VestasOnline
®
 Business
Advanced Reporting Module Administration
Manual
Version 3.9
958879.R10


VESTAS PROPRIETARY NOTICE: This document contains valuable confidential information of Vestas Wind Systems A/S. It is protected by copyright law as an unpublished work. Vestas reserves all patent, copyright, trade secret, and
other proprietary rights to it. The information in this document may not be used, reproduced, or disclosed except if and to the extent rights are expressly granted by Vestas in writing and subject to applicable conditions. Vestas
disclaims all warranties except as expressly granted by written agreement and is not responsible for unauthorized uses, for which it may pursue legal remedies against responsible parties.






VestasOnline® Business
Advanced Reporting Module Administration Manual
Version 3.9



© 2011 Vestas Wind Systems A/S. All rights reserved.
VestasOnline®® Business 3.9 – Advanced Reporting Module Administration Manual.
This manual, as well as the software described in it, is furnished under license and may be used or copied only in
accordance with the terms of such license. The content of this manual is furnished for informational use only, is subject
to change without notice, and should not be construed as a commitment by Vestas Wind System A/S.
Vestas Wind Systems A/S assumes no responsibility or liability for any errors or inaccuracies that may appear in this
documentation, and Vestas Wind Systems A/S shall to the fullest extent permitted by applicable law not be liable for any
indirect or direct damage or loss resulting from the use of such information, including but not limited to loss of profit,
loss of data, loss of production, loss of goodwill or damage to property or persons. Vestas Wind Systems A/S shall
however, be obligated to amend, or re-deliver the manual or parts thereof to the extent that licensee have notified Vestas
Wind Systems A/S of errors in the manuals within one year from date of the license being effective. The obligation to
repair or re-deliver the manual or parts thereof without error shall be the exclusive remedy of licensee in the event of
defective manuals.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, recording, or otherwise, without the prior written permission of Vestas Wind Systems A/S, except
as permitted by such license. Vestas Wind Systems A/S retains all rights to the manual, as well as the software described
in it, subject only to the right to use as set forth in the terms of the license.
VestasOnline®®is a trademark of Vestas Wind Systems A/S.
All terms of the license and this shall apply equally to the benefit of any affiliate of Vestas Wind Systems A/S, including
without limitation any subsidiary of Vestas Wind Systems A/S, any officer, manager, director or member of the board of
directors of Vestas Wind Systems A/S or its subsidiaries.
Item number: 958879.R10 (March 2012).





VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page i
Table of Contents

Chapter 1 Introduction ............................. 1
Chapter 2 Shadow Data Editor ....................... 2
2.1 The basic windows for editing of shadow data .................................... 2
2.1.1 Profile ....................................................................................................... 3
2.1.2 Date and time details ............................................................................. 3
2.1.3 Park unit .................................................................................................. 3
2.1.4 View ......................................................................................................... 3
2.1.5 Retrieving data ....................................................................................... 4
2.2 The Shadow Data Editor window ........................................................... 4
2.2.1 The toolbar buttons ................................................................................ 4
2.2.2 Selecting or changing the unit to be edited ........................................ 5
2.2.3 Presentation of unit information.......................................................... 5
2.3 Database maintenance tool ...................................................................... 7
2.3.1 Mass-editing tool.................................................................................. 10
2.4 The Shadow Data Quick Tools .............................................................. 11
2.4.1 Period ..................................................................................................... 12
2.4.2 Search ..................................................................................................... 12
2.4.3 Filter ....................................................................................................... 13
2.4.4 Comment ............................................................................................... 14
2.4.5 Legend ................................................................................................... 15
2.4.6 Validation .............................................................................................. 15
2.4.7 Options .................................................................................................. 15
2.5 Presentation of shadow data .................................................................. 16
2.5.1 Colour coding of shadow data (Legend tab) ................................... 17
2.6 Editing and presenting shadow data .................................................... 18
2.6.1 Editable columns in the Shadow Data table .................................... 20
2.6.2 Inserting and editing comments in the shadow data table ............ 21
2.7 Saving edited shadow data .................................................................... 23
Chapter 3 Template Designer ....................... 24
3.1 Template selection ................................................................................... 25
3.2 Template management ........................................................................... 26
3.3 New or Edit report template window .................................................. 28
3.3.1 Details section ....................................................................................... 28
3.3.2 Default report properties .................................................................... 29
3.3.3 Template columns ................................................................................ 29
3.3.4 The Available Column Templates Legend box ............................... 31
3.3.5 Formatting a template column ........................................................... 31
3.4 Template Access ...................................................................................... 32
3.5 Preview ..................................................................................................... 33
3.6 Standard Reports ..................................................................................... 34
3.7 Historical Reports .................................................................................... 39
3.8 Event Reports ........................................................................................... 40
3.8.1 Summarized Event Reports ................................................................ 41
Chapter 4 The Profile Administrator ............... 42
VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page ii
4.1 Overall configuration .............................................................................. 43
4.2 Report profile configuration .................................................................. 444.3 Creating profiles ...................................................................................... 44
4.3.1 Selecting and editing park units ........................................................ 46
4.3.2 Selecting and creating categories ....................................................... 52
4.3.3 Categorizing events in the event list ................................................. 54
4.3.4 Shadow data generation ..................................................................... 57
4.4 Locking a profile ...................................................................................... 57
4.5 Editing existing profiles .......................................................................... 58
4.6 Removing profiles ................................................................................... 58
4.7 Generation/regeneration of shadow data ............................................ 58
4.8 Shadow Data Sign-off Management ..................................................... 60
4.9 Reference Curve Editor .......................................................................... 62
4.10 Creating a reference curve ..................................................................... 63
4.10.1 Locking a reference curve ................................................................... 65
4.11 Setup of validation parameters ............................................................. 65
4.11.1 Selecting group or unit type parameters .......................................... 66
4.11.2 Editing validations ............................................................................... 66
4.11.3 Shadow data regeneration after validation changes ....................... 67
4.12 Profile and template access .................................................................... 68
4.13 Free wind parameter setup .................................................................... 69
4.14 Wind exclusion sectors ........................................................................... 70
Chapter 5 Calculation Procedures .................. 72
5.1 Collected 10-minute data from the wind turbines .............................. 72
5.2 Automatically processed and manually entered data ....................... 72
5.2.1 Auto-calculated shadow data ............................................................ 72
5.2.2 Manually entered shadow data ......................................................... 73
5.3 Reporting process work flow ................................................................. 74
5.3.1 The Report Generator module ........................................................... 74
5.3.2 The reporting work flow ..................................................................... 74
5.4 Reporting data basis ................................................................................ 76
5.4.1 Combining shadow data and collected 10-minute data ................. 76
5.4.2 Shadow Data Details ........................................................................... 76
5.4.3 Priorities used in the reporting process ............................................ 78
5.4.4 Expected production priority ............................................................. 78
5.4.5 Wind speed and priority ..................................................................... 79
5.4.6 Active power ........................................................................................ 79
5.4.7 Status code ............................................................................................ 80
5.4.8 Standard category ................................................................................ 80
5.4.9 Pitch angle ............................................................................................. 80
5.5 Report column calculation procedures – Standard Contractual
Availability.................................................................................................................. 81
5.5.1 Wind turbine reporting columns ....................................................... 81
5.5.2 Power meter reporting columns ........................................................ 82
5.5.3 Calculation of Standard Contractual Availability ........................... 83
5.5.4 Calculation of Manufacturer Loss kWh ............................................ 83
5.5.5 Calculation of Normal Operation Hours .......................................... 83
VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page iii
5.5.6 Calculation of Normal Operation Percentage .................................. 83
5.5.7 Calculation of Manufacturer Downtime Hours .............................. 84
5.5.8 Calculation of Manufacturer Downtime Percentage ...................... 84
5.5.9 Calculation of Missing Allocation Hours ......................................... 84
5.5.10 Calculation of Missing Allocation Percentage ................................. 84
5.5.11 Calculation of Average Free-Stream Wind Speed m/s ................... 84
5.5.12 Calculation of Actual Output kWh ................................................... 87
5.5.13 Calculation of Operating Net-Expected Energy kWh .................... 87
5.5.14 Calculation of Load Factor ................................................................. 88
5.5.15 Calculation of Operating Efficiency .................................................. 88
5.5.16 Calculation of Power Curve Efficiency ............................................. 88
5.6 Report Columns and Calculation – Energy-Based Availability ....... 89
5.6.1 Wind turbine reporting columns ....................................................... 89
5.6.2 Calculation of Energy-Based Availability ........................................ 90

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 1
Chapter 1 Introduction
The Advanced Reporting Module is an add-on module for the VestasOnline®
Business extending the features available in the Standard Reporting Module.
The Advanced Reporting Module consists of a number of sub-modules all
targeted at different system users. The Advanced Reporting sub-modules
described in this manual are Shadow Data Editor, Template Designer,
Calculation Procedures and Profile Administrator.
Besides the sub-modules this manual also describes the Calculation Procedures
by means of the collected data, shadow data, reporting system process work
flow and calculation formulas behind report columns.

Shadow Data Editor - is used for the maintenance of data in the
database. It is primarily a tool for on-site
operators responsible for downtime
allocation and data integrity.

Template Designer - is targeted at the system administrator
enabling him or her to make custom
report templates that address site-specific
requirements.

Profile Administrator - is designed to be used by the person
responsible for the configuration of the
system and the creation and maintenance
of reporting profiles.

Calculation Procedures - describes collected data, shadow data,
reporting system process work flow and
the formulas behind some of the report
columns used by the VestasOnline®
Business Reporting Module (Standard and
Advanced).





 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 2
Chapter 2 Shadow Data Editor
The Shadow Data Editor sub-module enables users to edit the data that form the
basis of the reports created by the Report Generator.

Shadow data are data generated by copying, calculating or modifying the 10-
minute data received from all the units of the wind park. The basic idea of
reporting using Shadow Data is that the original 10-minute data are kept
unchanged as when they were received by the VestasOnline® Business Server.
Neither automatic nor manual data modifications will influencethe original 10-
minute data as all modifications are made on the shadow data only.

Apart from the automatic calculations of shadow data by the report module, it
further allows for manual editing in the Shadow Data table and the Shadow
Data Editor is the tool provided for this purpose.

Note: It is very important that people using the Shadow Data Editor agree on the detail
level used in the Shadow Data Editor so that information will be stored in a consistent
way.
2.1 The basic windows for editing of shadow data
Start editing by clicking the menu item Shadow Data Editor in the Maintenance
submenu in the VestasOnline® Business Server menu.


Figure 1 - The opening window of the Shadow Data Editor
The opening window in Figure 1 that is part of the Shadow Data Quick Tools is
used for selecting the profile, the time period, the view and the park unit – see
section 2.4 The Shadow Data Quick Tools for more details.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 3
2.1.1 Profile
Report profiles contain the basic rules for data handling and report generation –
see chapter 4 – Profile Administrator for more information.
Start by selecting the profile (the profile selection is the only part of the window
that is active when the window is opened). To select a profile, click the down
arrow and choose a profile from the drop-down menu.

When you have selected the profile, the opening window changes as the rest of
the window becomes active. This is indicated by change of text colour from grey
to black for the now active features. At the same time, the first unit of the profile
is selected as default in the unit field.
2.1.2 Date and time details
The editing period can be selected by means of the calendar and the duration
selectors at the right hand side of the window. At the top of the calendar, you
select the month. By clicking on the left arrow you can go to the previous month
and by clicking on the right arrow you will go to the next month. If you point to
one of the arrow keys with the left mouse key and hold it down, the calendar
will continue to change months. A left-click on the name of the month opens a
month list in which the month may be selected by left or right clicking on the
name of the month. A left click on the year opens an up-down selector where
you can change the year by clicking on the up and down buttons. The date is
chosen by clicking the date in the month calendar. The present date can be
selected directly by clicking at the bottom left corner of the calendar. To select
the editing period, use the selectors below the calendar. The one to the left is the
number of days, weeks, months or years that is selected in the field to the right.
2.1.3 Park unit
The desired unit can be selected in the Park Unit field placed below the Profile
field. Select a unit from the drop-down list.
2.1.4 View
All 10-minute values:

Offers a 10-minute data detail level where it is possible to view all relevant
details and to make manual changes

Collapsed view:
Only displays events with processed information for the relevant report
columns
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 4
2.1.5 Retrieving data
When you have selected the profile, the time period and the unit, click the
Retrieve button.

The data retrieval may take
some time depending on the
length of the time period
selected. As long as the data
retrieval is active, the
information box shown to
the left will be open.
Figure 2 – Data retrieval in progress
The information box closes when the data have been retrieved and the Shadow
Data Editor window becomes available for data editing.
2.2 The Shadow Data Editor window


Figure 3 - The Shadow Data Editor window
2.2.1 The toolbar buttons
The Shadow Data Editor window contains several buttons, icons and selectors
that give access to tools and facilities.
These possibilities are introduced below:


Closes the Shadow Data Editor window.

Opens the Report Output window for selection of print output
format.

Copies table data to the clipboard.

Exports data to disk.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 5

Activates the Shadow Data Quick Tools (see section 2.4).

Gives a view of the Shadow Data details (see section 2.6).

Refreshes the displayed data.

Saves the changes made in the Shadow Data Editor to the
database.

Presents information about the unit selected (see section 2.2.3).

Park Data Maintenance Tool for the currently selected park unit
(see section 2.3).

Park Data Maintenance Tool for all park units.

Mass Editing tool for editing multiple units with the same data
(see section 2.3.1).
2.2.2 Selecting or changing the unit to be edited
The Shadow Data Editor window (Figure 3) also contains a
selector in the toolbar. The drop-down list of this field
comprises all the wind turbine units of the profile selected.
Select the unit to be edited from the drop-down list and the data for this unit
will be retrieved. If data from another unit are already in the editor, you will be
prompted to save these data before they are overwritten.
2.2.3 Presentation of unit information

The View Information icon in the tool bar presents basic information
about the selected park unit.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 6

Figure 4 - Unit information window
The Information window provides information about the unit such as type,
power, reference curve, event list, neighbouring turbines and associated
meteorological stations as well as commissioning date and information about
last service/maintenance visit.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 7
2.3 Database maintenance tool
Many of the columns in the shadow data table are editable and values may be
inserted in the fields of these columns. Section 2.6 describes how values can be
inserted, but the procedures described in section 2.6 may take a while if a larger
amount of data is missing. In this case, you can use the following procedure:


Figure 5 - Shadow data table





The example in Figure 5 contains a shadow data table in which data
from the time interval from 15:20 to 15:50 are missing.

You can insert average values in such rows by using the tool
associated to the icons shown to the left. A click on one of these icons
will open a selection window.

The first icon will open a park maintenance tool for the park unit
currently selected while the second icon will open the tool for all units.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 8

Figure 6 - Selection window for the shadow data – Park Maintenance tool

The selection window shown in Figure 6 (which can be opened only if a row
without data has been selected (Figure 5)) displays general information in the
upper part and contains selection boxes in the lower part.

When you open the window, the Set Production option is selected as default
and the values derived from the production counters are shown as blue on
white in the selection boxes. Furthermore, you can select status code, wind
speed and expected production.

The values shown in blue are the ones suggested by the maintenance tool (you
can change these values, however). The proposed wind speed is calculated from
the proposed, average production by going backwards through the reference
power curve.

In the Description field, you may add a comment. See an example in Figure 6.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 9

Figure 7 - The selection window after selections have been made and a comment has been added.
Figure 7 shows howselections can be made. All selection fields have check
marks indicating that all the values at the right hand side will be inserted in the
database. A comparison between Figure 6 and Figure 7 shows that some of the
values/settings and a comment have been added.

When you have made your selections, click the Proceed button.


Figure 8 – Save manually entered data dialog box
The Save dialog box will pop up. Click Yes to save the data.


Figure 9 - The shadow data table after insertions of data by the maintenance tool
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 10
When the data selected in Figure 7 has been inserted, the shadow data table will
look as shown in Figure 9.
2.3.1 Mass-editing tool
The Mass-Editing function is a convenient and time-saving tool as it lets you
insert or modify shadow data for a number of units in one operation. The
specified information will overwrite any existing shadow data information. The
maximum period for a mass-editing operation is 48 hours.
The icon for the Mass-Editing function is located at the far right in the
Shadow Editor toolbar. Click the icon to open the Mass-Edit window.

The upper part of the window lets you select the wind turbines on which you
want to make corrections to the shadow data.

The middle part contains the actual editing tools, while the lower part lets you
specify the time period for the corrections.


Figure 10 – Mass-Editing Tool window
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 11
Select the checkboxes for the information columns that you want to modify and
enter the new values. These values will be applied to all selected units for the
specified time period.

In the above illustration three fields are labelled “Not used”, as these categories
have not been configured for the selected reporting profile. If configured, they
will appear as shown below.

Figure 11 – Mass-Editing Tool window – Modify shadow data section
Finally, specify the wanted time period for the mass-editing of shadow data.
This period is restricted to a maximum of 48 hours.

The Reset button removes shadow data information for selected columns in the
specified time period.

Click Apply or OK to generate the shadow data, or click Cancel to regret.
2.4 The Shadow Data Quick Tools
The Shadow Data Quick Tools, part of which was used already to select unit
and editing period (Figure 1, section 2.1), is an important set of tools available
for you as user.


To select the Shadow Data Quick Tools, click this icon in the Shadow
Data Editor window.


Figure 12 - The Shadow Data Quick Tools window
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 12
2.4.1 Period
The Period tab is shown in Figure 12. The description of the Period tab is found
in section 2.1.
2.4.2 Search
The Search tab lets you find wind turbines in the wind power plant by
specifying targeted specific search criteria.

Figure 13 - The Search tab in the Shadow Data Quick Tools
The search criteria in Figure 13 are selected by clicking the appropriate option
button. The four lower selections in Figure 13 are selections with more complex
criteria. Here you can make selections from the selection fields by using the
arrows and select the desired criteria from the drop-down box.

The Advanced Search option lets you narrow the search by adding a time
period to the search criteria.
When a new search option is
selected, the Generate button below
the Unit List area will be active and
you must now click it in order to
generate a list of wind turbines
fulfilling the search criteria. During
the generation of the list, the process
can be cancelled by clicking the Cancel button.



 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 13

Figure 14 - Performing a search for wind turbines in the Utility category
Figure 14 illustrates how a complex search is established. In case you want an
event code search, select the event code by means of the up/down arrows or by
keying the event code directly in the Find all Turbines with Event Code field.
2.4.3 Filter
The Filter function acts on the data for the selected wind turbine and is used to
search for 10-minute periods fulfilling specific criteria among the displayed 10-
minute periods. The Filter function allows you to find the relevant 10-minute
periods in an easy way even when data for a longer period are being analysed.


Figure 15 - The Filter tab of the Shadow Data Quick Tools
As shown in Figure 15, a number of filtering options are available. Except for
the No Filter option, it is possible to display only those 10-minute periods that
fulfil a specific criterion regarding either Status Code, Category, Wind Speed,
Production or Expected Production.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 14
The Status Code and Category options both have a field for defining search
criteria. Click the down-arrows to have the possibilities listed. The Missing
possibility is always an option and the other possibilities will be the Status
Codes or Categories that are part of the data selected for display.

Figure 16 - Example of possibilities - Category
The section of the window shown above illustrates how a category is selected.
In this example, three different categories are present in the selected 10-minute
periods.

The three options - Wind Speed, Production and Expected Production - are to be
selected in the same way. The user may ask for all 10-minute periods in which a
value is missing, for all 10-minute periods containing a value below a user-
defined limit or for all 10-minute periods holding a value above a user-defined
limit.


Figure 17 – Example of selections – Wind speed, Production, Expected production
The selections Missing, Above and Below are made by using the down-arrow
placed to the right in the selection fields. When Above or Below has been
selected, the numerical selector to the right becomes active. The limit may be
entered directly in the numerical field or inserted by using the up-/down-
arrows.

Search criteria Unit of measurement
Wind Speed Meters per second - m/s
Production Kilowatt – kW
Status Code Number
Expected
Production
Kilowatt-- kW
Table 1 – Units of measurement for search criteria
When you have completed your selections, click the Apply button. After that,
only the 10-minute periods in accordance with the selected criteria and limits
will be displayed.
2.4.4 Comment
The Comment tab is described in section 2.6.2.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 15
2.4.5 Legend
The Legend tab is described in section 2.5.1.
2.4.6 Validation
The Validation tab contains information about the validation parameters used.


Figure 18 - The Validation tab of the Shadow Data Quick Tools
The validation parameters (the limits) cannot be modified in the Validation tab.
Changes in validation parameters must be made in the Profile Administrator
and special access rights are required to perform such changes.
2.4.7 Options
The Options tab lets you specify the font sizes used in the two main windows of
the Shadow Data Editor.


 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 16
2.5 Presentation of shadow data
The shadow data for the selected time and period (see section 2.1) and unit
(wind turbine) (see section 2.2.2) are retrieved by clicking the Retrieve button at
the bottom of the opening window in section 2.1 or by clicking on the unit in the
drop-down menu mentioned in section 2.2.2.


Figure 19 – Example of shadow data from a wind turbine
After data retrieval and closing of the opening window,the Shadow Data Editor
window will display data as shown in Figure 19.


Figure 20 – Example of shadow data from a meteorology station
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 17
2.5.1 Colour coding of shadow data (Legend tab)
The shadow data concept implies that the data in the shadow data table can
have different origins. Some data come from the original 10-minute data
packages from the units; some are based upon data from other units and some
have been manually entered etc. Therefore, colour coding is applied to make it
easier for the user to see how the data have been created.


Details about the colour coding are available in the Shadow Data Quick
Tools. Click the icon in the toolbar of the Shadow Data Editor window
(Figure 3) and further click the Legend tab.


Figure 21 - The colour coding used in the Shadow Data Editor
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 18
2.6 Editing and presenting shadow data
The shadow data table shown in Figure 19, which was shown as a result of the
data retrieval described in section 2.5, is the default table. You can modify the
displayed table by removing and adding columns.


Click this icon in the toolbar of the Shadow Data Editor window in
Figure 3 to make such changes and to see details about the shadow
data.


Figure 22 - Shadow Data Details – turbines with AOM 4000 service contract
The Shadow Data Details window provides a list of all available information
columns. Figure 22 shows the default setup of the information that is displayed
in the Shadow Data Editor window for a turbine with an AOM 4000 service
contract.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 19
Note that shadow data are affected by the selection of AOM service contract
(AOM 4000 or 5000) for each turbine in the wind power plant. Thus, for turbines
with an AOM 5000 service contract, an additional shadow data column value is
available – Average actual production (located in line 42 of the Shadow Data
Details window for turbines with an AOM 5000 contract – see Figure 23).
Average actual production calculates average production from all turbines of the
same type, except production from the actual turbine itself, primary and
secondary neighbour turbines, and de-rated turbines. As seen in Figure 23, the
additional column affects the prioritisation for calculating lost production for
turbines with an AOM 5000 contract.
Configuration of shadow data according to service contract is defined in Profile
Administrator, Profile properties (see 4.3 Creating profiles).


















Figure 23 - Shadow Data Details – turbines with AOM 5000 service contract
The information columns preceded by a check mark are displayed in the default
setup of the shadow data table shown in Figure 19.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 20
To include/exclude a column, click the corresponding check box.

In the Shadow Data Details table, the columns with the check marks, the line
number column and the Property column are common for the whole data table
whereas the Value column contains the actual value for the selected row in the
shadow data table.

The rows in blue text in the shadow data details table have all been edited
manually.

Line 5 – “Edited by” text deviates from this general rule. The user name of the
user editing in a row of the shadow data table is automatically inserted when
the changes are transferred to the database.
Smart columns
Some of the lines in the Shadow Data Details table appear in grey. This indicates
a “Smart Column”, i.e. a column where the value is determined by selection
among a number of options with a certain order of priority. For example,
Expected power (line 42, AOM 4000 / line 43, AOM 5000) will display the value
from line 37 (Expected Production – manually edited) if this information is
available. Otherwise, it will display the value from line 38 (Neighbour
production) if this information is OK and so on down to the last option which is
the value of line 39 (AOM 4000) / line 42 (AOM 5000).
2.6.1 Editable columns in the Shadow Data table
Some of the columns in the default presentation of the shadow data table are
editable:

Column title Manual edit Comment
Wind Speed YES
Production YES
Status Code YES
Status Text NO
Changes automatically when Status Code
is changed
Category YES Edited through drop-down menu
Expected power YES
Theoretical lost power NO
Always the difference between Production
and Expected production if this is not
categorized as “Normal operation”
Pitch Angle YES
Only applies for passive stall turbines
(former NEG-Micon wind turbines)
Comment YES
Special edit window in Shadow Data Quick
Tools (see section 2.6.2)
Table 1 - Editable columns in the default Shadow Data table
Apart from the Category and Comment columns, the positions in the editable
columns are opened for editing by a double left-click. Enter the new value and
press Enter. The new value is shown in blue to indicate that it is a manually
edited value.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 21
If you right-click a manually editable value, the options below become
available:


The selected manually edited value is the “188.1” which is indicated by the
thicker frame around the table cell.

Click the Clear Value line to return to the original value or click on Duplicate
Value to copy the “188.1” to the position below (presently displaying “633.8”).
The Paste from Clipboard option can be used for copying a value from the
clipboard to the selected field.

The keystrokes Del, Ctrl+D and Ctrl+P are shortcuts for the Clear Value,
Duplicate Value and Paste from
Clipboard options.

To open the fields in the Category
column, left-click to select the field
and then right-click. The drop-
down menu shown below will
open.

The list of categories in the bottom
section of the menu contains only
the categories used in the profile
chosen. Select the category to be
inserted by right- or left-clicking it
in the list of categories - or use the
shortcuts.


2.6.2 Inserting and editing comments in the shadow data table
The shadow data table has a column reserved for comments and the Shadow
Data Quick Tools have a facility that handles adding, editing and removal of
comments.
Note Before you can add a comment, you must indicate where you want to insert it.
This is done by selecting the corresponding cell in the shadow data table. By default,
the latest entry in the table is selected.


Click this icon in the toolbar of the basic edit window, Figure 1 to open
the Shadow Data Quick Tools and click the Comment tab.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 22

Figure 24 - Window for inserting, editing and removal of comments
The Unit and the Occurred fields in the Comment tab are filled in automatically
with information for the selected cell.

Now enter a Title and a description in the Description field; then click the Add
button to insert the comment in the selected row. The Author and Comment
Time fields are also filled in automatically.

Often, the same Comment applies to several rows in sequence. To copy a
Comment to the next row, click the Apply to Next button. If, for example, six
subsequent rows are to have the same comment, click the Apply button at the
top row and then the Apply to Next button five more times to apply the
comment to the five subsequent rows.

The Add for Event function lets you apply the same comment to all rows
belonging to an event.

If you want to remove a comment, double-clickthe comment in the table. This
opens the Comments window shown in Figure 24. To remove the comment,
click the Remove button. Comments must be selected individually in order to be
removed.

It is also possible to overwrite an existing Comment by a new Comment by
means of the Apply to Next button.

Furthermore, the below supplementary edit tool
for comments is available:

Select a Comment field by a single-click and then
right-click. In the menu, which then emerges,
click Clear Value to remove the selected
comment.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 23
The Duplicate Value menu item copies the comment to the field below and the
Copy Value item copies the value to the clipboard.
The last option - the Paste Value can be used for copying a comment from the
clipboard to a selected comment field. The corresponding keyboard shortcuts
are shown at the right side of the menu.

2.7 Saving edited shadow data

When shadow data are edited in the shadow data table, changes are
made in the displayed table only. In order to transfer the changes to the
database, you must click this icon in the toolbar of the Shadow Data
Editor window.
A message box informing you about the on-going activity is shown during the
saving procedure. When saving is finished, the message box disappears and a
new message box appears asking if you want to see the recalculated shadow
data now, or if you if want the data to be automatically recalculated within the
hour. The shadow data table is then updated according to your choice.

Note: Make sure that automatic shadow data generation is enabled in Profile
Administrator.



During the save process, the shadow data will be re-generated for the selected
period. Example: You have manually entered a status code, and the system will
now look for a Category matching the status code you entered.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 24
Chapter 3 Template Designer
The Template Designer enables the operator to design specific report templates
that will be available in the Report Generator. In these user-defined report
templates, headlines can be changed, result values formatted and minimum,
maximum and average values added to the column calculations.

To start the Template Designer, click Template Designer in the Administration
submenu in the VestasOnline® Business Server menu.


Figure 25 – The Template Designer window
When you open the main Template Designer window (Figure 25), all report
templates to which you have access are presented.

The Title column shows the name of the template.

The Report Type column lists show the type of report template (Event Detail,
Standard or Historical).

The Editable column shows whether the report template is editable (Yes) or not
(No), and in case of not editable show why (Predefined or Locked).

The Created by column shows which user created the report template (DCE
refers to the system account used for Predefined report templates).
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 25
The Last modified date column shows the date for the last modification of the
report template.

The toolbar button functions are briefly described below:


Closes the application window.

Opens a report menu where different presentations of data can be
selected.

Copies table data to the clipboard.

Refreshes the displayed data.

Opens a window for specifying access to templates.

3.1 Template selection

You can filter the report templates to be listed by using the drop-down box for
any of the columns and select the filtering details.


Figure 26 – Template Designer – report filter options

To filter by Report Type, click the drop-down box for Report Type column and
select what report type to be shown.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 26
3.2 Template management
In the main Template Designer window, you have a number of options for
managing the templates. The options for Edit and View depend on whether you
have selected an Editable template or not.
The Edit button is displayed if you have selected a report template that is
editable.


The View button is displayed if you have selected a report template that is not
editable (Predefined or Locked).




To generate a new template, click the New button and select the report type for
the new template.


Figure 27 –The Select Report Template Type dialogue
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 27
Two template types are available:

 Standard Report - includes several columns that cover the entire period
selected in the Report Generator.


Figure 28 – Example of standard report
 Historical Report - contains one column for each interval within the
selected period, which makes a historical presentation.


Figure 29- Example of historical report
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 28
If you want to change an existing report template, select it in the list and click
the Edit button.

To make a copy of an existing report template, select it in the list and click the
Duplicate button.

Clicking the Preview button will give you a preview of the last generated report
based on the selected report template - provided that one has been created.

3.3 New or Edit report template window
The New Template and the Edit Template windows are identical – except that
some fields (Title, Description and Report Columns) can be filled in when you
open an existing template for editing.


Figure 30 – The New or Edit Template window
3.3.1 Details section
In the Details section, enter the Title and Description of the template. The Type
box displays the template type.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 29
The Active, Visible and Locked check boxes allow you to set the status of the
template.

Active - the report template can be seen and used in the Report
Generator.
Visible Reports - remove the check mark in the Visible Reports
box when a number of reports have been generated and these
reports are no longer to be shown in the report archive.
Locked - is used only when a report template is not to be edited
again - not even by the creator.
3.3.2 Default report properties
The default report properties are shown when a report is printed out. In the
Default Report Properties section of the window, additional properties can be
added by selecting the corresponding check boxes.

Description is the additional specification you can add when making a report.

Comments are taken from the 10-minute shadow data
entered in the Shadow Data Editor.

Legend is the legend description of the report
columns.

Sub-calculations are descriptions of how each value is
calculated (not available for all report columns).

Graphics is a graphical representation of the data values (report columns) that
be added in the report.

These settings can be changed for individual reports when the reports have
been generated and are available in the report archive.

3.3.3 Template columns
The Available Column Template box shows which values are available for the
report. Report Columns are the columns selected for the actual report template
(see Figure 31).

The columns represent calculations based on data from the 10-minute data
and/or shadow data.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 30

Figure 31 – Column selection
The available columns listed with blue colour are the pre-defined report
columns. These columns are non-editable system stem data. The available
columnslisted with white colour are the project-specific columns. These
columns are editable project data.

Project-specific report columns are created using the Duplicate function that
allows you to create a copy of a report column and then edit this copy according
to your requirements.

The columns are organized in groups according to functionality. To display the
individual columns in a group, click the + in front of the group name; to collapse
the group, click the – in front of the group name.

To move a column from Available Column Templates to the Report Columns
box, select it and click the green right-arrow. To remove a column, select it and
click the red left-arrow. Double-clicking a column will also move it from one of
the column boxes to the other.

Note: For historical reports, you can only select one column.

The order of columns in the Report Columns box reflects the order (left-to-right)
in the report template. To change the order of the columns, click the up- or
down-arrows to the right of the Report Columns box.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 31
3.3.4 The Available Column Templates Legend box

The Available Column Templates Legend box at the bottom of the window
displays the textual legend information for the selected available report column.


3.3.5 Formatting a template column

If you want to present a template column in a way different from the default
setup, the settings for a template column can be overwritten.

To format a column, select the desired column in the Report Columns box and
click the Format button. This will bring up a dialog where the settings can be
overwritten or set to default. The modifications will only be saved for the
template in question.


Figure 32 – The Edit Template Column window used to format a selected report column
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 32
3.4 Template Access
The next step is to specify which users or user roles should have access to the
new template (see Figure 33 and Figure 34).

When the new template is generated, this dialog box appears:



Click No if you want no users but yourself to have access to the template or if
you want to specify template access at a later time. In this case use the Template
Access button in the toolbar to get access to the associated window.

Click Yes to switch to the window where you can assign which user roles or
individual users should have access to the new template.


Figure 33- Specifying access for user roles.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 33

Figure 34 – Specifying access for individual users.
3.5 Preview
If you click the Preview button in the Template Designer window (see Figure
25), you will have a preview of the last report generated by the Report
Generator on the selected report template, if available.

If you need to preview a new report template, you will have to make a report in
the Report Generator.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 34
3.6 Standard Reports
Standard reports such as the Standard Availability Report below contain several
columns in one report.


Figure 35 – Example of a standard report
Standard reports can also include information about the categorization
percentage of 10-minute values. If the categorization value for a wind turbine is
below 100%, this will be indicated by the actual percentage in the Park unit
column. In addition, all values for this wind turbine is shown in red italics – see
Figure 36. All 10-minutes values must be categorized in order to secure
accurate calculations in the reports. For more information on how to select this
option, refer to section 4.3 - Creating profiles.


Figure 36 – Example of a standard report with categorization percentage
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 35
To see what will be printed for the actual report, click the Print icon in the
toolbar (second to the left) to open the Report menu dialog box where you can
choose the output format for the report (see Figure 37).

The Report Output allows you to print reports as well as make PDF reports.
The type of report can be the selected
either as a report or a report containing
a screen dump of the previous window.

If you cannot browse PDF reports, a link
can selected, where the last version of
Adobe can be downloaded.

The orientation of the paper can also be
selected and saved so that you will not
have to make the selection again.



Figure 37 – Main page of a Report preview

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 36
The contents of the generated report are dependent on your selections in the
Report Details dialog box (see Figure 38).


Figure 38 – Report Details
If you choose to include the Report Description, Legend, Comments or Sub-
calculations options, additional pages will be added to the main report (see
Figure 39 - Figure 43).


Figure 39 – Preview of Report Details and Description page

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 37

Figure 40 – Preview of Legend page


Figure 41 – Preview of Comments page
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 38

Figure 42 – Sub-calculations page

Figure 43 – Graphics page
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 39
3.7 Historical Reports
A Historical Report such as the Active Power report below contains one value
selection for historical presentation.


Figure 44 – View of a Historical Report
The print options for Historical reports are identical to those of the General
reports (see section 3.6 Standard Reports).
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 40
3.8 Event Reports
In contrast to the Standard and the Historical reports that are based on
customized report templates, the Event reports are based on a single pre-
defined report template that cannot be modified.
Instead, selections for targeting reports are made directly from the Report
Generator every time an Event report is generated (see Figure 45). Note that
Event reports can be filtered to include a single wind turbine event or all events
for the selected reporting period


Figure 45 – Generating an Event Report
Figure 46 shows an example of a print preview of an Event Report.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 41

Figure 46 – Example of print preview of Event report
3.8.1 Summarized Event Reports
In addition to the detailed event report (see illustration above), you can also get
summarized (statistical) information about frequency, number of occurrences,
duration and lost kWh.

This functionality is controlled by the Grouping and Type option in the Report
Generator dialog box.









Figure 47 –Event Report (Summarized by Turbine and by Event)

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 42
Chapter 4 The Profile Administrator
The Profile Administrator module manages creation and maintenance of report
profiles.

A report profile is a set of basic setup rules for data handling and report
generation. The profile defines the Reference curves, the park units and the
parameters to be used and states the categories to be used for categorization of
the events. It is possible to define many profiles for the same wind park,
allowing creation of reports in different ways all depending on the purpose of
the reports.

An owner could, for example, have some profilesreflecting his needs, the
manufacturer other profiles focusing on e.g. availability and maintenance and
the utility could have profiles delivering information about the influence of the
wind park on the grid and vice versa. However, Vestas recommends that you
limit the number of reporting profile per wind power plant due to the
maintenance of report profiles.

A profile once created cannot be deleted. If a profile might need to be deleted, a
JIRA SCADA Support task has to be created. Subsequently, the SCADA Support
team will delete the informed profile.


Figure 48 - The basic window of the administrator sub-module
The window shown in Figure 48 appears when you select the Profile
Administrator item in the Administration submenu in the VestasOnline®
Business Server menu.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 43
In all VestasOnline® Business modules, a number of tools are available. The
toolbar icons shown in most windows of the Profile Administrator are described
below:


Closes the application window.

Opens a report menu where different print output options can be
selected.

Refreshes the data (reloads the data from the database).

Copies table data to the clipboard. For example to export the data to a
spread sheet.

4.1 Overall configuration
The area just below the toolbar contains information about the overall
configuration of the park and not only for a specific profile. The icons have the
following functions:


Opens the Reference Curve Editor window (see section 4.9). A power
and a wind distribution reference curve should be made for each wind
turbine type and can be attached to a wind turbine in the park unit
configuration.


Opens the profile and template access setup facility (see section 4.12).
In this window, access to profile and templates can be setup for all
users.


Opens the Validation Parameters window (see section 4.13).


Opens the Free Wind Parameter Setup window (see section 4.13). A
correlation of parameters can be attached to a wind turbine in the park
unit configuration.

 Opens the Wind Exclusion Sectors window. A wind sector group can
be defined with a number of wind sectors. A wind sector group can be
attached to a wind turbine in the park unit configuration (see section
4.14).

Reference curves, validation parameters and free wind parameters should be
defined before a report profile is defined. In case you change these after you
have defined a profile, the shadow data will need to be regenerated.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 44
4.2 Report profile configuration
The Report Profile Configuration area of the Profile Administrator window
(Figure 48) contains information about the profiles available for the user logged
in. The list of profiles only shows the profiles to which the user has access
according to his or her password.

The first column is the title of the profile.

The second column indicates if the profile is locked. If a profile is locked,
nobody can change the configuration of the profile. All users with access to a
profile may lock it. A locked profile can only be opened by the system
administrator.

The Start Date column indicates when data are available for the selected profile.
You select the start date when you create the profile. The start date cannot be
changed.

A continuous generation of shadow data can be enabled or disabled. The status
for this job is shown in the Auto Generate Shadow Data column and can be
changed in Profile Properties.

A change in the profile configuration will require that all shadow data have to
be regenerated. The Shadow Data Status column indicates whether regeneration
is needed or not.

Below the list of profiles, a description of the selected profile is found. This text
can be edited by clicking the Profile Properties button.

A number of buttons have different functions that concern the profile
configuration. Select a profile from the profile list before activating one of the
functions.
4.3 Creating profiles
Note: Before creating a new report profile, make sure that this report profile has not been
created already by one of your colleagues who has forgotten to grant you access to the
report profile.

The creation of a profile comprises a number of steps.

Click the Create New Profile item.

The Profile Properties window shown in Figure 49 appears.
Enter the title of the profile in the Title field and make a description in the
Description field. In the Contract field, select the service contract that should be
applied to the report profile (AOM 4000 or AOM 5000 contract). The selection
made is decisive for the calculation and presentation of shadow data in the
Shadow Data Editor (see 2.6 Editing and presenting shadow data).
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 45


Figure 49 - Window for profile name, description and contract selection
Do not select the Lock Profile for all Future Changes field, as this will inhibit
further editing. This field should only be signed off when you have finished
editing the profile and only if you want to prevent subsequent modifications of
the profile.

The field Auto Generate Shadow Data should be selected if you want shadow
data to be generated continuously. It is possible to disable/enable the auto-
generation of shadow data by editing in the Profile Properties window after the
profile has been created.

The third option - Enable integrity calculation on standard reports - includes
information about the percentage of categorized 10-minute values in all
standard reports. If the categorization value for a wind turbine is below 100%,
this will be indicated by the actual categorization percentage in the reports - see
Figure 36 – Example of a standard report with categorization percentage. To
secure accurate calculations in reports, all 10-minute values must be
categorized.

Finally, the fourth option – Add park units to profile – automatically includes
all units in the new profile. To close the Profile Properties window and save the
profile, click OK. Click Cancel if you want to stop the creation of a new profile.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 46
4.3.1 Selecting and editing park units
Start the unit selection by clicking the Select and Edit
Units button. The Park Unit Configuration window
shown in Figure 50 opens.


Figure 50 –The unit select and edit window

Copies the content of the selected cell in the table to the cell just below.
The button cannot be used if the profile is locked.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 47
Selecting park units for the profile
The selection of units for the profile is started by clicking this
button. The Assign Park Units to a Profile window shown in
Figure 51 emerges.


Figure 51 - Unit selection window
The list box to the left contains the park units available and the list box to the
right contains the units selected. The green single arrow button between the two
list boxes moves the selected (blue) units from the Available list box to the
Selected list box. The button above the green single-arrow button moves all
units to the Selected list box.

The red single-arrow button moves the selected (blue) units from the Selected
list box back to the Available list box. The button below the red single-arrow
button moves all units in the Selected list box to the Available list box.

The selected units in the right list box will be assigned to the profile when you
click the OK button. When you assign the first units to a new profile, the start
date for the new profile must be selected.VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 48
If any units have been removed from the profile, all shadow data for these units
will deleted from the database. A warning will be displayed before this
happens.
The start date selection
window will have the current
date as default and further
shows the date limits for the
database. The start date must
be within the allowed range.
To select a date different
from the default date, click
the down-arrow. A calendar
will pop up.

At the top of the calendar, you can select the month.
By clicking on the left arrow, you can go to the
previous month and by clicking on the right arrow,
you will go to the next month. If you point to one of
the arrow keys with the left mouse key and hold it
down, the calendar will continue to change months.
A left-click on the name of the month opens a
month list in which the month may be selected by
left or right clicking on the name of the month. A left click on the year opens an
up-down selector where you can change the year by clicking on the up and
down buttons. The date is chosen by clicking the date in the month calendar.

When you click OK, the selected units are inserted in the table area of the Park
Unit Configuration window.


Figure 52 – Park Unit Configuration window after selection of units
When the assignment of units is finished, the Park Unit Configuration window
could look like shown in Figure 52.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 49
Editing units selected for the profile
The window indicates that the profile now has a number of wind turbines
assigned. The default settings for the wind turbines have been transferred to the
profile but you may edit them as required.

The editing of park units is not possible if the profile is locked - please note that
if the profile is locked both the Edit and the Add and Remove buttons will be
dimmed.

Reference curve assignment
A wind turbine normally has a reference curve assigned per default. To choose
a different reference curve, double-click the Reference Curve field and select a
reference curve from the options in the drop-down list.


Hint: The button in the toolbar of the basic window of the Profile
Administrator module gives access to the Reference Curve Editor
described in section 4.9.

Editing hub height
The hub height of the wind turbine is of importance when the expected output
is calculated because the air pressure and temperature and thus also the air
density depends on the actual height. The hub height is used when processing
the height difference from the wind turbine to the met mast as the air pressure
changes with the height.

The hub heights of the different units are entered by selecting the hub height
fields one by one. To edit the hub height, left-click the hub height field twice
and enter the hub height as metres above sea level.

Editing assignments of neighbouring wind turbines
A wind turbine may have a default assignment of primary and secondary
neighbours indicating the priority of the neighbour wind turbines to be used
when data from a neighbouring wind turbine are required. In the example in
Figure 52 assignment of both primary and secondary neighbouring wind
turbines is made.

To edit an assignment, left-click on the field and select from the options in the
drop-down list.

Editing meteorology station assignment
Usually a wind turbine has default assignment of the primary, secondary and
alternative meteorology station, indicating the priority of meteorology stations
regarding meteorology station data for calculations on the wind turbine.
To edit an existing assignment or to create a new assignment, left-click the
respective met-station field and select an option from the drop-down list.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 50
Editing site calibration
To edit a value, left-click on the field twice. The field will go into edit mode and
a wind speed compensation value can be entered. Typically, this value is used
to compensate for difference between wind speed measured at the wind turbine
and at the meteorology station or to compensate for turbulence from
neighbouring wind turbines.

Editing pitch angle
To edit a value, left-click on the field twice. The field will go into edit mode and
a value can be entered.

Editing free wind parameter
To edit an existing assignment or to create a new assignment, left-click the field
and select from the options in the drop-down list.
A new configuration set of the free wind parameters can be made in the Free
Wind Parameter Editor.

The free wind 3rd order polynomial will be applied to the collected wind speed
and stored as the free stream wind speed in the shadow data. This is marked as
green in the Shadow Data editor.

The correlation is processed based on an analysis performed in the wind power
plant by measuring the wind speed on the reference met mast and the wind
turbine – giving the wind speed angle and data from a few months, a 3rd order
polynomial can be extracted. These wind studies are typically performed by a
third party institute.


Editing wind sector group
To edit a value, left-click on the field twice. The field will go into edit mode and
a value can be entered – see section 4.14 Wind exclusion sectors for more
information.

The wind sector group contains a definition of a 3rd order polynomial that can
be applied to a given sector, defined as a range of degrees from the nacelle
position. Each sector can also be defined to be excluded for Power curve
presentations. The corrections are applied on the wind speed measurements
from the nacelle anemometer using the angle from the nacelle position.


Editing connection point
To edit a value, left-click on the field twice. The field will go into edit mode and
a value can be entered.

The connection point defines the Grid connection point of the Wind Power
Plant. This can be applied if there is a Grid measuring station (VestasGridPanel
(VGMS III) / ION76x0) installed on the Wind Power Plant.

To select the grid station, you will need to add the grid to the report profile.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 51
Typically, this is used for processing possible power and other data related to
the grid connection point - often used for wind forecasting purposes.
Transfer of selected and edited data

Figure 53 - The park units after user editing
When you have finished editing all unit parameters, the park units may look as
shown in Figure 53.

To transfer the result of the selections and the subsequent editing to the
database, click the Apply-button. When the Apply button turns grey, the
transfer is finished and you can close the window by clicking the OK button.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 52
4.3.2 Selecting and creating categories
Events and categories
Each wind turbine type includes a list of events. The wind turbine controller
records changes in the operational status of the wind turbine as events. Each
event has a descriptive text and an event code which is a number used in the
registration of the events.
Typical events are:
 Overvoltage
 Vibration
 Overproduction
 High wind speeds
 Warnings
 Service
and more.

Warnings are always considered 'Normal operation', as the turbine is available
and can produce power during this state. Only downtime when the turbine has
an alarm and stopped/paused should be categorized to other categories than
'Normal operation'.

Occurrences of events indicate that the wind turbine has an abnormal or
unintended status, normally causing loss of productionand reduction in
availability.

One group of events is related to grid problems, another is related to the
environmental conditions, and some events can be grouped as wind turbine
alarms etc.

Events with certain similarities are grouped in categories such as Owner, Utility,
Environmental and Manufacturer.
Selecting and adding categories
For each profile, a selection of the categories must be made. You may also create
new categories for a profile. All categories created are available for all the
profiles in the report module.

To select categories, start by clicking the Category
Configuration button in the Profile Administrator
window.
The Categorize Events window emerges.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 53
.
Figure 54 – Window for selection of categories
The Category Set function in the upper part of the Categorize Events window
allows you to group frequently used combinations of categories into Category
sets.

Four Category sets are available:
 Standard
 Downtime type
 System Component
 Spare

The pre-defined combination of categories for each Category set is modified by
including or excluding categories from the group. Your modifications are saved
by clicking OK.

Note: You cannot de-select a category if it is in use, i.e. if one or more events
have been allocated to the category in question, or if the category has been
entered manually in the Shadow Data Editor.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 54
The Manage button lets you modify the name of a Category set and its position
in the Category set drop-down list.



The center part contains a list of the available categories.

The bottom part of the window contains a Description field with a description
of the category selected (shown highlighted) in the upper part of the window.
The lower right field displays a list of the profiles using the category selected in
the upper part of the Categorize Events window.

Categories are selected by clicking the respective check boxes in the upper part
of the Categorize Events window. The selection is transferred to the database
when you click the OK button that also will close the window.
4.3.3 Categorizing events in the event list
After having selected/created categories, you must assign one of the categories
to each event, which is to be categorised in the profile. In case an event is not
categorized, the 10-minute data will not be auto-categorized and this will have
to be handled manually.

A profile may contain different wind turbine types having different event lists.
In such cases, the event list to be categorised must be selected before the
categorization.
Select event list
The categorization is initiated by clicking the Categorize
Events button. If all the wind turbines in the profile have
the same event list, the window shown in Figure 56 is
opened.

Figure 55 – Category – Event List selection window
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 55
In case of profiles having more than one event list, the above selection window
is opened. The window contains list boxes with all the categories and event lists
relevant for the profile.

Select the event list to be categorized and click the OK button. The selection
window then closes and the window in Figure 56 opens.


Figure 56 - The Categorize Events window
Categorize events
The toolbar in the allocation window shown in Figure 56 contains the following
icons:


The two icons can expand and collapse the list. The expanded
view shows all events; the collapsed view shows only events that
are enabled by default for the controller type.

The list with categorised events can be exported to a XML file
and exported files can be imported into an existing list.

The table contains all the events in the selected event list shown with Event
Code number and Event Title to the left. The rest of the table contains columns
with all the categories selected for the profile.

The check marks indicate the actual category event allocations. The
checkmarks indicate the default category event allocations (system stem
data). An event can only have one category allocated but does not necessarily
have one allocated.

Note: The event code: “ 0 – Turbine OK” is always assigned to Normal Operation and
cannot be assigned to other categories.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 56
Event Codes that do not apply to the specific wind turbine can be removed in
the Expanded view by left-clicking the event text. The text will turn red and is
not displayed in the Collapsed view.
Unless the profile is locked, you can add or remove a check mark by left-
clicking the check box. By left-clicking an existing check mark you can remove
the mark and thus the event will have no category assigned. When the
categorisation matches your wishes, click the OK button. The information will
then be transferred to the database.

The space key on your keyboard can be used instead of left-clicks with the
mouse and the four arrow-keys on the keyboard can be used to move around in
the allocation area.

If the profile has more than one event list associated, the steps in section 4.3.3
have to be repeated until all event lists have been categorised.

Event 309 – Remote pause over RCS
Event 309 – Pause over RCS is unique as this event has associated ‘source’
information. The ‘source’ information is used to indicate the responsible party
for pausing a wind turbine. Consequently, event 309 will occupy several lines in
the list for categorization of events – see figure 54 below.

Event 309 is the only event with associated ‘source’ information.


Figure 57 – Event 309 Pause over RCS
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 57

Source no. Description
No source no. Only used for backwards compatibility
1 – 6 Used when a turbine is paused by the Power Regulation Module
(PRM) 7 - 11 Reserved for future use
12 - 15 Used when a turbine is paused from the VestasOnline
®
 Business
Client
Table 2 – List of available sources for event 309
Remapping categories
The Remap function offers a fast way of modifying a previous categorization as
it lets you move all events from one category column to another.

Click the Remap button to open the Map Category window; then select the
source and destination columns from the two drop-down lists and click Move.

The checkmarks are now moved from one column to the other.


Figure 58 - Map category window
4.3.4 Shadow data generation
Generation of shadow data is the last step in the creation
of a new profile. If the start date lies earlier than the
current date, click the Regenerate Shadow Data button in order to have shadow
data generated for the period elapsed since the start date selected.

For more details about the generation of shadow data, see section 4.7.
4.4 Locking a profile
When you have completed the profile, you can choose to lock the profile. This
could be relevant if e.g. the profile is used in a contractual context.

Locking the profile is done in Profile Properties window (See Figure 49). You
will be asked whether the profile is to be locked and informed that future
changes in case of locking will require unlocking by the system administrator. If
you confirm that the profiles shall be locked, the check mark changes to grey
and the information is transferred to the database when you click the OK
button.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 58
A profile may be locked as soon as it has been created or any time after.

When a profile is locked, this buttonmay be used to
unlock the profile (for system administrator only).

4.5 Editing existing profiles
It is possible to edit an existing profile by using the procedures described in
section 4.3 if the profile is unlocked and the user has the appropriate access
rights.

Regeneration of the shadow data may be required after editing (see section 4.7).
4.6 Removing profiles
It is possible to remove a profile if the profile is unlocked and the user has the
appropriate access rights for doing so. Click the Remove button shown in Figure
48 when you have selected the profile from the list of profiles.


Figure 59 – Remove profile dialog box
The window shown above will pop up informing you about the consequences if
you remove the profile. To confirm the removal, write YES (in capital letters!) in
the white text field and click OK.

All reports based upon the profile and the profile's shadow data will
subsequently be deleted together with the profile.

4.7 Generation/regeneration of shadow data
The shadow data may need regeneration if the profile has been modified in the
Profile Administrator in order to have the changes reflected in the existing
shadow data. This signalled by the “Config changed – regeneration needed”
message in the Shadow Data Status column in the Profile Administrator
window.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 59

Figure 60 – Regeneration is required
In case a new profile has just been created, shadow data will need to be
generated if the start date of the profile differs from the present date. Shadow
data will thus be generated for the period lying between the start date and the
present date.

The generation/regeneration of shadow data is started by clicking the
Regenerate Shadow Data button in Profile Administrator window.


Figure 61 – Regenerate Shadow Data window
The box shown above pops up when you click the button. A regeneration may
change all the existing shadow data apart from the manually inserted values
and you are therefore asked to confirm the regeneration.

After the confirmation is given, the regeneration of data will start. This is
indicated by the Generate Shadow Data dialog box shown below.

Note: This dialog only indicates the start of the regeneration process – NOT that the
full Shadow data generation has completed!


Figure 62 – Status window for generation of shadow data
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 60
The actual generation/regeneration can be a time-consuming process, which for
a large wind park and/or data for a long period may last for more than an hour.
This information is shown in the Profile Administrator window.


Figure 63 - Status of the regeneration process in the Profile Administrator window
When the generation/regeneration is finished, “OK” will be displayed in the
Shadow data status field.
4.8 Shadow Data Sign-off Management
Shadow data can be locked (‘signed off’) for a selected period of time. The
purpose of the locking functionality is to prevent further editing of shadow data
when Vestas and the customer have come to an agreement about the allocation
of events for a time period.

Locking and unlocking of shadow data can be done at any time both by a
designated Vestas administrator and by the customer upon agreement between
the parties.


Figure 64 - Periods of locked and unlocked shadow data in the Shadow Data Sign-off Management window
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 61
Shadow data are locked or unlocked by selecting the time period in the drop
down menus and setting or removing the ‘Lock shadow data’ check mark. The
Description field must also be filled in before the action can be performed. To
confirm the locking or unlocking of a period a password is also required as
shown in Figure 65.


Figure 65 – Locking shadow data for a specific time period
The dongle is used to recognize whether locking or unlocking of data is being
done by a customer or by a Vestas administrator. Thus it is not possible for a
Vestas administrator to lock/unlock shadow data as a customer and vice versa.

As soon as one of the parties has locked a period of shadow data, it is no longer
editable until the period is unlocked again.

Figure 66 shows how locked periods are indicated in the Shadow Data Editor.
The locked shadow data from May 28th 2010 are marked with a grey
background colour while the periods before and after have a white background
colour and can still be edited.


Figure 66 – Shadow data from May 28th 2010 are locked for editing
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 62
4.9 Reference Curve Editor
The Reference Curve is a corner stone in the report module as it forms the basis
of a number of expected production calculations. It is also possible to create
wind distribution curves, which can be used in efficiency reports (Power curve
module).

The Profile Administrator sub-module contains a reference power curve editor,
which can be used to create and edit reference curves.
Creation and modification of reference curves require that the user has special
access rights.



The window of the Reference Curve Editor is opened by clicking the
icon in the toolbar of the basic administrator window shown in Figure
48.


Figure 67 - Reference curve editor window
The left hand side of the area in the Reference Curve Editor window contains a
list of the available reference curves, a text box with a descriptive text for the
reference curve selected in the list above, information about whether the
selected reference curve is locked (cannot be edited) and information about the
air density for which the selected reference curve is valid.

Profiles containing wind turbines need a reference curve so if the list of
reference curves is empty; a reference curve has to be created before a profile
containing wind turbines is workable.

The Add New button is used for adding a new reference curve.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 63
Edit is used for the editing of an existing reference curve.

The Delete button is used for deleting a reference curve. Deletion of a reference
curve cannot be done if the reference curve is locked or used in any of the
profiles defined.

The Interpolate button makes an automatic linear interpolation between non-
zero values in the reference curve table.

The Reference Curve Data table contains the power output in kW for all wind
speeds from 0 m/s to 30 m/s in steps of 0.1 m/s, 0.5 m/s or 1.0 m/s. The Filter
Wind speed Values drop-down box controls the “size” of the steps.

The Generate Weibull button allows wind distribution curves to be made based
on 2 Weibull parameters and a y factor that is multiplied with the function
showed at the bottom of the window.


Figure 68 - Example of Weibull generation of wind distribution curve
The selected reference curve is presented graphically at the right hand side of
the window.
4.10 Creating a reference curve
To create a new reference curve, click the Add New button.
Select the curve type “Power reference curve” or “Wind distribution curve”.

Enter the title of the new reference curve in the Curve Title field. In the
Description field a text may be entered (optional).

The Cut-in / Cut-out fields let you specify when the wind turbine pauses due to
low and high wind speeds.

The Air Density field will per default hold 1.225 kg/m3. If needed, enter the
actual value for the new reference curve.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 64

Figure 69 – Selecting reference curve type
It is very important thatthe correct air density is entered as the results
generated by the report module are strongly influenced by the reference curve
air density.

The Lock Curve for Changes check box should not be selected at this point
because this will prevent reference curve data from being entered!

Click OK to close the window.
Inserting power/bin values for a reference curve
Next step is to enter the power output for each wind speed value. Normally,
power output values are available for integral m/s - values such as for 0, 1, 2, 3
…. m/s wind speed. If these values are entered, the Interpolate button may be
used for obtaining an automatic interpolation between all the non-zero power
values entered. All power values lying before the first non-zero power value
and after the last non-zero power value will remain equal to zero.

It is of course possible to insert power output values for all the individual wind
speeds but this is a time-consuming process.

The graphical area at the right hand side of the Reference Curve Editor window
is updated concurrently with power values being entered. This makes it easy for
you to check whether the correct reference curve values are being entered.
When you have entered the power values and interpolations have been made,
click the Apply button to transfer the new reference curve to the database.
Copy-paste of power output values from Excel
You can also copy-paste power output values from an Excel spread sheet.

In Excel, select two columns with wind speed and power output values; copy
this information. Then select a cell in the kW column in the Reference Curve
Data table and paste the information from Excel into the columns. Finally, use
the Interpolate button to create the reference curve.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 65
The values from the spread sheet will be assigned to the correct wind speeds in
the reference curve automatically. This way it is not necessary to include all
wind speed values in the spread sheet list.


Figure 70 – Excel Figure 71 – Reference curve editor
4.10.1 Locking a reference curve
It is possible to lock reference curves and thus prevent subsequent
modifications of the reference curve. To do this, click Edit and check off the
Lock Curve for Changes check box.

A locked curve cannot be unlocked by the user, only the system administrator is
able to do so. If the user then confirms that the curve shall be locked, the locking
is made. The status shown in the Reference Curve Editor window (Figure 67)
will then change from Open to Locked.
4.11 Setup of validation parameters
The report module performs validation of both the data received from the units
and the manually inserted values. Hence, the Profile Administrator has a special
function that allows users to change the validation parameters and to
activate/deactivate the individual validations. Special access rights are required
make changes in the validations.


To open the Validation Parameters window, click the icon in Profile
Administrator window shown in Figure 48.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 66

Figure 72 – The validation window
4.11.1 Selecting group or unit type parameters
A selector is placed below the toolbar to let you select the validation parameters
to be shown/edited. A click on the down-arrow to the right in the selection field
opens a menu from which parameters can be selected.

The list contains all the unit types. At the top a special group with the
meteorological parameters, which are common for the whole site is found.
When the group or unit type is clicked in the list, the related parameters are
shown.

A red check mark in the Active column indicates that the validation is active.
The name of the unit is stated in the Entity column and to the right the lower
and the upper validation limits are stated.
4.11.2 Editing validations
In order to be able to edit validations, the user must have the appropriate access
rights.

To activate/deactivate, click the leftmost field in the row. This will make the red
check mark appear or disappear. When changes have been made, click the
Apply button. The transfer of the change is confirmed by the Apply button
being greyed out.

To change the lower and upper limits left-click on the limits to be changed.
Enter the new limit values and transfer the changes to the database by clicking
the Apply button. In addition, here, greying out of the Apply button confirms
that the changes have been transferred to the database.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 67
4.11.3 Shadow data regeneration after validation changes
The validation changes will automatically be used on future data but for the
existing data to be validated in accordance with the new validation parameters,
a regeneration of the shadow data is necessary. For a description on
regeneration of shadow data, see section 4.7.

Changes in the group of meteorological parameters have impact on all the
profiles made for the site. Hence, shadow data for all profiles may need
regeneration as each profile has its own set of shadow data.

Changes in validation parameters for a unit type have impact only on the
profiles containing this unit type. Only these profiles may need shadow data
regeneration.

The green plus-sign changes to the red minus-sign in front of those profiles,
which need a shadow data regeneration to have the validation changes to take
effect also on the existing shadow data.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 68
4.12 Profile and template access
The administrator for the report module has a user access setup facility, which
is used for administration of the user access rights to profiles and report
templates.


The Profile and template access setup facility is started by clicking the
icon in the Profile Administrator window shown in Figure 48.

The Profile & Template Access window has two tab sheets one for profile access
and another for template access.


Figure 73 – Window for assigning access rights
The user roles or individual users are shown in the left column; the report
profiles or templates in the center column while access is indicated in the
Enabled column by a checkmark. The user creating the new profile may now
add check marks for the users who shall have access to the new profile.

The information is transferred to the database when you click the floppy disk
icon (Save) in the toolbar or the window is closed.

The user cannot change his or her own access rights. An attempt to do so will
result in an error message from the system administrator.

Note: You can see the report profiles and report templates that YOU have access
to. A special permission is required for setting permissions for other users.
Contact your system administrator for access rights.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 69
4.13 Free wind parameter setup
The Free Wind Parameter Setup contains a number of correlation parameters,
which can be set up for one or many parameter configurations. The correlation
parameters can be attached to a park unit in the park unit configuration
specifying how to calculate the free wind speed.


Figure 74 – The Free wind parameter window

The Free wind parameter setup facility is started by clicking the icon
in the Profile Administrator window shown in Figure 48.

If you click the remove button, the selected correlation parameters are removed.
Clicking the Add and Edit buttons activates the window shown in Figure 48 -
The basic window of the administrator sub-module .


The High Pitch angle must always be
smaller than theLow Pitch angle.

Interpolation is performed using the 3rd
order polynomial parameters.

The 3rd order polynomial is applied on the
wind turbine anemometer wind speed.

Note: IF wind exclusive sectors are applied, the
specifications in the Free wind parameter setup
will be overwritten.

Click OK to save and close the window and
Cancel to close the window.






Figure 75 Free wind parameters with neutral settings

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 70
4.14 Wind exclusion sectors
The data in a wind sector group is used in the calculation of free wind speed for
the shadow data. Additionally, wind exclusion sectors can also be used for the
calculation of power curves.

A wind sector group can be defined by means of a number of wind sectors. A
wind sector group can be attached to a wind turbine in the Park Unit
Configuration window – see Figure 52.

Note: Be sure to cover the full 360 degrees!



Figure 76 – Creating wind exclusion sectors
The following window appears when you click the Add or the Edit buttons.


Figure 77 – Definition of wind exclusion sector
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 71

Excluded: Select this option to exclude a wind sector which means that the 10-
minute data from wind directions within the specified sector will not be used in
the calculations.

The excluded wind sectors can also be applied to the calculation of power
curves if the Include WSG (Wind Sector Group) option is selected in the Power
Curve window (see chapter 13 in the VestasOnline Business Operator’s Manual
for more information).

Angle: A start angle and a stop angle can be defined for a sector. The example
shows that the start angle is included and the stop angle is excluded.
Parameters: The parameters in the last part are used in the calculation of free
wind speed.

The Run parameters are applied when the rotor of wind turbine is running and
creating turbulence; the Stop parameters are applied when the rotor is not
moving.

Note: Wind Exclusion sectors include the 3rd order polynomial and will overwrite any
existing parameters in the Free Wind parameter setup. The 3rd order polynomial is
applied on the wind turbine anemometer wind speed.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 72
Chapter 5 Calculation Procedures
This chapter describes the calculation formulas behind the report columns used
by the VestasOnline®Business Report Module.

The report column descriptions provide a detailed explanation on how results
are calculated together with a description of resolution and uncertainty.

The VestasOnline® Business Server database operates with two main data tables
for data storage. The tables are the following:

 Collected 10-minute data from the wind turbines (raw data tables)
 Auto-processed and manually entered data (shadow data tables)

5.1 Collected 10-minute data from the wind
turbines
The collected data from the wind turbines are processed, time stamped and
stored in a local 10-minute database in each wind turbine controller. The Data
Collection Module (DCM) installed on the VestasOnline® Business Server
collects the data packages every 10 minutes from all wind turbines and stores
these packages in the central SQL Server database. The number of values in
each 10-minute data package is dependent on the type of wind turbine.

Note: The 10-minute data collected from the wind turbines are never manipulated or
post-processed in any way.
5.2 Automatically processed and manually entered data
Shadow data are auto processed and manually entered. The auto-processed
data are used for pre-calculations of complicated expected outputs of the wind
turbine, downtime allocation and of free-stream wind speeds.
5.2.1 Auto-calculated shadow data
The following data are automatically calculated and stored as shadow data for
each wind turbine:
 10-minute average wind turbine expected output based on the reference
curve with air density correction using the wind turbine anemometer
 10-minute average wind turbine expected output based on the reference
curve without air density correction using the wind turbine anemometer
 10-minute average wind turbine expected output based on the reference
curve with air density correction using the meteorology anemometer
 Wind turbine free-stream wind speed using the 10-minute average wind
speed measured on the wind turbine applied with a 3rd order correction
polynomial
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 73
 Downtime category according to event information collected from the
wind turbine (e.g. Manufacturer, Owner, Substation, etc.) for all 10-
minute values based on the event allocation table entered into the Profile
Administrator module
 Downtime category based on manually entered status/event
information, which has been entered to overwrite existing information
from the wind turbine or to fill in information gaps due to data loss
5.2.2 Manually entered shadow data
To ensure 100% database integrity it is necessary to add manually entered data
into the database. In case a wind turbine loses power for an extended time
period, the normal 10-minute data cannot be generated and the data will be
missing in the database. Part of the database integrity procedure is to ensure
that all 10-minute periods hold valid data for:

 Actual average production (kW)
 Free-stream wind speed (m/s)
 Status code
 Category (Normal operation – Manufacturer – Owner – Substation –
etc.)
 Expected output (kW)

The following data can be manually entered into the shadow data tables for all
wind turbines:
 Average free-stream wind speed
 Average production
 Status code
 Category
 Expected production
 Blade pitch angle (applies only to certain wind power plants with
passive stall wind turbines from the former NEG-Micon turbine range)
 Comments (used for documenting manually entered data)

Note: The 10-minute data stored in the shadow data tables will always be manipulated
or processed data.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 74
5.3 Reporting process work flow
The reporting process involves all sub-modules in the Report Module.
5.3.1 The Report Generator module
The Report Module includes five different sub-modules in the reporting
workflow:
 The Report Archive is available for all users who can access archived
reports
 The Report Generator is available for all users who can generate reports
 The Template Designer is available for the on-site operator who needs to
design new reporting templates
 The Shadow Data Editor is available for on-site operators who are
responsible for event downtime allocation and database integrity
 The Profile Administrator is available for the administrator who is
responsible for the contractual system configuration. The module
includes event allocation list, wind turbine neighbour setup, power
reference curve, allocation category setup, report template user-rights
and raw data validation parameters
5.3.2 The reporting work flow
The reporting process consists of a number of different steps and processes. In
the following, the different stages will be described:
Collected 10-minute data
The raw data have been collected from the wind turbines and stored in the SQL
Server database.
Auto-generating shadow data
The shadow data are generated for all wind turbines with a 10-minute
resolution based on the configuration in the Profile Administrator.
Profile Configuration (Profile Administrator)
The contractual information such as power reference curves and downtime
allocation is made available for the auto-generatedshadow data.
Shadow data
The auto-generated shadow data have been stored in the wind turbine shadow
data tables in the SQL Server database.
Manually entered shadow data (Shadow Data Editor)
The Shadow Data Editor is used for validating the collected 10-minute data. The
manual database integrity procedure is executed and all necessary data are
entered into the shadow data tables.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 75
Generating results and storing them in a new report table
Reports are generated by means of combined data from the collected 10-minute
raw data and the shadow data. In combination, these merged data offer a
database with full integrity.
Report template configuration (Template Designer)
The generated reports use the predefined template, which has been set up and
configured in the Template Designer.
Report results (Report Generator)
A report result table is generated and stored in the SQL Server database.
Extracting reports (Report Archive)
Already processed reports can be presented, edited, re-calculated or removed.
Reports
Reports can be copied to a spread sheet, printed on paper or to a PDF file.


Figure 78 – Diagram of report generation
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 76
5.4 Reporting data basis
Report columns available in the Template Designer all use data from the SQL
Server database tables. All generated reports are based entirely on shadow data
tables and/or the collected 10-minute data tables (raw data).
5.4.1 Combining shadow data and collected 10-minute data
The philosophy in combining shadow data and collected 10-minute data is
prioritization.
An example of prioritization is the reported wind turbine wind speed
information, which is presented in three ways:

 1) The actual wind speed measured at the wind turbines (collected 10-
minute raw data)
 2) The free-stream wind speed which is automatically calculated using a
3rd order polynomial
 3) The manually entered wind speed which is added to the shadow data
using the Shadow Data Editor

All three above values may exist in the tables but only one of the above value
types is allowed to be used in the reporting process.
In this case the order of priority is 3 > 2 > 1, meaning that manually entered data
always have the highest priority and will be used for reporting when they are at
hand.

If no manual data are entered into the shadow data table, the free-stream wind
speed will be used. If the free-stream wind speed has not been calculated, the
collected data will be used.
5.4.2 Shadow Data Details
The Shadow Data Details menu in the Shadow Data Editor can be used for
viewing detailed information on shadow data and collected 10-minute data. The
table contains several values per wind turbine for each 10-minute period.

The Shadow Data Details screenshot shown in Figure 79 is an example of one
10-minute period from the wind turbine A1. Note that the values present in the
Shadow Data Details window differ depending on the selected report profile for
a turbine, i.e. whether the turbine has an AOM 4000 or AOM 5000 service
contract. For AOM 5000 contracts an additional line: 42 – Average actual
production – is added. For further information, see section 2.6 Editing and
presenting shadow data.

The lines in the data table are colour coded to illustrate the different types of
data. On the screen, the different colours will appear more distinct. For a
description of the different colour codes, see Figure 21 in chapter 2.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 77

Figure 79 – Example of Shadow Data Details for a turbine with AOM 5000 service contract. Note that line
42 is not present in shadow data for AOM 4000 turbines.
Note: ADC (appears in line 39-41) is an abbreviation for Air Density Correction
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 78
5.4.3 Priorities used in the reporting process
In the following section, all priorities used in the reporting process are
explained.
5.4.4 Expected production priority
The priority for calculating expected production used in the reports and
calculations is given as follows in the Shadow Data Details window:

 For turbines with an AOM 4000 service contract: line 42 (37, 38, 40, 41,
39) – see table 3

 For turbines with an AOM 5000 service contract: line 43 (37, 38, 40, 41,
39, 42) – see table 4

Priority Line No. Description
1 37 Expected production manually entered
2 (14) Turbine production (if it is in Normal operation)
3 38 Production of the neighbouring wind turbine
4 40 Expected production based on WTG anemometer wind speed
found in the guaranteed power curve with air density correction
5 41 Expected production based on meteorology anemometer wind
speed found in the reference power curve with air density
correction
6 39 Expected production based on WTG anemometer wind speed
found in the reference power curve without air density
correction
7 - Missing data – should be avoided in order to achieve accurate
reports on Lost or Expected production
Table 3 - Expected production values with priorities (AOM 4000)

Priority Line No. Description
1 37 Expected production manually entered
2 (14) Turbine production (if it is in Normal operation)
3 38 Production of the neighbouring wind turbine
4 40 Expected production based on WTG anemometer wind speed
found in the guaranteed power curve with air density correction
5 41 Expected production based on meteorology anemometer wind
speed found in the guaranteed power curve with air density
correction
6 39 Expected production based on WTG anemometer wind speed
found in the guaranteed power curve without air density
correction
7 42 Average actual production based on production from all
turbines of the same type (except production from the actual
turbine, primary and secondary neighbour turbines and de-
rated turbines).
8 - Missing data – should be avoided in order to achieve accurate
reports on Lost or Expected production
Table 4 - Expected production values with priorities (AOM 5000)
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 79
The value presented in the Expected production line (42 for AOM 4000 / 43 for
AOM 5000) and hence used in reports and calculations is taken from the highest
priority line of the lines containing valid values.
Line 38 contains the production from a neighbouring wind turbine or – if the
neighbouring turbine has been de-rated – the expected production for the
neighbouring turbine. The use of the production data from a neighbouring
wind turbine is optional. Each wind turbine can be set up in the Profile
Administrator to have two neighbours; a primary and a secondary. The
validation and priority of wind turbine neighbours is auto-calculated and stored
as shadow data - see line 6 in Figure 79.
Often, the wind turbines selected as neighbours are placed close to the wind
turbine but a neighbour can also be situated further away. The important thing
is that neighbouring wind turbines have similar wind and terrain conditions.
To secure the highest degree of data integrity, it may be advantageous to select
the secondary neighbouring wind turbine from a separate communication loop
or feeder, if available. This will secure data for expected production if the grid
connection is lost for parts of the wind power plant.
5.4.5 Wind speed and priority
The following tables contain the priority lists for wind speed, actual production,
status code, and category and pitch angle:

Priority Line no. Description
1 8 Wind speed manually edited
2 9 Free-stream wind speed
3 10 Actual wind speed
Table 5 - Wind speed values with priorities
Line 11 inthe Shadow Data Details table (see Figure 79 – Example of Shadow
Data Details) contains the highest ranking wind speed value from table 5, which
is the one used in reports and calculations.
5.4.6 Active power
Priority Line no. Description
1 12 Production manually edited
2 13 Actual production
Table 6 - Production values with priorities
Line 14 in the Shadow Data Details table (see Figure 79 – Example of Shadow
Data Details) contains the highest ranking, valid production value from table 6,
which is the one used in reports and calculations.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 80
5.4.7 Status code
Priority Line no. Description
1 16 Status code manually edited
2 17 Actual status code
Table 7 - Status codes with priorities
Line 18 in the Shadow Data Details table (see Figure 79 – Example of Shadow
Data Details) contains the highest ranking, valid status code from table 7, which
is the one used in reports and calculations.
5.4.8 Standard category
Priority Line no. Description
1 21 Category manually edited
2 22 Category based on manual status code
3 23 Auto category
Table 8 - Categories with priorities
Line 24 in the Shadow Data Details table (see Figure 79 – Example of Shadow
Data Details) contains the highest-ranking category from table 8, which is the
one used in reports, and categories.
5.4.9 Pitch angle
Note: Only applies to certain wind power plants with passive stall regulated wind
turbines (from the former NEG-Micon turbine range).

Priority Line no. Description
1 46 Pitch angle manually edited
2 47 Actual pitch angle
Table 9 - Pitch angles with priorities
Line 48 (AOM 4000) / line 49 (AOM 5000) in the Shadow Data Details table (see
Figure 22 - Shadow Data Details – turbines with AOM 4000 and Figure 23 -
Shadow Data Details – turbines with AOM 5000 service contract) contains the
highest ranking, valid pitch angle from table 9 which is the one used in the
expected production calculations.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 81
5.5 Report column calculation procedures – Standard
Contractual Availability
The description covers the calculation procedures used for some of the available
report columns listed for Standard Contractual Availability (wind turbines with
AOM 4000 contracts).
5.5.1 Wind turbine reporting columns

Available Report Columns in the category: Event Category - Availability
Standard Contractual
Availability:
Standard contractual availability calculated from the
turbine’s registration of 10 min. downtime and allocation of
event / error codes.

Available Report Columns in the category: Event Category – Power and Production
Manufacturer Loss kWh: Lost energy production during periods where the wind
turbine did not produce energy because of events allocated
to the manufacturer.

Available Report Columns in the category: Event Category - Time
Normal Operation Hours Calculation of the number of hours with turbine events
categorized to Normal Operation.
Normal Operation Percentage Calculation of the percentage for turbine events
categorized to Normal Operation.
Manufacturer Downtime Hours Calculation of the number of downtime hours with turbine
events categorized to Manufacturer.
Manufacturer Downtime
Percentage
Calculation of the downtime percentage for turbine events
categorized to Manufacturer.
Missing Allocation Hours Calculation of the number of hours with missing allocation
(no default allocation or missing data due to lost
communication).
Missing Allocation Percentage Calculation of the percentage for the missing allocation
hours.
Categorised Downtime Hours Calculation of the number of categorised downtime hours -
e.g. number of hours with turbine events categorized to
other than Normal Operation. The period of time with
missing allocation (no default allocation or missing data
due to lost communication) is not included in this
calculation as being downtime hours.
Categorised Downtime
Percentage
Calculation of the downtime percentage for the number of
categorised downtime hours.

Available Report Columns in the category: Turbine Wind Speed
Average Free-Stream Wind
Speed m/s:
The free-stream wind speed calculated based on the WTG
anemometer wind speed.






 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 82
Available Report Columns in the category: Turbine 10min – Production data
Actual Output kWh: Actual production in kWh.
Operating Net-Expected
Energy kWh:
Expected production based upon the reference curve and
the WTG anemometer, with air density correction.

Available Report Columns in the category: Turbine Efficiency
Load Factor %: Load factor compares the production to the max. possible
production.
Operating Efficiency: Indication of how well the wind turbine produces compared
to the expected production based upon the reference
curve.
Power Curve Efficiency: Wind turbine performance compared to the guaranteed
power curve.

5.5.2 Power meter reporting columns

Available Report Columns in the category: ION 7600 / 7700 Power Meter
Active Power Export: Exported kWh at the power meter installation.
Active Power Import: Imported kWh at the power meter installation.
Reactive Power Export: Exported kVarh at the power meter installation.
Reactive Power Import: Imported kVarh at the power meter installation.
Active Power Net: Exported minus imported kWh at the power meter
installation.
Reactive Power Net: Exported minus imported kVarh at the power meter
installation.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 83
5.5.3 Calculation of Standard Contractual Availability
The Standard Contractual Availability is based on the event codes of the
collected 10-minute data. The event categorisation is set up in the Profile
Administrator according to the contractual settings.

This report column contains a calculation of the Vestas Standard Contractual
Availability using the generic formula:
( TA / TCT ) * 100%,
where

 - TA means "Turbine Available" and shall be the accumulated number of hours
the WTG is operating or ready and available for operation for any given period
according to allocation of turbine events into categories in the VestasOnline
Business SCADA system.

 - TCT shall mean the "Total Calendar Time" in hours of the calculation period
(i.e. for availability on an annual basis TCT = 8760 hours).
Downtime allocated to other categories than Manufacturer and Unscheduled
Maintenance is not considered as WTG errors and is included in TA. TA is
though calculated as "TCT - T,Manufacturer - T,UnscheduledMaintenance",
where

 - T,Manufacturer is the downtime hours due to turbine events allocated to the
Manufacturer category
 - T,UnscheduledMaintenance is the downtime hours due to turbine events
allocated to the UnscheduledMaintenance category
5.5.4 Calculation of Manufacturer Loss kWh
Manufacturer Loss in kWh is calculated as a summation of the difference
between the expected production and the actual production divided by 6
(conversion from kW to kWh) for all 10-minute periods having the
Manufacturer category.

Description of the expected production calculations is found in section 5.4.4,
and the calculation of actual production is described in section 5.5.12.
5.5.5 Calculation of Normal Operation Hours
Normal Operation Hours are calculated as the sum of periods having the
Normal Operation event category within the report period.

The resulting number of seconds is converted into hours after summation.
5.5.6 Calculation of Normal Operation Percentage
Normal Operation Percentage is calculated as the ratio of Normal Operation
Hours to the reporting period (TCT).
 VestasOnline® Business 3.9 – Advanced ReportingModule Administration Manual Page 84
5.5.7 Calculation of Manufacturer Downtime Hours
Manufacturer Downtime Hours are calculated as the sum of periods having the
Manufacturer event category within the report period. The calculation
procedures do not distinguish between events causing a wind turbine to stop
and events not causing a wind turbine to stop (Warnings). All periods having
the Manufacturer category are included in Manufacturer Downtime Hours.
For periods having the Manufacturer category based on the event code from the
wind turbine, the time used for summation is the value in line 20 (see Figure 79
– Example of Shadow Data Details), which varies varies between 0 and 600
seconds.
For periods where the Manufacturer category is either entered manually or
based on a manually entered event code, the time used for the summation is
always 600 seconds.

The resulting number of seconds is converted into hours after summation.
5.5.8 Calculation of Manufacturer Downtime Percentage
Manufacturer Downtime Percentage is calculated as the ratio of Manufacturer
Downtime Hours to the reporting period (TCT).
5.5.9 Calculation of Missing Allocation Hours
Missing Allocation Hours are calculated as the sum of periods having the no
event allocation within the report period.
The resulting number of seconds is converted into hours after summation.
5.5.10 Calculation of Missing Allocation Percentage
Missing Allocation Percentage is calculated as the ratio of Missing Allocation
Hours to the reporting period (TCT).
5.5.11 Calculation of Average Free-Stream Wind Speed m/s
The Average Free-Stream Wind Speed in m/s is calculated as the average of the
wind speed values in line 11 (see Figure 79 – Example of Shadow Data Details) for all the
10-minute periods of the report period.
The wind speed value in line 11 is, as taken in order of priority:
1) Wind speed manually edited (line 8)
2) Free-stream wind speed (line 9)
3) Actual wind speed (line 10)

Priority 1 is simply a manually inserted value while priority 3 is the actual
average wind speed received from the wind turbine. Priority 2, the free-stream
wind speed, is a wind speed value derived from the actual wind speed by
means of a set of correlation expressions, as described below:
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 85
Calculation of the free-stream wind speed for wind turbines in
operation
The relation between the actual wind speed and the free-stream wind speed can
be established as a third order correlation expression:

01
2
2
3
3
kAWSkAWSkAWSkFSWS 

where FSWS is the free-stream wind speed in m/s and AWS is the actual wind
speed in m/s.

Stall regulated wind turbines
For a wind turbine in operation the set of constants depends on the pitch angle
of the wind turbine blade1, so the calculation procedures have room for two
correlation expressions for each shadow database, valid for two different pitch
angles.

Figure 80 – Free wind parameters
By means of these two correlation expressions and the pitch angle of the wind
turbine, which can be found in line 48 (see Figure 79), it is possible to calculate
the set of correlation constants valid for that wind turbine by
interpolation/extrapolation.


1 Stall-controlled wind turbines operate with a constant pitch angle of the blades but the pitch angle will normally vary as the
optimal pitch angle depends on the surroundings of the individual wind turbines.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 86
The general formula for calculation of the constants is:

      121
121

 nnnn
kkkk

where kβn is constant no. n for a wind turbine with the pitch angle β, kα1n and
kα2n are constants no. n from the correlation expressions valid for the two pitch
angles α1 and α2.

The free-stream wind speed is subsequently calculated as:

01
2
2
3
3 
 kAWSkAWSkAWSkFSWS
producing

The expression above is used if the generator status code is equal to 1, meaning
that the generator was connected to the grid during the whole 10-minute
period.
Calculation of the free-stream wind speed for wind turbines not
operating
For a non-producing wind turbine a single correlation expression independent
of the pitch angle is used:

producingnon
kAWS
producingnon
kAWS
producingnon
kAWS
producingnon
k
producingnon
FSWS









,0,1
2
,2
3
,3

This formula is used when the generator status code is equal to 0, meaning that
the generator was not connected to the grid during the whole 10-minute period.
Calculation of the free-stream wind speed before correlations have
been established
It requires some months of operation to collect sufficient data to establish the
correlation expressions. Until the correlations are ready, the free-stream wind
speed calculation is suppressed by using constant sets of the form k3=0, k2=0,
k1=1 and k0=0.

Using such a set of constants in all correlation expression causes the free-stream
wind speed to be calculated as:

AWSFSWS 


AWS, the wind speed based upon the wind turbine anemometer, approximates
because of the conversion formulas in the wind turbine controller the free-
stream wind speed. Hence, reasonable results are obtained also in the first part
of the operating period where the third order correlations have not been
determined yet.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 87
5.5.12 Calculation of Actual Output kWh
The calculation of Actual Output in kWh is based upon the average kW for each
10-minute period. The average kW (the production) is taken from line 14 (see
(see Figure 79 – Example of Shadow Data Details).
The actual output for each wind turbine is calculated as the sum of the
production values for all 10-minute periods of the report period. Conversion of
kW to kWh is done by a division by 6.
5.5.13 Calculation of Operating Net-Expected Energy kWh
Operating Net-Expected Energy, kWh is used in the calculation of the
theoretical operating efficiency (see section 5.5.15).

The calculation of the Operating Net-Expected Energy in kWh is based upon the
Expected reference production WTG anemometer with air density correction in
line 40 (see Figure 79 – Example of Shadow Data Details). No other lines with
expected production can be used, not even the lines 37 and 38 which have
higher priority.

A 10-minute period is excluded from the calculation if the user manually
changes wind speed, air temperature, air pressure, actual output, event code
and category or if the wind turbine has not been in normal operation during the
whole 10-minute period. A 10-minute period is furthermore excluded from the
calculation if the data received from the wind turbine or meteorology station are
invalid.

Contributions to the operating net-expected energy kWh from 10-minute
periods fulfilling the above requirements are calculated and converted to energy
through a division by six and then summed.
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 88
5.5.14 Calculation of Load Factor
The Load Factor is based upon the actual production of the wind turbine in the
report period in kWh together with the production, which would have been
produced if the wind turbine had been operating at rated power during the
whole report period.

The following example illustrates how the Load Factor is calculated:

The report period is assumed to be one week (168 hours) and the rated power of
the wind turbine is assumed to be 900 kW. Hence, if the wind turbine had been
producing at rated power during the whole report period, a total of 151200 kWh
would have been produced. If the actualoutput for the report, calculated as
described in 5.5.12, is 28000 kWh, the Load Factor will be the following:

%.%FactorLoad 5218100
151200
28000


The Load Factor is influenced both by wind turbine stops because of
disturbances and by the wind resources available in the report period. A load
factor of 100% requires so much wind during the report period that the wind
turbine has been able to run at full load all the time. In practice, Load Factors of
more than 50% are extremely rare.
5.5.15 Calculation of Operating Efficiency
The Operating Efficiency for the report period compares the measured
production in kWh to the operating net-expected energy (the theoretical
expected output). This means that if an event (untwisting, wind vane error, etc.)
has stopped the wind turbine and the actual output is zero or lower, the
expected output is calculated based on the wind speed from the wind turbines
or the meteorology mast.

The sum of measured production in kWh and the sum of operating net-
expected energy for all 10-minute periods with normal operation in the report
period are calculated. The operating efficiency for the whole report period is
calculated as the sum of measured production in percent of the sum of
operating net-expected energy. The Operating Efficiency is based on original
wind turbine and manually entered data.
5.5.16 Calculation of Power Curve Efficiency
The Power Curve Efficiency is a traditional presentation on how the wind
turbine performance compares to the guaranteed power curve. This means that
the data used in the efficiency column are all the data where the wind turbine
was connected to the grid for the entire 10-minute period, no faults, etc.

 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 89
The power curve efficiency for the whole report period is calculated as the sum
of the measured production in percent of the sum of operating net-expected
energy. Everything that is questionable (manually entered data etc.) is excluded
from the calculation in order to get a correct picture.
5.6 Report Columns and Calculation – Energy-Based
Availability
The following provides an overview of the available report columns for Energy
Based Availability (applying to wind turbines with AOM 5000 service
contracts). In addition, the formula for calculating Energy Based Availability is
given, including an elaboration of the concepts of availability and production.
5.6.1 Wind turbine reporting columns

Available Report Columns in Energy Based Availability
Actual Production WindAware Actual production in kWh when wind
speed is between the cut-in and cut-out
wind speed, excluding the turbine’s
consumption of energy (‘WindAware’).
Actual Production Actual production in kWh for each of
the following turbine event categories:
Utility, Owner, Manufacturer, Scheduled
Maintenance, and Unscheduled
Maintenance. Note: The calculation of
Actual Production corresponds to the
calculation of Actual Output used for
Standard Contractual Availability
(turbines with AOM 4000 service
contracts). See 5.5.12 above.
Expected Production Expected production in kWh for each of
the following turbine event categories:
Utility, Owner, Manufacturer, Scheduled
Maintenance, and Unscheduled
Maintenance.
Note: The calculation of Expected
Production corresponds to the
calculation of Operating Net-Expected
Production used for Standard
Contractual Availability (turbines with
AOM 4000 service contracts). See 5.5.13
above.
Possible Power WMS
Reduction
Value in kWh calculated by the turbine
controller as an estimation of the
possible power that the turbine can
produce in the given environmental
condition for the turbine event
categories Utility and Owner.
Calculated when the turbine is de-rated
and running in external power reduction
mode imposed by a power regulation
unit.
Energy Based Availability: The total energy-based availability in
% for the report period (see formula in
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 90
5.6.2 below).

5.6.2 Calculation of Energy-Based Availability

Energy-Based Availability is based on the event codes and power reduction
modes of the collected 10-minute data. The event categorisation is set up in the
Profile Administrator according to the contractual settings.

This report column contains a calculation of the Vestas Energy-Based
Availability using the formula:

100%
 Production le Unavailab Production Available
Production Available
tyAvailabili Based-Energy 




where

 Available Production indicates the actual energy produced (in MWh) by a
turbine during an availability period, plus the expected production
registered by a reference measurement (e.g. primary neighbouring
turbine) during each assumed available period during the availability
period.

 Unavailable Production indicates the expected production (in MWh)
registered by a reference measurement during each unavailable period
for a turbine during an availability period.

The concepts of availability period and production are further explained below.

Availability Period
As seen from the above formula, availability is calculated based on an
availability period and the energy produced during the availability period. Every
10-minute timestamp in the period is allocated to a sub-period (see below). Any
period that does not fall with any of the below definitions is considered as a
normal operation period.

Assumed Available Period
An Assumed Available Period is a period where the turbine is not able to operate
or is de-rated due to events such as downtime which the customer (owner) or
the grid operator (utility) is responsible for.

Excluded Period
An Excluded Period is a period where the turbine is not able to operate or is de-
rated due to unforeseen events such as Force Majeure, Environmental
(lightning, hail storms, ice, etc.), and corrupt or loss of data. As such events
 VestasOnline® Business 3.9 – Advanced Reporting Module Administration Manual Page 91
cannot be attributed to a responsible party, excluded periods are not included in
the calculation formula.

Unavailable Period
An Unavailable Period is a period where the turbine is not able to operate or is
de-rated due to an event that does not fall within any of the above two
categories. Scheduled Maintenance is an Unavailable Period, as are other
periods where downtime is caused by Vestas.

Production
Production values are calculated based on the above specified periods and
events.

Available Production
Available Production consists of two elements:
 Actual energy produced during the availability period
 Expected production from any Assumed Available Period during the
availability period

Unavailable Production
Unavailable Production is the production that would have been expected in any
Unavailable Period during the Availability Period (i.e. the turbine was not
operating or was de-rated because of Vestas).

	Advanced Reporting Module Administration Manual
	Version 3.98
	Table of Contents
	Chapter 1 Introduction
	Chapter 2 Shadow Data Editor
	2.1 The basic windows for editing of shadow data
	2.1.1 Profile
	2.1.2 Date and time details
	2.1.3 Park unit
	2.1.4 View
	2.1.5 Retrieving data
	2.2 The Shadow Data Editor window
	2.2.1 The toolbar buttons
	2.2.2 Selecting or changing the unit to be edited
	2.2.3 Presentation of unit information
	2.3 Database maintenance tool
	2.3.1 Mass-editing tool
	2.4 The Shadow Data Quick Tools
	2.4.1 Period
	2.4.2 Search
	2.4.3 Filter
	2.4.4 Comment
	2.4.5 Legend
	2.4.6 Validation
	2.4.7 Options
	2.5 Presentation of shadow data
	2.5.1 Colour coding of shadow data (Legend tab)
	2.6 Editing and presenting shadow data
	Smart columns
	2.6.1 Editable columnsin the Shadow Data table
	2.6.2 Inserting and editing comments in the shadow data table
	1.1
	1.1
	1.1
	2.7 Saving of edited shadow data
	Chapter 3 The Template Designer
	3.1 Template selection
	3.2 Template management
	3.3 New or Edit report template window
	3.3.1 Details section
	3.3.2 Default report properties
	3.3.3 Template columns
	3.3.4 The Available Column Templates Legend box
	3.3.5 Formatting a template column
	3.4 Template Access
	3.5 Preview
	3.6 Standard Rreports
	3.7 Historical Reports
	1.1
	1.1
	3.8 Event Reports
	3.8.1 Summarized Event Reports
	Chapter 4 The Profile Administrator
	4.1 Overall configuration
	4.2 Report profile configuration
	4.3 Creating profiles
	4.3.1 Selecting and editing park units
	Selecting park units for the profile
	Editing units selected for the profile
	Transfer of selected and edited data
	1.1.1
	4.3.2 Selecting and creating categories
	Events and categories
	Selecting and adding categories
	4.3.3 Categorizing events in the event list
	Select event list
	Remapping categories
	4.3.4 Shadow data generation
	4.4 Locking a profile
	4.5 Editing existing profiles
	4.6 Removing profiles
	4.7 Generation/regeneration of shadow data
	4.8 Shadow Data Sign-off Management
	4.9 Reference Curve Editor
	4.10 Creating a reference curve
	Inserting power/bin values for a reference curve
	Copy-paste of power output values from Excel
	4.10.1 Locking a reference curve
	4.11 Setup of validation parameters
	4.11.1 Selecting group or unit type parameters
	4.11.2 Editing validations
	4.11.3 Shadow data regeneration after validation changes
	4.12 Profile and template access
	4.13 Free wind parameter setup
	4.14 Wind exclusion sectors
	Chapter 5 Calculation Procedures
	5.1 Collected 10-minute data from the wind turbines
	5.2 Automatically processed and manually entered data
	5.2.1 Auto-calculated shadow data
	5.2.2 Manually entered shadow data
	5.3 Reporting process work flow
	5.3.1 The Report Generator module
	5.3.2 The reporting work flow
	Collected 10-minute data
	Auto-generating shadow data
	Profile Configuration (Profile Administrator)
	Shadow data
	Manually entered shadow data (Shadow Data Editor)
	Generating results and storing them in a new report table
	Report template configuration (Template Designer)
	Report results (Report Generator)
	Extracting reports (Report Archive)
	Reports
	1.1
	1.1
	1.1 Figure 74 – Diagram of report generation
	1.1
	5.4 Reporting data basis
	5.4.1 Combining shadow data and collected 10-minute data
	5.4.2 Shadow Data Details
	5.4.3 Priorities used in the reporting process
	5.4.4 Expected production priority
	5.4.5 Wind speed and priority
	5.4.6 Active power
	5.4.7 Status code
	5.4.8 Standard category
	5.4.9 Pitch angle
	5.5 Report column calculation procedures – Standard Contractual Availability
	5.5.1 Wind turbine reporting columns
	5.5.2 Power meter reporting columns
	5.5.3 Calculation of Standard Contractual Availability
	5.5.4 Calculation of Manufacturer Loss kWh
	5.5.5 Calculation of Normal Operation Hours
	5.5.6 Calculation of Normal Operation Percentage
	5.5.7 Calculation of Manufacturer Downtime Hours
	5.5.8 Calculation of Manufacturer Downtime Percentage
	5.5.9 Calculation of Missing Allocation Hours
	5.5.10 Calculation of Missing Allocation Percentage
	5.5.11 Calculation of Average Free-Stream Wind Speed m/s
	Calculation of the free-stream wind speed for wind turbines in operation
	Calculation of the free-stream wind speed for wind turbines not operating
	Calculation of the free-stream wind speed before correlations have been established
	5.5.12 Calculation of Actual Output kWh
	5.5.13 Calculation of Operating Net-Expected Energy kWh
	5.5.14 Calculation of Load Factor
	5.5.15 Calculation of Operating Efficiency
	5.5.16 Calculation of Power Curve Efficiency
	5.6 Report Columns and Calculation – Energy-Based Availability
	5.6.1 Wind turbine reporting columns
	5.6.2 Calculation of Energy-Based Availability
	Availability Period
	Production
