Journal Pre-proof
Treatment Outcomes of Manual Lymphatic Drainage in Pediatric
Lymphedema
Kausar Ali MD , Rami Dibbs BA , Catherine Dougherty PT, DPT ,
Ionela Iacobas MD , Renata Maricevich MD
PII: S0890-5096(21)00563-X
DOI: https://doi.org/10.1016/j.avsg.2021.06.021
Reference: AVSG 5897
To appear in: Annals of Vascular Surgery
Received date: May 5, 2021
Revised date: June 10, 2021
Accepted date: June 11, 2021
Please cite this article as: Kausar Ali MD , Rami Dibbs BA , Catherine Dougherty PT, DPT ,
Ionela Iacobas MD , Renata Maricevich MD , Treatment Outcomes of Manual Lym-
phatic Drainage in Pediatric Lymphedema, Annals of Vascular Surgery (2021), doi:
https://doi.org/10.1016/j.avsg.2021.06.021
This is a PDF file of an article that has undergone enhancements after acceptance, such as the addition
of a cover page and metadata, and formatting for readability, but it is not yet the definitive version of
record. This version will undergo additional copyediting, typesetting and review before it is published
in its final form, but we are providing this version to give early visibility of the article. Please note that,
during the production process, errors may be discovered which could affect the content, and all legal
disclaimers that apply to the journal pertain.
© 2021 Elsevier Inc. All rights reserved.
https://doi.org/10.1016/j.avsg.2021.06.021
https://doi.org/10.1016/j.avsg.2021.06.021
 1
Treatment Outcomes of Manual Lymphatic Drainage in Pediatric Lymphedema 1
Kausar Ali MD
1
, Rami P. Dibbs BA
1
, Catherine Dougherty PT, DPT
2
, Ionela Iacobas MD
2
, 2
Renata S. Maricevich MD
1,2
 3
1
Division of Plastic Surgery, Baylor College of Medicine, Houston, TX, USA 4
2
Division of Hematology/Oncology, Texas Children’s Hospital, Houston, TX, USA 5
Corresponding Author 6
Renata Souza Maricevich, MD 7
6701 Fannin St. Suite 610.00 8
Houston, TX. 77030 9
Phone: (832) 822-3180 10
Fax: (832) 825-3192 11
renata.maricevich@bcm.edu 12
 13
Short running title: Pediatric Lymphedema Manual Lymphatic Drainage 14
 15
Financial Disclosures / Commercial Associations: none 16
Sources of Support: none 17
Products / Devices / Drugs: none 18
Declaration of Interest: none 19
 20
 21
 22
 23

 2
Abstract 24
Background: Pediatric lymphedema can result in irreversible, debilitating limb swelling, 25
tissue fibrosis, skin ulcers, infection, and impaired limb function in children at an early age. 26
Manual lymphatic drainage (MLD) is a noninvasive technique, which is a part of intensive 27
decongestive therapy to reroute lymphatic flow to healthy channels used to manage 28
lymphedema. Outcomes of this treatment option in children have not been studied. We 29
evaluated the effect of decongestive therapy involving MLD in pediatric patients with 30
complex lymphatic anomalies by measuring treatment progress and functional outcomes via 31
changes in limb circumference, limb functionality, dexterity, skin quality, and pain. 32
Methods: A single-institution retrospective study on a cohort of eight pediatric patients with 33
lymphatic anomalies who completed a course of MLD was conducted from 2015 to 2017 to 34
investigate the role MLD plays in their lymphedema reduction. Pain scores were measured 35
on a scale of 0-10, with 0 being no pain and 10 being the worst pain imaginable. The 36
functional performance was measured by the Canadian Occupational Performance 37
Measurement questionnaire. 38
Results: Among all patients, there were four cases affecting the upper extremities, four 39
affecting the lower extremities, and three affecting the truncal region. 5 of 8 patients 40
demonstrated a reduction in lymphedema with an average girth reduction of 8.2% in the 41
lower extremities, 3.0% in the upper extremities, and 7.4% in the truncal regions. In 42
unilateral cases, the difference in limb circumference between the affected and normal 43
extremity decreased by an average of 25.6%. Four patients completed the Canadian 44
Occupational Performance Measurement questionnaire with an average improvement of 45
30% in daily task performance. Three patients reported complete resolution of pain. 46

 3
Conclusions: MLD can be used as a reliable noninvasive method for decongestion and 47
analgesia to delay the onset of lymphedema-associated fibrosis and long-term disability in 48
children with complex lymphatic malformations. 49
Keywords: pediatric, lymphedema, manual lymphatic drainage, outcomes, noninvasive 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69

 4
Introduction 70
Lymphedema is an abnormal collection of lymphatic fluid in the interstitial space, 71
resulting in protein and long-chain fatty acid accumulation, limb swelling, poor 72
immunologic responses, and eventually tissue fibrosis and impaired extremity function.
1
 In 73
the pediatric population, the majority of patients have primary lymphedema, usually due to 74
congenital lymphatic malformations or dysplasia of the lymphatic system.
1-2
 Some children 75
have limb swelling from lymphedema or complex, mixed vascular anomalies associated 76
with congenital syndromes like Milroy disease and Klippel-Trenaunay syndrome. 77
Decongestive therapy should be employed as early as possible to delay the onset of 78
the debilitating effects of lymphedema, such as tissue fibrosis, skin ulcers, infections, 79
functional disabilities, immobility, and psychosocial impairment.
3
 A wide array of 80
modalities are implemented in decongestive programs to treat lymphedema. Noninvasive 81
options include manual lymphatic drainage (MLD), decongestive exercises, compression 82
bandage, Kinesio Tape, lymphatic pumps, sclerotherapy, and sirolimus for lymphatic 83
anomalies.
1
 Invasive options include lymphovenous bypass surgery and autologous lymph 84
node transplantation.
4-5
 85
MLD is an established technique to treat lymphedema through superficial manual 86
therapy, which stimulates smooth muscle contractility of the lymphatic channels and 87
redirects lymphatic fluid towards existing healthy drainage tracts.
1
 This form of 88
decongestive therapy opens up collateral lymphatic routes, enhances reabsorption of 89
lymphatic load, and promotes lymphatic contractility for improved lymphatic outflow. The 90
Vodder technique is one of several methods to perform MLD and is performed five times 91
per week spanning about 4-6 weeks depending on the extremity affected and bilateral and/or 92

 5
truncal involvement.
6
 This method involves a constant change in pressure and stretching of 93
the skin along the affected limb in order to promote lymphangiomotricity and soften 94
fibrosis. Decongestion and softening of tissue through this MLD technique alleviates pain, 95
relaxes muscles, and over time improves limb dexterity and overall function.
6
 96
Few studies have described the use of MLD in children with lymphatic disease. 97
Pereira de Godoy et al. describe using their own manual drainage technique in a 16 year-old 98
female with primary lymphedema, achieving successful and stable edema reduction.
7
 99
Lasinksi et al. and Lopera et al. describe the benefits of combined MLD and compression 100
garment therapy for decongestion, but these studies were performed in adults.
8,9
 In our 101
study, we evaluate the effect of decongestive therapy involving MLD in pediatric patients 102
with complex lymphatic anomalies by measuring treatment progress and functional 103
outcomes through changes in limb circumference, limb functionality, dexterity, skin quality, 104
and pain. By exploring outcomes, MLD has great potential in being a part of intensive 105
decongestive therapy courses for reducing lymphedema and has possible long-term 106
sustainability, as the techniquecan be learned and performed at home for maintenance 107
therapy. 108
 109
Material and Methods 110
Patient population 111
An Institutional Review Board-approved retrospective chart review was performed 112
to look at outcomes of an intensive decongestive therapy course that included MLD for 113
lymphedema management in pediatric patients. Chart review was performed on all pediatric 114
patients with lymphedema who were referred to the outpatient Vascular Anomalies Center at 115

 6
Texas Children’s Hospital between 2015-2017. The primary outcome of the study was 116
reduction in lymphedema. Multiple secondary outcomes were also investigated, including 117
pain level, skin and tissue quality, and functionality and dexterity of the affected limbs. The 118
patients underwent an intensive MLD course, which entailed 60 to 120-minute sessions 119
occurring 3-5 times per week for a total of 4-6 weeks administered by a certified 120
lymphedema therapist (CLT). Selection criteria for patients in the study included at or below 121
18 years of age, diagnosis of extremity lymphedema and associated syndromes, and 122
completion of the intensive decongestive therapy program that included MLD. Patients with 123
deep vein thrombosis, acute infection in affected limb(s), known cardiac conditions causing 124
edema (i.e. congestive heart failure, severe hypertension, etc.), or other sources of 125
edematous extremities (i.e. renal failure, liver failure, malignancy) were excluded from the 126
study. 127
Data collection and analysis 128
Age, sex, and lymphedema diagnosis were recorded for each patient. The duration of 129
each therapy session and total length of the intensive MLD course was noted. Compliance 130
with the therapy was determined by missed sessions. In addition, the use of any concomitant 131
therapy during the MLD course, such as compression garments, sirolimus treatments, and 132
Kinesio Tape, were recognized. 133
Patients served as their own control with baseline measurements taken prior to 134
initiation of MLD and final measurements taken immediately upon completion of the 135
intensive MLD program at the final session. Pre- and post-MLD data points collected 136
included weight, limb girth of the affected extremity(s) and trunk, pain scores, and 137
functional limb performance. Limb girth was measured along the extremity distally to 138

 7
proximally. For example, in patients with upper extremity lymphedema, limb girth was 139
measured at the distal interphalangeal (DIP) joints, proximal interphalangeal (PIP) joints, 140
metacarpophalangeal (MCP) joints, wrist (radiocarpal joint), mid-forearm, elbow, mid-arm, 141
and axilla. In lower extremity lymphedema, limb girth was measured at midtarsal joint, 142
midfoot at the level of the navicular bone, ankle at the level of the malleoli, mid-calf, knee, 143
and mid-thigh. Truncal girth was also measured along the nipple line, mid ribs, distal ribs, 144
umbilicus, and ASIS planes. Pain scores were measured on a scale of 0-10, with 0 being no 145
pain and 10 being the worst pain imaginable. Functional performance was measured before 146
and after MLD therapy using the validated Canadian Occupational Performance 147
Measurement (COPM) questionnaire, which is an individualized measure to detect changes 148
in perception of performance over time and to quantify functionality and activity 149
performance of patient identified tasks.
10,11
 Only patients at or above the age of 1 were 150
eligible to take this validated questionnaire. Patients completed the questionnaires with 151
assistance from parents if needed. 152
To evaluate the primary outcome of lymphedema reduction, each patient’s total body 153
weight and limb circumference of the affected extremities were compared before and after 154
MLD. The percent change of weight and limb girth measurements from baseline (pre-155
therapy) to post-therapy were calculated (post-therapy measurement minus pre-therapy 156
measurement, difference divided by pre-therapy measurement). Positive results indicated an 157
increase from baseline, while negative results indicated a decrease from baseline. In patients 158
with unilateral lymphedema, the limb circumference of the affected extremity was also 159
compared to that of the normal contralateral extremity both before and after MLD. The 160
difference in normal and affected extremity measurements was compared before and after 161

 8
therapy as a percent change to understand how similar the treated extremity became to 162
normal unaffected limb after MLD therapy. In addition, pain scores, self-reported 163
functionality scaled by the COPM, weight-bearing status, dexterity measured by fine motor 164
skills, and skin quality (erythema, softening of tissue, and vesicles) were reviewed in clinical 165
documentation by the CLT as additional secondary measures before and after MLD therapy. 166
Finally, subsequent treatments provided after completion of the MLD program were noted 167
for each patient. 168
 169
Results 170
Our study included eight pediatric patients with a diagnosis of extremity swelling 171
and lymphedema who completed intensive decongestive therapy involving MLD. The 172
median age of our sample was 9.8 years with a range of five months to 18 years. Each 173
patient’s demographics, lymphedema diagnosis and associated condition, indication for 174
referral to the vascular anomalies clinic, and prior lymphedema treatments are described in 175
Table 1. The details of each patient’s MLD course, such as compliance with sessions and 176
concomitant therapies, are also shown. 177
All but two patients (75%) had full compliance with the MLD sessions. One patient 178
missed a single session each during her upper extremity and lower extremity MLD courses 179
and thus, had 83 and 97% completion rates, respectively. The second patient had been 180
admitted to the hospital during her final week of the MLD program and could only complete 181
88% of the sessions. 182
There was an average reduction in limb circumference measurements after MLD 183
compared to baseline (pre-therapy) measurements (Table 2). Average girth decreased by 184

 9
8.2% in lower extremities, 3.0% in the upper extremities, and 7.4% in truncal regions after 185
undergoing MLD (Figure 1). These reductions in average girth resulted in visibly apparent 186
changes in extremity lymphedema following MLD (Figure 2). Proximal and distal regions 187
of the upper and lower extremities had an approximately equal percent reduction in girth. 188
Overall, five out of eight patients demonstrated reduction in lymphedema volume, 189
which was defined as a decrease in both weight and limb girth following decongestive 190
therapy with MLD. Interestingly, patient #4 had a 12% increase in weight and girth increase 191
after MLD, which could be due to her normal growth rate and low absolute weight where 192
even small increases in weight and girth appear as a large overall percent increase. 193
In the unilateral lymphedema cases, the difference in limb circumference between 194
the affected and normal contralateral extremity decreased by an average of 25.6% after 195
MLD. In other words, the limb circumference of the affected extremity was reduced and 196
closer to the circumference of the normal side following MLD. However, the affected 197
extremity did not completely reach the same size as the normal limb at a 1:1 ratio. 198
Overall, even if a patient did not experience impressive reduction in limb 199
circumference, MLD provided a variety of secondary clinical benefits for the patients and 200
were documented in CLT reports (Table 3). For example, Patient #2 did not have a 201
significant decrease in lymphedema, but she still had palpablesoftening in her soft tissues 202
with decreased skin folds and improved truncal mobility. Three patients reported being pain-203
free (score 0) at the completion of MLD. Additionally, patients had improved skin changes, 204
such as reduced erythema and resolution of lymphatic vesicles, as described in CLT 205
documentation. Patients who presented with gait impairment due to lower extremity 206
lymphedema had improved mobility, weight-bearing status, and better fit of shoes. Patients 207

 10
with upper extremity lymphedema had more refined motor skills (i.e. Patient #3 had 40% 208
improvement in his keyboard use following MLD therapy). 209
The COPM questionnaire has been validated for its use in the pediatric 210
population.
10,11
 When looking at validated COPM questionnaires for a more standard 211
method to evaluate functional improvement, performance in daily tasks was found to 212
improve by an average of 30% (Table 4). However, only half of the patients in the study 213
completed COPM forms - two patients did not submit the post-therapy portion and another 214
two patients were ineligible to participate due to being under the age limit of 1. Given that 215
only four patients completed the COPM questionnaire, it is difficult to make definitive 216
conclusions. However, with greater limb girth reduction, there appeared to be a greater 217
degree of improvement in functional outcomes (Tables 2, 4). 218
Of the five patients who had lymphedema reduction following MLD, three still went 219
on to receive further treatment due to residual or recurring lymphedema. The most common 220
subsequent therapy provided was sclerotherapy. Patient #6 underwent a lymphovenous 221
bypass to her external jugular vein five months following MLD in order to improve her 222
extremity and face/neck lymphedema. 223
 224
Discussion 225
Pediatric lymphedema can result in progressive and debilitating fibrotic changes to 226
tissue. As the condition worsens over time, patients lose the dexterity to perform essential 227
motor functions required for activities of daily living.
3
 Poor functional performance 228
progresses to immobility if lymphedema is not addressed as soon as possible. Thus, manual 229
drainage techniques have been implemented by vascular anomalies centers to treat pediatric 230

 11
lymphedema. Outcomes-based research on MLD in the pediatric population is scant. This 231
study hopes to shed light on the beneficial features of MLD in children suffering from 232
lymphedema in order to combat the debilitating, progressive changes that lead to poor 233
function and disability. 234
In this study, MLD was able to promote reduction in lymphedema in 62.5% of 235
patients with average girth reductions of 8.2% in lower extremities, 3.0% in the upper 236
extremities, and 7.4% in truncal regions. Changes in limb circumference hold more value in 237
determining lymphedema reduction than weight, since weight changes tended to be 238
unreliable in infants and pubertal patients undergoing normal growth spurts. 239
MLD via the Vodder technique incorporates superficial manual therapy sequentially 240
from the trunk, then from proximal to distal regions of the extremity, and lastly back up to 241
the proximal regions.
6
 By beginning in proximal and truncal areas, this technique can recruit 242
large healthy accessory tracts in central areas to absorb lymphatic fluid. Subsequently, when 243
massaging the distal areas of the limb, lymphatic load can be pumped out proximally into 244
these recruited healthy lymphatic tracts for a reduction in both proximal and distal 245
lymphedema. Our study corroborates this report by showing approximately equal reductive 246
effects in proximal and distal limb girth after MLD. 247
MLD can also contribute to pronounced clinical improvements even if girth itself is 248
not significantly changed. Such improvements include palpable softening of soft tissue, 249
resolution of skin erythema and lymphatic vesicles, and analgesia.
6
 Through decongestion 250
and rerouting of lymphatic fluid to healthy outflow tracts, patients can gain dexterity with 251
enhanced gait, weight-bearing status, and clinical function, which was seen in our patient 252
population as demonstrated by improved validated functional performance scores after MLD 253

 12
therapy.
6
 In our study, one of the patients who did not have impressive reduction in limb 254
circumference did have clinically improved soft tissue softening and truncal mobility. Based 255
on these findings, this study highlights how MLD may improve a patient’s functional status 256
even if the actual absolute amount of lymphedema is not substantially reduced. Additionally, 257
despite varying levels of reduced limb girth following MLD therapy, functional 258
improvement was evident in all patients who completed the COPM questionnaires. 259
The underlying diagnosis and etiology of lymphedema plays a role in how extensive 260
and progressive lymphedema becomes. As Greives et al. reports, most diagnoses of pediatric 261
primary lymphedema involve abnormal lymphatic channels due to malformations or 262
dysplasia, though they can also involve poor contractility of lymphatic smooth musculature.
2
 263
However, MLD techniques may not be able to completely overcome significant lymphatic 264
accumulation in pediatric patients with widespread abnormal lymphatic anatomy and 265
dysfunctional vessels due to their underlying condition.
9,12
 Lack of girth reduction after 266
MLD was seen in three patients in our study diagnosed with generalized lymphatic anomaly, 267
CLOVES syndrome, and thigh malformation. These patients may have had less pronounced 268
improvements in limb girth and skin quality as a result of missing or dysfunctional 269
lymphatic channels.
 9,12
 270
Despite decongestive therapy involving MLD, subsequent therapy may be necessary 271
to treat residual lymphedema or to address recurring lymphedema in severe cases.
9
 In our 272
study, 60% of patients with lymphedema reduction after MLD still received subsequent 273
lymphedema therapy. Long-term data on maintenance of girth reduction was unable to be 274
obtained due to missed appointments after completion of the MLD program. MLD may 275
improve lymphedema temporarily and provide favorable outcomes for patients, but it is not 276

 13
enough to permanently cure the disease. In addition, MLD may benefit as a noninvasive 277
strategy to treat limb swelling and lymphedema temporarily, but the time and financial 278
burden of frequent MLD sessions as well as maintenance therapy at home may be difficult 279
to manage for some children and families. 280
Two CLTs treated all patients in the study, which eliminated variability in MLD 281
techniques used. Due to the retrospective design of the study, there are certain limitations to 282
account for. A large issue in lymphedema treatment outcomes research is poor patient 283
compliance and high dropout rates. For this reason, our study had a lack of power with a 284
small sample size as we found few patients who 1) qualified for MLD and 2) completed all 285
sessions with appropriate measurements taken. Additionally, it is difficult to ascertain the 286
effectiveness of MLD in one patient over another when the severity of lymphedema varied 287
between patients. Patients with more advanced-stage lymphedema may not have as 288
noticeable results from MLD due to their more significantly abnormal lymphatic anatomy 289
and dysfunction with potentially irreversible lymphedema changes in skin and soft tissue. 290
Lastly, it is important to note that while all patients had simultaneous compression garment 291
therapy during their MLD sessions, some also had concomitant sirolimus or a lymphatic292
pump. These concomitant therapies can be included as part of the overall decongestive plan 293
for an additive or synergistic effect in lymphedema reduction by preventing re-accumulation 294
of fluid in tissues and pumping lymphatic preload towards healthy collateral drainage tracts 295
recruited by MLD.
7
 Thus, while measurements compared in this study were pre- and post-296
MLD, the reduction in lymphedema cannot be attributed to MLD alone because 297
simultaneous compression bandage therapy, sirolimus, or lymphatic pump, may have 298
contributed towards reduction in girth. 299

 14
Large, prospective studies are needed to further evaluate the effectiveness of MLD 300
and determine MLD’s long-term sustainability for lymphedema reduction in children. 301
Overall, MLD is a reliable noninvasive technique that can be taught to parents or guardians 302
for maintenance therapy at home after completion of the outpatient intensive decongestive 303
therapy program. Continued maintenance self-therapy at home with MLD and compression 304
garment usage allows for more independence for the family and may improve the stability of 305
lymphedema reduction long-term in children with chronic lymphedema; however, the long-306
term effects and sustainability of MLD is currently still unknown and difficult to assess. 307
Selection of patients who would benefit would depend on the underlying condition and 308
etiology of limb swelling, severity of the disease, and feasibility for children and families to 309
participate in frequent MLD sessions as part of their overall intensive decongestive therapy 310
program. 311
 312
Conclusion 313
Manual lymphatic drainage is not a cure, but it can provide decongestion to help 314
ameliorate manifestations of progressive lymphedema, such as limb swelling, pain, impaired 315
limb function and dexterity, tissue fibrosis, skin ulcers, and infection. While it may not be 316
successful for all patients, MLD can attempt to counteract the debilitating effects of fibrosis 317
secondary to lymphedema at an early age and help preserve activity performance and limb 318
functionality before these effects become irreversible. It can also be performed at home for 319
maintenance therapy at the convenience of the patient and families. Overall, MLD, while not 320
a definitive cure, provides a bridge in treatment until more permanent solutions are widely 321
available. 322

 15
 323
 324
 325
 326
 327
References 328
1. Damstra RJ, Mortimer PS. Diagnosis and therapy in children with lymphedema. 329
Phlebology 2008;23(6):276-286 330
2. Greives MR, Aldrich MB, Sevick-Muraca EM, Rasmussen JC. Near-Infrared 331
fluorescence lymphatic imaging of a toddler with congenital lymphedema. 332
Pediatrics 2017;139(4): e20154456 333
3. Greene A, Meskell P. The impact of lower limb chronic oedema on patients’ 334
quality of life. Int Wound J 2017;14(3):561-568 335
4. Hadamitzky C, Pabst R, Gordon K, Vogt PM. Surgical procedures in lymphedema 336
management. J Vasc Surg Venous Lymphat Disord 2014;2(4):461-468 337
5. Mehrara BJ, Zampell JC, Suami H, Chang DW. Surgical management of 338
lymphedema: Past, present, and future. Lymphat Res Biol, 2011;9(3):159-67 339
6. Kasseroller RG. The Vodder school: the Vodder method. Cancer 1998;83(12 Suppl 340
American):2840-2842 341
7. Pereira de Godoy LM, Pereira de Godoy Capeletto P, de Fátima Guerreiro Godoy 342
M, Pereira de Godoy JM. Lymphatic drainage of legs reduces edema of the arms in 343
children with lymphedema. Case Rep Pediatr 2018:6038907 344

 16
8. Lasinski BB, McKillip Thrift K, Squire D, Austin MK, Smith KM, Wanchai A, 345
Green JM, Stewart BR, Cormier JN, Armer JM. A systematic review of the 346
evidence for complete decongestive therapy in the treatment of lymphedema from 347
2004 to 2011. PM R 2012;4(8):580-601 348
9. Lopera C, Worsley PR, Bader DL, Fenlon D. Investigating the short-term effects of 349
manual lymphatic drainage and compression garment therapies on lymphatic 350
function using near-infrared imaging. Lymphat Res Biol 2017;15(3):235-240 351
10. Verkerk GJQ, van der Molen-Meulmeester L, Alsem MW. How children and 352
their parents value using the Canadian Occupational Performance Measure 353
(COPM) with children themselves. J Pediatr Rehabil Med. 2021;14(1):7-17 354
11. Verkerk GJ, Wolf MJ, Louwers AM, Meester-Delver A, Nollet F. The 355
reproducibility and validity of the Canadian Occupational Performance Measure 356
in parents of children with disabilities. Clin Rehabil. 2006 Nov;20(11):980-8 357
12. Olszewski WL. Contractility patterns of human leg lymphatics in various stages of 358
obstructive lymphedema. Ann N Y Acad Sci 2008;1131:110-118 359
 360
 361
 362
 363
 364
 365
 366
 367

 17
 368
 369
 370
 371
Figure Legends 372
Figure 1. Mean and range of percent reductions in limb girth for each patient. The left half 373
of the graph shows cases of upper extremity manual lymphatic drainage, while the right half 374
shows cases of lower extremity manual lymphatic drainage. 375
 376
Figure 2. A patient with bilateral lower extremity lymphedema before manual lymphatic 377
drainage who has more notable edema, loss of skin folds, and poorly fitting shoes on the 378
right as compared to the left (left). After manual lymphatic drainage, limb girth has 379
improved in the right extremity, and the patient continues to wear compression garment for 380
maintenance of lymphedema reduction (right).381

 18


Table 1. Demographics, diagnosis, and the course of lymphedema treatment are described for each patient.
 Age
(yrs)
Sex Diagnosis Area of
lymphedema
Indication for
MLD referral
Prior treatments MLD sessions Concomitant
therapy
Compliance
1 13 M Left UE capillary-
lympho-venous
malformation
Left hand to
hemithorax, scar
contractures in
left digits
Severe pain,
lymphatic
vesicles, impaired
ROM
Compression garment,
sclerotherapy,
debulking surgeries
UE: 3 per week
for 5 weeks
Compression
bandage
100% completion
2 0.75 F CLOVES syndrome -
bilateral UE and chest
lymphatic
malformations
Bilateral UE and
trunk
Impaired function
and gross motor
delay
Compression garment,
sirolimus
UE: 4 per week
for 6 weeks
Compression
bandage
Missed 3 sessions
(88% completion)
3 18 M Blue rubber bleb
nevus syndrome
Left hand and
forearm
Severe pain,
impaired hand
function and fine
motor skills
Compression garment,
sclerotherapy,
debulking of hand
venous malformation
UE: weekly for 6
weeks
Compression
bandage,
sirolimus
100% completion
4 0.4 F Left thigh congenital
lymphatic
malformation
Left LE Impaired ROM None LE: 4 per week
for 8 weeks
Kinesio Tape 100% completion
5 17 F Generalized
lymphatic anomaly
Bilateral LE, right
UE, and abdomen
Impaired ROM
and overall
mobility, fibrotic
skin
Compression garment,
diuretics, sirolimus
LE: 4 per week
for 6 weeks
UE: weekly for 4
weeks
Compression
bandage,
lymphedema
pump
LE and UE: 100%
completion
6 6 F Generalized
lymphatic anomaly
Bilateral UE and
LE, neck, and
abdomen
Severe pain,
impaired ROM,
poor posture
Compression garment,
diuretics, sirolimus
LE: 4 per week
for 8 weeks
UE: weekly for 6
weeks
Compression
bandage,
sirolimus
LE: missed 1
session (97%
completion); UE:
missed 1 session
(83% completion)
7 16 M Left LE lymphatic
malformation
Left LE Impaired ROM Compression garment LE: 4 per week
for 5 weeks
Compression
bandage,
sirolimus
100% completion
8 7 M Klippel-Trenaunay
syndrome
Right LE
lymphedema
Impaired
function and
ROM
Compression garment LE: 3 per week
for 4 weeksCompressio
n bandage
100%
completion
UE = upper extremity, LE = lower extremity, ROM = range of motion

 19
 1
 2
Table 2. Aggregate percent change in weight, limb girth, and truncal girth after completion 3
of manual lymphatic drainage in each patient (calculation: post-therapy measurement minus 4
pre-therapy measurement, difference divided by pre-therapy measurement). Negative 5
percent changes illustrate a reduction from baseline, while positive percent changes illustrate 6
an increase from baseline. Ranges are used for the upper and lower extremities to include 7
measurements of different levels of the limb measured (i.e. proximal versus distal regions). 8
 9
 Weight Proximal
UE girth
Distal
UE girth
Proximal
LE girth
Distal
LE girth
Truncal
girth
Lymphedema
reduction
1 (-) 4% (-) 1-7% (-) 4-10% - - 0% Yes
2 (-) 2% (+) 2-6% (-) 0-6% - - (-) 4-22% No
3 (+) 5% (-) 0-10% (-) 0-5% - - - Yes
4 (+) 12% - - (+) 3-17% (+) 0-6% - No
5 (-) 19% (-) 0-3% 0% (-) 6-24% (-) 4-20% (-) 7-11% No
6 (-) 2% - - (-) 13-26% (-) 11-27% (-) 5-20% Yes
7 0% - - (-) 1-5% (-) 0-5% - Yes
8 0% - - (-) 4-18% (-) 4-8% - Yes
UE = upper extremity, LE = lower extremity 10
 11
 12
Table 3. Secondary outcomes of manual lymphatic drainage in each patient. Pain levels are 13
scaled 0-10, with 0 being no pain and 10 being the worst pain imaginable. 14
 15
 Improved
dexterity
Skin/tissue
softening
Initial
Pain
Final
pain
Other clinical
findings
Subsequent
therapy
1 Yes Yes 10/10 0/10 Resolution of skin
erythema/vesicles
No
2 No Yes - - Improved truncal mobility Yes
3 Yes Yes 4/10 0/10 Improved fine motor
skills/keyboard use
Yes
4 No No - - Unchanged soft tissue bulk,
but more weight bearing
Yes
5 No No - - Improved lower extremities,
not upper extremities
Yes
6 Yes Yes 4/10 0/10 Improved motor strength Yes
7 Yes Yes - - Improved range of motion No
8 Yes Yes - - Improved gait and fit of shoes Yes
 16
 17
 18
 19
Table 4. Percent changes in performance ratings of self-identified tasks in the Canadian 20
Occupational Performance Measurement questionnaire after MLD. 21
 22
 Patient #1 Patient #3 Patient #7 Patient #8
Total performance
scores
48%  72% 20%  38% 75%  87.5% 30%  90%

 20
Percent
improvement
24% 18% 12.5% 60%
Identified Tasks
Pincer grasp, zipper
closure and
grabbing food with
left hand, gripping
blade and lever
when mowing lawn,
keyboard typing
Picking up a pencil
and sandwich,
turning doorknob,
carrying a box,
using Xbox
controller
Walking > 1
block, running,
lifting heavy
object, running,
taking shower or
bath on own,
completing
chores around
the house
Taking pants and
socks on/off,
jumping, picking
up things from
floor, running
without leaning to
the side, running
endurance in
soccer
 23
 24
 25
 26
 27
