OTN Tutorial
Steve Surek
Ciena Corporation
October 27-28, 2011
2
Agenda
 OTN Introduction
 OTN Overhead
 OTN and OTN Client Signal Fault Propagation
 OTN Performance Monitoring
 OTN Multiplexing and Mapping Trees
 OTN Client Mappings
 Other 5430 OTN Capabilities
1
2
3
4
5
6
7
OTN Introduction
4
Motivation for OTN - The Original DWDM Problem
NE NE
Vendor A
Domain
NE
Vendor B
Domain
Carrier A
Domain
NE
Carrier B
Domain Carrier C
Domain
NE
NE
Proprietary DWDM systems
Vendor interop
only at client level
Lack of end-to-end service management End Customer
End
Customer
NE
NE
5
Motivation for OTN - The OTN Solution
NE NE
Vendor A
Domain
NE
Vendor B
Domain
Carrier A
Domain
NE
Carrier B
Domain Carrier C
Domain
NE
NE
End
Customer
End
Customer
NE
NE
Intra-domain Interfaces (IaDI)
remain proprietary
Standarize
Inter-domain
 Interfaces (IrDI)
End-to-end service management
Standardized Inter-Domain
Interface
 Single and multiple
wavelength interfaces
with or w/o OSC
 Standard rates and
formats (2.5G, 10G, 40G,
100G interfaces)
 Standard forward error
correction (FEC)
 Multiplexing and
switching
Standardized Management
Capability
 Digital wrapper providing
standard management
functions for signal quality
monitoring, connection and
connectivity monitoring,
maintenance signal generation
and detection, etc.
 Standardized management of
optical layers and end-to-end
service transport

6
OTN Layers
OTS
OMS
OCh
OTU
ODU
Optical
(Analog)
Domain
Electrical
(Digital)
Domain
Physical Optical Layers
Standardized Optical Layer Model
Provides Inter-Domain Interworking
Client Transparency
Full-Wavelength OCh Switching
Wavelength Selective Bypass
Physical Electrical Layers
End-to-End Monitoring
 Inter-Domain Interworking
Client Transparency
Sub-Wavelength ODU Switching
High Efficiency Grooming
OPU
7
Three Architectural Options for OTN
Switched
G.709
(Digital OTN)
Static WDM
(Analog OTN)
Flexible
WDM
(Analog OTN)
Switched
G.709
(Digital OTN)
Dynamic
WDM
(Analog OTN)
Framed G.709
(Digital OTN)
A B C
 G.709 provides all
dynamic capabilities
 WDM for capacity only
 G.709 provides dynamic
switching
 WDM with reconfigurable
connections
 G.709 provides framing
only
 WDM for all dynamic
capabilities
8
OTN Layer Descriptions – Optical Layers
Optical Transmission Section (OTS)
 Physical optical signal consisting of multiplexed payload wavelengths plus an optical
supervisory channel wavelength
 Provides for optical amplification, dispersion compensation, and management overhead for the
physical optical transmission section
Optical Multiplex Section (OMS)
 Optical signal consisting of multiplexed payload wavelengths (each wavelength representing
an individual optical channel)
 Provides for optical amplification, dispersion compensation, and management overhead for the
physical optical multiplex section
 Provides multiplexing/demultiplexing of optical channels and management overhead for the
optical multiplex section
Optical Physical Section (OPS)
 Optical signal consisting of multiplexed payload wavelengths but with no optical supervisory
channel (each wavelength representing an individual optical channel)
 Provides for optical amplification and dispersion compensation for the optical physical section
 Provides multiplexing/demultiplexing of optical channels for the optical physical section
Optical Channel (OCh)
 Represents a single traffic signal (single wavelength), contains optical functions which allow
purely optical implementations and electrical functions some of which reside in the OTU frame
 Provides traffic signal generation and recovery (framing, scrambling, FEC, etc.) and
management overhead for the optical channel (electrical functions)
9
OTN Layer Descriptions – Digital Layers
Optical Channel Transport Unit (OTU)
 Provides the electrical functions to support the management of an optical channel section,
i.e., section monitor (section trail trace identifier, section error detection code (BIP-8),
defect indication functions, general communications channel)
 Provides for transport of the optical channel data unit
Optical Channel Data Unit (ODU)
 Provides the electrical functions to support the management of an optical channel data
path, i.e., path monitor (path trail trace identifier, path error detection code (BIP-8), defect
indication functions), general communications channel, and automatic protection switching
channel
 Provides the electrical functions to support the management of optical channel data tandem
connections, i.e., tandem connection monitors (tandem connection trail trace identifier,
tandem connection path error detection code (BIP-8), defect indication functions), and
automatic protection switching channel
 Provides for transport of the optical channel payload
Optical Channel Payload Unit (OPU)
 Supports the mapping of a variety of client signal types (GFP, constant bit-rate (SDH), etc.)
 Provides payload type defect detection
 Provides payload structure information and defect detection (supports ODU multiplexing)
10
OTN Frame Structure – Electrical Layers
ODUk OH
FA OH OTUk OH
OPUk Payload
(4 x 3808 bytes)
OTUk FEC
(4 x 256 bytes)
O
P
U
k
OH
1
2
3
4
1 7 8 14 15 16 17 3824 3825 4080
Column
Row
Overhead for Frame Alignment
Overhead for ODU Operations (Tandem Connection and Path)
Overhead for the OTU Operations (Section)
Overhead for Client Mappings
Payload for Client Signal
Forward Error Correction
Supports Forward Error Correction (FEC) for reach extension
Supports section, tandem connection and end-to-end path monitoring (Fault & PM)
Supports transparent client mapping and transport (data & timing)
11
OTN Layers – End-to-End
OMS Link 1
OCH/OTU
Link 1
ODU SNC
OCH/OTU
Link 2
OMS Link 2
Node 2 Node 3 Node 4Node 1
Client Port
SONET/SDH
Ethernet
Fibre Channel
OTS Link 1 OTS Link 2 OTS Link 3
3R
ODU SNC
Client Service
OMS Link 1
OCH/OTU Link 1
ODU Path from
Source to Destination
(ODU termination)
Client Port
OCH/OTU Link 2
OMS Link 2
Integrated
WDM Optics SR Optics
ODU Switch ODU Switch OCH Switch
OTU Sections between
Regeneration Points
(OTU termination)
Transponder/
Regenerator
Optical
Amplifier
OTS Link 1
OTS Link 2
OMS Sections between
Optical Add/Drop Points
(OMS termination)
OTS Sections between
Optical Amplifier Points
(OSC termination)
12
OTM
Overhead
Signal
(OOS)
Optical Transport Module (OTM) - Interface
Optical Transmission Section (OTS)
Optical Multiplex Section (OMS)
OCC OCC OCC OCC
Optical Channel (OCh)
 OCh Transport Unit (OTU) Payload OTU OH FEC
 OCh Data Unit (ODU) Payload ODU OH
 OCh Payload Unit (OPU) Payload OPU OH
Client
OTS
OH
OMS
OH
OCC
OH
OCC
OH
OCh
OH
For Transmission
For Switching and Multiplexing
For Client Service Mapping
For Management
Optical Channel Carrier (OCC)
Analog
Digital
E/O and O/E Adaptation
13
Single Channel Interfaces – OTM-0.m
Reduced functionality interfaces (no OOS/OSC - OPS)
supporting various OTUk data rates
 OTM-0.m represents a single channel uncolored interface (m identifies the
supported data rates, e.g., m=234 identifies supporting 10G/40G/100G data
rates)
Domain A Domain Z
3R
3R
3R
…

3R
3R
3R
…

MPI-S
MPI-S
MPI-S
MPI-R
MPI-R
MPI-R
IrDI
λs
λs
λs
MPI-S=Single channel Main Path Interface Source
MPI-R=Single channel Main Path Interface Receive
14
Multi-Channel Interfaces – OTM-0.mvn, OTM-nr.m, OTM-n.m
Reduced functionality interfaces (no OOS/OSC - OPS) and full functionality
interfaces (include OOS/OSC – OTS/OMS) supportingvarious OTUk data rates
 OTM-0.mvn represents a parallel optical multi-lane interface (reduced functionality only, n = # of lanes)
 OTM-n[r].m represents a multi-wavelength interface with wavelengths on ITU grid (n = maximum number
of supported wavelengths)
 Wavelength multiplexing/demultiplexing and optional optical booster amplifiers or optical pre-amplifiers
Domain A Domain Z
MPI-Sm
MPI-Rm
IrDI 3R
3R
3R
…

3R
3R
3R
…

OM
OD
OA
OA
3R
3R
3R
…

3R
3R
3R
…
 OM
OD
OA
OA MPI-Rm
MPI-Sm
MPI-Sm=Multi-channel Main Path Interface Source
MPI-Rm=Multi-channel Main Path Interface Receive
15
OTN IrDI Application Codes
G.959.1 application code format: PnWx-ytz[s]
where
 P - (if present) indicates application code applies to any optical tributary signal
within the class
 n - defines the maximum number of optical tributary signals supported by the
application code
 W – indicates the span distance/attenuation supported by the application code
 x – maximum number of spans
 y – indicates the highest class (rate and format) of optical tributary signal
supported for the application code
 t – indicates power level assumptions (amplifier configurations) for the application
code
 z – indicates the source wavelength and fiber type
 s – optional, indicates additional restrictions for the application

Only single span application codes are currently defined in G.959.1

16
CWDM Application Codes
G.695 application code format: CnWx-ytz[F]
where
 C - (if present) indicates application code applies to any optical tributary signal
within the class
 n - defines the maximum number of optical tributary signals supported by the
application code
 W – indicates the span distance/attenuation supported by the application code
 x – maximum number of spans
 y – indicates the highest class (rate and format) of optical tributary signal
supported for the application code
 t – indicates power level assumptions (amplifier configurations) for the application
code
 z – indicates the source wavelength and fiber type
 F – optional, indicates the application requires FEC bytes be transmitted

Only single span application codes are currently defined in G.695

17
Intra-office Application Codes
G.693 application code format: W-yAz[F]
where
 W – indicates the span distance/attenuation supported by the application code
 y – indicates the highest class (rate and format) of optical tributary signal
supported for the application code
 A – indicates the attenuation category
 z – indicates the source wavelength and fiber type
 F – optional, indicates the application requires FEC bytes be transmitted



18
OTN Bitrates
ODU0
ODU1
ODU2
ODU3
ODU4
1.244
2.499
10.037
40.319
104.794
OTU1
OTU2
OTU3
OTU4
2.666
10.709
43.018
111.810
ODU1e OTU1e
ODU2e † OTU2e 10.400
10.356
11.096
11.049
OTU3e1
OTU3e2 44.583
44.569 ODU3e1
ODU3e2 41.786
41.773
All rates provided in Gbps and times in μs
OTU rate based on RS (255,239) FEC coding
Based on support for 100GE
(10 × OC192/STM64 × 239/227
OC768/STM256/40GE × 239/236
OC192/STM64 × 239/237
OC48/STM16 × 239/238
Based on support for GE
(1/2 of ODU1 payload)
10GE* × 239/238
10GE** × 239/237
Based on support for 4 x ODU2e (@1.25G TS)
(OC768/STM256 × 243/217 × 239/255)
G.709 Defined Rates
Non-Standard Supplemental Rates
* Transparent 10.3125 Gbps Bitstream
** Transparent 10.3125 Gbps Bitstream (Includes Fixed Stuff Bytes)
† ODU2e is included in G.709
× 255/239
Based on support for 4 x ODU2e (@2.5G TS)
(4 x ODU2e × 239/238)
48.971
12.191
3.035
1.168
11.767
11.816
2.928
2.929
98.354
Frame
Times
19
ODUFlex (2011 Update)
Flexible ODU rate for transport of arbitrary client rates to
improve ODUk bandwidth usage (transport efficiency)
Constant Bit Rate (CBR) client signals
ODUflex Rate = 239/238 x CBR rate with up to ± 100ppm clock tolerance
(synchronous to client clock)
For GFP-F mapped packet client signals
ODUflex Rate (suggested) = N × ~1.25* Gbps with ± 100ppm clock tolerance
(G.709 Amendment 2, 04/2011)
* Bandwidth per tributary slot (ts) varies according to line rate:
 ODU2: 1.249G/ts x up to 8ts  10.037G (max);
 ODU3: 1.254G/ts x up to 32ts  40.319G (max);
 ODU4: 1.301G/ts x up to 80ts  104.794G (max)
Traditional ODU2
ODUflex @ 5 x 1.25Gbps Tributary Slots
Stranded Capacity
Re-usable Capacity
6 Gbps Client
20
Potential ODUflex (CBR) Client Rates
Potential CBR Client Signal Client Rate (Gbps)
ODUflex (CBR)
Rate (Gbps)
Tolerance
(ppm)
1xSDR InfiniBand 2.500000000 2.510504202 100
3G-SDI Video (NTSC rate) 2.967032967 2.979499492 10
3G-SDI Video (PAL rate) 2.970000000 2.982478992 10
CPRI level 4 3.072000000 3.084907563 0.002
4G Fibre Channel 4.250000000 4.267857143 100
CPRI level 5 4.915200000 4.935852101 0.002
1xDDR InfiniBand 5.000000000 5.021008403 100
CPRI level 6 6.144000000 6.169815126 0.002
8G Fibre Channel 8.500000000 8.535714286 100
CPRI level 7 9.840400000 9.881746218 0.002
4xSDR InfiniBand 10.000000000 10.042016807 100
1xQDR InfiniBand 10.000000000 10.042016807 100
10G-SDI Video (NTSC rate) 10.681318681 10.726198172 10
10G-SDI Video (PAL rate) 10.692000000 10.736924370 10
16G Fibre Channel 17.000000000 17.071428571 100
8xSDR/4xDDR InfiniBand 20.000000000 20.084033613 100
12xSDR InfiniBand 30.000000000 30.126050420 100
8xDDR/4xQDR InfiniBand 40.000000000 40.168067227 100
12xDDR InfiniBand 60.000000000 60.252100840 100
8xQDR InfiniBand 80.000000000 80.336134454 100
12xQDR InfiniBand 120.000000000 120.504201681 100
Notes:
G.709 allows any ODUflex(CBR)
rate > 2.48832G
InfiniBand covers very broad
range of rates (2.5G-120G line
rate, 2G-96G data rate)
Video has pairs of closely
related rates (x and x/1.001)
CPRI requires very tight clock
tolerance (0.002ppm)
G.709 mapping defined

G.709v3 Appendix XI

G.709 Living List client

Other known CBR clients
21
Differences between SONET/SDH & OTN
Synchronous clocking
architecture
Originally specified to operate on a
single wavelength
SONET/SDH only scales to 40G
Uses a fixed frame rate and
increases frame size as the speed
increases
 Sized for voice data rate
 64kb/s voice requires 8,000
bytes/s (1 byte/125 µs)
 i.e. 1 frame/125 µs
Section, Line, and Path layers
Asynchronous clocking
architecture
Designed to operate on multiple
wavelengths (DWDM)
OTN scales to 100G (and beyond)
Uses a fixed frame size and
increases the frame rate as the
speed increases
 Sized for error correction to
correct 16 blocks per frame
 Reed Solomon RS(255/239)
 i.e. Correct 8 bit errors/block
Section and Path layers only
SONET/SDH OTN
22
Standards and References
ITU-T Recommendations
 G.693 - Optical interfaces for intra-office systems
 G.695 - Optical interfaces for coarse wavelength division applications
 G.709 - Interfaces for the Optical Transport Network (OTN)
 G.798 - Characteristics of optical transport network hierarchy equipment functional blocks
 G.808.1 - Generic protection switching - Linear trail and subnetwork protection
 G.870 - Terms and definitions for Optical Transport Networks (OTN)
 G.871 - Framework for optical transport network Recommendations
 G.872 - Architecture of optical transport networks
 G.873.1 - Optical Transport Network (OTN): Linear protection
 G.874 - Management aspects of the optical transport network element
 G.874.1 - Optical transport network (OTN): Protocol-neutral management information model for the network
element view
 G.959.1 - Optical transport network physical layer interfaces
 G.8201 - Error performance parameters and objectives for multi-operator international paths within the
Optical Transport Network (OTN)
 G.8251 - The control of jitterand wander within the optical transport network (OTN)
 G.Sup43 - Transport of IEEE 10G Base-R in Optical Transport Networks (OTN)
OTN Overhead Functions
24
OTN Overhead – Optical Layers
Overhead transported via Optical Supervisory Channel (OSC)
 OSC and OOS (OTM Overhead Signal) signal format are not standardized

Overhead covers payload channels and overhead channel (OSC)
 OTS Layer: Trail Trace identifier (TTI) – used to verify fiber connectivity
 Payload Missing indication (PMI) – used to suppress downstream LOS-P
 Backward Defect Indication (BDI-P and BDI-O) – used for single-ended
 maintenance
 OMS Layer: Payload Missing indication (PMI) – used to suppress downstream LOS-P
 Forward Defect Indication (FDI-P and FDI-O) – optical AIS
 Backward Defect Indication (BDI-P and BDI-O) – used for single-ended
 maintenance
 OCh Layer: Forward Defect Indication (FDI-P and FDI-O) – optical AIS
 Open Connection indication (OCI) – used to indicate cross-connection status

Overhead termination/generation
 OTS overhead is terminated/sourced at every node
 OMS overhead is terminated/sourced at every OADM node, but passed through OLA nodes
 OCh overhead is terminated/sourced or passed through at an OADM node
25
OTN Overhead Functions – Electrical Layers
Continuity Supervision
Connectivity Supervision
Maintenance Information
Signal Quality Supervision
Management Communications
Monitors the integrity of a link (LOS, OCI, LTC)
Monitors the integrity of a sequence of connections by comparing source and
destination IDs (TIM)
Monitors performance after transmission via error parity check (DEG)
Provides communications channels for path and section management
communications and path protection communications (FOP)
Suppress alarm escalation by informing upstream/downstream of defects (PMI,
FDI, AIS, BDI, IAE, BIAE)
Supports single-ended supervision of a connection (OCI, LCK)
Frame
Alignment
Path
Monitoring
Section
Monitoring
Tandem
Connection
Monitoring
Payload
Management
Payload Supervision Monitors for correct client payload at source and destination by matching
payload type (PLM) and monitors for incoming client signal failure (CSF)
Alignment Supervision Monitors alignment of OTN frames (LOF, LOM, LOFLOM, LOL, LOFLANE)
Multiplexing Supervision Monitors the multiplex structure supporting single-stage multiplexing (MSIM)
26
OTN Frame Structure – Electrical Layers
ODUk OH
FA OH OTUk OH
OPUk Payload
(4 x 3808 bytes)
OTUk FEC
(4 x 256 bytes)
O
P
U
k
OH
1
2
3
4
1 7 8 14 15 16 17 3824 3825 4080
Column
Row
Overhead for Frame Alignment
Overhead for ODU Operations (Path)
Overhead for the OTU Operations (Section)
Overhead for Client Mappings
Payload for Client Signal
Forward Error Correction
Add 1 overhead byte for every 238 payload bytes = 239
Add 16 FEC bytes for every {238+1 = 239} bytes = 255
Repeat 16 times per row x 4 rows = 16,320 bytes per frame
27
Forward Error Correction (FEC)
Forward Error Correction (FEC)
 Add redundancy to a message through encoding prior to transmission to enable
the receiver (decoder) to correct errors induced in the communication channel
 Roughly 7% of each OTN frame is dedicated to an error correcting code
 Resulting in (choice of) lower error rates, lower transmission power, greater
transport distance
 Standardized G.975 (Reed-Solomon) code and proprietary enhanced codes

Reed-Solomon Code (RS) 255/239
 239 base data bits
 16 added overhead bits: (6.7% overhead)
 Corrects for 8 or less bit errors in 239 bits
 8 x 16 x 4 = 512 bits per OTU frame
 Anything over 8 bits is completely uncorrected
 Typical gain is ~6.5 dB at 1e-12 BER
OSNR (dB)
Log
BER
10-12 ~6.5dB Gain @ 10
-12 BER
With FEC
No FEC
28
Reed-Solomon FEC RS (255/239)
1 2 238
1
2
3
4
1 16 17 3825 3840
Column
Row 32 33 48 3808 3824
1 2 239
OH
(1 byte)
Payload
(238 bytes)
240 255
FEC
(16 bytes)
3841 3856
16
4065 4080
2 1
239
1 2 239
OH
(1 byte)
Payload
(238 bytes)
240 255
FEC
(16 bytes)
1 2 239
OH
(1 byte)
Payload
(238 bytes)
240 255
FEC
(16 bytes)
Overhead Payload FEC
255 239 255 239 255
Information
Parity
Check
Information
Parity
Check
Information
Parity
Check
16 OTU
Sub-rows
per OTUk
Frame
x 4 rows
29
DAPI
(destination)
OTN Overhead Details – Electrical Layers
ACT Activation/deactivation control channel
APS Automatic Protection Switching channel
BDI Backward Defect Indication
BEI Backward Error Indication
BIAE Backward Incoming Alignment Error
BIP-8 Bit Interleaved Parity – level 8
DAPI Destination Access Point Identifier
DMp Delay Measurement – path level
DMtn Delay Measurement – tandem level n
EXP Experimental
FTFL Fault Type and Fault Location channel
GCC General Communications Channel
IAE Incoming Alignment Error
JC Justification Control
MFAS Multi-frame Alignment Signal
NJO Negative Justification Opportunity
PCC Protection Communication Channel
PM Path Monitor
PSI Payload Structure Identifier
PT Payload Type
RES Reserved
SAPI Source Access Point Identifier
SM Section Monitor
STAT Status
TCM Tandem Connection Monitor
TTI Trail Trace Identifier
Frame Alignment MFAS SM GCC0 RES
RES TCM6 TCM5 TCM4 TCM ACT FTFL
TCM3 TCM2 TCM1 PM EXP
GCC1 GCC2 APS/PCC RES
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1
2
3
4
Row
Column
TTI BIP-8
1 2 3
Section, Path & Tandem Connection Monitor
SAPI
(source)
Operator
Specific
0
15
16
31
32
63
BEI/BIAE BDI RES
BEI/BIAE BDI STAT
BEI BDI STAT
IAE SM
TCMi
PM
RES
RES
RES
PSI NJO
JC
JC
JC
PSI
PT
MSI/RES
PM&
TCM
DMt1
PM&
TCM DMt2 DMt3 DMt4 DMt5 DMt6 DMp RES
Path & Tandem Connection Delay
RES
30
Overhead Descriptions – Alignment
Frame Alignment Signal (FAS)
 Provided in the OTU frame to allow determination of the beginning of the OTU frame
 Detection of framing failure results in Loss of Frame (LOF) indication
Multiframe Alignment Signal (MFAS)
 Provided in the OTU frames to align overhead functions that require multiple frame operation
(e.g., Trail Trace Identifier (TTI) functions at OTU/ODU layers; fault type and fault locate,
tandem connection activation, mapping functions, and automatic protection switch functions
at ODU layer)
 Detection of multi-framing failure results in Loss of Multi-frame (LOM) indication
Incoming Alignment Error (IAE, included in STAT field for TCMs)
 Provided in the OTU and ODU frames to detect frame alignment errors detected by upstream
equipment (occurs for through-timed equipment when incoming clock signal is lost)
 Detection of alignment error results in suppression of near-end and far-end performance
monitoring data for current and previous seconds
Backward Incoming Alignment Error (BIAE, included in BEI field)
 Provided in the OTU and ODU frames to detect frame alignment errors detected by
downstream equipment (due to a detection of an IAE at a downstream node)
 Detection of alignment error results in suppression of far-end performance monitoring data for
current and previous seconds
31
OTN Framing
Frame
Type
IF Time
(μS)
ODU0 197
OTU1/
ODU1
97.9
OTU2/
ODU2
24.4
ODU2e 23.5
OTU3/
ODU3
6.07
OTU4/
ODU4
2.34
OA1 Framing Bytes (FAS & MFAS):
OA1 = ‘1111 0110’
OA2 = ‘0010 1000’
MFAS = 8-bit counter
OA1 OA1 OA2 OA2 OA2 MFAS Row 1
Column
1 2 3 4 5 6 7
Out of
Frame
In
Frame
IF to OOF
(OTUk)
OOF to IF
(any 4 bytes for OTUk, all bytes for ODUj demux)
Invalid FAS/MFAS for 5 frames
Valid FAS/MFAS for 2 frames
FAS
Frame
Type
OOF
Time (μS)
ODU0 492
OTU1/
ODU1
245
OTU2/
ODU2
61.0
ODU2e 58.8
OTU3/
ODU3
15.2
OTU4/
ODU4
5.84
IF to OOF
(ODUj demux)
LOF/LOM:OTUk
LOFLOM: ODUj demux
Set when OOF for >3ms
Cleared when IF for >3ms
32
OTN Signal Regeneration Model
ODUj ODUj ODUj
ODUk/OTUk
OH Generation
(Local clock)
OTUk CDR &
OTUk/ODUk OH
Termination
OTUk Section Regenerator Chain
ODUk ODUk ODUk
OTUk OH
Generation
& Retiming
OTUk CDR
& OH
Termination
OTUk OH
Generation
& Retiming
OTUk CDR
& OH
Termination
OTUk OH
Generation
& Retiming
OTUk CDR &
OH
Termination
OTUk OTUk
OTUk OTUk
OTUk CDR &
OTUk/ODUk OH
Termination
OTUk CDR &
OTUk/ODUk OH
Termination
ODUk/OTUk
OH Generation
(Local clock)
ODUk/OTUk
OH Generation
(Local clock)
ODUk/j
Demux &
ODUj CR
ODUk/j
Mux
ODUk/j
Mux
ODUk/j
Mux
ODUk/j
Demux &
ODUj CR
ODUk/j
Demux &
ODUj CR
X X X
ODUj Path Mux/Demux Chain
OTUk frame slip (OTUk LOF) propagates until CDR switches to local clock
ODUj frame slip (ODUj LOFLOM) propagates until demultiplexer switches to local clock
Incoming frame slip
Incoming frame slip
33
IAE and BIAE Processing (OTUk/section or ODUkT/path)
frame slip incoming
to section or
tandem connection
Inserted after
reframe or switch
to local clock
(active for 4096 frames)
Detect incoming IAE,
Suppress near/far end PM for
current and previous second
that IAE is active
Detect incoming BIAE,
Suppress far end PM for
current and previous second
that BIAE is active
OOF propagates downstream
OOF OOF
Node A Node Z
OTUk section or
ODUkT tandem connection
IAE dIAE
aBIAE
IF
LOF/LOFLOM
clear or switch
to local ref
dBIAE
Loss of upstream framing causes errors in performance monitoring of
downstream sections and/or tandem connections
 IAE function informs downstream nodes of upstream problems
 BIAE function provides notification in backward direction
 Generation/detection of IAE/BIAE does not affect end-to-end path monitoring
34
Path and Tandem Connection Monitoring (PM & TCM)
Provide management visibility at multiple (nested) levels
Path CM
User
User Operator A
Operator B
Operator C ODUk
Client
Signal
Client
Signal
UNI CM
NNI CM NNI CM NNI CM
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
QoS of Leased Connection is Monitored by User
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCMi
Overhead
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
35
Tandem Connection Monitoring Modes
Transparent Mode (source and sink ends)
 Pass all TCM overhead unchanged
Monitor Mode (sink end only)
 Pass all TCM overhead unchanged but report state of TC (shadow data)
 Extract TCM overhead including TTI, BIP-8, DMti, BDI, BEI, and STAT
 Detect defects including AIS, OCI, LCK, LTC, TIM, DEG, IAE and BIAE
 Compute BIP-8 and count errors and defect second in one second period to feed PM
 Count number frames for delay measurements
 Generate BDI, BEI and BIAE upstream
Operational Mode
 At source end:
 Compute BIP-8 and insert TCM overhead including TTI, BIP-8, DMti, BDI, BEI and BIAE
 Detect frame slip and insert IAE
 Insert APS/PCC fields for protection switching (future)
 At sink end:
 Perform functions provided by Monitor mode but set downstream TCM overhead to all zeros
 Perform downstream consequent actions (send AIS for OCI/LCK/TIM, send TSF/TSD)
 Retrieve APS/PCC fields for protection switching (future)
Non-Intrusive Monitor (sink function only)
 Same functions as Monitor Mode except BDI, BEI and BIAE are not generated upstream
 Generate TSF/TSD for protection switching
36
Tandem Connection Visibility
Service Provider Domain
Backhaul
Domain Underse
a
Domain
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
TCM6
TCM5
TCM4
TCM3
TCM2
TCM1
Backhaul
Domain
Problem: Performance data within a nested TCM may not be available for
sectionalization (example: drippling errors within a nested domain)
Application: Multi-carrier domain configurations (example: end-to-end
Service Provider providing service through 3rd party undersea link)
37
Tandem Connection Shadow
Solution: TCM termination does not reset TCM overhead bytes at the
destination end of the TCM, TCM shadow data continues to propagate and
is monitored further downstream (capability recently added to G.798)
Issues: Shadow data is affected by downstream domain performance
degradation, implementation requires negotiation of TCM functionality
across domains
38
SNCP and TCM
Non-intrusive TCMs Non-intrusive TCMs
Operational TCM Operational TCM
TCM layer is used to provide SNCP service and protection switch criteria
which is not subject to faults occurring outside of the domain
 TCM layer is terminated on the drop and provides PM relative to service as
opposed to either individual SNC
 TCM monitors on the line side provide input to determine which path to select
39
5430 TCM Usage
Problem: OTUk SM layer terminated at each segment
 Provides direct fault isolation to a given segment in the network, however, failure across OTUk regenerators
or between two DWDM transponders is only visible to ODUk switch at the PM layer
Solution: TCM4 (default) used to isolate failures between two switching nodes
 Every inter-switch line in the network utilizes this same TCM layer supporting role based usage of this TCM
layer for providing link monitoring between switching nodes
Problem: Domain SNCs may not terminate ODUk PM layer
 No end-to-end SNC monitoring is available via the PM layer (intermediate path monitoring non-standard)
Solution: TCM3 (default) used to provide per domain service level SNC monitoring associated
 Every SNC in the network utilizes the same TCM layer supporting role based usage of this TCM layer for
providing end-to-end SNC monitoring.
OMS
SM
TCM4
TCM3
PM
Client
OTUk / OCh
OMS
OTUk / OCh ODUk Switch Nodes
40
Overhead Descriptions – Connectivity and Continuity
TTI (Trail Trace Identifier)
 Provided in the OTU/ODU frame to allow detection of connectivity errors
 Supports provisioning of transmitted and expected values and allows retrieval of
accepted value
 Provides disabled, source access point identifier (SAPI), destination access point
identifier (DAPI), and SAPI+DAPI modes; provides mode for disabling automatic actions
due to trace identifier mismatch
 Detection of trace identifier mismatch results in Trail trace Identifier Mismatch (TIM)
indication
OCI (Open Connection indication, provided by STAT field for TCM/PM)
 Provided in the ODU frame to allow detection of continuity errors by indicating the status
of a switch matrix connection
 Generation/detection of ‘110’ results in Open Connection Indication (OCI) condition
(entire ODU frame except framing and FTFL bytes replaced with ‘01100110’)
41
Trail Trace Identifier Format
SAPI[0] and DAPI[0] are set to All-0s
7 84 5 61 2 3
15
1
2
…
..…
SAPI[1]
SAPI[2]
SAPI[15]
…
..…
DAPI[1]
DAPI[2]
DAPI[15]
…
..…
31
17
18
…
..…
0
16
32
63
…
…
…
…
…
…
…
…
…
…
…
…
…
..
Operator
Specific
SAPI[0]
DAPI[0]
Destination
Access
Point
Identifier
Source
Access
Point
Identifier
0
0
0
…
..…
0
0
0
…
..…
NS character #IS character #
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
CC ICC
ICC
ICC
ICC
ICC
ICC
CC
CC
CC
CC
CC
UAPC
UAPC
UAPC
UAPC
UAPC
UAPC
CC = ISO 3166 Country Code
ICC = ITU Carrier Code as per ITU-T Rec. M.1400
UAPC = Unique Access Point Code is carrier specific
 All TTIcharacters are from the T.50 character set
 Only SAPI and DAPI fields used for TIM detection
 Operator Specific bytes are user specified
SAPI/DAPI Field Format
42
SAPI and DAPI Applications
Point-to-Point
Application
(unidirectional or bidirectional)
Point-to-Multipoint
Application
(unidirectional bridge)
Multipoint-to-Point
Application
(unidirectional select)

(Note: only supported on
5430 for 2:1 selector)
Transmitted TTI Expected SAPI or SAPI+DAPI
Transmitted TTI
Expected SAPI
Expected SAPI
Expected SAPI
Transmitted TTI
Expected DAPI Transmitted TTI
Transmitted TTI
43
Overhead Descriptions – Signal Quality
FEC (Forward Error Correction)
 Provided in the OTU frame to allow detection and correction of line bit errors
BIP-8 (Bit Interleaved Parity-8)
 Provided in the OTU/ODU frame to allow detection of near-end bit errors and support
performance monitoring and protection switching functions (Signal Degrade, Note: signal fail
due to BER detection not provided)
 Detection of bit error counts are reported to the far end via the backward error indication
field (BEI) on a frame-by-frame basis
 Detection of bit errors within a frame generates an errored block (errored block counts are
the basis for near-end PM parameter value determination)
 Detection of N successive degraded seconds (based on percentage of errored blocks)
results in a Degraded (DEG) indication
BEI (Backward Error Indication)
 Provided in the OTU/ODU frame to allow detection of far-end bit errors and support
performance monitoring (single-ended maintenance)
 Detection of bit errors within a frame generates an errored block (errored block counts are
the basis for far-end PM parameter value determination) which are reported back to the near-
end via BEI bits
PM&TCM DMp & DMt[1-6] (path Delay Measurement)
 Provided in the ODU frame to allow measurement of round trip latency
44
BIP-8 Generation
BIP-8
Fr
am
e
n
1
2
3
4
1
2
3
4
Fr
am
e
n+
2
1
2
3
4
Fr
am
e
n+
1
1 14 15 3824……………………………………
SM
BIP-8
PM
BIP-8
TCM4
BIP-8
TCM5
BIP-8
TCM6
BIP-8
TCM4
BIP-8
TCM5
BIP-8
TCM6
BIP-8
SM
BIP-8
PM
BIP-8
TCM4
BIP-8
TCM5
BIP-8
TCM6
BIP-8
TCM4
BIP-8
TCM5
BIP-8
TCM6
BIP-8
SM
BIP-8
PM
BIP-8
TCM4
BIP-8
TCM5
BIP-8
TCM6
BIP-8
TCM4
BIP-8
TCM5
BIP-8
TCM6
BIP-8
………………………………………
 BIP-8 computed over the OPU frame for all monitors
 Allows ODU overhead to be modified without recomputing BIP-8 values
(essential for tandem connection monitoring)
45
BIP-8 Error Detection and BEI Generation
BIP-8
OTUk
BEI
OTUk
BBE
1 14 15 3824…………………………………………………………………………
>0
ODUkP
BEI
ODUkP
BBE
XOR
# of
BIP
Errors
ODUkT
BBE
ODUkT
BEI
Fr
am
e
n
1
2
3
4
1
2
3
4
Fr
am
e
n+
2
1
2
3
4
Fr
am
e
n+
1
SM
BIP-8
PM
BIP-8
TCM4
BIP-8
TCM5
BIP-8
TCM6
BIP-8
TCM4
BIP-8
TCM5
BIP-8
TCM6
BIP-8
SM
BIP-8
PM
BIP-8
TCM4
BIP-8
TCM5
BIP-8
TCM6
BIP-8
TCM4
BIP-8
TCM5
BIP-8
TCM6
BIP-8
SM
BIP-8
PM
BIP-8
TCM4
BIP-8
TCM5
BIP-8
TCM6
BIP-8
TCM4
BIP-8
TCM5
BIP-8
TCM6
BIP-8
XOR
XOR
# of
BIP
Errors
# of
BIP
Errors
>0 >0
 BBE/BEI counts used to calculate NE/FE PM
 BBE count used to trigger DEG defect
46
TCM Latency Measurement
Latency measurement accuracy determined by frame time and delay
asymmetry between transmit and receive directions
 Receive and transmit frames are not synchronous nor in-phase resulting in
latency variation of up to one frame time (single frame uncertainty at source and
loopback divided by two)
 Delay asymmetry results in latency error of one-half the delay differential
between the transmit and receive delay
0 0 0 0 1 1 1 1
Calculate latency = (Nf – Ni)×Tframe/2,
 where Tframe=ODU frame time

 errormax ≤ Tframe + (Dr-Dt)/2,
 where Dr and Dt are receive and
 transmit propagation delays
A-end node configured
to source and measure
specific PM/TCM DM bit
A Z
Z-end node configured
to loopback specified
PM/TCM DM bit
1 2
3 Insert bit transition
into specified
PM/TCM DM bit
and start frame
counter (value=Ni)
4 Detect bit transition
on specified
PM/TCM DM bit
and stop frame
counter (value=Nf )
1 1 1 1 0 0 0 0
5
Tframe
47
5430 Latency Based Routing
Lowest Cost Routing - Default
• Assuming all Admin Weights are the same then
algorithm will chose the lowest hop count for the route
• Default Admin Weight is 5040
AW: 5040 AW: 5040
AW: 5040 AW: 5040
AW: 5040
Lowest Cost Routing – Admin
Weight
• Operator has modified Admin Weights on two center
spans
• Route = lowest summed admin weight
AW: 10000 AW: 15000
AW: 5040 AW: 5040
AW: 5040
Lowest Cost Routing – Latency
• Operator has enabled auto-latency calculation in the
network (or applied them manually) and selected
lowest latency option for the circuit
• Route = lowest summed latency
AW: 10000 AW: 15000
AW: 5040 AW: 5040
AW: 5040
AW: Admin Weight
LT: Latency
LT: 4ms LT: 5ms
LT: 1.5ms LT: 1ms
LT: 3ms
TODAY
5430
5430
5430
5430
5430
5430
With
Addition of
Latency
48
Overhead Descriptions – Maintenance Signals
AIS (Alarm Indication Signal, provided by STAT field for
TCM/PM)
 Provided in the ODU frame to allow generation/detection of failure
suppression signal
 Generation/detection of ‘111’ results in Alarm Indication Signal (AIS) condition
(entire ODU frame except framing and FTFL bytes replaced with all-1s)
LCK (Locked, provided by STAT field for TCM/PM)
 Provided in the ODU frame to allow maintenance locking of ODU channel
 Generation/detection of ‘101’ results in Locked (LCK) condition (entire ODU
frame except framing and FTFL bytes replaced with ‘01010101’)
BDI (Backward Defect Indication)
 Provided in the OTU/ODU frame to allow detection of far-end defect conditions
for single-ended maintenance
FTFL (Fault Type Fault Locate)
 Provided in the ODU frame to support fault sectionalization (256-byte multi-
frame message format)
49
ODUj or
Client
OTN Overhead Signal Interactions
OCh OTUk ODUk
Loss of Signal – Payload (LOS-P)
Loss of Frame (LOF), Loss of Lane (LOL),
Loss of Lane Frame (LOLFRAME)
OTU Alarm Indication Signal (AIS)
Loss of Multiframe (LOM)
FEC Corrected Errors (FECcorrErr)
Bit Interleaved Parity (BIP-8)
Backward Error Indicator (BEI)
Trace Identifier Mismatch (TIM)
Backward Defect Indicator (BDI)
Incoming Alignment Error (IAE)
Section
Monitoring
(SM) Backward Incoming Alignment Error (BIAE)
Path &
Tandem Connection
Monitoring
(PM & TCM)
Bit Interleaved Parity (BIP-8)
Backward Error Indicator (BEI)
Trace Identifier Mismatch (TIM)
Backward Defect Indicator (BDI)
Locked (LCK), Open Connection Indication (OCI),
Loss of Tandem Connection (LTC, TCM only) (via STAT)
Multiplex Structure identifier (MSI) ODUj-AIS
Detect Generate
Payload
Structure Identifier
(PSI)
Optical
Channel
(OCh)
Incoming Alignment Error (IAE) (via STAT,TCM only)
Backward Incoming Alignment Error (BIAE) (TCM only)
Payload Type (PT)
Client Signal Fail (CSF) Client
Specific
Only applicable
when TIM
consequent actions
are enabled
E.g., PN-11, LF, etc.
Alarm Indication Signal (AIS) (via STAT)
ODUk-AIS
Loss of Frame and Multiframe (LOFLOM, only
applicable to ODUk/ODUj multiplexing)
DEG
DEG
All detection and
generation functions
specified for the
ODUk are repeated
for the ODUj
Signal Propagation Consequent Action Forward Operation Backward Operation
50
Mapping Overhead
PT (Payload Type, part of PSI multi-frame)
 Provided in the ODU (OPU OH) frames to allow detection of client payload mismatches
 Detection of mismatch between expected and received payload types results in Payload Label
Mismatch (PLM) indication
 Auto-payload type function for legacy multiplexing support
JC (Justification Control), NJO/PJO
 Provided in the ODU frames (OPU OH) to control stuffing operationsfor client signal and ODUjk
multiplexing rate adaptation (~131ppm range for client, ~197ppm range for muxing)
 Fixed payload format (predetermined data and fixed stuff positions)
 Supports synchronous and asynchronous client mapping and asynchronous ODUjk multiplexing
GMP Overhead
 Provided in the ODU frames (OPU OH) to control client signal rate adaptation and ODU multiplexing
with wide clock tolerance range
 Variable payload format (dynamic data and fixed stuff positions based on modulo arithmetic)
 Supports generic client mapping and ODUj-21 multiplexing
Other Mapping/Multiplexing Specific Overhead
 VCAT OH – virtual concatenation overhead (NxODUk container creation)
 MSI – multiplex structure identifier overhead (part of PSI used for ODUjk multiplexing)
 CSF – Client signal fail indication
51
Control of OTN Timing
OTN timing aspects are dominated by client mapping and muxing
functions
 Asynchronous mapping and muxing functions introduce phase discontinuities in
data plane clocking that must be filtered
 Discontinuities controlled by limiting buffer hysteresis (variation due to justification
operations), and/or by providing residual phase information between justification
events (residual buffer fill); 6.4ns/NE  640ns total: 13% or SDH wander budget or
34% of SONET wander budget, OTN not a significant source of wander
 Discontinuities are filtered at demuxing and demapping points to maintain OTN
and client timing compliance (jitter), filter bandwidths determined by simulation
UTC PRC
OTN
Island SSU
SEC/
EEC
SEC/
EEC
SEC/
EEC
Sync network limit
Reference point
Adapted Synchronization Reference Chain
10x
(100 OTN mapping/muxing operations)
20 SEC/EEC
1 mapping NE
+ 9 muxing NEs
Intervening SECs
replaced with OTN
equipment
bounded by SSUs
52
Bit-synchronous Mapping
LO ODUk clock is derived from and synchronous to the recovered client
clock (no justification or dynamic rate adaptation performed)
 LO ODUk clock = recovered client clock × 239/238
 Client signal into ODUflex(CBR)
 OC-48 into ODU1
 LO ODUk clock = recovered client clock × 239/237
 OC-192 into ODU2
 Transparent 10GbE and transcoded FC-1200 into ODU2e
 LO ODUk clock = recovered client clock × 239/236
 OC-768 mapping to ODU3
16
NJO
JC
JC
JC
Column
1
2
3
4
Row
PJO
Client Data Justification (0x00)
Not used
Not used 11
10
01
00
JC Bits NJO Byte PJO Byte
Not used
Not used
Not used
Not used
53
Frame
N
Frame
N+1
Frame
N+2
Bit-synchronous Mapping Procedure
P
• • •
• • •
• • •
• • •
00
00
00
N
Negative
Justification
Threshold
Positive
Justification
Threshold
OPU Payload OPU Overhead
P
• • •
• • •
• • •
• • •
00
00
00
N
P
• • •
• • •
• • •
• • •
00
00
00
N
P
• • •
• • •
• • •
• • •
00
00
00
N
Input Client
Datastream
First-In/
First-out
Data Buffer
Frame
N+3
54
Asynchronous Mapping
For client signal mapping, LO ODUk clock is derived from a local oscillator and the client signal
is rate adapted using positive/zero/negative justification process (supports +/-45ppm client clock
range)
 Justification control overhead used to provide the positive/zero/negative indication
 Negative justification opportunity (NJO) byte provides an additional client data position when required (client
bandwidth > payload bandwidth)
 Positive justification opportunity (PJO) byte (first payload byte following NJO byte) provides unused position
when required (client bandwidth < payload bandwidth)
 Supports OC-48/192/768 or STM-16/64/256 mapping into LO ODU1/2/3
For ODUjk multiplexing, HO ODUk clock is derived from a local oscillator and the LO ODUk
(ODUj) signal is rate adapted using positive/zero/negative justification process
 Same mechanism as asynchronous client mapping except two PJO positions are defined (+1, +2 justification
supported in order to provide required ppm range)
 ODU0 mapped to ODU1
 ODU1 mapped to ODU2/ODU3
 ODU2 mapped to ODU3
16
NJO
JC
JC
JC
Column
1
2
3
4
Row
PJO1
Client Data
PJO2
Justification (0x00)
Client Data
Justification (0x00)
Justification (0x00)
Client Data
Client Data
11
10
01
00
JC Bits NJO Byte PJO1 Byte PJO2 Byte
PJO2 used only for multiplexing
Justification (0x00)
Client Data
Justification (0x00)
Justification (0x00)
Client Data
10 case used
for multiplexing
55
Frame
N
No
Justification
Frame
N+1
Negative
Justification
Frame
N+2
No
Justification
Frame
N+3
Negative
Justification
Asynchronous Mapping Procedure – Fast Client
P
• • •
• • •
• • •
• • •
00
00
00
N
Negative
Justification
Threshold
Positive
Justification
Threshold
OPU Payload OPU Overhead
P
• • •
• • •
• • •
• • •
00
00
00
N
P
• • •
• • •
• • •
• • •
00
00
00
N
P
• • •
• • •
• • •
• • •
00
00
00
N
Input Client
Datastream
First-In/
First-out
Data Buffer
01
01
01
01
01
01
56
Frame
N
No
Justification
Frame
N+1
Positive
Justification
Frame
N+2
No
Justification
Frame
N+3
Positive
Justification
Asynchronous Mapping Procedure – Slow Client
P
• • •
• • •
• • •
• • •
00
00
00
N
Negative
Justification
Threshold
Positive
Justification
Threshold
OPU Payload OPU Overhead
P
• • •
• • •
• • •
• • •
00
00
00
N
P
• • •
• • •
• • •
• • •
00
00
00
N
P
• • •
• • •
• • •
• • •
00
00
00
N
Input Client
Datastream
First-In/
First-out
Data Buffer
11
11
11
11
11
11
57
Generic Mapping Procedure (GMP)
For client signal mapping, LO ODUk clock is derived from a local oscillator and the client signal
is rate adapted using GMP process (supports nearly unlimited client clock range)
 GMP overhead used to signal the number of payload bytes carrying client data each payload frame (Cm) plus
residual phase information (CnD)
 Client data positions and unused payload bytes identified through modulo arithmetic algorithm
 For payload positions j=1 to Cmax, if (j × Cm) mod Cmax < Cm, j is a client data byte
 For payload positions j=1 to Cmax, if (j × Cm) mod Cmax ≥ Cm, j is a stuff byte (0x00)
 Supports various client mappings
 STM-1/4, OC-3/12, timing transparent GbE, and FC-200 into ODU0
 HD-SDI video and FC-200 into ODU1
 Transcoded 40GbE into ODU3
 100GbE into ODU4
For ODUj-21 multiplexing, HO ODUk clock is derived from a local oscillator and the LO ODUk
signal is rate adapted using GMP process
 Same mechanism as GMP client mapping except CnD fixed at C8D
 Supports payload type 21 multiplexing
 Any LO ODUk to ODU4
 ODU0/2E/flex into ODU3
 ODU0/flex into ODU2
15
JC3
JC2
JC1
Column
1
2
3
Row
Cm (bits 1-8)
Cm (bits 9-14), II, DI
CRC-5
ΣCnD (bits 1-5)
ΣCnD (bits 1-5)
JC3
JC2
JC1
CRC-8
16
JC6
JC5
JC4
JC6
JC5
JC4
OTN and OTN Client Signal Fault Propagation
59
Fault Propagation Example – Bidirectional Fiber Cut
SM
TCM4
TCMi (opt)
PM
Client
ODUk Switch Nodes
ODU0
OTU2 OTU3 OTU4 OTU2 OTU3 OTU4
ODU0
ODU3
PM
ODU2
ODU4
ODU0 XC ODU0 XC ODU0 XC ODU0 XC
(tunnel)
3rd Party OTN
Domain
2/0 0/3 3/0 0/2/3 4/2/0 0/4 4/0 0/2
ODU0
TCM3
ODU0
×
LOS
ODU0-AIS
ODU0-AIS
ODU0-AIS
ODU3-AIS
ODU0-IAE
ODU0-BIAE
LOS
ODU3-AIS
ODU0-AIS
ODU0-AIS
ODU0-AIS
Frame slip
ODU0 XC ODU0 XC
60
Fault Propagation Example – Deleted Cross-Connection
SM
TCM4
TCMi (opt)
PM
Client
ODU0
OTU2 OTU3 OTU4 OTU2 OTU3 OTU4
ODU0
ODU3
PM
ODU2
ODU4
ODU0 XC ODU0 XC ODU0 XC ODU0 XC
(tunnel)
3rd Party OTN
Domain
2/0 0/3 3/0 0/2/3 4/2/0 0/4 4/0 0/2
ODU0
TCM3
ODU0
×
ODU0-OCI
ODU0-OCI
ODU0-OCI
ODU0-IAE
ODU0-BIAE ODU0-OCI
ODU0-OCI
ODU0-OCI
Frame slip
ODU0 XC ODU0 XC
ODUk Switch Nodes
61Fault Propagation Example – TCM4 Maintenance LCK
SM
TCM4
TCMi (opt)
PM
Client
ODU0
OTU2 OTU3 OTU4 OTU2 OTU3 OTU4
ODU0
ODU3
PM
ODU2
ODU4
ODU0 XC ODU0 XC ODU0 XC ODU0 XC
(tunnel)
3rd Party OTN
Domain
2/0 0/3 3/0 0/2/3 4/2/0 0/4 4/0 0/2
ODU0
TCM3
ODU0
|
ODU0-AIS
ODU0-AIS
ODU0-AIS
ODU0-AIS
ODU0-AIS
ODU0-AIS
ODU3-LCK
ODU0 XC ODU0 XC
ODUk Switch Nodes
ODU0-IAE
ODU0-BIAE
Frame slip
62
Fault Propagation Example – TCM3 Maintenance LCK
SM
TCM4
TCMi (opt)
PM
Client
ODU0
OTU2 OTU3 OTU4 OTU2 OTU3 OTU4
ODU0
ODU3
PM
ODU2
ODU4
ODU0 XC ODU0 XC ODU0 XC ODU0 XC
(tunnel)
3rd Party OTN
Domain
2/0 0/3 3/0 0/2/3 4/2/0 0/4 4/0 0/2
ODU0
TCM3
ODU0
|
ODU0-LCK
ODU0-LCK
ODU0-LCK
ODU0-LCK
ODU0-LCK
ODU0 XC ODU0 XC
ODUk Switch Nodes
63
Fault Propagation Example – PM Maintenance LCK
SM
TCM4
TCMi (opt)
PM
Client
ODU0
OTU2 OTU3 OTU4 OTU2 OTU3 OTU4
ODU0
ODU3
PM
ODU2
ODU4
ODU0 XC ODU0 XC ODU0 XC ODU0 XC
(tunnel)
3rd Party OTN
Domain
2/0 0/3 3/0 0/2/3 4/2/0 0/4 4/0 0/2
ODU0
TCM3
ODU0
|
ODU0-LCK
ODU0 XC ODU0 XC
ODUk Switch Nodes
64
5430 GbE OTN Fault Handling (GFP-T Mapped):
LOS, LOF, LOM, AIS, OCI, LCK, PLM
Transmit
GbE
Client
Ingress
Client
Adaptation
Ingress
OTN
Mapping
Egress
OTN
Demapping
Egress
Client
Adaptation
Receive
GbE
Client
Receive
GbE
Client
Egress
Client
Adaptation
Egress
OTN
Demapping
Ingress
OTN
Mapping
Ingress
Client
Adaptation
Transmit
GbE
Client
3R
Regen
3R
Regen
X ODU-AIS Cons. Action
Link
Down
• Egress client signal Consequent Action is provisionable to laser off, /V/ codes
(K30.7 error codes) or /C1/C2/ link fault sequences
65
Transmit
GbE
Client
Ingress
Client
Adaptation
Ingress
OTN
Mapping
Egress
OTN
Demapping
Egress
Client
Adaptation
Receive
GbE
Client
Receive
GbE
Client
Egress
Client
Adaptation
Egress
OTN
Demapping
Ingress
OTN
Mapping
Ingress
Client
Adaptation
Transmit
GbE
Client
5430 GbE Client Fault Handling (GFP-T Mapped):
Client Faults - LOS, Loss-of-character-sync (LOCS)
3R
Regen
3R
Regen
X GFP CMF (LOS, LOCS) Link Down
Cons. Action
• Rx Failure causes immediate insertion of GFP Loss of Signal (LOS) or Loss of Character
Synchronization (LOCS) client management frames (CMF) at ingress

• Egress client signal Consequent Action is provisionable to laser off, /V/ codes (K30.7
error codes) or /C1/C2/ link fault sequences

• Egress consequent action clears within 3 seconds after clearing of GFP LOS/LOCS CMF
(failure recovery time limited by LOS/LOCS CMF 3 second clear time), receipt of valid data
frames causes immediate clearing
66
Transmit
GbE
Client
Ingress
Client
Adaptation
Ingress
OTN
Mapping
Egress
OTN
Demapping
Egress
Client
Adaptation
Receive
GbE
Client
Receive
GbE
Client
Egress
Client
Adaptation
Egress
OTN
Demapping
Ingress
OTN
Mapping
Ingress
Client
Adaptation
Transmit
GbE
Client
5430 GbE Client Fault Handling (GFP-T Mapped):
Link Fault or Auto-negotiation
3R
Regen
3R
Regen
/C1/C2/
• Link fault/auto-negotiation code words passed transparently end-to-end
/C1/C2
67
Transmit
GbE
Client
Ingress
Client
Adaptation
Ingress
OTN
Mapping
Egress
OTN
Demapping
Egress
Client
Adaptation
Receive
GbE
Client
Receive
GbE
Client
Egress
Client
Adaptation
Egress
OTN
Demapping
Ingress
OTN
Mapping
Ingress
Client
Adaptation
Transmit
GbE
Client
5430 GbE Error Handling (GFP-T Mapped)
3R
Regen
3R
Regen
/V/ code
• Ingress 8B/10B coding violations (CV) or transport generated errors are
replaced with /V/ characters (K30.7 error codes) on egress
Ingress client errors Transport error Transport error
68
5430 10GbE OTN Fault Handling (GFP-Mapped):
LOS, LOF, LOM, AIS, OCI, LCK, PLM
Transmit
10GbE
Client
Ingress
Client
Adaptation
Ingress
OTN
Mapping
Egress
OTN
Demapping
Egress
Client
Adaptation
Receive
10GbE
Client
Receive
10GbE
Client
Egress
Client
Adaptation
Egress
OTN
Mapping
Ingress
OTN
Mapping
Ingress
Client
Adaptation
Transmit
10GbE
Client
3R
Regen
3R
Regen
X ODU-AIS
RF RF
Cons. Action
Link
Down
or LF
RF GFP CMF/CDF (RF)
Idle
• Egress client signal consequent action is provisionable to laser off, /I/ Idle
Ordered Sets (will not cause link down at receive 10GbE client interface), or
Local Fault (LF) ordered sets

• Egress consequent action clears immediately upon clearing of the OTN fault

69
Transmit
10GbE
Client
Ingress
Client
Adaptation
Ingress
OTN
Mapping
Egress
OTN
Demapping
Egress
Client
Adaptation
Receive
10GbE
Client
Receive
10GbE
Client
Egress
Client
Adaptation
Egress
OTN
Mapping
Ingress
OTN
Mapping
Ingress
Client
Adaptation
Transmit
10GbE
Client
5430 10GbE Client Fault Handling (GFP-mapped):
Client Faults - LOS, Loss-of-block-sync (LOCS)
3R
Regen
3R
Regen
X
GFP CMF (LOS, LOCS)
RF RF
Link
Down
or LF
Cons. Action
GFP CMF/CDF (RF) RF
Idle
• Rx Failure causes immediate insertion of GFP Loss of Signal (LOS) or Loss of Character
Synchronization (LOCS) client management frames (CMF) at ingress if the mapping uses
CMF for non-transparent ordered set fault propagation, or GFP client data frames (CDF)
carrying Local Fault (LF) if mapping uses CDF for transparent ordered set fault propagation

• Egress client signal consequent action is provisionable to laser off, /I/ Idle Ordered Set
(will not cause link down at receive 10GbE client interface), or /LF/ Local Fault

• If provisioned, egress LF clears 3 seconds after clearing of GFP LOS/LOCS CMF (failure
recovery time limited by LOS/LOCS CMF 3 second clear time ), receipt of valid data frames
causes immediate clearing
GFP CDF (LF ordered set)
70
Transmit
10GbE
Client
Ingress
Client
Adaptation
Ingress
OTN
Mapping
Egress
OTN
Demapping
Egress
Client
Adaptation
Receive
10GbE
Client
Receive
10GbE
Client
Egress
Client
Adaptation
Egress
OTN
Mapping
Ingress
OTN
Mapping
Ingress
Client
Adaptation
Transmit
10GbE
Client
5430 10GbE Client Fault Handling: Local Fault
3R
Regen
3R
Regen
GFP CMF/CDF (LF)
RF RF
LF LF
GFP CMF/CDF (RF) RF
LF
• Rx Local Fault (LF) ordered set causes immediate insertion at ingress of
GFP LF client management frame (CMF used if mapping provides non-
transparent ordered set fault propagation) or client data frame (CDF used if
mapping provides transparent ordered set fault propagation)

• Egress Local Fault clears within 3 seconds after clearing of GFP LF CMF
(failure recovery time limited by LF CMF 3 second clear time ), receipt of valid
data frame cause immediate clearing

71
Transmit
10GbE
Client
Ingress
Client
Adaptation
Ingress
OTN
Mapping
Egress
OTN
Demapping
Egress
Client
Adaptation
Receive
10GbE
Client
Receive
10GbE
Client
Egress
Client
Adaptation
Egress
OTN
Mapping
Ingress
OTN
Mapping
Ingress
Client
Adaptation
Transmit
10GbE
Client
5430 10GbE Client Fault Handling: Remote Fault
3R
Regen
3R
Regen
GFP CMF/CDF (RF)
Idle LOS
RF RF RF
X
Idle
• Rx Remote Fault (RF) ordered set causes immediate insertion at ingress of
GFP LF client management frame (CMF used if mapping provides non-
transparent ordered set fault propagation) or client data frame (CDF used if
mapping provides transparent ordered set fault propagation)

• Egress Local Fault clears within 3 seconds after clearing of GFP LF CMF
(failure recovery time limited by LF CMF 3 second clear time ), receipt of valid
data frame cause immediate clearing

72
Transmit
10GbE
Client
Ingress
Client
Adaptation
Ingress
OTN
Mapping
Egress
OTN
DemappingEgress
Client
Adaptation
Receive
10GbE
Client
Receive
10GbE
Client
Egress
Client
Adaptation
Egress
OTN
Demapping
Ingress
OTN
Mapping
Ingress
Client
Adaptation
Transmit
10GbE
Client
5430 10GbE Error Handling
3R
Regen
3R
Regen
Errors
• Ingress MAC frame errors produce Ethernet CRC errors resulting in dropped
frames, errors outside the MAC frame are ignored

• Transport errors in client data frames are propagated through to the client,
errors in client data frames do not produce egress errors toward the client
Ingress client errors Transport error Transport error
73
5430 SONET/SDH/CBR OTN Fault Handling:
LOS, LOF, LOM, AIS, OCI, LCK, PLM
Transmit
SONET/
SDH/CBR
Client
Ingress
Client
Adaptation
Ingress
OTN
Mapping
Egress
OTN
Demapping
Egress
Client
Adaptation
Receive
SONET/
SDH/CBR
Client
Receive
SONET/
SDH/CBR
Client
Egress
Client
Adaptation
Egress
OTN
Demapping
Ingress
OTN
Mapping
Ingress
Client
Adaptation
Transmit
SONET/
SDH/CBR
Client
3R
Regen
3R
Regen
X ODU-AIS
AIS-L/
MS-AIS
• AIS-L/MS-AIS transmitted for Transparent SONET/SDH service and PN-11
for CBR service

• Egress AIS-L/MS-AIS/PN-11 clears immediately upon detection of OTN
failure clear
LOF PN-11(CBR)
AIS-L/
MS-AIS
(TS)
74
Transmit
SONET/
SDH/CBR
Client
Ingress
Client
Adaptation
Ingress
OTN
Mapping
Egress
OTN
Demapping
Egress
Client
Adaptation
Receive
SONET/
SDH/CBR
Client
Receive
SONET/
SDH/CBR
Client
Egress
Client
Adaptation
Egress
OTN
Demapping
Ingress
OTN
Mapping
Ingress
Client
Adaptation
Transmit
SONET/
SDH/CBR
Client
5430 SONET/SDH/CBR Client Fault Handling: LOS, LOF
3R
Regen
3R
Regen
X
AIS-L/
MS-AIS
• Rx Failure causes insertion of AIS-L/MS-AIS for Transparent SONET/SDH
service and PN-11 for CBR service at ingress

• Egress AIS-L/MS-AIS/PN-11 clears immediately upon detection of client
failure clear

PN-11(CBR) LOF PN-11(CBR)
AIS-L/
MS-AIS
(TS) AIS-L/
MS-AIS
(TS)
75
Transmit
SONET/
SDH/CBR
Client
Ingress
Client
Adaptation
Ingress
OTN
Mapping
Egress
OTN
Demapping
Egress
Client
Adaptation
Receive
SONET/
SDH/CBR
Client
Receive
SONET/
SDH/CBR
Client
Egress
Client
Adaptation
Egress
OTN
Demapping
Ingress
OTN
Mapping
Ingress
Client
Adaptation
Transmit
SONET/
SDH/CBR
Client
5430 SONET/SDH/CBR Client Fault Handling: AIS-L/MS-AIS
3R
Regen
3R
Regen
AIS-L/
MS-AIS
AIS-L/MS-AIS
• Rx AIS-L/MS-AIS propagates end-to-end

76
Transmit
SONET/
SDH/CBR
Client
Ingress
Client
Adaptation
Ingress
OTN
Mapping
Egress
OTN
Demapping
Egress
Client
Adaptation
Receive
SONET/
SDH/CBR
Client
Receive
SONET/
SDH/CBR
Client
Egress
Client
Adaptation
Egress
OTN
Demapping
Ingress
OTN
Mapping
Ingress
Client
Adaptation
Transmit
SONET/
SDH/CBR
Client
5430 SONET/SDH/CBR Error Handling
3R
Regen
3R
Regen
Errors
• Ingress as well as transport errors are propagated to the client
Ingress client errors Transport error Transport error
OTN Performance Monitoring
78
OTN Performance Monitoring Basics
Standard OTN PM Parameters Based on BIP-8 EDC
 BIP-8 byte is provided within the SM, the TCMi, and the PM overhead fields
 BIP-8 computed only over OPU payload and overhead (OTU/ODU overhead is not included
in the BIP-8 computation) avoiding the need to recompute BIP-8 values due to ODU
overhead value changes occurring along the path (GCC, APS/PCC, etc)
 BIP-8 computed after any FEC error correction (if present) is performed
 BIP-8 EDC used to determine background block errors (BBE)
 BBE used to compute standard ES, SES, CSES, and UAS parameters
 SES threshold ≥15% errored blocks (1526@ODU0, 3064@ODU1, 12304@ODU2,
12748@ODU2e, and 49424@ODU3) or a defect second
 CSES thresholds are user provisionable (2-9 consecutive SES)
 OTN layer PM provides both Near-end (NE, directly via the BIP-8) and Far-end (FE, via the
BEI field) PM data
 NE and FE PM collection affected by IAE and BIAE functions (only applies to section and
tandem connection monitoring)
 OTN supports standard defect second processing (automatic creation of ES/SES during
defect seconds and suppression of BBE counts
 Support for parameter thresholding and TCA generation
 15-min and 24-hr PM collection intervals
79
Additional 5430 OTN Performance Monitoring Parameters
Additional OTU Layer (SM) PM Parameters
 Corrected FEC errors
 Severely Errored Frame Seconds
 Severely Errored Multi-frame Seconds
 Additional ODU Layer (TCMi and PM) PM Parameters
 Protection Switch Counts
 Delay Measurements
 GFP PM Parameters
 Corrected cHEC and tHEC errors
 Dropped frames
 Errored superblocks (GFP-T only)
 Client Specific PM Parameters
OTN Multiplexing and Mapping Trees
81
OTN Optical Multiplexing Structure
Multiplexing Mapping
OTM-n.m OCG-n.m
OCC
OCC
OCC
OOSOSC
OCh
OCh
OCh
OTU4
OTU2
OTU1
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x k
x j
x m
OTS, OMS, OCh, COMMS OH
OCC OCh OTU3
x 1 x 1
x i
1 ≤ i+j+k+m ≤ n
 OTUk frames mapped (E-O) to uncolored optical channels (OCh)
 Optical channels mapped (wavelength conversion) to colored
optical channel carrier (OCC)
 Optical channel carriers optically multiplexed into optical carrier
group (OCG)
 OCG combined with optical supervisory channel (OSC) to create
the optical transport module (OTM)
82
Multiplexing
Mapping ODUk (L) = Low Order ODU
ODUk (H) = High Order ODU
Pre-2009 OTN Multiplexing Structure with SONET Mapping
OPU1
OPU2 ODU2 (H)
OPU2 Client
OPU3 ODU3 (H)
OPU3 Client ODU3 (L)
OTU1
OTU2
OTU3
Client
OCh
OCh
OCh
ODU1 (L)
ODTU12
ODU2 (L)
ODTU13
ODTU23
x4
x16
x4
2.666G
10.709G
43.018G or
or
10.037G
2.499G
40.319G
OC48
OC192
OC768
x4
x4
SONET
Rate
Hierarchy
83
Multiplexing
Mapping ODUk (L) = Low Order ODU
ODUk (H) = High Order ODU
Post-2009 OTN Multiplexing Structure
OPU0
OPU1 ODU1 (H)
ODTU01
OPU1
OPU2 ODU2 (H)
OPU2 Client
OPU3 ODU3 (H)
OPU3 Client ODU3 (L)
OTU1
OTU2
OTU3
OPU4 ODU4 (H)
OPU4 Client ODU4 (L)
OTU4
Client
Client
OCh
OCh
OCh
OCh
ODU0 (L)
ODU1 (L)
ODTU2.ts
ODTU12
ODU2 (L)
ODTU3.ts
ODTU13
ODTU23
ODTU4.ts
x2
x8
x32
x80
x4
x16
x40
x4
x10
x2
or
or
or
or 2.666G
10.709G
43.018G
111.809G
10.037G
2.499G
40.319G
104.794G
1.244G
OPU2e 10GbE ODU2e (L)
x10
x3
OPUflex Client ODUflex (L)
x80/ts
x32/ts
x8/ts
84
OTN Electrical Multiplexing Structure (1 of 2)
19.6.3 GMP
19.6.2 GMP
19.5.3 AMP
19.5.2 AMP 19.3.2
19.3.6
19.3.6 19.2
OR
ODU3
(L)
OPU3-X
ODU3
(H)
OPU3
(L)
OTU3
ODU4
(L)
ODU4
(H)
OPU4
(L)
OTU4
ODTU4.1
ODTU4.2
ODTU4.8
ODTU4.31
Client Signal
Client Signal
Client Signal
x32
x40
x80
x1
x2
x10
x1
x1
x1/X
x1
ODTU4.ts x80/ts
CBR40G (17.2.3) STM-256 - AMP/BMP (17.2)
40GBASE-LR4 (17.7.4.1) converted to serial 66b
blocks (Annex E) then transcoded into 513b
blocks (Annex B) then 1027b framed (Annex F)
and GMP mapped (17.7.4 – Amd.1)
19.1.2
19.1.4
19.2 19.3.7 19.6.3 GMP
100GBASE-LR4/-ER4 converted to serial 66b
blocks (Annex E) and GMP mapped (17.7.5 –
Amd.1)
19.6.3 GMP
19.6.3 GMP
19.6.3 GMP
ODTU3.1
ODTU13
ODTU3.9
x16
x4
x3
19.2 19.6.2 GMP
19.2
19.2 19.3.3
ODU2e
(L)
OPU2e
(L) Client Signal
x1
CBR10G3 (17.2.4) 10GBASE-R - BMP (17.2)
FC-1200 (17.8.2) - 66b blocks transcoded into a
513b block (Annex B) then assembled into a
superblock then mapped into a special GFP
frame then byte sync mapped
OPU3 (H)
PT=21
OPU3 (H)
PT=20
19.1.2
x1
ODTU3.ts x32/ts
19.2 19.3.6 19.6.2 GMP
19.3.3
19.3.2
x16 ODTU13
ODTU23 x4
19.2 19.5.2 AMP
19.2
19.5.3AMP
OPU4 (H)
PT=21
19.2
19.2
19.2
19.2
19.3.7
19.3.7
19.3.7
19.3.7
ODU2
ODU0
ODU2e
ODU1
ODUflex
ODU3
ODU4
ODU4
O
D
TU
G
4
P
T=
21

ODU3 to
ODU (H)
ODU3 to
ODU (H)
ODU2e to
ODU (H)
O
D
TU
G
3
P
T=
21

O
D
TU
G
3
P
T=
20

ODU1
ODU2
ODU2e
ODU0
ODUflex
ODU2
ODU1
ODTU23
85
OTN Electrical Multiplexing Structure (2 of 2)
19.3.1
Sketch derived from: December 2009 G.709v3 published & June 2010 Amd.1 consented (TD 221r1/PLEN)
David W. Martin – July 16, 2010
ODU0
(L)
OPU0
(L)
ODU1
(L)
OPU1-X
ODU1
(H)
OPU1
(L)
OTU1
OPU1 (H)
PT=20 ODTU01
Client Signal
Client Signal
Client Signal
x2
x1
x1
x1/X
ODUflex
(L)
OPUflex
(L) Client Signal
x1
19.1.3
19.3.4 19.2 19.5.4 AMP
CBR2G5 (17.2.1) STM-16, CMGPON D/U2 -
AMP/BMP (17.2)
FC-200 (17.7.2) - GMP
1.5G HD SDI (Living List) - GMP
CPRI Option 3 (Appendix VIII, Amd.1) - GMP
1.238Gb/s < X ≤ 2.488Gb/s (17.7.2) - GMP
1000BASE-X (17.7.1.1) - TTT+GMP
STM-1, STM-4 (17.7.1) - GMP
FC-100 (17.7.1) - GMP
ESCON, DVB-ASI, SDI (Living List) - GMP
CPRI Options 1, 2 (Appendix VIII, Amd.1) - GMP
X ≤ 1.238Gb/s (17.7.1) - GMP
FC-400, FC-800 (17.9) - BMP
3G HD SDI (Living List) - BMP
IB 2G, 4G, 8G, CPRI 7 (Living List)
CPRI Options 4 - 6 (App. VIII, Amd.1) - BMP
X > 2.488Gb/s (17.9) - BMP
X > 0 possible (17.4) - GFP-F
X = Nx~1.244Gb/s recommended
OPUflex(CBR)
OPUflex(GFP)
x1
19.3.5
ODU2
(L)
OPU2-X
ODU2
(H)
OPU2
(L)
OTU2
OPU2 (H)
PT=21
ODTU2.1
Client Signal
Client Signal
x1/X
x1
x8
x4
ODTU2.ts x8/ts
19.2 19.3.5 19.6.1 GMP
19.2
19.5.1 AMP
19.2
19.6.1 GMP
19.1.1
CBR10G (17.2.2) STM-64 - AMP/BMP (17.2)
GFP / Extended OPU2 (17.4.1) - 10GBASE-R
payload + preamble + OS, G.7041 (7.9)
GFP (17.4) - 10GBASE-R payload G.sup43 (6.2) x1
OPU2 (H)
PT=20
19.1.1
OR
ODTU12 x4
19.2
19.3.1 19.5.1 AMP
x1
ODU2 to
ODU (H)
ODU2 to
ODU (H) ODU1
ODU1
ODU0
ODUflex
O
D
TU
G
2
P
T=
21

O
D
TU
G
2
P
T=
20

ODU0
ODU1 to
ODU (H)
ODU1 to
ODU (H)
O
D
TU
G
1
P
T=
20

ODU0 to
ODU (H)
ODUflex to
ODU (H)
Mapping Multiplexing OTU/ODU OH
ODTU12
86
Single Stage (Flat) vs. Multi-Stage (Step) Multiplexing
Single stage multiplexing recommended by ITU in G.872
 All LO ODUk muxed directly to HO ODUk (no LO to HO to even higher HO)
 Reduces complexity of networking topologies
 Reduces complexity of equipment multiplexing structure
 Reduces complexity of control plane bandwidth advertisement (available
timeslots)
 Adopted by Ciena for line side (Intra-domain, I-NNI) interfaces

Multi-stage muxing likely to be required due to network migration
 Allows LO ODUk to HO ODUk to even higher HO ODUk
 May be required when muxponders are used on line system (e.g., 40G switch
interface to line system 40G-to-100G muxponder to 100G switch interface)
 Significantly increases networking and muxing complexity
 Control plane bandwidth advertisement more complex than just available timeslots
 Supported by Ciena for client side (Inter-domain, E-NNI) interfaces
87
HO ODUk Timeslot Rate Differences
Timeslot rates are different for various HO ODUk (k=2,3,4)
 HO ODU2 timeslot ~ 1.249Gbps
 HO ODU3 timelsot ~ 1.254Gbps
 HO ODU4 timeslot ~ 1.301Gbps
Variation in timeslot rate may result in ODUk/flex tributary ports
containing different numbers of HO ODUk timeslots for different
HO timeslot rates
 ODUk/flex to HO ODUk multiplexing must address timeslot utilization
efficiency
 Most efficient mapping required for ODUk/flex(CBR) clients
 Equal timeslot mapping required for ODUflex(GFP) clients (to support ODUflex resizing)
 Cross-connect function should be based on tributary ports NOT timeslots,
HO ODUk timeslots are associated with tributary ports
88
Auto-Payload Type Function
Provide automatic interworking between legacy equipment supporting
only 2.5G timeslots (PT=20) and new equipment supporting 1.25G (PT=21)
timeslots (applies to muxing into HO ODU2 and ODU3 only)
 Set outgoing PT=20 if
 AutoPayloadType is enabled and
 Incoming PT=20 and
 HO ODU source has no provisioned traffic or LO ODU traffic provisioned with PT=20
timeslot arrangement
 HO ODU2 with ODU1s in TSi/TSj where j=i+4
 HO ODU3 with ODU1s in TSi/TSj where j=i+16
 HO ODU3 with ODU2s in TSa/TSa+16/TSb/TSb+16/TSc/TSc+16/TSd/TSd+16
 Otherwise set outgoing PT=21 (default value)
89
ODTU Mapping Methods
Mapping methods provide a means for rate adapting a client or lower rate
container into a server or higher rate container
 Used to map ODUj or ODUflex into an ODTU (same mechanisms are also used
for mapping client signals into and ODUj or ODUflex)
 Two methods: Asynchronous Mapping Procedure (AMP) and Generic Mapping
Procedure (GMP)

Asynchronous Mapping Procedure
 Monitors client rate relative to server rate and performs stuffing operations once
per lower rate container frame (negative and positive justification operations)
 Signals stuffing operations through justification control bits to far end (demux)

Generic Mapping Procedure
 Monitors client rate relative to server rate, adjusts number of bytes sent per server
frame, and distributes bytes evenly throughout server frame
 Signals bytes per frame via Cm and CnD control bits to far end (demux)
90
OPU1 Tributary Slots
1 16 17 38
24Frame
Row
Column
18 19 20 38
23
15
1.25G TS#
TS
O
H
TS
1
1 2 1 2 1 2
1
2
3
4
MFAS
bit
8
1
2
3
4
0
1
Multi
Frame
Row
1
2
3
4
5
6
7
8
TS
O
H
TS
2
• Timeslots assigned to specific column positions
for mapping/muxing purposes (column interleaving)
• Timeslot overhead for mapping/muxing control
assigned to HO OPU overhead area on a per frame
basis (frame interleaving) using multi-frame values
91
OPU2 Tributary Slots
1 16 17 38
24Frame
Row
Column
18 19 20 38
23
2115
1.25G TS#
2.5G TS#
1 2 3 4 5 6 7 8
1 2 3 4 1 2 3 4
1 2
1 2
7 8
3 4
1
2
3
4
MFAS
bits
(6)78
1
2
3
4
(0)00
(0)01
Multi
Frame
Row
1
2
3
4
5
6
7
8
1
2
3
4
1
2
3
4
(0)11
(1)00
13
14
15
16
17
18
19
20
1
2
3
4
(1)11
29
30
31
32
1
2
3
4
13
14
15
16
TS
OH TS
2
TS
OH

TS
4
TS
OH
TS
1 o
r T
S5
TS
OH
TS
4 o
r T
S8
23 24 25 2622
TS
OH TS
1
92
OPU3 Tributary Slots
1 16 17 38
24Frame
Row
Column
18 31 38
23
3215
1.25G TS#
2.5G TS#
TS
OH TS
1
1 2 15 16 17 18
1 2 15 16 1 2
31 32
15 16
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
TS
OH TS
2
TS
OH
TS
16
TS
OH
TS
1
or
 T
S1
7
TS
OH
TS
16
 o
r T
S3
2
3433
MFAS
bits
(4)5678
(0)0000
(0)0001
Multi
Frame
Row
1
2
3
4
5
6
7
8
(0)1111
(1)0000
61
62
63
64
65
66
76
68
(1)1111
125
126
127
128
1
2
3
4
61
62
63
64
47 48
31 32 1 2
15 16 1 2
5049
93
OPU4 Tributary Slots
1 16 17 38
24Frame
Row
Column
18 55 3
82
3
5615
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
5857
OMFI
bits
2345678
0000000
0000001
Multi
Frame
Row
1
2
3
4
5
6
7
8
1001110
1001111
313
314
315
316
317
318
319
320
95 96 9897
1
41
1
41
2
42
2
42
39
79
39
79
40
80
40
80
41
1
41
1
42
2
42
2
79
39
79
39
80
40
80
40
1
41
1
41
2
42
2
42
79
39
79
39
80
40
80
40 F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
38
22
38
21
38
20
38
19
38
18
38
17
38
16
38
15
1
41
1
41
2
42
2
42
39
79
39
79
40
80
40
80
41
1
41
1
42
2
42
2
79
39
79
39
80
40
80
40
1
41
1
41
2
42
2
42
79
39
79
39
80
40
80
40 F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
1
41
1
41
2
42
2
42
39
79
39
79
40
80
40
80
41
1
41
1
42
2
42
2
79
39
79
39
80
40
80
40
1
41
1
41
2
42
2
42
79
39
79
39
80
40
80
40 F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
SF
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
1
41
1
41
2
42
2
42
39
79
39
79
40
80
40
80
41
1
41
1
42
2
42
2
79
39
79
39
80
40
80
40
1
41
1
41
2
42
2
42
79
39
79
39
80
40
80
40 F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
F
S
TS
O
H
TS
1
OM
FIPSI
TS
O
H
TS
2
OM
FIPSI
TS
O
H
TS
79
OM
FIPSI
TS
O
H
TS
80
OM
FIPSI
94
ODTUjk Structure
2.5G TS c r ts
ODTUjk
payload
bytes
ODTUjk
overhead
bytes
ODTU12 952 16 1 15232 1 x 4
ODTU13 238 64 1 15232 1 x 4
ODTU23 952 64 4 60928 4 x 4
1
2
3
r-1
r
1 2 3 c
-1 c
1
ts ODTUjk Payload
ODTUjk
Overhead
jk=01,12,13,23
1.25G TS c r ts
ODTUjk
payload
bytes
ODTUjk
overhead
bytes
ODTU01 1904 8 1 15232 1 × 4
ODTU12 952 32 2 30464 2 × 4
ODTU13 238 128 2 30464 2 × 4
ODTU14 952 128 8 121856 8 × 4
95
ODTU.ts Structure
1
2
3
r-1
r
1 2 3 j
x t
s -
1
j x
 ts
ts
ODTUk.ts Payload
ODTUk.ts
Overhead
k=2,3,4
j r ts ODTUk.ts payload bytes
ODTUk.ts overhead
bytes
ODTU2.ts 476 32 1 to 8 15232 × ts 1 × 6
ODTU3.ts 119 128 1 to 32 15232 × ts 1 × 6
ODTU4.ts 95 160 1 to 80 15200 × ts 1 × 6
96
SWIO
ODU2e Cross Connect
ODU4XX SWIO
SWIO
ODU-4 Cross Connect
5430 OTU4 Single Stage Multiplexing Tree (TDM Switching)
ODU421
OTU-4
ODU3 Cross Connect
Sw
itch Fabric
Li
ne
/C
lie
nt

Cross Connect Multiplexing/Demultiplexing
ODU3xx
ODU1XX
ODU0XX
ODUFXX
SWIO
SWIO
SLP SWIO
ODU2XX SWIO
ODU2 Cross Connect
ODU1 Cross Connect
ODU0 Cross Connect
ODUFlex Cross Connect
ODU2exx
Note:
Packet Termination and OTN
Switching are supported
concurrently but illustrated here
separately
97
PP
ODU3 40G Termination
ODU402 PP
PP
ODU4 100GbE Termination
5430 OTU4 Single Stage Multiplexing Tree (Packet Switching)
ODU421
OTU-4
ODU3 40GbE Termination
Sw
itch Fabric
Li
ne
/C
lie
nt

Packet Processing Multiplexing/Demultiplexing
and Mapping/Demapping
ODU302
ODU209
ODU205
ODUF05
PP
PP
SLP PP
ODU2e03 PP
ODU2e 10GbE CBR Termination
ODU2 10GbE Termination
ODU2 10G Termination
ODUFlex Termination
ODU305
100GbE
MAC
1024B/
1027B
40GbE
MAC
GFP-F
10GbE
MAC
GFP-F
GFP-F
GFP-F
Note:
Up to a maximum of 10 ODUk
terminations are supported
Packet Termination and OTN
Switching are supported
concurrently but illustrated here
separately
WAN MAC refers to a MAC with no
PCS layer
10GbE
MAC
40G
WAN MAC
10G
WAN MAC
XG
WAN MAC
98
ODU402 SWIO
PP
Transparent 100GbE
5430 100G Client Mapping Tree
100GbE
MAC
100GbE
100GbE Termination
Sw
itch Fabric
C
lie
nt

Cross Connect Mapping/Demapping
100GbE
99
ODU3XX SWIO
SWIO
ODU-3 Cross Connect
5430 OTU3 Single Stage Multiplexing Tree
ODU321
OTU3
ODU2e Cross Connect
Sw
itch Fabric
Li
ne
/C
lie
nt

Cross Connect Multiplexing/Demultiplexing
ODU2exx
ODU1XX
ODU0XX
ODUFXX
SWIO
SWIO
SLP SWIO
ODU2XX SWIO
ODU2 Cross Connect
ODU1 Cross Connect
ODU0 Cross Connect
ODUFlex Cross Connect
100
ODU3XX SWIO
SWIO
ODU-3Cross Connect
SWIO
ODU320
OTU3
ODU2 Cross Connect
ODU-1 Cross Connect
Sw
itch Fabric
C
lie
nt

Cross Connect Multiplexing/Demultiplexing
ODU220
ODU1XX SWIO
ODU1 Cross Connect
ODU2XX
ODU1XX
ODU0XX
ODUFXX
ODU221
SWIO
ODU0 Cross Connect
SWIO
ODUFlex Cross Connect
5430 OTU3 Two Stage Multiplexing Tree
101
Sw
itch Fabric
C
lie
nt
s
Cross Connect Mapping/Demapping
SWIO OTU3e2 ODU3e2
4xODU2e
SWIO ODU302/0
3
OC768/
STM256
40GbE
Transparent OC768/STM256
ODU302 SWIO
Transparent 40GbE
ODU2eXX
1024B/
1027B
5430 40G Client Mapping Tree
ODU-3Cross Connect
ODU2e Cross Connect
ODU-3Cross Connect
102
ODU2XX SWIO
ODU2 Cross Connect
OTU2
Sw
itch Fabric
Li
ne
/C
lie
nt

Cross Connect Multiplexing/Demultiplexing
SWIO
ODU1 Cross Connect ODU221 ODU1XX
ODU0XX
ODUFXX
SWIO
ODU0 Cross Connect
SWIO
ODUFlex Cross Connect
5430 OTU2 Single Stage Multiplexing Tree
103
ODU2XX SWIO
SWIO
ODU2 Cross Connect
SWIO
ODU220
OTU2
ODU1 Cross Connect
ODU0 Cross Connect Sw
itch Fabric
C
lie
nt

Cross Connect Multiplexing/Demultiplexing
ODU120
SWIO
ODU1 Cross Connect
ODU1XX
ODU0XX
ODU221 ODU1XX
ODU0XX
ODUFXX
SWIO
ODU0 Cross Connect
SWIO
ODUFlex Cross Connect
5430 OTU2 Two Stage Multiplexing Tree
104
Sw
itch Fabric
C
lie
nt
s
Cross Connect Mapping/Demapping
SWIO OTU2e ODU2exx
ODU2e Cross Connect
SWIO
SWIO
Standard 10GbE mappings to ODU2
ODU202/03 OC192/ STM-64
10GbE
GFP-F MAC
Transparent OC192/STM64
ODU2e03 SWIO
Transparent 10GbE at 11.096G
10GbE mapping to ODU2 supports standard
G.709 payload mapping, and payload + preamble
+ ordered set as defined in G.7041 (3 variants)
ODU205/09 10GbE
5430 10G Client Mapping Tree
ODU2e Cross Connect
ODU2 Cross Connect
ODU2 Cross Connect
105
ODU1XX SWIO
SWIO
ODU1 Cross Connect
ODU120
OTU1
ODU0 Cross Connect
Sw
itch Fabric
C
lie
nt

Cross Connect Mapping/Demapping
ODU0XX
ODU102/0
3 SWIO
OC-48/STM-16 Transparency OC-48/
STM16
SWIO
GbE Transparency
GbE GFP-T ODU007
5430 OTU1/2.5G Multiplexing/Mapping Tree
ODU1 Cross Connect
ODU0 Cross Connect
SWIO
Client Transparency Future
Clients
GFP-T
CBR ODU0/1xx
ODU0/1 Cross Connect
106
Multiplex Structure Identifier (MSI)
OTUk / OCh
ODUk Switch Nodes
OTUk / OCh
Independent
MSI values
Multiplexing arrangement at
each end of link must match
MSI bytes (within PSI) indicate the multiplexing arrangement of tributaries
 Must match at each end of the link for proper interoperation
 Multiplexing arrangement of each link is independent
 Arrangement allows for flexible/arbitrary assignment of ODUs to timeslots
 Interconnection between arrangements defined by cross-connection
 Tributaries assigned to arbitrary timeslots (SW controlled, eliminate BW stranding)
 Cross-connections made between tributaries (trigger timeslot assignment, Auto-MSI)
Xmt MSI Exp MSI
Exp MSI Xmt MSI
Xmt MSI Exp MSI
Exp MSI Xmt MSI
Multiplexing arrangement at
each end of link must match
107
Multiplex Structure Identifier (1 of 4)
(PT=20 (AMP): 2.5G TS ODU2/ODU3, 1.25G TS ODU1)
ODU2
MSI
1 2 3 4 5 6 7 8 2.5G
TS #
PSI[2] 00 00 0000 1
PSI[3] 00 00 0001 2
PSI[4] 00 00 0010 3
PSI[5] 00 00 0011 4
ODU3
MSI
1 2 3 4 5 6 7 8 2.5G
TS #
PSI[2] ODTU type Tributary Port # 1
PSI[3] ODTU type Tributary Port # 2
PSI[4] ODTU type Tributary Port # 3
PSI[5] ODTU type Tributary Port # 4
PSI[6] ODTU type Tributary Port # 5
PSI[7] ODTU type Tributary Port # 6
PSI[8] ODTU type Tributary Port # 7
PSI[9] ODTU type Tributary Port # 8
PSI[10] ODTU type Tributary Port # 9
PSI[11] ODTU type Tributary Port # 10
PSI[12] ODTU type Tributary Port # 11
PSI[13] ODTU type Tributary Port # 12
PSI[14] ODTU type Tributary Port # 13
PSI[15] ODTU type Tributary Port # 14
PSI[16] ODTU type Tributary Port # 15
PSI[17] ODTU type Tributary Port # 16
ODU Tributary
Type Port #
00: ODTU13 00 0000: 1
01: ODTU23 00 0001: 2
10: RES ...
11: RES 00 1111: 16
Notes: (1) ODTU23 Tributary port # = 1-4
 (2) Default ODTU type is ODTU13
ODU1
MSI
1 2 3 4 5 6 7 8 1.25G
TS #
PSI[2] 00 00 0000 1
PSI[3] 00 00 0001 2
108
Multiplex Structure Identifier (2 of 4) (PT=21 (GMP): 1.25G TS ODU2)
ODU2
MSI
1 2 3 4 5 6 7 8 1.25G
TS #
PSI[2] ODTU type Tributary Port # 1
PSI[3] ODTU type Tributary Port # 2
PSI[4] ODTU type Tributary Port # 3
PSI[5] ODTU type Tributary Port # 4
PSI[6] ODTU type Tributary Port # 5
PSI[7] ODTU type Tributary Port # 6
PSI[8] ODTU type TributaryPort # 7
PSI[9] ODTU type Tributary Port # 8
ODU Tributary
Type Port #
00: ODTU12 00 0000: 1
01: RES 00 0001: 2
10: ODTU2.ts ...
11: Unallocated 00 0111: 8
109
Multiplex Structure Identifier (3 of 4) (PT=21 (GMP): 1.25G TS ODU3)
ODU3
MSI
1 2 3 4 5 6 7 8 1.25G
TS #
PSI[2] ODTU type Tributary Port # 1
PSI[3] ODTU type Tributary Port # 2
PSI[4] ODTU type Tributary Port # 3
PSI[5] ODTU type Tributary Port # 4
PSI[6] ODTU type Tributary Port # 5
PSI[7] ODTU type Tributary Port # 6
PSI[8] ODTU type Tributary Port # 7
PSI[9] ODTU type Tributary Port # 8
PSI[10] ODTU type Tributary Port # 9
PSI[11] ODTU type Tributary Port # 10
PSI[12] ODTU type Tributary Port # 11
: : : :
PSI[30] ODTU type Tributary Port # 29
PSI[31] ODTU type Tributary Port # 30
PSI[32] ODTU type Tributary Port # 31
PSI[33] ODTU type Tributary Port # 32
ODU Tributary
Type Port #
00: ODTU13 00 0000: 1
01: ODTU23 00 0001: 2
10: ODTU3.ts ...
11: Unallocated 01 1111: 32
110
Multiplex Structure Identifier (4 of 4)
(PT=21 (GMP): 1.25G TS ODU4, only ODTU4.ts supported)
ODU4
MSI
1 2 3 4 5 6 7 8 1.25G
TS #
PSI[2] Occupation Tributary Port # 1
PSI[3] Occupation Tributary Port # 2
PSI[4] Occupation Tributary Port # 3
PSI[5] Occupation Tributary Port # 4
PSI[6] Occupation Tributary Port # 5
PSI[7] Occupation Tributary Port # 6
PSI[8] Occupation Tributary Port # 7
PSI[9] Occupation Tributary Port # 8
PSI[10] Occupation Tributary Port # 9
PSI[11] Occupation Tributary Port # 10
PSI[12] Occupation Tributary Port # 11
: : : :
PSI[78] Occupation Tributary Port # 77
PSI[79] Occupation Tributary Port # 78
PSI[80] Occupation Tributary Port # 79
PSI[81] Occupation Tributary Port # 80
TS Tributary
Occupation Port #
0: Unallocated 000 0000: 1
1: Allocated 000 0001: 2
 ...
 100 1111: 80
Protection Switching
112
OTN Automatic Protection Support
 Linear and Ring OTN Protection Architectures
 Linear protection mechanisms (G.873.1)
 All supported linear protection mechanisms are forms of Subnetwork Connection
Protection (SNCP) at the ODUk level
 ODUk SNC/N – utilizes non-intrusive monitoring (non-intrusive monitor generates
trail SF/SD to trigger protection operations for associated trail, TCM or PM)
 ODUk SNC/I – utilizes inherent monitoring (inherent server layer termination of HO
ODU layer generates server SF/SD to trigger protection operations for all associated
clients)
 ODUk SNC/S – utilizes sub-layer monitoring (TCM server layer termination
generates server SF/SD to trigger protection operations)
 1+1 unidirectional with or without reversion and 1:N bidirectional revertive switching
supported
 OTN does not support line switching (no line concept in OTN), however the
equivalent of line level operation can be provided through SNCP with sub-layer
monitoring
 Ring protection (G.873.2, work in progress)
 Automatic Protection Switch/Protection Communications Channel
overhead provided across path and tandem connection layers to support
end-to-end protection operations
113
Supported OTN Protection Architectures
G.873.1/Table 7-1 Overview of linear OTN protection architectures and related monitoring
Protection
Architecture
Switching
Type
Protection
Subclass
Entity Set
Switched
APS
Channel
Protected Entity
Server Layer
Protection
Switched Entity
Trigger Criteria
1+1 uni SNC/I Individual no one HO ODUk or one
OTUk
ODUkP ODU(/OTU?) SSF/SSD
1+1 bi SNC/I individual 111 one OTUk ODUkP ODU SSF/SSD
1:n bi SNC/I individual 111 one OTUk ODUkP ODU SSF/SSD
1+1 uni SNC/N individual no one or more HO ODUk
and/or OTUk
ODUkP ODU TSF/TSD
1+1 uni SNC/S individual no one or more HO ODUk
and/or OTUk
ODUkT (/P?) ODUkT(/OTUk?)
SSF/SSD
1+1 bi SNC/S individual 001-110 one or more HO ODUk
and/or OTUk
ODUkT (/P?) ODUkT(/OTUk?)
SSF/SSD
1:n bi SNC/S individual 001-110 one or more HO ODUk
and/or OTUk
ODUkT (/P?) ODUkT(/OTUk?)
SSF/SSD
1+1 uni CL-SNCG/I group no one HO ODUk LO ODU HO ODUkP SSF/SSD
and HO ODUdPLM
1+1 bi CL-SNCG/I group HO 000 one HO ODUk LO ODU HO ODUkP SSF/SSD
and HO ODUdPLM
1:1 bi CL-SNCG/I group HO 000 one HO ODUk LO ODU HO ODUkP SSF/SSD
and HO ODUdPLM
Note 1 - bidir LO ODU SNC/I can not be supported over HO ODUk; reason is that there is only one HO ODUk Path APS channel and there are many
LO ODUk signals. No sharing of one APS channel by multiple protection switching instances is defined.
Note 2 - Bidir SNC/N, is not supported because it requires the transport of an APS signal between the Headend and the Tail end. This APS signal is to
be inserted on the ODUk signal which may contain AIS OCI or LCK signal. This ODUk AIS/OCI/LCK signal with APS cannot be distinguished from a
ODUk AIS/OCI/LCK signal without APS inserted at an intermediate point of the protection connection at the Tail-end. It is recommended to use 1+1
Bidir SNC/S instead.
Note 3 - CL-SNCG/I can assign all Normal signal to the Na subgroup and leave the Nb subgroup empty.
Case 1
Case 2
Case 3
Case 4
Case 5
Case 6
Case 7
Case 8
Case 9
Case 10
Other issues: No bidirectional or 1:N SNC/N, no CL-SNCG/S (nearest equivalent to Line APS)
114
SNC/I and CL-SNCG/I Protection Configurations (cases 1-2, 8-10)
Monitoring occurs at
server layer of the layer
cross-connected
(protection group rate !=
cross-connect rate)
For bidirectional SNC/I, Working and
Protection transport entities must be
at the same rate (OTUk),
Other forms may be different rates
For SNC/I, a single entity is
switched per protection group
For CL-SNCG/I multiple LO
entities are switched
Defects outside the Protected
domain have no effect on
protection switching operations
115
1+1 SNC/N Protection Configuration (case 4)
E E
Working transport entity
Protection transport entity
Protected domain
CI
CI
CI
CI
AI AI
Working transport entity
Protection transport entity
Protected domain
CI
CI
CI
CI
AI AI E ECI
Defects outside
protection domain
may cause false
switching
(not recommended,
use SNC/S)
Monitoring occurs at same
layer as cross-connections
(protection group rate =
cross-connect rate)
Working and
Protection transport
entities may be
carried across any
HO facilities
116
SNC/S Protection Configurations (cases 5-7)
Monitoring occurs at same
layer as cross-connections
(protection group rate =
cross-connect rate)
Working and
Protection transport
entities may be
carried across any
HO facilities
Defects outside
protection domain do
not affect protection
switching operation
117
OTN APS Channel Assignment
 The OTN standard provides 8 individual APS/PCC Channels in the ODU
overhead.
 Each channel is identified with a particular protection layer in the network. The
channel assignments are shown in the table below from G.709.
118
OTN APS Channel Protocol
 The OTN linear protection standard uses a similar APS Signaling Protocol to
SONET/SDH APS including;
 Switch Requests/States
 Protection Types
 Requested Signal
 Bridged Signal
 The transmission and acceptance of the APS Signaling is on a individual channel
basis (TCMs and PM channels).
 All SONET/SDH Manual Switch Requests are supported for OTN.
 Manual Switch
 Forced Switch
 Lockout of Protection
 Ring protection is being based on existing SONET/SDH ring protection functions
119
APS Channel Format
Request/State field values
 Lockout of Protection (1111), Forced Switch (1110), Signal Fail (1100), Signal
Degrade (1010), Manual Switch (1000), Wait-To-Restore (0110), Exercise (0100),
Reverse Request (0010), Do Not Revert (0001), No Request (0000), others reserved
Protection Type field values
 APS Channel (A): No APS Channel (0), APS Channel (1)
 Permanent Bridge (B): 1+1 (0), 1:N (1)
 Direction (D): Unidirectional (0), Bidirectional (1)
 Revertive(R): Non-revertive (0), Revertive (1)
Requested Signal field values
 Null Signal (0), Normal Traffic Signal (1-254), Extra Traffic Signal (255)
Bridged Signal field values
 Null Signal (0), Normal Traffic Signal (1-254), Extra Traffic Signal (255)
1 2 3 4
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
Request/
state
Protection
type
Requested Signal Bridged Signal Reserved
A B D R
OTN Client Mappings
121
Client Signal Mapping Methods
Mapping methods provide a means for rate adapting a client signal into a server
layer container (ODUj or ODUflex)
 Three methods: Asynchronous Mapping Procedure (AMP), Bit-synchronous Mapping
Procedure (BMP) and Generic Mapping Procedure (GMP)
 Mapping may also utilize client signal transcoding (e.g., GFP, 1024B/1027B, etc)

Bit-synchronous Mapping Procedure (server rate synchronous to client rate)
 Bit synchronously maps client signal into server layer payload area

Asynchronous Mapping Procedure (client and server rates asynchronous)
 Monitors client rate relative to server rate (derived from local oscillator) and performs stuffing
operations once per lower rate container frame (negative and positive justification operations)
 Signals stuffing operations through justification control bits to far end (demux)

Generic Mapping Procedure (client and server rates synchronous or asynchronous)
 Monitors client rate relative to server rate, adjusts number of bytes sent per server frame, and
distributes bytes evenly throughout server frame
 Signals bytes (and residual bits) per frame via Cm and CnD control bits to far end (demux)
122
GbE Timing Transparent Transcoding (TTT) Mapping (GFP-T)
 GFP-T mapping of GbE LAN PHY into OPU0 per G.7041 and
G.709 using timing transparent transcoding
 Apply GFP-T encapsulation of Ethernet data (full data stream including
the Preamble, SFD and Inter Frame Gap (IFG)) per G.709 clause 17.7.1.1
and G.7041 clause 8 (and applicable sub-clauses)
 Synchronously encode data stream into 75-byte GFP-T frames using 64B/65B
encoding without 65B Pad characters operating at 15/16 times incoming GbE
clock rate
 GFP payload FCS not supported
 Ignore (do not modify) Ethernet FCS
 Map GFP-T frames into OPU2 using Generic Mapping Procedure (GMP)
per G.709 clause 17.7.1

123
GbE GFP-T Mapping
OTN
 OPU0 Payload Clock Rate: 1.239Gbps
 OPU Payload Area: Row 1, 2, 3, 4 / Column 17 – 3824
 PSI/PT Assignment: 0x05 (GFP)
GFP-T Header Assignments
 Core Header: Byte 1 - 4
 Payload Header Byte 5 - 8
 PTI 000
 PFI 0
 EXI 0000
 UPI 0x06
 tHEC per G.7041
Client Management Frame (CSF, LF, RF) GFP Header Byte Assignments
 Core Header: Byte 1 - 4
 Payload Header Byte 5 – 8
 PTI 100
 PFI 0
 EXI 0000
 UPI 0x01 (Ethernet Ordered Set: LOS)
 0x02 (Ethernet Ordered Set: LOCS)
 tHEC per G.7041

124
10GbE LAN GFP-F Mapping – MAC Frames Only
 GFP-F mapping of 10GbE LAN PHY into OPU2 per G.7041
and G.709
 Terminate 64/66B (PCS layer) line code
 Apply GFP framing to Ethernet data (without the Preamble, SFD and Inter
Frame Gap (IFG)) per G.7041 clause 7.1
 GFP-F payload FCS not support
 Ignore (do not modify) Ethernet FCS
 Discard incoming Ethernet frames based on invalid Ethernet FCS
 Map Ethernet LF and RF into GFP Client Management Frames per
G.7041 clause 6.1.3.2
 Map GFP frame into OPU2 per G.709 clause 17.4

125
10GbE LAN GFP-F Mapping – MAC Frames Only Details
OTN
 OTN Clock Rate: 10.7Gbps
 OPU Payload Area: Row 1, 2, 3, 4 / Column 17 – 3824
 PSI/PT Assignment: 0x05 (GFP)
GFP Header Assignments
 Core Header: Byte 1 - 4
 Payload Header Byte 5 - 8
 PTI 000
 PFI 0
 EXI 0000
 UPI 0x01 (Frame-mapped Ethernet)
 tHEC per G.7041
Client Management Frame (CSF, LF, RF) GFP Header Byte Assignments
 Core Header: Byte 1 - 4
 Payload Header Byte 5 – 8
 PTI 100
 PFI 0
 EXI 0000
 UPI 0x01 (Ethernet Ordered Set: LOS)
 0x02 (Ethernet Ordered Set: LOCS)
 0x03 (Ethernet Ordered Set: Clear)
 0x04 (Ethernet Ordered Set: LF)
 0x05 (Ethernet Ordered Set: RF)
 tHEC per G.7041
126
10GbE LAN GFP-F Mapping – MAC Frames + Preamble
(Ordered Sets via Client Management Frames)
 GFP-F mapping of 10GbE LAN PHY into OPU2 per G.7041
and G.709
 Terminate 64/66B (PCS layer) line code
 Apply GFP framing to Ethernet data (without the Preamble, SFD and Inter
Frame Gap (IFG)) per G.7041 clause 7.9 (except clause 7.9.2.2)
 GFP-F payload FCS not support
 Ignore (do not modify) Ethernet FCS
 Discard incoming Ethernet frames based on invalid Ethernet FCS
 Map Ethernet LF and RF into GFP Client Management Frames per
G.7041 clause 6.1.3.2
 Map GFP frame into OPU2 using 7 OPU2 overhead bytes for data
mapping per G.709 clause 17.4.1

127
10GbE LAN GFP-F Mapping – MAC Frames + Preamble Details
(Ordered Sets via Client Management Frames)
OTN
 OTN Clock Rate: 10.7Gbps
 OPU Payload Area: Row 1, 2, 3, 4 / Column 17 – 3824
 PSI/PT Assignment: 0x09 (GFP into Extended OPU2)
GFP Header Assignments
 Core Header: Byte 1 - 4
 Payload Header Byte 5 - 8
 PTI 000
 PFI 0
 EXI 0000
 UPI 0x13 (Frame-mapped 64B/66B encoded Ethernet w/Preamble)
 tHEC per G.7041
Client Management Frame (CSF, LF, RF) GFP Header Byte Assignments
 Core Header: Byte 1 - 4
 Payload Header Byte 5 – 8
 PTI 100
 PFI 0
 EXI 0000
 UPI 0x01 (Ethernet Ordered Set: LOS)
 0x02 (Ethernet Ordered Set: LOCS)
 0x03 (Ethernet Ordered Set: Clear)
 0x04 (Ethernet Ordered Set: LF)
 0x05 (Ethernet Ordered Set: RF)
 tHEC per G.7041
128
10GbE LAN GFP-F Mapping – MAC Frames + Preamble
(Ordered Sets via Client Data Frames)
 GFP-F mapping of 10G LAN PHY into OPU2 plus RES Bytes
 Terminate 64/66B (PCS layer) line code
 Apply GFP framing to Ethernet data (with Preamble) per G.7041 clause 7.9
 GFP-F payload FCS not supported
 Ignore Ethernet FCS
 Discard incoming Ethernet frames based on invalid Ethernet FCS
 Map Ethernet LF and RF into GFP Client Data Frames per G.7041 clause 7.9.2.2
 Map GFP frame into OPU2 using 7 OPU2 overhead bytes for data mapping per
G.709 clause 17.4.1

129
10GbE LAN GFP-F Mapping – MAC + Preamble Frames Details
(Ordered Sets via Client Data Frames)
OTN
 OTN Clock Rate: 10.7Gbps
 OPU Payload Area: Row 1, 2, 3, 4 / Column 17 – 3824
 Add’l OPU Payload Area: Row 1, 2, 3 / Column 15 – 16, Row 4 / Column 16
 PSI/PT Assignment: 0x09 (GFP into Extended OPU2)
Ethernet Data Frame GFP Payload Mapping
 Core Header: Byte 1 – 4
 Payload Header Byte 5 - 8
 PTI 000
 PFI 0
 EXI 0000
 UPI 0x13 (Frame-mapped 64B/66B encoded Ethernet w/Preamble)
 tHEC per G.7041
Ordered Set (LF, RF) Data Frame GFP Mapping
 Core Header: Byte 1 - 4
 Payload Header Byte 5 – 8
 PTI 000
 PFI 0
 EXI 0000
 UPI 0x14 (Frame-mapped 64B/66B encoded Ethernet ordered sets)
 tHEC per G.7041

130
10GbE LAN Transparent Mapping Details
 Operate OTU2 at 11.09Gbps and map 10GbE PCS layer
into OPU2 payload per G.709 clauses 17.2 and 17.2.4
 Maintain 64 Fixed Stuffing bytes
 Maintain Ethernet PCS layer Bit transparency
 OTU2 line rate is non-standard

OTN OTU2 Payload Frame Byte Allocation and PSI/PT
Assignment
 OTN Clock: 11.096G ± 100ppm
 OPU Payload Area: Row 1, 2, 3, 4 / Column 17 – 1904
 & 1921 – 3824
 PSI/PT Assignment: 0x03 (bit-synchronous)

131
Bit-synchronous Mapping of OC-192
 Operate OTU2 at 10.7Gbps and bit-synchronously map OC-
192 into OPU2 payload per G.709 clauses 17.2 and 17.2.2
 Maintain 64 Fixed Stuffing bytes
 OTU2 line interface running on local clock

OTN OTU2 Payload Frame Byte Allocation and PSI/PT
Assignment
 OTN Clock: 10.709G ± 20ppm
 OPU PayloadArea: Row 1, 2, 3, 4 / Column 17 – 1904
 & 1921 – 3824
 PSI/PT Assignment: 0x02 (asynchronous)
 0x03 (bit-synchronous)

Note: Although the OC-192 mapping is always performed in a bit-synchronous manner,
5430 supports bit-synchronous and asynchronous demapping, and therefore allows the PT
value to be set to either 0x02 (asynchronous) or 0x03 (bit-synchronous) mapping in order to
support vendor interoperability
Other 5430 OTN Capabilities
133
Other 5430 OTN Capabilities

Connection Provisioning and Restoration
 Control plane based setup and restoration of OTN connections
 Mesh Restorable OTN SNCs with high and low priority service class
 OTN SNCP with Mesh Restoration
 Unprotected SNCs
 Exclusive and Preferred Designated Transit list routing for home and protection
routes
 Cost based routing and latency based routing
 Shared Risk Link Groups (SRLG) – up to 20 Bundle IDs per Link
OTN Maintenance
 Test Access, Remote Test Access
 Port level equipment and facility loopbacks
 Connection level loopbacks
134
5430 OTN ODUflex Hitless Circuit Resizing (future)
OTN Circuit Resizing being defined as part of ITU G.7044/Y.1347
(formerly G.hao)
 Standard being developed for ODUflex (GFP) resizing
 Significant effort still required (e.g., affect on control plane operation)
Designed to be “Hitless” for increases and decreases
 “Red” / LCR (Link Connection Resize) protocol is used to increase/decrease the
timeslots of the ODUflex between two adjacent nodes
 “Blue” / BWR (Bandwidth Resize) protocol is used to change the signal itself within
the set of timeslots from end to end
 Fabric connection resizing is vendor specific
ODU Link ODU Link
OPUx TS4 and TS5 exist
Add TS9
OPUx TS4 and TS7 exist
Add TS11
Add/Remove Timeslots Add/Remove Timeslots
Increase/Decrease underlying signal itself
10GbE
10GbE
Increase
client rate
from 4G to
6G
135
ODUflex Resizing Overhead
Resizing overhead provided in OPU overhead during resizing operation
- HO OPUk Tributary Slot Overhead (TSOH) of added/removed timeslots used for LCR (“Red”) and BWR
(“Blue”) protocol functions (all added/removed timeslots carry identical resizing overhead values)
- OPUflex OH used for BWR (“Blue”) protocol functions
136
LCR (“Red”) Protocol Fields and Functions
Tributary Port Identifier (TPID) Field
- Identifies tributary port ID to/from which tributaries slots are to be added/removed
- Encodes row 1 bits 4-8 and row 2 bits 7&8 as a single 7-bit tributary port ID




Control (CTRL) Field
- Used to transfer LCR protocol operation indication from source end to sink end
- Carried in row 2 bits 5&6







Tributary Slot Group Status (TSGS) Field
- Link connection acknowledgement indication sent by HO OPU sink to acknowledge tributary slot
match
- Carried in row 2 bit 4, ACK=1, NACK=0
21
7 8
TPID Field Bit Number
4 5 6 7 8
6 71 2 3 4 5
HO OPUk TSOH Row #
HO OPUk TSOH Col #
Value Command Comments
00
01
10
11
IDLE
ADD
REMOVE
NORM
Indication that the node has completed LCR and there is no new LCR
operation
Indication that the Tributary Slot is to be added to the ODUflex
Connection
Indication that the Tributary Slot is to be removed from the ODUflex
Connection
Indication that LCR will be started at the next resize multiframe
boundary when sending out NORM command after ADD or REMOVE
command at the resize multiframe boundary
Resizing CTRL Words
137
BWR (“Blue”) Protocol Fields and Functions
Tributary Slot Connectivity Check (TSCC) Field
- Used to check the connectivity of the link connection and the ODUflex connection
- Carried in row 2 bit 1 of the HO OPUk TSOH
- TSCC=0: initial value, also used by the source to indicate the completion of bandwidth resizing and
exit from GMP special mode in the source to sink direction, triggers the exit of GMP special mode at
intermediate nodes and the sink node, and is only forwarded by intermediate nodes after exit from
GMP special mode
- TSCC=1: confirms GMP special mode at intermediate nodes during the resizing period and signals
to the sink node that all nodes in the source to sink direction are ready to support bandwidth resizing
Resizing Protocol Indicator (RP) Field
- Indicates whether resizing protocol is being carried in RCOH bytes
- Carried in row 2 bit 4 of HO OPUk TSOH
- RP=0: initial value, set by source to indicate all resizing operations have been exited and causes the
termination of TSCC information relay and all other resizing operations at intermediate nodes in the
source to sink direction, forwarded by intermediate nodes after they exit GMP special mode and
terminate nay LCR processing, when received by sink it confirms exit from resizing protocol by the
source and all intermediate nodes and reports completion to the management or control plane
- RP=1: set by management plane or control plane to indicate the start of the resizing operation
138
BWR (“Blue”) Protocol Fields and Functions (cont’d)
Network Connectivity Status (NCS) Field
- Used for end-to-end network connection acknowledgement (passed transparently through
intermediate nodes)
- Carried in row 2 bit 2 of OPUflex overhead
- NCS=0: initial value, also used by sink to acknowledge completion of bandwidth resizing
- NCS=1: sent by sink when received TSCC=1 to acknowledge path resize preparation completion
Bandwidth Resizing Indicator (BWR_IND) Field
- Indicates whether the ODUflex source is adjusting the bit rate of the ODUflex signal; signals the start
and end of rate adjustment ramp
- Carried in bit 1 of rows 1 and 2 of OPUflex overhead
- BWR_IND=0 (detected at receiver when both bits set to 0, or either set to 0 and CRC-3 indicates
BWR_IND=0 and NCS=1): initial value, set indicate ODUflex rate adjustment is not active; transition
from 1 to 0 indicates the ODUflex source will stop rate adjustment ramping within Y μs (Y is in the
range of 125-250)
- BWR_IND=1 (detected at receiver when both bits set to 1, or either bit is set to 0 and CRC-3
indicates BWR_IND=0 and NCS=1): set to indicate the start of ODUflex rate adjustment ramping will
begin within X μs (X is close to Y and is in the range of 125-250)
139
Error Resiliency Overhead (CRC-3 and CRC-5)
CRC-5 used to perform error checking
on LCR protocol overhead
- Uses x5 + x + 1 generator polynomial
- Contents rejected if CRC check fails







CRC-3 used to perform error checking
on BWR protocol overhead
- Uses x3 + x2 + 1 generator polynomial
- Contents rejected if CRC check fails
Mapping
OH Bits
CRC Checksum Bits
RCOH1 bit 4
crc1 crc2 crc3 crc4 crc5
RCOH1 bit 5
RCOH1 bit 6
RCOH1 bit 7
RCOH1 bit 8
RCOH2 bit 4
RCOH2 bit 5
RCOH2 bit 6
RCOH2 bit 7
RCOH2 bit 8
X XX
X X X
X X
X X
X X
X XX
X X
X X
X X
X X
X indicates a mapping OH bit used in the EXOR equation of the associated CRC bit
Mapping
OH Bits
CRC Checksum Bits
RCOH1 bit 1
crc1 crc2 crc3
RCOH1 bit 2
RCOH1 bit 3
RCOH2 bit 1
RCOH2 bit 2
RCOH2 bit 3
X
X
X
X X
X
X X
X X
X indicates a mapping OH bit used in the EXOR equation of the associated CRC bit
X
140
Resizing Protocols
ODUkP/ODUj-21 ODUkP/ODUj-21ODUkP/ODUj-21ODUkP/ODUj-21
A1 B1 B2 C1
ODUfP/PKT ODUfP/PKT
BWR_Generator
BWR_Generator_Relay
LCR_Generator
BWR_Receiver
RP TSCC
LCR_Receiver
LCR_Receiver
BWR_Generator
BWR_Receiver
BWR_Receiver_Relay
LCR_Generator
BWR_Generator_Relay
RP TSCC
RP TSCC
A1 C1
NCS
NCS
BWR_Receiver_Relay
B1
LCR_Generator
BWR_Generator_Relay
LCR_Receiver
BWR_Receiver_Relay
RP TSCCBWR_Receiver_Relay
BWR_Generator_Relay
LCR_Receiver
LCR_Generator
RP TSCC
RP CTRL TPID TSGS
 RP CTRL TPID TSGS
RP TSCC
RP TSCC
 RP CTRL TPID TSGS
 RP CTRL TPID TSGS
 RP CTRL TPID TSGS RP CTRL TPID TSGS RP CTRL TPID TSGS
RP TSCC
 RP CTRL TPID TSGS
ODUfP/PCK
ODUkP/ODUj-21 ODUkP/ODUj-21 ODUkP/ODUj-21 ODUkP/ODUj-21
ODUfP/PCKRP TSCC
NCS
RP TSCC
NCS
 LCR protocol operates between ODUkP/ODUj-21 adaptation source and sink functions of
adjacent nodes (mux/demux functions)
 BWR protocol operates between ODUkP/ODUj-21 adaptation source and sink functions of
adjacent nodes (BWR relay functions) and between ODUfP/PCK adaptation source and sink
functions of end-to-end source and sink nodes (packet mapping functions)
141
Resize Procedure – Bandwidth Increase
1. Management or control plane issues a bandwidth increase (ADD) command to add M timeslots to each
connection and timeslot availability is verified
2. Each nodes starts LCR and BWR protocols: each ODUkP/ODUj-21 source issues RP=1, TSCC=0, and an LCR
ADD command (CTRL=ADD, TPID=TP#, TSGS=NACK); each ODUfP/PCK source issues NCS=NACK
3. Each ODUkP/ODUj-21 sink checks received set of added timeslots against provisioned set and if they match
sends ACK (CTRL=ADD, TPID=TP#, TSGS=ACK)
4. When ODUkP/ODUj-21 sink receives an ACK and source has sent an ACK, link resize process is entered on the
next multiframe boundary by sending NORM command (CTRL=NORM, TPID=TP#, TSGS=ACK) and link resize
occurs one multiframe later (Cm  Cm x N/(N+M), link resize results in step change of Cm)
5. After completion of link resizing in both direction (and for an intermediate node, on both sides), fabric resizing
(method TBD) is performed (for TDM fabric may require increase in XC timeslots filled with backplane idles)
6. Once fabric resizing is completed the link resizing process is exited, GMP special mode is entered, and an IDLE
command (CTRL=IDLE, TPID=TP#, TSGS=NACK) is sent by each ODUkP/ODUj-21 source; in addition, a source
node begins sending TSCC=1 and intermediate nodes begin relaying the incoming TSCC value
7. Once the sink node receives TSCC=1 which is forwarded to the associated ODUfP/PCK sink, the corresponding
ODUfP/PCK source issues NCS=ACK
8. Once the ODUfP/PCK function at a node has sent and received NCS=ACK, the bandwidth resizing process is
entered and the value of Cm is gradually increased to its final stable value (Cm x N/(N+M)  Cm); the fabric cross-
connection must adapt dynamically to the gradual increase in Cm (may require XC timeslots to gradually
decrease idle fill)
9. Once bandwidth resizing is complete the source node sends TSCC=0 signaling completion and enters GMP
normal mode; intermediate nodes enter GMP normal mode and relay the incoming TSCC value; the sink node
enters GMP normal mode and issues NCS=NACK
10. When the source node receives NCS=NACK it sends RP=0 and exits the resizing protocol; intermediate nodes
receive RP=0, exit the resizing protocol and send RP=0; the sink node receives RP=0, exits resizing and reports
the resizing completion to the management or control plane

142
Resize Procedure – Bandwidth Decrease
1. Management or control plane issues a bandwidth decrease (REMOVE) command to remove M timeslots from
each connection and timeslot availability is verified
2. Each nodes starts LCR and BWR protocols: each ODUkP/ODUj-21 source issues RP=1, TSCC=0, and an LCR
REMOVE command (CTRL=REMOVE, TPID=TP#, TSGS=NACK); each ODUfP/PCK source issues NCS=NACK
3. Each ODUkP/ODUj-21 sink checks received set of removed timeslots against provisioned set and if they match
sets the GMP processor to special mode, pauses the LCR protocol and runs the BWR protocol in that direction
4. After entering GMP special mode, the source node begins sending TSCC=1; intermediate nodes begin relaying
the TSCC value once GMP special mode has been entered in that direction; when TSCC=1 reaches the sink
node it enters GMP special mode and sends NCS=ACK
5. Once the end node receives TSCC=1 and NCS=ACK and has sent NCS=ACK in response to receiving TSCC=1,
the bandwidth resizing process is entered at the next multiframe boundary and Cm is gradually decreased to its
final stable value (Cm  Cm x N/(N-M), for TDM fabric may require increasing backplane XC timeslot idle fill)
6. Once bandwidth resizing is complete the source node sends TSCC=0 signaling completion and enters GMP
normal mode; intermediate nodes enter GMP normal mode and relay the incoming TSCC value; the sink node
enters GMP normal mode and issues NCS=NACK completing the bandwidth resizing; after entering normal
mode in one direction, node sends TSGS=ACK in opposite direction
7. After sending and receiving TSGS=ACK on both sides of the node, fabric resizing (method TBD) is performed
(for TDM fabric may require decrease in XC timeslots)
8. Once fabric resizing is completed the link resizing process is entered on the next multiframe boundary by
sending NORM command (CTRL=NORM, TPID=TP#, TSGS=ACK) and link resize occurs one multiframe later;
link resize results in step change of Cm x N/(N-M)  Cm)
9. After completing link resize process and receiving a NORM command the node exists the LCR protocol by
sending an IDLE command (CTRL=IDLE, TPID=TP#, TSGS=NACK) at the next multiframe boundary
10. Once the source node has sent and received NCS=ACK and the LCR protocol finishes, it sends RP=0; an
intermediate node relays RP=0 after it finishes the LCR protocol; once the sink node has sent and received
RP=0, it reports the resize completion status to the management or control plane
Q & A
	OTN Tutorial
	Agenda
	OTN Introduction
	Motivation for OTN - The Original DWDM Problem
	Motivation for OTN - The OTN Solution
	OTN Layers
	Three Architectural Options for OTN
	OTN Layer Descriptions – Optical Layers
	OTN Layer Descriptions – Digital Layers
	OTN Frame Structure – Electrical Layers
	OTN Layers – End-to-End
	Optical Transport Module (OTM) - Interface
	Single Channel Interfaces – OTM-0.m
	Multi-Channel Interfaces – OTM-0.mvn, OTM-nr.m, OTM-n.m
	OTN IrDI Application Codes
	CWDM Application Codes
	Intra-office Application Codes
	OTN Bitrates
	ODUFlex (2011 Update)
	Potential ODUflex (CBR) Client Rates
	Differences between SONET/SDH & OTN
	Standards and References
	OTN Overhead Functions
	OTN Overhead – Optical Layers
	OTN Overhead Functions – Electrical Layers
	OTN Frame Structure – Electrical Layers
	Forward Error Correction (FEC)
	Reed-Solomon FEC RS (255/239)
	OTN Overhead Details – Electrical Layers
	Overhead Descriptions – Alignment
	OTN Framing
	OTN Signal Regeneration Model
	IAE and BIAE Processing (OTUk/section or ODUkT/path)
	Path and Tandem Connection Monitoring (PM & TCM)
	Tandem Connection Monitoring Modes
	Tandem Connection Visibility
	Tandem Connection Shadow
	SNCP and TCM
	5430 TCM Usage
	Overhead Descriptions – Connectivity and Continuity
	Trail Trace Identifier Format
	SAPI and DAPI Applications
	Overhead Descriptions – Signal Quality
	BIP-8 Generation
	BIP-8 Error Detection and BEI Generation
	TCM Latency Measurement
	5430 Latency Based Routing
	Overhead Descriptions – Maintenance Signals
	OTN Overhead Signal Interactions
	Mapping Overhead
	Control of OTN Timing
	Bit-synchronous Mapping
	Bit-synchronous Mapping Procedure
	Asynchronous Mapping
	Asynchronous Mapping Procedure – Fast Client
	Asynchronous Mapping Procedure – Slow Client
	Generic Mapping Procedure (GMP)
	OTN and OTN Client Signal Fault Propagation
	Fault Propagation Example – Bidirectional Fiber Cut
	Fault Propagation Example – Deleted Cross-Connection
	Fault Propagation Example – TCM4 Maintenance LCK
	Fault Propagation Example – TCM3 Maintenance LCK
	Fault Propagation Example – PM Maintenance LCK
	5430 GbE OTN Fault Handling (GFP-T Mapped):�LOS, LOF, LOM, AIS, OCI, LCK, PLM
	5430 GbE Client Fault Handling (GFP-T Mapped):�Client Faults - LOS, Loss-of-character-sync (LOCS)
	5430 GbE Client Fault Handling (GFP-T Mapped):�Link Fault or Auto-negotiation
	5430 GbE Error Handling (GFP-T Mapped)
	5430 10GbE OTN Fault Handling (GFP-Mapped):�LOS, LOF, LOM, AIS, OCI, LCK, PLM
	5430 10GbE Client Fault Handling (GFP-mapped):�Client Faults - LOS, Loss-of-block-sync (LOCS)
	5430 10GbE Client Fault Handling: Local Fault
	5430 10GbE Client Fault Handling: Remote Fault
	543010GbE Error Handling
	5430 SONET/SDH/CBR OTN Fault Handling:�LOS, LOF, LOM, AIS, OCI, LCK, PLM
	5430 SONET/SDH/CBR Client Fault Handling: LOS, LOF
	5430 SONET/SDH/CBR Client Fault Handling: AIS-L/MS-AIS
	5430 SONET/SDH/CBR Error Handling
	OTN Performance Monitoring
	OTN Performance Monitoring Basics
	Additional 5430 OTN Performance Monitoring Parameters
	OTN Multiplexing and Mapping Trees
	OTN Optical Multiplexing Structure
	Pre-2009 OTN Multiplexing Structure with SONET Mapping
	Post-2009 OTN Multiplexing Structure
	OTN Electrical Multiplexing Structure (1 of 2)
	OTN Electrical Multiplexing Structure (2 of 2)
	Single Stage (Flat) vs. Multi-Stage (Step) Multiplexing
	HO ODUk Timeslot Rate Differences
	Auto-Payload Type Function
	ODTU Mapping Methods
	OPU1 Tributary Slots
	OPU2 Tributary Slots
	OPU3 Tributary Slots
	OPU4 Tributary Slots
	ODTUjk Structure
	ODTU.ts Structure
	Slide Number 96
	Slide Number 97
	Slide Number 98
	Slide Number 99
	Slide Number 100
	Slide Number 101
	Slide Number 102
	Slide Number 103
	Slide Number 104
	Slide Number 105
	Multiplex Structure Identifier (MSI)
	Multiplex Structure Identifier (1 of 4)�(PT=20 (AMP): 2.5G TS ODU2/ODU3, 1.25G TS ODU1)
	Multiplex Structure Identifier (2 of 4) (PT=21 (GMP): 1.25G TS ODU2)
	Multiplex Structure Identifier (3 of 4) (PT=21 (GMP): 1.25G TS ODU3)
	Multiplex Structure Identifier (4 of 4)�(PT=21 (GMP): 1.25G TS ODU4, only ODTU4.ts supported)
	Protection Switching
	OTN Automatic Protection Support
	Supported OTN Protection Architectures
	SNC/I and CL-SNCG/I Protection Configurations (cases 1-2, 8-10)
	1+1 SNC/N Protection Configuration (case 4)
	SNC/S Protection Configurations (cases 5-7)
	OTN APS Channel Assignment
	OTN APS Channel Protocol
	APS Channel Format
	OTN Client Mappings
	Client Signal Mapping Methods
	GbE Timing Transparent Transcoding (TTT) Mapping (GFP-T)
	GbE GFP-T Mapping
	10GbE LAN GFP-F Mapping – MAC Frames Only
	10GbE LAN GFP-F Mapping – MAC Frames Only Details
	10GbE LAN GFP-F Mapping – MAC Frames + Preamble �(Ordered Sets via Client Management Frames)
	10GbE LAN GFP-F Mapping – MAC Frames + Preamble Details �(Ordered Sets via Client Management Frames)
	10GbE LAN GFP-F Mapping – MAC Frames + Preamble�(Ordered Sets via Client Data Frames)
	10GbE LAN GFP-F Mapping – MAC + Preamble Frames Details�(Ordered Sets via Client Data Frames)
	10GbE LAN Transparent Mapping Details
	Bit-synchronous Mapping of OC-192
	Other 5430 OTN Capabilities
	Other 5430 OTN Capabilities�
	5430 OTN ODUflex Hitless Circuit Resizing (future)
	ODUflex Resizing Overhead
	LCR (“Red”) Protocol Fields and Functions
	BWR (“Blue”) Protocol Fields and Functions
	BWR (“Blue”) Protocol Fields and Functions (cont’d)
	Error Resiliency Overhead (CRC-3 and CRC-5)
	Resizing Protocols
	Resize Procedure – Bandwidth Increase
	Resize Procedure – Bandwidth Decrease
	Q & A
