C3NORMAL CHECKLIST
26 OCT 22
COCKPIT PREPARATION
GEAR PINS & COVERS.......................... REMOVED
FUEL QUANTITY................................... _____KG/LB
SEAT BELTS.........................................................ON
ADIRS..................................................................NAV
BARO REF.........................................._____ (BOTH)
BEFORE START
PARKING BRAKE............................................._____
T.O SPEEDS & THRUST...................._____ (BOTH)
WINDOWS......................................CLOSED (BOTH)
BEACON................................................................ON
BEFORE ONE ENGINE TAXI
GROUND EQPT & MECHANIC............... REMOVED
AFTER START
ANTI ICE......................................................... _____
ECAM STATUS.........................................CHECKED
PITCH TRIM................................................. _____%
RUDDER TRIM.......................................... NEUTRAL
*GROUND EQPT and MEC..................... REMOVED
*Only if One Engine Taxi was not performed.
TAXI
FLIGHT CONTROLS................... CHECKED (BOTH)
FLAPS SETTING...................... CONF_____ (BOTH)
RADAR & PRED W/S.............................ON & AUTO
ENG MODE SEL............................................. _____
ECAM MEMO...................................... T.O NO BLUE
‐ AUTO BRK MAX
‐ SIGNS ON
‐ CABIN READY 
‐ SPLRS ARM
‐ FLAPS TO
‐ TO CONFIG NORM
*CABIN........................................................... READY
*For ACFT not equipped with CABIN READY
LINE-UP
T.O RWY............................................._____ (BOTH)
TCAS................................................................._____
PACKS 1 & 2...................................................._____
>
RWY & SID......................................................._____
FLAPS SETTING...................... CONF_____ (BOTH)
T.O SPEEDS & THRUST...................._____ (BOTH)
FCU ALT..........................................................._____
APPROACH
BARO REF.......................................... _____(BOTH)
SEAT BELTS.........................................................ON
MINIMUM......................................................... _____
RWY COND  ..................................... _____SET
AUTO BRAKE................................................. _____
ENG MODE SEL............................................. _____
LANDING
ECAM MEMO.....................................LDG NO BLUE
‐ LDG GEAR DN
‐ SIGNS ON
‐ CABIN READY 
‐ SPLRS ARM
‐ FLAPS SET
*CABIN........................................................... READY
*For ACFT not equipped with CABIN READY
AFTER LANDING
RADAR & PRED W/S..........................................OFF
PARKING
PARKING BRAKE OR CHOCKS..............._____SET
ENGINES.............................................................OFF
WING LIGHTS.....................................................OFF
FUEL PUMPS......................................................OFF
SECURING THE AIRCRAFT
OXYGEN..............................................................OFF
EMER EXIT LT....................................................OFF
EFBs.......................................................OFF (BOTH)
BATTERIES......................................................... OFF
A319/A320/A321
QUICK REFERENCE HANDBOOK
LTM A319/A320/A321 FLEET AS PER AIRCRAFT ALLOCATION TABLE
26 OCT 22
EMERGENCY EVACUATION
AIRCRAFT/PARKING BRK.......................................................................... STOP/ON
ATC (VHF 1)....................................................................................................NOTIFY
CABIN CREW (PA)...........................................................................................ALERT
ΔP (only if MAN CAB PR has been used)............................................ CHECK ZERO
If not zero, MODE selector on MAN, V/S CTL FULL UP.
ENG MASTERS (ALL)...........................................................................................OFF
FIRE Pushbuttons (ALL : ENG and APU)..........................................................PUSH
AGENTS (ENG and APU)............................................................................AS RQRD
 If evacuation required:
EVACUATION........................................................................................... INITIATE
 If evacuation not required:
CABIN CREW and PASSENGERS (PA)................................................... NOTIFY
C3NORMAL CHECKLIST
A319/A320/A321
QUICK REFERENCE HANDBOOK
LTM A319/A320/A321 FLEET AS PER AIRCRAFT ALLOCATION TABLE
