CUSTOMER TECHNICAL MANUAL - EN
LUCEA 50 - 100
LUCEA LED
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 2 |
Copyright
All rights reserved. This document may not be copied, adapted or
translated without prior written permission, except as permitted under
copyright law.
© Copyright Maquet S.A.
Subject to technical changes.
The illustrations and technical specifications provided in this manual
may, on account of future product developments, differ slightly from
the actual product supplied.
03.02.2012 | Ed1C
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 3 |
CONTENTS
1 Symbols used in this manual | 4
2 Symbols used on the product | 4
3 Quality standards compliance | 5
3.1 Certification of MAQUET SA’s quality system | 5
3.2 CE Marking | 5
4 Specifications | 6
5 Electrical power supply specifications | 7
6 Cleaning and disinfection | 9
7 Maintenance | 10
7.1 Preventive maintenance | 10
7.2 Basic maintenance | 10
7.3 Electrical connections: installation diagrams | 14
7.4 Recommended cable cross-sections | 15
8 Configuring the second spare remote control (option) | 18
9 Maintenance kits | 19
10 Spare parts and consumables | 23
11 Maintenance tools (OPM) | 24
12 Diagrams and parts lists | 25
13 Wiring diagrams | 97
13.1 Wiring diagram: Lucea 100 lighthead | 97
13.2 Wiring diagram: Lucea 50 lighthead | 98
14 Drawings of ceiling covers | 99
15 Connecting and disconnecting - Mobile version | 101
16 Summary of power supply wiring diagrams | 102
17 Installation block diagrams | 104
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 4 |
1 SYMBOLS USED IN THIS MANUAL
Symbols Meaning
Absolute requirement
May endanger patient and user safety
F Recommendation
Risk of damage to device or accessories
CE label
The device complies with the requirements of European directive
93/42/EEC relating to medical devices
Medical Equipment
Classification for electric shocks, mechanical hazards and fire risks in
accordance with UL 60601-1,
IEC 60601-2-41 and CSA C22.2 No. 601-1-M90
2 SYMBOLS USED ON THE PRODUCT
Symbols Meaning
Caution
Carefully read the documentation supplied with the unit
~ Alternating current
Direct current
REF.
SN.
Product technical description and serial numbers.
S
Comply with the applicable handling precautions for products that are
sensitive to electrostatic discharges.
Protective earth
Medical Equipment
Classified with respect to electric shock, fire and mechanical hazards
only, in accordance with UL 60601-1, IEC 60601-2-41 and CSA C22.2
No. 601-M90
CE label
The device complies with the requirements of European directive
93/42/EEC relating to medical devices
Do not dispose of this device as unsorted municipal waste. Take it to a
collection facility for value enhancement, recycling or re-use.
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 5 |
LNE/G-MED certifies that the quality system developed by Maquet SA for design, implementa-
tion, sales, installation and after-sales service of surgical lights complies with the requirements
of the following international standards:
 ISO 9001:2008
 ISO 13485:2004
Compliance with the requirements of European Directive 93/42/EEC dated 14 June 1993 relat-
ing to medical devices was assessed as described in Annex VII of the Directive. Lucea 50-100
lights belong to Class I as described in Annex IX of Directive 93/42/EEC.
3 QUALITY STANDARDS COMPLIANCE
3.1 CERTIFICATION OF MAQUET SA’S QUALITY SYSTEM
3.2 CE MARKING
To be compliant with IEC 60364-7-710, lighting backup systems must function for at least 3
hours.
The external system must therefore have a capacity of at least 3 hours. The MAQUET
backup unit makes it possible to check compliance with this requirement.
WARNING!
MAQUET is not responsible for the customer's external backup system (capacity, charge
time, lifespan, etc.)
WARNING!
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 6 |
4 SPECIFICATIONS (IN ACCORDANCE WITH STANDARDS
IEC 60601-2-41 AND IEC 60601-1)
Specifications Unit LUCEA 50 LUCEA 100
Main light
Nominal illumination (Ec) lx > 50,000 > 100,000
Diameter d10 cm
(inches) 23 (9) ±10% 23 (9) ±10%
Diameter d50 cm
(inches) 12 (4.7) 12 (4.7)
Diameter d50/d10 cm
(inches) > 0.55 > 0.55
Illumination depth at 20% cm
(inches) 170 (67) 106 (41.7)
Illumination depth at 60% cm
(inches) 116 (45.5) 62.5 (24.5)
Colour temperature K 4,300 ±300 4,300 ±300
Colour rendering index (Ra) N/A 95 ±3 95 ±3
Special colour rendering index (R9) N/A 92 ±2 92 ±2
Radiating energy mW.m-2.lx-1 3.9 ±10% 3.9 ±10%
Irradiance (Ee) W/m2 195 ±10% 390 ±10%
Mechanical
Lighthead weight kg 2.25 4.7
Lighthead overall dimensions
mm
(inches)
437.1x246.39
(17.21x9.70)
675.8x243.8
(26.61x9.60)
Protection rating against a hazardous
inflow of water
- Normal
Methods of sterilisation
or disinfection
- See User's manual
Operating mode - Continuous operation
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 7 |
MOBILE VERSION SPECIFICATIONS
5 ELECTRICAL POWER SUPPLY SPECIFICATIONS
Description Specifications
Supply voltage 100V-240V/50-60 Hz
Max. power of power supply and Lucea 50 lighthead without
battery pack (mobile LCA 50)
Max. power of power supply and Lucea 100 lighthead without
battery pack (mobile LCA 100)
Max. power of power supply and Lucea 50 lighthead with battery
pack (mobile LCA 50 B)
Max. power of power supply and Lucea 100 lighthead with battery
pack (mobile LCA 100 B)
60 VA
120 VA
145 VA
247 VA
Weight of mobile Lucea 50 without battery pack (Mobile LCA 50)
Weight of mobile Lucea 50 with battery pack (Mobile LCA 100)
Weight of mobile Lucea 100 without battery pack (Mobile LCA 50 B)
Weight of mobile Lucea 100 with battery pack (Mobile LCA 100 B)
(lightheads included)
11 kg
21 kg
25 kg
59 kg
Length of mains supply cable 5 m
Two antistatic swivel casters with brakes
3 swivel casters
dia. 125 mm
Battery type Lead gel
Min. battery life (with lighthead) Lucea 50
Min. battery life (with lighthead) Lucea 100
3 hours
8 hours
Charge time 10 hours
Horizontal rotation of spring arm + 15°/- 15°
Vertical reach of spring arm + 15°/- 40°
Supply voltage V AC; Hz 100-240 / 50-60
Power consumption VA 145
Electrical class - Class I
Protection rating against electrical
shocks
- Normal
Output voltage V 28
Board for 24 V AC+DC external
backup supply
AC/DC/
AC+DC
24V ±10%
Cover dimensions (WxHxD) mm
(inches)
362x272x85 (14.25x10.71x3.35)
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 8 |
ELECTRICAL POWER SPECIFICATIONS (GERMANY)
SPECIFICATIONS OF THE MAQUET BACKUP POWER SUPPLY
Supply voltage AC/DC/
AC+DC
24V ±10%
Power consumption VA 90
Electrical class - Class I
Protection rating against electrical
shocks
- Normal
Output voltage V 24 V
Primary/secondary insulation V AC 500
Description Specifications
Battery type Lead gel
Min. battery life (with lighthead) Lucea 50
Min. battery life (with lighthead) Lucea 100
6 hours
3 hours
Charge time 10 hours
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 9 |
6 CLEANING AND DISINFECTION
Users must contact their hospital's sanitary specialists. The recommended products must be
used and the recommended procedures followed. Should there be any doubt concerning the
compatibility of active agents to be used, contact your authorised Maquet dealer.
CLEANING AND DISINFECTING THE SURGICAL LIGHT
Check that the power is switched off and the light has cooled down before starting cleaning.
RECOMMENDATIONF
GENERAL INSTRUCTIONS CONCERNING CLEANING, DISINFECTION AND SAFETY
 Wipe the equipment with a cloth moistened with a surface cleaner. Follow the manufacturer's
dilution, application time, and temperature recommendations.
 Rinse the unit with a cloth and clean water. Wipe dry.
 Wipe evenly with a cloth moistened with disinfectant. Follow the manufacturer's
recommendations.
 Use a cloth to rinse with clean water in orderto remove residues (in particular products
containing aldehydes, quaternary ammonium or surfactants).
 Wipe with a dry cloth.
 Make sure no liquid residue is left on the device after cleaning.
RECOMMENDED PRODUCTS
Getinge USA product: TEC-QUAT 256.
Anios products: SURFA’SAFE; 0.5% HEXANIOS G + R; ANIOSYME P.L.A; SALVANIOS
pH10; ANIOS DDSH.
Schülke & Mayr products: ANTIFECT PLUS.
PROHIBITED PRODUCTS
 Solutions containing glutaraldehyde, phenol, iodine, bleach, alcohol or chloride ions must
not be used.
 Fumigation methods are unsuitable for disinfecting the unit and must not be used.
WARNING!
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 10 |
7 MAINTENANCE
7.1 PREVENTIVE MAINTENANCE
To preserve your light's original performance and reliability, annual maintenance and inspec-
tions should be performed as follows:
 During the guarantee period: by a Maquet technician or Maquet-approved distributor.
 Outside the warranty period: by a Maquet technician or Maquet-approved distributor, or a
hospital technician trained in the Maquet SA products in question. (Please contact your
Maquet dealer to undergo the technical training required.)
7.2 BASIC MAINTENANCE
The operation and safety of the device may be affected by the removal of certain compo-
nents during servicing operations. For example: For example:
 When servicing the electrical power supply,
 When servicing the suspension arms and balance system,
 When servicing the lighthead.
Contact your authorised Maquet after-sales service department for this type of servicing.
WARNING!
Daily checks (user)
 Check the lightheads for chipped paint, impact marks,
any other damage, loose covers, etc.).
 Check that the cap protecting the brake screw is prop-
erly seated.
 Check for all the attachment screws.
 Check the stability/drift of the system.
 Check whether the LEDs operate correctly, by pressing
the On/Off button on the lighthead.
The surgical light is a high-intensity light source. Do not
look directly into it.
WARNING!
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 11 |
Daily checks (user)
Clic
 Check whether the sterilisable handle clicks and locks in
place correctly; replace it if not.
1 2
 Check that the remote control (optional) works properly:
lighthead lights up:
- Check the state of batteries
- Check the lighthead selection function
- If there is a camera, check the zoom adjustment and
camera rotation function (0° to 180°).
 Mobile stand: check the power lead for signs of
damage.
 Only for power supplies with battery backup:
- Make sure that the light operates correctly from the
backup power supply, in case of a power cut.
Monthly checks (user)
 Check the lightheads for chipped paint, impact marks,
any other damage, loose covers, etc.).
 Check the lighting for the entire operating (spring arm,
complete suspension with ceiling cover).
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 12 |
Monthly checks (user)
 Make sure that the light operates correctly from the
backup power supply, in case of a power cut (see
section 10.6). Do the same for the mobile versions with
batteries.
 Make sure that the charge left in the batteries meets
your needs.
Annual checks
(must be performed by an authorised technician)
 Check the verticality of the suspension tube (ceiling
model).
 Check the tightness of the attachment screws on the
suspension tube (ceiling model).
 Check for the stops and brake and measure their
efficiency.
Check for any loose covers and caps.
Check whether the spring arm is correctly balanced.
Check the illumination adjustment by pressing and
releasing or pressing and holding and
5
levels
Spring arm to be changed every six years (wearing
part).
WARNING!
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 13 |
Annual checks
(must be performed by an authorised technician)
1 m
Check standard illumination (at 1 m), using a calibrated
light meter.
Lucea 50: > 50,000 lux
Lucea 100: > 100,000 lux
Mobile stand: check the power lead for signs of
 damage.
Mobile stand: check the verticality of the pole.
Check that the retaining screws and all visible screws of
the pole and the arm are tightly fastened.
For the casters of the mobile model of the light:
- Check their overall condition
- Check they are tightly fastened
- Check that the brake locking system work properly.
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 14 |
7.3 ELECTRICAL CONNECTIONS: INSTALLATION DIAGRAMS
7.3.1 CEILING OR WALL-MOUNTED POWER SUPPLY WITHOUT BACKUP
Option A:
ceiling-mounted
power supply
Option B:
wall-mounted
power supply
Power supply output
7.3.2 CEILING OR WALL-MOUNTED POWER SUPPLY WITH CUSTOMER BACKUP
SWITCHOVER
RS
RS
RS
Option A
ceiling-mounted
power supply
Option B:
 wall-mounted
power supply
with backup unit
Option A:
with backup
unit
Power supply output
Customer backup input
Or
remote
C
us
to
m
er
 b
ac
ku
p
in
pu
t
RS: backup unit
Backup switchover/backup unit connection: cat. 5 (max. length: 80 m)
Equipment
room
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 15 |
7.3.3 POWER SUPPLY WITH A MAQUET BACKUP
RS
RS
CAT 5
Backup unit
Equipment
room
7.4 RECOMMENDED CABLE CROSS-SECTIONS
C1 Power supply
7.4.1 WALL-MOUNTED POWER SUPPLY WITHOUT BACKUP
C1 length Minimum recommended cross-section
number is not backlit
The switchover button is used to toggle between the two possibilities.
Once the setting has been chosen, store it by pressing the battery lifetime test button
The system returns to normal mode and the lighthead number backlight is as configured.
In configuration mode, the module does not respond to messages from the master.
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 19 |
9 MAINTENANCE KITS
References Description Quantities
Maquet backup power supply after-sales kit
368617998 Backup unit with control panel S/A 1
Unit housing 1
Mounting bracket 1
Terminal block cover 1
Grommet 1
Tapping screw 2
Cap 1
Insert 1
Panel penetration 1
Hazard label 1
Backup unit 1
Input label 1
Output label 2
CHc screw M5x12 2
CHc screw M3x25 2
Hex nut M3 2
368617555 Maquet backup power supply cable kit 1
Mains supply cable 1
Backup unit output cable 1
12 V battery cable 1
Interconnection cable 1
RJ45 cord (cat. 5) 2
369303555 Power supply Blue 30/80 and LUCEA 50/100 1
Supply unit MPS 1
Lucea 50 lighthead after-sales kit 1
368611998 Lucea 50 housing S/A 1
Transparent housing 1
Cover plate 1
Transparent housing interface 1
M4x10 screw 4
368609998 Lucea 50 top cover S/A and fork 1
Fork 1
M4x10 screw 1
Blue 30 bushing 1
Hc screw 1
White switch 1
Silicone cap 1
M6 brake screw 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 20 |
References Description Quantities
Top cover 1
Square nut 1
Fork cable 1
Switch cable 1
368612555 Pack of Lucea 50 lighthead cables + switch 1
White switch 1
Control cable 1
Lucea 50 & 100 LED board cable 1
Lucea 50 power supply cable 1
Switch cable 1
Lucea 50 fork cable 1
368610998 LED board, regulator and collimator S/A 1
Silicone pad 1
Faceted structure 1
Control board 1
Star washer 2
Nut 2
EJOT screw 52
Collimator 26
FR4 LED board 1
M3x8 screw 2
Spacer 2
368608998 Lucea 50 bottom cover and capacitive keypad S/A 1
EJOT screw 2
Mounting plate 1
Capacitive keypad 1
Bottom cover 1
Handle mount 1
M4x65 screw 2
Structure panel 1
Spacer 2
Screw 2
Washer 2
M3x8 screw 2
Control cable 1
368614555 Set of 5 silicone caps for Lucea 50 1
Silicone cap 5
693600062 Pack of ten 3 A fuses for control board LUCEA 50 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 21 |
References Description Quantities
Lucea 100 lighthead after-sales kit
368612998 Lucea 100 housing S/A 1
Transparent housing 1
Lucea 100 decorative cover plate 1
Transparent housing interface 1
ULF screw M4x12 4
368613998 LED board, regulator and collimator S/A 1
Collimator mount + collimators 26
EJOT PT screw, WN 1451 zinc-plated steel 52
LED 50 board 1
Lucea 100 lead screw 2
Lucea 50 & 100 faceted structures 1
Truarc circlip D5 stacked BN 4
Flat washer Z NFE 25513 dia.6 4
Spring Leduc 25455A dia.9.5x13 4
Star washer, A-shape 4
Hex nut M5 zinc-plated 2
Lucea 50 control board 1
Hex nut 2
Star washer 2
Lucea spacer MF 10 stainless steel 2
368613555 Pack of Lucea 100 cables 1
Lucea 100 I2C network cable 1
Lucea 100 camera cable 1
Lucea 50 keypad control cable 1
Lucea 50 & 100 LED board cable 2
Lucea 100 power supply cable 1
Switch cable 1
Lucea 100 fork cable 1
On/off switch 1
368602900 Lucea bottom housing with remote control 1
Remote control bottom 1
Hook 1
Cover 1
Label 1
Raised countersunk head screw, H type recess 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 22 |
References Description Quantities
368614998 Lucea 100 bottom cover with fork 1
Lucea 100 fork cable 1
Smooth bushing 1
Hc screw M5x4 1
CS screw M5x10 1
Lucea 100 fork 1
Z20 washer 1
Circlip 1
Brake screw 1
Frame 1
Silicone cap 1
On/off switch 1
CX screw M3x8 6
Camera cap 1
Bottom cover 1
Capacitive keypad PCB 1
Dimmer retaining plate 1
368616555 Lucea 100 top cover kit 1
Top cover 1
FX screw M3x12 1
Handle mount 1
M4x30 screw 2
368615555 Set of 5 silicone caps for Lucea 50 1
Silicone cap 5
693600062 Pack of ten 3 A fuses for Lucea control board 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 23 |
10 SPARE PARTS AND CONSUMABLES
References Description Quantities
ARD688700003 Clip-on ferrite bead 1
ARD693600063 Kit of ten 4 A fuses (Maquet backup power supply) 1
ARD699600040 Maquet backup battery (sold individually) 1
ARD699060624 Power supply board 1
ARD695100355 Plastic stanchion (pack of 100) 1
ARD568604949 Customer backup switchover kit 1
ARD369010524 Pair of mobile Lucea 100 batteries (2PCx12V) 1
HM56077897 Pair of mobile Lucea 50 batteries (2PCx12V) 1
ARD569010102 Blue 30 spring arm cap 1
ARD568603525 Lucea 50 spring arm cable 1
ARD568603526 Lucea 100 spring arm cable 1
ARD569010282 Blue 30-80 single suspension arm cap 2
ARD568603516 850 mm double extension arm cable (video) 1
ARD569010282 Blue 30-80 single suspension arm cap 1
ARD568603514 850 mm wall-mounted extension arm cable 1
ARD568603525 Lucea 50 spring arm cable 1
ARD569010100 Blue 80 spring arm cap 2
ARD568603526 Lucea 100 spring arm cable 1
ARD56010513 Connector 1
ARD569010282 Blue 30-80 single suspension arm cap 2
ARD568603514 850 mm wall-mounted extension arm cable 1
ARD569010102 Blue 30 spring arm cap 1
ARD568604523 Cable for Lucea 50 mobile spring arm with battery 1
ARD568603547 Cable for Lucea 100 mobile spring arm 1
ARD568604524 Lucea 50-100 mobile charger board 1
ARD688700002 Ferrite bead 1
ARD569003042 MPS 120-15 power supply for Blue Hospital 1
ARD369301555 Pack of 10 miniature 7.5 A 32 V quick-blow fuses 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 24 |
11 MAINTENANCE TOOLS (OPM)
Description Quantity Part number
OPM 039 Photometer 1 5 720 34 999
OPM 059 Multimeter M 54 RMS 1 5 720 59 999
OPM085 Insulated angled tweezers (for control
board fuse) 1 6 870 000 11
References Description
ARD568604960 POWER CORD EUR (CEE 7/7)

ARD568604967 POWER CORD US NEMA 5-15)

ARD568604961 POWER CORD GBR (BS 1363)

ARD568604964 POWER CORD AUS (AS/NZS 3112)
ARD568604963 POWER CORD BRA (IEC 60906-1)

ARD568604965 POWER CORD CHE (SEV 1011)

ARD568604962 POWER CORD ITA (CEI 23-16/VII)

ARD568604966 POWER CORD JPN (JIS C 8003, Class I)

Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 25 |
12 DIAGRAMS AND PARTS LISTS
PARTS LIST 1 LUCEA 50 LIGHTHEAD
5 686 04 999
No. Part number Description Qty
368609998 Lucea 50 top cover S/A and fork 1
1 Lucea 50 fork 1
2 Low-profile hexalobular slotted head cheese screw (Torx),
ISO 14580 M4x10 stainless steel
5
3 Blue 30 smooth pad 1
4 Hc screw ISO 4025 M5x4 Stainless steel 1
5 Switch cable 1
6 Lucea 50 silicone cap 1
7 Lucea 50 M6 stainless steel brake screw 1
8 Lucea 50 top cover 1
9 Square nut DIN 557 M6 stainless steel 1
17 Lucea 50 thrust washer 1
18 Circlip for shaft DIN 471-18 spring steel 1
368612555 Lucea 50 lighthead and switch cables 1
Not shown
368608998 Lucea 50 bottom cover and capacitive keypad S/A 1
10 EJOT PT screw, WN 1452 K30x8 stainless steel 2
11 Lucea 50 & 100 dimmer retaining plate 1
12 Lucea 50 & 100 capacitive keypad 1
13 Lucea 50 bottom cover 1
14 Complete Blue 80 handle bracket kit 1
15 Low-profile hexalobular slotted head cheese screw (Torx),
ISO 14580 M4x65 stainless steel
2
19 Very low profile hexalobular slotted head cheese screw
(Torx), M3x8 stainless steel
6
20 Washer L NFE 25513 M3 (dia.3.2xdia.12x0.8) 2
29 Lucea 50 structure panels 1
368614555 Set of 5 silicone caps for Lucea 50 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 26 |
DIAGRAM 1 LUCEA 50
1
2
3
4
5
6
7 8 109 11 12 13
14 15 16
17
18
19 20 36
21
22
23
24
25
26
27
28
30
19
32 33 34 3519
A
LIGHTHEAD
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 27 |
No. Part number Description Qty
6 Lucea 50 silicone cap 1
368610998 LED board, regulator and collimator S/A 1
19 Very low profile hexalobular slotted head cheese screw
(Torx), M3x8 stainless steel
6
20 Washer L NFE 25513 M3 (dia.3.2xdia.12x0.8) 2
21 Hex nut ISO 4032 M3 stainless steel 2
22 Star washerDIN 6798 A M3 stainless steel 2
23 Control board 1
25 Lucea 50 & 100 faceted structure 1
26 Adhesive silicone pad 1
30 Hexagonal spacer MF M3x20 2
32 Hexagonal spacer MF M3x10 2
33 FR4 LED board 1
34 Lucea 50 & 100 collimator mount + collimator 26
35 CBH tapping screw ISO 7049 ST2,9x6.5 white zinc-plated
steel
52
368611998 Lucea 50 housing S/A 1
24 Lucea 50 & 100 transparent housing interface 1
27 Lucea 50 decorative cover plate 1
28 Lucea 50 & 100 transparent housing 1
36 CHc screw ISO 4762 M4x10 A2-70 stainless steel 4
693600062 Pack of ten 3 A fuses 1
A - Fuse 1
16 Sterilisable handle 1
PARTS LIST 1 LUCEA 50 LIGHTHEAD
5 686 04 999
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 28 |
1
2
3
4
5
6
7 8 109 11 12 13
14 15 16
17
18
19 20 36
21
22
23
24
25
26
27
28
30
19
32 33 34 3519
A
DIAGRAM 1 LUCEA 50 LIGHTHEAD
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 29 |
PARTS LIST 2 LUCEA 100 LIGHTHEAD
5 686 03 999
No. Part number Description Qty
368614998 Lucea 100 bottom cover with fork 1
1 Lucea 100 bottom frame 1
2 Lucea 100 bottom cover 1
3 CX screw M3x8 A2 stainless steel BN20146 10
4 18 mm external circlip DIN 471 black steel 1
5 Lucea 50 & 100 dimmer retaining plate 1
8 Lucea 100 top frame 1
9 CX screw ISO 14580 M6x16 blue zinc-plated steel 2
31 Opaque camera cap 1
35 Blue 80 friction bushing 1
36 CX 9SO screw 145880 M5x10 A2-70 stainless steel 1
37 Hc flat-point screw M5x4 A2 stainless steel DIN 913 1
38 Lucea 100 brake screw 1
39 Lucea 100 silicone plug 1
40 Switch socket 1
41 Clamp 1
42 Lucea 100 fork 1
43 Thrust washer 1
45 Capacitive keypad 1
368612998 Lucea 100 housing S/A 1
10 Transparent housing - L50&L100 2
11 Transparent housing interface - L50 & L100 2
12 ULF screw M4x16 A2 stainless steel 8
26 Lucea 100 decorative cover plate 2
368610998 LED board, regulator and collimator S/A 1
Silicone spacer 1
3 CX screw M3x8 A2 stainless steel BN20146 10
21 Spacer MF M3 (L: 10 mm) A2 stainless steel 4
22 Control board 2
23 Star washer, A-shape, 3 mm A2 stainless steel DIN 6798 4
24 Hex nut M3 A2 stainless steel DIN 934 4
32 Lucea 50 and 100 collimator mount+collimator 52
33 EJOT screw, WN 1451, zinc-plated steel K30 length 104
34 LED 50 board 2
44 Faceted structure 2
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 30 |
DIAGRAM 2 LUCEA 100
35
37
36
42
27
9 8 28 7
6
24
23
22
43 4
38
14
15
16
13
17
18
21
302925312
333234
44
20
19
11
12
26
10
45
5
39
40
3
1
41
A
LIGHTHEAD
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 31 |
No. Part number Description Qty
13 Lucea 100 lead screw 4
14 Truarc circlip D5 stacked BN 818 DIN 6799 4
15 Flat washer Z NFE 25513 dia.6 zinc-plated, white 4
16 Spring Leduc 25455A dia.9.5x13.5 8/10 wire 4
17 External tooth star washer 4
18 Hex nut M5 zinc-plated ISO 4032 4
368616555 Lucea 100 top cover kit 1
25 Complete Blue 80 handle bracket kit 1
27 Lucea 100 top cover 1
28 FX screw ISO 14581 M3x12 A2-70 stainless steel 1
29 CS screw ISO 14580 M4x30 A2-70 stainless steel 2
368615555 Set of 5 silicone caps for Lucea 50 1
39 568603017 Lucea 100 silicone plug 1
693600062 Pack of ten 3 A fuses 1
A - Fuse 1
368613555 Pack of Lucea 100 cables 1
Not shown
6 Lucea 100 central shaft 1
7 Lucea 100 structure mount 1
19 Washer M M4 A2 stainless steel NFE 25-514 8
20 Hex nut M4 A2 stainless steel DIN 934 8
30 Sterilisable handle 1
PARTS LIST 2 LUCEA 100 LIGHTHEAD
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 32 |
35
37
36
42
27
9 8 28 7
6
24
23
22
43 4
38
14
15
16
13
17
18
21
302925312
333234
44
20
19
11
12
26
10
45
5
39
40
3
1
41
A
DIAGRAM 2 LUCEA 100 LIGHTHEAD
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 33 |
PARTS LIST 3 LUCEA 50 - SINGLE CEILING SUSPENSION
5 686 04 980
No. Part number Description Qty
1 Lucea 50-100 single shaft 1
2 568603802 Lucea 50-100 single extension arm (850 mm) S/A 1
3 568604810 Lucea 50 spring arm S/A 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 34 |
DIAGRAM 3 LUCEA 50
1
2
3
SINGLE CEILING SUSPENSION
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 35 |
PARTS LIST 4 LUCEA 50 - DOUBLE CEILING SUSPENSION
5 686 04 986
No. Part number Description Qty
1 568603805 Lucea 50-100 double shaft S/A 1
2 Lucea 50-100 1000 mm double extension arm 1
3 Lucea 50-100 850 mm double extension arm 1
4 Bumper 1
5 568604910 Lucea 50 spring arm S/A 2
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 36 |
DIAGRAM 4 LUCEA 50
1
4
2
35
5
DOUBLE CEILING SUSPENSION
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 37 |
PARTS LIST 5 LUCEA 100 - SINGLE CEILING SUSPENSION
5 686 03 980
No. Part number Description Qty
1 Lucea 50-100 single shaft 1
2 568603802 Lucea 50-100 single extension arm (850 mm) S/A 1
3 568603810 Lucea 100 spring arm S/A 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 38 |
DIAGRAM 5 LUCEA 100
1
2
3
SINGLE CEILING SUSPENSION
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 39 |
PARTS LIST 6 LUCEA 100 - DOUBLE CEILING SUSPENSION
5 686 03 984
No. Part number Description Qty
1 568603805 Lucea 50-100 double shaft S/A 1
2 Lucea 50-100 1000 mm double extension arm 1
3 Lucea 50-100 850 mm double extension arm 1
4 Bumper 1
5 568603810 Lucea 100 spring arm S/A 2
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 40 |
DIAGRAM 6 LUCEA 100
2
3
4
5
5
1
DOUBLE CEILING SUSPENSION
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 41 |
PARTS LIST 7 BLUE 30-80 DOUBLE SUSPENSION
5 686 04 985
No. Part number Description Qty
1 568603805 Lucea 50-100 double shaft S/A 1
2 Lucea 50-100 1000 mm double extension arm 1
3 Lucea 50-100 850 mm double extension arm 1
4 Bumper 1
5 568604810 Lucea 50 spring arm S/A 1
6 568603810 Lucea 100 spring arm S/A 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 42 |
DIAGRAM 7
4
2
3
5
6
1
BLUE 30-80 DOUBLE SUSPENSION
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 43 |
PARTS LIST 8 LUCEA 50 - SPRING ARM
5 686 04 941
No. Part number Description Qty
1 M5x16 FHc screw 2
2 Spring arm shaft 1
3 Spring washer 12
4 Washer 22x30x0.5 mm DIN 988 A4E 2
5 FHc screw ISO 10642 - M3x10 1
6 Blue 30 spring arm cam 1
7 Blue 30 spring arm interface 1
8 Circlip for dia. 32 mm shaft 1
9 NK 8/12 TN needle bearing 2
10 Blue 30 spring arm painted angled tube 1
11 AS 1226 stop washer 1
12 Axial needle bearing cage AXK 1226 1
13 LS 1226 stop washer 1
14 Nylstop nut DIN 985 A4E 1
15 569010102 Blue 30 spring arm cap 1
16 568603525 Lucea 50 spring arm cable 1
17 Ring 1
18 Set ring 2
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 44 |
DIAGRAM 8 LUCEA 50
1
2
3
6
57
9
10
11
12
13
14
15
4
16
8
17
18
SPRING ARM
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 45 |
PARTS LIST 9 LUCEA 100 - SPRING ARM
5 686 03 941
No. Part number Description Qty
1 569010100 Blue 80 spring arm cap 2
2 CHc screw ISO 4762 - M12x90 1
3 FHc screw ISO 10642 - M3x10 1
4 Blue 80 spring arm interface 1
5 Spring washer 70x30.5x3 mm 13
6 Blue 80 cam 1
7 NATV 10 axial guide cam roller 2
8 Pin ISO 8734 - 10H8x28 stainless steel 2
9 Blue 80 spring arm painted angled tube 1
10 AS 1226 stop washer 1
11 Axial needle bearing cage AXK 1226 1
12 Hc screw ISO 4026 - M6x12 stainless steel 2
13 LS 1226 stop washer 1
14 Nylstop nut DIN 985 A4E 1
15 568603526 Lucea 100 spring arm cable 1
16 Circlip for dia. 32 mm shaft 1
17 Ring 1
18 Set ring 2
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 46 |
DIAGRAM 9 LUCEA 100
1
2
3
4
5
6
8
7
9
10
11
12
13
141
15
16
17
18
SPRING ARM
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 47 |
PARTS LIST 10 850 MM SINGLE EXTENSION ARM
5 686 03 802No. Part number Description Qty
369302555 Kit: plastic ring with bearing 1
1 Suspension shaft plastic ring 2
7 Drawn cup needle roller bearing HK 32x39x24 2
12 Circlip for dia. 32 mm shaft 1
13 Tab washer 1
14 Set ring 1
2 HM nut ISO 4035 - M4 stainless steel 1
3 Star washer DIN 6798 AZ - M4 stainless steel 2
4 FHc screw ISO 10642 - M4x8 stainless steel 1
5 FHc screw ISO 10642 - M6x12 stainless steel 4
6 850 mm single extension arm cable (video) 1
8 569010282 Blue 30-80 single suspension arm cap 2
9 EJOT PT screw, WN 1413 K30x30 4
10 Lucea 50-100 850 mm single extension arm 1
11 Maquet mark (small size) 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 48 |
DIAGRAM 10 LUCEA 50-100
 1
19
,5

 =
 =
1
1
2
7
6
5
5
8
89
9
10
7
43
11
12
13 14
850 MM SINGLE EXTENSION ARM
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 49 |
PARTS LIST 11 850 MM DOUBLE EXTENSION ARM
5 686 03 804
No. Part number Description Qty
1 FHc screw ISO 10642 - M6x12 stainless steel 2
2 Suspension shaft plastic ring 1
3 568603516 850 mm double extension arm cable (video) 1
4 Thin nut ISO 4035 - M4 stainless steel 1
5 Star washer DIN 6798 AZ - M4 stainless steel 2
6 FHc screw ISO 10642 - M4x8 stainless steel 1
7 Drawn cup needle roller bearing HK 32x39x24 1
8 56010513 Connector 1
9 569010282 Blue 30-80 single suspension arm cap 1
10 EJOT PT screw, WN 1413 K30x30 2
11 Lucea 50-100 850 mm double extension arm 1
12 Maquet mark (small size) 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 50 |
DIAGRAM 11 LUCEA 50-100
 1
19
,5

 =
 =
1
2
3
4
5
6
7
8
910
11
12
850 MM DOUBLE EXTENSION ARM
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 51 |
PARTS LIST 12 1000 MM DOUBLE EXTENSION ARM
No. Part number Description Qty
1 FHc screw ISO 10642 - M6x12 stainless steel 2
2 Suspension shaft plastic ring 1
3 568603517 1000 mm double extension arm cable (non-video) 1
4 Thin nut ISO 4035 - M4 stainless steel 1
5 Star washer DIN 6798 AZ - M4 stainless steel 2
6 FHc screw ISO 10642 - M4x8 stainless steel 1
7 Drawn cup needle roller bearing HK 32x39x24 1
8 56010513 Connector 1
9 569010282 Blue 30-80 single suspension arm cap 1
10 EJOT PT screw, WN 1413 K30x30 2
11 Lucea 50-100 1000 mm double extension arm 1
12 Maquet mark (small size) 1
5 686 03 803
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 52 |
DIAGRAM 12 LUCEA 50-100
1000 MM DOUBLE EXTENSION ARM
 1
19
,5

 =
 =
1 234
5
6
11
10
7
8
9
12
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 53 |
PARTS LIST 13 850 MM WALL-MOUNTED EXTENSION ARM
5 686 03 808
No. Part number Description Qty
1 Suspension shaft plastic ring 2
2 HM nut ISO 4035 - M4 stainless steel 1
3 Star washer DIN 6798 AZ - M4 stainless steel 2
4 FHc screw ISO 10642 - M4x8 stainless steel 1
5 FHc screw ISO 10642 - M6x12 stainless steel 4
6 568603514 850 mm wall-mounted extension arm cable 1
7 Drawn cup needle roller bearing HK 32x39x24 2
8 569010282 Blue 30-80 single suspension arm cap 2
9 EJOT PT screw, WN 1413 K30x30 4
10 Lucea 50-10 850 mm single extension arm 1
11 Maquet mark (small size) 1
12 Circlip for dia. 32 mm shaft 1
13 Tab washer 1
14 Set ring 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 54 |
DIAGRAM 13 LUCEA 50-100
 =
 =
 1
19
,5

1
1
2 76
5
5 8
89
9
10
7
4
3
11
121314
850 MM WALL-MOUNTED EXTENSION ARM
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 55 |
PARTS LIST 14 LUCEA 50 - MOBILE SPRING ARM WITH BATTERY
5 686 04 942
No. Part number Description Qty
1 FHc screw ISO 10642 - M5x16 A2-70 stainless steel 2
2 Spring arm shaft 1
3 Spring washer 12
4 Washer 22x30x0.5 mm DIN 988 A4E 2
5 569010102 Blue 30 spring arm cap 1
6 Blue 30 spring arm cam 1
7 Blue 30 spring arm vertical tube 1
8 568604523 Cable for Lucea 50 mobile spring arm with battery 1
9 NK 8/12 TN needle bearing 2
10 Blue 30 spring arm painted angled tube 1
11 AS 1226 stop washer 1
12 Axial needle bearing cage XK 1226 1
13 LS 1226 stop washer 1
14 Nylstop nut DIN 985 A4E 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 56 |
DIAGRAM 14 LUCEA 50
1
2
3
4
5
6
7
9
10
11
12
13
14
8
SPRING ARM ON MOBILE SPRING ARM WITH BATTERY
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 57 |
PARTS LIST 15 LUCEA 50 - MOBILE SPRING ARM WITHOUT BATTERY
5 686 04 942
No. Part number Description Qty
1 FHc screw ISO 10642 - M5x16 A2-70 stainless steel 2
2 Spring arm shaft 1
3 40x20.4x2.25 mm spring washer DIN 2093-1.8159 14
4 22x30x0.5 mm washer DIN 988 A4E 2
5 BLUE 30 spring arm cap 1
6 Blue 30 Mobile spring arm cam 1
7 Blue 30 Mobile spring arm vertical tube 1
8 ∅8M6x20 cylindrical pin 2
9 NK 8/12 TN needle bearing 2
10 Blue 30 spring arm painted angled tube 1
11 AS 1226 stop washer 1
12 Axial needle bearing cage AXK 1226 1
13 LS 1226 stop washer 1
14 Nylstop nut DIN 985 A4E 1
15 LUCEA 40 mobile power supply cover 1
16 XPPOWER 80-100 W power supply DHW 1000US24 1
17 568604522 L50 mobile spring arm cable 1
18 ECOSYN hexalobular socket raised countersunk head screw,
M3x20 stainless steel
4
19 652000098 Skiffy ∅8 mm plug -054080260003 2
20 652000097 Skiffy ∅6.6 mm plug -055006611303 2
21 568604521 L50 mobile mains power supply cable 1
22 Panduit 8.9x173 cable tie Ref. HV940 1
23 Thermal protection foam 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 58 |
DIAGRAM 15 LUCEA 50
123 4
5
6
7
8
9
10
11
12
13
14
15
16
17
1819
21
20
20
19
22
23
MOBILE SPRING ARM WITHOUT BATTERY
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 59 |
PARTS LIST 16 LUCEA 100 - MOBILE SPRING ARM
5 686 03 940
No. Part number Description Qty
1 569010100 Blue 80 spring arm cap 2
2 CHc screw M12x90 DIN 912-8.8-A4E 1
3 Self-locking nut DIN 985 A4E 1
4 Blue 80 mobile spring arm interface 1
5 Spring washer 70x30.5x3 mm 13
6 Blue 80 cam 1
7 NATV 10 axial guide cam roller 2
8 Pin ISO 8734 - 10H4x28-A-ST 2
9 Blue 80 spring arm painted angled tube 1
10 AS 1226 stop washer 1
11 Axial needle bearing cage AXK 1226 1
12 Hc screw M6x30 DIN 913-45H A4E 2
13 LS 1226 stop washer 1
14 568603547 Cable for Lucea 100 mobile spring arm 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 60 |
DIAGRAM 16 LUCEA 100
1
1
2
4
5
6
7
8
9
10
11
12
13
3
14
MOBILE SPRING ARM
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 61 |
No. Part number Description Qty
1 CHc screw M4x8 DIN 7984 1
2 Blue 30 mobile stand tube 1
3 Plastic star section 1
4 Blue 30 short stand section 3
5 Blue 30 long stand section 2
6 Blue 30 cap 5
7 5 605 17 83 50-ZIO x 35.5 caster 3
8 5 605 17 82 50-ZIO x 35.5 caster with brake (set of 2) 2
5 605 17 84 Assembly kit for 3/5 legs
9 CHc screw M8x35 DIN 912 5
10 Star washer 8.4 mm DIN 6797 6
11 CHc screw M8x22 DIN 912 1
12 M8 nut DIN 934 5
13 Blue 30 stand star section 1
PARTS LIST 17 LUCEA 50 MOBILE STAND
5 690 72 999
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 62 |
DIAGRAM 17 LUCEA 50 ROLLING BASE
1
2
6
4
3
12
7
5
13
11
8
10
9
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 63 |
5 686 04 977
PARTS LIST 18 LUCEA 50 ROLLING BASE

No. Part number Description Qty
1 Blue 30 Hospital transformer unit 1
2 Sleeve 1
3 Mains connector 1
4 2-pole fuse drawer without voltage selector 1
5 F3 fuse, 14 AL 250 V 1
6 White mounting ring 2
7 568604524 Lucea 50-100 mobile charger board 1
8 Spacer 7x3.6x12 mm 4
9 Washer DIN 125 A - M3 (dia. 3.2x7x0.5) 12
10 Hex nut ISO 4032 - M3 stainless steel 4
11 688700002 Ferrite bead 1
12 56077897 Pack of two batteries (2N P712) 1
13 Hex nut ISO 4032 - M34 4
14 Star washer DIN 6797 - M4 8
15 Screw ISO 7045 - M3x10 2
16 Bush 2
17 Star washer DIN 6797 A - M3 2
18 Blue 30 Hospital light stand 1
369303555 Power supplyLUCEA 50/100 with batteries S/A
19 MPS 120-15 power supply for Blue Hospital 1
20 M3 x 10 stainless steel cylindrical spacer 4
21 Blue 30 Hospital PSU bracket 1
22 M3x8 screw DIN 966 - EN ISO 7047 12
23 CHc screw M3x6 A2 stainless steel 4
24 CHc screw M6x40 DIN 912-8.8 A4E 1
25 Washer DIN 125 A - M3 (dia. 6.4x12x1.6) 2
26 Star washer DIN 6797 A - M6 2
27 Hex nut ISO 4032 - M6 1
28 Blue charger mains power supply cable 1
29 Blue 30 Hospital charger board cable 1
30 Earth cable 1
31 Blue 30 battery charger cable 1
32 Blue 30 charger supply output cable 1
33 Earth symbol label 3
34 Lucea 50-100 mobile battery label 1
369301555 Pack of 10 miniature 7.5 A 32 V quick-blow fuses 1
A Miniature 7.5 A 32 V quick-blow fuse 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 64 |
DIAGRAM 18 LUCEA 50 ROLLING BASE
13
33
6 1
8
7 9 11 13 22 12 18
24
25
26
2715 9 16 17 10
2
3
4
5 21
20
23
19
9
22
34
10
14
30
29
28
32 31
A
5
68
6
04
 5
24
 C
ha
rg
er
 b
oa
rd
Tw
o-
po
si
tio
n
bu
tto
n:

Lu
ce
a
50
 p
os
iti
on
 a
nd

Lu
ce
a
10
0
po
si
tio
n
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 65 |
5 690 14 200
No. Part number Description Qty
1 CHc screw M4x8 DIN 7984 1
2 Stand tube 1
4 Plastic star section 1
5 M8 nut DIN 934 5
6 Blue 30 - Lucea 50 short stand section 3
7 Blue 30 - Lucea 50 long stand section 2
8 Blue 30 - Lucea 50 cap 5
5 605 17 84 Assembly kit for 8/5 legs
9 Blue 30 - Lucea 50 stand star section 1
10 Star washer 8.4 mm DIN 6797 6
11 CHc screw M8x35 DIN 912 5
3 CHc screw M8x22 DIN 912 1
12 50-ZIO x 35.5 caster 3
13 50-ZIO x 35.5 caster with brake 2
PARTS LIST 19 LUCEA 50 MOBILE STAND
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 66 |
13
1
2
3
4
5
7
8
6
11
12
9
10
DIAGRAM 19 LUCEA 50 MOBILE STAND
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 67 |
PARTS LIST 20 LUCEA 100 ROLLING BASE

No. Part number Description Qty
1 Mobile stand straight tube 1
2 Mobile 5-star stand 1
3 Mobile transformer unit 1
4 PSU bracket 1
5 M3x8 screw DIN 966 - EN ISO 7047 8
6 M3 x 10 stainless steel cylindrical spacer 4
7 MPS 120-228 power supply 1
8 Flat washer, A-shape, 3.2 mm DIN 125 4
9 CHc screw M3x6 A2 stainless steel 4
10 CHc screw, low profile M5x10 DIN 6912-8.8-A4E 3
11 Star washer, A-shape 5.3 mm DIN 6797-A4E 10
12 5 601 42 47 Lucea 100 caster (75 mm) 3
13 6 060 12 525 Flat anti-static caster 0443-01A 2
14 Mobile spring arm vertical tube 1
15 Low-profile CHc screw with guide hole M5x8 DIN 7984 A2 1
16 Stand cable 1
3 690 10 997 Blue 80 - Mobile Lucea 100 mains cable loom S/A
17 Wiring 1
18 KEC mains connector 1
19 2-pole fuse drawer without voltage selector 1
20 Sleeve 1
3 690 57 555 Pack of ten 5x20 3.15 A quick-blow fuses
21 5x20 3.15 A quick-blow fuse 2
3 690 11 997 Mobile Lucea 100 supply output cable loom
22 Ferrite bead 1
23 Blue 80 - Lucea 100 supply output cable 1
24 Earth cable 2
25 Thin nut M5 A2 stainless steel NF E27 411 2
26 5 607 52 05 Mains cable (Europe)
27 5 607 52 03 Mains cable (US)
5 690 75 999
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 68 |
DIAGRAM 20 LUCEA 100 ROLLING BASE
5
8
21
9
7
3 201762224 54
1
2
3
5
25 11 1013
19
26
27
15
14
24
18
12
23
16
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 69 |
PARTS LIST 21 LUCEA 100 ROLLING BASE
 5 686 03 977
No. Part number Description Qty
1 569010070 Blue 80 Hospital stand straight tube 1
2 568604022 Lucea 50-100 mobile battery label 1
3 569010072 Blue 80 Hospital transformer unit 1
4 56018921 Sleeve 1
5 691400095 Mains connector 1
6 56114152 Earth label 3
7 568604524 Lucea 50-100 mobile charger board 1
8 56019721 Spacer 7x3.6x12 mm 4
9 56653006 Washer DIN 125 A - M3 (dia. 3.2x7x0.5) 8
10 601320324 Hex nut ISO 4032 - M3 4
11 56653077 Star washer DIN 6797 A - M6 6
12 56650282 CHc screw ISO 4762 - M6x10 6
13 601320432 Hex nut M4 A2 stainless steel DIN 934 3
14 56653075 Star washer, A-shape dia. 5.3 mm DIN 6797 A4E 4
15 56077434 Ring, dia. 30xdia.21x10 1
16 56653071 Star washer DIN 6797 - M4 6
17 600530306 CHc screw M3x6 A2 stainless steel 4
18 56004369 Earth cable 1
369303555 Power supply LUCEA 50/100 with batteries S/A
19 569003042 MPS 120-15 power supply for Blue Hospital 1
20 695140310 Spacer M3x10 Harwin Ref. R6324-02 4
21 569014031 PSU bracket 1
22 56650762 CHc screw, low profile M5x10 DIN 6912-8.8-A4E 2
369010524 Pair of batteries (x2) 12 V 1
23 5690076900 AMP 9041 S12V-45Ah battery 2
24 56650733 Screw ISO 7047 - M3x8 - H 12
25 56653101 Star washer DIN 6797 A - M8 1
26 56650285 CHc screw ISO 4762 - M8 x 25 zinc-plated steel CL8.8 1
27 569003026 Blue 80 battery charger cable 1
28 569010081 Ring 1
29 56650823 CHc screw DIN 7984 - M5x8 1
30 688700002 Ferrite bead 1
31 569003032 Blue 80 supply output cable 1
32 569003036 Blue charger supply output cable 1
33 569003031 Blue charger mains power supply cable 1
34 689004520 2-pole fuse drawer without voltage selector 2
35 693600020 F3 fuse, 15 AL 250 V 2
36 56016289 Rubber bush 2
37 56653008 Flat washer, 4.3 mm DIN 125-ST A4E 2
38 56650750 Screw ISO 7045 - M4 x 12 - Z 2
39 56075831 Captive nut
369301555 Pack of 10 miniature 7.5 A 32 V quick-blow fuses 1
A 69360050 Miniature 7.5 A 32 V quick-blow fuse 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 70 |
1
2
3
4
5
6 7 8 9 10 11 12
13
14
17
19 20
21
2223
24
23
26
24
9
30
3435
363738 392829
13
16
18
3
15
25 26
31
32
33
27
A
DIAGRAM 21 LUCEA 100 ROLLING BASE
5
68
6
04
 5
24
 C
ha
rg
er
 b
oa
rd
Tw
o-
po
si
tio
n
bu
tto
n:

Lu
ce
a
50
 p
os
iti
on
 a
nd

Lu
ce
a
10
0
po
si
tio
n
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 71 |
PARTS LIST 22 LUCEA 50 & 100 1C POWER SUPPLY
568604956
No. Part number Description Qty
1 CHc screw ISO 4762 8
2 Star washer DIN 6798 A M3 A2 stainless steel 15
3 Hex nut ISO 4032 M3 A2 stainless steel 5
4 Ceiling power supply housing 1
5 Hexagonal spacer MF M3x10 Stainless steel 4
6 CHc screw ISO 4762 M3x8 nickel-plated steel CL8.8 9
7 Hexagonal spacer MF M3x10 Stainless steel 1
8 Diaphragm grommet (dia. 22) Ref. 161-4076 4
9 Ceiling power supply frame 2
368608555 Cover ring kit (pack of 2) 1
10 Ceiling cover half-ring B30-80 RAL 9016 4
- M3x25 screw (not shown) 1
11 Hex nut ISO 4032 M5 A2 stainless steel 4
12 Star washer DIN 6798 A M5 A2 stainless steel 8
13 CHc screw ISO 4762 M5x12 A2-70 stainless steel 4
14 Skiffy PCB spacer Ref. 100 0356 000 02 7
15 24 V AC/DC backup label 2
16 Output label 2
17 699606024 ECS power supply 100US 28 XE0344 80/100W XP
Power
1
18 100V-240 V AC input label 2
19 Electrical hazard label 1
20 Remote backup label 2
21 Lucea 50 & 100 mains supply cable 1
22 Lucea 50 & 100 supply output cable 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 72 |
DIAGRAM 22 LUCEA 50 & 100 1C POWER SUPPLY
12
3
4
5
6
7
8
9
10
11
13
12
14
15
16
17
1819
20
21
22
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 73 |
PARTS LIST 23 LUCEA 50 & 100 2C POWER SUPPLY
5 686 04957
No. Part number Description Qty
1 CHc screw ISO 4762 M3x25 A2-70 stainless steel 12
2 Star washer DIN 6798 A M3 A2 stainless steel 30
3 Hex nut ISO 4032 M3 A2 stainless steel 10
4 Ceiling power supply housing 2
5 Hexagonal spacer FF M3x55 Skiffy-301355040050 8
6 CHc screw ISO 4762 M3x8 nickel-plated steel CL8.8 18
7 Hexagonal spacer MF M3x10 Stainless steel 2
8 Diaphragm grommet (dia. 22) Ref. 161-4076 8
9 Ceiling power supply frame 2
368608555 Cover ring kit (pack of 2) 1
10 Ceiling cover half-ring B30-80 RAL 9016 4
- M3x25 screw (not shown) 1
11 Hex nut ISO 4032 M5 A2 stainless steel 4
12 Star washer DIN 6798 A M5 A2 stainless steel 8
13 CHc screw ISO 4762 M5x12 A2-70 stainless steel 4
14 Skiffy PCB spacer Ref. 100 0356 000 02 14
15 24 V AC/DC backup label 4
16 Output label4
17 699606024 ECS power supply 100US 28 XE0344 80/100W XP
Power
2
18 100V-240 V AC input label 4
19 Electrical hazard label 2
20 Remote backup label 4
21 Lucea 50 & 100 mains supply cable 2
22 Lucea 50 & 100 supply output cable 2
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 74 |
DIAGRAM 23 LUCEA 50 & 100 2C POWER SUPPLY
1142
8
18
5
17
3
9
13 12 10
11
4
2016
15
6
7
19
21
22
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 75 |
PARTS LIST 24 LUCEA 50 & 100 24V 1C POWER SUPPLY
5 686 04 952
No. Part number Description Qty
1 CHc screw ISO 4762 M3x25 A2-70 stainless steel 8
2 Star washer DIN 6798 A M3 A2 stainless steel 16
3 Hex nut ISO 4032 M3 A2 stainless steel 5
4 Ceiling power supply housing 1
5 Hexagonal spacer FF M3x55 Skiffy-301355040050 4
6 CHc screw ISO 4762 M3x8 nickel-plated steel CL8.8 9
7 Hexagonal spacer MF M3x10 Stainless steel 1
8 Diaphragm grommet (dia. 22) Ref. 161-4076 4
9 Ceiling power supply frame 2
368608555 Cover ring kit (pack of 2) 1
10 Ceiling cover half-ring B30-80 RAL 9016 4
- M3x25 screw (not shown) 1
11 Hex nut ISO 4032 M5 A2 stainless steel 4
12 Star washer DIN 6798 A M5 A2 stainless steel 4
13 CHc screw ISO 4762 M5x12 A2-70 stainless steel 4
14 Skiffy PCB spacer Ref. 100 0356 000 02 3
15 24 V AC/DC input label 1
16 Output label 1
17 568604509 24V insulation modules 1
18 Lucea 50 & 100 supply output cable 1
19 24 V input power supply cable 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 76 |
DIAGRAM 24 LUCEA 50 & 100 24V 1C POWER SUPPLY
1
2
3
6
14
8
15
4
5
7
9
1013 12
16
17
11
18
19
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 77 |
PARTS LIST 25 LUCEA 50 & 100 24V 2C POWER SUPPLY
5 686 04 953
No. Part number Description Qty
1 CHc screw ISO 4762 M3x25 A2-70 stainless steel 12
2 Star washer DIN 6798 A M3 A2 stainless steel 32
3 Hex nut ISO 4032 M3 A2 stainless steel 10
4 Ceiling power supply housing 2
5 Hexagonal spacer FF M3x55 Skiffy-301355040050 8
6 CHc screw ISO 4762 M3x8 nickel-plated steel CL8.8 18
7 Hexagonal spacer MF M3x10 Stainless steel 2
8 Diaphragm grommet (dia. 22) Ref. 161-4076 8
9 Ceiling power supply frame 2
368608555 Cover ring kit (pack of 2) 1
10 Ceiling cover half-ring B30-80 RAL 9016 4
- M3x25 screw (not shown) 1
11 Hex nut ISO 4032 M5 A2 stainless steel 4
12 Star washer DIN 6798 A M5 A2 stainless steel 8
13 CHc screw ISO 4762 M5x12 A2-70 stainless steel 4
14 Skiffy PCB spacer Ref. 100 0356 000 02 6
15 24 V AC/DC input label 2
16 Output label 2
17 568604509 24V insulation modules 2
18 Lucea 50 & 100 supply output cable 2
19 24 V input power supply cable 2
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 78 |
DIAGRAM 25 LUCEA 50 & 100 24V 2C POWER SUPPLY
1
2
3
6 14
8
15
4
5
7
9
1013 12
16
17
11
18
19
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 79 |
PARTS LIST 26 LUCEA 1W POWER SUPPLY
568604954
No. Part number Description Qty
1 Wall power supply frame 1
2 Wall-mounted PSU cover 1
3 699606024 ECS power supply 100US 25 XE0344 80/100W XP
Power
1
4 Lucea 50 & 100 mains supply cable 1
5 Lucea 50 & 100 supply output cable 1
6 CHc screw M3x8 nickel plated 4
7 Star washer, A-shape, M3 stainless steel DIN 6798 5
8 CHc screw M3x12 stainless steel DIN 912 4
9 Star washer DIN 6798 A M5 stainless steel 4
10 Hex nut M5 stainless steel DIN 934 2
11 100V-240 V AC input label 1
12 Output label 1
13 Blue Mobile/Hospital earth cable 1
14 ULF M4x12 stainless steel screw 4
15 Blanking plate 1
16 24 V AC/DC backup label 1
17 Remote backup label 1
18 Electrical hazard label 1
19 Elettrogibi PA 27 connecting block (12 poles) 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 80 |
DIAGRAM 26 LUCEA 1W POWER SUPPLY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 81 |
PARTS LIST 27 LUCEA 2W POWER SUPPLY
568604955
No. Part number Description Qty
1 Wall power supply frame 1
2 Wall-mounted PSU cover 1
3 699606024 ECS power supply 100US 25-XE0344 80/100W XP
POWER
2
4 Lucea 50 - 100 mains supply cable 2
5 Lucea 50-100 supply output cable 2
6 CHc screw M3x8 nickel plated 8
7 Star washer, A-shape, M3 stainless steel DIN 6798 10
8 CHc screw M3x12 stainless steel DIN 912 8
9 Star washer DIN 6798 A M5 stainless steel 4
10 Hex nut M5 stainless steel DIN 934 2
11 100V-240 V AC input label 2
12 Output label 2
13 Blue Mobile/Hospital earth cable 1
14 ULF M4x12 stainless steel screw 4
15 Blanking plate 1
16 24 V AC/DC backup label 2
17 Remote backup label 2
18 Electrical hazard label 2
19 Elettrogibi PA 27 connecting block (12 poles) 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 82 |
DIAGRAM 27 LUCEA 2W POWER SUPPLY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 83 |
PARTS LIST 28 BACKUP POWER SUPPLY
5 686 04 959
No. Part number Description Qty
368617998 Backup unit with control panel S/A 1
3 Power supply unit housing 1
11 Mounting bracket 1
12 Terminal block cover 1
13 Diaphragm grommet, dia. 22 1
14 CBL tapping screw ISO 7049 ST2,9x6.5 2
15 Heyco dome plug - 1500 white 1
16 RJ45 fastening insert INS88N 1
17 RJ45 panel penetration PRP886BL 1
22 Electrical hazard label 1
23 Single backup unit 1
24 RJ45 cord (cat. 5) - 0.5 m 2
25 100V-240 V AC input label 1
26 Output label 1
27 CHc screw M5x12 stainless steel 11
28 CHc screw ISO 4762 M3x25 stainless steel 2
29 Hex nut M3 stainless steel DIN 934 2
368617555 Maquet backup power supply cable kit 1
Not shown
1 Battery pack housing 1
2 Battery pack cover 1
4 Power supply unit base 1
5 ECS power supply 100US 28 XE0344 80/100W XP Power 1
6 Charger board 1
7 12 V/12 Ah battery Ref. YUASA NP 12-12FR 2
8 Skiffy clip-on mounts 068010000203 16
9 ULF screw M3x8 stainless steel 8
10 Wall bracket 1
18 Lucea 50 - 100 mains supply cable 1
19 Backup unit output cable 1
20 Battery cable 1
21 Charger power supply interconnection cable 1
30 CHc screw M3x8 nickel plated 2
31 Star washer, A-shape, M3 stainless steel DIN 6798 4
32 Star washer, A-shape M5 stainless steel 1
33 Blue Mobile/Hospital earth cable 2
34 Hex nut M5 stainless steel DIN 934 1
35 Elettrogibi PA 27 connecting block (12 poles) 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 84 |
DIAGRAM 28 BACKUP POWER SUPPLY
12
3
4
5
6
7
8
9
10
11
12 1314
15
16
17
18
1920
21
22
23
24
25
26
27 28
2930
31
3233 34
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 85 |
PARTS LIST 29 SINGLE-CHANNEL BACKUP SWITCHOVER BOARD
5 686 04 950
No. Part number Description Qty
1 WALL-MOUNTED BACKUP UNIT FACEPLATE 1
2 SINGLE BACKUP UNIT 1
3 JUNCTION BOX LEGRAND (REF. 80052) 1
4 COUNTERSUNK WOOD SCREW TORX 4x35 STAIN-
LESS STEEL
4
5 Anchor bolt, Hilti HUD-1 5x25 4
DIAGRAM 29 SINGLE-CHANNEL BACKUP SWITCHOVER BOARD
4
2
1
5
3
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 86 |
PARTS LIST 30 DUAL-CHANNEL BACKUP SWITCHOVER BOARD
5 686 04 951
No. Part number Description Qty
1 WALL-MOUNTED BACKUP UNIT FACEPLATE 1
2 DOUBLE BACKUP UNIT 1
3 JUNCTION BOX LEGRAND (REF. 80052) 1
4 COUNTERSUNK WOOD SCREW TORX 4x35 STAIN-
LESS STEEL
4
5 Anchor bolt, Hilti HUD-1 5x25 4
DIAGRAM 30 BACKUP POWER SUPPLY
4 1 2
5
3
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 87 |
PARTS LIST 31 LUCEA 50-100 WALL-MOUNTED POWER SUPPLY KIT
5 686 04 958
No. Part number Description Qty
1 CHc screw ISO 4762 - M3x12 stainless steel 4
2 Star washer DIN 6798 A M3 stainless steel 5
3 Lucea 50 & 100 wall cable 1
4 Cylindrical spacer dia.3.2xdia.6x6 Skiffy 4
5 Power supply ECS100US28 XE0344 80/100W XP Power 1
6 Mains power supply cable 1
DIAGRAM 31 LUCEA 50-100
1
2
3
4
5
6
WALL-MOUNTED POWER SUPPLY KIT
Lucea 50-100 | Customertechnical manual | EN | 0174301 | 1C |
| 88 |
PARTS LIST 32 WALL BRACKET S/A
5 686 03 809
No. Part number Description Qty
1 Wall-mounted Blue 30-80 mounting point 1
2 4-way connection strip 1
3 CBL H screw ISO 7045 - M3x16 3
4 CBL Z screw ISO 7045 - M4x8 1
5 Star washer DIN 6797 A - M4 3
6 Earth label 1
7 Suspension earth cable 1
8 CBL H screw ISO 7045 - M3x16 11
DIAGRAM 32 LUCEA 50-100
WALL BRACKET S/A
1
2
3
4
5
6
7
8
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 89 |
PARTS LIST 33 LUCEA 50 - WALL-MOUNTED SUSPENSION
5 686 04 987
No. Part number Description Qty
1 568603809 Lucea 50-100 wall bracket S/A 1
2 569010107 Blue 30-80 wall-mounting cover 1
3 Lucea 50-100 double extension arm (850 mm) 1
4 568604810 Lucea 50 spring arm S/A 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 90 |
DIAGRAM 33 LUCEA 50
WALL-MOUNTED SUSPENSION
1
2
3
4
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 91 |
PARTS LIST 34 LUCEA 100 - WALL-MOUNTED SUSPENSION
5 686 03 987
No. Part number Description Qty
1 568603809 Lucea 50-100 wall bracket S/A 1
2 569010107 Blue 30-80 wall-mounting cover 1
3 Lucea 50-100 wall-mounted extension arm (850 mm) S/A 1
4 568603810 Lucea 100 spring arm S/A 1
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 92 |
DIAGRAM 34 LUCEA 100
WALL-MOUNTED SUSPENSION
1
2 3
4
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 93 |
PARTS LIST 35 SINGLE SHAFT S/A
5 686 03 801
No. Part number Description Qty
1 Blue 30-80 single shaft 1
2 FHc screw ISO 10642 - M6x12 stainless steel 4
3 FH screw ISO 7046 - M4x10 stainless steel 1
4 Ceiling cable, single suspension (video) 1
DIAGRAM 35 LUCEA 50-100
SINGLE SHAFT S/A
1
2
3
4
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 94 |
PARTS LIST 36 DOUBLE SHAFT S/A
5 686 03 805
No. Part number Description Qty
1 Blue 30-80 double shaft
2 CHc screw ISO 4762 - M5x8 Stainless steel
3 Drawn cup needle roller bearing HK 32x39x24
4 Needle bearing ring
5 Blue 30-80 bottom shaft ring
6 Lucea 50-100 non-video slip ring
7 Blue 30-80 bottom shaft ring
8 Set ring
9 Circlip for dia. 32 mm shaft
10 FHc screw ISO 10642 - M6x12 stainless steel
11 Lucea 50-100 video slip ring
DIAGRAM 36 LUCEA 50-100
DOUBLE SHAFT S/A
1
2
3
4
5
6
7
8
9
3
4
5
11
7
8
9
10
2
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 95 |
PARTS LIST 37 SINGLE WALL-MOUNTED POWER SUPPLY BACKUP UNIT KIT
5 686 04 947
No. Part number Description Qty
1 WALL-MOUNTED PSU COVER 1
2 SINGLE BACKUP UNIT 1
3 RJ45 cable (not shown) 1
DIAGRAM 37 SINGLE WALL-MOUNTED POWER SUPPLY BACKUP UNIT KIT
PARTS LIST 38 DOUBLE WALL-MOUNTED POWER SUPPLY BACKUP UNIT KIT
5 686 04 948
No. Part number Description Qty
1 WALL-MOUNTED PSU COVER 1
2 DOUBLE BACKUP UNIT 1
3 RJ45 cable(not shown) 2
DIAGRAM 38 DOUBLE WALL-MOUNTED POWER SUPPLY BACKUP UNIT KIT
1
2
1
2
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 96 |
PARTS LIST 39 LUCEA 50 &100 REMOTE CONTROL
5 686 04 970
No. Part number Description Qty
368602900 Lucea bottom housing with remote control
5 Remote control bottom section 1
6 Remote control hook 1
8 Raised countersunk head screw, H type recess ISO 7047
M3x8 stainless steel
1
9 Remote control battery compartment cover 1
11 Remote control identification label 1
1 Remote control lexan panel 1
2 Remote control top section 1
3 Remote control IR plate 1
4 Remote control board 1
7 Eco-syn screw, FZ Bossard BN82427 dia.3x14 mm zinc-plated
steel
4
10 Remote control wall bracket 1
12 Pack of two AA batteries 1
DIAGRAM 39 LUCEA 50 &100 REMOTE CONTROL
1
2
3
4
5
6
7
8
9
11
12
10
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 97 |
13 WIRING DIAGRAMS
13.1 WIRING DIAGRAM: LUCEA 100 LIGHTHEAD
Fork cable
Switch cable
On/off switch
Keypad cable
Capacitive keypad
I2C network cable
LED board cable
LED board cable
Camera cable
Two video wires
Camera
Ferrite bead
Control
board
Control
board
Lucea 100 power
supply cable
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 98 |
13.2 WIRING DIAGRAM: LUCEA 50 LIGHTHEAD
Fork cable
L50 power supply cable
Ferrite bead
Control board
LED board cable
Capacitive keypad
Keypad cable
Switch cable
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 99 |
14 DRAWINGS OF CEILING COVERS
1
1
5
0
+
2
Ø478 ±1
Ø77±0,2
126 ±1
R
6
0
0
R13
A
1
7
±
1
47±1
9±0,2
8
3
±
0
,5
8
8
3
±
0
,5
2x Ø5,5
R8 R4
1
6
2
5,
0
±
2
±
0
,5
A (1:1)
CEILING COVER - 250 MM (5 690 29 999)
2
5
0
0
+
2
488±1
Ø77±0,2
Ø126 ±1
R13
R
6
0
0
±
1
A
9±0,2
8
3
±
0
,5
1
4
2
±
0
,5
8
8
3
±
0
,5
4x Ø5,5
1
4
2
±
0
,5
1
7
±
1
47±1
1
6
2
5,
0
±
2
5,
0
±
R8 R4
A ( 1 : 1 )
CEILING COVER - 115 MM - LOW-CEILING VERSION (5 690 28 999)
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 100 |
CEILING RING - 65 MM - LOW-CEILING VERSION (5 690 27 999)
6
-
0
,1
0
6
-
0
,1
0
Ø500±0,3
Ø77±0,2
7 x
 Ø
4
45° 45°
Ø480
100±0,2
165±0,2
1,5
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 101 |
15 CONNECTING AND DISCONNECTING - MOBILE VERSION
The light is designed to operate using a 100 V-240 V power supply.
Higher or lower voltages may affect the light intensity and operating life of the LEDs.
WARNING!
Insert the mobile light's plug (A) into a
mains socket (make sure that it is in good
condition and protected/shielded).
Do not pull on the power supply lead to disconnect it from the power outlet.
WARNING!
A
Example with
a mobile Lucea 50
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 102 |
16 SUMMARY OF POWER SUPPLY WIRING DIAGRAMS
POWER SUPPLY WITHOUT BACKUP
Mains
100/120V -
50/60Hz
Power supply
28 V output
4 mm²
recommended
up to 80 m
POWER SUPPLY WITH CUSTOMER BACKUP
Mains
100/120V -
50/60Hz Power supply
+
Switchover board
28 V output
4 mm²
recommended
up to 80 m
RJ45 cable (cat. 5)
50 m max. Backup unit
Customer backup
4 mm²
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 103 |
POWER SUPPLY WITH MAQUET BACKUP
POWER SUPPLY (GERMANY ONLY)
Mains
100/120V -
50/60Hz Power supply
with Maquet backup
28 V output
4 mm²
recommended
up to 80 m
RJ45 cable (cat. 5)
50 m max.
Backup unit
24V customer
input, 4 mm²
recommended
(AC/DC)
24 V
power supply
24 V DC output
(insulated cable)
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 104 |
LU
C
E
A
50
 s
im
pl
e
pl
af
on
ni
er
 :
A
R
D
LC
A
20
90
12
C
LU
C
E
A
50
 d
uo
 p
la
fo
nn
ie
r :
 A
R
D
LC
A
20
90
13
C
LU
C
E
A
10
0
+
LU
C
A
50
 p
la
fo
nn
ie
r :
 A
R
D
LC
A
20
90
2C
LU
C
E
A
10
0
si
m
pl
e
pl
af
on
ni
er
 :
A
R
D
LC
A
21
90
00
C
LU
C
E
A
10
0
du
o
pl
af
on
ni
er
 :
A
R
D
LC
A
21
90
01
C
Lo
ng
ue
ur
 e
t
ré
fé
re
nc
e
de
 tu
be

se
lo
n
la
 h
au
te
ur
 d
e
pl
af
on
d
A
R
D
56
90
60
99
9
à
A
R
D
56
90
70
99
9
K
it
co
nt
re
 p
la
qu
e
po
ur
 v
er
si
on
 d
uo
A
R
D
56
90
58
99
9
A
nn
ea
u
d’
an
cr
ag
e
H
M
56
07
76
44
R
éh
au
ss
e
R
E
H
00
06
/0
00
7/
00
08
C
ap
ot
 p
la
fo
nn
ni
er
 b
om
bé
A
R
D
56
90
28
99
9
C
ap
ot
 p
la
fo
nn
ni
er
 b
om
bé
A
R
D
69
02
99
99
B
rid
e
P
la
fo
nd
 n
or
m
al
 :
A
R
D
56
86
04
90
2
C
ap
ot
 p
la
t
A
R
D
56
90
27
99
9
A
lim
en
ta
tio
n
90
-2
40
V
:
M
ur
al
e
si
m
pl
e
: A
R
D
56
86
04
95
4
M
ur
al
e
do
ub
le
 :
A
R
D
56
86
04
95
5
P
la
fo
nn
iè
re
 s
im
pl
e
: A
R
D
56
86
04
95
6
P
la
fo
nn
iè
re
 d
ou
bl
e
: A
R
D
56
86
04
95
7
A
lim
en
ta
tio
n
24
V
A
C
/D
C
 :
P
la
fo
nn
iè
re
 s
im
pl
e
: A
R
D
56
86
04
95
2
P
la
fo
nn
iè
re
 d
ou
bl
e
: A
R
D
56
86
04
95
3
Pa
ck
 b
at
te
rie
s+
A
lim
en
ta
tio
n/
C
ha
rg
eu
r (
se
co
ur
s)
 :
P
ow
er
 M
od
ul
e
LC
A
1W
 B
M
 :
A
R
D
56
86
04
95
9
A
lim
en
ta
tio
n
U
S
 a
ve
c
«t
er
m
in
at
io
n
bo
x»
 :
O
pt
io
ns
 :
C
am
ér
a
: A
R
D
56
86
04
97
1
Té
lé
co
m
m
an
de
 :
A
R
D
 5
68
60
49
70
K
it
S
ec
ou
rs
 :
A
R
D
56
86
04
94
9
K
it
m
ur
al
 1
 c
ou
po
le
 :
A
R
D
56
86
04
95
0
K
it
m
ur
al
 2
 c
ou
po
le
s
: A
R
D
56
86
04
95
1
B
rid
e
P
la
fo
nd
 b
as
 :
A
R
D
56
86
04
90
4
17 INSTALLATION BLOCK DIAGRAMS
INSTALLATION BLOCK DIAGRAM: CEILING-MOUNTED LUCEA
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 105 |
51
50
11
99
9
51
50
09
99
9
51
50
53
99
9
51
50
53
99
9
B
ra
s
de
 s
us
pe
ns
io
n
vi
dé
o
12
00
 m
m
 :
A
R
D
56
86
04
91
2
13
50
 m
m
 :
A
R
D
56
86
04
91
3
B
ra
s
re
ss
or
t L
C
A
50
 :
A
R
D
56
86
04
94
1
C
ou
po
le
 L
C
A
50
 :
A
R
D
56
86
04
99
9
B
ra
s
re
ss
or
t L
C
A
10
0
: A
R
D
56
86
03
94
1
C
ou
po
le
 L
C
A
10
0
: A
R
D
56
86
03
99
9
Ad
ap
ta
te
ur
 B
LU
E/
LU
C
A
50
/1
00
51
50
88
99
9
LU
C
E
A
50
 s
im
pl
e
pl
af
on
ni
er
 :
A
R
D
LC
A
20
90
12
C
LU
C
E
A
50
 d
uo
 p
la
fo
nn
ie
r :
 A
R
D
LC
A
20
90
13
C
LU
C
E
A
10
0
+
LU
C
A
50
 p
la
fo
nn
ie
r :
 A
R
D
LC
A
20
90
2C
LU
C
E
A
10
0
si
m
pl
e
pl
af
on
ni
er
 :
A
R
D
LC
A
21
90
00
C
LU
C
E
A
10
0
du
o
pl
af
on
ni
er
 :
A
R
D
LC
A
21
90
01
C
Tu
be
 d
e
su
sp
en
si
on
 3
 a
xe
s
A
lim
en
ta
tio
n
m
ur
al
e
:
S
im
pl
e
: A
R
D
56
86
04
95
4
D
ou
bl
e
: A
R
D
56
86
04
95
5
SY
N
O
PT
IQ
U
E
LU
C
EA
 5
0
ET
 1
00
 S
AT
EL
IT
E
INSTALLATION BLOCK DIAGRAM: SATELITE VERSION
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 106 |
K
it
al
im
en
ta
tio
n
LC
A
50
 e
t L
C
A
10
0
: A
R
D
56
86
04
95
8
B
ra
s
de
 s
us
pe
ns
io
n
m
ur
al

LC
A
50
 :
A
R
D
56
86
01
84
6
B
ra
s
de
 s
us
pe
ns
io
n
m
ur
al

LC
A
10
0
: A
R
D
56
90
01
84
6
B
ra
s
re
ss
or
t L
C
A
50
 :
A
R
D
 5
68
60
18
42
B
ra
s
re
ss
or
t L
C
A
10
0
: A
R
D
 5
69
00
18
41
C
ou
po
le
 L
C
A
50
 :
A
R
D
56
86
04
99
9
C
ou
po
le
 L
C
A
10
0
: A
R
D
56
86
03
99
9
SY
N
O
PT
IQ
U
E
LU
C
EA
 5
0
ET
 1
00
 M
U
R
A
L
LC
A
50
 :
A
R
D
56
86
04
98
7
LC
A
10
0
: A
R
D
56
86
03
98
7
C
on
tre
-p
la
qu
e
:
A
R
D
56
90
79
99
9
INSTALLATION BLOCK DIAGRAM: WALL-MOUNTED LUCEA
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 107 |
B
ra
s
re
ss
or
t L
C
A
10
0
: A
R
D
 5
68
60
39
40
B
ra
s
re
ss
or
t M
O
B
 L
C
A
50
 :
A
R
D
 5
68
60
49
40
B
ra
s
re
ss
or
t M
O
B
 B
AT
 :
A
R
D
 5
68
60
49
42
C
ou
po
le
 L
C
A
10
0
: A
R
D
56
86
03
99
9
C
ou
po
le
 L
C
A
50
 :
A
R
D
56
86
04
99
9
Li
st
e
câ
bl
es
 d
’a
lim
en
ta
tio
n
:
E
ur
op
e
: A
R
D
56
86
04
96
0
U
K
 :
A
R
D
56
86
04
96
1
Ita
lie
 :
A
R
D
56
86
04
96
2
B
ré
si
l :
 A
R
D
56
86
04
96
3
A
us
tra
lie
 :
A
R
D
56
86
04
96
4
S
ui
ss
e
: A
R
D
56
86
04
96
5
Ja
po
n
: A
R
D
56
86
04
96
6
O
U
O
U
A
lim
en
ta
tio
n
av
ec
B
ra
s
re
ss
or
t M
O
B
 L
50
 :
A
R
D
 5
68
60
49
40
E
m
ba
se
 m
ob
ile

B
AT
 L
50
 :
A
R
D
 5
68
60
49
77
P
ie
d
m
ob
ile

B
AT
 B
30
 :
A
R
D
 5
69
07
29
99
P
ie
d
m
ob
ile

B
AT
 B
80
/L
10
0
: A
R
D
 5
69
07
49
99
E
m
ba
se
 m
ob
ile

L1
00
 :
A
R
D
 5
69
07
59
99
E
m
ba
se
 M
O
B
 B
AT
 L
10
0
56
86
03
97
7
INSTALLATION BLOCK DIAGRAM: MOBILE LUCEA
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 108 |
A
lim
en
ta
tio
n
P
la
fo
nn
iè
re
 2
4
V
A
lim
en
ta
tio
n
P
la
fo
nn
iè
re
 9
0-
24
0V
A
lim
en
ta
tio
n
m
ur
al
e
90
-2
40
V
A
lim
en
ta
tio
n
m
ur
al
e
90
-2
40
V

S
ec
ou
rs
 M
A
Q
U
E
T
A
lim
en
ta
tio
n
m
ur
al
e
U
S
S
im
pl
e
re
f.
56
86
04
95
2
1
vo
ie
D
ou
bl
e
re
f.
56
86
04
95
3
2
vo
ie
s
S
im
pl
e
re
f.
56
86
04
95
6
1
vo
ie
D
ou
bl
e
re
f.
56
86
04
95
7
2
vo
ie
s
K
it
ba
sc
ul
e
se
co
ur
s
(o
pt
io
n)
1
vo
ie

re
f.
56
86
04
94
9
K
it
ba
sc
ul
e
se
co
ur
s
(o
pt
io
n)
2
x
1
vo
ie
re
f.
56
86
04
94
9
K
it
re
po
rt
m
ur
al

1
vo
ie
 re
f 5
68
60
49
50
(o
pt
io
n)
K
it
re
po
rt
m
ur
al

2
vo
ie
s
re
f 5
68
60
49
51
(o
pt
io
n)
K
it
ba
sc
ul
e
se
co
ur
s
(o
pt
io
n)
1
vo
ie

re
f.
56
86
04
94
9
K
it
ba
sc
ul
e
se
co
ur
s
(o
pt
io
n)
2
x
1
vo
ie
re
f.
56
86
04
94
9
S
im
pl
e
re
f.
56
86
04
95
4
1
vo
ie
D
ou
bl
e
re
f.
56
86
04
95
5
2
vo
ie
s
Te
rm
in
at
io
n
B
ox
re
f.
56
86
04
94
6
Te
rm
in
at
io
n
B
ox
re
f.
56
86
04
94
6
S
im
pl
e
re
f.
56
86
04
95
4
1
vo
ie
D
ou
bl
e
re
f.
56
86
04
95
5
2
vo
ie
s
A
lim
en
ta
tio
n
1
vo
ie
re
f.
56
86
04
95
9
K
it
re
po
rt
m
ur
al

1
vo
ie
 re
f 5
68
60
49
50
(o
pt
io
n)
K
it
re
po
rt
m
ur
al

1
vo
ie
 re
f 5
68
60
49
50
(o
pt
io
n)
K
it
re
po
rt
m
ur
al

2
vo
ie
s
re
f 5
68
60
49
51
(o
pt
io
n)
C
ap
ot
 a
ve
c
cl
av
ie
r c
on
trô
le
re
f.
56
86
04
94
7
C
ap
ot
 a
ve
c
cl
av
ie
r c
on
trô
le
re
f.
56
86
04
94
8
INSTALLATION BLOCK DIAGRAM: POWER SUPPLY
Lucea 50-100 | Customer technical manual | EN | 0174301 | 1C |
| 109 |
MAQUET SA
Parc de Limère
Avenue de la Pomme de Pin
CS 10008 ARDON
45074 ORLÉANS CEDEX 2, France
Telephone: +33 (0) 2 38 25 88 88
Fax: +33 (0) 2 38 25 88 00
To find your closest representative:
Please go to
www.maquet.com
The Getinge Group is a leading global provider of equipment and
systems that contribute to quality enhancement and cost efficiency
within healthcare and life sciences. Equipment, service and tech-
nologies are supplied under the brands ArjoHuntleigh for patient
handling and hygiene, disinfection, DVT prevention, medical beds,
therapeutic surfaces and diagnostics, Getinge for infection control
and prevention within Healthcare and Life Science and Maquet for
Surgical Workplaces, Cardiovascular and Critical Care.
M
A
Q
U
E
T
®
 is
 a
 re
gi
st
er
ed
 tr
ad
em
ar
k
of
 M
A
Q
U
E
T
G
m
bH
 &
 C
o.
 K
G
 •
 T
he
 M
aq
ue
t s
pe
ci
fic
at
io
ns
 p
ro
vi
de
d
he
re
in
 a
re
 fo
r g
ui
da
nc
e
on
ly.
 M
aq
ue
t r
es
er
ve
s
th
e
rig
ht
 to
 c
ha
ng
e
th
em
 w
ith
ou
t n
ot
ic
e.
 •
C
us
to
m
er
 te
ch
ni
ca
l m
an
ua
l •
 R
ef
er
en
ce
: 0
17
43
01
 E
N
 E
d
1C
 •
