UVT610V Series Processing Guidelines



Release Date: 24 June 2013
Page 1 of 3

PROCESS STEP CONDITION/PARAMETER
Room Environment Class 10,000 or better
Temperature: 25 ± 5°C Relative Humidity 45 – 65%
All wetted surfaces must be stainless steel or solvent resistant plastic.
Lens Cleaning Method Ensure parts are clean and free of dirt/contamination and static charge.
If needed IPA wipe with Clean Room Wipes (>Class 10) can be used.
Coating Application Class 1000 or better.
Spray (conventional or HVLP) or flowcoat are the recommended application methods
A reclaim, dry filter, or water wash booth can be used for spray applications.
It is important to use a coating robot for spraying, repeatability and safety.
A drip pan, knife blade, or curtain weir may be used for flowcoat applications.
Control of the coating properties for flowcoating should be accomplished by adjusting one of the
following:
 Solids of the coating
 Both specific gravity and temperature of the coating
 Viscosity and temperature of the coating
A chart showing specific gravity versus temperature data at various solids levels is shown on the final
page of this document.
Film Thickness Total film thickness recommendation is 6-16µm for all Class A surfaces. This is “pure coating” + “IPL”
Minimum of 6µm of “pure coating” is recommended for optimum performance.
Some test specifications will require a measurable IPL in order to comply with all tests. IPL is
influenced by a number of factors including: heated flash temperature, heated flash time, substrate,
substrate stress level, and other factors. Increasing the heated flash time or temperature will increase the
amount of IPL measured.
Performance testing has been completed with UVT610V series coating up to 22µm but does not show
any additional performance benefit.
A refractive index of 1.511 should be used for both the “pure coating” and “IPL” layers.
A recommended film thickness gauge is FTM Lite NIR from www.applied-spectroscopy.com
Application Room Any lights or windows must be covered by amber UV shielding from UVPS part numbers F007-006,
F007-008, or F007-010 for windows and F007-003 for lights. Light must be filtered to 500nm.
All fluid tubes must be stainless steel or black opaque solvent resistant plastic.
Ambient Flash Less than or equal to 2 minutes at room temperature in an enclosed, ventilated tunnel.
Heated Flash IR: 2.0 – 3.0 minutes, convection 5.0 – 8.0 minutes, or 2.0 – 3.0 minutes combo IR + convection with a
peak lens surface temperature of 65 - 82°C. The actual temperature range needed may vary from this
range to properly control IPL.
The ideal profile is a gradual increase in temperature from ambient to the target temperature. It is not
advised to hold the part temperature at a temperature for any duration.
Optimum performance is obtained by exposing all coated surfaces to the proper heated flash temperature
and time.
The IR elements must emit only long wavelength.

http://www.applied-spectroscopy.com/


UVT610V Series Processing Guidelines



Page 2 of 3

Heated Flash
Measurement
Use a temperature profiling device such as a DataPaq Oven Tracker XL2 or Easy Track2 to ensure
proper temperature control. www.datapaq.com
Recommended thermocouples include: exposed junction thermocouples, PA0063, PA0065, PA0064,
PA0071, PA0180, PA0182, PA0181.
Probes should be attached to the surface of the lens either by melting the probe onto the surface or
attaching with a high temperature polyamide tape such as DataPaq CS1030 or Dupont ™ Kapton. Probe
should be located on all extreme areas of the lenses to ensure proper temperature distribution over the
entire coated surface. One surface probe should be on the highest and lowest points on the lenses.
Cool Down Less than 2 minutes at room temperature in an enclosed, ventilated tunnel. Chilled air should not be used
in the cooling tunnel between the heated flash and UV cure zones.
Do not expose the coating to stray UV light until ready to cure.
UV Ovens Full cure is achieved in less than one minute at 3200-5500 mJ/cm² UVA by the EIT PowerMAP. The
minimum intensity level for optimum performance is 250 mW/cm² UVA PowerMAP. www.eit.com
The UV lamps must have a standard mercury bulb or the equivalent. Additive or doped bulbs are not
recommended and are used at the end user’s own risk.
Proper cure must be achieved on all coated surfaces of the lens in order to meet optimum performance.
UV Cure Measurement Radiometers should ideally be placed in the part position in both high and low positions for UV energy
and intensity measurements.
All coated surfaces requiring performance require sufficient UV energy and intensity.
PowerMAP settings include:
 Cursors ON – cursors should be moved in as close as possible to the beginning and end of the
UV curing profile
 All 4 bands of UV Energy and Intensity should be measured and recorded
 The sample rate should be 128 Hz
 The time and date should be correctly set on the internal PowerMAP clock
When profiling a process, the radiometer should not pass through the heated flash zone unless it cannot
be avoided
Radiometer
Correlations
Different models of radiometers read different values for the same amount of UV exposure. Some
common radiometers and their respective UV energy (mJ/cm²) are listed below. Data was collected
using a standard mercury bulb using both arc and microwave lamps. It is important to note that the UV
energies listed below are guidelines.
Puck 2
UVA
PowerMAP
UVA

UVR-N1
3672 3284 1839
4986 4453 2494
5644 5622 3148
The radiometers listed are: EIT Power Puck 2, EIT PowerMAP, GS YUASA UVR-N1.
All measurements in the table above are in mJ/cm².


http://www.datapaq.com/
http://www.eit.com/


UVT610V Series Processing Guidelines



Page 3 of 3


















Exclusions of Warranties: The Fujikura Global Network ("The Company") makes no warranties, expressed or implied, in connection with the
sale of (this)(these) product(s), and all implied warranties of merchantability and fitness for a particular purpose are excluded and shall not
apply to the goods sold. The company's employees, agents, and/or representatives may have made oral statements about the merchandise
sold. Such statements do not constitute warranties and are not a part of the contract for sale of the merchandise sold.
