Principles of Instrumental Analysis, 6th ed. Chapter 9

 7
9-20. Setting up two equations in two unknowns
 0.599 = 0.450m + b
 0.396 = 0.250m + b
 Subtracting the second equation from the first gives
 0.203 = 0.200 m
 or the slope m = 0.203/0.200 = 1.015
 Then using this value in the first equation gives
 b = 0.599 – 0.450 × 1.015 = 0.14225
 The unknown Pb concentration is then x = (0.444 – 0.14225)/1.015 = 0.297 ppm Pb
9-21. In the spreadsheet below we first calculate the equation for the line in cells B10 and B11.
 y = 0.920 x + 3.180
 The mean readings for the samples and blanks are calculated in cells D7:G7, and the
mean Na concentrations in cell D8:G8. These values are uncorrected for the blank. The
blank corrections are made in Cells B14:D14. These are then converted to %Na2O in
cells B15:D15 by the following equation
 2
2 6
conc. Na O in μg/mL 100.0 mL %Na O = 100%
1.0 g 10 μg/g
×
×
×

 The error analysis shows the calculations of the 4 standard deviations by the equations in
Appendix 1, Section a1-D2. Since the final result is obtained by subtracting the blank
reading, the standard deviations must be calculated from the difference in cells E24:G24
by 2
d A = + s s s2
bl where sA is the standard deviation for the concentration of A and sbl is
the standard deviation of the blank. These are then converted to absolute and relative
standard deviations of %Na2O in cells E25:G26.
