185ACI Structural Journal/May 2020
ACI STRUCTURAL JOURNAL TECHNICAL PAPER
Fiber-reinforced polymers (FRPs), as noncorrosive materials, offer
a great potential for use as reinforcement in concrete construc-
tion. Nevertheless, the characteristics of these materials have led
to new challenges in the design of FRP-reinforced concrete (RC)
components. Design of steel-RC beams usually results in under-
reinforced beams, with failure governed by the yielding of steel,
while in the FRP-RC counterparts, concrete crushing is the most
desirable failure mode. Compared to steel bars, FRP displays higher
strength and lower Young’s modulus, thus indicating that the design
of FRP-RC elements will be largely influenced by the serviceability
limit state of excessive deflections. A significant body of knowl-
edge has been accrued towards the safety of FRP-RC components
with respect to ultimate limit states; on the contrary, the probabi-
listic assessment of the serviceability of FRP-RC beams is almost
nonexistent. This study presents a contribution to the development
of reliability-based design recommendations for deflection control
of FRP-RC beams. A framework for the probabilistic assessment
of the deflections of FRP-RC beams designed according to ACI
440 is described. Monte Carlo simulation is used in the proba-
bilistic description of beam deflections and in the computation of
the probabilities of excessive deflections (and attendant reliability
indexes) of 81 representative beams. The results indicate a wide
range of values for the reliability indexes (from positive up to nega-
tive ones); additionally, all parameters (load ratio, FRP strength,
concrete compressive strength, and failure mode) have a consider-
able impact on the resulting reliability levels. The use of a smaller
strength-reduction factor led to a significant improvement in the
resulting reliability levels for FRP-RC beams.
Keywords: beams; deflections; design codes; fiber-reinforced polymer
(FRP); Monte Carlo simulation; reinforced concrete (RC); reliability;
serviceability limit state.
INTRODUCTION
Durability of reinforced concrete (RC) structures and,
consequently, the service life of these structures is often
dictated by the corrosion of reinforcing steel usually caused
by chloride ingress (Lorensini and Diniz 2010) or carbon-
ation (Couto and Diniz 2018). Accordingly, a major chal-
lenge in increasing sustainability of RC structures is to
reduce/eliminate corrosion of the reinforcing bars. While
this may be achieved by a number of techniques as presented
in ACI 222.3R (ACI Committee 222 2011), fiber-reinforced
polymers (FRPs), as noncorrosive materials, offer a great
potential for use as reinforcement in concrete construction.
Although the use of FRP bars as structural reinforcement
shows great promise in terms of durability, the character-
istics of these materials have led to new challenges in the
design of FRP-RC components. Design of steel-RC beams
usually results in under-reinforced beams, with the failure
governed by yielding of steel, while in the FRP-RC coun-
terparts, concrete crushing is the most desirable failure
mode (Nanni 1993). Furthermore, compared to steel bars,
FRP displays higher strength and lower Young’s modulus,
thus indicating that the design of FRP-RC elements will be
largely influenced by the serviceability limit state of exces-
sive deflections (Mota et al. 2006; La Tegola 1998).
Deflections of RC beams have traditionally been computed
using an elastic deflection equation that includes an effec-
tive moment of inertia, Ie, originally introduced by Branson
(1965) for steel-reinforced concrete (Bischoff and Gross
2011). However, it has been recognized that Branson’s empir-
ical equation gives a too-stiff response for FRP-RC beams
and underestimates deflection of such members (Nawy and
Neuwerth 1977; Yost et al. 2003). At the same longitudinal
reinforcement ratio, the replacement of steel bars with FRP
would typically result in larger deflections (Gao et al. 1998;
Tighiouart et al. 1999). Numerous equations have been
proposed for calculating the effective moment of inertia of
FRP-RC members (Peña 2010; Silva 2017).
Current design recommendations of steel-reinforced
members (for example, ACI 318 [ACI Committee 318 2014]
and Eurocode 2 [CEN 2004]) are based on limit state design
principles—that is, the member is designed for its required
strength and then checked for serviceability criteria. The
limit states format, also known as semi-probabilistic format,
employs one “characteristic” value of each uncertain param-
eter (usually resistances and load effects) with reduced resis-
tances and majored loads obtained via partial resistance and
load factors. These factors are currently defined via probabi-
listic methods (Ang and Tang 1984) in a process known as
code calibration. An example of such a procedure is found
in Szerszen and Nowak (2003), describing the calibration of
ACI 318 for different structural components and the perti-
nent ultimate limit states.
While much has been achieved in terms of developing a
clear rationale for code calibration with respect to ultimate
limit states of traditional steel RC construction, the same is
not true for serviceability limit states. Although conceptual
models have long been available, the implementation of
reliability-based performance indicators for serviceability
Title No. 117-S61
Reliability-Based Design Recommendations for Deflection
Control of Fiber-Reinforced Polymer-Reinforced
Concrete Beams
by Elayne M. Silva, Sidnea E. C. Ribeiro, and Sofia M. C. Diniz
ACI Structural Journal, V. 117, No. 3, May 2020.
MS No. S-2019-163.R1, doi: 10.14359/51723499, received May 20, 2019, and
reviewed under Institute publication policies. Copyright © 2020, American Concrete
Institute. All rights reserved, including the making of copies unless permission is
obtained from the copyright proprietors. Pertinent discussion including author’s
closure, if any, will be published ten months from this journal’s date if the discussion
is received within four months of the paper’s print publication.
186 ACI Structural Journal/May 2020
limit states in current codes has lagged for a number of
reasons (Ghosn et al. 2016).
RESEARCH SIGNIFICANCE
In spite of the important differences between steel-RC and
FRP-RC structures, code development regarding the latter
has followed a similar path as for traditional steel RC, with
an initial emphasis on the design of safe FRP-RC structures
and definition of the requisite partial safety factors. To this
end, a significant body of knowledge has been accrued
towards the safety of FRP-RC components with respect to
ultimate limit states (ACI Committee 440 2015; Ribeiro and
Diniz 2013; Shield et al. 2011). On the contrary, probabi-
listic assessment of the serviceability of FRP-RC beams and
derivation of reliability-based design recommendations for
deflection control of such elements is almost nonexistent. In
this context, this study presents a contribution to the
development of reliability-based design recommendations
for deflection control of FRP-RC beams. A framework for
the probabilistic assessment of deflections of FRP-RC beams
designed according to ACI 440.1R (ACI Committee 440
2015) is described. Monte Carlo simulation is used in the
probabilistic description of the beam deflections, and in the
computation of the probability of excessive deflections (and
attendant reliability indexes) of representative beams.
RELIABILITY BASICS FOR DEFLECTION
CONTROL OF FRP-RC BEAMS
Supply versus demand problem
The basic problem of structural reliability may be cast as
a supply versus demand problem—that is, to ascertain that
the supply (for example, strength), X, will be larger than the
demand (for example, load effects), Y, throughout a refer-
ence period (for example, the service life of the structure),
represented by (X > Y). Considering the uncertainties asso-ciated to these variables, this assurance is possible only in
terms of the probability P(X > Y), thus representing a real-
istic measure of the reliability of the structural component
(Ang and Tang 1984).
Margin of safety
The supply-demand problem may be formulated in terms
of the margin of safety, M, where M = X – Y. Because X and Y
are random variables, M is also a random variable with corre-
sponding probability density function, fM(m). Failure corre-
sponds to the condition (M 0 represents “satisfactory performance” and g(X) ρfb) or FRP rupture (ρf ρfb (over-reinforced
beams), the nominal bending resistance, Mn, is given by
 M A f d a
n f f= −


2
 (8)
where a and the stress level at the FRP reinforcement, ff, are,
respectively
 a
A f
f b
f f
c
=
′0 85.
 (9)
 f
E f
E E ff
f cu c
f
f cu f cu fu= +
′
−








≤
( ) .
.
ε β
ρ
ε ε
2
1
4
0 85
0 5
(10)
For ρf


ε
ε ε
 (12)
According to ACI 440.1R (ACI Committee 440 2015),
to account for long-term exposure to the environment, the
design tensile strength of FRP bars is
 ffu = CE f*fu (13)
where CE is the environmental reduction factor; and f*fu
is guaranteed tensile strength of FRP bar, defined as mean
tensile strength of sample of test specimens minus three
times the standard deviation.
MONTE CARLO SIMULATION OF DEFLECTIONS
OF GFRP-RC BEAMS
In this section, the framework of the Monte Carlo simu-
lation of deflections of GFRP-RC beams is detailed. The
selected beams are presented, a procedure for the calculation
of the total deflection of GFRP-RC beams is established, the
statistical description of the basic variables are reviewed,
and the corresponding statistics of the total deflections of the
selected beams are obtained.
Selected beams
Eighty-one GFRP-RC beams, designed according to ACI
440.1R (ACI Committee 440 2015) recommendations for
flexure, were selected for analysis. Due to the smaller costs
compared to other types of fibers used in civil engineering
construction, GFRP has been considered for the reinforcement
of the selected beams (Ribeiro and Diniz 2013). All beams
are simply supported, 3 m span, 20 x 30 cm2 rectangular
cross sections, and subjected to uniformly distributed loads.
The analysis was planned to verify the influence of concrete
compressive strength, amount of longitudinal reinforcement,
GFRP tensile strength, and load ratio on the implicit reliability
levels with respect to the limit state of excessive deflections.
Three specified concrete compressive strengths—30, 50,
and 70 MPa—were chosen. Higher concrete compressive
strengths (50 and 70 MPa) have been included because it has
been reported that the high tensile strength of FRP is most
efficiently used when paired with high-strength concrete
(Nanni 1993). Three GFRP tensile strengths, f*fu—485,
850, and 1275 MPa, consistent with those suggested in
ACI 440.1R (ACI Committee 440 2015) for GFRP—were
selected; the environmental reduction factor, CE, is assumed
as 0.8. FRP reinforcement ratios in the range of 0.82 to 2.10
ρfb have been used, representing under-reinforced, in the
transition zone, and over-reinforced beams. The selected
GFRP bars have diameters ranging from 6.3 to 22.5 mm.
Three mean dead load to mean live load ratios (μDL/μLL = 0.5,
1.0, and 2.0) have been selected.
Each beam is identified by four groups of numbers and/or
letters. The first group—C30, C50, and C70—represents the
specified concrete compressive strength in MPa. The second
group is related to the tensile strength of GFRP bars (P1:
485 MPa, P2: 850 MPa, and P3: 1275 MPa). The third group
is related to the load ratio (R5, R1, and R2 correspond to
μDL/μLL = 0.5, 1.0, and 2.0, respectively). The fourth group is
associated to the GFRP longitudinal ratio (UR is under-
reinforced beams, TR is transition zone, and OR is over-
reinforced beams). For example, Beam C50-P2-R2-UR has
a specified concrete cylinder strength of 50 MPa, GFRP
tensile strength of 850 MPa, load ratio equal to 2.0, and is
under-reinforced.
Deflection equation for GFRP-RC beams
Total deflection, ∆total, is calculated by the sum of the
immediate deflection, ∆i, and the long-term deflection due to
creep and shrinkage, ∆(cp + sh).
Immediate deflection, ∆i, of FRP-RC beams is calculated
by an elastic equation that takes into account the load acting
on the structure at service pserv, Young’s modulus of concrete,
Ec, and effective moment of inertia Ie. For simply supported
beams subjected to uniformly distributed loads, the determin-
istic equation to calculate the immediate deflection is
 ∆ i
serv
c e
p
E I
=
5
384
4
 (14)
Equation (14) requires the effective moment of inertia, Ie,
which, for steel-reinforced beams, is usually calculated by
Branson’s equation. In the case of FRP-RC beams, it has been
reported that Branson’s equation overestimates the effective
moment of inertia (ACI Committee 440 2015). Therefore,
different equations have been suggested for the calculation
of the effective moment of inertia of FRP-RC beams.
In addition to uncertainties inherent in the variables relevant
to the problem at hand, reliability analysis must include uncer-
tainty in model predictions. In this light, the main problem
related to Eq. (14) is the selection of the equation for the effec-
tive moment of inertia, Ie, and the incorporation of the atten-
dant uncertainty in the deflection prediction, into the analysis.
Mota et al. (2006) present the statistics of the random vari-
able “model error”—that is, the ratio “experimental deflec-
tion/calculated deflection”, η = ∆exp/∆calc, for FRP-RC beams.
The calculated deflection, ∆calc, was obtained using different
equations for the effective moment of inertia in the prediction
of deflections at service. For GFRP-RC beams, those results
indicate the ranges 0.49 to 1.45 for the mean model error, μη,
and 0.063 to 0.082 for the coefficient of variation, COV(η).
The statistics of the model error, η, may be used in the selec-
tion of the equation to best represent the effective moment of
inertia. To this end, a mean model error, μη, close to 1.0 and a
small COV(η) are desirable features of the model.
Considering that the model error associated to the equa-
tion suggested by Yost et al. (2003) has mean μ = 0.95 and
COV = 0.0698, this is the equation used in this study for the
prediction of the effective moment of inertia of GFRP-RC
beams. As a comparison, the corresponding statistics found
by Mota et al. (2006) for the equation proposed by Gao
et al. (1998) are μ = 1.24 and COV = 0.074. Accordingly, the
effective moment of inertia, Ie, is given by (Yost et al. 2003)
189ACI Structural Journal/May 2020
 I M
M
I M
M
I Ie
cr
a
d g
cr
a
cr g= 



+ − 



















≤
3 3
1β (15)
where Mcr is cracking moment; Ma is maximum moment in the
beam at the stage deflection is computed; Ig is gross moment
of inertia; Icr is moment of inertia of transformed cracked
section, βd is reduction coefficient, βd = α([Ef/Es] + 1); α is
bond dependent coefficient, α = 0.064 (ρf/ρfb) + 0.13; and Es is
steel modulus of elasticity. The model error, η, is then used as
a multiplier of the immediate deflection given by Eq. (14), thus
resulting in the adjusted immediate deflection, ∆i,a
 ∆ i a
serv
c e
p
E I, =
5
384
4

η (16)
The long-term deflection due to creep and shrinkage,
∆(cp + sh), for FRP-RC beams can be calculated according to
the following equations (ACI Committee 440 2015)
 ∆(cp + sh) = 0.6λ(∆i)sus (17)
 λ
ξ
ρ
=
+ ′( )1 50
 (18)
where (∆i)sus is the immediate deflection due to sustained
loads; and ρ′ is the ratio of compression reinforcement. The
parameter λ in Eq. (17) reduces to ξ because compression
reinforcement is not considered for FRP-RC members (ρ′ =
0). Values of the time-dependent factor for sustained loads,
ξ, are reported in ACI 318 (ACI Committee 318 2014).
In this study, ξ is taken as 2.0 (sustained load duration of
5 years or more). This value is consistent with the 8-year
reference period for live loads adopted in this study for
the serviceability analysis (refer to the section “Loads”).
Furthermore, it is assumed that 20% of the live load is
sustained loading. In this way, the long-term deflection of
GFRP-RC beams is calculated by
 ∆(cp + sh) = 1.2 [(∆i,a)D + 0.2 (∆i,a)L] (19)
where the subscripts D and L in the adjusted immediate
deflections, ∆i,a, correspond to deflections caused by dead
and live loads, respectively. Thus, the total deflection is
given by
 ∆total = [0.8 (∆i,a)L] + ∆(cp + sh) (20)
This deterministic procedure for the computation of the
beam total deflection is illustrated by the flowchart presented
in Fig. 2.
Fig. 2—Flowchart of deterministic procedure for computation of total deflection.
190 ACI Structural Journal/May 2020
Statistical descriptionof basic variables
The statistics (mean, coefficient of variation, and type of
distribution) of the basic variables considered in this study
(cross section geometry, concrete compressive strength,
GFRP tensile strength, GFRP modulus of elasticity, dead
loads, live loads at service, and model error) are summa-
rized in Table 1. The rationale for the assumed statistics
is presented in the following. Beam span (ℓ = 3.0 m) and
FRP reinforcement area (nominal area of the FRP bar) are
assumed as deterministic.
Compressive strength, modulus of elasticity of
concrete, and cracking moment
Evolution of quality control worldwide has resulted in
coefficients of variation close to 0.10 for a wide range of
compressive strengths (Azevedo and Diniz 2008; Nowak
and Szerszen 2003). Nowak and Szerszen (2003) recom-
mend a Normal distribution to describe the variability of
the concrete compressive strength; nevertheless, other
researchers suggest a Lognormal distribution (Azevedo
and Diniz 2008; Diniz and Frangopol 1997). In this study, a
Lognormal distribution is assumed for the random variable
concrete compressive strength (cylinder strength).
For a given specified strength, fc′, obtained from cylinder
tests, if the coefficient of variation of the concrete compressive
strength, V, is known, then the mean, μ, may be calculated
by ACI 318 (ACI Committee 318 2014)
 fc′ = μ(1 – 1.34V) (21)
The random variable in-place concrete compressive
strength, fc, is obtained by multiplying the random variable
cylinder strength by a reduction factor, αc, equal to 0.85 for
fc′ ≤ 55 MPa; or αc = 0.85 – 0.004 (fc′ – 55) ≥ 0.75, for fc′ >
55 MPa (Diniz and Frangopol 1997).
The modulus of elasticity of concrete, Ec, is taken as a
random variable derived from the in-place compressive
strength of concrete, fc
 E fc c= 4700 (22)
with fc given in MPa. Cracking moment, Mcr, is also a
random variable derived from the modulus of rupture of
concrete, fr, and the gross moment of inertia, Ig, Mcr = frIg/yt.
The distance from centroidal axis of gross section to tension
face, yt, is assumed as deterministic. Modulus of rupture of
concrete, fr, is taken as a random variable derived from the
in-place compressive strength, fc, calculated by
 f fr c= 0 62. � (23)
Table 1—Statistics of basic variables
Basic variable μ σ COV Probability distribution
Dimensions*
∆h, ∆b 1.524 mm 6.35 mm 0.0417 Normal
Cover, ∆c 6.35 + 0.004h, mm 4.22 mm — Normal
Concrete compressive strength†
fc′ = 30 MPa 34.64 MPa 3.46 MPa 0.10 Lognormal
fc′ = 50 MPa 57.74 MPa 5.77 MPa 0.10 Lognormal
fc′ = 70 MPa 80.83 MPa 8.08 MPa 0.10 Lognormal
GFRP tensile strength (f*fu)
f*fu = 485 MPa 570.59 MPa 28.53 MPa 0.05 Normal
f*fu = 850 MPa 1000 MPa 50 MPa 0.05 Normal
f*fu = 1275 MPa 1500 MPa 75 MPa 0.05 Normal
GFRP modulus of elasticity (Ef)
Ef = 35 GPa 35 GPa 1750 MPa 0.05 Normal
Ef = 42.5 GPa 42.5 GPa 2125 MPa 0.05 Normal
Ef = 50 GPa 50 GPa 2500 MPa 0.05 Normal
Model error
η 0.95 0.066 0.0698 Normal
Loads
Type μU/Un
‡ COV Probability distribution
Dead load, D 1.05 0.10 Normal
Live load (ULS), LULS 1.00 0.25 Type I
Live load (SLS), LSLS 0.65 0.32 Type I
*Deviations from nominal values.
†Cylinder strength.
‡Ratio mean to unfactored nominal load.
191ACI Structural Journal/May 2020
Gross moment of inertia, Ig, is assumed as a random vari-
able (refer to the section “Cross section geometry” for the
variability of beam depth, h, and beam width, b). For rectan-
gular cross sections, Ig is given by
 I bh
g =
3
12
 (24)
Mechanical properties of FRP bars
In this sudy, three nominal tensile strengths, f*fu, of the
GFRP bar are adopted: 485, 850, and 1275 MPa; a Normal
distribution with coefficient of variation of 0.05 is assumed
to describe the variability of the tensile strength, ffu (Pilak-
outas et al. 2002). The corresponding mean tensile strength,
ffu, ave, of the FRP bar is given by ACI Committee 440 (2015)
 ffu, ave = f*fu + 3s (25)
The design modulus of elasticity of FRP, Ef, is the same as
the value reported by the manufacturer—that is, it is equal to
the mean elastic modulus (nominal value), Ef,ave, of a sample
of test specimens (ACI Committee 440 2015)
 Ef = Ef, ave (26)
It is assumed that the modulus of elasticity of FRP, Ef, is
a random variable with mean 35, 42.5, and 50 GPa for the
strengths of 485, 850, and 1275 MPa, respectively; it follows
a Normal distribution and has coefficient of variation of 0.05
(Pilakoutas et al. 2002).
Cross section geometry
Following Mirza and Macgregor (1979), it is considered
that the variability of the deviations in the nominal depth,
∆h, and the nominal width, ∆b, are described by a Normal
distribution with mean of 1.524 mm and standard deviation
of 6.35 mm. Concrete cover is also a random variable, and
the deviation in the nominal value, ∆c, has mean
 μ∆c = 6.35 + 0.004h (27)
and standard deviation equal to 4.22 mm.
Model error
The “model error”, η, is assumed as a Normal random
variable, with parameters μ = 0.95 and COV = 0.0698 (refer
to the section “Deflection equation for GFRP-RC beams”).
Loads
Table 1 presents information (ratio of mean to unfactored
nominal load, coefficient of variation, and type of distribu-
tion) on the random variables: 1) dead load, DL; 2) live load
at the ultimate limit state (Galambos et al. 1982); LL(ULS),
and 3) live load at service, LL(SLS), for an 8-year reference
period (Galambos and Ellingwood 1986). It is assumed that
only dead and live loads act on the FRP-RC beam. In a reli-
ability analysis for the limit state of excessive deflections,
the corresponding mean values of dead loads and live loads
at service must be defined for each beam.
The design flexural capacity of the beam, Md = ϕMn, is
assumed as identical to the FRP-RC beam flexural demand,
Mu. The design moment is computed by
 ϕMn = γD MDn + γLMLn (28)
where γD is the dead load factor, equal to 1.2; MDn is the
nominal moment due to dead load; γL is the live load factor,
equal to 1.6; and MLn is the nominal moment due to live load.
For simply supported beams subjected to uniformly distrib-
uted nominal dead and live loads (Dn and Ln, respectively),
then
 φ γ γM
D L
n D
n
L
n= +
 
2 2
8 8
 (29)
According to the load statistics in Table 1 for the ratio of
mean to unfactored nominal load, μU/Un at the ultimate limit
states, it is obtained
 Dn
DL=
µ
1 05.
 (30)
 Ln
LL ULS=
µ ( )
.1 00
 (31)
where μDL and μLL(ULS) are the means of the random vari-
ables dead load, DL, and live load, at the ultimate limit state,
LL(ULS), respectively. It follows that
 φ γ
µ
γ µMn D
DL
L LL ULS= +




2
8 1 05.
( )
 (32)
In terms of the load ratio, r = μDL/μLL(ULS), Eq. (32) can be
rewritten as
 φ µ γ γM r
n LL ULS D L= +


( )

2
8 1 05.
 (33)
Thus, resulting for the mean live load at the ultimate limit
state
 µ
γ γ
LL ULS
d
D L
M
r( )
.
=
+



8
1 05
2

 (34)
The mean live load at service, μLL(SLS), is calculated
from the data in Table 1 for the serviceability limit state,
μLL(SLS) = 0.65μLL(ULS).
This procedure is used in the calculation of the mean dead
load and mean live load at service for each of the 81 repre-
sentative beams. These results are summarized in Table 2,
which presents design moment Md, mean dead load μDL,
mean live load at ultimate limit state μLL(ULS), and mean live
load at service μLL(SLS), for R5, R1, and R2 beams (r = 0.5,
1.0, and 2.0, respectively).
192 ACI Structural Journal/May 2020
Statistical description of deflections of GFRP-RC
beams
Monte Carlo simulation was used to obtain the statis-
tics of total deflections, ∆total, for each of the 81 GFRP-RC
beams designed according to ACI 440 provisions. To this
end: 1) the deterministic procedure presented in Fig. 2; and
2) generation of random numbers consistent with the statis-
tics summarized in Tables 1 and 2 are required. For each
GFRP-RC beam, a sample of 100,000 total deflections, ∆total,
wasgenerated. This computational procedure was imple-
mented using the Matlab software, version 7.0.1 (and Statis-
tics toolbox). The main steps in the Monte Carlo simulation
are shown in the flowchart displayed in Fig. 3.
The statistics of the total deflections (minimum, mean,
and maximum) corresponding to the 81 GFRP-RC beams
are presented in Tables 3, 4, and 5 for load ratios 0.5, 1.0,
and 2.0, respectively. These tables also display the nominal
value of the total deflection computed according to ACI
440.1R (ACI Committee 440 2006), ∆total,ACI, and the ratio
μMSC/∆total,ACI (μMSC is the mean total deflection obtained via
Monte Carlo simulation). From these results, it is seen that, as
expected, total deflections (immediate plus long-term deflec-
tions) increase as the load ratio increases—that is, as more
sustained loads act on the beam. For instance, the mean total
deflections for Beams C30-P3-R5-OR, C30-P3-R1-OR, and
C30-P3-R2-OR, are 0.0081, 0.0116, and 0.0164 m, respec-
tively. Most importantly, it is seen that most over-reinforced
beams—which correspond to the desirable failure mode for
FRP-RC beams—present larger deflections as compared to
under-reinforced and transition zone beams. This results
from the fact that comparatively more loads are allowed in
over-reinforced beams due to larger strength-reduction
factors for such beams; refer to Eq. (6a) through (6c).
From Tables 3 through 5, it is seen that the ratios
μMSC/∆total,ACI are in the range of 0.99 to 1.34, 1.01 to 1.28,
and 1.03 to 1.26 for r = 0.5, 1.0, and 2.0, respectively.
Considering that in most cases these ratios are larger than
the unit, it can be concluded that there is a trend for the mean
Table 2—Design moment Md, mean dead load μDL, mean live load at ultimate state μLL(ULS), and mean live
load at service μLL(SLS) of GFRP-RC beams
Beam Md, kN·m
R5 R1 R2
μDL, kN μLL(ULS), kN μLL(SLS), kN μDL, kN μLL(ULS), kN μLL(SLS), kN μDL, kN μLL(ULS) , kN μLL(SLS), kN
C30-P1-R*-UR 17.52 3.59 7.17 4.66 5.68 5.68 3.69 8.02 4.01 2.61
C30-P1-R*-TR 28.84 5.90 11.81 7.67 9.35 9.35 6.08 13.19 6.60 4.29
C30-P1-R*-OR 42.26 8.65 17.30 11.24 13.70 13.70 8.90 19.33 9.67 6.28
C30-P2-R*-UR 18.37 3.76 7.52 4.89 5.95 5.95 3.87 8.40 4.20 2.73
C30-P2-R*-TR 24.48 5.01 10.02 6.51 7.93 7.93 5.16 11.20 5.60 3.64
C30-P2-R*-OR 29.94 6.13 12.25 7.97 9.70 9.70 6.31 13.70 6.85 4.45
C30-P3-R*-UR 16.51 3.38 6.76 4.39 5.35 5.35 3.48 7.55 3.78 2.46
C30-P3-R*-TR 20.61 4.22 8.44 5.48 6.68 6.68 4.34 9.43 4.71 3.06
C30-P3-R*-OR 25.72 5.27 10.53 6.84 8.34 8.34 5.42 11.77 5.88 3.82
C50-P1-R*-UR 24.84 4.88 9.76 6.34 7.73 7.73 5.02 10.91 5.45 3.54
C50-P1-R*-TR 40.97 8.38 16.77 10.90 13.28 13.28 8.63 18.74 9.37 6.09
C50-P1-R*-OR 58.88 12.05 24.10 15.67 19.08 19.08 12.40 26.94 13.47 8.76
C50-P2-R*-UR 24.85 5.09 10.17 6.61 8.05 8.05 5.24 11.37 5.69 3.70
C50-P2-R*-TR 32.16 6.58 13.17 8.56 10.42 10.42 6.77 14.71 7.36 4.78
C50-P2-R*-OR 41.27 8.45 16.89 10.98 13.37 13.37 8.69 18.88 9.44 6.14
C50-P3-R*-UR 20.89 4.28 8.55 5.56 6.77 6.77 4.40 9.56 4.78 3.11
C50-P3-R*-TR 28.24 5.78 11.56 7.51 9.15 9.15 5.95 12.92 6.46 4.20
C50-P3-R*-OR 35.36 7.24 14.47 9.41 11.46 11.46 7.45 16.18 8.09 5.26
C70-P1-R*-UR 38.99 7.98 15.96 10.37 12.64 12.64 8.21 17.84 8.92 5.80
C70-P1-R*-TR 54.82 11.22 22.44 14.59 17.76 17.76 11.55 25.08 12.54 8.15
C70-P1-R*-OR 75.75 15.50 31.01 20.16 24.55 24.55 15.96 34.66 17.33 11.26
C70-P2-R*-UR 32.20 6.59 13.18 8.57 10.44 10.44 6.78 14.73 7.37 4.79
C70-P2-R*-TR 42.99 8.80 17.60 11.44 13.93 13.93 9.06 19.67 9.84 6.39
C70-P2-R*-OR 57.76 11.82 23.64 15.37 18.72 18.72 12.17 26.43 13.21 8.59
C70-P3-R*-UR 28.40 5.81 11.63 7.56 9.20 9.20 5.98 13.00 6.50 4.22
C70-P3-R*-TR 37.74 7.72 15.45 10.04 12.23 12.23 7.95 17.27 8.63 5.61
C70-P3-R*-OR 46.12 9.44 18.88 12.27 14.95 14.95 9.71 21.10 10.55 6.86
193ACI Structural Journal/May 2020
total deflection to be larger than those predicted by ACI
440.1R (ACI Committee 440 2006) procedures. The level
of conservatism in the computation of the total deflection
∆total,ACI is approximately the same for all values of the load
ratio r considered in this study.
Figures 4 through 6 show histograms of deflections for
some analyzed beams. As a reference, the attendant allowable
deflection, δa, is indicated in each histogram; δa is assumed as
deterministic and equal to ℓ/240. Considering that the main
goal in this study is the assessment of reliability levels corre-
sponding to the limit state of excessive deflections, distribu-
tion fitting of the generated samples was not pursued.
RELIABILITY ANALYSIS OF SERVICEABILITY OF
GFRP-RC BEAMS
In this study, the performance function represented by
the margin of safety, g(X) = δa – ∆total, Eq. (4), is used in a
Monte Carlo simulation procedure for the reliability assess-
ment of 81 GFRP-RC beams with respect to the limit state
of excessive deflections. With the samples of the random
variable “total deflection”, ∆total, generated according to the
procedure previously described and an assumed determin-
istic “allowable deflection”, the probabilities of underperfor-
mance (probabilities of failure) can be easily obtained.
Figures 7 through 9 show the histograms of the margin of
safety, g(X), for selected beams. As a reference, the line corre-
sponding to the limit state condition—that is, g(X) = 0, is drawn
in each histogram; the larger the area of the histogram in the
g(X)0.0006 0.0071 0.0457 0.0066 1.0773
C30-P3-R*-OR 0.0013 0.0116 0.0519 0.0112 1.0368
C50-P1-R*-UR 0.0006 0.0060 0.0296 0.0056 1.0708
C50-P1-R*-TR 0.0038 0.0149 0.0385 0.0146 1.0211
C50-P1-R*-OR 0.0065 0.0152 0.0338 0.0147 1.0315
C50-P2-R*-UR 0.0006 0.0065 0.0382 0.0059 1.0953
C50-P2-R*-TR 0.0015 0.0119 0.0469 0.0113 1.0466
C50-P2-R*-OR 0.0033 0.0171 0.0502 0.0168 1.0238
C50-P3-R*-UR 0.0003 0.0036 0.0335 0.0031 1.1493
C50-P3-R*-TR 0.0009 0.0087 0.0496 0.0080 1.0881
C50-P3-R*-OR 0.0018 0.0139 0.0555 0.0133 1.0451
C70-P1-R*-UR 0.0023 0.0125 0.0364 0.0114 1.0914
C70-P1-R*-TR 0.0056 0.0171 0.0400 0.0162 1.0533
C70-P1-R*-OR 0.0077 0.0167 0.0362 0.0159 1.0494
C70-P2-R*-UR 0.0010 0.0094 0.0435 0.0078 1.2005
C70-P2-R*-TR 0.0027 0.0162 0.0507 0.0146 1.1051
C70-P2-R*-OR 0.0057 0.0202 0.0499 0.0191 1.0580
C70-P3-R*-UR 0.0006 0.0066 0.0448 0.0051 1.2837
C70-P3-R*-TR 0.0016 0.0133 0.0568 0.0113 1.1740
C70-P3-R*-OR 0.0029 0.0184 0.0602 0.0166 1.1098
Table 5—Statistics of total deflection (r = 2.0)
Beam
R2
∆total, m ∆total, ACI,
m
μMCS/
∆total,ACIMinimum Mean Maximum
C30-P1-R*-UR 0.0010 0.0073 0.0281 0.0070 1.0556
C30-P1-R*-TR 0.0048 0.0166 0.0374 0.0162 1.0273
C30-P1-R*-OR 0.0075 0.0168 0.0326 0.0162 1.0384
C30-P2-R*-UR 0.0010 0.0081 0.0360 0.0075 1.0732
C30-P2-R*-TR 0.0027 0.0152 0.0460 0.0147 1.0378
C30-P2-R*-OR 0.0047 0.0197 0.0484 0.0191 1.0287
C30-P3-R*-UR 0.0006 0.0056 0.0333 0.0051 1.1030
C30-P3-R*-TR 0.0013 0.0106 0.0461 0.0099 1.0700
C30-P3-R*-OR 0.0027 0.0164 0.0526 0.0157 1.0409
C50-P1-R*-UR 0.0014 0.0086 0.0300 0.0081 1.0687
C50-P1-R*-TR 0.0066 0.0185 0.0391 0.0178 1.0364
C50-P1-R*-OR 0.0082 0.0179 0.0347 0.0172 1.0431
C50-P2-R*-UR 0.0014 0.0095 0.0387 0.0088 1.0878
C50-P2-R*-TR 0.0032 0.0163 0.0476 0.0155 1.0518
C50-P2-R*-OR 0.0063 0.0220 0.0510 0.0212 1.0375
C50-P3-R*-UR 0.0006 0.0056 0.0326 0.0049 1.1330
C50-P3-R*-TR 0.0019 0.0127 0.0502 0.0118 1.0820
C50-P3-R*-OR 0.0038 0.0192 0.0563 0.0183 1.0504
C70-P1-R*-UR 0.0044 0.0160 0.0370 0.0147 1.0917
C70-P1-R*-TR 0.0087 0.0205 0.0407 0.0193 1.0613
C70-P1-R*-OR 0.0092 0.0195 0.0371 0.0184 1.0580
C70-P2-R*-UR 0.0021 0.0133 0.0441 0.0113 1.1827
C70-P2-R*-TR 0.0052 0.0211 0.0515 0.0192 1.1026
C70-P2-R*-OR 0.0094 0.0247 0.0507 0.0232 1.0651
C70-P3-R*-UR 0.0012 0.0098 0.0442 0.0078 1.2587
C70-P3-R*-TR 0.0033 0.0186 0.0576 0.0161 1.1597
C70-P3-R*-OR 0.0057 0.0243 0.0611 0.0220 1.1064
Fig. 4—Histogram of deflections: C30-P3-R5-UR beam. Fig. 5—Histogram of deflections: C50-P3-R1-TR beam.
195ACI Structural Journal/May 2020
adjusting a probability distribution to the data represented by
the histogram of the margin of safety can be bypassed.
Table 6 exhibits the probabilities of failure, Pf, obtained
in this study and the corresponding reliability indexes, β,
for each of the 81 GFRP-RC beams. It can be seen that all
parameters (load ratio, GFRP strength, concrete compres-
sive strength, and failure mode) have a considerable impact
on the resulting reliability levels. These results indicate a
wide range of values for the reliability index, β, from posi-
tive up to negative ones: 2.54 up to –0.40 (with r = 0.5);
2.44 up to –1.91 (r =1.0); and 2.08 up to –3.14 (r = 2.0).
It is reminded that a negative value of β corresponds to Pf
in excess of 0.5. All other parameters remaining constant,
beams with a larger load ratio—that is, more sustained
loading—present a smaller reliability index (and larger Pf).
For instance, comparing Beams C30-P1-R5-UR, C30-P1-
R1-UR, and C30-P1-R2-UR, it is observed that β is equal to
2.37, 2.18, and 1.67, respectively.
Regarding the effect of the GFRP strength, all other param-
eters remaining the same, β is the largest for beams with
the highest GFRP strength considered in this research—that
is, Beams P3. For instance, for Beams C30-P1-R5-OR and
C30-P3-R5-OR, the reliability indexes are 0.40 and 1.03,
respectively. Furthermore, it is observed that β decreases as
the concrete compressive strength increases. For example,
for Beams C30-P3-R5-OR, C50-P3-R5-OR, and C70-P3-
R5-OR, the reliability indexes are 1.03, 0.70, and 0.04,
respectively. With respect to the failure mode, as represented
by under-reinforced, transition zone, and over-reinforced
beams, β is the largest for under-reinforced beams and the
smallest for over-reinforced ones. For example, for Beams
C30-P1-R5-UR, C30-P1-R5-TR, and C30-P1-R5-OR, the
reliability indexes are 2.38, 0.74, and 0.40, respectively.
DISCUSSION OF RESULTS
For further analyses of the reliability levels obtained
in this study for the limit state of excessive deflections of
GFRP-RC beams, a target reliability index, βtarget, equal to
1.5, as suggested by Galambos and Ellingwood (1986) for
the serviceability limit state, is considered. This target reli-
ability corresponds to floor beams under occupancy load
for an 8-year reference period and is consistent with the
analysis performed in this research. For this target value,
it is observed that out of the 81 representative beams, the
target is met in only 19 beams, none of them being over-
reinforced (refer to Table 6). Additionally, only two of the
C70 grade GFRP-RC beams (out of 27), display a reliability
index above the chosen target value.
Larger strength-reduction factors, ϕ, for over-reinforced
beams, as recommended by ACI 440 (2015), result in
comparatively more loads acting on such beams. Submitting
that the larger ϕ factors for over-reinforced beams are one of
Fig. 6—Histogram of deflections: C70-P2-R2-OR beam.
Fig. 7—Histogram of margin of safety: C30-P1-R2-OR beam.
Fig. 8—Histogram of margin of safety: C50-P3-R5-UR beam.
Fig. 9—Histogram of margin of safety: C70-P1-R1-TR beam.
196 ACI Structural Journal/May 2020
the reasons for larger deflections in such beams, the use of
a constant ϕ factor equal to 0.55 in the design process was
investigated. The corresponding results are shown in Table 7. It
is observed that, as expected, there is an improvement in the
reliability levels. For example, for Beam C30-P3-R5-OR,
β = 1.03 when ϕ = 0.65 (refer to Table 6) while β = 1.80
for ϕ = 0.55 (refer to Table 7). However, only 22 of the 81
GFRP-RC beams present reliability indexes that meet the
target value and two beams are over-reinforced.
In an attempt to further improve the reliability levels for
the limit state of excessive deflections, the use of a smaller
factor is also investigated. From the results in Table 8 for
ϕ = 0.50, it is observed that there is a significant improve-
ment in the reliability levels and βtarget is met in 37 out of
the 81 GFRP-RC beams, six of them being over-reinforced.
For a variable ϕ factor (Eq. (6)), ϕ = 0.55, and ϕ = 0.50,
C50-P3-R1-OR beam have reliability indexes –0.11, 1.00,
and 1.57, respectively. For ϕ = 0.50, five of the high-strength
concrete GFRP-RC beams (C70 grade) display a reliability
index above βtarget.
Based on these results, it is observed that the smaller the
strength reduction factor, the greater the improvement in
the reliability index and the implicit reliability levels for the
limit state of excessive deflections. From the results shown
in Table 8, it is seen that in general terms, βtarget can be satis-
fied on the condition of using GFRP’s of higher strengths
(and consequently higher Young’s modulus) and avoiding
higher concrete compressive strengths. Furthermore, it must
be emphasized that the adequacy, or not, of the implicit reli-
ability levels are highly dependent on the selected target
value, a condition for which no consensus exists to date.
SUMMARY AND CONCLUSIONS
In this research, the reliability of GFRP-RC beams
designed according to ACI 440 (2015), with respect to the
limit state of excessive deflections, was assessed. To this end,
Table 6—Probabilities of failure (and reliability
indexes), limit state of excessive deflections
Beam
R5 R1 R2
Pf β Pf β Pf β
C30-P1-R*-UR 0.0088 2.3756 0.0145 2.1832 0.0471 1.6741
C30-P1-R*-TR 0.2307 0.7366 0.5267 –0.06690.8844 –1.1972
C30-P1-R*-OR 0.3445 0.4002 0.7027 –0.5321 0.9527 –1.6717
C30-P2-R*-UR 0.0159 2.1464 0.0289 1.8968 0.0974 1.2968
C30-P2-R*-TR 0.1280 1.1360 0.3082 0.5011 0.7001 –0.5247
C30-P2-R*-OR 0.3232 0.4587 0.6693 –0.4379 0.9474 –1.6202
C30-P3-R*-UR 0.0057 2.5296 0.0080 2.4103 0.0211 2.0311
C30-P3-R*-TR 0.0390 1.7629 0.0845 1.3752 0.2764 0.5937
C30-P3-R*-OR 0.1516 1.0297 0.3590 0.3612 0.7566 –0.6955
C50-P1-R*-UR 0.0159 2.1462 0.0299 1.8824 0.1041 1.2586
C50-P1-R*-TR 0.3645 0.3463 0.7278 –0.6061 0.9648 –1.8093
C50-P1-R*-OR 0.4736 0.0662 0.8310 –0.9580 0.9832 –2.1246
C50-P2-R*-UR 0.0265 1.9348 0.0542 1.6058 0.1853 0.8952
C50-P2-R*-TR 0.1597 0.9956 0.3799 0.3059 0.7810 –0.7754
C50-P2-R*-OR 0.4638 0.0908 0.8253 –0.9359 0.9854 –2.1794
C50-P3-R*-UR 0.0054 2.5484 0.0072 2.4471 0.0188 2.0788
C50-P3-R*-TR 0.0681 1.4900 0.1577 1.0041 0.4629 0.0932
C50-P3-R*-OR 0.2435 0.6951 0.5427 –0.1073 0.8974 –1.2666
C70-P1-R*-UR 0.1911 0.8737 0.4538 0.1161 0.8407 –0.9972
C70-P1-R*-TR 0.5964 –0.2441 0.9155 –1.3757 0.9951 –2.5814
C70-P1-R*-OR 0.6565 –0.4029 0.9368 –1.5282 0.9962 –2.6711
C70-P2-R*-UR 0.0803 1.4029 0.1912 0.8736 0.5319 –0.0801
C70-P2-R*-TR 0.3846 0.2933 0.7485 –0.6698 0.9706 –1.8901
C70-P2-R*-OR 0.7461 –0.6624 0.9719 –1.9093 0.9992 –3.1382
C70-P3-R*-UR 0.0306 1.8715 0.0632 1.5285 0.2156 0.7871
C70-P3-R*-TR 0.2138 0.7933 0.4894 0.0265 0.8648 –1.1020
C70-P3-R*-OR 0.4832 0.0421 0.8414 –1.0004 0.9876 –2.2445
Table 7—Probabilities of failure (and reliability
indexes), limit state of excessive deflections (φφ = 0.55)
ϕ= 0.55
Beam
R5 R1 R2
Pf β Pf β Pf β
C30-P1-R*-UR 0.0088 2.3756 0.0145 2.1832 0.0471 1.6741
C30-P1-R*-TR 0.2008 0.8386 0.4719 0.0705 0.8499 –1.0360
C30-P1-R*-OR 0.1126 1.2129 0.2908 0.5512 0.6778 –0.4615
C30-P2-R*-UR 0.0159 2.1464 0.0289 1.8968 0.0974 1.2968
C30-P2-R*-TR 0.0757 1.4346 0.1804 0.9139 0.5063 –0.0157
C30-P2-R*-OR 0.1012 1.2747 0.2451 0.6901 0.6208 –0.3075
C30-P3-R*-UR 0.0057 2.5296 0.0080 2.4103 0.0211 2.0311
C30-P3-R*-TR 0.0198 2.0575 0.0378 1.7766 0.1289 1.1317
C30-P3-R*-OR 0.0367 1.7908 0.0791 1.4114 0.2644 0.6297
C50-P1-R*-UR 0.0159 2.1462 0.0299 1.8824 0.1041 1.2586
C50-P1-R*-TR 0.2990 0.5274 0.6424 –0.3650 0.9392 –1.5480
C50-P1-R*-OR 0.1823 0.9066 0.4452 0.1379 0.8246 –0.9332
C50-P2-R*-UR 0.0265 1.9348 0.0542 1.6058 0.1853 0.8952
C50-P2-R*-TR 0.1183 1.1837 0.2845 0.5694 0.6772 –0.4597
C50-P2-R*-OR 0.1709 0.9505 0.4072 0.2347 0.8075 –0.8687
C50-P3-R*-UR 0.0054 2.5485 0.0072 2.4471 0.0188 2.0788
C50-P3-R*-TR 0.0366 1.7917 0.0789 1.4125 0.2610 0.6402
C50-P3-R*-OR 0.0677 1.4934 0.1582 1.0018 0.4673 0.0820
C70-P1-R*-UR 0.1911 0.8737 0.4538 0.1161 0.8407 –0.9972
C70-P1-R*-TR 0.5143 –0.0359 0.8660 –1.1076 0.9900 –2.3248
C70-P1-R*-OR 0.3155 0.4802 0.6665 –0.4304 0.9384 –1.5411
C70-P2-R*-UR 0.0803 1.4029 0.1912 0.8736 0.5319 –0.0801
C70-P2-R*-TR 0.3023 0.5178 0.6420 –0.3637 0.9400 –1.5544
C70-P2-R*-OR 0.3909 0.2770 0.7588 –0.7025 0.9729 –1.9251
C70-P3-R*-UR 0.0306 1.8715 0.0632 1.5285 0.2156 0.7871
C70-P3-R*-TR 0.1267 1.1421 0.3039 0.5133 0.7014 –0.5284
C70-P3-R*-OR 0.1818 0.9084 0.4273 0.1834 0.8238 –0.9301
197ACI Structural Journal/May 2020
samples of deflections of the selected beams were generated
by Monte Carlo simulation, and the corresponding probabil-
ities of excessive deflections were obtained.
Based on the results of the research presented herein, the
following conclusions can be drawn:
• A comparison of the nominal value of the total deflec-
tion computed according to ACI 440 (2006) recommen-
dations, ∆total,ACI, and the mean total deflection obtained
via Monte Carlo simulation, μMSC, indicates that there
is a trend for the mean total deflection to be larger than
those predicted by ACI 440 procedures;
• The reliability levels associated to the limit state of
excessive deflections indicate a wide range of values for
the reliability indexes, β, from positive up to negative
ones;
• The load ratio has a great influence on the implicit
reliability levels; all other parameters remaining
constant, the higher the load ratio μDL/μLL (that is, more
sustained loading), the smaller the reliability index, and,
consequently, the larger the probability of excessive
deflections;
• Over-reinforced beams present larger deflections—and,
consequently, smaller reliability indexes—as compared
to under-reinforced and transition zone beams;
• The highest probabilities of failure (exceeding 0.5), are
found for high-strength concrete GFRP-RC beams (C70
grade);
• For a target reliability index, βtarget, equal to 1.5 (as
suggested by Galambos and Ellingwood 1986), only 19
GFRP-RC beams present reliability indexes that meet
this target value, none of them being over-reinforced;
• Only two of the C70 grade GFRP-RC beams, out of the
27, displays a reliability index above the selected target
value. Therefore, caution should be exercized in the use
of higher concrete strengths in GFRP-RC beams;
• The use of a constant and smaller strength-reduction
factor (ϕ = 0.50) lead to a significant improvement in
the resulting reliability levels for GFRP-RC beams, and
particularly for C50 beams paired with higher GFRP
strengths (P2 and P3). This could be a simple alterna-
tive for designing GFRP-RC beams for both safety and
serviceability.
The reliability results with respect to the limit state of
excessive deflections reported in this research have been
obtained for FRP-RC beams designed according to ACI
440 recommendations. The procedures presented herein
can be easily extended to the assessment of the implicit reli-
ability levels in design recommendations for FRP-RC beams
other than ACI 440. Moreover, it must be emphasized that
the results obtained—and their interpretation—were made
under a number of assumptions such as allowable deflection
limit, load ratio, reference period, and target reliability level.
Particularly, no consensus exist on the target reliability (and
attendant issues such as reference periods) for the service-
ability limit state of excessive deflections and more research
is needed on this subject.
AUTHOR BIOS
Elayne M. Silva is a PhD Candidate in the Civil Engineering Department
of the Federal Center of Technological Education of Minas Gerais, Belo
Horizonte, Brazil.
Sidnea E. C. Ribeiro is an Associate Professor in the Department of Mate-
rials and Construction at Federal University of Minas Gerais.
Sofia M. C. Diniz, FACI, is a Professor of structural engineering in the
Department of Structural Engineering at the Federal University of Minas
Gerais. She is past Chair and current member of ACI Committee 348,
Structural Reliability and Safety.
ACKNOWLEDGMENTS
The financial support provided by the Brazilian agencies CAPES (Coor-
denação de Aperfeiçoamento de Pessoal de Nível Superior) and CNPq
(Conselho Nacional de Desenvolvimento Científico e Tecnológico) is grate-
fully acknowledged.
REFERENCES
ACI Committee 222, 2011, “Guide to Design and Construction Prac-
tices to Mitigate Corrosion of Reinforcement in Concrete Structures (ACI
222.3R-11),” American Concrete Institute, Farmington Hills, MI, 32 pp.
Table 8—Probabilities of failure (and reliability
indexes), limit state of excessive deflections (φφ = 0.50)
ϕ= 0.50
Beam
R5 R1 R2
Pf β Pf β Pf β
C30-P1-R*-UR 0.0028 2.7750 0.0035 2.6968 0.0086 2.3833
C30-P1-R*-TR 0.0976 1.2955 0.2421 0.6995 0.6172 –0.2982
C30-P1-R*-OR 0.0506 1.6388 0.1290 1.1312 0.4048 0.2409
C30-P2-R*-UR 0.0057 2.5302 0.0079 2.4121 0.0216 2.0212
C30-P2-R*-TR 0.0318 1.8553 0.0678 1.4925 0.2313 0.7347
C30-P2-R*-OR 0.0441 1.7051 0.1002 1.2805 0.3288 0.4433
C30-P3-R*-UR 0.0016 2.9557 0.0017 2.9218 0.0033 2.7144
C30-P3-R*-TR 0.0073 2.4422 0.0107 2.3001 0.0315 1.8593
C30-P3-R*-OR 0.0143 2.1901 0.0255 1.9510 0.0849 1.3727
C50-P1-R*-UR 0.0056 2.5370 0.0083 2.3972 0.0236 1.9849
C50-P1-R*-TR 0.1593 0.9975 0.3888 0.2824 0.7900 –0.8063
C50-P1-R*-OR 0.0872 1.3581 0.2284 0.7440 0.5930 –0.2353
C50-P2-R*-UR 0.0099 2.3313 0.0163 2.1367 0.0516 1.6299C50-P2-R*-TR 0.0527 1.6194 0.1204 1.1730 0.3811 0.3027
C50-P2-R*-OR 0.0803 1.4033 0.1944 0.8619 0.5407 –0.1021
C50-P3-R*-UR 0.0014 2.9933 0.0016 2.9517 0.0029 2.7646
C50-P3-R*-TR 0.0143 2.1884 0.0249 1.9612 0.0826 1.3881
C50-P3-R*-OR 0.0279 1.9123 0.0579 1.5731 0.1986 0.8467
C70-P1-R*-UR 0.0918 1.3298 0.2276 0.7468 0.5979 –0.2480
C70-P1-R*-TR 0.3176 0.4744 0.6701 –0.4401 0.9475 –1.6206
C70-P1-R*-OR 0.1732 0.9416 0.4282 0.1809 0.8088 –0.8735
C70-P2-R*-UR 0.0340 1.8249 0.0726 1.4567 0.2464 0.6858
C70-P2-R*-TR 0.1604 0.9929 0.3844 0.2939 0.7869 –0.7957
C70-P2-R*-OR 0.2223 0.7645 0.5147 –0.0369 0.8811 –1.1805
C70-P3-R*-UR 0.0117 2.2662 0.0196 2.0629 0.0622 1.5366
C70-P3-R*-TR 0.0569 1.5818 0.1310 1.1217 0.4059 0.2381
C70-P3-R*-OR 0.0865 1.3626 0.2071 0.8164 0.5638 –0.1606
198 ACI Structural Journal/May 2020
ACI Committee 318, 2014, “Building Code Requirements for Struc-
tural Concrete (ACI 318-14) and Commentary (ACI 318R-14),” American
Concrete Institute, Farmington Hills, MI, 520 pp.
ACI Committee 440, 2006, “Guide for the Design and Construction of
Structural Concrete Reinforced with FRP Bars (ACI 440.1R-06),” Amer-
ican Concrete Institute, Farmington Hills, MI, 44 pp.
ACI Committee 440, 2015, “Guide for the Design and Construction of
Structural Concrete Reinforced with FRP Bars (ACI 440.1R-15),” Amer-
ican Concrete Institute, Farmington Hills, MI, 88 pp.
Ang, A. H., and Tang, W. H., 1984, Probability Concepts in Engineering
Planning and Design—Decision, Risk and Reliability, V. II, John Wiley &
Sons, Inc., New York.
Azevedo, C. P. B., and Diniz, S. M. C., 2008, “Estudo Probabilístico
da Resistência à Compressão de Concretos Utilizados em Fundações,” 50º
Congresso Brasileiro do Concreto, Salvador, Brazil. (in Portuguese)
Bischoff, P. H., and Gross, S. P., 2011, “Design Approach for Calcu-
lating Deflection of FRP-Reinforced Concrete,” Journal of Composites
for Construction, ASCE, V. 15, No. 4, pp. 490-499. doi: 10.1061/(ASCE)
CC.1943-5614.0000195
Branson, D. E., 1965, “Instantaneous and Time-Dependent Deflections
of Simple and Continuous Reinforced Concrete Beams,” HPR Report
No. 7, Part 1, Alabama Highway Department, Bureau of Public Roads,
Montgomery, AL.
Comite Europeen de Normalisation (CEN), 2004, “Eurocode 2: Design
of Concrete Structures - Part 1-1: General Rules and Rules for Buildings,”
Brussels, Belgium.
Couto, R. A., and Diniz, S. M. C., 2018, “Probabilistic Evaluation of
Service-Life of RC Structures Subjected to Carbonation,” Sixth Interna-
tional Symposium on Life-Cycle Civil Engineering (IALCCE 2018),
Ghent, Belgium, pp. 1293-1300.
Diniz, S. M. C., 2008, “Structural Reliability: Rational Tools for Design
Code Development,” ASCE Structures Congress, Vancouver, BC, Canada.
Diniz, S. M. C., and Frangopol, D. M., 1997, “Reliability Bases for
High-Strength Concrete Columns,” Journal of Structural Engineering,
ASCE, V. 123, No. 10.
fib, 2007, “FRP Reinforcement in RC Structures,” Bulletin No. 40,
Federal Institute of Technology, Lausanne, Switzerland.
Galambos, T. V., and Ellingwood, B. R., 1986, “Serviceability Limit
States: Deflection,” Journal of Structural Engineering, ASCE, V. 112,
No. 1, pp. 67-84. doi: 10.1061/(ASCE)0733-9445(1986)112:1(67)
Galambos, T. V.; Ellingwood, B. R.; MacGregor, J. G.; and Cornell, C.
A., 1982, “Probability-Based Load Criteria: Assessment of Current Design
Practice,” Journal of the Structural Division, ASCE, V. 108, No. 5.
Gao, D.; Benmokrane, B.; and Masmoudi, R., 1998, “A Calculating
Method of Flexural Properties of FRP-Reinforced Concrete Beam: Part 1:
Crack Width and Deflection,” Technical Report, Department of Civil Engi-
neering, University of Sherbrooke, Sherbrooke, QC, Canada, 24 pp.
Ghosn, M.; Frangopol, D. M.; Mcallister, T. P.; Shah, M.; Diniz,
S. M. C.; Ellingwood, B. R.; Manuel, L.; Biondini, F.; Catbas, N.; Strauss,
A.; Zhao, X. L., 2016, “Reliability-Based Performance Indicators for Struc-
tural Members,” Journal of Structural Engineering, ASCE, V. 142, No. 9.
doi: 10.1061/(ASCE)ST.1943-541X.0001546
La Tegola, A., 1998, “Actions for Verification of RC Structures with
FRP Bars,” Journal of Composites for Construction, ASCE, V. 2, No. 3,
pp. 145-148. doi: 10.1061/(ASCE)1090-0268(1998)2:3(145)
Lorensini, R. V., and Diniz, S. M. C., 2010, “Probabilistic Modeling of
Service Life of Reinforced Concrete Structures under Corrosion,” Second
International Symposium on Life-Cycle Civil Engineering (IALCEE’10),
Life-Cycle of Civil Engineering Systems, Taipei, Taiwan.
Melchers, R. E., 1999, Structural Reliability Analysis and Prediction,
second edition, Wiley, New York.
Mota, C.; Alminar, S.; and Svecova, D., 2006, “Critical Review
of Deflection Formulas for FRP-RC Members,” Journal of Compos-
ites for Construction, ASCE, V. 10, No. 3, pp. 183-194. doi: 10.1061/
(ASCE)1090-0268(2006)10:3(183)
Mirza, S. A., and MacGregor, J. G., 1979, “Variations in Dimensions of
Reinforced Concrete Members,” Journal of the Structural Division, ASCE,
V. 105, No. 4, pp. 751-766.
Nanni, A., 1993, “Flexural Behavior and Design of Reinforced Concrete
Using FRP Rods,” Journal of Structural Engineering, ASCE, V. 119,
No. 11, pp. 3344-3359. doi: 10.1061/(ASCE)0733-9445(1993)119:11(3344)
Nawy, E., and Neuwerth, G., 1977, “Fiberglass Reinforced Concrete
Slabs and Beams,” Journal of the Structural Division, ASCE, V. 103,
pp. 421-440.
Nowak, A. S., and Collins, K. R., 2000, Reliability of Structures,
McGraw-Hill, New York.
Nowak, A. S., and Szerszen, M., 2003, “Calibration of Design Code
for Buildings (ACI 318): Part 1—Statistical Models for Resistance,” ACI
Structural Journal, V. 100, No. 3, May-June, pp. 377-382.
Peña, C. B., 2010, “Serviceability Behaviour of Fibre Reinforced
Polymer Reinforced Concrete Beams,” PhD thesis, University of Girona,
Girona, Spain.
Pilakoutas, K.; Neocleous, K.; and Guadagnini, M., 2002, “Design
Philosophy Issues of Fiber Reinforced Polymer Reinforced Concrete Struc-
tures,” Journal of Composites for Construction, ASCE, V. 6, No. 3,
pp. 154-161. doi: 10.1061/(ASCE)1090-0268(2002)6:3(154)
Ribeiro, S. E. C., and Diniz, S. M. C., 2013, “Reliability-Based Design
Recommendations for FRP-Reinforced Concrete Beams,” Engineering
Structures, V. 52, pp. 273-283. doi: 10.1016/j.engstruct.2013.02.026
Shield, C. K.; Galambos, T. V.; and Gulbrandsen, P., 2011, “On the
History and Reliability of the Flexural Strength of FRP Reinforced Concrete
Members in ACI 440.1R,” Fiber-Reinforced Polymer Reinforcement for
Concrete Structures, SP-275, R. Sen, R. Seracino, C. Shield, and W. Gold,
eds., American Concrete Institute, Farmington Hills, MI.
Silva, E. M., 2017, “Probabilistic Assessment of Serviceability of
FRP-Reinforced Concrete Beams,” MSc thesis, Federal University of
Minas Gerais, Belo Horizonte, Brazil.
Szerszen, M., and Nowak, A., 2003, “Calibration of Design Code for
Buildings (ACI 318): Part 2—Reliability Analysis and Resistance Factors,”
ACI Structural Journal, V. 100, No. 3, May-June, pp. 383-391.
Tighiouart, B.; Benmokrane, B.; and Mukhopadhyaya, P., 1999, “Bond
Strength of Glass FRP Rebar Splices in Beams Under Static Loading,”
Construction and Building Materials, V. 13, No. 7, pp. 383-392.
Yost, J. R.; Gross, S. P.; and Dinehart, D. W., 2003, “Effective Moment of
Inertia for Glass Fiber-Reinforced Polymer-Reinforced Concrete Beams,”
ACI Structural Journal, V. 100, No. 6, Nov.-Dec., pp. 732-739.
