A BESS Control System for Reducing Fuel­
Consumption and Maintenance Costs of Diesel­
Hybrid Mini-Grids with High Penetration of
Renewables
Nayeem A. Ninad and Luiz A. C. Lopes
Department of Electrical and Computer Engineering
Concordia University
Montreal, Quebec, Canada
Email: {na_ahrued.lalopes}@encs.concordia.ca
Abstract- Diesel hybrid mini-grids with high penetration of
renewables have the potential for reduced operation costs and
environmental impacts. However, the fluctuating characteristics
of wind and Photovoltaics (PV) and the large variations of the
frequently unbalanced mini-grid loads, result in additional
challenges for optimizing the operation of the diesel genset(s). In
such a case, a Battery Energy Storage System (BESS) can be very
beneficial. This paper presents a control system of a BESS that
allows it to operate in multiple modes. In the genset support
mode, it balances the load, compensates for reactive power and
forces the genset(s) to operate in a desired power range. In the
grid forming mode, it supplies balanced voltages to highly
unbalanced loads. Simulation results are provided.
Keywords- diesel genset, mini-grid, renewabies, BESS, load
unbalance, dq-control, grid forming, genset support.
I. INTRODUCTION
Traditionally, remote communities worldwide consist of
autonomous power systems (mini-grids) supplied by diesel­
engine generator sets (gensets) [1]. This is a mature
technology, but the optimization of the operation of the diesel
system for reduced fuel consumption and maintenance costs is
not an easy task. Remote communities are characterized by
highly variable load profiles with the peak load as high as 5 to
10 times the average load [2]. Normally the gensets are sized
for the peak load condition of the mini-grid. Thus, they
frequently operate at low load conditions, at low efficiency
points and subject to carbon build up, what increases
maintenance costs [3]. A minimum load of about 40% is
recommended by genset manufacturers to prevent carbon
build-up [3]. Often this is imposed by means of dump loads.
The use of renewable energy sources (RESs) offers good
potential for reducing fuel consumption in diesel based mini­
grids. However, due to its fluctuating characteristics, they
further complicate the optimization of the operation of the
gensets. In practice, a significant part of the renewable energy
might need to be either curtailed or dissipated in dump loads to
prevent operation of the genset under low load conditions [4].
The above mentioned issues can be mitigated with a battery
energy storage system (BESS). In the grid support mode, it can
978-1-4799-0482-2/13/$31.00 ©2013 IEEE 409
provide minimum loading for the genset and supplement it
under peak load conditions. In cases when the power demand
from the genset is low, due to high supply of RESs and/or low
load consumption, the genset can be shut-down and the BESS
forms the grid, regulating voltage and frequency.
Diesel-hybrid mini-grids with high penetration of RESs
present some very particular characteristics. One issue that is
frequently overlooked in small « 100 kVA) mini-grids, which
usually present a low number of loads thus reducing the
averaging effect, is load unbalance. Diesel gensets supplying
unbalanced loads experience overheating in the synchronous
generator and vibration in the shaft [5]. In fact, the ANSI
standard specifies general-purpose multifunctional generator
protective device with the maximum limit of 2% voltage
unbalance and 10-20% current unbalance [5, 6]. If a BESS is
used in a diesel-hybrid mini-grid, it can help minimize this
problem and also provide additional ancillary services to
reduce operating costs and increase power quality and
reliability. It should be noted that autonomous power systems
(mini-grids) are subject to some less stringent requirements
than large interconnected systems. For instance, the European
standard EN-51060 allows a wider range of frequency
variation in non-interconnected systems, what can be used for
additional control and energy management purposes [6].
Diesel-hybrid mini-grids with BESS, RESs and three-phase
unbalanced loads have been discussed in the literature but
mostly for the BESS supporting the genset [7, 8]. The BESS
control logic was limited to load balancing and power factor
correction in the genset support mode. The issue of light load
operation of the genset, which leads to operation with low
efficiency and increased maintenance costs, was not addressed.
The operation of a BESS in the grid forming mode supplying
balanced voltages to unbalanced loads was discussed in [9-11].
However, the impact of unbalanced renewable supply,
commonly based on single-phase inverters, and the possibility
of operating with variable frequency have not been considered.
A common inverter control approach to provide balanced
voltages to unbalanced loads is using dq control with
symmetrical components to avoid the first and second order
ripple components in the dq signals [9-11]. However, the
Authorized licensed use limited to: Centro Federal de Educacao Tec do Rio de Janeiro. Downloaded on December 30,2024 at 14:08:10 UTC from IEEE Xplore. Restrictions apply.
symmetrical components calculator (SCC) usually introduces a
significant delay difficult to be compensated for in the control
loops and most of them, are not suitable for variable frequency
operation. SCC-Iess techniques have been proposed in the
literature. One, based on sliding mode control, presented a
slow transient response (> 3 line cycles) [12]. Another was
only verified by simulation under steady-state conditions [13].
This paper deals with a multi-functional control system of a
BESS for a variable frequency diesel-hybrid mini-grid with
high penetration of RESs and highly unbalanced loads. In the
grid support mode, it provides active power control of the
genset for reducing fuel consumption and maintenance costs,
on the top of load balancing and reactive power compensation.
In the grid forming mode, it provides balanced voltages even
when supplying power in two phases and absorbing in the
other one, due to the presence of unbalanced loads and
renewable generation. For fast dynamic response, it employs a
per-phase, instead of three-phase, dq control scheme that does
away with the need for a SCC [14].
II. DESCRIPTION OF THE SYSTEM
The power circuit of the system under consideration is
shown in Fig. 1. In the left-hand side, there is a three-phase
diesel genset that operates with primary frequency control
based on active power vs. frequency droop. It can be
disconnected from the system in case of need or convenience.
A three-phase BESS, based on a three-phase voltage source
inverter (VSI) with an LC output filter, is connected in parallel
to the genset at the point of common coupling (PCC). A three­
wire distribution system connects the diesel power plant and
the BESS to loads and residential rooftop type PV systems.
The latter are usually rated below 10 kW and are connected to
the mini-grid by single-phase current controlled VSIs with
maximum power point tracking (MPPT) capabilities.
The BESS has two basic operation modes: Genset support,
when the genset forms the grid, and grid forming, when the
genset is off and the BESS regulates voltage and frequency. In
T Va
the first mode, it operates as a three-phase independently
controlled current source. The injected currents have four main
components: 1) The negative sequence current components
(Jaben) of the load, so that the genset only supplies balance
positive sequence current; 2) The reactive current components
(Jabccap) of the output capacitors of the BESS; 3) the reactive
current components (Jaber) of the load, so that the genset
operates with unity power factor (UPF); and 4) The positive
sequence active components of current (Jabcp) to inject/absorb
the active power needed to force thegenset to operate within
an ideal output power range. If the output power of the genset
falls below a certain value (Pmin= 0.4 pU), the BESS absorbs
active power to provide minimum loading for the genset.
Conversely, the BESS will supply active power when the
output power of the genset exceeds another value (Pmax = 0.9
pu). The BESS does not deal any average active power when
the genset operates in the ideal power range.
In the second mode, the BESS forms the grid, what requires
operation as a three-phase voltage source. One major challenge
in this case is to provide balanced voltage to an unbalanced
load. Appropriate control loops have to be used so as to
guarantee that even under highly unbalanced output currents,
the grid forming battery inverter can supply balanced voltages
to the distribution grid. For defming the mode of operation of
the BESS, and when a transition is needed, an Energy
Management System (EMS), not discussed in this paper,
should be used. For instance, if the genset operates under light
load conditions and the BESS is fully charged while operating
in the genset support mode, it could be advantageous to turn
off the genset and have the BESS form the grid.
III. OVERVIEW OF CONTROL CIRCUIT OF THE BESS
The general block diagram of the control circuit of the
BESS is shown in Fig. 2. It consists of a per-phase dq
controller, a reference current generator module for the genset
support mode, a PLL module and a "Mode Selection and
Transition System (MSTS)" module. These components are
discussed in the following sub-sections.
Ia
T Vb Ib 1---:-2"---40---"----1'--T"---""":O'------.,.--,---j Unbalanced
T Ve Ie Load
Diesel Genset loa lob loe
-i -i -i PV Inverter . . ......... . . . . . . . .. ...... . . . : :
. ......... . . . . . . . ......... . . . . . . .
Unbalanced Distribution System
BESS
Fig. I - Circuit diagram of a three-phase three-wire diesel-hybrid mini-grid with battery inverter, single-phase RES and unbalanced load.
410
Authorized licensed use limited to: Centro Federal de Educacao Tec do Rio de Janeiro. Downloaded on December 30,2024 at 14:08:10 UTC from IEEE Xplore. Restrictions apply.
I:
I:
I:
I:
IrejGenerator
in Gensel
. S1:'PP',!�/. A1'?d.�
,'-"-"-"-' -"�' �Id�: __ -+� --�:�Id��----�
Ea I Current
Controller
vsabC3
E
mode
Vabc MSTS gs2f
ill gf2'
Vq L-__ ---.J fnvctrl
Fig. 2 - Schematic diagram of the proposed control circuit for the BESS.
A. The Per-Phase Cascaded DQ Control Block
The BESS operates either as a controlled current source, for
genset support, or as voltage source, fonning the grid. In such a
case, it is convenient to employ a two loop cascaded control
scheme with an inner current loop and an outer voltage loop.
The key element for fast dynamic response is the frequency
adaptive per-phase dq control block [15], that is used for the
BESS with some modifications as shown in Fig. 3 and allows
operation in both modes. The per-phase dq control strategy
employs fictive axis emulation (F AE) in the inner current loop
and frequency adaptive second order generalized integrator
(SOGI) [16] in the outer voltage loop, to obtain the orthogonal
components required for getting dq components from single­
phase quantities. As a result, the per-phase control strategy is
fast and frequency adaptive, with zero error in steady-state.
+ + + �
�:
Feed-forward (FF) loops are also used to compensate for
the coupling between the dq equivalent circuits created by the
presence of the LC filter. More details on this technique are
presented in [15].
The three legs of the BESS are controlled independently
from each other, as single-phase units with per-phase dq
control. A switch controlled by the signal mode is used to
select the reference current for the inner current loop, which
can be either the output of the voltage control loop, when the
BESS forms the grid, or an external signal coming from
reference current generator (Idqext), when the BESS is
supporting the genset. Besides, the input error of the voltage
controller is also controlled by the signal mode, so that during
genset support mode the output of the PI controller of the
voltage loop is kept at zero which ensures minimal transition
for the voltage during the mode transfer.
The per-phase controller for phase "a" is shown in Fig. 3.
The angular frequency (w) used in the SOGIs for orthogonal
signal generation is provided by the PLL block. Besides, the
sine and case terms required for the Park and inverse Park
transformations are also obtained from the phase angle
provided by the PLL block. Similar per-phase controllers also
apply for phase "b" and phase "c" with the three e angles 1200
apart. The reference voltages for the three phases have the
same magnitude and are phase shifted by 1200 in the grid
forming mode. Vq' is set at the peak value of the reference
phase voltage as defined by the PLL block while V/ is set at 0
V for the three per-phase controllers in the grid forming mode.
B. Reference Current Generation in Genset Support Mode
During the genset support mode, the reference current for
the inner current loop is generated externally from the "1re/
Generator in Genset Support Mode" block as shown in Fig. 2.
The generation of its four components is described below.
1. Negative Sequence Component Extraction
Any sets of unbalance voltages or currents can be
expressed as three symmetrical components of positive,
negative and zero sequence. In the absence of a neutral wire,
like in the case considered in this paper, there are no zero
sequence components. The negative sequence current
components can be extracted as follows. Clark transformation
is used for transforming the variables between the abc and the
a.p frames, as shown in (1) and (2).
V· q
+ Vd
Fig. 3 - Schematic diagram of the per-phase dq control block.
411
Authorized licensed use limited to: Centro Federal de Educacao Tec do Rio de Janeiro. Downloaded on December 30,2024 at 14:08:10 UTC from IEEE Xplore. Restrictions apply.
[�:l=�[� -: -�Ej
r�:L�[-� lXcJ -�
o
(1)
(2)
The positive and negative sequence a� components of the
three-phase unbalanced signals can be obtained with (3).
X+ a 0 0 Xa
x+
= � 0 -1 0 Xp (3) p
X- 0 0 -1 jXa a
X- 0 0 jXp P
In order to use (3) to obtain the positive and negative
sequence components in a� frame, one needs to implement the
j operator, that corresponds to a 90° phase shift. For that, one
can use a SOGI [16] which is frequency adaptive, allowing
operation under variable frequency conditions. In this case, the
load currents (iabJ are fIrst converted into the a� frame (iaP)
by (1), then (3) is used to extract the negative sequence
components of the load current in a� frame (i;;p). Finally, (2)
is applied to obtain the reference negative sequence current in
abc frame (iabcn) which the BESS needs to inject for balancing
the load.
2. BESS Capacitor Current Compensation
In the genset support mode, the BESS acts as a controlled
current source. The purpose of the output capacitor is to reduce
switching frequency harmonics mainly during the grid forming
mode. The BESS can supply the reactive currents of the
capacitors in the grid support mode. If Va and vp are the a�
voltage components for 'a' phase, then the amplitude of the
required reactive current of the capacitor is given by,
�va2 +v/
III = -'-------'-Xc
(4)
Where, Xc is the capacitive reactance and it should be
updated depending on the value of the angular frequency (w) .
The three-phase instantaneous reference currents (iabccap) to
compensate the capacitor current of the BESS will have the
same amplitude and is generated using the cosine of the phase
angle with abc phase sequence.
3. Load Reactive Power Compensation
The BESS should also supply the reactive power of the
load, so that the genset operates with UPF. Note that in system
with a small genset, it is advantageous touse all its apparent
power for active power control. The total positive sequence
reactive power of the load can be calculated as,
(5)
412
Where the positive sequence a� components (v:p and i:p)
of the pee voltage and the load currents are obtained using (1)
and (3).
The reactive power calculated from (5) is used to calculate
the peak value of the reference reactive component of the
current of the BESS for load reactive power compensation as,
Q+ 2 I =--- (6)
ar
3 V+
Where, V+ is the peak value of the posItive sequence
voltage components. The negative sign indicates that the BESS
supplies reactive power while the load is consuming. The
three-phase instantaneous reference reactive currents (iabcr) of
the BESS for load reactive power compensation will have the
same amplitude and is generated using the cosine of the phase
angle with abc phase sequence.
4. BESS' Active Component Current Calculation
In order to avoid the carbon build-up phenomenon as well
as low efficiency of the genset, it should typically run above a
power capacity of Pm in = 0.4 pu. The BESS can absorb power
to provide minimum loading for the genset and also supply
extra power when the genset is about to operate at its
maximum capacity ( Pmax = 0.9 pu). This logic can be
implemented using the information of the mini-grid load power
demand. The total positive sequence power of the load can be
calculated from the positive sequence a� components (v:p and
i:p) of the pee voltage and the load currents, as follows,
P+ + .+ + .+ (7) = Vala +Vf31f3
Then p+ is passed to a look-up table to determine the
reference positive sequence power command for the BESS.
The characteristics of the look-up table describing the
relationship between the BESS positive sequence power
(NESS) and the load positive sequence power (p+) is given by,
(8)
Therefore the peak value of the reference positive sequence
active component of the current of the BESS is given by,
I = P;ESS �
ap 3 V+ (9)
The instantaneous reference active currents (iabcP) of the
BESS will have the same amplitude and is generated using the
sine of the phase angle with abc phase sequence.
C. Mode Selection & Transition System (MSTS) Module
The Mode Selection & Transition System (MSTS) module
is used to select and operate the BESS in the appropriate mode,
genset support or grid forming, depending on the
status/condition of the system. For instance, during daytime
with high penetration of PV power generation, the genset can
be turned off, and the BESS forms the grid, balancing active
and reactive powers in the mini-grid. The MSTS module
Authorized licensed use limited to: Centro Federal de Educacao Tec do Rio de Janeiro. Downloaded on December 30,2024 at 14:08:10 UTC from IEEE Xplore. Restrictions apply.
generates four control signals: 1) mode signal, 2) gs2[ signal, 3)
gj2s signal and 4) InvC/rl signal.
The mode signal indicates the operating mode of the BESS
in the mini-grid system. The BESS operates in the genset
support mode when mode = 1, and in the grid forming mode
when mode = O. The mode signal controls the genset breaker
directly depending on the operating mode of the BESS. The
genset breaker is open when the BESS forms the grid. The gs2[
and the gj2s signal can be used to perform planned transitions
between the BESS operating modes. Finally, signal lnvclrl is
used for controlling the breaker of the BESS, which is on when
lnvc,rl = 1. In case of maintenance of the BESS, Invc'rI = 0 to
disconnect the BESS from the mini-grid.
The control signals generated by the MSTS module are
used in the reference current generator module and the PLL
module. The synchronization of the BESS with the genset and
the disconnection process of the genset are coordinated by the
PLL module based on the control signals gs2[and gj2s generated
by the MSTS. Besides, the PLL module should be
synchronized, depending on the signal mode, with the PCC
voltage, in the genset support mode, or with the reference mini­
grid voltage in the grid forming mode.
D. P LL Module
The per-phase dq controller requires a phase angle and an
angular frequency for the Park and inverse Park
transformations during both modes, which are supplied by the
PLL module. Besides, the external reference current generator
also uses these signals to generate the reference current in the
genset support mode. During the grid forming mode, the PLL
module also provides the reference voltage signal for the per­
phase dq controllers. The angular frequency and magnitude of
the PCC voltage provided by the PLL module are used as input
signals in the MSTS module. In the genset support mode, the
PCC voltage is the reference for phase angle and frequency
while during the grid forming mode, the desired rated mini­
grid voltage is the reference signal which is generated
internally in the PLL. More details about the PLL module can
be found in [16].
IV. PERFORMANCE VERIFICATION
The performance of the proposed control strategy for the
BESS is verified by means of simulation using SIMULINK.
The BESS operates with SPWM at 5 kHz from a 1000 V dc
bus supplying 460 VL.L-60 Hz. Its output filter is given by L =
3 mH, R = 0.1 nand C = 25 /IF. PI controllers were employed
in both loops of the per-phase controllers. Tests of the
proposed control strategy for the BESS operating in the two
main modes are presented in the following subsections.
A. BESS Supporting the Diesel Genset
In this case, the genset forms the grid and the BESS
balances the load, compensates the load reactive power and
forces the genset to operate within an ideal power range: 0.4-
0.9pu. The genset is rated at 30 kW/460 V, 1800 RPM/60 Hz
and presents a 5% droop characteristic (p vs. f and Q vs. E).
Further details of the diesel genset model can be found in [17].
Table I shows the loads at different time instants.
413
TABLE T. MINI-GRID LOADS FOR THE BESS IN THE GENSET SUPPORT MODE
No. Time(s) Load (A-B) Load (B-C) Load (C-A)
1 0-17 6 kW 6 kW 6 kW
2 17 -35 9 kW 6 kW 6 kW
3 35 -52 12 kW 12 kW 9 kW
4 52-70 9 kW &3 kVAR 6 kW 6 kW
5 70-85 2.25 kW 2.25 kW 4.5 kW
Fig. 4 shows key waveforms during load variations with the
BESS in the genset support mode. As the load demand varies,
the genset speed and mini-grid frequency vary as per the droop
characteristics of the genset as shown in Fig. 4(a). During
heavy load (#3) these quantities have the minimum value while
during light load (#5), they have the maximum values. The
magnitude of the peak value (of the positive sequence
component) of the PCC voltage is not affected though the
genset operates with Q-E droop characteristics. This happens
because the reactive power demanded by the load is provided
by the BESS. Fig. 4(b) shows the three-phase average or
positive sequence real and reactive power of the genset, load
and BESS in the genset support mode. The BESS supplies
active power during load#3, when the load demand is higher
than Pmax and absorbs active power when the load demand is
lower than Pnlln as seen with load#5. Besides, when an
inductive load (#4) is connected to the system, its reactive
power is supplied entirely by the BESS.
Shaft Speed (radls)
Time[s)
(a)
50 �-
-:---::---:---:----:---::---:r=�� 40
-10 '--__ --"---__ -'-__ ----L __ ---" ____ -'----__ -'-__ ----L __ ---'_
20 �--:---::---:---:�--:---::--�==��
� 15
> :- 10
� ;: � O r---+-�-r---+��----++--�--_+--�� 't � -5 "
Time(s)
(b)
Fig. 4 -Waveforms for the genset support mode. (a) Diesel genset shaft
speed, Mini-grid frequency and peak value of the positive sequence phase
voltage; (b) Real and reactive power of the gensel, load and BESS.
Authorized licensed use limited to: Centro Federal de Educacao Tec do Rio de Janeiro. Downloaded on December 30,2024 at 14:08:10 UTC from IEEE Xplore. Restrictions apply.
Fig. 5 shows the steady-state waveforms of the PCC
voltages, genset currents, load currents and the BESS outputcurrents in the genset support mode. Depending on the load
demand, the BESS supplies/absorbs active power, performs
load balancing by supplying the negative sequence currents
and compensates the PF so that the genset operates with UPF.
Due to all these actions, the PCC voltage is balanced and fixed
at the rated value. Also, it ensures that the genset currents are
balanced and limited to 48 A (peak) corresponding to a genset
power of 27 kW (0.9 pu) while the load current in the three
phases are in the range of 56 to 64 A (peak) for load#3. It also
ensures the minimum current to be 21.3 A (peak) for the genset
corresponding to the genset minimum power of 12 kW (0.4
pU), while the load current in the three phases are in the range
of 12 to 18 A (peak) for load#5.
400�
�,:::� -400
�� �r:)(:*�----:-)E -·· ···�)(··· -�···:·) ··· r 'f")("'�"")("": "':'J"
�"
-
2�
-50
�l :l '�--:.:=::·-: .:- : :- .:- ::"":-::-:.-:: -:.-:: -: .·:;II""":.-::-:.-::-:.-::-::'t -:: -.: -:: ./ : :=:::- .:T,-.:- : :-'.
-70
�! : l '�-"-"-" -"'-:"- "" -"-"-"-"-"-""-"'-: .. -.. -.. -.. -.. -.. r!-.. -
..
-
..
-
...
-: .. -.. ,!-.. -
.. ---,.
-g � .955 51.965 51.975 51.985 51.995 52
Time [sl
(a)
���� -400
�o .�:�'- :: -:: _-:::-::-:.-.. ,... •. -.. -.. -.:-:: -:: -:: --r: __ -:::-::-.. - .. - .. -.. -.. ':: -:: -:: -:: -::--:::-:: ".- .. - .. '.
4::��
J '2� -50
j :!.-r-�-'-=E¥--'-:::::: ::=�.-+fB
-gR.955 84.965 84.975 84.985 84.995 85
Time [sl
(b)
Fig. 5 - Steady-state waveforms of the PCC voltages, genset currents, load
currents and the BESS currents for: a) Load #3 and b) Load #5.
414
B. BESS Acting as Grid Forming Unit
In the grid forming mode, the BESS is expected to provide
balanced 460 V L-L at 60 Hz to the mini-grid even under severe
load unbalance. The following conditions are simulated for
testing the proposed control scheme: Initially the load is
balanced with 7.5 kW (2.5kW/phase). At t = 0.2 s, the load
demand increases to 5 kW between lines A and B. At t = 0.3 s,
the load demand changes to 3 kW with PF = 0.8 lagging
between lines C and A. Finally, at t = 0.4 s a single-phase PV
inverter connected between lines B and C, starts supplying 3.5
kW with UPF. The resulting three-phase load voltages and load
currents are shown in Fig. 6 for the proposed control scheme.
There one sees that the load voltages remain balanced for all
cases. The proposed method presents a very fast response
regulating the load voltages almost instantaneously even under
highly unbalanced loads.
Fig. 7 shows the reference and actual voltages and currents
for the grid forming BESS in the dq frame. The deviations in
the voltage signals are small and short. Variations in the
reference current signals to compensate for voltage unbalances
take place fast and only in the phases directly related to the
load variations, while the others remain unaffected.
t�_-::
-400;=====;:====�===�====�=� � ::� .. .... . .. j j : ........... -IN I
�
I,:� == ::
-3�.1 0.2 0.3 0.4 0.5 Time[sl
Fig. 6 - Waveforms of the output voltages and currents of the grid forming
BESS for varying load conditions.
V. CONCLUSION
A Battery Energy Storage System (BESS) has the potential
for reducing the fuel consumption and the maintenance costs of
diesel hybrid mini-grids with high penetration of Renewable
Energy Sources (RESs). For that, it should be able to support
the grid forming genset or diesel power plant, by balancing the
load and supplying/absorbing average active power so that the
diesel genset(s) can operate in a high efficiency region.
Besides, it should be able to allow the shut-down of the
genset(s) and form the grid when the favorable conditions
arise. The control system presented in this paper was capable to
perform all this tasks as demonstrated by simulation. The main
aspects of this paper were the actual configuration of the
control circuit using per-phase dq control and the approach for
controlling the active power absorbed/supplied by the BESS to
force the genset to operate in a desired region supplying
balanced currents. Also, the operation of the BESS in the grid
forming mode, providing balanced voltages while supplying
active power in two phases and absorbing in one.
Authorized licensed use limited to: Centro Federal de Educacao Tec do Rio de Janeiro. Downloaded on December 30,2024 at 14:08:10 UTC from IEEE Xplore. Restrictions apply.
� :�� [···············-I:················:l ............... -:: ................
• = :'/ 1 o 200 ............... , ................ , ............... ,................ ,d
� 100 .............. .;. ............... � ............... ; ................ --V,q'
� : : : v
i 0 --'q
1 ::: [::::::::::::::::11::::::::::::::::1-::::::::::::::::[1::::::::::::::::1 ::: 1 p:l 100 ............... , ................ , ............... ,................ bq
j 0 : � : __ Vbq
P-
�
:�� [···············-I:················:: ...............
_,:
................ 1 = :
ro
' l o 200 ............... , ................ , ............... ,................
ro
o 100 ............... ; ................ � ............... ; ................ --V"l'
� , , ,
� 0 : : : -- V"l
P- 0.1 0.2 0.3 OA 0.5 0.6
Time Is]
(a) � 30,-------,-------,-------,--------,-------,
� ---- Ia/ � 20 --------------- ..
�' � ...... ..,.v.��� ......... ._H ____ I,d a 10· . . . . ... . . ........ , ... . . ... . . ... . . .
____
,
' � 0 ____ ___ _ aq
" ---- I f _10 L-------L-------�-------L-------L------��
� 30,-------,-------,-------,--------,-----
,
- -"
-- bd
�
'''''Mi� ---- � a 1 0 TJ'
� _ l : [
·
�
·
�
··
�
·
�
·
�
··
�
·
�
··
�'�������������=;-;=�:�:�'J
� 30,-------,-------,-------,--------,====
-
,
--"
� 20 - r� ...... tt4---------------- cd
��It+I ............... if ---- I,d � 1 0�������H+��������� ---- �' " ---- � � _10 L-----��------�------�------��--�� 0.1 0.5 0.6
Time Is]
(b)
Fig. 7 -Waveforms of the control loops of the grid forming BESS in dq
frames, a) Reference & actual voltages; b) Reference & actual currents.
REFERENCES
[I] K. Mauch, G. Bopp, M. Vandenbergh, and l-C. Marcel, "PV Hybrids in
Mini-Grids - New lEA PVPS Task II," Proc. of l7'h Photovoltaic Solar
Energy Conf., Fukuoka, Japan, pp. 1-4,2007.
[2] F. Katiraei, D. Turcotte, A. Swingler, and J. Ayoub, "Modeling and
Dynamic Analysis of a Medium Penetration PV-Diesel Mini-Grid
System," presented at the 4th European Conj on PV-Hybrid and Mini­
Grid, Greece, 2008.
[3] R. Pena, R. Cardenas, J. Proboste, J. Clare, and G. Asher, "Wind-Diesel
Generation Using Doubly Fed Induction Machines," iEEE Trans.
Energy Convers., vol. 23, No. 1, pp. 202-214, 2008.
[4] R. Tonkoski, L. A. C. Lopes, and D. Turcotte, "Active power
curtailment of PV inverters in diesel hybrid mini-grids," Proc. of 2009
iEEE Electrical Power & Energy Conf. (EPEC), pp. 1-6, 22-23 Oct.,
2009.
[5] M. W. Davis, R. Broadwater and J. Hambrick, "Modeling and testing of
unbalanced loading and voltage regulation final report," Joint Project
from DTE Energy Company, Electrical Distribution Design Inc.,
Virginia Polytechnic Institute and State University, and National
Renewable Energy Laboratory (US.), (2007).
[6] L. A. C. Lopes, F. Katiraei, K. Mauch, M. Vandenberg, and L. Arribas,
"PV Hybrid Mini-grids: Applicable Control Methos for Various
415
Situations," International Energy Aagency (IEA) : Photovoltaic Power
Systems (PVPS) Programme, IEA-PVPS TII-07:2012, 2012.
[7] B. Singh, A. Adya, A. P. Mittal, and l R. P. Gupta, "Application of
Battery Energy Operated System to Isolated Power Distribution
Systems," Proc. of 7th iEEE international Conj on Power Electronics
and Drive Systems (PEDS '07), pp. 526-532,27-30 Nov., 2007.
[8] F. Shahnia, R. Majumder, A. Ghosh, G. Ledwich, and F. Zare,
"Operation and control of a hybrid microgrid containing unbalanced and
nonlinear loads," Electric Power Systems Research, vol. 80, No. 8, pp.
954-965,2010.
[9] E. Ortjohann, A. Arias, D. Morton,A. Mohd, N. Hamsic, and O. Omari,
"Grid-Forming Three-Phase Inverters for Unbalanced Loads in Hybrid
Power Systems," Proc. of iEEE 4th World Conj on Photo voltaic Energy
ConverSion, vol. 2, pp. 2396-2399, May, 2006.
[10] K.-H. Kim, N.-l Park, and D.-S. Hyun, "Advanced Synchronous
Reference Frame Controller for Three-phase UPS Powering Unbalanced
and Nonlinear Loads," Proc. of IEEE 36th Power Electronics SpeCialists
Conj (PESC '05), pp. 1699-1704, June, 2005.
[II] I. Vechiu, O. Curea, and H. Camblong, "Transient Operation of a Four­
Leg Inverter for Autonomous Applications With Unbalanced Load,"
iEEE Trans. Power Electron., vol. 25, No. 2, pp. 399-407,2010.
[12] M. Dai, M. N. Marwali, J. Jin-Woo, and A. Keyhani, "A Three-Phase
Four-Wire Inverter Control Technique for a Single Distributed
Generation Unit in Island Mode," iEEE Trans. Power Electron., vol. 23,
No. I, pp. 322-331, 2008.
[13] R. A. Gannett, J. C. Sozio, and D. Boroyevich, "Application of
synchronous and stationary frame controllers for unbalanced and
nonlinear load compensation in 4-leg inverters," Proc. of 2002 iEEE
Applied Power Electronics Conf. and Expo. (A PEC-2002) , vol. 2, pp.
1038-1043, 2002.
[14] N. A. Ninad and L. A. C. Lopes, "A Vector-controlled Single-phase
Voltage Source Inverter Based Grid Interface Suitable for Variable
Frequency Operation in Autonomous Microgrids," Electric Power
Components and Systems, vol. 40, No. 11, pp. 1266-1284,2012.
[15] N. A. Ninad and L. A. C. Lopes, "Per-phase vector (dq) controlled three­
phase grid-forming inverter for stand-alone systems," Proc. of 20i 1
IEEE international Sympo. on Industrial Electronics (ISiE), pp. 1626-
1631,27-30 June, 2011.
[16] l Rocabert, G. M. S. Azevedo, A. Luna, J. M. Guerrero, l I. Candela,
Rodri, x, and P. guez, "Intelligent Connection Agent for Three-Phase
Grid-Connected Microgrids," IEEE Trans. Power Electron., vol. 26, No.
10, pp. 2993-3005,2011.
[17] M. Torres and L. A. C. Lopes, "Frequency control improvement in an
autonomous power system: An application of virtual synchronous
machines," Proc. of 20i 1 iEEE 8'h international Conj on Power
Electronics and ECCE Asia (ICPE & ECCE), pp. 2188-2195, May 30 -
June 3,2011.
Authorized licensed use limited to: Centro Federal de Educacao Tec do Rio de Janeiro. Downloaded on December 30,2024 at 14:08:10 UTC from IEEE Xplore. Restrictions apply.
