LG+32LB550B

Prévia do material em texto

Printed in KoreaP/NO : MFL67988304(1401-REV00)
CHASSIS : LA44B
MODEL : 32LB550B 32LB550B-UC
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
LED TV
SERVICE MANUAL
North/Latin America http://aic.lgservice.com
Europe/Africa http://eic.lgservice.com
Asia/Oceania http://biz.lgservice.com
Internal Use Only
- 2 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
CONTENTS
CONTENTS .............................................................................................. 2
PRODUCT SAFETY ................................................................................. 3
SPECIFICATION ....................................................................................... 4
ADJUSTMENT INSTRUCTION ................................................................ 9
TROUBLE SHOOTING ............................................................................16
BLOCK DIAGRAM .................................................................................. 22
EXPLODED VIEW .................................................................................. 23
SCHEMATIC CIRCUIT DIAGRAM ..............................................................
- 3 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in the
Schematic Diagram and Exploded View.
It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent
Shock, Fire, or other Hazards.
Do not modify the original design without permission of manufacturer.
General Guidance
An isolation Transformer should always be used during the
servicing of a receiver whose chassis is not isolated from the AC
power line. Use a transformer of adequate power rating as this
protects the technician from accidents resulting in personal injury
from electrical shocks.
It will also protect the receiver and it's components from being
damaged by accidental shorts of the circuitry that may be
inadvertently introduced during the service operation.
If any fuse (or Fusible Resistor) in this TV receiver is blown,
replace it with the specified.
When replacing a high wattage resistor (Oxide Metal Film Resistor,
over 1 W), keep the resistor 10 mm away from PCB.
Keep wires away from high voltage or high temperature parts.
Before returning the receiver to the customer,
always perform an AC leakage current check on the exposed
metallic parts of the cabinet, such as antennas, terminals, etc., to
be sure the set is safe to operate without damage of electrical
shock.
Leakage Current Cold Check(Antenna Cold Check)
With the instrument AC plug removed from AC source, connect an
electrical jumper across the two AC plug prongs. Place the AC
switch in the on position, connect one lead of ohm-meter to the AC
plug prongs tied together and touch other ohm-meter lead in turn to
each exposed metallic parts such as antenna terminals, phone
jacks, etc.
If the exposed metallic part has a return path to the chassis, the
measured resistance should be between 1 MΩ and 5.2 MΩ.
When the exposed metal has no return path to the chassis the
reading must be infinite.
An other abnormality exists that must be corrected before the
receiver is returned to the customer.
Leakage Current Hot Check (See below Figure)
Plug the AC cord directly into the AC outlet.
Do not use a line Isolation Transformer during this check.
Connect 1.5 K / 10 watt resistor in parallel with a 0.15 uF capacitor
between a known good earth ground (Water Pipe, Conduit, etc.)
and the exposed metallic parts.
Measure the AC voltage across the resistor using AC voltmeter
with 1000 ohms/volt or more sensitivity.
Reverse plug the AC cord into the AC outlet and repeat AC voltage
measurements for each exposed metallic part. Any voltage
measured must not exceed 0.75 volt RMS which is corresponds to
0.5 mA.
In case any measurement is out of the limits specified, there is
possibility of shock hazard and the set must be checked and
repaired before it is returned to the customer.
Leakage Current Hot Check circuit
IMPORTANT SAFETY NOTICE
SAFETY PRECAUTIONS
- 4 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
SERVICING PRECAUTIONS
CAUTION: Before servicing receivers covered by this service
manual and its supplements and addenda, read and follow the
SAFETY PRECAUTIONS on page 3 of this publication.
NOTE: If unforeseen circumstances create conflict between the
following servicing precautions and any of the safety precautions
on page 3 of this publication, always follow the safety precautions.
Remember: Safety First.
General Servicing Precautions
1. Always unplug the receiver AC power cord from the AC power
source before;
a. Removing or reinstalling any component, circuit board mod-
ule or any other receiver assembly.
b. Disconnecting or reconnecting any receiver electrical plug or
other electrical connection.
c. Connecting a test substitute in parallel with an electrolytic
capacitor in the receiver.
CAUTION: A wrong part substitution or incorrect polarity
installation of electrolytic capacitors may result in an explo-
sion hazard.
2. Test high voltage only by measuring it with an appropriate
high voltage meter or other voltage measuring device (DVM,
FETVOM, etc) equipped with a suitable high voltage probe.
Do not test high voltage by "drawing an arc".
3. Do not spray chemicals on or near this receiver or any of its
assemblies.
4. Unless specified otherwise in this service manual, clean
electrical contacts only by applying the following mixture to the
contacts with a pipe cleaner, cotton-tipped stick or comparable
non-abrasive applicator; 10 % (by volume) Acetone and 90 %
(by volume) isopropyl alcohol (90 % - 99 % strength)
CAUTION: This is a flammable mixture.
Unless specified otherwise in this service manual, lubrication of
contacts in not required.
5. Do not defeat any plug/socket B+ voltage interlocks with which
receivers covered by this service manual might be equipped.
6. Do not apply AC power to this instrument and/or any of its
electrical assemblies unless all solid-state device heat sinks are
correctly installed.
7. Always connect the test receiver ground lead to the receiver
chassis ground before connecting the test receiver positive
lead.
Always remove the test receiver ground lead last.
8. Use with this receiver only the test fixtures specified in this
service manual.
CAUTION: Do not connect the test fixture ground strap to any
heat sink in this receiver.
Electrostatically Sensitive (ES) Devices
Some semiconductor (solid-state) devices can be damaged eas-
ily by static electricity. Such components commonly are called
Electrostatically Sensitive (ES) Devices. Examples of typical ES
devices are integrated circuits and some field-effect transistors
and semiconductor “chip” components. The following techniques
should be used to help reduce the incidence of component dam-
age caused by static by static electricity.
1. Immediately before handling any semiconductor component or
semiconductor-equipped assembly, drain off any electrostatic
charge on your body by touching a known earth ground. Alter-
natively, obtain and wear a commercially available discharging
wrist strap device, which should be removed to prevent poten-
tial shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES
devices, place the assembly on a conductive surface such as
aluminum foil, to prevent electrostatic charge buildup or expo-
sure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES
devices.
4. Use only an anti-statictype solder removal device. Some solder
removal devices not classified as “anti-static” can generate
electrical charges sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate
electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective
package until immediately before you are ready to install it.
(Most replacement ES devices are packaged with leads electri-
cally shorted together by conductive foam, aluminum foil or
comparable conductive material).
7. Immediately before removing the protective material from the
leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be
installed.
CAUTION: Be sure no power is applied to the chassis or circuit,
and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replace-
ment ES devices. (Otherwise harmless motion such as the
brushing together of your clothes fabric or the lifting of your
foot from a carpeted floor can generate static electricity suf-
ficient to damage an ES device.)
General Soldering Guidelines
1. Use a grounded-tip, low-wattage soldering iron and appropriate
tip size and shape that will maintain tip temperature within the
range or 500 °F to 600 °F.
2. Use an appropriate gauge of RMA resin-core solder composed
of 60 parts tin/40 parts lead.
3. Keep the soldering iron tip clean and well tinned.
4. Thoroughly clean the surfaces to be soldered. Use a mall wire-
bristle (0.5 inch, or 1.25 cm) brush with a metal handle.
Do not use freon-propelled spray-on cleaners.
5. Use the following unsoldering technique
a. Allow the soldering iron tip to reach normal temperature.
(500 °F to 600 °F)
b. Heat the component lead until the solder melts.
c. Quickly draw the melted solder with an anti-static, suction-
type solder removal device or with solder braid.
CAUTION: Work quickly to avoid overheating the circuit
board printed foil.
6. Use the following soldering technique.
a. Allow the soldering iron tip to reach a normal temperature
(500 °F to 600 °F)
b. First, hold the soldering iron tip and solder the strand against
the component lead until the solder melts.
c. Quickly move the soldering iron tip to the junction of the
component lead and the printed circuit foil, and hold it there
only until the solder flows onto and around both the compo-
nent lead and the foil.
CAUTION: Work quickly to avoid overheating the circuit
board printed foil.
d. Closely inspect the solder area and remove any excess or
splashed solder with a small wire-bristle brush.
- 5 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
IC Remove/Replacement
Some chassis circuit boards have slotted holes (oblong) through
which the IC leads are inserted and then bent flat against the cir-
cuit foil. When holes are the slotted type, the following technique
should be used to remove and replace the IC. When working with
boards using the familiar round hole, use the standard technique
as outlined in paragraphs 5 and 6 above.
Removal
1. Desolder and straighten each IC lead in one operation by
gently prying up on the lead with the soldering iron tip as the
solder melts.
2. Draw away the melted solder with an anti-static suction-type
solder removal device (or with solder braid) before removing
the IC.
Replacement
1. Carefully insert the replacement IC in the circuit board.
2. Carefully bend each IC lead against the circuit foil pad and
solder it.
3. Clean the soldered areas with a small wire-bristle brush.
(It is not necessary to reapply acrylic coating to the areas).
"Small-Signal" Discrete Transistor
Removal/Replacement
1. Remove the defective transistor by clipping its leads as close
as possible to the component body.
2. Bend into a "U" shape the end of each of three leads remaining
on the circuit board.
3. Bend into a "U" shape the replacement transistor leads.
4. Connect the replacement transistor leads to the corresponding
leads extending from the circuit board and crimp the "U" with
long nose pliers to insure metal to metal contact then solder
each connection.
Power Output, Transistor Device
Removal/Replacement
1. Heat and remove all solder from around the transistor leads.
2. Remove the heat sink mounting screw (if so equipped).
3. Carefully remove the transistor from the heat sink of the circuit
board.
4. Insert new transistor in the circuit board.
5. Solder each transistor lead, and clip off excess lead.
6. Replace heat sink.
Diode Removal/Replacement
1. Remove defective diode by clipping its leads as close as pos-
sible to diode body.
2. Bend the two remaining leads perpendicular y to the circuit
board.
3. Observing diode polarity, wrap each lead of the new diode
around the corresponding lead on the circuit board.
4. Securely crimp each connection and solder it.
5. Inspect (on the circuit board copper side) the solder joints of
the two "original" leads. If they are not shiny, reheat them and if
necessary, apply additional solder.
Fuse and Conventional Resistor
Removal/Replacement
1. Clip each fuse or resistor lead at top of the circuit board hollow
stake.
2. Securely crimp the leads of replacement component around
notch at stake top.
3. Solder the connections.
CAUTION: Maintain original spacing between the replaced
component and adjacent components and the circuit board to
prevent excessive component temperatures.
Circuit Board Foil Repair
Excessive heat applied to the copper foil of any printed circuit
board will weaken the adhesive that bonds the foil to the circuit
board causing the foil to separate from or "lift-off" the board. The
following guidelines and procedures should be followed whenever
this condition is encountered.
At IC Connections
To repair a defective copper pattern at IC connections use the
following procedure to install a jumper wire on the copper pattern
side of the circuit board. (Use this technique only on IC connec-
tions).
1. Carefully remove the damaged copper pattern with a sharp
knife. (Remove only as much copper as absolutely necessary).
2. carefully scratch away the solder resist and acrylic coating (if
used) from the end of the remaining copper pattern.
3. Bend a small "U" in one end of a small gauge jumper wire and
carefully crimp it around the IC pin. Solder the IC connection.
4. Route the jumper wire along the path of the out-away copper
pattern and let it overlap the previously scraped end of the
good copper pattern. Solder the overlapped area and clip off
any excess jumper wire.
At Other Connections
Use the following technique to repair the defective copper pattern
at connections other than IC Pins. This technique involves the
installation of a jumper wire on the component side of the circuit
board.
1. Remove the defective copper pattern with a sharp knife.
Remove at least 1/4 inch of copper, to ensure that a hazardous
condition will not exist if the jumper wire opens.
2. Trace along the copper pattern from both sides of the pattern
break and locate the nearest component that is directly con-
nected to the affected copper pattern.
3. Connect insulated 20-gauge jumper wire from the lead of the
nearest component on one side of the pattern break to the lead
of the nearest component on the other side.
Carefully crimp and solder the connections.
CAUTION: Be sure the insulated jumper wire is dressed so the
it does not touch components or sharp edges.
- 6 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement.
1. Application range
This spec sheet is applied LED TV with LA44Bchassis
2. Test condition
Each part is tested as below without special notice.
1) Temperature : 25 ºC ± 5ºC(77 ± 9 ºF) , CST : 40 ºC±5 ºC
2) Relative Humidity: 65 % ± 10 %
3) Power Voltage
Market Input voltage Frequency Remark
USA 110~240V 50/60Hz Standard Voltage of each
product is marked by
models
4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM
5) The receiver must be operated for about 20 minutes prior to
the adjustment
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety : UL, CSA, IEC specification
- EMC: FCC, ICES, IEC specification

4. General Specification
No Item Specification Result Remark
1. Receiving System 1) ATSC / NTSC-M / 64 QAM / 256 QAM
1) ATSC / NTSC-M / 64 QAM / 256 QAM
 PAL-M / PAL-N /
ATSC Suffix (“WD”) only model
2. Available Channel 1) VHF : 02~13
2) UHF : 14~69
3) DTV : 02-69
4) CATV : 01~135
5) CADTV : 01~135
3. Input Voltage AC 100 ~ 240V 50/60Hz Mark : 110V, 60Hz (N.America)
4. Market NORTH AMERICA
5. Screen Size 32/39/42/47/50/55inch Wide (1920 × 1080) FHD + 60Hz 32LB5600-UH
39LB5600-UH
42LB5600-UH
55LB5500-UC
49LB5500-UC
42LB5500-UC
32/37inch Wide (1366 × 768) HD + 60Hz 32LB560B-UH
32LB550B-UC
6. Aspect Ratio 16:9
7. Tuning System FS
- 7 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
No Item Specification Result Remark
8. Module DIRECT L TBD LGD 32LB5600-UH
DIRECT L LC420DUE-FGA3 LGD 42LB5600-UH
DIRECT L T420HVF07.0 AUO 42LB5600-UH
DIRECT L NC390DUN-VXBP1 INX 39LB5600-UH
DIRECT L LC320DUE-FGA3 LGD 32LB5600-UH
DIRECT L NC320DXN-VSBP1 Sharp 32LB560B-UH
DIRECT L HC320DXN-VSHS1 CSOT 32LB560B-UH
DIRECT L LC320DXE-FGA3 LGD 32LB560B-UH
DIRECT L HC550DUN-ABHR1 BOE 55LB5500-UC
DIRECT L LC550DUE-FGA5 LGD 55LB5500-UC
DIRECT L LC490DUE-FGA5 LGD 49LB5500-UC
DIRECT L LC420DUE-FGA5 LGD 42LB5500-UC
DIRECT L NC320DXN-VSBP2 Sharp 32LB550B-UC
DIRECT L LC320DXE-FGA5 LGD 32LB550B-UC
9. Operating Environment 1) Temp : 0 ~ 40 deg
2) Humidity : ~ 80 %
10. Storage Environment 1) Temp : -20 ~ 60 deg
2) Humidity : ~ 85 %
5. Supported video resolutions
5.1. Component input(Y, CB/PB, CR/PR)
No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed
1. 720*480 15.73 60.00 13.5135 SDTV ,DVD 480I
2. 720*480 15.73 59.94 13.50 SDTV ,DVD 480I
3. 720*480 31.50 60.00 27.027 SDTV 480P
4. 720*480 31.47 59.94 27.00 SDTV 480P
5. 1280*720 45.00 60.00 74.25 HDTV 720P
6. 1280*720 44.96 59.94 74.176 HDTV 720P
7. 1920*1080 33.75 60.00 74.25 HDTV 1080I
8. 1920*1080 33.72 59.94 74.176 HDTV 1080I
9. 1920*1080 67.50 60.00 148.50 HDTV 1080P
10. 1920*1080 67.432 59.94 148.352 HDTV 1080P
11. 1920*1080 27.00 24.00 74.25 HDTV 1080P
12. 1920*1080 26.97 23.94 74.176 HDTV 1080P
13. 1920*1080 33.75 30.00 74.25 HDTV 1080P
14. 1920*1080 33.71 29.97 74.176 HDTV 1080P
- 8 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
5.2. HDMI Input (DTV/PC)
No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed Remark
DTV
1. 720*480 31.47 60.00 27.027 SDTV 480P
2. 720*480 31.47 59.94 27.00 SDTV 480P
3. 1280*720 45.00 60.00 74.25 HDTV 720P
4. 1280*720 44.96 59.94 74.176 HDTV 720P
5. 1920*1080 33.75 60.00 74.25 HDTV 1080I
6. 1920*1080 33.72 59.94 74.176 HDTV 1080I
7. 1920*1080 67.50 60.00 148.50 HDTV 1080P
8. 1920*1080 67.432 59.94 148.352 HDTV 1080P
9. 1920*1080 27.00 24.00 74.25 HDTV 1080P
10. 1920*1080 26.97 23.976 74.176 HDTV 1080P
11. 1920*1080 33.75 30.00 74.25 HDTV 1080P
12. 1920*1080 33.71 29.97 74.176 HDTV 1080P
PC DDC
1 640*350 31.468 70.09 25.17 EGA X
2 720*400 31.469 70.08 28.32 DOS O
3 640*480 31.469 59.94 25.17 VESA(VGA) O
4 800*600 37.879 60.31 40.00 VESA(SVGA) O
5 1024*768 48.363 60.00 65.00 VESA(XGA) O
6 1152*864 54.348 60.053 VESA O
7 1280*1024 63.981 60.020 108.0 VESA (SXGA) O Full HD model Only
8 1360*768 47.712 60.015 85.50 VESA (WXGA) O
9 1920*1080 67.50 60.00 148.5 HDTV 1080P O Full HD model Only
- 9 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
ADJUSTMENT INSTRUCTION
1. Application
This spec. sheet applies to LA44B Chassis applied LED TV all
models manufactured in TV factory
2. Specification
(1) Because this is not a hot chassis, it is not necessary to use
an isolation transformer. However, the use of isolation
transformer will help protect test instrument.
(2) Adjustment must be done in the correct order.
(3) The adjustment must be performed in the circumstance of
25 ±5 ºC of temperature and 65±10% of relative humidity if
there is no specific designation
(4) The input voltage of the receiver must keep 100~240V,
50/60Hz
(5) At first Worker must turn on the SET by using Power Only
key.
(6) The receiver must be operated for about 5 minutes prior to
the adjustment when module is in the circumstance of over
15 ºC
 In case of keeping module is in the circumstance of 0°C, it
should be placed in the circumstance of above 15°C for 2
hours
 In case of keeping module is in the circumstance of below
-20°C, it should be placed in the circumstance of above
15°C for 3 hours.
※ Caution
When still image is displayed for a period of 20 minutes or
longer (especially where W/B scale is strong.
Digital pattern 13ch and/or Cross hatch pattern 09ch), there
can some afterimage in the black level area

3. Adjustment items
3.1. Main PCBA Adjustments
(1) ADC adjustment : ADC adjustment is OTP (Auto ADC)
(2) EDID download : HDMI
■ Above adjustment items can be also performed in Final
Assembly if needed.
 Both Board-level and Final assembly adjustment items can
be check using In-Start Menu (1.Adjust Check).
3.2. Final assembly adjustment
(1) White Balance adjustment
(2) RS-232C functionality check
(3) Factory Option setting per destination
(4) Shipment mode setting (In-Stop)
(5) GND and HI-POT test
3.3. Appendix
(1) Shipment conditions
(2) Tool option menu
(3) USB Download (S/W Update, Option and Service only)
(4) Preset CH Information
4. MAIN PCBA Adjustments
* Download
(1) Execute ISP program “Mstar ISP Utility” and then click
“Config” tab.
(2) Set as below, and then click “Auto Detect” and check “OK”
message
 If display “Error”, Check connect computer, jig, and set.
(3) Click “Connect” tab. If display “Can’t ”, Check connect
computer, jig, and set.
(4) Click “Read” tab, and then load download file(XXXX.bin) by
clicking “Read”
(5) Click “Auto” tab and set as below.
(6) Click “Run”.
(7) After downloading, check “OK” message.

(1)
(2) OK
(3)
Please Check the Speed :
To use speed between from 200KHz to 400KHz
(4)
filexxx.bin
(5)
(6)
(7) ……….OK
- 10 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
4.1. ADC Adjustment
4.1.1. Overview
▪ ADC adjustment is needed to find the optimum black level
and gain in Analog-to-Digital device and to compensate RGB
deviation.
▪ ADC adjustment is OTP (Auto ADC)
4.2. EDID Download
4.2.1. Overview
▪ It is a VESA regulation. A PC or a MNT will display an
optimal resolution through information sharing without any
necessity of user input. It is a realization of “Plug and Play”.
4.2.2. Equipment
(1) Since EDID data is embedded, EDID download JIG, HDMI
cable is not need.
(2) Adjust by using remote controller
4.2.3. Download method (using DFT)
※ PC(for communication through RS-232C), UART baud rate:
115200 bps
Command : aa 00 00 (Start Factory mode)
Command : ae 00 10 (Download All EDID)
Command : aa 00 90 (End of Factory mode)
4.2.4. Download method (using Service Remocon)
(1) Press Adj. key on the Adj. R/C.
(2) Select EDID D/L menu.
(3) By pressing Enter key, EDID download will begin
(4) If Download is successful, OK is display, but If Download is
failure, NG is displayed.
(5) If Download is failure, Re-try downloads.
 ※Caution : When EDID Download, must remove HDMI
Cable.
(6) EDID Write confirmation4.2.5. Models for EDID Data
2D
HD / 8bit
HDMI 2ea
FHD / 8bit
HDMI 2ea
HD / 8bit
HDMI 1ea
FHD / 8bit
HDMI 1ea
North
America
(PCM)
32LB560B-UH
32LB550B-UC
32LB5600-UH
39LB5600-UH
42LB5600-UH
55LB5500-UC
49LB5500-UC
42LB5500-UC
i
4.2.5. EDID DATA
4.2.5.1. North America (PCM)
4.2.5.1.1. FHD Model
■ HDMI 1-FHD-8BIT (C/S : E708)
 EDID Block 0, Bytes 0-127 [00H-7FH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
 10 | 01 18 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
 20 | 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80
 30 | 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C
 40 | 45 00 40 84 63 00 00 1E 66 21 50 B0 51 00 1B 30
 50 | 40 70 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A
 60 | 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC
 70 | 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 E7
 EDID Block 1, Bytes 128-255 [80H-FFH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 02 03 19 F1 48 90 22 20 05 04 03 02 01 23 09 57
 10 | 07 67 03 0C 00 10 00 80 1E 02 3A 80 18 71 38 2D
 20 | 40 58 2C 04 05 40 84 63 00 00 1E 01 1D 80 18 71
 30 | 1C 16 20 58 2C 25 00 40 84 63 00 00 9E 01 1D 00
 40 | 72 51 D0 1E 20 6E 28 55 00 40 84 63 00 00 1E 8C
 50 | 0A D0 8A 20 E0 2D 10 10 3E 96 00 40 84 63 00 00
 60 | 18 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
 70 | 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 08
■ HDMI 2-FHD-8BIT (C/S : E7F8)
 EDID Block 0, Bytes 0-127 [00H-7FH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
 10 | 01 18 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
 20 | 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80
 30 | 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C
 40 | 45 00 40 84 63 00 00 1E 66 21 50 B0 51 00 1B 30
 50 | 40 70 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A
 60 | 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC
 70 | 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 E7
 EDID Block 1, Bytes 128-255 [80H-FFH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 02 03 19 F1 48 90 22 20 05 04 03 02 01 23 09 57
 10 | 07 67 03 0C 00 20 00 80 1E 02 3A 80 18 71 38 2D
 20 | 40 58 2C 04 05 40 84 63 00 00 1E 01 1D 80 18 71
 30 | 1C 16 20 58 2C 25 00 40 84 63 00 00 9E 01 1D 00
 40 | 72 51 D0 1E 20 6E 28 55 00 40 84 63 00 00 1E 8C
 50 | 0A D0 8A 20 E0 2D 10 10 3E 96 00 40 84 63 00 00
 60 | 18 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
 70 | 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 F8
EDID D/L (PCM)
HDMI1 : OK
HDMI2 : OK
- 11 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
4.2.5.1.2. HD Model
■ HDMI 1-HD (C/S : 6F08)
 EDID Block 0, Bytes 0-127 [00H-7FH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
 10 | 01 18 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
 20 | 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 01 01
 30 | 01 01 01 01 01 01 66 21 50 B0 51 00 1B 30 40 70
 40 | 36 00 40 84 63 00 00 1E 64 19 00 40 41 00 26 30
 50 | 18 88 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A
 60 | 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC
 70 | 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 6F
 EDID Block 1, Bytes 128-255 [80H-FFH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 02 03 19 F1 48 10 22 20 05 84 03 02 01 23 09 57
 10 | 07 67 03 0C 00 10 00 80 1E 02 3A 80 18 71 38 2D
 20 | 40 58 2C 04 05 40 84 63 00 00 1E 01 1D 80 18 71
 30 | 1C 16 20 58 2C 25 00 40 84 63 00 00 9E 01 1D 00
 40 | 72 51 D0 1E 20 6E 28 55 00 40 84 63 00 00 1E 8C
 50 | 0A D0 8A 20 E0 2D 10 10 3E 96 00 40 84 63 00 00
 60 | 18 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
 70 | 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 08
■ HDMI 2-HD (C/S : 6FF8)
EDID Block 0, Bytes 0-127 [00H-7FH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
 10 | 01 18 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
 20 | 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 01 01
 30 | 01 01 01 01 01 01 66 21 50 B0 51 00 1B 30 40 70
 40 | 36 00 40 84 63 00 00 1E 64 19 00 40 41 00 26 30
 50 | 18 88 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A
 60 | 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC
 70 | 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 6F
 EDID Block 1, Bytes 128-255 [80H-FFH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 02 03 19 F1 48 10 22 20 05 84 03 02 01 23 09 57
 10 | 07 67 03 0C 00 20 00 80 1E 02 3A 80 18 71 38 2D
 20 | 40 58 2C 04 05 40 84 63 00 00 1E 01 1D 80 18 71
 30 | 1C 16 20 58 2C 25 00 40 84 63 00 00 9E 01 1D 00
 40 | 72 51 D0 1E 20 6E 28 55 00 40 84 63 00 00 1E 8C
 50 | 0A D0 8A 20 E0 2D 10 10 3E 96 00 40 84 63 00 00
 60 | 18 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
 70 | 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 F8
4.2.5.2. AC3 EDID Data
4.2.5.2.1. FHD Model
■ HDMI 1-FHD-8BIT (C/S : E796)
 EDID Block 0, Bytes 0-127 [00H-7FH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
 10 | 01 18 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
 20 | 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80
 30 | 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C
 40 | 45 00 40 84 63 00 00 1E 66 21 50 B0 51 00 1B 30
 50 | 40 70 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A
 60 | 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC
 70 | 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 E7
 EDID Block 1, Bytes 128-255 [80H-FFH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 02 03 1C F1 48 90 22 20 05 04 03 02 01 26 15 07
 10 | 50 09 57 07 67 03 0C 00 10 00 80 1E 02 3A 80 18
 20 | 71 38 2D 40 58 2C 04 05 40 84 63 00 00 1E 01 1D
 30 | 80 18 71 1C 16 20 58 2C 25 00 40 84 6300 00 9E
 40 | 01 1D 00 72 51 D0 1E 20 6E 28 55 00 40 84 63 00
 50 | 00 1E 8C 0A D0 8A 20 E0 2D 10 10 3E 96 00 40 84
 60 | 63 00 00 18 00 00 00 00 00 00 00 00 00 00 00 00
 70 | 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 96
■ HDMI 2-FHD-8BIT (C/S : E786)
EDID Block 0, Bytes 0-127 [00H-7FH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
 10 | 01 18 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
 20 | 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80
 30 | 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C
 40 | 45 00 40 84 63 00 00 1E 66 21 50 B0 51 00 1B 30
 50 | 40 70 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A
 60 | 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC
 70 | 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 E7
 EDID Block 1, Bytes 128-255 [80H-FFH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 02 03 1C F1 48 90 22 20 05 04 03 02 01 26 15 07
 10 | 50 09 57 07 67 03 0C 00 20 00 80 1E 02 3A 80 18
 20 | 71 38 2D 40 58 2C 04 05 40 84 63 00 00 1E 01 1D
 30 | 80 18 71 1C 16 20 58 2C 25 00 40 84 63 00 00 9E
 40 | 01 1D 00 72 51 D0 1E 20 6E 28 55 00 40 84 63 00
 50 | 00 1E 8C 0A D0 8A 20 E0 2D 10 10 3E 96 00 40 84
 60 | 63 00 00 18 00 00 00 00 00 00 00 00 00 00 00 00
 70 | 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 86
- 12 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
4.2.5.2.2. HD Model
■ HDMI 1-HD (C/S : 6F96)
 EDID Block 0, Bytes 0-127 [00H-7FH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
 10 | 01 18 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
 20 | 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 01 01
 30 | 01 01 01 01 01 01 66 21 50 B0 51 00 1B 30 40 70
 40 | 36 00 40 84 63 00 00 1E 64 19 00 40 41 00 26 30
 50 | 18 88 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A
 60 | 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC
 70 | 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 6F
 EDID Block 1, Bytes 128-255 [80H-FFH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 02 03 1C F1 48 10 22 20 05 84 03 02 01 26 15 07
 10 | 50 09 57 07 67 03 0C 00 10 00 80 1E 02 3A 80 18
 20 | 71 38 2D 40 58 2C 04 05 40 84 63 00 00 1E 01 1D
 30 | 80 18 71 1C 16 20 58 2C 25 00 40 84 63 00 00 9E
 40 | 01 1D 00 72 51 D0 1E 20 6E 28 55 00 40 84 63 00
 50 | 00 1E 8C 0A D0 8A 20 E0 2D 10 10 3E 96 00 40 84
 60 | 63 00 00 18 00 00 00 00 00 00 00 00 00 00 00 00
 70 | 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 96
■ HDMI 2-HD (C/S : 6F86)
EDID Block 0, Bytes 0-127 [00H-7FH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
 10 | 01 18 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
 20 | 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 01 01
 30 | 01 01 01 01 01 01 66 21 50 B0 51 00 1B 30 40 70
 40 | 36 00 40 84 63 00 00 1E 64 19 00 40 41 00 26 30
 50 | 18 88 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A
 60 | 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC
 70 | 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 6F
 EDID Block 1, Bytes 128-255 [80H-FFH]
 0 1 2 3 4 5 6 7 8 9 A B C D E F
 -----------------------------------------------------------------------------
 0 | 02 03 1C F1 48 10 22 20 05 84 03 02 01 26 15 07
 10 | 50 09 57 07 67 03 0C 00 20 00 80 1E 02 3A 80 18
 20 | 71 38 2D 40 58 2C 04 05 40 84 63 00 00 1E 01 1D
 30 | 80 18 71 1C 16 20 58 2C 25 00 40 84 63 00 00 9E
 40 | 01 1D 00 72 51 D0 1E 20 6E 28 55 00 40 84 63 00
 50 | 00 1E 8C 0A D0 8A 20 E0 2D 10 10 3E 96 00 40 84
 60 | 63 00 00 18 00 00 00 00 00 00 00 00 00 00 00 00
 70 | 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 86
4.3. Tool Option Input
- Input Model Tool Option according to BOM
5. Final Assembly Adjustment
5.1. White Balance Adjustment
5.1.1. Overview
5.1.1.1. W/B adj. Objective & How-it-works
(1) Objective: To reduce each Panel’s W/B deviation
(2) How-it-works: When R/G/B gain in the OSD is at 192, it
means the panel is at its Full Dynamic Range. In order to
prevent saturation of Full Dynamic range and data, one of
R/G/B is fixed at 192, and the other two is lowered to find
the desired value.
(3) Adj. condition: normal temperature
- Surrounding Temperature: 25±5 ºC
- Warm-up time: About 5 Min
- Surrounding Humidity: 20% ~ 80%
- Before White balance adjustment, Keep power on status,
don’t power off
5.1.1.2. Adj. condition and cautionary items
(1) Lighting condition in surrounding area surrounding lighting
should be lower 10 lux. Try to isolate adj. area into dark
surrounding.
(2) Probe location: Color Analyzer (CA-210) probe should be
within 10cm and perpendicular of the module surface
(80°~ 100°)
(3) Aging time
- After Aging Start, Keep the Power ON status during 5
Minutes.
- In case of LCD, Back-light on should be checked using no
signal or Full-white pattern.
5.1.2. Equipment
(1) Color Analyzer: CA-210 (NCG: CH 9 / WCG: CH12 / LED:
CH14)
(2) Adj. Computer(During auto adj., RS-232C protocol is
needed)
(3) Adjust Remocon
(4) Video Signal Generator MSPG-925F 720p/204-Gray
(Model:217, Pattern:49)
 → Only when internal pattern is not available
 ※ Color Analyzer Matrix should be calibrated using
CS-1000
- 13 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
5.1.3. Equipment connection
5.1.4. Adjustment Command (Protocol)
(1) RS-232C Command used during auto-adj
RS-232C COMMAND
Explanation
CMD DATA ID
Wb 00 00 Begin White Balance adj.
Wb 00 ff End White Balance adj.
(internal pattern disappears )
(2) Adjustment Map
Adj. item
Command
(lower case ASCII)
Data Range
(Hex.)
Default
(Decimal)
CMD1 CMD2 MIN MAX
Cool R Gain j g 00 C0 172
G Gain j h 00 C0 172
B Gain j i 00 C0 192
R Cut 128
G Cut 128
B Cut 128
Medium R Gain j a 00 C0 192
G Gain j b 00 C0 192
B Gain j c 00 C0 192
R Cut 128
G Cut 128
B Cut 128
Warm R Gain j d 00 C0 192
G Gain j e 00 C0 192
B Gain j f 00 C0 172
R Cut 128
G Cut 128
B Cut 128
5.1.5. Adjustment method
5.1.5.1. Auto WB calibration
(1) Set TV in ADJ mode using P-ONLY key (or POWER ON
key)
(2) Place optical probe on the center of the display
 - It need to check probe condition of zero calibration before
adjustment.
(3) Connect RS-232C Cable
(4) Select mode in ADJ Program and begin a adjustment.
(5) When WB adjustment is completed with OK message,
check adjustment status of pre-set mode (Cool, Medium,
Warm)
(6) Remove probe and RS-232C cable.
※ W/B Adj. must begin as start command “wb 00 00” , and
finish as endcommand “wb 00 ff”, and Adj. offset if need.
5.1.5.2. Manual adj. method
(1) Set TV in Adj. mode using POWER ON
(2) Zero Calibrate the probe of Color Analyzer, then place it on
the center of LCD module within 10cm of the surface..
(3) Press ADJ key -> EZ adjust using adj. R/C -> 6. White-
Balance then press the cursor to the right (KEY►).
 (When KEY(►) is pressed 204 Gray(80IRE) internal
pattern will be displayed)
(4) One of R Gain / G Gain / B Gain should be fixed at 192,
and the rest will be lowered to meet the desired value.
(5) Adj. is performed in COOL, MEDIUM, WARM 3 modes of
color temperature.
※ CASE
First adjust the coordinate far away from the target value(x, y).
(1) x, y > target
i) Decrease the R, G.
(2) x, y < target
i) First decrease the B gain,
ii) Decrease the one of the others.
(3) x >target , y < target
i) First decrease B, so make y a little more than the target.
ii) Adjust x value by decreasing the R
(4) x < target , y > target
i) First decrease B, so make x a little more than the target.
ii) Adjust x value by decreasing the G
► How to adjust
(1) Fix G gain at least 172
Adjust R, B Gain (In Case of Mostly Blue Gain Saturation)
(2) When R or B Gain > 255, Release Fixed G Gain and
Readjust
※ CASE Medium / Warm
First adjust the coordinate far away from the target value(x, y).
(1) x, y > target
i) Decrease the R, G.
(2) x, y < target
i) First decrease the B gain,
ii) Decrease the one of the others.
(3) x > target , y < target
i) First decrease B, so make y a little more than the target.
ii) Adjust x value by decreasing the R
(4) x < target , y > target
i) First decrease B, so make x a little more than the target.
ii) Adjust x value by decreasing the G
- 14 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
5.1.6. Reference
 (White Balance Adj. coordinate and color
temperature)
▪ Luminance: 204 Gray, 80IRE
**(normal line) Model : For LGD (LB56xx, LB55xx)
▪ Standard color coordinate and temperature us ing
CA-210(CH-14) – by aging time
H/R Time(Min)
Cool Medium Warm
x y x x y x
271 270 285 293 313 329
1 0-2 281 285 295 308 323 344
2 3-5 280 284 294 307 322 343
3 6-9 279 282 293 305 321 341
4 10-19 277 279 291 302 319 338
5 20-35 275 275 289 298 317 334
6 36-49 273 273 287 296 315 332
7 50-79 272 272 286 295 314 331
8 80-119 271 270 285 293 313 329
9 Over 120 271 270 285 293 313 329
**(aging chamber) Model : For LGD (LB56xx, LB55xx)
▪ Standard color coordinate and temperature using
CA-210(CH-14) – by aging time
H/R Time(Min)
Cool Medium Warm
x y x x y x
271 270 285 293 313 329
1 0-5 280 285 294 308 319 340
2 6-10 276 280 290 303 315 335
3 11-20 272 275 286 298 311 330
4 21-30 269 272 283 295 308 327
5 31-40 267 268 281 291 306 323
6 41-50 266 265 280 288 305 320
7 51-80 265 263 279 286 304 318
8 81-119 264 261 278 284 303 316
9 Over 120 264 260 278 283 303 315
5.2. Option selection per country
5.2.1. Overview
(1) Tool option selection is only done for models in Non-USA
North America due to rating
(2) Applied model: LA32B Chassis applied to CANADA and
MEXICO
5.2.2. Country Group selection
(1) Press ADJ key on the Adj. R/C, and then select Country
Group Menu
(2) Depending on destination, select US, then on the lower
Country option, select US, CA, MX.
 Selection is done using +, - KEY
(3) Using DFT(Auto)
※ PC (for communication through RS-232C) -> UART Baud
rate : 115200 bps
Command : ah 00 00 DATA(Area Number(hexadecimal))
ITEM DATA(Area Number) AREA
AREA OPTION1 0 USA
1 CANADA
2 MEXICO
5.2.3. Tool Option inspection
▪ Press Adj. key on the Adj. R/C, then select Tool option
Model Module Tool option1
Tool
option2
Tool
option3
Tool
option4
32LB5600-UH LGD 00529 01030 24716 20544
32LB550B-UC LGD 00529 13314 24716 20544
42LB5600-UH LGD 01297 01030 24716 20544
42LB5600-UH AUO 09488 01030 24716 20544
39LB5600-UH INX 17426 01030 24716 20544
32LB560B-UH SHARP 12816(MIRROR?) 09218 24716 20544
32LB560B-UH BOE 21008(MIRROR?) 09218 24716 20544
32LB560B-UH LGD 00529 09218 24716 20544
55LB5500-UC BOE 22800 05126 24716 20544
55LB5500-UC LGD 02321 05126 24716 20544
49LB5500-UC LGD 01809 05126 24716 20544
42LB5500-UC LGD 01297 05126 24716 20544
32LB550B-UC SHARP 12816 13314 24716 20544
※ Tool option can be reconstructed by Software
5.3. Ship-out mode check (In-stop)
- After final inspection, press In-Stop key of the Adj. R/C and
check that the unit goes to Stand-by mode
- 15 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
6. GND and HI-POT Test
6.1. GND & HI-POT auto-check preparation
(1) Check the POWER CABLE and SIGNAL CABE insertion
condition
6.2. GND & HI-POT auto-check
(1) Pallet moves in the station. (POWER CORD / AV CORD is
tightly inserted)
(2) Connect the AV JACK Tester.
(3) Controller (GWS103-4) on.
(4) GND Test (Auto)
 - If Test is failed, Buzzer operates.
 - If Test is passed, execute next process (Hi-pot test).
(Remove A/V CORD from A/V JACK BOX)
(5) HI-POT test (Auto)
 - If Test is failed, Buzzer operates.
 - If Test is passed, GOOD Lamp on and move to next
process automatically
6.3. Checkpoint
(1) Test voltage
 - GND: 1.5KV/min at 100mA
 - SIGNAL: 3KV/min at 100mA
(2) TEST time: 1 second
(3) TEST POINT
 - GND Test = POWER CORD GND and SIGNAL CABLE
GND.
 - Hi-pot Test = POWER CORD GND and LIVE & NEUTRAL.
(4) LEAKAGE CURRENT: At 0.5mArms
7. AUDIO output check
7.1. Audio input condition
(1) RF input: Mono, 1KHz sine wave signal, 100% Modulation
(2) CVBS, Component: 1KHz sine wave signal (0.4Vrms)
7.2. Specification
No Item Min Typ Max Unit Remark
1 Audio practical
max Output, L/R
(Distortion=10%
max Output)
9.0
8.5
10.9
9.3
12.0
9.8
W
Vrms
(1) Measurement
condition
- EQ/AVL/Clear
Voice: Off
(2) Speaker
(8Ω Impedance)
8. Eye Sensor Function check
(1) Press EYE key of Adj. R/C in dark room
(2) Check below two conditions in dark room
 i) Check if Check Result is OK.
 ii) Check if the Backlight value is lower than 40
 -> When Check Result is OK and Backlight value is lower
than 40, Eye Sensor operates normally.
(3) After coming out of Darkroom, check if Sensor Data value
and Backlight value rise
* USB S/W Download (option, Service only)
(1) Put the USB Stick to the USB socket.
(2) Automatically detecting update file in USB Stick.
- If your downloaded program version in USB Stick is Low,
it didn't work. But your downloaded version is High, USB
data is automatically detecting
(3) Show the message "Copying files from memory"
(4) Updating is staring.
(5) After updating is complete, The TV will restart automatically.
(6) If TV turns on, check your updated version and Tool option.
(refer to the next page about tool option)
* If downloading version is higher than your TV have, TV
can lost all channel data. In this case, you have to
channel recover. If all channel data is cleared, you didn't
have a DTV/ATV test on production line.
※After downloading, TOOL OPTION setting is needed again.
(1) Push "IN-START" key in service remote controller.
(2) Select "Tool Option 1" and Push “OK” button.
(3) Punch in the number. (Each model has their number.)
- 16 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
TROUBLE SHOOTING
1. Power-up boot check
Check stand-by Voltage.
P401 3, 5, 6pin : +3.5V_ST
Check 18pin Power connector
Main B/D 3.5V Line
Short Check
Check X201 clock
24 MHz
Replace X201
Check P401 PWR_ON.
1pin : 3.3V
Replace Mstar(IC101) or Main board
Check Multi Voltage
P401 9, 10pin : 24V
/ 13, 14, 15pin:12V
Replace Power Board
Check DRV ON Control
P401 2 pin : High
Check Power Board
Check IC402/3/4 Output Voltage
IC402 : 2.5V
IC403 : 1.5V
IC404 : 1.15V
Q403 : 3.3V
Replace IC402, IC403, IC404, Q403
Re-download software.
Check stand-by Voltage
L401,L404 : +3.5V
Replace L401, L404
Check LVDS Power Voltage
Q409 : 12V Replace Q409
Check Mstar LVDS Output Replace Mstar(IC101) or Main Board
Change Module
ok
ok
ok
ok
ok
ok
ok
ok
okNo
No
ok
Replace Power board.
ok
No
No
No
No
No
No
No
No
- 17 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
2. Digital/Analog TV Video
Check RF Cable & Signal
Check Tuner 3.3V Power
L3703 Replace L3703
Check Tuner 1.8V Power
IC3703 2 pin : 1.8V
Check IF_P/N Signal
TU3700 10/11 Pin
Replace IC3703
Check Mstar LVDS Output Replace Mstar(IC101) or Main Board.
ok
ok
ok
ok
No
No
No
No
Bad Tuner. Replace Tuner.
3. AV Video
Check input signal format.
Is it supported?
Check AV Cable for damage
for damage or open conductor
Check JK1701, CVBS Signal Line
R1707
ok
ok
ok
No
Replace Jack
ok
Check CVBS_DET Signal Replace R1713
No
Check Mstar LVDS Output Replace Mstar(IC101) or Main Board.
No
- 18 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
4. Component Video
Check input signal format.
Is it supported?
Check Component Cable
for damage or open conductor.
Check JK1701
Y/PB/PR signal Line
ok
ok
ok
No
Replace Jack
Check COMP_DET Signal Replace R1712 or R1713
No
Check Mstar LVDS Output Replace Mstar(IC101) or Main Board.
ok
No
5. HDMI Video
Check input signal format.
Is it supported?
Check HDMI Cable conductors
for damage or open conductor.
Check EDID
R810, R811, R815, R816 I2C Signal
Check JK800, JK801
ok
ok
ok
No
No
Replace the defective IC or re-download EDID data
ok
Replace Jack
Check HDMI Signal Check other set
If no problem, check signal line
ok
No
Check Mstar LVDS Output Replace Mstar(IC101) or Main Board.
ok
No
Replace Main Board
No
Check HDMI_DET (HPD) No Replace R808, R809, Q800, R803, R814
- 19 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
6. MHL Video
Check input signal format.
Is it supported?
Check MHL Cable conductors
for damage or open conductor.
Check MHL Signal (R214, R215)
Check JK801
ok
ok
ok
No
No
Replace the defective IC or re-download EDID data
ok
Replace Jack
Check MHL Signal Check other set
If no problem, check signal line
ok
No
Check Mstar LVDS Output Replace Mstar(IC101) or Main Board.
ok
No
Replace Main Board
No
Check CD_Sense, Cbus, Vbus No Replace R817, C800
- 20 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
7. All Source Audio
Check the TV Speaker Menu
(Menu -> Audio -> TV Speaker)
On
ok
ok
Check Output Signal P5600
1, 2, 3, 4 pin. Replace Audio AMP IC(IC5600)
ok
No
Check Connector & P5600 Replace connectorif found to be damaged.
ok
No
Check speaker resistance
and connector damage. Replace speaker.
ok
No
Off
Toggle the Menu
Check AMP IC(IC5600) Power
24V, 3.3V
No
Replace Amp IC(IC5600)
Check Mstar I2S Output
IC5600 20,21,22 Pin
No
Check signal line. Or replace Mstar(IC101)
Check Mstar AUDIO_MASTER_CLK
R148
No
Replace Mstar(IC101) or Main Board.
ok
Check AMP I2C Line
R140, R141
No
Check signal line. Or replace Mstar(IC101)
- 21 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
8. Digital/Analog TV Audio
Check RF Cable & Signal
Follow procedure
‘7. All source audio’
trouble shooting guide.
ok
Check Tuner 3.3V Power
L3703 Replace L3703
Check Tuner 1.8V Power
IC3703 2 pin : 1.8V
Check IF_P/N Signal
TU3700 10/11 Pin
Replace IC3703
ok
ok
ok
No
No
No
Bad Tuner. Replace Tuner.
9. AV Audio
Check AV Cable for damage
for damage or open conductor
Check JK1702 Signal Line
R1714,R1715
ok
ok
No
Replace Jack
Follow procedure
‘7. All source audio’
trouble shooting guide.
10. Component Audio
Check Component Cable
for damage or open conductor.
Check JK1702 Signal Line
R1714,R1715
ok
ok
No
Replace Jack
Follow procedure
‘7. All source audio’
trouble shooting guide.
- 22 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
BLOCK DIAGRAM
SP
D
IF
C
om
po
ne
nt
 H
D
M
I
D
_I
F
M
1
SE
R
IA
L
FL
AS
H
M
XI
C
 8
M
B
(6
4M
b)

M
X2
5L
64
06
EM
I
LV
D
S
(F
H
D
/H
D
 6
0z
)
U
SB
2.
0
D
P
/D
M
SP
K
 L
/R
X-
ta
l
24
M
H
z
FP
C(
51
P/
FH
D)
I2
S
S
P
D
IF
L/
R
Y
/P
b/
P
r,
 L
/RR
ea
r
TM
D
S
D
D
R
3
A
dd
.
D
D
R
3
D
at
a
S
P
I
AV
Si
de
TM
D
S
H
D
M
I
M
H
L
C
V
B
S
, L
/R
C
O
N
TR
O
L
IR
 &
 L
ED

K
E
Y
1
K
E
Y
2
IR
LE
D
_R
I2
C
R
S-
23
2C
FP
C(
30
P/
HD
)
M
AX
32
32
R
S
23
2C
C
LK
 6
67
M
H
z
In
te
rn
al

M
ic
om
(P
M
)
I2
C
D
D
R
3
12
8M
B
(1
G
b)

H
yn
ic
H
5T
Q
1G
63
D
FR
A
T2
4C
51
2C
-S
SH
D
-T
51
2k
 b
it
H
al
f N
IM
(S
I2
15
8B
_A
TS
C
_1
IN
PU
T)
A
_I
F
A
M
P
ST
A
38
0B
W
E
(C
LK
 8
00
M
H
z)
- 23 - LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
EXPLODED VIEW
Many electrical and mechanical parts in this chassis have special safety-related characteristics. These
parts are identified by in the Schematic Diagram and EXPLODED VIEW.
It is essential that these special safety parts should be replaced with the same components as
recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards.
Do not modify the original design without permission of manufacturer.
IMPORTANT SAFETY NOTICE
20
0
53
0
50
0
50
2
50
154
0
52
1
41
0
40
0
12
0
12
1
90
0
A
2
A
10
LV
1
* S
et
 +
 S
ta
nd
* S
ta
nd
 B
as
e
+
Bo
dy
THERMAL
T
H
E
R
M
A
L
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Power_PD2
2013/05/07
4_CI
NC4_S7LRM
Q407
MMBT3904(NXP)
E
B
CR426
10K
PANEL_VCC
PWM_DIM
Q401
MMBT3904(NXP)
E
B
C
R419
1K
R462
10K
R430
10K
C440
0.1uF
16V
Q400
MMBT3904(NXP)
E
B
C
R489
10K
+3.5V_ST
R439
33K
R445
2.2K
R443
10K
+12V
INV_CTL
R461
10K OPT
+3.5V_ST
R421
10K
Q405
MMBT3904(NXP)
E
B
C
+3.3V_Normal
L402
MLB-201209-0120P-N2
POWER_ON/OFF_1
RL_ON
+3.3V_Normal
+3.5V_ST
L407
MLB-201209-0120P-N2
+3.3V_Normal
C425
0.1uF
16V
R408 100
PANEL_CTL
051:AL22
R434
10K
R416
10K
R415
100
+3.5V_ST
C438
0.1uF
25V
OPT
+2.5V_Normal
R405
5.6K
R406
4.7K
R401
10K
R407
5.6K
R411
33K
OPT
Q402
MMBT3906(NXP)
1
2
3
PWM1
C403
10uF
10V
85C
IC402
TJ1118S-2.5
1
GND
2 OUT3IN
C437
22uF
10V
C423
2.2uF
10V
C443
10uF
16V
D402
5V
OPT
SD05
D405
5V
SD05
L404
CB2012PK501T
L412
UBW2012-121F
120OHM
R404
0
OPT
R414
0
D403
5V
C406
0.1uF
50V
+24V
L401
CB2012PK501T
+3.5V_ST
+12V
C401
10uF
10V
2012
+3.5V_POWER_DET
C404
4.7uF
50V
3216
C407
0.1uF
16V
C402
1uF
10V
1005
D401
5V
R428
3.9K
AVDD5V_MHL
C414
10uF
10V
+12V
C412
10uF
10V
R422
100K
OPT
MHL_5V_EN
R413
10K
C413
0.047uF
25V
10uF
C410
+5V_USB
R402
4.7K
OPT
U
S
B
1
_
O
C
D
+5V_Normal
+3.3V_Normal
/
M
H
L
_
O
C
P
_
D
E
T
R410
10K
C411
10uF
16V
C416
22uF
16V
USB1_CTL
R412
100K
L405
4.7uH
R424
10
5V_HDMI_4
+3.3V_Normal
R429
10K
OPT
Q406
OPT
E
B
C
R433
10K
OPT
R431
10K
OPT
Q408
OPT
E
B
C
R435
10K
OPT
MHL_OCP_EN
Q404
OPT
E
B
C
/VBUS_EN
MHL_5V_EN
R432
2.7K
OPT
R436
20K
L408
CB2012PK501T
10uF
C418
10V
+3.3V_Normal +1.5V_DDR
10uF
C417
10V
D404
2.5V
L406
BLM18PG121SN1D
R459
4.7K
OPT
C424
0.1uF
16V
OPT
R455
100K
POWER_DET
C422
0.1uF
16V
+24V +12V
POWER_DET_RESET
IC405
APX803D29
1
GND
3VCC 2 RESET
+3.5V_POWER_DET
+3.5V_POWER_DET
C433
0.1uF
R450
0
5%
OPT
R447
1.2K
1%
R446
2.7K
1%C420
1uF
10V
1005
OPT
R444
8.2K
1%
OPT
R458
100
OPT
+24V
IC406
APX803D29
OPT
1
GND
3VCC 2 RESET
R456
100K
OPT
+3.5V_ST
C419
1uF
10V
1005
OPT
R451
0
5%
OPT
C435
390pF
50V
L410
3.6uH
C430
0.1uF
16V
+3.5V_ST
C431
0.1uF
16V
C421
0.1uF
16V
OPT
C432
0.01uF
C429
10uF
10V
C428
270pF
50V
C426
22uF
10V C434
0.039uF
50V
R454
0
C427
22uF
10V
+3.3V_Normal
L409
CB2012PK501T
+1.10V_VDDC
D406
2.5V
C436
0.33uF
16V
R463
10K
L403
PZ1608U121-2R0TF
MHL_CD_SENSE
R464
10K
OPT
+3.3V_Normal
C408
100pF
50V
OPT
R403
4.7K
C409
4700pF
50V
C415
82pF
50V
R420
15K
R437
1K
1/16W
1%
R441
200
1/16W
1%
R460
2.7K
R438
22K
Q403
DMP2130L
G
DS
Q409
DMP2130L
G
DS
D407
30V
MBR230LSFT1G
C441
10uF
10V
OPT
C439
0.1uF
16V
R448
27K
1%
OPT
R449
5.1K
1%
OPT
TPS65282REGR
IC401
1
EN
3
SS
7
F
A
U
L
T
2
9
S
W
_
O
U
T
2
1
0
R
L
I
M
1
1
A
G
N
D
1
2
S
W
_
O
U
T
1
13
SW_IN_1
14
SW_IN_2
15
FB
16
LX_1
17
LX_2
18
BST
1
9
P
G
N
D
_
1
2
0
P
G
N
D
_
2
2
1
V
I
N
_
1
2
2
V
I
N
_
2
2
3
P
G
O
O
D
2
4
V
7
V
5
EN_SW2
8
F
A
U
L
T
1
6
EN_SW1
4
ROSC
2
COMP 25
[
E
P
]
G
N
D
IC404
TPS5432DDAR
3
PH
2
VIN
4
GND
1
BOOT
5
VSENSE
6
COMP
7
EN
8
SS
9
[EP]GND
IC403
AZ1117EH-ADJTRG1
ADJ/GND
OUTIN
R409
0
OPT
R457
100
IC5601
74LVC1G08GW
3
GND
2
A
4
Y
1
B
5
VCC
+3.3V_Normal
MHL_5V_EN
MHL_CD_SENSE
MHL_OCP_EN
R425
18K
1%
R427
3.3K
1%
C405
4.7uF
16V
P401
SMAW200-H18S5
14 12V
924V
4 PDIM#1
18 GND
1312V
8 PDIM#2
33.5V
17GND
12 GND
7GND
2 DRV ON
16 N.C
11GND
6 3.5V
1PWR ON
1512V
10 24V
53.5V
19
.
R453
30K
1%
R452
13K
1%
R440
12K
R442
0
PANEL_POWER
+2.5V_Normal
S7LR core 1.15V volt
+3.5V_ST --> 3.375V --> 3.46V
CHANGE TO
10UF/10V/X5R
+3.3V_Normal
Power_DET +24V --> 3.78V --> 3.92V (3.79V)FROM LIPS & POWER B/D +12V --> 3.58V --> 3.82V (3.68V)
L13 POWER BLOCK (POWER DETECT 2)
+5V_Normal & +5V_USB with OCP
Vout=0.8*(1+R1/R2)
4A
R1
R2
(Active Low)
(Active High)
R2
+1.5V_DDR
1.3A
R1
R1
3A
R2
Vout=1.25*(1+R2/R1)+Iadj*R2
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
U
S
B

D
O
W
N

S
T
R
E
A
M
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
13/03/27
USB 7
NC4_S7LRM
JK700
3
A
U
0
4
S
-
3
0
5
-
Z
C
-
(
L
G
) 1
2
3
4
5
D700
RCLAMP0502BA
OPT
SIDE_USB1_DM
SIDE_USB1_DP
+5V_USB
C700
22uF
10V
ZD700
5V
OPT
C701
5pF
50V
OPT
C702
5pF
50V
OPT
C703
22uF
10V
USB (SIDE)
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
2013/05/07
HDMI_R1_S1 8_CI
NC4_S7LRM
C800
0.047uF
25V
5V_HDMI_4
D801
MMBD6100
A
2
C
A
1
5V_DET_HDMI_2
VA801
ESD_HDMI1
R816 100
DDC_SDA_4
VA805
ESD_HDMI2
+5V_Normal
MHL_CD_SENSE
5V_HDMI_2
CK-_HDMI4
R813
3.3K
D804-*1
RCLAMP0524PA
ESD_HDMI1_SEMTECH
1
8
2
7
3
6
4
5
9
10
CK+_HDMI4
D803-*1
RCLAMP0524PA
ESD_HDMI1_SEMTECH
1
8
2
7
3
6
4
5
9
10
R806
2.7K
CK-_HDMI2
VA807
OPT
5.6V
R804
100
D2+_HDMI4
HDMI_ARC
D2-_HDMI4
D1+_HDMI4
CK+_HDMI2
DDC_SDA_2
D2+_HDMI2
D800
MMBD6100
A
2
C
A
1
D802
MMBD6100
A
2
C
A
1
HDMI_CEC
R809
10K
VA808
ESD_HDMI2
VA800
ESD_HDMI1
VA809
ESD_HDMI2
VA806
ESD_HDMI2
CEC_REMOTE_S7
VA803
ESD_HDMI1
5V_DET_HDMI_4
5V_HDMI_4
VA804
ESD_HDMI1
D1-_HDMI2
DDC_SDA_2
D2-_HDMI2
R802
1.8K
+3.5V_ST
D0+_HDMI4
R803
1K
D805-*1
RCLAMP0524PA
ESD_HDMI2_SEMTECH
1
8
2
7
3
6
4
5
9
10
5V_HDMI_2
R
8
0
5
3
.
3
K
+5V_Normal
HDMI_CEC
DDC_SDA_4
R808
10K
Q800
MMBT3904(NXP)
E
B
C
JK800
E
A
G
5
9
0
2
3
3
0
2
14
13
5
D1_GND
20
SHIELD
12
11
2
D2_GND
19
18
10
CK+
4
D1+
1
D2+
17
9
D0-
8
D0_GND
3
D2-
16
7
D0+
6
D1-
15
R801
2.7K
D806-*1
RCLAMP0524PA
ESD_HDMI2_SEMTECH
1
8
2
7
3
6
4
5
9
10
VA810
ESD_HDMI2
R815 100
DDC_SCL_2
D0+_HDMI2
DDC_SCL_4
D1-_HDMI4
R812
1.8K
R800
2.7K
D0-_HDMI2
HPD2
HPD4
HDMI_CEC
R817
300K
R811 100
R807
2.7K
VA802
ESD_HDMI1
DDC_SCL_2
VA811
ESD_HDMI2
R810 100
D1+_HDMI2
DDC_SCL_4
D0-_HDMI4
R814
100
JK801
E
A
G
6
3
5
3
0
1
0
1
SIDE_HDMI_EMI
14 NC
13 CE_REMOTE
5
D1_GND
20
GND
12 CK-
11 CK_GND
2
D2_GND
19 HP_DET
18 5V
10
CK+
4
D1+
1
D2+
17 GND
9
D0-
8
D0_GND
3
D2-
16 DDC_DATA
7
D0+
6
D1-
15 DDC_CLK
JK801-*1
51U019S-312HFN-E-R-B-LG
SIDE_HDMI_NON_EMI
14
RESERVED
13
CEC
5
TMDS_DATA1_SHIELD
20
BODY_SHIELD
12
TMDS_CLK-
11
TMDS_CLK_SHIELD
2
TMDS_DATA2_SHIELD
19
HOT_PLUG_DETECT
18
VDD[+5V]
10
TMDS_CLK+
4
TMDS_DATA1+
1
TMDS_DATA2+
17
DDC/CEC_GND
9
TMDS_DATA0-
8
TMDS_DATA0_SHIELD
3
TMDS_DATA2-
16
SDA
7
TMDS_DATA0+
6
TMDS_DATA1-
15
SCL
D805
IP4294CZ10-TBR
ESD_HDMI2_NXP
1
8
2
7
3
6
4
5
9
10
D806
IP4294CZ10-TBR
ESD_HDMI2_NXP
1
8
2
7
3
6
4
5
9
10
D803
IP4294CZ10-TBR
ESD_HDMI1_NXP
1
8
2
7
3
6
4
5
9
10
D804
IP4294CZ10-TBR
ESD_HDMI1_NXP
1
8
2
7
3
6
4
5
9
10
HDMI (REAR 1 / SIDE 1 MHL)
CEC
HDMI_2 MHLHDMI_1
MHL Spec
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
F
i
b
e
r

O
p
t
i
c
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. SPDIF
2012/06/12
10
NC4_S7LRM
+3.3V_Normal
SPDIF_OUT
JK1001
JST1223-001
SPDIF
1
GND
2
VCC
3
VINPUT
4
F
I
X
_
P
O
L
EC1002
68pF
50V
SPDIF-68pF
C1001
1uF
10V
OPT
C1002-*1
47pF
50V
SPDIF-47pF
C1002-*2
18pF
50V
SPDIF-18pF
SPDIF OPTIC JACK
5.15 Mstar Circuit Application
SPDIF
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. LVDS_NON_EU
2013/03/21
11
NC4_S7LRM
RXB0-
RXA0+
RXA0-
C1101
0.1uF
16V
HD
RXA2-
C1100
0.1uF
16V
FHD
RXA3-
RXBCK-
RXA1-
RXA1-
RXB4-
RXA2+
+3.3V_Normal
RXB1+
RXBCK+
PANEL_VCC
RXB3+
RXA0+
RXA3-
RXB4+
RXA4-
RXA4+
RXA1+
RXA2+
RXB2-
RXA1+
RXA2-
RXB1-
R1103
3.3K
OPT
RXACK+
RXA3+
RXA0-
PANEL_VCC
RXA3+
RXACK-
RXB2+
R1104
10K
OPT
RXB3-
RXB0+
P1100
FI-RE51S-HF-J-R1500
FHD
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
RXACK+
RXACK-
R1111 0
FHD
R1112 0
FHD
R1113 0
FHD
R1101
10K
OPT
R1100
3.3K
OPT
+3.3V_Normal
L1101
UBW2012-121F
120OHM
HD
L1100
UBW2012-121F
120OHM
FHD
+3.3V_Normal
VCOM_SCL
R1108
0
OPT
V-COM_SCL
V-COM_SDA
R1115
2K
OPT
R1109
0
OPT
R1114
2K
OPT
VCOM_SDA
VCOM_SCL
VCOM_SDA
P1101
10031HR-30
HD
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
VCOM_SDA
VCOM_SCL
RXB1-
RXB0-
RXA4+
RXA1-
Pol-change
RXB4+
RXACK+
RXBCK-
RXA0+
RXA2+
LVDS (NON EU)
RXA2+
RXBCK-
RXB4-
RXA3+
RXA1+
RXB2+
RXB3-
RXA3-
RXBCK-
RXACK-
RXA2+
RXA1-
RXB1-
RXB3-
RXA3+
RXA2-
RXA0+
RXA4+
Shift
RXBCK+
RXB2-RXA4+
[51Pin LVDS Connector]
 (For FHD 60Hz)
RXACK+
RXA3-
RXACK-
RXB3+
RXA3+
RXA1-
RXB0-
RXA0-
RXACK+
RXB3+
RXA4-
RXB3+
RXA4+
RXA2-
RXA2+
RXA1+
RXB2-
Pol-change
RXB4+
RXB1-
RXA4-
RXACK+
RXB3-
RXB0+
RXB3+
RXBCK+
RXB4-
RXA0+
RXA2+
RXB0+
RXB1+
RXA3-
RXA2-
RXBCK+
RXB4-
RXA0+
RXA4+
RXA2+
RXB3-
RXA0-
RXB0-
RXA4-
RXACK-
RXB0-
RXA4+
RXB2+
RXA1-
RXB2+
RXACK-
RXA3-
RXA1+
RXA3-
RXA1+
RXB3+
RXB3-
RXA3-
RXB1-
RXB4+
FOR FHD REVERSE(10bit)
RXB0+
RXB3-
RXA3+
RXA0+
RXA2- RXACK-
RXB1-
RXA3+
RXB2- RXBCK-
RXBCK+
RXA1+
RXA0-
RXA3+
RXA0-
RXB2+
RXB0-
RXA0-
RXB2-
RXACK-
MIRROR
RXB4-
RXA0-
RXB2+
RXA4+
RXB4-
RXA1+
RXB3+
RXB0+
RXB1+
RXA1-
RXA0-
RXA4-
RXB2-
Change in S7LR
RXA4-
RXB2+
MIRROR
RXB1-
RXA3+
RXA1-
RXACK+
RXB3+
RXB0+
RXB4-
RXACK+
RXB1+
RXACK-
RXA4-
RXA1-
RXA2-
RXA0+
RXB0-
RXB1+
RXB4+
RXB2+
RXBCK-
RXB0-
FOR FHD REVERSE(8bit)
RXBCK-
RXBCK+
RXB4+
RXB0+
RXB2-
RXA1+
RXBCK-
RXA2-
RXB1+
RXB1+
RXB1-
RXA4-
RXB4+
[30Pin LVDS Connector]
 (For HD 60Hz_Normal)
Change in S7LR
RXB1+
RXB3-
RXA2+
RXA3-
RXA2-
RXB2-
LVDS_SEL
RXBCK+
RXB4-
RXB0+
RXA0+
RXB4+
RXBCK+
RXACK+
EU pin assign is different from NON EU.
Because of position of HD wafer.
LVDS_SEL
V-COM I2C : For FHD 60Hz M+S module - 42LN54(M+S)
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
C3711
18pF
50V
R3740
1.8K
C3701
0.1uF
16V
TU_SCL
C3738
0.1uF
16V
R3741
1.8K
R3732
100
TUNER_RESET
TU3700
TDSS-H501F(B)
5
+B1[3.3V]
11
DIF[N]
2
RESET
10
DIF[P]
4
SDA
1
NC_1
9
IF_AGC
8
NC_3
3
SCL
7
+B2[1.8]
6
NC_2
12
SHIELD
A1
A1
B1
B1
IC3703
AP1117E18G-13
2
OUT
3 IN 1ADJ/GND
+3.3V_TU
+3.3V_TU
C3725
0.1uF
16V
IF_N_MSTAR
R3735 33
+1.8V_TU
C3741
10uF
10V
85C
C3715
22uF
6.3V
C3727
0.1uF
16V
R3761 0
+3.3V_TU
R3766
1
C3716
0.1uF
16V
C3737
100pF
50V
+1.8V_TU
R3733
100K
C3717
0.1uF
16V
IF_P_MSTAR
+3.3V_Normal
R3760 0
C3708
0.1uF
16V
C3740
0.1uF
16V
TU_SDA
IF_AGC_MAIN
C3710
0.1uF
16V
R3736 33
C3743
20pF
50V
OPT
+3.3V_TU
C3707
100pF
50V
+3.3V_TU
C3713
18pF
50V C3723
22uF
6.3V
R3704 100
L3703
UBW2012-121F
C3742
20pF
50V
OPT
2012.06.21NC4_S7LRM
TUNER_NON_EU 14
ATSC tuner block
1. should be guarded by ground
2. No via on both of them
3. Signal Width >= 12mils
 Signal to Signal Width = 12mils
 Ground Width >= 24mils
should be guarded by ground
Close to the tuner
Close to the tuner
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
COMP2_Pr+
R1714
10K
R1721
12K
R1715
10K
R1713
1K
R1704
470K
D1706
5.6V
OPT
R1712
1K
COMP2_Pb+
+3.3V_Normal
COMP2_DET
R1705
75
R1709
10K
COMP2_R_IN
R1703
470K
D1709
5.6V
OPT
R1710
10K
C1704
1000pF
50V
OPT
R1706
75
COMP2_L_IN
+3.3V_Normal
COMP2_Y+/AV_CVBS_IN
R1720
12K
AV_CVBS_DET
C1705
1000pF
50V
OPT
DTV/MNT_VOUT
R1723
75
OPT
+3.3V_Normal
C1706
0.1uF
OPT
C1707
0.1uF
OPT
4.7uF
C1708
OPT
IC1700
MM1756DURE
OPT
3
BIAS
2
GND
4
OUT
1
IN
6
VCC
5
PS
R1707
75
D1705
D1704
D1710
D1707
D1712
D1708
D1711
D1703
JK1701
PPJ245N2-01
5A [GN/YL]O-SPRING
6A [GN/YL]E-LUG
4A [GN/YL]CONTACT
5B [BL]O-SPRING
7C [RD1]E-LUG-S
5C [RD1]O-SPRING
4C [RD1]CONTACT
5D [WH]O-SPRING
4E [RD2]CONTACT
5E [RD2]O-SPRING
6E [RD2]E-LUG
R1708
75
OPT
2013.05.07NC4_S7LRM
REAR_NON_EU_L 17_CI
COMPONENT & AV(COMMON)
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
T
H
E
R
M
A
L
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
2013/05/07
AMP_TI 34_CI
NC4_S7LRM
R5601
10K
C5618
0.1uF
50V
C
5
6
1
3
2
2
0
0
p
F
5
0
V
L5600
UBW2012-121F
C5625
0.033uF
50V
C5609 4700pF
SPK_R+
C5601
0.1uF
50V
R5613
18
R5607
18K
1%
C5607
0.1uF
R5609
470
C5602
1000pF
50V
C5604
0.1uF
16V
AUD_LRCK
AMP_MUTE
C
5
6
1
5
1
u
F
2
5
V
AMP_RESET
SPK_L+
SPK_L+
+3.3V_Normal
+24V_AMP
AMP_SCL
R5600
10K
C5637
2200pF
50V
OPT
R5603
100
AUD_LRCH
C5619
0.1uF
50V
+3.3V_Normal
Z
D
5
6
0
0
5
V
O
P
T
+24V
AUD_SCK
C5621
10uF
35V
C5608
0.047uF
C5629
330pF
50V
+24V_AMP
SPK_R-
R5611
18
SPK_L-
AUD_MASTER_CLK
SPK_R-
C5620
10uF
35V
C
5
6
1
2
0
.
0
4
7
u
F
R5614
18
POWER_DET
C5626
330pF
50V
C5628
330pF
50V
C5636
2200pF
50V
OPT
C5614
0.1uF
+3.5V_ST
I
C
5
6
0
0
T
A
S
5
7
3
3
1
O
U
T
_
A
2
P
V
D
D
_
A
B
_
1
3
P
V
D
D
_
A
B
_
2
4
B
S
T
_
A
5
N
C
_
1
6
S
S
T
I
M
E
R
7
N
C
_
2
8
P
B
T
L
9
A
V
S
S
1
0
P
L
L
_
F
L
T
M
1
1
P
L
L
_
F
L
T
P
1
2
V
R
_
A
N
A
13AVDD
14A_SEL_FAULT
15MCLK
16OSC_RES
17DVSSO
18VR_DIG
19PDN
20LRCLK
21SCLK
22SDIN
23SDA
24SCL
2
5
R
E
S
E
T
2
6
S
T
E
S
T
2
7
D
V
D
D
2
8
D
V
S
S
2
9
G
N
D
3
0
A
G
N
D
3
1
V
R
E
G
3
2
G
V
D
D
_
O
U
T
3
3
B
S
T
_
D
3
4
P
V
D
D
_
C
D
_
1
3
5
P
V
D
D
_
C
D
_
2
3
6
O
U
T
_
D
37 PGND_CD_1
38 PGND_CD_2
39 OUT_C
40 NC_3
41 NC_4
42 BST_C
43 BST_B
44 NC_5
45 NC_6
46 OUT_B
47 PGND_AB_1
48 PGND_AB_2
4
9
[EP]
C5638
2200pF
50V
OPT
C
5
6
1
6
0
.
0
3
3
u
F
5
0
V
C5617 0.033uF
50V
Q5600
MMBT3904(NXP)
E
B
C
R
5
6
1
0
4
7
0
C5630
0.47uF
50V
R3405
0
OPT
C5639
2200pF
50V
OPT
AMP_SDA
SPK_L-
C5610
0.1uF
16V
C5606
0.1uF
16V
R5612
18
C5631
0.47uF
50V
+24V_AMP
C
5
6
1
1
4
7
0
0
p
F
SPK_R+
C5624
0.033uF
50V
C5627
330pF
50V
P5600
WAFER-ANGLE
1
2
3
4
R5608 2K
L5606
LPH6045T-100M
AMP_COIL_ABCO
10uH
L5603
LPH6045T-100M
AMP_COIL_ABCO
10uH
L5605
LPH6045T-100M
AMP_COIL_ABCO
10uH
L5604
LPH6045T-100M
AMP_COIL_ABCO
10uH
L5604-*1
10.0uH
AMP_COIL_GET
L5606-*2
10.0uH
AMP_COIL_TAIYO
L5603-*2
10.0uH
AMP_COIL_TAIYO
L5605-*2
10.0uH
AMP_COIL_TAIYO
L5605-*1
10.0uH
AMP_COIL_GET
L5604-*2
10.0uH
AMP_COIL_TAIYO
L5603-*1
10.0uH
AMP_COIL_GET
L5606-*1
10.0uH
AMP_COIL_GET
C5632
0.1uF
50V
C5633
0.1uF
50V
C5634
0.1uF
50V
C5635
0.1uF
50V
C5640
4.7uF
50V
OPT
C5641
4.7uF
50V
OPT
SPEAKER_R
AUDIO AMP(TI)
SPEAKER_L
Close to Speaker
This parts are Located
on AVSS area.
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
2012/06/20
MSTAR DEBUG_4PIN 39
NC4_S7LRM
RGB_DDC_SCL
RGB_DDC_SDA
J
P
_
G
N
D
2
J
P
_
G
N
D
3
J
P
_
G
N
D
4
J
P
_
G
N
D
1
P3900
12507WS-04L
1
2
3
4
5
MSTART DEBUG_4PIN
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. IR/CONTROL
2013/05/07
46_CI
NC4_S7LRM
+3.3V_Normal
R609
1KDigital Eye
R608
1K
Digital Eye
R600
100
SENSOR_SCL
P600
12507WR-08L
OPT
1
2
3
4
5
6
7
8
9
KEY1
R602
10K
1%
C605
18pF
50V
OPT
R607
3.3K
+3.5V_ST
R601
100
R605 100
Digital Eye
R604 100
Digital Eye
C606
18pF
50V
OPT
KEY2
C602
0.1uF
16V
IR
SENSOR_SDA
C603
1000pF
50V
R603
10K
1%
+3.5V_ST
R610
1.8K
LED_R/BUZZ+3.5V_ST
P601
12507WR-10L
1
2
3
4
5
6
7
8
9
10
11
C604
100pF
50V
C608
0.1uF
16V
OPT
C609
0.1uF
16V
OPT
L600
PZ1608U121-2R0TF
D601
D602
OPT
IR/LED and Control
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
2012/09/19
MAIN1_NON_EU 51
NC4_S7LRM
MODEL_OPT_5
R
1
2
1
1
K
R
1
2
4
1
K
R
1
1
6
1
K
R157 100
AMP_SDA
RXB3+
RXA4-
PWM2
RXB2+
RXA1-
R
1
1
5
1
K
O
P
T
R
1
2
3
1
K
O
P
T
RXACK-
PWM1
MODEL_OPT_3
+3.3V_Normal
PWM0
R177
10K
OPT
R151 33
MODEL_OPT_2
I2C_SDA
R174
10K
OPT
AMP_RESET
PANEL_CTL
RXA0-
C112
100pF
50V
OPT
PM_MODEL_OPT_0
R
1
5
3
1
K
LED_R/BUZZ
RXACK+
I2C_SCL
+3.3V_Normal
R144
2.2K
RXB4-
C105
0.1uF
LED_R/BUZZ
C106
8pF
OPT
R146 33
PM_TXD
R111 22
PM_MODEL_OPT_0
R140
1K
RGB_DDC_SCL
SPI_SDO
R176
10K
OPT
R
1
6
5
1
K
O
P
T
AUD_MASTER_CLK_0
PM_RXD
+3.5V_ST
+3.5V_ST
/FLASH_WP
RXA3-
RXA2+
I2C_SDA
RXB1-
MODEL_OPT_0
MODEL_OPT_4
RXA0+
I2C_SCL
RXA2-
R147 33
RXB4+
SPI_SDI
MODEL_OPT_6
USB1_OCD
R145
2.2K
R137 22
RXB1+
R141
1K
C104
8pF
OPT
KEY1
RL_ON
R
1
5
2
1
K
O
P
T
RXB0+
R156 10K
OPT
RXBCK-
PWM0
R136 22
RXA3+
AV_CVBS_DET
PM_MODEL_OPT_1
KEY2
5V_DET_HDMI_2
R148
56
AMP_SCL
R112 22
POWER_ON/OFF_1
I2C_SDA
R
1
1
7
1
K
O
P
T
PWM_DIM
PM_TXD
POWER_DET
MODEL_OPT_1
INV_CTL
R175
10K
OPT
R
1
1
8
1
K
/SPI_CS
RXB2-
SPI_SCK
PM_RXD
AMP_MUTE
PWM1
I2C_SCL
RXBCK+
PWM0
5V_DET_HDMI_4
RXB3-
MODEL_OPT_7
C111
2.2uF
OPT
R180
4.7K
RXA4+
+3.3V_Normal
RXB0-
AUD_SCK
USB1_CTL
RGB_DDC_SDA
AUD_MASTER_CLK
PWM2
RXA1+
IC101
MSD804KKX
PCMDATA[0]/GPIO129
W21
PCMDATA[1]/GPIO130
AA18
PCMDATA[2]/GPIO131
AB22
PCMDATA[3]/GPIO123
AE20
PCMDATA[4]/GPIO122
AA15
PCMDATA[5]/GPIO121
AE21
PCMDATA[6]/GPIO120
AB21
PCMDATA[7]/GPIO119
Y15
PCMADR[0]/GPIO128
W20
PCMADR[1]/GPIO127
V20
PCMADR[2]/GPIO125
W22
PCMADR[3]/GPIO124
AB18
PCMADR[4]/GPIO102
AA20
PCMADR[5]/GPIO104
AA21
PCMADR[6]/GPIO105
Y19
PCMADR[7]/GPIO106
AB17
PCMADR[8]/GPIO111
Y16
PCMADR[9]/GPIO113
AB19
PCMADR[10]/GPIO117
AB20
PCMADR[11]/GPIO115
AA16
PCMADR[12]/GPIO107
AA19
PCMADR[13]/GPIO110
AC21
PCMADR[14]/GPIO109
AA17
PCMREG_N/GPIO126
Y20
PCMOE_N/GPIO116
AB15
PCMWE_N/GPIO195
AA22
PCMIORD_N/GPIO114
AD22
PCMIOWR_N/GPIO112
AD20
PCMCE_N/GPIO118
AD21
PCMIRQA_N/GPIO108
AC20
PCMCD_N/GPIO133
Y18
PCMWAIT_N/GPIO103
Y21
PCM_RESET/GPIO132
Y22
PCM2_CE_N/GPIO134
U21
PCM2_IRQA_N/GPIO135
V21
PCM2_CD_N/GPIO138
R20
PCM2_WAIT_N/GPIO136
T20
PCM2_RESET/GPIO137
U22
UART1_TX/GPIO46
D4
UART1_RX/GPIO47
E4
UART2_TX/GPIO68
N25
UART2_RX/GPIO67
N24
UART3_TX/GPIO50
B8
UART3_RX/GPIO51
A8
I2C_SCKM2/DDCR_CK/GPIO75
P23
I2C_SDAM2/DDCR_DA/GPIO74
P24
DDCA_DA/UART0_TX
D2
DDCA_CK/UART0_RX
D1
PWM0/GPIO69
P21
PWM1/GPIO70
N23
PWM2/GPIO71
P22
PWM3/GPIO72
R21
PWM4/GPIO73
P20
PWM_PM/GPIO197
F6
SAR0/GPIO34
H6
SAR1/GPIO35
G5
SAR2/GPIO36
G4
SAR3/GPIO37
J5
SAR4/GPIO38
J4
VSYNC_LIKE/GPIO146
R23
SPI1_CK/GPIO199
R24
SPI1_DI/GPIO200
R25
SPI2_CK/GPIO201
T21
SPI2_DI/GPIO202
T22
NF_CE1Z/GPIO141
AE18
NF_WPZ/GPIO196
AC17
NF_CEZ/GPIO140
AD18
NF_CLE/GPIO139
AC18
NF_REZ/GPIO142
AC19
NF_WEZ/GPIO143
AD17
NF_ALE/GPIO144
AE17
NF_RBZ/GPIO145
AD19
GPIO_PM[0]/GPIO6
H5
PM_UART_TX/GPIO_PM[1]/GPIO7
K6
GPIO_PM[2]/GPIO8
K5
GPIO_PM[3]/GPIO9
J6
GPIO_PM[4]/GPIO10
K4
PM_UART_RX/GPIO_PM[5]/GPIO11
L6
PM_SPI_SCZ1/GPIO_PM[6]/GPIO12
C2
GPIO_PM[7]/GPIO13
L5
GPIO_PM[8]/GPIO14
M6
GPIO_PM[9]/GPIO15
M5
PM_SPI_SCZ2/GPIO_PM[10]/GPIO16
C1
GPIO_PM[11]/GPIO17
M4
PM_SPI_SCK/GPIO1
A2
PM_SPI_CZ0/GPIO_PM[12]/GPIO0
D3
PM_SPI_SDI/GPIO2
B2
PM_SPI_SDO/GPIO3
B1
TS0CLK/GPIO90
Y14
TS0VALID/GPIO88
AA10
TS0SYNC/GPIO89
Y12
TS0DATA_[0]/GPIO80
Y13
TS0DATA_[1]/GPIO81
Y11
TS0DATA_[2]/GPIO82
AA12
TS0DATA_[3]/GPIO83
AB12
TS0DATA_[4]/GPIO84
AA14
TS0DATA_[5]/GPIO85
AB14
TS0DATA_[6]/GPIO86
AA13
TS0DATA_[7]/GPIO87
AB11
TS1CLK/GPIO101
AC15
TS1VALID/GPI99
AD15
TS1SYNC/GPIO100
AC16
TS1DATA_[0]/GPIO91
AD16
TS1DATA_[1]/GPIO92
AE15
TS1DATA_[2]/GPIO93
AE14
TS1DATA_[3]/GPIO94
AC13
TS1DATA_[4]/GPIO95
AC14
TS1DATA_[5]/GPIO96
AD12
TS1DATA_[6]/GPIO97
AD13
TS1DATA_[7]/GPIO98
AD14
IC101
MSD804KKX
GPIO39
C7
GPIO40
E6
GPIO41
F5
GPIO42
B6
GPIO43
E5
GPIO44
D5
GPIO45
B7
GPIO48
E7
GPIO49
F7
GPIO52
AB5
GPIO53
AB3
GPIO54
A9
GPIO55
F4
I2C_SCKM0/GPIO56
AB1
I2C_SDAM0/GPIO57
N6
GPIO76
AB2
GPIO77
AC2
LVA0P
AB25
LVA0N
AB23
LVA1P
AC25
LVA1N
AB24
LVA2P
AD25
LVA2N
AC24
LVA3P
AE23
LVA3N
AC23
LVA4P
AC22
LVA4N
AD23
LVB0P
V23
LVB0N
U24
LVB1P
V25
LVB1N
V24
LVB2P
W25
LVB2N
W23
LVB3P
AA23
LVB3N
Y24
LVB4P
AA25
LVB4N
AA24
LVACLKP
AE24
LVACLKN
AD24
LVBCLKP
Y23
LVBCLKN
W24
GPIO194
T25
GPIO191
U23
GPIO192
T24
GPIO193
T23
/MHL_OCP_DET
MHL_OCP_EN
MODEL_OPT_8
SENSOR_SCL
SENSOR_SDA
V-COM_SCL
V-COM_SDA
IC104
AT24C512C-SSHD-T
NVRAM_ATMEL
3
A2
2
A1
4
GND
1
A0
5
SDA
6
SCL
7
WP
8
VCC
TUNER_RESET
IC104-*1
BR24G512FJ-3
EAN43349005
NVRAM_ROHM
3
A2
2
A1
4
GND
1
A0
5
SDA
6
SCL
7
WP
8
VCC
A0’h
PM MODEL OPTION
<CHIP Config(LED_R/BUZZ)>
Boot from SPI CS1N(EXT_FLASH) 1’b0
Boot from SPI_CS0N(INT_FLASH) 1’b1
SYM.D
EEPROM
<CHIP Config>
(I2S_OUT_BCK,I2S_OUT_MCK,PAD_PWM1PAD_PWM0)
I2C
B51_no_EJ : 4’b0000 Boot from 8051 with SPI flash
SB51_WOS : 4’b0001 Secure B51 without scramble
SB51_WS : 4’b0010 Secure B51 with scramble
MIPS_SPE_NO_EJ : 4’b0100 Boot from MIPS with SPI flash
MIPS_SPI_EJ_1 : 4’b0101 Boot from MIPS with SPI flash
MIPS_SPI_EJ_2 : 4’b0110 Boot from MIPS with SPI flash
MIPS_WOS : 4’b1001 Secure MIPS without scramble
MIPS_WS : 4’b1010 Scerur MIPS with SCRAMBLE
SYM.A
DIMMING
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
R230 100OPT
C258 0.1uF
C219 0.047uF
D0-_HDMI4
COMP2_Y+/AV_CVBS_IN
C257 0.1uF
+3.5V_ST
R
2
0
6
1
K
O
P
T
+3.3V_Normal
R204 100OPT
MODEL_OPT_4
AUD_LRCK
/VBUS_EN
AVDD5V_MHL
+3.3V_Normal
D1-_HDMI4
C
2
5
5
0
.
1
u
F
DDC_SCL_4
R
2
0
9
1
K
R296 100
SPDIF
DDC_SCL_2
MODEL_OPT_0
R237 33
AVDD_AU33
R
2
1
2
1
K
TP209
D0+_HDMI2
C240
0.1uF
+3.5V_ST
C218 0.047uF
+3.3V_Normal
AVDD_AU33
C220 0.047uF
CK+_HDMI4
D0-_HDMI2
CK+_HDMI2
C279
0.1uF
R240 68
CK-_HDMI4
C287
100pF
OPT
MODEL_OPT_2
AVDD2P5
C263
10uF
SOC_RESET
D0+_HDMI4
R
2
9
4
1
K
D1+_HDMI2 AUD_MASTER_CLK_0
R225 100OPT
IF_N_MSTAR
C223 0.047uF
IF_P_MSTAR
C274
0.1uF
MODEL_OPT_5
+1.10V_VDDC
AMP_SCL
HDMI_ARC
D1+_HDMI4
COMP2_Pr+
AVDD2P5
C256
0.1uF
COMP2_Pb+
HPD2
R
2
2
4
1
K
C282
0.1uF
R
2
2
6
1
K
H
D
C
2
0
9
0
.
1
u
F
C231 1uF
OPT
MODEL_OPT_1
SOC_RESET
COMP2_R_IN
R205
100
SWITCH
C285
0.047uF
25V
R252 68
R220
10K
C227 0.047uF
R
2
1
1
1
K
O
P
T
+1.5V_DDR
R288 100
IF_AGC_MAIN
AVDD2P5_MOD
MODEL_OPT_6
AUD_SCK
C201
0.1uF
R
2
9
1
1
K
O
P
T
CK-_HDMI2
+3.3V_Normal
C241
0.1uF
TU_SCL
C221 0.047uF
HPD4
DDC_SDA_4
AVDD_NODIE
R
2
9
0
1
K
O
P
T
R
2
2
2
1
K
O
P
T
R
2
8
7
1
M
R
2
2
7
1K
F
H
D
C273
0.1uF
MODEL_OPT_3
D2+_HDMI4
IR
C
2
8
3
0
.
1
u
F
R
2
0
8
1
K
O
P
T
C
2
5
9
0
.
1
u
F
SIDE_USB1_DP
R246 33
SPDIF_OUT
TU_SDA
R228 100OPT
FB_CORE
COMP2_L_IN
R210 0
OPT
VDD33
D2+_HDMI2
AUD_LRCH
SIDE_USB1_DM
VDD33
AVDD2P5_MOD
R200
62K
+1.10V_VDDC
D2-_HDMI2
VDD33
R266
470
OPT
+1.10V_VDDC
C
2
3
5
0
.
1
u
F
R239 33
R242 68
C242 2.2uF
+1.10V_VDDC
+2.5V_Normal
AVDD_NODIE
+1.10V_VDDC
COMP2_Y+/AV_CVBS_IN
D1-_HDMI2
R
2
0
7
1
K
R
2
9
3
1
K
C224 1000pF
DTV/MNT_VOUT
AMP_SDA
R241 33
D2-_HDMI4
C233 0.047uF
PM_MODEL_OPT_1
SW200
JTP-1127WEM
SWITCH
1
2 4
3
R238 68
C
2
4
5
0
.
1
u
F
C291
0.1uF
16V
C222 0.047uF
R
2
2
1
1
K
O
P
T
CEC_REMOTE_S7
FB_CORE
C243 2.2uF
MODEL_OPT_7R229 100
OPT
COMP2_DET
R289 100
R
2
2
3
1
K
POWER_DET_RESET
C286
0.1uF
+2.5V_Normal
DDC_SDA_2
MHL_CD_SENSE
IC101
MSD804KKX
RXACKP
J2
RXACKN
J3
RXA0P
K3
RXA0N
J1
RXA1P
K2
RXA1N
K1
RXA2P
L2
RXA2N
L3
DDCDA_DA/GPIO27
T5
DDCDA_CK/GPIO26
T4
HOTPLUGA/GPIO22
V5
HOTPLUGD/GPIO25
R5
RXCCKP
AE9
RXCCKN
AC9
RXC0P
AC10
RXC0N
AD9
RXC1P
AC11
RXC1N
AD10
RXC2P
AE11
RXC2N
AD11
DDCDC_DA/GPIO31
AE8
DDCDC_CK/GPIO30
AD8
HOTPLUGC/GPIO24
AC8
RXBCKP
F2
RXBCKN
F3
RXB0P
G3
RXB0N
F1
RXB1P
G2
RXB1N
G1
RXB2P
H2
RXB2N
H3
DDCDB_DA/GPIO29
R6
DDCDB_CK/GPIO28
U6
HOTPLUGB/GPIO23
P5
CEC/GPIO5
R4
HSYNC0
P2
VSYNC0
R3
RIN0P
N2
RIN0M
P3
GIN0P
N3
GIN0M
N1
BIN0P
M3
BIN0M
M2
SOGIN0
M1
HSYNC1
V2
VSYNC1
V3
RIN1P
U3
RIN1M
U2
GIN1P
T1
GIN1M
T2
BIN1P
R2
BIN1M
R1
SOGIN1
T3
HSYNC2
AA2
RIN2P
Y2
RIN2M
AA3
GIN2P
W2
GIN2M
Y3
BIN2P
V1
BIN2M
W3
SOGIN2
W1
CVBS0
AA8
CVBS1
Y4
CVBS2
W4
CVBS3
AA5
NC_5
Y5
NC_7
AA4
NC_6
Y6
CVBSOUT1
AA1
VCOM
AB4
NC_8
AC4
NC_9
AD3
IP
AC3
IM
AE3
SIFP
AD4
SIFM
AC5
IF_AGC
AD2
RF_AGC
AE2
I2C_SCKM1/GPIO78
AE6
I2C_SDAM1/GPIO79
AD6
XIN
AD1
XOUT
AC1
SPDIF_IN/GPIO150
D7
SPDIF_OUT/GPIO151
D6
USB0_DM
E3
USB0_DP
E2
USB1_DM
AC12
USB1_DP
AE12
I2S_IN_BCK/GPIO148
C8
I2S_IN_SD/GPIO149
D8
I2S_IN_WS/GPIO147
D9
I2S_OUT_BCK/GPIO154
B10
I2S_OUT_MCK/GPIO152
C9
I2S_OUT_SD/GPIO155
B9
I2S_OUT_WS/GPIO153
C10
AUL0
AB9
AUR0
AA11
AUL1
Y9
AUR1
AA9
AUL2
AA7
AUR2
AB8
AUL3
Y8
AUR3
Y10
AUL4
AC7
AUR4
AD7
GPIO_PM[13]/GPIO19
W6
AUOUTL2
V6
AVDD5V_MHL
V4
GPIO_PM[14]/GPIO20
Y7
AUOUTR2
W5
GPIO_PM[15]/GPIO21
U5
AUVRM
AD5
AUVAG
AE5
AUVRP
AC6
EARPHONE_OUTL
AA6
EARPHONE_OUTR
AB6
RP/GPIO63
C6
TP/GPIO60
C5
RN/GPIO66
A6
LED1/GPIO59
C4
TN/GPIO62
B5
GPIO61
C3
GPIO64
A3
GPIO65
B3
LED0/GPIO58
B4
IRIN/GPIO4
N4
ARC0
T6
HWRESET
N5
IC101
MSD804KKX
AVDDLV_USB
K12
VDDC_1
G9
VDDC_2
H9
VDDC_3
K10
VDDC_4
K11
VDDC_5
L10
VDDC_6
M12
VDDC_7
M13
VDDC_8
N12
VDDC_9
P14
VDDC_10
P15
VDDC_11
R10
VDDC_12
R14
VDDC_13
R15
VDDC_14
T10
NC_2
P10
FB_CORE
P19
AVDDL_MOD
R16
NC_1
L11
DVDD_DDR
M14
AVDD2P5_ADC_1
W9
AVDD2P5_ADC_2
W10
AVDD2P5_ADC_3
W11
AVDD2P5_ADC_4
W12
AVDD25_LAN
Y17
AVDD_MOD_1
V18
AVDD_MOD_2
U19
NC_3
W14
NC_4
W15
AVDD_NODIE
U7
AVDD_DVI_USB_1
L7
AVDD_DVI_USB_2
M7
AVDD3P3_MPLL
P7
AVDD_DMPLL
R7
DVDD_NODIE
M19
AVDD_AU33
V7
AVDD_EAR33
W7
VDDP_1
R19
VDDP_2
T19
AVDD_LPLL_1
W18
AVDD_LPLL_2
W19
VDDP_NAND
V19
AVDD_DDR0_D_1
J17
AVDD_DDR0_D_2
K15
AVDD_DDR0_D_3
K16
AVDD_DDR0_C
L15
AVDD_DDR1_D_1
K17
AVDD_DDR1_D_2
L17
AVDD_DDR1_D_3
M17
AVDD_DDR1_C
L16
GND_EFUSE
E9
GND_1
A23
GND_2
B17
GND_3
C23
GND_4
A5
GND_5
C11
GND_6
C19
GND_7
C22
GND_8
D14
GND_9
D18
GND_10
D19
GND_11
E17
GND_12
E18
GND_13
E19
GND_14
E22
GND_15
F8
GND_16
F17
GND_17
F18
GND_18
F19
GND_19
G8
GND_20
H8
GND_21
N22
GND_22
N21
GND_23
N20
GND_24
M22
GND_25
M21
GND_26
M20
GND_27
F10
GND_28
V15
GND_29
W16
GND_30
V8
GND_31
T18
GND_32
G10
GND_33
G11
GND_34
G12
GND_35
G13
GND_36
G14
GND_37
G17
GND_38
G18
GND_39
G19
GND_40
G24
GND_41
H11
GND_42
H12
GND_43
H13
GND_44
H14
GND_45
H15
GND_46
H16
GND_47
H17
GND_48
H18
GND_49
H19
GND_50
J9
GND_51
J10
GND_52
J11
GND_53
J12
GND_54
J13
GND_55
J14
GND_56
J15
GND_57
J16
GND_58
J18
GND_59
J19
GND_60
J25
GND_61
K9
GND_62
K13
GND_63
K14
GND_64
H10
GND_65
K18
GND_66
K19
GND_67
K22
GND_68
L8
GND_69
L9
GND_70
J8
GND_71
L12
GND_72
L13
GND_73
L18
GND_74
L19
GND_75
M8
GND_76
K8
GND_77
M10
GND_78
M11
GND_79
L14
GND_80
M15
GND_81
M16
GND_82
M18
GND_83
M25
GND_84
N10
GND_85
N11
GND_86
N13
GND_87
N14
GND_88
N15
GND_89
N16
GND_90
N17
GND_91
N19
GND_92
K7
GND_93
P8
GND_94
P9
GND_95
M9
GND_96
P11
GND_97
P13
GND_98
P16
GND_99
P17
GND_100
P18
GND_101
P12
GND_102
R8
GND_103
R9
GND_104
R11
GND_105
R12
GND_106
R13
GND_107
R17
GND_108
T8
GND_109
T9
GND_110
N7
GND_111
T11
GND_112
T12
GND_113
T13
GND_114
T14
GND_115
T15
GND_116
T16
GND_117
T17
GND_118
U8
GND_119
U9
GND_120
U10
GND_121
U11
GND_122
U12
GND_123
U13
GND_124
U14
GND_125
U15
GND_126
U16
GND_127
U17
GND_128
R18
GND_129
V9
GND_130
V10
GND_131
V11
GND_132
V12
GND_133
V14
GND_134
V17
GND_135
T7
GND_136
E8
1
0
u
F
1
0
V
C
2
0
4
8
5
C
1
0
u
F
1
0
V
C
2
8
4
8
5
C
10uF
10V
C269
85C
AVDD_DMPLL
AVDD_DMPLL
C205
0.1uF
C288
33pF
OPT
C289
33pF
OPT
C202
4.7uF
10V
OPT
C200
4.7uF
10V
C260
1uF
C
2
7
7
1
u
F
C
2
8
0
1
u
F
1
0
u
F
1
0
V
C
2
2
8
1
0
u
F
1
0
V
C
2
7
5
10uF
10V
C296
MODEL_OPT_8
R
2
9
8
1
K
O
P
T
R
2
9
7
1
K
O
P
T
R213 100OPT
+2.5V_Normal
C
2
5
4
1
u
F
C
2
0
7
0
.
1
u
F
1
0
u
F
1
0
V
C
2
7
8 C
2
4
8
0
.
1
u
F
C
2
6
6
0
.
1
u
F
+1.5V_DDR
C249
4.7uF
125C
C253
1uF
125C
R219
0
C252
1uF 10uF
C210
10uF
C206
10uF
C208
L227
PZ1608U121-2R0TF
L202
PZ1608U121-2R0TF
L206
PZ1608U121-2R0TF
L207
PZ1608U121-2R0TF
L211
PZ1608U121-2R0TF
L229
PZ1608U121-2R0TF
L208
PZ1608U121-2R0TF
L204
PZ1608U121-2R0TF
C211
0.1uF
X201
24MHz
C261 15pF
C262 15pF
C203
1uF
R214 10
R215 10
NC4_S7LRM
52_CI
2013/05/07
MAIN2_NON_EU
U23MODEL OPTION
MODEL_OPT_3
MODEL OPTION
MIU0-128M
0
TUNER_I2C
Normal Power 3.3V
I2S_I/F
HIGH
DTV_IF
S/W_NON_AJ
DDR3 1.5V
M120
MODEL_OPT_5
0
NON_M120
SOC_RESET
MIU0-256M
0
Close to MSTAR
PIN NAME
Close to MSTAR
Ginga
AB3
Memory OPTION
MODEL_OPT_6
CVBS In/OUT
U23
NON_DVB_T2
CHANGE TO X5R AUDIO IN
PIN NO.
1
MIU1-128M
FHD
MIU1-NO_DDR
Memory VDDC 1.05V
DVB_T2
MODEL_OPT_4
128M
HD
Close to MSTAR
COMP2
STby 3.5V
MODEL_OPT_6
T25
1256M
MODEL_OPT_4
1
SIDE USB
B8
A8
Note
MODEL_OPT_6
128M+128M
VDDC : 2026mA
AVDD25_PGA:13mA
NON_DVB_S DVB_ST24
AB2
LOW
S/W_AJ
B8
MODEL_OPT_1
MODEL_OPT_7
SYM.E
H
D
M
I
MODEL_OPT_0
1
MODEL_OPT_4
256M+128M
AVDD2P5:172mA
* Dual Stream is only Korea 3D spec
MODEL_OPT_2
Normal 2.5V
PIN NO. PIN NO.
SYM.C
F4
0
DUALSTREAMNON_DUALSTREAM
AVDD_DDR1:55mA
AVDD_DDR0:55mA
cDMS : X7R
(CL=12pF)
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. RS232C_PHONE
2012/06/21
53
NC4_S7LRM
R5302
100
R5301
100
D5301
ADUC 20S 02 010L
20V
OPT
IC5301
MAX3232CDR
EAN41348201
3
C1-
2
V+
4
C2+
1
C1+
6
V-
5
C2-
7
DOUT2
8
RIN2
9
ROUT2
10
DIN2
11
DIN1
12
ROUT1
13
RIN1
14
DOUT1
15
GND
16
VCC
D5302
20V
ADUC 20S 02 010L
OPT
C5302
0.1uF
PM_RXD
C5304
0.1uF
JK5301
KJA-PH-1-0177
3M3_DETECT
4M4
5M5_GND
1M1
6M6
C5306
0.1uF
C5305
0.1uF
C5303
0.1uF
+3.5V_ST
PM_TXD
R5309
0
OPT
RS-232C
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. M1_DDR(1DDR)
2012/06/21
54
NC4_S7LRM
A-MDMU
A-MWEB
A-MA7
A-MDQL5
A-MBA2
A-MCASB
A-MA8
A-MDQSU
A-MA12
A-MDQL7
A-MA14
A-MDQL2
R
1
2
3
6
5
6 1
%
A-MDQL0
A-MODT
A-MCASB
A-MA2
A-MDQU7
A-MA1
A-MDQL0
A-MDQL2
A-MA3
C
1
2
0
1
0
.
1
u
F
A-MDQL3
A-MDQU0
A-MA14
A-MDQL1
C
1
2
0
2 1
0
0
0
p
F
A-MDQSLB
A-MA4
A-MRESETB
A-MDQL4
A-MDML
R
1
2
0
1
1
K
1
%
A-MVREFDQ
A-MRESETB
A-MCKB
A-MDQU7
A-MODT
A-MA5
A-MDQU4
A-MCKE
A-MDQL3
A-MDMU
A-MA13
A-MVREFCA
R
1
2
0
2
1
K
1
%
A-MBA2
A-MDQL4
A-MDQU2
A-MBA1
A-MDQSLB
R
1
2
0
5
1
K
1
%
A-MDQU2
R1203
240
1%
A-MDQSU
R1231
10K
A-MBA0
A-MDQU1
A-MDQU5
A-MA5
A-MRASB
A-MDQU1
A-MDQSL
A-MDQSUB
A-MA9A-MA9
R
1
2
3
5
5
6 1
%
A-MDQSL
A-MDQU3
C
1
2
0
4 1
0
0
0
p
F
A-MCKE
A-MVREFDQ
A-MDML
A-MA10 A-MA10
A-MDQU0
A-MA4
A-MA13
A-MBA1
A-MBA0
A-MDQU3
A-MA11
A-MDQL6
A-MCK
A-MDQU6
A-MA2
A-MA12
A-MDQSUB
C
1
2
0
3
0
.
1
u
F
A-MWEB
A-MA8
A-MRASB
A-MVREFCA
A-MDQL5
A-MA0
A-MDQU4
A-MDQU5
A-MDQL7
A-MDQU6
A-MA6
A-MA0
A-MDQL6
A-MA3
A-MCKB
A-MA7
A-MDQL1
A-MA11
A-MA1
A-MA6
A-MCK
R
1
2
0
4
1
K
1
%
+1.5V_DDR
C
1
2
0
6
0
.
1
u
F
C1209
0.01uF
50V
C
1
2
3
9
0
.
1
u
F
C1213 0.1uF
C1208 0.1uF
C1211 0.1uF
C1214 0.1uF
C1212 0.1uF
C1210 0.1uF
C1215 0.1uF
C1207 0.1uF
IC101
MSD804KKX
A_DDR3_A[0]
A11
A_DDR3_A[1]
C14
A_DDR3_A[2]
B11
A_DDR3_A[3]
F12
A_DDR3_A[4]
C15
A_DDR3_A[5]
E12
A_DDR3_A[6]
A14
A_DDR3_A[7]
D11
A_DDR3_A[8]
B14
A_DDR3_A[9]
D12
A_DDR3_A[10]
C16
A_DDR3_A[11]
C13
A_DDR3_A[12]
A15
A_DDR3_A[13]
E11
A_DDR3_A[14]
B13
A_DDR3_BA[0]
F13
A_DDR3_BA[1]
B15
A_DDR3_BA[2]
E13
A_DDR3_MCLK
C17
A_DDR3_MCLKZ
A17
A_DDR3_MCLKE
B16
A_DDR3_ODT
E14
A_DDR3_RASZ
B12
A_DDR3_CASZ
A12
A_DDR3_WEZ
C12
A_DDR3_RESET
F11
A_DDR3_DQSL
B19
A_DDR3_DQSLB
C18
A_DDR3_DQSU
B18
A_DDR3_DQSUB
A18
A_DDR3_DQML
E15
A_DDR3_DQMU
A21
A_DDR3_DQL[0]
D17
A_DDR3_DQL[1]
G15
A_DDR3_DQL[2]
B21
A_DDR3_DQL[3]
F15
A_DDR3_DQL[4]
B22
A_DDR3_DQL[5]
F14
A_DDR3_DQL[6]
A22
A_DDR3_DQL[7]
D15
A_DDR3_DQU[0]
G16
A_DDR3_DQU[1]
B20
A_DDR3_DQU[2]
F16
A_DDR3_DQU[3]
C21
A_DDR3_DQU[4]
E16
A_DDR3_DQU[5]
A20
A_DDR3_DQU[6]
D16
A_DDR3_DQU[7]
C20
B_DDR3_A[0]
B23
B_DDR3_A[1]
D25
B_DDR3_A[2]
F22
B_DDR3_A[3]
G22
B_DDR3_A[4]
E24
B_DDR3_A[5]
F21
B_DDR3_A[6]
E23
B_DDR3_A[7]
D22
B_DDR3_A[8]
D24
B_DDR3_A[9]
D21
B_DDR3_A[10]
C24
B_DDR3_A[11]
C25
B_DDR3_A[12]
F23
B_DDR3_A[13]
E21
B_DDR3_A[14]
D23
B_DDR3_BA[0]
G20
B_DDR3_BA[1]
F24
B_DDR3_BA[2]
F20
B_DDR3_MCLK
G25
B_DDR3_MCLKZ
G23
B_DDR3_MCLKE
F25
B_DDR3_ODT
D20
B_DDR3_RASZ
B25
B_DDR3_CASZ
B24
B_DDR3_WEZ
A24
B_DDR3_RESET
E20
B_DDR3_DQSL
K24
B_DDR3_DQSLB
K25
B_DDR3_DQSU
J21
B_DDR3_DQSUB
J20
B_DDR3_DQML
H24
B_DDR3_DQMU
L20
B_DDR3_DQL[0]
L23
B_DDR3_DQL[1]
J24
B_DDR3_DQL[2]
L24
B_DDR3_DQL[3]
J23
B_DDR3_DQL[4]
M24
B_DDR3_DQL[5]
H23
B_DDR3_DQL[6]
M23
B_DDR3_DQL[7]
K23
B_DDR3_DQU[0]
G21
B_DDR3_DQU[1]
L22
B_DDR3_DQU[2]
H22
B_DDR3_DQU[3]
K20
B_DDR3_DQU[4]
H20
B_DDR3_DQU[5]
L21
B_DDR3_DQU[6]
H21
B_DDR3_DQU[7]
K21
C120510uF10V
C122710uF10V
C
1
2
5
1
1
0
u
F
1
0
V
C
1
2
1
7
1
u
F
C
1
2
1
8
1
u
F
C
1
2
1
9
1
u
F
C
1
2
3
8
1
u
F
C
1
2
4
1
1
u
F
+1.5V_DDR +1.5V_DDR
+1.5V_DDR
+1.5V_DDR
H5TQ1G63EFR-PBC
IC1201
DDR_HYNIX
EAN61829003
A0
N3
A1
P7
A2
P3
A3
N2
A4
P8
A5
P2
A6
R8
A7
R2
A8
T8
A9
R3
A10/AP
L7
A11
R7
A12/BC
N7
NC_7
T3
NC_5
M7
BA0
M2
BA1
N8
BA2
M3
CK
J7
CK
K7
CKE
K9
CS
L2
ODT
K1
RAS
J3
CAS
K3
WE
L3
RESET
T2
DQSL
F3
DQSL
G3
DQSU
C7
DQSU
B7
DML
E7
DMU
D3
DQL0
E3
DQL1
F7
DQL2
F2
DQL3
F8
DQL4
H3
DQL5
H8
DQL6
G2
DQL7
H7
DQU0
D7
DQU1
C3
DQU2
C8
DQU3
C2
DQU4
A7
DQU5
A2
DQU6
B8
DQU7
A3
VREFCA
M8
VREFDQ
H1
ZQ
L8
VDD_1
B2
VDD_2
D9
VDD_3
G7
VDD_4
K2
VDD_5
K8
VDD_6
N1
VDD_7
N9
VDD_8
R1
VDD_9
R9
VDDQ_1
A1
VDDQ_2
A8
VDDQ_3
C1
VDDQ_4
C9
VDDQ_5
D2
VDDQ_6
E9
VDDQ_7
F1
VDDQ_8
H2
VDDQ_9
H9
NC_1
J1
NC_2
J9
NC_3
L1
NC_4
L9
NC_6
T7
VSS_1
A9
VSS_2
B3
VSS_3
E1
VSS_4
G8
VSS_5
J2
VSS_6
J8
VSS_7
M1
VSS_8
M9
VSS_9
P1
VSS_10
P9
VSS_11
T1
VSS_12
T9
VSSQ_1
B1
VSSQ_2
B9
VSSQ_3
D1
VSSQ_4
D8
VSSQ_5
E2
VSSQ_6
E8
VSSQ_7
F9
VSSQ_8
G1
VSSQ_9
G9
K4B1G1646G-BCK0
IC1201-*1
DDR_SAMSUNG
A0
N3
A1
P7
A2
P3
A3
N2
A4
P8
A5
P2
A6
R8
A7
R2
A8
T8
A9
R3
A10/AP
L7
A11
R7
A12/BC
N7
A13
T3
NC_5
M7
BA0
M2
BA1
N8
BA2
M3
CK
J7
CK
K7
CKE
K9
CS
L2
ODT
K1
RAS
J3
CAS
K3
WE
L3
RESET
T2
DQSL
F3
DQSL
G3
DQSU
C7
DQSU
B7
DML
E7
DMU
D3
DQL0
E3
DQL1
F7
DQL2
F2
DQL3
F8
DQL4
H3
DQL5
H8
DQL6
G2
DQL7
H7
DQU0
D7
DQU1
C3
DQU2
C8
DQU3
C2
DQU4
A7
DQU5
A2
DQU6
B8
DQU7
A3
VREFCA
M8
VREFDQ
H1
ZQ
L8
VDD_1
B2
VDD_2
D9
VDD_3
G7
VDD_4
K2
VDD_5
K8
VDD_6
N1
VDD_7
N9
VDD_8
R1
VDD_9
R9
VDDQ_1
A1
VDDQ_2
A8
VDDQ_3
C1
VDDQ_4
C9
VDDQ_5
D2
VDDQ_6
E9
VDDQ_7
F1
VDDQ_8
H2
VDDQ_9
H9
NC_1
J1
NC_2
J9
NC_3
L1
NC_4
L9
NC_6
T7
VSS_1
A9
VSS_2
B3
VSS_3
E1
VSS_4
G8
VSS_5
J2
VSS_6
J8
VSS_7
M1
VSS_8
M9
VSS_9
P1
VSS_10
P9
VSS_11
T1
VSS_12
T9
VSSQ_1
B1
VSSQ_2
B9
VSSQ_3
D1
VSSQ_4
D8
VSSQ_5
E2
VSSQ_6
E8
VSSQ_7
F9
VSSQ_8
G1
VSSQ_9
G9
CLose to Saturn7M ICCLose to DDR3
SYMBOL.B
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
/FLASH_WP
C5501
0.1uF
R5504
33
SPI_SCK
R5503
4.7K
OPT
SPI_SDO
SPI_SDI
+3.5V_ST
/SPI_CS
+3.5V_ST
IC1300
MX25L6406EM2I-12G
SFLASH_MX
3
WP
2
SO/SIO1
4
GND
1
CS
5
SI/SIO0
6
SCLK
7
HOLD
8
VCC
IC1300-*1
W25Q64FVSSIG
SFLASH_WINBOND
3
WP[IO2]
2
DO[IO1]
4
GND
1
CS
5
DI[IO0]
6
CLK
7
%HOLD[IO3]
8
VCC
R5508
10K
OPT
R5507
10K
OPT
+3.5V_ST
R5505
0
S_FLASH_NON_OS
2013/05/07
55_CI
NC4_S7LRM
Serial Flash for SPI boot_NON_OS
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
	#EV#
