524 CHAPTER 15

(e) This compound has five different kinds of protons
(highlighted below), giving rise to five signals.


(f) This compound has three different kinds of protons
(highlighted below), giving rise to three signals.



(g) This compound has four protons and none of them
can be interchanged by rotational or reflectional
symmetry. Each of the four protons occupies a unique
electronic environment, giving rise to four signals.

(h) This compound has two different kinds of protons
(highlighted below), giving rise to two signals.

H3C
CH3
H3C
CH3
H
CH3
H3C
H
These two protons can
be interchanged by
rotational symmetry, so
they are all equivalent
These four methyl groups
can be interchanged
by rotational symmetry, so
all twelve protons are
homotopic
CH3
H3C


(i) Due to the location of the two bromine atoms, each
CH2 group occupies a unique electron environment,
giving rise to two separate signals (one for each CH2
group). In addition, the two methyl groups are also in
different electronic environments, giving two separate
signals. In total, we expect four signals.

(j) Each of the protons in each CH2 group is in a unique
electronic environment, as a result of the presence of a
chiral center. That is, each CH2 group gives rise to two
separate signals, so the two CH2 groups collectively give
rise to four different signals. The two methyl groups are
also different from each other (because of their proximity
to the bromine atom), giving two more signals. In
addition, there is one signal from the proton attached to
the carbon bearing the bromine atom. In total, we expect
seven signals.

(k) As we saw in the solution to Problem 15.2c, pentane
is expected to produce three signals in its 1H NMR
spectrum. A similar analysis of heptane indicates that its
1H NMR spectrum should contain four signals.

(l) Each of the three vinylic protons occupies a unique
electronic environment, giving rise to three separate
signals:


The two vinylic protons at the very end are different
from each other because one is cis to the main chain and
the other is trans to the main chain, as shown. Each of
the CH2 groups provides one signal (because each CH2
group occupies a unique electronic environment), and the
CH3 provides one more signal, giving a total of seven
signals.

15.6. The presence of the bromine atom does not render
C3 a chiral center because there are two ethyl groups
connected to C3. Nevertheless, the presence of the
bromine atom does prevent the two protons at C2 from
being interchangeable by reflection. The replacement
test gives a pair of diastereomers, so the protons are
diastereotopic (which means that they are not chemically
equivalent).


15.7. Each of the protons in the following highlighted
CH2 groups is in a unique electronic environment, as a
result of the presence of the chiral center. That is, each
CH2 group will give rise to two separate signals, because
one H is on the same face as (cis to) the propenyl
substituent, while the other H is further away from it, on
the opposite face as (trans to) the propenyl substituent.
Therefore, these two CH2 groups collectively give rise to
four different signals:
