 2.0001.000
GENV+ Generator Voltage High Required
Select: Y, NN
25SLO Minimum Slip Fequency (Hz)
Range = -1.00 to 0.990.00
25SHI Maximum Slip Frequency (Hz)
Range = -0.99 to 1.000.10
25ANG 1X Maximum Angle 1 (degrees)
Range = 0 to 8010
25ANG2X Maximum Angle 2 (degrees)
Range = 0 to 8030
CANGLE Target Close Angle (degrees)
Range = -15 to 15-3
SYNCPX Synchronism Check Phase (VABX, VBCX, VCAX or deg lag VABX)
Select: 0, 30, 60, 90, 120, 150, 180, 210, 240, 270, 300, 330, VABX, VBCX, VCAXVBCX
TCLOSDX Breaker Close Time for Angle Compensation (milliseconds)
Range = 1 to 1000, OFF83
Synchronism Check Elements
Phase Angle Limit: 0 90 (Degree)10
Upper Voltage Limit: 60 140 (V)127
Lower Voltage Limit: 40 120 (V)104
Sync Check Delay: 1 8160 (Cycles)1
Delta Voltage: 1.0 50.0 (V)5.8
Delta Frequency: 0.001 0.500 (Hz)0.100
+
–
Setting
25VHIX
filter|VS|
|VSf|
|Vpxc|
|(1-VPXc∕VSf)|•100%
+
–
+
–
+
–
+
–
+
–
+
–|(1-VPXc∕VSf)|•100%
Setting
25VDIFX
Relay
Word
Bits
59VPX
59VSX
GENVHI
GENVLO
VDIFX
25VCDB
VENX 1
Settings
25VLOX
BSYNCHX
GENV+ = Y
25VDIFX•0.80
GENV+ = Y
Vpxc = 25RCFX•VP (where 25RCFX is the setting and VP is determined by SYNCPX setting).
Setting
VDIFX
25VDIFX = OFF
59VPX
59VSX
BSYNCHX
SELOGIC
Setting
3.0
CYC
0
Figure 2: Double Supervision
Figure 3: R1 Settings
E25X := Y # ENABLE SYNC CHECK FUNCTION
25VLOX := 104 V # LOW VOLTAGE THRESHOLD
25VHIX := 127 V # HIGH VOLTAGE THRESHOLD
25VDIFX := 5.1% # MAXIMUM VOLTAGE DIFFERENCE
GENV+ := N # GENERATOR VOLTAGE HIGH REQUIRED
25SLO := 0.00 # MINIMUM SLIP FREQUENCY (Hz)
25SHI := 0.10 Hz # MAXIMUM SLIP FREQUENCY
25ANG1X := 10 degrees # MAXIMUM ANGLE 1
TCLOSDX := 83 ms # BREAKER CLOSE TIME (milliseconds)
Figure 4: R2 Settings
16 • SUMMER 2022
Figure 8 shows the voltage comparison
(VDIF and VENX) logic for R1. The voltage
difference logic includes the GENV+ input
and that this must be true for at least three
cycles before VENX asserts and enables the
angle comparison calculation. Therefore,
25AX1, 25AX2, and 25C cannot assert if
VENX is not true. As previously noted, R2
does not have this logic, so this functionality
was lost.
SYNC CHECK SUPERVISION
RELAY COLUMN
Figure 5: COMTRADE Record 1
Figure 6: COMTRADE Record 2
Figure 7: COMTRADE Record 3
NETAWorld • 17SYNC CHECK SUPERVISION
RELAY COLUMN
Generator
52X
13.8 kV
PTRS
PTRX
A to B
R1
R2
25
a
c b
E25X Synchronism Check Enable
Y Select: Y, N
25VLOX Voltage Window - Low Threshold (volts)
Range = 0.00 to 300.00104.00
25VHIX Voltage Window - High Threshold (volts)
Range = 0.00 to 300.00127.00
25VDIFX Maximum Voltage Difference (%)
Range = 1.0 to 15.0, OFFS. 1
25RCFX Voltage Ratio Correction Factor
Range = 0.500 to 2.0001.000
GENV+ Generator Voltage High Required
Select: Y, NN
25SLO Minimum Slip Fequency (Hz)
Range = -1.00 to 0.990.00
25SHI Maximum Slip Frequency (Hz)
Range = -0.99 to 1.000.10
25ANG 1X Maximum Angle 1 (degrees)
Range = 0 to 8010
25ANG2X Maximum Angle 2 (degrees)
Range = 0 to 8030
CANGLE Target Close Angle (degrees)
Range = -15 to 15-3
SYNCPX Synchronism Check Phase (VABX, VBCX, VCAX or deg lag VABX)
Select: 0, 30, 60, 90, 120, 150, 180, 210, 240, 270, 300, 330, VABX, VBCX, VCAXVBCX
TCLOSDX Breaker Close Time for Angle Compensation (milliseconds)
Range = 1 to 1000, OFF83
Synchronism Check Elements
Phase Angle Limit: 0 90 (Degree)10
Upper Voltage Limit: 60 140 (V)127
Lower Voltage Limit: 40 120 (V)104
Sync Check Delay: 1 8160 (Cycles)1
Delta Voltage: 1.0 50.0 (V)5.8
Delta Frequency: 0.001 0.500 (Hz)0.100
+
–
Setting
25VHIX
filter|VS|
|VSf|
|Vpxc|
|(1-VPXc∕VSf)|•100%
+
–
+
–
+
–
+
–
+
–
+
–|(1-VPXc∕VSf)|•100%
Setting
25VDIFX
Relay
Word
Bits
59VPX
59VSX
GENVHI
GENVLO
VDIFX
25VCDB
VENX 1
Settings
25VLOX
BSYNCHX
GENV+ = Y
25VDIFX•0.80
GENV+ = Y
Vpxc = 25RCFX•VP (where 25RCFX is the setting and VP is determined by SYNCPX setting).
Setting
VDIFX
25VDIFX = OFF
59VPX
59VSX
BSYNCHX
SELOGIC
Setting
3.0
CYC
0
Generator
52X
13.8 kV
PTRS
PTRX
A to B
R1
R2
25
a
c b
E25X Synchronism Check Enable
Y Select: Y, N
25VLOX Voltage Window - Low Threshold (volts)
Range = 0.00 to 300.00104.00
25VHIX Voltage Window - High Threshold (volts)
Range = 0.00 to 300.00127.00
25VDIFX Maximum Voltage Difference (%)
Range = 1.0 to 15.0, OFFS. 1
25RCFX Voltage Ratio Correction Factor
Range = 0.500 to 2.0001.000
GENV+ Generator Voltage High Required
Select: Y, NN
25SLO Minimum Slip Fequency (Hz)
Range = -1.00 to 0.990.00
25SHI Maximum Slip Frequency (Hz)
Range = -0.99 to 1.000.10
25ANG 1X Maximum Angle 1 (degrees)
Range = 0 to 8010
25ANG2X Maximum Angle 2 (degrees)
Range = 0 to 8030
CANGLE Target Close Angle (degrees)
Range = -15 to 15-3
SYNCPX Synchronism Check Phase (VABX, VBCX, VCAX or deg lag VABX)
Select: 0, 30, 60, 90, 120, 150, 180, 210, 240, 270, 300, 330, VABX, VBCX, VCAXVBCX
TCLOSDX Breaker Close Time for Angle Compensation (milliseconds)
Range = 1 to 1000, OFF83
Synchronism Check Elements
Phase Angle Limit: 0 90 (Degree)10
Upper Voltage Limit: 60 140 (V)127
Lower Voltage Limit: 40 120 (V)104
Sync Check Delay: 1 8160 (Cycles)1
Delta Voltage: 1.0 50.0 (V)5.8
Delta Frequency: 0.001 0.500 (Hz)0.100
+
–
Setting
25VHIX
filter|VS|
|VSf|
|Vpxc|
|(1-VPXc∕VSf)|•100%
+
–
+
–
+
–
+
–
+
–
+
–|(1-VPXc∕VSf)|•100%
Setting
25VDIFX
Relay
Word
Bits
59VPX
59VSX
GENVHI
GENVLO
VDIFX
25VCDB
VENX 1
Settings
25VLOX
BSYNCHX
GENV+ = Y
25VDIFX•0.80
GENV+ = Y
Vpxc = 25RCFX•VP (where 25RCFX is the settingand VP is determined by SYNCPX setting).
Setting
VDIFX
25VDIFX = OFF
59VPX
59VSX
BSYNCHX
SELOGIC
Setting
3.0
CYC
0
Figure 8a: R1 Logic
Figure 8b: R1 Logic
18 • SUMMER 2022
Slip Frequency
We can estimate the slip frequency by measuring
the time (period) between zero crossings.
System frequency = 1/0.016667 = 59.999 Hz
(Figure 9)
Generator frequency = 1/ 0.016648 = 60.067
Hz (Figure 10)
Therefore, the slip frequency is 60.067 –
59.999 = 0.068 Hz.
SUMMARY
Using two different relays to supervise
sync check means that some of the overall
functionality is lost since they do not
completely duplicate each other. For example,
SYNC CHECK SUPERVISION
INDUSTRY TOPICS
the GENV+ setting originally blocked closing
since the voltages are matched, so this function
had to be disabled. Matching settings results
in much more consistent performance between
the two relays.
Steve Turner is in charge of system protection
for the Fossil Generation Department
at Arizona Public Service Company in
Phoenix. Steve worked as a consultant for
two years, and held positions at Beckwith
Electric Company, GEC Alstom, SEL, and
Duke Energy, where he developed the first
patent for double-ended fault location on overhead high-voltage
transmission lines and was in charge of maintenance standards
in the transmission department for protective relaying. Steve has
BSEE and MSEE degrees from Virginia Tech University. Steve is
an IEEE Senior Member and a member of the IEEE PSRC, and
has presented at numerous conferences.
Figure 9: System Frequency
Figure 10: Generator Frequency
Absolute con�dence. Every time.
Toll Free 1+ (855)767-4446
8100 West Little York | Houston, Texas 77040
Email: Alan Postiglione | apost@absolutetesting.com | www.absolutetesting.com
Like us on:
You can count on us for specialized experience in healthcare, data center, o� ce complex, and commercial
acceptance and maintenance testing. Absolutely. Power generation, petrochemical, oil & gas, and heavy
industries also look to us for high demand services such as start-up commissioning, maintenance testing,
shut-down and turnarounds, and breaker shop repair. Get started today.
20 • SUMMER 2022 IMPROVING SAFETY IN THE FIELD
BY MATT EAKINS, Advanced Electrical Services, Ltd.
Becoming a great company doesn’t happen overnight. Instead, it is about
small, incremental steps as we progress down the road of becoming
better and better at what we do and how we do it.
This is the most critical as it relates to our safety
processes and safety culture. It is important to
note that the first step in making a situation
safer is to engineer the hazard out of it; the last
step is to use PPE.
Technology also plays a huge role, but at
the end of the day, it is often an individual’s
decisions and actions that lead to an incident.
Unfortunately, humans will make mistakes
regardless of how many processes, procedures,
and rules companies implement. These
mistakes can lead to damaged equipment and
injury to the individual or someone else. So,
what can we do?
One tool we use is to put a giant red or yellow
flag figuratively and literally in front of people’s
faces. Human performance improvement
(HPI) methods are a way of alerting someone
regardless of whether they are an inexperienced
junior technician or a senior technician who
may have become complacent to the fact that a
step must be taken before moving forward with
a task. HPIs help with common hazards from
slips, trips, and falls all the way to catastrophic
incidents such as leaving ground chains applied
during energization or working on a live
current transformer (CT) circuit.
The goal of this discussion is to share some best
practices from the field and provide the reader
with the opportunity to think critically about
using HPIs within their organization as a way
to continually improve safety and efficiency.
BARRIERS
The first example is a high-voltage substation
where the team is following required safe work
methods by, among other steps, installing
barriers (Figure 1 and Figure 2) in places where
live CTs and in-service protections are energized.
This physical barrier allows technicians to easily
flag the location where the work is to take
place by covering nearby modules, racks, etc.
This greatly reduces the chance of technicians
mistakenly working on modules that are outside
the work zone or isolations. It also minimizes
the likelihood of opening live CT secondaries,
IMPROVING
SAFETY
 FIELD
IN THE FIELD
I N
T H E
NETAWorld • 21IMPROVING SAFETY IN THE FIELD
which can cause serious injury or death as well as
major damage to equipment and systems.
All CT circuits in the uncovered modules are
verified for zero current prior to work starting.
In addition to assuring personnel safety, it
reduces the chance of tripping any in-service
equipment as these modules are covered up
(Figure 3), and improves efficiency as the work
locations are obvious and clearly marked. The
absence of voltage and current can be verified
based on isolations including guarantee of
isolation (GOI), clearance, and lockout, and
live terminals can be flagged or taped off. This
must remain consistent throughout the work.
When work must be performed on flagged
racks, these methods remind technicians that
terminals must be checked for voltage and
current since this has not previously been
verified. Unfortunately, there have been too
many incidents where a technician or electrician
is exposed to an arc flash or electric shock from
working in the wrong location after a lunch
IN THE FIELD
PHOTO: © ISTOCKPHOTO.COM/PORTFOLIO/MATEJMO
Figure 1: Front of Protection and Control
Racks in a High-Voltage Substation
Figure 2: Rear of Protection and Control
Racks in a High-Voltage Substation
22 • SUMMER 2022
break, shift change, or days off. HPI steps like
this are critical to continuous improvement
within a safety system, and we must make it a
priority to reduce or eliminate this hazard.
VEHICLE HAZARDS
One of the biggest causes of workplace injuries is
slips, trips, and falls, which can occur more often
when exiting vehicles during inclement weather.
At the same time, crashes and collisions while
driving, regardless of the industry, continue
to be a leading cause of injuries. To address
these issues, we have implemented an HPI for
360-degree vehicle walk-arounds (Figure 4)
to be completed when entering and exiting a
vehicle. The goal is simple but critical: Reduce
slips when entering and exiting, make sure the
vehicle is safe to drive, and ensure no one will be
hurt when the vehicle moves.
Yellow steering-wheel covers (Figure 4) with a
message remind our drivers to always use three
points of contact when entering or exiting the
vehicles. To ensure safety for those around our
vehicles, drivers are reminded to do a complete
360-degree walk-around before operating the
vehicle. Additional precautions could include
placing a cover on the passenger-side mirror
as a reminder to walk around the vehicle. To
supplement the walk-around process, our
team uses a safety app to complete an online
checklist that documents and submits their
findings for future review and audits.
HPI AND NETA
Where can HPIs be used in the NETA service
world?
•	 Remove ground chains prior to
energization.
•	 Record “as left” and “as found” settings of
relays and breakers during a maintenance
turnaround.
•	 Remove and re-terminate leads, i.e.,
remove transformer leads for testing.
•	 Erect red flags or physical barriers in front
of equipment that may still be energized
during maintenance.
OTHER HAZARDS
What other hazards or injuries can HPIs
address? A great starting point would be to look
at what could have stopped an incident or near
IMPROVING SAFETY IN THE FIELD
IN THE FIELD
Figure 3: Before and After a Protection & Control Relay Upgrade Project
Figure 4: Steering-Wheel Cover
miss from occurringand implement an HPI so
it does not happen again. Additionally, it may
make sense for your organization to start with
the most common workplace incidences:
•	 Slips, trips, and falls
•	 Muscle strains
•	 Repetitive strains
•	 Crashes and collisions
•	 Cuts and lacerations
•	 Inhaling toxic fumes
•	 Exposure to loud noise
•	 Walking into objects
In fiscal year 2020 (October 1, 2019, through
September 30, 2020), these 10 OSHA standards
were cited most frequently:
 1. Fall Protection, Construction 29 CFR
1926.501, www.osha.gov/fall-protection.
 2. Hazard Communication Standard,
General Industry 29 CFR 1910.1200,
www.osha.gov/hazcom.
IN THE FIELD
 3. Respiratory Protection, General
Industry 29 CFR 1910.134,
www.osha.gov/respiratory-protection.
 4. Scaffolding, General Requirements,
Construction 29 CFR 1926.451,
www.osha.gov/scaffolding.
 5. Ladders, Construction 29 CFR
1926.1053, www.osha.gov/fall-protection.
 6. Control of Hazardous Energy (Lockout/
Tagout), General Industry 29 CFR
1910.147, www.osha.gov/control-
hazardous-energy.
 7. Powered Industrial Trucks, General
Industry 29 CFR 1910.178, www.osha.
gov/powered-industrial-trucks.
 8. Fall Protection, Training Requirements 29
CFR 1926.503, www.osha.gov/fall-
protection.
 9. Eye and Face Protection 29 CFR
1926.102, www.osha.gov/eye-face-protection.
 10. Machinery and Machine Guarding,
General Requirements 29 CFR 1910.212,
www.osha.gov/machine-guarding.
Editor’s Note: Watch for OSHA’s 2021 report
soon after April 1, 2022.
CONCLUSION
Human performance improvements can be a
great auditing tool. It can be difficult during
a site safety audit to know, for example,
whether the crew knew whether equipment
was energized or not energized. However, if
an energized area should have been covered
and it was not, you have a red flag that more
training is required. In the case of an HPI like
the steering wheel cover, it is either on or off.
Whether the HPI is a traditional barrier or a
visual reminder, the intent is to force a critical
step in the sequence of events. The goal of this
forced step is to break the chain of events that
might have led to an incident. In addition
to creating a safer company, HPIs can also
contribute to making it more profitable.
REFERENCES
[1] Work Safety Blog. “10 of the Most
Common Workplace Accidents and
Injuries,” Accessed at 10 of the Most
Common Workplace Accidents and Injuries |
Work Safety Blog (blog4safety.com).
[2] OSHA. “Top 10 Most Frequently Cited
OSHA Standards Violated in FY2020.”
Available at www.osha.gov/data/commonstats.
Matt Eakins is the Technical Services
Manager at Advanced Electrical Services
Ltd. He has 12-plus years of experience
testing and commissioning in the industrial
and utility sectors of Western Canada.
Matt is a NETA Level 3 Technician and
an ASET CET who studied electronics
engineering at the RCC Institute of Technology (Concord,
Ontario) as well as electrical techniques at Loyalist College
(Bellville, Ontario). Matt began his career with AES in 2009;
he is now responsible for managing medium- to large-scale
electrical commissioning and maintenance projects for AES’s
many clients across Western Canada.
IN THE FIELD

• Full Member of the InterNational Electrical Testing Association (NETA)
• Licensed Electricians (IBEW-JIW)
• Member of the National Electrical Contractors Association (NECA)
• ISO/IEC 17025 Accredited
Acceptance Testing •Preventative and Predictive Maintenance •Technical
Support•Protective Relays • Transformers• Switchgear • Breakers • Infrared &
Ultrasonic Survey • Cable Locating • VLF & Tan Delta Testing• Partial Discharge•
Meters• Grounding• Generator Controls• ATS• UPS• Battery Systems • Motor
Control Centers • Switches• Capacitor Banks
888-956-9833
Ann Arbor, MI • Dayton, OH
www.teamuis.com
Electrical Studies
Short Circuit/Device Coordination Studies • Arc Flash/Shock Hazard Studies •
Harmonic/Power Factor/Transient Studies & Corrections
Training
• Electrical Safety & Troubleshooting • NFPA 70E
Contact UIS
Electrical Testing & Commissioning
Electrical Studies & Training
When downtime is not an option.TM
When downtime is not an option.TM
_ 11
- 1 1
■■■■
AET Brings Precision and Value to Electrical
Testing, Commissioning and Engineering ...
and Positive Results to Our Customers.
AET delivers the best value in the marketplace by offering the highest
quality service at competitive prices. With a workforce and offices
located throughout the country, AET is an industry leader and one of
the largest independent electrical testing companies in the U.S.
To learn more about AET's full range of testing and
engineering services, visit www.aetco.us
� WWW.AITCO.US • 800.992.3826
AET-IBEW Full Page Ad-FINAL-8.75 X 11.25.indd 1
� � 11 _
AMERICAN
ELECTRICAL
TESTING
10/5/17 11:44AM I I-

March 8– 12, 2023
Rosen Shingle Creek | Orlando, Florida
Promote your products and services to a valuable audience of
key industry decision-makers while increasing brand visibility.
THE PREMIER ELECTRICAL MAINTENANCE AND SAFETY CONFERENCE
POWERTEST.ORG | 888.300.6382
HOSTED BY
OFFERING IN-PERSON AND
VIRTUAL ATTENDANCE OPTIONS
NETAWorld • 27PERFORMING PERSONNEL AUDITS
SAFETY CORNER
PH
O
TO
: ©
 IS
TO
C
KP
H
O
TO
.C
O
M
/P
O
RT
FO
LIO
/A
LE
KS
A
N
D
A
RG
EO
RG
IE
V
BY PAUL CHAMBERLAIN, American Electrical Testing Co. LLC
They are called many things — observations, audits, assessments —
but they are all intended to accomplish the same task: Evaluate the
people in the field performing the task at hand. Generally, you observe
an employee doing a task, then audit or assess whether performance of
the task meets expectation.
These inspections can be performed by any level
within a company and should be performed on all
levels. Some companies hire a third-party entity
to ensure the inspections remain completely
impartial. However, in most cases, companies
choose to have a manager or a member of the
supervisory team conduct the inspection of their
field personnel. If this is the case, it is a wise idea
to set up some standards, such as frequency, for
the inspection and have a verification done by a
third party or safety manager.
While the main intent of these inspections
is to ascertain several things, not everyone is
aware of the potential benefits to the company.
A check sheet should be used to facilitate the
observation and to help gain the most out of
it. Let’s review the aspects of a proper field
observation and the benefits any company,
employee, and manager could gain from it.
LOCKOUT/TAGOUT
First, let’s review some important items that
should be verified when a manager is observing
a crew performing work in the field. OSHA
requires lockout/tagout procedures to be
verified annually. Under 29 Code of Federal
Regulations 1910.147, OSHA specifically states
PERFORMING
PERSONNEL
AUDITS
28 • SUMMER 2022 PERFORMING PERSONNEL AUDITS
SAFETY CORNER
when this verification is required, although the
requirements may be slightly different across
each of the industries OSHA regulates. Within
OSHA, each industry-specific regulation has its
own separate section indicating the control of
hazardous energy. Let’s consider two specific areas
that pertain directly to electrical testing: 1910.147
regulates commercial installations, and 1910.269
specifically regulates utility installations.
1910.147
Under 1910.147, you are required to ensure
that procedures are being correctly followed by
the employee performing the lockout/tagout.
Specifically it states:
1910.147(c)(6) Periodic Inspection
1910.147(c)(6)(i) The employer shall conduct a
periodic inspection of the energy control procedure
at least annually to ensure that the procedure
and the requirements of this standard are being
followed.
1910.147(c)(6)(i)(A) The periodic inspection shall
be performed by an authorized employee other than
the ones(s)utilizing the energy control procedure
being inspected.
1910.147(c)(6)(i)(B) The periodic inspection
shall be conducted to correct any deviations or
inadequacies identified.
1910.147(c)(6)(i)(C) Where lockout is used for
energy control, the periodic inspection shall include
a review, between the inspector and each authorized
employee, of that employee’s responsibilities under
the energy control procedure being inspected.
1910.147(c)(6)(i)(D) Where tagout is used
for energy control, the periodic inspection shall
include a review, between the inspector and
each authorized and affected employee, of that
employee’s responsibilities under the energy control
procedure being inspected, and the elements set
forth in paragraph (c)(7)(ii) of this section.
1910.147(c)(6)(ii) The employer shall certify
that the periodic inspections have been performed.
The certification shall identify the machine or
equipment on which the energy control procedure
was being utilized, the date of the inspection, the
employees included in the inspection, and the
person performing the inspection.
1910.269
We can further see that the 1910.269 standard
does not differ greatly from 1910.147 in its
requirements:
1910.269(a)(2)(ii)(D) The proper use of the
special precautionary techniques, personal protective
equipment, insulating and shielding materials,
and insulated tools for working on or near exposed
energized parts of electric equipment. Note: For
the purposes of this section, a person must have
this training in order to be considered a qualified
person.
1910.269(a)(2)(iii) The employer shall
determine, through regular supervision and
through inspections conducted on at least an
annual basis, that each employee is complying
with the safety-related work practices required by
this section.
After reviewing these regulatory excerpts, it
can be seen that every company is required
to inspect and certify that employees are
properly performing lockout/tagout whether
they are working for a utility or a commercial
entity. Incorporating this certification as part
of a field observation or assessment kills
two birds with one stone. Other regulatory
mandated observations are dependent
upon the task and industry. Please check
www.osha.gov to guide you in determining
which regulations apply.
VEHICLE SAFETY
Another benefit gained by performing field
observations of employees is that the employer
can ensure they are following other pertinent
company policies. For example, observing
vehicle use might verify whether employees
wear seatbelts while driving company vehicles,
only use hands-free devices, do not talk on
a cell phone while driving or performing a
complex task, and minimize the need for
backing.
Additionally, if your company does a lot of
driving or uses federally regulated vehicles, it
may be necessary to observe employees as they
operate the vehicle. This can be conducted as
a ride-along observation where the supervisor
rides in the vehicle with the employee, or as a
follow-along observation where the supervisor
follows the employee while in a separate
vehicle. It is usually wise to create separate
forms just for these types of observations, since
the rules of the road are extensive and can vary
depending upon the state they operate in and
the type of vehicle they are driving. Another
example would be the operation of a fork truck.
FLAGGING AND TAGGING
A company could also include a check sheet
for documenting the proper use of protective
and cautionary flagging and tagging. In
some instances, a client may have a different
procedure for this, so it is good company policy
to ensure that employees not only follow your
company’s policy, but also the client’s company
policy if applicable. The default course of action
in this type of scenario is to play it safe and
follow the stronger policy. The observer would
need to know what the client’s requirements are
prior to going to the site.
PERSONAL PROTECTIVE
EQUIPMENT
One benefit to conducting field observations
and audits is to ensure that employees use the
correct personal protective equipment (PPE).
Hard hats, safety glasses. The inspector should
check to see that employees are wearing hard hats
whenever something could fall or strike their
head or when they could make incidental contact
with high-voltage equipment. The inspector
should examine the hard hat for cracks, wear,
discoloration, or torn cradles and straps. Safety
glasses are necessary whenever there is potential
for a liquid or solid to fly through the air and
SAFETY CORNER
Power Factor / Tan Delta
& Capacitance
MIDAS micro 2883
Winding
Analyzer
2293
Turns Ratio
Meters
TTR 2795 / TTR 2796
Sweep Frequency
Response Analyzer
FRA 5311
Your Trusted Source for HAEFELY / TETTEX Substation Test Equipment
T: (703) 365-2330 | F: (703) 365-2331 | hvsales@hvtechnologies.com
Request a quote online at hvtechnologies.com
HV TECHNOLOGIES, Inc. is now the exclusive distributor and
service center for all HAEFELY / TETTEX Substation Test
Equipment Products in USA!
30 • SUMMER 2022 PERFORMING PERSONNEL AUDITS
SAFETY CORNER
enter the eye. The inspector should ensure that
the glasses are ANSI Z87-approved, which is
indicated on the lens or the brow.
Clothing, footwear, gloves. Verifying correct
PPE clothing can also be an item on the check
sheet, as can ensuring employees are wearing
the proper footwear, such as ASTM F2413.05-
approved electrical hazard safety-toed footwear,
which may or may not have height and laces
requirements. Ensuring that the clothing
they are wearing is cotton or calorie-rated
for fire and arc protection could be an item.
Additionally, verify that electrical protection
such as voltage-rated gloves are inspected before
each use, the correct level of protection is worn,
and the test date is within the required date
range. If a manager is planning to inspect these
more-disposable PPE items, it is always a good
idea to bring extra hard hats and safety glasses
out into the field in case an employee needs a
new set.
Heat-related illness. In companies where
there is extensive physical labor or employees
work in very hot areas, the observer could
supply drinking water or other suitable fluids.
This will not only boost morale, but will also
improve productivity. Just the act of a manager
supplying the drink and talking with employees
can provide the adequate cool-off time needed
to prevent a potential heat-related illness, and
preventing that heat-related illness can prevent
a potential OSHA-recordable injury.
ENVIRONMENT
Inspection of the general work environment
can also benefit the company and the manager.
Even though a lead technician or foreman
may be conducting this inspection daily, they
can still miss things or get used to seeing
something that needs correction. Having
someone different as well as new to the site can
provide a new set of eyes, which may make it
easier to identify potential problems or issues
that could contribute to lost production or an
injury. In some cases, the manager can arrange
to meet with the client during the audit, thus
presenting that all-important face for the client
to remember.
During the observation, the observer should
make it a point to ask questions:
• Is there anything the company could do
to make the job easier, safer, or better?
The answers to this question can range
from thought-provoking to ludicrous.
But occasionally, a brilliant idea that can
revolutionize a task can be evoked by
simply asking that question. Remember,
employees don’t know how much you
care until you show them you care. If they
give a good answer, act on it, and a reward
should accompany any good idea that is a
benefit to the company.
• Is all the equipment you need for the job
present and working properly, and is it
the right equipment for the task? Newer
employees may be hesitant to speak up
if something doesn’t work rightand just
struggle along using what they’ve got. This
can obviously slow down task performance
and potentially contribute to injury or
equipment damage.
THE OBSERVER’S ROLE
The observer should be familiar with the
procedure they are observing. In some cases,
they may be considered experts in the task. If
this is the case, the inspector could provide
direction and add to the employee’s knowledge
of the task by observing and critiquing. Being
knowledgeable in the procedure can also help
the inspector identify when a procedure is
being performed incorrectly. We all develop
bad habits, and in many cases, we are unaware
of them. If the observer is knowledgeable of
the proper procedure and notices an employee
performing it in a different or incorrect
manner, the manager can correct the task
before the error causes an incident.
An added benefit to having an upper-level
manager perform these observations is simply
face time. All too often, field employees don’t
associate a face with a name. All they know
is the name and that when the phone rings,
the manager will likely have another request
or change in scope. Sending the manager
SAFETY CORNER
out into the field increases the camaraderie
in the project, which in turn can potentially
make it more productive. If the manager is
just some faceless voice that calls to change
things, it becomes easier for employees
to become complacent in responding to
requests. If you show up on site and form a
bond with employees, it goes a long way to
improve your relationship with them. And
with the stress placed upon a manager these
days when managing a client, getting outside
of the cubicle or office can go a long way to
improving morale. The best way a manager can
ensure getting out there happens is to schedule
it, and the best way a company can ensure it
gets done is to mandate it and reward those
who meet or exceed the requirement.
CONCLUSION
There are many advantages to performing field
observations, audits, or inspections. They boost
morale and prevent injuries and ensure that the
correct equipment is available, is being used
correctly, and can be used to satisfy regulatory
requirements. It helps to select observers
knowledgeable in the scope of work, schedule
adequate time to get them out in the field, and
give praise when it is due. Utilize a check sheet
to make the observer’s job easier to perform.
Properly performed field inspections can go a
long way to improving your company’s safety
culture.
Paul Chamberlain has been the Safety
Manager for American Electrical Testing
Co. LLC since 2009. He has been in the
safety field since 1998, working for various
companies and in various industries. Paul
received a BS from the Massachusetts
Maritime Academy.
32 • SUMMER 2022 TECH QUIZ
TECH QUIZ
SAFETY
BY VIRGINIA BALITSKI, Magna IV Engineering
Safety is an important consideration for any workplace and for NETA Certified
Technicians. ANSI/NETA MTS-2019 recognizes that an overwhelming majority of
the tests and inspections carried out by NETA Certified Technicians are potentially
hazardous. It is essential that workers are aware of the hazards involved with the
tasks they perform.
QUESTIONS
1. What United States regulatory agency
exists regarding workplace safety?
a. Occupational Safety and Health
Administration (OSHA)
b. National Fire Protection Association
(NFPA)
c. Bureau of Labor Statistics (BLS)
d. Centers for Disease Control and
Protection (CDC)
2. What is the standard for electrical safety in
the workplace in the US?
a. NFPA 70
b. NFPA 101A
c. NFPA 70E
d. NFPA 5000
3. According to ANSI/NETA MTS-2019,
5.1 Safety and Precautions, what shall be
conducted prior to the commencement of
work?
a. Test report
b. Safety briefing
c. Power system study
d. Detailed safety program
4. According to OSHA, what is one of the
root causes of workplace injuries, illnesses,
and incidents?
a. Untrained workers
b. Inadequate personal protective
equipment
c. Failure to identify or recognize hazards
d. Age of the equipment
5. Which electrical hazards should be
considered and identified prior to starting
work?
a. Electrical shock
b. Arc flash
c. Arc blast
d. All of the above
6. What must be introduced to eliminate the
electrical hazards associated with any work
task?
a. Safe work procedures
b. Electrically safe working condition
c. Personal protective equipment
d. Barriers and safeguarding devices
No. 137
See answers on page 121.
Offering
in-person and
virtual attendance
options
M A R C H 8 – 1 2 , 2 0 2 3
ROSEN SHINGLE CREEK | ORLANDO, FLORIDA
HOSTED BY
POWERTEST.ORG | 888 .300 .6382
SAVE THE
DATE
T H E P R E M I E R E L E C T R I C A L M A I N T E N A N C E A N D S A F E T Y C O N F E R E N C E
34 • SUMMER 2022 SAFETY TESTING OF EV CHARGERS
BY JEFF JOWETT, Megger
Electric vehicles are prominently heralded as the trend of the future, a
vital part of many planned economies’ efforts to combat global warming,
widespread pollution, and the squandering of resources. But there has also
been negative publicity over safety issues like car fires.
The key to enjoying the best of both worlds —
excellent performance under complete safety
— is to practice diligent maintenance. Do not
take performance for granted. It’s easy to ride
the crest of a popular trend and overlook the
details, but don’t. Become familiar with the
possible safety hazards and industry-standard
recommendations for preventing them.
The electric vehicle charger forms a dynamic
link between the nearly infinite power of the
electrical grid and the volatile potential of the
car battery, possibly with the added potential
hazard of a tank of gasoline only inches away
in the case of hybrids. Be sure to maintain
the safety of this vital link with regular and
thorough maintenance of the charger.
EV CHARGER TESTING
Electric vehicle charger testers are available
and dedicated to assuring the function and
safety of the unique configuration of an
electric vehicle charger. An electric vehicle
charger tester should perform seven tests:
SAFETY TESTING OF
EV CHARGERS
TECH TIPS
PH
O
TO
: ©
 S
TO
C
K.
A
D
O
BE
.C
O
M
/C
O
N
TR
IB
U
TO
R/
20
34
59
82
0/
IR
O
N
TR
YB
EX
NETAWorld • 35SAFETY TESTING OF EV CHARGERS
four for safety, plus two operational tests and
a check for nuisance tripping.
It is a good idea to head off any potential
dangers by testing the charger upon acquisition
so it isn’t merely assumed to be fully functional
because it is new.
Make sure the new charger meets manufacturing
specifications. Do the same after any repair, and
incorporate charger testing into any preventive/
predictive maintenance program. It is important
to perform the tests in a specific sequence,
assuring safety first. Always remember, however,
that the charger is an electrical connection
between the vehicle and an electrical facility,
such as a building service. That service must also
be grounded, tested, and maintained.
Protective Earth
The first test verifies protective earth. The EV
charger tester takes the place of the vehicle for
the performance of the tests. The charger is
plugged into the on-site power source, just as it
would be if it were charging a vehicle.
The power grid, if not correctly utilized,
can be a potential source of electrocution,
fire, equipment damage, and other hazards.
Therefore, the vehicle charger must maintain a
protective ground, and this is not to be taken for
granted. Ground connection can be lost while
performing its designated function, as fault
currents can open bonds even while being safely
cleared. The next person using the faulted item
— in this case, the vehicle charger — will be at
unwitting risk should another hazard arise.
The charger tester will ensure that a proper
ground is in place and functional. The tester
applies a charging code to the charger to put it
into a charging state.
