Effects of water-unextractable arabinoxylan from wheat processing
wastewater on the quality characteristics of multigrain bread
Sihai Han a,b, Yanbin Wang a, Yunhui Zhang a, Honglin Lan a, Xingguo Li a, Jiahao Wan a,
Chonghui Yue a, Junwei Feng c, Denglin Luo a,b, Zhouya Bai a,b,*
a College of Food and Bioengineering, Henan University of Science and Technology, 471023, Luoyang, Henan, China
b Henan Food Raw Material Engineering Technology Research Center (Henan University of Science and Technology), Luoyang, 471023, China
c Henan Feitian Biotechnology Co., Ltd., Hebi, 456750, China
A R T I C L E I N F O
Keywords:
Arabinoxylan
Wheat processing wastewater
Water-unextractable arabinoxylan
Substitution
Functional bread
A B S T R A C T
The water-unextractable arabinoxylan (WUAX) was extracted from the wheat processing wastewater to replace
the flour in the bread formula and improve the quality characteristics of the multigrain bread. We investigated
the effects of WUAX substitution concentration (0, 2.5, 5, 7.5 and 10 g/100 g high gluten flour weight) on
multigrain bread texture, microstructure, color difference variation, relative crystallinity, moisture distribution,
and sensory evaluation. Within the specified range, the bread hardness increased by 4.0 N, a negative effect on
the bound water in bread and significant changes in the color difference were observed. The optimal substitution
level was 7.5%, increasing the crude fiber content by 33% (dry weight ratio) and reducing the starch content by
10%, maintaining the specific volume and hardness similar to the control group. The scanning electron micro-
scopy X-ray diffraction (XRD) measurements showed that WUAX affected the aggregation of protein and starch,
and reduced the relative crystallinity of bread, retarding bread staling. The WUAX replacing flour (7.5%
replacement level) also provided good sensory evaluation. Overall, WUAX boosts bread’s dietary fiber content
while lowering its starch proportion. Although WUAX had negatively impact on bread texture, a 7.5% substi-
tution level could minimize these effects. This study offered insights for the dietary applications of WUAX from
wheat processing wastewater.
1. Introduction
The history of wheat cultivation in China can be traced back to the
Neolithic period. With the continuous improvement of varieties and the
promotion of ancient rulers, wheat has had a profound influence on
China’s agricultural industrial structure, people’s diet structure and
culture. In the process of wheat processing, a large amount of high-
concentration organic wastewater is produced from the washing, pres-
sure filtration, concentration and other process steps. The wastewater
contains a lot of soluble organic matter, such as starch, sugar, fat, amino
acids, inorganic substances, etc (Bai & Lan, 2024; Geng and Li et al.,
2024). Among them, arabinoxylan (AX) is a highly researched
non-starch polysaccharide, which has been widely used as nutritional
supplement to regulate the quality of flour products (Li and Li et al.,
2023).
Arabinoxylan mainly consists of a 1,4-linked pyran xylose residue
backbone with random O-2, O-3, or O-2 and O-3 arabinose substitutions,
and can be classified as water-extractable arabinoxylan (WEAX) and
water-unextractable arabinoxylan (WUAX) (Pandeirada and Merkx
et al., 2021). The content of WUAX in wheat processing wastewater is
much greater than that of WEAX, and has the possibility of extraction in
large quantities. The extraction of WUAX from wheat processing
wastewater offers a unique opportunity for both environmental reme-
diation and economic benefits (Li, Li & et al, 2023), and could develop a
source of valuable dietary fiber for various functional food applications
(Asif & Khan, 2014).
Bread is a staple food around the world, and has become a symbol of
cultural diversity and culinary craftsmanship. Each country and region
boast its own unique bread variety, reflecting local climate, agricultural
conditions, and historical-cultural influences that have shaped the
people’s taste preferences (Gao & Zhou, 2021). In recent years, the
functionally fortified breads have received increased interests. There
have been many novel functional breads, such as moringa seeds fortified
bread (Bolarinwa and Aruna et al., 2019), bee pollen bread (Conte and
* Corresponding author. College of Food and Bioengineering, Henan University of Science and Technology, 471023, Luoyang, Henan, China.
E-mail address: spbaizhouya@163.com (Z. Bai).
Contents lists available at ScienceDirect
LWT
journal homepage: www.elsevier.com/locate/lwt
https://doi.org/10.1016/j.lwt.2024.116867
Received 31 July 2024; Received in revised form 24 September 2024; Accepted 5 October 2024
LWT - Food Science and Technology 210 (2024) 116867
Available online 9 October 2024
0023-6438/© 2024 The Authors. Published by Elsevier Ltd. This is an open access article under the CC BY-NC-ND license ( http://creativecommons.org/licenses/by-
nc-nd/4.0/ ).
mailto:spbaizhouya@163.com
www.sciencedirect.com/science/journal/00236438
https://www.elsevier.com/locate/lwt
https://doi.org/10.1016/j.lwt.2024.116867
https://doi.org/10.1016/j.lwt.2024.116867
http://crossmark.crossref.org/dialog/?doi=10.1016/j.lwt.2024.116867&domain=pdf
http://creativecommons.org/licenses/by-nc-nd/4.0/
http://creativecommons.org/licenses/by-nc-nd/4.0/
Del et al., 2018), olive pulp bread (AlJuhaimi and Ahmed et al., 2024),
and bread with sheep whey powder (Secchi and Fadda et al., 2018).
With the rise of health consciousness, consumers are paying more
attention to the nutritional value of bread. Whole-grain bread, enriched
with fiber and essential nutrients, has become a popular choice (Mir and
Farooq et al., 2022). The baking process has also undergone innovations
to reduce the energy content while maintaining the flavor and texture
(Kikuchi and Nozaki et al., 2018). Furthermore, the combination of
traditional baking methods with modern technology has given birth to a
range of innovative bread products. From gluten-free options for those
with dietary restrictions to low-sugar and high-fiber varieties for
health-conscious consumers, the possibilities are endless.
AX is a natural dietary fiber with many bioactivities such as regu-
lating intestinal microbiota (Paesani et al., 2020), reducing risk of type 2
diabetes (Pereira et al., 2021) and enhancing immunomodulation
(Zhang, Yang, Zhou, Shen, & Hu, 2021). In recent years, AXs have been
applied to improve the quality of flour baking products (Bieniek &
Buksa, 2024). It was reported that WEAX could improve the viscoelas-
ticity of gluten in dough while WUAX could induce fragile discontinuous
structure of gluten (Li & Li et al., 2023). It was also reported that both
WEAX and WUAX could impart positive influence on dough properties
by increasing the water absorption capacities of flours and enhancing
the stability of dough, and that WEAX could improve physical and
sensory attributes of bread while WUAX exhibited negative effects (Arif,
Ahmed, Chaudhry, & Hasnain, 2018). However, WUAX was a valuable
dietary fiber with high content and availability, and could provide many
health benefits such as regulating short-chain fatty acid in the colon,
enhancing antioxidant capacity, and reducing blood glucose response
(Huang & Bai et al., 2024).
Most studies about effects of WUAX on bread properties were per-
formed using the WUAX extracted from cereals, and few of them
employed the WUAX from wheat processing wastewater. Therefore, the
objective of this work is to evaluate the feasibility of fortifying a func-
tional bread with WUAX isolated from wheat processing wastewater.
The effect of WUAX on multigrain bread texture, microstructure, color
difference variation, moisture distribution, staling properties, as well as
sensory evaluation, was investigated, which provided a scientific sup-
port for the application of WUAX in baking products.
2. Materialsand methods
2.1. Preparation of WUAX
The WUAX with particle size less than 100 mesh was extracted from
wheat processing wastewater (produced by Henan Feitian Agriculture
Development Co., Ltd., Hebi City, China). The wheat processing
wastewater was centrifuged at 4000 rpm for 15 min, and the sediment
was obtained. The WUAX was extracted from the sediment with an
alkaline solution (pH 12) at 65 ◦C for 3 h. The extraction solution was
adjusted to pH 7, standing for 2 h, then was centrifuged to obtain the
supernatant. Subsequently, the WUAX was purified from the superna-
tant by condensing (to 1/20 of original volume) with rotary evapora-
tion, dialyzing at 4 ◦C for 24 h, and vacuum freeze-drying (− 20 ◦C for 24
h) in sequence.
2.2. Bread making process
The high gluten flour and red kidney bean powder were purchased
from Yihai Wheat Co., Ltd. (Henan, China). The butter was purchased
from Jinshan Branch of Inner Mongolia Yili Industrial Group Co., Ltd
(Inner Mongolia, China). The sugar (purity 99.5%) was purchased from
Rizhao Lingyunhai Sugar Co., Ltd (Nanjing, China). The active dry yeast
was purchased from Anqi yeast Co., Ltd (Hubei, China).
The WUAX was used instead of 2.5%, 5%, 7.5% and 10% of wheat
flour (dry basis, w/w) for bread making, respectively. The blank control
group was made using the same bread formula without the WUAX
substitution. The base formulation of bread included 100g of high gluten
flour, 20 g of egg mixture, 10 g of red kidney bean powder, 10 g of broad
bean flour, 10 g of oat flour, 10 g of buckwheat flour, 10 g of gluten
flour, 8 g of butter, 10 g of white sugar, 1.8 g of dry yeast and 60 g of
water.
The formulation ingredients were mix thoroughly and kneaded for
20 min with a multifunctional chef machine (PE4680, Guangdong Liran
Electric Appliance Industry Co., Ltd., Guangdong, China). The dough
transferred into molds for a brief relaxation period, following a
fermentation at 37 ◦C and 80% relative humidity for 90 min in a
fermentation chamber (FJX-16, Guangdong Demas Intelligent Kitchen
Equipment Co., Ltd. Guangdong, China). After fermentation, the molds
with dough were baked in a preheated (160 ◦C) oven (SM 522, Xinmai
Machinery Co., Ltd.) and baked with temperature 150 ◦C (top and bot-
tom) for 10 min.
2.3. Determination of specific volume and porosity of bread
The specific volume of bread samples (cm3/g) was determined using
the reference method (Wang and Chen et al., 2017). The bread core part
with uneven pores in the bread was not used as the determination
sample. The Image J software was used for the bread picture processing
and the data calculation (Han and Liu et al., 2024). The results were
presented as images and porosity values.
2.4. Color analysis
The color difference measurement referred to literature
(Iglesias-Puig & Haros, 2013) with minor modifications. A square bread
sample (20✕20✕20 mm3) was taken from the center of the bread core.
The color values were measured using a colorimeter (X-rite color i5,
USA) with a pulse xenon lamp illuminant and di:8◦ measurement ge-
ometry. The color values determined included L*, a* and b*
(García-Hernández and Roldan-Cruz et al., 2023), which represent
brightness (0 for black, 100 for white), red-green degree (-a for green,
+a for red), and yellow-blue degree (-b for blue, +b for yellow),
respectively. The total color change (ΔE) was calculated using formula
(1).
ΔE=
̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅
(ΔL*)2
+ (Δa*)2
+ (Δb*)2
√
(1)
2.5. Texture profile analysis (TPA)
The texture characteristics of the bread were determined by the
professional texture analyzer (TA.XT. Express, Stable Micro Systems,
UK) equipped with a P/75 probe. to ensure the stable and reliable re-
sults. The bread sample was cut into a square (20✕20 ✕20 mm), and
determined with trigger force of 5 g, compression ratio 50%, early
extrusion rate of 12 mm/s and 2 mm/s in middle-late stages (Li &
Gidley, 2022; Liu, Liu, Huang, & Zhang, 2021). The interval of extrusion
was 1 s. The results were expressed in terms of hardness, springiness and
other data.
2.6. X-ray diffraction (XRD) analysis
Grilled freeze-dried bread samples were analyzed using an X-ray
diffractometer. The sample powder was tested at 40 mA, 40 kV, and
room temperature. Diffraction angle ranged from 5◦ to 40◦, scanned at
5◦/minute. The crystal properties of the peak and amorphous regions
were analyzed using the Origin software, and the relative crystallinity
was calculated using the crystal formula TC = lc/(lc + la). The results
were presented as crystallinity data.
S. Han et al. LWT 210 (2024) 116867
2
2.7. Moisture mobility and distribution determination (LF-NMR)
The water distribution of the bread was determined using a low-field
nuclear magnetic resonance instrument (LF-NMR, NMI 20-015 V-I,
Shanghai Newmarket Electronics Technology Co., Ltd., China). The in-
strument mainly determines the moisture content of three different
binding states by measuring the lateral relaxation time of the bread. The
proportion of bound water, weakly bound water, and free water was
determined. Experiments were performed at 32 ◦C, with each sample
weight set to 1.5 g, and placed evenly in a glass bottle with a sampling
frequency of 200 kHz and a sampling interval of 3500 ms. The results
were expressed in terms of relaxation time and inverse peak area of NMR
images.
2.8. Scanning electron microscopy (SEM) analysis
The protein and starch microstructure of bread were studied by
electron scanning microscopy (TM3030Plus desktop scanning electron
microscope: Hitachi, Japan). The bread was cut into large pieces and
then sprayed with gold. Images were taken at a magnification of 400 and
1000. The results were shown as SEM images.
2.9. Analysis of physicochemical properties of bread
The protein, fat, crude fiber, starch content and water absorption
rate of bread were analyzed. Protein content was determined by Kjeldahl
method (Qi and Li et al., 2013). Chloroform methanol measurement was
used to measure fat (Elliott & Elliott, 2016). The determination of crude
fiber was carried out using an acid-based solution method, taking
advantage of the insolubility of cellulose in weak acids and bases (Taus
and Tahuk et al., 2022). The starch content was measured with anthrone
colorimetry kit (Nanjing Jiancheng Bioengineering Institute). Water
absorption was analyzed as described in literature (Liu, Liu, & Huang
et al., 2021). The results were presented in bar charts.
2.10. Sensory evaluation of bread
The sensory evaluation of bread samples was performed by a panel of
10 trained panelists (5 males and 5 females, mean ages: 20–55 years)
complying with National Bread Sensory Evaluation Standard GB/T
20981-2021 of China (Han and Liu et al., 2024). All the panelists were
from the College of Food and Bioengineering, Henan University of Sci-
ence and Technology. The informed consent from the participants was
obtained. The sensory evaluation was carried out in a spacious and clean
room with 360 Lx brightness, relative humidity 75%, and temperature
25 ◦C. The bread was cut into slice (1 × 1 × 2 cm) and placed in a white
porcelain plate randomly encoded. The order of tasting was random.
Mouth rinsing was performed after each test and at 5-min intervals. The
panelists were asked to rate and give score for different sensory pa-
rameters including shape (15 points), crust color (15 points), crumb
color (15 points), texture (20 points), flavor/taste (20 points), impurity
(15 points). The results were presented with the sum of the sensory
evaluation score.
2.11. Statistical analysis
All experiments were conducted in triplicate, and the results were
reported as mean ± standarddeviation (SD). Correlation and signifi-
cance analyses of the indicators were performed using SPSS software.
The significance of the difference between control and treatment sam-
ples was assessed using the least significant difference (LSD) at pof crude WUAX substitution on the structural characteristics of bread.
Hardness
(N)
Springiness Gumminess Chewiness Resilience
Control 8.3394 ±
0.21c
0.92 ±
0.09a
416.99 ±
27.87d
395.99 ±
9.78c
0.22 ±
0.01b
WUAX
2.5%
11.4179
± 0.30ab
0.88 ±
0.07ab
675.08 ±
16.25c
590.54 ±
29.89 b
0.22 ±
0.00b
WUAX
5%
10.5035
± 0.94b
0.82 ±
0.00ab
823.15 ±
32.09a
708.14 ±
49.27a
0.20 ±
0.00c
WUAX
7.5%
10.7555
± 0.87b
0.86 ±
0.00ab
632.05 ±
17.30c
544.94 ±
17.25b
0.24 ±
0.00a
WUAX
10%
12.3233
± 0.36a
0.80 ±
0.01b
750.40 ±
39.20b
591.68 ±
42.18b
0.22 ±
0.01bc
The data were expressed mean ± standard deviation (SD) (n = 3). Means within
a row with different superscript letters are significantly different (pwas high. Both T22 and T21 achieved a minimum at a substitution value
of 7.5%. Compared with the control group, all the A21 (indicating the
content of bound water) of breads with WUAX addition showed a
downward trend, indicating that WUAX had a negative effect on the
binding water in bread. The A22 (indicating the weakly bound water
content) values had no significant difference between the WUAX sub-
stitution group and the control. With the WUAX addition increased, the
A23 (indicating the content free water) showed a growth trend, and had a
minimum growth at 7.5% substitution level. Compared with the other
substitution proportions, the 7.5% WUAX substitution level had the least
negative effect on the moisture distribution in bread.
3.5. Effect of WUAX addition on bread microstructure
The microstructure of the bread samples with WUAX and without
WUAX was analyzed by scanning electron microscopy (SEM) compari-
son. SEM micrographs of bread cores of compound bread supplemented
with different proportions of WUAX are shown (Fig. 4). Compared with
the control, the breads with WUAX addition had rough edges, local
structure destruction and debris. This was due to the entanglement of
gluten protein molecules, which hinders the formation of gluten
network. WUAX has long molecular chains and many branches that may
wrap around the gluten structure and organize it to form larger gluten
polymers. As the substitution amount of WUAX increases, the ability of
starch to bind between proteins decreases, because the high molecular
weight of WUAX leads to a large steric hindrance, forming a physical
barrier to the starch exposed outside of the gluten structure (Ling, Wang
et al., 2017). In order to more clearly observe the differences between
bread structures, SEM micrographs of the same dough magnified by
1000× were shown. It could be seen that there were more cracks in the
bread after the increase of substitution, and the surface became rougher
and irregular, and some filamentous structures and discontinuous gluten
networks appeared. This indicated that the substitution of WUAX
destroyed the gluten network structure and made the starch exposed,
which leaded to the poor quality of the bread.
3.6. Analysis of physicochemical properties of bread
Starch content is an important indicator of the energy source of food.
Food with higher starch content will generally have a higher glycemic
index, which is unfavorable for those who need to control blood sugar.
In bread with WUAX substitution (2.5%, 5%, 7.5%, 10% substitution for
flour), the starch content is much less than that of high-gluten flour
bread. When the WUAX substitution level was 10%, the starch content
reached the lowest value, which was about 12% lower than that of the
control group (Fig. 5). The amount of dietary fiber in bread increased
with WUAX substitution and reaching a minimum at 10%, about 35%
higher than that in the blank control group. The protein content also
decreased, achieving the lowest value at 10%, which was about 3%
lower compared to the blank control group. There were no significant
changes in fat content or water absorption. Water absorption could
reflect the quality characteristics of bread from the side. The addition of
AX increased the water absorption of bread (Koegelenberg & Chim-
phango, 2017). De Bondt and Hermans et al. studied the addition of
modified bran to bread and found that bran addition caused a greater
effect than water absorption (De Bondt and Hermans et al., 2021). The
effect of WUAX addition was greater than the effect of water absorption
on bread quality. Natal and de Souza Dantas et al. investigated the effect
of adding whole soybean flour to potato bread on its physicochemical
properties and found that the content of protein, dietary fiber, and the
minerals calcium, zinc, magnesium, copper, and phosphorus increased
as the concentration of soybean flour increased (Natal and de Souza
Dantas et al., 2013). The physicochemical data of the bread changed
mainly because of the different levels of nutrients contained in the added
functional ingredients. The water absorption rate of WUAX substituted
breads did not change significantly compared to the control group.
Generally speaking, the stronger water absorption, the stronger the
ability of bread to maintain its own combined water, the better the
quality of bread (Schopf & Scherf, 2021).
The starch in bread is mainly derived from the high gluten flour used
in the formula, and the starch content can be effectively reduced by
replacing the high gluten flour with WUAX in bread. The main purpose
is to reduce the fast digestion of starch in the bread. Fast-digestible
Table 3
Effect of crude WUAX on the lateral relaxation time (T2) and peak area (A2).
Group T21 T22 T23 A21 A22 A23
Control 0.21 ±
0.02ab
4.04 ±
0.00a
75.65 ±
0.00a
16.76 ±
0.36a
72.52
± 0.35a
10.45 ±
0.32c
WUAX
2.5%
0.20 ±
0.02b
3.86 ±
0.30ab
75.65 ±
5.69ab
16.16 ±
0.69a
71.97
± 0.58a
11.32 ±
0.35b
WUAX
5%
0.21 ±
0.02ab
4.24 ±
0.35a
75.65 ±
0.00a
15.76 ±
0.71b
72.04
± 1.07a
11.85 ±
0.22a
WUAX
7.5%
0.19 ±
0.00b
3.51 ±
0.00b
65.79 ±
0.00b
14.56 ±
0.63ab
73.15
± 0.65a
11.53 ±
0.06ab
WUAX
10%
0.23 ±
0.02a
4.04 ±
0.00a
75.65 ±
5.69ab
15.59 ±
0.79ab
72.10
± 0.28a
11.77 ±
0.16ab
The data were expressed mean ± standard deviation (SD) (n = 3). Means within
a row with different superscript letters are significantly different (pcertain health
benefits that outweigh the sensory drawbacks. This balance between
Fig. 5. The texture of bread (A), (B), (C), (D), (E), (F), they represent the starch content, fiber content, protein content, color content, color difference, water ab-
sorption and fat content of 0%, 2.5%, 5%, 7.5% and 10% WUAX replaced bread, respectively. *pW. (2021). Oral processing of bread: Implications of designing healthier
bread products. Trends in Food Science & Technology, 112, 720–734. https://10.1016
/j.tifs.2021.04.030.
García-Hernández, A., Roldan-Cruz, C., et al. (2023). Stale bread waste recycling as
ingredient for fresh oven-baked white bread: Effects on dough viscoelasticity, bread
molecular organization, texture, and starch digestibility. Journal of the Science of
Food and Agriculture, 103, 4174–4183. https://10.1002/jsfa.12442.
Geng, M., Li, J., et al. (2024). Recycling of wheat gluten wastewater: Separation,
characterisation, and solution rheology of arabinoxylans. International Journal of
Food Science and Technology, 59, 1852–1863. https://10.1111/ijfs.16937.
Han, S., Liu, X., et al. (2024). Quality and staling characteristics of wheat bread improved
by adding Eucommia ulmoides oliver leaf micropowder. LWT-food Science &
Technology, 198, Article 116008. https://10.1016/j.lwt.2024.116008.
Hopkins, E. J., Newling, B., et al. (2019). Water mobility and association by 1H NMR and
diffusion experiments in simple model bread dough systems containing organic
acids. Food Hydrocolloids, 95, 283–291. https://10.1016/j.foodhyd.2019.04.018.
Huang, M., Bai, J., Buccato, D. G., Zhang, J., He, Y., Zhu, Y., et al. (2024). Cereal-derived
water-unextractable arabinoxylans: Structure feature, effects on baking products and
human health. Foods, 13(15), 2369. https://doi.org/10.3390/foods13152369.
Iglesias-Puig, E., & Haros, M. (2013). Evaluation of performance of dough and bread
incorporating chia (Salvia hispanica L.). European Food Research and Technology, 237,
865–874. https://10.1007/s00217-013-2067-x.
Jiang, Z., Liu, L., et al. (2018). Improving the physicochemical properties of whole wheat
model dough by modifying the water-unextractable solids. Food Chemistry, 259,
18–24. https://10.1016/j.foodchem.2018.03.093.
Kikuchi, Y., Nozaki, S., et al. (2018). Effects of whole grain wheat bread on visceral fat
obesity in Japanese subjects: A randomized double-blind study. Plant Foods for
Human Nutrition, 73, 161–165. https://10.1007/s11130-018-0666-1.
Koegelenberg, D., & Chimphango, A. F. A. (2017). Effects of wheat-bran arabinoxylan as
partial flour replacer on bread properties. Food Chemistry, 221, 1606–1613.
https://10.1016/j.foodchem.2016.10.130.
Lagrain, B., Leman, P., et al. (2008). Impact of thermostable amylases during bread
making on wheat bread crumb structure and texture. Food Research International, 41,
819–827. https://10.1016/j.foodres.2008.07.006.
Li, C. (2022). Recent progress in understanding starch gelatinization - an important
property determining food quality. Carbohydrate Polymers, 293, 119735. https://10.
1016/j.carbpol.2022.119735.
Li, C., Dhital, S., et al. (2022). High-amylose wheat bread with reduced in vitro digestion
rate and enhanced resistant starch content. Food Hydrocolloids, 123, Article 107181.
https://10.1016/j.foodhyd.2021.107181.
Li, C., & Gidley, M. J. (2022). Starch structure and exchangeable protons contribute to
reduced aging of high-amylose wheat bread. Food Chemistry, 385, Article 132673.
https://10.1016/j.foodchem.2022.132673.
Li, C., & Hu, Y. (2020). Combination of parallel and sequential digestion kinetics reveals
the nature of digestive characteristics of short-term retrograded rice starches. Food
Hydrocolloids, 108, Article 106071. https://10.1016/j.foodhyd.2020.106071.
Li, F., Li, T., et al. (2023). Unraveling the deterioration mechanism of dough during
whole wheat flour processing: A case study of gluten protein containing
S. Han et al. LWT 210 (2024) 116867
8
https://10.1016/j.foodres.2021.110477
https://10.1111/ijfs.17133
https://10.1016/j.lwt.2018.07.066
https://10.1016/j.lwt.2018.07.066
https://10.1080/19443994.2014.990927
https://10.1080/19443994.2014.990927
https://doi.org/10.1016/j.fochx.2024.101415
https://10.3390/FOODS13162482
https://10.1016/j.jssas.2017.05.002
https://10.1016/j.lwt.2017.12.002
https://10.1016/j.lwt.2010.11.021
https://10.3390/foods13030478
https://10.1016/j.foodhyd.2020.106348
https://10.1016/j.lwt.2022.113079
https://10.1016/j.jembe.2015.09.017
https://10.1016/s0144-8617(97)00247-6
https://10.1016/j.tifs.2021.04.030
https://10.1016/j.tifs.2021.04.030
https://10.1002/jsfa.12442
https://10.1111/ijfs.16937
https://10.1016/j.lwt.2024.116008
https://10.1016/j.foodhyd.2019.04.018
https://doi.org/10.3390/foods13152369
https://10.1007/s00217-013-2067-x
https://10.1016/j.foodchem.2018.03.093
https://10.1007/s11130-018-0666-1
https://10.1016/j.foodchem.2016.10.130
https://10.1016/j.foodres.2008.07.006
https://10.1016/j.carbpol.2022.119735
https://10.1016/j.carbpol.2022.119735
https://10.1016/j.foodhyd.2021.107181
https://10.1016/j.foodchem.2022.132673
https://10.1016/j.foodhyd.2020.106071
arabinoxylan with different molecular weights. Food Chemistry, 432, Article 137199.
https://10.1016/j.foodchem.2023.137199.
Ling, L., Wang, W., et al. (2017). Effects of water-unextractable arabinoxylans on the
physicochemical and rheological properties of traditional Chinese youtiao.
International Journal of Food Science and Technology, 53, 962–968. https://10.1111/i
jfs.13669.
Liu, Y., Liu, M., Huang, S., & Zhang, Z. (2021). Optimisation of the extrusion process
through a response surface methodology for improvement of the physical properties
and nutritional components of whole black-grained wheat flour. Foods, 10, 437.
https://10.3390/foods10020437.
Liu, H., Xing, Y., et al. (2023). Quality deterioration of frozen dough bread during
terminal freezing and thawing: From the insight of moisture and starch properties.
Food Bioscience, 56, Article 103435. https://10.1016/j.fbio.2023.103435.
Luo, D., Li, X., et al. (2023). Effect of arabinoxylan from wastewater generated during
vital wheat gluten production on liver metabolism in type 2 diabetic mice. Foods, 12,
2640. https://10.3390/foods12142640.
Mir, S. A., Farooq, S., et al. (2022). Recent advancements in the development of
multigrain bread. Cereal Chemistry, 100, 72–82. https://10.1002/cche.10578.
Natal, D. I. G., de Souza Dantas, M. I., et al. (2013). Physical and sensorial properties of
potato breads fortified with whole soybean flour. Revista Chilena de Nutricion, 40,
62–70. https://10.4067/s0717-75182013000100010.
Nishitsuji, Y., Whitney, K., Nakamura, K., Hayakawa, K., & Simsek, S. (2020). Changes in
structure and solubility of wheat arabinoxylan during the breadmaking process. Food
Hydrocolloids, 109, 106129. https://10.1016/j.foodhyd.2020.106129.
Paesani, C., Sciarini, L. S., Moiraghi, M., Salvucci, E., Prado, S. B., Pérez, G. T., et al.
(2020). Human colonic in vitro fermentation of water-soluble arabinoxylans from
hard and soft wheat alters Bifidobacterium abundance and short-chain fatty acids
concentration. LWT-food Science & Technology, 134, Article 110253. https://10.101
6/j.lwt.2020.110253.
Pandeirada, C. O., Merkx, D. W. H., et al. (2021). TEMPO/NaClO2/NaOCl oxidation of
arabinoxylans. Carbohydrate Polymers, 259(0144–8617), 117781. https://10.1016/j.
carbpol.2021.117781.
Parenti, O., Guerrini, L., Si, X., et al. (2021). Use of the 1H NMR technique to describe the
kneading step of wholewheat dough: The effect of kneading time and total water
content. Food Chemistry, 338, Article 128120. https://10.1016/j.foodchem.2020
.128120.
Pereira, G. V., Abdelhamid, A., et al. (2021). Degradation of complex arabinoxylans by
human colonic Bacteroidetes. Nature Communications, 12. https://10.1038
/s41467-020-20737-5.
Protonotariou, S., Stergiou, P., et al. (2020). Physical properties and sensory evaluation
of bread containing micronized whole wheat flour. Food Chemistry, 318, Article
126497. https://10.1016/j.foodchem.2020.126497.Qi, N., Li, P. W., et al. (2013). Comparison of Kjeldahl and the elemental analysis
methods for determination of nitrogen content in raw natural rubber. Advanced
Materials Research, 815, 722–726. https://10.4028/www.scientific.net/am
r.815.722.
Qi, X., Zhang, Y., et al. (2023). Research on the properties of polysaccharides, starch,
protein, pectin, and fibre in food processing. Foods, 12, 249. https://10.3390/food
s12020249.
Ribotta, P. D., Cuffini, S. L., et al. (2004). The staling of bread: An X-ray diffraction study.
European Food Research and Technology, 218, 219–223. https://10.1007/s00217-00
3-0835-8.
Schopf, M., & Scherf, K. A. (2021). Water absorption capacity determines the
functionality of vital gluten related to specific bread volume. Foods, 10, 228.
https://10.3390/foods10020228.
Secchi, N., Fadda, C., et al. (2018). Improving baking quality of weak gluten semolina
using ovine whey powder. Journal of Food Quality, 2018, 1–10. https://10.1155/201
8/7901901.
Sullivan, W. R., Hughes, J. G., et al. (2017). The effects of temperature on the crystalline
properties and resistant starch during storage of white bread. Food Chemistry, 228,
57–61. https://10.1016/j.foodchem.2017.01.140.
Sun, J., Si, X., et al. (2022). The influence of water-unextractable arabinoxylan and its
hydrolysates on the aggregation and structure of gluten proteins. Frontiers in
Nutrition, 9, Article 877135. https://10.3389/fnut.2022.877135.
Sun, J., Zhou, R., et al. (2022b). Investigation the influences of water-extractable and
water-unextractable arabinoxylan on the quality of whole wheat you-tiao and its
mechanism. Food Chemistry, 386, Article 132809. https://10.1016/j.foodchem.20
22.132809.
Szkudlarz, S. M., Różańska, M. B., et al. (2023). Formation of Maillard reaction products
in a model bread system of different gluten-free flours. Food Chemistry, 429, Article
136994. https://10.1016/j.foodchem.2023.136994.
Taus, A. L., Tahuk, P. K., et al. (2022). The effect use of different binding materials on
water holding capacity, water content and crude fiber content of chicken nuggets.
Journal of Tropical Animal Science and Technology, 4, 74–81. https://10.32938/jtast.
v4i1.1330.
Wang, Y., Chen, Y., et al. (2017). Effects of konjac glucomannan on heat-induced changes
of wheat gluten structure. Food Chemistry, 229, 409–416. https://10.1016/j.foodch
em.2017.02.056.
Zelada, C. R. E., Cadavez, V., et al. (2018). Combined effect of xanthan gum and water
content on physicochemical and textural properties of gluten-free batter and bread.
Food Research International, 111, 544–555. https://10.1016/j.foodres.2018.05.070.
Zhang, G., Wang, D., Si, X., et al. (2024). Effect and mechanism of insoluble dietary fiber
on postprandial blood sugar regulation. Trends in Food Science and Technology, 146,
Article 104354. https://10.1016/j.tifs.2024.104354.
Zhang, J., Yang, H., Zhou, J., Shen, T., & Hu, W. (2021). Immunomodulatory effects of
wheat bran arabinoxylan on RAW264.7 macrophages via the NF-κB signaling
pathway using RNA-seq analysis. Food Research International, 140, 110067. https://
10.1016/j.foodres.2020.110067.
S. Han et al. LWT 210 (2024) 116867
9
https://10.1016/j.foodchem.2023.137199
https://10.1111/ijfs.13669
https://10.1111/ijfs.13669
https://10.3390/foods10020437
https://10.1016/j.fbio.2023.103435
https://10.3390/foods12142640
https://10.1002/cche.10578
https://10.4067/s0717-75182013000100010
https://10.1016/j.foodhyd.2020.106129
https://10.1016/j.lwt.2020.110253
https://10.1016/j.lwt.2020.110253
https://10.1016/j.carbpol.2021.117781
https://10.1016/j.carbpol.2021.117781
https://10.1016/j.foodchem.2020.128120
https://10.1016/j.foodchem.2020.128120
https://10.1038/s41467-020-20737-5
https://10.1038/s41467-020-20737-5
https://10.1016/j.foodchem.2020.126497
https://10.4028/www.scientific.net/amr.815.722
https://10.4028/www.scientific.net/amr.815.722
https://10.3390/foods12020249
https://10.3390/foods12020249
https://10.1007/s00217-003-0835-8
https://10.1007/s00217-003-0835-8
https://10.3390/foods10020228
https://10.1155/2018/7901901
https://10.1155/2018/7901901
https://10.1016/j.foodchem.2017.01.140
https://10.3389/fnut.2022.877135
https://10.1016/j.foodchem.2022.132809
https://10.1016/j.foodchem.2022.132809
https://10.1016/j.foodchem.2023.136994
https://10.32938/jtast.v4i1.1330
https://10.32938/jtast.v4i1.1330
https://10.1016/j.foodchem.2017.02.056
https://10.1016/j.foodchem.2017.02.056
https://10.1016/j.foodres.2018.05.070
https://10.1016/j.tifs.2024.104354
https://10.1016/j.foodres.2020.110067
https://10.1016/j.foodres.2020.110067
	Effects of water-unextractable arabinoxylan from wheat processing wastewater on the quality characteristics of multigrain bread
	1 Introduction
	2 Materials and methods
	2.1 Preparation of WUAX
	2.2 Bread making process
	2.3 Determination of specific volume and porosity of bread
	2.4 Color analysis
	2.5 Texture profile analysis (TPA)
	2.6 X-ray diffraction (XRD) analysis
	2.7 Moisture mobility and distribution determination (LF-NMR)
	2.8 Scanning electron microscopy (SEM) analysis
	2.9 Analysis of physicochemical properties of bread
	2.10 Sensory evaluation of bread
	2.11 Statistical analysis
	3 Results and discussion
	3.1 Effect of adding WUAX on bread specific volume, color and texture
	3.1.1 Bread specific volume and porosity
	3.1.2 Color attributes
	3.2 Texture profile analysis (TPA)
	3.3 Crystal structure and relative crystallinity
	3.4 Moisture mobility and moisture distribution in bread
	3.5 Effect of WUAX addition on bread microstructure
	3.6 Analysis of physicochemical properties of bread
	3.7 Sensory evaluation
	4 Conclusion
	CRediT authorship contribution statement
	Declaration of competing interest
	Acknowledgments
	datalink4
	References
