Marine Crane

M170/2S











Use & maintenance manual
Documentation book

SORMEC s.r.l.
 C.da Sasi area artigianale, ALCAMO (TP) ITALY
 ++39-924-502655 FAX ++39-924-27047

INDEX

SORMEC s.r.l.
MAINTENANCE MANUAL

1 CRANE DESCRIPTION
1.1 INTRODUCTION
1.2 WORKING TEMPERATURE
1.3 INDICATION OF THE CRANE MODEL
1.4 GENERAL ARRANGMENT
1.5 HYDRAULIC POWER PACK
1.6 STRENGTH CALCULATION
1.7 IDENTIFICATION OF THE MAIN COMPONENTS
1.8 CRANE ACTUATION

2 DIRECTION FOR THE USE OF THE
CRANE
2.1 RECOMMENDACTIONS FOR THE USE
2.2 OPERATIVE WORKING SIGNALS

3 SAFETY NORMS
4 INSTALLATION OF A SORMEC
CRANE
5 MAINTENANCE
5.1 REGULAR INSPECTION
5.2 ANNUAL INSPECTION
5.3 DEFICIENCIES ARISING FROM INSPECTION
5.4 INSPECTION RECORDS
5.5 CRANES NOT IN REGULAR USE
5.6 TRAINING AND RULES OF MAINTENANCE AND
OPERATING STAFF
5.7 ROPES
5.8 ROPES MAINTENANCE PLANNING
5.9 WINCH DRUMS MAINTENANCE PLANNING
5.10 WINCH BRAKES
5.11 HOOK AND HOOK BLOCKS
5.12 SLEWRING BEARING AND FASTENERS
5.13 WELDED PEDESTAL
5.14 BOLTED PEDESTAL
5.15 BOOMS
5.16 ELECTRIC MOTORS
5.17 HYDRAULIC OIL - FILTER CLEANING
5.18 CHANGE OF HYDRAULIC OIL
5.19 CONTROL VALVES BLOCK
5.20 BLOCK VALVES
5.21 HYDRAULIC CONNECTIONS
5.22 LUBRICATION


6 FUNCTIONAL INSPECTION
6.1 PUMP FUNCTIONAL CHECK
6.2 SETTING OF THE CONTROL VALVES BLOCK
7 LOAD MOMENT LIMIT – OPTIONAL
SAFETY DEVICE
7.1 FUNCTIONAL SYSTEM
7.2 MAINTENANCE
8 HOISTING ACCESSORIES
8.1 WORKING AT HOOK
8.2 WORKING AT WINCH
8.3 NUMBER OF WIRE ROPE REEVES
8.4 COUNTERWEIGHT
8.5 HOOK
8.6 STOWING POSITION
8.7 END STROKE DEVICE
8.8 USE OF THE WINCH
8.9 LOAD HANDLING
8.10 PENDULUM EFFECT
8.11 LOAD HOISTING
8.12 LOAD APPLICATION
8.13 HOOK SAFETY LATCH
8.14 OPERATIONAL PERFORMANCES
8.15 WIRE ROPE REEVES
9 TROUBLE SHOOTING
10 HYDRAULIC CIRCUIT
11 ELECTRIC CIRCUIT


SORMEC s.r.l.
MAINTENANCE MANUAL
1
1. CRANE DESCRIPTION
1.1 INTRODUCTION
The Sormec marine cranes are hydraulic lifting appliances suitable for installation
on quay, deck, on offshore platforms, driven by electro-hydraulic power units.
The Sormec marine crane’s structure is composed of welded box type girders
made from high tensile steel, the booms are of telescoping type, stiff boom type
and knuckle boom type. The manufacturing materials comply with the
requirements of the Leading Classification Societies such as R.I.N.A. L.R.S.
Bureau Veritas, ABS, DNK etc..
The welding and the welders are in accordance with the ASME NORMS.
All Sormec cranes are designed and calculated in accordance to DIN 15018.
Strength verifications in compliance with other standards are available upon
request.

1.2 WORKING TEMPERATURE
Sormec marine cranes can normally operate at
temperatures varying from -10°C to + 40°C.
For more severe weather conditions the crane has to be
built with special materials and components.

1.3 INDICATIONS OF THE CRANE MODEL
At one side of the crane column, in a visible position, a manufacturing-plate will be
attached, indicating all necessary details for the identification of the crane.
Herebeside, a manufacturing plate fac-simile is shown.









SORMEC s.r.l.
MAINTENANCE MANUAL
2
1.4 GENERAL ARRANGEMENT



SORMEC s.r.l.
MAINTENANCE MANUAL
3
1.5 HYDRAULIC POWERPACK


SORMEC s.r.l.
MAINTENANCE MANUAL
4
1.6 STRENGTH CALCULATION



SORMEC s.r.l.
MAINTENANCE MANUAL
5
1.7 IDENTIFICATION OF THE MAIN COMPONENTS
A sketch of the crane is shown here below, from which all crane components can
be identified:
















1 Pedestal 7 1st Extension
2 Slewing Ring 8 2nd Extension
3 Crane Column 9 1st Extension Cylinder
4 Boom 10 2nd Extension Cylinder
5 Boom Cylinders 11 Sheave Block
6 Winch 12

SORMEC s.r.l.
MAINTENANCE MANUAL
6
1.8 CRANE ACTUATION
Even if the operator has previous experience in driving lifting equipments, we
would recommend the complete reading of this hand book. Sormec declines all
responsibility in case of damages caused by an untrained operator.
Sormec marine cranes are equipped with hand operated hydraulic control valves.
Each control handle corresponds to a given motion. When released it returns back
to its “neutral” position, thus stopping the crane motion.
By manoeuvring the handle mildly, the crane will work smoothly and without any
sudden acceleration.
Cranes booms and hydraulic extensions are driven by double acting hydraulic
cylinders.
The rotation of the crane is executed by a toothed crown and a pinion system in
which:
• The pinion is operated by an oleodinamic reduction gear which is integral with
the boom foot.
• The toothed crown is made up of a slewing ring bearing with ball/rolling where
the external crown is integral with the boom foot, the internal section is integral
with the pedestal and is complete of the toothed crown coupled with pinion.

All cranes motions are protected by pilot operated counterbalance valves which
automatically prevent slippage and load drop in case of pipe failure or burst hoses.
















SORMEC s.r.l.
MAINTENANCE MANUAL
7
2. DIRECTIONS FOR THE USE OF THE CRANE
2.1 RECOMMENDATIONS FOR THE USE
• When starting up the crane, especially in cold weather, it is advisable to carry
out some manoeuvres without load in order to reach the correct fluidity inside
the hydraulic circuit and verify the regular crane working. When working with
the crane, once the control handle is at its end stroke, release the handle
immediately to avoid unnecessary oil overheating.

• Avoid any sudden stop of the crane movements when the load is hanging on.
Because this, during the lowering manoeuvres mainly, may damage and
unnecessarily stress the crane.

• Avoid sudden and abrupt manoeuvres.
Operate the control levers smoothly and
gradually.

• Operate the crane control levers following
the instructions shown on the knob labels.

• Never drag loads along the deck or the
ground, but slew them raised from deck or
ground.

• In case of welding to be carried out on
pieces suspended by the crane hook: never
use the crane hook, never use the crane
structure as the weld earth path.

• Make sure that the loads lifted, in relation to the outreaches, do not exceed the
load chart ratings.








SORMEC s.r.l.
MAINTENANCE MANUAL
8

• The crane load chart must be carefully respected especially in case the manoeuvre to
be executed is that to lift a load close to the crane and move it far away. Never trust on
the intervention of the overpressure valves, which might be unset or out of order if
not constantly inspected














• Crane must be properly maintained so as to overcome possible periodical
inspections made by the Inspection Bodies.

















SORMEC s.r.l.
MAINTENANCE MANUAL
9
2.2 OPERATIVE WORKING SIGNALS
In case the crane’s operator, from this operating spot, cannot see the load to be
handled, a communication with another operator is then necessary.
For that purpose the following system of clear visual signals is advisable:


Should the operator not clearly understand the signals, the crane must not be
activated. The operator and the signalman can decide, before starting any loading
operation, to use a different communication system.




SORMEC s.r.l.
MAINTENANCE MANUAL
10
3. SAFETY NORMS
Before manoeuvring the crane, make sure that the hook and omega are perfectly
efficient.

Make sure that the lifted loads, in relation to the outreaches, do not exceed those
stated on the diagram.
Please remember that the load diagram gives maximum lifting capacities and in
case of supplementary equipments (such as grabs, power blocks, supplementary
hooks etc.) it is necessary to deduce the weight of the accessories from the ratedloads.


Never walk under an overhanging load and
never stand in the crane operating area.
Never tamper with the crane hydraulic
circuit. Please make sure that nobody
stands or walks in the crane operating
area.





It is Strictly forbidden to hoist (with the winch) higher loads than the ones given on the
load diagram.

















SORMEC s.r.l.
MAINTENANCE MANUAL
11
4. INSTALLATION OF A SORMEC CRANE
The crane arrives complete with supports for installation and screws.

PROCEDURE OF INSTALLATION:

1. Position the pedestal in the location pre-arranged for the installation.
2. Weld the pedestal along the whole contour.

3. Position the crane on the pedestal and start tightening all bolts .
4. Rotate the column to create a coincidence between the hole in the column
plate (detail A) and the bolts head.
5. Tighten the bolts with a torque as report in the Page 13, by a dynamometric
key.



SORMEC s.r.l.
MAINTENANCE MANUAL
12
The bolt connection is crucial to the slew bearing function and life. A proper
fastening of the slew bearing is required by relevant calculation. This calculation
determines the quantity and preload force of the fastening bolts.
Proper preload is met with:

1. High precision torque wrench
2. Hydraulic tensioning equipment
3. length measure on calibrated bolts


The torque is affected by: bolt quality and grade thread connection friction nad
friction between the contact surfaces of bolt head, nut and parts themselves.


The bolts must be carefully tightened crosswise to the specified preload.




SORMEC s.r.l.
MAINTENANCE MANUAL
13
The tightening torque MA to pre-load FM, for a medium friction value of μG ≈ μK =
0.14, is indicated in the following table.

Strength class to DIN/ISO
898
8.8 10.9 12.9
Yield limit Rp 0,2 N/mm2 640 for ≥ M 16
660 for > M 16
940 1100
Metric
ISO-
thread
DIM 13
Cross section
of area under
stress

AS
mm2
Cross section
of thread


AT
mm2
Clamping force


FM
N
For hydr.
and electric
torque
wrench
Mλ
Nm
Ma' 0.9 Ma *
For spanner


Mλ'
Nm
Clamping force


FM
N
For hydr.
and electric
torque
wrench
Mλ
Nm
Ma' 0.9 Ma *
For spanner


Mλ'
Nm
Clamping force


FM
N
For hydr.
and electric
torque
wrench
Mλ
Nm
Ma' 0.9 Ma *
For spanner


Mλ'
Nm
M12 84.3 76.2 38500 87 78 56000 130 117 66000 150 135
M14 115 105 53000 140 126 77000 205 184 90000 240 216
M16 157 144 72000 215 193 106000 310 279 124000 370 333
M18 193 175 91000 300 270 129000 430 387 151000 510 459
M20 245 225 117000 430 378 166000 620 558 194000 720 648
M22 303 282 146000 580 522 208000 830 747 243000 970 873
M24 353 324 168000 740 666 239000 1060 954 280000 1240 1116
M27 459 427 221000 1100 990 315000 1550 1395 370000 1850 1665
M30 561 519 270000 1500 1350 385000 2100 1890 450000 2500 2250
M33 694 647 335000
Determined bolt
through yield
measurement
480000
Determined bolt
through yield
measurement
560000
Determined bolt
through yield
measurement
M36 817 759 395000 560000 660000
M39 976 913 475000 670000 790000
M42 1120 1045 542000 772000 904000
M45 1300 1224 635000 905000 1059000
M48 1470 1377 714000 1018000 1191000
M52 1760 1652 857000 1221000 1429000
M56 2030 1905 989000 1408000 1648000
M60 2360 2227 1156000 1647000 1927000
* Mλ will change with deviating μG ≈ μK

Dry threads require higher tightening torques, heavily oiled threads require lower
tightening torques.

It is absolutely necessary to tighten the bolts to the required preload. It is to be
ensured that the necessary bolt torque data are maintained over the whole time of
operation. We recommend to check the torque after 3 month of operation and than
after 1 year.

NOTE: In no case securing elements such as loch and spring washers may be
used. Only the preloading force of the bolt serves to secure the bolt.

SORMEC s.r.l.
MAINTENANCE MANUAL
14

Boom connecting Instructions ( If Present )



Connect the boom and tighten the bolts (following the sequence shown in the draw
above) with a torque as report in the Page 13 by a dynamometric key.

5. MAINTENANCE
These maintenance planning identify:
a. Deficiencies which could reduce the capability and operational safety of the
crane.
b. Actions required to correct deficiencies to maintain good operational
capability
It is envisaged that this Recommended Practice will assist Operators in
development of their own Inspection and Maintenance schedules according to
their specific equipment and its location and operational use. Where established
Inspection and Maintenance schedules are in place, the Operator may use this
Recommended Practice to support or complement such schedules as appropriate.
It is expected that the crane and its elements, particularly those of high utilization
such as prime mover, gearboxes, pumps, motors etc. would be maintained on the
basis of condition. The frequency of Inspection and levels of Maintenance stated
in this Recommended Practice are for guidance only.


SORMEC s.r.l.
MAINTENANCE MANUAL
15
5.1 REGULAR INSPECTION
For cranes in regular service, the inspection intervals are dependent upon the
nature of the cranes components or systems and of the degree of their exposure
to wear, deterioration or malfunction and of the consequences to operational
safety. Two inspection categories have been assigned herein 'frequent' and
'periodic'
a. Frequent inspection - visual daily to monthly intervals
b. Periodic inspection - at stated intervals which shall include daily and monthly
inspection.

5.2 ANNUAL INSPECTION
Each crane shall be inspected fully every 12 months by a qualified inspector,
whereby all remedial work will be identified and cleared prior to issue of an
inspection certificate. Annual inspection shall include regular inspection
schedules.

5.3 DEFICIENCIES ARISING FROM INSPECTION
a. All deficiencies arising from inspections shall be carefully examined for
impairing safe operation. In such instances the crane shall be taken out
of service or its operation limited to remove the unsafe condition
'CAUTION' notices shall be positioned at the control cabin and at the
prime mover as appropriate.
b. Where cranes have been subjected to major repair or modification to either
structural members or to the main functional services, the cranes shall be
thoroughly inspected and function/load tested by a qualified inspector.

5.4 INSPECTION RECORDS
a. Inspection details which include reports as well as records of repairs and
modifications carried out on the cranes shall be dated and signed for monthly,
quarterly and annual inspection. These records shall be kept readily available
by the operator.

5.5 CRANES NOT IN REGULAR USE
Cranes which have been idle for a period of one month up to six months, shall be
inspected according to the periodic requirements of Regular Inspection.


SORMEC s.r.l.
MAINTENANCE MANUAL
16
5.6 TRAINING AND RULES OF MAINTENANCE AND OPERATING
STAFF
Maintenance of Offshore and Harbour Lifting Equipment will primarily involve
platform maintenance staff, crane driver and crane manufacturers staff. Such
personnel should be competent in the services they provide. The minimum
requirements expected of maintenance and operating personnel are as follows:

• Maintenance Staff
a. Understand fully the Crane Manufacturers procedures as described in the
Maintenance and Instruction Manuals.
b. Conversant with the cranes safe operational envelope e.g., lifting duties,
safety systems/limits and of emergency recovery and safe shutdown
procedures.
c. Where appropriate to have received training and instruction on more
specialized aspects of maintenance.
d. Understand the effects of dynamic loading.

• Crane Driver
a. Physicallyable to operate the crane; able to judge distances heights and
clearances during day and night operation under all weather conditions.
b. Adequately trained for the type of crane being driven. The training should
cover instruction at the crane manufacturer's works/test site followed by
instruction by a qualified driver on the crane at it's location.
c. Familiar with the cranes safe operational envelope e.g. lifting duties, safety
systems/limits and of emergency recovery and safe shut down procedures.
d. Correctly respond to all crane warning systems.
e. Trained in day to day crane inspection including routine checks on lubrication
levels, rope condition, loose or damaged components, healthy status check on
safety systems and general wear and tear.
f. Trained to perform routine maintenance tasks including all crane lubricants,
rope change-out, hook/block change-out and general rigging.
g. Fully conversant with the duties and instructions of the slinger
h. Have an understanding of dynamic loading and effects on the crane




SORMEC s.r.l.
MAINTENANCE MANUAL
17
5.7 ROPES
Crane ropes used for luff and load hoist systems, are often spooled onto their
drums in multiple layers and, as such, they need to be tolerant to crushing and
abrasion. The load hoist rope will usually be of non-rotating, multi-strand
construction. Both rope types should incorporate an independent wire core with all
wires in the construction galvanised. Galvanising gives added protection to the
rope when in store whilst enhancing its fatigue life in operation.










Where non-rotating rope is used, the following should be noted:

a. Failure of non-rotating rope can occur suddenly and without apparent warning
and is usually initiated by breakages of the inner wires of the construction.
Total failure could therefore occur without showing any visible indication at the
outer wires Evidence of one broken external wire, is a strong indicator that the
rope may already have several broken internal wires and could therefore be
close to total failure.
b. Loss or drying-out of the lubricant accelerates corrosion and fatigue of the
internal wires Such conditions will promote early failure of the rope. Close
proximity of gas turbine exhausts and flare radiation effects in addition to a
saline environment, will serve to exacerbate the problem.

WIRES BREAK
(BREAKAGES DUE TO FATIGUE
STRENGTH)
WIRES BREAK
(BREAKAGES DUE TO EXCESSIVE
TENSILE STRESS)
REPEATED TEARING STRESSES CAN
CAUSE WIRES RUN OUT OF THE ROPE
THE WIRE ROPE IS DEFORMED IN SUCH A WAY
THAT THE INTERNAL SIDE IS VISIBLE OR RUST
IS APPEARING

SORMEC s.r.l.
MAINTENANCE MANUAL
18
The following practices should be observed:

The outer and inner wires of the rope should be inspected for any visible breaks.
The internal wires should be examined by twist-opening the strands with rope
grips or lever clamps. For non-rotating rope constructions, the ropes should be
discarded if broken wires are found and /or corrosion is evident. For the rope, use
discard criteria according to national regulations. Example:

a. Ropes should be lubricated with a penetrative lubricant- oil with viscosity of 30
SAE is recommended. The lubricant should be applied by pressure lubricator.
It is essential that the lubricant penetrates the inner wires particularly on non-
rotating ropes. Never use viscous (thick/heavy) lubricants on wire rope, these
create a harmful 'barrier' effect leading to corrosion and rapid failure of the
internal wires.
b. Rope change-out (according to rope condition or prevailing statutory
requirements) should be undertaken only in accordance with the crane/rope
manufacturers procedures. Where provided, dedicated spooling or rope
change- out drums should always be used.
c. Pendant ropes should be inspected and lubricated as for running ropes with
particular attention paid to the condition of the wires local to the entry point at
the terminations. With the application of good lubrication/inspection
procedures pendant rope can be expected to remain in service for 3/5 years.
d. Other ropes on the crane, which are not in the primary load path but which
have important functions such as, safety harness wires, boom handrail wires,
boom back stop support wires, constant tension wires (e.g., supporting
temperature sensors in the luff system) etc. should be checked as part of the
drivers daily routine, with a more thorough examination every three months.
e. All rope terminations and anchor points should be examined on the same
frequency as wire ropes.









SORMEC s.r.l.
MAINTENANCE MANUAL
19
5.8 ROPES MAINTENANCE PLANNING
• Daily – Monthly
a. Check rope is spooling evenly on drums without loss of pattern and without
undue gapping.
b. Check rope for condition - abrasion, particularly at flanges and cross-over
points; crushing, usually due to slackly spooled rope corrosion, signs of rust;
loss of lubricant, particularly on active sections e.g., continued use around
sheaves; broken wires.
c. Check rope for other abnormalities, e.g., spiralling, basketing etc.
d. Check terminations for condition and security
e. Check levels of lubrication at the rope and its terminations

• Monthly - 3 Monthly
Lubricate ropes using a penetrative lubricant with viscosity of 30 SAE by a
pressure lubricator. For sections of rope which are difficult to access, such as
'dead lengths' and terminations, lubricate by hand.

• 3 Monthly - 12 Monthly
Inspect the internal wires of the rope for corrosion, broken wires and lubricant
quality. Use the correct tools - twist-grips and procedures as specified by the rope
manufacturer only for this operation.

• Change-Out
According to rope condition and/or discard assessment .
a. Check that the replacement rope is the correct size (diameter and length) and
construction. Ensure these details are as specified by the crane manufacturer.
b. Check that the test certificate clearly identifies with the rope and that the rope
taken from store was on a 'first in', 'first out' basis.
c. Only use change-out practices specified by the rope/crane manufacturer.
d. Ensure new rope is not dragged over the ground/deck or fouls obstacles or
any part of the crane structure when spooling onto the winch drums. Where
possible use dedicated rope spooling gear.
e. Check that 'turn' is not induced during spooling.
f. Ensure all terminations are compatible with the rope



SORMEC s.r.l.
MAINTENANCE MANUAL
20
5.9 WINCH DRUMS MAINTENANCE PLANNING
• Daily - Monthly
a. Check drum flanges and kicker strip if fitted, for undue rope scrubbing or
heavy wear.
b. Check drum flanges for spreading or splaying.
c. Check drum mountings for general condition and security.
d. Check condition of all external lubrication/environmental seals.
e. Check brake drums/discs for scoring or uneven wear.
f. Check for condition and security of rope termination clamps at drum flanges

• Monthly - 6 Monthly
a. Check all major fasteners associated with the drum against the
manufacturers recommended. Typically and where applicable, such fasteners
would be:
i. Main drum unit foundation bolts
ii. Bolted/screwed-on drum flanges
iii. Bolted/screwed-on back stops or brake drums/discs.
iv. Bolted/screwed-on back stops or spragg clutches
v. Bolted/screwed-on ratchet (boom hoist drum only)
b. Check condition and securement of final drive gear/chain pinions/wheels.
c. Visually check for 'cracks' at all main weld areas on drum and drive mounting;
this may be indicated initially by local paint cracking.

 After 1000 hours of winch operation (with average operating cycles at 60%
nominal load) a full service of the negative brake is mandatory. This work
must be done by the Producer.











SORMEC s.r.l.
MAINTENANCE MANUAL
21
5.10 HOOK AND HOOK BLOCKS
• Daily- Monthly
a. Check safety catch functions correctly without hang-up.
b. Check that hook swivels smoothly and that by 'feel' there are no signs of
bearing 'catch' or brinnelling.
c. Check hook for increased admittance dimension, undue flattening (burring)
'nicks' and cracks.
d. Check that all split pins securing hook swivel nut and rope guards are intact.
e. Ensure rope anchor points are in good order and properly secured.
f. Visually check that all sheave and hook shank bearing seals are sound.
g. Ensure all rope guards are secure and are set at correct clearances from
Sheaves.
h. Check sheave tread profiles for undue wear and damage.
i. Ensure all lubricant channels (grease points) are clear, undamaged and
provide free flow of lubricant.

5.11 SLEWRING BEARING AND FASTENERS
• Monthly to 6 Monthly
a. Check the tension in four bolts (one in each quadrant) at slewring to pedestal
and slewring to crane according to crane manufacturers procedures as show
in the chart on page 15.
b. Check bolt tension in any associated retaining device.
c. Check that the main bearing environmental seals are in good condition.
Renew immediately if damaged or distorted.
d. Check final drive slew gear teeth for undue wear - tearing and plucking.
e. Ensure pinion drive has full face width contact and correct pitch line setting -
check backlash.
f. Ensure all guards are in place, correctly fitted and secure.
g. Check rocking clearances.
h. Ensure all lubrication points are undamaged and provide free flow of lubricant.

• 6 Months to 12 Months
a. Remove at least one fastener from each mounting circle and examine for
corrosion and stress corrosion cracking. Renew rather than replace the bolt.
b. Check lubricant for water content and particle content.


SORMEC s.r.l.
MAINTENANCE MANUAL
22
5.12 WELDED PEDESTAL
• Every 6 - 12 Months
Visually inspect all welds for cracks and corrosion - if in doubt, use NDT
inspection methods
• Every 5 Years
Blast clean selective welds and fully inspect using NDT procedures. This
inspection should also extend into the pedestal column/stand and deck
structure. The scope of this inspection should be developed by a competent
Structural Engineer

5.13 BOLTED PEDESTAL
• Monthly to 6 Monthly
a. Check the tension in four bolts (one in each quadrant) at slew ring to pedestal
and slew ring to crane according to crane manufacturers procedures as show
in the chart on page 15.
b. Check bolt tension in any associated retaining device.
• 6 Months to 12 Months
a. Remove at least one fastener from each mounting circle and examine for
corrosion and stress corrosion cracking. Renew rather than replace the bolt.
b. Check lubricant for water content and particle content.

5.14 BOOMS
• Daily - Monthly
a. Check that all aircraft warning , floodlighting and any other luminaries and their
enclosures used on the boom are securely in place, free of damage and that
they function correctly. (if Installed)
b. Ensure all appendages are secure and that all pins, bolts, split pins, etc., are
in good condition.
c. Check condition of sheave treads and bearing seals and security of rope
guards.
d. Check condition and security of rope anchor and load sensor points.
e. Ensure all walkways and handrail systems are secure and are in good order.
f. Check visually for undue cracking of paint at welded joints - investigate further
if in doubt.


SORMEC s.r.l.
MAINTENANCE MANUAL
23
• 6 Monthly - 12 Monthly
a. Remove and examine for corrosion and thread condition one fastener from
one lower boom section flange joint. Replenish with new bolt.
b. By hand check sheaves for smooth rotation, and lateral movement - this is
best done at time of rope change-out.
c. Check rope guards for wear
• Every 5 Years
Overhaul beam completely and fully NDT inspect selected welded joints. The
scope of this inspection should be developed by a competent Structural Engineer.


5.15 ELECTRIC MOTORS
• Daily - Monthly
a. Ensure all guards are secure and correctly fitted
b. Check all locally mounted gauges/instruments are functioning
c. Check for condition, security and chaffing of locally run electrical cables
d. Check for correct function of local start/stop and emergency stop controls
e. Check for securement and performance of ancillary equipment i.e.,
compressors etc.


5.16 HYDRAULIC OIL-FILTER CLEANING
For proper crane functioning, use hydraulic oil of HLP
type, ISO viscosity, to be selected according to the outside
temperature as per table below:



-15 °C ÷ 0 °C VG 15
0 °C ÷ +40 °C VG 46
+40 °C < °C VG 68







SORMEC s.r.l.
MAINTENANCE MANUAL
24


OUTSIDE TEMPERATURE
 -15°C ÷ 0°C 0°C ÷ +40°C > +40°C
AGIP OSO15 OSO 48 OSO 68
ESSO NUTO H 16 NUTO H 46 NUTO H 68
IP HIDRUS OIL 15 HIDRUS OIL 46 HIDRUS OIL 68
MOBIL DTE 22 DTE 25 DTE 26
SHELL TELLUS 22 TELLUS 46 TELLUS 68




For proper crane functioning, a filter must be installed on the electro-hydraulic power
pack. The return line filter between the control valves block and the oil tank is 30 microns.
The filter must be cleaned after 8 working hours and subsequently every 50 working
hours.
The cartridges must be washed with solvents and air sprayed.
The filter body must show no impurities and no cracks.
If this occurs it is necessary to replace the cartridge with another one having similar
features.

It is advisable to replace all filter cartridges at any oil change


5.17 CHANGE OF HYDRAULIC OIL
The hydraulic oil has to be replaced with the same make or with similar one.
To change the hydraulic oil please refer to the following operations:
a. Remove the oil left in the tank, wash the inside of it and the filter.
b. Fill in the tank with the same quantity of clean oil as the one removed.
c. Close the crane cylinders completely. Make sure that the oil coming out from
the return pipe fitted to the upper filter doesn’t flow into the tank: this oil is dirty.
d. Fill in the oil tank with clean oil, up to the correct level


SORMEC s.r.l.
MAINTENANCE MANUAL
25
5.18 CONTROL VALVES BLOCK
For the control of the crane motions, all Sormec
marine cranes are equipped with hydraulic control
valves block, of a proportional type. Each element
is protected by two auxiliary valves: one on the
suction line and one on the return line.
The complete block is also protected by a main
check valve (main valve). Operate the crane
controls following the instructions placed on each
knob.
When the selected lever is released, it returns
automatically to the neutral position and it stops
the motion. Operate the lever smoothly and
gradually to avoid abrupt movements. Sormec
crane control banks may allow (if requested)
several movements to be carried out
simultaneously. When maintenance on the crane
is carried out, verify that the handles automatically
return to their neutral position, oil the pins on
which the handle turns, if necessary.
Verify that no leak appears.

In case it is necessary to dismantle the control block elements of crane, when re-
assembling the whole, pay particular attention to the tightening of the fixing bolts.

















SORMEC s.r.l.
MAINTENANCE MANUAL
26
5.19 OVERCENTER VALVES
On all boom cylinders brake valves are fitted.
The exact name is “pilot operated counter
balance” valves and they prevent the slippage in
the event of a pipe failure or burst hose.
These valves allow the oil to come out from the
cylinder only when, from the opposite side of the
control bank, oil is delivered to increase pressure
and open the valve.
In this way it is impossible to move the booms if
the hydraulic pump is not working.

Sormec’s technological aim has always been to
create hydraulic circuits more and more reliable
and capable of facing any problems of structural
overload.
To this purpose, Sormec has employed the
“block valves”whose further function is to let the
oil out of the cylinder each time the max,
pressure is reached.

In case of replacement, to have perfectly working
crane and with the same performances please
remember to assemble Sormec valves (ref. to
spare parts list) with the same setting values.

When the ordinary maintenance on the crane is
carried out please also verify that no oil leak
appears on the block valves.











SORMEC s.r.l.
MAINTENANCE MANUAL
27
5.20 HYDRAULIC CONNECTIONS
The fittings used on the Sormec cranes hydraulic circuits are of type “TRIPLE-
LOK, UNFJIC 37, BSP”, according to the following approvals: SAE j 514, ASME,
MILITARY STANDARD from MS 51500 up to MS 51534.
Further to the above, the Sormec fittings are also accepted by the main
classification Societies such as Lloyd’s Register, Det Norske Veritas,
Germanischer Lloyd and R.I.Na.
The only maintenance required is the prevention from corrosion.
Particularly, during the first working months of the crane, it may happen that some
oil leaks in the junction points, especially at the pipes edges.
In this case you should first of all screw it manually to the end of the stroke and
then tighten it with a spanner by not more that half a turn.
If there is still oil leak from the connection, you should seek the cause in the
coupling surfaces, as it is absolutely useless trying to achieve the perfect tightness
by tightening the fitting more than the given instructions.
The fittings would be then subject to a useless strain, involving very dangerous
conditions.
Listed below are the torque wrench settings for fittings with O’ring seals and
revolving counter nuts.




















SORMEC s.r.l.
MAINTENANCE MANUAL
28

TORQUE WRENCH FOR O’ RING FITTING AND COUNTERNUTS

Threads
UN - UNF
Torque
Nm
Threads
GAS
Torque
Nm
Threads
metrical
Torque
Nm
7/16-20 18 ÷ 20 1/8 18 ÷ 20 10 x 1 18 ÷ 20
1/2-20 21 ÷ 24 1/4 25 ÷ 30 12 x 1,5 20 ÷ 25
9/16-18 31 ÷ 33 3/8 45 ÷ 55 14 x1,5 25 ÷ 30
3/4-16 58 ÷ 68 1/2 75 ÷ 96 16 x 1,5 45 ÷ 55
7/8-14 88 ÷ 98 3/4 104 ÷ 160 18 x 1,5 50 ÷ 60
1”1 /16-12 157 ÷170 1” 220 ÷250 20 x 1,5 70 ÷ 90
1”7/16-12 185 ÷ 215 1”1/2 230 ÷ 260 22 x 1,5 75 ÷ 96
1”5 /16-12 240 ÷ 270 1”1/4 350 ÷ 470 26 x 1,5 110 ÷ 130
1”3/2-12 250 ÷ 285 27 x 2 130 ÷ 150
1”2/2-12 370 ÷ 450 33 x 2 220 ÷ 250



When a replacement of a fitting is needed, please carefully check that all
coupling cone shaped areas are perfectly clean to guarantee the tightness.
















SORMEC s.r.l.
MAINTENANCE MANUAL
29
5.21 LUBRICATION
The articulation’s pins and the extensions need a periodic lubrication. Such
intervals of greasing the articulation pins vary in relationship to the use and the
particular type of crane. In the underlying chart are show the periods of greasing
recommended.


Inject fat in pressure until it doesn't escape from the coupled elements so that to
replace the old lubricant. After the lubrication, perform some complete movements
of all the articulations of the crane and add some fat to guarantee an optimal
lubrication.


SORMEC s.r.l.
MAINTENANCE MANUAL
30
Clean the hydraulic extensions from the impurities. Keep the sliding pod well
greasing, cover the external inferior side and the external superior side from the
telescopic arm with grease. To make sure that all the points of greasing are
always well lubricated, using the type of suitable grease on the chart. Other
greases having the same characteristics can be used.



GREASING POINT TYPE OF GREASE
GREASING
PERIODS
1 - ROTATING TURRET PIN
Shell Albida
GREASE
EP 2
50 HOURS
2 – SLEWING RING 50 HOURS
3 – CYLINDER PIN 50 HOURS
4 – SHEAVE PIN 8 HOURS
5 – SLIDING POD &
EXTENSION 8 HOURS



















SORMEC s.r.l.
MAINTENANCE MANUAL
31
6. FUNCTIONAL INSPECTIONS
6.1 PUMP FUNCTIONAL CHECK
The pump capacity must correspond, for each crane model, to the values given on
the power pack.

6.2 SETTING OF THE CONTROL VALVES BLOCK
To set the distributor proceed as follows:
a. Check that the pressure at the power pack is normal
b. For each control valve the following instructions must be carried out:
1. Installation of a control manometer on the delivery.
2. set the pressure until it reaches the service on using a screwdriver on the
adjusting screw relative to the same control.
3. Once the above conditions are reached, block the screw with a nut.
4. Carry out movement tests relative to the valve
c. Carry out the same operation on all the distributor valves.




















SORMEC s.r.l.
MAINTENANCE MANUAL
32
7. LOAD MOMENT LIMIT - OPTIONAL SAFETY DEVICE
7.1 FUNCTIONAL SYSTEM
Where the load moment limiting device is foreseen, proceed as follows:
a) Be sure that the pressure at the power pack is correct.
b) Install a manometer on the delivery .
c) Set the pressure to reach the working pressure adapt the relative screw until the
service pressure is reached.
d) Once the above conditions are reached, block the screw with a lock nut.
e) The working pressure is that shown on the table below.

Please find, here following, an example on how setting has to be carried out:
The load moment limit must intervene when, by operating the crane, the maximum
loading point is achieved.
If the above operation cannot be executed it means that:
- the load moment limit is not properly set (too high values)
- the control valve block is not properly set .

In case the activation point of the load moment limit needs to be changed, adjust the
setting of the reference valve as follows:
- tighten it if the load moment limit actuates too early or loose it if the load moment
limit actuates too late

7.2 MAINTENANCE
The application of the load moment limit involves the use of a filter installed close
to the control valves block.
This filter needs periodical cleaning, as do all other filters installed on the crane.

Furthermore, it is advisable to check periodically the proper working of the load
moment limit hydraulics as well.






SORMEC s.r.l.
MAINTENANCE MANUAL
33
8. HOISTING ACCESSORIES
We believe that a paragraph of this handbook should be dedicated to the
accessories which can be installed to the crane’s hook for lifting the load. The
experience has taught us that unintentional accidents represent a minimum
percentage compared to those caused by neglection or non-compliance with the
basic safety norms. Carelessness can cause damages to properties or even worse
injuries to people. We always recommend to verify, periodically, the integrity of the
wire ropes and belts using for lifting the loads. When selecting their diameters
please consider the additional stress they are subject to when not used in vertical
position.
8.1 WORKING AT HOOK
Before handling the load, make sure it is balanced
by lifting it a few centimetres only. Never store the
ropes in wet areas and never expose them to
excessive heat.
Never use chains connected with screw bolts.
The incorrect application of the rope to the hook can
open the hook safety latch. The safety latch must
always return to its original seat after the ropes
have been attached.
8.2 WORKING AT WINCH
When the use of the crane depends on the winch,
the operator must be much more careful during
ordinary operations with the crane; most of the
accidents depend on the sheave block or load
pendulum effect or by accidental breakage of the
wire rope.
Here below are some recommendations which
should be carefully respected in order to operate
with the crane safely and to improve its efficiency in
the long run.
8.3 NUMBER OF WIRE ROPE REEVES
The number of original wire rope reeves supplied by Sormec cannot be modified,
for any reason, by the customer or third parties.

SORMEC s.r.l.
MAINTENANCE MANUAL
34
8.4COUNTERWEIGHT
A counterweight is installed at wire rope tip in order to
properly hoist and lower the wire rope without bringing any
damage to the same especially when the load is not
hanged on. In case of winches with more than one reeve
the sheave block can replace the counterweight.
8.5 HOOK
The supply of the winch, installed on the crane, always
includes the hoisting hook. The most common system to
install the hook to the wire rope is to use a wedge shaped
socket.
It is one of the operator responsibility to verify, before
starting any job, that all mentioned components,
particularly the hook safety latch is efficient and integral.
8.6 STOWING POSITION
The cylinders rods must be as much protected as possible.
The hydraulic extensions should be re-entered as much as
possible at the end of the working day. It is necessary to
stow the crane at very low speed, making sure that no
damage or impact occur between the crane itself and its
hoisting accessories.
In order to make it easier for the operator we recommend
to lock the hoisting hook on a fastener and to tension the
winch wire rope.
8.7 END STROKE DEVICE
The supply of a winch can also include the supply of an
automatic end stroke device both for upward and downward
wire rope control.
The intervention of the end of stroke device immediately
stops the crane’s operations, avoid to use the end stroke
device voluntarily, especially with the maximum load
hanged on; this would imply useless stresses to the crane
structure.






SORMEC s.r.l.
MAINTENANCE MANUAL
35
8.8 USE OF THE WINCH
Avoid to use the winch if the load hook stands on the ground. The inconvenients
involved by hoisting the load hook from ground should be an irregular overlap of
the wire rope or the running out of the rope from the drum.
Before starting to hoist the load, move the crane winch at empty hook. This
operation is extremely important especially when the crane and the winch have
been stored for several days. The empty hook operations allow a proper of control
of the winch function and guarantee the oil filling inside the winch brake.
When the outside temperature is rather low (+5°/ -20° C) the above operations
have to be carried out for several minutes before starting the ordinary work with
the winch.

8.9 LOAD HANDLING
The load to be hoisted must be placed below
the hook vertically. It is absolutely forbidden to
hang a load in a different way, even in case of
a lighter load compared to the winch hoisting
performances.

8.10 PENDULUM EFFECT
In order to decrease the pendulum effect, bring the load as close as possible to
the crane boom tip. A minimum distance between,
the crane boom tip and the load will allow a faster
load handling thus reducing the pendulum effect.

8.11 LOAD HOISTING
The load hoisting from the ground must be
executed through the winch. If the load is topped
by the crane main topping cylinder, the load will
immediately move sideways with a dangerous
oscillation. This oscillation will increase
proportionally to the increase of the boom vertical
position.





SORMEC s.r.l.
MAINTENANCE MANUAL
36
8.12 LOAD APPLICATION
We highly recommend to always verify the integrity of the wire rope and belts in
relation to the load to be hoisted up. When selecting the proper wire rope or belt
diameters, please take into account superior strength the rope and belt have to
stand when not working in vertical position.
Before hoisting the load from ground, please verify if the load is balanced by lifting
it up by some centimetres. Never use chains connected with screw bolts.

8.13 HOOK SAFETY LATCH
The hoisted load must be hanged to the hook
making sure that the latch is completely closed.
The application of wire ropes or chains in such a
quantity that the latch cannot be closed,
determinates a reduction of the safety
performances as well as danger that the wire
rope can run out of the hook with consequent
load crash.

8.14 OPERATIONAL PERFORMANCES
1. It is absolutely forbidden to hang to the wire rope a load heavier than the winch
hoisting capacity and trying to handle the load topping with the crane. The
winch and all accessories would then be subject to an overstress which could
involve the breakage or the damage of some of the components.
2. It is absolutely forbidden to hoist with the winch a load heavier than the crane
lifting performances, the crane should then be subject to an over stresses which
could involve the breakage or the damage of some of the components.
3. The maximum load at hook cannot exceed the maximum crane lifting capacity
or the maximum winch hoisting capacity.









SORMEC s.r.l.
MAINTENANCE MANUAL
37
8.15 WIRE ROPE REEVES
Check the sheaves, the transmission pulleys, the head pulleys very often. The
structure must not show any deformation deriving from crashes/collisions and the
structural strength must not be compromised by the corrosion.
Pay particular attention to the pulley slewing motion which must not show
excessive clearance, pay attention to the rope side walls which must not show any
deformation, crack or breakage.


The pulley slew on a support which needs to be periodically greased: this will
increase the life of the bearings and decrease the
slewing friction of the pulley itself.

















SORMEC s.r.l.
MAINTENANCE MANUAL
38
9. TROUBLE SHOOTING
The following chapter reports some of the incovenients which might occur to the crane and the
pertinent solutions Warning: in case of an inconvenient to the crane, never work on the hydraulic
settings without the specific knowledge that such an action will solve the problem.

FAULT CAUSE SOLUTION/REMEDY
Noisy pump Low oil quantity inside the pump Verify the oil level (the crane must be
folded), if necessary bring the oil inside
the power pack to the right level
 Dirty suction line filter the oil cannot
flow through
Dismount the filter, clean it or replace it
if worn (see instructions given on the
handbook)
 Worn pump Verify the pump features. Compare the
maximum pressure value shown on the
gauge meter and the topping time of the
main boom cylinder to the specific
cranes data (see technical sheet
referred to the crane hydraulic
connections)
 The pump support is loosen Verify the screw tightening which
connect the pump to the electric motor
 The bleeder vent inside the oil tank is
plugged
Verify that no piece of material or other
things are left on the bleeder vent inside
the oil tank
The crane move jerks Low oil quantity inside the oil tank Verify the oil level (the crane must be
folded), if necessary fill in additional oil
which must have the same features (see
handbook)
 Worn pump Verify the pump features. Compare the
maximum pressure value shown on the
gauge meter and the topping time of the
main boom cylinder to the specific crane
data (see technical data sheet relative to
the crane’s hydraulic connections)
The crane doesn’t lift the rated loads The geometrical indications relative to
the proper crane configuration are not
respected
Carefully read the handbook, chapter
“Directions for use of the crane”
 Insufficient pressure inside the crane
hydraulic circuit
Compare the maximum pressure value
shown on the gauge meter with the
specific crane data
Control handle doesn’t return to the
central seat
Lack of lubricant on the handle linkage Remove the inferior support of the
control handle and the cap placed i the
opposite side of the control handle,
Clean carefully and grease..
 Damage/breakage to the handle spring


Remove the cap mounted to the
opposite side of the control handle.
Replace the spring, reference is shown
on the spare parts of book


SORMEC s.r.l.
MAINTENANCE MANUAL
39

FAULT CAUSE SOLUTION/REMEDY
The crane slewing doesn’t stop when
the relativecontrol handle returns to its
central seat
Inefficient piloted block valve Replace the block valve with another
one having similar properties and setting
values
One crane motion is slow The control valve handle doesn’t
complete its stroke
Verify that the handles fixing screws are
not loosen. Verify that the rod return
spring is opposite the control handle, on
the control valves block tip

The crane boom lowers when lifting
rated loads
Worn cylinder seal Identify the cylinder which moves in
under loading. Replace the seal

Replace the piloted block valve with
another one same setting values

Worn cylinder piloted block valve

It’s impossible to inject grease from a
greaser
Broken greaser Replace the greaser, the code for order
placing is shown on the spare parts book

Dismount the pin and remove the set
grease. Inject new grease
 The injected grease set
Oil leakage from one hydraulic
connection
The connection is loosen Tighten the connection following the
instructions given on the handbook to
see the right torque wrench
 A fittings has been damaged Replace the fitting: place the order giving
the code number shown on the spare
parts book
Oil leakage from the bottom side of the
crane base
Worn slewing cylinders seals Dismount the slewing cylinders and
replace the gaskets

The crane has a winch with electro-
hydraulic end stroke device: no
crane motion is allowed
No electric supply to the system By means of a tester verify the right
inlet tension in the crane electric
circuit
 Broken electric cable Verify the integrity of the electric
cables and micro-switches
 Jammed oil return electro valve At the boom of the electro valve
there is a socket screw. Loose the
counter nut and tighten the socket
screw. In such a way the electro
valve shuts mechanically.
WARNING: with the electro valve
off, the end stroke device does not
work any longer, therefore such an
operation must be done only in
emergency cases


SORMEC s.r.l.
MAINTENANCE MANUAL
40
10. HYDRAULIC CIRCUIT



SORMEC s.r.l.
MAINTENANCE MANUAL
41





SORMEC s.r.l.
MAINTENANCE MANUAL
42
11. ELECTRIC CIRCUIT



SORMEC s.r.l.
MAINTENANCE MANUAL
43





SORMEC s.r.l.
MAINTENANCE MANUAL
44





SORMEC s.r.l.
MAINTENANCE MANUAL
45
