Journal of Cleaner Production 434 (2024) 140215
Available online 22 December 2023
0959-6526/© 2023 Elsevier Ltd. All rights reserved.
A urea-loaded hydrogel comprising of cellulose nanofibers and
carboxymethyl cellulose: An effective slow-release fertilizer
Priya E a, Akash Jha b, Sudipta Sarkar a,b,*, Pradip K. Maji c,**
a Centre for Nanotechnology, Indian Institute of Technology Roorkee, Roorkee, 247667, Uttarakhand, India
b Department of Civil Engineering, Indian Institute of Technology Roorkee, Roorkee, 247667, Uttarakhand, India
c Department of Polymer & Process Engineering, Indian Institute of Technology Roorkee, Saharanpur Campus, Saharanpur, 247001, Uttar Pradesh, India
A R T I C L E I N F O
Handling Editor: Jian Zuo
Keywords:
Biodegradable
Cellulose nanofibers
Slow-released urea
Seed germination
Water absorption
and retention
A B S T R A C T
Conventional fertilizers used worldwide to increase crop yield have several environmental and economic issues
resulting from their quickly soluble nature, causing most of the fertilizers to be lost through agricultural field
runoff and leachate. Utilizing slow or controlled-release fertilizers may reduce the issues associated with con-
ventional fertilizers. However, many commercially available variants of slow-release formulations are ecologi-
cally unsustainable as they are made of non-biodegradable polymers. In the present study, a hydrogel composed
of cellulose nanofibers (CNF) and carboxyl methyl cellulose (CMC) was synthesized for use as a biodegradable
and environmentally sustainable host for carrying urea within its matrix and released the same slowly over a long
period of time. The swelling measurements showed that the thermally stable urea-loaded CNF/CMC hydrogel
(UCNF) had a high water absorption capacity of 147 g/g in distilled water owing to its porous morphology and
the presence of various polar groups. When exposed to a dry environment, it released the absorbed moisture
slowly over a period of more than 2 weeks. The urea release rate was also relatively slow; it took about 30 days to
release the urea loaded in UCNF. The results indicated that urea diffusion from the material was non-Fickian in
character and fit well with the pseudo-second-order kinetics model. The hydrogel demonstrated excellent
biodegradability; more than 80% by weight of the hydrogel disappeared through biodegradation by soil bacteria
within 3 months. The plant study revealed that adding UCNF to the soil effectively enhanced the seed germi-
nation and growth of the plant. Also, plants treated with urea-loaded hydrogel had better growth than the pure
urea- and control plant samples. The study found that crosslinked and functionalized cellulose nanofiber may
effectively transport water and fertilizer slowly and sustainably.
1. Introduction
Population growth is driving the growing food demands around the
globe. Additionally, dwindling land fertility compels farmers to use
excessive mineral fertilizers to enhance crop yield and meet demand
(Guo et al., 2021; Rop et al., 2018; Wen et al., 2017). Urea is arguably
the most widely utilized fertilizer, often used for nitrogen supplemen-
tation due to its high nitrogen content (Lin et al., 2021; Shaghaleh et al.,
2022). Despite its distinct advantages, urea has disadvantages - it has
low thermal stability, high solubility, and low molecular weight,
resulting in its tendency to vaporize quickly to the atmosphere and to be
lost through runoff and leachate into aquatic systems (Zhou et al., 2018).
Excessive use of fertilizers in agricultural fields can result in
environmental degradation and increased production costs caused by
the leaching of nutrients beyond the plant’s requirements (Dhanapal
et al., 2021; Guo et al., 2021; Zonatto et al., 2017). Researchers have
used superabsorbent hydrogels (SAHs) as a slow-release fertilizer (SRF)
system in agriculture to overcome these drawbacks. SAHs are
three-dimensional crosslinked polymer networks. They are insoluble in
water and can absorb and retain large volumes of aqueous solutions or
biological fluids within their structure, even under high-pressure con-
ditions (Bao et al., 2011; Tally and Atassi, 2015). Due to their cross-
linked structure, SAHs are stable in various media and environmental
conditions (Pourjavadi et al., 2004). They have gained significant
attention as hydrophilic materials suitable for agricultural applications
in arid and semi-arid climatic conditions (Bora and Karak, 2022).
* Corresponding author. Centre for Nanotechnology, Indian Institute of Technology Roorkee, Roorkee, 247667, Uttarakhand, India.
** Corresponding author.
E-mail addresses: sudipta.sarkar@ce.iitr.ac.in (S. Sarkar), pradip@pe.iitr.ac.in (P.K. Maji).
Contents lists available at ScienceDirect
Journal of Cleaner Production
journal homepage: www.elsevier.com/locate/jclepro
https://doi.org/10.1016/j.jclepro.2023.140215
Received 1 August 2023; Received in revised form 29 November 2023; Accepted 14 December 2023
mailto:sudipta.sarkar@ce.iitr.ac.in
mailto:pradip@pe.iitr.ac.in
www.sciencedirect.com/science/journal/09596526
https://www.elsevier.com/locate/jclepro
https://doi.org/10.1016/j.jclepro.2023.140215
https://doi.org/10.1016/j.jclepro.2023.140215
https://doi.org/10.1016/j.jclepro.2023.140215
http://crossmark.crossref.org/dialog/?doi=10.1016/j.jclepro.2023.140215&domain=pdf
Journal of Cleaner Production 434 (2024) 140215
2
Superabsorbent hydrogels have been synthesized using diverse mate-
rials, such as inorganic constituents and synthetic and natural polymers.
Notwithstanding their advantages, SAHs encounter various chal-
lenges. The fertilizers often take a long time to degrade under natural
conditions; the synthesis process suffers from problems such as poly-
merization inhibition; excessive use of methanol calls for the by-product
removal before the fertilizer can be used in the field. Moreover, often,
there is a quicker release of nutrients (Salimi et al., 2021). These unfa-
vorable factors necessitate exploring alternative environmentally
friendly, biodegradable SRFs that can be synthesized using environ-
mentally sound, sustainable resources and production methods (Man-
zoor Ghumman et al., 2022). Polysaccharides are a crucial ingredient in
the hydrogels industry, supporting the polymer network and imparting
other qualities like biodegradability. Polysaccharide-based slow-release
fertilizers have been found to tackle environmental and economic issues
effectively. These SRFs facilitate the efficient utilization of fertilizers by
steadily releasing mineral nutrients readily absorbed by crops (Di Mar-
tino et al., 2021; Liu et al., 2022). In other words, the
polysaccharides-based hydrogel disassembles if the chains of poly-
saccharides are broken, and this is due to the polysaccharide’s suscep-
tibility to biodegradation by microorganisms. This property makes the
polysaccharide-based hydrogels suitable for soil usage as a biodegrad-
able system for regulating nutrient release (Baldrian and Valášková,
2008). Furthermore, the incorporation of polysaccharide materials has
been reported to enhance various properties of superabsorbent mate-
rials, such as swelling capacity, gel strength, acid or alkaline resistance,
temperature sensitivity, nutrition release, and thermal (Hua and Wang,
2009; Liang et al., 2009). In contrast, synthetic superabsorbents based
on polymers are produced through the synthesis of chemical substances
such as poly (acrylic acid), poly (vinyl alcohol), and poly-N-isopropyl
acrylamide (Madduma-Bandarage and Madihally, 2021). The synthetic
materials in question have poor biodegradability, implying that hydro-
gels made from them do not readily undergo degradation processes.
Several studies have examined the application of environmentally
friendly cellulose-based hydrogels for slow-release fertilizers due to the
importance of being nontoxic and cheap, thushttps://doi.org/10.1016/J.CARBPOL.2011.03.028
https://doi.org/10.1016/J.JARE.2013.07.006
https://doi.org/10.1021/acssuschemeng.8b01062
https://doi.org/10.1021/acsomega.9b00651
https://doi.org/10.1016/j.envexpbot.2023.105376
https://doi.org/10.1016/j.envexpbot.2023.105376
https://doi.org/10.1016/J.CARBPOL.2022.119555
https://doi.org/10.1016/J.CARBPOL.2022.119555
https://doi.org/10.1016/B978-0-12-811978-5.00006-7
https://doi.org/10.1016/B978-0-12-811978-5.00006-7
https://doi.org/10.14502/Tekstilec2014.57.118
https://doi.org/10.1111/j.1574-6976.2008.00106.x
https://doi.org/10.1111/j.1574-6976.2008.00106.x
https://doi.org/10.1016/j.carbpol.2010.10.061
https://doi.org/10.1016/J.CARBPOL.2011.06.015
https://doi.org/10.1016/J.EURPOLYMJ.2022.111430
https://doi.org/10.1016/J.EURPOLYMJ.2022.111430
https://doi.org/10.1007/s10973-016-5653-x
https://doi.org/10.1016/j.ces.2013.11.013
https://doi.org/10.1016/j.compositesb.2013.03.027
https://doi.org/10.1002/MACP.200800161
https://doi.org/10.1016/J.EURPOLYMJ.2009.04.033
https://doi.org/10.1016/J.CARBPOL.2019.115286
https://doi.org/10.1016/J.MARPOLBUL.2022.113790
https://doi.org/10.1016/J.MARPOLBUL.2022.113790
https://doi.org/10.1021/SC400358B/ASSET/IMAGES/LARGE/SC-2013-00358B_0008.JPEG
https://doi.org/10.1021/SC400358B/ASSET/IMAGES/LARGE/SC-2013-00358B_0008.JPEG
https://doi.org/10.1016/S0008-6215(99)00108-1
https://doi.org/10.1016/j.matpr.2020.11.101
https://doi.org/10.1016/J.JCLEPRO.2020.124848
https://doi.org/10.1016/J.JCLEPRO.2020.124848
https://doi.org/10.3390/polym13193274
https://doi.org/10.3390/polym13193274
https://doi.org/10.1021/ACSOMEGA.8B02790/ASSET/IMAGES/MEDIUM/AO-2018-02790W_M004.GIF
https://doi.org/10.1021/ACSOMEGA.8B02790/ASSET/IMAGES/MEDIUM/AO-2018-02790W_M004.GIF
Journal of Cleaner Production 434 (2024) 140215
13
Part I. Pyrolysis and hydrolysis of urea over zeolite catalysts. Appl. Catal. B Environ.
97, 90–97. https://doi.org/10.1016/j.apcatb.2010.03.027.
El-Sakhawy, M., Tohamy, H.A.S., Salama, A., Kamel, S., 2019. Thermal properties of
carboxymethyl cellulose acetate butyrate. Cellul. Chem. Technol. 53, 667–675.
https://doi.org/10.35812/CelluloseChemTechnol.2019.53.65.
Falkiewicz-Dulik, Michalina, J.A.N.D.A., 2010. Ka- Tarzyna, WYPYCH, George.
Handbook of Bio- Degradation, Biodeterioration and Biostabiliza- Tion. ChemTec
Publishing, Toronto, p. 250.
Gharekhani, H., Olad, A., Mirmohseni, A., Bybordi, A., 2017. Superabsorbent hydrogel
made of NaAlg-g-poly(AA-co-AAm) and rice husk ash: synthesis, characterization,
and swelling kinetic studies. Carbohydr. Polym. 168, 1–13. https://doi.org/
10.1016/J.CARBPOL.2017.03.047.
Guo, L., Wang, Y., Wang, M., Shaghaleh, H., Hamoud, Y.A., Xu, X., Liu, H., 2021.
Synthesis of bio-based MIL-100(Fe)@CNF-SA composite hydrogel and its application
in slow-release N-fertilizer. J. Clean. Prod. 324, 129274 https://doi.org/10.1016/J.
JCLEPRO.2021.129274.
Hua, S., Wang, A., 2009. Synthesis, characterization and swelling behaviors of sodium
alginate-g-poly(acrylic acid)/sodium humate superabsorbent. Carbohydr. Polym. 75,
79–84. https://doi.org/10.1016/j.carbpol.2008.06.013.
Kabiri, K., Omidian, H., Zohuriaan-Mehr, M.J., Doroudiani, S., 2010. Superabsorbent
hydrogel composites and nanocomposites: a review. Polym. Compos. 32, 277–289.
https://doi.org/10.1002/PC.21046.
Kiran, Tiwari, R., Krishnamoorthi, S., Kumar, K., 2019. Synthesis of cross-linker devoid
novel hydrogels: swelling behaviour and controlled urea release studies. J. Environ.
Chem. Eng. 7, 103162 https://doi.org/10.1016/j.jece.2019.103162.
Kittipongpatana, O.S., Kittipongpatana, N., 2013. Physicochemical, in vitro digestibility
and functional properties of carboxymethyl rice starch cross-linked with
epichlorohydrin. Food Chem. 141, 1438–1444. https://doi.org/10.1016/J.
FOODCHEM.2013.04.030.
Liang, R., Yuan, H., Xi, G., Zhou, Q., 2009. Synthesis of wheat straw-g-poly(acrylic acid)
superabsorbent composites and release of urea from it. Carbohydr. Polym. 77,
181–187. https://doi.org/10.1016/j.carbpol.2008.12.018.
Lin, X., Guo, L., Shaghaleh, H., Hamoud, Y.A., Xu, X., Liu, H., 2021. A TEMPO-oxidized
cellulose nanofibers/MOFs hydrogel with temperature and pH responsiveness for
fertilizers slow-release. Int. J. Biol. Macromol. 191, 483–491. https://doi.org/
10.1016/J.IJBIOMAC.2021.09.075.
Liu, Y., Wang, J., Chen, H., Cheng, D., 2022. Environmentally friendly hydrogel: a review
of classification, preparation and application in agriculture. Sci. Total Environ. 846,
157303 https://doi.org/10.1016/j.scitotenv.2022.157303.
Madduma-Bandarage, U.S.K., Madihally, S.V., 2021. Synthetic hydrogels: synthesis,
novel trends, and applications. J. Appl. Polym. Sci. 138, 1–23. https://doi.org/
10.1002/app.50376.
Mahdavinia, G.R., Zohuriaan-Mehr, M.J., Pourjavadi, A., 2004. Modified chitosan III,
superabsorbency, salt- and pH-sensitivity of smart ampholytic hydrogels from
chitosan-g-PAN. Polym. Adv. Technol. 15, 173–180. https://doi.org/10.1002/
pat.408.
Maiti, S., Jayaramudu, J., Das, K., Reddy, S.M., Sadiku, R., Sinha Ray, S., Liu, D., 2013.
Preparation and characterization of nano-cellulose with new shape from different
precursor. Carbohydr. Polym. 98, 562–567. https://doi.org/10.1016/j.
carbpol.2013.06.029.
Mandal, A., Chakrabarty, D., 2011. Isolation of nanocellulose from waste sugarcane
bagasse (SCB) and its characterization. Carbohydr. Polym. 86, 1291–1299. https://
doi.org/10.1016/j.carbpol.2011.06.030.
Manzoor Ghumman, A.S., Shamsuddin, R., Nasef, M.M., Maucieri, C., Rehman, O.U.,
Rosman, A.A., Haziq, M.I., Abbasi, A., 2022. Degradable slow-release fertilizer
composite prepared by ex situ mixing of inverse vulcanized copolymer with urea.
Agronomy 12. https://doi.org/10.3390/agronomy12010065.
Mohammadbagheri, Z., Rahmati, A., Hoshyarmanesh, P., 2021. Synthesis of a novel
superabsorbent with slow-release urea fertilizer using modified cellulose as a
grafting agent and flexible copolymer. Int. J. Biol. Macromol. 182, 1893–1905.
https://doi.org/10.1016/J.IJBIOMAC.2021.05.191.
Mohammadi-khoo, S., Moghadam, P.N., Fareghi, A.R., 2016. Synthesis of a cellulose-
based hydrogel network : characterization and study of urea fertilizer slow release
42935, 1–9. https://doi.org/10.1002/app.42935.
Mondal, M.I.H., Yeasmin, M.S., Rahman, M.S., 2015. Preparation of food grade
carboxymethyl cellulose from corn husk agrowaste. Int. J. Biol. Macromol. 79,
144–150. https://doi.org/10.1016/J.IJBIOMAC.2015.04.061.
Nomura, K., Terwilliger, P., 2020. Self-dual Leonard Pairs Preparation and Properties of
Hydrogel Based on Sawdust Cellulose for Environmentally Friendly 139–152.
Pourjavadi, A., Harzandi, A.M., Hosseinzadeh, H., 2004. Modified carrageenan 3.
Synthesis of a novel polysaccharide-based superabsorbent hydrogel via graft
copolymerization of acrylic acid onto kappa-carrageenan in air. Eur. Polym. J. 40,
1363–1370. https://doi.org/10.1016/j.eurpolymj.2004.02.016.
Rizwan, M., Rubina Gilani, S., Iqbal Durani, A., Naseem, S., 2021. Materials diversity of
hydrogel: synthesis, polymerization process and soil conditioning properties in
agricultural field. J. Adv. Res. 33, 15–40. https://doi.org/10.1016/j.
jare.2021.03.007.
Rodrigues, F.H.A., Fajardo, A.R., Pereira, A.G.B., Ricardo, Ń.M.P.S., Feitosa, J.P.A.,
Muniz, E.C., 2012. Chitosan-graft-poly(acrylic acid)/rice husk ash based
superabsorbent hydrogel composite: preparation and characterization. J. Polym.
Res. 19 https://doi.org/10.1007/s10965-012-0001-8.
Rop, K., Karuku, G.N., Mbui, D., Michira, I., Njomo, N., 2018. Formulation of slow
release NPK fertilizer (cellulose-graft-poly(acrylamide)/nano-hydroxyapatite/
soluble fertilizer) composite and evaluating its N mineralization potential. Ann.
Agric. Sci. 63, 163–172. https://doi.org/10.1016/j.aoas.2018.11.001.
Salimi, M., Motamedi, E., Safari, M., Motesharezadeh, B., 2021. Synthesis of urea slow-
release fertilizer using a novel starch-g-poly (styrene-co-butylacrylate)
nanocompositelatex and its impact on a model crop production in greenhouse.
J. Clean. Prod. 322, 129082 https://doi.org/10.1016/j.jclepro.2021.129082.
Sarmah, D., Karak, N., 2020. Biodegradable superabsorbent hydrogel for water holding
in soil and controlled-release fertilizer. J. Appl. Polym. Sci. 137, 48495 https://doi.
org/10.1002/APP.48495.
Shaghaleh, H., Hamoud, Y.A., Xu, X., Liu, H., Wang, S., Sheteiwy, M., Dong, F., Guo, L.,
Qian, Y., Li, P., Zhang, S., 2021. Thermo-/pH-responsive preservative delivery based
on TEMPO cellulose nanofiber/cationic copolymer hydrogel film in fruit packaging.
Int. J. Biol. Macromol. 183, 1911–1924. https://doi.org/10.1016/J.
IJBIOMAC.2021.05.208.
Shaghaleh, H., Alhaj Hamoud, Y., Xu, X., Wang, S., Liu, H., 2022. A pH-responsive/
sustained release nitrogen fertilizer hydrogel based on aminated cellulose nanofiber/
cationic copolymer for application in irrigated neutral soils. J. Clean. Prod. 368,
133098 https://doi.org/10.1016/J.JCLEPRO.2022.133098.
Shang, H., Yang, X., Liu, H., 2023. Temperature-responsive hydrogel prepared from
carboxymethyl cellulose-stabilized N-vinylcaprolactam with potential for fertilizer
delivery. Carbohydr. Polym. 313, 120875 https://doi.org/10.1016/j.
carbpol.2023.120875.
Sharma, N., Allardyce, B.J., Rajkhowa, R., Agrawal, R., 2023. Controlled release fertilizer
delivery system derived from rice straw cellulose nanofibres: a circular economy
based solution for sustainable development. Bioengineered 14. https://doi.org/
10.1080/21655979.2023.2242124.
Shaviv, Avi, 2000. A DVANCES IN C ONTROLLED -R ELEASE 71.
Shoji, S., Kanno, H., 1994. Use of polyolefin-coated fertilizers for increasing fertilizer
efficiency and reducing nitrate leaching and nitrous oxide emissions. Fert. Res. 39,
147–152. https://doi.org/10.1007/BF00750913.
Ski, T.U., 1969. Daniewski, Dabrowska, Piasek, a.Nd Urbadski : Infrared 6 0 . Infrayed
Absorption Spectra 2340–2343.
Tally, M., Atassi, Y., 2015. Optimized synthesis and swelling properties of a pH-sensitive
semi-IPN superabsorbent polymer based on sodium alginate-g-poly(acrylic acid-co-
acrylamide) and polyvinylpyrrolidone and obtained via microwave irradiation.
J. Polym. Res. 22 https://doi.org/10.1007/s10965-015-0822-3.
Tanan, W., Panichpakdee, J., Suwanakood, P., Saengsuwan, S., 2021. Biodegradable
hydrogels of cassava starch-g-polyacrylic acid/natural rubber/polyvinyl alcohol as
environmentally friendly and highly efficient coating material for slow-release urea
fertilizers. J. Ind. Eng. Chem. 101, 237–252. https://doi.org/10.1016/J.
JIEC.2021.06.008.
Vudjung, C., Saengsuwan, S., 2018. Biodegradable IPN hydrogels based on pre-
vulcanized natural rubber and cassava starch as coating membrane for environment-
friendly slow-release urea fertilizer. J. Polym. Environ. 26, 3967–3980. https://doi.
org/10.1007/S10924-018-1274-8/FIGURES/9.
Wang, Y., Shaghaleh, H., Hamoud, Y.A., Zhang, S., Li, P., Xu, X., Liu, H., 2021. Synthesis
of a pH-responsive nano-cellulose/sodium alginate/MOFs hydrogel and its
application in the regulation of water and N-fertilizer. Int. J. Biol. Macromol. 187,
262–271. https://doi.org/10.1016/j.ijbiomac.2021.07.154.
Wen, P., Wu, Z., Han, Y., Cravotto, G., Wang, J., Ye, B.C., 2017. Microwave-assisted
synthesis of a novel biochar-based slow-release nitrogen fertilizer with enhanced
water-retention capacity. ACS Sustain. Chem. Eng. 5, 7374–7382. https://doi.org/
10.1021/acssuschemeng.7b01721.
Xiang, A., Qi, R., Wang, M., Zhang, K., Jiang, E., Ren, Y., Hu, Z., 2020. Study on the
infiltration mechanism of molten urea and biochar for a novel fertilizer preparation.
Ind. Crops Prod. 153, 112558 https://doi.org/10.1016/j.indcrop.2020.112558.
Yadav, C., Saini, A., Maji, P.K., 2017. Energy efficient facile extraction process of
cellulose nanofibres and their dimensional characterization using light scattering
techniques. Carbohydr. Polym. 165, 276–284. https://doi.org/10.1016/j.
carbpol.2017.02.049.
Zhou, T., Wang, Y., Huang, S., Zhao, Y., 2018. Synthesis composite hydrogels from
inorganic-organic hybrids based on leftover rice for environment-friendly controlled-
release urea fertilizers. Sci. Total Environ. 615, 422–430. https://doi.org/10.1016/j.
scitotenv.2017.09.084.
Zonatto, F., Muniz, E.C., Tambourgi, E.B., Paulino, A.T., 2017. Adsorption and controlled
release of potassium, phosphate and ammonia from modified Arabic gum-based
hydrogel. Int. J. Biol. Macromol. 105, 363–369. https://doi.org/10.1016/j.
ijbiomac.2017.07.051.
P. E et al.
https://doi.org/10.1016/j.apcatb.2010.03.027
https://doi.org/10.35812/CelluloseChemTechnol.2019.53.65
http://refhub.elsevier.com/S0959-6526(23)04373-1/sref28
http://refhub.elsevier.com/S0959-6526(23)04373-1/sref28
http://refhub.elsevier.com/S0959-6526(23)04373-1/sref28
https://doi.org/10.1016/J.CARBPOL.2017.03.047
https://doi.org/10.1016/J.CARBPOL.2017.03.047
https://doi.org/10.1016/J.JCLEPRO.2021.129274
https://doi.org/10.1016/J.JCLEPRO.2021.129274
https://doi.org/10.1016/j.carbpol.2008.06.013
https://doi.org/10.1002/PC.21046
https://doi.org/10.1016/j.jece.2019.103162
https://doi.org/10.1016/J.FOODCHEM.2013.04.030
https://doi.org/10.1016/J.FOODCHEM.2013.04.030
https://doi.org/10.1016/j.carbpol.2008.12.018
https://doi.org/10.1016/J.IJBIOMAC.2021.09.075
https://doi.org/10.1016/J.IJBIOMAC.2021.09.075
https://doi.org/10.1016/j.scitotenv.2022.157303
https://doi.org/10.1002/app.50376
https://doi.org/10.1002/app.50376
https://doi.org/10.1002/pat.408
https://doi.org/10.1002/pat.408
https://doi.org/10.1016/j.carbpol.2013.06.029
https://doi.org/10.1016/j.carbpol.2013.06.029
https://doi.org/10.1016/j.carbpol.2011.06.030
https://doi.org/10.1016/j.carbpol.2011.06.030
https://doi.org/10.3390/agronomy12010065
https://doi.org/10.1016/J.IJBIOMAC.2021.05.191
https://doi.org/10.1002/app.42935
https://doi.org/10.1016/J.IJBIOMAC.2015.04.061
http://refhub.elsevier.com/S0959-6526(23)04373-1/sref46
http://refhub.elsevier.com/S0959-6526(23)04373-1/sref46
https://doi.org/10.1016/j.eurpolymj.2004.02.016
https://doi.org/10.1016/j.jare.2021.03.007
https://doi.org/10.1016/j.jare.2021.03.007
https://doi.org/10.1007/s10965-012-0001-8
https://doi.org/10.1016/j.aoas.2018.11.001
https://doi.org/10.1016/j.jclepro.2021.129082
https://doi.org/10.1002/APP.48495
https://doi.org/10.1002/APP.48495
https://doi.org/10.1016/J.IJBIOMAC.2021.05.208
https://doi.org/10.1016/J.IJBIOMAC.2021.05.208
https://doi.org/10.1016/J.JCLEPRO.2022.133098
https://doi.org/10.1016/j.carbpol.2023.120875
https://doi.org/10.1016/j.carbpol.2023.120875
https://doi.org/10.1080/21655979.2023.2242124
https://doi.org/10.1080/21655979.2023.2242124
http://refhub.elsevier.com/S0959-6526(23)04373-1/sref57
https://doi.org/10.1007/BF00750913
http://refhub.elsevier.com/S0959-6526(23)04373-1/sref59
http://refhub.elsevier.com/S0959-6526(23)04373-1/sref59
https://doi.org/10.1007/s10965-015-0822-3
https://doi.org/10.1016/J.JIEC.2021.06.008
https://doi.org/10.1016/J.JIEC.2021.06.008
https://doi.org/10.1007/S10924-018-1274-8/FIGURES/9
https://doi.org/10.1007/S10924-018-1274-8/FIGURES/9
https://doi.org/10.1016/j.ijbiomac.2021.07.154
https://doi.org/10.1021/acssuschemeng.7b01721
https://doi.org/10.1021/acssuschemeng.7b01721
https://doi.org/10.1016/j.indcrop.2020.112558
https://doi.org/10.1016/j.carbpol.2017.02.049
https://doi.org/10.1016/j.carbpol.2017.02.049
https://doi.org/10.1016/j.scitotenv.2017.09.084
https://doi.org/10.1016/j.scitotenv.2017.09.084
https://doi.org/10.1016/j.ijbiomac.2017.07.051
https://doi.org/10.1016/j.ijbiomac.2017.07.051
	A urea-loaded hydrogel comprising of cellulose nanofibers and carboxymethyl cellulose: An effective slow-release fertilizer
	1 Introduction
	2 Experimental methods
	2.1 Materials
	2.2 Synthesis of cellulose nanofibre(CNF)
	2.3 Preparation of urea-loaded CNF/CMC hydrogel (UCNF)
	2.4 Material characterization
	2.5 Water absorbance capacity of the synthesized hydrogel
	2.6 Water retention analysis
	2.7 Urea loading and release study
	2.8 Swelling kinetics
	2.9 Biodegradation test
	2.10 Soil burial method of biodegradation
	2.11 Plant growth experiment
	2.12 Cost analysis
	3 Result and discussion
	3.1 Characterization of slow-release hydrogel containing urea (UCNF)
	3.1.1 Fourier transform infrared Spectroscopy(FTIR)
	3.1.2 Field-emission scanning electron micrograph (FESEM) and X-ray diffraction (XRD) analysis
	3.1.3 Thermo-gravimetric analysis (TGA)
	3.1.4 Discussion: property, structure, and morphology of CNF and UCNF
	3.2 Water absorption and retention behavior of the UCNF hydrogel
	3.3 Biodegradability study
	3.3.1 Biodegradability test with a pure bacterial strain
	3.3.2 Soil burial test
	3.4 Studies on the urea release by UCNF
	3.5 Plant study
	3.6 Cost analysis
	4 Conclusion
	CRediT authorship contribution statement
	Declaration of competing interest
	Data availability
	Acknowledgments
	Appendix A Supplementary data
	Referencesimproving soil quality
(Kabiri et al., 2010; Lin et al., 2021). Cellulose is a naturally occurring
crystalline polymer that exhibits favorable mechanical properties as a
carrier/host. It can be obtained from diverse natural sources such as flax,
straw, cotton, bamboo, wood, bacteria, and algae. Compared to con-
ventional cellulose, cellulose nanofibers (CNF) present distinct advan-
tages as a promising and environmentally-friendly constituent at the
nanoscale due to their nanometer-scale diameter and increased specific
surface area (Shaghaleh et al., 2021; Wang et al., 2021). Also, cellulose
nanofiber-based hydrogels exhibit exceptional physical properties due
to their complex three-dimensional nanofiber networks. Due to their
high absorptive capacity, they can serve as reservoirs for carrying
additional water and nutrients to agricultural fields (Abe and Yano,
2011). According to the standard definition, hydrogels are complex
structures consisting of polymeric networks in three dimensions (3D)
established through physical or chemical crosslinking of polymer
(Ahmed, 2015). The formation of nanoscale 3D networks of nanofibers
within the CNF-based hydrogel offers unique chemical and physical
properties due to the formation of hydrogen bonds. The material ex-
hibits essential characteristics such as high strength and stiffness, hy-
drophilic properties, and a surface that can be readily modified (Alhaj
Hamoud et al., 2023). The exceptional physicochemical characteristics
of CNFs make them a highly favorable constituent for constructing
advanced functional hydrogels with superior performance. Cellulosic
hydrogels have emerged as a promising option for large-scale applica-
tions for cost-effective feedstock and environmentally friendly fertilizer
formulations (Alhaj Hamoud et al., 2023; Guo et al., 2021).
In this article, we report the synthesis, characterization, water up-
take, and urea and water release characteristics of a biodegradable urea-
loaded CNF/CMC hydrogel (UCNF) and validation of the UCNF hydrogel
as a slow-release plant growth-promoting fertilizer. The hydrogel has
been synthesized through green processing of pine wood scraps to pro-
duce cellulose nanofibers and crosslinking with epichlorohydrin in the
presence of carboxymethyl cellulose used as a hydrophilic filler in the
hydrogel matrix to improve its water uptake capacity. During the gela-
tion process, the hydrogel imbibed the urea solution within its matrix,
and the process did not use any catalyst, nor was there any requirement
for any energy-intensive post-purification or post-processing step. This
article also presents the swelling characteristics of UCNF, water reten-
tion capability, and urea release characteristics. We also report the re-
sults of the study on the biodegradability of the material and on
validation as a plant germination and growth-promoting fertilizer.
2. Experimental methods
2.1. Materials
Waste wood scraps, the starting material for the preparation of cel-
lulose nanofiber, were collected from a timber manufacturing company
located in Saharanpur, Uttar Pradesh, India. All other chemicals used in
this study were of reagent grade and were procured as follows: dimethyl
sulfoxide (DMSO), toluene from Avantor Performance Materials India
Limited, ethanol from Changshu Hongsheng Fine Chemical Co., Ltd.,
sodium chlorite (NaClO2), potassium hydroxide (KOH), urea, sodium
hydroxide (NaOH), and carboxymethyl cellulose sodium salt (CMC)
with 1500–3000 cp (1% in water at 25 ◦C) from HiMedia Laboratories
Pvt. Ltd. And glacial acetic acid from Sisco Research Laboratories Pvt.
Ltd. These reagents were used without further purification.
2.2. Synthesis of cellulose nanofibre (CNF)
Cellulose fibers (CF) and cellulose nanofibers (CNF) were obtained
following a process described by (Chhajed et al., 2019; Yadav et al.,
2017) with some modifications. Briefly, wood fibers were first dewaxed
using a soxhlet extraction apparatus at 50 ◦C for 8 h to remove impu-
rities like waxes, pectin, and resin, followed by cleaning and drying, and
bleaching with a 6% solution of acidified sodium chlorite at 75 ◦C for 4 h
to obtain hollocellulose, which is cellulose fibers with white color. The
bleaching step was repeated twice. Next, the fibers were de-lignified by
subjecting them to two rounds of treatment with a 4% KOH (potassium
hydroxide) solution at 90 ◦C for 2 h each, after which the pure CFs were
obtained. A 0.2 wt percent CF suspension was then defibrillated to the
nanoscale through homogenization using a REMI (RQ-140-D) homoge-
nizer for 3h, followed by sonication using a probe sonicator (UP400S
Hielsher Ultrasonics GmbH, Germany, 24 kHz) 20 min while main-
taining an ice water bath to prevent sample burning from elevated
temperatures. After sonication, the milky suspension of CNF was
centrifuged at ambient temperature for 15 min using a Laby T-70 B L
centrifuge (India) to obtain a concentrated solid content of 2 wt% (w/w)
of CNF. Finally, the synthesized CNF was stored at 4 ◦C for subsequent
use. A suspension with a solid content of about 0.2% was subjected to
centrifugation at a speed of 4500 revolutions per minute (rpm) for 20
min to separate the nanofibrillated material. The yield of the produced
nanofibres was calculated using Equation (1) (Besbes et al., 2011;
Yadav et al., 2017).
Yield (%)=
(
1 −
weight of dried sediment
weight of diluted samples × % solid content
)
× 100 (1)
2.3. Preparation of urea-loaded CNF/CMC hydrogel (UCNF)
Cellulose nanofibers (CNF) and carboxymethyl cellulose (CMC) were
mixed at 1:1 ratio to make 5% (w/v) concentration in a solution con-
taining 4% NaOH and 4% urea under continuous stirring to ensure the
formation of a homogeneous solution. 3 mL of epichlorohydrin was
mixed into the homogeneous solution under gentle stirring at 30 ◦C for
30 min to form the crosslinking. Subsequently, the solution was
P. E et al.
Journal of Cleaner Production 434 (2024) 140215
3
subjected to a temperature of 45 ◦C for 5 h to facilitate the gelation
process to form hydrogel of CNF/CMC with urea imbibed. The resulting
hydrogels were washed with water to remove excess reagents and im-
purities. A schematic representation of the synthesis process of the UCNF
hydrogel is provided in Fig. 1. From the material balance calculations
performed during several synthesis campaigns, it was observed that
there was on average 0.375 g urea/g of UCNF. The same was confirmed
through accelerated desorption experiments using DI water.
2.4. Material characterization
The UCNF hydrogel samples were dried and crushed into tiny beads
before casting them into KBr pellets for analysis through Fourier trans-
form infrared spectroscopy (FTIR) (PerkinElmer FTIR spectrum two,
USA). Each spectrum was acquired by performing 16 scans on each
sample within a wavenumber range of 4000-400 cm− 1, with a resolution
of 4 cm− 1. The structural morphology of the hydrogel was evaluated
using Field Emission Scanning Electron Microscopy (Carl-Zeiss Gemini
FESEM), operated at an accelerating voltage of 5–10 kV and a working
distance of 10 mm. The thermal decomposition characteristics of the
hydrogel were analyzed using a TGA apparatus (NETZSCH TG209 F3
Tarsus, Germany) with a consistent heating rate of 10 ◦C/min in the
presence of nitrogen gas with a flow rate of 10 mL/min. The XRD pattern
was recorded at a 4◦/min scanning rate using Cu-k radiation as the X-ray
source over an angular range of 5–80◦ and 40 kV (XRD, Rigaku Ultima
IV, Japan). The samples were dried in an oven before testing.
2.5. Water absorbance capacity of the synthesized hydrogel
0.5 g of dried UCNF hydrogel was submerged in deionized water at
ambienttemperature. The hydrogels absorbed water and swelled. The
swollen hydrogels were periodically extracted from the aqueous solu-
tion, gently cleansed with filtered paper, and subsequently weighed,
following the method reported by (Bora and Karak, 2022). The weighing
and measuring process continued until the swollen hydrogel reached a
constant weight. The water absorption capacity was calculated using
Equation (2).
Water absorption (g / g)=
[
Ms− M0
Mo
]
(2)
Where Mo and Ms are masses of the dry hydrogel and swollen hydrogel
after time t, respectively, all the experiments were performed in tripli-
cate, and the mean values were used for analysis.
Additionally, the swelling capacity of UCNF was also evaluated in
different salt concentrations, specifically 0.01% and 0.05% for NaCl,
KCl, NH4Cl, and CaCl2 (Rodrigues et al., 2012). The swelling test was
conducted in triplicate, and the result shown is the average of the three
values measured. Additionally, the dimensionless salt sensitivity factor
(f) was calculated (Alam and Christopher, 2018) as per Equation (3).
f = 1 −
Ws
Ww
(3)
Where Ws is the equilibrium swelling capacity in salt solution, and Ww is
the equilibrium swelling capacity in distilled water.
2.6. Water retention analysis
The water retention behavior of the synthesized hydrogel material
was analyzed using the gravimetric technique, following the method
described by (Kiran et al., 2019). Dry UCNF weighing 0.5 g was allowed
to absorb water at room temperature under ambient conditions of
neutral pH until it reached constant equilibrium weight, at which the
water imbibition was maximum. The swollen UCNF hydrogel was then
exposed to ambient conditions (25 ◦C and 60% RH) for drying and
weighed until a stable mass was achieved. The water retention per-
centage was calculated using Equation (4), where WR, Mo, and Mt stand
for the water retention ratio, dry hydrogel mass, and mass of the
hydrogel at time t. Water retention was measured thrice, and the
calculated average of the three outcomes is presented in the result.
WR(%)=
[
Mt− M0
Mo
]
× 100 (4)
2.7. Urea loading and release study
Urea concentration was determined by a colorimetric method pre-
viously reported (Dutta and Karak, 2018; Sarmah and Karak, 2020). The
colorimetric reagent of p-dimethylaminobenzaldehyde (P-DMABH) re-
acts with urea to produce a complex that makes a greenish-yellow color
in the acidic environment by Ehrlich reaction, which was used to mea-
sure the urea concentration in water. The p-DMABH and urea complex
absorbs light at 430 nm in the visible spectrum. Initially, a standard
calibration curve was plotted using absorbance values obtained using a
UV–visible spectrophotometer with urea solutions of six known con-
centrations (0.25M, 0.125M, 0.062M, 0.031M, 0.016M, and 0.008M).
For the urea release study, the 5 g of UCNF (containing 1.8 g urea)
was submerged in a beaker with 1000 mL of sterile DI water kept under
Fig. 1. A schematic showing the synthesis process of the hydrogel loaded with urea (UCNF).
P. E et al.
Journal of Cleaner Production 434 (2024) 140215
4
insulated conditions under a nitrogen atmosphere with gentle stirring.
At regular intervals, 1 mL of the solution was collected to determine urea
concentration, and 1 mL of sterile water was added to the beaker,
thereby maintaining a constant volume of the solution. The urea con-
centration in the collected sample was determined using the above
method and against the calibration curve obtained. The percentage of
urea released was calculated using Equation (5).
Urea release (%)=
Mt
M1
× 100 (5)
Where, Mt is the mass of urea released from hydrogel at time t, and M1 is
the total mass of urea loaded on the UCNF hydrogel.
2.8. Swelling kinetics
The UCNF hydrogel’s water swelling capacity and absorption rate
were examined using swelling kinetics. In order to conduct this experi-
ment, 0.5g of hydrogel was submerged for various time periods (10, 20,
30, 40, 50, 60, 90, 120, and 240 min) in excess distilled water. After the
specified period, the swollen hydrogel was filtered out to remove the
remaining water. The mass of the hydrogel after water absorption was
then measured, and Equation (2) was used to calculate the swelling
capacity of water at a specific time. The general sorption-time re-
lationships for a polymeric hydrogel can be modeled using the following
Equations 6 and 7.
Wt
Weq
= ktn (6)
log
(
Wt
Weq
)
= logk + n log t (7)
Where Wt stands for the weight of the hydrogel at a particular time t, and
Weq is the equilibrium weight of the swollen hydrogel, k and n are
constants. The n and k parameters were determined from the slope and
intercept of the linear regression curve, resulting from plotting the
logarithm of the ratio (Wt/Weq) against log(t), respectively. The value of
n obtained in this study can indicate the mechanism of water diffusion
during the swelling process. The Fickian mechanism of diffusion is
observed when the value of nwas quantified by observing the weight loss of the UCNF hydrogel over 6
weeks. This was achieved by removing the sample from the medium,
rinsing it with water, and drying and weighing it. The weight remaining
was thus measured, and the weight loss was calculated using following
Equation (9).
Weight loss(%)=
[
Wo− Wt
Wo
]
× 100 (9)
Where, W0 and Wt are the weights of the swollen UCNF hydrogel
initially and after time t, respectively.
2.10. Soil burial method of biodegradation
The biodegradability of the UCNF hydrogel was determined at actual
conditions by using the soil burial test. For this purpose, 0.5 g of the
dried hydrogel sample was introduced into paper cups, each holding 60
g of the soil sample. The soil samples obtained from the field were
subjected to a sun-drying process for three days, followed by manual
removal of unwanted dirt particles. Subsequently, 40 mL of DI water was
introduced into each cup, then their submersion into the soil at a depth
ranging from 8 to 9 cm. After a specific pre-determined time, the
hydrogel sample was recovered from the soil and cleaned using water to
eliminate any adhered soil particles. It was dried, and the remaining
weight was measured. The following Equation (10) determined the
percentage biodegradation of the UCNF hydrogel:
Percentage hydrogel remaining (%)=
[
Wi− Wf
Wi
]
× 100 (10)
Where, Wi represents the initial weight, and Wf denotes the weight after
biodegradation within the soil.
2.11. Plant growth experiment
The performance validation of the slow-release UCNF hydrogel as an
effective fertilizer was done by observing the impact of the hydrogel on
the germination and growth of wheatgrass plants in a pot experiment
performed under a controlled environment. The soil that was used in the
experiments was a mixture of silt and sand particles with a pH value of
7.08. The carbon content of the soil was analyzed to be 0.42%, with a
total content of organic matter of 0.73% and an electrical conductivity of
0.174 mS/cm. The plant growth studies were conducted using five
groups, each with three pots as replicates. 50 number seeds of Triticum
aestivum (wheatgrass) were sown in each pot at a depth of 3 cm below
the soil surface. The pots in the control group had untreated soil, which
was used as the benchmark for comparison purposes. The test groups
P. E et al.
Journal of Cleaner Production 434 (2024) 140215
5
consisted of two groups: a) plants grown in pots having soil with 1 and 3
g of UCNF, which had approximately 0.4 and 1.2 g of urea loaded on
them, respectively (1 g of UCNF contained approximately 0.4 g of urea)
and b) plants grown in pots treated with 0.4 and 1.2 g of pure urea. The
UCNF hydrogel was buried at a depth of 5 cm below the soil surface.
After 14 days, the wheatgrass plants were taken out, and a total of 40
plants were randomly selected from the three pots in each group.
Further, their fresh weight and the length of their shoots and roots were
measured and recorded. The collected grasses were dried, and their dry
weights were recorded. All the results were statistically analyzed.
2.12. Cost analysis
Evaluation of cost associated with material and energy is important
for finding a competitive market price for a new product. Material and
energy balance analysis was conducted on the synthesis of UCNF from a
20 g batch of raw fiber. The tentative material and energy balance cal-
culations are mentioned in the supplemental data.
3. Result and discussion
3.1. Characterization of slow-release hydrogel containing urea (UCNF)
The present study involved the extraction of cellulose nanofibers and
the subsequent synthesis of a urea-loaded CNF/CMC (UCNF) slow-
release hydrogel. Epichlorohydrin (ECH), a commonly used crosslinker
in various biopolymers, cellulose, and starch, has been used here (Chang
et al., 2008; De Miguel et al., 1999). The yield of CNF from the raw fibers
and the extracted CF was 41% and 31%, respectively. After a second
processing of sedimented fibers, the yield of CNF from raw fibers
increased to 73%. CNF plays a crucial role in maintaining the structural
integrity of the synthesized hydrogel, whereas the addition of CMC aids
in gelation and binding in the material and also helps in facilitating
improved water absorption capabilities. Therefore, it is essential to
maintain an appropriate balance of both constituents to ensure the
hydrogel’s structural stability and water absorption properties. Among
the number of variants tested, the UCNF hydrogel with a 1:1 ratio of CNF
and CMC showed the most favorable results in terms of structural
strength and water absorption properties, and therefore it was chosen
for further studies. The photographs of UCNF hydrogel with different
ratios of CNF and CMC are shown in Fig. S1.
3.1.1. Fourier transform infrared Spectroscopy(FTIR)
FTIR spectroscopy was conducted to gain information about the
possible chemical structures of the hydrogel. The spectra of raw fiber
(RF), chemically purified cellulose fibers (CF), and cellulose nanofiber
(CNF) were analyzed and are presented in Fig. 2a. All three samples - RF,
CF, and CNF showed an absorbance peak at around 3400 cm− 1, asso-
ciated with the stretching vibration of free–OH groups. The presence of
this group signifies that all three samples were hydrophilic. The ab-
sorption bands at 898 and 1636 cm− 1 were linked to the glycosidic
linkage (–C1–O–C4) between the cellobiose unit and the bending of O–H
due to water adsorption, respectively (Maiti et al., 2013; Mandal and
Chakrabarty, 2011; Yadav et al., 2017). In the spectra of RF, a carbonyl
(− C=O) stretching vibration of acetyl and uronic ester group from
pectin/hemicellulose was observed at 1735 cm− 1 (Chhajed et al., 2022).
The same was absent in the spectra of CF and CNF, confirming that the
purification step during the synthesis process has successfully elimi-
nated these impurities. The band at 1509 cm− 1 represents the –C=C
stretching vibration of the aromatic ring present in lignin, while the
band at 1462 cm− 1 is associated with –CH3 asymmetric bending, and the
band at 1263 cm− 1 belongs to C–O stretching vibration, indicating the
presence of aryl groups in the lignin structure of the raw fiber (Chhajed
et al., 2022; Maiti et al., 2013; Mandal and Chakrabarty, 2011; Yadav
et al., 2017). The FTIR spectra of CF and CNF did not show all the bands
mentioned above, indicating the effective elimination of components
such as lignin and hemicellulose. Fig. 3a shows the comparative FTIR
spectra of CNF and urea-loaded CNF (UCNF). The FTIR of CNF showed
the presence of a peak at 2925 cm− 1, indicating that C–H stretching
vibration and peak at 1424 cm− 1 confirmed the carboxyl group as a salt
(Mondal et al., 2015). The peak at wave numbers 1675 cm− 1 and 790
cm− 1 of the FTIR spectra of UCNF confirmed the presence of C=O
stretching vibration and C=O and NH bending vibration, respectively
(Ski, 1969) arising out of the presence of urea inside the hydrogel.
3.1.2. Field-emission scanning electron micrograph (FESEM) and X-ray
diffraction (XRD) analysis
The surface morphology of RF, CF, and CNF was investigated using
FESEM analysis, presented in Fig. 2b. It may be observed that the
diameter of the RF was approximately 150–200 μm. The morphological
characteristics of the extracted CFs show that the extracted CF had a
symmetrically dense structure attributed to hydrogen bonding. The fiber
dimensions of the extracted CFs were 10–25 μm. The cellulose structure
Fig. 2. (a) FTIR spectra and (b) SEM images at different magnifications of raw fiber (RF), chemically purified cellulose (CF) and cellulose nanofibers (CNF).
P. E et al.Journal of Cleaner Production 434 (2024) 140215
6
with high-density CF was defibrillated from a micro to a nano range by
applying high-intensity sonication waves, and the SEM of the resulting
CNF may also be observed in Fig. 2b. The high magnification image of
CNF reveals that most of the fibers had a diameter in the nanoscale
range. Fig. 3c shows the SEM of the surface morphology and the cross-
section of the UCNF. The porous nature of the UCNF can be readily
observed. The X-ray diffraction (XRD) pattern presented in Fig. S2 shows
the urea’s well-defined peaks at approximately 2θ = 22.8◦, 25.18◦,
30.1◦, 32.32◦, and 35.9◦, along with two minor peaks at around 2θ =
45.60◦ and 55.60◦(Arafa et al., 2022). XRD pattern of the UCNF
hydrogel exhibited a significantly wider peak at approximately 2θ = 22◦,
which can be attributed to the presence of urea. Additionally, two sig-
nificant peaks at 2θ = 32◦ and 35.8◦ along with two minor peaks at
around 2θ = 45.80 and 56.80◦ were observed, which are also associated
with the presence of urea. The observed peaks in the UCNF are com-
parable to those found in pure urea, suggesting that the urea has been
effectively incorporated into the synthesized hydrogel.
3.1.3. Thermo-gravimetric analysis (TGA)
The thermal decomposition experiment was carried out to examine
the thermal degradation of CNF, CMC, CNF/CMC, pure urea, and UCNF
at different temperatures. Fig. 3b shows the thermograms and their
corresponding first derivatives (DTG) of CNF, CMC, CNF/CMC, pure
urea, and UCNF. The TGA graphs indicate weight losses at 800 ◦C for
CNF, CMC, CNF/CMC, pure urea, and UCNF as 100%, 86%, 94%, 100%,
and 83%, respectively. These values represent the weight loss observed
after heating the materials up to 800 ◦C. The primary breakdown of
cellulose nanofibers (CNF) takes place at temperatures above 250 ◦C,
which can be linked to the degradation and decomposition of the
chemical structure of cellulose. At temperatures below 250 ◦C, the pri-
mary mechanisms responsible for degradation processes involve the
dehydration of water and the generation of peroxides, which function as
catalysts for the degradation of cellulose. Degradation at temperatures
above 250 ◦C exhibits faster rates and distinct characteristics than
degradation at lower temperatures. Within this specific range of tem-
perature, the hydrogen bonds are destroyed, resulting in a modification
of the crystalline structure. This process is responsible for generating
free radicals, carbonyl, and carboxyl groups, thus enhancing cellulose
degradation (Borsoi et al., 2016). Carboxymethyl cellulose (CMC) has
higher heat stability than CNF. Above 160 ◦C, the temperature at which
carboxymethyl cellulose (CMC) shows a 5% initial weight loss. The
subsequent reduction in weight was observed between the temperature
range of 250 ◦C to 300 ◦C, followed by the end of the third stage,
occurring approximately between 560 ◦C to 620 ◦C. The subsequent
weight loss steps were ascribed to the dehydration of saccharide rings
and the disintegration of the primary cellulose chain (El-Sakhawy et al.,
2019; Shang et al., 2023). The decomposition process of urea took place
in three distinct steps, as can be observed from the TGA and DTG curves.
The first stage of thermal decomposition exhibited a substantial mass
reduction of approximately 79%, which took place in the temperature
range from 135 ◦C to 260 ◦C. The phenomenon can be described as the
process of urea decomposition, which is further superposed by the for-
mation and decomposition of biurets (Xiang et al., 2020). The second
stage of decomposition, which had a mass loss of about 16%, involves
breaking down cyanuric acid in the temperature range from 260 ◦C to
328 ◦C (Brack et al., 2014; Eichelbaum et al., 2010). Also, some
ammelide, ammeline, and melamine might have been created. These
small amounts break down in the final step, and the mass loss is around
5% (Brack et al., 2014; Eichelbaum et al., 2010). On the other hand, the
TGA/DTG curve of UCNF clearly displays four distinct stages of weight
loss when it undergoes thermal degradation. The dried UCNF lost about
10 % of its weight at a temperature of 179 ◦C, which can be attributed to
the evaporative loss of water molecules inside it. Additionally, the UCNF
hydrogel undergoes thermal degradation at temperatures between
180 ◦C and 260 ◦C, resulting in a weight loss of approximately 22%. The
weight loss occurred because the urea in the hydrogel broke down, and
the bonds between the polymer and crosslinker in the hydrogel network
were destroyed (Mohammadi-khoo et al., 2016). The disintegration of
carboxymethyl cellulose, cellulose, and degradation of the remaining
urea was attributed to the subsequent reduction in weight during the
third phase, which occurred at a temperature range of 257 ◦C–340 ◦C
and resulted in a weight loss of approximately 32% (Chang et al., 2010;
Fig. 3. (a) FTIR spectra of (a) CNF/CMC and UCNF; (b) TGA and DTG curve of CNF, CMC, CNF/CMC, pure urea, and UCNF; (c) SEM images of UCNF hydrogel
showing surface and cross-sectional morphology.
P. E et al.
https://www.sciencedirect.com/topics/earth-and-planetary-sciences/diffraction-pattern
Journal of Cleaner Production 434 (2024) 140215
7
Shang et al., 2023). The broad fourth peak was observed due to the
degradation of complex molecules, which might have been formed by
the reaction of CNF, CMC, and epichlorohydrin in the solution, and it is
degraded over the range of temperature between 357 ◦C and 536 ◦C,
resulting in a weight loss of approximately 9 %. At a temperature of
800 ◦C, a residual amount of 17% of the UCNF hydrogel remained,
which may be due to the presence of CMC within the hydrogel. The
TGA/DTG results showed that the UCNF was thermally more stable than
pure urea.
3.1.4. Discussion: property, structure, and morphology of CNF and UCNF
The SEM images Fig. 2b indicate that the nanofibrils of CNF were
successfully extracted from pine wood scraps. During the chemical
treatment, the primary and secondary cell walls of the wood scrap or
raw fiber underwent breakdown, leading to the dissolution of non-
cellulosic components such as lignin, hemicellulose, and pectin, leav-
ing behind the pure cellulose fibers (CF). Micro-nano-dimensioned CNFs
can form complex structures through hydrogen bonding, resulting in an
ultrafine and uncharged entangled structure. The FTIR results of RF, CF,
CNF, and UCNF reveal some essential aspects of the structural frame-
work of these materials. First, the results indicate that the chemical
cleaning procedure was able to eliminate impurities present in RF like
pectin, hemicellulose, and lignin; almost impurity-free CF thus produced
could be nano-fibrillated to create the UCNF through further cross-
linking using epichlorohydrin (ECH) as a crosslinker. The addition of
CNF and CMC in the NaOH/urea solution leads to hydrogen-bond-
induced inclusion complex formation. Epichlorohydrin is added to
create a crosslinked structure, and urea remains within the final product,
a network-like structure with all the components chemically bonded
together. The hydrogel created has chemical stability, and the urea ex-
hibits favorable interactions with carboxymethyl cellulose (CMC) and
cellulose nanofibers (CNF). The gelation phenomenon in poly-
saccharides such as cellulose mainly occurs through the reaction be-
tween the ECH and hydroxyl (OH) groups on the polymer chain. As a
crosslinking agent, ECH provides many beneficial properties to the
resultant material - hydrogels have increased pore size, improved water
retention ability, enhanced chemical stability, and superior mechanical
strength (Kittipongpatana and Kittipongpatana,2013). Fig. 4 depicts the
suggested pathway as to how ECH crosslinks cellulose and CMC in an
alkaline medium. The hydroxyl group on CF or CMC reacts with NaOH
to form an alcoholate anion in a basic medium. The alcoholate anion
(RO− ) from cellulose or CMC attacks the epichlorohydrin molecule to
start the reaction. The alcoholate anion attacks the carbon atom
attached to chlorine in epichlorohydrin. Alcoholate anion attacks
epichlorohydrin, displaces chloride ion (Cl− ), and forms an ether link-
age. More epoxide forms when the chloride ion (Cl− ) reacts with water
(H2O) after being displaced from the monoether. The water hydroxyl
group replaces the chloride ion, forming a new epoxide molecule. Then,
the new epoxide reacted with another alcoholate anion and complete
the crosslinking process (Chang et al., 2010). Furthermore, the proposed
reaction suggests that cellulose in cellulose nanofiber form within the
hydrogel provides robust structural support, thereby preserving its ri-
gidity. Cellulose nanofibers have unique qualities, such as high me-
chanical strength and a large surface area. The urea is trapped within the
hydrogel during the gelation process. The interconnected crosslinked
structure in the hydrogel hinders the quick dissolution and release of
urea from the hydrogel. Crosslinking produces a homogenous porous
framework in the hydrogels, which is advantageous for more water
absorbance and subsequent retention. The porous nature allows for easy
diffusion and storage of water molecules, increasing swelling behavior.
The porous hollow structure allows the urea solution to stay within the
hydrogel only to be released slowly through diffusion along with the
degradation of the hydrogel structure. The FTIR results confirm the
presence of urea within the UCNF hydrogel in pure and unaltered form.
3.2. Water absorption and retention behavior of the UCNF hydrogel
The UCNF hydrogel contains hydrophilic –OH and ionizable
carboxylate (-COOH) groups, making the material hydrophilic. There-
fore, it can absorb water and swell when placed in a polar solvent such as
an aqueous solution. The dry hydrogel was immersed into different
aqueous solutions containing deionized water and different amounts of
common salts, such as 0.01% and 0.05% NaCl, KCl, NH4Cl, and CaCl2
solution, to check for the water absorption capacity of the hydrogel.
Fig. 5a provides the UCNF’s water absorption capacity over time when
placed in solutions with different salinity at neutral pH. It may be
observed that the highest degree of swelling occurred when the UCNF
hydrogel was placed in DI water. The maximum water absorption ca-
pacity was 147 g/g, about 150 times greater than the initial weight of
the dry UCNF. The swelling capacity decreased when placed in solutions
Fig. 4. Proposed mechanism of the crosslinking reaction of epichlorohydrin (ECH) with CNF and CMC to produce UCNF hydrogel.
P. E et al.
Journal of Cleaner Production 434 (2024) 140215
8
of higher salinity. This phenomenon of decreased water absorption of
UCNF hydrogel in media with higher salinity indicates that the water
absorption depends on the osmotic pressure differential between the
UCNF hydrogel and the surrounding media. The effect of different ion
types on the swelling ability of the UCNF is shown in Table 1. The type of
salt present in the water significantly impacts the hydrogel’s water ab-
sorption capacity. Among the salt solutions, a higher degree of swelling
occurred when the UCNF was placed in NH4Cl salt and lowest for the
CaCl2 salt solution. Monovalent cations possessing a lower charge and
exhibiting a larger ionic radius have a favorable impact, resulting in the
attainment of maximum swelling. Conversely, cations possessing a
divalent charge and exhibiting a smaller ionic radius exert a relatively
adverse influence, leading to less swelling. The sequence in which the
cations exhibit swelling is as follows: ammonium (NH+
4 ) > potassium
(K+) > sodium (Na+) > calcium (Ca2+) (Alam and Christopher, 2018;
Rizwan et al., 2021). Moreover, this phenomenon can be explained by
considering the exchange capabilities of several cations with varying
valencies. There is a positive correlation between the valency of a cation
and its exchange capacity, whereby an increase in cation valency leads
to a corresponding increase in exchange capacity. The observed phe-
nomenon can be attributed to the enhanced complexing ability resulting
from the coordination between multivalent cations, carboxylate, and
hydroxyl groups present in UCNF. The process of ionic crosslinking
primarily occurs on the surface of particles, resulting in their rubbery
and very rigid nature upon swelling in solutions having Ca2+ ions
(Cândido et al., 2013; Mahdavinia et al., 2004). Additionally, The ab-
sorption capacity of the hydrogel has an inverse relationship with the
salt sensitivity factor (f) (Alam et al., 2019).
In order to learn the process of water transportation in agriculture, it
is vital to investigate the swelling kinetics of CNF/CMC hydrogel loaded
with urea. Fig. S3 shows a log (Wt/Weq) versus log (t) plot for the water
absorption data obtained for the UCNF hydrogel when soaked in DI
water. An excellent fit was observed, with the correlation coefficient
value (r2 = 0.98) close to 1. The values of n and k obtained from the
fitted model were 0.651 and 0.019, respectively. Further, swelling ki-
netics parameters are indicated in Table S1. The Fickian diffusion
mechanism is found to be the rate-controlling step when the value of n
non-Fickian diffusion, reaching
saturation may be considerably prolonged. The phenomenon of mois-
ture sorption can be observed in two separate stages, usually known as
dual-stage sorption. The formation of hydrogen bonds between water
molecules and hydrophilic polymer chains can also account for the
occurrence of non-Fickian behavior. This binding and molecules’ sub-
sequent expansion and deformation can result in non-Fickian diffusion
behavior. Conversely, unbound water molecules within micro- and
macro gaps are responsible for generating Fickian diffusion behavior. A
plot of t/Wt versus t with the experimentally obtained data presented in
Fig. S4 helped to determine the kinetic parameters. A linear plot with a
high correlation coefficient (r2 = 0.99) was obtained, signifying that the
water absorption and swelling followed pseudo-second-order kinetics.
The Weq value of UCNF hydrogel was theoretically determined to be 147
g/g, almost the same as the experimentally obtained equilibrium
swelling capacity of the hydrogel. The ks value was also 7.64 × 10− 5 g g−
1min− 1 and is indicated in Table S1.
Fig. 5c shows the water retention behavior of the fully swollen UCNF
hydrogel. The graph depicts almost a linear decline in the quantity of
imbibed water over 16 days when kept under room conditions (25 ◦C
and 60% RH). Inside the soil matrix, the temperature would be lower
than the room temperature, and RH values shall be higher than the
ambient. Hence, in practice, the CNF hydrogel would retain water longer
than that observed in the laboratory experiment. Therefore, when used
in arid and semi-arid regions, the UCNF hydrogel shall release water
slowly so that there is no water shortage in the plants’ root zone for an
extended period. Thus, the UCNF would benefit sustainable agriculture
in arid and semi-arid regions. Fig. 5d shows the photographs of a dry
UCNF and a fully swollen UCNF. The extent of swelling can be quickly
figured out.
3.3. Biodegradability study
The material’s biodegradability is an essential virtue that makes
UCNF hydrogel a more sustainable SRF than other commercial variants.
We employed two methods to test its biodegradability – a biodegrad-
ability test with pure strains of bacteria under controlled conditions and
a natural biodegradability test by keeping UCNF under soil burial.
3.3.1. Biodegradability test with a pure bacterial strain
The biodegradability of the UCNF hydrogel was tested using two
pure species of bacteria, namely Bacillus subtilis and Pseudomonas aeru-
ginosa. Each species of bacteria was allowed to grow in a nutrient me-
dium containing inorganic micronutrients, in which a specific weight of
UCNF hydrogel was added so that the UCNF hydrogel was the only
source of organic carbon. Without any other organic material present,
the biodegradation of UCNF would provide the carbon source required
for the growth of the bacteria within the medium. A control experiment
was also run where UCNF hydrogel was added only to a sterilized
nutrient medium without containing any bacteria. The bacterial growth
was indirectly measured by observing changes in the optical density
(OD) of the medium at 600 nm wavelength with respect to the control.
Fig. 6a shows the gradual increase in the turbidity as measured by the
OD of the bacterial medium, indicating a gradual increase in bacterial
populations over 6 weeks. Fig. 6b shows the percentage of the initial
weight remaining over time for the UCNF hydrogel placed within the
bacterial medium. There was a gradual decrease in the weight of the
UCNF hydrogel, indicating that the material underwent biodegradation
over time. At the end of the 6 weeks, there was a significant reduction in
the weight of the UCNF. The SEM of the UCNF hydrogel after being kept
for 6 weeks within the control and in the two types of bacterial media,
are shown in Fig. 7. It is evident that compared to the control, the UCNF
has undergone significant fragmentation inside the bacterial media.
Figs. 6 and 7 show that B. subtilis strain was more effective in the
biodegradation of the hydrogel than the P. aeruginosa strain.
3.3.2. Soil burial test
The natural biodegradability of UCNF hydrogel was tested through
the soil burial experiments conducted by putting a known weight of fully
hydrated and swelled UCNF within the soil for varying time intervals. A
biodegradable substance has the ability to be broken down into simpler
compunds by naturally occurring decomposers. The material under
consideration should possess nontoxic characteristics and can undergo
decomposition within a short period. Within soil, the process of
biodegradation can occur in three distinct stages: biodeterioration,
biofragmentation, and assimilation. The process of biodeterioration in
materials is a consequence of several degradative factors, including
thermal degradation, mechanical degradation, and degradation result-
ing from the presence of oxygen, moisture, environmental pollutants,
and ultraviolet radiation (Arshad et al., 2014). As a consequence of the
Fig. 6. (a) Growth kinetics of B. subtilis and P. aeruginosa on UCNF hydrogel; (b) Weight residual percentage of UCNF hydrogel due to bacterial breakdown vs.
incubation period (c) Weight loss of UCNF after 3 months (biodegradation by soil burial method).
P. E et al.
Journal of Cleaner Production 434 (2024) 140215
10
aforementioned circumstances, a substantial quantity of microbes ad-
heres to the surface of biodegradable material. Biofragmentation is a
biological phenomenon characterized by the proliferation of microor-
ganisms which subsequently release enzymes and free radicals to facil-
itate the degradation of complex macromolecules into smaller units such
as oligomers, monomers, and dimers. During the process of assimilation,
microbes generate energy, new biomass, and different metabolites while
simultaneously releasing simple gaseous molecules and mineral salts
into the surrounding environment (Arshad et al., 2014; Falkiewicz-Dulik
and Michalina, 2010). The UCNF hydrogels were taken out at specific
time intervals and weighed so that the percentage weight loss of the
hydrogel over various burial times could be calculated. Fig. 6c shows the
percentage weight loss of the swollen UCNF over time after it was placed
under the soil. It may be observed that after 30 days, there was a loss of
only about 34% of the initial weight of the material due to biodegra-
dation. After 90 days, a weight loss of about 81% was observed.
3.4. Studies on the urea release by UCNF
The measurements performed during the synthesis indicated that the
UCNF had 92 wt% of urea loaded on the hydrogel. To observe the
dissolution kinetics of urea from the UCNF, a known weight of UCNF
was placed in sterile water under a nitrogen atmosphere with gentle
stirring, and a small volume of a sample of the solution was taken
regularly to determine urea content. Each time a sample was taken, it
was replaced by the same amount of sterile water to keep the total so-
lution volume constant. Fig. 8 shows the time history of the percentage
of initial urea content in the UCNF hydrogel released in the solution. It
may be observed that during the initial phase, up to 5 days, there was
only a 15% release of urea. Between days 5 and 20, over 60% of the urea
was released, whereas, between days 20 and 30, nearly 90% was
released. UCNF being a hydrogel, the increased water absorption results
in the diffusion of a larger quantity of water into the hydrogel network,
which subsequently leads to the discharge of a greater quantity of urea
molecules. In addition, a densely interconnected structure can effec-
tively retain urea molecules, leading to a gradual releasefrom the
hydrogel matrix. The change in osmotic pressure between the inside and
outside of the gel is the cause of the urea being released by the hydrogel
and diffusing throughout the porous network structure. Table 2 is a
comparison between the percentage of urea release from UCNF and
other slow-release fertilizers at specific points in time.
3.5. Plant study
Once the slow-release properties of UCNF hydrogel have been
established, it is customary to validate the UCNF slow-release fertilizer’s
performance through real-life plant studies. We undertook a study to
observe the growth of wheatgrass plants in pots under controlled envi-
ronmental conditions using different amounts of UCNF and pure urea as
a fertilizer. All the experiments were performed in triplicate, with each
pot containing plants germinated out of 50 seeds (Fig. S5). The study
groups had one control group without any fertilizer and four groups
containing fertilizer in the form of either UCNF or urea. Among the four
groups containing fertilizer, two groups had UCNF as fertilizer con-
taining 1g and 3g of UCNF. The other two groups had 0.4 g and 1.2 g of
pure urea, the same as the amount of urea contained in 1g and 3g UCNF,
respectively. The average root and shoot length values of plant growth
were used for further analysis. Fig. 9a shows a photograph of the growth
of the wheat plants after two (2) weeks of germinating the seeds. It may
be observed that the wheatgrass grown with UCNF exhibited more
growth in terms of size and height compared to the control group and
pure urea. Fig. 9b shows the photograph of the shoot and root of the
plants grown in pots treated with different amounts of UCNF and pure
urea.
Fig. 9c presents a quantitative comparison of the effect of UCNF and
pure urea on the root and shoot length of the plant samples. Using the
UCNF as a fertilizer effectively imparted higher growth in the wheat-
grass plant. Fig. 9d shows the fresh and dry weight of the plants after 14
days of germination. The effect of UCNF on the plants’ length and weight
is evident. Thus, the results indicate that the use of UCNF could poten-
tially enhance the process of seed germination and subsequent growth.
Additionally, the quality of the wheatgrass was enhanced, as indicated
by the increased plant height with a higher amount of UCNF.
Fig. 7. SEM images of UCNF hydrogel after 6 weeks of residence in an aqueous medium with inorganic micronutrients when: (a) the medium was sterile; (b)
inoculated with B. subtilis; and (c) inoculated with P. aeruginosa.
Fig. 8. Urea release profile of the UCNF hydrogel over time when placed in
DI water.
P. E et al.
Journal of Cleaner Production 434 (2024) 140215
11
3.6. Cost analysis
Cost assessment is essential before the commercialization of any
product synthesized in the laboratory. The cost analysis of UCNF
hydrogel was carried out only on the basis of material and energy bal-
ance applied on a batch size synthesized from 20 g of raw wood fiber.
Table S2 shows the prices of chemicals and electrical energy in India,
based on which the cost of production of UCNF has been calculated in
Table S3 using energy consumption and material balance. Results of the
study reveal that the estimated cost of the UCNF per kg without labor
cost and profit would be $7.23, taking into account the subsidized rate of
urea in India. The cost marginally increases to around $7.38 per kg when
considering the international price of urea. Slow-release fertilizers are
currently available in the Indian market. Some examples include
Nutricote 13-11-11 type 180, Basacote plus6M, and Wonder Cote 90,
priced at $15.56, $13.36, and $12.02 per kg, respectively. Slow-release
fertilizers such as Osmocote Plus 15-9-12, Osmocote Smart-Release, and
Jack’s nutrient bloom fertilizer 10-30-20 are available internationally at
prices of $7.48, $22.16, and $25.94 per kg, respectively. UCNF contains
only urea, whereas slow-release fertilizers normally encompass nitrogen
(N), phosphorous (P), and potassium (K). If P and K had been incorpo-
rated, UCNF would have an estimated cost of INR 633.67 per kg,
approximately equivalent to $7.62/kg. Thus, it can be concluded that
the UCNF would have a price likely to be comparable and competitive
Table 2
The percentage urea release of UCNF compared to other slow-release fertilizers.
Type of fertilizer Nutrient Nutrient release performance in
water
biodegradation References
UCNF urea 33 % released in 10 days After 90 days, a weight loss of about
81%
This study
CCDEUs-g-poly(AA)/urea slow-release fertilizer urea 40.1% after 10 h. Superabsorbent biodegradability was
39.14% after 40 days.
Mohammadbagheri et al.
(2021)
CSt-g-PAA/NR/PVA semi-IPN hydrogel (BHWCU/
9:1)
urea 41.5% released in 7 days Biodegradation of the material is 77.8
after the 90 days
Tanan et al. (2021)
NR/Cassava Starch (W-IPN-CUB) urea 100 % released in 72 h 48% of the biodegradability after 90
days
Vudjung and Saengsuwan
(2018)
SC-g-PAA/PAM/Urea urea 82 % released in 8 h – Nomura and Terwilliger
(2020)
carboxymethylcellulose and
hydroxyethylcellulose (H15CA)
urea 80 % released in 5 days 87.5 % degradation in 20 days Durpekova et al. (2021)
CNFs were loaded with nitrogen-based fertilizer
(ammonium chloride) in 1:1
Ammonium
chloride
58% cumulative release of
ammonium ions within 8 days
– Sharma et al. (2023)
P(AM-co-NHMA) hydrogel Synthetic (P(AM-co-
NHMA)/U 4)
urea Around 43 % were released within
3 days
– Kiran et al. (2019)
Fig. 9. (a) Photograph of plants after two weeks of seeding under different doses of UCNF fertilizer and pure urea; (b) photographs of the shoot and root of the plants
grown with different amounts of UCNF and pure urea; (c) the lengths of shoots and roots and (d) the fresh and dry weight of plants after two weeks of seeding under
different dose of UCNF fertilizer and pure urea.
P. E et al.
Journal of Cleaner Production 434 (2024) 140215
12
with other commercially available slow-release fertilizers, but being
completely biodegradable would provide excellent environmental sus-
tainability over other products.
4. Conclusion
This study indicates the synthesis of a biodegradable UCNF hydrogel
via solution polymerization utilizing water as the reaction medium. The
FTIR, XRD, and SEM techniques were employed to determine the
structural morphology of the synthesized CNF and UCNF hydrogel. TGA
data indicates that the synthesized UCNF hydrogel is thermally stable.
The hydrogel synthesized demonstrated potential for agricultural
application due to its optimal blend of natural polysaccharides cellulose
and carboxyl methylcellulose, which met the necessary criteria,
including biodegradability. The synthesized hydrogel exhibited a
remarkable capacity for water absorption and demonstrated an excellent
ability to retain water. The synthesized hydrogel shows a water trans-
port mechanism following non-Fickian-type diffusion. The investigation
of the pseudo-second-order kinetics model suggests that the theoretical
water swelling capacity closely approximates the observed experimental
values. The loading capacity of urea was demonstrated to be 92% in
terms of efficiency. One significant outcome of this study was the
development of UCNF for the slow release of urea in agricultural ap-
plications. Moreover, it exhibits exceptional urea encapsulation perfor-
mance and enables slow regulation of urea discharge. The incorporation
of UCNFinto soil exhibited a significant positive impact on both seed
germination and plant growth. The cellulose nanofibers can also be
derived from agricultural residues, thereby addressing the waste mate-
rial’s upcycling and reusability. Thus, this study would usher in a new
direction toward synthesizing biodegradable hydrogel fertilizer exhib-
iting exceptional water retention and controlled nutrient release
capabilities.
CRediT authorship contribution statement
Priya E: Conceptualization, Data curation, Formal analysis, Inves-
tigation, Methodology, Writing – original draft. Akash Jha: Data cura-
tion, Investigation. Sudipta Sarkar: Conceptualization, Supervision,
Validation, Visualization, Writing – review & editing. Pradip K. Maji:
Conceptualization, Supervision, Validation, Visualization, Writing –
review & editing.
Declaration of competing interest
None.
Data availability
No data was used for the research described in the article.
Acknowledgments
This work was supported by the Department of Science and Tech-
nology, Govt of India [DST/TDT/AGRO-39/2020]; and the Council of
Scientific and Industrial Research, Govt of India [09/143(0971)/2019-
EMR-I].
Appendix A. Supplementary data
Supplementary data to this article can be found online at https://doi.
org/10.1016/j.jclepro.2023.140215.
References
Abe, K., Yano, H., 2011. Formation of hydrogels from cellulose nanofibers. Carbohydr.
Polym. 85, 733–737. https://doi.org/10.1016/J.CARBPOL.2011.03.028.
Ahmed, E.M., 2015. Hydrogel: preparation, characterization, and applications: a review.
J. Adv. Res. 6, 105–121. https://doi.org/10.1016/J.JARE.2013.07.006.
Alam, M.N., Christopher, L.P., 2018. Natural cellulose-chitosan cross-linked
superabsorbent hydrogels with superior swelling properties. ACS Sustain. Chem.
Eng. 6, 8736–8742. https://doi.org/10.1021/acssuschemeng.8b01062.
Alam, M.N., Islam, M.S., Christopher, L.P., 2019. Sustainable production of cellulose-
based hydrogels with Superb absorbing potential in physiological saline. ACS Omega
4, 9419–9426. https://doi.org/10.1021/acsomega.9b00651.
Alhaj Hamoud, Y., Shaghaleh, H., Guo, X., Zhang, K., 2023. pH-responsive/sustained
release nitrogen fertilizer hydrogel improves yield, nitrogen metabolism, and
nitrogen use efficiency of rice under alternative wetting and moderate drying
irrigation. Environ. Exp. Bot. 211, 105376 https://doi.org/10.1016/j.
envexpbot.2023.105376.
Arafa, E.G., Sabaa, M.W., Mohamed, R.R., Kamel, E.M., Elzanaty, A.M., Mahmoud, A.M.,
Abdel-Gawad, O.F., 2022. Eco-friendly and biodegradable sodium alginate/
quaternized chitosan hydrogel for controlled release of urea and its antimicrobial
activity. Carbohydr. Polym. 291, 119555 https://doi.org/10.1016/J.
CARBPOL.2022.119555.
Ardebili, H., Zhang, J., Pecht, M.G., 2018. Characterization of encapsulant properties.
Encapsulation Technologies for Electronic Applications. https://doi.org/10.1016/
B978-0-12-811978-5.00006-7.
Arshad, K., Skrifvars, M., Vivod, V., Valh, J.V., Vončina, B., 2014. Str. 118-132
biodegradation of natural textile materials in soil tekstilec, 57(2), Letn 57, 118–132.
https://doi.org/10.14502/Tekstilec2014.57.118.
Baldrian, P., Valášková, V., 2008. Degradation of cellulose by basidiomycetous fungi.
FEMS Microbiol. Rev. 32, 501–521. https://doi.org/10.1111/j.1574-
6976.2008.00106.x.
Bao, Y., Ma, J., Li, N., 2011. Synthesis and swelling behaviors of sodium carboxymethyl
cellulose-g-poly(AA-co-AM-co-AMPS)/MMT superabsorbent hydrogel. Carbohydr.
Polym. 84, 76–82. https://doi.org/10.1016/j.carbpol.2010.10.061.
Besbes, I., Vilar, M.R., Boufi, S., 2011. Nanofibrillated cellulose from Alfa, Eucalyptus
and Pine fibres: preparation, characteristics and reinforcing potential. Carbohydr.
Polym. 86, 1198–1206. https://doi.org/10.1016/J.CARBPOL.2011.06.015.
Bora, A., Karak, N., 2022. Starch and itaconic acid-based superabsorbent hydrogels for
agricultural application. Eur. Polym. J. 176, 111430 https://doi.org/10.1016/J.
EURPOLYMJ.2022.111430.
Borsoi, C., Zimmernnam, M.V.G., Zattera, A.J., Santana, R.M.C., Ferreira, C.A., 2016.
Thermal degradation behavior of cellulose nanofibers and nanowhiskers. J. Therm.
Anal. Calorim. 126, 1867–1878. https://doi.org/10.1007/s10973-016-5653-x.
Brack, W., Heine, B., Birkhold, F., Kruse, M., Schoch, G., Tischer, S., Deutschmann, O.,
2014. Kinetic modeling of urea decomposition based on systematic
thermogravimetric analyses of urea and its most important by-products. Chem. Eng.
Sci. 106, 1–8. https://doi.org/10.1016/j.ces.2013.11.013.
Cândido, J.D.S., Pereira, A.G.B., Fajardo, A.R., Ricardo, N.M.P.S., Feitosa, J.P.A.,
Muniz, E.C., Rodrigues, F.H.A., 2013. Poly(acrylamide-co-acrylate)/rice husk ash
hydrogel composites. II. Temperature effect on rice husk ash obtention. Compos. Part
B Eng. 51, 246–253. https://doi.org/10.1016/j.compositesb.2013.03.027.
Chang, C., Lue, A., Zhang, L., 2008. Effects of crosslinking methods on structure and
properties of cellulose/PVA hydrogels. Macromol. Chem. Phys. 209, 1266–1273.
https://doi.org/10.1002/MACP.200800161.
Chang, C., Duan, B., Cai, J., Zhang, L., 2010. Superabsorbent hydrogels based on
cellulose for smart swelling and controllable delivery. Eur. Polym. J. 46, 92–100.
https://doi.org/10.1016/J.EURPOLYMJ.2009.04.033.
Chhajed, M., Yadav, C., Agrawal, A.K., Maji, P.K., 2019. Esterified superhydrophobic
nanofibrillated cellulose based aerogel for oil spill treatment. Carbohydr. Polym.
226, 115286 https://doi.org/10.1016/J.CARBPOL.2019.115286.
Chhajed, M., Verma, C., Sathawane, M., Singh, S., Maji, P.K., 2022. Mechanically durable
green aerogel composite based on agricultural lignocellulosic residue for organic
liquids/oil sorption. Mar. Pollut. Bull. 180, 113790 https://doi.org/10.1016/J.
MARPOLBUL.2022.113790.
De, B., Gupta, K., Mandal, M., Karak, N., 2014. Biodegradable hyperbranched epoxy from
castor oil-based hyperbranched polyester polyol. ACS Sustain. Chem. Eng. 2,
445–453. https://doi.org/10.1021/SC400358B/ASSET/IMAGES/LARGE/SC-2013-
00358B_0008.JPEG.
De Miguel, I., Rieumajou, V., Betbeder, D., 1999. New methods to determine the extent
of reaction of epichlorohydrin with maltodextrins. Carbohydr. Res. 319, 17–23.
https://doi.org/10.1016/S0008-6215(99)00108-1.
Dhanapal, V., Subhapriya, P., Nithyanandam, K.P., Kiruthika, M.V., Keerthana, T.,
Dineshkumar, G., 2021. Design, synthesis and evaluation of N,N1-
methylenebisacrylamide crosslinked smart polymer hydrogel for the controlled
release of water and plant nutrients in agriculture field. Mater. Today Proc. 45,
2491–2497. https://doi.org/10.1016/j.matpr.2020.11.101.
Di Martino, A., Khan, Y.A., Durpekova, S., Sedlarik, V., Elich, O., Cechmankova, J., 2021.
Ecofriendly renewable hydrogels based on whey protein and for slow release of
fertilizers and soil conditioning. J. Clean. Prod. 285, 124848 https://doi.org/
10.1016/J.JCLEPRO.2020.124848.
Durpekova, S., Di Martino, A., Dusankova, M., Drohsler, P., Sedlarik, V., 2021.
Biopolymer hydrogel based on acid whey and cellulose derivatives for enhancement
water retention capacity of soil and slow release of fertilizers. Polymers 13. https://
doi.org/10.3390/polym13193274.
Dutta, G.K., Karak, N., 2018. One-pot synthesis of bio-based waterborne polyester as UV-
resistant biodegradable sustainable material with controlled release attributes. ACS
Omega 3, 16812–16822. https://doi.org/10.1021/ACSOMEGA.8B02790/ASSET/
IMAGES/MEDIUM/AO-2018-02790W_M004.GIF.
Eichelbaum, M., Farrauto, R.J., Castaldi, M.J., 2010. The impact of urea on the
performance of metal exchanged zeolites for the selective catalytic reduction of NOx.
P. E et al.
https://doi.org/10.1016/j.jclepro.2023.140215
https://doi.org/10.1016/j.jclepro.2023.140215
