ization • Jean-Pierre Corriou and Jean-Claude Assaf
Chemical Process
Design, Simulation
and Optimization
Printed Edition of the Special Issue Published in Processes
www.mdpi.com/journal/processes
Jean-Pierre Corriou and Jean-Claude Assaf
Edited by
