Power Quality in Microgrids with Distributed
Generation

Andrey V. Shalukho
Electric Power Engineering Institute
Nizhny Novgorod State Technical University
n.a. R. E. Alekseev
Nizhny Novgorod, Russia
shaluho@nntu.ru
Ivan A. Lipuzhin
Electric Power Engineering Institute
Nizhny Novgorod State Technical University
n.a. R. E. Alekseev
Nizhny Novgorod, Russia
lipuzhin@nntu.ru
Alexander A. Voroshilov
Electric Power Engineering Institute
Nizhny Novgorod State Technical University
n.a. R. E. Alekseev
Nizhny Novgorod, Russia
alejandro.voroshilov@yandex.ru


Abstract—The actual direction of increasing the efficiency of
distributed generation and renewable energy resources is the
aggregation of low-power sources in a microgrid or virtual
power plant. There are many features in these systems: a large
number of semiconductor equipment, stochastic nature of the
RES generation and bi-directional power flows. Therefore, an
important task is to ensure the required power quality
indicators. The article is devoted to experimental studies of the
influence of distributed generation sources on the power quality
at consumer buses. A physical model of a microgrid was
assembled containing solar and wind power plants simulators
with the help of a laboratory bench. The power quality
indicators, such as voltage fluctuations, frequency deviation,
non-sinusoidality were studied for three operation modes.
Causes of power quality violations have been identified.
Solutions to reduce the negative impact of distributed generation
on the power quality in the microgrid are proposed.
Keywords—distributed generation, renewable energy
resources, microgrids, bi-directional power flow, power quality
I. INTRODUCTION
Nowadays, the development of distributed generation
(DG) and renewable energy sources (RES) is an important
direction in energy security ensuring for the remote consumers
[1, 2]. A new approach to improving the efficiency of
renewable energy usage is to aggregate distributed objects
with their own RES in multi-scale smart systems (minigrid,
microgrid, nanogrid or virtual power plants) that have the
ability to exchange electricity between objects.
Technical devices (energy convertors and switching
devices, information and communication equipment) allowing
to ensure information interaction and energy transfer from
objects with their own power plant to the centralized electrical
network (CEN), are already available on the electricity market.
However, the implemented projects on the aggregation of low-
power RES into a single system are rare [3–5], while they are
absent in Russia.
The development of DG aggregation technologies requires
solving a number of technical problems. Many companies,
organizations and scientific teams are engaged in research in
this area [6–8]. The most studied areas are: ensuring stable
operation [9, 10], selecting effective structures [11, 12],
ensuring information and energy exchange between elements
[13–15], ensuring the correct operation of relay protection and
automation [16, 17].
Distinctive features of systems with DG are: use of
semiconductor equipment (inverters, charge controllers), bi-
directional energy flows between the objects and stochastic
nature of the RES generation. These factors negatively affect
the power quality at consumer buses [18, 19]. Therefore, an
important task is to provide required power quality for
microgrid consumers [20, 21].
Researches of the power quality in systems with DG are
not sufficiently covered in scientific papers. Mathematical and
computer modeling is used in most studies on this subject [22].
These approaches do not allow to fully take into account the
technical features of the equipment (operation algorithms) and
to obtain objective data. Therefore, it is necessary to
supplement the theoretical studies of power quality in systems
with DG with the results of physical modeling.
The laboratory bench of a virtual power plant with
renewable energy sources [23] was developed at NNSTU. It is
designed to study the operation modes of systems with DG.
The purpose of this paper is an experimental research of the
power quality in a system with DG, and the development of
recommendations for improving the power quality.
II. MATERIALS AND METHODS
A model of a microgrid with DG was assembled at the
laboratory bench for conducting experimental research. The
following units are included in this model (Fig. 1):
uninterruptible power source (UPS), regulating transformers
(AT), active (R) and motor loads (Z), solar and wind power
plant simulators with storage battery (GB) connected to the
microgrid using single-phase converters (UZ). Energy sources
and consumers are aggregated into the microgrid. The
microgrid is connected to an external network (centralized
electrical network (CEN)) with the help of UPS and
transformers.
The work has been carried out with the financial support of the Ministry
of Science and Higher Education of the Russian Federation (state task
№13.2078.2017/4.6 on May 31, 2017).
54
2019 International Ural Conference on Electrical Power Engineering (UralCon)
0.4 kV
RW2
UPS
M~
RB
RL1
WG
0.4 kV
AT1 AT2
RW4RW3
QF1
Q1
Q2
Q3 Q4
Q5
RW5
Q7
RW7
UZ1
Q6
RW6
GB1
RL3
Q8
RW8 RW9
Solar Plant
UZ3
GB2
Q9
RW1
Q11 RW11
=
~
~
=
~
=
F
0.4/0.4 kV 0.4/0.4 kV
UZ2
~
=
=UZ4
ZL2
Wind Plant
SP
CEN
- installation site of power quality analyzers
1
2

Fig. 1. Simplified single-line diagram of the simulated microgrid with DG
sources.
The main parameters of the stand are presented in table I.
TABLE I. LABORATORY BENCH PARAMETERS
Parameter Value
Input voltage, V 220
Active load, W 1900
Reactive load, VA 550
Wind generator simulator power W 2000
Power simulator solar power, W 2000
These equipment and construction of the microgrid allow
the study of three operation modes:
1. microgrid consumers receive power only from the CEN;
2. microgrid consumers receive power from DG and CEN;
3. microgrid consumers receive power only from DG and
surplus electricity is provided to the CEN.
Oscillograms of current and voltage were obtained with the
help of the power quality analyzers HT PQA824, and the
measurements of power quality were made: voltage
fluctuations, frequency deviation, non-sinusoidality. Values of
the power quality indicators were recorded at the connection
points of DG sources to the microgrid (point 1, Fig. 1) and at
consumers buses (point 2). Control of power quality indicators
was carried out in accordance with the requirements [24].
A research program was developed for each of the modes:
• turn on the UPS: microgrid receives power from CEN;
• turn on the DG sources: first solar plant, then after
reaching the nominal mode, wind plant;
• turn on and stepwise regulation of the load of the
consumer without own generation sources;
• stepwise regulation of the voltage at the connection
point of the microgrid to the CEN by transformers;
• turn off the DG sources and UPS.
III. EXPERIMENTAL RESULTS
Researches of the three modes of microgrid operation have
been conducted. The values of voltage fluctuations, frequency
deviations and voltage harmonic composition are investigated.
Microgrid operation modes are described by the following
equations:
 B CON SB CEN DGP P P P P+ ± = + (1)
 B CON RPC CEN DGQ Q Q Q Q+ ± = + (2)
where P, Q – active and reactive power; indexes: B –
ballast load, C – consumers load, SB – storage battery, CEN –
centralized electrical network, DG – distributed generation,
RPC – reactive power compensation.
It has been established that in modes 2 and 3 a brief
imbalance of power is possible. This leads to short-term
increases in current in modes 2 and 3 - up to 70% of the
parameters of the normalmode; and increases in voltage - up
to 11.5% of the nominal value (Fig. 2). These factors must be
considered when choosing the relay protection and automation
settings. The power of DG sources is small compared to CEN,
so the problem of excess power from the sequential connection
of DG sources does not lead to system failures. To avoid large
deviations of current and voltage levels, it is necessary to
exclude the possibility of simultaneously switching on DG
sources.
Frequency deviation is also possible when DG sources
supplies the microgrid in modes 2 and 3. Frequency deviations
above the normal permissible value (0.2 Hz) were not
recorded in the investigated microgrid (Fig. 3).
Since the connection of RES is carried out with the help of
power converting devices, the analysis of the spectrum of the
highest harmonic components in the investigated microgrid is
relevant.
The measurement of harmonic components was carried out
at the connection point of consumer without own generation
sources to the microgrid (point 2, Fig. 1).
55
2019 International Ural Conference on Electrical Power Engineering (UralCon)

a)

b)
Fig. 2. Oscillograms of current and voltage at the connection point of
consumer to the microgrid at the start of power output from the DG: a -
with one DG; b - with two DG.

Fig. 3. Graph of frequency changes in the microgrid with DG.
The research of harmonic components showed that the
number of higher harmonics, including multiples of three,
sharply increases when RES is connected to the microgrid
using single-phase converters in modes 2 and 3 (Fig. 4, a).
The negative consequences arising from the presence of
higher harmonic components are overheating of transformers
and rotating machines, neutral overload, increased voltages
between neutral and earth, failure of capacitor banks, tripping
of circuit breakers and fuses, improper operation of electronic
equipment and generators, energy loss and network bandwidth
loss. These problems lead to additional costs, such as higher
energy consumption, costs due to faster aging of equipment,
equipment downtime, increased maintenance and repair costs,
as well as losses due to lower product quality and productivity
[25].

a)

b)
Fig. 4. Spectrum of higher harmonic voltage components on bus of
consumer: a - without own generation; b - with own generation.
Possible approaches to reducing the non-sinusoidal
relationship are the use of filter-compensating devices (FCD)
and circuit design - connecting converter equipment according
to the phase multiplication scheme [26].
Connection of converters by the phase multiplication
scheme cannot be an effective solution, since this approach
56
2019 International Ural Conference on Electrical Power Engineering (UralCon)
eliminates the possibility of flexible changes in the network
composition, which is an essential requirement for developing
networks with DG.
Similar to the phase multiplication scheme, inefficient in
networks with distributed generation is the use of passive
FCD. When using passive FCD, its circuit is tuned to a
specific frequency. The resonant frequencies of the filter are
very close to the frequencies of the existing harmonics. When
designing a passive FCD, careful analysis of the load and
power quality is of great importance, and the magnitude of the
network impedance is also very important. Another
disadvantage of passive resonant filters is that there is always
the danger of overload due to an increase in load with an
increased harmonic content and the appearance of other
sources of distortion.
The most effective approach to reducing higher harmonics
is the use of active FCD. The advantage of active filters is that
they can filter harmonics in systems with varying parameters.
When using active FCD, neutral conductor currents can be
reduced (3rd harmonic and harmonics that are multiples of
three). There is also no mandatory need for careful harmonic
analysis before designing a filter. A new trend in the use of
modular filters makes it easy to upgrade without performing
assembly. In addition to eliminating harmonics, active filters
can also be used for load balancing, power factor correction.
The main drawback of active filters is the cost.
The diagram of voltage harmonic composition on bus of
consumer with own DG source (Fig. 4, b) shows that the
values of the harmonic components are within acceptable
limits. This is due to the fact that the inverters have inside their
own filter device.
IV. DISCUSSION
Based on the conducted research, it can be concluded that
the connection of DG sources by the single-phase converters
does not allow adjusting of the power quality in the microgrid.
Single-phase connection of DG sources leads to a distortion of
the shape of the sinusoid voltage.
A scheme for connecting objects with DG to the microgrid
using three-phase converters (Fig. 5) can be proposed to solve
this problem.
This approach supposes a multi-level structure of
connecting DG sources, which makes it possible to ensure
high power quality within the microgrid.
The use of a three-phase system allows one to eliminate
the negative impact of higher harmonic components without
installing individual FCD. Permissible levels of harmonics are
provided with the correct distribution by the phases of the
objects with DG sources and consumers due to the built-in
filters of the three-phase inverters.
This approach involves the division of the microgrid into
smaller areas. Power supply of a separate section is carried out
through a three-phase inverter. Consumers with their own
generation and consumers without their own generation are
connected to different phases. This solution allows you to
localize the excess of higher harmonic components on phases
with consumers connected using their own inverters with the
FCD function. As a result, the permissible level of harmonics is
ensured for all consumers within the microgrid.
A
B
C
N
PE
~
=
~
=
~
=
= ~
UZRES1
~
= = ~
UZcont.1 RES1
UZcont.2
RES2
RL1
UZRES.2
GBRES.1
...
0.4 kV
System 1
GBRES.2
RL2
RL3
RL5
~
= = ~
UZcont.3
RES3UZRES.3 GBRES.3
RL4
~
=
~
=
~
=
= ~
UZRESn
UZcont.n RESn
RLn
GBRES.n
System n

Fig. 5. Connection of DG sources to the 0.4 kV microgrid by three-phase
converters.
Also, the proposed scheme will provide an isolated mode
of the entire microgrid. When the micro grid is disconnected
from the CEN, part of the electricity from DG sources can be
transferred to other consumers in the microgrid.
However, this approach involves the use of additional
equipment (three-phase inverter), which leads to a significant
increase in the system cost.
V. CONCLUSION
The article discusses issues of the power quality in
microgrid with DG.
The microgrid model with DG (the wind turbine and the
solar photovoltaic station) was assembled with the help of a
laboratory bench. Experimental researches of the influence of
the microgrid operation modes on the power quality have been
carried out.
57
2019 International Ural Conference on Electrical Power Engineering (UralCon)
It has been established that the turn-on of DG sources leads
to a short-term increase in current and voltage levels in the
microgrid. This should be taken into account when choosing
the relay protection and automation systems. The operation of
DG in the microgrid negatively affects the voltage harmonic
composition.
Technical and circuit solutions to ensure the required
power quality in microgrid with DG were considered.
REFERENCES
[1] The energy strategy of Russia for the period until 2030. [Online].
Available: http://www.minenergo.gov.ru/aboutminen/energostrategy/
[2] A. B. Loskutov, “Solving problems in trasition of electrical industry to
digital technologies,” Smart Electrical Engineering, no. 1, pp. 9–27,
2018.
[3] B. Zhao, X. Zhang, P. Li, and K. Wang, “Optimal sizing, operatingstrategy and operational experience of a bench-alone microgrid on
Dongfushan Island,” Applied Energy, vol. 113, pp. 1656–1666, 2014.
[4] M. Braun, Virtual Power Plants in real applications: Pilot
demonstrations in Spain and England as part of the European project
FENIX, 2019.
[5] Wildpolsderied – The Energy Village. [Online]. Available:
https://www.wildpoldsried.de/
[6] O. A. Surzhikova, “Problems and key directions in developing power
supply in remote and sparsely populated settlements,” Siberian Journal
of Science, no. 3(4), pp. 103–108, 2012.
[7] V. P. Kuprianovsky, F. Y. Fokin, S. A. Bulancha, and Y. V.
Kuprianovsky, “Microgrids – energy, economy, ecology and IT-
services in Smart Cities,” INJOIT, vol. 4, no. 4, pp. 10–19, 2016.
[8] V. V. Kharchenko, V. B. Adomavichus, and V. A. Gusarov, “RES-
based microgrid as an instrument of distributed energy concept,”
ISJAEE, no. 2(119), pp. 80–85, 2013.
[9] P. Ilyshin, “The analysis of dispersed generation influence on power
system automatics settings and function algorithms,” E3S Web of
Conf., vol. 58, 2018.
[10] E. N. Sosnina, A. V. Shalukho, I. A. Lipuzhin, and A. Y. Kechkin,
“Stability investigation of the virtual power plants electrical systems,”
IJAER, vol. 10, no. 24, pp. 44363–44368, 2015.
[11] V. P. Zhukov, D. A. Osipov, D. A. Ulanov, and G. V. Ledukhovsky,
“Optimal control of the structure and operating conditions of integrated
power systems,” Vestnik of Ivanovo State Power Engineering
University. no. 2, pp. 33–37, 2016.
[12] E. N. Sosnina, A. V. Shalukho, I. A. Lipuzhin, and A. Yu. Kechkin,
“Optimization of virtual power plant topology with distributed
generation sources,” Proc. 2018 Int. Conf. and Utility Exhibition on
Green Energy for Sustainable Development, pp. 1–7, 2018.
[13] D. Kennedi, “Virtual Power Station - Smart Control of Distributed
Generation,” Power and Industry of Russia, no. 08(244), pp. 14–15,
2014.
[14] E. N. Sosnina, A. I. Chivenkov, A. V. Shalukho, and N. V. Shumskii,
“Power flow control in a virtual power plant network,” IJRER, vol.
8(1), рр. 328–335, 2018.
[15] J. A. Barbosa, R. P. S. Leao, C. F. P. Lima, and M. C. O. Rego,
“Decentralized energy management system to virtual power plants,”
RE&PQJ, vol. 1(8), pp. 1079–1085, 2010.
[16] К. А. Skurihina, А. Yu. Arestova, and D. V. Armeev, “Research of
microgrid dynamic properties as a part of the power system,” Siberian
Journal of Science, no. 1(15), pp. 93–102, 2015.
[17] P. V. Ilyshin, “Peculiarities of the implementation of fission automation
in generating installations for distributed generation projects,” Proc. Int.
Conf. and Exhibition Relay Protection and Automation for Electric
Power Systems, pp. 1–8, 2017.
[18] D. S. Aleksandrov and E. F. Shcherbakov, Reliability and Quality of
Power Supply for Enterprises. Ul'yanovsk: UlGTU, 2010.
[19] L. I. Kovernikova, V. V. Sudnova, and R. G. Shamonov, Electric
Energy Quality: Current State, Problems and Suggestions for Solving
Them. Novosibirsk: Nauka, 2017.
[20] I. S. Kozhuhovskiy, “On the problems of development of small-
distributed energy in Russia,” Proc. ENES 2014, unpublished.
[21] A. Khokhlov, Y. Melnikov, F. Veselov, D. Kholkin, and K. Datsko,
Distributed Energy in Russia: Development Potential. Moscow: Energy
Center of the Moscow School of Management SKOLKOVO, 2018.
[22] K. V. Suslov, N. N. Solonina, A. S. Smirnov, and Z. V. Solonina,
“Application of distributed power quality monitoring in MicroGrid,”
Proc. of Irkutsk State Technical University, vol. 6(89), pp. 185–189,
2014.
[23] E. N. Sosnina, A. V. Shalukho, I. A. Lipuzhin, and A. Yu. Kechkin,
“Laboratory stand of the electrotechnological complex of a virtual
power plant with renewable energy sources,” RU Patent 185802, 2018.
[24] GOST 32144-2013. Electric energy. Electromagnetic compatibility of
technical equipment. Power quality limits in the public power supply
systems. Мoscow: Standartinform, 2014.
[25] I. V. Zhezhelenko, Higher Harmonics in Industrial Power Supply
Systems. Мoscow: Ehnergoatomizdat, 2004.
[26] K. Shidlovsky and A. Zharkin, Higher Harmonics in Low Voltage
Networks. Kiev: Naukova Dumka, 2005.

58
>
 /ColorImageDict >
 /JPEG2000ColorACSImageDict >
 /JPEG2000ColorImageDict >
 /AntiAliasGrayImages false
 /CropGrayImages true
 /GrayImageMinResolution 200
 /GrayImageMinResolutionPolicy /OK
 /DownsampleGrayImages true
 /GrayImageDownsampleType /Bicubic
 /GrayImageResolution 300
 /GrayImageDepth -1
 /GrayImageMinDownsampleDepth 2
 /GrayImageDownsampleThreshold 1.50000
 /EncodeGrayImages true
 /GrayImageFilter /DCTEncode
 /AutoFilterGrayImages false
 /GrayImageAutoFilterStrategy /JPEG
 /GrayACSImageDict >
 /GrayImageDict >
 /JPEG2000GrayACSImageDict >
 /JPEG2000GrayImageDict >
 /AntiAliasMonoImages false
 /CropMonoImages true
 /MonoImageMinResolution 400
 /MonoImageMinResolutionPolicy /OK
 /DownsampleMonoImages true
 /MonoImageDownsampleType /Bicubic
 /MonoImageResolution 600
 /MonoImageDepth -1
 /MonoImageDownsampleThreshold 1.50000
 /EncodeMonoImages true
 /MonoImageFilter /CCITTFaxEncode
 /MonoImageDict >
 /AllowPSXObjects false
 /CheckCompliance [
 /None
 ]
 /PDFX1aCheck false
 /PDFX3Check false
 /PDFXCompliantPDFOnly false
 /PDFXNoTrimBoxError true
 /PDFXTrimBoxToMediaBoxOffset [
 0.00000
 0.00000
 0.00000
 0.00000
 ]
 /PDFXSetBleedBoxToMediaBox true
 /PDFXBleedBoxToTrimBoxOffset [
 0.00000
 0.00000
 0.00000
 0.00000
 ]
 /PDFXOutputIntentProfile (None)
 /PDFXOutputConditionIdentifier()
 /PDFXOutputCondition ()
 /PDFXRegistryName ()
 /PDFXTrapped /False
 /CreateJDFFile false
 /Description
 /BGR
 /CHS
 /CHT
 /CZE
 /DAN
 /DEU
 /ESP
 /ETI
 /FRA
 /GRE/HEB
 /HRV
 /HUN
 /ITA (Utilizzare queste impostazioni per creare documenti Adobe PDF adatti per visualizzare e stampare documenti aziendali in modo affidabile. I documenti PDF creati possono essere aperti con Acrobat e Adobe Reader 6.0 e versioni successive.)
 /JPN
 /KOR
 /LTH
 /LVI
 /NLD (Gebruik deze instellingen om Adobe PDF-documenten te maken waarmee zakelijke documenten betrouwbaar kunnen worden weergegeven en afgedrukt. De gemaakte PDF-documenten kunnen worden geopend met Acrobat en Adobe Reader 6.0 en hoger.)
 /NOR
 /POL/PTB
 /RUM
 /SKY
 /SLV
 /SUO
 /SVE
 /TUR
 /UKR
 /ENU (Use these settings to create Adobe PDF documents suitable for reliable viewing and printing of business documents. Created PDF documents can be opened with Acrobat and Adobe Reader 6.0 and later.)
 /RUS>>
>> setdistillerparams
> setpagedevice



 HistoryItem_V1
 AddNumbers

 Range: From page 1 to page 40
 Font: TimesNewRoman;TimesNewRomanPSMT 10.0 point
 Origin: bottom centre
 Offset: horizontal 0.00 points, vertical 35.72 points
 Prefix text: ''
 Suffix text: ''
 Colour: Default (black)


 D:20191008154337


 1
 0

 BC

 1
 1
 0
 0
 1
 54
 TimesNewRoman;TimesNewRomanPSMT
 1
 0
 0
 538
 212

 0
 1
 R0
 10.0000


 Both
 1
 SubDoc
 40

 CurrentAVDoc

 0.0000
 35.7165


 QITE_QuiteImposingPlus4
 Quite Imposing Plus 4.0b
 Quite Imposing Plus 4
 1


 0
 5
 4
 ae111ba3-a103-4eff-96a6-a324b26f8c31
 5

 1

 HistoryList_V1
 qi2base
