Study on electrochemical impedance spectroscopy and cell voltage
composition of a PEM SO2-depolarized electrolyzer using graphite felt as
diffusion layer
Xifeng Ding a, Songzhe Chen a,b,*, Laijun Wang a,b, Ping Zhang a,b,*
a Institute of Nuclear and New Energy Technology, Key Laboratory of Advanced Reactor Engineering and Safety of Ministry of Education, Tsinghua University, Beijing
100084, China
b Tsinghua University-Zhang Jiagang Joint Institute for Hydrogen Energy and Lithium-Ion Battery Technology, Tsinghua University, Beijing 100084, China
A R T I C L E I N F O
Keywords:
SO2-depolarized electrolysis
Electrochemical impedance spectroscopy
Cell voltage
Overpotential
Polarization impedance
A B S T R A C T
SO2-depolarized electrolysis (SDE) is the hydrogen-producing step of the hybrid sulfur (HyS) process. In this
study, electrochemical impedance spectroscopy (EIS) is used to study the composition of cell voltage of SDE
electrolyzers, which apply porous graphite felts as diffusing layers. By measuring the open circuit potential, the
possible side reactions and the methods to avoid the side reactions are discussed from the perspectives of
thermodynamics and kinetics. According to EIS results obtained at different voltages, the impedance and its
components are determined by equivalent circuit fitting calculation. The obtained impedance values of different
cells agree very well with their SDE performance results. The voltage loss in the SDE process is split into ohmic
impedance loss, kinetics impedance loss and concentration polarization impedance loss. The influences of the
graphite felt compression ratio, operating temperature and anolyte flow rate on the impedance and performance
of SDE cell are investigated.
1. Introduction
Hydrogen is a widely used industrial raw material as well as a
promising clean energy carrier with great application potential [1–3]. In
recent years, the global demand for hydrogen has increased sharply,
consequently the development of reliable large-scale hydrogen pro-
duction technology became a very important topic. Because hydrogen
production basing on fossil energy is accompanied by a large amount of
CO2 emissions, renewable hydrogen production basing on water
decomposition has attracted great attention.
Since water is a very stable compound, the decomposition of water is
usually accompanied by harsh reaction conditions, such as high tem-
perature or high voltage. Thermochemical water splitting cycles are
proposed to produce hydrogen at relatively mild conditions [4,5], by
combining several chemical reactions to form a close cycle, while the net
reaction is the decomposition of water.
Among the numerous proposed thermochemical cycles, the hybrid
sulfur (HyS) process is a relatively simple thermochemical cycle process
[6–8], containing only two independent chemical reactions, namely,
sulfuric acid decomposition and SO2 depolarization electrolysis (SDE) as
follows:
H2SO4→SO2 + H2O+ 1 / 2O2 (1)
2H2O+ SO2→H2SO4 + H2 (2)
The net reaction of the whole process is:
H2O→H2 + 1 / 2O2 (3)
Compared with other thermochemical cycles, all the materials
involved in the HyS process are fluid, and the engineering application of
this cycle is also relatively easier. Thus, HyS process is considered one of
the most promising thermochemical cycles.
In this process, the hydrogen production step is the SDE, whose half-
cell reactions are described by Eqs. (4) and (5).
Anode:
SO2 + 2H2O→SO2−
4 + 4H+ + 2e− (4)
Cathode:
2H+ + 2e− →H2 (5)
* Corresponding authors.
E-mail addresses: chenszh@mail.tsinghua.edu.cn (S. Chen), zhangping77@mail.tsinghua.edu.cn (P. Zhang).
Contents lists available at ScienceDirect
Electrochimica Acta
journal homepage: www.journals.elsevier.com/electrochimica-acta
https://doi.org/10.1016/j.electacta.2022.140837
Received 24 May 2022; Received in revised form 3 July 2022; Accepted 10 July 2022
mailto:chenszh@mail.tsinghua.edu.cn
mailto:zhangping77@mail.tsinghua.edu.cn
www.sciencedirect.com/science/journal/00134686
https://www.journals.elsevier.com/electrochimica-acta
https://doi.org/10.1016/j.electacta.2022.140837
https://doi.org/10.1016/j.electacta.2022.140837
https://doi.org/10.1016/j.electacta.2022.140837
http://crossmark.crossref.org/dialog/?doi=10.1016/j.electacta.2022.140837&domain=pdf
Electrochimica Acta 426 (2022) 140837
2
The cathode reaction of the SDE process is the same as that of pure
water electrolysis. However, for the anodic reaction, i.e. the oxidation of
SO2 to H2SO4, the reversible potential ΦθH2SO4/SO2 = 0.158 V [9],
significantly lower than the reversible potential ΦθO2/H2O = 1.23 V
[10] for the anodic reaction of pure water electrolysis, i.e. the oxidation
of water to oxygen.
Unfortunately, in the actual SDE operation, the cell voltage is
significantly higher than the theoretical reversible potential. The voltage
higher than the reversible potential, in other words, overpotential, is
directly related to the energy efficiency of the SDE process. It is neces-
sary to study the composition of the overpotential and its influencing
factors. For a SDE cell, the total cell voltage U could be split into four
parts as expressed by Eq. (6) [11]:
U=Ueq + i⋅RA + ηa + ηc (6)
where Ueq is the reversible potential of SDE, RA is the ohmic impedance
and i⋅RA is the ohmic impedance overpotential, while ηa and ηc represent
the anode and cathode polarization overpotentials, respectively. i⋅RA, ηa
and ηc form the overpotential consumed by the SDE cell.
For the SDE process, i⋅RA includes the voltage loss caused by inherent
impedance of each component of the cell, such as the electrodes, cata-
lytic layers, proton exchange membrane, electrolyte, etc. ηA and ηC can
be divided into kinetics impedance voltage loss and concentration po-
larization impedance voltage loss. Kinetics impedance, also known as
charge transfer impedance, refers to the charge transfer potential dif-
ference caused by the inability of electrochemical reaction to complete
instantly. Concentration polarization impedance, also known as diffu-
sion impedance, is the resistance caused by the difference in material
concentration between the liquid phase and the surface of membrane
electrode. During SDE process, a small amount of SO2 in anolyte will
cross the MEA into cathodic region and undergo reduction reactions,
thus forming an internal galvanic cell. The galvanic potential offsets part
of the working voltage in the SDE process, leading to an apparent rise of
cell voltage.
Electrochemical impedance spectroscopy (EIS) has been applied for
the study on pure water electrolysis system extensively [12]. However,
the impedance of the SDE cell and its influencing factors are rarely re-
ported. In our previous work [13,14], EIS were conducted on SDE cells
with carbon papers as the diffusion layers. However, the performance of
the cells was poor and the overall impedance is quite large. In addition,
crossover of SO2 and the subsequent side reactions were not considered.
In a recent cooperating research work [15] among the Savannah River
National Laboratory (SRNL), Sandia National Laboratories and the
University of South Carolina (USC), EIS technology was used to measure
the overpotential of gas-phase feed SDE cells. Researchers adopted a
simplified method to work out the composition of overpotential. With
EIS, the ohmic impedance was measured at high frequency, then the
potential loss on ohmic impedance was calculated. The reversible po-
tential and ohmic impedance potential loss were subtracted from the
total cell voltage, obtaining the kinetics overpotential. However, over-
potential caused by side reactions, concentration polarization, etc. was
not discussed in details.
For the purpose of further understanding of SDE process and
improvingthe performance, it is of great importance to carry out sys-
tematical impedance composition research and identify/quantify the
kinetics overpotential, concentration polarization overpotential and
side reaction overpotential of SDE process. In our previous work [16],
porous graphite felts were used to replace carbon papers as the diffusion
layers of the liquid-phase feed SDE cells, which were proved to possess
quite high performance and the performance is dramatically influenced
by graphite felt compression ratio, operating temperature, anodic fluid
flow rate and so on. It is necessary and also interesting to study the
impedance and overpotential of above SDE cells. In this study, in situ EIS
tests are conducted on these cells. The composition of cell voltage and
overpotential is discussed in depth, based on EIS results and the
equivalent circuit fitting calculations. Meantime, the influence of cell
structure and operating conditions on each component of the cell
voltage is investigated.
2. Experimental section
2.1. Chemicals and test solution
Analytically pure 98% sulfuric acid (Beijing Tongguang Fine
Chemical Co., LTD.) is diluted to 30 wt.% with deionized water, and
then saturated with SO2 (99.99%, liquefied air (Tianjin) Co., LTD.) to
obtain anolyte for SDE cells.
2.2. Electrolyzers and experiment apparatus
The EIS test objects, i.e., the 4 SDE electrolyzer cells, are the same as
those used in our previous work [8], which reveals the performance of
these cells equipped with porous graphite felts as diffusion layers. The
electrolyzers adopt symmetrical structure. Fig. 1(a) gives an exploded
sectional view of the half part of an electrolyzer.
Briefly, graphite plates (Fig. 1(b), Shanghai Hongfeng Industrial Co.,
Ltd., China) with 5 cm × 5 cm square groove of different depths, 0.8 or
1.0 mm, are used as polar plates of the electrolyzers. Viton gaskets have
square holes of the same outline size as the grooves in graphite plates,
namely, 5 cm × 5 cm. The Viton gaskets are 0.55 or 1.10 mm thick
originally and 0.5 or 1.0 mm thick after compressed during cell as-
sembly. The MEA is of “sandwich” with three layers, i.e. a thin film of
catalyst, a membrane (Nafion membrane N117CS (E. I. du Pont)),
another film of catalyst. Catalyst amounts on both sides of MEA are the
same, 0.42 mg Pt/cm2. The diffusion layer, namely graphite felt of 5 cm
× 5 cm × 2.5 mm is placed in the interior square space enclosed by polar
plate, gasket and MEA, as illustrated by Fig. 1(a). During assembly, the
deformation of polar plate and MEA is very limited, therefore above
space is compressed due to the reduction of the gasket’s thickness. Ac-
curate control the final thickness of the gaskets of a SDE cell is achieved
with the help of a vernier caliper. After assembly processes, the gasket
thickness of the 4 cells A, B, C and D are 1.0, 1.0, 0.5 and 0.5 mm,
respectively. Since the compress of the space is well controlled, the
graphite felt wrapped around the interior space will be compressed
along with it, and the compression ratio of graphite felt could also be
controlled as a specific value.
The structural parameters of the 4 cells are listed in Table 1. In the
table, compression ratio (rc) of graphite felt is calculated as the ratio of
the reduced thickness of a compressed graphite felt to the original
thickness. It should be noted that the key difference among the 4 SDE
cells is their different rc of graphite felts, and the values of Cell A, B, C
and D are 20%, 28%, 40% and 48%, respectively.
The EIS test facility is illustrated by Fig. 2, with photograph and
schematic diagram. Anolyte, SO2 saturated 30wt.% sulfuric acid solu-
tion is contained in a quartz reservoir with temperature controlled
heating jacket.
The mounted electrolyzer is also equipped with heater, thermo-
couple, and PID digital temperature controller (type SR1, Shimaden Co.,
Ltd., Japan). The tubes connecting reservoir and SDE cell are wrapped
by foam pipe for heat preservation. A pump (WT600-2J, Baoding Longer
Precision Pump Co., Ltd, China),) is equipped to circulate the anolyte
between the tank and the anodic region of the electrolyzer cell. The EIS
tests are driven by an electrochemical workstation (Zennium pro, with a
4-quadrant power potentiostat PP241, Zahner Scientific Instruments,
Germany).
2.3. EIS test method
In situ EIS method is used to measure the impedance composition of
the SDE cell with the anode as the working electrode, and cathode as the
reference electrode and counter electrode. A constant voltage (CV) mode
X. Ding et al.
Electrochimica Acta 426 (2022) 140837
3
is used to provide periodic amplitude over a set frequency range around
a set voltage. The frequency range is 100 kHz to 0.1 Hz, and the DC
voltage amplitude is 10 mV.
The SDE process is sensitive to electrolytic voltage. When no elec-
trolytic voltage is applied, the electrolysis process will not take place
spontaneously, and the SDE cell is a galvanic cell. The open-circuit
voltage of the electrolytic cell is first measured, as an important elec-
trochemical indicator for side reactions. At this time, the current is
formed by the charge transfer driven by the redox reactions on the two
sides of the cell. The expected SDE reaction will not occur until the
applied cell voltage can overcome the potential of side reactions and the
reversible potential of the expected reaction.
Before EIS experiment, 30 wt.% sulfuric acid in the reservoir is
preheated to the desired temperature. SO2 is then bubbled into the
sulfuric acid for enough time ensuring the sulfuric acid is saturated.
Anodic solution is pumped into anode side of the cell at flow rate of
240mL/min. During the test, there is no input on the cathode side, where
the fluid is hydrogen product and a small amount of water permeating
through the MEA from anode side. After the measurement of OCP using
the electrochemical workstation, the cell voltage of 1.00 V is applied to
the electrolyzer in constant voltage (CV) mode. Keep the system running
for more than 30 minutes to stabilize. Then, the parameters (anodic fluid
flow rate, cell voltage, frequency range and the DC voltage amplitude)
are set and the EIS test is triggered. In this work, EIS tests are conducted
at different cell voltages (OCP, 0.40 V, 0.70 V, 1.00 V and 1.20 V),
temperatures (25◦C – 80◦C) and anodic fluid flow rates (160 – 360 mL/
min).
2.4. Equivalent circuit fitting
Zahner Analysis software is used to fit the Nyquist curves resulted
from EIS tests, assisting to build the equivalent circuits. The ohm
impedance, anode/cathode kinetics impedance and concentration po-
larization impedance are determined by equivalent circuit fitting
calculations.
3. Results and discussion
3.1. Establishment of equivalent circuit model
According to Eq. (6), impedance is divided into ohm impedance,
anode impedance and cathode impedance. Both anode and cathode
impedance could be further divided into anode kinetics impedance,
cathode kinetics impedance and concentration polarization impedance.
With different cell voltage applied, the SDE process is in different
states. When applying relatively low cell voltage, the SDE process is
controlled by kinetics and the kinetics impedance accounts for most of
the total impedance [17]. Under high applied voltage, the electro-
chemical reaction rate and SO2 consumption rate accelerate signifi-
cantly, resulting in concentration polarization impedance between the
volume phase of electrolyte and catalyst layer of MEA. At this time, SDE
process is in combined control stage of kinetics and mass transfer,
concentration polarization impedance contributes a lot to the total
impedance [18]. Obviously,cell voltage is an important variable to SDE.
Taking the EIS results of cell C at 60 ◦C and 360 ml/min as examples,
the Nyquist curves obtained can be divided into three types when
different cell voltages are applied, as shown in Fig. 3. The tested voltages
ranges from open circuit voltage to 1.20 V. The highest voltage 1.20 V is
set to ensure the stable and secure application of graphite materials in
the SDE cells.
When the cell works under open circuit voltage, the Nyquist curve
consists of a short straight line in the high frequency region and an
incomplete arc in the middle and low frequency regions, as shown in
Fig. 3(a). At this time, the electrolytic process has not occurred, the open
circuit voltage direction is opposite to the applied voltage of the elec-
trolytic cell, and the measured internal resistance of a galvanic cell, so it
Fig. 1. Structure of SDE electrolyzer
(a) assembling of graphite plate, gasket, graphite felt, and MEA; (b) graphite plate with square groove.
Table 1
Structural parameters of the SDE cells.
Cell number A B C D
Origin graphite felt thickness (mm) 2.5 2.5 2.5 2.5
Depth of groove in carbon plates (mm) 1.0 0.8 1.0 0.8
Gasket thickness in assembled cells (mm) 1.0 1.0 0.5 0.5
Graphite felt thickness in assembled cells (mm) 2.0 1.8 1.5 1.3
Compression ratio of graphite felt rc (%) 20 28 40 48
X. Ding et al.
Electrochimica Acta 426 (2022) 140837
4
Fig. 2. EIS test facility (a) photograph; (b) schematic diagram.
X. Ding et al.
Electrochimica Acta 426 (2022) 140837
5
Fig. 3. Nyquist diagram at different cell voltages on Cell C (rc = 40%) at 60◦C and anolyte flow rate of 360 ml/min
(a) OCP; (b) 0.40 V; (c) 0.70 V; (d) 1.00 V; (e) 1.20 V.
X. Ding et al.
Electrochimica Acta 426 (2022) 140837
6
is necessary to judge the possible reaction of the galvanic cell according
to the measured value of the open circuit voltage.
Once the voltage applied to the cell can overcome the sum of the
open circuit voltage and reversible electromotive force, the electrolytic
reaction is triggered. When the voltage is at a lower level, namely 0.40
or 0.70 V, as shown in Fig. 3(b) and (c), the curve consists of a short
straight line in the high-frequency region and a complete arc in the
middle and low frequency regions, representing ohmic impedance and
electrochemical polarization impedance (i.e., dynamic impedance),
respectively.
When the voltage is set at a higher level, 1.00 or 1.20 V, the obtained
Nyquist curves are of different shape, as shown in Fig. 3(d) and (e). The
curve consists of four parts, i.e., the straight line of the high frequency
area, two incomplete arcs appear in the middle and low frequency re-
gions, and a straight line appears in the low-frequency region.
At low electrolytic voltages such as 0.40 V and 0.70 V, the anodic
electrochemical reaction is slow, and the electrolytic process is in the
dynamic control stage. The equivalent circuit is shown in Fig. 4(a).
Resistor R1 represents the ohmic impedance of the circuit, including the
inherent resistance of the electrolytic cell element and the impedance
caused by the solution and cathode bubbles. Resistance R2 represents
the total kinetics impedance of the circuit, i.e. the dynamic impedance.
This model does not involve diffusion impedance and does not need to
consider concentration polarization. Therefore, it is suitable for low cell
voltage and low current density, as well as operation at low tempera-
tures such as 25◦C, at which the electrochemical reaction rate is slow.
However, when the electrolytic voltage is high (1.00 V and 1.20 V),
the reaction rate increases, and the reactant consumption rate increases,
making the mass transfer rate gradually unable to meet the needs of
maintaining the reactant concentration on the catalyst surface, and the
SDE process transfers to the diffusion control stage. The equivalent
circuit model at this point is shown in Fig. 4(b). Where resistance R1 still
represents the ohmic impedance of the circuit, and resistors R2 and R3
represent the kinetics impedance of the anode and cathode respectively
[19].
R2 corresponds to the anodic kinetics impedance, which appears in
the high-frequency region. The reason is that the oxidation of SO2 in
acidic aqueous solution is more difficult than the reduction of H+.
Therefore, a relatively short period of low voltage process will also
significantly affect the rate of SO2 oxidation reaction. Accordingly, R3
represents the dynamic impedance of the cathode and appears in the
following relatively lower frequency region.
R4 represents the concentration polarization impedance, and the
capacitor in series with resistor R4 represents the volumetric reactance
of the concentration gradient region formed on the surface of the MEA
due to concentration polarization. SDE reaction only occurs on the
surface of MEA. With increasing electrolytic voltage, the chemical re-
action rate on the surface of the MEA accelerates so that the gap between
the SO2 concentration on the surface of the MEA and the solution body
expands rapidly, forming a concentration gradient of SO2 supply
shortage, thus forming a capacitor that can block direct current in the
local area.
3.2. Open-circuit voltage measurement
The open-circuit voltages of each cell are measured at different
anolyte flow rates and operating temperatures. At open-circuit voltage,
the electrolytic cells are of equilibrium state, and no polarization occurs
on the electrode. In the absence of an applied voltage, the measured
voltage of the electrolytic cell is considered to have two sources: 1)
hydrogen ions or other charged substances on anode side cross the MEA
into the cathode side, forming a concentration cell; 2) the occurrence of
the following side reactions at cathode side [20,21]:
SO2 + 4H+ + 4e− →S+ 2H2O E0 = 0.45V (7)
SO2 + 6H+ + 6e− →H2S+ 2H2O E0 = 0.35V (8)
Thus, the following two groups of REDOX pairs could form galvanic
cells.
Pt
⃒
⃒SO2(aq)
⃒
⃒SO2−
4 (aq) ‖ SO2(aq)
⃒
⃒S(s)
⃒
⃒Pt
Pt
⃒
⃒SO2(aq)
⃒
⃒SO2−
4 (aq) ‖ SO2(aq)
⃒
⃒H2S(aq)
⃒
⃒Pt
As the reversible potential of SO2 oxidation to SO4
2− in the standard
state is 0.158 V, according to electrochemical theory, the reversible
potentials of the above two galvano cells are approximately 0.292 V (i.e.
0.45 V - 0.158 V = 0.292 V). When the open circuit voltage is signifi-
cantly lower than the above value, the side effects can be considered to
be negligible.
Fig. 5 shows the open-circuit voltage of each electrolytic cell at
different anodic flow rates when the electrolytic temperature is 60◦C.
Under the same conditions, the open-circuit voltage increases with
increasing compression ratio of graphite felt in the electrolytic cell.
Whether charged particles such as H+ diffuse to the cathode or the
reduction side reaction of SO2 occurs at the cathode, trans-membrane
diffusion of materials is required. Therefore, the lower pole spacing is
beneficial to shorten the trans-membrane distance and strengthen the
trans-membrane diffusion effect. However, when the pole spacing is
compressed to a certain extent, the contribution of the shortening of pole
spacing to the enhancement of membrane crossing begins to signifi-
cantly decrease, which is reflectedin the same open-circuit voltage of
electrolytic cell C and electrolytic cell D under the same conditions.
Fig. 4. Equivalent circuit models
(a) model 1: low electrolytic voltage; (b) model 2: high electrolytic voltage.
Fig. 5. Open circuit voltages at 60 ◦C and different anolyte flow rates
(Cell A, rc = 20%; Cell B, rc = 28%; Cell C, rc = 40%; Cell D, rc = 48%).
X. Ding et al.
Electrochimica Acta 426 (2022) 140837
7
At the same time, when the anodic fluid flow rate is low (< 360 mL/
min), the open circuit voltage is significantly less than 0.192 V. When
the anodic fluid flow rate is relatively low, the side reaction can be
almost ignored. This is because when the anodic fluid flow rate is low,
the trans-membrane diffusion is weak, and the SO2 concentration of the
cathode is too low to form the side reaction galvanic cell.
Fig. 6 shows the open-circuit voltage of cell C at different tempera-
tures and anodic flow rates. At the same temperature, the larger the
anodic flow rate, the more significant the trans-membrane diffusion, the
higher the chemical potential of side reactions, and the higher the open-
circuit voltage. The effect of temperature on the open-circuit voltage is
twofold. On the one hand, an increase in temperature decreases the
solubility of SO2, the concentration of SO2 in the anodic solution and the
concentration gradient between the anode and cathode, which inhibits
diffusion across the membrane. On the other hand, the increase of
temperature will improve the mass transfer rate, so that SO2 cross the
membrane intensified, at the same time, the activity of MEA also in-
creases with the increase of temperature, so that the electrochemical
reaction rate is accelerated, improving the galvanic potential. Therefore,
under the same conditions, from 25 to 80◦C, the open-circuit voltage
shows a trend that it decreases at first and then increases. The highest
value of open-circuit voltage obtained on Cell C in this work is 0.287 V,
at 25◦C, and anolyte flow rate of 360 mL/min. This measured value is
very close to above mentioned theoretical value 0.292 V.
Therefore, for the SDE process, the total potential composition
relation described in Eq. (6) should be decomposed into:
U = Ueq + iRA + ηa + ηc + ηs (9)
where ηS represents the galvanic potential of side reactions in the SDE
process.
Because side reactions are detrimental to the SDE process, they need
to be avoided. To suppress the spontaneous reaction in the galvanic cell,
an initial voltage should be applied to the electrolytic cell before feeding
anolyte, and the initial voltage should be higher than the reversible
potential of the side reaction. This operation has two effects. First, from
a thermodynamic point of view, the initial voltage inhibits the side re-
actions. Second, in terms of kinetics, a higher voltage in advance can
accelerate the consumption rate of SO2 at the beginning of electrolysis,
reduce the concentration gradient of SO2 between the anode and cath-
ode, slowing down the diffusion rate across the membrane.
According to the highest value of open-circuit voltage obtained in
this work (0.287V) and the reversible potential of the SDE process, the
lowest working voltage of the SDE cells involved in this work should not
be less than 0.400 V.
3.3. EIS research under working voltage
3.3.1. Influence of electrolytic voltage
According to the selected working voltage after the open-circuit
voltage experiment, the impedance composition of each electrolytic
cell under different working voltages was measured. Fig. 7 shows the
impedance composition of electrolytic cells A – D at different electrolytic
voltages, 60◦C and 360 mL/min anolyte flow rate.
Ohm impedance is unchangeable at the same temperature and flow
rate, for a specific electrolytic cell. When the electrolytic voltage is low
(0.400 V), due to the extremely low rate of the SDE reaction, the SDE
process is applicable to equivalent circuit model 1, and the kinetics
impedance is dominant. When the electrolytic voltage rises, equivalent
circuit model 2 is applicable. In addition, due to the rapid SO2 con-
sumption rate in the initial stage of 1.20 V, the concentration of re-
actants on the surface of the catalytic layer drops sharply, increasing the
SO2 concentration difference between the catalytic layer and the solu-
tion body. At the same time, under the condition of a constant anodic
flow rate, the concentration of SO2 in the catalytic layer could not be
supplemented in a timely manner, resulting in a decrease in the elec-
trochemical reaction rate and an increase in the anodic kinetics
impedance.
3.3.2. Influence of compression ratio of graphite felt
Fig. 8 shows the impedance composition of electrolytic cells A – D at
1.00 V and anolyte flow rate of 360 mL/min. The total impedance order
of the 4 electrolytic cells is C < D < B < A, which is in good agreement
with the performance order of the 4 cells as illustrated by Fig. 9. For cell
A which has the lowest compression ratio of graphite felt, the anode
electrochemical impedance accounts for the highest proportion in the
total impedance. While in other 3 cells, the concentration polarization
impedance accounts for the highest proportion.
As shown in Fig. 8(a) The ohmic impedance measured at 60◦C is of
the order of cell A > cell B > cell D > cell C. The relationship between
the ohmic impedance and the compression ratio of graphite felt is as
follows: the ohmic impedance decreases first and then increases with the
increase in the compression ratio of graphite felt. At 80◦C, the ohmic
impedance of the electrolytic cell and the compression ratio of graphite
decrease and fluctuated slightly.
Ohm impedance can be considered to be composed of two parts, one
is the ohm impedance of the cell components, including the inherent
impedance of the components such as the graphite collector plate,
diffusion layer, catalytic layer and proton exchange membrane, and the
contact resistance caused by the contact between components. The other
is the ohm impedance of anolyte. As the graphite felt gradually com-
pressed the contact resistance decreased. At the stage when the contact
resistance was dominant, the compressed graphite felt could effectively
reduce the contact resistance, thus reducing the overall ohmic imped-
ance. When the compression ratio of graphite felt is greater than 40%,
the void ratio of graphite felt is significantly reduced, the flow space of
solution in the diffusion layer is significantly compressed, and even local
solution discontinuity occurs, which makes the solution impedance
significantly increased; thus, the overall ohmic impedance increases.
The kinetics impedance of the cathode decreases with increasing
compression ratio of the graphite felt. With the continuous compression
of graphite felt, the pole spacing shrinks, and the voltage gradient in-
creases at the same voltage. A higher potential on the catalytic layer
speeds up the reaction rate and reduces the electrochemical polarization
impedance.
Anodic kinetics impedance and concentration polarization imped-
ance need to be discussed as a whole because the two impedance
changes have a strong correlation. When the consumption rate of SO2
increases, the anode kinetics impedance decreases. However, the
Fig. 6. Open circuit voltages of cell C at different operating temperatures and
anolyte flow rates.
X. Ding et al.
Electrochimica Acta 426 (2022) 140837
8
Fig. 7. Impedance compositioncomparison of different electrolytic cells at different voltages, at 60◦C and anolyte flow rate 360 ml/min
(a) Cell A; (b) Cell B; (c) Cell C; (d) Cell D.
Fig. 8. Impedance composition comparison among different electrolytic cells
(a) 1.00 V, 60◦C, 360 ml/min; (b) 1.00 V, 80◦C, 360 ml/min.
X. Ding et al.
Electrochimica Acta 426 (2022) 140837
9
difference in SO2 concentration between the catalytic layer surface and
the solution body increases at the same time. When the concentration
difference increases to a certain extent, the concentration polarization
impedance will increase significantly.
Fig. 10 shows the change in the sum of the anode kinetics impedance
and concentration polarization impedance with the compression ratio of
graphite felt. The sum of impedance decreases first and then increases
with the increase of the compression ratio of graphite felt. This is mainly
caused by the change in the sufficient degree of anodic fluid distribution
caused by the increase in the compression ratio of graphite felt.
3.3.3. Influence of anodic fluid flow rate
Fig. 11 shows the impedance composition of cell C at different anodic
flow rates at 60◦C and 1.00 V voltage. Ohmic impedance is unchanged at
the same voltage and anolyte flow rate for a certain SDE cell. The ki-
netics impedance at the cathode is also constant because the concen-
tration of hydrogen ions in the cathode is considered to be sufficient and
much larger than that of other species. The kinetics impedance and
concentration polarization impedance at the anodes decrease with
increasing anodic flow, which is due to the increase in SO2 supply, which
not only accelerates the electrochemical reaction rate but also improves
the mass transfer.
3.3.4. Influence of electrolysis temperature
Fig. 12 shows the impedance composition of electrolytic cell C at
1.00 V, 360 mL/min anodic fluid flow rate, and different operating
temperatures. Since the resistance of membrane and electrolyte solution
increase with decreasing temperature, so the ohmic impedance is rela-
tively large at 25◦C. On the other hand, the catalyst and proton exchange
membrane are not fully activated at 25◦C, so the SDE is in the kinetic
control stage.
Model 2 applies to the SDE process at 60◦C and 80◦C. The cathodic
kinetics impedances at above two temperature points are approximately
the same. At 80◦C, the chemical reaction rate constant is relatively high
[22], thus consumption rate of the SO2 on catalytic layer is very fast.
While the SO2 solubility at this temperature is very low, leading to a
poor reactants supply to the catalytic layer. Thus, anode kinetics
impedance and concentration polarization impedance at 80◦C are both
greater than those at 60◦C. Above is consistent with the SDE perfor-
mance test results at different temperatures, as shown in Fig. 12.
Fig. 9. SDE performance of different electrolytic cells [16]
1.00 V, 60◦C, 360 ml/min; (b) 1.00 V, 80◦C, 360 ml/min.
Fig. 10. Comparison of R2+R4 in different cells
(a) 1.00 V, 60◦C, 360 ml/min; (b) 1.00 V, 80◦C, 360 mL/min.
X. Ding et al.
Electrochimica Acta 426 (2022) 140837
10
4. Conclusions
In this work, EIS technology is used to study the composition of cell
voltage of SDE electrolyzers with porous graphite felt as diffusing layers.
A close look is taken at the composition of overpotential. The influence
of graphite felt compression ratio and operating conditions on the SDE
cell voltage, together with the mechanism and control steps of SDE are
discussed. The internal reasons for the performance differences of the 4
electrolytic cells at different operating conditions are explained from the
perspectives of electrochemistry, in other words, EIS or impedance. The
following conclusions are obtained:
1) The transmembrane diffusion of SO2 leads to the formation of side
reaction galvanic cells possessing open circuit voltage up to 0.287 V.
To avoid these side reactions, it is necessary to apply a sufficiently
high cell voltage before feeding the cell with anolyte, such as 1.00
and 1.2 V, at which the side reactions (galvanic cells) are inhibited
thermodynamically, while the consumption rate of SO2 by the
expected reaction (oxidation of SO2 to H2SO4) is accelerated
dynamically, and SO2 crossover could be controlled effectively.
2) The SDE process is sensitive to cell voltage. At a lower operating
voltage such as 0.40 V and 0.70 V, the SDE process is in the kinetics
control state, and the impedance mainly consists of ohm impedance
and anode electrochemical polarization impedance. At higher oper-
ating voltage, the SDE process is transferred to the combined control
stage of kinetics and mass transfer, and the impedance includes ohm
impedance, anode and cathode kinetics impedance, and concentra-
tion polarization impedance.
3) Graphite felt compression ratio, anolyte flow rate, and operating
temperature have great effects on the different component of the
impedance, consequently show a complex influence on the SDE
performance. Increasing graphite felt compression ratio will
decrease the ohm impedance of the felt, while increase that of
electrolyte. Anolyte flow rate has little effect on ohm impedance and
cathodic kinetics impedance, while the kinetics impedance and
concentration polarization impedance at the anodes decrease with
increasing anolyte flow ratio. Increasing temperature can decrease
the ohm impedance effectively, while at 80◦C, poor SO2 solubility
causes the obvious rise of anode kinetics impedance and concentra-
tion polarization impedance, bring out the degradation of SDE
performance.
CRediT authorship contribution statement
Xifeng Ding: Methodology, Conceptualization, Data curation,
Writing – original draft. Songzhe Chen: Methodology, Data curation,
Writing – review & editing. Laijun Wang: Investigation, Validation,
Supervision. Ping Zhang: Conceptualization, Methodology, Writing –
review & editing.
Declaration of Competing Interest
The authors declare that they have no known competing financial
interests or personal relationships that could have appeared to influence
the work reported in this paper.
Data availability
The data is available upon request.
Acknowledgment
This work was financially supported by the National Key R & D
Program of China (Grant No. 2018YFE0202001), the Chinese National
Science & Technology Major Project (Grant No. ZX06901), and the
Tsinghua University Initiative Scientific Research Program.
References
[1] Fuel Cells Technology Office, US Department of Energy. H2@Scale: enabling
affordable, reliable, clean, and secure energy across sectors. 2019.
[2] A. Midilli, I. Dincer, Hydrogen as a renewable and sustainable solution in reducing
global fossil fuel consumption, Int. J. Hydrogen Energy 33 (2008) 4209.
[3] B. Yildiz, M.S. Kazimi, Efficiency of hydrogen production systems using alternative
nuclear energy technologies, Int. J. Hydrogen Energy 31 (2006) 77.
[4] S. Kasahara, S. Kubo, R. Hino, Flowsheet study of the thermochemical water-
splitting iodine-sulfur process for effective hydrogen production, Int. J. Hydrogen
Energy 32 (2007) 489.
[5] M.A. Rosen, Advances in hydrogen production by thermochemical water
decomposition: a review, Energy 35 (2010) 1068.
[6] L.E. Brecher, C.K. Wu, Electrolytic Decomposition of Water, Westinghouse Electric
Corp., United States of America, 1975, p. 13.
[7] P.W. Lu, E.R. Garcia, R.L. Ammon, Recent developments in the technology of sulfur
dioxide depolarizedelectrolysis, J. Appl. Electrochem. 11 (1981) 347.
[8] M. Venturin, L. Turchetti, R. Liberatore, Uncertainty quantification in a hydrogen
production system based on the solar hybrid sulfur process, Int. J. Hydrogen
Energy 45 (2020) 14679.
Fig. 11. Impedance composition of electrolytic Cell C at 60◦C, 1.00 V and
different anodic fluid flow rates.
Fig. 12. Impedance composition and SDE performance of electrolytic cell C at
different temperatures and 1.00 V, 360 ml/min.
X. Ding et al.
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0002
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0002
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0003
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0003
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0004
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0004
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0004
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0005
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0005
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0006
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0006
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0007
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0007
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0008
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0008
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0008
Electrochimica Acta 426 (2022) 140837
11
[9] M.B. Gorensek, J.A. Staser, T.G. Stanford, J.W. Weidner, A thermodynamic analysis
of the SO2/H2SO4 system in SO2-depolarized electrolysis, Int. J. Hydrogen Energy
34 (2009) 6089.
[10] A.J. Bard, R. Parsons, J. Jordan, Standard Potentials in Aqueous Solution, Marcel-
Dekker, Inc., New York, 1985, p. 102.
[11] R.G. Taylor, H.W. Cody, T.P. Andrew, M. Jacob, G. Alex, C.B. Brian, J.W. Weidner,
Characterizing voltage losses in an SO2 depolarized electrolyzer using sulfonated
polybenzimidazole membranes, J. Electrochem. Soc. 164 (2017) F1591.
[12] L. Tânia, A. Luı́sa, A.R. Helena, M. Adélio, Characterization of
photoelectrochemical cells for water splitting by electrochemical impedance
spectroscopy, Int. J. Hydrogen Energy 35 (2010) 11601.
[13] L. Xue, P. Zhang, S. Chen, L. Wang, In-situ electrochemical impedance
spectroscopy measurement of anodic reaction in SO2 depolarized electrolysis
process, Chem. Eng. Process. 89 (2015) 70.
[14] L. Xue, P. Zhang, S. Chen, L. Wang, Quantitative analysis of the cell voltage of SO2-
depolarized electrolysis in hybrid sulfur process, Nucl. Eng. Des. 306 (2016) 203.
[15] H.R. Colόn-Mercado, M.B. Gorensek, C.H. Fujimoto, A.A. Lando, B.H. Meekins,
High-performance SO2-depolarized electrolysis cell using advanced polymer
electrolyte membranes, Int. J. Hydrogen Energy 34 (2022) 57.
[16] X. Ding, S. Chen, P. Xiao, L. Wang, P. Zhang, SO2-depolarized electrolysis using
porous graphite felt as diffusion layer in proton exchange membrane electrolyzer,
Int. J. Hydrogen Energy 47 (2022) 2200.
[17] J.A. Staser, M.B. Gorensek, J.W. Weidner, Quantifying individual potential
contributions of the hybrid sulfur electrolyzer, J. Electrochem. Soc. 157 (2010)
B952.
[18] J.A. Staser, K. Norman, C.H. Fujimoto, M.A. Hickner, J.W. Weidner, Transport
properties and performance of polymer electrolyte membranes for the hybrid sulfur
electrolyzer, J. Electrochem. Soc. 156 (2009) B842.
[19] E.B. Easton, P.G. Pickup, An electrochemical impedance spectroscopy study of fuel
cell electrodes, Electrochim. Acta 50 (2005) 2469.
[20] A. Santasalo, J. Virtanen, M. Gasik, SO2 carry-over and sulphur formation in a SO2-
depolarized electrolyser, J. Solid State Electrochem. 20 (2016) 1655.
[21] J.L. Steimke, T.J. Steeper, H.R. Colόn-Mercado, M.B. Gorensek, Development and
testing of a PEM SO2-depolarized electrolyzer and an operating method that
prevents sulfur accumulation, Int. J. Hydrogen Energy 40 (2015) 13281.
[22] H.R. Colόn-Mercado, D.T. Hobbs, Catalyst evaluation for a sulfur dioxide-
depolarized electrolyzer, Electrochem. Commun. 9 (2007) 2649.
X. Ding et al.
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0009
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0009
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0009
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0010
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0010
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0011
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0011
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0011
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0012
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0012
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0012
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0013
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0013
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0013
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0014
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0014
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0015
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0015
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0015
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0016
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0016
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0016
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0017
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0017
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0017
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0018
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0018
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0018
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0019
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0019
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0020
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0020
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0021
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0021
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0021
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0022
http://refhub.elsevier.com/S0013-4686(22)00996-3/sbref0022
	Study on electrochemical impedance spectroscopy and cell voltage composition of a PEM SO2-depolarized electrolyzer using gr ...
	1 Introduction
	2 Experimental section
	2.1 Chemicals and test solution
	2.2 Electrolyzers and experiment apparatus
	2.3 EIS test method
	2.4 Equivalent circuit fitting
	3 Results and discussion
	3.1 Establishment of equivalent circuit model
	3.2 Open-circuit voltage measurement
	3.3 EIS research under working voltage
	3.3.1 Influence of electrolytic voltage
	3.3.2 Influence of compression ratio of graphite felt
	3.3.3 Influence of anodic fluid flow rate
	3.3.4 Influence of electrolysis temperature
	4 Conclusions
	CRediT authorship contribution statement
	Declaration of Competing Interest
	Data availability
	Acknowledgment
	References
