Bateria Global EVG6-340 6V340Ah

Prévia do material em texto

GEL Electrolyte:
The battery is constructed with special plates, separators, safety valves and GEL electrolyte. The batteries use silica gel to
immobilize the electrolyte inside the battery. The proven silica gel technology improves battery cycle life and performance at cold
ambient temperatures. The deep discharge cycles is increased by 50% as compared with the AGM battery. Moreover this battery
can use in any direction and position for operation.



Dimensions and Weight
Length ( mm )………….……….……….……..…295
Width ( mm ) ………………….………...…....… 178
Height ( mm ) …………………………….…….. 350
Total Height ( mm )…………….…. ..…..….……366
Approx.Weight ( Kg )………..…... ……………..44.0
Performance Characteristics
Nominal Voltage ………..………………..…………………… 6V
Number of cell …………………………………..……………... 3
Design Life ………………………………………..……………. 5 years
Nominal Capacity (25°C):
20 hour rate (17.0A, 5.25V) ………….……….….….….…..…340Ah
10 hour rate (32A, 5.25V) …………..……….….….….…..…320Ah
5 hour rate (58A, 5.25V) ………..………………...…..….........290Ah
1 hour rate (221A, 4.80V) …..…....……………..………….…..221Ah
Internal Resistance: Fully Charged battery (25°C) ….. .….…2 mΩ
Self-Discharge: 3% of capacity declined per month at 20°C(average)
Operation Temperature Range:
Discharge ………………………………………..…………. -20~60°C
Charge …………………………………………..………….. -10~60°C
Storage ……………………………………………………… -20~60°C
Max. Discharge Current (25°C) …………….....…...……. 4320A (5s)
Short Circuit Current ……...…………………………...………..5400A


Battery Constructionn
COMPONENT Positive plate Negative plate Container Cover Safety valve Terminal Separator Electrolyte
RAW MATERIAL Lead dioxide Lead ABS ABS Rubber Copper Fiberglass GEL

Charging Methods
Application
Charging
method
Charging
Voltage
 at 25°C
Temperature
compensation
coefficient of
charging voltage
Max.charging
current

Charging time
 25°C(h)
Temp
(°C)
100%
discharge
50%
discharge
For standby
power
source
Constant
voltage &
Constant
Current
 Charging
 (with current
restriction)
6.75-6.90V -20 mV/°C 72A 24 20
0~40°C
For
cycle service
7.30-7.50V -30 mV/°C 72A 16 10
*Temperature compensation of charging voltage is not needed. When using the batteries within 15°C to 35°C range.

EVG6-340 6V340Ah
 EVG6-340 6V340Ah













































Discharge Constant Current (Amperes at 25°C)
F.V/Time 5min 10min 15min 30min 45min 1h 2h 3h 5h 8h 10h 20h
1.60V 1190 952 680 393 280 221 119 86.0 58.8 38.4 33.2 17.5
1.65V 1156 918 646 384 275 220 118 85.8 58.5 38.4 32.8 17.3
1.70V 1088 850 612 374 272 218 118 85.0 58.3 38.2 32.6 17.2
1.75V 952 714 578 356 269 214 115 84.1 58.0 37.6 32.0 17.0
1.80V 850 612 544 306 265 212 112 81.6 57.1 37.6 31.8 16.9

Discharge Constant Power (Watts/cell at 25°C)
F.V/Time 5min 10min 15min 30min 45min 1h 2h 3h 5h 8h 10h 20h
1.60V 2168 1736 1251 757 529 428 229 166 115 74.5 62.4 34.5
1.65V 2441 1666 1183 733 524 417 227 164 113 74.3 62.2 34.0
1.70V 2328 1567 1129 700 518 417 224 164 112 74.1 62.0 33.7
1.75V 2040 1325 1064 656 510 411 223 162 112 73.3 61.2 33.2
1.80V 1821 1190 1005 569 503 405 214 158 111 73.3 60.4 32.5

Globalbat Importação e Exportação Ltda
Rua Francisco Silveira Bitencourt, 945 - Porto Aleg re/RS - CEP 91.150-010
 TEL:(51) 3355 23 00 - FAX:(51) 3348 00 66
 www.globalbat.com.br - globalbat@globa lbat.com.br

Testing Conditions:Floating Voltagr:2.25 to 2.30 /Cell
Ambient Temperature:20¡ ãC to 25¡ ãC (68¡ ãF to 77¡ ãF)
