394
PROBLEM 12.60 (Continued)

(b) Assume that the block is at rest with respect to the plate.
 : nm mΣ = + =F a W R a
 From Part a (above), it then follows that

2
2 298
3
32.2 ft/s
tan ( 50 )
( ) (13 5sin 40 ) ft/sABCD
gφ
ρ φ
− ° = =
− °
 or 50 5.752φ − ° = °
 and 55.752φ = °
 Now 19.29sφ = °
 so that sφ φ>
 The block will slide in the slot and then
 ,φ φ= k where tan 0.25k k kφ μ μ= =
 or 14.0362kφ = °
 To determine in which direction the block will slide, consider the free-body diagrams for the two
possible cases.

 Now /plate: n Em m mΣ = + = +F a W R a a
 From the diagrams it can be concluded that this equation can be satisfied only if the block is sliding
downward. Then

2
: cos 40 cos sin 40E
x x k
v
F ma W R mφ
ρ
Σ = ° + = °
 Now sin kF R φ=
 Then
2
cos 40 sin 40
tan
E
k
vF W
W
gφ ρ
° + = °
 or
2
cos40 sin 40E
k
v
F W
g
μ
ρ
 
= − ° + °  
 

 1.123 lb= (see the first solution)
 The block slides downward in the slot and 1.123 lb=F 40° 
