A simple neural vector space model for medical concept
normalization using concept embeddings
Dongfang Xu,
Computational Health Informatics Program, Boston Children’s Hospital, Boston, Massachusetts,
USA
Department of Pediatrics, Harvard Medical School, Boston, Massachusetts, USA
Timothy Miller
Computational Health Informatics Program, Boston Children’s Hospital, Boston, Massachusetts,
USA
Department of Pediatrics, Harvard Medical School, Boston, Massachusetts, USA
Abstract
Objective—Medical concept normalization (MCN), the task of linking textual mentions to
concepts in an ontology, provides a solution to unify different ways of referring to the same
concept. In this paper, we present a simple neural MCN model that takes mentions as input and
directly predicts concepts.
Materials and Methods—We evaluate our proposed model on clinical datasets from ShARe/
CLEF eHealth 2013 shared task and 2019 n2c2/OHNLP shared task track 3. Our neural MCN
model consists of an encoder, and a normalized temperature-scaled softmax (NT-softmax) layer
that maximizes the cosine similarity score of matching the mention to the correct concept.
We adopt SAPBERT as the encoder and initialize the weights in the NT-softmax layer with
pre-computed concept embeddings from SAPBERT.
Results—Our proposed neural model achieves competitive performance on ShARe/CLEF 2013
and establishes a new state-of-the-art on 2019-n2c2-MCN. Yet this model is simpler than most
prior work: it requires no complex pipelines, no hand-crafted rules, and no preprocessing, making
it simpler to apply in new settings.
Discussion—Analyses of our proposed model show that the NT-softmax is better than the
conventional softmax on the MCN task, and both the CUI-less threshold parameter and the
initialization of the weight vectors in the NT-softmax layer contribute to the improvements.
Conclusion—We propose a simple neural model for clinical MCN, an one-step approach with
simpler inference and more effective performance than prior work. Our analyses demonstrate
future work on MCN may require more effort on unseen concepts.
Corresponding Author: Dongfang Xu, PhD, Computational Health Informatics Program, Boston Children’s Hospital, 300 Longwood
Avenue, Boston, MA 02115-5724, USA, Dongfang.Xu@childrens.harvard.edu, Phone: 520-301-6605.
COMPETING INTERESTS
None declared.
HHS Public Access
Author manuscript
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
Published in final edited form as:
J Biomed Inform. 2022 June ; 130: 104080. doi:10.1016/j.jbi.2022.104080.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
Keywords
Deep Learning; Natural Language Processing; Medical Concept Normalization; Vector Space
Model; Normalized Temperature-scaled Softmax
1. Introduction
Mining and analyzing the constantly-growing unstructured text from the clinical notes offers
great opportunities to improve a wide range of medical and healthcare practices, ranging
from clinical trial recruitment[1] to pharmacovigilance[2,3] to clinical decision support[4,5].
However, texts describing biomedical concepts such as findings, symptoms, diseases,
diagnoses, procedures, and medications have many morphological and orthographical
variations, and utilize different word orderings or equivalent words. For instance, heart
attack, coronary attack, MI, myocardial infarction, cardiac infarction, and cardiovascular
stroke all refer to the same concept. Linking such terms with their corresponding concepts
in an ontology or knowledge base is critical for data interoperability and the development of
downstream natural language processing (NLP) techniques.
Medical concept normalization (MCN) -- a form of entity linking or entity normalization
in the biomedical domain -- maps concept mentions, the in-text natural-language mentions
of medical concepts, to concept entries in a standardized ontology or knowledge base.
In this work, we focus on MCN in clinical notes since it is less studied compared with
MCN in consumer health[6–8] or in scientific articles[9–12], largely due to fewer publicly
available datasets and the restrictions of data use agreements. Three main challenges of
MCN include: 1) novel concept mentions (i.e., CUI-less mentions) that may not be linked
to any concepts in an ontology, 2) ambiguous mentions where a single term/phrase can
refer to multiple distinct concepts, 3) lexical variants of concept mentions such as aliases,
misspellings, abbreviations, etc. Among these challenges, ambiguity is less common in
the existing clinical MCN datasets[13–16]. So, in the following sections, we focus on the
approaches that only take the mentions as input, and leave the resolution of ambiguous
mentions, which will require exploration of contextual information, for future work.
Approaches developed for the clinical MCN datasets include rule-based approaches and
supervised-based approaches. Rule-based approaches[13,17–21] focus on how to construct
a look-up dictionary and conduct string matching. They rely heavily on matching rules and
domain knowledge, for example, D’Souza et al.[13] define 10 types of rules at different
priority levels to measure morphological similarity between mentions and concept names
from an ontology, Kate[18,21] implements a system to automatically learn the generalizable
edit distance patterns from the Unified Medical Language System (UMLS) and the given
training data. These approaches are easy to interpret how they normalize mentions, but they
work poorly when there is a lack of lexical overlap between mentions and concept names,
for example, in consumer health data like social media posts[6].
Supervised-based approaches can be categorized into classification-based approaches,
learning to rank approaches, and vector space models (VSMs). Classification-based
approaches[6,22–26] take mentions as input to various neural architectures such as Gated
Xu and Miller Page 2
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
Recurrent Units (GRU) with attention mechanisms[26] or pre-trained transformer networks
with extra features[23], and predict their concept using a softmax classification layer. Such
approaches work well on a few consumer-health datasets[6,23], where only a smaller subset
of medical concepts are of interest, and each concept has a few more training examples,
but such classification-based approaches struggle when there are hundreds of thousands
of concepts in an ontology and the annotated training data does not contain examples
for all concepts. To alleviate the problems of classification-based approaches, researchers
apply learning to rank approaches [14,16,27–32], such as a generate-and-rank framework
that typically includes a non-trained candidate generator that generates a smaller list of
candidate concepts, and a supervised candidate ranker that takes both mention and candidate
concept as input to rank the candidate concepts. However, these approaches require complex
pipelines and fail if their candidate generators do not find the gold-truth concepts.
Recently, VSMs have been widely applied in the MCN because they set up MCN as
a one-step process requiring no complex pipelines: they encode mentions and concept
names as vectors, and mentions are matched to concepts by computing the vector
similarity between vector representations of mentions and of all concept names from an
ontology. They are trained via similar objectives that pull semantically close texts together
and pushes apart semantically dissimilar ones, but differ in their implementations, e.g.,
different encoders such as ELMO[33] or pre-trained transformer networks[34–38], different
instance mining techniques such as online hard instance mining[34–36,38] or offline hard
instance mining[33,37],different loss functions such as multi-similarity loss[34], cosine
similarity loss[38], triplet loss[37], adaptive hinge loss[33], batch hard soft margin loss[36],
or maximizing the marginal likelihood over synonyms[35]. Amongst these approaches,
SAPBERT[34] and BIOSYN[35] (when initialized with SAPBERT) achieve new state-of-
the-art performances on multiple MCN tasks in social media domain and scientific article
domain, but it is unclear whether these approaches are generalizable in clinical texts where
there are more CUI-less mentions. Another limitation of these two approaches is that they
separate their training objectives from the task objective. So to predict concepts during
inference, they first match the mention representation to the representation of concept
text using nearest neighbor’s search, and then find the corresponding concept (unique
identifier) for that concept text, which is not always a one-to-one mapping. For instance,
the concept text “potassium” can be mapped to the medical substance (C0032821) or the
procedure of measuring potassium (C0202194), and their solution is to pick one arbitrarily.
Besides, each concept has multiple texts (synonyms), and searching over texts is more
computationally expensive than searching over concepts, especially considering all the
concepts from UMLS1. To alleviate these limitations, Xu et al.[36] explore similarity search
using the concept representations, but their concept representations are not learnable during
the training of VSM.
In this paper, we propose a neural MCN model (shown in Figure 1) that takes the mention
texts as input and directly predicts the medical concept or the CUI-less label. Our system
consists of a transformer network that encodes the mention as a vector, and a normalized
1The 2021AB Metathesaurus contains approximately 4.54 million concepts and 16.5 million unique concept names from 220 source
vocabularies. Searching over concept names requires 4 times more computation.
Xu and Miller Page 3
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
temperature-scaled softmax (NT-softmax) layer that maximizes the cosine similarity score
of matching the mention to the correct concept label, where the representation for each
concept is pre-computed and then updated during training. Our system outperforms previous
state-of-the-art systems on two clinical MCN datasets, and is simpler than most prior work–
it requires no pre-processing, no complex pipelines, no rules for CUI-less prediction, and
no nearest neighbor’s search. We also conduct analysis to understand what contributes to
the improvements, where we find that NT-softmax layer is better than the conventional
softmax, and initializing the weights in NT-softmax using concept embeddings generated
from SAPBERT further improves the performance.
2. MATERIALS AND METHODS
2.1. Dataset
To the best of our knowledge, there are four shared tasks for MCN in clinical notes,
including ShARe/CLEF eHealth 2013, SemEval-2014 Task 7, SemEval-2015 Task 14,
and 2019 n2c2/OHNLP shared task track 3. The first three shared tasks focus on the
normalization of disease/disorder concept mentions from the same ShARe corpus, and
datasets used in these tasks are built on each other by iteratively adding more annotations
each year. The 2019 n2c2/OHNLP shared task track 3 uses the MCN corpus[39] (named
2019-n2c2-MCN), and covers a broader set of concepts including medical problems,
treatments, and tests. In this study, we select the datasets from ShARe/CLEF eHealth 2013
and the 2019 n2c2/OHNLP shared task track 3. Table 1 shows the statistics of these two
datasets.
The ShARe/CLEF 2013 corpus consists of 298 de-identified clinical notes from the ShARe
corpus. Each note was annotated for mentions of disorders and normalized using 88,150
CUIs from the SNOMED CT subset of the 2012AB version of UMLS. We keep the same
shared task setting: 199 clinical notes consisting of 5,816 disorder mentions are used as the
train and development set, and 5,351 mentions from the remaining 99 clinical notes as the
test set. One characteristic in this dataset is that around 30.4% of the mentions could not
be mapped to any concepts in an ontology, and are assigned the CUI-less label. The 2019-
n2c2-MCN corpus contains 100 clinical notes derived from the 2010 i2b2/VA shared task.
All the mentions are mapped to one of 434,056 possible concepts from the SNOMED-CT
and RxNorm subset of UMLS version 2017AB. We take 40 clinical notes from the released
data as training, consisting of 5,334 mentions, and the standard evaluation data from 50
notes with 6,925 mentions as our test set. Around 2% of mentions in 2019-n2c2-MCN are
assigned the CUI-less label.
From table 1, we can see that both two datasets have few ambiguous mentions – 4.5%
mentions on the ShARe/CLEF 2013 test set and 2.8% mentions on the 2019-n2c2-MCN test
set – so the context where mentions appear plays only a minor role in these datasets. Two
major challenges for these two datasets are the unseen concepts (concepts that do not appear
in the train or dev set, but appear in the test set) and fewer instances per concept label:
11.6% of unseen concepts on the ShARe/CLEF 2013, while 29.8% of unseen concepts on
the 2019-n2c2-MCN; around 6 instances per concept on the ShARe/CLEF 2013, while only
Xu and Miller Page 4
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
2.5 instances per concept on the 2019-n2c2-MCN. Systems that memorize the training data
or rely on it to determine the space of output concepts will thus perform poorly.
2.2. System description
We define a concept mention m as a textual string of medical concept. Given a list of
pre-identified concept mentions {m1, m2,…,mt} from clinical notes, an ontology O with a
set of concepts {c1, c2,…,cn}, the goal of MCN is to find a mapping function that maps each
textual mention m to its corresponding concept c, or CUI-less label if there is no mapping
concept for m.
We propose a neural MCN model that mainly consists of a transformer network and a
NT-softmax layer (shown in figure 1). We first take mention m as input to the transformer
network to generate a vector representation f(m); our NT-softmax layer computes the cosine
similarity score si between the input f(m) and the weight vector wi for each concept ci in
an ontology, formally, si = (wi, f(m)). To model the CUI-less label, we adopt a learnable
scalar parameter s0 as a threshold to encourage max
1 ≤ i ≤ n
si > s0 for all linkable mentions, and
max
1 ≤ i ≤ n
si 0) or CUI-less label (i = 0),
p i m =
exp si
τ
∑j = 0
n exp sj
τ
(1)
where si = (wi f(m))/‖wi f(m)‖ is the dot product between l2 normalized wi and f(m), i.e., si =
cosine(wi, f(m)); τ is a temperature/scaling parameter that controls the concentration level of
the distribution[40]. For simplicity, we ignore the s0 in the following system description.
We adopt the off-the-shelf SAPBERT[34] as the encoder to generate vector representations,
where the representation for each mention f(m) could be the representation from the [CLS]
token or an average pooling of the representations for all sub-word tokens. SAPBERT
is initialized with PubMedBERT[41], and further fine-tuned on UMLS synonyms via a
contrastive learning objective. SAPBERT has shown better capabilities than PubMedBERT
(a state-of-the-art pre-trained language model for the biomedical domain) in representing
medical texts in a well-separated space. Inspired by the technique of memory bank incontrastive learning[42,43], we similarly maintain a matrix to store the representations for
all concepts by initializing the weight vectors W in NT-softmax layer with a pre-computed
concept embeddings matrix V. We compute the concept embedding vi by averaging the
representations of all the synonyms of this concept ci generated by SAPBERT, formally,
vi = Avg
tci ∈ Text ci
f tci
(2)
Where Text(ci) is all the concept texts denoting concept ci, including synonyms from
an ontology and mentions from an annotated corpus. Conceptually, initializing with such
Xu and Miller Page 5
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
concept embeddings can speed up the training process since both mention representation and
concept embeddings are generated from the same encoder, and the embeddings for different
concepts from SAPBERT are better separated than randomly initialized weight vectors.
2.2.1. Normalized Temperature-scaled Softmax—To explain the NT-softmax in our
model, we first compare NT-softmax with the conventional softmax where it approaches
MCN as a multiclass classification problem, and each concept including the CUI-less label
is an individual class. However, unlike typical classification settings where the class size
is small, and each class has many instances, in most MCN tasks, we have more than ten
thousand concepts in an ontology, and each concept only has few training instances. During
each mini-batch training, we only have mentions from tens of concepts, and only weight
vectors of these concepts are activated, which leads to large variance of gradients for the
weight vectors and thus cannot be learned effectively[42]. Another limitation of directly
applying softmax to MCN is the modeling of the CUI-less label, where it assumes all the
CUI-less mentions are encoded in the similar output space. However, this assumption is
inappropriate for CUI-less mentions, as they represent areas of the ontology with lack of
coverage, but do not necessarily share semantics, and would therefore be likely to map to
highly varying parts of the concept space.
Under the conventional softmax formulation, the probability of a mention being classified as
ith concept is,
p ci m = exp si
∑j = 0
n exp sj
(3)
where the similarity metric si = wiTf m is an inner product between a mention
representation f(m) and a weight vector wi for concept ci. Comparing equation (1) and
(3), there are two differences: l2 normalized inner product (cosine similarity) and scaling
parameter. For l2 normalized inner product, previous experiments[42–47] show that the
angle between feature vectors is also a good similarity metric compared with Euclidean
distance or inner-product operations. As for the scaling parameter, it is an important
hyperparameter for learning from cosine similarity score[44]. Wang et al.[40] also show
that the scaling parameter plays a role in controlling the strength of penalties on the hard
negative samples, in our case, the mentions that are likely to be mapped to incorrect
concepts but with high cosine similarity scores.
We further discuss the connection of our NT-softmax layer with contrastive learning
approach as the NT-Softmax is also widely used there[43,45,46,48]. In contrastive learning,
the probability of text tci have the same concept as tcj is:
Pi, j =
exp si, j
τ
∑k ≠ iexp si, k
τ + exp si, i
τ
(4)
Xu and Miller Page 6
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
where si, j = cosine f tci , g tcj , the cosine similarity score between texts of the ith and jth
concept. In most contrastive learning approaches[45,46,48], g(∙) is the same encoder as f(∙),
and the negative examples are sampled within a smaller mini-batch. Meanwhile, g(∙) could
also be a memory bank[42,43], a matrix to store the representation for all the available
concepts in an ontology, and during training the negative examples are sampled from the
entire ontology. Our NT-softmax layer has commonalities with both settings: firstly, g(∙) is
a weight matrix in the NT-softmax layer, which is able to compare a mention against all the
concepts during the training; secondly, the concept embeddings used to initialize the matrix
g(∙) are computed using the encoder f(∙).
2.3. Implementation Details
Unless specifically noted otherwise, we keep the default hyper-parameters as in
huggingface’s pytorch implementation across all datasets. We set the learning rate = 2e-5,
sequence length=16, and temperature parameter τ =0.03 for both two dataset. On ShARe/
CLEF 2013 dataset, we set the batch size = 16, epoch size =10, and s0 = 0.9; on the 2019-
n2c2-MCN dataset, we set batch size = 128, epoch size = 5, and s0 = 0.65. Following the
setting in[36], we combine the mentions from annotated datasets and synonyms from their
corresponding ontologies to train our system. During the training of our system, we initialize
the weight vectors at the NT-softmax layer with pre-computed concept embeddings, and
keep them learnable. We experiment with different settings for CUI-less threshold s0,
and it turns out fixing s0 during training leads to better performance. In our preliminary
experiments, we experimented with both the [CLS] token and the average pooling of all
sub-word tokens to generate the representations. We found average pooling achieved slightly
better performance, so we stick with this choice for all the experiments.
2.4. Experiments
2.4.1. Evaluation Metrics—For all the experiments, we adopt the standard evaluation
metrics accuracy for MCN, which was the percentage of entity mentions that were correctly
normalized.
Comparison with Related Work: We compare our proposed approaches with the current
related work.
• Sieve-based dictionary look-up[13,39]: rule-based approaches that carefully
selects combinations and orders of dictionaries, exact and partial matching, and
heuristic rules.
• BERT-based ranker[14,29]: a generate and rank framework that consists of a
dictionary look-up system and a supervised candidate ranker.
• VSM triplet network[36]: a vector space model that encodes mentions and
concepts as vectors via a transformer network. The transformer network is
trained via a triplet objective with online hard triplet mining.
• SAPBERT[34] (off-the-shelf): a state-of-the-art MCN system on the social
media and science articles dataset. The architecture of SAPBERT is similar
Xu and Miller Page 7
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
to[36] but trained on all the concept synonyms from UMLS via a multi-similarity
loss.
• SAPBERT (fine-tuned): the off-the-shelf SAPBERT model that is further fine-
tuned on the ShARe/CLEF 2013 and 2019-n2c2-MCN dataset.
Since our focus is individual systems, not ensembles, we compare only to other non-
ensembles. TTI-COIN [49] is an ensemble system of five different runs that achieves
85.26 on 2019-n2c2-MCN. Their individual model is a transformer network that takes
mention as input to generate a vector representation, which is then matched to learnable
concept vectors to compute cosine similarity. The cosine similarity is then fed to an ArcFace
loss[50] for optimization. Their individual model is like our approach, but requires two-step
training. The average performance of five individual system runs (TTI-COIN-Average) is
84.40%[51].
2.4.2. Models—For all the models, we apply SAPBERT as encoders and experiment
with the following output layers:
• NT-softmax: our complete model with an NT-softmax layer and a threshold
parameter to model the CUI-less label. The weight vectors in NT-softmax are
initialized with the pre-computed conceptembeddings from SAPBERT.
• NT-softmax (Random): same as our complete model but with weight vectors
randomly initialized.
• NT-softmax (Fixed): same as our complete model, except that the weight vectors
initialized with the pre-computed concept embeddings from SAPBERT are not
updated during fine-tuning.
• Softmax: a conventional softmax layer that approaches the concept normalization
as a multiclass classification problem, where each concept including the CUI-
less label is an individual class. The weight vectors are randomly initialized.
• Softmax (CUI-less): similar to the above conventional softmax, but modeling the
CUI-less label using a threshold parameter as in NT-softmax.
3. RESULTS
Table 2 shows the results of our proposed models on two clinical MCN datasets, alongside
the best models in the literature. Our complete model -- SAPBERT + NT-softmax --
achieves competitive performance on ShARe/CLEF 2013 and establishes a new state-of-the-
art on 2019-n2c2-MCN: our model outperforms the previous state-of-the-art[13, 14] by
small margins, and yet it requires no complex pipelines, no hand-crafted rules, and no
preprocessing such as acronym expansion and spelling corrections; on 2019-n2c2-MCN, a
dataset with a more realistic setting where the number of candidate concepts is large and
many test concepts were never seen during training, we see bigger performance gains over
previous work, for instance, 1.8 points over BERT-based ranker[29] and around 1 point over
TTI-COIN-Average[51]. Compared with the VSM triplet network[36] that also requires no
hand-crafted rules and preprocessing, and is easily adapted to both clinical datasets, our
Xu and Miller Page 8
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
model achieves around 1 point better on ShARe/CLEF 2013 and around 1.5 points better on
2019-n2c2-MCN.
The last six rows in table 2 present the performances of different SAPBERT settings.
Firstly, the off-the-shelf SAPBERT achieves worse performance than the previous state of
the art, especially around 8 points worse on ShARe/Clef 2013 data, where more than 30%
of mentions are annotated with CUI-less labels. This is most likely because SAPBERT
does not model the CUI-less label during the training, and they predict the CUI-less label
equivalent to other concepts during inference. After fine-tuning SAPBERT on each task, the
performance gains are marginal on the test set, which is consistent with their fine-tuning
experiments on multiple MCN datasets from scientific publications[34].
When applying SAPBERT in neural models with different output layers, we find
that approaching MCN as a multi-class classification problem using a conventional
softmax barely works on the two datasets, with the performances no better than the
fine-tuned SAPBERT on both datasets. Adding a threshold parameter to model the CUI-
less label prediction improves performance over using the conventional softmax layer.
Comparing + softmax (CUI-less) and + NT-softmax (Random) where both have a CUI-
less threshold parameter and randomly initialized weight vectors, we find that part of
the performance gains come from the NT-softmax, i.e., using a cosine similarity function
and a scaling parameter in the softmax. Lastly, initializing the weights with pre-computed
concept embeddings in NT-softmax (NT-softmax (Fixed) and NT-softmax) further improve
performance, especially on the 2019-n2c2-MCN data where lots of unseen mentions on
dev and test set. When the weights in NT-softmax are fixed, we can see the performances
on two datasets are close to our complete model, and tuning the weights in NT-softmax
slightly improves the performance, indicating that the initialization of pre-computed concept
embeddings is the key to our success.
4. Discussion
4.1. Impacts of Model Initialization
To see whether our proposed approach only works when starting from SAPBERT,
we conducted experiments that use the same hyperparameters as SAPBERT but adopt
PubMedBERT as encoder and experiment different weight vectors: 1) PubMedBERT as the
encoder and randomly initialized weight vectors, PubMedBERT + NT-softmax (Random), 2)
PubMedBERT and pre-computed concept embeddings from PubMedBERT, PubMedBERT
+ NT-Softmax. Table 3 shows their performance on two datasets. When the weight vectors
are randomly initialized, we can see the performance of SAPBERT is slightly better than
PubMedBERT, 90.66 vs. 89.77 on ShARe/CLEF test set, and 82.65 vs. 82.17 on 2019-
n2c2-MCN test set. However, initializing the weight vectors with PubMedBERT concept
embeddings obtains lower scores than SAPBERT concept embeddings, e.g., around 30
points drop on 2019-n2c2-MCN test set. Since the performance gap is so large between
SAPBERT + NT-softmax and PubMedBERT + NT-softmax, we did not spend much
time on hyperparameter tuning. In our preliminary experiments, we explored different
hyperparameters for PubMedBERT such as learning rate, batch size and CUI-less parameter
s0, but none of these resulted in big differences.
Xu and Miller Page 9
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
To study why the pre-computed concept embeddings from PubMedBERT are harder for
the model training, we check the cosine similarity scores between mentions and their
gold-truth concepts, and the cosine similarity scores between mentions and their top 10
negative concepts across five epochs for all four models on the 2019-n2c2-MCN dev
set. We simplify the training objective as increasing the cosine similarity scores between
mentions and gold-truth concepts, and decreasing the cosine similarity scores between
mentions and top 10 negative concepts. From Figure 2, we can see all four models are
optimized towards this objective as the differences of these two cosine similarity scores
are increasing during training. However, such differences for PubMedBERT + NT-Softmax
are much smaller than the other three models, especially at the early epochs. For instance,
at the first epoch, the difference for PubMedBERT + NT-Softmax is around 0.06. This
indicates PubMedBERT concept embeddings for dissimilar concepts are much closer in
the vector space than SAPBERT, making the model harder to distinguish them during
training. While for SAPBERT + NT-softmax, the differences of cosine similarity score
between gold-truth concept and top 10 negative concepts are already large enough at the first
epoch, this is likely because SAPBERT is already trained to distinguish medical texts with
different semantics. Surprisingly, when the concept embeddings are randomly initializing,
we find both PubMedBERT and SAPBERT models could distinguish dissimilar concepts
even at the early stage of training, but the cosine similarity scores of gold truth concepts
are relatively small and close to the CUI-less threshold hyperparameter. To conclude, we
find that PubMedBERT is not a good starting point for our proposed approach, and the
initialization of weight vectors in NT-softmax has more impacts on the training than the
initialization of the encoder.
4.2. Qualitative Analysis
Table 4 shows the top 5 predicted CUIs from SAPBERT + NT-softmax during training
(before training vs. 5th epoch). For both mentions, our best model SAPBERT + NT-softmax
could find their gold-truth concept before or after fine-tuning, but after fine-tuning the
model could learn better ranks. For the mention “Her alkaline phosphatase,” the model more
depends on the text overlap rather than the semantic type of the mention when not fine-
tuned. For example, although all the incorrect predictions contain the same terms “Alkaline
phosphatase” as in the mention, all of them mean the chemical substance; however,after
fine-tuning, our model is able to understand “Her alkaline phosphatase” is a measurement
or finding. For the mention “pelvic lymph node dissection,” the preferred name of the gold
truth concept is “Pelvic lymphadenectomy,” which means “the surgery to remove lymph
nodes in the pelvis for examination”. The concept prediction “Excision of pelvic lymph node
(C0398429)” has the similar meaning as the gold-truth concept, but is ranked 5th using the
original SAPBERT concept embeddings. After fine tuning, the model re-ranks the concept
“Excision of pelvic lymph node (C0398429)” at rank 2.
4.3. Evaluation on CUI-less Mentions and Unseen Concepts
To estimate how well our proposed approach would work on the realistic setting, we analyze
the performances of our systems on unseen concepts and CUI-less mentions on both datasets
because they are likely to appear more frequently in real-life clinical data. Table 5 shows that
our proposed approach could achieve more than 90% accuracy for seen concepts on both
Xu and Miller Page 10
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
datasets, while the performances for the unseen concepts on both datasets are around 70%.
Comparing with previous work[28] on 2019-n2c2 MCN dataset, we find that our proposed
approach obtain some improvements on both seen and unseen concepts, but the prediction
for the unseen concepts is still a major challenge in MCN task.
4.4. Limitations and Future Work
One limitation of our approach is the memory size of the weight vectors in the NT-softmax
layer. For the experiments on 2019-n2c2-MCN dataset where it considers SNOMED CT
and Rx-Norm as the concept space, the weight vectors in NT-softmax are initialized with a
434056*768 concept embeddings matrix, around 1.4 GB memory. Such embeddings matrix
could be 10 times larger if we consider all 4 million concepts from UMLS. In the future,
we would like to explore different strategies to reduce the size of the embedding matrix, like
adding a projection matrix between the encoder and the NT-softmax layer.
Although our simple one-step approach directly matches the mention representation to the
concept embeddings, the ability to normalize ambiguous mentions is still limited by our
context-independent mention representation as we only feed mention text to the encoder.
However, as both our data analysis and previous work[15] show that the ambiguity ratios in
most clinical notes MCN datasets are relatively low, it will not be fair to evaluate ambiguity
resolution approach on current datasets. An interesting direction for future research would
be the creation of and evaluation on datasets created to maximize ambiguity, along the lines
of new adversarial datasets in other domains[52].
5. CONCLUSION
In this paper, we present a simple one-step neural MCN model consisting of a transformer
network that encodes the mention as a vector, and a NT-softmax layer that maximizes the
cosine similarity score of matching the mention to the correct concept label. Our proposed
approach achieves competitive performance on ShARe/CLEF 2013 and establishes a new
state-of-the-art on 2019-n2c2-MCN. Our analyses show that each component in NT-softmax
layer is important, especially the initialization of weight vectors with pre-computed concept
embeddings from SAPBERT. Our approach is simpler and more effective than prior work,
but the prediction for the unseen concepts remains challenging.
The code for these experiments is publicly available in a GitHub repository
https://github.com/Machine-Learning-for-Medical-Language/cnlp_transformers. The code
repository also contains a FastAPI-based demonstration server that sets up a REST server to
predict CUI for a given concept text.
ACKNOWLEDGMENTS
We thank the anonymous reviewers as well as the associate editor, Dr. Meliha Yetisgen, for helpful comments on an
earlier draft of this paper.
FUNDING
Research reported in this publication was supported by the National Library Of Medicine of the National Institutes
of Health under Award Numbers R01LM012918 and R01LM012973. The content is solely the responsibility of the
authors and does not necessarily represent the official views of the National Institutes of Health.
Xu and Miller Page 11
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
https://github.com/Machine-Learning-for-Medical-Language/cnlp_transformers
REFERENCE
1. Wu H, Toti G, Morley KI, et al. SemEHR: A general-purpose semantic search system to surface
semantic data from clinical notes for tailored care, trial recruitment, and clinical research. J Am
Med Informatics Assoc 2018;25:530–7.
2. Lependu P, Liu Y, Iyer S, et al. Analyzing patterns of drug use in clinical notes for patient safety.
AMIA Jt Summits Transl Sci proceedings AMIA Jt Summits Transl Sci 2012;2012:63–70.
3. Li Y, Salmasian H, Vilar S, et al. A method for controlling complex confounding effects in the
detection of adverse drug reactions using electronic health records. J Am Med Informatics Assoc
2014;21:308–14.
4. Topaz M, Lai K, Dowding D, et al. Automated identification of wound information in clinical notes
of patients with heart diseases: Developing and validating a natural language processing application.
Int J Nurs Stud 2016;64:25–31. [PubMed: 27668855]
5. Shao Y, Mohanty AF, Ahmed A, et al. Identification and Use of Frailty Indicators from Text to
Examine Associations with Clinical Outcomes Among Patients with Heart Failure. AMIA Annu
Symp Proc 2016;2016:1110–1118. [PubMed: 28269908]
6. Limsopatham N, Collier N. Normalising Medical Concepts in Social Media Texts by Learning
Semantic Representation. In: Proceedings of the 54th Annual Meeting of the Association for
Computational Linguistics (Volume 1: Long Papers) 2016;2016:1014–1023.
7. Sarker A, Belousov M, Friedrichs J, et al. Data and systems for medication-related text classification
and concept normalization from Twitter: Insights from the Social Media Mining for Health
(SMM4H)-2017 shared task. J Am Med Informatics Assoc 2018;25:1274–1283.
8. Karimi S, Metke-Jimenez A, Kemp M, et al. Cadec: A corpus of adverse drug event annotations. J
Biomed Inform 2015;55:73–81. [PubMed: 25817970]
9. Roberts K, Demner-Fushman D, Tonning JM. Overview of the TAC 2017 Adverse Reaction
Extraction from Drug Labels Track. Text Anal Conf Proc 2017. https://tac.nist.gov/publications/
2017/additional.papers/TAC2017.ADR_overview.proceedings.pdf?attredirects=0 ((accessed 3 Oct
2021))
10. Doǧan RI, Leaman R, Lu Z. NCBI disease corpus: A resource for disease name recognition and
concept normalization. J Biomed Inform 2014;47:1–10. [PubMed: 24393765]
11. Morgan AA, Lu Z, Wang X, et al. Overview of BioCreative II gene normalization. Genome Biol
2008;9,s3.
12. Li J, Sun Y, Johnson RJ, et al. BioCreative V CDR task corpus: a resource for chemical disease
relation extraction. Database (Oxford) 2016;2016:1–10.
13. D’Souza J, Ng V. Sieve-Based Entity Linking for the Biomedical Domain. In: Proceedings of the
53rd Annual Meeting of the Association for Computational Linguistics and the 7th International
Joint Conference on Natural Language Processing (Volume 2: Short Papers) 2015;2015:297–302.
14. Ji Z, Wei Q, Xu H. BERT-based Ranking for Biomedical Entity Normalization. AMIA Jt Summits
Transi Sci Proc 2020; 2020:269–277.
15. Newman-Griffis D, Divita G, Desmet B, et al. Ambiguity in medical concept normalization: An
analysis of types and coverage in electronic health record datasets. J Am Med Informatics Assoc
2020;00:1–17.
16. Li H, Chen Q, Tang B, et al. CNN-based ranking for biomedical entity normalization. BMC
Bioinformatics 2017;18:385. [PubMed: 28984180]
17. Jonnagaddala J, Jue TR, Chang NW, et al. Improving the dictionary lookupapproach for disease
normalization using enhanced dictionary and query expansion. Database (Oxford) 2016;2016:
baw112. [PubMed: 27504009]
18. Kate RJ. Normalizing clinical terms using learned edit distance patterns. J Am Med Informatics
Assoc 2016;23(2):380–386.
19. Leaman R, Wei CH, Lu Z. TmChem: A high performance approach for chemical named entity
recognition and normalization. J Cheminform 2015;7(1):1–10. [PubMed: 25705261]
20. Kang N, Singh B, Afzal Z, et al. Using rule-based natural language processing to improve disease
normalization in biomedical text. J Am Med Informatics Assoc 2013;20(5):876–881.
Xu and Miller Page 12
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
https://tac.nist.gov/publications/2017/additional.papers/TAC2017.ADR_overview.proceedings.pdf?attredirects=0
https://tac.nist.gov/publications/2017/additional.papers/TAC2017.ADR_overview.proceedings.pdf?attredirects=0
21. Kate RJ. Clinical term normalization using learned edit patterns and subconcept matching: System
development and evaluation. JMIR Med Informatics 2021;9(1): e23104.
22. Jimeno Yepes A. Word embeddings and recurrent neural networks based on Long-Short
Term Memory nodes in supervised biomedical word sense disambiguation. J Biomed Inform
2017;73:137–147. [PubMed: 28797709]
23. Miftahutdinov Z, Tutubalina E. Deep Neural Models for Medical Concept Normalization in
User-Generated Texts. In: Proceedings of the 57th Annual Meeting of the Association for
Computational Linguistics: Student Research Workshop 2019;32019:393–399.
24. Niu J, Yang Y, Zhang S, et al. Multi-task Character-Level Attentional Networks for Medical
Concept Normalization. Neural Process Lett 2018;49:1239–1256.
25. Lee K, Hasan SA, Farri O, et al. Medical Concept Normalization for Online User-Generated Texts.
In: Proc - 2017 IEEE Int Conf Healthc Informatics (ICHI) 2017;2017:462–469.
26. Tutubalina E, Miftahutdinov Z, Nikolenko S, et al. Medical concept normalization in social media
posts with recurrent neural networks. J Biomed Inform 2018;84:93–102. [PubMed: 29906585]
27. Nguyen TN, Nguyen MT, Dang TH. Disease Named Entity Normalization
Using Pairwise Learning To Rank and Deep Learning. VNU University of
Engineering and Technology 2018. https://eprints.uet.vnu.edu.vn/eprints/id/eprint/3200/1/
TechnicalReport_NguyenThanhNgan%20(1).pdf (accessed 3 Nov 2021)
28. Xu D, Gopale M, Zhang J, et al. Unified medical language system resources improve sieve-based
generation and bidirectional encoder representations from transformers (BERT)–based ranking for
concept normalization. J Am Med Informatics Assoc 2020;27:1510–1519.
29. Xu D, Zhang Z, Bethard S. A Generate-and-Rank Framework with Semantic Type Regularization
for Biomedical Concept Normalization. In: Proceedings of the 58th Annual Meeting of the
Association for Computational Linguistics 2020.2020:8452–8464.
30. Liu H, Xu Y. A deep learning way for disease name representation and normalization. National
CCF conference on natural language processing and Chinese computing 2017;2017:10619
31. Leaman R, Doǧan RI, Lu Z. DNorm: Disease name normalization with pairwise learning to rank.
Bioinformatics 2013;29(22):2909–2917. [PubMed: 23969135]
32. Mondal I, Purkayastha S, Sarkar S, et al. Medical Entity Linking using Triplet Network. In:
Proceedings of the 2nd Clinical Natural Language Processing Workshop 2019; 2019:95–100
33. Schumacher E, Mulyar A, Dredze M. Clinical Concept Linking with Contextualized Neural
Representations. In: Proceedings of the 58th Annual Meeting of the Association for Computational
Linguistics 2020;2020:8585–8592.
34. Liu F, Shareghi E, Meng Z, et al. Self-alignment Pre-training for Biomedical Entity
Representations. In: Proceedings of the 2021 Conference of the North American Chapter of
the Association for Computational Linguistics: Human Language Technologies 2021.2021:4228–
4238.
35. Sung M, Jeon H, Lee J, et al. Biomedical Entity Representations with Synonym Marginalization.
In: Proceedings of the 58th Annual Meeting of the Association for Computational Linguistics
2020;2020:3641–3650.
36. Xu D, Bethard S. Triplet-Trained Vector Space and Sieve-Based Search Improve Biomedical
Concept Normalization. In: Proceedings of the 20th Workshop on Biomedical Language
Processing 2021;2021:11–22.
37. Miftahutdinov Z, Kadurin A, Kudrin R, et al. Drug and Disease Interpretation Learning with
Biomedical Entity Representation Transformer. arXiv preprint arXiv 2021; 2021: 2101.09311.
38. Priyatam N, Patil S, Palshikar G, et al. Medical Concept Normalization by Encoding Target
Knowledge. In: Proceedings of the Machine Learning for Health NeurIPS Workshop, PMLR
2020;116:246–259.
39. Luo YF, Sun W, Rumshisky A. MCN: A comprehensive corpus for medical concept normalization.
J Biomed Inform 2019;92:103132. [PubMed: 30802545]
40. Wang F, Liu H. Understanding the Behaviour of Contrastive Loss. In: Proceedings of the
IEEE/CVF Conference on Computer Vision and Pattern Recognition 2021;2021:2495–2504.
Xu and Miller Page 13
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
https://eprints.uet.vnu.edu.vn/eprints/id/eprint/3200/1/TechnicalReport_NguyenThanhNgan%20(1).pdf
https://eprints.uet.vnu.edu.vn/eprints/id/eprint/3200/1/TechnicalReport_NguyenThanhNgan%20(1).pdf
41. Gu Y, Tinn R, Cheng H, et al. Domain-Specific Language Model Pretraining for Biomedical
Natural Language Processing. ACM Transactions on Computing for Healthcare (HEALTH)
2021;3(1):1–23.
42. Xiao T, Li S, Wang B, et al. Joint Detection and Identification Feature Learning for Person
Search. In: Proceedings of the IEEE Conference on Computer Vision and Pattern Recognition
2017;2017:3415–3424.
43. Wu Z, Xiong Y, Yu SX, et al. Unsupervised Feature Learning via Non-Parametric Instance
Discrimination. In: Proceedings of the IEEE conference on computer vision and pattern
recognition (CVPR) 2018;2018:3733–3742.
44. Wang F, Xiang X, Cheng J, et al. NormFace: L2 hypersphere embedding for face verification. In:
Proceedings of the 25th ACM international conference on Multimedia MM 2017;2017:1041–1049.
45. Chen T, Kornblith S, Norouzi M, et al. A simple framework for contrastive learning of visual
representations. In: Proceedings of the 37th International Conference on Machine Learning PMLR
2020;119:1597–1607.
46. Gao T, Yao X, Chen D. SimCSE: Simple Contrastive Learning of Sentence Embeddings. In:
Proceedings of the 2021 Conference on Empirical Methods in Natural Language Processing
2021.2021:6894–6910.
47. Liu W, Wen Y, Yu Z, et al. SphereFace: Deep hypersphere embedding for face recognition.
In: Proceedings of the IEEE Conference on Computer Vision and Pattern Recognition (CVPR)
2017;2017:212–220.
48. Yan Y, Li R, Wang S, et al. ConSERT: A Contrastive Framework for Self-Supervised Sentence
Representation Transfer. In: Proceedings of the 59th Annual Meeting of the Association for
Computational Linguistics and the 11th International Joint Conference on Natural Language
Processing (Volume 1: Long Papers) 2021;2021:5065–5075.
49. Henry S, Wang Y, Shen F, et al. The 2019 national natural language processing (NLP) clinical
challenges (n2c2)/Open health NLP (OHNLP) shared task on clinical concept normalization for
clinical records. J Am Med Informatics Assoc 2020;27:1529–37.
50. Deng J, Guo J, Xue N, et al. ArcFace: Additive angular margin loss for deep face recognition. In:
Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR)
2019;2019:4690–4699.
51. Tsujimura T, Mori N, Asada M, et al. TTI-COIN at n2c2 2019 Track 3: Neural Medical
Concept Normalization with Two-Step Training [presentation]. 2019 n2c2/OHNLP Shared-Task
and Workshop, Washington, D.C., United States. Nov. 15, 2019.
52. Kiela D, Bartolo M, Nie Y, etal. Dynabench: Rethinking Benchmarking in NLP. In: Proceedings
of the 2021 Conference of the North American Chapter of the Association for Computational
Linguistics: Human Language Technologies 2021;2021:4110–4124.
Xu and Miller Page 14
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
Figure 1.
Architecture of our proposed end-to-end neural MCN model.
Xu and Miller Page 15
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
Figure 2.
The average cosine similarity score on the 2019-n2c2-MCN dev set across 5 training
epochs. “Gold concept” denotes the cosine similarity scores between mentions and their
gold truth concepts during each epoch, “Top 10 negative concepts” denotes the average
cosine similarity scores between mentions and their top 10 negative concepts (concepts that
are different from gold truth concept but have highest cosine similarity scores) during each
epoch. Both cosine similarity scores are averaged across all mentions on the dev set.
Xu and Miller Page 16
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
Xu and Miller Page 17
Table 1
Statistics of two clinical note datasets used in this study.
ShARe/CLEF 2013 2019-n2c2-MCN
train + dev test train + dev test
Data
# of documents 199 99 50 50
# of mentions 5816 5351 6684 6925
# of CUI-less mentions 1641 1750 151 217
# of ambiguous mentions 397 240 190 192
# of unique concepts 1011 796 2331 2579
# of unseen concepts - 623 - 2067
# of mentions per concept 5.75 6.72 2.5 2.69
Ontology
source SNOMED-CT SNOMED-CT + RxNorm
# of concepts 88150 434056
# of concept synonyms 312506 1127171
# of synonyms per concept 3.55 2.6
# of CUI-less mentions: # of mentions that are annotated with the CUI-less label.
# of ambiguous mentions: # of mentions that are annotated with more than one concepts.
# of unseen concepts: # of mentions whose normalized concepts do not appear in the train or dev set, but appear in the test set.
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
Xu and Miller Page 18
Table 2
Comparison of our proposed concept normalization system against the current state-of-the-art performances
on ShARe/CLEF 2013 and 2019-n2c2-MCN datasets.
ShARe/CLEF 2013 2019-n2c2-MCN
Dev Test Dev Test
Sieve-based dictionary look-up [13] - 90.75 - -
Sieve-based dictionary look-up [39] - - - 76.35
VSM triplet network [36] 90.2 90.4 84.67 83.7
TTI-COIN-Average [51] - - - 84.40
BERT-based ranker [29] - - 84.44 83.56
BERT-based ranker [14] - 91.1 - -
SAPBERT [34] (off-the-shelf) 83.97 82.77 82.89 83.02
SAPBERT (fine-tuned) 86.91 83.33 85.17 83.46
SAPBERT+ Softmax 85.55 83.30 78.88 78.30
SAPBERT+ Softmax (CUI-less) 87.34 85.37 82.60 81.31
SAPBERT + NT-softmax (Random) 90.93 90.66 83.70 82.65
SAPBERT + NT-softmax (Fixed) 92.31 91.18 90.52 85.15
SAPBERT + NT-softmax 92.51 91.31 90.74 85.32
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
Xu and Miller Page 19
Table 3
Comparison of our proposed concept normalization system using different encoders and concept embeddings
on ShARe/CLEF 2013 and 2019-n2c2-MCN datasets.
ShARe/CLEF 2013 2019-n2c2-MCN
Dev Test Dev Test
PubMedBERT + NT-softmax (Rand) 90.17 89.77 83.26 82.17
PubMedBERT + NT-softmax 52.11 52.94 60.07 58.99
SAPBERT + NT-softmax (Rand) 90.93 90.66 83.70 82.65
SAPBERT + NT-softmax 92.51 91.31 90.74 85.32
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
Xu and Miller Page 20
Table 4
Comparison of the top 5 predicted CUIs from SAPBERT + NT-softmax before any training and at the end of
training (5th epoch) for mentions “Her alkaline phosphatase” and “pelvic lymph node dissection”. The bolded
concepts are the gold truth concepts for these two mentions.
Top 5
predictions
Her alkaline phosphatase pelvic lymph node dissection
before training 5th epoch before training 5th epoch
1
Alkaline phosphatase
measurement
(C0201850)
Alkaline phosphatase
measurement
(C0201850)
Pelvic lymphadenectomy
(C0193883)
Pelvic lymphadenectomy
(C0193883)
2
Alkaline phosphatase
isoenzyme, bone
fraction (C0312399)
Alkaline phosphatase
level - finding
(C0428332)
Block dissection of pelvic lymph
nodes (C0398405)
Excision of pelvic lymph node
(C0398429)
3 Alkaline Phosphatase
(C0002059) CUI-less Operation on pelvic lymph node
draining prostate (C0401597)
Block dissection of pelvic
lymph nodes (C0398405)
4 Alkaline phosphatase
stain (C1318717)
Alkaline Phosphatase
(C0002059)
Excision of inguinal lymph
node and pelvic lymph node
(C2959401)
Pelvic lymph node group
(C0729595)
5
Alkaline phosphatase
isoenzyme, renal
fraction (C0368634)
Serum alkaline
phosphatase
measurement
(C0036776)
Excision of pelvic lymph node
(C0398429)
Pelvic lymph nodes sampling
(C0398426)
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
A
uthor M
anuscript
Xu and Miller Page 21
Table 5
Accuracy of our best model SAPBERT + NT-softmax on seen concepts, unseen concepts, and CUI-less
mentions in test data from ShARe/CLEF 2013 and 2019-n2c2-MCN.
ShARe/CLEF 2013 2019-n2c2-MCN
Seen concepts 94.16 93.40
Unseen concepts 71.68 69.15
CUI-less 93.56 66.36
J Biomed Inform. Author manuscript; available in PMC 2023 June 01.
	Abstract
	Introduction
	MATERIALS AND METHODS
	Dataset
	System description
	Normalized Temperature-scaled Softmax
	Implementation Details
	Experiments
	Evaluation Metrics
	Comparison with Related Work
	Models
	RESULTS
	Discussion
	Impacts of Model Initialization
	Qualitative Analysis
	Evaluation on CUI-less Mentions and Unseen Concepts
	Limitations and Future Work
	CONCLUSION
	References
	Figure 1
	Figure 2
	Table 1
	Table 2
	Table 3
	Table 4
	Table 5
